Cordless Stick Vacuum Cleaner
User Manual
EN
VRT 94929 VI
01M-8910723200-4220-01
ENGLISH 07-16
CONTENTS
3
1
2
3
4
7
8
9
10
11
12
13
14
5
6
15 16 17 18 19 20
21
22
4
EN
OPERATION CLEANING AND CARE
5
1 2 3
4
5
6
7
12
1
2
1
2
1
2
102-104cm
10
11
1
1
2
2
3
3
OR
8
1
2
9
6
1 32
4 5 6
1
2
24h
18
NEW
14
15
TURBO
17
13
14
ON/OFF
16
7
11
1
2
1
2
24h
13
18
OR
17
1514
16
1
12
2
7 8 9
10
1
1
1
2
2
2
Please read this manual
first!
Dear Customer,
Thank you for selecting a Beko product.
We hope that you get the best results
from your appliance which has been
manufactured with high quality and
state-of-the-art technology. For this
reason, please read this user manual and
all other provided documents carefully
before using the appliance and keep it
as a reference for future use. If you hand
over the appliance to someone else, give
the user manual as well.
Ths applance has been produced n envronmentally-frendly, state-of-the-art facltes.
Ths product does not contan PCB’S.
Follow the instructions by paying
attention to all the information and
warnings in the user manual.
Meanings of the symbols
Following symbols are used in various
sections of this manual:
Important information and useful
hints about usage.
WARNING:
Warnings against
dangerous situations concerning the
security of life and property.
Protection class for electric shock.
1. On/off button
2. Mode button +
3. Mode button -
4. Tube release button
5. Brush release button
6. Electrcal turbo brush
7. Battery pack release button
8. Machne body
9. Dust cup
10. Dust cup release button
11. Foldable tube button
12. Chargng staton
13. Chargng staton tube
14. Chargng staton support
15. Hard floor roller
16. Power supply plug
17. Elbow
18. Crevce
19. Mn turbo brush
20. Soft brush
21. Screw
22. Wall plug
-Extra battery
Techncal data
Rated nput power :
450 W
Input :
100 - 240 V~ 50/60Hz 0.8 A (max)
Output :
36 V
0.6A
Chargng tme :
4-5 hours
Runnng tme max. power:
7 mn.
Run tme at medum power:
22 mn
Runnng tme mn. power to up to:
45 mn.
Techncal and desgn modfcatons reserved.
The values whch are declared n the markngs affxed
on your applance or the other prnted documents
suppled wth t represent the values whch were
obtaned n the laboratores pursuant to the pertnent
standards. These values may vary accordng to the
usage of the applance and ambent condtons.
Cordless Stick Vacuum Cleaner / User Manual
9 / 14 EN
9 / EN
This section contains safety
instructions that will help protect
from risk of personal injury or
property damage.
Failure to follow these instructions
invalidates the granted warranty.
1.1 General safety
• Ths applance comples wth
nternatonal safety standards.
• Ths applance ntended to be
used n household and smlar
applcatons suchas:
- Staff kitchen areas in shops,
offices and other working
environments;
- Farms houses
- By clients in hotels, motels
and other residential type
environments
- Bed and Breakfast type
environments.
-It is not fit for industrial use.
• Ths applance can be used by
chldren aged from 8 years and
above and persons wth reduced
physcal, sensory or mental
capabltes or lack of experence
and knowledge f they have been
gven supervson or nstructon
concernng use of the applance
n a safe way and understand
the hazards nvolved. Chldren
shall not play wth the applance.
Cleanng and user mantenance
shall not be made by chldren
wthout supervson.
• If the adapter or the applance
tself s damaged, do not use t.
Contact an authorsed servce.
• Your mans power supply should
comply wth the nformaton
suppled on the ratng plate of the
applance.
1 Important safety and envronmental nstructons
10 / 14 EN
Cordless Stick Vacuum Cleaner / User Manual
10 / EN
• Do not use the applance wth an
extenson cable.
• Prevent damage to the power
cable by not squeezng, bendng,
or rubbng t on sharp edges.
• Do not touch the applance or ts
plug when t s plugged f your
hands are damp or wet.
• Do not pull the power cable when
unpluggng the applance.
• Do not vacuum flammable
materals and when vacuumng
cgarette ash, make sure that t
has cooled down.
• Do not vacuum water or other
lquds.
• Protect the applance from ran,
humdty and heat sources.
• Never use the applance n or
near places where combustble or
nflammable ambence or places
are present.
• Unplug the applance before
cleanng and mantenance.
• Do not mmerse the applance
or ts power cable n water for
cleanng.
• Do not attempt to dsmantle the
applance.
• Use the orgnal parts or
parts recommended by the
manufacturer only.
• Do not clean the partcles such as
cement, plaster and compressed
paper n order to prevent the flter
from beng clogged and the motor
beng damaged.
• Use the applance only wth the
adapter suppled wth.
• Do not use the applance wthout
flters; otherwse t can get
damaged.
• If you keep the packagng
materals, store them out of the
reach of chldren.
• Ths applance s not ntended for
use by persons (ncludng chldren)
wth reduced physcal, sensory
or mental capabltes, or lack of
experence and knowledge, unless
they have been gven supervson
or nstructon concernng use
of the applance by a person
responsble for ther safety
• Chldren should be supervsed to
ensure that they do not play wth
the applance
• The applance s only to be used
wth the power supply unt
provded wth the applance.
1 Important safety and envronmental nstructons
Cordless Stick Vacuum Cleaner / User Manual
11 / 14 EN
11 / EN
• The adapter must be removed
from the socket-outlet and the
battery pack must be removed
from the applance before cleanng
or mantanng the applance
• If the adapter s damaged, t must
be replaced by the manufacturer
or ts agent or smlarly qualfed
person n order to avod hazard.
• Keep fngers, har and loose
clothng from movng parts and
openngs whlst usng the vacuum
cleaner
• The battery must be removed
from the applance before t s
scrapped;
• The applance must be
dsconnected from the supply
mans when removng the battery;
• Please dspose of used batteres
accordng to local laws and
regulatons.
• Ths applance contans batteres
that are only replaceable by sklled
persons.
•
WARNING:
For the purposes
of rechargng the battery, only
use the detachable supply unt
YLS0241A-A360060 provded
wth ths applance.
• Please remove and nsert the
batteres accordng to UM.
1 Important safety and envronmental nstructons
• Rechargeable batteres are to
be removed from the applance
before beng charged;
• Dfferent types of batteres or
new and used batteres are not to
be mxed.
• Batteres are to be nserted wth
the correct polarty.
• Exhausted batteres are to be
removed from the applance and
safely dsposed of.
• If the applance s to be stored
unused for a long perod, the
batteres should be removed.
• The supply termnals are not to be
short-crcuted.
• Only use wth ZB1858 battery.
• The applance s not to be used
by persons (ncludng chldren)
wth reduced physcal, sensory
or mental capabltes, or lack of
experence and knowledge, unless
they have been gven supervson
or nstructon.
• Chldren beng supervsed not to
play wth the applance.
12 / EN
Cordless Stick Vacuum Cleaner / User Manual
2 Part assemblng
2.1 Elbow (17)
The elbow s extenson tools, one end s nserted
nto the sucton port , the other end s connected
wth the accessores, whch can clean corners or
narrow spaces (7).
2.2 Crevice (18) and soft brush
(20)
Push the round part of the accessory nto the
sucton part untl t clcks. Soft brush cleans your
furnture wthout harmng t (6-7).
2.3 Mini turbo brush (19)
Push the end of the Mn-brush nto the sucton
part untl t clcks.
Remove t by pullng the buttons (6).
2.4 Hard floor roller (15)
Hard floor roller provdes hgher cleanng
performance on parquet, tles etc. (17)
3.1 Charging Indicator
It ndcates the
battery charge
status.
Workng Chargng
Fully
charged
Lower
power
Persstent
whte lght
Blnkng
whte lght
Persstent
whte lght
Blnkng red
lght
3.2 Charging station (12)
Whle chargng the battery on the chargng dock
the charge ndcator flashes whte.
C
• When you receive this product,
please use the charger provided
by our company to recharge the
battery for 3 hours (no need to
charge it full) and the charging
frequency should be every 3
months.
• Do not place the battery on the
charging base for a very long time.
• When the battery is not in use for a
long time or it is over-discharged,
you may find the working time is
reduced at the first few times.
We recommend you fully charge
the battery (usually 6 hours) and
discharge it. Repeat this action
two times.
• The product has the ablty to stand n
uprght poston wth the lockng
mechansm of the brush. The floor
must be level for ths functon to be
used correctly (hard floor, parquet,
etc.). If the product s not used and
when t s to be stored, t must be
kept on ts chargng staton. The
vacuum cleaner can stand n uprght
poston (on surfaces such as hard
floors, parquet, etc.) for short duratons (2-3
mnutes) thanks to the brush lockng
mechansm.
3 Use
Cordless Stick Vacuum Cleaner / User Manual
13 / EN
4.1 Cleaning and care
Switch off and unplug the appliance ,before cleaning it.
A
WARNING:
Never use gasoline,
solvent, abrasive cleaning agents,
metal objects or hard brushes to
clean the appliance.
4.2 Hepa filter
• In order to ensure the performance of the
product, we recommend you clean regularly,
and replace one after 3-6 months. (Depending
on usage)
A
WARNING:
Long-term no use,
please keep the battery intact,
stored in a cool dry place, and let the
battery in the semi-state of charge.
Not full or empty. Please enclose
the battery with non-conductive
material to avoid the metal touching
the battery directly, causing the
battery to be damaged.
4.3 Storage
• If you do not intend to use the appliance for a
long time, store it carefully.
• Pull the appliance’s plug out.
• Keep the appliance out of the reach of children.
• Long-term no use, please keep the battery
intact, stored in a cool dry place, and let the
battery in the semi-state of charge. Not full or
empty.
• Please enclose the battery with non-conductive
material to avoid the metal touching the battery
directly, causing the battery to be damaged.
4.4 Handling and
transportation
• During handling and transportation, carry
the appliance in its original packaging. The
packaging of the appliance protects it against
physical damages.
• Do not place heavy loads on the appliance or on
the packaging. The appliance may get damaged.
• Dropping the appliance may render it non-
operational or cause permanent damage.
4.5 Compliance with the WEEE
Directive and disposal of the
waste product
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE).
This symbol indicates that this product shall not be
disposed with other household wastes at the end
of its service life. Used device must be returned to
offical collection point for recycling of electrical
and electronic devices. To find these collection
systems please contact to your local authorities
or retailer where the product was puchased. Each
household performs important role in recovering
and recycling of old appliance. Appropriate
disposal of used appliance helps prevent potential
negative consequences for the environment and
human health.
4 Informaton
14 / EN
Cordless Stick Vacuum Cleaner / User Manual
4.6 Information on waste
batteries
This symbol on rechargeable batteries/
batteries or on the packaging indicates
that the rechargeable battery/battery
may not be disposed of with regular
house hold rubbish. For certain recharge able
batteries/batteries, this symbol may be
supplemented by a chemical symbol. Symbols for
mercury (Hg) or lead (Pb) are provided if the
rechargeable batter ies/batteries contain more
than 0,0005 % mercury or more than 0,004 %
lead.
Rechargeable batteries/batteries, including those
which do not contain heavy metal, may not be dis-
posed of with household waste. Always dispose of
used batteries in accordance with local environ-
mental regulations. Make enquiries about the ap-
plicable disposal regulations where you live.
4.7 Compliance with RoHS
Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
4.8 Package information
Packaging materials of the product are
manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials together
with the domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.
4 Informaton
Cordless Stick Vacuum Cleaner / User Manual
15 / EN
5 Troubleshooting
Common falure Possble cause Solutons
The vacuum doesn’t work
Product s power off or battery s low
Please charge the product before
use
Product sucton port s blocked. Cleanng product sucton mouth
Sucton s too weak
Dust barrel & flter assembly s dusty Clean the dustbn and flter materal
Rollng brush s wrapped around the
har and other objects
Clean roller brush
Stuaton stll remans
Please contact wth our after sales
team
Dfferent motor operaton sound
The alumnum tube s blocked Clean up the obstacles
Stuaton stll remans
Please contact wth our after sales
team
Vacuum cleaner n trouble at work
Too many obstacles n the cleanng
area
Manually remove obstacles
Product sucton port s blocked Clean product sucton mouth
Stuaton stll remans
Please contact wth our after sales
team
Product can not be charged
Battery pack and charger nterface
not connected well
Please check and contact well
Charger or receptacle s not fully
charged or loose
Check t and put away
Stuaton stll remans Please contact wth us
Common LED falure Possble cause Solutons
The red lght flcker Product s power off or battery s low
Please charge the product before
use
The red lght flash
Brush pluggng and the man brush
motor s workng
Clean roller brush
Overchargng current s too lager Change the correct adapter
The red and whte lght tradng flash
when the dscharge process
The battery pack has a problem
Please contact wth our after sales
team
The red and whte lght tradng flash
when the charge process
The battery pack s not nstalled well
1- Remove adapter
2- Installed the battery pack agan
3- Insert adapter
4- Strctly follow the above steps
55 Blanck Street, Ormeau Q 4208
P O Box 354, Ormeau Q 4208
p : 5549 3146 f : 5549 3546
ABN : 49 152 055 162
Sensitivity: Public
ORIGINAL MANUFACTURER’S WARRANTY
ADVICE FORM
BEKO SMALL DOMESTIC APPLIANCE
12 months warranty, full parts and labour warranty only.
WARRANTY CONDITIONS
The following conditions apply only in relations to the warranty expressly given on this Warranty Advice Form supplied with the product. This
warranty only applies to appliances purchased and used in Australia or New Zealand and is in addition to (and does not exclude, restrict or
modify in any way) other rights and remedies under a law to which the appliances relate, including any non-excludable statutory guarantees in
Australia and New Zealand. It applies to the original purchaser and for appliances used in domestic applications only.
1. This warranty does not apply:
(a) if the identification number attached to the appliance has been altered, rendered illegible or removed;
(b) to light globes;
(c) to paint and vitreous enamel finishes and glass;
(d) to surfaces damaged by use of aerosols or cleaners;
(e) if the appliance has been –
(i) subject to misuse, abuse, negligence, accident, fire or floods;
(ii) connected or improper, inadequate or faulty electricity, gas, water or drainage services or intake or exhaust
ducts or flues, or operated using incorrect or contaminated fuels or lubricants;
(iii) installed, maintained or operated otherwise than in accordance with the instructions furnished by Beko including the
improper use of detergents, bleaches, cleaners or other additives;
(iv) damaged by foreign objects in the appliance;
(v) serviced, repaired or altered otherwise than by Beko authorised service agents of Beko, or using other than Beko
approved replacement parts.
2. The purchaser shall be responsible for any expenses involved in making the appliances readily accessible for servicing, the purchaser
shall be responsible for any costs of transporting the appliance or parts thereof to and from the nearest Beko authorised service agent.
3. This warranty is the only expressed warranty given by Beko.
4. Beko reserves the right to determine whether or not the fault is caused by faulty workmanship or material or that any part is defective.
5. Where permitted by law, this warranty shall not apply to loss suffered through or resulting from the non-operation or the ineffective
operation of the appliance or any part of the appliance.
6. The purchaser must produce proof of the date of purchase together with this Warranty Advise Form when making a claim.
7. Subject to your statutory rights as to the merchantable quality of the product or accessory. In the event of a product or accessory being
replaced during the guarantee, the guarantee on the replacement will expire at the original date, i.e., 12 months from the original
purchase date.
8. Australia: For Appliances and services provided by Beko in Australia, Beko goods come with a guarantee by Beko that cannot be
excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance
fails to be of acceptable quality and the failure does not amount to a major failure. ‘Acceptable quality’ and ‘major failure’ have the
same meaning as referred to in the Australian Consumer Law.
9. New Zealand: For Appliances and services provided by Beko in New Zealand, the Appliances come with a guarantee by Beko
pursuant to the provisions of the Consumer Guarantees Act, the Sales of Goods Act and the Fair Trading Act. Where the Appliance
was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.
These Warranty Conditions supersedes and excludes all other representations, conditions and warranties, except those implied
by legislation previously referred to.
For Service or Spare Parts: Aust 1300 282 356 NZ 0800 692 356
Beko A&NZ Pty Ltd
55 Blanck Street ,
Ormeau QLD, 4208
AUSTRALIA
www.beko.com.au
Ph: 1300 282 356
