www.lorextechnology.com
LW1740 Series
WIRELESS WAY TO STAY AWARE
Secure what matters most with simplified installation and
secure wireless video. View live and recorded video on the
rechargeable & portable monitor. Protect your property with
cameras that feature listen-in audio and night vision.
1,2 OR 4
Cameras
7 INCH
Monitor
65/45 FT
Night Vision
WIRELESS
Video Surveillance System
www.lorextechnology.com
• 7” rechargeable wireless LCD monitor
1
• Weather resistant wireless camera
2
• Manual, motion, and schedule recording
• Listen-in audio monitoring
5
• Expandable up to 4 cameras
• 4GB micro SD card included; 32GB supported
• Easy to use menu with icons
• Simple installation. No video cables required
• Video motion detection
• Time and date stamped recordings for easy retrieval
• Front panel feather touch controls
• Motorized camera filter provides accurate color reproduction in all lighting
conditions
• Night time viewing up to 65ft (20m) away in ambient night time lighting
conditions and up to 45ft (14m) away in total darkness
3
• View and record up to 4 cameras at the same time in quad screen
• Secure wireless signal (FHSS)
• Up to 150ft (50m) indoor / 450ft (150m) outdoor wireless range
4
• 2x Digital Zoom
FEATURES:
LW1740 Series
WIRELESS
Video Surveillance System
1. Up to 5 hours of portable wireless monitoring. For extended monitoring ensure the wireless monitor is
connected to a local power outlet.
2. Wireless cameras require a wired connection to power outlet. Not intended for direct exposure to rain or
snow. For outdoor applications, install under shelter protected from the elements.
3. Stated IR illumination ranges are based on ideal conditions in total darkness and typical outdoor night time
ambient lighting. Actual range and image clarity depends on installation location, viewing area and light
reflection / absorption.
4. Range up to 450ft/150m outdoor, 150ft/50m indoor based on line of sight. Actual range will vary depending
on obstructions.
5. Audio recording without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for
use of its products that does not conform with local laws.
Disclaimers
Specifications
Product Information
LW1741 7” LCD Monitor with 1 Wireless Indoor/Outdoor Camera
UPC 6-95529-00192-0
Package Weight: 1.3 kg / 2.9 lbs
Package Dimensions:
(W x D x H)
213 x 119 x 150mm/8.4 x 4.7 x 5.9”
Package Cube: 0.003 CBM / 0.13 CBF
Contents: 7” LCD Monitor, 1 x wireless camera, 2 x power adapters,
4GB microSD memory card, quick setup guide
LW1742 7” LCD Monitor with 2 Wireless Indoor/Outdoor Cameras
UPC 6-95529-00193-7
Package Weight: 1.6 kg / 3.6 lbs
Package Dimensions:
(W x D x H)
259 x 101 x 150mm / 10.2 x 4.0 x 5.9
Package Cube: 0.008 CBM / 0.0003 CBF
Contents: 7” LCD Monitor, 2 x wireless cameras, 3 x power adapters,
4GB microSD memory card, quick setup guide
General
Transmission Frequency 2,400 ~ 2,43.5GHz
Transmission Power 18dBm
Data Rate 3 Mbps
Unobstructed Wireless Range Up to 450ft (150m) outdoors
Up to 150ft (50m) indoors
4
Spread Spectrum FHSS
Modulation GFSK
Operating Humidity < 80%
Camera
Image Sensor 1/4” CMOS Image Sensor
Supported Resolution VGA (640x480)
AGC Auto
IR LEDs 16 pieces; 850nm
Night Vision Range 65ft (20m) / 45ft (14m)
3
Lens/Lens Type 3.6mm F2.0 / Fixed
Power Consumption 570mA
Power Supply 6V DC 800mA ±5%
Indoor/Outdoor Both (IP65)
2
Operating Temperature 14 ~ 122°F / -10 ~ 50°C
Dimensions (WxDxH) 5.4” x 3.1” x 9.1”
138mm x 78mm x 232mm
Weight 0.34kg / 0.75lbs
0.40kg / 0.90lbs (with stand)
Monitor
Display 7” diagonal
LCD Resolution 800x480
Receiving Sensitivity -88dBm
Image Processing MPEG4
Battery 3.7V 3000mAh Li-polymer
Power Consumption 1050mA
Power Supply 5V DC 2A ±5%
Operating Temperature 32 ~ 122°F / 0 ~ 50°C
Dimensions (WxDxH) 188mm x 132mm x 17mm
7.4” x 5.2” x 0.7”
Weight 0.34kg / 0.75lbs
WIRELESS
Video Surveillance System
© 2015 Lorex Corporation
As our product is subject to continuous improvement, Lorex Corporation
& subsidiaries reserve the right to modify product design, specifications &
prices without notice and without incurring any obligation. E&OE.
Lorex Corporation
250 Royal Crest Court
Markham, Ontario,
Canada L3R 3S1
3-02092015
901 Elkridge Landing Road, Suite 100
Linthicum, Maryland 21090,
USA
www.lorextechnology.com
LW1741AC1 Wireless Add-On Camera
UPC 6-95529-00200-2
Package Weight: 0.5 kg / 1.2 lbs
Package Dimensions:
(W x D x H)
101 x 93 x 165mm / 4.0 x 3.7 x 6.5”
Package Cube: 0.001 CBM / 0.05 CBF
Contents: Wireless camera, power adapter
Dimensions
OK
5.2” /
132mm
7.4” /
188mm
0.7” /
17mm
9.1” /
232mm
5.4” /
138mm
3.1” /
78mm
OK
5.2” /
132mm
7.4” /
188mm
0.7” /
17mm
LW1741AC1UK Wireless Add-On Camera
UPC TBD
Package Weight: 0.5 kg / 1.2 lbs
Package Dimensions:
(W x D x H)
101 x 93 x 165mm / 4.0 x 3.7 x 6.5”
Package Cube: 0.001 CBM / 0.05 CBF
Contents: Wireless camera, power adapter
LW1744B 7” LCD Monitor with 4 Wireless Indoor/Outdoor Cameras
UPC 6-95529-00279-8
Package Weight: 3.1 kg / 7 lbs
Package Dimensions:
(W x D x H)
304 x 254 x 203mm / 12 x 10 x 8”
Package Cube: 0.01 CBM / 0.55 CBF
Contents: 7” LCD Monitor, 4 x wireless cameras, 5 x power adapters,
4GB microSD memory card, quick setup guide
