Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352
Refrigerator
use & care
Introduction .......................................................2
Important Safety Information ....................3
Features ..............................................................6
Installation .........................................................8
Door Removal ................................................. 10
Door Handle Installation .............................14
Water Supply Connection .......................... 15
External Dispenser
Controls and Settings .................................. 17
Internal Dispenser
Controls and Settings .................................. 21
External Ice and Water Dispenser ......... 24
Internal Water Dispenser........................... 27
Internal Water Dispenser
Freezer Ice Maker ......................................... 28
Storage Features ..........................................29
Storing Food and Saving Energy ........... 33
Normal Operating Sounds ........................ 34
Filter Replacement ...................................... 35
Care and Cleaning .......................................38
Troubleshooting ............................................40
Limited Warranty .........................................44
A27727102 (February 2024)
INTRODUCTION
Doors
Handles are secure and tight
Door seals completely to cabinet on
all sides
Leveling
Refrigerator is level side-to-side and
slightly elevated in front to assist
with door and drawer closing (front
should be higher than back)
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to
refrigerator (Warning: Potable water
supply only.)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser operates
correctly
Final Checks
Shipping material removed
Fresh food and freezer temperatures set
Registration submitted
Installation Checklist
Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number
Serial Number
Purchase Date
jfdka; jfdk;a jfdk; jfdk;a j;da
jfdka; jfdk;a jfdk; jfdk;a j;da
Serial Number Location
2
WARNING
WARNING indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
3
IMPORTANT SAFETY INFORMATION
WARNING
Please read all instructions before using
this refrigerator.
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be
repaired only by trained service person-
nel. Use only manufacturer-authorized
service parts. Any repair equipment
used must be designed for flammable
refrigerants. Follow all manufacturer
repair instructions. Do not puncture
refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
4
IMPORTANT SAFETY INFORMATION
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regard-
ing flammability and other hazards.
• DO NOT operate the refrigerator in
the presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and
also destroy finishes if they come in
contact with other appliances
or furniture.
IMPORTANT
CFC/HCFC Disposal
Some old refrigerators may have a cool-
ing system that used CFCs or HCFCs
(chlorofluorocarbons or hydrochloro-
fluorocarbons). CFCs and HCFCs are
believed to harm stratospheric ozone if
released to the atmosphere. Other refrig-
erants may also cause harm to the envi-
ronment if released to the atmosphere.
If disposing of an old refrigerator, make
sure the refrigerant is removed for proper
disposal by a qualified technician. Inten-
tionally released refrigerant may subject
one to fines and imprisonment under
provisions of environmental legislation.
Before disposing an old
refrigerator/freezer:
• Remove doors.
• Leave shelves in place so children
may not easily climb inside.
• Have refrigerant removed by a
qualified service technician.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
Child Safety
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the refrigerator is
unpacked. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
Proper Disposal of Refrigerator
or Freezer
Risk of child entrapment
Child entrapment and suocation are not
problems of the past. Junked or aban-
doned refrigerators or freezers are still
dangerous – even if they will sit for “just
a few days”. When disposing of an old
refrigerator or freezer, please follow the in-
structions below to help prevent accidents.
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with the utility company or visit energy-
star.gov/recycle for more information on
recycling an old refrigerator.
5
IMPORTANT SAFETY INFORMATION
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Electrical information
• The refrigerator must be plugged
into its own dedicated 115 Volt, 60
Hz., 15 Amp, AC only electrical outlet.
The power cord of the appliance
is equipped with a three-prong
grounding plug for protection against
electrical shock hazards. It must
be plugged directly into a properly
grounded three prong receptacle.
The receptacle must be installed in
accordance with local codes and
ordinances. Consult a qualified
electrician. Avoid connecting
refrigerator to a Ground Fault
Interrupter (GFI) circuit. Do not use
an extension cord or adapter plug.
• If the power cord is damaged, it
should be replaced by an authorized
service technician to prevent any risk.
• Never unplug the refrigerator by
pulling on the power cord. Always
grip the plug firmly, and pull straight
out from the receptacle to prevent
damaging the power cord.
• Unplug the refrigerator before
cleaning and before replacing a light
bulb to avoid electrical shock.
• Performance may be aected if
the voltage varies by 10% or more.
Operating the refrigerator with
insucient power can damage the
compressor. Such damage is not
covered under the warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the refrigerator
from being turned o accidentally.
NOTE
This unit is equipped with a cooling system
where one of the Refrigerator/ Freezer
sections may cool slower than the other
initially. Allow 24 hours for unit to stabilize
and reach the desired temperatures.
IMPORTANT
Accessories are available for refrigerator and can be purchased at Frigidaire.com or
by calling 1-800-374-4432.
6
FEATURES
A Anti-tip Leg
B Lower Freezer Basket
C Upper Freezer Basket
D Custom-Flex™ Temp Drawer
E Ice/Water Dispenser
F External Appliance Control Display
G Adjustable Hinges
H Door Bin
I Flipper Mullion
J Ice Chute
K Ice Maker
L Flipper Guide
M Water Filter
N Dairy Compartment
O Air Filter
P Shelves
Q Adjustable Door Bin
R
CrispSeal
�
Fresh Crispers
S Gallon Door Bins
A
B
C
D
G
E
S
J
I
K O
N
P
Q
R
A
M
L
P
P
H
F
G
H
S
External Water Dispenser Model
7
IMPORTANT
Accessories are available for refrigerator and can be purchased at Frigidaire.com or
by calling 1-800-374-4432.
FEATURES
A Anti-tip Leg
B Lower Freezer Basket
C Upper Freezer Drawer
D Ice Bin
E Ice Maker
F Custom-Flex™ Temp Drawer
G Adjustable Hinges
H Door Bin*
I Internal Water Dispenser
J Appliance Control Display
K Flipper Mullion
L Flipper Guide
M Air Filter
N Water Filter
O Dairy Compartment*
P Shelf
Q Adjustable Door Bin
R CrispSeal
®
Fresh Crispers
S Gallon Door Bins
R
H
K
L
J
I
A
B
C
D
F
G
S
M
O
P
R
N
G
A
H
H
Q
P
P
S
E
H
Internal Water Dispenser Model
CAUTION
Do Not install the refrigerator where
the temperature will drop below 55°F
(13°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside
the refrigerator.
WARNING
Installation
Allow the following clearances
for ease of installation, proper air
circulation, and plumbing and electrical
connections:
Sides & Top ⅜" (9.5 mm)
Back 1" (25.4 mm)
WARNING
This appliance is intended for use
in residential household and similar
interior applications such as:
• a kitchen/kitchenette
• a pantry room
• a basement
• an enclosed garage
• other interior
residential-type environments
8
INSTALLATION
This Use & Care Manual provides general
installation and operating instructions for
this model. We recommend using a service
or kitchen contracting professional to
install the refrigerator. Use the refrigerator
only as instructed in this Use & Care
Manual. Before starting the refrigerator,
follow these important first steps.
Location
• Choose a place near a grounded, non-
GFCI, electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator
out of direct sunlight and away
from the range, dishwasher, or
other heat sources.
• You must install the refrigerator on a
floor that is level and strong enough
to support a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic
ice maker.
Door opening
Position the refrigerator to allow easy
access to a counter when removing
food. For best use of the refrigerator
drawers and freezer baskets, position the
refrigerator where you can fully open both.
Tools Necessary:
Phillips Head
or
Quadrex Head
Screwdriver
(OR)
OR
8mm Socket
Wrench
Adjustable
Wrench
OR
⅜"
Fixed
Wrench
ANDAND
6mm
Allen Wrench
NOTE
If you place the refrigerator with the
door hinge side against a wall, allow
additional space so you can open the
door wider.
9
INSTALLATION
Cabinet Leveling & Refrigerator
Door Alignment (if necessary)
Guidelines for final positioning of refrigerator:
• Rest all 4 corners of the cabinet
firmly on the floor.
• Slightly elevate the front to ensure
the doors close and seal properly.
• Align and level the doors with
each other.
Meet most of these conditions by raising
or lowering the adjustable anti-tip legs.
To level the cabinet using the anti-tip legs:
1. Slightly open freezer drawer.
2. Lower anti-tip legs until they are
both touching the floor. Use a pair of
pliers to adjust.
To raise unit: turn leg clockwise
(as shown).
To lower unit: turn leg counterclockwise.
Raise
Flipper Mullion
Adjust the flipper mullion for proper
connection with the mullion guide by ensuring
the flipper mullion is folded and perpendicular
to the fresh food door. If the mullion guide is
not in the correct position, it could prevent
the door from closing completely.
WRONG
Anti-Tip
Legs
3. Ensure both doors are bind-free with
their seals touching the cabinet on all
4 sides and that the cabinet is stable.
Door
Door
Door
Door
To make final door height adjustments:
1. Open Custom-Flex Temp drawer to
make the lower hinge visible.
2. Insert 6 mm Allen
TM
wrench into the
shaft of the lower hinge.
To lower door: turn the adjustment
screw clockwise.
To raise door: turn the adjustment
screw counterclockwise
(as shown below).
12.25 in
8.75 in
1 in
1 in
36.75 in
933.4 mm
25.4 mm
.37 in
9.5 mm
.37 in
9.5 mm
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury, or damage to the
doors or handles.
10
DOOR REMOVAL
Getting through narrow spaces
If your refrigerator will not fit through an
entrance area, you can remove the doors.
Check first by measuring the entrance.
To prepare for removing the doors:
1. Unplug the electrical power cord
from the wall outlet.
2. Remove any food from the door
shelves and close the doors.
To remove the refrigerator doors:
1. Open doors to 90°.
2. Remove all 5 Phillips
TM
screws from
top hinge cover and lift up. You can
easily access 3 Phillips screws. You
can access the other 2 screws by
removing the 2 panels from the top
hinge cover as shown.
5. Pull up on water line gently to
remove from door.
3. Trace lightly around the door’s top
hinges with a pencil. This makes
reinstallation easier.
4. Disconnect any electrical harnesses
running from the doors to the
hinge cover.
NOTE
Use care while pulling the water tube
from the door to be sure the tube does
not kink.
NOTE
You will pull approximately 4' of water
tube from the refrigerator door.
11
6. Remove three 8 mm bolts from both
top hinges. Lift doors up o lower
hinges and carefully set aside.
x2
Lower Hinge Removal
8. To reinstall the doors, reverse
the procedure.
7. In certain circumstances, you may need
to remove the lower hinges for clearance
purposes. To gain access to the lower
hinges, first extend the Custom-Flex
Temp Drawer. Unscrew the 3 lower hinge
screws and slide the hinge inward.
DOOR REMOVAL
IMPORTANT
Make sure the water line tubing goes
through the hole at the top of the
dispenser pocket. A metal wrap on the
tubing prevents damage from the hinge
rubbing against it. You need to fix this
back around the tube in the proper loca-
tion upon reinstallation to protect the
tube from the hinge.
External Dispenser Model
Internal Dispenser Model
12
4. Remove the screw and the retaining
clip and disconnect the harness
5. To fully remove drawer from
cabinet, press the tabs on both
sides, and slide the rails past the
clips on both sides.
Once both doors are in place, ensure they
are aligned with each other and level
(Reference INSTALLATION for more de-
tails), and replace the top hinge cover.
To remove the Custom-Flex Temp Drawer
1. Fully open the drawer.
2. Remove the basket from the drawer.
3. Unsnap the 4 cable ties by pressing
clip sides together and pushing
them through the opening.
NOTE
When reinserting the water tube and
replacing the top hinge cover, carefully
ensure the tube does not kink.
DOOR REMOVAL
CAUTION
Drawer is heavy. Use caution when lifting.
13
DOOR REMOVAL
To reinstall the Custom-Flex Temp Drawer
1. Place the drawer with the brackets
and sliders inside the compartment
and click the sliders into place on
each side.
2. Reconnect the cabinet harness.
3. Replace the retaining clip and secure it
with the screw.
4. Reattach the electrical harness by
positioning the cable clips over the
black markings on the harness and
push the 4 cable clips through the
openings in the rail to secure the
harness in place.
5. Slide the basket into place.
6. Close the drawer.
To remove the freezer drawer
1. Open the drawer and fully extend it.
2. Remove the upper freezer drawer.
3. Remove the lower freezer basket.
4. Inside the cabinet, press the tab on
both sides to release the sliders.
5. Remove the drawer with brackets
and sliders.
To reinstall the freezer drawer
1. Place the drawer with brackets and
sliders inside the cabinet and click
into place.
2. Replace the lower freezer basket
first, and then the upper freezer
basket. Ensure the upper freezer
basket rollers are seated correctly
into the tracks before closing the
freezer drawer.
NOTE
For additional instructions, see
STORAGE FEATURES.
1
2
3
4
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
14
NOTE
Tighten all set screws so the screw is below the surface of the handle. Draw the
handles tight to the doors/drawer with no gaps. Open the opposite door while
tightening the Allen screw to make installation easier.
The door handle may loosen over time if you installed it improperly. If this happens,
tighten the set screws on the handles.
Door Handle Mounting Instructions
Mounting Refrigerator Handles
DOOR HANDLE INSTALLATION
NOTE
When tightening the Allen set screws, you must apply force to the longer arm of the
Allen wrench supplied in the handle packaging.
1. Remove the handles from the
carton and any other protective
packaging.
2. Position the fresh food handle
end caps over the upper and
lower pre-installed shoulder bolts
(A) fastened into door, ensuring
the holes for the set screws are
facing toward the opposite door.
3. While holding the handle firmly
against door, fasten the upper
and lower Allen set screws (B)
with the supplied Allen wrench.
4. Repeat steps 2 and 3 to install
opposite handle. Ensure the
holes for the set screws are
facing toward the first door.
CAUTION
To Avoid Property Damage:
• We recommend copper or stainless
Steel braided tubing for the water
supply line. We do not recommend
using water supply tubing made of
¼ in. plastic. Plastic tubing greatly
increases the potential for water
leaks, and the manufacturer will not
be responsible for any damage if you
use plastic tubing for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
water softener can damage the ice
maker. If a water softening system
is present, ensure you maintain the
softener and it is working properly.
15
WATER SUPPLY CONNECTION
IMPORTANT
Ensure the water supply line connections
comply with all local plumbing codes.
To install the water supply line, you need
the following:
• Basic Tools: adjustable wrench,
flat-blade screwdriver, and Phillips
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100psi.
• A water supply line made of ¼"
(6.4mm) OD, copper or braided
stainless steel tubing. To determine
the length of tubing needed, measure
the distance from the main water inlet
valve at the back of the refrigerator
to the cold water pipe. Then add
approximately 6' (1.8m), so you can
move the refrigerator out for cleaning.
• A shuto valve to connect the water
supply line to the household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
• A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the main water
inlet valve.
IMPORTANT
The refrigerator’s water supply system
includes several tubing lines, a water filter,
and a water valve. To ensure the water
dispenser works properly, completely
fill this system with water when you first
connect the refrigerator to the household
water supply line.
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the refrigerator from
electrical power before connecting a
water supply line to the refrigerator.
NOTE
Check with local building authority for
recommendations on water lines and
associated materials prior to install-
ing refrigerator. Depending on local/
state building codes, we recommend
for homes with existing valves its Smart
Choice
®
water line kit 5304437642 with
a 6' (1.8 meters) braided Stainless Steel
Water Line. Please refer to
Frigidaire.com for more information.
NOTE
Expect the first ice harvest within the first
24hours of unit operation. To prevent any
issues concerning ice production, please en-
sure you prime all water lines. See Priming
the water supply system in the AUTOMAT-
IC ICE AND WATER DISPENSER section.
16
WATER SUPPLY CONNECTION
To Connect Water Tube to
Household Water Supply
1. Disconnect
refrigerator
from electrical
power source.
2. Place the end
of the water
supply line
into a sink or
bucket. Turn
ON the water
supply and
flush the supply
line until the
water is clear.
Turn OFF the
water supply at the shuto valve.
Place ½" wrench
here. Do not turn.
Place ½" wrench
here. Turn
clockwise.
6. Replace the connected tubes into
the clips and lock the clips back
in place to keep the tubing in the
right position.
7. Turn ON the water supply at
the shuto valve and tighten any
leaky connections.
8. Reconnect refrigerator to an
electrical power source.
9. Ensure the ice maker is turned ON.
10. Purge air from the Ice and Water
Dispenser System by operating the
water dispenser for 3-4 minutes. This
will require dispensing several glasses
of water.
3. Open the locking
clips and grab
the water line
coming from
the refrigerator.
Remove the
plastic cap
from the water
inlet fitting and
discard the cap.
4. If using (recommended) stainless
steel braided tubing - the nut and
ferrule are already assembled on
the tubing. Slide the compression
nut onto the water inlet fitting and
finger tighten.
5. Using two ½" wrenches (one to hold
the household water line nut and the
other to hold the water inlet fitting
nut), tighten a half turn with the
wrench. DO NOT over tighten.
Water
inlet
fitting
Plastic
tubing
to
water
valve
6 ft. (1.8 Meters) Stainless
Steel water line from
household water supply line
Connection to Household Water Supply
with 1/4" compression
fitting
Plastic
Cap
Remove
plastic cap
from water
inlet fitting
Water Inlet
Brass
Fitting
¼ inch
plastic tube
to water
valve
To
household
water
supply
To
unit
water valve
17
Awake Mode Display
Awake Mode
To change from sleep mode (on) to awake mode (o), simultaneously press and hold
Crush and
for 5 seconds. The display will show the current temperature/ice maker
status. A tone will confirm.
Sleep Mode Display
Sleep Mode
As a default, the display will go to sleep after a short time. If you press any icon, you
will awaken the display. After a short time, it will go back to sleep. When in sleep
mode, wake up the display to confirm the ice maker is On/O. Turn o sleep mode to
have the display on full time (awake mode). When sleep mode is O, the display will
always illuminate. To turn sleep mode On/O, simultaneously press and hold Crush
and for 5 seconds. A tone will confirm.
EXTERNAL DISPENSER
CONTROLS AND SETTINGS
18
EXTERNAL DISPENSER
CONTROLS AND SETTINGS
1
Freeze Boost (on/o)
Prior to grocery shopping, activate
Freeze Boost so newly purchased
food designated for the freezer will
be preserved as quickly as possible.
It automatically deactivates after
12 hours.
2
Cold Drink Timer
Quickly chills a drink inside the
freezer compartment. To enable,
touch Cold Drink Timer. A time
value (in minutes) will appear on
the freezer temp display and can
be changed using the +/— buttons.
A tone will sound when you input
the time. The range is from 20-45
minutes in 5 minute intervals. Drinks
will freeze if the temperature setting
is too low or the timer setting is
too long.
3
Ice Maker
Press and hold for 3 seconds to
turn the ice maker on/o. When the
indicator is lit, the ice maker is on.
When the ice maker is OFF, the Ice
Maker O indicator is lit. When the
ice maker is OFF, it stops making ice.
When you enable the sleep mode,
wake the display to confirm the ice
maker is on/o (see Sleep Mode
section). While o, you can continue
dispensing ice as long as ice is in the
bucket. When the ice maker is o
and ice is dispensing, the indicator
above Ice Maker and Ice Maker O
both blink.
4
Use the lock button to lock the
display preventing it from being
used in certain situations. Press and
hold for 3 seconds to enable/dis-
able. While locked, you can make no
changes to settings on the display.
Dispensing ice and water are dis-
abled. The indicator will flash and
an audible warning will sound.
5
Power Outage
In the event of a power failure,
Power Outage illuminates once you
restore power and a tone sounds.
The alert only illuminates if the
refrigerator or freezer reached
unsafe temperatures during the
outage. Press any button to silence
the tone.
10
1
2
3
4
5
6
7
9
8
11 12
13
14
15
16
17
WARNING
When using the Cold Drink Timer, make
sure to remove drinks from freezer
compartment when the alarm sounds.
Carbonated drinks may explode if left in
the freezer for too long.
19
6
Adjusting Temp
Illuminates when you change
temperatures on the display and will
remain illuminated until the desired
temperatures are reached inside
the refrigerator and freezer. Press
either the + or — to adjust to desired
temperature setting.
Freezer temp
Control temperatures range from
-6°F / -21°C to 6°F / -15°C.
Refrigerator temp
Control temperatures range from
34°F / 1°C to 44°F / 7°C.
7
Door Open
Illuminates whenever you open the
doors. If you leave a door open for
5 minutes or more, an alarm will
sound and the display will illuminate
until you shut the door. Pressing any
button mutes the alarm temporarily.
Check to make sure no food is
blocking the doorway.
8
Replace Water Filter
Illuminates every 6 months or when
the filter needs replacing. After
you replace with an authentic filter
and complete the authentication
process, the warning on the display
should disappear. See FILTER
REPLACEMENT for more information.
9
Replace Air Filters
Display illuminates every 6 months
or when filter needs replacing.
Replace the filter and then press
and hold Reset Air Filter for 3
seconds to deactivate warning on
display. See FILTER REPLACEMENT
for more information.
10
Water
Press Water to dispense water. An
indicator light illuminates above the
active feature.
11
Cube
Press Cube to dispense cubed ice.
An indicator light illuminates above
the active feature.
12
Crush
Press Crush to dispense crushed ice.
An indicator light illuminates above
the active feature.
13
°F/°C
To toggle between Fahrenheit (°F)
and Celsius (°C), simultaneously
press and hold + and — for 5 seconds
on the refrigerator side of display.
14
Chill Boost
Chill Boost is a faster rate for chilling
food in the refrigerator compartment.
Use this feature when loading several
items into the refrigerator at one
time. It deactivates after 6 hours.
15
Reset Air Filters
After replacing the filter, press and
hold for 3 seconds to reset.
16
Water Filter
Your appliance is equipped with an
electronically authenticated water filter.
If an error relating to authentication
occurs, press and hold Water Filter for
3 seconds to delay the alert. See FILTER
REPLACEMENT for more information.
17
Toggles dispenser light On and
O. Press and hold for 5 seconds
to enable ambient lighting. Once
enabled, press and hold for 2
seconds to disable ambient lighting
IMPORTANT
If food is freezing in the fresh food
compartment, increase the temperature
setting 1 or 2 degrees.
IMPORTANT
Placing food within 1" in front of the air
ports may cause food to freeze.
NOTE
The recommended settings for a product
installed in a kitchen is 37°F for the fresh
food compartment and 0°F for the freezer.
EXTERNAL DISPENSER
CONTROLS AND SETTINGS
NOTE
This unit is equipped with a cooling system
where one section (Refrigerator/ Freezer)
may cool slower than the other initially.
Allow 24 hours for unit to stabilize and
reach the desired temperatures.
20
EXTERNAL DISPENSER
CONTROLS AND SETTINGS
Alarms
Power Outage
In the event of a power failure, the power
outage alert will illuminate once power
has been restored and a tone will sound.
The alert will only illuminate if the refrig-
erator or freezer reached unsafe tempera-
tures during the outage. Press any button
to silence the tone.
Water Filter
When illuminated, you need to replace
the water filter. Change the water filter
every 6 months or when 125 gallons of
water has been dispensed. Once you have
replaced the filter with a genuine authen-
tic filter, the alert should disappear after
30 seconds. A tone will sound once you
have reset it.
Air Filter
When illuminated, you need to replace
the air filter. Change the air filter every 6
months. To reset, press and hold Air Filter
for 3 seconds. A tone will sound once you
have reset it.
Door Open
If you leave a door open for 5 minutes or
more, an alarm sounds and Door Open
illuminates on the display. Turn the alarm
o by closing the door or pressing any
key. The appliance control display will re-
turn to normal operations after you close
the door.
High Temp
In the event of a high temperature condi-
tion, an alarm sounds. The appliance
control display will show HI on whichever
compartment the alarm is detected. An
alarm sounds for at least 10 seconds until
you acknowledge the alert. Reset this
alarm by touching any key or opening
a door.
Sabbath Mode
The Sabbath Mode disables portions
of the refrigerator and its controls in
accordance with observance of the
weekly Sabbath and religious holidays
within the Orthodox Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding both
the FZ— and FF+ for 5 seconds. Other
than the High Temp alarm, no audible
sounds occur until you exit the Sabbath
mode. The display shows Sb while in
Sabbath Mode.
In the Sabbath Mode, the High Temp
alarm is active for health reasons. For
example, if you leave the door ajar,
the High Temp alarm activates. The
refrigerator functions normally, once
you close the door, without any violation
of the Sabbath/Holidays. The High
Temp alarm sounds when the cabinet
temperature is outside the safe zone for
20 minutes. The alarm silences itself after
10 minutes while High Temp stays lit until
you exit the Sabbath Mode.
For further assistance, guidelines
for proper usage and a complete
list of models with the Sabbath
feature, please visit the web at
star-k.org.
NOTE
Control features and alarms may vary
by model.
NOTE
While in Sabbath Mode, neither the
lights, dispenser, nor the appliance con-
trol display will work until you deacti-
vate the Sabbath Mode.
Refrigerator stays in Sabbath Mode
after power failure recovery. You must
deactivate it with the buttons on the
appliance control display.
NOTE
Although you have initiated the Sab-
bath Mode, the ice maker will complete
the cycle it had already started. The
ice cube compartment remains cold
and you can make new ice cubes with
standard trays.
21
INTERNAL DISPENSER
CONTROLS AND SETTINGS
Your display is equipped with a sleep and lock mode to prevent accidental changes
to the unit settings during opening and closing of the doors. When both doors are
closed, the display is in sleep mode. When either door is first opened, the display is in
lock mode where all the current settings are visible but dimmed.
Pressing any button on the display awakens the display and a tone sounds. All
settings will then fully light. Touch the display again to change any setting.
If you do not press a button for 10 seconds while any door is open, the display
defaults back to lock mode.
Awake Mode Display Lock Mode Display Sleep Mode Display
22
INTERNAL DISPENSER
CONTROLS AND SETTINGS
1
CONTROL LOCK
Use to lock the display. Press and
hold
for 3 seconds to enable/
disable. The indicator flashes and
an alert sounds when CONTROL
LOCK is enabled. You cannot
make changes on the display
while the lock is engaged.
2
EXTERIOR LIGHT
Your appliance has exterior lights
under the refrigerator doors and
the Custom-Flex Temp drawer.
Press and hold for 5 seconds
to enable the lights. The lights
will remain on until you disable
them by pressing and holding
for 2 seconds.
2
10
9
87
65
4
3
1
3
Temp Settings
Select compartment for tem-
perature change (FREEZER or RE-
FRIGERATOR). Press either the +
or — to adjust to desired tempera-
ture setting.
Freezer temp - Control tempera-
tures range from -6°F / -21°C to
6°F / -15°C.
Refrigerator temp - Control tem-
peratures range from 34°F / 1°C
to 44°F / 7°C.
4
Clear Alerts
Resets any alarms that are active
and illuminated on the display (Door
Open, High Temp, Power Outage).
NOTE
The recommended settings for a prod-
uct installed in a kitchen is 37°F for the
fresh food compartment and 0°F for
the freezer.
NOTE
This unit is equipped with a cooling
system where one section (REFRIGERA-
TOR/ FREEZER) may cool slower than
the other initially. Allow 24 hours for
unit to stabilize and reach the desired
temperatures.
23
INTERNAL DISPENSER
CONTROLS AND SETTINGS
Clear Alerts
Door Open
If the freezer or fresh food doors have
been left open for 5 minutes or more, an
alarm will sound and the door ajar indica-
tor will illuminate on the display. Press
Clear Alerts to reset any system alarms.
High Temp Alarm
High temp will illuminate next to Clear
Alerts. Alarm plays every 60 seconds. Press
Clear Alerts to acknowledge the alarm The
highest temp value will be displayed when
the alarm is first acknowledged.
Power Outage
In the event of a power failure, the power
fail alert will be illuminated. Press Clear
Alerts to acknowledge the alarm. Other
modes may be turned o until the alarm is
acknowledged. While a power failure alert is
displayed on the control panel, the unit will
Sabbath Mode
The Sabbath Mode is a feature that
disables portions of the refrigerator
and its controls in accordance with
observance of the weekly Sabbath and
religious holidays within the Orthodox
Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding both
- and Temp F-C for 5 seconds. Other than
the High Temp alarm, no audible sounds
will occur until the user exits the Sabbath
mode. The display shows Sb while in
Sabbath mode.
In the Sabbath Mode, the High Temp
alarm is active for health reasons. For
example, if the door is left ajar the High
Temp alarm is activated. The refrigerator
will function normally once the door
is closed, without any violation of the
Sabbath/Holidays. The High Temp alarm
is permitted when cabinet temperature is
outside the safe zone for 20 minutes. The
alarm silences itself after 10 minutes while
High Temp stays lit until the Sabbath
mode is exited.
For further assistance, guidelines
for proper usage and a complete
list of models with the Sabbath
feature, please visit the web at
star-k.org.
NOTE
While in Sabbath Mode, neither the lights,
dispenser, nor the control panel will work
until you deactivate Sabbath Mode.
The refrigerator stays in Sabbath Mode
after power failure recovery. You must
deactivate it with the buttons on the ap-
pliance control display.
NOTE
Although you have initiated the Sab-
bath Mode, the ice maker will complete
the cycle it had already started. The
ice cube compartment will remain cold
and you can make new ice cubes with
standard trays.
5
Freeze Boost
Prior to grocery shopping,
activate Freeze Boost so newly
purchased food designated for
the freezer will be preserved as
quickly as possible. It automati-
cally deactivates after 12 hours.
6
Temp F•C Press to toggle display
settings between Fahrenheit (°F)
and Celsius (°C).
7
Water Dispenser
Press and hold for 3 seconds to
enable/disable the water dispenser.
When enabled, the LEDs above
Water Dispenser illuminate.
8
Default Settings
Press and hold for 3 seconds to
reset to default settings.
9
Water Filter
Your appliance is equipped with
an electronically authenticated
water filter. If an error relating to
authentication occurs, press and hold
Water Filter for 3 seconds to delay
the alert. See FILTER REPLACEMENT
for more information.
10
Air Filters
Status is shown at the right of
button. After replacing the filters,
press and hold for 3 seconds to
reset. Status resets to Good.
continue normal operation. The high temp
alarm may also be illuminated until a safe op-
erating range temperature has been reached.
CAUTION
For proper dispenser operation,
recommended water supply pressure
should fall between 30psi and 100psi.
Excessive pressure may cause the
system to malfunction.
IMPORTANT
The ice maker is turned on at the
factory so it can work as soon as the
refrigerator is installed. If it is not pos-
sible to connect a water supply, set the
ice maker’s On/O feature to O either
by using the display or by pressing
the switch (features vary by model).
Otherwise, the ice maker’s fill valve may
make a loud chattering noise when it
attempts to operate without water.
24
EXTERNAL ICE AND WATER DISPENSER
NOTE
The water dispenser has a built-in de-
vice that shuts o the water flow after
two minutes of continuous use. To reset
this shuto device, simply release the
dispenser paddle.
Ice Maker Operation & Care
After the refrigerator is installed properly
and has cooled for several hours, the ice
maker can produce ice within 24hours.
The ice maker will fill the ice bin from the
rear. Dispense some ice to force the ice
forward in the bin. This will allow the bin
to fill completely.
Ice Maker and Storage
Bin Capacity
Both counter depth and standard depth
model ice makers should produce 3.2 to
3.7 lbs of ice per 24 hours depending on
usage conditions. The counter depth ice
bin will hold about 4 lbs of ice, and the
standard depth ice bin will hold about 5
lbs of ice.
NOTE
After the initial 26 oz (750 ml), water
will remain room temperature until the
tank has refilled and been given enough
time to chill the next 26 oz (750 ml) of
water. May take up to 8 hours to chill.
Using the ice maker
after installation
Before making ice for the first time, be
sure to prime the water supply system.
Air in new plumbing lines can result in
two or three empty ice maker cycles.
Furthermore, if the system is not flushed,
the first ice cubes may be discolored or
have an odd flavor.
Priming the water supply system
Dispenser
1. Hold a glass against the paddle for
about 4 minutes to purge air from
the system.
2. Continue dispensing at least 1 full
gallon (3.6 L) of water and discard.
Turning the ice maker on and o
Press and hold Ice Maker on the external
appliance control display for 3 seconds to
turn ice production on and o.
Before dispensing water for the first
time, be sure to prime the water supply
system. If the system is not flushed, the
first glasses of water may have discolored
water or have an odd flavor.
CAUTION
If the water supply to the refrigerator is
softened, be sure the softener is properly
maintained. Chemicals from a water
softener can damage the ice maker.
IMPORTANT
Turning o the ice maker simply dis-
ables ice making. Existing ice can still be
dispensed, and water can be dispensed.
IMPORTANT
On occasion, unusually small ice cubes
may be noticed in the bucket or in dis-
pensed ice. This could occur in normal
operation of the ice maker. If happening
frequently, it may be an indication of
low water pressure or the water filter
needs to be replaced. As the water
filter nears the end of its useful life and
becomes clogged with particles, less
water is delivered to the ice maker dur-
ing each cycle. Remember, if it’s been
six months or longer since last chang-
ing the water filter, replace it with a
new one. Poor quality household water
may require the filter to be changed
more frequently.
25
NOTE
The ice maker also has a built-in plastic
signal arm that automatically stops ice
production when the ice bin is full. This
signal arm should not be used to manu-
ally stop the ice maker.
EXTERNAL ICE AND WATER DISPENSER
Ice maker/dispenser tips
• If refrigerator is not connected to a
water supply or the water supply is
turned o, turn o the ice maker as
described in the previous section.
• The following sounds are normal
when the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• If a large quantity of ice is needed
at one time, it is best to get cubes
directly from the ice bin.
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
bin as explained below.
• When dispensing cubed ice, it is
normal to have a small quantity of
little pieces along with the whole
cubes.
• To avoid splashing, dispense ice into
the container before adding liquids.
• It is normal for ice to fill to the top of
the ice bin.
Cleaning the ice maker
Clean the ice maker and ice bin at
regular intervals, especially prior to
vacation or moving.
1. Turn o the ice maker using the
button on the display.
2. Remove the ice bin by lifting upward
and pulling straight out.
3. Empty and carefully clean the ice
bin with mild detergent. Do not
use harsh or abrasive cleaners. Do
not place in dishwasher. Rinse with
clear water.
4. Allow the ice bin to dry completely
before replacing in the freezer.
5. Replace the ice bin. Turn the ice
maker on.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
26
EXTERNAL ICE AND WATER DISPENSER
Remove and empty the ice bin if:
• An extended power failure (one hour
or longer) causes ice cubes in the
ice bin to melt and refreeze together
after power is restored, jamming the
dispenser mechanism.
• The ice dispenser is used
infrequently. Ice cubes will freeze
together in the bin, jamming the
dispenser mechanism. Shake the
bin to loosen the cubes, or clean as
explained above.
Removing Ice Bin
27
Your refrigerator is equipped with a side
water dispenser mounted to the inside
face of the left hand refrigerator door.
Water dispenser OFF Water dispenser ON
Your appliance will arrive with the side
water dispenser already activated and
ready to use. To disable the water dispens-
er, press and hold Water Dispenser for 3
seconds. When the LEDs are lit above, the
water dispensing function is enabled.
To use the dispenser, place a cup against
the paddle and press to dispense water.
Priming the water supply system
CAUTION
For proper dispenser operation, the
recommended water supply pressure
should fall between 30psi and 100psi.
Excessive pressure may cause the
system to malfunction.
Before dispensing water for the first
time, be sure to prime the water supply
system. If the system is not flushed, the
first glasses of water may have discolored
water or have an odd flavor.
Using the dispenser
after installation
CAUTION
Hold the door with one hand while
dispensing water to keep the door from
moving and possibly dispensing water
on floor.
NOTE
If you prefer to keep the side water
dispenser disabled, use the appliance
control display to disable it by press-
ing and holding Water Dispenser for
3 seconds. When the LEDs are not
illuminated above Water Dispenser, the
dispenser will be disabled.
1. Hold a glass against the paddle for
about 4 minutes to purge air from
the system.
2. Continue dispensing at least 1 full
gallon (3.6 L) of water and discard.
INTERNAL WATER DISPENSER
NOTE
The water dispenser has a built-in device
that shuts o the water flow after 2
minutes of continuous use. To reset this
shuto device, simply release the paddle.
NOTE
If your glass doesn’t enable the paddle
due to size, use your finger to activate
the paddle for dispensing.
NOTE
Ensure you enable Water Dispenser on the
display (LEDs above the button are lit).
28
Ice maker tips
• The following sounds are normal
when the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
bin as explained below.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
Cleaning the ice maker
Clean the ice maker and ice bin at
regular intervals, especially prior to
vacation or moving.
1. Turn o the ice maker using
the switch. The indicator will
no longer illuminate.
2. Extend the upper freezer basket,
and then remove the ice bin.
3. Empty and carefully clean the ice
bin with mild detergent. Do not use
harsh or abrasive cleaners. Rinse
with clean water.
4. Allow the ice bin to dry completely
before replacing in the freezer.
5. Replace the ice bin. Turn the ice
maker on.
Remove and empty the ice bin if an
extended power failure (one hour or longer)
causes ice cubes in the ice bin to melt and
refreeze together after power is restored.
Remove the ice bin and shake to loosen
the cubes or clean as explained above.
Ice Maker Operation & Care
After you have properly installed the re-
frigerator, the ice maker can produce ice
within 24hours. When using the ice mak-
er for the first time, and in order for it to
work properly, you must clear air from the
water tubing and the filter. Furthermore,
you do not flush the system, the first ice
cubes may be discolored or have an odd
flavor. Once the ice maker begins making
ice, allow the bin to fill completely, and
then discard the first FULL bin of ice.
Ice Maker and Storage
Bin Capacity
Both counter depth and standard depth
model ice makers should produce 2 to
2.5 lbs. of ice per 24 hours depending on
usage conditions. The counter depth ice
bin will hold about 4.5 pounds of ice, and
the standard depth ice bin will hold about
7 to 7.5 lbs. of ice.
Turning the ice maker on and o
Press the power button to turn the ice
maker on (button should illuminate).
NOTE
The ice maker will only produce the ad-
vertised production rate if the product
is set at 0°F.
NOTE
The freezer ice maker fills in the center
of the ice bin. Occasionally move the
ice to the borders to allow the bin to
fill completely.
INTERNAL WATER DISPENSER
FREEZER ICE MAKER
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to
sudden temperature change. Allow
the glass shelves to stabilize to room
temperature before cleaning. Do not
wash in dishwasher.
29
STORAGE FEATURES
NOTE
Features may vary according to model.
Shelf positions can easily be adjusted in
the fresh food compartments as needed.
The shelves have mounting brackets that
attach to slotted supports at the rear of
each compartment.
Change the Position of a Shelf
1. Remove all food from the shelf.
2. Lift the front edge up and pull the
shelf out.
3. Replace by inserting the mounting
bracket hooks into the desired
support slots.
4. Lower the shelf and lock it
into position.
To adjust the flip shelf (External
Dispenser only):
1. Remove food from shelf.
2. Lift the right side edge of shelf
upwards and push to the left
towards ice maker.
Flip Shelf
Drawers
The refrigerator includes a variety of
storage drawers.
CrispSeal Fresh Crisper
Use our crisper to keep your produce fresh
for longer, or flip it around to use as an
open compartment to easily access items
such has beverages, yogurts or snacks.
Slide-Under Shelf
To adjust slide-under shelf:
1. Push front
half shelf
backward
toward the
rear of the
cabinet until
the rear half
shelf drops
down, and then gently continue
pushing the front half shelf back and
under the rear half shelf.
Flexible Storage with our Reversible Bin
Angle the bin up to reinstall
30
Removing CrispSeal Fresh Drawer
STORAGE FEATURES
Removing Auto Humidity
Control Membrane
Opening SnackZone
Recessed Snack Drawers
4. Remove the humidity membrane from
the housing by lifting up sliding over.
5. Clean humidity membrane with hot
soapy water.
6. Replace membrane in housing and
unit by reversing the steps above.
NOTE
We do not recommend replacing the au-
to-humidity membrane unless it becomes
damaged or ruined. If the membrane
becomes soiled, you can wash it with
soap and water. Ensure the membrane is
dry before replacing it in the unit.
To remove the auto humidity control
membrane for cleaning:
1. Reach to back of humidity control
cover.
2. Place fingers between the humidity
control and the back wall, pull up
on cover.
3. Pull cover toward the front of
cabinet and remove.
Removing Auto Humidity
Control Membrane
To remove the CrispSeal Fresh drawer
for cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove
the drawer.
SnackZone - Recessed Snack Drawers
These drawers are ideal for storage of deli
meats and cheeses.
To open: slide back the cover to allow
access to the drawers.
NOTE
Remove the crisper insert and the
Produce Keeper Plus filter before
washing the crisper.
IMPORTANT
Do not use the Custom-Flex
TM
Temp Drawer
to store fresh produce as these items may
freeze and cause damage to the fruits and
leafy vegetables stored in the drawer.
31
STORAGE FEATURES
Doors
Storage bins
The doors to the fresh food compartment
use a system of modular storage bins.
All of these bins are removable for easy
cleaning. Bins can be adjusted as needed.
Door bins are ideal for storing jars, bottles,
cans, and large drink containers. They
also enable quick selection of frequently
used items.
Adjustable door bins
Some models have adjustable door bins
that can be moved to suit individual needs.
To adjust the collapsible door bin:
1. Make sure bin is securely seated on
rail in door.
2. Grab one side of bin and place other
hand on adjustable side.
3. Pull on side of bin until the bin is
adjusted to desired width.
NOTE
It can be dicult to pull out the collapsible
bin. Some force may be required.
1 2 3 4 5 6
Using Your Custom-Flex Temp
Drawer Controls
1
The drawer automatically defaults to a
locked state to prevent any unwanted
use. To change the drawer’s settings, it
first needs to be unlocked. To unlock,
press and hold the UNLOCK icon for 3
seconds. It will automatically lock after
10 seconds without any interaction.
Custom-Flex Temp Drawer Dividers
To position
drawer dividers,
slide left or
right. For easier
repositioning,
dividers do not
lock but instead
use the weight
of stored items
to keep the
dividers in place.
Dividers may shift when opening/closing
drawer when fewer items are stored.
CAUTION
Do not store glass bottles in the Custom-
Flex Temp Drawer when the Temperature
setting is in Freezer, Meat/Seafood, or Cold
Drink modes. The glass may break and
shatter, causing physical harm and injury.
Freezer:
2
To change the drawer temperature
when in the freezer temp setting, use
the control panel display on the front
door. Changing the temp on the display
will change both the drawer temp
setting AND the freezer compartment.
Refrigerator:
3
Choosing Meat/Seafood will set drawer
temperature to 28°F (-2°C). A tone will
sound to confirm choice. Use this setting
for short term storage. Any meat to be kept
longer than two days should be frozen.
4
Choosing Cold Drinks will set drawer
temperature to 32°F (0°C). A tone will
sound to confirm choice.
5
Choosing Deli/Snacks will set drawer
temperature to 37°F (3°C). A tone will
sound to confirm choice.
6
Choosing Chilled Wine will set drawer
temperature to 45°F (7°C). A tone will
sound to confirm choice.
32
To remove upper freezer drawer:
1. Open freezer compartment completely.
2. Lift up and out to remove upper
freezer drawer.
3. Reverse the steps to reinstall drawer.
Freezer Drawer
Freezer Features
STORAGE FEATURES
NOTE
If basket is not resting on stabilizer bar retainer
clips, the drawer will not close properly.
Plastic Lower Basket Divider
Dividers
Grab hand hold on lower divider and pull
up slightly to slide to next position. (The
divider cannot be removed.)
IMPORTANT
There are wheels on the bottom of the
drawer. Make sure all wheels are aligned on
their respective tracks for proper function.
If drawer is not aligned properly, it will
cause problems with the door operation.
To move door bin side-to-side:
1. Tilt bin up so the back of the bin
is o the door but the hook is still
engaged.
2. Slide bin along rail to desired position.
3. Lower bin back into place.
To move door bin up or down:
1. Lift bin up disengaging the hook.
2. Move bin to desired rail location.
3. Push bin hook into rail engaging
the hook.
To remove freezer basket:
1. Open freezer compartment
completely.
2. Lift the
basket up
and remove.
3. Reverse
the steps
to reinstall
freezer
basket.
External Dispenser
Door Bins
Internal Dispenser
Door Bins
33
STORING FOOD AND SAVING ENERGY
Ideas for storing foods
Fresh food storage
• Keep the fresh food compartment
between 34°F and 44°F with an
optimum temperature of 37°F.
• Avoid overcrowding the refrigerator
shelves, which reduces air circulation
and causes uneven cooling.
• Avoid placing food in front of
air ports. (See CONTROLS AND
SETTINGS for illustration.)
Fruits and vegetables
• Store fruits and vegetables in crisper
drawers, where trapped moisture
helps preserve food quality for longer
time periods.
• Do not wash items until ready to use.
Remove excess water before placing
inside unit.
• Wrap any items that have strong
odors or high moisture content.
Meat
• Wrap raw meat and poultry separately
and securely to prevent leaks and
contamination of other foods or surfaces.
• Use the Custom-Flex
TM
Temp Drawer
to store meat/poultry for short-term
storage. Any meat to be kept longer
than two days should be frozen.
Frozen food storage
• Keep the freezer compartment at 0°F
(-18°C) or lower.
• A freezer operates most eciently
when it is at least ⅔ full.
Packaging foods for freezing
• To minimize food dehydration and quality
deterioration, use aluminum foil, freezer
wrap, freezer bags, or airtight containers.
Force as much air out of the packages as
possible and seal them tightly. Trapped air
can cause food to dry out, change color,
and develop an o-flavor (freezer burn).
• Wrap fresh meats and poultry with
suitable freezer wrap prior to freezing.
• Do not refreeze meat that has
completely thawed.
Loading the freezer
• Prior to grocery shopping, activate
Freeze Boost
so newly purchased
food designated for the freezer will
be preserved as quickly as possible.
• Activating Freeze Boost also will
help the freezer more eciently
maintain the selected temperature
after placing new purchases with
pre-existing frozen foods.
• Avoid adding too much warm food
to the freezer at one time. This
overloads the freezer, slows the
rate of freezing, and can raise the
temperature of frozen foods.
• Leave a space between packages, so
cold air can circulate freely, allowing
food to freeze as quickly as possible.
Ideas for saving energy
Installation
• Locate the refrigerator in the coolest
part of the room, out of direct
sunlight, and away from heating
ducts or registers.
• Do not place the refrigerator next to
heat-producing appliances such as a
range, oven, or dishwasher. If this is
not possible, a section of cabinetry or
an added layer of insulation between
the two appliances will help the
refrigerator operate more eciently.
• Level the refrigerator so that the
doors close tightly.
Temperature settings
• Refer to CONTROLS AND
SETTINGS for illustration and
recommended settings.
Food storage
• Avoid overcrowding the refrigerator
or blocking cold air vents. Doing so
causes the refrigerator to run longer
and use more energy.
• Cover foods and wipe containers
dry before placing them in the
refrigerator. This cuts down on
moisture build-up inside the unit.
• Organize the refrigerator to reduce
door openings. Remove as many
items as needed at one time and
close the door as soon as possible.
• Do not place a hot container directly
on a cold shelf. Remember, such an
extreme temperature change may
damage the glass.
34
NORMAL OPERATING SOUNDS
Understanding the sounds
coming from the refrigerator
High-eciency refrigerators may
introduce unfamiliar sounds. These
sounds normally indicate the refrigerator
is operating correctly. Some surfaces on
floors, walls, and kitchen cabinets may
make these sounds more noticeable.
The following is a list of major
components in the refrigerator and the
sounds they can cause:
A Evaporators Refrigerant through the
evaporators may create a boiling or
gurgling sound.
B Evaporator fans Sounds of air being
forced through the refrigerator by the
evaporator fans may be heard.
C Defrost heaters During defrost cycles,
water dripping onto the defrost
heaters may cause a hissing or sizzling
sound. After defrosting, a popping
sound may occur.
D Automatic ice maker When ice has
been produced, sounds of ice cubes
falling into the ice bin may be heard.
Ice maker fan, water valve activation,
and refrigerant gas fluid may create
sounds from its operation.
E Electronic control & automatic
defrost control These parts can
produce a snapping or clicking sound
when turning the cooling system on
and o.
F Condenser fan Sounds of air being
forced through the condenser may be
heard.
G Compressor Modern, high-eciency
compressors run much faster than
previous models. The compressor may
have a noticeable hum or pulsating
sound during operation.
H Water valves Make a buzzing sound
each time they open to fill the ice
maker.
I Drain pan (not removable) Sounds
of water dripping into the drain pan
during the defrost cycle may be heard.
J Condenser May create minimal sounds
from forced air.
K Motorized damper May produce a
light humming during operation.
L Ice dispenser When dispensing ice, a
snapping, clicking, or popping sound
may be heard.
NOTE
Energy ecient foam in the refrigerator
is not a sound insulator.
NOTE
During automatic defrost cycle, a red
glow in the back wall vents of the freez-
er compartment is normal.
A
BC
D
G
E
JI
K
A
L
H
F
35
FILTER REPLACEMENT
Ordering your replacement water filters
If you have not used the refrigerator for a
period of time (during moving for example),
change the filter before reinstalling the
refrigerator. To order your replacement
filters, please visit our online store at
Frigidaire.com, by calling toll-free at 1 (800)
372-4432, or by visiting the dealer where you
purchased your refrigerator. We recommend
you order extra filters when you first install
your refrigerator, and you replace your filters
at least once every 6 months.
Here are the product numbers to request
when ordering your water filters:
Models GRMS2773 and GRMN2872:
PurePour Connect PWF-1 FPPWFU01
Models GRMC2273 and GRMG2272:
PurePour Connect PWF-2 FPPWFU02
NOTE
When ordering replacement filters, please
reorder the same filter type that is cur-
rently in the refrigerator.
PurePour Connect™ PWF-1™ and
PWF-2™ Water Filters
Keep safe, great-tasting water flowing with
a PurePour Connect water filter. Using a
PurePour Connect water filter:
• Makes Safer Water Second Nature
PurePour Connect water filters are
certified to reduce contaminants* and
keep great-tasting water flowing for you
and your family.
• Produces Purity You Can Trust
Know for certain yourPurePour Connect
water filter is a protector. Counterfeits
and knockos put your refrigerator and
health at risk. Frigidaire Genuine Filters
are the smarter, safer choice.
• Every Drop Gives Back
Partnered on sustainability eorts, the
use of a PurePour Connect water filter
saves the cost of bottled water and cuts
back on plastic.
*Find the PurePour Connect PWF-1
Performance Data Sheet and PurePour
Connect PWF-2 Performance Data
Sheet located in the Guides and Manuals
section for your specific water filter on
Frigidaire.com.
Do not use with water that is microbiologi-
cally unsafe or of unknown quality without
adequate disinfection before or after the
system. Use systems certified for cyst reduc-
tion on disinfected waters that may contain
filterable cysts.
Test & certification results:
• Rated Capacity - 125 gal/453 L for Pure-
Pour and ice and water filter
• Rated service flow - .50 gal/min.
• Operating Temp.: Min. 33°F, Max. 100°F
• Maximum Rated Pressure - 100 lbs/in.²
• Recommended Minimum Operating
Pressure: 30 lbs/in²
Certified by IAPMO R&T against NSF/ANSI
Standards 42, 53, 401, CSA B483.1 and NSF/
ANSI/CAN 372 in PurePour Connect PWF-1
and PurePour Connect PWF-2 systems for
reduction of the claims on the Performance
Data Sheet*.
More about your Advanced
Water Filter
PurePour Connect
Authentication
(only Models GRMC2273 and GRMG2272)
Your refrigerator contains a water filter
authentication system to protect you from
the harm that can occur when using coun-
terfeit filters. We recommend you use only
the PurePour Connect water filter with this
appliance. Using any other filter can cause
an error (Er FA) to appear on the appliance
control display.
Errors can occur:
• If you remove and reinsert an authentic
expired filter into the appliance
• If you install an authentic, but
incorrect filter
• If you install a non-authentic filter
• If you do not install the filter properly
36
It is not necessary to turn the water
supply o to change the filter. Be ready
to wipe up any small amounts of water
released during the filter replacement.
1. Turn O the ice maker(s).
2. Pull the water filter cover forward
and the cover will drop down to
allow access to the filter.
3. Remove the filter by pushing on
the end/face of the filter (you
should hear a click as the cartridge
disengages the snap-in connector).
4. Slide the old water filter cartridge
straight out of the housing and
discard it.
5. Unpack the new filter cartridge.
Remove the 2 clear plastic cap
covers on the filter connector. Using
the alignment guide, slide the filter
gently into the filter housing until it
stops against the snap-in connector
at the back of the housing.
FILTER REPLACEMENT
Replacing your water filter
The water filter is located at the left side
of the Adjustable Temp Drawer. In general,
you should change the water filter every
6 months to ensure the highest possible
water quality. Water Filter Status on the
user interface prompts you to replace the
filter after a standard amount of water (125
gal/453 L for PurePour)
has flowed through
the system.
In the cases above, the appliance control
display may show an error code related to
the filter authentication, and Replace Water
Filter will appear on the display. You can still
use dispensing functions while the error dis-
plays. You can temporarily dismiss the error
twice by holding Water Filter for 3 seconds
to delay the alert each time it appears. On
the third appearance of the error, the error
code permanently displays on the appliance
control until you install a new authentic filter.
6. Push firmly until the cartridge snaps
into place (you should hear a click as
the cartridge engages the
snap-in connector).
7. Press a drinking glass against the
water dispenser while checking for
any leaks at the filter housing. Any
spurts and sputters that occur as
the system purges air out of the
dispenser system are normal.
8. Push the cover up toward the liner.
Then push the filter cover toward
the rear of the cabinet. The filter
cover will snap back into place.
9. After filling one glass of water,
continue flushing the system for about
4 minutes. See Priming the water
supply system for more information
10. Once you have properly installed the
filter, the authentication process may
take up to 30 seconds to complete.
After authentication is complete,
the filter status on the display will
automatically update based on the
condition of the filter
11. Turn on the ice maker(s).
37
PureAir PK-2 Produce Keeper Plus™
Keep fruits and vegetables fresher longer with
PureAir Produce Keeper Plus. Our produce
keeper absorbs ethylene gas, the natural gas
that causes produce to ripen quicker. Reduce
food waste, save money and enjoy fresh-
tasting produce with a longer storage life.
Ordering your replacement filter
Order replacement filters online at
Frigidaire.com, by calling 1-800-374- 4432 or
through the dealer from which the refrigera-
tor was purchased. We recommend replacing
filters at least once every 12 months.
Here is the product number to request
when ordering:
PureAir Produce Keeper Plus
FRPAPK2RF™
Installing the PureAir Produce Keeper Plus:
1. Remove the plastic wrapper. Insert the
packet into the holder in the rear of
the Crisper.
2. For optimal results, replace the
refill every 12 months along with your
air filter.
=
FILTER REPLACEMENT
CAUTION
DO NOT OPEN CLOTH POUCH. Keep out
of the reach of children.
DO NOT EAT. If ingested, seek medical
treatment immediately.
WASH HANDS AFTER HANDLING.
DO NOT SUBMERGE IN WATER.
Ordering your air filter
Order replacement filters online at
Frigidaire.com, by calling 1-800-374- 4432
or through the dealer from where you
purchased your unit.
Here is the product number to request
when ordering:
PureAir RAF-2 Air Filter FRGPAAF2
PureAir
®
RAF-2™Air Filter
(select models)
The air filter is located in the top center of
the fresh food compartment.
Replacing your air filter
To ensure optimal filtering of refrigerator
odors, change the air filter every 6
months (Replace Air Filter on the
appliance control display indicates
replacing the filter after 6 months).
1. Remove the
air filter cover
by squeezing
the top and
bottom of
the cover
together and
removing
from liner.
2. Remove the
old filter and
discard it.
3. Unpack the new filter and snap it
into the filter cover. The open face
(carbon media) of the filter should be
installed facing outward in the cover.
4. Replace the air filter cover by
squeezing the sides and snapping it
back into place.
5. To reset, press and hold Reset Air Filter
on the
appliance control display
for
3 seconds. Tone will sounds once it has
been reset.
IMPORTANT
When storing or moving refrigerator in freezing temperatures, be sure to completely drain
the water supply system. Failure to do so could result in water leaks when the refrigerator
is put back into service. Contact a service representative to perform this operation.
CAUTION
• Pull the refrigerator straight out to move it. Shifting it from side to side may damage
flooring. Be careful not to move the refrigerator beyond the plumbing connections.
• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces
with wet or damp hands.
NOTE
Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable
fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing
petroleum products on plastic parts, interior doors, gaskets, or cabinet liners. Do
not use scouring pads or other abrasive cleaning materials.
NOTE
When setting temperature controls to turn o cooling, power to lights and other electrical
components will continue until the power cord is unplugged from the wall outlet.
38
CARE AND CLEANING
Care & Cleaning Tips
Keeping the refrigerator clean maintains its appearance and prevents odor build-up. Wipe up
any spills immediately and clean the freezer and fresh food compartments at least twice a year.
• Always unplug the electrical power cord from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do not use razor blades or other sharp
instruments which can scratch the appliance surface.
• Do not remove the serial plate. Removal of the serial plate voids the warranty.
• Before moving refrigerator, raise the anti-tip brackets so the rollers will work
correctly. This will prevent the floor from being damaged.
Refer to the guide on the next page for details on caring and cleaning specific areas of refrigerator.
• Never use metallic scouring pads, brushes, abrasive cleaners, or strong alkaline
solutions on any surface.
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
Vacation and moving tips
Occasion Tips
Short
Vacations
• Leave refrigerator operating during vacations of 3 weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn automatic ice maker o and empty ice bucket, even if only away a few days.
Long
Vacations
• Remove all food and ice if leaving for one month or more.
• Turn the cooling system o (see CONTROLS AND SETTINGS for the
location of On/O) and disconnect the power cord.
• Turn the water supply valve to close.
• Clean interior thoroughly.
• Leave both doors open to prevent odors and mold build-up. Block
doors open if necessary.
Moving • Unplug the unit.
• Remove all food and ice.
• If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching surface.
39
CARE AND CLEANING
Care & Cleaning Tips
Part What To Use Tips and Precautions
Interior & Door
Liners
• Soap and water
• Baking soda and
water
Use two tablespoons of baking soda in
one quart of warm water. Be sure to wring
excess water out of sponge or cloth
before cleaning around controls, light
bulb or any electrical part.
Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.
Drawers & Bins • Soap and water Use a soft cloth to clean drawer runners
and tracks.
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature
before immersing in warm water.
Exterior &
Handles
• Soap and water
• Non Abrasive Glass
Cleaner
Do not use commercial household clean-
ers containing ammonia, bleach or alcohol
to clean handles. Use a soft cloth to clean
smooth handles or exterior. DO NOT use a
dry cloth to clean smooth doors.
Exterior &
Handles
(Stainless Steel
Models Only)
• Soap and water
• Stainless Steel
Cleaners such
as Frigidaire
ReadyClean™
Stainless Steel
Cleaner.
Never use CHLORIDE or cleaners with
bleach to clean stainless steel.
Clean stainless steel front and handles
with non-abrasive soapy water and a dish-
cloth. Rinse with clean water and a soft
cloth. Use a non-abrasive stainless steel
cleaner. These cleaners can be purchased
at most home improvement or major de-
partment stores. Always follow manufac-
turer’s instructions. Do not use household
cleaners containing ammonia or bleach.
NOTE: Always clean, wipe and dry with
the grain to prevent scratching. Wash the
rest of the cabinet with warm water and
mild liquid detergent. Rinse well, and wipe
dry with a clean soft cloth. Stainless steel
cleaning supplies can be purchased from
Frigidaire.com
40
TROUBLESHOOTING
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
Concern Potential Cause Common Solution
Automatic Ice Maker
Ice maker is
not making
any ice.
• Ice maker is turned o.
• Refrigerator is not con-
nected to water line or
water valve is not open.
• The water supply line
is kinked.
• The water filter is not
seated properly.
• The water filter may
be clogged with
foreign material.
• Press and hold the ice maker button
on the appliance control display for 3
seconds. The LED indicator illuminates
to indicate the ice maker is ON.
• Connect the unit to the household
water supply and ensure the water
valve is open.
• Ensure the supply line does not kink
when the refrigerator is pushed into
place against the wall.
• Remove and reinstall the water filter.
Be sure to seat it fully into the locked
position.
• If water dispenses slowly or not at all,
or if the filter is 6 months old or older,
replace it.
Ice maker is
not making
enough ice.
• Ice maker is producing less
ice than expected.
• The water filter may
be clogged with
foreign material.
• The water supply line
is kinked.
• Saddle valve on
cold water pipe is clogged
or restricted
by foreign material.
• Water pressure is extremely
low. Cut-o and cut-on
pressures are too low (well
systems only).
• Reverse osmosis system is
in regenerative phase.
• Heavy trac, opening
or closing of the
doors excessively.
• Both counter depth and standard
depth model ice makers should
produce 3.2 to 3.7 lbs of ice per 24
hours depending on usage conditions.
The counter depth ice bin holds about
4 lbs of ice, and the standard depth
ice bin holds about 5 lbs of ice.
• If water dispenses slower than normal,
or if the filter is 6 months old or older,
replace it.
• Ensure the supply line does not kink
when the refrigerator is pushed into
place against the wall.
• Turn o household water line valve.
Remove the valve. Ensure the valve
is not a self-piercing saddle valve.
Clean the valve. Replace the valve if
necessary.
• Have someone turn up the cut-o and
cut-on pressure on the water pump
system (well systems only).
• It is normal for a reverse osmosis
system to be below 20 psi during the
regenerative phase.
41
TROUBLESHOOTING
Concern Potential Cause Common Solution
Automatic Ice Maker (continued)
Ice cubes
are freezing
together.
• Ice cubes are not being
used frequently enough or
power has been interrupted
for prolonged time.
• Ice cubes are hollow
(shells of ice with water
inside). The hollow cubes
break open in the bin and
leak their water onto exist-
ing ice, which causes it to
freeze together.
• Remove the ice bin and discard the
ice. The ice maker will produce a
fresh supply. Use the ice at least twice
weekly to keep the cubes separated.
• This generally occurs when the ice
maker does not get enough water.
This is usually the result of a clogged
water filter or restricted water supply.
Replace the water filter and if the con-
dition still occurs, check to see if the
water valve is not turned on all the way
or if there is a kinked water supply line.
Dispenser
Dispenser will
not dispense
ice.
• No ice in the bin to
be dispensed.
• The refrigerator doors are
not completely closed.
• Dispenser paddle has been
pressed too long
and the dispenser motor
has overheated.
• See the Ice maker is not making any
ice section.
• Be sure the refrigerator doors are
completely closed.
• The motor overload protector will
reset in about 3 minutes and then you
can dispense ice.
Ice dispenser
is jammed.
• Ice has melted and frozen
around the auger due
to infrequent use,
temperature fluctuations,
and/or power outages.
• Ice cubes are jammed
between the ice maker and
the back of the ice bin.
• Remove the ice bin, thaw, and empty
the contents. Clean the container,
wipe dry, and replace it in the proper
position. When new ice is made, the
dispenser should operate.
• Remove ice cubes jamming
the dispenser.
Dispenser will
not dispense
water.
• Water filter is not
seated properly.
• Water filter is clogged.
• Household water line valve
is not open.
• Remove and reinstall the water filter.
For PurePour Connect, be sure to
push the filter in all the way until it
clicks into place and is secured inside
the water filter housing.
• Replace the filter cartridge. Be sure
to push the filter all the way in until it
clicks into place and is secured inside
the water filter housing.
• Open the household water line valve.
See CONCERN column AUTOMATIC
ICE MAKER.
Water not
cold enough.
• As warmer tap water goes
through the filter and
enters the water supply
system, the chilled water
is pushed through to the
dispenser. Once the chilled
water is used up, it will take
several hours to bring the
freshly replaced water to a
cooler temperature.
• Add ice to your cup or container
before dispensing water.
Note: Only the first 26 oz are chilled.
42
TROUBLESHOOTING
Concern Potential Cause Common Solution
Dispenser (continued)
Water has an
odd taste
and/or odor.
• Water has not been
dispensed for an extended
period of time.
• Unit not properly
connected to cold
water line.
• Draw and discard 10-12 glasses of
water to freshen the supply.
• Connect the unit to the cold
water line that supplies water to the
kitchen faucet.
Opening/Closing Of Doors/Drawers
Door(s) will
not close.
• Door was closed too hard,
causing other door to
open slightly.
• Refrigerator is not level.
It rocks on the floor when
moved slightly.
• Refrigerator is touching a
wall or cabinet.
• Food/packaging is
obstructing the door
from closing.
• Flipper mullion on left fresh
food door is not in the
correct position.
• Close both doors gently.
• Ensure floor is level and solid, and can
adequately support the refrigerator.
Contact a carpenter to correct a
sagging or sloping floor.
• Ensure floor is level and solid, and can
adequately support the refrigerator.
Contact a carpenter to correct a
sagging or sloping floor.
• Make sure there is no food/packaging
blocking the doorway.
• Ensure the flipper mullion is in the correct
position to allow the door to close. (See
Flipper Mullion in INSTALLATION.)
Drawers are
dicult to
move.
• Food is touching the shelf
on top of drawer.
• Track that drawers slide on
is dirty.
• Remove the top layer of items in
the drawer.
• Ensure the drawer is properly installed
on track.
• Clean drawer, rollers, and track.
See CARE AND CLEANING.
Running of Refrigerator
Compressor
does not run.
• Refrigerator is in
defrost cycle.
• Plug at electrical outlet is
disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• This is normal for a fully automatic
defrost refrigerator. The defrost
cycle occurs periodically, lasting
about 30 minutes.
• Ensure the plug is tightly pushed
into outlet.
• Check/replace the fuse with a 15-amp
time-delay fuse. Reset the circuit breaker.
• Check house lights. Call the local
electric company.
Refrigerator
seems to run
too much or
too long.
• The variable speed
compressor is designed
to run 100% of the time
except during the defrost
cycle. At times it will run
faster, such as after a
defrost cycle.
• It is normal for the compressor to
run continuously except during
defrost mode.
43
TROUBLESHOOTING
Concern Potential Cause Common Solution
Running of Refrigerator (continued)
One compart-
ment feels
cooler than
the other after
installation.
• This unit is equipped with
a refrigeration system
that changes between
compartments periodically.
• This is normal behavior right after
installation. Allow 24 hours for
the unit to stabilize and reach the
desired temperatures.
Digital Temperature Setting Display
Digital temper-
ature displays
an error.
• Electronic control
system has detected a
performance problem.
• For assistance with any errors or
codes flashing in the appliance control
display call 1-800-374-4432.
Water/Moisture/Frost Inside Refrigerator
Moisture
collects on
inside of refrig-
erator walls.
• Weather is hot
and humid.
• Flipper mullion
• The rate of frost buildup and internal
sweating increases.
• Adjust flipper mullion. (See Flipper
Mullion in INSTALLATION.)
Water collects
on bottom
side of drawer
cover.
• Vegetables contain and
give o moisture.
• It is not unusual to have moisture on
the bottom side of the cover.
• Both crispers contain an automatic
humidity control, which should adjust
automatically to the varying levels of
moisture inside the drawer without
creating additional condensation or
drying out the air inside the crisper
drawer, works with various types
of produce. If you notice excess
moisture, check to verify humidity
membrane is not damaged and
replace as necessary.
Water collects
in bottom
of drawer.
• Washed vegetables
and fruit drain while in
the drawer.
• Dry items before putting them in the
drawer. Water collecting in bottom of
drawer is normal.
Water/Moisture/Frost Outside Refrigerator
Moisture
collects on
outside of
refrigerator or
between doors.
• Weather is humid. • This is normal in humid weather.
When humidity is lower, the moisture
should disappear.
Food/Drinks in Fresh Food Compartment/Custom-Flex Drawer
Food is
freezing.
• Temperature setting is
too low.
• Temperature sensor is
covered by food (right side
of fresh food area).
• Food is covering the
air ports.
• Move the setting to a higher degree.
• Allow space for air flow to the sensor.
• Allow space between the air ports
and the food.
44
LIMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your date of
delivery, Electrolux will pay all costs for repairing or replacing any parts of this appliance that
prove to be defective in materials or workmanship when such appliance is installed, used and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be
readily determined.
2. Product that has been transferred from its original owner to another party or removed
outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship,
or for appliances not in ordinary household use or used other than in accordance with
the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use
your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other
consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service
calls, tolls, ferry trip charges, or mileage expense for service calls to remote areas,
including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but
not limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of
parts other than genuine Electrolux parts or parts obtained from persons other than
authorized service companies; or external causes such as abuse, misuse, inadequate
power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL
BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON
IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD
ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX SHALL NOT BE LIABLE
FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND
INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED
WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted
by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In
Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person
to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product
features or specifications as described or illustrated are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Frigidaire.com
1-800-374-4432
Frigidaire.ca
1-800-265-8352
owner support
accessories
service
Our home is your home. Visit us if you
need help with any of these things:
registration
(See your registration card
for more information.)
welcome home
