T27020
3 IN 1
Deep Fill
Sandwich,
Panini &
Waffle Maker
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.
2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been designing,
developing and manufacturing housewares and small
appliances used by millions of households throughout the
UK and beyond. During the 1960s, the rise in popularity
of pressure cooking saw Tower become the UK’s largest
producer of pressure cookers, right through into the late
1980s. In recent years the Tower brand has been reborn with
an exciting and varied range of housewares and electrical
appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.
The Tower Deep Fill Sandwich Maker means you can enjoy delicious toasted
sandwiches quickly and at any time of the day or night. The Deep Fill Sandwich
Maker provides you with more space for extra fillings, making your toasted
sandwiches bigger and better.
The ceramic non-stick plates close to seal your sandwich and its contents. There is
no need for extra oil which means healthier eating for you and your family.
3
Contents:
Thank you for purchasing this appliance from the
Tower range.
Please read this manual carefully BEFORE using the
appliance for your own safety.
It has been designed to provide many years of
trouble-free use.
There are many benefits to using a Tower 3-IN-1
Deep Fill Sandwich, Panini & Waffle Maker:
• Easy clean, non-stick ceramic plates
• Cool-touch housing
• Power on and ready to use indicator lights
• Overheat protection
• Automatic temperature control
1. Specifications
Components and
structure
2. Technical Data
3. Important Safety
Information
4. Before First Use
5. Using your Appliance
6. Troubleshooting
7. Recycling
8. Cleaning & Care
9. Wiring Safety
10. Warranty Information
11. Weights and Measures
12. Recipes
See back page for Customer
Service Information.
4
This box contains:
Instruction Manual
2 Slice Deep Sandwich Maker
3 x Sets Non-stick plates:
(Waffle Plates)
(Panini Plates)
(Sandwich Plates)
1. Locking latch
2. Cool touch handle
3. Cooking plates
release buttons
4. Non-stick cooking
plates (3 options)
5. Power light
6. Ready light
1 - Specifications:
Structure of your appliance:
4
3
1 2
6 5
5
Description: 3-IN-1 Deep Fill Sandwich, Panini & Waffle Maker
Model: T27020
Rated Voltage: 220-240V
Frequency: ~50/60Hz
Power Consumption: 900W
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
1935/2004/EC Materials & Articles in Contact With Food
(LFGB section 30 & 31).
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom.
2 - Technical Data:
Should you encounter problems or require a replacement part, contact the Tower
Customer Support Team: +44 (0) 333 220 6066.
Some spare parts may be ordered from the Tower website.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Guarantee for spare parts:
The spares and accessories are guaranteed for 1 year from date of purchase.
The main body and housing are guaranteed for the extended free warranty subject
to registration.
If any defect arises due to faulty materials of workmanship, the faulty products must
be returned to the place of purchase within 12 months from the date of purchase.
Refund or replacement is at the discretion of the retailer.
6
Please read these notes carefully BEFORE using your
Tower appliance
3 - Important Safety Information:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the
appliance immediately
and seek advice from
the manufacturer,
its service agent or
a similarly qualified
person.
• DO NOT let the cord
hang over the edge of a
table or counter or let it
come into contact with
any hot surfaces.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use any
extension cords with
this appliance.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or
before cleaning.
• Switch off and
unplug before fitting
or removing tools/
attachments, after use
and before cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not
play with the appliance.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.
• Take care when any
appliance is used near
pets.
7
• DO NOT use this
product for anything
other than its intended
use.
• This appliance is for
household use only.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse
cords, plugs or any
part of the appliance
in water or any other
liquid.
• DO NOT use the
appliance outdoors.
• High temperatures
are present during
operation.
• Only touch the handles
on the unit.
• This appliance can
produce steam as part
of the cooking process.
Avoid contact with
steam escaping from
the appliance.
• The appliance is
not intended to be
operated by means of
an external timer or
separate remote control
system.
• Extreme caution must
be used when moving
an appliance that
produces hot oil or
other hot liquids from
the cooking process.
• Bread, oil, and other
foods may burn. Don’t
use the Sandwich
Maker near or below
curtains or other
combustible materials,
and watch it while in
use.
• DO NOT wrap food in
plastic film, polythene
bags, or metal foil. You’ll
damage the Sandwich
Maker, and you may
cause a fire hazard.
• Keep the Sandwich
Maker and the cable
away from hotplates,
hobs or burners.
• Unplug the Sandwich
Maker when not in use,
before moving and
before cleaning.
• DO NOT use the
Sandwich Maker for
any purpose other than
toasting sandwiches/
making toasties.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support
Team:
+44 (0) 333 220 6066
8
Read all instructions and safety information carefully before first use. Please retain
this information for future reference.
1. Carefully unpack the appliance. Remove all packaging materials.
2. Place the appliance on a flat, level surface. Open the sandwich maker lid.
3. Wipe the cooking plates with a damp cloth so that they are clean.
Note: Use a small amount of cooking oil to season the cooking plates, and wipe off
any excess with a dry cloth. This only needs to be done once.
4. Wipe the outside of the housing with a soft damp cloth. NEVER immerse the
power cord and plug in water or any other liquid.
5. Close the appliance.
6. Plug into the wall outlet and pre-heat for 10 minutes.
Note: During this initial phase some smoke may be emitted from the sandwich
maker. This is normal.
4 - Before First Use
9
Preparing Your Appliance:
1. Connect to your electrical supply and both indicator lamps will switch on to
show that the appliance is pre-heating.
2. Close the lid while the pre-heating occurs. During this time prepare your
sandwich ingredients.
3. The appliance is ready for use once the green indicator goes out. This will take
approximately 5 minutes.
Note: Initially, the appliance may release a slight harmless odour and smoke. This
is a normal occurrence caused by the initial heating of the heating elements and
should not re-occur.
Preparing sandwiches:
1. Butter the bread on the outer surfaces and place desired fillings within.
2. Lift safety catch and open the sandwich maker. Place sandwiches on the
heating plates.
3. Close the casing to ensure that the sandwich is placed evenly.
4. Lock the safety catch.
5. Normal cooking times will be 3-6 minutes for each sandwich. The red light will
turn on and off, as the thermostat keeps the sandwich maker at the proper
baking temperature.
CAUTION: The appliance is not to be operated in the open position.
CAUTION: The cooking surface is hot; handle with care.
Serving your sandwiches:
1. Remove the sandwiches from the heating plates with a plastic or wooden
spatula.
2. Be careful with your sandwiches, the fillings will be quite hot.
3. Allow to cool for a few minutes before enjoying.
Heating a Panini:
1. Place the panini plates onto the sandwich maker and turn on the unit. Once
the green light goes out the appliance is ready to cook.
2. Prepare your Panini with your chosen ingredients and turn on the unit. Close
the lid while the plates heat.
3. Once the green indicator goes out, open the sandwich maker and place the
Panini into the centre.
4. Press the top down with a little pressure upon the Panini and then allow it to
cook for 3-6 minutes according to your preference.
5 - Using Your Appliance
10
Making Waffles:
1. Place the waffle plates onto the sandwich maker and turn on the unit. Once
the green indicator light goes out the appliance is ready to cook.
2. Once you have prepared your favourite waffle mix and it is at the correct
consistency, pour slowly and evenly, making sure liquid doesn’t overflow, into
the waffle plates.
3. Waffle cooking times will vary according to the consistency of your mix, we
recommend no less than 2 minutes, and that cooking until golden brown
offers an ideal result.
4. Once cooked to your satisfaction, carefully remove with tongs and add your
favourite toppings.
Tips:
• Always preheat your sandwich maker fully.
• Ensure the lid of the sandwich maker is down whilst preheating.
• Butter, margarine and olive oil can all be used to coat the outside of your
bread.
• Light/Low fat versions of margarines are not recommended as they do not
withstand heat.
• Fillings: Try to use canned or pre-cooked fruit as fresh fruit may give off
excessive juices when heated. Be careful when biting into toasted sandwiches
containing fillings such as cheese and tomato or jam as they retain heat and
can burn if eaten too quickly.
• Processed cheeses tend to ‘run’ under higher temperatures.
• Pat moist ingredients (such as sliced tomatoes and fruits) dry before adding to
your sandwich.
• Allow hot sandwiches to rest for 2-3 minutes after removing them from the
sandwich maker. This helps the fillings cool slightly and means they will run
less.
Removing the Cooking Plates:
• Always unplug the Sandwich Maker and allow it to cool before removing
cooking plates.
• Open the lid, locate the plate release buttons on front of the unit. Press firmly
on the button and the plate will pop up slightly from the base. Grasp the plate
with two hands, slide it out from under the metal brackets, and lift it out of
the base. Press on the other plate release button to remove the other cooking
plate in the same manner.
11
Questions Answers
Do the indicator
lights show when my
sandwich is done?
No. The indicator lights only indicate power, and that the sandwich
maker has reached the correct temperature. Ensure you do not
leave the sandwich maker unattended during use.
How long will it take
to make a toasted
sandwich?
We recommend toasting your sandwiches for around five minutes.
Generally the sandwiches will be ready approximately 3 – 6 minutes
after adding them to the sandwich maker, depending on your
preference.
Why are my fillings
spilling over during
cooking?
You may have added too many fillings to your sandwiches. Ensure
that no fillings are ‘overflowing’ when you add the sandwich to the
Sandwich Maker. Fillings such as cheese and jam reach very high
temperatures when heated and can spill over.
6 - Troubleshooting
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to
information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.
7 - Recycling
12
This appliance requires little maintenance. It contains no user serviceable parts.
Do not try to repair it yourself. Refer it to qualified personnel if servicing needed.
Always unplug this sandwich maker from power source and wait until it cool down
before cleaning.
There is no need to take your sandwich maker apart for cleaning. Dry with a paper
towel to absorb excess oil. Brush crumbs from the grooves, and wipe with damp
cloth and mild soap.
Never immerse in water. Avoid using scratching or sharp utensils, as they will
scratch the nonstick surface.
Do not use cleansers or oven cleaners on the heating plates.
To clean handles and other parts, use a damp cloth with mild soap. Should any
filling be difficult to remove, pour a little cooking oil onto the plate and wipe off
after 5 minutes, when the filling has softened.
To clean handles and other parts, use a damp cloth with mild soap.
Should any filling be difficult to remove, pour a little cooking oil onto the plate and
wipe off after 5 minutes, when the filling has softened.
IMPORTANT:
After cleaning allow to dry fully before using again.
Do not use the appliance if damp. Ensure the appliance is completely clean and
dry before storing.
Storage:
To store your appliance:
1. Unplug power cord from the power outlet and clean as above.
2. Allow the appliance to dry fully.
3. Store on a flat, dry level surface out of reach of children.
8 - Cleaning & Care
13
9 - Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals
in your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and
must be connected to the terminal marked
[N].
The wire labelled brown is the live wire and
must be connected to the terminal marked
[L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the
same rating already tted and conforming to
BS 1362 and be ASTA approved.
If in doubt consult a qualied electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must
use an ASTA approved one (conforming to
BS 1362 of the same rating).
If in doubt, consult a qualied electrician
who will be pleased to do this for you.
If you need to remove the plug - disconnect
it from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug
or insert it into a socket outlet as there is a
danger of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!
14
This product is guaranteed for 12 months
from the date of original purchase.
If any defect arises due to faulty materials
of workmanship, the faulty products must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase or a
receipt.
• The product must be installed and
used in accordance with the
instructions contained in this
instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear,
damage, misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire
only.
The standard one year guarantee is only
extended to the maximum available for
each particular product upon registration
of the product within 28 days of purchase.
If you do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and
register with us online.
Please note that length of extended
warranty offered is dependent on product
type and that each qualifying product
needs to be registered individually in order
to extend its warranty past the standard
1 year.
Extended warranty is only valid with proof
of purchase or receipt.
As a thank you for purchasing
one of our fantastic products,
we are offering you an extra
2 years peace of mind in
addition to your 1 year
guarantee.
To receive your extra 2 year
guarantee, register your
appliance online within 28
days of purchase by visiting
www.towerhousewares.co.uk
10 - Warranty
15
Check these charts for basic imperial to metric
conversions of weights.
Food Allergies
Important Note: Some of the recipes contained in this document may
contain nuts and/or other allergens. Please be careful when making any of our
sample recipes that you ARE NOT allergic to any of the ingredients. For more
information on allergies, please visit the Food Standards Agency’s website at:
www.food.gov.uk
11 - Weights & Measures
Metric Imperial US cups
250ml 8 floz 1 cup
180ml 6 fl oz 3/4 cup
150ml 5 floz 2/3 cup
120ml 4 floz 1/2 cup
75ml 2 1/2 floz 1/3 cup
60ml 2 floz 1/4 cup
30ml 1 floz 1/8 cup
15ml 1/2 floz 1 tablespoon
Imperial Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
15 oz 425g
1 lb 450g
16
For more great recipes and inspiration from the
Tower Kitchen, visit
www.towerhousewares.co.uk/blog
Recipes
Recipes for use with the T27020 Deep Fill Sandwich, Panini & Waffle
Maker
.
17
Cooking with your sandwich maker.
Fillings:
Savoury:
• Ham, Cheese and Tomato
• Tuna Melt - Tuna, Mayonnaise and Cheese
• Roast Pork and Apple Sauce
• Turkey, Stuffing and Cranberry
• Cheese, Beans and Sausage
• BLT - Bacon, Lettuce and Tomato
• Brie, Cranberry Sauce and Rocket
Sweet:
• Chocolate Spread and Banana
• Toffee and Apple
• Cherry Pie Filling
• Apple and Blackcurrant
• Apple and Sultanas
18
Ingredients
4 slices of bread
6 slices prosciutto
55g fresh mozzarella
(approximately 2 to 3 slices per
sandwich)
Ingredients
4 Slices of bread
Smoked salmon
Cream cheese
Prosciutto and Fresh Mozzarella
Makes 2 sandwiches
Smoked Salmon and Cream Cheese
Makes 2 sandwiches
Method
1. Plug in your Sandwich Maker to preheat.
2. Place two slices of bread on your work surface and butter.
3. Turn the bread butter side down and evenly place the
prosciutto and mozzarella slices on to the bread.
4. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
5. Once the sandwich maker has preheated, place the
sandwiches in the heater plates and close.
6. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
7. Cut sandwiches along the perforated edges and serve.
Method
1. Plug in your Sandwich Maker to preheat.
2. Place two slices of bread on your work surface and butter.
3. Turn the bread butter side down and evenly spread the
cream cheese and place the smoked salmon on to the
bread.
4. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
5. Once the sandwich maker has preheated, place the
sandwiches in the heater plates and close.
6. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
7. Cut sandwiches along the perforated edges and serve.
19
Ingredients
4 slices of bread
4-6 slices Cheddar cheese (or your
favourite cheese)
Traditional Grilled Cheese
Makes 2 sandwiches
Method
1. Plug in your Sandwich Maker to preheat.
2. Place two slices of bread on your work surface and butter.
3. Turn the bread butter side down and add slices of cheese.
4. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
5. Once the sandwich maker has preheated, place the
sandwiches in the heater plates and close.
6. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
7. Cut sandwiches along the perforated edges and serve.
Ingredients
4 slices bread
1 tomato, sliced
4 bacon strips
2 thick slices of cheese
Breakfast Sandwich
Makes 2 sandwiches
Method
1. Pre-cook your bacon.
2. Plug in your Sandwich Maker to preheat.
3. Place two slices of bread on your work surface and butter.
4. Turn the bread butter side down and the cooked bacon,
tomato slices and cheese.
5. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
6. Once the sandwich maker has preheated, place the
sandwiches in the heater plates and close.
7. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
8. Cut sandwiches along the perforated edges and serve.
thank you!
We hope you enjoy your appliance for many years. As a thank you for
purchasing one of our fantastic products, we are offering you an extra
2 years peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6066
0120.V5
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
