1. Please read this user manual
first!....................................... . 4
2. Important safety and
environmental instructions . ...5
2.1 General safety . . . . . . . . . . . . . . . . . .5
2.1.1 Electrical safety. . . . . . . . . . . . . . . .6
2.1.2 Product safety . . . . . . . . . . . . . . . .7
2.2 Mounting over a washing machine .9
2.3 Intended use. . . . . . . . . . . . . . . . . . . .9
2.4 Child safety . . . . . . . . . . . . . . . . . . . .10
2.5 Compliance with the WEEE
regulation and disposing of the
waste product. . . . . . . . . . . . . . . . .10
2.6 Compliance with RoHS Directive . .10
2.7 Package information . . . . . . . . . . . .10
2.8 Technical specifications . . . . . . . . .11
3 Your Dryer .............................12
3.1 Overview . . . . . . . . . . . . . . . . . . . . . .12
3.2 Package Contents . . . . . . . . . . . . . .13
4 Installation ............................14
4.1 Appropriate installation location . .14
4.2 Removing the transportation safety
assembly . . . . . . . . . . . . . . . . . . . . .14
4.3 Under counter installation . . . . . . .15
4.4 Connecting to the drain. . . . . . . . . .15
4.5 Adjusting the feet . . . . . . . . . . . . . . .16
4.6 Electrical connection. . . . . . . . . . . .16
4.7 Transporation of the dryer . . . . . . .16
4.8 Warnings about sounds. . . . . . . . . .17
4.9 Changing the illumination lamp. . .17
5 Preparation ...........................18
5.1 Laundry suitable for drying in the
dryer . . . . . . . . . . . . . . . . . . . . . . . .18
5.2 Laundry not suitable for drying in
the dryer . . . . . . . . . . . . . . . . . . . . .18
5.3 Preparing laundry for
drying. . . . . . . . . . . . . . . . . . . . . . . . . . . .18
5.4 Things to be done for energy saving 18
5.5 Correct load capacity. . . . . . . . . . . .19
6 Operating the product............20
6.1 Control panel . . . . . . . . . . . . . . . . . .20
6.2 Display Symbols. . . . . . . . . . . . . . . .20
6.3 Preparing the machine . . . . . . . . . .21
6.4 Programme selection . . . . . . . . . . .21
6.5 Main programmes . . . . . . . . . . . . . .21
6.6 Additional programmes . . . . . . . . .22
6.7 Program selection and consumption
table. . . . . . . . . . . . . . . . . . . . . . . . .24
6.8 Express Dry. . . . . . . . . . . . . . . . . . . .25
6.9 Auxiliary function . . . . . . . . . . . . . . .25
6.10 Warning symbols . . . . . . . . . . . . . .25
6.11 Starting the programme . . . . . . . .26
6.12 Child lock . . . . . . . . . . . . . . . . . . . .27
6.13 Changing the programme after it
has started . . . . . . . . . . . . . . . . . . .27
6.14 Cancelling the programme. . . . . .28
6.15 End of programme. . . . . . . . . . . . .28
7 Maintenance and cleaning .....29
7.1 Cleaning Lint Filter / Loading Door
Inner Surface . . . . . . . . . . . . . . . . .29
7.2 Cleaning the sensor. . . . . . . . . . . . .30
7.3 Draining the water tank. . . . . . . . . .30
7.4 Cleaning the filter drawer . . . . . . .31
7.5 Cleaning the evaporator . . . . . . . . .32
8 Troubleshooting ....................33
9 Electrical Connection ............35
9.1 Attention! . . . . . . . . . . . . . . . . . . . . .35
9.2 Electrical requirements . . . . . . . . .35
9.3 Fitting a dif ferent plug . . . . . . . . . .35
9.4 Washer/dryer combination . . . . . . .35
TABLE OF CONTENTS
4
1. Please read this user manual first!
Dear Customer,
Thank you for preferring an Grundig product. We hope that
your product which has been manufactured with high quality
and technology will give you the best results. We advise you
to read through this manual and the other accompanying
documentation carefully before using your product and keep it
for future reference. If you transfer the product to someone else,
give its manual as well. Pay attention to all details and warnings
specified in the user manual and follow the instructions given
therein.
Remember that this user manual is also applicable for several
other models. Differences between models will be identified in
the manual.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful hints about usage.
A
Warning for hazardous situations with regard to life and
property.
B
Warning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging of the product is made of recyclable materials
pursuant to our national environment legislation.
Do not dispose of the packaging wastes with the domestic waste
or other wastes, discard them to the dedicated collection points
designated by the local authorities.
5
EN
2. Important instructions for safety and
environment
This section contains safety instructions that will help protect
from risk of personal injury or property damage. Failure to follow
these instructions shall void any warranty.
2.1 General safety
• The dryer can be used by children at and above 8 years old
and by persons whose physical, sensory or mental capabilities
were not fully developed or who lack experience and knowledge
provided that they are supervised or trained on the safe usage
of the product and the risks it brings out. Children should not
play with the product. Cleaning and maintenance works should
not be performed by children unless they are supervised by
someone.
• Children of less than 3 years should be kept away unless
continously supervised.
• Adjustable feet should not be removed. The gap between the
dryer and the floor should not be reduced with materials such
as carpet, wood and tape. This will cause problems with the
dryer.
• Always have the installation and repairing procedures carried
out by the Authorized Service. Manufacturer shall not be held
liable for damages that may arise from procedures carried out
by unauthorized persons.
• Never wash the dryer by spraying or pouring water onto it!
There is the risk of electric shock!
6
2.1.1 Electrical safety
A
Electrical safety instructions should be followed while
electrical connection is made during the installation.
A
The appliance must not be supplied through an external
switching device, such as a timer,or connected to a circuit
that is regularly switched on and off by utility.
• Connect the dryer to a grounded outlet protected by a fuse
at the value specified on the type label. Have the grounding
installation performed by a qualified electrician. Our company
shall not be liable for any damages that will arise when the
dryer is used without grounding in accordance with the local
regulations.
• The voltage and allowed fuse protection is stated on the type
label plate.
• The voltage specified on the type label must be equal to your
mains voltage.
• Unplug the dryer when it is not in use.
• Unplug the dryer from the mains during installation,
maintenance, cleaning and repair works.
• Do not touch the plug with wet hands! Never unplug by pulling
on the cable, always pull out by grabbing the plug.
• Do not use extension cords, multi-plugs or adaptors to connect
the dryer to power supply in order to decrease the risk of fire
and electric shock.
• Power cable plug must be easily accessible after installation.
B
Damaged mains cable should be changed notifying the
Authorized Service.
B
If the dryer is faulty, it must not be operated unless it is
repaired by an authorized service agent! There is the risk
of electric shock!
7
EN
2.1.2 Product safety
Superheating of the clothes inside of the dryer can occur
if you cancel the programme or in the event of a power
failure whilst the dryer is running, this concentration
of heat can cause self-combustion and fire so always
activate the ventilation programme to cool down or
quickly remove all laundry from the dryer in order to
hang them up and dissipate the heat.
Points to be taken into consideration for fire hazard:
Below specified laundry or items must not be dried in the
dryer considering fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone, alcohol, fuel oil,
kerosene, stain removers, turpentine, paraffin or
paraffin removers must be washed in hot water with
plenty of detergent before being dried in the dryer.
For this reason especially the items containing the
above specified stains must be washed very well, to do
this use adequate detergent and choose a high washing
temperature.
Below specified laundry or items must not be dried in
the dryer due to the fire hazard:
• Garments or pillows bolstered with rubber foam
(latex foam), shower bonnets, water resistant textiles,
materials with rubber reinforcement and rubber foam
pads.
• Clothing cleaned with industrial chemicals.
Items such as lighter, match, coins, metal parts, needle
etc. may damage the drum set or may lead to functional
problems. Therefore check all the laundry that you will
load into your dryer.
Never stop your dryer before the programme completes.
If you must do this, remove all laundry quickly and lay
them out to dissipate the heat.
Clothes that are washed inadequately may ignite on their
own and even may ignite after drying ends.
8
• You must provide enough ventilation in order to prevent
gases exiting from devices operating with other types of fuels
including the naked flame from accumulating in the room due
to the back fire effect.
A
Underwear that contains metal reinforcements should
not be dried in the dryer. Dryer may be damaged if metal
reinforcements come loose and break off during drying.
C
Use softeners and similar products in accordance with
the instructions of their manufacturers.
C
Always clean the lint filter before or after each loading.
Never operate the dryer without the lint filter installed.
• Never attempt to repair the dryer by yourself. Do not perform
any repair or replacement procedures on the product even if
you know or have the ability to perform the required procedure
unless it is clearly suggested in the operating instructions or the
published service manual. Otherwise, you will be putting your
life and others’ lives in danger.
• There must not be a lockable, sliding or hinged door that may
block the opening of the loading door in the place where your
dryer is to be installed.
• Install your dryer at places suitable for home use. (Bathroom,
closed balcony, garage etc.)
• Make sure that pets do not enter the dryer. Check the inside of
the dryer before operating it.
• Do not lean on the loading door of your dryer when it is open,
otherwise it may fall over.
• The lint must not be allowed to accumulate around the tumble
dryer
9
EN
2.2 Mounting over a washing machine
• A fixing device should be used between the two machines when
installing the dryer above a washing machine. The fitting device
must be installed by the authorized service agent.
• Total weight of the washing machine and the dryer -with full
load- when they are placed on top of each other reaches to
approx. 180 kilograms. Place the products on a solid floor that
has sufficient load carrying capacity!
A
Washing machine cannot be placed on the dryer. Pay
attention to the above warnings during the installation on
your washing machine.
Installation Table for Washing Machine and Dryer
Dryer Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm
Can be stacked
Can be
stacked
Cannot be
stacked
60 cm
Can be stacked
Cannot be
stacked
2.3 Intended use
• Dryer has been designed for domestic use. It is not suitable for
commercial use and it must not be used out of its intended use.
• Use the dryer only for drying laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from
incorrect usage or transportation.
• The service life of the dryer that you purchased is 10 years.
During this period, original spare parts will be available to
operate the dryer properly.
10
2.4 Child safety
• Packaging materials are dangerous for the children. Keep
packaging materials away from children.
• Electrical products are dangerous for the children. Keep
children away from the product when it is operating. Do not let
them tamper with the dryer. Use the child-proof lock in order to
prevent the children to tamper with the dryer.
C
Child-proof lock is on the control panel. (See Child lock)
• Keep loading door closed even when the dryer is not in use.
2.5 Compliance with the WEEE regulation
and disposing of the waste product
This product complies with EU WEEE Directive (2012/19/
EU). This product bears a classification symbol for waste
electrical and electronic equipment (WEEE).
This product has been manufactured with high quality
parts and materials which can be reused and are suitable
for recycling. Do not dispose of the waste product with normal
domestic and other wastes at the end of its service life. Take it to
the collection center for the recycling of electrical and electronic
equipment. Please consult your local authorities to learn about
these collection centers.
2.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
2.7 Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our National
Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take them
to the packaging material collection points designated by the
local authorities.
11
EN
2.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 59,8 cm
Capacity (max.) 8 kg **
Net weight (plastic front door usage) 48,5 kg
Net weight (glass front door usage) 51 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
C
Technical specifications of the dryer are subject to
specification without notice to improve the quality of the
product.
C
Figures in this manual are schematic and may not match
the product exactly.
C
Values stated on markers on the dryer or in the other
published documentation accompanying with the dryer
are obtained in laboratory in accordance with the relevant
standards. Depending on operational and environmental
conditions of the dryer, these values may vary.
12
3. Your Dryer
3.1 Overview
1
8
7
6
11
4
9
2
3
10
5
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable feet
7. Kick plate
8. Type label
9. Lint filter
10. Water tank drawer
11. Power cord
13
EN
3.2 Package Contents
1
2 3
5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.
14
4. Installation
Before the calling the nearest
Authorized Service for the
installation of the dryer, ensure that
electrical installation and water drain
is appropriate referring to the user's
manual.(See 4.4 Connecting to the
drain and 4.6 Electrical connection)
If they are not suitable, contact a
qualified electrician and technician to
make necessary arrangements.
C
Preparation of the dryer's
location as well as the
electrical and waste water
installations is under
customer's responsibility.
A
Prior to installation,
visually check if the dryer
has any defects on it. If the
drier is damaged, do not
have it installed. Damaged
products cause risks for
your safety.
A
Let your dryer wait for 12
hours before starting to
use it.
4.1 Appropriate installation
location
Install the dryer on a stable and
level surface.
Dryer is heavy. Do not move it by
yourself.
• Operate your dryer in a
well ventilated, dust-free
environment.
• The gap between the dryer
and the surface should not be
reduced by the materials such as
carpet, wood and tape.
• Do not cover the ventilation grills
of the dryer.
• There must not be a lockable,
sliding or hinged door that may
block the opening of the loading
door in the place where your
dryer is to be installed.
• Once the dryer is installed, it
should stay at the same place
where its connections have been
made. When installing the dryer,
make sure that its rear wall does
not touch anywhere (tap, socket,
etc.).
• Place the dryer at least 1 cm
away from the edges of other
furniture.
• Your dryer can be operated at
temperatures between +5°C
and +35°C. If the operating
conditions fall outside of this
range, operation of the dryer will
be adversely affected and it can
get damaged.
B
Do not place the dryer on
the power cable.
4.2 Removing the transportation
safety assembly
A
Remove the transportation
safety assembly before
using the dryer for the first
time.
Open the loading door.
• There is a nylon bag inside the
drum that contains a piece
of styrofoam. Hold it from its
section marked with XX XX.
• Pull the nylon towards yourself
and remove the transportation
safety assembly.
15
EN
A
Check that no part of
the transportation safety
assembly remains inside
the drum.
4.3 Under counter installation
• This product can be installed
under a counter if the height of
the counter is sufficient.
A
While using undercounter
dryer, it should never
be operated without
undercounter installation
part. For the appropriate
undercounter installation
part contact the Authorized
Service.
Dryer Depth 60 cm 54 cm
Stock number
of under-bench
installation
part
2979700200 2973600100
• Leave at least 1 cm of space
around the sides and the rear
wall of the dryer when installing
it under a counter.
C
If installed under a
countertop, drying
durations can extend.
4.4 Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water
tank during the drying cycle. You
should drain accumulated water
after each drying cycle.
You can directly drain accumulated
water through the water drain hose
supplied with the product instead
of periodically draining the water
collected in the water tank.
Connecting the water drain hose
1-2 Pull hose at the behind of
the dryer by hand in order to
disconnect it from where it is
connected. Do not use any tools
to remove the hose.
3 Connect one end of the drain
hose supplied with the dryer to
the connection point from where
you removed the hose of the
product in previous step.
4 Connect the other end of the
drain hose directly to the
wastewater drain or to the
washbasin.
1
3 4
2
16
A
Hose connection should
be made in a safe manner.
Your drain house will be
flooded if the hose comes
out of its housing during
water discharge.
C
Water drain hose should
be attached to a height of
maximum 80 cm.
C
Make sure that the water
drain hose is not stepped
on and it is not folded
between the drain and the
machine.
4.5 Adjusting the feet
In order to ensure that the dryer
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet.
Turn the feet to left or right until the
dryer stands level and firmly.
C
Never unscrew the
adjustable feet from their
housings.
4.6 Electrical connection
For specific instructions for
electrical connection required during
installation (see 2.1.1 Electrical
Safety)
4.7 Transporation of the dryer
• Unplug the dryer before
transporting it.
• Drain all water that has
remained in the dryer.
If direct water drain connection
is made, then remove the hose
connections.
A
We recommend carrying
the dryer in upright
position. If it is not possible
to carry the machine in
the upright position, we
recommend carrying it by
tilting towards the right
side when looked from the
front.
17
EN
4.8 Warnings about sounds
C
It is normal to hear a
metallic noise from the
compressor sometimes
during operation.
C
Water collected during
operation is pumped to
water tank. It is normal to
hear pumping noise during
this process.
4.9 Changing the illumination
lamp
In case an illumination lamp is used
in your laundry dryer.To change
the Bulb/LED used for illumination
of your tumble dryer, call your
Authorized Service.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose
of this lamp is to assist the user to
place laundry in the tumble dryer in
a comfortable way. The lamps used
in this appliance have to withstand
extreme physical conditions such as
vibrations and temperatures above
50 °C.
18
5. Preparation
5.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry
having a label stating that they are suitable for drying in a dryer and make sure
that you select the appropriate programme.
Drying
Settings
At any temperature
At high temperature
At medium
temperature
At low temperature
Without heating
Hang to dry
Lay to dry
Hang wet to dry
Lay in shadow
to dry
Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature
200
0
C 150
0
C 110
0
C
LAUNDRY DRYING SYMBOLS
Drying
Symbols
Suitable for
dryer
No Iron
Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry
Do not dry-
clean
5.2 Laundry not suitable for
drying in the dryer
C
Delicate embroidered
fabrics, woolen, silk
garments, delicate and
valuable fabrics, airtight
items and tulle curtains are
not suitable for machine
drying.
5.3 Preparing laundry for drying
• Laundry may be tangled with
each other after washing.
Separate the laundry items
before placing them into the
dryer.
• Dry garments having metal
accessories such as zippers,
inside out.
• Fasten the zippers, hooks and
buckles and button sheets.
5.4 Things to be done for energy
saving
Following information will help you
use the dryer in an ecological and
energy-efficient manner.
• Spin your laundry at the
highest speed possible when
washing them. Thus, the drying
time is shortened and energy
consumption is reduced.
• Sort out the laundry depending
on their type and thickness.
Dry the same type of laundry
together. For example thin
kitchen towels and table clothes
dries earlier than thick bathroom
towels.
19
EN
• Follow the instructions in the
user manual for programme
selection.
• Do not open the loading door
of the machine during drying
unless necessary. If you must
certainly open the loading door,
do not to keep it open for a long
time.
• Do not add wet laundry while the
dryer is in operation
• Clean the filter drawer regularly
either when the Filter Drawer
Cleaning warning symbol
appears or after every 3 drying
cycles. (See 7.1 Cleaning Lint
Filter / Loading Door Inner
Surface)
• Clean the filter drawer once
filter drawer cleaning warning
symbol is on. (See 7.4 Cleaning
the filter drawer)
• Ventilate the room, where the
dryer is located, well during
drying.
5.5 Correct load capacity
Follow the instructions in the
“Programme selection and
consumption table”. Do not load
more than the capacity values stated
in the table.
C
It is not recommended
to load the dryer with
laundry exceeding the level
indicated in the figure.
Drying performance will
degrade when the machine
is overloaded. Furthermore,
dryer and the laundry can
get damaged.
Following weights are given as
examples.
Laundry
Approximate
weights (g)*
Cotton quit covers
(double)
1500
Cotton quit covers
(single)
1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces)
100
T-Shirts 125
*Dry laundry weight before washing.
20
6. Operating the Product
6.1 Control panel
8
1 2
7 6
5
4
3
Remaining time indicator*
Filter Drawer Cleaning warning symbol
Filter cleaning warning symbol
Audio warning Symbol
Child Lock warning symbol
Water Tank warning symbol
End Time Symbol
Start / Pause symbol
Programme progress bar
*Time that appears on display indicates the remaining time
until the end of the programme and changes according to
the dampness level of the laundry and model of the dryer.
1. On/Off/Cancel
2. Programme number display
3. Display
4. Start/Pause
5. Time delay
6. Alarm sound volume / child safety lock
7. Express dry /Selection of timer programmes
8. Programme selection
6.2 Display Symbols
21
EN
6.3 Preparing the machine
1. Plug in the machine.
2. Place the laundry in the
machine.
3. Press the On/off/cancel button
for 1 second (long).
4. When your machine is operated
for the first time, it starts
with the default programme
(wardrobe dryness for cottons).
C
Pressing the On/Off/
Cancel button does not
necessarily mean the
programme has started.
Press Start/Pause button
to start the programme.
6.4 Programme selection
1. Decide the appropriate
programme from the table below
which includes drying levels.
2. Select the desired programme
with the Programme Selection
knob.
Extra Dry
Only the cotton laundry
is dried at normal
temperature. Thick and
multi layered laundry
(towels, linens, jeans
and etc.) are dried in
a way that they do not
require ironing before
being placed in the
wardrobe.
Cupboard
Dry
Normal laundry
(tablecloths, underwear
and etc.) are dried in
a way that they do not
require ironing before
being placed in the
wardrobe.
Cupboard
Dry Plus
Normal laundry (E.g.:
tablecloths, underwear)
are dried in a way that
they do not require
ironing before placing in
the drawers, but more
than those in the ready
to wear option.
Iron Dry
Normal laundry (shirts,
dresses and etc.) are
dried ready to be ironed.
C
For further programme
details, see, "Programme
selection and consumption
table".
6.5 Main programmes
Depending on the fabric type, the
following main programmes are
available:
• Cottons
Dry durable laundry with this
programme. Dries at normal
temperature. It is recommended to
use for your cotton items (bed sheets,
quilt covers, towels, bathrobes, etc.).
• Synthetics
Dry less durable laundry with this
programme. Recommended for
synthetics.
22
6.6 Additional programmes
For special occasions, the following
additional programmes are available:
C
Depending on the different
device model, the additional
programmes may vary.
• Shirts
This programme dries the shirts
more sensitively and creases them
less and thus, helps to iron them
more easily.
C
There may be a little
moisture on the shirts at
the end of the programme.
We recommend you not
to leave the shirts in the
dryer.
• Jeans
Use this programme to dry your
jeans that are spun at high speeds in
the washing machine.
C
Put the jeans into the dryer
with the inside turned out.
• Sportswear
Use this programme to dry together
the synthetic and cotton laundry
items and the laundry items made of
mixed fabrics.
• Daily
This programme is used to dry
cottons and synthetics daily, and lasts
for 100 minutes.
• Night (Silent)
In this programme the level of
noise emitted to the environment
will be the lowest. Volume level will
be fifty percent lower with respect
to the ‘wardrobe dry for cottons’
programme.
• Bedding
Dry fiber quilts with ‘machine-
dryable’ label only. Make sure you are
loading the quilt in the correct way
to avoid damages on the machine
and the quilt. Take out the quilt
cover before loading the quilt in the
machine. Fold the quilt in two before
loading.
- Do not load more than 1 double-
size fiber quilt (200x200 cm). Do not
dry items containing cotton such as
quilts, pillows and etc.
- Do not dry items other than quilts
such as carpets, rugs or mats.
Permanent damage may arise in
your machine.
C
To obtain better results
from your dryer, your
laundry must be washed
with suitable programmes
and spun at the
recommended spin speeds
in the washing machine.
23
EN
• Wool Protect
Use this programme for drying wool
fabrics and textiles such as sweaters,
which have been washed according
to their care label instructions.
We recommend taking the
laundry out of the device, once the
programme is completed.
The wool programme of
this tumble dryer has been
approved by The Woolmark
Company for drying any
machine-launderable wool
fabrics, provided that the
products have been washed
as indicated by their care
label instructions and will
be dried in accordance with
this device manufacturer’s
instructions (M1606).
Woolmark is a registered
trademark in the UK,
Ireland, Hong Kong and
India.
• Delicates
You can dry your highly delicate
laundry (silk blouses, fine underwear,
etc.) that are suitable for drying or
laundry which is advised to be hand-
washed at a lower temperature.
C
It is recommended to
use a cloth bag to avoid
certain delicate garments
and laundry from getting
creased or damaged. Take
your laundry immediately
out of the dryer and hang
them after the programme
ends in order to prevent
them being creased.
• Freshen Up
Only ventilation is performed for 10
minutes without blowing hot air. You
can air the clothes that have been
kept in closed environments for a
long time and deodorize unpleasant
odours thanks to this programme.
• Timer Prog.
Using timer programmes (10
minutes, 20 minutes, 30 minutes, 40
minutes, 50 minutes, 60 minutes, 80
minutes, 100 minutes, 120 minutes,
140 minutes, and 160 minutes),
may help you to achieve the desired
degree of dryness even at low
temperatures.
In order to select any drying time, you
need to press the timer selection “
“key.
C
With this programme, the
machine dries for the time
selected regardless of the
dryness level.
24
6.7 Programme selection and consumption table
* : Energy assessment - standard programme (EN 61121:2012) All filters must be
cleaned before initiating any test series.Any values in the table have be determined in
accordance with the standard EN 61121:2012. Depending on the laundry type, spin-
drying speed and voltage fluctuations, the values may vary.
„Cotton cupboard dry programme“ used at full and partial load is the standard
drying programme to which the information in the label and the fiche relates,
that this programme is suitable for drying normal wet cotton laundry and that it
is the most efficient programme in terms of energy consumption for cotton.
EN
Programmes
Capacity
(kg)
Spin speed in washing
machine (rpm)
Approximate amount
of remaining humidity
Drying time
(minutes)
Express
Dry
Cottons / Coloreds
A
Extra dry 8 1000 % 60 165 130
A
Cupboard dry 8 / 4 1000 % 60 152 / 95 115
A
Iron dry 8 1000 % 60 124 95
Shirts 1,5 1200 % 50 50 35
Jeans 4 1200 % 50 117 85
Bedding 2,5 1000 % 50 120
Sportswear 4 1000 % 60 105 70
Daily 4 1200 % 50 100 65
Cottons Cupboard Dry
Night
8 1000 % 60 240
Delicates 2 600 % 40 50
Wool Protect 1,5 600 % 50 146
Synthetics
B Cupboard dry
4 800 % 40 75 50
B Iron dry
4 800 % 40 59 34
Energy consumption values
Programmes
Capacity
(kg)
Spin speed in washing
machine (rpm)
Approximate amount
of remaining humidity
Energy
consumption
value kWh
Express
Dry
(kwh)
Cupboard dry for cottons* 8 / 4 1000 % 60 1,42 / 0,83 2,33
Iron dry for cottons 8 1000 % 60 1,15 1,99
Cupboard dry for synthetics 4 800 % 40 0,51 0,87
Power consumption of the off-mode for the standart cotton programme at full load, PO (W) 0,4
Power consumption of the left-on mode for the standart cotton programme at full load, PL (W) 1,0
Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed.
R134a / 0,52 kg - GWP:1430 - 0,744 tCO2e
25
EN
6.8 Express Dry
This application is available for all
programmes highlighted with dark
colour on the control panel.
For example in case of “wardrobe
ready for cotton” the usual
programme duration is 2:32, the
ExpressDy feature reduces the
required time to 1:55.
6.9 Auxiliary functions
Audio Warning
After completing a programme,
the dryer generates an acoustic
signal. To adjust the volume, use the
acoustic signal key.
C
The volume may be
adjusted either before
starting the programme or
when the dryer is running
the programme.
Anti-creasing
A 2-hour anti creasing programme
to prevent laundry from creasing will
be activated if you do not take the
laundry out after the programme has
come to an end. This programme
rotates the laundry in 10-minute
intervals without heat to prevent
creasing.
6.10 Warning symbols
C
Warning symbols may
differ according to the
model of your machine.
Lint filter cleaning
When the programme is completed,
a warning symbol will appear to
remind that the filter needs to be
cleaned.
C
If the Filter Cleaning
symbol in continuously,
refer to “Troubleshooting”
section.
Water tank
When the programme is completed,
a warning symbol will appear to
remind that the water tank needs to
be drained.
If the water tank becomes full while
the programme is running, the
warning symbol will start to flash
and machine will pause. Drain the
water in the water tank and press
Start / Pause button to resume the
programme. The warning symbol
turns off and the programme
resumes operating.
26
Changing the End Time
If you want to change the time during
countdown:
1. Press On/Off/Cancel button
for 3 seconds to cancel the
programme. Restart the
machine and repeat the End
Time procedure for the desired
time.
2. When your machine is operated
for the first time, it starts
with the default programme
(wardrobe dryness for cottons).
Cancelling End Time function
If you want to cancel the End Time
countdown and start the programme
immediately:
1. Press On/Off/Cancel button
for 3 seconds to cancel the
programme.
2. Press On/Off/Cancel button to
start the programme you have
previously selected.
6.11 Starting the programme
Press Start/Pause button to start the
programme.
Start symbol will light up to
indicate that the programme has
started and “:” symbol in the middle
of the remaining time will keep
flashing.
Cleaning the filter drawer
Warning symbol flashes to remind
that the filter drawer needs to be
cleaned.
End Time Setting
End Time Setting function allows
you to delay the ending time of the
programme up to 24 hours.
1. Open the loading door and put
the laundry in.
2. Select the drying programme,
spin speed and, if required, the
auxiliary functions.
3. Press End Time Setting selection
button to set the desired End
Time Setting symbol lights up
on the display.(When the button
is pressed and hold, End Time
proceeds uninterruptedly).
4. Press Start/Pause button. End
Time Setting starts to count
down. The “:” in the middle of the
displayed End Time Setting will
start to flash.
C
Additional laundry may be
loaded / taken out during
the End Time period. At
the end of the End Time
countdown process, End
Time symbol disappears,
drying process starts and
the programme duration
is displayed. The time on
the display is the total of
normal drying time and
End Time .
27
EN
6.12 Child Lock
Machine is equipped with a Child
Lock which prevents interfering
with the current programme flow
by pressing any button. All buttons
except the On/Off/Cancel button on
the control panel are deactivated
when the Child Lock is active.
In order to activate the Child Lock,
press Audio Warning, Child Lock
button for 3 seconds.
To start a new programme after the
current programme is over or to
interrupt the current programme,
the Child Lock should be deactivated.
Press the same button for 3 seconds
again to deactivate the Child Lock.
C
Lock symbol will appear
on the display when the
Child Lock is activated.
C
Child Lock is deactivated
when the machine is
switched off and on with
On/Off/Cancel button.
When the Child Lock is activated:
Display symbols will not change
even if the position of Programme
Selection knob is changed while the
machine is running or in halt.
If the Child Lock is deactivated
after changing the position of
the Programme Selection knob
while the machine is running, the
machine stops and new programme
information is displayed.
6.13 Changing the programme
after it has started
After the machine starts, you can
change the selected programme
and dry your laundry in a different
programme.
1. If you want to select Extra Dry
programme instead of Iron Dry
programme, for instance, press
the Start / Pause button for 1
second to stop the programme.
2. Select Extra Dry programme
by turning the Programme
Selection knob.
3. Press the Start/Pause button to
start the programme.
Adding / removing laundry in Pause
mode
In order to add or take out laundry
after the drying programme has
started:
1. Press Start/Pause button to
switch the machine to Pause
mode. Drying process will stop.
2. While in Pause mode, open the
loading door, add or take out
laundry and close the loading
door.
3. Press the Start/Pause button to
start the programme.
C
Any laundry added after
the drying process has
started may cause the
clothes that are already
dried in the machine
intermingle with wet
clothes and the result will
be wet laundry after the
drying process is over.
28
C
You may repeat laundry
adding or removing
process as many times
as you desire during
drying. However, this
process will increase
the programme time
and energy consumption
since the drying process
will be interrupted
repeatedly. Therefore, it
is recommended to add
laundry before the drying
programme has started.
C
If you select a new
programme by turning
the Programme Selection
knob while your machine
is in Pause mode, then
the current programme
is aborted and new
programme information is
displayed.
CAUTION: Do not touch
the inner surface of the
drum when adding or
taking out laundry while
a programme is running.
Surfaces of the drum are
hot.
6.14 Cancelling the programme
If you want to stop drying and cancel
the programme for any reason after
the machine has started to run, press
and hold the On/Off/Cancel button
for 3 seconds.
A
CAUTION: As the inside
of the machine will be
excessively hot when you
cancel the programme
while the machine is
running, activate the
ventilation programme to
cool it down.
6.15 End of programme
Lint Filter Cleaning and Water Tank
warning symbols light up in the
programme follow-up indicator when
the programme comes to an end. The
loading door can be opened and the
machine becomes ready for a second
cycle.
Press On/Off/Cancel button to switch
off the machine.
C
2-hour Anti-creasing
programme will be
activated if the laundry
is not taken out after the
programme has come to an
end.
C
Clean the lint filter after
each drying. (See "Lint
Filter and Loading Door
Inner Surface")
C
Drain the water tank after
each drying cycle. (See
"Draining the water tank")
29
EN
7. Maintenance and
cleaning
Service life of product extends and
frequently experienced problems will
be reduced if it is cleaned at regular
intervals.
7.1 Cleaning Lint Filter / Loading
Door Inner Surface
Lint and fiber released from the
laundry to the air during the drying
cycle are collected in the Lint Filter.
C
Such fiber and lint are
generally formed during
wearing and washing.
A
Always clean the lint filter
and the inner surfaces of
the loading door after each
drying process.
C
You can clean the lint filter
housing with a vacuum
cleaner.
To clean the lint filter:
• Open the loading door.
• Remove the lint filter by pulling it
up and open the lint filter.
• Clean lint, fiber, and cotton
raveling by hand or with a soft
piece of cloth.
• Close the lint filter and place it
back into its housing.
• A layer can build up on the filter
pores that can cause clogging
of the filter after using the dryer
for a while. Wash the lint filter
with warm water to remove the
layer that builds up on the lint
filter surface. Dry the lint filter
completely before reinstalling it.
• Clean the entire inner surface
of the loading door and loading
door gasket with a soft damp
cloth.
30
7.2 Cleaning the sensor
There are dampness sensors in the
dryer that detect whether the laundry
is dry or not.
To clean the sensors:
• Open the loading doorof the
dryer.
• Allow the machine to cool down
if it is still hot due to the drying
process.
• Wipe the metal surfaces of
the sensor with a soft cloth,
dampened with vinegar and dry
them.
C
Clean metal surfaces of the
sensors 4 times a year.
C
Do not use metal tools
when cleaning metal
surfaces of the sensors.
A
Never use solvents,
cleaning agents or similar
substances for cleaning
due to the risk of fire and
explosion!
7.3 Draining the water tank
Dampness of the laundry is removed
and condensed during drying process
and the water that arise accumulates
in the water tank. Drain the water
tank after each drying cycle.
A
Condensed water is not
drinkable!
A
Never remove the water
tank when the program is
running!
If you forget to drain the water tank,
the machine will stop during the
subsequent drying cycles when the
water tank is full and the Water Tank
warning symbol will flash. If this is
the case, drain the water tank and
press Start / Pause button to resume
the drying cycle.
To drain the water tank:
Pull the drawer and remove the
water tank carefully.
• Drain the water in the tank.
• If there is lint accumulation in
the funnel of the water tank,
clean it under running water.
• Place the water tank into its
seat.
31
EN
C
If the direct water draining
is used as an option, there
is no need to empty the
water tank.
7.4 Cleaning the filter drawer
Lint and fiber that could not be
captured by the lint filter are blocked
in the filter drawer behind the kick
plate. Clean the filter drawer once
filter drawer cleaning warning
symbol is on.
There is an one stage filter. This one
stage filter is from sponge
To clean the filter drawer:
• Press the kick plate button to
open the kick plate.
• Remove the filter drawer cover
by turning it in the direction of
arrow.
• Pull out the filter drawer.
• Open the filter drawer by
pressing the red button.
• Take out the filter drawer
sponge.
• Wash the filter drawer sponge by
hand to remove the fiber and lint
on the surface. After washing the
sponge, squeeze it by hand and
remove the excess water.Replace
the sponge.
C
It is not necessary to clean
the sponge if lint and fiber
accumulation on it is not
significant.
• Place the sponge back into its
place.
C
Please place the sponge
carefully inside the frame
of the filter cassette shown
by arrows in order to avoid
squeezing when filter
drawer closed”.:
32
• Close the filter drawer as to lock
the red button.
• Place the filter drawer back into
its place, turn the filter drawer
cover in the arrow direction and
close it securely.
• Close the kick plate cover.
A
Drying without the filter
drawer sponge in place will
damage the machine!
C
A dirty lint filter and filter
drawer will cause longer
drying periods and higher
energy consumption.
C
The sponge filter must not
be replaced dripping wet as
this can cause a fault.
7.5 Cleaning the evaporator
Clean the lint accumulated on the
fins of the evaporator located behind
the filter drawer with a vacuum
cleaner.
A
You can also clean by hand
provided that you wear
protective gloves. Do not
attempt to clean with bare
hands. Evaporator fins can
harm your hand.
33
EN
8. Troubleshooting
Drying process takes too much time.
• Pores of the lint filter are clogged. >>> Wash the lint filter with warm
water.
• Filter drawer is clogged. >>> Clean the sponge and the filter cloth in
the filter drawer.
• Ventilation grids on the front side of the machine are blocked. >>>
Remove the objects (if any) that block ventilation in front of the
ventilation grids.
• Ventilation may not be sufficient since the room where the machine is
installed is very small. >>> Open the door and windows of the room to
avoid the room temperature increase too much.
• Lime deposit has built up on the dampness sensor. >>> Clean the
dampness sensor.
• Excessive laundry might have been loaded in. >>> Do not overload the
dryer.
• Laundry might not be spun sufficiently. >>> Spin your laundry at a
higher speed in your washing machine.
Laundry comes out wet at the end of drying.
• A programme suitable for the laundry type might have not been
used.>>> Check the garment tag and select a programme suitable for
the fabric type or use the timer programmes additionally.
• Pores of the lint filter are clogged. >>> Wash the lint filter with warm
water.
• Filter drawer is clogged. >>> Clean the sponge and the filter cloth in
the filter drawer.
• Excessive laundry might have been loaded in. >>> Do not load the dryer
in excess.
• Laundry might not be spun sufficiently. >>> Spin your laundry at a
higher speed in your washing machine.
Dryer does not switch on or the programme does not start. Dryer does
not start when it is set.
• It might have not been plugged in. >>> Make sure that the machine is
plugged in.
• The loading door is ajar. >>> Make sure that the loading door is closed
securely.
• Programme is not selected or the Start / Pause button is not pressed.
>>> Make sure that the programme is selected and it is not in the
Pause position.
• "Child Lock" might have been activated. >>> Deactivate the Childproof
Lock.
Programme is interrupted without any cause.
• The loading door might not be closed securely. >>> Push the loading
door to close until you hear a locking sound.
• A power failure might have occurred. >>> Press Start / Pause button to
start the programme.
• Water tank may be full. >>> Drain the water tank.
34
Laundry has shrunk, become felted or deteriorated.
• A programme suitable for the laundry type might have not been used.
>>> Check the garment tag and select a programme suitable for the
fabric type.
Water leaks from the loading door.
• Lint has accumulated on the inner surfaces of the loading door and on
the surfaces of the loading door gasket. >>> Clean the inner surfaces
of the loading door and the surfaces of the loading door gasket.
Loading door opens spontaneously.
• The loading door might not be closed securely. >>> Push the loading
door to close until you hear a locking sound.
Water Tank warning symbol is on/flashing.
• Water tank may be full. >>> Drain the water tank.
• Water draining hose might be bent. >>> If the product is connected
directly to a wastewater drain, check the water drain hose.
A
CAUTION: If you cannot eliminate the problem although you
follow the instructions in this section, consult your dealer or the
Authorised Service Agent. Never try to repair a nonfunctional
product yourself.
35
EN
9. Electrical
Connection
Make sure that you have an earthed
power outlet socket rated at 13 amps
(minimum).
9.1 Attention!
When installed, the socket must be
reachable after installation, or a separate
switch (which can disconnect the two
poles) must be used in the installation.
Check for suitability.
For a permanent connection, a master
switch with at least 3mm contact
clearance and minimum 13 A rating
must be used.
9.2 Electrical requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket in a
readily accessible position.
Should the mains lead of the appliance
become damaged or need replacing at
any time, it must be replaced by a special
purpose made mains lead which can only
be obtained from an Authorised Service
Agent.
A
Warning
This appliance must be earthed
If the fitted moulded plug is not suitable
for your socket, then the plug should be
cut off and an appropriate plug fitted.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse
need to be replaced an ASTA approved
BS1362 fuse of the same rating must
be used. Do not forget to refit the fuse
cover. In the event of losing the fuse
cover, the plug must not be used until a
replacement fuse cover has been fitted.
Colour of the replacement fuse cover
must be the same colour as that visible
on the pin face of the plug. Fuse covers
are available from any good electrical
store.
In order to avoid hazards, damaged
supply cord should be replaced by
the manufacturer, its service agent or
similarly qualified people.
A
Do not operate without the top
cover fitted. Risk of injury.
A
Important
9.3 Fitting a different plug
As the colours of the wires in the
mains lead of this appliance may not
correspond with the coloured markings
identifying the terminals on your plug,
proceed as follows:
1 Connect the green - yellow or green
(earth) wire to the terminal in the plug
marked ‘E’ or with the symbol or
coloured green and yellow or green.
2 Connect the blue (neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3 Connect the brown (live) wire to the
terminal in the plug marked ‘L’ or
coloured red.
With the alternative plugs a 13 A fuse
must be fitted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualified electrician.
Green and yellow
or green
N
Blue or black
L
Brown or red
9.4 Washer/dryer combination
Do not stack washing machine on top
of the tumble dryer. This would damage
both appliances and guarantees would
become void. It is also unsafe to stack an
appliance on top of another without using
a suitable and approved stacking kit
obtained from specialist retailers.
36
Guarantee
De
tails
Your new Grundig product is guaranteed against faulty materials, defective components or
manufacturing defects. The guarantee starts from the date of original purchase of the product
for a period of three (3) years unless Beko plc (the “Manufacturer”) agrees to extend the
guarantee for the product in writing. If you have any questions about the guarantee on your
product (including how long it is valid), please contact your retailer or our Call Centre on 0333
207 9920.
This guarantee does not in any way diminish or affect your statutory rights in connection with
the product. This guarantee is in addition to your statutory rights as a consumer. If you have
any question about these rights, please contact the retailer from which you purchased the
product. In certain circumstances, it is possible that your statutory rights may offer additional
or higher levels of protection than those offered under the terms of this guarantee.
What is covered by this guarantee?
Repairs to the product required as a result of faulty materials, defective components
or manufacturing defects.
Functional replacement parts to repair a product.
The costs of a Grundig Approved Engineer to carry out the repair.
What is not covered?
Transit and delivery damage.
Cabinet or appearance parts, including but not limited to control knobs, flaps and
handles.
Accessories and/or consumable items including but not limited to ice trays, scrapers,
cutlery baskets, filters and light bulbs.
Repairs necessary as a direct or indirect result of:
- Accidental damage, misuse or abuse of a product.
- An attempted repair of a product by anyone other than a Grundig Approved
Engineer (the “Engineer”).
- Installation or use of a product where such installation or use fails to meet the
requirements contained in this guarantee or the User Instructions Booklet.
Repairs to a product operated at any time on commercial or non-residential household
premises (unless we have previously agreed to the installation environment).
This guarantee is limited to the cost of repairing the product. To the extent permitted by law,
Beko plc (the “Manufacturer”) does not accept and will not be held liable for any financial loss
incurred in connection with the failure of any product to operate in accordance with the
expected standards. Such financial loss includes but is not limited to loss arising from:
Time taken off work.
Damaged food, clothing or other items.
Meals taken at restaurants or from takeaways.
37
EN
General compensation for inconvenience.
Important Notes
Your product is designed and built for domestic household use only.
The guarantee will automatically be void if the product is installed or is used in
commercial or non-residential domestic household premises, unless we have
previously agreed to the installation environment.
The product must be correctly installed, located and operated in accordance with the
instructions contained in the User Instructions Booklet provided with your product.
Professional installation by a qualified Electrical Domestic Appliance Installer is
recommended for all Washing Machines, Dishwashers and Electric Cookers (as
incorrect installation may result in you having to pay for the cost of repairing the
product).
Gas Cookers must be professionally installed by a Gas Safe (or Gas Networks Ireland
for Republic of Ireland) registered gas installer.
This guarantee is given in respect of products purchased and used within the United
Kingdom and the Republic of Ireland.
This guarantee is effective from the initial date of purchase of a new product from an
authorised retailer and will be void if the product is resold.
This guarantee does not apply to graded sales (where the product is purchased as a
“second”).
Possession of a copy of these terms and conditions does not necessarily mean that a
product has the benefit of this guarantee. If you have any questions, please call our
Call Centre on the number set out above.
The Manufacturer reserves the right to terminate the guarantee if its staff or
representatives are subjected to physical or verbal abuse in the course of carrying out
their duties.
Optional extras, where available (i.e. extendable feet) are supplied on a chargeable
basis only.
Does Grundig offer replacements?
This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion,
replace your product with a new product instead of carrying out a repair. Where a replacement
is offered, this would normally be an identical model, but when this is not possible, a model of
similar specification will be provided. The Manufacturer will cover the costs and arrange for
the delivery of the new product and for the return of the old product. Any costs related to
disconnecting the faulty product and installing the replacement product will not be borne by
the Manufacturer unless previously agreed to in writing. The original guarantee will continue
to apply to the replacement product; the new product will not come with a new guarantee.
When will the repair take place?
Our Engineers work Monday to Friday 9.00am to 5.00pm. Appointments outside these hours
may be possible at the sole discretion of the Manufacturer but cannot be guaranteed. Whilst
our Engineers will endeavour to minimize inconvenience and to meet requests for specific
timed appointments, this cannot be guaranteed. We will not be liable for delays or if it is unable
to carry out a repair because a convenient appointment cannot be arranged.
38
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this
guarantee with a proof of purchase. The Manufacturer reserves the right to charge for the
reasonable cost of any service call if:
You cannot provide evidence that your product is covered by this guarantee.
Where a service call has been made and the engineer finds that there is no fault with
your product.
That your product has not been installed or operated in accordance with the User
Instructions Booklet.
That the fault was caused by something other than faulty materials, defective
components or manufacturing defects.
For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice.
The Manufacturer reserves the right to terminate the guarantee if you fail to pay the costs for
the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law
and subject to the English Courts, save where you live in another part of the United Kingdom,
in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and
the Irish courts will have jurisdiction.
HOW TO OBTAIN SERVICE
Please keep your purchase receipt or other proof of purchase in a safe place; you will need to
have it should the product require attention under guarantee.
It will be useful if you complete the details below, as it will help us assist you when requesting
service (the model number is printed on the Instruction Booklet and the serial number is printed
on the Rating Label affixed to the appliance). Recording of these details alone will not count
as proof of purchase. A valid proof of purchase is required for under guarantee service.
The area around the product must be easily accessible to the Engineer without the need for
cabinets or furniture being removed.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry
out any repairs.
…………………………………………………………………………………………………………
Model No:
Serial No:
Retailer:
Date of purchase:
…………………………………………………………………………………………………………..
For service under guarantee simply telephone the appropriate number below
39
EN
Will there be any charge for the repairs?
It is your responsibility to provide evidence to the Engineer that your product is covered by this
guarantee with a proof of purchase. The Manufacturer reserves the right to charge for the
reasonable cost of any service call if:
You cannot provide evidence that your product is covered by this guarantee.
Where a service call has been made and the engineer finds that there is no fault with
your product.
That your product has not been installed or operated in accordance with the User
Instructions Booklet.
That the fault was caused by something other than faulty materials, defective
components or manufacturing defects.
For missed appointments.
Payment of these costs are due immediately upon the Engineer providing you with an invoice.
The Manufacturer reserves the right to terminate the guarantee if you fail to pay the costs for
the service call in a timely manner.
If you are a resident of the United Kingdom, this guarantee will be governed by English law
and subject to the English Courts, save where you live in another part of the United Kingdom,
in which case the law and courts of that location will apply.
If you are resident in the Republic of Ireland, this guarantee will be governed by Irish law and
the Irish courts will have jurisdiction.
HOW TO OBTAIN SERVICE
Please keep your purchase receipt or other proof of purchase in a safe place; you will need to
have it should the product require attention under guarantee.
It will be useful if you complete the details below, as it will help us assist you when requesting
service (the model number is printed on the Instruction Booklet and the serial number is printed
on the Rating Label affixed to the appliance). Recording of these details alone will not count
as proof of purchase. A valid proof of purchase is required for under guarantee service.
The area around the product must be easily accessible to the Engineer without the need for
cabinets or furniture being removed.
It is your responsibility to ensure our Engineers have a clean and safe environment to carry
out any repairs.
…………………………………………………………………………………………………………
Model No:
Serial No:
Retailer:
Date of purchase:
…………………………………………………………………………………………………………..
For service under guarantee simply telephone the appropriate number below
UK Mainland & Northern Ireland 0333 207 9920 or customerservice@support.grundig.co.uk
Republic of Ireland: 01 691 0203
Register your appliance at: grundig.co.uk/support/register
Before requesting service please check the troubleshooting guide in the Operating Instructions
as a charge may be levied where no fault is found even though your product may still be under
guarantee.
Service once the manufacturers guarantee has expired
If you have purchased an extended guarantee please refer to the instructions contained within
the extended guarantee agreement document, otherwise please call the appropriate number
above where service can be obtained at a charge.
Should you experience any difficulty in obtaining service contact the Grundig Customer
…………………………………………………………........................................... .........................
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent, Watford, Herts,
WD18 8QU. Beko plc is registered in England and Wales with company registration number
02415578.
www.grundig.com
2960311308_KM/040117.1918
Document Number
