45$"GP
%GGLDCAQGML4LGQ
P1
indoor
50Hz
60Hz
220V
240V
Max.
40 °C
Min.
°C
89&$
D
VE
1/5
Type Desc
Power
Lamp
Lamp
Holder
Ballast
Shading cloth
UVCA200 EU
UVCA200 UKI
120W
4×TUV PL-L 18W
9279 030 04007
2G11
HF-P218
/236
9114 0
18 21890
9114 018 20890 12.3
U
V-C wavelength
:
2
54nm
1 – Control panel
2 – Air outlet
3 – Body
4 – Air inlet
5 – Timing
6 – Fan speed light
7 – UV working light
8 – Power switch
9 – Lock
10 – Timing switch
11 – Fan speed control
Operation
1. Plug in
Plug in the power cord, power the machine, the buzzer will beep, at the same time, the power key indicator is always on, indicating the success of power.
2. Power on/off
Power on: touch the power on key to start the machine when it is off. Default display mode is:
A. The fan speed indicator is on 2/3, and the fan speed is in gear 2;
B. The UV indicator is on and the UV lamp is in working state;
C. The time indicator is "060", indicating that the disinfection time is 60 minutes, and the machine will automatically shut down after 60 minutes.
Power off: to shut down the product before disinfection duration is finished, please press the power switch button. Only the power indicator will remain on
while all the rest will turn off with notification tone.
3. Fan Speed Button
Press fan speed button to select the fan speed, 1 (low speed), /2 (medium speed), /3 (Max speed). The product starts quickly and smoothly and can reach the
maximum air volume within 20 seconds (if set to the maximum speed).
4. Timing Settings
Press Timer button to select disinfection duration, ON-30min-60min-120min as a cycle.
5. Lock
Long press the lock key above 3s, and the lock indicator light will always be on, indicating that the lock mode has started. At this point, pressing any key is
invalid (the lock indicator will flash 3 times when pressing any key). Long press the lock key above 3s to exit the lock mode. You can also exit the lock mode by
removing the power or when disinfection duration is finished.
1
2
3
4
5
6
7
8
9
10
11
© 2021, Signify Holding All rights reserved
UKI
EU
OR
12NC
9114 015 48581
9114 015 48681
