AHPD8000W
OPERATION MANUAL
APPLIANCES
FOR LIVING
Congratulations, you are now the proud owner of an ARTUSI cooking appliance. Thank you for purchasing ARTUSI
and welcome to the ARTUSI Family.
This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance
has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.
We present detailed information on each of the features your ARTUSI appliance consists of. Once you have read
this section you will be able to choose the most appropriate settings for your appliance when cooking different
types of food.
We ask you to read the instructions in this booklet very carefully as this will allow you to get the best results from
using your appliance. KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
TO REGISTER YOUR PRODUCT WITH ARTUSI, PLEASE FILL OUT THE WARRANTY CARD AT THE END OF
THIS BOOKLET AND POST IT TO: REPLY PAID 83617
LEICHHARDT NSW 2040
Dear Artusi Customer, please read this user manual carefully before using the product and, keep it permanently at
your disposal.
Note: This user manual is prepared for more than one model. Some of the features specified in this Manual may not
be available on your appliance.
All our appliances are only for domestic use, not for commercial use. Products marked with (*) are optional.
“THIS APPLIANCE SHALL BE INSTALLED IN ACCORDANCE WITH THE REGULA TIONS FORCE AND ONLY USED
IN A WELL VENTILATED SPACE. READ THE INSTRUCTIONS BEFORE INSTALLING OR USING THIS APPLIANCE”
“Conforms with the WEEE Regulations.”
Thank you for choosing this dryer.
This User Manual contains important safety information and instructions on the
operation and maintenance of your dryer.
Please take the time to read this User Manual before using your dryer and keep this
book for future reference.
Icon Caption Description
WARNING Risk of serious injury or death
RISK OF ELECTRIC SHOCK Dangerous voltage
FIRE
ATTENTION Risk of injury or material damage
IMPORTANT/NOTE Information on correct operation of the system
Read the instructions.
Hot surface
EN - III
CONTENTS
1. SAFETY INSTRUCTIONS ................................................................................. 5
1.1. Electrical Safety ............................................................................................... 5
1.2. Children's Safety ............................................................................................. 6
1.3. Dryer Safety..................................................................................................... 7
1.4. Correct Use ..................................................................................................... 8
1.5. Installing On Top Of a Washing Machine....................................................... 10
2. INSTALLATION ................................................................................................ 11
2.1. Connection to Water Outlet (with optional drain hose) .................................. 11
2.1.1. Connecting the Water Discharge Hose ...................................................... 11
2.2. Adjusting the Feet .......................................................................................... 11
2.3. Electrical Connection ..................................................................................... 11
2.4. Under Counter Installation ............................................................................. 11
3. OVERVIEW ...................................................................................................... 12
4. PREPARING THE LAUNDRY .......................................................................... 13
4.1. Sorting the Laundry to be Dried..................................................................... 13
4.2. Preparing the Laundry to be Dried ................................................................ 14
4.3. Load Capacity................................................................................................ 14
5. USING THE DRYER ........................................................................................ 15
5.1. Control Panel ................................................................................................. 15
5.1.1. Programme Selection Knob........................................................................ 15
5.1.2. Electronic Indicator and Additional Functions ............................................. 15
5.2. Programme Selection and Consumption Table ............................................. 16
5.2.1. Auxiliary Functions...................................................................................... 17
5.2.2. Starting the Programme ............................................................................. 18
5.2.3. Programme Progress ................................................................................ 19
5.3. Drum Light Information .................................................................................. 19
6. CLEANING AND CARE ................................................................................... 21
6.1. Cleaning the Lint Filters ................................................................................. 21
6.2. Emptying the Water Tank............................................................................... 21
6.3. Cleaning the Heat Exchanger........................................................................ 22
6.4. Cleaning the Humidity Sensor ....................................................................... 22
6.5. Cleaning the Inner Surface of the Loading Door ........................................... 23
7. TECHNICAL SPECIFICATIONS ...................................................................... 24
8. TROUBLESHOOTING ..................................................................................... 25
9. AUTOMATIC FAULT WARNINGS AND WHAT TO DO ................................... 27
10. ENVIRONMENTAL PROTECTION AND PACKAGING INFORMATION ...... 28
10.1. Packaging Information ................................................................................. 28
10.2. Energy Efficiency ......................................................................................... 28
EN - 1
PRIMARY CONSIDERATIONS
• This dryer can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
dryer in a safe way and understand the hazards
involved. Children must not play with the dryer.
Cleaning and user maintenance must not be made
by children without supervision.
• This dryer is intended only for household and
indoor use. The warranty will be void in case of
commercial use.
• Use this dryer only for laundry with a label that
indicates it is suitable for drying.
• The manufacturer will not accept responsibility for
damages resulting from incorrect use or transport.
•
ventilation openings.
• Installation and repair of the dryer should only
be made by an authorised repair agent. The
manufacturer cannot be held responsible for
damages resulting from un-authorised repairs.
WARNING: Never spray or pour water onto the
dryer to wash it! There is risk of electric shock!
• Leave at least 3 cm of space between the side and
rear walls of the dryer and above if you plan on
placing your dryer under a worktop.
• Assembly / disassembly for under-counter
installation if neccessary must be done by an
authorised service agent.
• Before installation, check the dryer for visible
damage. Never install or operate a damaged dryer.
• Keep pets away from the dryer.
• Fabric softeners or similar dryer should be used in
EN - 2
accordance with the manufacturers instructions.
• Remove all objects from pockets such as lighters
and matches.
• The dryer must not be installed behind a lockable
door, a sliding door or a door with a hinge on the
opposite side to that of the dryer, if it prevents the
door from being fully opened.
WARNING: In the dryer enclosure or in the built-
in structure, keep ventilation openings clear of
obstruction.
• Before contacting the local Authorised Service
Provider for the installation of the dryer, check the
information in the user manual to make sure that
the electrical installation and water outlet is suitable.
plumber to have the necessary adjustments made.
• It is the customer’s responsibility to prepare the
dryer’s installation place, as well as the electricity
and waste water installation. Before installation,
check the dryer for damage. If damaged, do not
have it installed. Damaged dryer may endanger
your health.
•
• Run the dryer in a dust-free environment where the
air ventilation is good.
•
should not be reduced with objects such as
carpets, wood or tape.
• Do not block the ventilation grills found on the
plinth of the dryer.
• The dryer must not be installed behind a lockable
door, a sliding door or a door with a hinge on the
EN - 3
opposite side of the dryer, in such a way that blocks
the full opening of the dryer door.
• Once the dryer has been installed, the connections
must remain stable. When installing the dryer, make
sure that the rear surface is not leaning on anything
(e.g. tap, socket).
• The operating temperature of the dryer is +5°C to
+35°C. If operated out of this temperature range,
negatively and the dryer will be damaged.
• Be careful when carrying the dryer since it is heavy.
Always wear safety gloves.
• Always install the dryer against a wall.
• The rear surface of the dryer should be placed
against the wall.
• When the dryer is placed on a stable surface,
use a level to check if it is fully level/stable. If not,
adjust the feet until it becomes steady. Repeat this
process every time you relocate the dryer.
• Do not place the dryer onto the power cable.
EN - 4
Disposing the Old Dryer
This dryer complies with EU WEEE Directive
symbol for waste electrical and electronic
equipment (WEEE).
This symbol, which is found on the dryer or
information label, indicates that this dryer must not be
disposed together with other household waste at the
end of its service life. To prevent the potential harms of
uncontrolled waste disposal on the environment and
human health, please keep this dryer separate from
other types of waste, and to prevent sustainable reuse
of material resources, make sure that it is recycled
responsibly. Contact your dealer or local authorities to
get information on how and where you can take the
dryer for environmentally-safe recycling. This dryer
cannot be mixed with other commercial wastes for
recycling.
EN - 5
1. SAFETY INSTRUCTIONS
This section contains safety instructions that will help
protect you from risk of personal injury or property
damage. Failure to follow these instructions will void
any warranty.
1.1. Electrical Safety
• The dryer must not be supplied through an external
switching device, such as a timer, or connected to
utility.
• Do not touch the power plug with wet hands. Always
pull the plug to unplug the dryer, otherwise, there
will be risk of an electric shock.
• Connect the dryer to a grounded socket with fuse
protection. The earth connection must be installed
held responsible for damages/losses resulting from
using the dryer without an earth connection as
required by local regulations.
• The voltage and the allowable fuse protection are
indicated on the type plate.(For the type plate,
please see Overview)
• Voltage and frequency values indicated on the
type plate must be equal to the mains voltage and
frequency value in your house.
• Unplug the dryer when it is not used for an
extended period, and before installation,
maintenance, cleaning and repair, otherwise, the
dryer may get damaged.
• The plug socket must be freely accessible at all
times after installation.
give you an electric shock. When damaged it must
personnel.
EN - 6
use extension cords, multi sockets or adapters to
connect the dryer to mains power.
1.2. Children's Safety
• This dryer is not intended for use by people
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
dryer by a person responsible for their safety.
• This dryer can be used by children aged from
8 years and above, and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
dryer in a safe way and understand the hazards
involved. Children must not play with the dryer.
Cleaning and user maintenance must not be made
by children without supervision.
• Do not leave children unattended near the dryer.
• Children might lock themselves in the dryer
resulting in risk of death.
• Do not allow children to touch the glass door during
operation. The surface becomes extremely hot and
may cause skin damage.
• Keep packaging material away from children.
• Poisoning and irritation may occur if detergent and
cleaning materials are consumed or come into
contact with the skin and eyes.
• Keep cleaning materials out of the reach of children
Electrical dryer are dangerous for children.
• Keep children away from the dryer while it is
running.
• To prevent children from interrupting the dryer cycle,
you can use the child lock to avoid any changes in
EN - 7
the running programme.
• Do not allow children to sit/climb on or climb inside
the dryer.
1.3. Dryer Safety
Due to risk of re, the following laundry items
and dryer should NEVER be dried in the dryer:
• Do not dry unwashed items in the dryer.
• Items that have been soiled with substances such
as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax
removers should be washed in hot water with an
extra amount of detergent before being dried in the
dryer.
• Cleaning cloths and mats that have residues
patrol, stain remover, turpentine, candle, wax, wax
remover or chemicals.
• Laundry that has residues of hair sprays, nail polish
remover and similar substances.
• Laundry on which industrial chemicals have been
used for cleaning (such as chemical cleaning).
• Laundry that has any kind of foam, sponge, rubber
or rubber-like parts or accessories. These include
latex foam sponge, shower caps, waterproof
•
during the drying process.
• Operating the dryer in environments that contain
ATTENTION: Underwear that contains metal
reinforcements should not be put in the dryer. The
dryer may be damaged if metal reinforcements come
EN - 8
FIRE:R290
Risk of re and damage!
This dryer contains enviromental friendly but
sources away from the dryer.
1.4. Correct Use
ATTENTION: Never stop a dryer before the end of
the drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
ATTENTION: Make sure that pets do not enter
the dryer. Check the inside of the dryer before
using it.
ATTENTION: Superheating of clothes inside the
dryer can occur if you cancel the programme or in the
event of a power failure whilst the dryer is running.
This concentration of heat can cause self-combustion
so always activate the Refresh programme to cool
down or quickly remove all laundry from the dryer in
order to hang them up and dissipate the heat.
• Use the dryer only for household drying and to dry
fabrics with a label that indicates they are suitable
for drying. All other uses are out of the scope of
intended use and are prohibited.
• The warranty will be void in case of any commercial
use.
• This dryer is designed to be used inside domestic
residences only, and should be placed on a straight
and stable surface.
• Do not lean against or sit on the door of the dryer.
The dryer may tip over.
EN - 9
• To maintain a temperature that will not harm the
laundry (e.g. to prevent the laundry from catching
process. After this, the programme ends. At the
end of the programme, always remove the laundry
promptly.
•
especially when exposed to heat sources such as
in a dryer. The items become warm, causing an
oxidation reaction in oil. Oxidations creates heat. If
the heat cannot escape the items can become hot
• If it is unavoidable that fabrics that contain
vegetable or cooking oil or have been contaminated
by hair care products be placed in a dryer
extradetergent - this will reduce, but not eliminate,
the hazard
ATTENTION: Never use the dryer without a lint
• after each use as
indicated in Cleaning the Lint Filter.
•
process.
• Lint accumulation must not to be allowed around
the dryer (not applicable for dryers intended to be
vented to the exterior of the building)
IMPORTANT: The clearance between the dryer
intake cannot be ensured for the dryer.
EN - 10
• Do not install the dryer in rooms where there is
risk of freezing. Freezing temperatures negatively
freezes in the pump and hose may cause damage.
1.5. Installing On Top Of a Washing Machine
ATTENTION: A washing machine cannot be placed
on the dryer. Pay attention to the warnings below
when installing the dryer on a washing machine.
ATTENTION: The dryer can only be placed on
washing machines that have a same capacity and
above.
•
part must be attached by an Authorised Service
Provider.
• When the dryer is placed on the washing machine,
the total weight of these dryer may reach almost
150 kilograms (when loaded). Place the dryer on a
Appropriate Installation Table for Washing Machine and Dryer
Dryer
(Depth)
Washing Machine
37 cm 42 cm 53 cm 56 cm 59 cm 85 cm
56 cm X X
61 cm X X X
(For the depth information, please see 7. Technical Specications)
In order to put the dryer onto the washing machine,
a special stacking kit is required as an optional extra.
Please contact customer service to acquire. The
assembly instruction will be served together with the
stacking kit.
CE Declaration of conformity
We declare that our dryer meet the applicable European Directives, Decisions and
Regulations and the requirements listed in the standards referenced.
EN - 11
2. INSTALLATION
2.1. Connection to Water Outlet (with
optional drain hose)
In dryer with a heat pump unit, water
accumulates in the water tank during
the drying process. You must empty the
accumulated water after each drying
process. Instead of periodically emptying
the water tank, you can also use the water
drain hose provided with the dryer to
directly drain the water outside.
2.1.1. Connecting the Water Discharge
Hose
1. Pull and take out the end of the hose at the
back of the dryer. Do not use any tools to
take out the hose.
2.
3.
.
ATTENTION: The hose must be
connected in a manner that it cannot be
displaced. If the hose comes out during
your house.
IMPORTANT: The water discharge
house must be installed at a height of 80
cm maximum.
IMPORTANT: The water discharge
hose must not be bent between the outlet
and the dryer, folded or stepped over.
2
1
3
2.2. Adjusting the Feet
• For the dryer to work with less noise
and vibration, it must be stable and
balanced on its feet. Adjust the feed to
ensure that the dryer is balanced.
• Rotate the feet to the right and to the
left until the dryer is even and stable.
IMPORTANT: Never remove the
adjustable feet.
2.3. Electrical Connection
ATTENTION:
electric shock.
• Your dryer is set to 220-240 V and 50
Hz.
• The mains cable of the dryer is
equipped with a special plug. This
plug must be connected to an earthed
socket protected by a fuse of 10
Amperes as indicated on the type plate.
The fuse current rating of the power
line where the outlet is connected must
electrician if you do not have such an
outlet or fuse.
• Our company cannot be held
responsible for damages resulting from
usage without earthing.
IMPORTANT: Operating your dryer at
low voltage values will shorten the service
life and decrease the performance of your
dryer.
2.4. Under Counter Installation
• Leave at least 3 cm of space between
the side and rear walls of the dryer
and the underside of the worktop when
installing your dryer under a counter.
• Assembly / disassembly under the
counter if neccessary must be done by
authorized service.
EN - 12
3. OVERVIEW
1
2
3
4
5
6
7
8
9
10
11
1. Upper tray
2. Control panel
3. Loading door
4. Plinth
5. Plinth opening slot
6. Ventilation grills
7. Adjustable feet
8. Plinth cover
9. Type plate
10.
11. Drawer Cover
EN - 13
4. PREPARING THE LAUNDRY
4.1. Sorting the Laundry to be Dried
Follow the instructions on the labels of the laundry to be dried. Only dry items that have a
statement/symbol that indicates "they can be dried in a dryer".
• Do not operate the dryer with load amounts and laundry types other than those given
in 4.3. Load Capacity.
Suitable for drying in a
dryer
Does not need ironing
Sensitive/Delicate drying
Not suitable for drying in a
dryer
No drying
Do not dry-clean
At any temperature
At high temperatures
At medium temperatures At low temperatures Heatless Hang to dry
Spread to dry Hang wet to dry Spread in shadow to dry Suitable for dry cleaning
this reason, dry clothes together that have the same structure and fabric type. This way,
you can get an even drying result. If you think that the laundry is still wet, you can select a
time programme for additional drying.
Please dry your big (like duvets) and small sizes of laundries seperately in order to avoid
damp laundries.
EN - 14
IMPORTANT: Delicate fabrics,
embroided fabrics, woolen/silk fabrics,
clothes made of delicate and expensive
fabrics, airtight clothes and tulle curtains
are not suitable for drying in the dryer.
4.2. Preparing the Laundry to be Dried
Risk of explosion and re!
Remove all objects from pockets such as
lighters and matches.
ATTENTION: The drum of the dryer and
the fabrics may get damaged.
• The clothes may have become
entangled during the washing process.
Separate them from each other before
placing them in the dryer.
• Remove all objects in the pockets of
the clothes and apply the following:
• Tie fabric belts, apron laces etc. to each
other or use a laundry bag.
• Lock the zips, clasps and fasteners, do
up the buttons of covers.
• To get the best drying result, sort the
laundry according to the textile type
and drying programme.
• Remove clips and similar metal parts
from the clothes.
• Woven goods such as t-shirts and knit
clothes generally shrink in the rst
drying. Use a protective programme.
• Do not over-dry synthetics. This will
cause creases.
• When washing the laundry to be dried,
adjust the amount of softener according
to the data from the manufacturer of the
washing machine.
4.3. Load Capacity
Follow the instructions in the "Programme
selection and consumption table". (See: 5.2
Programme selection and consumption
table). Do not load the dryer with more
in the table.
IMPORTANT: It is not recommended
to load the dryer with more laundry than
overloaded, the drying performance of
the dryer will decrease and the dryer and
laundry might be damaged.
Laundry Dry load weight (gr)
Bedsheet (double) 725
Pillowcase 240
Bath Towel 700
Hand Towel 225
Shirt 190
Cotton Shirt 200
Jean 650
Fabric - Gabardine Trousers 400
T-shirt 120
EN - 15
5. USING THE DRYER
5.1. Control Panel
1. Programme Selection Knob
2. Electronic indicator and additional
functions
5.1.1. Programme Selection Knob
Use the programme selection knob to select
the desired drying programme
1
2
5.1.2. Electronic Indicator and Additional
Functions
Display symbols:
Water tank warning indicator
Heat exchanger cleaning warning
indicator
EN - 16
5.2. Programme Selection and Consumption Table
Press the Start/Pause button to start the programme. The Start/Pause LED that indicates
that the programme has started and the remaining the of the program is seen on the
display.
Programme Load (kg)
Washing
machine
spin speed
Approximate
amount of
remaining
humidity
Duration
(minutes)
Cotton Extra Dry 8 1000 60% 179
Cotton Cupboard Dry 8 1000 60% 174
Cotton Iron Dry 8 1000 60% 148
Synthetics Cupboard
Dry
4 800 40% 74
Synthetics Iron Dry 4 800 40% 64
Delicate 2 600 50% 55
Time drying - - - -
Baby Care 3 1000 60% 78
Duvet 2,5 800 60% 140
Sport 4 800 40% 103
Mix 4 1000 60% 112
Wool Refresh - - - 5
Refresh - - - 10
Express 34' 1 1200 50% 34
Shirts 20' 0.5 1200 50% 20
Energy consumption values
Programme Load (kg)
Energy Consumption
Value (kWh/year)
Energy Rating Star
Cotton Cupboard Dry
Drying Level 3
8 149 7
before test series.
All values in the table were determined in accordance with standard laboratory conditions.
Consumption values may vary from the values in the table depending on the fabric type,
spin speed, environment conditions and voltage values.
EN - 17
5.2.1. Auxiliary Functions
The table that summarises the options that can be selected in programmes is given below.
Option Description
Drying Level
The humidity level obtained after drying can be increased by 3 levels. This way,
level of required dryness can be selected. The levels that can be selected other
than the standard setting: 1, 2, 3. After selection, the LED of the relevant drying
level will turn on.
Delicate Delicate fabrics are dried for a longer time at a low temperature
Delay Start
You can delay the start time of the programme by selecting the 1-hour to 23-hour
option. You can activate the desired delay time by pressing the Start/Pause button.
When the time is up, the selected programme will start automatically. During the
delay time, options compatible with the programme can be activated/deactivated.
Long pressing on Delayed Start button changes delay time continuously.
Buzzer Cancel
The dryer gives an audible warning when programme selection knob is turned,
buttons are pressed and at the end of programme. To cancel the warnings, press
and hold the "Anti-Crease Option" button for 3 seconds. When you press the
button, you will hear an audible warning that the option has been cancelled.
Time Drying
When knob is positioned to Time Drying programme, option can be selected by
pressing Time Drying option button and program starts by pressing Start/Pause
button. Long pressing on tme dyring button changes time continuously.
Child Lock
are pressed during the programme. To activate the child lock, press and hold
the "Delay Start" and "Anti-Crease" keys simultaneously for 3 seconds. When
the child lock is active, all keys will be deactivated. Child lock will be deactivated
automatically at the end of the programme. When activating/deactivating the child
active, if you turn the programme selection knob, you will hear an audible warning
the programme knob to another programme, the previous programme will continue
running. To select a new programme, you need to deactivate the child lock and
start the desired programme.
EN - 18
5.2.2. Starting the Programme
to start the programme. The Start/Pause LED that indicates that the programme has
started and the drying LED will come on.
Programme Description
Cotton Extra Dry
This programme dries thick and multi-layer fabrics, such as cotton towels,
bedsheets, pillowcases, bathrobes, at a high temperature to allow you to place
them in a closet.
Cotton Cupboard Dry
This programme dries cotton pyjamas, underwear, tablecloths etc. to allow you to
place them in a closet.
Cotton Iron Dry
This programme dries cotton laundry to prepare it for ironing. Laundry removed
from the machine will be damp.
Synthetics Cupboard Dry
This programme dries synthetics, such as shirts, t-shirts, blouses, at a lower
temperature compared to the cottons programme to allow you to place them in a
closet.
Synthetics Iron Dry
This programme dries synthetics, such as shirts, t-shirts, blouses, at a lower
temperature compared to the cottons programme to prepare them for ironing.
Laundry removed from the machine will be damp.
Delicate
This programme dries thin clothes like shirts, blouses and silk garments at a low
temperature to make them ready to wear.
Time Drying
To reach the required drying level at a low temperature, you can use the time
programmes of 20 min. to 200 min. Regardless of the drying level, the programme
stops at the desired time.
Baby Care
This programme dries delicate infant clothes at a low temperature to make them
ready to wear.
Duvet This programme is used to dry duvet.
Sport
Sport program is used for synthetic sport laundries like shorts, t-shirts at low
temperature.
Mix
This programme dries cotton-synthetic mixed garments that do not discolour to
make them ready to wear.
Wool Refresh
Wool refresh helps wool textiles to remove excess water after washing by applying
low temperature and gentle movements of drum.
Refresh
This programme provides ventilation for 10 minutes without applying heat to help
freshen up your garments.
Express 34'
1 kg of synthetics shirts spun at high speed in the washing machine are dried in
34 minutes.
Shirts 20' 2 to 3 shirts are ready for to be ironed in 20 minutes
IMPORTANT: Do not open the loading door while the programme is running. If you
have to open the door, do not keep it open for a long time.
EN - 19
5.2.3. Programme Progress
During the Programme
If you open the door when the programme
is running, the dryer will switch to standby
mode. Once the door has been closed,
press the Start/Pause key to resume the
programme.
Do not open the loading door when the
programme is running. If you have to open
the door, do not keep it open for a long
time.
Programme End
Once the programme is over, the warning
cleaning and heat exchanger cleaning will
turn on. Additionally, an audible warning
will be given at the end of the programme.
You can remove the laundry to make the
machine ready for a new load.
IMPORTANT:
every programme. Empty the water tank
after every programme.
IMPORTANT: If you do not remove the
laundry after the programme has ended, the
1-hour Anti Crease phase will automatically
be activated. This programme rotates the
drum at regular intervals to prevent creases.
5.3. Drum Light Information
• This dryer includes LED Drum Light.
• The light works automatically when you
open the door. And closes itself after a while
automatically.
• It is not an adjustable option.
• Please do not try to replace or modify the
LED Light.
EN - 20
PROGRAMMES
OPTIONS
Delay
Start
Buzzer
Cancel
Child Lock Delicate
Time
Drying
Drying
Level
Cotton Extra Dry
X
Cotton Cupboard
Dry
X
Cotton Iron Dry X
Synthetics
Cupboard Dry
X
Synthetics Iron
Dry
X
Delicate X X
Time drying
X X
Baby Care
X
Duvet X X
Sport
X
Mix X
Wool Refres X X X
Refresh
X X X
Express 34'
X X X
Shirts 20'
X X X
X Not selectable
Selectable
EN - 21
6. CLEANING AND CARE
IMPORTANT: Do not use industrial
chemicals to clean your dryer. Do not use a
dryer that has been cleaned with industrial
chemicals.
6.1. Cleaning the Lint Filters
IMPORTANT: DO NOT FORGET TO
CLEAN THE LINT FILTERS AFTER EACH
USE.
1. Open the loading door.
2.
3.
4.
using a soft cloth.
5.
6.
using a soft cloth
7.
8.
9.
After the dryer has been used for a certain
period of time, if you encounter a layer that
reinstalling it again.
6.2. Emptying the Water Tank
1. Pull the drawer cover and carefully take
out the tank.
2. Empty the water in the tank.
1
2
EN - 22
3. If there is lint accumulated on the
discharge cap in the tank, clean it with
water.
4.
IMPORTANT: Never remove the water
tank when the programme is running. The
water condensed in the water tank is not
suitable for human consumption.
IMPORTANT: DO NOT FORGET TO
EMPTY THE WATER TANK AFTER EACH
USE.
6.3. Cleaning the Heat Exchanger
IMPORTANT: Clean the heat exchanger
when you see the warning “Heat Exchanger
cleaning”.
IMPORTANT: EVEN IF THE “HEAT
EXCHANGER CLEANING WARNING
LED” IS NOT ON: CLEAN THE HEAT
EXCHANGER AFTER EVERY 30 DRYING
PROCESSES OR ONCE A MONTH.
If the drying process is completed, open the
loading door and wait for it to cool down.
1. Open the kick plate cover as shown.
3. Take out the exchanger cover as shown.
4. Clean the front surface of the exchanger
as shown.
WARNING: DO NOT CLEAN
WITH BARE HANDS SINCE THE
EXCHANGER FINS ARE SHARP.
THEY MAY HURT YOUR HANDS
6.4. Cleaning the Humidity Sensor
Inside the machine, there are humidity
sensors that detect whether the laundry is
dry or not.
To clean the sensors:
1. Open the loading door of the dryer.
2. If the dryer is still hot due to the drying
process, wait for it to cool down.
3. Using a soft cloth soaked in vinegar, wipe
the metal surfaces of the sensor and dry
them.
IMPORTANT: CLEAN THE METAL
SURFACES OF THE SENSOR 4 TIMES A
YEAR.
IMPORTANT: Do not use metal tools to
clean the metal surfaces of the sensor.
EN - 23
WARNING:
explosion, do not use solution agents,
cleaning agents or similar dryer when
cleaning the sensors.
6.5. Cleaning the Inner Surface of the
Loading Door
IMPORTANT: DO NOT FORGET TO
CLEAN THE INNER SURFACE OF THE
LOADING DOOR AFTER EACH DRYING
PROCESS.
Open the loading door of the dryer and
clean all of the inner surfaces and the
gasket with a soft, damp cloth.
EN - 24
7. TECHNICAL SPECIFICATIONS
Brand ARTUSI
Model name AHPD8000W
Height Min: 845 mm / Max: 855 mm*
Width 596 mm
Depth 609 mm
Capacity (max.) 8 kg**
Net weight (with plastic door) 46,8 kg
Net weight (with glass door) 48,8 kg
Voltage
220-240 V
Power
1000 W
*Min. height: Height with the adjustable feet not used. Max. height: Height with the
adjustable feet extended to the maximum.
**Dry laundry weight before washing.
IMPORTANT:
change without prior notice.
IMPORTANT: The values declared have been obtained in a laboratory environment
according to the relevant standards. These values may change depending on the
environmental conditions and use of the dryer.
ATTENTION:
1. Due to safety reasons, legislation forces a room of at least 1 m³ per 8 g refrigerant for
such equipment. For 150 g propane, the minimum allowed room size would be 18.75 m³.
2.
properly and do not damage the pipes in the refrigerant circuit.
• Type of refrigerant : R290
• Quantity of gas : 150 g
• ODP (Ozone Depletion Potential) : 0
• GWP (Global Warning Potential) : 3
3.
4.
EN - 25
8. TROUBLESHOOTING
process to take the necessary measures and warn you in case of any malfunction.
WARNING: If the problem persists even if you have applied the steps in this section,
please contact the your dealer or an Authorised Service Provider. Never try to repair a
nonfunctional dryer.
PROBLEM REASON SOLUTION
The drying process takes a long
time.
clogged.
The heat exchanger might be
clogged.
Clean the heat exchanger
The ventilation grills in front of the
machine might be closed.
Open the doors/windows to prevent
the room temperature from rising
too much.
There might be a layer of limescale
on the humidity sensor.
Clean the humidity sensor.
The dryer might be overloaded with
laundry.
Do not overload the dryer.
spun.
Select a higher spin speed on your
washing machine.
Laundry comes out damp at the end
of the drying process.
The laundry that comes out hot at the end of the drying process
generally feels more humid.
The programme used might not be
suitable for the type of laundry.
Check the care labels on the
laundry items, select a suitable
programme for the type of laundry
and additionally, use the time
programmes.
clogged.
The heat exchanger might be
clogged.
Clean the heat exchanger
The dryer might be overloaded with
laundry.
Do not overload the dryer.
spun.
Select a higher spin speed on your
washing machine.
The dryer cannot be opened or the
programme cannot be started. The
dryer does not get activated when
adjusted.
The dryer might not be plugged in.
the socket.
The loading door might be open. Make sure that the loading door is
properly closed.
You might not have set a
programme or pressed the Start/
Pause key.
Make sure that the programme has
been set and the dryer is not in the
Standby (Pause) mode.
Child lock might be active. Deactivate the child lock.
The programme has been
interrupted for no reason.
The loading door might not be
closed properly.
Make sure that the loading door is
properly closed.
There might have been a power
failure.
Press the Start/Pause key to start
the programme.
The water tank might be full. Empty the water tank.
EN - 26
PROBLEM REASON SOLUTION
Clothes have shrunk, felted or
deteriorated.
The programme used might not be
suitable for the type of laundry.
Check the care labels on the
laundry items, select a suitable
programme for the type of laundry.
Water leaking from the loading door.
There might be lint accumulated on
the inner surfaces of the loading
door and on the surfaces of the
gasket of the loading door.
Clean the inner surfaces of the
loading door and the surfaces of the
gasket of the loading door.
The loading door opens on its own.
The loading door might not be
closed properly.
Push the loading door until you hear
the closing sound.
The water tank warning symbol is
The water tank might be full. Empty the water tank.
The water discharge hose might
be bent.
If the dryer is connected directly to
the water outlet, check the water
discharge hose.
is on.
by lint.
There might be a layer that causes
obstruction on the surface of the
The heat exchanger cleaning
warning symbol is on.
The heat exchanger might be
unclean.
Clean the heat exchanger.
EN - 27
9. AUTOMATIC FAULT WARNINGS AND WHAT TO DO
Your dryer is equipped with a built-in fault detection system, indicated by a combination of
ERROR CODE SOLUTION
E00 Contact the nearest authorised service agent.
E03 /
Empty the water tank, if problem does not solved, contact
the nearest authorised service agent.
E04 Contact the nearest authorised service agent.
E05 Contact the nearest authorised service agent.
E06 Contact the nearest authorised service agent.
E07 Contact the nearest authorised service agent.
E08
There may be voltage fluctuation in mains.Wait until
voltage is appropriate for working range.
EN - 28
10. ENVIRONMENTAL
PROTECTION AND PACKAGING
INFORMATION
10.1. Packaging Information
The packaging of this dryer is made of
recyclable materials. Do not dispose of the
packaging, waste together with household
or other waste. Instead, take it to a
local authority.
10.2. Energy Eciency
• You should operate the dryer to full
capacity, but make sure that it is not
overloaded.
• When the laundry is being washed,
the spin speed should be at the
highest level possible. This will shorten
the drying time and reduce energy
consumption.
• Make sure that the same kinds of
laundry are dried together.
• Please follow the recommendations
in the user manual for programme
selection.
• For air circulation, leave an appropriate
clearance on the front and back sides
of the dryer. Do not cover the grills on
the front side of the dryer.
• Unless necessary, do not open the door
of the dryer when drying. If you have to
open it, do not keep it open for a long
time.
• Do not add new (wet) laundry during
the drying process.
• Hairs and lint that detach from the
laundry and merge in the air are
collected by the "Lint Filters". Please
before and after each use.
• For models with a heat pump, make
sure that the heat exchanger is cleaned
at least once a month or after each 30
uses.
• During the drying process, the
environment where the dryer is installed
must be well ventilated.
Warranty Card
Worldwide Appliances Pty Limited
A.B.N. 45868077422
Office:
48-50 Moore Street, Leichhardt N.S.W 2040
Post:
Locked Bag 3000, Annandale, N.S.W 2038
P: 1300 694 583
WARRANTY REGISTRATION
Your ongoing satisfaction with your artusi
product is important to us. We ask that you
complete the enclosed Warranty Registration
Card and return it to us so that we have a record
of the artusi product purchased by you.
PRIVACY
Worldwide Appliances respects your
privacy and is committed to handling your
personal information in accordance with the
National Privacy Principles and the Privacy
Act 1988 (Cth). A copy of the Worldwide
Appliances Privacy Policy is available at
www.artusi.com.au. Worldwide Appliances will
not disclose any personal information set out
in the Warranty Registration Card (“Personal
Information”) without your consent unless
required by:
1. law;
2. any Worldwide Appliances related company;
3. any service provider which provide services
to artusi or assist artusi in providing services
(including repair and warranty services) to
customers. Our purpose in collecting the
Personal Information is
to keep a record of the artusi product purchased
by you, in order to provide a better warranty
service to you in the unlikely event that there is
a problem with your artusi product. Worldwide
Appliances may contact you at any one or more
of the address, email address or telephone
numbers set out in the Warranty Registration
Card. Please contact artusi on 1300 694
583 should you not wish to be contacted by
Worldwide Appliances.
WARRANTY
1. Warranty
Worldwide Appliances warrants that each artusi
product will remain, for a period of either 12
months or 24 months of warranty. All Warranties
are valid from the original date of purchase, And
warranty claims must be accompanied by the
proof of purchase.
24 months warranty products:
All Built-in Appliances – Limited to Ovens,
Gas, Induction and Electric Cooktops, and All
Rangehoods
Freestanding Cookers - Gas and Electric Models
(900mm Width)
artusi.com.au
Dishwashers - Freestanding, Fully Integrated,
Semi Integrated and built-in
12 months warranty products:
Freestanding Cookers - Gas and Electric Models
in 50cm, 54cm and 60cm Widths
Portable Appliances* – Benchtop Models and
Portable Gas Models
2. What is not Covered by the Warranty.
The Warranty does not apply if an artusi product
is defective by a factor other than a defect arising
in the manufacture of the artusi product, including
but not limited to:
(a) damage through misuse (including failure
to maintain, service or use with proper care),
neglect, accident or ordinary wear and tear
(including deterioration of parts and accessories
and glass breakage);
(b) use for purpose for which the artusi product
was not sold or designed;
(c) use or installation which is not in accordance
with any specied instructions for use or
installation;
(d) use or operation after a defect has occurred or
been discovered;
(e) damage through freight, transportation or
handling in transit (other than when Worldwide
Appliances is responsible);
(f) damage through exposure to chemicals, dusts,
residues, excessive voltage, heat, atmospheric
conditions or other forces or environmental
factors outside the control or Worldwide
Appliances;
(g) repair, modication or tampering by the
purchaser or any person other than Worldwide
Appliances, an employee of Worldwide
Appliances or an authorised artusi service
contractor*;
(h) use of parts, components or accessories
which have not been supplied or specically
approved by artusi.
(i) damage to surface coatings caused by cleaning
or maintenance using products not recommended
in the artusi product handbook provided to the
purchaser upon purchase of the artusi product;
(j) damage to the base of an electric oven due to
items having been placed on the base of the oven
cavity or covering the base, such as aluminium
foil (this impedes the transfer of heat from the
element to the oven cavity and can result in
irreparable damage); or
(k) damages, dents or other cosmetic
imperfections not aecting the performance of the
artusi in respect of an artusi product purchased
as a “factory second” or from display
The Warranty does not extend to light globes
used in artusi products.
3. Domestic Use
Each artusi product is made for domestic use.
This Warranty may not extend to artusi products
used for commercial purposes.
Continued over...
4
Please complete and send to ARTUSI at: REPLY PAID 83617
LEICHHARDT NSW 2040
Last Name: First Name:
Address:
State: Postcode: Email:
Home Phone: Mobile:
Purchase Date: / / (Please attach proof of purchase to validate warranty)
MODEL NUMBER
SERIAL NUMBER
(if you cannot locate the serial number please call ARTUSI on 1300 694 583)
1
2
3
4
WARRANTY REGISTRATION CARD
01052013
01032014
4. Time for Claim under the Warranty
You must make any claim under this Warranty
within twenty eight (28) days after the occurrence
of an event which gives rise to a claim pursuant
to the Warranty, by booking a service call on the
telephone number below.
5. Proof of Purchase
Customers must retain proof of purchase in order
to be eligible to make a warranty claim in respect
of an artusi product.
6. Claiming under the Warranty
Customers will bear the cost of claiming under
this Warranty unless Worldwide Appliances
determines the expenses are reasonable, in which
case the customer must claim those expenses
by providing written evidence of each expense
to Worldwide Appliances at the address on the
Warranty Registration Card.
7. Statutory Rights
(a) These terms and conditions do not aect your
statutory rights.
(b) The limitations on the Warranty set out in this
document do not exclude or limit the application
of the consumer guarantees set out in the Act or
any other equivalent or corresponding legislation
in the relevant jurisdiction where to do so would:
(i) contravene the law of the relevant jurisdiction;
or
(ii) cause any part of the Warranty to be void.
(c) Worldwide Appliances excludes indirect or
consequential loss of any kind (including, without
limitation, loss of use of the artusi product) and
(other than expressly provided for in these terms
and conditions) subject to all terms,
conditions and warranties implied by custom, the
general law, the Act or other statute.
(d) The liability of Worldwide Appliances to you
for a breach of any express or non-excludable
implied term, condition or warranty is limited at
the option of Worldwide Appliances to:
(i) replacing or repairing the defective part of the
artusi product;
(ii) paying the cost of replacing or repairing the
defective part of the artusi product;
(iii) replacing the artusi product; or
(iv) paying the cost of replacing the artusi
product.
(e) Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund
for a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.
8. Defects
Any part of an artusi product deemed to be
defective and replaced by Worldwide Appliances
is the property of Worldwide Appliances.
Worldwide Appliances reserves the right to
inspect and test artusi products in order to
determine the extent of any defect and the
validity of a claim under the Warranty.
*To locate your closest artusi authorised service
agent please contact us on 1300 652 100 or visit
www.artusi.com.au
ALL SERVICE CALLS MUST BE BOOKED
THROUGH AN AUTHORISED DEALER OR
WARRANTY DEPARTMENT ON 1300 652 100
OR stokesaps.com.au/artusi-service
01032014
Warranty Card continued
artusi.com.au
Warranty Card tear off
ARTUSI.COM.AUP: 1300 649 583
NSW & ACT (HEAD OFFICE)
48-50 MOORE STREET
LEICHHARDT
F 02 8569 4699
QLD
1/42 CAVENDISH ROAD
COORPAROO
F 07 3397 0850
VIC, TAS & SA
1211 TOORAK ROAD
CAMBERWELL
F 03 9809 2155
WA & NT
UNIT 10/55 HOWE STREET
OSBORNE PARK
F 08 9201 9188
NZ
PO BOX 11.160
SOCKBURN CHRISTCHURCH
F 03 344 5906
ARTUSI OFFICES ARE OPEN DAILY FROM 9AM–5PM AND SATURDAYS 10AM–4PM
DISCLAIMER
Worldwide Appliances PTY LTD, trading as ARTUSI, is continually seeking ways to improve the design specifications, aesthetics and production
techniques of its products. As a result alterations to our products and designs take place continually. Whilst every effort is made to produce
information and literature that is up to date, this brochure should not be regarded as an infallible guide to the current specifications, nor does it
constitute an offer for the sale of any particular product. Product dimensions indicated in our literature is indicative only. Actual product only
should be used to define dimension cutouts. Distributors, and retailers are not agents of ARTUSI and are not authorised to bind ARTUSI by any
express or implied undertaking or representation.
