QUICK REFERENCE GUIDE > HI90BLX1
Date: 29.07.2021 > 1
Wall Rangehood, 90cm, Island
Stainless Steel
Perfect for kitchens with a cooktop built into a central island – this efficient
rangehood looks stylish from all angles.
Efficient 700m3/hr air flow
Easy to clean, with dishwasher-safe filters
Four energy-efficient LED lights illuminate your cooktop perfectly
Ducted or recirculation options for more flexibility when installing
DIMENSIONS
Height
950 - 1100 mm
Width
898 mm
Depth
600 mm
FEATURES & BENEFITS
Effective, efficient extraction
Select between three fan speeds to ensure steam, odours and grease
are extracted from your kitchen at the rate you need for your cooking.
Clean and pristine
Built from beautiful stainless steel, this rangehood is easy to keep clean.
Put the aluminium filters into your dishwasher regularly for a quick, simple
clean.
A joy to use
Creating culinary delights is a pleasure thanks to design features such as
simple push-button controls that turn on extraction immediately, and low-
energy LED lighting to perfectly illuminate your cooktop.
Installed to suit
This rangehood offers ducted or recirculated extraction, so you can
choose the solution that best suits your kitchen.
SPECIFICATIONS
Accessories
Aluminium filter
H0530061772
Chimney extension
H0530062213
Light bulb
H0530061789
Recirculation carbon filter
H0530061771
Recirculation kit
H0530062211
Fan ratings
Maximum air movement
700m³/hr
Maximum sound rating
73dBA
Installation and cleaning
Air outlet size
150mm
Dishwasher safe filters
•
Ducted
Top extraction
Recirculation
Optional - top extraction
Two piece height adjustable flue
•
Performance
Extraction type
Surface
Fan speeds
3
Filter type
Mesh
Number of filters
3
Power requirements
Supply frequency
50Hz
Supply voltage
220 - 240V
Product dimensions
Depth
600 mm
Height
950 - 1100 mm
Width
898 mm
Product information
Control type
Push button
Ventilation features
Light type
LED 4 x 2W
Warranty
QUICK REFERENCE GUIDE > HI90BLX1
Date: 29.07.2021 > 2
Parts and labour
2 years
SKU 50187
TEST The product dimensions and specifications in this page apply to the specific product and
model. Under our policy of continuous improvement, these dimensions and specifications may
change at any time. You should therefore check with Fisher & Paykel's Customer Care Centre
to ensure this page correctly describes the model currently available. ? 2020 Haier Inc. All
rights reserved.
Other product downloads available at haier.com
User Guide
Installation Guide
