SIGNATURE SERIES 2000ES, 2000E BUILT IN & MOBILE
NATURAL GAS CONVERSION
WARNING
WARNING
Conversion of this unit to natural gas must be carried out by
a qualified licensed person and a Certificate of Compliance
must be issued to the owner on completion of the installation
and conversion. Conversion of this barbecue by unlicensed
persons may result in improper functioning of the appliance,
injury, property damage and may affect your ability to make a
claim under the manufacturer’s warranty.
Converting the unit to natural gas
This barbecue is set up for LPG gas and is labelled
accordingly. A natural gas conversion kit is available as an
accessory if required.
The components in the kit are:
• 6 x brass injectors (natural gas)
• 700mm hose with ½” male pipe thread at one end and
3/8” SAE Flare with 5/8-18 UNF female thread at the
other end
• Natural gas regulator with ½” female pipe threads on
inlet and outlet
• 1500mm hose with ½” male pipe thread at one end and
quick connect at the other end
• 2000mm tether (mobile use only)
• Natural gas sticker
1. Replace ‘gas type’ sticker
• Locate LPG gas sticker located on the lower face of the
control panel and remove it. Put natural gas sticker in
its place
2. Change the injectors
• Remove the burners and grease tray from the appliance
to gain access to the injectors
• Unscrew the LPG injectors and replace with natural
gas injectors on all valves. All injectors are marked
with the orifice size
• Do not overtighten injectors
3. Change the aeration shutter
• Remove the burners from the appliance
• Remove the locating screw from the aeration shutter
• Slide the aeration shutter off the burner and then refit
using the natural gas location hole
• Repeat this procedure on all burners and then reinstall
back into the appliance
Remove LPG injector and
install injector for natural gas
Natural gas
location hole
Locating screw
1NATURAL GAS CONVERSION
4. Connecting the appliance to a natural gas supply
• The appliance shall be installed in accordance to
AS/NZS5601 gas installations and any relevant local
gas fitting rules
• Remove the fitted LPG gas bottle hose and
regulator from the adaptor mounted to the
semi-rigid appliance pipe
• Connect the conversion kit hoses and natural gas
regulator. Ensure the flow arrow on the regulator points
towards the appliance
• Carry out a leakage check on all connections
5. Adjust the turndown setting on the valve
NOTE: The final step in the conversion of the barbecue
to natural gas is the adjustment of the turndown setting.
• Light each burner and rotate the control knob to
the lowest setting, then remove the knob from the
valve shaft
• Using a small flat-blade screwdriver adjust the
turndown adjustment screw to achieve a small steady
flame on the burner
Turndown screw
View with
knob removed
• Replace the knob
• Recheck the operation of the burner
at the maximum and turndown
• Repeat procedures for all valves
SIGNATURE SERIES 2000ES, 2000E BUILT IN & MOBILE
NATURAL GAS CONVERSION
2NATURAL GAS CONVERSION
© 2018 Electrolux Home Products Pty Ltd. ABN 51 004 762 341
BMAN_Signature2000_NG_ConvKit_Aug18
