Frigidaire PRMC2290BF Smart Counter-Depth 4-Door User Manual

EN User Manual | Fridge Freezer

Welcome to our family

Thank you for bringing Frigidaire into your home! We see your purchase as the

beginning of a long relationship together.

This manual is your resource for the use and care of your product. Please read it

before using your appliance. Keep it handy for quick reference. If something doesn’t

seem right, the troubleshooting section will help you with common issues.

FAQ, helpful tips and videos, cleaning products, and kitchen and home accessories

are available at http://www.frigidaire.com.

We are here for you! Visit our website, chat with an agent, or call us if you need

help. We may be able to help you avoid a service visit. If you do need service, we

can get that started for you.

Let’s make it official! Be sure to register your product.

CONTENTS

1. IMPORTANT SAFETY INFORMATION................................................. 2

2. FCC INTERFERENCE STATEMENT.................................................... 5

3. FEATURES............................................................................................ 6

4. INSTALLATION......................................................................................7

5. DOOR REMOVAL.................................................................................. 9

6. DOOR HANDLE INSTALLATION........................................................ 14

7. WATER SUPPLY CONNECTION........................................................ 15

8. CONTROLS AND SETTINGS: EXTERNAL WATER DISPENSER

MODEL.....................................................................................................17

9. AUTOMATIC ICE AND WATER DISPENSER.....................................20

10. ICE MAKER........................................................................................22

11. STORAGE FEATURES......................................................................23

12. STORING FOOD AND SAVING ENERGY........................................ 26

13. NORMAL OPERATING SOUNDS..................................................... 27

14. FILTER REPLACEMENT................................................................... 28

15. CARE AND CLEANING..................................................................... 31

16. TROUBLESHOOTING....................................................................... 33

17. LIMITED WARRANTY........................................................................38

18. QUEBEC RIGHT TO REPAIR............................................................39

1. IMPORTANT SAFETY

INFORMATION

1.1 Keep a record for

quick reference

Model number

..........................................................

Serial number

..........................................................

Purchase date

..........................................................

2 ENGLISH

1.2 Serial number

location

jfdk

a; jfdk;a j

;

jfdk

;a j;da

jfdk

a; jfdk;a j

;

jfdk;a j;da

WARNING!

You must follow these guidelines to

ensure that your appliance’s safety

mechanisms are operating correctly.

1.3 Safety definitions

This is the safety alert symbol. It is

used to alert of potential personal

injury hazards. Obey all safety

messages that follow this symbol to

avoid possible injury or death.

DANGER

DANGER indicates an imminently

hazardous situation which, if not

avoided, will result in death or serious

injury.

WARNING!

WARNING indicates a potentially

hazardous situation which, if not

avoided, could result in death or

serious injury.

CAUTION!

CAUTION indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

IMPORTANT

IMPORTANT indicates installation,

operation or maintenance information

which is important but not hazard-

related.

1.4 Child safety

This appliance is not intended for

use by persons (including children)

with reduced physical, sensory or

mental capabilities, or lack of

experience and knowledge, unless

they have been given supervision or

instruction concerning use of the

appliance by a person responsible

for their safety.

Destroy or recycle the carton,

plastic bags, and any exterior

wrapping material immediately after

the appliance is unpacked. Children

should never use these items to

play. Cartons covered with rugs,

bedspreads, plastic sheets or

stretch wrap may become airtight

chambers, and can quickly cause

suffocation.

1.5 Important safety

instructions

DANGER

DANGER Risk of fire or

explosion. Flammable

refrigerant used. Do not use

mechanical devices to defrost

the appliance. Do not puncture

refrigerant tubing.

DANGER Risk of fire or

explosion. Flammable

refrigerant used. To be

repaired only by trained

service personnel. Use only

manufacturer-authorized

service parts. Any repair

equipment used must be

designed for flammable

refrigerants. Follow all

manufacturer repair

instructions. Do not puncture

refrigerant tubing.

ENGLISH 3

CAUTION!

CAUTION Risk of fire or

explosion due to puncture of

refrigerant tubing. Follow

handling instructions carefully.

Flammable refrigerant used.

This appliance is for storage only

and should not be used for any

other purpose.

Do not store or use gasoline or

other flammable vapors and liquids

in the vicinity of this or any other

appliance.

Do not store explosive substances

such as aerosol cans with a

flammable propellant in this

appliance.

Do not operate the appliance in the

presence of explosive fumes

Avoid contact with any moving parts

of automatic ice maker.

Remove all staples from the carton.

Staples can cause severe cuts, and

also destroy finishes if they come in

contact with other appliances or

furniture.

WARNING!

Do not use electrical appliances inside

the food storage compartments of the

appliance unless they are of the type

recommended by the manufacturer.

WARNING!

CALIFORNIA RESIDENTS ONLY

WARNING! Cancer and Reproductive

Harm http://www.P65Warnings.ca.gov

1.6 Proper disposal of

your appliance

CAUTION!

Risk of fire or explosion.

Dispose of the appliance

properly in accordance with the

applicable federal or local

regulations. Flammable

refrigerant used.

Risk of child entrapment

Child entrapment and suffocation

are not problems of the past.

Junked or abandoned appliances

are still dangerous – even if they will

sit for “just a few days”. If you are

getting rid of your old appliance,

follow the instructions below to help

prevent accidents.

We strongly encourage responsible

appliance recycling/disposal

methods. Check with your utility

company or visit http://

www.energystar.gov/recycle for

more information on recycling your

old appliance.

Before you throw away your old

appliance:

• Remove doors.

• Leave shelves in place so children may

not easily climb inside.

• Have it removed by a qualified service

technician.

4 ENGLISH

1.7 Electrical

information

• The appliance must be plugged into its

own dedicated 115 Volt, 60 Hz., 15

Amp, AC only electrical outlet. The

power cord of the appliance is

equipped with a three-prong grounding

plug for your protection against

electrical shock hazards. It must be

plugged directly into a properly

grounded three-prong receptacle. The

receptacle must be installed in

accordance with local codes and

ordinances. Consult a qualified

electrician. Do not use an extension

cord or adapter plug.

WARNING!

Avoid fire hazard or electric shock.

• If the power cord is damaged, it should

be replaced by an authorized service

technician to prevent any risk.

• Never unplug the appliance by pulling

on the power cord. Always grip the plug

firmly, and pull straight out from the

receptacle to prevent damaging the

power cord.

• Unplug the appliance before cleaning

and before replacing the light bulb to

avoid electrical shock.

• Performance may be affected if the

voltage varies by 10% or more.

Operating the appliance with

insufficient power can damage the

compressor. Such damage is not

covered under your warranty.

• Do not plug the unit into an electrical

outlet controlled by a wall switch or pull

cord to prevent the appliance from

being turned off accidentally.

• Do not pinch, knot, or bend the power

cord in any manner.

WARNING!

When positioning the appliance,

ensure the supply cord is not trapped

or damaged.

Do not locate multiple portable socket-

outlets or portable power supplies at

the rear of the appliance.

WARNING!

Do not, under any circumstances, cut,

remove, or bypass the grounding

prong (A). Always use the power cord

with a three-prong grounded plug and

grounding type wall receptacle.

2. FCC INTERFERENCE STATEMENT

This equipment has been tested and found

to comply with the limits for a Class B

digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to

provide reasonable protection against

harmful interference in a residential

environment. This equipment generates,

uses, and can radiate radio frequency

energy and, if not installed and used in

accordance with the instructions, may

cause harmful interference to radio

communications. However, there is no

guarantee that interference will not occur

in a particular installation. If this equipment

does cause harmful interference to radio

or television reception, which can be

determined by turning the device off and

on, the user is encouraged to try to correct

the interference by one or more of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

device and receiver.

• Connect the equipment into an outlet

other than the one used for the

receiver.

• Consult the dealer or an experienced

radio/TV technician for assistance.

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference, and

(2) This device must accept any

interference received, including

interference that may cause undesired

operation.

FCC CAUTION: Any changes or

modifications not expressly approved by

the party responsible for compliance could

ENGLISH 5

void the user’s authority to operate the

equipment.

Host Device Labeling

This device includes the following module.

Contains FCC ID: 2AIBX-NIULL

RF Exposure Statement

This equipment complies with FCC

radiation exposure limits set forth for an

uncontrolled environment. This equipment

should be installed and operated with

minimum 20 cm between the radiator and

your body. This transmitter must not be

collocated or operating in conjunction with

any other antenna or transmitter unless

authorized to do so by the FCC.

Industry Canada (IC) Statement

This Class B digital apparatus complies

with Canadian ICES-003.

This device complies with Industry Canada

license-exempt RSS standard(s).

Operation is subject to the following two

conditions: (1) this device may not cause

interference, and (2) this device must

accept any interference, including

interference that may cause undesired

operation of the device.

RF Exposure

The antenna (or antennas) must be

installed so as to maintain at all times a

distance minimum of at least 20 cm

between the radiation source (antenna)

and any individual. This device may not be

installed or used in conjunction with any

other antenna or transmitter.

Host device Labeling

This device includes the following module.

Contains IC: 2AIBX-NIULL

Canada: 21700-NIULL

Disclaimer: The software in this product

contains components that are based on

free and open source software. Electrolux

gratefully acknowledges the contributions

of the open software and robotics

communities to the development project.

To access the source code of these free

and open source software components

whose license conditions require

publishing, and to see their full copyright

information and applicable license terms,

visit: http://

electrolux.opensoftwarerepository.com

(folder NIU5).

3. FEATURES

Table title

IMPORTANT

Features may vary by model.

Accessories are available for your appliance and may be purchased at

Frigidaire.com or by calling toll-free 1-800-374-4432.

6 ENGLISH

3.1 External Water Dispenser Model

3 1

6 9 10 118

Adjustable feet

Ice/Water Dispenser

External Appliance Control Panel

Door Bins

Ice Chute

Flipper Mullion

Ice Maker

Flipper Guide

Air Filter

Shelves

Water Filter

Door Bin

CrispSeal™ Fresh Crispers

Snack Zone

Adjustable Hinges

Custom-Flex™ Temp Drawer

Ice Maker

Ice Bin

Upper Freezer Basket

Lower Freezer Basket

4. INSTALLATION

This User Manual provides general

installation and operating instructions for

your model. We recommend using a

service or kitchen contracting professional

to install your appliance. Use the

appliance only as instructed in this User

Manual. Before starting the appliance,

follow these important first steps.

4.1 Installation Checklist

Doors

❐ Handles are secure and tight

Leveling

❐ Cabinet is setting solid on all corners

Electrical Power

❐ House power is turned on

❐ Appliance is plugged in

Ice Maker

❐ House water supply is connected to

the appliance

WARNING!

Potable water supply only.

❐ No water leaks present in any

connections - recheck in 24 hours

❐ Ice maker is turned on

Final Checks

❐ Shipping material is removed

❐ Registration card is sent in

4.2 Tools necessary

These tools are necessary at different

stages of the installation process:

A. Adjustable Wrench

B. 3/8" Fixed Wrench

C. 5/16"Socket Wrench

D. Screwdriver: Phillips™ Head or

Quadrex Head

E. 6 mm Allen Wrench

4.3 Location

• If possible, place the appliance out of

direct sunlight and away from the

range, dishwasher, or other heat

sources.

• The appliance must be installed on a

floor that is level and strong enough to

support a fully loaded appliance.

ENGLISH 7

• Consider water supply availability for

models equipped with an automatic ice

maker.

WARNING!

This appliance is intended for use in

residential household and similar

interior applications such as:

• Kitchen / kitchenette

• Pantry room

• Basement

• Enclosed garage

• Other interior residential type

environments

WARNING!

Allow the following clearances for

ease of installation, proper air

circulation, plumbing, and electrical

connections:

• Top 3/8" (9.5 mm)

• Sides 3/8" (9.5 mm)

• Back 1" (25.4 mm)

4.4 Door opening

Position the appliance to allow easy

access to a counter when removing food.

Make sure the refrigerator drawers and

freezer baskets can be fully open.

220

312

8.75

12.25

120°

933.4 mm

36.75 in

25.4 mm

1 in

9.5 mm

0.37 in

9.5 mm

0.37 in

4.5 Cabinet leveling and door

alignment

Guidelines for final positioning of

appliance:

• All 4 corners of the cabinet must rest

firmly on the floor.

• Slightly elevate the front to ensure that

doors close and seal properly.

• Align the doors with each other and

level them.

You can meet most of these conditions by

raising or lowering the adjustable front

feet.

4.6 Leveling

Level the cabinet by raising or lowering the

front adjustable feet.

1. Slightly open the freezer drawer.

2. Lower the adjustable feet until they

touch the floor. Use pliers to adjust.

• To raise the unit, turn the feet

clockwise.

• To lower the unit, turn the feet

counterclockwise.

3. Ensure both doors are free of binding.

The seals must touch the cabinet on

all 4 sides.

4. Ensure the cabinet is stable.

4.7 Door leveling

To adjust the door height:

8 ENGLISH

1. Open the Custom-Flex™ Temp drawer

to access the lower hinges.

2. Insert a 6 mm Allen wrench into the

lower hinge shaft.

• To lower the door, turn the

adjustment screw clockwise.

• To raise the door, turn the

adjustment screw

counterclockwise.

4.8 Flipper mullion

Adjust the flipper mullion for proper

connection with the mullion guide. Ensure

the flipper mullion is folded and

perpendicular to the fresh food door. If the

mullion guide is not in the correct position,

it could prevent the door from closing

completely.

5. DOOR REMOVAL

5.1 Getting through narrow

spaces

If your appliance does not fit through an

entrance area, you can remove the doors.

Check first by measuring the entrance.

5.2 Removing/Installing

refrigerator doors

To prepare for removing the doors:

1. Unplug the electrical power cord from

the wall outlet.

2. Remove any food from the door

shelves and close the doors.

WARNING!

Make sure the electrical power cord is

unplugged from the wall outlet.

To remove refrigerator doors:

1. Open doors to 90°.

2. Remove all 5 Phillips™ screws from

top hinge cover and lift up.

3. Trace lightly around the door top

hinges with a pencil. This makes

reinstallation easier.

4. Disconnect any electrical harnesses

running from the doors to the hinge

cover.

ENGLISH 9

5. Pull up on the water line gently to

remove it from the door.



NOTE

Be careful while pulling the water tube

from the door to be sure the tube does

not kink.



NOTE

You will pull approximately 4ft of water

tube from the refrigerator door.

CAUTION!

Make sure the doors are set aside in a

secure position where they cannot fall

and cause personal injury, or damage

to the doors or handles.

6. Remove the three 8mm bolts from

both top hinges. Lift the doors up off

lower hinges and carefully set them

aside.

7. You may need to remove the lower

hinges for clearance purposes. To

gain access to the lower hinges,

extend the Custom-Flex™ Temp

Drawer. Unscrew the 3 lower hinge

screws and slide the hinge inward.

8. To reinstall the doors, reverse the

procedure.

IMPORTANT

Make sure the water line tubing goes

through the hole at the top of the

dispenser pocket. A metal wrap on the

tubing prevents damage from the

hinge rubbing against it. Fix the back

around the tube in the proper location

upon reinstallation to protect the tube

from the hinge.

10 ENGLISH

External dispenser model



NOTE

When reinserting the water tube and

replacing the top hinge cover, ensure

the tube does not kink.

Once both doors are in place, ensure they

are aligned with each other and level.

Refer to Installation. Replace the top hinge

cover.

5.3 Door opening angle feature

If your refrigerator doors are touching

objects located close to the side of the

appliance, the doorstop can be replaced

with the provided optional door opening

angle feature, to reduce the maximum

door opening angle.



NOTE

Optional door opening angle feature

parts are identified:

LH - Left Hand, to apply on left door.

RH - Right Hand, to apply on right

door.

Optional Door Opening Angle Feature

Default Door Stop

ə

Optional Door Stop Feature

ə

To remove and replace the door stop:

1. Remove the doors. Refer to Door

Removal.

2. Turn the doors upside down to access

the door stop located in the hinge area

of the door.

ENGLISH 11

Door Stopper Removal

3. Remove the 2 screws from the door

stop.

4. Replace the door stop with optional

door opening angle feature. Reinsert

the 2 screws.

5. Repeat the process for the opposite

refrigerator door.

6. Reinstall the doors to the cabinet.

5.4 Custom-Flex™ Temp Drawer

To remove the Custom-Flex™ Temp

Drawer:

1. Fully open the drawer.

2. Remove the basket from the drawer.

3. For some models only: Unsnap the 4

cable ties by pressing clip sides

together and pushing them through the

opening.

For some models only: Remove the

screw and the retaining clip and

disconnect the harness.

5. To fully remove the drawer from the

cabinet, press the tabs on both sides,

and slide the rails past the clips on

both sides.

To reinstall the Custom-Flex™ Temp

Drawer:

1. Place the drawer with the brackets and

sliders inside the compartment, and

12 ENGLISH

click the sliders into place on each

side.

2. For some models only: Reconnect the

cabinet harness.

3. For some models only: Replace the

retaining clip and secure it with the

screw.

4. For some models only: Reattach the

electrical harness by positioning the

cable clips over the black markings on

the harness. Push the 4 cable clips

through the openings in the rail to

secure the harness in place.

5. Slide the basket into place.

6. Close the drawer.

CAUTION!

The drawer is heavy. Use caution

when lifting.

5.5 Removing The Freezer Drawer

To remove the freezer drawer:

1. Open the drawer and fully extend it.

2. Remove the upper freezer drawer.

3. Remove the lower freezer basket.

4. Inside the cabinet, press the tab on

both sides to release the sliders.

5. Remove the drawer with brackets and

sliders.

To reinstall the freezer drawer:

1. Place the drawer with brackets and

sliders inside the cabinet and click into

place.

2. Replace the lower freezer basket first,

and then the upper freezer basket.

Ensure the upper freezer basket

rollers are seated correctly into the

tracks before closing the freezer

drawer.

For additional instructions, refer to

Storage Features

ENGLISH 13

6. DOOR HANDLE INSTALLATION

CAUTION!

Wear gloves and safety goggles. Use

extreme caution when installing these

handles.

The rounded end of the handles may

be sharp (some models).

6.1 Door handle installation

To install the door handle:

1. Remove the handles and any other

protective packaging from the carton.

2. Position the handle end caps over

upper and lower preinstalled shoulder

bolts (A) that are fastened into door,

ensuring the holes for the set screws

are facing towards the opposite door.

3. While holding handle firmly against

door, fasten upper and lower Allen set

screws (B) with supplied Allen wrench.

4. Repeat the steps above to install the

opposite handle. Ensure the holes for

the set screws are facing towards the

opposite door.



NOTE

When tightening the Allen set screws,

apply force to the longer arm of the

Allen wrench supplied in the handle

packaging.



NOTE

Tighten and sub-flush all set screws

(place the Allen set screw just below

the surface of the end cap) of the

handle end cap. Draw the end caps

tight to the freezer and refrigerator

doors with no gaps. To avoid

scratching the metal door, keep the

door open while torquing down the set

screws.

The door handle may loosen over

time. If this happens, tighten the set

screws on the handles.

14 ENGLISH

7. WATER SUPPLY CONNECTION

7.1 Before Installing The Water

Supply Line

WARNING!

To avoid electric shock, which can

cause death or severe personal injury,

disconnect the appliance from the

electrical power before connecting a

water supply line to the appliance.

CAUTION!

To avoid property damage:

• Use copper or stainless steel

braided tubing for the water supply

line. Do not use water supply

tubing made of 1/4" plastic. Plastic

tubing greatly increases the

potential for water leaks, and the

manufacturer will not be

responsible for any damage if you

use plastic tubing for the supply

line.

• Do not install water supply tubing in

areas where temperatures fall

below freezing.

• Chemicals from a malfunctioning

softener can damage the ice

maker. If the ice maker is

connected to soft water, ensure

that the softener is maintained and

working properly.

IMPORTANT

Ensure your water supply line

connections comply with all local

plumbing codes.

7.2 You will need

• Basic tools: adjustable wrench, flat-

blade screwdriver, and Phillips™

screwdriver.

• Access to a household cold water line

with water pressure between 30 and

100 psi.

• A water supply line made of 1/4" (6.4

mm) OD, copper or stainless steel

tubing. To determine the length of

tubing needed, measure the distance

from the ice maker inlet valve at the

back of the appliance to your cold

water pipe. Then add approximately 6 ft

(1.8 m) to ensure you can move the

appliance for cleaning.

• A shutoff valve to connect the water

supply line to your household water

system. Do not use a self-piercing type

shutoff valve.

• Do not reuse compression fitting or use

thread seal tape.

• A compression nut and ferrule (sleeve)

for connecting a copper water supply

line to the ice maker inlet valve.



NOTE

Check with your local building

authority for recommendations on

water lines and associated materials

prior to installing your new refrigerator.

Depending on your local/state building

codes, Frigidaire recommends:

• for homes with existing valves its

Smart Choice® water line kit

5304437642 with a 6 ft stainless

steel water line.

Please refer to Frigidaire.com for

more information.

7.3 Installing the Water Supply

Line

IMPORTANT

Your appliance water supply system

includes several tubing lines, a water

filter, and a water valve. To ensure

that your water dispenser works

properly, this system must be

completely filled with water when your

appliance is first connected to the

household water supply line.

Connection to household water supply

with 1/4" compression fitting

A. Water inlet fitting

B. Plastic tubing to water valve

ENGLISH 15

6 ft (1.8 meters) Stainless Steel water

line from household water supply line

Water inlet brass fitting

A. Plastic cap

B. Remove plastic cap from water inlet

fitting

C. 1/4" plastic tube to water valve

To connect water tube to household water

supply:

1. Disconnect refrigerator from electric

power source.

2. Place end of water supply line into sink

or bucket. Turn on water supply and

flush supply line until water is clear.

Turn off water supply at shutoff valve.

A. To household water supply

B. To unit water valve

3. Open the locking clips and grab the

water line coming from the refrigerator.

Remove the plastic cap from the water

inlet fitting and discard the cap.

4. If using (recommended) stainless steel

braided tubing - the nut and the ferrule

are already assembled on the tubing.

Slide the compression nut onto the

water inlet fitting and finger tighten.

5. Using two 1/2" wrenches, one to hold

the household water line nut (A) and

the other to hold the water inlet fitting

nut (B), tighten a half turn with the

wrench (A). Do not over tighten.

6. Replace the connected tubes into the

clips and lock the clips back in place to

keep the tubing in the right position.

7. Turn on water supply at shutoff valve

and tighten any connections that leak.

8. Reconnect refrigerator to electrical

power source.

9. Turn the ice maker on.

10. Purge air from the Ice and Water

Dispenser System by operating the

water dispenser for 3 - 4 minutes. This

requires dispensing several glasses of

water.

16 ENGLISH

8. CONTROLS AND SETTINGS: EXTERNAL WATER

DISPENSER MODEL

Control display

1213

85 7

Table title

Ice Maker but

ton

Press and hold for 3 seconds to turn the ice maker on/off.

Custom-Flex

Temp Drawer

button

Press the button to adjust the temperature.

Chill Drinks but

ton

Press the button to quickly chill a drink inside the freezer compartment. A time

value appears on the freezer temperature display (in minutes). Set the timer

using the + / - buttons. The range is from 20 to 45 minutes in 5 minute inter

vals. A tone sounds when you input the time.

Drinks may freeze if the temperature is too low or timer setting is too long.

Freeze Boost

Prior to grocery shopping, activate Freeze Boost to lower the temperature and

freeze food faster. Freeze Boost stays active for up to 24 hours before auto

matic deactivation. You can turn it off manually by pressing Freeze Boost. This

restores the freezer to the previous temperature setting.

Water filter/Air

filter replace

ment indicators

Replace the filter when the indicator illuminates

Freezer control

Press either the + or - to adjust the temperature.

The temperatures range from -6°F (-21°C) to 6°F (-15°C).

Alarms indica

tors

In case of alarm, the indicators lights up, and a tone sounds. Press any button

to silence the tone.

Refrigerator

control

Press either the + or - to adjust the temperature.

The temperatures range from 34°F (1°C) to 44°F (7°C).

°F/°C

To toggle between Fahrenheit (°F) and Celsius (°C), simultaneously press and

hold + and – for 5 seconds.

Chill Boost

Prior to grocery shopping, activate Chill Boost to lower the temperature and

cool food faster. Chill Boost stays active for up to 6 hours.

Reset Air Filter Press and hold the button for 3 seconds to reset after changing the filter.

Reset Water

Filter

Press and hold the button for 3 seconds to reset after changing the filter.

Cubes/Light

Press Cubes to dispense cubed ice.

Press Light to switch the dispenser light on and off.

Press and hold Cubes and Light simultaneously until the tone sounds and the

wi-fi indicator starts to blink.

ENGLISH 17

Water/Crushed

Press Water to dispense water.

Press Crushed to dispense crushed ice.

Press Water and Crushed simultaneously for 3 seconds to enable/disable the

lock function. The lock function disables the access to the display and to the

ice and water dispenser. The indicator flashes and a sound alarm sounds.

Display modes

• Sleep mode

As a default, the display goes to sleep

after a short time. If you press any icon,

the display awakens. After a short time,

it goes back to sleep. When in sleep

mode, wake up the appliance control

display to confirm the ice maker is on/

off. You can turn sleep mode off to

have the display on full time (awake

mode). When sleep mode is off, the

display is always illuminated. To turn

sleep mode on/off, simultaneously

press and hold Ice and Light for 5

seconds. A tone confirms.

• Awake Mode

To change from sleep mode to awake

mode, simultaneously press and hold

Ice and Light for 5 seconds. The

display shows the current

temperature/ice maker status. A tone

confirms.

Custom-Flex Temp Drawer

Freezer

Meat & f ish

28°F/-2°C

Drinks

32°F/0°C

Fresh food

37°F/3°C

Wines

45°F/7°C

1 2 3 4 5

Press the Custom Flex Temp Drawer

button on the control panel display to

adjust the temperature. A tone sounds to

confirm the choice.

Freezer

To change the drawer temperature

use the control panel display.

Changing the temperature on the

display changes the temperature both

in the drawer and in the freezer

compartment.

Meat&fish

This function sets the drawer

temperature to 28°F (-2°C).

Drinks

This function sets the drawer

temperature to 32°F (0°C).

Fresh food

This function sets the drawer

temperature to 37°F (3°C).

Wines

This function sets the drawer

temperature to 45°F (7°C).

8.1 Clear Alerts

High Temp

The alarm sounds in the event of a high

temperature condition. The indicator

illuminated and the appliance control panel

displays HI for whichever compartment the

alarm is detected in. The alarm sounds

every 10 seconds until acknowledged.

Touch any key or open a door to silence

the alarm.

Power Outage

In the event of a power outage, a tone

sounds and the power outage indicator

illuminates once power has been restored.

Press any key on the appliance control

display to silence the alarm.

Call Service

Indicates that the appliance has detected

an issue that requires professional

attention. When this alarm appears on the

control panel, the appliance may continue

to operate, but some functions could be

limited or unavailable.

8.2 Connecting the appliance to

the internet

Requirements:

• This app requires the latest OS on your

smartphone. Refer to Frigidaire.com for

compatibility information.

• A secure password-protected 2.4GHz

internet connection on a WPA/WPA2

compliant network.

• Valid email address and password.

• A Wi-Fi router that supports IEEE

802.11 b/g/n.

• When setting up your connection, make

sure you are in front of the appliance.

To connect the appliance to the home

internet:

1. Download the app.

18 ENGLISH

2. When prompted to "Turn on appliance

network," press and hold the Cubes

and Light buttons on the control panel

simultaneously for 5 seconds. Once

the network is activated, 'AP' appears

on the control panel display. The

appliance is now ready to join the

home network.

3. Follow the instructions in the app to

complete the process.

4. Confirm the appliance is visible in the

app.

5. Send a command from the app to the

appliance. The app should update to

show the new settings, and the

appliance should respond to the

command.

For connectivity-related assistance, call

1-800-311-4667 Monday - Friday, 9:00 am

- 6:00 pm EST or email

[email protected]. Find the

frequently asked questions on

Frigidaire.com.

8.3 Sabbath Mode



NOTE

While in Sabbath Mode, neither the

lights, dispenser, nor the control panel

will work until Sabbath Mode is

deactivated. Refrigerator stays in

Sabbath Mode after power failure

recovery. It must be deactivated with

the buttons on the control panel.



NOTE

Although you have entered the

Sabbath Mode, the ice maker will

complete the cycle it had already

initiated. The ice cube compartment

will remain cold and new ice cubes

can be made with standard trays.

The Sabbath Mode is a feature that

disables portions of the refrigerator and its

controls in accordance with observance of

the weekly Sabbath and religious holidays

within the Orthodox Jewish community.

Sabbath Mode is turned on and off by

simultaneously pressing and holding both

the FZ- and FF+ for 10 seconds. The

display shows Sb while in Sabbath mode.

In the Sabbath Mode, the High Temp

alarm is active for health reasons. For

example, if the door is left ajar the High

Temp alarm is activated. The refrigerator

will function normally once the door is

closed, without any violation of the

Sabbath/Holidays. The High Temp alarm

is permitted when cabinet temperature is

outside the safe zone for 20 minutes. The

alarm silences itself after 10 minutes while

the High Temp icon stays lit until the

Sabbath mode is exited.

Table title

For further assistance, guidelines

for proper usage and a complete

list of models with the Sabbath

feature, visit the web at star-k.org.

8.4 Setting cooling temperatures

(options may vary)



NOTE

The recommended settings for a

product installed in a kitchen is 37°F

for the fresh food compartment and

0°F for the freezer.

IMPORTANT

If your product has food freezing in the

fresh food compartment, increase the

temperature setting 1 or 2°.

IMPORTANT

If you place food within 1" in front of

the air ports, there may be the chance

of freezing food.

ENGLISH 19

9. AUTOMATIC ICE AND WATER DISPENSER

Table title



NOTE

Refrigerator Ice Maker (External Dispenser Models Only)

9.1 Priming the water supply

system

Before making ice for the first time, prime

the water supply system. Air in new

plumbing lines can result in two or three

empty ice maker cycles. If the system is

not flushed, the first ice cubes may have

discolored water or have an odd flavor.

Purge air from the system:

1. Press and hold a drinking glass

against the water dispenser paddle

until water comes out (it may take up

to 4 minutes to purge air from the

system).

2. Run approximately 1 full gallon of

water through the dispenser before

use, and discard.

Dispenser (varies by model)

uick

Freeze

CAUTION!

For proper dispenser operation, the

recommended water supply pressure

should fall between 30 psi and 100

psi. Excessive pressure may cause

the system to malfunction.



NOTE

The water dispenser has a built-in

device that shuts off the water flow

after 2 minutes of continuous use. To

reset this shutoff device, release the

dispenser paddle.



NOTE

Dispensed water is not chilled. For

colder water, add ice to cup or

container before dispensing water.

9.2 Ice maker Operation and Care

After you properly install the refrigerator

and it has cooled for several hours, the ice

maker can produce ice within 24 hours.

9.3 Storage bin capacity

The refrigerator ice maker should produce:

• In a standard depth model: 3.2 to 3.7

lbs of ice per 24 hours.

• In a counter depth model: 3.2 to 3.7 lbs

of ice per 24 hours.

The refrigerator ice bin holds around:

• In a standard depth model: 5 lbs of ice.

20 ENGLISH

• In a counter depth model: 4 lbs of ice.

9.4 Turning the ice maker on/off

Ice production is controlled by the ice

maker On/Off feature on the appliance

control display. Press the On/Off feature to

turn the ice maker on and off.

IMPORTANT

Turning off the ice maker disables ice

making. You will still be able to

dispense existing ice, and dispense

water.



NOTE

The ice maker also has a built-in

plastic signal arm that automatically

stops ice production when the ice bin

is full. This signal arm should not be

used to manually stop the ice maker.

IMPORTANT

Your ice maker is turned on at the

factory so it can work as soon as you

install your refrigerator. If you cannot

connect a water supply, set the ice

maker On/Off feature to Off;

otherwise, the ice maker fill valve may

make a loud chattering noise when it

attempts to operate without water.

IMPORTANT

On occasion, you may notice

unusually small ice cubes in the

bucket or in dispensed ice. This could

occur in normal operation of the ice

maker. If you start seeing these more

frequently, it may be an indication of

low water pressure or the water filter

needs to be replaced. As the water

filter nears the end of its useful life

and becomes clogged with particles,

less water is delivered to the ice

maker during each cycle. If it has

been 6 months or longer since you

last changed your water filter, replace

the water filter with a new one. Poor

quality household water may require

the filter to be changed more

frequently.

9.5 Ice maker/Dispenser Tips

• Ice cubes stored too long may develop

an odd flavor. Empty the ice container

as explained in Cleaning the ice maker

section.

• If your refrigerator is not connected to a

water supply or the water supply is

turned off, turn off the ice maker.

• If you need a large quantity of ice at

one time, it is best to get cubes directly

from the ice container.

• The following sounds are normal when

the ice maker is operating:

– Motor running

– Ice dropping into ice container

– Water valve opening or closing

– Running water

When dispensing ice, hold the cup in

position for a moment after releasing

the paddle. This ensures all ice falls

into the cup.

CAUTION!

Chemicals from a malfunctioning

water softener can damage the ice

maker. If the water supply to your

refrigerator is softened, be sure the

softener is maintained to work

properly.

9.6 Cleaning the Ice Maker Bin

Clean the ice maker and ice bin at regular

intervals, especially prior to vacation or

moving.

1. Turn off the ice maker.

2. Remove the ice bin. Lift the ice bin

upward, and then pull it straight out.

3. Empty the ice bin.

CAUTION!

Never use an ice pick or similar sharp

instrument to break up the ice. This

could damage the ice bin. To loosen

stuck ice, use warm water.

ENGLISH 21

4. Clean the ice bin with mild detergent.

Do not use harsh or abrasive cleaners.

Rinse with clean water.

5. Let the ice bin dry completely before

you put it back in the freezer.

6. Replace the ice bin.

7. Turn the ice maker on.

If there is a power failure for one hour or

longer, the ice cubes in the ice bin may

melt and re-freeze together. Remove and

empty the ice bin if this happens.

9.7 When to remove and empty

the ice bin

Remove and empty the ice bin if:

• An extended power failure (one hour or

longer) causes ice cubes in the ice bin

to melt and re-freeze together after

power is restored, jamming the

dispenser mechanism.

• You do not use the ice dispenser

frequently. Ice cubes will freeze

together in the bin, jamming the

dispenser mechanism.

Refer to Cleaning the Ice Maker Bin.

10. ICE MAKER

10.1 Ice maker operation and care

After you properly install the appliance, the

ice maker can produce ice within 24 hours.

When using the ice maker for the first

time, and in order for it to work properly,

you need to clear air from the water tubing

and the filter. If you do not flush the

system, the first ice cubes may be

discolored or have an odd flavor. Once the

ice maker begins making ice, allow the bin

to fill completely, and then discard the first

full bin of ice.

10.2 Storage Bin Capacity

This ice maker should produce between 2

and 2.5 lbs of ice per 24 hours depending

on use.

The ice bin should hold:

• For a standard depth appliance: around

7.5 lbs of ice.

• For a counter depth appliance: around

4.5 lbs of ice.



NOTE

The ice maker only produces the

specified rate if you set the

temperature to 0°F.



NOTE

The freezer ice maker fills the ice bin

more in one spot. Move the ice to the

edges of the bin to allow it to fill

completely.

10.3 Turning the Ice Maker On/Off

Press or slide the power button to turn the

ice maker on/off. The button and LED

illuminate when active.

varies by model

(A - power button, B - test button)

The ice maker regulates the ice

production. It stops making ice when full

and resumes when ice is low in the ice bin.

Remove the Ice Bin if:

An extended power failure (1 hour or

longer) cause ice cubes in the ice bin to

melt and re-freeze together after power is

restored.

To remove ice bin lift it upward and pull

straight out. Shake to loosen the cubes or

clean.

22 ENGLISH

CAUTION!

Never use an ice pick or similar sharp

instrument to loosen the ice cubes.

This could damage the ice bin. To

loosen ice clumps, use warm water.

Before replacing the ice bin, ensure it

is completely dry.

10.4 Ice maker tips

The following sounds are normal when the

ice maker is operating:

• Motor running

• Ice dropping into ice bin

• Water valve opening or closing

• Running water

Ice cubes stored too long may develop an

odd flavor. Empty the ice bin as explained

below.

CAUTION!

If the water supply to your refrigerator

is softened, properly maintain be sure

the softener. Chemicals from a water

softener can damage the ice maker.

11. STORAGE FEATURES

11.1 Shelves

CAUTION!

To avoid personal injury or property

damage, handle tempered glass

shelves carefully. Shelves may break

suddenly if nicked, scratched, or

exposed to sudden temperature

change. Allow the glass shelves to

stabilize to room temperature before

cleaning. Do not wash in dishwasher.

You can easily adjust shelf positions in the

refrigerator compartments to suit your

needs. The shelves have mounting

brackets that attach to slotted supports at

the rear of each compartment.

1. Remove all the food from the shelf.

2. Lift the front edge up and pull the shelf

out.

3. Replace by inserting the mounting

bracket hooks into the desired support

slots.

4. Lower the shelf and lock into position.

11.2 Slide-Under Shelf

For some models only.

To adjust the slide-under shelf, push the

front half of the shelf backward toward the

rear of the cabinet until the rear half shelf

drops down. Then, gently continue

pushing the front half shelf back so it

slides under the rear half shelf.

11.3 Flip Shelf

To adjust the flip shelf:

1. Remove food from the shelf.

2. Lift the right edge of the shelf upwards.

3. Push the shelf to the left towards the

ice maker.

11.4 Drawers

This appliance includes a variety of

storage drawers.

11.5 CrispSeal® Fresh Crisper

For some models only.

ENGLISH 23

Use the crisper to keep produce fresh for

longer.

Flip the crisper to use it as an open

compartment for items such as beverages,

yogurts, or snacks.

1 2

To remove the crisper:

1. Pull the drawer out until it stops.

2. Lift the front slightly.

3. Remove the drawer.

Remove the crisper insert and the

PureAir Produce Keeper Plus™ filter

before washing the crisper.

11.6 Auto-humidity Control

Removal

To remove the auto humidity control

membrane for cleaning:

1. Reach to the back of the humidity

control cover.

2. Place your fingers between the

humidity control and the back wall. Pull

up on the cover.

3. Pull the cover toward the front of the

cabinet and remove it.

4. Remove the humidity membrane from

the housing by lifting it up and sliding it

over.

5. Clean the humidity membrane with

hot, soapy water.

6. Replace the membrane in the housing

by reversing the steps above.

24 ENGLISH

We do not recommend replacing the

auto-humidity membrane unless it

becomes damaged or ruined. If the

membrane becomes soiled, you can

wash it with soap and water. Ensure

the membrane is dry before replacing

it in the housing.

11.7 SnackZone - Recessed

Snack Drawer

These drawers are ideal for storing deli

meats and cheeses.

Slide back the cover to access the

drawers.

11.8 Custom-Flex™ Temp Drawer

(some models)



NOTE

Do not use the Custom-Flex™ Temp

Drawer to store fresh produce. These

items may freeze and cause damage

to fruits and leafy vegetables.

The drawer locks automatically to prevent

unwanted use. To unlock, press and hold

the Unlock button for 3 seconds. The

drawer locks again after 10 seconds

without interaction.

Do not store glass bottles in the

Custom-Flex™ Temp Drawer when

the temperature setting is in Freezer

or Cold Drinks modes. The glass may

break and shatter, causing physical

harm and injury.

11.9 Custom-Flex™ Temp Drawer

Divider

For some models only.

To position drawer dividers, slide them left

or right. Dividers do not lock but use the

weight of stored items to stay in place.

Dividers may shift when opening or closing

the drawer if fewer items are stored.

11.10 Doors

Storage bins (varies by model)

The doors to your refrigerator

compartment use a system of modular

storage bins. All of these bins are

removable for easy cleaning. Some of

them have fixed positions, while others

can be adjusted to your needs.

Door bins are ideal for storing jars, bottles,

cans, and large drink containers. They

also enable quick selection of frequently

used items.

11.11 Changing position of

adjustable door bin

To change the position of an adjustable

door bin:

1. Remove all food from door bin.

2. Grip the bin firmly with both hands and

lift it upward.

3. Remove the bin.

4. Place the bin just above desired

position.

5. Lower the bin onto supports until it is

locked in place.

6. Place the bin liner into the bin.

ENGLISH 25

11.12 Removing/Installing Upper

Freezer Drawer

To remove the upper freezer drawer:

1. Open the freezer compartment fully.

2. Lift the upper freezer drawer up and

out.

Reverse these steps to reinstall the

drawer.

IMPORTANT

There are wheels on the bottom of the

drawer. Make sure all wheels are

aligned with their tracks for proper

function. If the drawer is not aligned, it

will cause problems with the door

operation.



NOTE

If the basket does not rest on the

stabilizer bar retainer clips, the drawer

does not close correctly.

11.13 Freezer accessories

Your freezer has baskets and dividers you

can adjust to your needs.

11.14 Lower basket divider

To reposition the lower basket divider,

grab the lower divider and slightly pull it up

to slide the divider to the next position.

You cannot remove the divider.

11.15 Removing/Installing

Freezer Basket

To remove the freezer basket:

1. Open the freezer compartment

completely.

2. Lift the basket up and remove it.

Reverse the steps to reinstall the freezer

basket.

12. STORING FOOD AND SAVING ENERGY

12.1 Ideas for storing food

Fresh food storage

• Keep the fresh food compartment

between 34°F and 40°F, with an

optimum temperature of 37°F.

• Avoid overcrowding the refrigerator

shelves, which reduces air circulation

and causes uneven cooling.

• Avoid placing food in front of air ports.

Fruits and vegetables

• Store fruits and vegetables in crisper

drawers, where trapped moisture helps

preserve food quality for longer time

periods.

• Wash items and remove excess water.

• Wrap any items that have strong odors

or high moisture content.

Meat

• Wrap raw meat and poultry separately

and securely to prevent leaks and

contamination of other foods or

surfaces.

• Use the deli drawer to store meat/

poultry for short-term storage. Any

26 ENGLISH

meat to be kept longer than two days

should be frozen.

Frozen foods storage

• Keep the freezer compartment at 0°F

or lower.

• A freezer operates most efficiently

when it is at least 2/3 full.

Packaging foods for freezing

• To minimize food dehydration and

quality deterioration, use aluminum foil,

freezer wrap, freezer bags, or airtight

containers. Force as much air out of

the packages as possible and seal

them tightly. Trapped air can cause

food to dry out, change color, and

develop an off-flavor (freezer burn).

• Wrap fresh meats and poultry with

suitable freezer wrap prior to freezing.

• Do not refreeze meat that has

completely thawed.

Loading the freezer

• Prior to grocery shopping, activate

Freeze Boost so that on your return

you can ensure your newly purchased

food designated for the freezer will be

preserved as quickly as possible.

• Activating Freeze Boost also will help

your freezer more efficiently maintain

the selected temperature after placing

new purchases with pre-existing frozen

foods.

• Avoid adding too much warm food to

the freezer at one time. This overloads

the freezer, slows the rate of freezing,

and can raise the temperature of frozen

foods.

• Leave a space between packages, so

cold air can circulate freely, allowing

food to freeze as quickly as possible.

12.2 Ideas for energy saving

Installation

• Locate the refrigerator in the coolest

part of the room, out of direct sunlight,

and away from heating ducts or

registers.

• Do not place the refrigerator next to

heat-producing appliances such as a

range, oven, or dishwasher. If this is

not possible, a section of cabinetry or

an added layer of insulation between

the two appliances will help the

refrigerator operate more efficiently.

• Level the refrigerator so that the doors

close tightly.

Temperature setting

• Refer to Controls and Settings for

procedures on temperature settings.

Food storage

• Avoid overcrowding the refrigerator or

blocking cold air vents. Doing so

causes the refrigerator to run longer

and use more energy.

• Cover foods and wipe containers dry

before placing them in the refrigerator.

This cuts down on moisture build-up

inside the unit.

• Organize the refrigerator to reduce

door openings. Remove as many items

as needed at one time and close the

door as soon as possible.

• Do not place a hot container directly on

a cold shelf. Remember, such an

extreme temperature change may

damage the glass.

13. NORMAL OPERATING SOUNDS

13.1 Understanding the sounds

you may hear

Your new, high-efficiency appliance may

introduce unfamiliar sounds. These

sounds normally indicate your appliance is

operating correctly. Some surfaces on

floors, walls, and kitchen cabinets may

make these sounds more noticeable.



NOTE

Energy efficient foam in your

appliance is not a sound insulator.

Following is a list of major components in

your appliance and the sounds they can

cause:

A. Evaporator. Refrigerant through the

evaporator may create a boiling or

gurgling sound.

B. Evaporator fan. You may hear air

being forced through the refrigerator

by the evaporator fan.

C. Defrost heater. During defrost cycles,

water dripping onto the defrost heater

may cause a hissing or sizzling sound.

ENGLISH 27

After defrosting, a popping sound may

occur.

D. Automatic Ice maker. When ice has

been produced, you will hear ice

cubes falling into the ice bin.

E. Electronic control & automatic defrost

control. These parts can produce

snapping or clicking sound when

turning the cooling system on and off.

F. Condenser fan. You may hear air

being forced through the condenser.

G. Compressor. Modern, high-efficiency

compressors run much faster than

previous models. The compressor may

have a noticeable hum or pulsating

sound during operation.

H. Water valve. Makes a buzzing sound

each time it opens to fill the ice maker.

I. Drain pan (not removable). You may

hear water dripping into the drain pan

during the defrost cycle.

J. Condenser. May create minimal

sounds from forced air.

K. Motorized damper. May produce

intermittent humming during operation.

L. Ice chute. When dispensing ice, you

will hear a snapping or clicking sound

when the solenoid opens and closes

the ice chute.

M. Ice dispenser. When dispensing ice

you can hear a snapping, clicking or

popping sound.



NOTE

During automatic defrost cycle, a red

glow in the back wall vents of your

freezer compartment is normal.

14. FILTER REPLACEMENT

14.1 PurePour Connect™ Water

Filter

Keep safe, great-tasting water flowing with

a PurePour Connect™ water filter. Using a

PurePour Connect™ water filter:

• Makes safe water second nature

PurePour Connect™ water filters are

certified to reduce contaminates* and

keep great-tasting water flowing for you

and your family.

• Produces purity you can trust

Know for certain your PurePour

Connect™ water filter is a protector.

Counterfeits and knockoffs put your

refrigerator and health at risk. Frigidaire

Genuine Filters are the smarter, safer

choice.

• Every drop gives back

Partnered on sustainability efforts the

use of a PurePour Connect™ water

filter helps cut back on the cost and use

of plastic used to produce and package

bottled water

*For the complete list, please see

Performance Data Sheet on

Frigidaire.com.

14.2 Ordering replacement filters



NOTE

When you order your replacement

filter, please reorder the same filter

type currently in your refrigerator.

To order your replacement filters, please

call toll-free at 1-800-374-4432, or visit

Frigidaire.com. Frigidaire recommends

that you order extra filters when you first

install your appliance, and that you replace

your filters at least once every 6 months.

Here are the product numbers to request

when ordering:

• PurePour Connect™ Water Filter

PWF-1™ FPPWFUO1

for models: GRMS2773, GRMN2872,

FRMS2733

28 ENGLISH

• PurePour Connect™ Water Filter

PWF-2™ FPPWFUO2

for models: GRMC2273, GRMG2272

Find the Performance Data Sheet located

in the Guides and Manuals section for

your specific water filter on Frigidaire.com:

• PWF-1™ FPPWFUO1

Performance Data Sheet

• PWF-2™ FPPWFUO2

Performance Data Sheet

14.3 More about your advanced

water filter

Table title

The PurePour Connect™ PWF-1™

FPPWFUO1, PurePour Connect™ PWF-2™

FPPWFUO2 ice and water filter system is

tested and certified by IAPMO R&T against

Standards 42, 53, 401 and NSF/ANSI/CAN

372CSA B483.1 in PurePour Connect™

PWF-1/PWF-2 for the reduction of claims

specified on the Performance Data Sheet.

Visit Frigidaire.com for more information.

Do not use with water that is

microbiologically unsafe or of unknown

quality without adequate disinfection

before or after the system. Use systems

certified for cyst reduction on disinfected

waters that may contain filterable cysts.

Test & certification results

• Rated Capacity - 125 gal / 453 L for

PurePour Connect™ and ice and water

filter

• Rated service flow - .50 gal/min

• Operating Temperature: Minimum:

33°F, Maximum: 100°F

• Maximum rated pressure - 100 lbs/in²

• Recommended minimum operating

pressure: 30 lbs/in²

PurePour Connect™ Authentication

Only for models: GRMC2273, GRMG2272

The refrigerator contains a water filter

authentication system to protect you from

the harm that can occur when using

counterfeit filters. We recommend you use

only the PurePour Connect™ water filter

with this appliance. Using any other filter

can cause an error (Er FA) to appear on

the appliance control display.

Errors can occur:

• If you remove and reinsert an authentic

expired filter into the appliance.

• If you install an authentic, but incorrect

filter.

• If you install a non-authentic filter.

• If you do not install the filter properly.

In the cases above, the appliance control

display may show an error code related to

the filter authentication, and Replace

Water Filter appears on the display. You

can still use dispensing functions while the

error displays.

Press and hold the Water Filter button for

3 seconds to dismiss the error. You can

dismiss the error twice. On the third

appearance, the error code permanently

displays on the appliance control until you

install a new authentic filter.

14.4 Replacing your PurePour

Connect™ water filter

The water filter is located at the top right

side of the refrigerator compartment.

In general, you should change the water

filter every 6 months to ensure the highest

possible water quality. Water Filter Status

on the user interface prompts you to

replace the filter after a standard amount

of water (125 gal / 453 L for PurePour

Connect™) has flowed through the

system.

If you have not used your appliance for a

period of time (during moving for

example), change the filter before

reinstalling the appliance.

It is not necessary to turn the water supply

off to change the filter. Small amounts of

water may be released during the filter

replacement.

1. Turn off the ice maker.

ENGLISH 29

2. Pull the water filter cover forward.

Cover drops down to allow access to

the filter.

3. Remove the filter by pushing on the

end/face of the filter.

4. Slide the old water filter cartridge

straight out of the housing and discard

it.

5. Unpack the new filter cartridge. Using

the alignment guide, slide it gently into

the filter housing until it stops against

the snap-in connector at the back of

the housing.

6. Push firmly until the cartridge snaps

into place. There is a clicking sound as

the cartridge engages with the snap-in

connector.

7. Press a drinking glass against the

water dispenser while checking for any

leaks at the filter housing. Any spurts

and sputters that occur as the system

purges air out of the dispenser system

are normal.

8. Push the cover up toward the liner.

Then push the filter cover toward the

rear of the cabinet. The filter cover

snaps back into place.

9. After filling one glass of water,

continue flushing the system for about

4 minutes.

10. Once the filter is installed, the

authentication process may take up to

30 seconds to complete. After

authentication is complete, the filter

status on the display automatically

updates based on the condition of the

filter

11. Turn on the ice maker.

14.5 PureAir Ultra II™ Air Filter

For some models.

The air filter is located in the top center of

the fresh food compartment.

To order replacement filters, please visit

our online store at Frigidaire.com or call

toll-free at 1-800-374-4432. Here are the

product numbers to request when

ordering:

• PureAir Ultra II™ Air Filter PAULTRA2



NOTE

We recommend you always use

genuine Frigidaire replacement filters

only.

14.6 Replacing your PureAir Ultra

II™

To ensure optimal filtering of refrigerator

odors, you should change the air filter

every 6 months. Replace Air Filter on the

appliance control display indicates

replacing the filter after 6 months.

To remove and replace the air filter:

1. Remove the air filter cover by

squeezing the top and bottom of the

cover together and removing from

liner.

2. Remove the old filter and discard it.

3. Unpack the new filter and snap it into

the filter cover. The open face (carbon

media) of the filter should be installed

facing outward in the cover.

4. Replace the air filter cover by

squeezing the sides and snapping it

back into place.

5. To reset, press and hold Reset Air

Filter on the appliance control display

for 3 seconds until you hear a sound.

14.7 PureAir Produce Keeper

Plus™

Keep fruits and vegetables fresher longer

with PureAir Produce Keeper Plus™. Our

produce keeper absorbs ethylene gas, the

natural gas that causes produce to ripen

quicker. Reduce food waste, save money

and enjoy fresh-tasting produce with a

longer storage life.

30 ENGLISH

Ordering Base Starter Kit

To keep food fresh for longer, you can

purchase PureAir Produce Keeper Plus™

Base Starter Kit, one for each crisper

drawer.

Here are the product numbers to request

when ordering:

Part #FRPAPK2SKT

Ordering Replacement Filters

To order your replacement filters, please

visit our online store at Frigidaire.com, by

calling toll-free at 1-800-374-4432, or by

visiting the dealer where you purchased

your refrigerator. Frigidaire recommends

that you replace your filters at least once

every 6 months.

Here are the product numbers to request

when ordering:

PureAir Produce Keeper Plus™ PK-2 Part

#FRPAPK2RF

14.8 Installing the PureAir

Produce Keeper Plus™

1. Remove the plastic wrapper. Insert

unopened packet into the holder in the

crisper drawer.

2. For optimal results, replace the refill

every 12 months along with your air

filter.

CAUTION!

• Do not open cloth pouch. Keep out

of the reach of children.

• Do not eat. If ingested, seek

medical treatment immediately.

• Wash hands after handling.

• Do not submerge in water.

15. CARE AND CLEANING

15.1 Protecting your investment

Keeping your appliance clean maintains its

appearance and prevents odor build-up.

Wipe up any spills immediately and clean

the freezer and fresh food compartments

at least twice a year. When cleaning, take

the following precautions:

• Never use chloride or cleaners with

bleach to clean stainless steel.

• Do not wash any removable parts in a

dishwasher.

• Always unplug the electrical power cord

from the wall outlet before cleaning.

• Do not remove the serial plate.

Removal of your serial plate voids your

warranty.

• Remove adhesive labels by hand. Do

not use razor blades or other sharp

instruments which can scratch the

appliance surface.

Do not use abrasive cleaners such as

window sprays, scouring cleansers,

brushes, flammable fluids, cleaning

waxes, concentrated detergents, bleaches

or cleansers containing petroleum

products on plastic parts, interior doors,

gaskets or cabinet liners. Do not use

paper towels, metallic scouring pads, or

other abrasive cleaning materials or strong

alkaline solutions.

Refer to the guide below for more details

on caring and cleaning specific areas of

your appliance.

CAUTION!

Pull the appliance straight out to move

it. Shifting it from side to side may

damage flooring.

Be careful not to move the appliance

beyond the plumbing connections.

IMPORTANT

If you store or move your appliance in

freezing temperatures, be sure to

completely drain the water supply

system. Failure to do so could result in

water leaks when the appliance is put

back into service. Contact a service

representative to perform this

operation.

ENGLISH 31

15.2 Vacation and moving tips

Table title

Occasion Tips

Short vacations

• Leave the appliance operating during vacations

of three weeks or less.

• Use all perishable items from the appliance

compartment.

• Turn automatic ice maker off and empty ice

bucket, even if you will only be gone a few days.

Long vacations

• Remove all food and ice if you will be gone one

month or more.

• Turn water supply valve to closed position.

• Clean interior thoroughly.

• Leave both doors open to prevent odors and

mold build-up. Block doors open if necessary.

Moving

• Unplug the appliance

• Remove all food and ice.

• Recommend use of a handcart, load from the

side.

• Adjust rollers all the way up to protect them dur

ing sliding or moving.

• Pad cabinet to avoid scratching surface.

15.3 Care & Cleaning Tips

Table title

Part What to use Tips and precautions

Interior and door liners

• Soap and water

• Baking soda and water

Use 2 tablespoons of baking soda in 1 quart of

warm water. Be sure to wring excess water out of

sponge or cloth before cleaning around controls,

light bulb or any electrical part.

Door gaskets Soap and water Wipe gaskets with a clean soft cloth.

Glass shelves

• Soap and water

• Glass cleaner

• Mild liquid sprays

Allow glass to warm to room temperature before

immersing in warm water.

Exterior and handles

• Soap and water

• Non abrasive glass

cleaner

Do not use commercial household cleaners con

taining ammonia, bleach or alcohol to clean han

dles. Use a soft cloth to clean smooth handles.

Do not use a dry cloth to clean smooth doors.

Exterior and handles

(Stainless steel models

only)

• Soap and water

• Stainless steel cleaners

Never use chloride or cleaners with bleach to

clean stainless steel.

Clean stainless steel front and handles with non-

abrasive soapy water and a dishcloth. Rinse with

clean water and a soft cloth. Use a non-abrasive

stainless steel cleaner. These cleaners can be

purchased at most home improvement or major

department stores. Always follow manufacturer’s

instructions. Do not use household cleaners con

taining ammonia or bleach.

Always clean, wipe and dry with the grain to pre

vent scratching. Wash the rest of the cabinet with

warm water and mild liquid detergent. Rinse well,

and wipe dry with a clean soft cloth.

32 ENGLISH

16. TROUBLESHOOTING

Table title

Let us help you troubleshoot your concern! This section will help you with common issues. If

you need us, visit our website, chat with an agent, or call us. We may be able to help you

avoid a service visit. If you do need service, we can get that started for you!

Visit Frigidaire.com or call toll-free 1-800-374-4432.

Automatic Ice Maker

Table title

Concern Potential Cause Common solution

Ice maker is not making any ice. Ice maker is turned off. Refer to Ice Maker and Controls

and Settings.

Fresh Food Ice Maker: Press

and hold the ice maker button on

the appliance control for 3 sec

onds to turn the ice maker on.

The LED indicator illuminates to

indicate the ice maker is on.

Freezer Ice Maker: Press or slide

the power button to turn the ice

maker on. The button and LED il

luminate when active.

Refrigerator is not connected to

water line or water valve is not

open.

Connect the unit to the household

water supply and ensure the wa

ter valve is open.

The water supply line is kinked. Ensure that the supply line does

not kink when the refrigerator is

pushed into place against the

wall.

The water filter is not seated

properly.

Remove and re-install the water

filter. Be sure to seat it fully into

the locked position.

The water filter may be clogged

with foreign material.

If water dispenses slowly or not at

all, or if the filter is 6 months old

or older, it should be replaced.

ENGLISH 33

Concern Potential Cause Common solution

Ice maker is not making enough

ice.

Ice maker is producing less ice

than you expect.

The water filter may be clogged

with foreign material.

If water dispenses slower than

normal, or if the filter is six

months old or older, it should be

replaced.

Saddle valve on cold water pipe

is clogged or restricted by foreign

material.

Ensure that the supply line does

not kink when the refrigerator is

pushed into place against the

wall.

Heavy traffic, opening or closing

of the doors excessively.

Turn off household water line

valve. Remove valve. Clean

valve. Replace valve if necessary.

Freezer control is set too warm

(freezer ice maker).

Set freezer control to colder set

ting to improve performance of

the ice maker (freezer ice maker).

Allow 24 hours for temperature to

stabilize.

Water pressure is extremely low.

Cut-off and cut-on pressures are

too low (well systems only).

Have someone turn up the cut-off

and cut-on pressure on the water

pump system (well systems only).

Reverse osmosis system is in re

generative phase.

It is normal for a reverse osmosis

system to be below 20 psi during

the regenerative phase.

Freezer ice maker will not stop

making ice (some models).

Ice maker bail arm is being held

down by a package in the freezer

that has fallen against ice maker.

Move any item or frozen ice

cubes that may block the bail arm

from being in the off or upward

position.

Ice cubes are located in once

spot inside the freezer ice bin.

Periodically move ice cubes

around the ice bin so that ice

maker will continue to make ice.

Ice cubes are freezing together. Ice cubes are not being used fre

quently enough or interruption of

power for prolonged time.

Remove ice container and dis

card ice. The ice maker will pro

duce fresh supply. Ice should be

used at least twice weekly to

keep the cubes separated.

Ice cubes are hollow (shells of ice

with water inside). The hollow

cubes break open in the bin and

leak their water onto existing ice,

which causes it to freeze togeth

er.

• This generally occurs when

the ice maker does not get

enough water. This is usually

the result of a clogged water

filter or restricted water sup

ply.

• Replace the water filter and if

the condition still occurs

check for a clogged saddle

valve, water valve not turned

on all the way or kinked water

supply line.

34 ENGLISH

Ice and water dispenser

Table title

Concern Potential cause Common solution

Dispenser does not dispense ice. There is no ice in the bin to be

dispensed.

See the section above: Ice maker

is not making any ice.

The refrigerator doors are not

completely closed.

Completely close the refrigerator

doors.

Dispenser paddle has been

pressed too long and the dispens

er motor has overheated.

The motor overload protector will

reset in about 3 minutes, and

then ice can be dispensed.

Not dispensing ice regularly may

melt and re-freeze ice causing ice

clumping. Dispensing clumps

could damage the ice bucket.

Empty the ice bucket monthly or

regularly dispense ice. For longer

periods of time (vacation or va

cant homes) turn off the ice mak

er. See tips in Automatic Ice and

Water Dispenser.

Ice dispenser is jammed. Ice has melted and frozen around

auger due to infrequent use, tem

perature fluctuations, and/or pow

er outages.

Remove ice container, thaw, and

empty the contents. Clean con

tainer, wipe dry, and replace in

proper position. When new ice is

made, dispenser should operate.

See tips on cleaning in Automatic

Ice and Water Dispenser.

Ice cubes are jammed between

ice maker and back of ice con

tainer.

Remove ice cubes that are jam

ming the dispenser.

Dispenser does not dispense wa

ter.

Water filter not seated properly. Remove and reinstall the water fil

ter. For PurePour Connect™, be

sure to push the filter in all the

way until it clicks into place and is

secured inside of the water filter

housing.

Water filter is clogged. Replace filter cartridge. Be sure to

push filter all the way in until it

clicks into place and is secured

inside of the water filter housing.

Household water line valve is not

open.

Open household water line valve.

Water not cold enough. The water dispensing system is

not designed to chill water.

As warmer tap water goes

through the filter and enters the

water supply system, the chilled

water is pushed through to the

dispenser. Once the chilled water

is used up, it will take several

hours to bring the freshly re

placed water to a cooler tempera

ture.

Add ice to cup or container before

dispensing water.

Only the first 26 oz are chilled.

Water has an odd taste and/or

odor.

Water has not been dispensed for

an extended period of time.

Draw and discard 10-12 glasses

of water to freshen the supply.

The appliance not properly con

nected to cold water line.

Connect the appliance to cold wa

ter line that supplies water to the

kitchen faucet.

ENGLISH 35

Opening/Closing of Doors/Drawers

Table title

Concern Potential cause Common solution

Door(s) does not close. Door was closed too hard, caus

ing other door to open slightly.

Close both doors gently.

Refrigerator is not level. It rocks

on the floor when moved slightly.

Ensure floor is level and solid,

and can adequately support the

refrigerator. Contact a carpenter

to correct a sagging or sloping

floor.

Refrigerator is touching a wall or

cabinet.

Ensure floor is level and solid,

and can adequately support the

refrigerator. Contact a carpenter

to correct a sagging or sloping

floor.

Food/packaging is obstructing the

door from closing.

Make sure there is no food/pack

aging blocking the doorway.

Doors are not aligned. Flipper mullion on left fresh food

door is not in the correct position.

Ensure the flipper mullion is in the

correct position to allow the door

to close. Refer to Flipper Mullionin

Installation.

Drawers are difficult to move. Food is touching shelf on top of

drawer.

Remove top layer of items in

drawer.

Track that drawers slide on is

dirty.

• Ensure drawer is properly in

stalled on track.

• Clean drawer, rollers, and

track. Refer to Care and

Cleaning.

Running of appliance

Table title

Concern Potential cause Common solution

Compressor does not run. The appliance is unplugged. Ensure plug is tightly pushed into

outlet.

Refrigerator is in defrost cycle. This is normal for a fully automat

ic defrost refrigerator. The defrost

cycle occurs periodically, lasting

about 30 minutes.

House fuse blown or tripped cir

cuit breaker.

Check/replace fuse with a 15 amp

time-delay fuse.

Reset circuit breaker.

Power outage. Check house lights. Call local

electric company.

Refrigerator seems to run too

much or too long.

The variable speed compressor is

designed to run 100% of the time

except during the defrost cycle. At

times it will run faster, such as af

ter a defrost cycle.

It is normal for the compressor to

run continuously except during

defrost mode.

One compartment feels cooler

than the other after installation.

This appliance is equipped with a

refrigeration system that changes

between compartments periodi

cally.

This is normal behavior right after

installation. Allow 24 hours for the

appliance to stabilize and reach

the desired temperatures.

36 ENGLISH

Digital temperature display

Table title

Concern Potential cause Common solution

Digital temperature displays an

error.

Electronic control system has de

tected a performance problem.

Call your Frigidaire service repre

sentative, who can interpret any

messages or number codes flash

ing on the digital displays.

Water/Moisture/Frost Inside

Refrigerator

Table title

Concern Potential cause Common solution

Moisture collects on inside of re

frigerator walls.

Weather is hot and humid. The rate of frost buildup and inter

nal sweating increases.

Flipper mullion Adjust flipper mullion. Refer to

Flipper Mullion in Installation.

Door is slightly open. See the Opening/Closing of

Doors/Drawers section above.

Water collects on bottom side of

drawer cover.

Vegetables contain and give off

moisture.

• It is not unusual to have mois

ture on the bottom side of the

cover.

• Move humidity control (some

models) to lower setting.

• Both crispers contain an auto

matic humidity control, which

should adjust automatically to

the varying levels of moisture

inside the drawer without cre

ating additional condensation

or drying out the air inside the

crisper drawer, works with

various types of produce. If

you notice excess moisture,

check to verify humidity mem

brane is not damaged and re

place as necessary.

Water collects in bottom of draw

er.

Washed vegetables and fruit

drain while in the drawer.

Water collecting in bottom of

drawer is normal. Dry items be

fore putting them in the drawer or

store produce in tightly sealed

bags to help reduce condensation

inside of the drawer.

Water/Moisture/Frost Outside

Refrigerator

Table title

Concern Potential cause Common solution

Moisture collects on outside of re

frigerator or between doors.

Weather is humid. This is normal in humid weather.

When humidity is lower, the mois

ture should disappear.

Door is slightly open, causing

cold air from inside refrigerator to

meet warm air from outside.

See the Opening/Closing of

Doors/Drawers section above.

ENGLISH 37

Food in Fresh food compartment

Table title

Concern Potential cause Common solution

Food is freezing. Temperature setting is too low. Move the setting to a higher de

gree.

Temperature sensor is covered

by food (right side of fresh food

area).

Allow space for air flow to the

sensor.

Food is covering the air ports. Allow space between the air ports

and the food.

17. LIMITED WARRANTY

Your appliance is covered by a one year

limited warranty. For one year from your

date of delivery, Electrolux will pay all

costs for repairing or replacing any parts of

this appliance that prove to be defective in

materials or workmanship when such

appliance is installed, used and

maintained in accordance with the

provided instructions.

Exclusions

This warranty does not cover the following:

1. Products with original serial numbers

that have been removed, altered or

cannot be readily determined.

2. Product that has been transferred from

its original owner to another party or

removed outside the USA, Puerto

Rico, or Canada.

3. Rust on the interior or exterior of the

unit.

4. Products purchased “as-is” are not

covered by this warranty.

5. Food loss due to any refrigerator or

freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve

malfunction or defects in materials or

workmanship, or for appliances not in

ordinary household use or used other

than in accordance with the provided

instructions.

8. Service calls to correct the installation

of your appliance or to instruct you

how to use your appliance.

9. Expenses for making the appliance

accessible for servicing, such as

removal of trim, cupboards, shelves,

etc., which are not a part of the

appliance when it is shipped from the

factory.

10. Service calls to repair or replace

appliance light bulbs, air filters, water

filters, other consumables, or knobs,

handles, or other cosmetic parts.

11. Surcharges including, but not limited

to, any after hour, weekend, or holiday

service calls, tolls, ferry trip charges,

or mileage expense for service calls to

remote areas, including the state of

Alaska.

12. Damages to the finish of appliance or

home incurred during transportation or

installation, including but not limited to

floors, cabinets, walls, etc.

13. Damages caused by: services

performed by unauthorized service

companies; use of parts other than

genuine Electrolux parts or parts

obtained from persons other than

authorized service companies; or

external causes such as abuse,

misuse, inadequate power supply,

accidents, fires, or acts of God.

DISCLAIMER OF IMPLIED

WARRANTIES; LIMITATION OF

REMEDIES

CUSTOMER’S SOLE AND EXCLUSIVE

REMEDY UNDER THIS LIMITED

WARRANTY SHALL BE PRODUCT

REPAIR OR REPLACEMENT AS

PROVIDED HEREIN. CLAIMS BASED

ON IMPLIED WARRANTIES, INCLUDING

WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR

PURPOSE, ARE LIMITED TO ONE YEAR

OR THE SHORTEST PERIOD ALLOWED

BY LAW, BUT NOT LESS THAN ONE

YEAR. ELECTROLUX SHALL NOT BE

LIABLE FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES SUCH AS

PROPERTY DAMAGE AND INCIDENTAL

EXPENSES RESULTING FROM ANY

BREACH OF THIS WRITTEN LIMITED

WARRANTY OR ANY IMPLIED

38 ENGLISH

WARRANTY. SOME STATES AND

PROVINCES DO NOT ALLOW THE

EXCLUSION OR LIMITATION OF

INCIDENTAL OR CONSEQUENTIAL

DAMAGES, OR LIMITATIONS ON THE

DURATION OF IMPLIED WARRANTIES,

SO THESE LIMITATIONS OR

EXCLUSIONS MAY NOT APPLY TO

YOU. THIS WRITTEN WARRANTY

GIVES YOU SPECIFIC LEGAL RIGHTS.

YOU MAY ALSO HAVE OTHER RIGHTS

THAT VARY FROM STATE TO STATE.

If You Need Service

Keep your receipt, delivery slip, or some

other appropriate payment record to

establish the warranty period should

service be required. If service is

performed, it is in your best interest to

obtain and keep all receipts. Service under

this warranty must be obtained by

contacting Electrolux at the addresses or

phone numbers below.

This warranty only applies in the USA,

Puerto Rico and Canada. In the USA and

Puerto Rico, your appliance is warranted

by Electrolux Consumer Products, Inc. In

Canada, your appliance is warranted by

Electrolux Canada Corp. Electrolux

authorizes no person to change or add to

any obligations under this warranty.

Obligations for service and parts under

this warranty must be performed by

Electrolux or an authorized service

company. Product features or

specifications as described or illustrated

are subject to change without notice.

USA

1-800-374-4432

Electrolux Consumer Products, Inc.

10200 David Taylor Drive

Charlotte, NC 28262

Canada

1-800-265-8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga, Ontario, Canada L5V 3E4

18. QUEBEC RIGHT TO REPAIR

Though Frigidaire makes every effort to

make replacement parts, repair services

and information necessary to maintain or

repair our products available to

consumers, parts, service and information

are not guaranteed, pursuant to section 39

of the Consumer Protection Act, CQLR, c.

P-40.1 and sections 79.18 to 79.20 of the

Regulation respecting the application of

the Consumer Protection Act, CQLR, c

P-40.1, r. 3. If you need replacement

parts, you may call us at 1 (800) 265-8352

for service in French or English, or

purchase online at Frigidaire Parts |

Shop Frigidaire Replacement Parts &

Accessories - Frigidaire Appliance

Parts.

You may book repair services online at

information | Book a service | Frigidaire.

Alternatively, our resource library is

available at Resource Library | Frigidaire

to help you diagnose and resolve issues

which may arise during the lifetime of your

appliance.

Though most parts are available for

purchase, subject to short-term availability

constraints, the following appliances and

parts are not serviceable.

Legend

Availability of replacement parts, repair

services, and information for mainte

nance or repair.

Partially Available

Not Available

Available

Table title

Refrigerators Cabinet, 14cu ft and

less no sealed system

parts

Freezer 9 cu. ft and less no

sealed system parts.

Beverage

Centers

Only cosmetic parts

available

ENGLISH 39

A31247501 (December 2025)

Frigidaire PRMC2290BF Smart Counter-Depth 4-Door Refrigerator with Custom-Flex Temp Drawer and Ice/Water Dispenser

Product's Documents

Use and Care Manual.

Specifications

Frigidaire PRMC2290BF Questions and Answers

Related Products

Frigidaire FHWW104TE1 10,000 BTU Smart Window-Mounted Room Air Conditioner

Frigidaire FRFG1723S Refrigerator Counter Depth French Door 17.6 Cu Ft in Brushed Steel

Frigidaire FRFC2323SS Refrigerator Counter Depth French Door 22.6 Cu Ft in Stainless Steel

Frigidaire GRFC2353SS Refrigerator Gallery Counter Depth French Door 22.6 Cu Ft in Smudge Proof Stainless Steel

Frigidaire FRFG2011AV Counter-Depth French Door Refrigerator

Frigidaire FRFG2033AV Counter-Depth French Door Refrigerator
