User Manual
Model
Use & Care
Guide
WINIX AIR CLEANER
ZERO+ (AUS-1250AZPU)
ˍ
Please read and follow all safety rules and instructions
in this manual before operating.
ˍ
The product warranty is printed on the back of this
guide, so please keep it in a safe place for future use.
ZERO
+
English
CONTENTS
▶
This product is suitable for 220 - 240 V only.
5-STAGE AIR PURIFICATION
3
CONTROLS
4
WHERE TO USE
5
INSTALLING THE FILTERS
6
SAFETY AND CAUTIONS
8
INITIAL OPERATION
9
AUTO AND SLEEP
10
MANUAL MODE, TIMER AND PLASMAWAVE
®
11
CHILD LOCK, AIR QUALITY LED LIGHT
12
FILTER CARE
13
CLEANING THE DUST SENSOR
17
CLEANING CARE
18
FREQUENTLY ASKED QUESTIONS
19
UNIT SPECIFICATIONS
21
SAFETY INSTRUCTIONS
22
PRODUCT WARRANTY
23
English ZERO
+
5-STAGE AIR PURIFICATION
PlasmaWave
Deodorization lter
Pre-lter
True HEPA lter
Pet lter
1
2
3
4
5
Product User ManualPre-lter/
Deodorization lter/
True HEPA lter
Pet lter
English ZERO
+
CONTROLS
Air Outlet Vent
PLASMAWAVE
Light Sensor
Detects the amount
of ambient light within
the environment,
to adjust the brightness
of the LED indicators.
Mode / Fan Speed Button
Every time the Mode button
is pressed, the Mode LED light
will cycle through the settings.
(Auto, Sleep, Low, Medium,
High, Turbo)
Child Lock Button
Press and hold for 3 seconds
to enable or disable
the Child Lock mode.
Timer Indicator
If timer has been set,
the LED light Indicates
the set time of operation.
Timer / Air Quality Button
Press to cycle through and set
desired length of operation
(1hr, 4hr, 8hr, [NO TIMER]).
Smart Sensor
Automatically
detects indoor
air quality.
Reset Button
After replacing a lter,
press the RESET button
for at least 5 seconds.
Power Button
Turns the unit on
or o.
Child Lock Indicator
LED light indicates whether
Child Lock mode is
enabled or disabled.
Check Filter Indicator
LED light indicates when it is
time to change the lter.
PlasmaWave
Indicator
Indicates whether
PlasmaWave® is
enabled or disabled.
PLASMAWAVE
PlasmaWave Button
Enables or disables
PlasmaWave®.
Press and hold for 3 seconds
to enable or disable the
Air Quality light.
English ZERO
+
WHERE TO USE
Allow 30 ~ 45 cm of space between TVs, radios, and other electronic products
electromagnetic interference from certain electronics may cause product malfunction.
Place indoors away from direct sun light
direct exposure may cause product malfunction or failure.
Only place on hard, flat surfaces
flimsy or slanted surfaces may result in abnormal noise and vibrations.
30~45cm
10cm
WARNING
Follow these instructions to reduce the risk of serious injury
or death and to reduce risk of damaging the unit.
Do not use around mist or fumes from
industrial oil or around large quantities of
metallic dust
Do not place around heating elements
Do not install in any sort of motor or
transport vehicle (trucks, boats, ships, etc.)
Do not place in an area with excessive
amounts of noxious gases
Do not place near any flammable
materials (aerosols, fuel, gases etc.)
Do not have unit facing into wind or draft
Do not place below any electrical outlet
Do not place in excessively humid areas
where unit may become wet
English ZERO
+
This product comes with all of the required filters. The protective plastic wrap must be
removed from the filters before use.
※
Operating the unit without removing the plastic wrap may result in product failure.
※
Unplug and make sure the unit is turned off before installing filters.
※
The unit will automatically power off when front panel is opened.
①
Remove the front panel by grasping its
upper edge and gently pulling towards
yourself.
ˍ
To remove the front panel, the latch at
the lower edge of the panel must be
released from its position.
Latch
②
Remove the filters from the unit, they are
protected inside a plastic wrap.
③
Remove filters from protective plastic wrap.
ˍ
Operating the unit without removing
filters from plastic may cause abnormal
noise, deformation, or fire as a result of
overheating.
NOTE
ˍ
Refer to pages 13 - 16 for detailed information on filter care
and how to replace them.
INSTALLING THE FILTERS
English ZERO
+
INSTALLING THE FILTERS
④
Install the filters until they fit securely in
place.
Filters must be installed in this order:
3 True HEPA filter (rear)
2 Deodorization filter (middle)
1 Pre-filter (front)
ˍ
To install the pre-filter, insert bottom tabs
into the slots on either side of the lower part
of the unit, then rotate upward to insert the
upper tabs into the slots at the top part of
the unit until both sides audibly click into
place.
Deodorization
lter
True
HEPA lter
Pre-lter
⑤
Replace the front panel by first inserting
the latch at the bottom edge into the
base of the unit, then rotate the panel
upward toward the top of the unit until it
magnetically snaps closed.
Latch
⑥
When to service and replace filters:
Filter Indicator Light When to service When to replace
1 Pre-filter none
Clean once every
14days
Permanent
2 Deodorization filter
Can NOT be
WASHED
Lasts up to
12months
3 True HEPA filter
※
Intervals between filter replacement may vary depending on environment.
※
For optimal use, Pre-filter can be cleaned every 14 days which can extend the life of
other filters.
※
Pet filter replacement guide separately mentioned on the Pet filter package board.
To purchase replacement Winix filters :
contact our authorized distributor
‘Ausclimate’ or visit the below web site.
ˍ
TEL : 1800 122 100
ˍ
www.ausclimate.com.au
ˍ
www.winixaustralia.com.au
this unit
is compatible
with this
filter
FILTER
item : 1712-0092-01
GJ
this unit
is compatible
with this
filter
FILTER
item : 1712-0095-01
GU
English ZERO
+
SAFETY AND CAUTIONS
Before operating this equipment, carefully read and follow these safety cautions and
instructions to avoid damage and ensure safe use.
Ensure filters are inserted before running unit
running unit without filters can shorten the units life and cause electric shock or injury.
Be sure foreign objects are NOT inserted into the vents on the unit
objects can include pins, rods, and coins.
Do not touch any part of the interior of the unit with wet hands
the high voltage may cause electric shock.
Ensure unit intake and outlet vents do not become blocked
blockage may lead to increased internal temperatures causing product failure and
deformation.
Do not use the unit as a step stool or place heavy objects on it
personal injury may occur or product failure and deformation.
WARNING
Follow these instructions to reduce the risk of serious
injury or death and to reduce risk of damaging the unit.
Do not pull on the power cord when
unplugging the unit
Do not tie or knot power cord when unit
is in operation
If the unit becomes submerged in water,
unplug it and contact customer service
Do not unplug or move the unit while in
operation
Do not plug additional appliances into
the same outlet or power supply
Do not touch the plug with wet hands
Unplug unit when not in operation for
extended periods of time
Cord can become damaged by forcefully
bending, pulling, twisting, bundling,
pinching or placing heavy objects on it
※
If the supply cord is damaged, it must be replaced by a special cord or assembly
available from the manufacturer or its service agent.
※
This appliance is not intended for use by a person (including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
※
Children should be supervised to ensure that they do not play with the appliance.
English ZERO
+
INITIAL OPERATION
①
Insert the unit plug into an electrical outlet.
ˍ
The Control Panel lights will turn on and
off.
②
Press the 'Power' button.
NOTE
ˍ
During the first 4 minutes of power up, the Air Quality light
will flash as the Smart Sensors measure the air quality in the
environment, after which normal operation will begin.
③
By default, when the unit first powers on, the
mode will be set to Auto with PlasmaWave
®
enabled.
ˍ
When in Auto Mode the fan speed will
be automatically adjusted according to
the environments air quality.
ˍ
PlasmaWave
®
works to remove harmful
airborne contaminants.
NOTE
ˍ
In Auto mode, as the indoor air quality improves, the fan
speed will automatically be reduced to Low.
ˍ
When the unit is running, you may hear a chirping or buzzing
sound. The sound is from large particles passing through
PlasmaWave
®
, it is normal and does not signify product
failure. To disable PlasmaWave
®
, see page 11.
English ZERO
+
AUTO AND SLEEP
Every time the Mode button is pressed, the Mode LED light will cycle through the
settings. (Auto, Sleep, Low, Medium, High, Turbo)
1. Auto Mode
Enables Auto operation based on the unit's air quality Smart Sensors.
①
Press the Mode button to select Auto mode.
ˍ
The mode LED light will indicate when
‘Auto’ mode has been selected, and
operation will begin.
ˍ
Each time the Mode button is pressed,
the modes will be cycled. (Auto, Sleep,
Low, Medium, High, Turbo).
NOTE
ˍ
When in Auto Mode the fan speed is automatically adjusted
according to the indoor air quality. As the indoor air quality
improves, the fan speed will automatically be reduced. If the
indoor air quality decreases the fan speed will automatically
be increased.
ˍ
When unit is first started, Auto Mode is enabled and set to
Low fan speed.
2. Sleep Mode
①
Press the Mode button to select Sleep mode.
ˍ
The mode LED light will indicate when
‘Sleep’ mode has been selected, and
operation in that mode will begin.
NOTE
ˍ
When Sleep mode is selected, the fan speed is automatically
set to Low. Fan speed can be changed by pressing the Fan
Speed (Mode) Button.
ˍ
When Sleep Mode is enabled, the Air Quality light is disabled.
English ZERO
+
MANUAL MODE, TIMER AND PLASMAWAVE
®
Every time the Mode button is pressed, the Mode LED light will cycle through the
settings. (Auto, Sleep, Low, Medium, High, Turbo)
3. Manual Mode (setting fan speed)
Users can opt to manually set the fan speed to Low, Medium, High, or Turbo.
①
Press the Mode button to select the desired
fan speed.
ˍ
The mode LED light will indicate the
selected fan speed, and operation will
begin.
NOTE
ˍ
When Manual Mode is in use, Auto and Sleep modes are
automatically disabled.
4. Timer
The timer can be set for when you want the unit to run for a specified period of time.
①
Select the desired period by pressing the
Timer button.
ˍ
The Timer LED light will indicate the
selected length of operation.
ˍ
Every time the Timer button is pressed
the Timer LED light will cycle through
the settings. (1hr, 4hr, 8hr, [NO TIMER]).
5. PlasmaWave
®
By default, PlasmaWave
®
is enabled whenever the unit is powered on.
①
Press the Plasma button when the power is
on to enable or disable this feature.
PLASMAWAVE
English ZERO
+
CHILD LOCK, AIR QUALITY LED LIGHT
6. Child Lock
This feature prevents children from tampering with the control panel.
①
Press and hold the Child Lock button for
3seconds to enable or disable the feature.
ˍ
When the Child Lock indicator is lit, the
feature is enabled.
ˍ
When Child Lock is enabled, the
control panel is locked and the settings
cannot be changed.
ˍ
To disable, press and hold the Child
Lock button again for 3seconds.
3 seconds
7. Air Quality LED Light
The Air Quality LED light may be turned on or off.
①
To turn the Air Quality LED light on or
off, press and hold the Timer button for
3seconds.
ˍ
When on, the LED light will indicate the
current indoor air quality according to
three levels BLUE/GREEN/AMBER/RED
3 seconds
Air Quality Indicator
NOTE
ˍ
When Auto Mode is enabled the Air Quality LED light may or
may not be on, depending on the amount of ambient light
in the room.
ˍ
When Sleep Mode is activated, the Air Quality Indicator light
is turned off.
English ZERO
+
FILTER CARE
1. Changing Filters
When the Check Filter indicator LED is on, it is time to replace both the
True HEPA and Deodorization filter.
Filter Indicator Light When to service When to replace
1 Pre-filter none
Clean once every
14days
Permanent
2 Deodorization filter
Can NOT be
WASHED
Lasts up to
12months
3 True HEPA filter
※
Intervals between filter replacement may vary depending on environment.
※
For optimal use, Pre-filter can be cleaned every 14 days which can extend the life of
other filters.
※
Pet filter replacement guide separately mentioned on the Pet filter package board.
To purchase replacement Winix filters :
contact our authorized distributor
‘Ausclimate’ or visit the below web site.
ˍ
TEL : 1800 122 100
ˍ
www.ausclimate.com.au
ˍ
www.winixaustralia.com.au
this unit
is compatible
with this
filter
FILTER
item : 1712-0092-01
GJ
this unit
is compatible
with this
filter
FILTER
item : 1712-0095-01
GU
English ZERO
+
FILTER CARE
2. Removing Filters
Ensure the unit is turned off and unplugged before removing filters.
※
The unit will automatically power off when front panel is opened.
①
Remove the front panel by grasping its
upper edge and gently pulling towards
yourself.
ˍ
To remove the front panel, the latch at
the lower edge of the panel must be
released from its position.
Latch
②
Press the tabs on the top edge to remove
the 1 Pre-filter.
Tabs
③
First remove the 2 Deodorization filter and
then the 3 True HEPA filter by pulling on
the numbered tags at the top of each filter.
NOTICE
ˍ
For optimal performance, only genuine Winix filters should
be used with this unit.
English ZERO
+
FILTER CARE
3. Filter Assembly and Replacement
Filters should be re-installed in the reverse order of their removal.
①
Insert the replacement
3 True HEPA filter (rear)
2 Deodorization filter (middle)
ˍ
Remove the protective plastic wrap from
new filters. Operating the unit without
removing the protective plastic wrap
may cause abnormal noise, deformation,
or fire as a result of overheating.
Deodorization
lter
True
HEPA lter
②
Insert the 1 Pre-filter (front).
ˍ
To install the pre-filter, insert bottom
tabs into the slots on either side of
the lower part of the unit, then rotate
upward to insert the upper tabs into
the slots at the top part of the unit until
both sides audibly click into place.
③
Replace the front panel by first inserting
the latch at the bottom edge into the
base of the unit, then rotate the panel
upward toward the top of the unit until it
magnetically snaps closed.
Latch
④
After replacing the filters, power on the unit.
Once the unit running, press and hold the
RESET button for 5seconds.
English ZERO
+
FILTER CARE
4. Cleaning the Pre-filter
Intervals between filter cleanings may vary depending on the air quality.
①
Use a vacuum cleaner or soft brush to clean
the Pre-filter. If it is excessively dirty, wash
with room temperature water.
ˍ
Use only water, do not use volatile
substances such as alcohol or acetone.
※
If the pre-filter becomes damaged or in any way needs replacement:
Please contact your local dealer
NOTICE
ˍ
Do not use benzene, alcohol, or other volatile fluids, which
may cause damage or discoloration.
ˍ
The Pre-filter is reusable after cleaning, ensuring it has
completely dried.
ˍ
Do not use hot water over 104°F or volatile fluids such as
paint thinner.
ˍ
After washing the pre-filter, allow it to dry completely in a
wellventilated area. Otherwise, it may develop a bad odor.
English ZERO
+
CLEANING THE DUST SENSOR
Cleaning the Dust Sensor
For optimal performance of the Dust Sensor, which detects airborne dust and ultrafine
particles, clean it every two months. Clean it more frequently when the unit is running
in a place with high dust levels.
①
Open the Dust Sensor cover.
②
Use a damp cotton swab to wipe the lens
and intake area of the Dust Sensor.
ˍ
To clean the sensor area, use only water.
Do not use volatile substances such as
alcohol or acetone.
Lens
Cotton swab
③
Wipe away any remaining moisture with a
dry cotton swab.
④
Close the Dust Sensor cover.
ˍ
The Dust Sensor cover may be cleaned
using a vacuum cleaner.
English ZERO
+
CLEANING CARE
Cleaning the exterior and interior
Cleaning the exterior
Wipe with a soft damp cloth using room
temperature water. Afterwards, wipe it down
with a clean dry cloth.
ˍ
For optimal performance, clean the front
panel 1-2times a month.
Cleaning the interior
Open the front panel and clean the interior with
a vacuum cleaner.
ˍ
For optimal performance, clean the interior
1-2times a month.
NOTICE
ˍ
When cleaning the unit, always unplug the power cord first
and then wait until the unit has cooled off.
ˍ
Never disassemble, repair or modify this unit yourself.
ˍ
Do not use flammable sprays or liquid detergents.
ˍ
Do not allow children to clean or maintain the unit.
ˍ
Before cleaning or maintaining, ensure unit is off and
unplugged.
English ZERO
+
FREQUENTLY ASKED QUESTIONS
Problem Check / Actions to take
It does not turn on
at all.
ˍ
Is there a power outage?
Check to see if other lights and electrical
equipment are working and try again.
It doesn’t work in
Auto mode.
ˍ
Has Auto mode been selected?
Press the Mode button until Auto mode is
selected.
ˍ
Is the sensor blocked or clogged?
Clear the sensor using a vacuum cleaner. view
page 17.
It vibrates and
makes a lot of
noise.
ˍ
Is it running on a slanted surface?
Move the unit to a hard, flat area of the floor.
English ZERO
+
FREQUENTLY ASKED QUESTIONS
Problem Check / Actions to take
The power plug
and outlet feel
hot.
ˍ
Is the plug securely plugged in?
Make sure the plug is properly plugged into the
outlet.
There is a strange
smell.
ˍ
Is it being used in a place with a lot of smoke, dust,
or odors?
Clean the air intakes on the front sides of the
unit and clean the pre-filter.
Contact customer service to confirm the exact
cause.
Replace the Deodorization filter and True HEPA
filter.
The product is not
purifying the air
enough.
ˍ
Is the Check Filter indicator light on?
Replace the filters as required.
English ZERO
+
UNIT SPECIFICATIONS
Model Name AUS-1250AZPU
Power Voltage 220 - 240 V, 50 / 60 Hz
Power Rate 50 W
Recommended room
capacity
49.5 m
2
Weight 8.5 kg
Dimensions 415 mm(W) x 245 mm(D) x 600 mm(H)
Replacement Filter
FILTER GU, item : 1712-0095-01
FILTER GJ, item : 1712-0092-01
※
The exterior, design, and product specifications may be changed without
prior notice to improve product performance.
English ZERO
+
SAFETY INSTRUCTIONS
Thank you for purchasing a Winix air purifier. This product is for household use only.
IMPORTANT CAUTIONS FOR
USING YOUR AIR PURIFIER
WARNING : Follow the instructions in this
manual to reduce the risk of electric shock,
short circuit, and/or fire.
ˍ
Do not repair or modify the unit unless
specifically recommended in this manual.
All other repairs should be completed by a
qualified technician.
ˍ
Do not use if the power cord or plug is
damaged or the connection to the wall
outlet is loose.
ˍ
Use AC 220 - 240 V only.
ˍ
Do not damage, break, forcefully bend, pull,
twist, bundle, coat, pinch, or place heavy
objects on the power cord.
ˍ
Periodically remove dust from the power
plug. This will reduce the risk of shock due
to humidity build up.
ˍ
If the power plug is damaged, it must be
replaced by the manufacturer or a qualified
technician.
ˍ
Remove the power plug from the outlet
before cleaning the unit. When removing
the power plug, grasp by holding the plug
itself, never hold by the cord.
ˍ
Remove the power plug from the outlet
when not in use.
ˍ
Do not handle the power plug with wet
hands.
ˍ
Do not operate the unit when using indoor
smoke-generating insecticides.
ˍ
Do not clean unit with benzene or paint
thinner. Do not spray insecticides on the unit.
ˍ
Do no
t use the unit where it is humid or
where the unit may become wet, such as
the bathroom.
ˍ
Do not insert fingers or foreign objects into
air intake or outlet.
ˍ
Do not use the unit near flammable gases.
Do not use near cigarettes, incense, or
other spark-creating items.
ˍ
Unit will not remove carbon monoxide
emitted from heating appliances or other
sources.
IMPORTANT PRECAUTIONS FOR
USING YOUR AIR PURIFIER
ˍ
Do not block the intake or outlet vents.
ˍ
Do not use near hot objects, such as a
stove.
ˍ
Do not use where the unit may come into
contact with steam.
ˍ
Do not use the unit on its side.
ˍ
Keep away from products that generate
oily residue, such as a deep fryer.
ˍ
Do not use detergent to clean the unit.
ˍ
Do not operate without a filter.
ˍ
Do not wash and reuse the True HEPA Filter
or the Deodorization filter.
ˍ
Hold the handle on the back of the unit to
transport.
ˍ
Do not hold by the front panel.
English ZERO
+
PRODUCT WARRANTY
Product Name
Air Purifier
Model Name
AUS-1250AZPU
Purchase Date
Warranty period
Two (2) years
Place of purchase
Place of purchase Tel.
Customer
Address
Name
Tel.
※
After purchase, be sure to complete all of the above information.
To expedite service, please specify the model name and number, the
nature of the problem, your contact information, and your address.
Contact for product
related inquiries and
customer service
Distributed by
Ausclimate Pty Ltd
After sales and warranty enquiries, visit website or call 1800 122 100
Website : www.ausclimate.com.au / www.winixaustralia.com.au
2610-0208-00 Rev.00
