Instruction Manual
Manuale di istruzioni
Manual de instrucciones
es
ar
ﻡﺪﺨﺘﺴﳌﺍ ﻞﻴﻟﺩ
FA 120 A
FA 120 AS
FA 120 AP
FA 120 APS
FA 120 ES
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the user
manual as well.
The user manual will help you use the product in a fast and safe way.
Read the manual before installing and operating the product.
Make sure you read the safety instructions.
Keep the manual in an easily accessible place as you may need it later.
Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
EN
2
CONTENTS
1 Your cooler/freezer 3
2 Important Safety Warnings 4
Intended use .....................................4
General safety ...................................5
For products with a ..........................9
water dispenser; ................................9
Child safety ........................................9
Compliance with WEEE Directive and
Disposing of the Waste Product: .......9
Package information ........................10
HC warning .....................................10
Things to be done for energy saving 10
3 Installation 12
Points to be paid attention to when the
relocation of the cooler/freezer .........12
Before you start the cooler/freezer, ..12
Electrical connection ........................12
Disposing of the packaging .............13
Disposing of your old cooler/freezer .13
Placing and Installation ....................13
Adjusting the legs ............................14
Changing the illumination lamp .......14
4 Preparation 15
Reversing the doors ........................17
5 Using your cooler/freezer 19
Freezing food ...................................19
Making ice cubes ............................20
Defrosting of the appliance ..............20
Cooling ............................................21
Food storage ...................................21
Defrosting of the appliance ..............21
6 Maintenance and cleaning 22
Protection of plastic surfaces ..........22
7 Troubleshooting 23
EN
3
1 Your cooler/freezer
1. a.) Freezing compartment & ice tray
(for models) b.) Frozen food
compartment & ice tray (for
models)
2. Interior light & Thermostat knob
3. Movable shelves
4. Crisper cover
5. Crisper
6. Adjustable front feet
7. Dairy compartment
8. Door shelf
9. Egg tray
10. Bottle shelf
11. Bottle gripper
12. Top t ri m
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
2
3
4
5
3
6
1
10
7
9
8
11
12
EN
4
2 Important Safety Warnings
Please review the
following information.
Failure to observe this
information may cause
injuries or material
damage. Otherwise, all
warranty and reliability
commitments will become
invalid.
Original spare parts will
be provided for 10 years,
following the product
purchasing date.
Intended use
A
WARNING:
Keep ventilation
openings, in the
appliance enclosure
or in the built-in
structure, clear of
obstruction.
A
WARNING:
Do not use
mechanical devices
or other means
to accelerate the
defrostingprocess,
other than those
recommended by
the manufacturer.
A
WARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of the
appliance, unless
they are of the type
recommended by
the manufacturer.
A
WARNING:
Do not store
e x p l o s i v e
substances such
as aerosol cans
with a flammable
propellant in this
appliance.
This appliance is intended
to be used in household
and similar applications
such as
– staff kitchen areas in
shops, offices and other
working environments;
– farm houses and by
clients in hotels, motels
and other residential type
environments;
EN
5
– bed and breakfast type
environments;
– catering and similar
non-retail applications.
General safety
When you want to
dispose/scrap the
product, we recommend
you to consult the
authorized service
in order to learn the
required information and
authorized bodies.
Consult your authorized
service for all your
questions and problems
related to the refrigerator.
Do not intervene or let
someone intervene to
the refrigerator without
notifying the authorised
services.
For products with a
freezer compartment;
Do not eat cone ice
cream and ice cubes
immediately after you
take them out of the
freezer compartment!
(This may cause frostbite
in your mouth.)
For products with a
freezer compartment;
Do not put bottled
and canned liquid
beverages in the
freezer compartment.
Otherwise, these may
burst.
Do not touch frozen food
by hand; they may stick
to your hand.
Unplug your refrigerator
before cleaning or
defrosting.
Vapor and vaporized
cleaning materials
should never be used in
cleaning and defrosting
processes of your
refrigerator. In such
cases, the vapor may
get in contact with the
electrical parts and
cause short circuit or
electric shock.
Never use the parts on
your refrigerator such as
the door as a means of
support or step.
Do not use electrical
devices inside the
refrigerator.
Do not damage the
parts, where the
refrigerant is circulating,
EN
6
with drilling or cutting
tools. The refrigerant
that might blow out
when the gas channels
of the evaporator, pipe
extensions or surface
coatings are punctured
causes skin irritations
and eye injuries.
Do not cover or block
the ventilation holes on
your refrigerator with any
material.
Electrical devices must
be repaired by only
authorised persons.
Repairs performed by
incompetent persons
create a risk for the user.
In case of any failure or
during a maintenance or
repair work, disconnect
your refrigerator’s mains
supply by either turning
off the relevant fuse
or unplugging your
appliance.
Do not pull by the cable
when pulling off the plug.
Ensure highly alcoholic
beverages are stored
securely with the lid
fastened and placed
upright.
Never store spray
cans containing
flammable and explosive
substances in the
refrigerator.
Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
This product is not
intended to be used by
persons with physical,
sensory or mental
disorders or unlearned
or inexperienced people
(including children)
unless they are attended
by a person who will
be responsible for their
safety or who will instruct
them accordingly for use
of the product
Do not operate a
damaged refrigerator.
Consult with the service
agent if you have any
concerns.
Electrical safety of your
refrigerator shall be
guaranteed only if the
earth system in your
house complies with
standards.
EN
7
Exposing the product
to rain, snow, sun and
wind is dangerous with
respect to electrical
safety.
Contact authorized
service when there is a
power cable damage to
avoid danger.
Never plug the
refrigerator into the wall
outlet during installation.
Otherwise, risk of death
or serious injury may
arise.
This refrigerator is
intended for only storing
food items. It must not
be used for any other
purpose.
Label of technical
specifications is located
on the left wall inside the
refrigerator.
Never connect your
refrigerator to electricity-
saving systems; they
may damage the
refrigerator.
If there is a blue light on
the refrigerator, do not
look at the blue light with
optical tools.
For manually controlled
refrigerators, wait for at
least 5 minutes to start
the refrigerator after
power failure.
This operation manual
should be handed in to
the new owner of the
product when it is given
to others.
Avoid causing damage
on power cable when
transporting the
refrigerator. Bending
cable may cause fire.
Never place heavy
objects on power cable.
Do not touch the plug
with wet hands when
plugging the product
Do not plug the
refrigerator if the wall
outlet is loose.
Water should not be
sprayed on inner or outer
parts of the product for
safety purposes.
EN
8
Do not spray substances
containing inflammable
gases such as propane
gas near the refrigerator
to avoid fire and
explosion risk.
Never place containers
filled with water on top
of the refrigerator; in
the event of spillages,
this may cause electric
shock or fire.
Do not overload the
refrigerator with food.
If overloaded, the food
items may fall down and
hurt you and damage
refrigerator when you
open the door.
Never place objects on
top of the refrigerator;
otherwise, these objects
may fall down when
you open or close the
refrigerator’s door.
As they require a precise
temperature, vaccines,
heat-sensitive medicine
and scientific materials
and etc. should not be
kept in the refrigerator.
If not to be used for a
long time, refrigerator
should be unplugged.
A possible problem in
power cable may cause
fire.
Refrigerator may move
if adjustable legs are not
properly secured on the
floor. Properly securing
adjustable legs on the
floor can prevent the
refrigerator to move.
When carrying the
refrigerator, do not hold
it from door handle.
Otherwise, it may be
snapped.
When you have to place
your product next to
another refrigerator or
freezer, the distance
between devices
should be at least 8cm.
Otherwise, adjacent side
walls may be humidified.
The product shall never
be used while the
compartment which is
located at the top or
back of your product
and in which electronic
boards are available
(electronic board box
cover) (1) is open.
EN
9
1
1
For products with a
water dispenser;
Pressure for cold water
inlet shall be maximum
90 psi (6.2 bar). If your
water pressure exceeds
80 psi (5.5 bar), use a
pressure limiting valve
in your mains system. If
you do not know how
to check your water
pressure, ask for the
help of a professional
plumber.
If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment
in your installation.
Consult Professional
plumbers is you are not
sure that there is no
water hammer effect in
your installation.
Do not install on the
hot water inlet. Take
precautions against
of the risk of freezing
of the hoses. Water
temperature operating
interval shall be 33°F
(0.6°C) minimum
and 100°F (38°C)
maximum.
Use only potable water.
Child safety
If the door has a lock,
the key should be kept
away from reach of
children.
Children must be
supervised to prevent
them from tampering
with the product.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE Directive
(2012/19/EU). This product
bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).
EN
10
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Therefore, do not dispose
the product with normal domestic
waste at the end of its service life. Take
it to a collection point for the recycling
of electrical and electronic equipment.
Please consult your local authorities
to learn the nearest collection point.
Help protect the environment and
natural resources by recycling used
products. For children’s safety, cut the
power cable and break the locking
mechanism of the door, if any, so that it
will be non-functional before disposing
of the product.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and our
national asset wealth.
If you want to contribute to the re-
evaluation of the packaging materials,
you can consult to your environmentalist
organizations or the municipalities
where you are located.
HC warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the product
catch a fire and ventilate the room in
which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving
Do not leave the doors of your
refrigerator open for a long time.
Do not put hot food or drinks in your
refrigerator.
Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
Pay attention to keep your food in
closed containers.
EN
11
For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.
EN
12
3 Installation
B The manufacturer will not be liable
for any event caused by disregarding
the information supplied in this user
manual.
Points to be paid attention
to when the relocation of the
cooler/freezer
1. Your cooler/freezer should be
unplugged.Before transportation
of your cooler/freezer, it should be
emptied and cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside
your cooler/freezer should be fixed
with adhesive tape and secured
against impacts. Package should
be bound with a thick tape and the
transportation rules on the package
should be strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the cooler/
freezer,
Check the following before you start
to use your cooler/freezer:
1. Attach 2 plastic wedges as illustrated
below. Plastic wedges are intended
to keep the distance which will
ensure the air circulation between
your cooler/freezer and the wall.
(The picture is drawn up as a
representation and it is not identical
with your product.)
2. Clean the interior of the cooler/
freezer as recommended in the
“Maintenance and cleaning” section.
3. Connect the plug of the cooler/
freezer to the wall socket. When the
fridge door is opened, fridge internal
lamp will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is
not running and this is quite normal.
5. Front edges of the cooler/freezer
may feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
The power plug must be easily
accessible after installation.
Electrical safety of your cooler/freezer
shall be guaranteed only if the earth
system in your house complies with
standards.
EN
13
The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
Extension cables and multi plugs
must not be used for connection.
B A damaged power cable must be
replaced by a qualified electrician.
B Faulty product must not be operated
before it is repaired! There is the risk
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated by
the local authorities.
The packing of your cooler/freezer is
produced from recyclable materials.
Disposing of your old cooler/
freezer
Dispose of your old cooler/freezer
without giving any harm to the
environment.
You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your cooler/freezer.
Before disposing of your cooler/
freezer, cut out the electric plug and, if
there are any locks on the door, make
them inoperable in order to protect
children against any danger.
Placing and Installation
A If the entrance door of the room
where the cooler/freezer will be installed
is not wide enough for the cooler/
freezer to pass through, then carefully
remove the doors of your cooler/freezer
and pass it sideways through the door.
1. Install your cooler/freezer to a place
that allows ease of use.
2. Keep your cooler/freezer away from
heat sources, humid places and
direct sunlight.
3. There must be appropriate air
ventilation around your cooler/
freezer in order to achieve an efficient
operation. If the cooler/freezer is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on
the materials such as rug or carpet.
4. Place your cooler/freezer on an even
floor surface to prevent jolts.
WARNING:
Do not locate extension
sockets or charging transformers/
power supplies or Lithium-Iron battery
operated products adjacent to the
compressor as they could overheat.
If your appliance is equipped with an
air grille, please refer for installation of
the air grille.
1
2
3
3
3
1
EN
14
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning its front legs as illustrated in the
figure. The corner where the leg exists is
lowered when you turn in the direction
of black arrow and raised when you
turn in the opposite direction. Taking
help from someone to slightly lift the
refrigerator will facilitate this process.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call your
AuthorisedService.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer in
a safe and comfortable way.The lamps
used in this appliance have to withstand
extreme physical conditions such as
temperatures below -20 °C.
(only chest and upright freezer)
EN
15
4 Preparation
Your cooler/freezer should be
installed at least 30 cm away from
heat sources such as hobs, ovens,
central heater and stoves and at least
5 cm away from electrical ovens and
should not be located under direct
sunlight.
The ambient temperature of the room
where you install your cooler/freezer
should at least be 10°C. Operating
your cooler/freezer under cooler
conditions is not recommended with
regard to its efficiency.
Please make sure that the interior
of your cooler/freezer is cleaned
thoroughly.
If two cooler/freezers are to be
installed side by side, there should be
at least 4 cm distance between them.
When you operate your cooler/freezer
for the first time, please observe the
following instructions during the initial
six hours.
The door should not be opened
frequently.
It must be operated empty without
any food in it.
Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
Original packaging and foam
materials should be kept for future
transportations or moving.
EN
16
1
55 mm
595 mm
820 mm
2
3
4
a
a
c
b
b
d
e
b b
EN
17
Reversing the doors
Proceed in numerical order
a
H
G
D
E
I
F
B
C
A
EN
18
EN
19
5 Using your cooler/freezer
The operating temperature is regulated
by the temperature control.
1 = Lowest cooling setting
(Warmest setting)
5 = Highest cooling setting
(Coldest setting)
(Or)
Min. = Lowest cooling setting
(Warmest setting)
Max. = Highest cooling setting
(Coldest setting)
The average temperature inside the
fridge should be around +4°C.
Recommended thermostat knob
position is 4 .It's recommended 1
at cold ambient conditions such as
10 °C.
Please choose the setting according
to the desired temperature.
You can stop operation of your
appliance by turning the thermostat
knob to “0” position.
Please note that there will be different
temperatures in the cooling area.
The coldest region is immediately
above the vegetable compartment on
crisper cover.
Warm Cold
1 2 3 4 5
(Or) Min. Max.
The interior temperature also depends
on ambient temperature, the frequency
with which the door is opened and the
amount of food kept inside.
Frequently opening the door causes
the interior temperature to rise.
For this reason, it is recommended
to close the door again as soon as
possible after use.
Freezing food
The freezing compartment is marked
with this symbol.
You can use the appliance for freezing
fresh food as well as for storing pre-
frozen food.
Please refer to the recommendations
given on the packaging of your food.
Do not freeze fizzy drinks, as the bottle
may burst when the liquid in it is frozen.
Be careful with frozen products such
as coloured ice-cubes.
In order to maintain the quality of the
food, the freezing must be effected as
rapidly as possible.
Keep the already deep-frozen food
always separated with freshly placed
food.
When deep-freezing hot food, the
cooling compressor will work until the
food is completely frozen. This can
temporarily cause excessive cooling of
the refrigeration compartment.
EN
20
If you find the freezer door difficult
to open just after you have closed it,
don’t worry. This is due to the pressure
difference which will equalize and allow
the door to open normally after a few
minutes.
You will hear a vacuum sound just after
closing the door. This is quite normal.
Making ice cubes
Fill the ice-cube tray 3/4 full with water
and place it in the freezer.
As soon as the water has turned into
ice, you can take out the ice cubes.
Never use sharp objects such as
knives or forks to remove the ice cubes.
There is a risk of injury!
Let the ice cubes slightly thaw instead,
or put the bottom of the tray in hot
water for a short moment.
Defrosting of the appliance
Excessive build-up of ice will affect the
freezing performance of your device.
It is therefore recommended that you
defrost your appliance at least twice
a year, or whenever the ice build-up
exceeds 7 mm.
Defrost your device when there is only
little or no food in it.
Take out the deep-frozen food. Wrap
the deep-frozen food in several layers
of paper, or a blanket, and keep it in a
cold place.
Unplug the appliance or switch off the
circuit breaker to start the defrosting
process.
Take out the accessories (like shelf,
drawer etc.) from the appliance and
use a suitable container to collect the
thawing water.
Use a sponge or a soft cloth to
remove thawing water if necessary at
the freezing compartment and
frozen food compartment
Keep the door open during defrosting.
For quicker defrosting, place
containers with warm water inside the
appliance.
Never use electrical devices,
defrosting sprays or pointed or sharp-
edged objects such as knives or forks
to remove the ice.
After the defrosting is done, clean
interior walls of the compartment.
Reconnect the appliance to the mains.
Place the frozen food into the drawers
and slide the drawers into the freezer.
EN
21
Cooling
Food storage
The fridge compartment is for the
short-term storage of fresh food and
drinks.
Store milk products in the intended
compartment in the cooler/freezer.
Bottles can be stored in the bottle
holder or in the bottle shelf of the door.
Raw meat is best kept in a polyethylene
bag in the compartment at the very
bottom of the cooler/freezer.
Allow hot food and beverages to cool
to room temperature prior to placing
them in the cooler/freezer.
Store concentrated alcohol in a
container only standing upright and
tightly closed.
Do not store explosive substances or
containers with flammable propellant
gases (canned cream, spray cans etc.)
in the appliance.
There is a danger of explosion.
Defrosting of the appliance
The fridge compartment defrosts
automatically. The thawing water
flows through the drain channel into a
collection container at the back of the
appliance.
During defrosting, water droplets form
at the back wall of the fridge due to the
evaporation.
If not all of the drops run down,
they may freeze again after defrosting
completes. Remove them with a soft
cloth dampened with warm water. Do
not use hard or sharp objects.
Check the flow of the thawed water
from time to time. It may become
blocked occasionally. Clean it with a
pipe-cleaner or similar implement as
shown below.
EN
22
6 Maintenance and cleaning
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
B We recommend that you unplug the
appliance before cleaning.
B Never use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish for
cleaning.
C Use lukewarm water to clean the
cabinet of your cooler/freezer and
wipe it dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your cooler/freezer is not going to
be used for a long period of time,
unplug the power cable, remove all
food, clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
A To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
ANever use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
A Do not use sharp, abrasive tools,
soap, household cleaning agents,
detergents, kerosene, fuel oil,
varnish etc. to prevent removal and
deformation of the prints on the
plastic part. Use lukewarm water
and a soft cloth for cleaning and then
wipe it dry.
Protection of plastic
surfaces
C Do not put the liquid oils or oil-
cooked meals in your cooler/freezer
in unsealed containers as they
damage the plastic surfaces of your
cooler/freezer. In case of spilling or
smearing oil on the plastic surfaces,
clean and rinse the relevant part of
the surface at once with warm water.
EN
23
7 Troubleshooting
Please review this list before calling the service. It will save your time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The cooler/freezer does not operate.
The plug is not inserted into the socket correctly. >>>Insert the plug into the
socket securely.
The fuse of the socket which your cooler/freezer is connected to or the main
fuse have blown out. >>>Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
Door has been opened frequently. >>>Do not open and close the door of
cooler/freezer frequently.
Ambient is very humid. >>>Do not install your cooler/freezer into highly humid
places.
Food containing liquid is stored in open containers. >>>Do not store food with
liquid content in open containers.
Door of the cooler/freezer is left ajar. >>>Close the door of the cooler/freezer.
Thermostat is set to a very cold level. >>>Set the thermostat to a suitable level.
Compressor is not running
Protective thermic of the compressor will blow out during sudden power failures
or plug-out plug-ins as the refrigerant pressure in the cooling system of the
cooler/freezer has not been balanced yet. The cooler/freezer will start running
approximately after 6 minutes. Please call the service if the cooler/freezer does
not startup at the end of this period.
The fridge is in defrost cycle. >>>This is normal for a full-automatically defrosting
cooler/freezer. Defrosting cycle occurs periodically.
The cooler/freezer is not plugged into the socket. >>>Make sure that the plug is
fit into the socket.
Temperature settings are not made correctly. >>>Select the suitable temperature
value.
There is a power outage. >>>Cooler/freezer returns to normal operation when
the power restores.
EN
24
The operation noise increases when the cooler/freezer is running.
The operating performance of the cooler/freezer may change due to the
changes in the ambient temperature. It is normal and not a fault.
The cooler/freezer is running frequently or for a long time.
New product may be wider than the previous one. Larger cooler/freezers
operate for a longer period of time.
The room temperature may be high. >>>It is normal that the product operates
for longer periods in hot ambient.
The cooler/freezer might be plugged in recently or might be loaded with food.
>>>When the cooler/freezer is plugged in or loaded with food recently, it will take
longer for it to attain the set temperature. This is normal.
Large amounts of hot food might be put in the cooler/freezer recently. >>>Do
not put hot food into the cooler/freezer.
Doors might be opened frequently or left ajar for a long time. >>>The warm
air that has entered into the cooler/freezer causes the cooler/freezer to run for
longer periods. Do not open the doors frequently.
Freezer or fridge compartment door might be left ajar. >>>Check if the doors are
closed completely.
The cooler/freezer is adjusted to a very low temperature. >>>Adjust the cooler/
freezer temperature to a warmer degree and wait until the temperature is
achieved.
Door seal of the fridge or freezer may be soiled, worn out, broken or not properly
seated. >>>Clean or replace the seal. Damaged/broken seal causes the
cooler/freezer to run for a longer period of time in order to maintain the current
temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
The freezer temperature is adjusted to a very low value. >>>Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
The fridge temperature is adjusted to a very low value. >>>Adjust the fridge
temperature to a warmer degree and check.
Food kept in the fridge compartment drawers is frozen.
The fridge temperature is adjusted to a very high value. >>>Adjust the fridge
temperature to a lower value and check.
EN
25
Temperature in the fridge or freezer is very high.
The fridge temperature is adjusted to a very high value. >>>Fridge compartment
temperature setting has an effect on the temperature of the freezer. Change the
temperatures of the fridge or freezer and wait until the relevant compartments
attain a sufficient temperature.
Doors are opened frequently or left ajar for a long time. >>>Do not open the
doors frequently.
Door is ajar. >>>Close the door completely.
The cooler/freezer is plugged in or loaded with food recently. >>>This is normal.
When the cooler/freezer is plugged in or loaded with food recently, it will take
longer for it to attain the set temperature.
Large amounts of hot food might be put in the cooler/freezer recently. >>>Do
not put hot food into the cooler/freezer.
Vibrations or noise.
The floor is not level or stable. >>> If the cooler/freezer rocks when moved
slowly, balance it by adjusting its feet. Also make sure that the floor is strong
enough to carry the cooler/freezer, and level.
The items put onto the cooler/freezer may cause noise. >>>Remove the items
on top of the cooler/freezer.
There are noises coming from the cooler/freezer like liquid flowing, spraying,
etc.
Liquid and gas flows occur in accordance with the operating principles of your
cooler/freezer. It is normal and not a fault.
Whistle comes from the cooler/freezer.
Fans are used in order to cool the cooler/freezer. It is normal and not a fault.
Condensation on the inner walls of cooler/freezer.
Hot and humid weather increases icing and condensation. It is normal and not a
fault.
Doors are opened frequently or left ajar for a long time. >>>Do not open the
doors frequently. Close them if they are open.
Door is ajar. >>>Close the door completely.
Humidity occurs on the outside of the cooler/freezer or between the doors.
There might be humidity in the air; this is quite normal in humid weather. When
the humidity is less, condensation will disappear.
EN
26
Bad odour inside the cooler/freezer.
No regular cleaning is performed. >>>Clean the inside of the cooler/freezer
regularly with a sponge, lukewarm water or carbonate dissolved in water.
Some containers or package materials may cause the smell. >>>Use a different
container or different brand packaging material.
Food is put into the cooler/freezer in uncovered containers. >>>Keep the food
in closed containers. Microorganisms spreading out from uncovered containers
can cause unpleasant odours.
Remove the foods that have expired best before dates and spoiled from the
cooler/freezer.
The door is not closing.
Food packages are preventing the door from closing. >>>Replace the packages
that are obstructing the door.
The cooler/freezer is not completely even on the floor. >>>Adjust the feet to
balance the cooler/freezer.
The floor is not level or strong. >>>Make sure that the floor is level and capable
to carry the cooler/freezer.
Crispers are stuck.
The food is touching the ceiling of the drawer. >>>Rearrange food in the drawer.
