Washer-Dryer
User Manual
BWD7541W
2820529346_EN/ 19-03-21.(9:19)
Document Number :
Please read this user
manual first!
Dear Customer,
Thank you for choosing a Beko product. We
hope that you get the best results from your
product which has been manufactured with
high quality and state-of-the-art technology.
Therefore, please read this entire user manual
and all other accompanying documents
carefully before using the product and keep it
as a reference for future use. If you handover
the product to someone else, give the user
manual as well. Follow all warnings and
information in the user manual.Throughout this
user manual the following symbols are used:
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
This product was manufactured using the latest technology in environmentally friendly conditions.
3 / EN
Washer-Dryer / User Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of
personal injury or property damage.
Failure to follow these instructions
shall invalidate any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities
were not fully developed or who
lack experience and knowledge
provided that they are supervised
or trained on the safe usage of the
product and the risks it brings out.
Children should not play with the
device. Cleaning and maintenance
works should not be performed by
children unless they are supervised
by someone. Children under the
age of 3 should be kept away
unless continuously supervised.
A
PRECAUTION!
• Never place the product on a
carpet-covered floor. Otherwise,
lack of airflow beneath the machine
will cause electrical parts to
overheat. This will cause problems
with your product.
• Adequate ventilation has to be
provided to avoid the back flow
of gases into the room from
appliances burning other fuels,
including open fires. Only for
ducted appliances.
A
PRECAUTION!
• The appliance must not be installed
behind a lockable door, a sliding
door or a door with a hinge on the
opposite side to that of the tumble
dryer in such a way that a full
opening of the tumble dryer door is
restricted.
C
INFORMATION
• Always have the installation
procedures carried out by the
competent persons. Manufacturer
shall not be held liable for damages
that may arise from procedures
carried out by unauthorised persons.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is the risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!
A
CAUTION!
• If the power cable is damaged,
it must be replaced by the
manufacturer, after sales service
or a similarly qualified person
(preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.
4 / EN
Washer-Dryer / User Manual
A
WARNING!
• The appliance must not be
supplied through an external
switching device, such as a timer,
or connected to a circuit that is
regularly switched on and off by a
utility.
A
PRECAUTION!
• Unplug the product when it is not
in use.
• Never touch the plug with wet
hands! Never unplug by pulling on
the cable, always unplug by holding
the plug.
• Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme,
see “Cancelling the programme”
section.
1.1.2 Product safety
B
DANGER!
• Never open the loading door or
remove the filter while there is
still water in the drum. Otherwise,
risk of flooding and injury from hot
water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
C
INFORMATION
• Do not force open the locked
loading door. The door will open
immediately after the washing
cycle has ended. If the machine
is not cooled enough at the end
of the programme, the loading
door cannot be opened. Wait for
the product to cool down. If the
door still does not open, apply the
solutions provided for “Loading
door cannot be opened” in the
Troubleshooting section. Do not
force the loading door to open.
The loading door and the lock
mechanism may get damaged.
• In the installation location of this
product, there must not be a
lockable, sliding or hinged door that
will restrict the full opening of the
loading door.
• Follow the instructions on the textile
tags and on the detergent package.
• Use only detergents, softeners and
supplements suitable for washing
machines.
• Do not install or leave this product
in places where it might be exposed
to outdoor conditions.
• Controls must not be tampered with.
5 / EN
Washer-Dryer / User Manual
C
INFORMATION
• If a non-self-resetting thermal cut-out
is required in order to comply with
the standard then the instructions for
appliances incorporating a non-self-
resetting thermal cutout that is reset
by disconnection of the supply mains
shall contain the substance of the
following:
CAUTION: In order to avoid a hazard
due to inadvertent resetting of the
thermal cut-out, this appliance must
not be supplied through an external
switching device, such as a timer, or
connected to a circuit that is regularly
switched on and off by the utility.
1.1.3 Warnings for drying
DANGER!
• Laundry that is previously washed,
cleaned, soiled or stained with
petrol / gasoline, dry cleaning
solvents or other flammable or
explosive substances must not be
dried in the machine as they give
out flammable or explosive steam.
It may cause fire risk.
• Lint must not be allowed to
accumulate around the dryer. Not
applicable for appliances intended
to be vented.
• DO NOT dry unwashed items in the
dryer.
DANGER!
• Laundry stained with Liquid
cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes and wax
removers must be washed in hot
water with plenty of detergent
before drying. It may cause fire risk.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as
a tumble dryer. The items become
warm, causing an oxidation
reaction in the oil. Oxidation creates
heat. If the heat cannot escape, the
items can become hot enough to
catch fire. Piling,stacking or storing
oil-affected items can prevent heat
from escaping and so create a fire
hazard.
• If it is unavoidable that fabrics
that contain vegetable or cooking
oil or have been contaminated by
hair care products be placed in a
tumble dryer they should first be
washed in hot water with extra
detergent – this will reduce, but not
eliminate, the hazard.
• Foam rubber (latex foam), shower
caps, waterproof textiles, clothes
or pillows with rubber support or
rubber foam pads must not be
dried with drying function. It may
cause fire risk.
• Fabric softeners or similar products
should be used as specified by the
fabric softener instructions.
6 / EN
Washer-Dryer / User Manual
DANGER!
• If you use washing ball, detergent
scale, laundry clothing cages and
balls in your machine, they can
melt during drying. Do not use
these products if drying option will
be selected. It may cause fire risk.
• When you use industrial chemicals
for cleaning, do not use drying
function. It may cause fire risk.
B
DANGER!
• Do not touch loading door glass
with bare hands after drying. There
is the risk of getting burnt.
• In order to maintain laundry in a
temperature that will prevent them
from getting damaged, a cooling step
is performed as a final step to ensure
items will not be damaged. You may
be exposed to hot steam if you open
the door before cooling is complete.
There is the risk of scalding.
B
DANGER!
• If the drying programmes
are interrupted (as a result of
programme cancellation or power
failure), laundry in the machine can
be hot. Be careful.
A
WARNING!
• Never stop the tumble dryer before
the end of the drying cycle unless all
items are quickly removed and spread
out so that the heat is dissipated.
A
CAUTION!
• Do not stop the machine before
drying programme is completed.
If you have to stop the machine,
remove all laundry and lay them in a
suitable place to let them cool down.
• Your product is suitable to operate
in ambient temperatures between
0°C and +35°C.
A
CAUTION!
• Ambient temperatures between 15°C
and +25°C are ideal temperatures
for your product.
• Do not let pets enter the product.
Check inside the product before using.
• Remove all items from the pockets
such as lighters and matches.
• Do not overload the machine for
drying. Observe the maximum load
levels specified for drying.
A
PRECAUTION!
• Do not dry leather laundry or laundry
that contains leather (such as leather
jeans label). The colour from Leather
parts can run into other textiles.
• In failures that cannot be repaired
using information given in safety
instructions, turn off the machine,
unplug the power cable and call the
Authorised Service Agent.
• You can just wash laundry, just dry
laundry or wash and dry laundry in
your washer-dryer. Machine must not
be used only to dry wet loads for a
long time. When machine is used only
for drying, it must be operated empty
without loading laundry in a short wash
programme after every 15 operation.
7 / EN
Washer-Dryer / User Manual
A
PRECAUTION!
• Check all clothes before loading them
into the machine and ensure that they
do not have objects such as lighters,
coins, metal pieces, needles in the
pockets or inside.
• Underwear with metal supports must
not be dried in the machine. Metal
supports might come off during drying
and cause damage in the machine.
Place in a bag or pillowcase.
• Do not dry large laundry such as tulle
curtain, curtain, bedding, blanket, rug
in the machine. Your laundry might get
damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use fabric softeners or static
preventers in the machine unless
recommended by the manufacturer.
• Products such as fabric softeners
must be used in accordance with
manufacturer’s instructions.
• Do not dry sensitive clothes such
as silk, wool, etc. in the machine.
Otherwise, wool clothes may get
shrunken and other sensitive
clothes may get damaged.
• Check symbols on the garment tag
before washing and drying.
• The water supply pressure required
to run the product is between 1 to
10 bars (0.1 – 1 MPa).
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must only be used for
washing, rinsing and drying of textile
products that are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect
usage or t
ransportation.
• This appliance is intended to be used
in household and similar applications
such as:
• – staff kitchen areas in shops, offices
and other working environments;
• – farm houses;
• – by clients in hotels, motels and
other residential type environments;
• – bed and breakfast type
environments;
• – areas for communal use in blocks
of flats or in launderettes.
8 / EN
Washer-Dryer / User Manual
1.3 Children's safety
A
CAUTION!
• Children below the age of 3 must be
kept away from the machine unless
they are continuously supervised.
• Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
• Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing the
detergent package.
1.4 Compliance with WEEE
Directive and disposing
of the waste product
This product does not contain harmful and
forbidden materials described in the "Regulation on
the Control of the Waste Electrical and Electronic
Equipment". It complies with the WEEE Directive.
This product has been
manufactured with high quality
parts and materials which can
be reused and are suitable for
recycling. Therefore, do not
dispose the product with normal
domestic waste at the end of its
service life. Take it to a collection
point for the recycling of electrical
and electronic equipment. Please
consult your local authorities to
learn the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power cable
and break the locking mechanism of the
loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
with normal domestic waste. Take them
to the packaging material collection points
designated by the local authorities.
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable 5- Loading door
2- Top panel 6- Filter cover
3- Control panel 7- Adjustable feet
4- Water
discharge hose
8- Detergent drawer
9 / EN
Washer-Dryer / User Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
C
INFORMATION
• Figures in this manual are schematic and may not match the product exactly.
(*) This may be supplied with the machine depending on the model of your product.
10 / EN
Washer-Dryer / User Manual
2.3 Technical specifications
Supplier name or trademark Beko
Model name BWD7541W
Maximum spin speed (rpm) 1400
Built-in No
Rated capacity - Washing (kg) of Dry clothes/laundry 7,5
Rated capacity - Drying (kg) of Dry clothes/laundry 4
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Single Water inlet / Double Water inlet
• / -
• Available
Electrical input (V/Hz) 220-240 V / 50Hz
Total current (A) 10
Total power (W) 2000-2350
VDE Main model code 1420
Rinse Spin+Drain
Prewash Fast Fast+ Extra
Rinse
Extra
Water
Anti
Crease
Pet Hair
Removal
Rinse
Hold
No
Water
Drain
Soaking
Spin No
Spin
Tap
Water
(Cold)
Steam
Time
Delay
Night
Modu
Temperature Door
Lock
Child
Lock
On/Off Start /
Pause
Soil Level Add
Garment
AutoDose Liquid
Detergent
Selection
Softener
Selection
Wash
Downloaded
Program
Steeping
Ok
(End)
Cancel
AntiCrease+ Iron
Dry
Cupboard
Dry
Extra
Dry
Timed
Drying
Clean&
Wear
Symbols Table
Drying
11 / EN
Washer-Dryer / User Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
3.2 Removing packaging
reinforcement
Tilt the machine
backwards to remove
the packaging
reinforcement.
Remove the
packaging
reinforcement
attached to
the ribbon.
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise,
the product will get damaged.
12 / EN
Washer-Dryer / User Manual
1
1 Use a tool to
loosen all bolts until
they rotate freely.
2
2 Remove the transit
bolts by turning
them slightly.
3
3 Attach the plastic
covers supplied in
the user manual
bag into the holes
on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place
to reuse when the product needs
to be moved again in the future.
• Never move the product without the
transit bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• It is necessary to have 10 – 80 liters of
water flowing from the fully open tap in
one minute to have your product run
smoothly. Attach a pressure reducing
valve if water pressure is higher.
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
1
1 Connect the special
hose supplied
with the product
to the water inlet
on the product.
A
CAUTION!
• Ensure that the cold water connection
is made correctly when installing the
product. Otherwise, your laundry
will come out hot at the end of the
washing process and wear out.
2
2 Tighten the hose
nuts securely
by hand. Never
use a tool when
tightening the nuts.
2 3
3 Open the taps
completely after
making the hose
connection to
check for water
leaks at the
connection points.
If any leak occurs, turn off the tap and
remove the nut. Retighten the nut carefully
after checking the seal. In order to prevent
the water leaks, keep the taps closed
when you do not use the product.
13 / EN
Washer-Dryer / User Manual
3.5 Connecting to the drain
• Attach the end of the drain hose directly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the hose
comes out of its housing during water
discharge. Moreover, there is risk of
scalding due to high washing temperatures!
To prevent such situations and to ensure
smooth water intake and discharge of
the machine, fix the end of the discharge
hose tightly so that it cannot displace.
90 cm
90 cm
min.40
90 cm
90
40
90
40
• Connect the hose to a minimum height of
40 cm and a maximum height of 90 cm.
• If the hose is run along the floor (or at less
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
• To prevent flowing of dirty water back into
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, add an
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the
product from upper diagonal edges.
• Otherwise, the product may move
from its place and cause crushing,
noise and vibration problems.
• Do not use any tools to loosen
the lock nuts. Otherwise, the
lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product stands level
and balanced.
c) Tighten all lock nuts again by hand.
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding
in accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Ground Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within
easy reach after installation.
14 / EN
Washer-Dryer / User Manual
• If the current value of the fuse or breaker
in the house is less than 16 Amps, have a
qualified electrician install a 16 Amp fuse.
• The voltage specified in the “Technical
specifications” section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
DANGER!
• Your product is too heavy for
one person to carry.
• Your product is heavy; two persons
must carry it and extra precaution
taken on stairs. If your product falls
on you, it may cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the
transit bolts properly fixed in place!
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, degree of soiling and
the suitable water temperature.
* Always obey the instructions
given on the garment tags.
4.2 Preparing the laundry for washing
• Underwire bras and clothes with metal pieces
such as buckles or buttons damage the
machine. Remove the metal pieces or wash
such clothes after putting them in a cotton
laundry bag or cotton pillow case. Moreover,
this type of clothes may overheat during the
drying process and damage other clothes.
Do not use the machine to dry such clothes.
• Put small size clothes such as infant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fasten zippers, sew loose buttons
and mend rips and tears.
• Wash “Machine washable” or “Hand
washable” labelled products only with
an appropriate programme. Dry them by
hanging them or laying them flat. Do not
use the machine to dry such clothes.
• Do not wash colours and whites together.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Only use the dyes / colour changers and
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.
15 / EN
Washer-Dryer / User Manual
C
INFORMATION
• Laundry that are subjected to materials
such as flour, lime dust, milk powder,
etc. intensely must be shaken off before
being placed into the machine. Such
dusts and powders on the laundry may
build up on the inner parts of the product
in time and can cause damage.
• Keep laundry items made of Angora wool in
a plastic bag in the freezer for a few hours
before washing. This can reduce piling.
• Wash trousers and delicate
laundry turned inside out.
• Tough stains must be treated
properly before washing.
• Take out all substances in the pockets
such as coins, pens and paper clips,
and turn pockets inside out and brush
if possible. Such objects may damage
the product or cause noise problem.
4.3 Tips for energy and water saving
Following information will help you use the product
in an ecological and energy/water-efficient manner.
• Operate the product in the highest load
capacity allowed for the programme you
have selected, but do not overload. See,
“Programme and consumption table”.
• Observe the temperature instructions
on the detergent packaging.
• Wash slightly soiled laundry at low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing process.
• Do not use more detergent than the
recommended on the detergent packaging.
4.4 First use
Before starting to use
the product make sure
that all preparations are
made in accordance
with the “Important
safety and environment
instructions” and the
instructions in the
“Installation” section.
To prepare the product for washing
laundry, perform first operation in Drum
Cleaning programme. If this programme
is not available on your machine, apply
the method described in section 6.2.
C
INFORMATION
• Use an anti-limescale agent
suitable for washing machines.
• Some water has remained in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the selected washing programme.
The product automatically adjusts
the water amount according to the
weight of the laundry put inside it.
A
CAUTION!
• Follow the information in the “Programme
and consumption table”. When overloaded,
machine's washing performance will
drop. Moreover, noise and vibration
problems may occur. For a good drying
performance, do not load the machine
with more laundry than recommended.
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100 Nightgown 200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s work shirts 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Place the laundry loosely in the product.
3. Push the loading door to close it until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
16 / EN
Washer-Dryer / User Manual
• The loading door is locked while a programme
is running. The door lock will open
immediately after the washing programme has
ended. If the inner part of the machine is too
hot at the end of the programme, the loading
door will not open until the temperature drops.
If the door does not open, apply the solutions
provided for "Loading Door Cannot be
Opened." error in the Troubleshooting section.
A
CAUTION!
• If the laundry is misplaced, noise and
vibration problems may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach or limescale remover,
read the manufacturer's instructions on the
package carefully and follow the suggested
dosage values. Use measuring cup if any.
4.7.1 Detergent drawer
The detergent drawer is composed
of three compartments:
1
3
2
– (1) for prewash
– (2) for main wash
– (3) for softener
–(
) in addition, there
is a siphon part in the
softener compartment.
4.7.2 Detergent, softener
and other cleaning agents
• Add detergent and softener before
starting the washing programme.
• Never leave the detergent drawer open
while the washing programme is running!
• When using a programme without prewash,
do not put liquid detergent into the prewash
compartment (compartment no. "1").
• In a programme with prewash, put
liquid detergent into the prewash
compartment (compartment no. “1”).
• Do not select a programme with prewash if
you are using a detergent bag or dispensing
ball. Place the detergent bag or the
dispensing ball directly among the laundry
in the machine. Remove them after drying.
• If you are using liquid detergent, do not forget
to place the liquid detergent container into the
main wash compartment (compartment no. 2).
• When the machine is in Drying step,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.3 Choosing the detergent type
Detergent type to be used depends on the
washing programme, fabric type and colour.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only with
special detergents (liquid detergent, wool
shampoo, etc.) intended solely for delicate
clothes and at suggested programmes.
• When washing dark coloured clothes and quilts,
it is recommended to use liquid detergent.
• Wash woollens at suggested programme with
special detergent made specifically for woollens
• Please review the programme descriptions part
for suggested programme for different textiles.
• All recommendations about detergents are valid
for selectable temperature range of programmes.
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use soap powder.
4.7.4 Adjusting the
amount of detergent
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Use less detergent for small loads,
lightly soiled clothes and short duration
programmes, especially in soft water areas.
17 / EN
Washer-Dryer / User Manual
4.7.5 Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Do not exceed the (>max<) level marking
in the softener compartment.
• If the softener has lost its fluidity or if it is
concentrated, dilute it with water before
putting it in the detergent drawer.
4.7.6 Using liquid detergents
4.7.6.1 If the product contains
a liquid detergent container
• Place the liquid detergent container
in compartment no. “2”.
• If the liquid detergent has lost its fluidity, dilute it
with water before putting in the compartment.
2
4.7.6.2 If the product is equipped
with a liquid detergent apparatus:
• When you want to use liquid detergent,
press on the point shown to rotate the
apparatus. The part that falls off will function
as a barrier for the liquid detergent.
•
If required, clean the apparatus with water
when it is in place or by removing it.
• If you will use powder detergent, the
apparatus must be secured at top position.
4.7.6.3 If the product does not
contain a liquid detergent container
• Do not use liquid detergent for the
prewash in a programme with prewash.
• Liquid detergent stains your clothes
when used with Delayed Start function.
If you are going to use the Delayed Start
function, do not use liquid detergent.
4.7.7 Using gel and tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special
liquid detergent container, put the gel
detergent into the main wash detergent
compartment during first water intake. If
your machine contains a liquid detergent
container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment no. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in the
detergent compartment. If you encounter
such residues, place the tablet detergent
between the laundry, close to the lower
part of the drum in future washings.
• Use the tablet or gel detergent without
selecting the prewash function.
C
INFORMATION
• Before drying, remember to remove
objects such as the plastic detergent
container from the drum.
4.7.8 Using laundry starch
• Add liquid starch, powder starch or the
fabric dye into the softener compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.
4.7.9 Using bleach
• Select a programme with prewash and add the
bleach at the beginning of the prewash. Do not
put detergent in the prewash compartment.
Alternatively, select a programme with an
extra drying step, add the bleach to the empty
detergent compartment and once you see the
rinsing step on the display for the first time, add
1 glass of water into the same compartment.
18 / EN
Washer-Dryer / User Manual
• Do not use bleach and detergent
by mixing them.
• Use just a little amount (approximately
50 ml) of bleach and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the coloured items.
• When using oxygen-based bleaches,
select a programme that washes the
laundry at a low temperature.
• You can use oxygen-based bleaches
together with the detergent. However, if it
has a different consistency, first add the
detergent into the detergent compartment
no “2” and wait for the machine to take in
the detergent together with water. While
the product continues taking in water,
add bleach in the same compartment.
4.7.10 Using limescale remover
• When required, use limescale
removers manufactured specifically
for washing machines only.
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites
Colours
Black/Dark
Colours
Delicates/
Woollens/Silks
(Recommended temperature range
based on soiling level: 40-90˚C)
(Recommended temperature range
based on soiling level: cold -40˚C)
(Recommended
temperature range based
on soiling level: cold -40˚C)
(Recommended temperature
range based on soiling level:
cold -30˚C)
Soiling Level
Heavily Soiled
(difficult stains such as grass,
coffee, fruits and blood.)
It may be necessary to pre-treat the
stains or perform prewash. Powder
and liquid detergents recommended
for whites can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for coloured
laundry can be used at dosages
recommended for heavily soiled
clothes. It is recommended to use
powder detergents to clean clay and
soil stains and the stains that are
sensitive to bleaches. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes
must be washed with special
woollen detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
normally soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes
must be washed with special
woollen detergents.
Lightly
Soiled
(No visible stains
exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended for
lightly soiled clothes.
Powder and liquid detergents
recommended for colours can be
used at dosages recommended for
lightly soiled clothes. Detergents
which do not contain bleach should
be used.
Liquid detergents suitable
for colours and dark
colours can be used at
dosages recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate clothes.
Woollen and silk clothes
must be washed with special
woollen detergents.
19 / EN
Washer-Dryer / User Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Washing and Drying Wash&Wear
Types of Clothes
Durable Clothes with
Cotton-Content
Sheet, bedding, baby
clothes, t-shirts, sweatshirts,
durable knit clothing, jeans,
canvas trousers, shirts,
cotton socks etc.
Not recommended!
Washes and dries
respectively! Sheet,
bedding, baby clothes,
t-shirts, sweatshirts,
durable knit clothing,
jeans, canvas trousers,
shirts, cotton socks etc.
Washes and dries respectively!
Sheet, bedding, baby clothes,
t-shirts, sweatshirts, durable
knit clothing, jeans, canvas
trousers, shirts, cotton socks
etc.
Stainless clothes that has
been worn for a short time
such as shirts, t-shirts,
sweatshirts A very small
amount of laundry must
be loaded.
Synthetics Clothes
(Polyester, nylon, etc.)
Not recommended!
It is recommended for the
polyester, nylon, polyacetate,
acrylic-content clothes. Drying
is not recommended for the
viscose-content clothes. Drying
explanations in the maintenance
label should be taken into
account.
It is recommended
for polyester, nylon,
polyacetate, acrylic
content clothes at low
temperatures, taking into
account the washing and
drying warnings on the
care label.
It is recommended for
polyester, nylon, polyacetate,
acrylic content clothes at low
temperatures, taking into
account the washing and
drying warnings on the care
label.
Lightly soiled and stainless
shirts, t-shirts and
synthetic-content clothes.
A very small amount of
laundry should be loaded.
Delicate (Silk, Woollens,
Cashmere, Angora wool,
etc. content) Clothes
Not recommended! Not recommended! Not recommended! Not recommended! Not recommended!
Bulky laundry such
as blankets, coats,
curtains etc.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is not
appropriate to dry bulky laundry
in the washer. Dry them by
hanging them or laying them flat.
Not recommended! It
is not appropriate to
dry bulky laundry in the
washer. Dry them by
hanging them or laying
them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
Not recommended! It is
not appropriate to dry bulky
laundry in the washer. Dry
them by hanging them or
laying them flat.
4.10 Displayed Programme Time
You can see the programme duration
on the display of your machine while
selecting a programme. Depending on the
amount of laundry you have loaded into
your machine, foaming, unbalanced load
conditions, fluctuations in power supply,
water pressure and programme settings,
the programme duration is automatically
adjusted while the programme is running.
SPECIAL CASE:
At programme start of
Cottons and Cotton Eco programmes,
display shows the duration of half load,
which is the most common use case. After
programme starts, in 20-25 minutes actual
load is detected by the machine. And if the
detected load is higher than half load; washing
programme will be adjusted accordingly and
programme duration increased automatically.
You may follow this change on the display.
20 / EN
Washer-Dryer / User Manual
5 Operating the product
5.1 Control panel
1 - Programme selection knob
2 - Temperature level lights
3 - Spin speed level lights
4 - Display
5 - Start/Pause button
6 - Remote Control button
7 - End Time Adjustment button
8 - Drying Level Adjustment Button
9 - Auxiliary function button 2
10 - Auxiliary function button 1
11 - Spin speed adjustment button
12 - Temperature adjustment button
5.2 Display Symbols
1400
1200
800
600
90
˚
60
˚
40
˚
30
˚
20
˚
a b c d e
f
h
g
ikl jno mpr
a - Temperature indicator
b - Spin speed indicator
c - Duration information
d - Door lock engaged symbol
e - Programme follow-up indicator
f - No water indicator
g - Add laundry indicator
h - Bluetooth connection indicator
i - Remote Control indicator
j - Delayed Start enabled indicator
k - Drying level indicator
l - Child lock enabled symbol
m - Auxiliary function indicators 2
n - Auxiliary function indicators 1
o - No spin indicator
p - Rinse hold indicator
r - Cold water indicator
5.3 Preparing the Machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4. Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting a washing
programme
1. In accordance with the “Programme
and consumption table”, select a
suitable programme for the amount
and soiling level of the laundry.
2. Select the desired programme with
the
Programme Selection
knob.
C
INFORMATION
• Programmes are limited to the
highest spin speed appropriate for
that particular type of fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
• Always select the lowest appropriate
temperature. Higher temperature means
higher electricity consumption.
5.5 Washing programmes
Depending on the type of fabric, use
the following main programmes.
C
INFORMATION
• After selecting a washing programme suitable
for your laundry, you can press the Drying
button to set the machine to perform drying
after the washing programme. Each time you
press the button, info line shows at which
step the drying process will take place and
the relevant symbol will turn on. If you want,
you can keep pressing the button to perform
drying for the maximum period allowed.
• The symbols shown on the display
are schematic and may not
match the product exactly.
• When you will perform washing and
drying by using the Drying function of your
machine, load maximum 4 kg of laundry
into the machine. If you exceed the capacity
of the machine, your laundry will not dry
and the machine will work longer, which
will result in more energy consumption.
1
2 3 4
79 8101112
6 5
21 / EN
Washer-Dryer / User Manual
• Cottons
You can wash your durable cotton laundry
(sheets, bedlinen, towels, bathrobes, underwear
etc.) in this programme. When you press the
quick wash function key, programme duration
becomes notably shorter but effective washing is
ensured thanks to intense washing movements.
If the quick wash function is not selected,
superior washing and rinsing performance
is ensured for your heavily soiled laundry.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Synthetics
You can use this programme to wash
t-shirts, syntetic/cotton mix fabrics etc.
Programme duration is notably shorter and
efficient washing performance is ensured.
If the quick wash function is not selected,
superior washing and rinsing performance
is ensured for your heavily soiled laundry.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Wool / Hand Wash
Use this programme to wash your woolen
clothes. Select the appropriate temperature
complying with the tag of your clothes. Your
laundry will be washed with very delicate
movements to avoid any damage.
C
INFORMATION
• The drying function cannot be
selected for the washing programme
designed for woolen laundry.
• Cottons Eco
Use to wash your normally soiled, durable
cotton and linen laundry. Although it washes
longer than all other programmes, it provides
high energy and water savings. Actual
water temperature may be different from the
washing temperature stated. When washing
less amount of laundry (e.g. half the capacity
or less), duration of programme steps may
automatically become shorter. In this case,
energy and water consumption will decrease
more, providing a more economic wash.
Normally soiled laundry may be washed
with reduced amount of detergent to save
energy and protect the environment.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
22 / EN
Washer-Dryer / User Manual
• Daily-Quick / Quick 14’
Use this programme to wash your lightly soiled
cotton clothes in a short time. The programme
duration can be reduced down to 14 minutes
when the quick wash function is selected. When
the quick wash function is selected, maximum
2 (two) kg of laundry must be washed.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Shirts
Use this programme to wash shirts made of
cotton and synthetic blended fabrics together.
This programme ensures that your clothes
wrinkle less. When the quick wash function is
selected, the Pre-treatment algorithm is used.
• Apply the pre-treatment chemical
directly onto the clothes, or add it together
with the detergent to the powder detergent
compartment when the machine starts
to take in water. This way, it will take you
much shorter to get the performance you
would normally get with a regular washing
cycle. Life of your shirts will be longer.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Down Wear
Use this programme to wash down coats, vests,
jackets etc. that bear a “machine-washable” tag.
Thanks to special spin profiles, it is ensured that
water reaches the air gaps between feathers.
• Downloaded Program
This is a special programme that allows you to
download different programmes when you want
to. At the start, there is a programme you will
see with the HomeWhiz application as default.
However, you can use the HomeWhiz application
to select a programme from the predefined
programme settings, and then change it.
C
INFORMATION
• If you wish to use the HomeWhiz and
Remote Control functions, you need to
select Download Programme. Please
see the section HomeWhiz and Remote
Control Function for more details.
23 / EN
Washer-Dryer / User Manual
• Mix
You can use this programme to wash cottons and
synthetics together without the need to sort them.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Outdoor / Sports
Use this programme to wash outdoor/sports
clothes that contain cotton/synthetic mix, as
well as waterproof cloths like gore-tex. This
programme washes your laundry delicately
thanks to its special turning movements.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Dark Care / Jeans
Use this programme to preserve the colour
of your dark-coloured clothes and jeans. This
programme provides high efficiency in washing,
thanks to a special drum movement, even at low
temperatures. It is recommended to use liquid
detergent or woolen shampoo for dark coloured
laundry. Do not wash your delicate clothes
that contain wool etc. in this programme.
C
INFORMATION
• You can dry your laundry without any
interruption right after the washing
programme (it is possible to perform
automatic or scheduled drying after
the washing cycle). For this, you must
also select the Drying function before
starting the washing programme.
• According to the drying selections you
will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don't want drying to take place
after the programme you have selected,
press and hold the Drying auxiliary function
button until the Drying light turns off.
• Lingerie
You can use this programme to wash delicate
garments that are suitable for hand wash
and delicate women’s underwear. Small
amount of garments must be washed in a
washing net. Hooks, buttons etc. must be
done up and zips must be zipped up.
• Towel
Use this program to wash durable cotton
laundry such as towels. Load the towels into the
machine paying attention to place them in a way
that they will not contact the bellow or the glass.
• Rinse
Use when you want to rinse or starch separately.
• Spin+Drain
Use this programme to drain
the water in the machine.
5.6 Temperature selection
-
-
-
-
-
-
Whenever a new programme is selected,
the temperature recommended for that
programme appears on the temperature
indicator. It is possible that the recommended
temperature is not the highest value that can
be selected for the relevant programme.
24 / EN
Washer-Dryer / User Manual
Press the
Temperature Adjustment
key to change the temperature.
C
INFORMATION
• Temperature Adjustment button works only
backwards. For example, if the display
shows 40°C but you want to select 60°C,
you will need to press the button for a few
times until you reach 60°C from 40°C.
C
INFORMATION
• If you scroll to Cold Wash option and press
the Temperature Adjustment button again,
the recommended maximum temperature for
the selected programme will appear on the
display. To decrease the temperature, press
the Temperature Adjustment button again.
Finally, the Cold light will turn
on, indicating cold wash.
You can also change the temperature after
the washing cycle has started. You can select
the desired temperature after the washing
programme has started. However, you need
to do this before the heating step starts.
5.7 Spin speed selection
-
-
-
-
-
-
Whenever a new programme is
selected, the spin speed recommended
for the selected programme appears
on the
Spin Speed
indicator.
C
INFORMATION
• It is possible that the recommended spin
speed is not the highest value that can
be selected for the relevant programme.
Press the
Spin Speed Adjustment
button to change the spin speed.
Spin speed decreases gradually.
Then, depending on the model of the
product, "Rinse Hold" and "No Spin"
options appear on the display.
C
INFORMATION
• Spin Speed Adjustment button works
only backwards. For example, if the
display shows 800 rpm but you want
to select 1000 rpm, you will need to
press the button for a few times until
you reach 1000 rpm from 800 rpm.
5.7.1 If you want to spin your laundry
after the Rinse Hold function:
- Adjust the
Spin Speed
.
- Press the
Start/Pause
button.
Programme will resume. The machine will
drain the water and spin the clothes.
If you want to drain the water at the end
of the programme without spinning,
you can use the
No Spin
function.
C
INFORMATION
• If you press the Spin Speed adjustment
button in programmes where the spin
speed is not allowed, the spin speed setting
will not change and you will hear a warning.
You can also change the spin speed after
the washing cycle has started. After the
washing cycle has ended, you can press
the spin speed adjustment button to select
a spin speed. However, you need to do
this before the spinning step begins.
5.7.2 Auxiliary function
selection for drying
-
-
-
-
When you select a new washing
programme, press the Auxiliary Function
Selection button to set the drying
option suitable for this programme.
C
INFORMATION
• If you press the Drying auxiliary function
button in programmes where the drying
step is not allowed, the drying light will
not change and you will hear a warning.
25 / EN
Washer-Dryer / User Manual
C
INFORMATION
• Only for dying programmes, press the
Auxiliary Function Selection button
to set the suitable drying option.
5.8 Drying programmes
A
CAUTION!
• During the drying programme, the
machine automatically removes the lints
coming from the clothes. The machine
uses water in the drying step. For this
reason, water tap of the machine should
be open also in the drying programmes.
• When you select a new washing
programme, press the Auxiliary Function
Selection button to set the drying
option suitable for this programme.
C
INFORMATION
• There is a spinning step in the drying
programmes. Your machine performs
this process in order to shorten the
drying time. While the drying programme
is selected, the spin speed setting is
within the Maximum spin speed range.
• If you press the Drying auxiliary function
button in programmes where the drying
step is not allowed, the drying light will
not change and you will hear a warning.
• Only for dying programmes, press the
Auxiliary Function Selection button
to set the suitable drying option.
• In case of water outage, washing
or drying cannot be performed.
• Synthetic Dry
Use this programme to dry synthetic
clothes with dry weight up to 3 kg. You can
perform only drying in this programme.
C
INFORMATION
• For dry wright of laundry, see
Section 4, Step 4.5.
• Cotton Dry
Use this programme to dry cotton clothes
with dry weight up to 4 kg. You can
perform only drying in this programme.
C
INFORMATION
• If you are going to dry laundry that
comprises only towels and bathrobes,
the maximum amount of laundry
that can be loaded is 4 kg.
• For dry wright of laundry, see
Section 4, Step 4.5.
5.9 Washing and drying
programmes
A
CAUTION!
• During the drying programme, the
machine automatically removes the lints
coming from the clothes. The machine
uses water in the drying step. For this
reason, water tap of the machine should
be open also in the drying programmes.
• 4 kg Wash & Dry
Use this programme to wash cotton laundry of
up to 4 kg and to dry right after the washing
programme without making any other selection.
C
INFORMATION
• When this programme is selected,
the external Drying auxiliary
function cannot be selected.
In the 4 kg Washing and 4 kg Drying
programme, it is recommended to load the
machine up to the level shown above for
ideal drying conditions (you can see the
level arrow if you open the loading door).
• Wash & Wear
Use this programme to wash 0.5 kg of
laundry (2 shirts) in 40 minutes or 1 kg
of laundry (5 shirts) in 60 minutes.
26 / EN
Washer-Dryer / User Manual
C
INFORMATION
• The Wash&Wear programme is designed
to quickly wash and dry daily clothes
that have been worn for a short time and
are not heavily soiled. This programme
is suitable for thin-textured clothes
that dry quickly (shirts, t-shirts).
• Other drying options or programmes
should be used for thick texture
laundry that takes long to dry.
• Anti Allergy+ Wash & Dry
Applying a steam step at the beginning of the
programme allows to soften the dirt easily.
Use this programme to wash and quickly
dry laundry (up to 2 kg) that requires anti-
allergic and hygienic washing (cottons such
as baby clothes, sheets and underwear).
C
INFORMATION
• The Hygiene+ programme has been tested and
approved by the “British Allergy Foundation”
(Allergy UK) based in the United Kingdom.
EN
1
Auxiliary functions
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption
(kWh)
Max. Speed***
Steam
Fast+
Prewash
Anti-Crease+
Drying (max 4 kg)
Selectable
temperature
range °C
Cottons
90
7,5 90 2,50
1400
• • • • •
Cold - 90
60
7,5 90 1,80
1400
• • • • •
Cold - 90
40
7,5 88 0,97
1400
• • • • •
Cold - 90
Cottons Eco 40**
7,5 77 0,840
1400
•
Cold - 60
Synthetics
60
3 60 1,35 1200 • • • • •
Cold - 60
40
3 58 0,85 1200 • • • • •
Cold - 60
Daily-Quick / Quick 14’
90
7,5 68 2,20 1400 • • • •
Cold - 90
60
7,5 68 1,20 1400 • • • •
Cold - 90
30
7,5 68 0,20 1400 • • • •
Cold - 90
Daily-Quick / Quick 14’ + Fast+ 30
2 40 0,15 1400 • • • •
Cold - 90
Wool / Hand Wash 40
1,5 55 0,50 1200
Cold - 40
Down Wear 60
2 75 1,30 1000 •
Cold - 60
Shirts 60
3 63 1,23 800 • • • • •
Cold - 60
Drum Clean+ 90
- 76 2,60 600 * *
90
Downloaded Program *****
Mix 40
3,5 70 0,90 800 • • • • •
Cold - 40
Outdoor / Sports 40
3,5 52 0,65 1200 • •
Cold - 40
Dark Care / Jeans 40
3,5 70 0,85 1200 • • • • •
Cold - 40
Towel 60
1 86 1,20 1000
• Cold - 60
Lingerie 30
1 65 0,56 600
Cold - 30
5.10 Programme and consumption table (for washing)
C
INFORMATION
•
Note for test institutions:
Data required for performance tests shall be provided upon request.Requests can be e-mailed to the following address:
•
Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your
contact information. Code, stock and serial numbers of the product is located on the type label attached to the inside of the door.
27 / EN
Washer-Dryer / User Manual
• : Selectable.
* : Automatically selected, cannot be cancelled.
** : Energy Label programme
***: If the maximum spin speed of the machine is lower, you can
select values up to the maximum spin speed value.
*****: These programmes can be used with the HomeWhiz application.
- : See the programme description for maximum load.
C
INFORMATION
• The auxiliary functions in the table may vary according to the model of your machine.
• Water and power consumption may vary subject to the changes in water pressure, water
hardness and water temperature, ambient temperature, type and amount of laundry, selection of
auxiliary functions and spin speed, and changes in the mains voltage.
• When selecting a programme, you can see the washing duration on the display of your machine.
Depending on the amount of laundry you have loaded into the machine, there might be a
difference of 1 to 1.5 hours between the duration shown on the display and the actual duration
of the washing programme. The duration will be corrected automatically right after the washing
programme has started.
• "Auxiliary function selection modes can be changed by the manufacturing company.
New selection models may be added, or the existing ones may be removed.”
• "Spin speed of your machine may vary depending on the programme; the
spin speed cannot exceed the maximum spin speed of your machine."
EN 1 Auxiliary functions Drying level
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Steam
Prewash
Fast+
Anti-Crease+
Drying (max 4 kg)
Extra Dry
Cupboard Dry
Iron Dry
Time based drying - minutes
Selectable
temperature
range °C
Cotton Dry -
4 45 3,20
1400
• * • • • •
-
Synthetic Dry -
3 30 2,10 - • * • • •
-
Anti Allergy+ Wash & Dry 60
2 120
3,80 1400
* • * • • • •
90-30
4 kg Wash & Dry 60
4 94
5,00 1400
• * • • • •
60-Cold
Wash & Wear 30
0,5 35 0,60 1200 • * •
30-Cold
Wash & Wear 30
1 44 1,00 1200 • * •
30-Cold
Programme and consumption table (for drying)
28 / EN
Washer-Dryer / User Manual
5.11 Auxiliary function selection
Select the desired auxiliary functions before starting
the programme. When a programme is selected,
lights of the auxiliary functions that can be selected
together with that programme will turn on.
-
-
-
-
C
INFORMATION
• Lights of the auxiliary functions that
cannot be selected together with the
selected programme will not turn on. If
you press the buttons of these auxiliary
functions, you will hear a warning
and selection will be disabled.
If the washing programme has reached a
point where an auxiliary function cannot be
selected, you cannot select any function.
C
INFORMATION
• Some functions cannot be selected
together. If a second auxiliary function
conflicting with the first one is selected
before starting the machine, the
function selected first will be canceled
and the second auxiliary function
selection will remain active.
• An auxiliary function which is not compatible
with the programme cannot be selected.
(See "Programme and consumption table")
• Some programmes have auxiliary
functions that must run together with the
selected programme. These functions
cannot be cancelled. The light of the
relevant auxiliary function is already on.
C
INFORMATION
• If the selected wetness level (Iron Dry,
Cupboard Dry, Cupboard Extra Dry)
cannot be reached at the end of the
drying programme, your machine will
automatically extent the programme
duration. The programme will take longer.
• If Timed Drying is selected, the programme
will end at the end of the drying time
even if the laundry is not dry.
• If, during the drying programme, the selected
wetness level (Iron Dry, Cupboard Dry,
Cupboard Extra Dry) is reached or extra
dryness is detected in the timed drying
options, the programme will take shorter. The
time decrease will be shown on the display.
5.11.1 Auxiliary Functions
• Prewash
A Prewash is required only for heavily
soiled laundry. Not using the Prewash will
save energy, water, detergent and time.
• Fast+
You can press the Quick Wash button to
shorten the programme time after selecting
the programme. For some programmes, the
time can be shortened by over 50%. Still, for
medium and lightly soiled laundry, you will get
the same washing results in a shorter time.
Although it depends on the programme,
pressing the Quick Wash button once will
shorten the programme time down to a certain
level. Press the same button for the second
time to drop the time to the minimum level.
For better washing results, do not use the
Quick Wash button for heavily soiled laundry.
For medium and lightly soiled laundry, use the
Quick Wash button to shorten the programme time.
29 / EN
Washer-Dryer / User Manual
• Remote Control
/
You can use this auxiliary function button
to connect your product to smart devices.
For detailed information, see HomeWhiz
and the Remote Control Function.
• Custom Programme
This auxiliary function can be used for
Cottons and Synthetics programmes only
with the HomeWhiz application. When
this auxiliary function is enabled, you can
add up to 4 additional rinse steps to the
programme. You can select and use some
auxiliary functions even though they are not
found on your product. You can increase
and decrease the time of the Cottons and
Synthetics programmes within a safe range.
• Drying (max 4 kg)
This function dries your laundry after the washing
cycle. Please see the programme table for
programmes that can be used with this function.
5.11.2 Functions/Programmes
Selected by Pressing the
Function Buttons for 3 Seconds
• Drum Clean+
To select this programme, press and hold the
auxiliary function button 1 for 3 seconds. Use
regularly (once in every 1-2 months) to clean the
drum and provide the required hygiene. Before
the programme, it applies steam to soften
residues in the drum. Operate the programme
while the machine is completely empty. To obtain
better results, put powder lime-scale remover
for washing machines into the detergent
compartment no. “2”. This programme contains
a drying step that runs after the drum cleaning
step to dry the inside of the machine.
C
INFORMATION
• This is not a washing programme.
It is a maintenance programme.
• Do not run this programme when
there are any objects in the machine.
If you try to do so, the machine will
automatically detect that there is load
inside and abort the programme.
• Anti-Crease+
/
If you press and hold the spin selection button
for 3 seconds, this function will be selected
and the programme follow-up light of the
relevant programme will turn on. When this
function is selected, it aerates the laundry for
up to 8 hours at the end of the programme
to prevent creasing. You can cancel the
programme and take your laundry out at any
time during the 8-hour duration. Press the
function selection key or the machine on/off
key to cancel the function. The programme
follow-up light will remain on until the function
is canceled or the step is complete. If the
function cannot be cancelled, it will be active
in the subsequent washing cycles as well.
• Steam
/
You can press and hold the auxiliary function
key 2 for 3 seconds to select this function.
Use this programme to reduce the
wrinkles and shorten the ironing times
for a small amount of cotton, synthetic
or mixed clothes that are not stained.
• Child lock
You can use the Child Lock to prevent children
from tampering with the machine. Thus you can
avoid any changes in a running programme.
C
INFORMATION
• When the Child Lock is enabled, you
can press the On/Off key to switch the
machine on or off. Programme resumes
when you start the machine again.
• You will hear a warning if the buttons
are pressed while Child Lock is
enabled. This audible warning
will be canceled if the buttons are
pressed five times consecutively.
To enable Child Lock:
Press and hold the Drying Level
Adjustment button
for 3 seconds. When
the countdown
“3-2-1”
on the display
ends, child lock icon will be displayed. Once
you see this warning, you can release the
Drying Level Adjustment button
.
To disable Child Lock:
Press and hold the Drying Level
Adjustment button
for 3 seconds. When
the countdown
“3-2-1”
on the display
ends, child lock icon will disappear.
30 / EN
Washer-Dryer / User Manual
• Bluetooth
You can use the Bluetooth connection function
to pair your machine with your smart device.
This way, you can use your smart device to get
information about your machine and control it.
To enable Bluetooth:
Press and hold the Remote Control
function button
for 3 seconds. You will
see the countdown
“3-2-1”
, and bluetooth
symbol will be displayed. Release the
Remote
Control function button
. The Bluetooth
icon will flash while the product is being paired
with the smart device. If the connection is
successful, the light of the icon will remain on.
To disable Bluetooth:
Press and hold the Remote Control
function button
for 3 seconds. You
will see the countdown
“3-2-1”
, and
bluetooth symbol will be disappear.
C
INFORMATION
• You must complete the first setup of
the HomeWhiz app for Bluetooth to be
enabled. After the setup, if you press the
Remote Control function button while the
button is in the Programme Download/
Remote Control position, the Bluetooth
connection will be enabled automatically.
5.12 Drying steps
-
-
-
-
5.12.1 Iron Dry /
Drying continues until the drying
level reaches the Iron Dry step.
5.12.2 Cupboard Dry
/
Drying continues until the drying level
reaches the Cupboard Dry step.
5.12.3 Extra Dry
/
Drying continues until the drying level
reaches the Cupboard Extra Dry step.
C
INFORMATION
• The dryness level might change depending
on the mix of laundry, type of material,
amount and wetness level of the laundry.
• Do not use the machine to dry laundry that
contains lace, tulle, bling, beads, paillette,
wire etc. or laundry with high silk content.
5.12.4 Time based drying
- minutes
/
You can select 30, 90 or 150 minutes
drying to reach the desired dryness
level at a low temperature.
C
INFORMATION
• When drying small amount of laundry
(2 pieces maximum), select the
timed drying steps in the Cottons or
Synthetics drying programmes.
• If the laundry has not reached the
desired dryness level at the end of the
drying programme, you can select
timed drying to end the process.
• When this function is selected, the
machine performs drying for the adjusted
time irrespective of the drying level.
5.13 Time display
While the programme is running, the time
remaining to the end of the programme will be
displayed in hours and minutes, e.g. “01:30”.
C
INFORMATION
• Programme time may differ from the values
in section "Programme and consumption
table" depending on the water pressure,
water hardness and temperature, ambient
temperature, amount and the type of
laundry, auxiliary functions selected and
the changes in the mains voltage.
31 / EN
Washer-Dryer / User Manual
5.14 End Time
-
With the
End Time
function, start of
the programme can be delayed up to
24 hours. After pressing the
End Time
button, the programme's estimated end
time will be displayed. If an
End Time
is
set, the
End Time
light will turn on.
To ensure that the End Time function is
enabled and the program ends at the end of
the defined duration, you should press
Start
/ Pause
after setting the duration. The
Start/
Pause
button will stop flashing and remain on.
If you want to cancel End Time function,
press the
End Time
button until the End
Time light turns off or press the
On/Off
button to turn off and on the machine.
1. Open the loading door, place the
laundry and add detergent, etc.
2. Select the washing programme,
temperature, spin speed and, if
required, the auxiliary functions.
3. Press the
End Time
button to set the desired
end time. The
End Time
light will turn on.
4. Press the
Start / Pause
button. Countdown
will start. ":" sign in the middle of the end
time on the display will start flashing.
C
INFORMATION
• Do not use liquid detergents when
you enable the End Time function!
Stains might remain on the clothes.
• The door will remain locked during the End
Time countdown. If you want to unlock
the door, press the programme start/
pause button to switch the machine to
pause mode. At the end of the countdown,
End Time indicator turns off, washing
cycle starts and the time of the selected
programme appears on the display.
• When End Time is selected, the time
displayed on the screen consists
of the end time plus the duration
of the selected programme.
5.15 Starting the programme
1. Press the
Start/Pause
button
to start the programme.
2. The flashing light of the
Start/Pause
button will remain on, indicating that
the programme has started.
3. Loading door will be locked. When
the door is being locked, “Locking
Door” warning will be displayed.
5.16 Loading door lock
There is a locking system on the loading
door of the machine that prevents opening
of the loading door when the water
level is unsuitable to open the door.
"Loading door locked" light on the panel
turns on when the loading door is locked.
C
INFORMATION
• The door will be locked if the Remote
Control function is selected. To open the
door, you need to press the Remote Control
key or change the programme position to
deactivate the Remote Control function.
Opening the loading door in
case of power failure:
C
INFORMATION
• In case of a power failure, you may open the
loading door manually using the emergency
handle under the pump filter cover.
A
WARNING!
• Make sure that no water remains inside
the machine to prevent overflow of water
before opening the loading door.
32 / EN
Washer-Dryer / User Manual
•
Turn off and unplug the appliance.
•
Open the pump filter cover.
•
Remove the loading door emergency
handle behind the filter cover with a tool.
•
Open the loading door by pulling the loading
door emergency handle downwards.
•
Try to pull the handle downwards again
if the loading door is not opened.
•
Bring the loading door emergency handle to its
original position after opening the loading door.
5.17 Changing the selections
after programme has started
5.17.1 Adding laundry after the
programme has started
/ :
When you press the
Start/Pause
button, the
“Loading door locked” light on the panel will go
off if the water level in the machine is suitable.
If the water level in the machine is not suitable
when you press the
Start/Pause
button, the
panel will warn you that the door is closed.
5.17.2 Switching the
machine to pause mode
Press the
Start/Pause
button to
switch the machine to pause mode.
5.17.3 Changing the
programme selection after
the programme has started:
If Child Lock is not enabled, you can change
programme while the current one is running.
This will cancel the current programme.
C
INFORMATION
• The newly selected programme
will start anew.
5.17.4 Changing the auxiliary
function, spin speed and
temperature settings
Depending on the step the programme has
reached, you can cancel or select auxiliary
functions. See “Auxiliary function selection”.
Also, you can change the spin speed,
temperature and drying settings. See "Spin
speed selection" and "Temperature selection".
C
INFORMATION
• If the temperature of the water inside the
machine is high or if the water level is above
the door line, the loading door will not open.
33 / EN
Washer-Dryer / User Manual
5.18 Cancelling the programme
The programme will be cancelled if the
programme selection knob is switched to
another programme or if the machine is
switched off and on with this button.
C
INFORMATION
• The programme will not be cancelled
if you turn the programme selection
knob while child lock is enabled. You
should cancel the Child Lock first.
• If you want to open the loading door after
you have cancelled the programme but
you cannot do it since the water level in
the machine is above the loading door
baseline, turn the Programme Selection
knob to Pump+Spin programme and
discharge the water in the machine.
5.19 End of programme
Once the programme is completed,
the End symbol will be displayed.
If you do not press any button for 10 minutes,
the machine will switch to OFF mode.
Display and all indicators are turned off.
If you press any button, the completed
programme steps will be displayed.
5.20 Your machine has the
"Pause Mode" function.
After using the On/Off button to switch on the
machine, if you do not start any programme in
the selection step or do not perform anything
else, or if you do not do anything in 2 minutes
after the selected programme has ended, the
programme will automatically switch to energy
saving mode. Also, if your product has a display
that shows programme time, this display will be
completely turned off. If you turn the programme
knob or touch any button, the lights will switch
back to previous position. The selections you
make when exiting the energy efficiency mode
may change. Check if your selections are correct
before starting the programme. If necessary,
make adjustments again. This is not an error.
5.21 HomeWhiz and the
Remote Control Function
HomeWhiz allows you to use your smart device
to control your washing machine and get
information about it. Thanks to the HomeWhiz
application, you can use your smart device
to carry out some procedures you can also
do on the machine. Plus, you can use some
features only with the HomeWhiz function.
To use the Bluetooth function of your machine,
you should download the HomeWhiz app
from the application store of your device.
Make sure that your smart device is
connected to internet to download the app.
If you are using the app for the first time,
please follow the on-screen instructions
to complete the user registration process.
Once the registration is complete, you
can use all products with the HomeWhiz
feature in your house on this account.
On the HomeWhiz app, you can tap
“Add/Remove Appliance” to see the
products paired with your account. You
can pair these products on this page.
C
INFORMATION
• To be able to use the HomeWhiz function,
make sure that the app is installed on
your smart device and that your washing
machine is paired with your smart
device via Bluetooth. If the washing
machine is not paired with your smart
device, it will function as an appliance
without the HomeWhiz feature.
• Your product will run once it is paired with
your smart device via Bluetooth. Controls
made from the app will be enabled through
this pairing. For this reason, the Bluetooth
signal between the product and the
smart device must be strong enough.
• Please visit www.homewhiz.com to see
the Android and iOS versions supported
by the HomeWhiz application.
A
WARNING!
• All the safety measures described in
"GENERAL SAFETY INSTRUCTIONS"
section of your user manual apply
to remote control through the
HomeWhiz function as well.
34 / EN
Washer-Dryer / User Manual
5.21.1 HomeWhiz Setup
Your product and the HomeWhiz app
must be connected for the app to run. To
establish this connection, please follow
the steps below for setup both on your
product and on the HomeWhiz App.
• If you are adding an appliance for the first
time, tap “Add/Remove Appliance” on the
HomeWhiz App. Then tap “Tap here to
setup new appliance”. Follow the steps
below as well as the instructions on the
HomeWhiz App to complete the setup.
• To start the setup process, make sure that your
machine is switched off. Press and hold the
Temperature button and the Remote Control
Function button simultaneously for 3 seconds to
switch your machine to HomeWhiz setup mode.
• While the device is in HomeWhiz setup mode,
you will see an animation on the display,
and the Bluetooth icon will flash until the
machine is paired with your smart device.
In this mode, only the programme button
is enabled. Other buttons are disabled.
• On the screen of the app, select the
desired washing machine and tap Next.
• Follow on-screen instructions until the
HomeWhiz app asks you about the product
you wish to connect to your smart device.
• Return to the HomeWhiz app and wait until
the setup is complete. Once the setup is
complete, give your washing machine a name.
You can now tap the screen to see the product
you have added to the HomeWhiz App.
C
INFORMATION
• If you cannot complete the setup
successfully in 5 minutes, the washing
machine will switch off automatically. In this
case, you will have to start over the setup
procedure. If the problem persists, please
contact the Authorised Service Agent.
• You can use your washing machine with
more than one smart device. To do this,
download the HomeWhiz app on the other
smart device as well. After launching the
app, you will need to sign in to your account
you have previously created and paired with
your washing machine. Otherwise, please
read “Setting up a washing machine that
is connected to someone else’s account”.
A
WARNING!
• For HomeWhiz setup, your smart device must
be connected to internet. Otherwise, the
HomeWhiz App will not let you complete the
setup process successfully. If you are having
problems with your internet connection,
please contact your internet service provider.
C
INFORMATION
• The HomeWhiz application may ask you
to enter the product number stated on
the label of the product. Product label is
found on the inner side of the product door.
Product number is written on this label.
5.21.2 Setting up a washing
machine that is connected to
someone else’s account
If the washing machine you want to use has
previously been registered in the system
with someone else’s account, you need
to establish a new connection between
the HomeWhiz App and the product.
• Download the HomeWhiz App on the
new smart device you want to use.
• Create a new account and log in to this
account on the HomeWhiz app.
35 / EN
Washer-Dryer / User Manual
• Follow the steps in the HomeWhiz
Setup (5.21.1 HomeWhiz Setup)
to complete the setup.
A
WARNING!
• Since the HomeWhiz and Remote Control
functions of your product work through
pairing via Bluetooth, the product can be
run by only one HomeWhiz app at a time.
5.21.3 Using the Remote
Control function
After HomeWhiz setup, Bluetooth will turn on
automatically. To enable or disable the Bluetooth
connection, please see 5.11.2 Bluetooth 3”.
If you switch your machine off and on
while Bluetooth is enabled, it will reconnect
automatically. If the paired device goes out
of the range, the Bluetooth connection will
turn off automatically. For this reason, you
will need to turn on Bluetooth again if you
want to use the Remote Control function.
You can check the Bluetooth symbol on
the display to follow the connection status.
If the symbol is on, this means that the
Bluetooth connection is established. If
the symbol is established, the product is
trying to connect. If the symbol is off, this
means that you have no connection.
A
WARNING!
• If the Bluetooth connection is enabled on your
product, you can select the Remote Control
function. If the Remote Control function
cannot be selected, check the connection
status. If the connection fails, repeat the
initial set-up settings on the appliance.
• For safety reasons, the product’s door
will remain locked while the Remote
Control function is enabled, independently
of the operating mode. If you want to
open the door of the product, you will
need to turn the program selection knob
or press the Remote Control key to
disable the Remote Control function.
If you want to control your washing machine
remotely, enable the Remote Control function
by pressing the Remote Control button while
the programme knob is in the Programme
Download/Remote Control position on the
control panel. Once the product is accessed,
you will see a screen similar to the one below.
When Remote Control is enabled, you can
only manage and switch off the machine
and follow status on the washing machine.
All functions except child lock can be
managed through the application.
You can check the function indicator on
the key to follow whether the Remote
Control function is On or Off.
If the Remote Control function is Off,
all the operations are handled on the
washing machine and only status follow-
up is allowed on the application.
If the Remote Control function cannot be
enabled, you will hear a warning after pressing
the button. This might occur if the product
is switched on or if there is no product
paired through Bluetooth. Bluetooth setting
being Off or the washing machine's door
being open are examples for such cases.
When you enable this function on the washing
machine, said function will remain on except
for certain cases, allowing you to control your
washing machine remotely via Bluetooth.
In certain cases, it deactivates
itself for safety reasons:
• When your washing machine
undergoes a power interruption.
• When the programme knob is turned
to select a different programme or
when the product is switched off.
5.21.4 Troubleshooting
Follow the steps below if you are having
problem with controlling or connection.
Observe whether the problem persists or not
after the action you have performed. Do the
following if the problem is not resolved.
• Check whether your smart device is
connected to the relevant home network.
• Restart the product application.
• Turn Bluetooth off and on through
the user control panel.
• If the connection cannot be established
with the above processes, repeat the initial
set-up settings on the washing machine.
If the problem persists, consult an
Authorised Service Agent.
36 / EN
Washer-Dryer / User Manual
6 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced
if it is cleaned at regular intervals.
6.1 Cleaning the detergent drawer
Clean the detergent
drawer at regular
intervals (every 4-5
washing cycles)
as shown below
in order to prevent
accumulation of
powder detergent
in time.
1 Remove the siphon by lifting it from behind
as shown in the picture. After performing
the below mentioned cleaning procedures,
replace the siphon back to its seating
and push its front section downwards to
make sure that the locking tab engages.
C
INFORMATION
• If more than normal amount of water and
softener mixture remains in the softener
compartment, the siphon must be cleaned.
2. Wash the detergent drawer and the siphon
with plenty of lukewarm water in a washbasin.
In order to prevent the residues to contact
your skin, clean it with an appropriate
brush by wearing a pair of gloves.
3 Insert the drawer back into its place after
cleaning and make sure that it is seated well.
6.2 Cleaning the loading
door and the drum
A washer dryer produces combustible lint;
therefore cleaning the door and rubber
gasket after each wash is important.
Use a soft damp cloth to wipe the door,
cleaning any water marks or residue off it.
Wipe the rubber seal around the door. Remove
any items or lint accumulating in the bottom
of the seal catchment and wipe out any
water accumulated here. If this is not cleaned
out, unpleasant odours can also develop.
For products with drum cleaning
programme, please see Operating
the product - Programmes.
C
INFORMATION
• Repeat Drum Cleaning process in
every 2 months or whenever there’s
excessive lint build up on the rubber
gasket and drum, that could adversely
affect washing & drying performance.
• Use an detergent /anti-limescale
suitable for the washing machines.
After every washing
and drying make
sure that no foreign
substance is left
in the drum.
C
INFORMATION
• Foreign metal substances will cause
rust stains in the drum. Clean the
stains on the drum surface by using
cleaning agents for stainless steel.
Never use steel wool or wire wool.
A
CAUTION!
• Never use sponge or scrub materials.
These will damage the painted,
chrome and plastic surfaces.
6.3 Cleaning the body
and control panel
Wipe the body of the machine with soapy
water or non-corrosive mild gel detergents
as necessary, and dry with a soft cloth.
Use only a soft and damp cloth
to clean the control panel.
6.4 Cleaning the water
intake filters
37 / EN
Washer-Dryer / User Manual
There is a filter at the end of each water
intake valve at the rear of the machine and
also at the end of each water intake hose
where they are connected to the tap. These
filters prevent foreign substances and dirt
in the water to enter the washing machine.
Filters should be cleaned if they are dirty.
1. Close the taps.
2. Remove the nuts of the water intake
hoses to access the filters on the water
intake valves. Clean residues on them
with an appropriate brush. If the filters are
too dirty, remove them from their places
with a pliers and clean in this way.
3. Take out the filters on the flat ends of the
water intake hoses together with the gaskets
and clean thoroughly under running water.
4. Replace the gaskets and filters
carefully in their places and tighten
the hose nuts by hand.
6.5 Draining remaining water
and cleaning the pump filter
The filter system in your machine prevents
solid items such as buttons, coins and fabric
fibres clogging the pump impeller during
discharge of washing water. Thus, the water
will be drained without any problem and
the service life of the pump will extend.
If the machine fails to drain water, the pump filter
is clogged. Filter must be cleaned whenever it
is clogged or in every 3 months. Water must
be drained off first to clean the pump filter.
In addition, prior to transporting the machine
(e.g., when moving to another house)
and in case of freezing of the water, water
may have to be drained completely.
A
CAUTION!
• Foreign substances left in the pump
filter may damage your product
or may cause noise problem.
• If the product is not being used, shut the
tap, remove mains hose and drain the
water inside the machine in places where
there is the risk of the product freezing .
• After each use, turn off the water tap to
which the mains hose is connected.
1. In order to clean the dirty filter and
discharge the water, unplug the
machine to cut off the supply power.
A
CAUTION!
• Temperature of the water inside the
machine may rise up to 90 ºC. To avoid
the risk of burning, clean the filter after the
water inside the machine is cooled down.
2. Open the filter cover. Press the tab
in the direction of the arrow and pull
the cover out towards yourself.
3.To drain the water in the machine.
a. In order to collect the water to flow
out of the filter, place a large shallow
vessel in front of the filter.
b. Turn and loosen the pump filter until
water starts to flow (counterclockwise).
Fill the flowing water into the container
you have placed in front of the filter.
Always keep a piece of cloth handy
to absorb any spilled water.
c When the water inside the machine is finished,
take out the filter completely by turning it.
4. Clean any residues inside the filter as well
as fibres, if any, around the pump impeller
region.
5. Replace the filter.
6. Close the filter cover.
38 / EN
Washer-Dryer / User Manual
7 Troubleshooting
Programmes won’t start after the loading door has
been closed.
• You did not press the Start/Pause/Cancel button.>>>
*Press the
Start/Pause/Cancel button.
• If the load is too much, it might be hard for the loading door to be
closed.>>>
*Load less laundry and make sure that the loading
door is closed properly.
Programme cannot be started or selected.
• The machine may have switched itself to self-protection mode
due to a supply problem (mains voltage, water pressure etc.).
>>>
Press and hold the On/Off button for 3 seconds to reset the
machine to factory settings (See "Cancelling the programme").
To cancel the programme, turn the Programme Selection knob
to select another programme. Previous programme will be
cancelled. (see. “Cancellation of programme”)
Water inside the machine.
• There might be some water remaining in the product due to the
quality control processes carried out during production. >>>
This is not a failure, water does not harm the machine.
Water is leaking from the bottom of the machine.
• There might be a problem with the hoses or the pump filter.
>>>
Make sure that the seals of the water inlet hoses are
securely fitted. Attach the hose to the tap tightly.
• Pump filter might not be closed securely. >>>
Make sure that
the pump filter is closed securely.
Machine does not take in water.
• Tap might be turned off. >>>
Turn on the taps.
• Water inlet hose might be bent. >>>
Flatten the hose.
• Water inlet filter might be clogged. >>>
Clean the filter.
• Loading door might not be closed. >>>
Close the loading door.
Machine does not drain water.
• Water drain hose might be clogged or twisted. >>>
Clean or
flatten the hose.
• Pump filter might be clogged. >>>
Clean the pump filter.
Machine vibrates or makes noise.
• Machine might be unbalanced. >>>
Adjust the feet to level the
machine.
• A hard substance might have entered the pump filter. >>>
Clean the pump filter.
• Transportation safety bolts might not be removed. >>>
Remove the transportation safety bolts.
• The amount of laundry might be too little. >>>
Add more
laundry to the machine.
• The machine might be overloaded with laundry. >>>
Take out
some of the laundry from the machine or distribute the load by
hand to balance it evenly in the machine.
• The machine might be in contact with a hard surface. >>>
Make sure that the machine is not in contact with anything.
Machine stopped shortly after the programme started.
• The machine might have stopped temporarily due to low
voltage. >>>
It will resume running once the voltage returns to
a normal level.
Machine directly discharges the water it takes in.
• The drain hose might be at an inappropriate height. >>>
Connect the water drain hose as described in the user manual.
No water can be seen in the machine during
washing.
• Water level cannot be seen outside the machine. This is not a
failure.
Loading door cannot be opened.
• Door lock might be enabled because of the water level in the
machine. >>>
Drain the water by running the Pump or Spin
programme.
• Machine might be heating the water or at the spinning
step.>>>
Wait until the programme is complete.
• The loading door might be jammed due to the pressure it is
exposed to. >>>
Hold the grip, push and pull the loading door
to free it from the pressure and open it.
• The loading door will not open if there is no power. >>>
To
open the loading door, open the pump filter cap and pull down
the emergency handle positioned at the rear side of the said
cap. See “Loading door lock”
Washing takes longer than specified in the user
manual.(*)
• Water pressure might be low. >>>
Since the amount of the
water has decreased, the machine will wait until it takes
adequate water to avoid poor washing quality. Therefore, the
washing time extends.
• Voltage might be low. >>>
If the supply voltage is low, the
washing time is extended to prevent poor washing quality.
• Inlet temperature of water might be too low. >>>
The time
required to heat up the water extends in cold seasons. Also,
washing time can be extended to avoid poor washing results.
• The number of rinsing cycles and/or the amount of rinsing
water might have increased. >>>
When a better rinsing
performance is needed, the machine increases the amount of
rinsing water, and adds another rinsing cycle, if necessary.
• Excessive foam might have formed due to use of too much
detergent, and the automatic foam absorption system might
have been activated. >>>
Use the recommended amount of
detergent.
Programme time does not countdown. (On models
with display) (*)
• The timer may stop during water intake. >>>
The timer
indicator will not count down until the machine takes in an
adequate amount of water. When the amount of the water
taken in decreases, the machine will wait until it takes in
enough water to avoid poor washing results. Timer indicator
will resume countdown after this.
• The timer indicator might stop during heating. >>>
The timer
indicator will not count down until the machine reaches the
selected temperature.
• The timer indicator might stop during spinning. >>>
The
automatic unbalanced load detection system might have been
activated due to uneven distribution of the laundry in the drum.
39 / EN
Washer-Dryer / User Manual
Programme time does not countdown. (*)
• The laundry in the machine might be unbalanced. >>>
The
automatic unbalanced load detection system might have been
activated due to uneven distribution of the laundry in the drum.
Machine does not switch to spinning step. (*)
• The laundry in the machine might be unbalanced. >>>
The
automatic unbalanced load detection system might have been
activated due to uneven distribution of the laundry in the drum.
• The machine cannot spin if the water in it is not drained
completely. >>>
Check the filter and the drain hose.
• Excessive foam might have formed due to use of too much
detergent, and the automatic foam absorption system might
have been activated. >>>
Use the recommended amount of
detergent.
Washing performance is poor: Clothes are going grey.(**)
• Insufficient amount of detergent might have been used over
a long period of time. >>>
Use the recommended amount of
detergent according to water hardness and the laundry.
• Washing might have been performed at low temperatures for a
long time. >>>
Select the proper temperature for the laundry
to be washed.
• Hard water and insufficient amount of detergent. >>>
Using
hard water together with insufficient amount of detergent
might cause dirt accumulation and greying on laundry in
time. It is difficult to eliminate greying once it happens. Use
the recommended amount of detergent appropriate for water
hardness and the laundry.
• Excessive amount of detergent might have been used. >>>
Use the recommended amount of detergent appropriate for
water hardness and the laundry.
Washing performance is poor: Stains persist or the
laundry is not whitened. (**)
• Insufficient amount of detergent might have been used. >>> Use
recommended amount of detergent appropriate for the laundry.
• Machine might have been overloaded. >>>
Do not overload the
machine. Load the machine with the amounts recommended in
the "Programme and consumption table".
• Wrong programme and temperature might have been selected.
>>>
Select the right programme and temperature for the
laundry to be washed.
• Wrong type of detergent might have been used. >>>
Use
original detergent appropriate for the machine.
• Detergent might have been put in the wrong compartment.
>>> Put the detergent in the correct compartment. Do not mix
the bleaching agent and the detergent with each other.
Washing performance is poor: Oily stains appeared
on the laundry. (**)
• The drum might not have been cleaned regularly. >>>
Clean
the drum regularly. To do this, please see. 6.2.
Washing performance is poor: Clothes smell bad. (**)
• Washing at low temperatures and/or with short programmes
for a long time will cause smell and bacteria in the drum. >>>
Leave the detergent drawer and loading door of the machine
ajar after every washing cycle. Thus, a humid environment
favorable for bacteria cannot occur in the machine.
Colour of the clothes faded. (**)
• Machine might have been overloaded. >>>
Do not overload
the machine.
• Detergent used might be damp. >>> Keep detergents closed
in an environment free of humidity and do not expose them to
excessive temperatures.
• A high temperature might have been selected. >>> Select
a programme and temperature suitable for the type and soiling
degree of the laundry.
Rinsing performance is poor
• The amount, brand or storage conditions of the detergent might
not be suitable. >>> Use a detergent appropriate for the washing
machine and your laundry. Keep detergents closed in an environment
free of humidity and do not expose them to excessive temperatures.
• The detergent might have been added to the wrong compartment.
>>> If you add detergent to the prewash compartment even if
you have not selected a prewash programme, the machine might
take this detergent during the rinsing or softener step. Put the
detergent in the correct compartment.
• Pump filter might have been clogged. >>>
Check the filter.
• Drain hose might be folded. >>>
Check the drain hose.
Laundry became stiff after washing. (**)
• Insufficient amount of detergent might have been used. >>>
Using insufficient amount of detergent for the water hardness
can cause the laundry to become stiff in time. Use appropriate
amount of detergent according to the water hardness.
• The detergent might have been added to the wrong compartment.
>>> If you add detergent to the prewash compartment even if
you have not selected a prewash programme, the machine might
take this detergent during the rinsing or softener step. Put the
detergent in the correct compartment.
• Detergent might have been mixed with softener. >>> Do not mix the
detergent with softener. Wash and clean the drawer with hot water.
Laundry does not smell like softener. (**)
• The detergent might have been added to the wrong compartment.
>>> If you add detergent to the prewash compartment even if you
have not selected a prewash programme, the machine might take
this detergent during the rinsing or softener step. Wash and clean the
drawer with hot water. Put the detergent in the correct compartment.
• Detergent might have been mixed with softener. >>> Do not mix the
detergent with softener. Wash and clean the drawer with hot water.
Detergent residue in the detergent drawer. (**)
• Detergent might have been added to wet drawer. >>>
Dry the
detergent drawer before adding detergent.
• Detergent might have gotten damp. >>>
Keep detergents
closed in an environment free of humidity and do not expose
them to excessive temperatures.
• Water pressure might be low. >>>
Check the water pressure.
• The detergent in the main wash compartment got wet while
the machine was taking in the prewash water. Holes of the
detergent compartment might have been blocked. >>>
Check
the holes and clean if they are clogged.
• There might be a problem with the detergent drawer valves.
>>>
Call the Authorised Service Agent.
• Detergent might have been mixed with softener. >>> Do not mix the
detergent with softener. Wash and clean the drawer with hot water.
40 / EN
Washer-Dryer / User Manual
There is detergent left on the laundry.
• Machine might have been overloaded. >>>
Do not overload
the machine.
• Wrong programme and temperature might have been selected.
>>>
Select the right programme and temperature for the
laundry to be washed.
• Wrong detergent might have been used. >>>
Select a proper
detergent for the laundry to be washed.
Too much foam forms in the machine. (**)
• Improper detergents for the washing machine might have been
used. >>>
Use detergents suitable for washing machine.
• Excessive amount of detergent might have been used. >>>
Use only sufficient amount of detergent.
• Detergent might have been stored under inappropriate
conditions. >>>
Keep the detergent in a closed and dry area.
Do not store it in excessively hot places.
• Meshed laundry such as tulles might foam too much due to
their texture. >>>
Use less detergent for these types of fabrics.
• Detergent might have been put in the wrong compartment.
>>> Put the detergent in the correct compartment.
• Softener is taken early. >>> There might be a problem with the
valves or the detergent drawer. Call the Authorised Service Agent.
Foam is overflowing from the detergent drawer.
• Excessive amount of detergent might have been used.
>>>>
Mix 1 tablespoonful softener and ½ l water and pour
into the main wash compartment of the detergent drawer.
• Put detergent into the machine suitable for the programmes
and maximum loads indicated in the “Programme and
consumption table”. If you use additional chemicals (stain
removers, bleaches and etc), reduce the amount of detergent.
Laundry remains wet at the end of the programme. (*)
• Excessive foam might have formed due to use of too much
detergent, and the automatic foam absorption system might have
been activated. >>> Use the recommended amount of detergent.
(*) Machine does not switch to spinning step
when the laundry is not evenly distributed in the
drum to prevent any damage to the machine
and to its surrounding environment. Readjust
the laundry and perform spinning again.
(**) The drum might not have been cleaned
regularly.
>>>
Clean the drum regularly. See 6.2
A
CAUTION!
• If you cannot eliminate the problem
although you follow the instructions in
this section, consult your dealer or the
Authorised Service Agent. Never try to
repair a nonfunctional product yourself.
Drying lasts too long.
• Excessive laundry loaded. >>>
Do not load the machine
in excess.
• Laundry is not spun enough.>>> Spin at a higher spin
speed in washing step in the Dryer-Washing Machine.
• Tap is turned off. >>> Turn on the taps.
Laundry is still damp after drying.
• An appropriate programme according to laundry
type might is not selected.>>>
Check care labels on
clothes and select an appropriate programme or use timed
programmes in addition.
• Excessive laundry loaded. >>> Do not load the machine
in excess.
• Laundry is not spun enough.>>> Spin at a higher spin
speed in washing step in the Dryer-Washing Machine.
Machine does not start or programme cannot be started.
• Power cable is not connected. >>> Make sure the power
cable is connected.
• Programme is not set or Start / Pause / Cancel button
is not pressed. >>>
Make sure the programme is set and
it is not in Stand-by mode.
• Child lock enabled. >>> Disable Child lock.
Loading door cannot be opened.
• Your machine’s door is not opened for safety
reasons.>>>
If door locked indicator is still active on display
after drying, machine keeps the loading door locked until it
cools for your safety.
• The loading door will not open if there is no power.
>>>
To open the loading door, open the pump filter cap and
pull down the emergency handle positioned at the rear side of
the said cap. See “Loading door lock”
A
WARNING!
• Check the HomeWhiz section for the
relevant troubleshooting information.
