Oscillating Dimensions and Specications
99533 24” 14 1/2” 26 3/4” 120 60 3 3 Pedestal
99532 30” 14 1/2” 33 3/8” 120 60 3 3 Pedestal
2
Prop.
Model Dia. A B Volts Hz Speeds Blades Mounting Accessory
99533 24” 1025/880/480 1/4 5030 4320 2280 500/350/220 7.7/5.7/1.8 2.3/1.6/0.6 3.5
99532 30” 1010/860/530 1/4 7450 6090 3450 700/520/300 6.7/5.4/2.0 2.3/1.6/0.6 3.7
Prop. Motor CFM Air Velocity Sones @ Operating Full Load
Model Dia. RPM HP High Med Low @ 20 Ft. (FPM) 0.000SP Amps Amps
2
Operating Instructions & Parts Manual Models 99533, 99532
PLEASE READ AND SAVE THESE INSTRUCTIONS. Read carefully before attempting to assemble, install, operate or
maintain the product described. Protect yourself and others by observing all safety information. Failure to comply
with instructions could result in personal injury and/or property damage! Retain instructions for future reference.
Description
Designed for cooling workers in factories, warehouses, manufacturing facilities and garages where
humid and demanding conditions exist. All circulator heads have high efciency corrosion resistant
propellers with steel blades. Circulator heads utilize a vertical tilt/locking adjustment for directional
ow. Wire guards are black power-coated steel and comply with OSHA Standard 1910.212 (1/2”
maximum opening). All circulator heads are oscillating that sweep through a 45° or 90° arc.
24” & 30” Quiet Design
Oscillating Pedestal
Fan
Unpacking
1. Inspect for any damage that may have occurred during transit.
2. Shipping damage claim must be led with carrier.
3. Check all bolts, screws, setscrews, etc. for looseness that
may have occurred during transit. Retighten as needed.
Printed in U.S.A. New 5/11
5085460
