Before using or storing your ISSOMI Portable
Power Station, please plug it into a suitable
power outlet until it is fully charged.
SAFETY REQUEST
SPECIFICATIONS
PRODUCT USE GUIDANCE
PRODUCT FUNCTIONS
TROUBLESHOOTING
WARRANTY
Type-C PD(45W Max)x1
QC 3.0(30W Max)x1
USB-A(10W Max)x2
DC Out Put(36W Max)x1
DC In Put(58.8W)x1
AC Out Put(110V 300W Max)x1
1
1
2
3
4
5
6
7
8
9
2
3
4
5
6
7
8
9
Wireless charging working indicator
Wireless Malfunction Light
USB Indicator
Battery capacity percentage
Operating power & Remaining sustainable use time
AC/DC Working Indicator
QC 3.0 Working Indicator
LED Working Indicator
Type-C Working Indicator
1
Power Switch
Wireless Charge Area
LED Lighting Switch
LED Light
LCD Display
USB-A/C Output Port
DC Input and Output Port
AC 110V Output Port
AC Power ON/OFF
Thank you for purchasing our multi-function portable generator. Before using this unit, please read the user
manual carefully and refer to it as needed.
Please read this "Safety Request" carefully before use our product.
Note: In order to prevent harm to the user and other people, and damage to property, you must follow the
precautions as follows.
2
This product is only for domestic use in United Stated. Please refrain from using it overseas. Using it at a voltage
other than the specified power supply voltage may cause an accident, injury, or malfunction.
Please check the rated voltage and current value of your device. And be careful not to exceed the AC rating of this
product. Be careful of overload. (This may cause overheating, over-current or damage.)
Do not cover the power station with a cloth or bedding while charging. (It may cause overheating, damage, or fire.)
Don't immerse it in water or rain for a long time. In addition, do not use it when wet. Otherwise, it may cause a
short circuit, electric shock or malfunction. (There is a risk of failure, short circuit, or fire.)
Do not disassemble or modify the product without the guidance of professionals. Otherwise, it may cause a
malfunction. (There is a risk of short circuit or fire.)
SAFETY REQUEST
DANGER WARNING
3
Do not insert, remove or operate various cords with wet hands. (It may cause electric shock.)
When the power station is not in use, be sure to remove various cords. (It may cause fire or electric shock.)
Be careful not to let children (under age 8) to operate this product. (It may cause an accident, injury or malfunction.)
Do not damage, forcibly bend, or fracture various cords. (If the cord is damaged, stop using it immediately. Continued
use may cause fire or electric shock.)
Do not place flammable items or items that are easily deformed by heat on this product. (It may cause fire or injury.)
If you experience any abnormalities such as unstable operation, smoke, or strange odor during use, stop using the
product at once, and contact us immediately by email.
WARNING
SAFETY INSTRUCTIONS
Read the following instruction to ensure safe usage
4
When connecting the device to be used to this product, carefully read the instruction manual of each device, and
connect according to the instructions.
When cleaning, please make sure the power station is turned off and remove various cords.
Do not fully discharge the battery of the product multiple times. It will reduce the performance and life of the
battery and may make the battery unable to charge.
Even if you are not using it, check it at least every three months to make sure it is fully charged. If the battery is
not fully charged, it will not be able to perform to its full potential.
When charging, if charging is not completed even if the specified charging time is significantly exceeded, stop
charging immediately.
CAUTION
5
Please refer to the actual product specification before you use the product.
This product has built-in high-quality lithium-ion battery, please use it at room temperature. Do not store or use it
near high temperature (exceeding 65°C) or in a strong sunlight to avoid hazards such as disasters.
Please use the original charger in the package to charge the device. Any charger with a nominal charging voltage
exceeding 16.8V will cause irreversible damage to the product itself.
Please don't squeeze, hit or drop the product vigorously to avoid danger.
If you find that the outer shell of this product is seriously damaged or deformed, please stop using it at once and
contact manufacturer for advice.
Even if you are not using it, check it at least every three months to make sure it is fully charged. If the battery is
not fully charged, it will not be able to perform to its full potential.
ATTENTION
6
SPECIFICATIONS
This product is a multi-function portable generator, it provides a variety of PD, USB, DC and AC(110 V) output ports.
All PD, DC, USB sockets are plug-and-play, making your life more convenient.
This product adapt advanced core technology and supports PD, QC 3.0, wireless charging and fast charging proto-
cols for a variety of digital products, which can quickly recharge your devices.
PRODUCT SPECIFICATIONS
Model C3001
IP63
296 Wh/ 80000 mAh
Lithium ion Battery
15WMax
＞500times
8.4 lb
11.2*9.1*7.3 inch
3 modes : Low(1W) Medium(2W) High(3W)
AC adaptor (58.8W): 7-8 hrs/ Solar panel (90W): 6-7 hrs/
Car charger (24W): 10-12 hrs
Type-C PD x 1: 45W Max/ QC3.0 x 1: 30W Max/ USB-A x 2: 10W Max/
DC x 1: 12V 36W Max/ AC x 1: 110V 300W Max (Pure Sine Wave)
Waterproof level
Battery Capacity
Battery Type
Recharge time
Wireless charging
Output ports
LED
Cycle life
Weight
Size
7
PRODUCT USE GUIDANCE
Power on
Wireless Charging
LED Lighting
Before using the product, please turn on the power switch to light up the LCD display, you can check the power of
the device, the remaining power percentage and the current power available time. It should be noted that you
need to press and hold the AC button for 3 seconds to use the AC output function. At the same time, all other USB,
DC ports and are plug and play. This battery has an energy saving function, it will automatically shut down if there
is no output for more than 3 minutes.
1. Press the power button to turn on.
2. No any load for 3minutes, the power station will automatically shut down.
3. If you need to shut down manually, please hold down the LED button and AC button at the same time for 5 seconds.
1.You need to turn on the power switch first
2.It can be used when the phone is placed correctly
1.Turn on the power first
2.Long press the LED button for 3s to turn on/off the LED light.
3.Short press the light button to adjust the brightness mode of the LED light.
Low→Medium→High
8
USB/DC Interface
AC Output Turn on/off
AC Standby Function
1.Turn on the power switch first, then all USB & DC sockets are plug and play.
1: Long press the AC button for 3s to enable or close the AC socket.
Note: For safety reasons, the AC power socket will automatically shut down after 3minutes of no-load standby and
when the load power is less than 5W.
This function not only prevents the AC power from automatically shutting down, but also supports AC to power
devices below 5W.
1.Please turn on the AC button first,then press LED light button twice shortly.
2.After hearing “Di” sound, “AC 110V” will blink on the digital screen. The AC Standby Function is ready to use.
3.Long press the AC button for 3s to turn off the AC socket.
Note： The AC standby function only can manually shut off. If not, the AC power function will always be on working
status until running out the battery power.
9
AC ON/ O FF
AC
LED
AC ON/OF F
AC
PRODUCT FUNCTIONS
WIRELESS CHARGING FUNCTION
LED LIGHT
Please place your mobile phone (with wireless charging function) in the wireless charging area on the top, the
battery will automatically match, if the connection is successful, the wireless charging indicator will display.
When metal-bearing objects are placed in the area of wireless charging, the battery will be detected as FOD state. At
the same time, the wireless charging will not output externally for automatic protection. After removing the met-
al-bearing objects, the wireless charging will automatically resume (the alarm indicator of "FOD" automatically
goes off).
1.The LED light adopts three brightness modes designs, you can adjust it according to your needs.
2.Press and hold the LED button for 3s to turn on/off the LED light, the LED indicator on the display will show/
disappear, the default brightness is the lowest level.
3.LED light is a cyclic switching mode, please press the LED button to adjust the "low, medium and high" bright
ness modes.
10
AC OUTPUT FUNCTION
1.When you need to turn on/off the AC output function, please press and hold the AC button for 3s, the AC power
icon on the display screen will be displayed/disappear.
AC automatic standby function, when you turn on the AC output function without plugging in any appliance
within 1 minute, the AC output will be automatically turned off after 1 minute, the whole machine will automatically
shut down after 3 minutes. After enabling the AC socket, press the LED button twice in succession, then you will
hear a "beep" and the AC 110V on the LCD display is flashing, which indicates that the AC standby function has
been turned on. At this time, even if the power station is not connected to any equipment used, it will not auto-
matically shut down.
2.AC overload alarm prompt, when the AC load power exceeds 350W, and more than 15 seconds, the AC output
port will automatically protect and cut off the output.
Please check whether your devices match to the output voltage of this product, and then insert the AC socket
(Please note that the maximum output power of AC output power is 300W continuously, and the maximum is 500W
in an instant).
3.
11
USB/DC OUTPUT
DC INPUT PORT
LOW BATTERY ALARM
The USB output port is plug-and-play, please insert the electrical product into the corresponding interface to
automatically recognize and automatically output power.
Type-CPD outputs 36W according to the demand of the equipment standard (PD protocol matches the corre-
sponding fast charging protocol), and supports up to 45W output.
The output power of QC 3.0 is based on the demand of the equipment. QC3.0 supports up to 30W output.
The DC port output voltage is 12V and the maximum power is 36W. When the power is too high, it will be auto-
matically protected. The output can be automatically recovered after the high load is removed.
Please Note: The indicator of the corresponding plug port will be automatically displayed on the display screen
when each port works.
The input of the charging port(the nominal voltage is 16.8V 3.5A) please use the charger provided with this product.
When the battery is charging, the capacity bar of the display flashes in sequence and the LED charging indicator on
the charger after the battery is fully charged The lamp will turn green, please refer to the technical description for
charging parameters.
When the remaining battery is less than 20%, the buzzer will prompt "Beep" for 1 second, stop for 2 seconds. And it
will prompt for 5 consecutive times.
1.
2.
3.
4.
5.
12
COMMON FAULTS AND TROUBLESHOOTING METHODS
Common error Cause of issue
"Beep" alarm sounds when in use.
When the AC switch is turned on,
the AC110 or 220V indicator is
displayed on the display, but it
will automatically turn off soon.
The AC output port stops output.
If the “ERR” signal sign blink on
the digital screen, please refer to
the next page table.
The FOD lamp is shown on the
display.
Wireless charging output failure protection. There
are metal products in the wireless charging
area.Wireless charging overheat protection.
When the AC starts, the display shows AC11 OV as
the indicator icon. If there is no electrical
appliance connected to the AC within 1 minute, it
means that the electrical equipment is not turned
on. When AC starts, the display shows AC110V as
the indicator light on the icon, and the electric
equipment is also turned on but the power of the
electric equipment.perform automatic overpower
protection. 3. When the battery charge is 20%
lower, the AC cannot output.
When the capacity of the battery is less than 20%,
the alarm prompt will be issued at intervals of
"beep". At this time, you need to pay attention to
save the relevant electrical equipment informa-
tion to avoid automatic shutdown and data loss.
When the capacity of the battery is less than 20%,
the alarm prompt will be issued at intervals of
"beep". At this time, you need to pay attention to
save the relevant electrical equipment informa-
tion to avoid automatic shutdown and data loss.
Problem-solving method
Remove the wireless charging product and check the device
for short circuits.Check if there are any belongings in the
wireless charging area, and remove the metal objects to
recover automatically.
1. When the AC output indicator on the display screen is
displayed, if the battery of the powered device is not inserted
within 1 minute, the automatic energy saving mode will be
automatically turned on. If you want to continue to connect
the battery, you need to turn on the AC power output switch
again.
2. The AC output is too high power protection, please
confirm whether the power of the connected equipment is
greater than 300W. if the power exceeds 300w. the electric
equipment will not Work for a long time.
3. Please charge the battery in time for normal use.
Low battery reminder please charge the device n time.
It is the battery mode of working. Please press and hold the
AC power output switch for 3 seconds to exit the UPS mode.
The battery emits a "beep"audible
alarm and the AC icon on the
display keeps flashing.
13
COMMON FAULTS AND TROUBLESHOOTING METHODS
Common error Cause of issue
“ERR2” signal sign blinks on the
digital screen and with alarm.
“ERR1” signal sign blinks on the
digital screen and with alarm.
It’s AC Inverter overload protection. When the
continuous load power of the portable power
station is over 350W, the inverter will automatically
protect and stop the AC inverter output.
It’s AC inverter output short circuit protection.
When a short circuit occurs at the output of the
portable power station AC inverter, the inverter
will automatically protect and stop the AC
inverter output.
When the AC inverter output over-temperature
protection is triggered, the portable power station
inverter will automatically protect and stop the
AC inverter output
Problem-solving method
Please do not use overpowered load, and reboot AC button
again.
Please check whether your load is short-circuited, and
remove the load and reboot the AC button again.
Please wait until the temperature drops to room tempera-
ture before rebooting the AC function
“ERR3” signal sign blinks on the
digital screen and with alarm.
14
The display program has the fault with unknown
randomness.
Please press the AC power output switch, and restart the
battery to restore the normal display.
After unplugging the electrical
equipment, the display remains at
the same power as the load for
more than 30 seconds.
WARRANTY
PLEASE NOTE
The warranty period of this product is 12 months from the date of purchase.
The specifications of this product are subject to change without notice. Please note.
The production and sale of this product may be discontinued due to the discontinuation of the electronic parts
used.
Order number and product model number
Failure status (please explain in as much detail as possible.)
For any questions or inquiries regarding malfunctions, please contact us.
If you suspect a malfunction of this product, please let us know the following information.
15
Manufacturer：SHENZHEN HEXINYU TECHNOLOGY CO LTD
