User Manual Dyson DY-31138301 Pure Hot + Cool HP01 Air Purifier, Heater, and Fan

Dyson DY-31138301 Pure Hot + Cool HP01 Air Purifier, Heater, and Fan - Use Manual - Use Guide PDF.
Documents: Go to donwload!
  • Owner's manual - (English)

User manual of Dyson DY-31138301 (24 pages)
file thumbnail

IMPORTANT SAFETY INSTRUCTIONS BEFORE USING THIS MACHINE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN THIS MANUAL AND ON THE MACHINE When using an electrical machine. basic precautions should always be followed. including the following: WARNING THE FAN AND THE REMOTE CONTROL BOTH CONTAIN MAGNETS.

1. Pacemakers and defibrillators may be affected by strong magnetic fields. If you or someone in your household has a pacemaker or defibrillator. avoid placing the remote control in a pocket or near to the device.

2. Credit cards and electronic storage media may also be affected by magnets and should be kept away from the remote control and the top of the machine.

WARNING These warnings apply to the machine. and also where applicable. to all tools. accessories. chargers or mains adaptors.

TO REDUCE THE RISK OF FIRE. ELECTRIC SHOCK. OR INJURY: 1. This Dyson machine is not intended for use by persons (including children) with reduced physical. sensory or reasoning capabilities. or lack of experience and knowledge. unless they have been given supervision or instruction concerning use of the machine by a person responsible for their safety.

2. Ensure machine is fully assembled in line with the instructions before use. Do not dismantle the machine or use without the loop amplifier fitted.

3. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

Children should be supervised to ensure that they do not play with the machine.

4. Use only as described in this Dyson Operating Manual. Do not carry out any maintenance other than that shown in this manual. or advised by the Dyson Helpline.

5. Suitable for dry location ONLY. Do not use outdoors or on wet surfaces and do not expose to water or rain.

6. Do not handle any part of the plug or machine with wet hands.

Do not operate any machine with a damaged cord or plug. Discard the machine or return to an authorized service facility for examination and/or repair. If the supply cord is damaged it must be replaced by Dyson. its service agent or similarly qualified person in order to avoid a hazard.

8. If the machine is not working as it should. has received a sharp blow. has been dropped. damaged. left outdoors. or dropped into water. do not use and contact the Dyson Helpline.

Do not stretch the cord or place the cord under strain. Keep cord away from heated surfaces.

10. Do not run cord under carpeting. Do not cover cord with throw rugs. runners or similar coverings.

Do not route cord under furniture or appliances. Arrange cord away from traffic area and where it will not be tripped over.

11. Do not unplug by pulling on the cord. To unplug. grasp the plug. not the cord. The use of an extension cord is not recommended.

12. Do not put any object into openings or the inlet grill. Do not use with any opening blocked; keep free of dust. lint. hair. and anything that may reduce airflow.

13. Do not use any cleaning agents or lubricants on this machine. Unplug before cleaning or carrying out any maintenance.

14. Always carry the machine by the base. do not carry it by the loop amplifier.

15. Turn off all controls before unplugging. Unplug from outlet when not in use for extended periods.

To avoid a tripping hazard. safely coil the cord.

16. Do not use near furnaces. fireplaces. stoves or other high temperature heat sources.

17. Do not use in conjunction with or directly next to an air freshener or similar products.

Keep essential oils and chemicals away from the appliance.

Do not pull on the cord.

Do not store near heat sources.

Do not use near open flames.

Do not carry by the loop amplifier.

18. This product employs overload protection (fuse). A blown fuse indicates an overload or short-circuit situation. If the fuse blows. unplug the product from the outlet. Replace the fuse as per the user servicing instructions (follow product marking for proper fuse rating) and check the product. If the replacement fuse blows. a short-circuit may be present and the product should be discarded or returned to an authorized service facility for examination and/or repair.

19. Choking hazard – This remote control unit contains a small battery. Keep the remote control away from children and do not swallow the battery. If the battery is swallowed seek medical advice at once.

20. When removing or replacing the filter. take care to keep your fingers clear between the filter and the purifier base.

21. WARNING: This product contains chemicals known to the State of California to cause cancer. birth defects or other reproductive harm.

READ AND SAVE THESE INSTRUCTIONS THIS DYSON MACHINE IS INTENDED FOR HOUSEHOLD USE ONLY POLARIZATION INSTRUCTIONS To reduce the risk of electric shock. this machine has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet. reverse the plug. If it still does not fit. contact a qualified electrician to install the proper outlet.

Do not attempt to defeat this safety feature and do not change the plug in any way.

Control

Airflow Sleep timer

Display icons

To operate. point the remote control toward the front of the base.

Attach the remote control to the top of the machine with the buttons facing down.

Select a high flow of air.

Flashing green = Wi-Fi is ready to connect to your Dyson Link app

Flashing white = Wi-Fi connecting

Solid white = Wi-Fi connected

Off = Wi-Fi disabled

Solid white = cleaning/below air quality target

Solid green = clean/air quality target has been met

Off = machine is not in auto cleaning mode

Off = appliance is not in night mode

Solid white = machine is in night mode

Select a low flow of air.

Airflow control

Standby ON/OFF Auto mode

Oscillation ON/OFF Night mode

Sleep timer

To set the sleep timer. select the desired time.

When time reaches zero. the machine will go into standby mode. To cancel. reduce the time until two dashes appear.

5 secs

Product SSID XXXXX-XXX-XX-XXXXXXXX-XXXX

Product Wi-Fi Password

XXXXXXXX

Mac address XX:XX:XX:XX:XX:XX

Poor air quality Air quality target has been met.

Air quality improving

When Auto mode is enabled (indicated by an A symbol in the bottom left corner of the display). the on-board sensors will intelligently adjust the speed of the machine according to the air quality.

Night mode

Auto mode

If in manual mode. the power will reduce to level 4. When night mode is activated. if it is already below level 4. it will remain the same.

This can be manually changed if desired. The display will illuminate briefly. then fade as before.

When night mode is enabled (indicated by an illuminated half moon symbol in the top right corner of the display). the display will dim and after 5 seconds will fade to off. The half moon symbol remains illuminated.

The night mode will dim the display and run quietly. making it ideal for use while sleeping.

Setting up Dyson Link app

Select Add a Product’ from within the app and follow the on screen instructions.

Download the Dyson Link app. available on iOS and Android.

The machine can be enhanced when connected to the Dyson Link app on your smart device.

For additional control the Dyson Link app can be used to further adjust the sensitivity of the machine.

If the air is clean the A symbol will turn green and the numerical display will switch off. If the air quality worsens the A symbol will turn white and the machine will automatically restart cleaning the room.

In order to connect the machine. you will need the information on the front of this manual.

Auto mode adjusts the power according to the air quality in the room.

If in Auto mode the power will be reduced automatically.

A period of 6 days is required after the machine is first used for the sensor to calibrate. During this period the machine may be more sensitive to VOCs than normal.

Clean the hatch every time the filter is replaced. Open the small hatch on the side of the machine. Use a cotton swab to clean inside and remove any debris. This maintains sensor accuracy and ensures the continuing high performance of the machine.

Look for blockages in the small aperture inside the loop amplifier.

Use a soft brush to remove debris.

Ensure the machine is unplugged. Dust may accumulate on the surface of the machine.

Wipe dust from the loop amplifier. filter unit and other parts with a dry or damp cloth when dust accumulates.

Press buttons to lift off loop amplifier and lift off filter.

Ensure the machine is unplugged. Look for blockages in the air inlet holes on the filter. Use a soft brush to remove debris.

Look for blockages in the air inlet holes under the filter and use a soft brush to remove debris. Replace the filter and then the loop amplifier.

Do not use detergents or polishes to clean the machine.

Clearing blockages

Cleaning

6 sec

When your non-washable filter unit needs replacing the machine will display the pattern shown. To replace the non-washable filter unit. follow these steps. Ensure your machine is unplugged. Your Dyson machine is programmed to remind you to replace the filter unit after 12 months based on 12 hours usage a day. Please note your indicator will activate sooner with more use. The indicator is only a guide and you may need to replace the filter unit more regularly.

A clockwise-rotating loading pattern will be shown on the LED display.

Once the loading pattern is complete. the appliance will return to its normal usage.

When you have re-assembled your appliance. press and hold the 'Standby ON/OFF' button for 6 seconds.

Replacing the filter unit

10-20 secs

21 secs

Enabling or Disabling Wi-Fi

Clearing your Wi-Fi settings

If you see a solid E’ when trying to use the appliance. it shows the appliance has stopped functioning correctly.

Make sure you have checked the following:

The room temperature is above 5°C/ 41°F.

There are no blockages in the inlet grille or loop amplifier outlet.

The filter has been correctly assembled and doesn’t need to be replaced.

The appliance is correctly plugged in directly to the wall outlet.

If the message still displays. unplug and leave for 10 seconds before turning on again.

If the problem persists. please call the Dyson Helpline.

If you see a flashing E’ when trying to use the appliance. it is unable to do what has been requested.

Troubleshooting

Press and hold the ON/ OFF button on the appliance for longer than 20 seconds.

It is possible to remove your network details from the appliance.

The Wi-Fi symbol will flash alternately between white and green to indicate that your network details have been removed.

Wi-Fi can be enabled or disabled by pressing and holding the ON/ OFF button on the appliance for between 10 and 20 seconds.

Wi-Fi disabled Wi-Fi enabled

If Wi-Fi is disabled. the appliance will not connect to the Dyson Link app.

If you clear your network settings the appliance will not connect to the Dyson Link app.

Flashing green = Wi-Fi is ready to connect to your Dyson Link app

Off = Wi-Fi disabled

Flashing white = Wi-Fi connecting

Solid white = Wi-Fi connected

USING YOUR DYSON MACHINE

PLEASE READ THE “IMPORTANT SAFETY INSTRUCTIONS” IN THIS DYSON OPERATING MANUAL BEFORE PROCEEDING.

LOOKING AFTER YOUR DYSON MACHINE

Do not carry out any maintenance or repair work other than that shown and described in this Dyson Operating Manual. or advised by the Dyson Helpline. Always disconnect the plug from the main outlet before inspecting for problems.

If the machine will not operate. first check the main outlet has electricity supply and that the plug is properly inserted into the outlet. If the fuse needs replacing. please check User servicing instructions’.

CONTROL WITHOUT REMOTE

The machine can be controlled through your Dyson Link app.

REPLACEABLE PARTS

BATTERY REPLACEMENT

CAUTION

Unscrew the battery compartment on the remote control. Loosen the base and pull to remove the battery. Do not install backwards or short circuit the batteries. Do not attempt to dismantle or charge the batteries. Keep away from fire. Follow battery manufacturers' instructions when installing new batteries (battery type CR 2032). Choking hazard – This remote control unit contains a small battery. Keep the remote control away from children and do not swallow the battery. If the battery is swallowed seek medical advice at once.

NON-WASHABLE FILTER UNIT

Your filter unit is non-washable and non-recyclable. To replace your filter unit follow the steps as shown. To dispose of your old filter unit: remove it from the appliance and place it in your household waste bin. A new filter unit can be purchased at www.dyson.com/filter.

AUTO MODE

A period of 6 days is required after the machine is first used for the sensor to calibrate. During this period the machine may be more sensitive to VOCs than normal.

DYSON CUSTOMER CARE

THANK YOU FOR CHOOSING TO BUY A DYSON MACHINE

If you have a question about your Dyson machine. call the Dyson Helpline with your serial number and details of where and when you bought the machine.

Most questions can be solved over the phone by one of our Dyson Helpline staff.

If your Dyson machine needs service. call the Dyson Helpline so we can discuss the available options. If your Dyson machine is under warranty. and it is a covered repair. it will be repaired at no cost.

Your serial number can be found on your rating plate which is on the base of the machine.

PLEASE REGISTER AS A DYSON MACHINE OWNER

To help us ensure you receive prompt and efficient service. please register as a Dyson appliance owner. There are four ways to do this: Online at www.dyson.com Telephone the Dyson Helpline. 866-277-9896. Complete the enclosed Warranty Form and mail it to us. SMARTPHONE. Download the Dyson Link app and you will be taken through registration as part of the set up.

This will confirm ownership of your Dyson machine in the event of an insurance loss. and enable us to contact you if necessary.

2 YEAR LIMITED WARRANTY

TERMS AND CONDITIONS OF THE DYSON 2 YEAR LIMITED WARRANTY

WHAT IS COVERED

Your Dyson machine is warranted against original defects in materials and workmanship for a period of 2 years from the date of purchase. when used for normal domestic purposes in accordance with the Dyson Operating Manual.

Please retain your proof of purchase. If you do not have your proof of purchase. your warranty will start 90 days after the date of manufacture. according to Dyson’s records. This warranty provides. at no extra cost to you. all labor and parts necessary to ensure your machine is in proper operating condition during the warranty period. The replacement of any part of your machine under warranty will not extend the period of warranty. Any parts which are returned and replaced by Dyson will become the property of Dyson. Please call the Dyson Helpline at 866-277-9896 for more information. This warranty is only valid if the machine is used in the country in which it was sold. This limited warranty is subject to the following terms:

WHAT IS NOT COVERED

Replacement filters. The machine's filter is not covered by the warranty. Damage caused by not carrying out the recommended machine maintenance.

Dyson shall not be liable for costs. damages or repairs incurred as a result of. due to. or from: Purchases of machines from unauthorized dealers. Careless operation or handling. misuse. abuse and/or lack of maintenance or use not in accordance with the Dyson Operating Manual. Use of the machine other than for normal domestic purposes within the United States. e.g. for commercial or rental purposes. Use of parts not in accordance with the Dyson Operating Manual. Use of parts and accessories other than those produced or recommended by Dyson. External sources such as weather. electrical outages or power surges. Repairs or alterations carried out by unauthorized parties or agents. Clearing blockages from your machine. Normal wear and tear (e.g. fuse etc.). Damage as a result of use not in accordance with the rating plate. Additionally. this limited warranty does not apply to any machine that has had the serial number altered or removed. If there is any doubt as to what is covered by the warranty. please contact Dyson.

USER SERVICING INSTRUCTIONS

Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling on cord.

Remove fuse carefully.

Slide open the fuse access cover on top of the plug towards blades.

Risk of fire.

Replace fuse only with 5 Amp. 125 Volt fuse.

Slide closed the fuse access cover on top of the attachment plug.

Close the fuse cover.

DO NOT REPLACE ATTACHMENT PLUG

Risk of fire. Do not replace attachment plug. Contains a safety device (fuse) that should not be removed. Discard product if the attachment plug is damaged.

US/CA

EU/FE

FLOORCARE RECHARGEABLE FANS

GENEPLUGGLOBPLUGSMASTER001CMYK.ai

CENSHARE ID:1418850

DATE.19.05.15

US/CA

EU/FE

WARRANTY LIMITATIONS AND EXCLUSIONS

Any implied warranties relating to your machine including but not limited to warranty of merchantability or warranty of fitness for a particular purpose. are limited to the duration of this warranty. This limitation is not allowed by some States and so this limitation may not apply to you. Your remedy for breach of this warranty is limited to the warranty service described below. Dyson will not be liable for any consequential damages or incidental damages you may incur in connection with your purchase and use of your machine. This limitation is not allowed by some States and so this limitation may not apply to you. This limited warranty gives you specific legal rights. You may also have other rights which vary by State. This limited warranty is not transferable.

WARRANTY SERVICE

Please fill out and return the Warranty Form. or register online at www.dyson.com Before service can take place. the terms of the warranty require that you contact the Dyson Helpline with your model name/number. serial number. date and place of purchase. Please keep your purchase receipt in a safe place to ensure you have this information. All work will be coordinated by Dyson or its authorized agents. Any replaced defective parts will become the property of Dyson. Service under this warranty will not extend the period of this warranty. If your fan is not functioning properly. please call the Dyson Helpline at 866-277-9896. Most issues can be rectified over the telephone by our trained Customer Care staff.

IMPORTANT DATA PROTECTION INFORMATION

If you choose to opt-in to receive communications from us. your details will be held by Dyson or others on behalf of Dyson so that we can assist you more quickly with our Dyson Helpline. From time to time. Dyson may send you special offers and news of our latest innovations. For more information about our data collection practices. please refer to the Dyson privacy policy at www.dyson.com/privacy

DISPOSAL INFORMATION

Dyson products are made from high grade recyclable materials.

Recycle where possible. The battery should be removed from the product before disposal. Dispose of or recycle the battery in accordance with local ordinances or regulations. California: This product includes a separate remote control device with a coin cell battery. The coin cell battery contains Perchlorates. Special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate

CONFORMITY INFORMATION

This equipment has been tested and found to comply with the limits for a Class B digital device. pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates. uses and can radiate radio frequency energy and. if not installed and used in accordance with the instructions. may cause harmful interference to radio communications. However. there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception. which can be determined by turning the equipment off and on. the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

MAIL Complete and return the form in the envelope supplied.

POR CORREO Complete este formulario y envíelo.

Title | Tratamiento

Last name | Apellido

First name | Nombre

Telephone | Teléfono

Store of purchase | Tienda de compra

Zip Code | Código postal

Address | Dirección

4 EASY WAYS TO REGISTER YOUR 2 YEAR LIMITED WARRANTY.

4 MANERAS FÁCILES DE REGISTRAR SU GARANTÍA LIMITADA DE 2 AÑOS.

Date of purchase | Fecha de compra

Serial number | Número de série

From time to time. we’d like to send you emails about new Dyson technology and services or get your opinion about your purchase. If you’d like us to keep in touch. please check this box.

Ocasionalmente. nos gustaría enviarle correos electrónicos con información sobre los nuevos servicios y tecnologías de Dyson o para saber su opinión sobre su compra. Si desea que nos mantengamos en contacto. seleccione esta casilla.

SMARTPHONE Download the Dyson Link app and you will be taken through registration as part of the set up.

TELÉFONO INTELIGENTE Descargue la aplicación del vínculo Dyson y se lo guiará por la registración como parte de la configuración.

PHONE Dyson Helpline: 1-855-533-1098 (Mon-Fri 8am to 8pm CST; Sat 9am to 6pm CST).

POR TELĖFONO 1-855-533-1098 (lunes a viernes de 8 a.m. – 8 p.m. hora Centro; sábados de 9 a.m. – 6 p.m. hora Centro).

ONLINE Convenient and instant. www.dyson.com/register

EN LÍNEA Conveniente y al instante. www.dyson.com/register
