IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, especially when children are present, basic
safety precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING.
DANGER
As with most electrical appliances, electrical parts are electrically live
even when switch is off. To reduce the risk of death by electric shock:
• Do not reach for a trimmer that has fallen into water. Unplug immediately.
• Do not use while bathing or in a shower.
• Do not place or store trimmer where it can fall or be pulled into a tub or sink.
• Do not place in or drop into water or other liquid.
• Except when charging, always unplug this trimmer from the electrical outlet
immediately after using.
• Unplug this trimmer before cleaning.
WARNING
To reduce the risk of burns, fire, electric shock or injury to persons:
• Do not crush, disassemble, expose to excessive heat or incinerate the appliance.
• Your trimmer should never be left unattended when plugged in, except when
charging your rechargeable trimmer.
• Close supervision is necessary when this trimmer is used by, on, or near
children or persons with certain disabilities.
• Use this trimmer only for its intended use as described in this manual. Do not
use attachments not recommended by the manufacturer.
• Keep the cord away from heated surfaces.
• Never operate this trimmer if it has a damaged cord or if it is not working
properly, if it has been dropped or damaged, or dropped into water.
• Never drop or insert any object into any opening.
• Do not use outdoors or operate where aerosol (spray) products are being used
or where oxygen is being administered.
• Do not use this trimmer with a damaged or broken cutting unit, as injury may
occur.
• Always attach plug to trimmer, then adapter to outlet. To disconnect, turn all
controls to OFF, then remove adapter from outlet, then detach power cord from
the trimmer for storage.
• Always store your trimmer and adapter in a moisture-free area. Make sure the
cord is disconnected from the trimmer.
• Keep trimmer out of extreme heat and cold. Product must be stored at
0º F to 120º F.
• Dispose of used batteries properly. Do not incinerate. Batteries may explode if
overheated. Do not wrap in metal or aluminum foil. Wrap in newspaper before
discarding. It is suggested that you contact local town/city officials to determine
proper battery redemption site(s) in your area.
• For household use only.
SAVE THESE INSTRUCTIONS
KEEP AWAY FROM CHILDREN
Product Features
Before Using
Quick Release Blades
Zoom Wheel and Removable Adjustable Combs
NOTE: The Adjustable Combs must be attached to the trimmer in order to use
the Zoom Wheel.
• To adjust, roll the Zoom Wheel toward the top of the trimmer for a longer
length, and toward the bottom of the trimmer for a shorter length. The wheel
will click into one of nine positions.
• Begin trimming at one of the longest settings 8 or 9 to avoid accidentally
trimming hair too short. As you become familiar with the settings, you can then
select your desired length setting.
• Remove Adjustable Combs if you are: defining hairline edges such as
sideburns, trimming the nape of your neck, trimming your beard line on front
of neck, or if you want to clean cutter assembly.
• To remove the comb, with the adjustable zoom wheel set to 1, pull the comb
off the beard trimmer.
NOTE: The Adjustable Combs can only be placed on the trimmer one way; if a
comb does not fit properly, remove and reverse it.
Before Using Your Trimmer
• Before using your trimmer for the
first time, charge the unit 16 hours
for optimal performance.
• Make sure your face and facial hair
are clean and dry.
• Double check that the Adjustable
Comb is in the desired position.
Cutting length is visible in Length
Indicator.
Charging/Recharging
To recharge this trimmer, use only
the charging adapter provided.
• Turn the trimmer off. Insert the
adapter plug into the Power Port,
then plug the adapter into an
electric wall outlet. The Charging
Indicator will illuminate, indicating
unit is charging. A full charge will
take approx. 16 hours.
• Your trimmer cannot be
overcharged. You may leave it
plugged in between uses. However,
if the trimmer is not going to
be used for an extended period
(2 weeks), unplug the unit and
recharge when resuming use.
• Charge the trimmer at
temperatures between 40 – 90°F,
to avoid adversely affecting
battery life.
• In order to preserve the life of
the batteries, they should be fully
discharged every six months and
then fully charged for 16 hours.
• In cordless mode, your trimmer
will run up to 90 minutes before
additional charging is required.
Rechargeable Operation
Plugging in the adapter cord will not
provide power to the trimmer, but
only recharge the batteries.
Quick Release Blades
• The blade assembly can be
removed to change blades or for
easy cleaning.
• To remove blade assembly, press
the Quick Release Button and pull
blade away from trimmer body.
• To replace blade, align the guide
rails of the blade assembly with
the slots on the trimmer body and
snap into place. Make sure blade is
secure before turning on trimmer.
Operating Your Trimmer
MB4046
Use and Care Guide
Register Your New Product Today!
By registering your new Remington
®
product, you will receive special offers.
Register online at: RemingtonProducts.com
Feature Checklist
1. Length Indicator
2. On/Off Switch
3. Charging Indicator
4. Power Port
5. Beard Blade
6. Quick Release Button
7. Zoom Wheel
8. Goatee Blade
9. Stubble Blade
10. Stubble comb (1-5mm)
11. Short length adjustable
comb (1.5-18mm)
12. XL adjustable comb
(20-35mm)
13. Beard brush)
14. Scissors
15. Cleaning brush
(not shown)
16. Pop-up trimmer
(other side of unit)
1
2
3
4
7
6
5
8
9
Setting Style Length
1 Stubble 1.5mm 1/16"
2 2.5mm 3/32"
3 Short 4mm 5/32"
4 5.5mm 13/64"
5 Medium 7mm 17/64"
6 9mm 11/32"
7 11mm 27/64"
8 Long 14mm 35/64"
9 18mm 45/64"
Trimming Length with
Short Length Adjustable Comb
Setting Length
1 20mm 6/8"
2 21mm 13/16"
3 22mm 7/8"
4 23.5mm 15/16"
5 25.5mm 1"
6 27.5mm 1 1/16"
7 29.5mm 1 3/16"
8 32mm 1 1/4"
9 35mm 1 3/8"
Trimming Length with
XL Length Adjustable Comb
