Read all instructions and explanations for
the installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
appliance is sold or passed on, ensure
that the new owner always receives this operation instructions.
delete installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
product is sold or passed on then ensure
that the new owner always receives this
manual.
EN
TUMBLE DRYER
Dryer
MODEL:
MDG09EH80
CONTENTS
SAFETY INSTRUCTIONS
Safety Instructions ..................................................
INSTALLATION
Product Description ................................................
Installation ...........................................................
OPERATION
Quick Start .............................................................
Before each Drying ..................................................
Control Panel .........................................................
Option....................................................................
Drying Programmes Table ........................................
MAINTENANCE
Cleaning and Care .................................................
Trouble Shooting ....................................................
Technical Specifications .........................................
Product Fiches.........................................................
2
9
9
12
13
15
16
19
21
24
26
27
1
SAFETY INSTRUCTIONS
Safety Instructions
2
Warning!
！
To prevent any damages to your and others' life or
property, you have to follow the safety notes.
This heat pump dryer is intended for drying typical
amounts of household laundry, which have been washed
with water. It has been designed solely for private use
and is not suitable for commercial or shared use (i.e. by
several families in an apartment building).
• Use this appliance only as described in this user manual.
• This appliance is for indoor use only.
• Any other use is deemed improper and may result in
damage to property or even personal injury.
• The manufacturer accepts no liability for damage caused
by improper use.
•
Safety Instructions
•
only be connected to a plug with a protective conductor
that has been installed properly. When connecting the
appliance to the mains, make sure that the mains voltage
is correct. You can find more information about this on
the rating plate.
The appliance corresponds to protection class I and may
Intended use
CAUTION: RISK OF FIRE !
SAFETY INSTRUCTIONS
3
• The electrical safety of this tumble dryer can only be
guaranteed when correctly earthed. It is essential that
this standard safety requirement is met. If in any doubt,
please have the household wiring system tested by a
qualified electrician. The manufacturer cannot be held
liable for the consequences of an inadequate earthing
system (e.g. electric shock).
Warning!
！
Electric shock hazard
•
connection parameter on the rating plate (fuse rating,
voltage and frequency) match the mains electricity supply.
If in any doubt, consult a qualified electrician.
• The electrical safety of this tumble dryer can only be
guaranteed when correctly earthed. It is essential that
this standard safety requirement is met. If in any doubt,
please have the household wiring system tested by a
qualified electrician. The manufacturer cannot be held
liable for the consequences of an inadequate earthing
system (e.g. electric shock).
• Do not pull the power cord forcefully. Please grasp the
mains plug instead
• Do not plug/draw the mains plug with wet hands.
• Do not bend, clamp or damage the power cord and the
power plug.
• If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Before connecting the tumble dryer, ensure that the
SAFETY INSTRUCTIONS
4
•
external switching device, such as a timer, or connected
to a circuit that is regularly switched on and off by a utility.
• Do not connect the appliance to the mains electricity
supply by an extension lead, multi-socket adapter or similar.
• The accessibility of the plug must always be ensured, in
order to disconnect the tumble dryer from the mains.
• If the appliance appear high temperature abnormally,
please draw the mail plug immediately.
Warning: The appliance must not be supplied through an
Injury danger
•
a sliding door or a door with a hinge on the opposite side
to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
• Do not disassemble or install the dryer without any
instruction or supervision.
• Do not stack this dryer on washing machine without
stacking kits. (If you want to stack this dryer on a washing
machine, please purchase the independent parts.
Installation shall be done by the manufacturer, its service
agent or similarly qualified persons to avoid any hazards.)
• Do not lean on the opened door of the dryer.
• Condensed water is not drinking water. It can cause
health problems in both people and animals if consumed.
The appliance must not be installed behind a lockable door,
Damage danger
•
See the related chapter in the user manual.
Do not put more load than rated in this user manual.
SAFETY INSTRUCTIONS
5
CAUTION: RISK OF FIRE !
Explosion & Fire danger
•
substances such as kerosene or alcohol. Otherwise, there
may be explosion.
• The appliance contains an environmentally friendly but
flammable R290 refrigerant. Keep away from open flame
and other sources of ignition.
• The tumble dryer is not to be used if industrial chemicals
have been used for cleaning.
• Do not dry unwashed items in the tumble dryer.
• Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should be
washed in hot water with an extra amount of detergent
before being dried in the tumble dryer.
Please do not dry the clothes with any flammable
• Do not operate the dryer without the door filter.
• Do not dry the clothes before being spun.
• Do not expose the dryer directly under the sun.
• Do not install the dryer in humid and drenching environment.
• While cleaning and maintenance, please do remember to
pull out the power plug and do not directly spray the dryer
with water.
• The appliance should not be overturned during normal use
or maintenance.
SAFETY INSTRUCTIONS
6
• Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in
the tumble dryer.
• Fabric softeners, or similar products, should be used as
specified by the fabric softener instructions.
• Oil-affected items can ignite spontaneously, especially
when exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in
the oil. Oxidation creates heat. If the heat cannot escape,
the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat
from escaping and so create a fire hazard.
• Remove all objects from pockets such as lighters and
matches.
• If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products be placed in a tumble dryer they should first be
washed in hot water with extra detergent. This will reduce,
but not eliminate, the hazard.
• WARNING: Never stop a tumble dryer before the end of the
drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Openings must not be obstructed.
• The lint trap has to be cleaned frequently.
• Lint must not to be allowed to accumulate around the
tumble dryer.
Safety with children
SAFETY INSTRUCTIONS
7
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by
children without supervision.
• Children should be supervised to ensure that they do not
play with the appliance.
• Children of less than 3 years should be kept away unless
continuously supervised.
• Always close the door after use. In this way you will avoid
the danger of:
1. Children climbing onto or into the dryer or hiding things
in it.
2. Pets or other small animals climbing into it.
SAFETY INSTRUCTIONS
8
Model
Rated capacity
MDG09EH80
8.0kg
The packaging is designed to protect the appliance from
damage during transportation. The packaging materials
are environmentally friendly and should be recycled.
Recycling the packaging can reduce the use of raw
materials in the manufacturing process and the amount
of waste in landfill sites.
•
Disposal of packaging material
Correct Disposal of this product:
This marking indicates that this product should not
be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection systems
or contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
INSTALLATION
9
Product Description
Installation
Pull up the upper drain hose Connect the external
drain hose to the water
pump
Put the external drain hose into the floor drain
(be careful not to bend the external drain hose)
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves to them
as per the instruction below .
install
Power cord
Door filter
Water container
Door
Control panel
Air inlet
Maintenance cover
Drum
Top board
Note: The actual model you purchased might differ. Please see the product you purchased in kind prevail.
Connector
10
INSTALLATION
Installation Position
Transport
Move cautiously. Do not grasp any salient parts of machine. The machine door cannot
be used as the handle for transport. If the dryer can't be transported erectly, the dryer
can be tilted to right less than 30°.
Risk of injury and damage!
Improper handling of the appliance may result in injury.
• The appliance is very heavy. Never transport or carry the appliance alone; always
with the assistance of another person.
• Remove all obstacles on the transport route and from the installation location, e.g.
open doors and clear away objects lying on the floor.
• Do not use the open door as a handhold.
• Remove all package material before using the appliance.
• Before setting up the tumble dryer, check it for any externally visible damage.
Do not install or use a damaged tumble dryer.
• Do not install the tumble dryer in a room where there is a risk of frost occurring.
At temperatures around freezing point the tumble dryer may not be able to operate
properly. There is a risk of damage if the condensed water is allowed to freeze in the
pump and hoses.
Warning!
！
• Children can become entangled in the packaging film or swallow small parts and s
uffocate. Do not allow children to play with the packaging.
• The appliance must not be installed behind a lockable door, a sliding door or a door
with a hinge on the opposite side to that of the tumble dryer, in such a way that a
full opening of the tumble dryer door is restricted.
• Do not restrict the floor clearance through deep pile carpets, strips of wood or
similar. This might cause heat built-up which would interfere with the operation of
the appliance.
1. It is recommended that, for your convenience, the machine is positioned close to
your washing machine.
2. Do not stack this dryer on washing machine without stacking kits. (If you want to
stack this dryer on a washing machine, please purchase the independent parts.
Installation shall be done by the manufacturer, its service agent or similarly qualified
persons to avoid any hazards.)
3. The tumble dryer must be installed in a clean place, where dirt does not accumulate.
Air must be able to circulate freely around the appliance. Do not obstruct the front
air inlet or the air intake grilles at the back of the machine.
11
INSTALLATION
Level Adjusting
Once in its permanent operating position, check that
the dryer is absolutely level with the aid of a spirit level.
If it is not, adjust the feet by hand or using a tool.
Power Supply Connection
4. To keep vibration and noise within minimum level when the dryer is in use, it must
be placed on a firm and level surface.
5. The feet must never be removed.
1.Make sure that the voltage of the power supply is the same as the electric specification.
2.Do not connect the dryer with the power connection board, a universal plug or socket,
do not use multi-plug adapters and extension cables.
OPERATION
12
After Drying
Drying
Buzzer beep and " :00"on display.0
1 2 3 4 5
open the door and
take out laundry
pull out the
container
pour out
condensate water
clean the filter power off
Quick Start
Before using, make sure the tumble dryer is installed correctly.
Note!
1
plug in
2
load
3
close the door
start
on
select program
select function
or default
• If the socket with a switch is used, please press the switch to turn off the power
directly.
Note!
Before Drying
13
OPERATION
Before Each Drying
•
Put some clean rags into the drum.
Plug the power, press 【On/Off 】
Select the 【Refresh】 Programme, press 【Start/Pause】 button
After finishing this programme, please follow the “cleaning and care ”
(refer to page 21) to clean the filter door.
• During drying, the compressor and the water will generate some noise
which is entirely normal.
Leave it to stand for 2 hours after transporting. Before first use, please use
the soft fabric to clean the inside drum.
.
1.
2. .
3. .
4.
Note!
1.Before drying, thoroughly spin the laundry in washing machine. High spin speed
shortens the drying time and saves energy.
2.For uniform drying result, sort the laundry according to fabric type and select the
appropriate drying programme.
3.Before drying, please close zips, hooks and eyelets, button, tie fabric belts, etc.
4.Remove all objects from pockets such as lighters and matches.
5.Sew in or remove underwiring from bras.
6.Close duvet covers and pillow cases to prevent small items from being rolled up
inside them.
7.Leave jackets open and undo any long zips so that textiles dry evenly.
8.Do not over dry the clothes, because over dried clothes can easily get creases.
9.Do not dry the articles containing rubber or similar elastic materials.
10.Keep the area around the tumble dryer clean. Coal dust or flour may cause an
explosion.
11.The door shall be opened only after the programme of the tumble dryer is finished
to avoid being scalded by hot steam or over heated drying machine.
12.Clean the lint filter and empty water container after each use to avoid extension of
drying time and increase of energy consumption.
13.Do not dry clothes after dry-clean process.
14
OPERATION
Do not put more load than rated.
• Do not dry dripping wet laundry. The dryer might get damaged
•
Note!
The reference weight of dry clothes (weight per item)
Sweater
(mixed 800g)
Jacket
( 800g ) cotton
Jeans
(800g)
Bath Towel
( 900g )cotton
Single bedsheet
( 600g )cotton
T-Shirt
( 180g )cotton
Work clothes
( 1120g)
Underwear
( 70g )cotton
Pyjamas
( 200g)
Socks
( 50g )mixed-weave
Shirt
( 300g )cotton
Only dry laundry suitable for tumble drying. Regard the laundry care labels:
Suitable for tumble drying
Normal drying process: Drying in the tumbler is possible under normal load and
temperature 80°C.
Mild drying process: Caution is appropriate when tumble drying. Select mild
process with reduced thermal action.
Do not tumble dry: Articles unsuitable for drying in the tumbler.
15
OPERATION
Control Panel
On/Off
Product is switched on or off.
1
1
Start/Pause
the button to start or pause the
drying cycle.
Press
1
2
Option
These buttons are used for setting
additional functions.
3
Display
The display shows the setting, estimated
program time remaining and status messages
of your dryer.
4
Programmes
Different drying cycles can be selected
according to the users need and the type of
laundry to be dried.
5
16
OPERATION
Option
Time
When the【 Time】 programme is selected, the 【Time】button can be used to adjust
the drying time in 10 min. steps.
Delay
This function is used for delaying the start of the drying programme up to 24 hours.
When the delayed programme starts, the time starts to countdown on the display and
the delay icon blinks.
1.Load your laundry and make sure the machine door is closed.
2.Press the 【On/Off】button,then use the programme selector knob to select
the desired programme.
3.You can additionally select the 【Anti-Crease】or【Signal】functions according to
your need.
4.Press the【Delay】 button.
5.Repeatedly to press the 【Delay】button to select the desired delay time.
6.After the 【Start/Pause】 button is pressed, the Dryer is at the running condition.
The drying procedure will be automatically performed when the delay time is over.
7.If you press the【Start/Pause】button again, the delay function will be paused.
8.If you want to cancel the “Delay” function, please press the 【On/Off】button.
Delay
Time
Intensity
You can adjust the dryness level of the laundry by pressing the【Intensity】button.
There are four grades.
1.The intensity function can be activated only before the programme starts.
2.Press the【Intensity】button repeatedly to increase the drying grade.
3.Except the【Cotton Iron】,【Delicate】,【Wool】,【Time】programme, all the
other programmes can be adjusted with the【Intensity】function.
Intensity
17
OPERATION
Intensity
My Cycle
Display
Child lock
Remaining Time indicator/Error message
Clean filters (warning)
Anti-crease
Empty water container (warning)
Anti-Crease
At the end of the drying cycle, the anti-crease time is 60 minutes (default) or 30 120 minutes (selected).
This function prevents the laundry from creases. The laundry can be removed during the anti-crease phase.
Except【Cool】,【Wool】and【Refresh】, all the other programmes have this function.
、90、
Anti-Crease
My Cycle
Used to define and save your favourite programme, which is used frequently.
1.Select the desired programme and other drying functions.
2.Press and hold the【Intensity】for 3 seconds until the beep sounds and the desired programme has been saved.
3. Turn the programme selector to the【My Cycle】 position, then you can start your favourite programme. If you want to
change the【My Cycle】 settings, repeat the steps (1) and (2).
My Cycle
Child Lock
1.This machine incorporates a special child safety lock, which can prevent children from carelessly pressing buttons or
making the faulty operation.
2.When the drying cycle is running, press the【Anti-Crease】and【Time】buttons at the same time for 3 seconds to
start child lock function.
3.When child lock function is set, the display will show Child lock icon and all button are deactivated, except【On/Off】
button.
4.To deactivate the child lock function, the【Anti-Crease】and【Time】buttons shall be pressed at the same time for
3 seconds.
Child Lock
18
OPERATION
Programme selector
1.When the LED display screen brightens up, rotate the programme knob to select the
desired programme.
2.Select the【Delay】,【Time】,【Intensity】,【Anti-Crease】 functions for
additional options.
3.Press the【Start/Pause】button.
4.Press the【On/Off】button after the programme has comlpeted.
Programme start
Programme end
The drum will rotate after the programme starts. The cycle phase LED in the display
will light up and the remaining programme time will be displayed.
Programmes
1.The drum will stop rotating after the programme ends. The display will show "0:00",
also the cycle phase LED showing "End" and related LED will illuminate. The dryer
will start【Anti-Crease】function if user doesn't remove the load. (Refer to page 17).
Please press【On/Off】button after unloading the tumble dryer to cut off power and
pull out the plug.
2.Deal with the problems according to “Trouble Shooting” section, if there is an
unexpected stop during the drying procedure or the dryer shows an Error Code (Refer
to page 24).
19
OPERATION
Drying Programmes Table
Programme
Application/Properties
Delay
Time
Max
Load
Cotton
Delicate
Mix
Synthetics
Wool
Special
My Cycle
Time
Extra
Iron
Extra
Standard
Jeans
Bed Linen
Sports
Shirts
Warm
Cool
8.0kg
1.0kg
3.5kg
3.5kg
1.0kg
4.0kg
4.0kg
3.0kg
1.0kg
Y N
Y N
Y N
Y N
Y N
Y N
Y Y
Y
For single or multi-layer cotton laundry to be dried completely
direct storage.for
Standard
For single layer cotton laundry to remain damp ironing.for
For delicate laundry that is suitable for drying or laundry
to be hand washed at low temperature.adviced
For mixed fabrics from cotton and synthetics.
For thick or multi-layer synthetic to be dried completely .fabrics
To dry thin synthetic textiles, which are not ironed, such as easy
care shirts, baby cloths or socks.
To refresh you wool items and make them more fresh and
fluffy.
To dry jeans or leisure clothes that are spun at high speed in the
washing machine.
To dry bed linen, bed sheets or other large items.
To dry sportswear and thin fabrics from polyesther, which are
not ironed.
For
.
Place clothes loosely in the dryer. Once dried, remove quickly
and hang it on a clothes hanger.
easy care laundry, such as shirts and blouses equipped with
anti-crease functionality to minimize the ironing effort
Define and save your favourite programme.
To dry individual items or complete the drying process of
multi-layer fabrics with different drying behavior, such as
jackets, pillows or voluminous items. Min 10 min. to max. 120
min.(in 10 min.steps)
Refresh
1.0kg
To air items without heating. Min. 10 min to max. 30 min.(in 10
min. steps)
To refresh clothes kept at closed environment for a long time
or to remove odors.
Min. 20 min to max. 150 min.(in 10 min. steps)
•
Test programme in accordance with Regulation 392/2012/EU for energy labelling,
measured in accordance with EN 61121 and suitable for drying normal cotton load
at rated load capacity.
Note for Test Institutes:
20
OPERATION
Consumption Data
Note!
Model
Program
Capacity
Spin Speed /
Residual
Humidity
Drying
Time
Energy
Consumption
Cotton Standard
Cotton Standard
Synthetic Standard
8kg
4kg
3.5kg
1000rpm / 60%
1000rpm / 60%
800rpm / 40%
175min
105min
60min
1.90kWh
1.10kWh
0.60kWh
• Thick or multi-layered fabrics, e.g. jackets etc., are not easy to dry. You had better
choose Cotton Extra programme or use “Intensity” function.
• As uneven material, thick and multi-layered clothes are not easy to dry, it is better
to choose the appropriate time drying programme to completely dry them if some
parts of the clothes are still damp after programme finishes.
All data are measured in accordance with EN 61121.
The actual consumption may differ from the values given in the table,
depending on the amount of the laundry, type of fabric, residual moisture and
any additional functions selected.
1
1
MDG09EH80
1
1
MAINTENANCE
21
Empty the water container
Clean the filter door
1. Pull out and hold the water container
with two hands.
2. Tilt the water container, pour out the
condensate water into the basin.
3. Install the
water container.
Cleaning and Care
1. Open the door.
2. Take out the filter.
3. Open the filter and remove the fluff on
the filter, You can clean it in water.
4. Dry the filter thoroughly before
installing it back.
door
running
door
• Take notice of the correct orientation
before to insert the door filter.
Note!
Door Filter
• Empty the water container after each use. Once the water container is filled
completely, the programme will be paused and the " " icon will light. After
the container is emptied, the dryer can be restarted by pressing
【Start/Pause】button.
• Do not drink the condensate water.
• Do not use the dryer without the water container.
Warning!
！
Clean the filters
This dryer has a primary door lint filter for additional protection.
Make sure you clean the door filter after each cycle.
MAINTENANCE
22
As necessary, approx. once every 6 months, remove the fluff from the heat
exchanger using a vacuum cleaner with a dusting brush attached.
Clean the heat exchanger without applying any pressure. Otherwise the heat
exchanger could be damaged. The dryer will not dry
if the cooling fins are damaged or bent.
•
•
Clean the heat exchanger
Warning!
！
Do not touch the heat exchanger with your hand,
which may cause an injury.
MAINTENANCE
23
Clean Tumble dryer
Warning!
！
• Disconnect the power cord before cleaning!
• Clean the dryer with a wet cloth which is only damped
by clean water.
• Do not use solvents, abrasive cleaners, glass cleaners
or all-purpose cleaners. These could damage plastic
surfaces and other parts.
• Please wear gloves when cleaning.
• Prepare a wet cloth damped by clean water.
• Clean the door, especially the inside window.
• Clean the sealing around the door opening.
• Clean the humidity sensor inside the drum.
• Take out all the filters, clean the sealing and air flow openings.
• Before starting the dryer, dry all parts with a soft cloth.
MAINTENANCE
24
Trouble Shooting
• Only authorised technicians can carry out repairs.
• If the LED displays other prompt and the dryer does not work, please call
the service.
Warning!
！
Many malfunctions and faults that might occur in daily operation can be easily
remedied. Time and money will be saved because a service call won't be needed.
The following guide may help you to find the reason for a malfunction and correct it.
Note!
Before you call the service, please check if you have dealt with the problems yourself
consulting the user instructions.
“ ” E32
“ ”E33
Display
Reason
Solutions
Humidity sensor error
Temperature sensor error
Please contact your local
problem occurs.
service center if the
“ ”E82
Communication error
MAINTENANCE
25
If you cannot deal with the problems by yourself and need help:
• Press the 【On/Off】button.
• Pull out the mains plug and call the service.
Warning!
！
• Clean lint filter and .
• Empty the water container.
• Check the drain hose.
• Check installation place is appropriate.
• Keep the air inlet clean.
• Use higher drying intensity level programme or
time programme.
heat exchanger
• “ ”is lighting
•“ ”is inglight
Problem
Solution
•Display is not
on
• Check if the power supply works.
• Check if the mains plug is inserted.
• Check the selected programme .
• Press the 【On/Off】button.
•
out the condensate water and restart the dryer.
If the container is not full please restart the dryer
directly.
• If the “ “ icon is still lighting after you have
finished the first two steps, please call the service.
Check the water container. If it's full, please pour
• ,
• Clean the lint filter.
•Dryer does not start
•
• Turn on the tumble dryer.
• Check the the door is closed.
• Check the programme is set.
• Press the【Start/Pause】button.
Connect the tumble dryer to the mains.
•Degree of dryness was
reached or drying time too
long
not
•There are humming noises
• The compressor is operating. These noises are
quite normal and do not indicate a fault.
•The dryer switches off at
the end of the programme
• The dryer switches off automatically for energy
saving. This is not an error but a normal function.
MAINTENANCE
26
• The rated capacity is the maximum capacity to be dried at one time. Make sure that
the dry clothes which are loaded into the appliance do not exceed the rated capacity.
• Do not install the tumble dryer in a room when there is a risk of frost occurring. At
temperatures around freezing point the tumble dryer may not be able to operate
properly.
• There is a risk of damage if the condensate water is allowed to freeze in the pump,
hoses and / or condensate water container.
Technical Specifications
Rated capacity
Rated frequency
Dimension(L*W*H)
Rated input power
Rated voltage
Weight of product
Model
Parameter
Ambient temperature
+ 5°C ~ +35°C
220-240V~
650*595*845(mm)
800W
49kg
50Hz
Note!
Refrigerant
R290
Contains fluorinated greenhouse gases covered by the Kyoto Protocol.
Hermetically sealed.
8.0kg
GWP
CO - eq
2
Quantity of refrigerant
3
0.00t
150g
MDG09EH80
MAINTENANCE
27
Product Fiches
MDG09EH80
8.0kg
Condenser
A++
234.2kWh/year
Automatic
N/A
1.44kWh
1.90kWh
1.10kWh
0.4W
0.8 W
10 min
135min
175min
105min
B
81%
81%
81%
69dB
Model
Rated Capacity
Dryer Type
Energy efficiency class
Weighted annual energy consumption (AE )
Automatic or non-automatic
EU Ecolabel
Energy consumption of the standard cotton programme
Weighted energy consumption of the standard cotton programme at full and partial load
Energy consumption of the standard cotton programme at full load
Energy consumption of the standard cotton programme at partial load
Power consumption of the off-mode (Po)
Power consumption of the left-on mode (Pl)
Duration of the left-on mode
Programme time of the 'standard cotton programme'
Weighted programme time of the standard cotton programme at full and partial load
Programme time of the standard cotton programme at full load
Programme time of the standard cotton programme at partial load
Condensation efficiency class A (most efficient) to G (least efficient)
Average condensation efficiency of the standard cotton programme at full load
Average condensation efficiency of the standard cotton programme at partial load
Weighted condensation efficiency for the standard cotton programme at full and partial load
Sound power level for the standard cotton programme at full load
❶
c
❶
Energy consumption per year, based on 160 drying cycles of the standard cotton
programme at full and partial load, and the consumption of the low-power modes.
Actual energy consumption per cycle will depend on how the appliance is used
The programme 'Cotton Standard' used at full and partial load is the standard
drying programme to which the information in the label and the fiche relates.
This programme is suitable for drying normal wet cotton laundry and it is the most
efficient programme in terms of energy consumption for cotton.
Remarks:
16138100A33205
