Owner’s Manual
AVANT 23" ROUND GAS FIRE COLUMN
DANGER
WARNING
WARNING
WARNING
For outdoor use only.
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier
or fire department.
Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury, or death.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected
for use shall not be stored in the vicinity of
this or any other appliance.
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury, or loss of life.
•
•
•
•
Installation and service must be performed
by a qualified installer, service agency,
or the gas supplier.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
INSTALLER: Leave this
manual with the appliance.
CONSUMER: Retain this
manual for future reference.
service agency, or the gas supplier.
with this appliance. Installation and service must be performed by a qualified installer,
damage, personal injury or loss of life. Refer to the owner's information manual provided
Improper installation, adjustment, alteration, service or maintenance can cause property
Sku# 25952
43
Item# 52285
Model# HYFP50085-36
SAFETY INFORMATION
Page 2
WARNING
Before you assemble or operate this unit, please carefully read this entire manual. Failure to do so
may r
•
• THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used outdoors, in a
ventilated space and shall not be used in any enclosed area.
•This unit is to be used with propane gas only! (sold separately)
•Do not attach a remote gas supply to this unit.
•Only use propane gas for this unit.
•Solid fuels shall not be burned in this appliance.
•
• LP GAS WARNING: Do not use any more than 1/4in depth lava rocks/pumice stones/LavaGlass
®
above the bur
•If the propane gas tank is leaking gas, you may smell, see, or hear a hiss. Do the following:
e department for help.
•Applying too much propane may result in gas pooling and will not burn. Allow fresh air into the unit
so that the remaining gas may escape.
•
• Manifold pressure: 11 inch w.c. (2.74kPa).
•
• You must use a propane tank that has a collar to protect the gas valve.
•
• The tank system must be set up for vapor withdrawal.
•Discontinue use if any part of the propane tank is damaged. Rust and dents may be hazardous and
should be inspected by a gas supplier.
•
•
rocks/pumice stones/LavaGlass
®
could pop out and cause injury. Should any rocks pop out, discard
them.
•Always ensure that lava rocks/pumice stones/LavaGlass
®
are completely dry before use. Failure to
do so will cause them to crack or pop.
•Do not operate unit until all parts are fully assembled.
•Do not paint or color any part of this heating unit.
•Unit may be hot while in use, do not attempt to move it while in use.
•Never leave this heating unit unattended while in use.
•This unit is not intended for cooking.
•
• Keep a safe distance to avoid burning skin or clothing.
•Do not sit or rest hands or feet on this heating unit.
•
• Keep all electrical cords and fuel supply hose away from heated surfaces.
Use LP propane tanks with the following dimensions: diameter 12 in, height 18 in - capacity 20 lbs.
The installation of this unit must adhere to local codes or Propane Storage and Handling Code,
CSA B149.2.
pit.
•Cover must be removed when burner is in operation.
Page 3
IF APPLICABLE:
•Allow heating item to cool completely before placing on lid.
•DO NOT use heating item while lid is installed. Always remove the lid while heating item is in use.
•
Combustible material should not be within 60 inches of the top of the unit, or within 48 inches
around the entire unit.
•
Keep the appliance area clear and free fr
vapors and liquids.
•
• Do not add water into the unit.
• Do not operate unit if any part has been under water. Immediately call a qualified service technician
to inspect the appliance and replace any part of the control system and any gas control that has been
under water.
•Do not disconnect any part while unit is in use.
•Do not store a spare propane tank on or near this unit.
•If the heating unit is indoors, detach the propane tank and leave outdoors.
•Always remove protective cover before operating (if applicable).
•Do not set the protective cover over the unit until it is turned off and completely cooled down.
•Check for leaks after not using the unit for long periods of time.
•Children should never operate this unit. Children must be supervised while near this unit.
•Keep gas tank at least 5 feet away from unit when lit. (if external tank)
•Maximum gas supply: 250 psi; Min. gas supply: 10 psi.
inspected annually and cleaned regularly.
• Inspect all elements of this heating unit before each use. If there is damage, the burner must be
replaced.
• Keep the hose out from any pathways to eliminate any accidental damage. (if external tank)
• Be aware of the hazards of high temperatures and stay away from the unit to avoid any burns or
injury.
of the U.S. Department of Transportation or the National Standard of Canada CAN/CSA-B339, LP gas
tanks, spheres and tubes for Transportation of Dangerous Goods; and Commission.
gas tank connection.
cks.
• Children and adults should be alerted to the hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the area of the appliance.
near the appliance.
• Any guard or other protective device removed for servicing the appliance shall be replaced
prior to operating the appliance.
may be required as necessary. It is imperative that the control compartment, burners and
circulating airways of the appliance are kept clean.
(CGA791) LP
SAFETY INFORMATION
Page 4
Combustible materials should not be within 60
inches of the top of the unit, or within 48 inches
around the entire unit.
Min. Clearance
48 in. ( 121.9 cm )
Min. Clearance
60
in. (1
52
.
4
cm )
Min. Clearance
48 in. ( 121.9 cm )
Always place this outdoor fire pit
on a hard, level,
non-combustible surface such as concrete, rock or
stone.
DANGER
NOTE: You must follow all steps to properly assemble this heating item. Make sure the gas
valve is turned ‘OFF’ before assembling. Do NOT attempt to assemble without proper tools.
Only use the r
egulator and hose assembly provided with this unit. Replacement parts must be supplied
dir
ectly by manufacturer.
Inspect the burner before use of this unit. If the burner shows any kind of damage, do not operate
the appliance. For assistance with repair or replacement of the bur
ner or any other parts, call
manufacturer at 1.877.447.4768.
Page 5
CONTENTS
Item Description Qty
A Lava Rocks 2 boxes
B Battery (AA) 1
C Body 1
D 1
E
PVC Cover
1
F Control Knob (preassembled) 1
G 1
H 1
I 1
A
B
D
Burner (preassembled)
Guard (preassembled)
Electronic Igniter (within firebowl insert body)
E
Door
F
C
G
H
I
(4 kg)
ASSEMBLY INSTRUCTIONS
1. Check that the control knob (F) for the gas
supply system is turned to the 'OFF' position
before starting any assembly.
2.
Page 6
Remove door (E) from body (C) . Remove the
and slide battery (B) into the battery slot. Make
sure the positive side of the battery faces battery
faces outwards. Screw the electronic igniter cap (G)
over the battery tightly.
cap on the electronic igniter (G) by unscrewing
Place propane gas tank (not included) into the
the metal stand inside of the body (C).
3.
F
G
B
H
L
OFF
OFF
44 .
connections by hand only.
Make sure it is fastened securely and tighten
by turning the regulator coupling nut clockwise.
regulator from the body (C) to the cylinder valve
close the propane tank. Attach the preassembled
Turn the cylinder valve on the tank clockwise to
5 .
Page 7
Once the tank is attached to the regulator,
make sure the propane gas tank sits on the
metal stand inside body (C) completely. Turn the
preassembled wing screw on the outer part of
metal stand clockwise to secure the propane gas
tank tightly.
6. Replace door (E) onto the body (C).
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
RUBBER O RING
WARNING
Please inspect the rubber O ring in the
propane tank valve to ensure it is not
worn before attaching regulator. Worn
and serious injury by propane tank.
rubber O ring can cause leaks, explosions
7. Pour the box of lava rocks (A) into the body (C).
Page 8
To ensure proper function, the guard (I) on this
burner (H) should be free of lava rocks at all times.
C
A
I
K
eep away from the unit and allow the unit to
burn 20 minutes for the first time use.
Always ensure that lava rocks/pumice stones/
LavaGlass
®
are completely dry before use. Failure
to do so will cause them to crack or pop.
WARNING
Once the fire product is lit, the fame intensity may be controlled by turning the control knob (F)
counterclockwise to the 'LOW' position will ignite the fuel.
OPERATION
Before performing a leak test, be sure that no sparks can occur and you are in a spacious outdoor
area. Connect the propane gas tank to the regulator and turn the valve on the unit to the 'OFF'
position. Brush a soap and water mixture on all connections. Turn the gas supply on; if bubbles
occur on any connection there may be a leak. If you smell gas or a leak is discovered turn the
gas valve off, disconnect propane gas tank and do not use the appliance until the leak is
repaired.
Do not use the heating unit without inspecting the gas hose. If there are signs of wear or abrasion
you must replace the hose (if applicable).
Pumice stones/lava rocks/LavaGlass
®
could pop up and
strike somebody’s face during the
20 minutes after igniting. Flame height should be a yellow/blue color between 2 - 10 inches in height.
Wait 50 minutes after extinguishing flame prior to placing a lid (if applicable) or protective cover on
heating item.
To Light
To Extinguish
1. Make sure the control knob (F) is in the 'OFF' position.
2. Open the door (E) and slowly open the valve on the propane gas tank by turning the knob
counterclockwise.
3. Close the door (E) on the body.
5. If ignition doesn’t occur within a few seconds release the control knob (F) and rotate to the
'OFF' position. Wait for 5 minutes for gas to clear and then repeat the above lighting instructions.
6.
between the 'LOW' and 'HIGH' positions.
1. Turn control knob (F) clockwise to the 'LOW' position; let the knob pop up and continue turning
the control knob (F) to the 'OFF' position.
2. Close the cylinder valve on the propane gas tank if you don’t intend to use it for a long time.
4. A pulse igniter is built into the control knob (F) so pushing and truning the control knob (F)
for 15 seconds.
Keep holding down the control knob
WARNING
If the burner does not ignite with the burner
control valve open, gas will continue to flow
out of the burner and could accidentally ignite
causing injury or property damage.
OFF
H
L
OFF
H
L
in.
10
25
2
5
cm
in.
cm
Page 9
• Before performing any maintenance always disconnect propane gas tank.
• Keep the heating item free and clear from combustible materials.
• Visually inspect burner for obstructions and keep tank enclosure free and clear from debris.
• Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner and
pumice stones/
lava rocks/LavaGlass
®
are completely cooled down. Wipe down with a soft cloth.
• Harsh weather conditions may cause stubborn stains, discoloration and possibly rust pitting.
• Permanent damage may occur if powder or solvent comes in contact with painted or plastic
components on this heating unit.
• Keep the heating unit stored away from direct sunlight.
• If storing this unit inside, disconnect the propane gas tank from the gas valve.
• Not using manufacturer approved or supplied parts/accessories may result in a defective condition
and void the warranty of this heating unit.
• Always place lid (if applicable) or protective cover on heating item when not in use.
Store your product indoors during winter months. Avoiding extreme cold temperatures will
prevent from exposure damage.
•
Page 10
TROUBLESHOOTING
Page 11
TROUBLESHOOTING
Problem Cause Solution
Igniter pin and burner are wet Dry off with a soft cloth
Igniter battery is incorrectly inserted Check which direction the battery is
inserted
Igniter pin is broken
Contact Manufacturer for a replacement
part
Electrode wire is loose or disconnected Reconnect wire to the igniter box located
inside the unit behind the igniter box
Electrode wire is shorting between valve
and igniter pin
Contact Manufacturer for a replacement
part
No gas flow Check that the gas tank isn’t empty
Regulator isn’t connected securely to the
tank
Tighten regulator connection to the gas
tank
Gas flow is obstructed Check all hoses for kinks and bends
Burner ports are clogged Turn all gas flow connections off. Insert
an opened paperclip (or similar item) into
each of the burner ports to clear them
out.
Flame is obstructed at burner ports Check that all burner ports are free of any
small lava rocks/pumice stones/Lava-
Glass
®
pieces
Regulator hose is kinked Straighten hose of all bends or kinks
No gas flow Check that the gas tank isn’t empty
Excess flow safety valve has been
activated
High or gusting winds
No gas flow Check that the gas tank isn’t empty
Excess flow safety valve has been
activated
See ‘sudden drop in gas flow’ above
Heating unit won’t light
Burner won’t light
while using a match
Heating unit emits a lot
of black smoke
Sudden drop in gas
flow
Flame blows out easily
Turn the contr
ol knob to the ‘OFF
’ posi-
tion. Close the tank valve and disconnect
propane gas tank. Turn the control knob
to ‘HIGH’; wait 1 minute.
Turn the control
knob back to the ‘OFF
’ position. Recon-
nect propane gas tank. Light the fire unit
as indicated in the ‘To Light’ section of
this manual.
Incr
ease flame to ‘HIGH’
WARRANTY
CONTACT
This product has a one-year warranty against manufacturing defects in workmanship, or materials.
The manufacturer warranty will be voided by, and manufacturer disclaims any responsibility for, the
following actions:
•
•Use of any component part not manufactured or appr
oved by Manufacturer.
•Use and installation other than what is listed in this manual.
Please contact the manufacturer for replacement parts.
If you have any questions or concerns, please contact manufacturer at the below
resources:
Website
1-877-447-4768 | Monday - Friday,
8:00 am - 4: 30 pm CST
www.ghpgroupinc.com
Email
Toll free phone
Page 12
