Product Overview
1. Upper Handle
2. Spray Trigger
3. Cord Clip
4. Easy Fill / Formula Cap
5. Clean Water Tank
6. Carry Handle
7. Cleaning Mode Switch
8. Power Button
9. Dirty Water Tank
10. Float Stack
11. Recline Pedal
12. Belt Access Door
13. Nozzle
14. Foot
Important Safety Instructions ................................2
What’s in the Box? ......................................................... 2
Assembly .............................................................................. 3
Filling the Clean Water Tank....................................3
Cleaning Carpets and Area Rugs ........................4
Cleaning with Hose and Tools ................................5
Emptying the Dirty Water Tank ............................ 7
After-Cleaning Care ...................................................... 7
Replacing the Belts and Brush Rolls ..................8
Troubleshooting ............................................................... 8
Warranty ............................................................................... 8
REVOLUTION® PET
UPRIGHT CARPET CLEANER
3579 SERIES
7
11
1
3
5
9
10
12
13
14
4
2
6
8
Meet your new BISSELL product!
Go to support.BISSELL.com for a comprehensive walkthrough
of your new purchase, including videos, tips, support, and more.
Want to get started right away? This guide has all the information
you need to set up your new product. Let’s take a look…
2 BISSELL.com
IMPORTANT SAFETY INSTRUCTIONS
WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
• Connect to a properly grounded outlet only. See
grounding instructions. Do not modify the three-
prong grounded plug.
• Do not leave appliance when it is plugged in. Unplug
from outlet when not in use and before servicing.
• Use indoors only.
• Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
• Do not use for any purpose other than described
in this user guide. Use only manufacturer’s
recommended attachments.
• Do not use with damaged cord or plug. If appliance
is not working as it should, or has been dropped,
damaged, left outdoors, or dropped into water,
have it repaired at an authorized service center.
• Do not pull or carry by cord, use cord as a handle,
close a door on cord, or pull cord around sharp
edges or corners.
• Do not run appliance over cord. Keep cord away
from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp
the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use
with any opening blocked; keep openings free
of dust, lint, hair, and anything that may reduce
air flow.
• Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts of
the appliance and its accessories.
• Turn OFF all controls before plugging or
unplugging appliance.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible
materials (lighter fluid, gasoline, kerosene, etc.) or
use in areas where they may be present.
• Do not use appliance in an enclosed space filled with
vapors given off by oil-based paint, paint thinner,
some moth-proofing substances, flammable dust,
or other explosive or toxic vapors.
• Do not use to pick up toxic material (chlorine
bleach, ammonia, drain cleaner, etc.).
• Do not pick up anything that is burning or
smoking, such as cigarettes, matches or hot ashes.
• Do not pick up hard or sharp objects such as glass,
nails, screws, coins, etc.
• Do not use without filters in place.
• Use only BISSELL® cleaning formulas intended
for use with this appliance to prevent internal
component damage. See the “Cleaning Formulas”
section of this guide.
• Do not immerse. Use only on surfaces moistened
by the cleaning process.
• Keep appliance on a level surface.
• Do not carry the appliance while in use.
• Always install float before any wet pick-up
operation.
• Unplug before connecting TurboBrush® Tool.
• Plastic film can be dangerous. To avoid danger of
suffocation, keep away from children.
• Liquid must not be directed towards equipment
containing electrical components.
• Use only the type and amount of liquids specified
under the operations section of this guide.
SAVE THESE INSTRUCTIONS
THIS MODEL IS FOR HOUSEHOLD USE ONLY. COMMERCIAL USE OF THIS UNIT VOIDS THE MANUFACTURER’S WARRANTY.
IMPORTANT INFORMATION
If your appliance has a motorized brush roll, do not leave machine running in the same spot without the handle fully upright.
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE.
When using an electrical appliance, basic precautions should be observed, including the following:
WARNING
Improper connection of the equipment-grounding conductor can result
in a risk of electrical shock. Check with a qualified electrician or service
person if you aren’t sure if the outlet is properly grounded. DO NOT MODIFY
THE PLUG. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician. This appliance is designed for use on a nominal 120-volt
circuit and has a grounding attachment plug that looks like the plug in the
illustration. Make certain that the appliance is connected to an outlet having
the same configuration as the plug. No plug adapter should be used with
this appliance.
GROUNDING INSTRUCTIONS
This appliance must be connected to a grounded
wiring system. If it should malfunction or break
down, grounding provides a safe path of least
resistance for electrical current, reducing the risk
of electrical shock. The cord for this appliance
has an equipment-grounding conductor and
a grounding plug. It must only be plugged into an outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
Grounded
Outlets
Grounding
Pin
Handle
(screw attached)
Base & Dirty
Water Tank
Clean Water
Tank
Carry
Handle
Trial
Formula(s)
Accessory
Bag & Hose
Tools
(vary by model)
What’s in the Box?
Standard accessories may vary by model.To identify what should be included with your purchase,
please refer to the “Carton Contents” list located on the carton top flap.
BISSELL.com 3
This machine is compatible with BISSELL® formulas made for upright carpet cleaners.
Always use genuine BISSELL formulas in your machine. Other formulas may harm the machine.
1. Choose your formula.*
Scan the QR code with your
smartphone camera or visit
BISSELL.com for formulas.
2. Lift the clean water tank up
to remove from the machine.
Unscrew the cap.
3. Use MAX/DEEP Clean or
Express Clean lines for regular
formula. Use lines for
ANTIBACTERIAL formula.
Regular Formula
ANTIBACTERIAL Formula
4. Fill the tank with warm tap water (140°F/60°C MAX) to the
WATER line. Do not use boiling water. Do not heat water or tank
in microwave. Add formula to FORMULA line.
Optional: Add 2 oz of OXY Boost. OXY Boost is not compatible
with ANTIBACTERIAL formula.
5. Screw the cap back on and
slide tank into place.
*Compatible BISSELL formulas include: Clean + Refresh, PET Stain & Odor, PRO MAX Clean + Protect, PET PRO OXY Urine Eliminator,
PET Stain Pretreat, PET PRO OXY Stain Destroyer, PET Pretreat + Sanitize, Pet Stain & Odor + Antibacterial, OXY Boost, PET OXY Boost
Assembly
1. Insert handle at
the top of the base
until it clicks.
2. Align carry handle with slots on either side of
base until it clicks into place. Use a Phillips-head
screwdriver to insert screw (taped to handle).
3. Align the clean water
tank with grooves and
slide into place.
Filling the Clean Water Tank
NOTICE BISSELL ANTIBACTERIAL formula is only for BISSELL machines with Easy Fill System.
WARNING To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL
cleaning formula intended for use with this machine.
4 BISSELL.com
Cleaning Carpets and Area Rugs
Visit support.BISSELL.com for helpful how-to carpet cleaning videos.
• Remove any solids and use a dry vacuum cleaner before using your deep cleaner.
• To prevent damage to Berber carpets, avoid repeated strokes in the same area. Before cleaning
area rugs, check the manufacturer’s tag and test an inconspicuous spot for colorfastness. Don’t
use on silk or delicate rugs.
• Stay off carpet until dry.
1. Plug into a properly
grounded outlet. Select
cleaning mode using the chart
below. Press the power button
to turn the machine ON.
2. Press the recline pedal with
your foot. Hold spray trigger
for 10 seconds to wet the
brush roll.
3. Make passes based on your
selected cleaning mode (see
chart below). When finished,
turn machine OFF.
Cleaning Modes & Instructions
MAX or DEEP Clean Mode
Delivers a deep clean to
your carpet.
Suggested Pace: 8 inches
per second
1. Hold spray trigger
• One pass forward
• One pass back
2. Release the spray
trigger
• One pass forward
• One pass back
MAX or DEEP Clean
Mode with BISSELL®
ANTIBACTERIAL Formula
Suggested Pace: 8 inches
per second
1. Hold spray trigger
• One pass forward
• One pass back
• One pass forward
2. Release the spray
trigger
• One pass back
Express Clean Mode
Provides a lighter clean that dries in
about 30 minutes.
Suggested Pace: 12 inches per second
1. Hold spray trigger
• One pass forward
• One pass back
2. Release the spray trigger
• One pass forward
• One pass back
3. With trigger released, make passes until
little water comes through the nozzle.
BISSELL.com 5
Cleaning with Hose and Tools
Tools vary by model. Visit BISSELL.com to purchase additional tools.
1. Lift the accessory hose door
toward the machine to open.
2. Insert the hose and snap into
place with colored release clip
facing away from machine.
3. Attach the tool to the end of
the hose.
Deep Stain Tool; 3", 4" and 6" Tools; and Spraying Crevice Tool
1. Point the tool about 1 inch
above the spot or stain and
press the spray trigger.
Deep Stain Tool: Set the tool
directly on the surface and pull
the trigger. Always keep tool
in contact with carpet to avoid
over-spraying.
2. Release spray trigger and
gently scrub the stain.
3. Suction the stain by placing
tool onto surface and slowly
moving backwards.
3-in-1 Stair Tool
a
b
c
1. Twist tool to desired
position. The downward facing
edge is the active cleaning
mode.
2. Use to clean stairs three ways:
a. Flat edge: stair tread
b. Indented area: outer corner
c. Pointed edge: inner corner
3. Point the tool about 1 inch
above the stain and press the
spray trigger. Suction the stain
by placing tool onto surface
and slowly moving backwards.
CONTINUED ON NEXT PAGE
6 BISSELL.com
WARNING To reduce the risk of fire, electric shock or injury, turn power OFF and disconnect plug from
electrical outlet before performing maintenance or troubleshooting.
Stain Trapper Tool
1. Point the tool about 1
inch above the spot or stain
and press the spray trigger.
Suction up the stain by placing
tool onto surface and slowly
moving backwards.
2. To empty the tool tank,
rotate clockwise. Pour dirty
liquid into sink or toilet and
rinse. Allow time to air dry.
3. Return the tank to the tool
by lining up the grooves and
twisting it into place.
2-in-1 Upholstery Tool
Dry
Suction
Channel
Wet
Suction
Channel
Switch between
dry and wet
settings and turn
machine ON.
Dry Cleaning
Vacuum up debris from
carpet or upholstery.
Wet Cleaning
1. Hold down trigger to activate spray.
2. Release trigger and suction up the stain.
Emptying the Dirt Bin
1. Twist dirt bin to open. Empty debris into a garbage bin.
2. Rinse dirt bin. Let dry completely before reinstalling.
Cleaning with Hose and Tools (continued)
BISSELL.com 7
Emptying the Dirty Water Tank
For more helpful maintenance tips, check out support.BISSELL.com.
1. Press tank handle
and tilt tank toward
you. Grab handle
and tank with both
hands and pull up
and away to remove.
2. Empty the tank. Quick empty: Pull the rubber tab and
tilt to pour. When closing, ensure tab is sealed tight.
Final clean and rinse: Unscrew ring at bottom of tank.
Remove and rinse float stack. Reinstall float stack by
aligning arrows and lock into place. Twist and lock ring to
keep water from leaking.
3. Clean the
red filter
below the tank
by wiping off
any remaining
dirt or debris.
Important:
The float stack
prevents your
dirty tank from
overflowing.
WARNING To reduce the risk of fire, electric shock or injury, turn power OFF and disconnect plug from
electrical outlet before performing maintenance or troubleshooting.
After-Cleaning Care
For more helpful maintenance tips, check out support.BISSELL.com.
Rinsing the Machine
1. Rinse out the clean water tank to remove formula. Fill tank with warm tap water. Twist cap back on tightly.
2. Turn machine ON and press trigger for 15 seconds while making back and forth passes on a section of
carpet. Release the trigger and extract the water. See above to clean the dirty water tank.
Cleaning the Nozzle
1. Turn machine OFF. Pull the
accessory hose door up to
remove nozzle.
2. Rinse the nozzle. Use the
clean out tool to unclog debris.
3. Align nozzle from bottom
and rotate to snap into place.
Cleaning the Brush Rolls
4. Turn machine OFF. Lay
machine on it’s side or back.
5. Use the comb to brush out
debris or hair from brush rolls.
8
©2022 BISSELL Inc. All rights reserved.
Part Number 1633020 06/22 RevC
Every Purchase Saves Pets
™
BISSELL proudly supports BISSELL Pet Foundation®
and its mission to help save homeless pets. When you
buy a BISSELL® product, you help save pets, too. We’re
proud to design products that help make pet messes,
odors and pet homelessness disappear.
Visit BISSELLsavespets.com to learn more.
For a comprehensive walkthrough of your product and support tips visit
support.BISSELL.com. Any other servicing should be performed by an authorized
service representative.
Troubleshooting
Replacing the Belts and Brush Rolls
Scan the QR code or visit support.BISSELL.com for videos.
Warranty
Limited 5-year warranty, may vary by state. Visit support.BISSELL.com or call 1-800-237-7691 for
complete warranty information.
1. Unplug machine and remove
both tanks. Remove nozzle
and brush roll cover (see steps
in “After-Cleaning Care”).
Press the recline pedal and lay
machine on its back.
2. Use a flathead screwdriver
to press into the slot at the
back and then front of the belt
access door. Lift to remove. Use
a Phillips-head screwdriver to
remove the screw under the
wheel, slide down to remove.
3. Lay machine on its back.
Use a Phillips-head screwdriver
to remove the screw on the
brush roll endcap.
4. If the gear belt is broken
or if replacing brush rolls,
remove the belt. Be careful
the washers at the end of the
brush rolls do not fall off or
get lost.
5. Align brush rolls with
belt at other end. To ensure
alignment, hold the end of one
brush roll and twist. Check
that washers are in place.
Reassemble the belt and
endcap, securing with screws.
6. If the flat belt is broken,
gently remove. If it needs
replacing for any reason,
remove the gear belt before
removing the flat belt. With
machine on its side, feed the
new belt through the opening
and wrap around red pulley.
7. Lay machine on its back.
Stretch the flat belt to wrap
around the metal axle.
8. Slide the wheel back into
the slot and secure with screw.
9. Snap the belt access door
back into place.
