User manual
Bluetooth Headset
BLP4220-002
Safety Precautions
Read these safety instructions before using your device and store them for possible future
reference.
• The device is not intended for use by persons (including children) with reduced
physical, sensory or mental capacity. Persons who have not read the manual, unless
they have received explanations by a person responsible for their safety and
supervision should not use this unit.
• Children should be monitored to ensure that they do not play with the device.
• The device should always be readily accessible.
• The device should not be exposed to dripping or splashing water.
• No objects filled with liquids such as vases shall be placed on the device.
• Always leave a minimum distance of 10 cm around the unit to ensure sufficient
ventilation.
• Open flame sources, such as candles, should not be placed on top of the device.
• The device is intended for use only in a temperate climate.
• At full volume, prolonged listening to the portable audio device may damage the
user’s hearing and cause hearing troubles (temporary or permanent deafness,
hearing drone, tinnitus, hyperacusis).
• So we recommend not to listen to the portable audio device at high audio volume
and no more than one hour per day at medium audio volume.
• CAUTION: Danger of explosion if battery is incorrectly replaced or not replaced by
the same type or equivalent.
• The battery should not be exposed to excessive heat such as sunshine, fire or similar.
• Different types of batteries, new and used batteries should not be mixed.
• The battery must be installed according to the polarity.
• If the battery is worn, it must be removed from the product.
• The battery must be disposed of safely. Always use the collection bins provided
(check with your dealer) to protect the environment.
• The battery can’t be replaced by the user, but only by the maker of this product, the
after sales department or a qualified person.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off where the use of the device is not allowed or where there is a risk of
causing interference or danger, for example on board an aircraft, near medical equipment,
fuel, chemicals or blasting sites.
ROAD SAFETY COMES FIRST
Check the current laws and regulations regarding the use of this device in the areas where
you drive.
• Do not handle the device when driving.
• Concentrate fully on the driving
• Radio signals could affect some of the car’s electronic systems such as the audio
stereo and alarm systems.
INTERFERENCE
All wireless devices are susceptible to interference which may affect their performance.
All our device conform to international standards and regulations, and if need be national
ones, with a view to limiting user exposure to electromagnetic fields. These standards and
regulations were adopted after the completion of extensive scientific research. This research
established no link between the use of the mobile headset and any adverse effects on
health if the device is used in accordance with standard practices.
AUTHORISED PERSONNEL
Only qualified people are authorized to install or repair this product.
ACCESSORIES
Only use batteries, chargers and other accessories which are compatible with this
equipment. Do not connect incompatible products.
KEEP THE EQUIPMENT DRY
This equipment is not water proof. Keep it dry.
CHILDREN
Keep your device in a safe place, out of the reach of young children.
The device contains small parts that may present a choking hazard.
Specifications
Rated voltage: DC 5V 0.5A
Max consumption: 35mW
Radio frequency: 2.402-2.480GHz
Frequency range: 20Hz-20KHz
Sound power: 15mW
Po Li-ion battery 400mAh
Max RF power : 0.97mW
Bluetooth compatible version: 5.0
Distance Bluetooth stays connected: 10m
Charging time: 2 hours
Music playing time: about 10-11hours (only Bluetooth)/about 9-10hours (BT off + ANC on) about 7hours (ANC &
Bluetooth mode)
Dimensions: 180 x 170 x 75 mm
Weight: 232g
Operations
ON/OFF: Toggle switch, noise reduction state will be NO/OFF.
: Short press to lower volume and long press to switch to previous song.
: Long press key three seconds to turn on；Short press to play or pause；When call comes, short press to
answer, long press to reject, double click to redial.
: Short press to raise volume and long press to switch to next song.
Indicator light：
In pairing state, the red light and the blue light flash alternately, and the blue light flashes after pairing is successful.
Noise reduction state: green light is always on.
Charging state: the red light is always on when charging, and is off when charging is finished.
Operating instructions：
Long press key three seconds to turn on, the red right and the blue light flash alternately and the wireless enters
pairing state.
Search this wireless product with your mobile phone and the wireless name is：BLP4220.
This time open the mobile music player will play music. The wireless can control mobile music up and down, play and
pause, answer and redial and etc. When the headset is playing music, the blue light is flashing slowly.
Toggle switch, noise reduction state will be NO/OFF.
Line external audio input operation instructions：
Power on status: insert audio cable to AUX LINE IN mode.
Support mobile/MP4/MP3/CD/notebook computer and other external audio input.
Declaration of conformity UE
Dag Technologie®, herby declares that this equipment conforms to the essential requirements and other relevant
provisions of Directive 2014/53/UE. The declaration of Conformity can be viewed at the following address:
http://www.mms-support.net/OTA/ECD_DAG_BLP4220-002.pdf
The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be
collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the
impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of
your obligation, that when you dispose of the appliance, it must be separately collected.
To avoid possible hearing damage, do not listen at high audio volume for long periods of time.
Imported by Dag Technologie®
79/81 Ancienne route Nationale 7
69570 Dardilly
France
www.blaupunkt.com
Dag Technologie
®
79/81 Ancienne Route Nationale 7
69570 Dardilly – France
All rights reserved. All brand names are registered trademarks of their respective owners. Specifications are subject to change without prior
