Compatible TV Size
This TV Wall Mount fits 32-65”
(81-165cm) TV screens
32-65”
Maximum TV Weight
This TV Wall Mount supports TVs
weighing up to 50kg
HOLDS
50
kg
Maximum Mounting Pattern
This TV Wall Mount has a mounting
hole pattern up to 400x600mm (HxW)
400x600mm
Hardware Kit Contents
ITEM DESCRIPTION QTY ITEM DESCRIPTION QTY
A Lag bolt 6
I M5 x 15mm Bolt
4
B Concrete anchor 6
J M6 x 30mm Bolt
4
C D5 Washer 4 K M6 x 15mm Bolt
4
D Spacer 4 L M8 x 30mm Bolt
4
E D6 Washer 6 M M8 x 15mm Bolt 4
F M4 x 30mm Bolt 4 N Wall Plate 1
G M4 x 15mm Bolt 4 O Mounting Arms 2
H M5 x 30mm Bolt 4 1
Fixed Position
This TV Wall Mount fixes your TV flat
to the wall without any movement and
sits 20mm from the wall
