Washer-Dryer
User’s Manual
BWD7541IG
EN
Document Number=
Please read this user
manual first!
Dear Customer,
Thank you for choosing a Beko product. We
hope that you get the best results from your
product which has been manufactured with
high quality and state-of-the-art technology.
Therefore, please read this entire user manual
and all other accompanying documents
carefully before using the product and keep it
as a reference for future use. If you handover
the product to someone else, give the user
manual as well. Follow all warnings and
information in the user manual.Throughout this
user manual the following symbols are used:
B
DANGER!
• Warning for electric shock.
DANGER!
• Product weight warning
DANGER!
• Fire risk warning.
A
CAUTION!
• Warning for hazardous situations
with regard to life and property.
A
PRECAUTION!
• Precautions that need to be taken.
C
INFORMATION
• Important information or useful hints about
usage.
• Read user manual.
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with regulations.
• Do not dispose of the
Packaging materials
together with the domestic
or other wastes. Take them
to the packaging material
collection points designated
by the local authorities.
• Allergy UK, is the brand of
British Allergy Association. Their
main endorsement is the ‚Seal
of Approval‘. When you see
a product with this logo on it,
you have the reassurance the
product has been scientifically
tested to prove it is efficient at
reducing/removing allergens
from the environment
of allergy and asthma
sufferers or the products
have significantly reduced
allergen/chemical content.
“The wool wash cycle of this
machine has been approved
by The Woolmark Company
for the washing of machine
washable wool products provided
that the products are washed
according to the instructions
on the garment label and those
issued by the manufacturer of
this washing machine. M1527 “
“In UK, Eire, Hong Kong and
India the Woolmark trade mark
is a Certification trade mark.”
This product was manufactured using the latest technology in environmentally friendly conditions.
3 / EN
Washer-Dryer / User’s Manual
1 Important instructions for safety and environment
This section contains safety instructions
that will help protect from risk of
personal injury or property damage.
Failure to follow these instructions
shall invalidate any warranty.
1.1 General safety
A
CAUTION!
• This product can be used by
children at and above 8 years old
and by persons whose physical,
sensory or mental capabilities
were not fully developed or who
lack experience and knowledge
provided that they are supervised
or trained on the safe usage of the
product and the risks it brings out.
Children should not play with the
device. Cleaning and maintenance
works should not be performed by
children unless they are supervised
by someone. Children under the
age of 3 should be kept away
unless continuously supervised.
A
PRECAUTION!
• Never place the product on a
carpet-covered floor. Otherwise,
lack of airflow beneath the machine
will cause electrical parts to
overheat. This will cause problems
with your product.
• Adequate ventilation has to be
provided to avoid the back flow
of gases into the room from
appliances burning other fuels,
including open fires. Only for
ducted appliances.
A
PRECAUTION!
• The appliance must not be installed
behind a lockable door, a sliding
door or a door with a hinge on the
opposite side to that of the tumble
dryer in such a way that a full
opening of the tumble dryer door is
restricted.
C
INFORMATION
• Always have the installation
procedures carried out by the
competent persons. Manufacturer
shall not be held liable for damages
that may arise from procedures
carried out by unauthorised persons.
1.1.1 Electrical safety
B
DANGER!
• If the product has a failure, it should
not be operated unless it is repaired
by the Authorised Service Agent.
There is the risk of electric shock!
• Never wash the product by
spreading or pouring water onto it!
There is the risk of electric shock!
A
CAUTION!
• If the power cable is damaged,
it must be replaced by the
manufacturer, after sales service
or a similarly qualified person
(preferably an electrician) or
someone designated by the importer
in order to avoid possible risks.
4 / EN
Washer-Dryer / User’s Manual
A
WARNING!
• The appliance must not be
supplied through an external
switching device, such as a timer,
or connected to a circuit that is
regularly switched on and off by a
utility.
A
PRECAUTION!
• Unplug the product when it is not
in use.
• Never touch the plug with wet
hands! Never unplug by pulling on
the cable, always unplug by holding
the plug.
• Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
• Do not make connections via
extension cables or multi-plugs.
C
INFORMATION
• This product is designed to resume
operating in the event of powering
on after a power interruption. If you
wish to cancel the programme,
see “Cancelling the programme”
section.
1.1.2 Product safety
B
DANGER!
• Never open the loading door or
remove the filter while there is
still water in the drum. Otherwise,
risk of flooding and injury from hot
water will occur.
A
CAUTION!
• The water supply and draining
hoses must be securely fastened
and remain undamaged. Otherwise,
there is the risk of water leakage.
C
INFORMATION
• Do not force open the locked
loading door. Door can be opened
a few minutes after the washing
cycle ends. If the machine has not
cooled enough at the end of the
programme, loading door cannot
be opened. Do not force the loading
door to open. It must be left to cool
itself. The loading door and the lock
mechanism may get damaged.
• In the installation location of this
product, there must not be a
lockable, sliding or hinged door that
will restrict the full opening of the
loading door.
• Follow the instructions on the textile
tags and on the detergent package.
• Use only detergents, softeners and
supplements suitable for washing
machines.
• Do not install or leave this product
in places where it might be exposed
to outdoor conditions.
• Controls must not be tampered with.
5 / EN
Washer-Dryer / User’s Manual
1.1.3 Warnings for drying
DANGER!
• Laundry that is previously washed,
cleaned, soiled or stained with
petrol / gasoline, dry cleaning
solvents or other flammable or
explosive substances must not be
dried in the machine as they give
out flammable or explosive steam.
It may cause fire risk.
• Lint must not be allowed to
accumulate around the dryer. Not
applicable for appliances intended
to be vented.
• DO NOT dry unwashed items in the
dryer.
DANGER!
• Laundry stained with Liquid
cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes and wax
removers must be washed in hot
water with plenty of detergent
before drying. It may cause fire risk.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as
a tumble dryer. The items become
warm, causing an oxidation
reaction in the oil. Oxidation creates
heat. If the heat cannot escape, the
items can become hot enough to
catch fire. Piling,stacking or storing
oil-affected items can prevent heat
from escaping and so create a fire
hazard.
DANGER!
• If it is unavoidable that fabrics
that contain vegetable or cooking
oil or have been contaminated by
hair care products be placed in a
tumble dryer they should first be
washed in hot water with extra
detergent – this will reduce, but not
eliminate, the hazard.
• Foam rubber (latex foam), shower
caps, waterproof textiles, clothes
or pillows with rubber support or
rubber foam pads must not be
dried with drying function. It may
cause fire risk.
• Fabric softeners or similar products
should be used as specified by the
fabric softener instructions.
• If you use washing ball, detergent
scale, laundry clothing cages and
balls in your machine, they can
melt during drying. Do not use
these products if drying option will
be selected. It may cause fire risk.
• When you use industrial chemicals
for cleaning, do not use drying
function. It may cause fire risk.
6 / EN
Washer-Dryer / User’s Manual
B
DANGER!
• Do not touch loading door glass
with bare hands after drying. There
is the risk of getting burnt.
• In order to maintain laundry in a
temperature that will prevent them
from getting damaged, a cooling
step is performed as a final step to
ensure items will not be damaged.
You may be exposed to hot steam
if you open the door before cooling
is complete. There is the risk of
scalding.
B
DANGER!
• If the drying programmes
are interrupted (as a result of
programme cancellation or power
failure), laundry in the machine can
be hot. Be careful.
A
WARNING!
• Never stop the tumble dryer before
the end of the drying cycle unless
all items are quickly removed and
spread out so that the heat is
dissipated.
A
CAUTION!
• Do not stop the machine before
drying programme is completed.
If you have to stop the machine,
remove all laundry and lay them in a
suitable place to let them cool down.
• Your product is suitable to operate
in ambient temperatures between
0°C and +35°C.
A
CAUTION!
• Ambient temperatures between
15°C and +25°C are ideal
temperatures for your product.
• Do not let pets enter the product.
Check inside the product before using.
• Remove all items from the pockets
such as lighters and matches.
• Do not overload the machine for
drying. Observe the maximum load
levels specified for drying.
A
PRECAUTION!
• Do not dry leather laundry or laundry
that contains leather (such as leather
jeans label). The colour from Leather
parts can run into other textiles.
• In failures that cannot be repaired
using information given in safety
instructions, turn off the machine,
unplug the power cable and call the
Authorised Service Agent.
• You can just wash laundry, just dry
laundry or wash and dry laundry in
your washer-dryer. Machine must not
be used only to dry wet loads for a
long time. When machine is used only
for drying, it must be operated empty
without loading laundry in a short wash
programme after every 15 operation.
• Check all clothes before loading them
into the machine and ensure that they
do not have objects such as lighters,
coins, metal pieces, needles in the
pockets or inside.
• Underwear with metal supports must
not be dried in the machine. Metal
supports might come off during drying
and cause damage in the machine.
Place in a bag or pillowcase.
7 / EN
Washer-Dryer / User’s Manual
A
PRECAUTION!
• Do not dry large laundry such as tulle
curtain, curtain, bedding, blanket, rug
in the machine. Your laundry might get
damaged.
C
INFORMATION
• Do not dry unwashed laundry in the
machine.
• Do not use fabric softeners or static
preventers in the machine unless
recommended by the manufacturer.
• Products such as fabric softeners
must be used in accordance with
manufacturer’s instructions.
• Do not dry sensitive clothes such
as silk, wool, etc. in the machine.
Otherwise, wool clothes may get
shrunken and other sensitive
clothes may get damaged.
• Check symbols on the garment tag
before washing and drying.
1.2 Intended use
C
INFORMATION
• This product has been designed for
domestic use. It is not suitable for
commercial use and it must not be
used out of its intended use.
• The product must only be used for
washing, rinsing and drying of textile
products that are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect
usage or transportation.
1.3 Children's safety
A
CAUTION!
• Children below the age of 3 must be
kept away from the machine unless
they are continuously supervised.
• Packaging materials are dangerous to
children. Keep packaging materials in
a safe place away from reach of the
children.
• Electrical products are dangerous for
the children. Keep children away from
the product when it is in use. Do not
allow them to play with the product.
Use child lock to prevent children
from intervening with the product.
• Do not forget to close the loading
door when leaving the room where
the product is located.
• Store all detergents and additives in
a safe place away from the reach of
the children by closing the cover of
the detergent container or sealing the
detergent package.
8 / EN
Washer-Dryer / User’s Manual
1.4 Compliance with WEEE
Directive and disposing
of the waste product
This product does not contain harmful and
forbidden materials described in the "Regulation on
the Control of the Waste Electrical and Electronic
Equipment". It complies with the WEEE Directive.
This product has been
manufactured with high quality
parts and materials which can
be reused and are suitable for
recycling. Therefore, do not
dispose the product with normal
domestic waste at the end of its
service life. Take it to a collection
point for the recycling of electrical
and electronic equipment. Please
consult your local authorities to
learn the nearest collection point.
Help protect the environment and natural
resources by recycling used products.
For children’s safety, cut the power cable
and break the locking mechanism of the
loading door so that it will be non-functional
before disposing of the product.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
1.5 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
with normal domestic waste. Take them
to the packaging material collection points
designated by the local authorities.
2 Your washer-dryer
2.1 Overview
1
2
3
4
5
6
7
8
1- Power cable 5- Loading door
2- Top panel 6- Filter cover
3- Control panel 7- Adjustable feet
4- Water
discharge hose
8- Detergent drawer
9 / EN
Washer-Dryer / User’s Manual
2.2 Package contents
Power cable
Water discharge hose
Transit bolts
Mains water inlet hose
Liquid detergent container (*)
User manual
Plastic plug group
C
INFORMATION
• Figures in this manual are schematic and may not match the product exactly.
(*) This may be supplied with the machine depending on the model of your product.
10 / EN
Washer-Dryer / User’s Manual
2.3 Technical specifications
Supplier name or trademark Beko
Model name BWD7541IG
Maximum spin speed (rpm) 1400
Built-in No
Rated capacity - Washing (kg) of Dry clothes/laundry 7,5
Rated capacity - Drying (kg) of Dry clothes/laundry 4
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Net weight (±4 kg.) 69
Single Water inlet / Double Water inlet
• / -
• Available
Electrical input (V/Hz) 220-240 V / 50Hz
Total current (A) 10
Total power (W) 2000-2350
VDE Main model code 9620
Technical specifications may be changed without prior notice to improve the quality of the product.
11 / EN
Washer-Dryer / User’s Manual
3 Installation
To make the product ready for use, review the
information in the user manual and make sure
that the electricity, tap water supply and water
drainage systems are appropriate. If they are
not, call a qualified technician and plumber to
have any necessary arrangements carried out.
B
DANGER!
• Make sure that the installation and
electrical connections of the product
are performed by competent persons.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorised persons.
DANGER!
• Your product is too heavy for
one person to carry.
A
CAUTION!
• Prior to installation, visually check if
the product has any defects on it. If
so, do not have it installed. Damaged
products cause risks for your safety.
A
PRECAUTION!
• Preparation of the location and
electrical, tap water and waste water
installations at the place of installation
is under customer’s responsibility.
• Make sure that the water inlet and
discharge hoses as well as the power
cable are not folded, pinched or crushed
while pushing the product into its place
after installation or cleaning procedures.
3.1 Appropriate
installation location
• Place the product on a solid and level
floor. Do not place it onto a carpet with
high pile or other similar surfaces.
• Do not place the product close to the
edge if the floor contains steps. Do not
also place the product on a platform.
• Do not place the product on the power cable.
• Do not install the product in environments
where the temperature falls below
0 ºC.(See. Warnings for Drying)
• Leaving a gap at the sides of the machine
is suggested to reduce vibration and noise
• In the area where this product is
installed, there must not be a lockable,
sliding or hinged door that will restrict
the full opening of loading door.
• Operate the product in a well ventilated
and dust free environment.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
3.2 Removing packaging
reinforcement
Tilt the machine
backwards to remove
the packaging
reinforcement.
Remove the
packaging
reinforcement
attached to
the ribbon.
DANGER!
• Your product is heavy. Remove packaging
reinforcement as displayed in the figure.
• Be careful not to get your hand caught
under the machine during this procedure.
3.3 Removing the transit bolts
A
PRECAUTION!
• Do not remove the transit bolts before
removing the packaging reinforcement.
• Remove the transit bolts before operating
the washing machine! Otherwise,
the product will get damaged.
12 / EN
Washer-Dryer / User’s Manual
3
2
1
1 Use a tool to
loosen all bolts until
they rotate freely.
3
2
1
2 Remove the transit
bolts by turning
them slightly.
3
2
1
3 Attach the plastic
covers supplied in
the user manual
bag into the holes
on the rear panel.
C
INFORMATION
• Keep the transit bolts in a safe place
to reuse when the product needs
to be moved again in the future.
• Never move the product without the
transit bolts properly fixed in place!
3.4 Connecting water supply
C
INFORMATION
• The water supply pressure required to
run the product is between 1 to 10 bars
(0.1 – 1 MPa). It is necessary to have
10 – 80 liters of water flowing from the
fully open tap in one minute to have your
product run smoothly. Attach a pressure
reducing valve if water pressure is higher.
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1 2 3
1 Connect the special
hose supplied
with the product
to the water inlet
on the product.
A
CAUTION!
• Ensure that the cold water connection
is made correctly when installing the
product. Otherwise, your laundry
will come out hot at the end of the
washing process and wear out.
1 2 3
2 Tighten the hose
nuts securely
by hand. Never
use a tool when
tightening the nuts.
1 2 3
3 Open the taps
completely after
making the hose
connection to
check for water
leaks at the
connection points.
If any leak occurs, turn off the tap and
remove the nut. Retighten the nut carefully
after checking the seal. In order to prevent
the water leaks, keep the taps closed
when you do not use the product.
13 / EN
Washer-Dryer / User’s Manual
3.5 Connecting to the drain
• Attach the end of the drain hose directly
to waste water drain, sink or bathtub.
A
CAUTION!
• Your house will be flooded if the hose
comes out of its housing during water
discharge. Moreover, there is risk of
scalding due to high washing temperatures!
To prevent such situations and to ensure
smooth water intake and discharge of
the machine, fix the end of the discharge
hose tightly so that it cannot displace.
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
90 cm
90
40
90
40
90 cm
90 cm
min.40
• Connect the hose to a minimum height of
40 cm and a maximum height of 90 cm.
• If the hose is run along the floor (or at less
than 40 cm above it) and raised later on,
water drain becomes difficult and laundry
may come out extremely wet. Therefore,
observe the heights described in the figure.
• To prevent flowing of dirty water back into
the machine and to allow for easy discharge,
do not immerse the hose end into the dirty
water or do not drive it in the drain more
than 15 cm. If it is too long, cut it short.
• The end of the hose should not be
bent, it should not be stepped on
and the hose must not be pinched
between the drain and the machine.
• If the length of the hose is too short, add an
original extension hose. Length of the hose
may not be longer than 3.2 m. To avoid water
leak failures, the connection between the
extension hose and the drain hose of the
product must be fitted well with an appropriate
clamp as not to come off and leak.
3.6 Adjusting the feet
A
CAUTION!
• Adjust feet so that the product will be
balanced in the location it will be used.
• Balance the machine by adjusting the feet.
• Check for any play by pressing the
product from upper diagonal edges.
• Otherwise, the product may move
from its place and cause crushing,
noise and vibration problems.
• Do not use any tools to loosen
the lock nuts. Otherwise, the
lock nuts may get damaged.
a) Loosen the lock nuts on the feet by hand.
b) Adjust the feet until the product stands level
and balanced.
c) Tighten all lock nuts again by hand.
3.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding
in accordance with the local regulations.
• Connection must comply with
national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Ground Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within
easy reach after installation.
14 / EN
Washer-Dryer / User’s Manual
• If the current value of the fuse or breaker
in the house is less than 16 Amps, have a
qualified electrician install a 16 Amp fuse.
• The voltage specified in the “Technical
specifications” section must be
equal to your mains voltage.
B
DANGER!
• Damaged power cables must be replaced
by the Authorised Service Agent.
3.8 Transportation of the product
1 Unplug the product before transporting it.
2 Remove water drain and water
supply connections.
3 Drain all water that has remained
in the product. See 6.5
4 Install the transit bolts in reverse order of
the disassembly procedure. See 3.3
DANGER!
• Your product is too heavy for
one person to carry.
• Your product is heavy; two persons
must carry it and extra precaution
taken on stairs. If your product falls
on you, it may cause injuries.
A
CAUTION!
• Packaging materials are dangerous to
children. Keep packaging materials in a
safe place away from reach of the children.
C
INFORMATION
• Never move the product without the
transit bolts properly fixed in place!
4 Preparation
4.1 Sorting the laundry
* Sort laundry according to type of
fabric, colour, and degree of soiling
and allowable water temperature.
* Always observe the instructions given
on the garment care labels.
4.2 Preparing laundry for washing
• Laundry items with metal attachments
such as, underwired bras, belt buckles or
metal buttons will damage the machine.
Remove the metal pieces or wash such
clothes by putting them in a cotton laundry
bag or cotton pillow case. Also these
type of clothes can heat too much during
drying and damage your other clothes.
Do not dry such laundry in the machine.
• Put small size clothes such as infant's
socks and nylon stockings in cotton a
laundry bag or cotton pillow case.
• Place curtains in without compressing
them. Remove curtain attachment items.
Do not dry tulle curtains in your machine.
• Fasten zips, sew loose buttons
and mend rips and tears.
• Wash “machine washable” or “hand
washable” labelled products only with an
appropriate programme. Dry these type
of clothes by hanging or laying down.
Do not dry them in the machine.
• Do not wash colours and whites together.
New, dark coloured cottons release a
lot of dye. Wash them separately.
• Only use the dyes / colour changers and
descaling agents which are appropriate
to machine wash. Always follow the
instructions on the package.
15 / EN
Washer-Dryer / User’s Manual
C
INFORMATION
• Laundry that is subjected to heavy
deposits of materials such as flour, lime
dust, milk powder, etc. Must be shaken
off before placing into the machine.
Such dusts and powders on the laundry
may build up on the inner parts of the
product in time and can cause damage.
• Keep laundry items made of Angora
wool in the freezer for a few hours before
washing. This will reduce pilling.
• Wash trousers and delicate
laundry turned inside out.
• Tough stains must be treated
properly before washing. If unsure,
check with a dry cleaner.
• Take out all substances in the pockets
such as coins, pens and paper clips,
and turn pockets inside out and
brush. Such objects may damage the
product or cause noise problem.
4.3 Tips for energy saving
Energy efficiency will be improved by
using lower temperature programmes
and appropriate detergents.
• Operate the product in the highest
capacity allowed by the programme you
have selected, but do not overload; see,
"Programme and consumption table". See,
“Programme and consumption table"
• Always follow the instructions on
the detergent packaging.
• Wash slightly soiled laundry
at low temperatures.
• Use faster programmes for small
quantities of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or stained.
• If you plan to dry your laundry in a
dryer, select the highest spin speed
recommended during washing process.
• Do not use more detergent than the
recommended on the detergent packaging.
4.4 Initial use
Before starting to
use the product
make sure that all
preparations are made
in accordance with
the “Important safety
and environment
instructions” and the
instructions in the
“Installation” section.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this programme is not
available in your machine, apply the method
which is described in the section 6.2.
C
INFORMATION
• Use an anti-limescale product suitable
for the washing machines.
• Some water may remain in the product
due to the quality control processes in the
production. It is not harmful for the product.
4.5 Correct load capacity
The maximum load capacity depends on
the type of laundry, the degree of soiling
and the desired washing programme.
The product automatically adjusts
the water amount according to the
weight of the laundry put inside it.
A
CAUTION!
• Follow the information in the
“Programme and consumption table”.
When overloaded, machine’s washing
performance will drop. Moreover, noise
and vibration problems may occur. For
a successful drying performance, do
not dry more laundry than stated.
16 / EN
Washer-Dryer / User’s Manual
Laundry
type
Weight
(g)
Laundry
type
Weight
(g)
Bathrobe 1200 Hand towel 100
Fabric napkin 100 Women‘s night gown 200
Bed sheet 700 Underclothing 100
Bed sheet 500 Men’s overalls 600
Pillowcase 200 Men’s shirt 200
Tablecloth 250 Men’s pyjamas 500
Towel 200 Blouses 100
4.6 Loading the laundry
1. Open the loading door.
2. Put the laundry items into the
product in a loose manner.
3. Push the loading door to close until
you hear a locking sound. Ensure that
no items are caught in the door.
C
INFORMATION
• The loading door is locked while a
programme is running. The loading door
is unlocked a while after the programme
comes to an end. If the inside part of
the machine is too hot at the end of
the programme, loading door will not
open until the temperature decreases.
A
CAUTION!
• If the laundry is misplaced,
noise and vibration problems
may occur in the machine.
4.7 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach and descaling agents;
read the manufacturer’s instructions written
on the package and follow the dosages
specified. Use a measuring cup if available.
4.7.1 Detergent drawer
The detergent drawer is composed
of three compartments:
1
3
2
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition,
there is a siphon
piece in the softener
compartment.
4.7.2 Detergent, softener
and other cleaning agents
• Add detergent and softener before
starting the washing programme.
• Never leave the detergent drawer open
while the washing programme is running!
• When using a programme without prewash,
do not put any detergent into the prewash
compartment (compartment nr. "1").
• In a programme with prewash, do not
put liquid detergent into the prewash
compartment (compartment nr. "1").
• Do not select a programme with prewash if
you are using a detergent bag or dispensing
ball. Place the detergent bag or the
dispensing ball directly among the laundry
in the machine. Remove these if drying
• If you are using liquid detergent,
do not forget to place the liquid
detergent container into the main wash
compartment (compartment nr. “2”).
• When machine is in Drying step,
do not add any washing chemicals
(Liquid detergent, Softener, etc.).
4.7.3 Choosing the detergent
Detergent type to be used depends
on the fabric type and colour.
• Use different detergents for
coloured and white laundry.
• Wash your delicate clothes only with special
detergents (liquid detergent, wool shampoo,
etc.) intended solely for delicate clothes.
• When washing dark coloured clothes
and quilts, it is recommended
to use liquid detergent.
• Wash woollens with special detergent
made specifically for woollens.
17 / EN
Washer-Dryer / User’s Manual
A
CAUTION!
• Use only detergents manufactured
specifically for washing machines.
• Do not use Powdered Soap.
4.7.4 Adjusting the
amount of detergent
The amount of washing detergent to be
used depends on the amount of laundry,
the degree of soiling and water hardness.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings
and finally, environmental protection.
• Use lesser detergent for small
amounts or lightly soiled clothes.
4.7.5 Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Do not exceed the (>max<) level sign
on the softener compartment.
• If the softener has lost its fluidity or the
concentrated type, dilute it with water
before putting it in the detergent drawer.
4.7.6 Using liquid detergents
4.7.6.1 If the product contains
a liquid detergent container
• Put the liquid detergent container
into the compartment no “2”.
• If the liquid detergent lost its fluidity,
dilute it with water before putting
it into the detergent container.
2
4.7.6.2 If the product does not
contain a liquid detergent container
• Do not use liquid detergent for the prewash
step in a programme with prewash.
• Liquid detergent stains your clothes
when used with Delayed Start function.
If you are going to use the Delayed Start
function, do not use liquid detergent.
4.7.7 Using gel and
tablet detergent
• If the gel detergent thickness is fluidal and
your machine does not contain a special liquid
detergent cup, put the gel detergent into the
main wash detergent compartment during first
water intake. If your machine contains a liquid
detergent container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal
or in the shape of capsule liquid tablet, put
it directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment nr. "2") or
directly into the drum before washing.
C
INFORMATION
• Tablet detergents may leave residues in
the detergent compartment. If you notice
such residues, place the tablet detergent
between the laundry, close to the lower
part of the drum in future washings.
C
INFORMATION
• Use the tablet or gel detergent without
selecting the prewash function.
• Bear in mind that any plastic detergent
cup, bowl etc in the drum should
be removed before drying..
4.7.8 Using laundry starch
• Add liquid starch, powder starch or the
dyestuff into the softener compartment.
• Do not use softener and starch
together in a washing cycle.
• Wipe the inside of the machine with a
damp and clean cloth after using starch.
18 / EN
Washer-Dryer / User’s Manual
4.7.9 Using bleaches
• Select a programme with prewash and
add the bleach at the beginning of the
prewash. Do not put detergent in the
prewash compartment. As an alternative
application, select a programme with
extra rinse, add the bleach into an empty
detergent drawer compartment and
also add 1 glass of water from the same
compartment when you see the rinsing
step on the display for the first time.
• Do not use bleach and detergent
by mixing them.
• Use just a little amount (approx. 50 ml)
of bleaching agent and rinse the clothes
very well as it causes skin irritation. Do
not pour the bleach onto the laundry and
do not use it with the coloured items.
• When using oxygen-based whitener,
select a programme which washes
the laundry at a low temperature.
• Oxygen-based whitener can be used with
the detergent; however, if it is a different
consistency, first put detergent in the
compartment number “2” in the detergent
dispenser and wait for the machine to flush
the detergent when taking in water. While
the product continues taking in water, add
whitener in the same compartment.
4.7.10 Using limescale remover
• When required, use limescale
removers manufactured specifically
for washing machines only.
4.8 Tips for efficient washing
Clothes
Light Colours and
Whites
Colours
Black/Dark
Colours
Delicates/
Woollens/Silks
(Recommended temperature
range based on soiling level:
40-90
o
C)
(Recommended temperature
range based on soiling level:
cold -40
o
C)
(Recommended
temperature range
based on soiling level:
cold -40
o
C)
(Recommended
temperature range based
on soiling level: cold
-30
o
C)
Soiling Level
Heavily Soiled
(difficult stains such as grass, coffee,
fruits and blood.)
It may be necessary to pre-treat
the stains or perform prewash.
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and soil
stains and the stains that are
sensitive to bleaches.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for heavily soiled
clothes. It is recommended
to use powder detergents to
clean clay and soil stains and
the stains that are sensitive to
bleaches. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
heavily soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed
with special woollen
detergents.
Normally
Soiled
(For example, stains
caused by body on
collars and cuffs)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for normally soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for normally
soiled clothes. Detergents which
do not contain bleach should
be used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
normally soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed
with special woollen
detergents.
Lightly Soiled
(No visible stains exist.)
Powder and liquid detergents
recommended for whites can be
used at dosages recommended
for lightly soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for lightly soiled
clothes. Detergents which do
not contain bleach should be
used.
Liquid detergents
suitable for colours
and dark colours can
be used at dosages
recommended for
lightly soiled clothes.
Prefer liquid detergents
produced for delicate
clothes. Woollen and silk
clothes must be washed
with special woollen
detergents.
19 / EN
Washer-Dryer / User’s Manual
4.9 Tips for correct drying
Programmes
Cottons Drying Synthetics Drying Babyprotect + Wash&Dry Wash&Wear
Types of Clothes
Durable Clothes with
Cotton-Content
Bed sheet, bedding, baby
clothes, t-shirt, sweatshirt,
durable knitted clothes,
denim, canvas trousers,
shirts, cotton socks, etc.
Not recommended!
It washes and dries
consecutively! Bed sheet,
bedding, baby clothes,
t-shirt, sweatshirt,
durable knitted clothes,
denim, canvas trousers,
shirts, cotton socks, etc.
It washes and dries
consecutively! Bed sheet,
bedding, baby clothes,
t-shirt, sweatshirt,
durable knitted clothes,
denim, canvas trousers,
shirts, cotton socks, etc.
Clothes which are worn for
a short period of time an
unstained, such as shirts,
t-shirts, sweatshirts, etc.
A very small amount of
laundry should be loaded.
Synthetics Clothes (Polyester,
nylon, etc.)
Not recommended!
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes. Drying is
not recommended for the
viscose-content clothes.
Drying explanations in
the maintenance label
should be taken into
account.
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes at low
temperatures with the
washing and drying
warnings given in the
maintenance label taken
into consideration.
It is recommended for
the polyester, nylon,
polyacetate, acrylic-
content clothes at low
temperatures with the
washing and drying
warnings given in the
maintenance label taken
into consideration.
Very slightly soiled and
unstained shirts, t-shirts
and synthetic content items.
A very small amount of
laundry should be loaded.
Delicate (Silk, Woollens,
Cashmere, Angora wool,
etc. content) Clothes
Not recommended!
Not recommended!
Not recommended!
Not recommended!
Not recommended!
Bulky laundry such as
quilts, coats, curtains, etc.
Not recommended! It is
not appropriate to dry bulky
laundry inside the washing
machine. Dry them by
hanging or laying down.
Not recommended!
It is not appropriate to
dry bulky laundry inside
the washing machine.
Dry them by hanging or
laying down.
Not recommended! It is
not appropriate to dry
bulky laundry inside
the washing machine.
Dry them by hanging or
laying down.
Not recommended!
It is not appropriate to
dry bulky laundry inside
the washing machine.
Dry them by hanging or
laying down.
Not recommended! It is
not appropriate to dry bulky
laundry inside the washing
machine. Dry them by
hanging or laying down.
20 / EN
Washer-Dryer / User’s Manual
5 Operating the product
5.1 Control panel
1 2 3 4 5 6
789
101112
13
1 - Programme selection knob
2 - Temperature selection lights
3 - Spin speed selection lights
4 - Display
5 - Drying Programme Lights
6 - On / Off button
7 - Start / Pause button
8 - End Time Adjustment button
9 - Drying Level Adjustment button
10 - Auxiliary Function buttons
11 - Spin Speed Adjustment button
12 - Temperature Adjustment button
13 - Programme Selection lights
5.2 Display symbols
a b c d e
f
g
h
i
a- Washing indicator
b - Rinsing indicator
c - Spinning indicator
d- Drying indicator
e- End indicator
f- No Water indicator
g - Duration Information display
h- Loading Door Lock indicator
i- Child Lock indicator
5.3 Preparing the machine
1. Check if the hoses are connected tightly.
2. Plug in your machine.
3. Turn the tap on completely.
4.Place the laundry in the machine.
5. Add detergent and fabric softener.
5.4 Selecting the washing
programme
1. Determine the programme suitable
for the type, quantity and soiling level
of the laundry in accordance with the
"Programme and consumption table".
2. Select the desired programme with
the
Programme Selection
knob.
C
INFORMATION
• Programmes are limited with the
highest spin speed appropriate for
that particular type of fabric.
• When selecting a programme, always
consider the type of fabric, colour, soiling
level and permissible water temperature.
• Always select the lowest appropriate
temperature. Higher temperature means
higher electricity consumption.
5.5 Washing programmes
Depending on the type of fabric, use
the following main programmes.
C
INFORMATION
• You can set you machine to switch to
drying step at the end of washing cycle
by pressing the Drying button after you
have selected the washing programme
for your laundry. Each time you press the
button, info line shows at which step the
drying process will take place and the
relevant symbol will turn on. If you want,
by continuing to press the button, you can
perform drying for the maximum period of
time allowed by the machine for drying.
• Symbols in the display are schematic
and may not match the product exactly.
• When you will perform washing and
drying by using the Drying function of
your machine, load maximum 5 kg of
laundry into the machine. If you load
excessively, your laundry will not dry
and machine will operate for a long
time and consume more energy.
21 / EN
Washer-Dryer / User’s Manual
• Cottons
Use for your cotton laundry (such as bed
sheets, duvet and pillowcase sets, towels,
bathrobes, underwear, etc.). Your laundry
will be washed with vigorous washing
action for a longer washing cycle.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Synthetics
Use to wash your synthetic clothes (shirts,
blouses, synthetic/cotton blends, etc.).
Your laundry will be washed with a gentle
action for a shorter washing cycle when
compared to the Cottons programme.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Wool
Use to wash your woollen laundry. Select
the appropriate temperature complying
with the tag of your clothes. Use
appropriate detergents for woollens.
C
INFORMATION
• Drying function cannot be selected
for the woollen wash programme.
• Cottons Eco
Use to wash your normally soiled, durable
cotton and linen laundry. Although it washes
longer than all other programmes, it provides
significant energy and water savings. Actual
water temperature may be different from
the stated washing temperature. When you
load the machine with less laundry (e.g.
½ capacity or less), programme duration
may automatically get shorter. In this
case, energy and water consumption will
decrease more, providing a more economic
wash. This programme is available in the
models with the remaining time indicator.
Normally soiled laundry may be washed
with reduced amount of detergent to save
energy and protect the environment.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
22 / EN
Washer-Dryer / User’s Manual
•Daily / Quick
Use to wash your lightly soiled and
unstained cotton laundry in a short time.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Quick 14’
Use it to wash a small amount of lightly soiled
cotton laundry in a short time. This programme
washes your laundry in 14 minutes.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Shirts
Use to wash the shirts made of cotton, synthetic
and synthetic blended fabrics together.
C
INFORMATION
• You can dry your laundry after the
washing cycle without any interruption
(automatic or timed drying can be
performed after washing). For this, you
must also select the Drying function
before starting the washing programme.
• According to the drying selections which
you will add to the washing programmes,
you can see when the programme will
end on the display of the machine.
• If you don’t want drying to take place after
the programme you have selected, press
and hold the Drying auxiliary function
button until the Drying light is turned off.
• Rinse
Use when you want to rinse or starch separately.
• Spin+Drain
Use to drain the water in the machine.
5.6 Temperature selection
Whenever a new programme is selected, the
recommended temperature for the programme
appears on the temperature indicator. It is
possible that the recommended temperature
value is not the maximum temperature that
can be selected for the current programme.
Press the
Temperature Adjustment
button to change the temperature.
C
INFORMATION
• Temperature Adjustment button works
only backwards. For example, when you
want to select 60
0
C when the display
shows 40
0
C you need to press the
button for several times until you reach
60
0
C by going backwards from 40
0
C.
23 / EN
Washer-Dryer / User’s Manual
C
INFORMATION
• If you scroll to Cold Wash option and press
Temperature Adjustment button again,
the recommended maximum temperature
for the selected programme is displayed.
Press the Temperature Adjustment button
again to decrease the temperature.
Finally, Cold light indicating the cold
wash option appears on the display.
You can also change the temperature after
the washing has started. You can select the
desired temperature after washing starts but
you must do this before heating step starts.
5.7 Spin speed selection
Whenever a new programme is selected,
the spin speed recommended for
the selected programme is displayed
on the
Spin Speed
indicator.
C
INFORMATION
• It is possible that the recommended
spin speed value is not the maximum
spin speed that can be selected
for the current programme.
Press the
Spin Speed Adjustment
button to change the spin speed.
Spin speed decreases gradually.
Then, depending on the model of the
product, "Rinse Hold" and "No Spin"
options appear on the display.
C
INFORMATION
• Spin Speed Adjustment button works only
backwards. For example, when you want
to select 1000 rpm when the display shows
800 rpm, you need to press the button
for several times until you reach 1000
rpm by going backwards from 800 rpm.
C
INFORMATION
• Rinse Hold option is indicated with “
” symbol and No Spin option
is indicated with “ ” symbol.
5.7.1 If you want to spin
your laundry after the
Rinse Hold function:
- Adjust the
Spin Speed
.
- Press
Start / Pause / Cancel
button.
The programme resumes. Machine drains
the water and spins the laundry.
If you want to drain the water at
the end of the programme without
spinning, use
No Spin
function.
C
INFORMATION
• In programmes that do not allow
spin speed adjustment, when
Spin Speed adjustment button is
pressed, spin speed light does not
change and the buzzer is heard.
You can also change the Spin Speed
after the washing starts. You can select
spin speed by pressing spin speed
adjustment button after washing has
started but before the spinning step.
5.7.2 Auxiliary function
selection for drying
When a new programme is selected,
press Auxiliary Function Selection button
to adjust the drying option that is suitable
for the selected washing programme.
C
INFORMATION
• In programmes that do not allow drying
adjustment, when Drying auxiliary function
button is pressed drying light does not
change and the buzzer is heard.
24 / EN
Washer-Dryer / User’s Manual
C
INFORMATION
• Only for drying programmes, press
Auxiliary Function Selection button to
adjust the suitable drying option.
5.8 Drying programmes
A
CAUTION!
• Machine cleans the lint coming off
the laundry automatically during the
drying cycle. Machine uses water
during drying. For this reason, water
tap of the machine should be open
also in the drying programmes.
• When a new programme is selected,
press Auxiliary Function Selection button
to adjust the drying option that is suitable
for the selected washing programme.
C
INFORMATION
• Drying programmes contain spinning step.
Your machine performs this process in
order to shorten the drying time. When
drying is selected, spin speed setting
is in Maximum spin speed range.
• In programmes that do not allow drying
adjustment, when Drying auxiliary function
button is pressed drying light does not
change and the buzzer is heard.
• Only for drying programmes, press
Auxiliary Function Selection button to
adjust the suitable drying option.
• While there is a water cut, both washing
and drying could not be performed.
• Synthetic Dry
Use to dry damp synthetic laundry
equivalent to 3 kg dry weight. This
programme performs drying only.
C
INFORMATION
• For the dry weights of the laundry,
see Section 4, Step 4.5
• Cotton Dry
Use to dry damp cotton laundry
equivalent to 4 kg dry weight. This
programme performs drying only.
C
INFORMATION
• In order to dry the laundry which
contains only towels and bathrobes,
load 4 kg laundry maximum.
• For the dry weights of the laundry,
see Section 4, Step 4.5
5.9 Washing and drying
programmes
A
CAUTION!
• Machine cleans the lint coming off
the laundry automatically during the
drying cycle. Machine uses water
during drying. For this reason, water
tap of the machine should be open
also in the drying programmes.
• 4 Kg Wash & Dry
Use to wash cotton laundry up to 4 kg
and dry it right after the washing cycle
without making any other selection.
C
INFORMATION
• When this programme is selected,
external Drying auxiliary function
cannot be selected.
In 4 kg Wash & 4 kg Dry programme, it
is recommended to load laundry until the
level indicated in the above figure for ideal
drying conditions (you will see the level
arrow when you open the loading door).
25 / EN
Washer-Dryer / User’s Manual
• Wash & Wear
Use to wash and dry 0.5 kg laundry
(2 shirts) in 40 minutes or 1 kg
laundry (5 shirts) in 60 minutes.
C
INFORMATION
• Wash&Wear programme is intended to
quickly wash and dry the daily clothes
which were worn for a short period of time
and are not soiled. This programme is
suitable for the laundry which contains thin-
texture and can dry quickly. (shirts, t-shirts)
• Other drying options or programmes
should be used for the thick texture
laundry which take longer to dry.
• Anti Allergy+ Wash & Dry
Use to wash and then immediately dry your
laundry up to 2 kg which requires an anti-allergic
and hygienic washing (baby clothes, bed sheets,
bedding, underpants, etc. cotton items).
C
INFORMATION
• Hygiene+ programme is tested and
approved by “The British Allergy Foundation”
(Allergy UK) in United Kingdom.
• Refresh
Use this programme to remove the odour
on the laundry that are worn only for once
and do not contain any stains or dirt. In the
aeration programme, the ioniser function also
gets activated and cleans your laundry.
• Drum Clean+
To clean the drum, operate the machine once
in every one or two months without loading
it. To obtain better results, put powder lime-
scale remover for washing machines into
the detergent compartment no. „2“. This
programme contains a short drying step which
is activated after the drum cleaning is over.
5.10 Programme and consumption table (for washing)
EN
2
Auxiliary functions
Programme (°C)
Max. Load (kg)
Water Consumption
(l)
Energy Consumption
(kWh)
Max. Speed***
Prewash
Anti Crease+
Pet Hair Removal
Drying
Selectable temperature range
°C
Cottons
90 7,5 78 2,40 1400 • • • • 90-Cold
60 7,5 78 1,50 1400 • • • • 90-Cold
40 7,5 78 1,00 1400 • • • • 90-Cold
Cottons Eco 40** 7,5 77 0,840 1400 • 40-Cold
Synthetics
60 3 67 1,05 1200 • • • • 60-Cold
40 3 67 0,75 1200 • • • • 60-Cold
Wool 40 1,5 45 0,45 1200 40-Cold
Quick 14’ 30 2 32 0,10 1400 • • 30-Cold
Daily/Quick
90 7,5 54 1,90 1400 • • 90-Cold
60 7,5 54 1,10 1400 • • 90-Cold
30 7,5 50 0,18 1400 • • 90-Cold
Shirts 60 3,5 45 0,85 800 • • • • 60-Cold
C
INFORMATION
•
Note for test institutions:
Data required for performance tests shall be provided upon request.Requests can be e-mailed to the following address:
•
Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your
contact information. Code, stock and serial numbers of the product is located on the type label attached to the inside of the door.
26 / EN
Washer-Dryer / User’s Manual
• : Selectable.
* : Automatically selected, no cancelling.
** : Energy Label programme
***: If maximum spin speed of the machine is lower then this value,
you can only select up to the maximum spin speed.
- : See the programme description for maximum load.
C
INFORMATION
• The auxiliary functions in the table may vary according to the model of your machine.
• Water and power consumption may vary subject to the changes in water pressure, water
hardness and temperature, ambient temperature, type and amount of laundry, selection of
auxiliary functions and spin speed, and changes in mains voltage.
• You can see the washing duration on the display of your machine while selecting a programme.
Depending on the amount of laundry you have loaded into your machine, there may be a
difference of 1-1.5 hours between the duration shown on the display and the actual duration of
the wash cycle. Duration will be automatically updated soon after the washing starts.
• “Selection patterns for auxiliary functions can be changed by the
manufacturer. New selection patterns can be added or removed.”
• “The spin speed of your machine may vary according to the programme; this
spin speed cannot exceed the max. spin speed of your machine.”
Programme and consumption table (for drying)
EN
2
Auxiliary
functions
Drying level
Programme (°C)
Max. Load (kg)
Water Consumption (l)
Energy Consumption (kWh)
Max. Speed***
Prewash
Anti Crease+
Pet Hair Removal
Drying
Extra Dry
Cupboard Dry
Iron Dry
Time based drying - minutes
Selectable temperature
range °C
Cotton Dry -
4 36 3,18
1400
•
* • • • • -
Synthetic Dry -
2 20 1,35
-
•
* • • • -
Anti Allergy+ Wash & Dry 60
2 135 3,20
1400 • * • • • • 90-30
4 Kg Wash & Dry 60
4 94 4,10
1400
•
* • • • • 60-Cold
Wash & Wear 20
0,5 35 0,60
1000 • * • 30-Cold
Wash & Wear 30
1 44 1,00
1000 • * • 30-Cold
Refresh - 1 - 0,40 - * -
Drum Clean+ 90 - 77 2,30 600 • 90
27 / EN
Washer-Dryer / User’s Manual
5.11 Auxiliary function selection
Select the desired auxiliary functions
before starting the programme. Whenever
a programme is selected, lights of the
auxiliary functions that can be selected
together with that programme illuminate.
C
INFORMATION
• Light of the auxiliary function that cannot
be selected with the selected programme
does not illuminate. When you press the
buttons of these auxiliary functions, buzzer
is heard and selection is prohibited.
If the wash cycle has reached a point where
you cannot select the auxiliary function,
the function cannot be selected.
C
INFORMATION
• Some functions cannot be selected
together. If a second auxiliary function
conflicting with the first one is selected
before starting the machine, the function
selected first will be cancelled and the
second auxiliary function selection will
remain active. For example, if you want to
select Quick Wash after you have selected
the Prewash, Prewash will be cancelled
and Quick Wash will remain active.
• An auxiliary function that is not compatible
with the programme cannot be selected.
(See “Programme and consumption table”)
• Some programmes have auxiliary
functions that must be operated
with the selected programme. Those
functions cannot be cancelled. Auxiliary
function light is already selected.
C
INFORMATION
• If the selected dampness level (Iron Dry,
Cupboard Dry, Extra Cupboard Dry)
cannot be reached at the end of the
drying cycle, your machine will extend
the programme duration automatically.
Programme will last longer.
• If Timed-Drying is selected, programme
is finished at the end of the drying period
even if the laundry does not get dry.
• If the selected dampness level (Iron
Dry, Cupboard Dry, Extra Cupboard
Dry) is reached during drying cycle,
or extra dryness is detected in the
timed-drying options, programme will
take a shorter time. Time decrease
will be shown on the display.
• Prewash
A Prewash is only worthwhile for heavily
soiled laundry. Not using the Prewash will
save energy, water, detergent and time.
• Pet Hair Removal
This function helps to remove pet hair that
remain on your garments more effectively.
When you select this function, Prewash
and Extra Rinse steps are added to the
normal programme. Thus, washing is
performed with more water (30%) and the
pet hair is removed more effectively.
A
CAUTION!
• Never wash your pets in the
washing machine.
• Anti Crease+
This function makes the garments in the
machine at the end of the programme crease
less. It adds special rotation movements
to the programme, and once the cycle has
ended, it provides aeration for your garments
that will be effective up to 8 hours.
• Drying
This function enables drying of the
laundry after washing. Check with which
programmes this auxiliary function can be
selected, from the programme table.
28 / EN
Washer-Dryer / User’s Manual
5.12 Drying steps
5.12.1 Iron Dry
Drying is performed until the drying level
reaches Iron Dry. It leaves clothes damp
to touch so makes ironing easier.
5.12.2 Cupboard Dry
Drying is performed until the drying level
reaches Cupboard Dry. Clothes are dried
enough to put straight in the cupboard.
5.12.3 Extra Dry
Drying is performed until the drying level
reaches Extra Cupboard Dry. A longer program
for multi-layered or thick fabrics to be dried.
eg bedsheets, towels, bathrobes & blankets.
C
INFORMATION
• Dryness level may change according
to the mixture, material types, amount
and dampness level of the laundry.
• Items which contain accessories such
as lace, tulle, stones, beads, spacer,
wire, etc. and high silk-content items
should not be dried in the machine.
5.12.4 Time based drying-minutes
In order to reach the desired drying level
at low temperature, you select any of 30,
90 and 150 minutes of drying periods.
C
INFORMATION
• When drying small amount of laundry
(up to maximum 2 pieces), timed-drying
steps in the Cottons or Synthetics drying
programmes should be selected.
• If the laundry is not at the desired
dryness level at the end of the drying
programme, timed-drying can be
selected to finish the process.
• When this function is selected, machine
performs drying for the adjusted time
irrespective of the drying level.
5.13 Time display
Remaining time for the completion of the
programme while it is running is displayed
as “01:30” in hours and minutes format.
C
INFORMATION
• Programme time may differ from the values
in section “Programme and consumption
table” depending on the water pressure,
water hardness and temperature, ambient
temperature, amount and the type of
laundry, auxiliary functions selected and
the changes at the mains voltage.
5.14 End Time
With the
End Time
function, the startup of the
programme can be delayed up to 24 hours. After
pressing
End Time
button, the programme's
estimated ending time is displayed. If the
End
Time
is adjusted,
End Time
light illuminates.
In order for the End Time function is activated
and the programme is completed at the
end of the specified time, you must press
Start / Pause
button after adjusting the
time.
Start / Pause
button stops flashing
and remains illuminated continuously.
If you want to cancel End Time function,
press
End Time
button until the End
Time light turns off or press
On / Off
button to turn off and on the machine.
1. Open the loading door, place the
laundry and put detergent, etc.
2. Select the washing programme,
temperature, spin speed and, if
required, the auxiliary functions.
3. Set the end time of your choice
by pressing the
End Time
button.
End Time
light is illuminated.
4. Press
Start / Pause
button. Time countdown
starts. “:” symbol in the middle of the
end time on the display starts flashing.
29 / EN
Washer-Dryer / User’s Manual
C
INFORMATION
• Do not use liquid detergents when you
activate End Time function! There is
the risk of staining of the clothes.
• Door keeps locked during the End
Time countdown period. In order
to unlock the door, machine should
be switched to the pause mode by
pressing the programme start/pause
button. At the end of the countdown,
End Time indicator turns off, washing
cycle starts and the time of the selected
programme appears on the display.
• When the End Time selection is
completed, the time appearing on the
display consists of end time plus the
duration of the selected programme.
5.15 Starting the programme
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
1. Press
Start / Pause
button
to start the programme.
2. The light of
Start / Pause
button which
was flashing starts to illuminate steadily now,
indicating that the programme has started.
3. Loading door is locked. "Locking
the Door" appears on the display
when the door is being locked.
5.16 Loading door lock
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
There is a locking system on the loading
door of the machine that prevents opening
of the loading door in cases when the water
level is unsuitable for door opening.
"Loading door locked" light in the panel
turns on when the loading door is locked.
5.17 Changing the selections
after programme has started
5.17.1 Adding laundry after
the programme has started:
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
If the water level in the machine is suitable when
you press
Start / Pause
button, “Loading
door locked” light on the panel is turned off.
If the water level in the machine is not suitable
when you press
Start / Pause
button, the panel
will indicate that the loading door is locked.
5.17.2 Switching the
machine to pause mode:
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
Press the
Start / Pause
button to
switch the machine to pause mode.
5.17.3 Changing the
programme selection after
programme has started:
Changing the programme is not allowed
when a programme is already running.
If you turn the
Programme Selection
knob while the programme is running,
buzzer is heard and change is prohibited.
You can select the new programme
after switching the current
programme to pause mode.
C
INFORMATION
• The newly selected programme
starts from beginning.
30 / EN
Washer-Dryer / User’s Manual
5.17.4 Changing the
auxiliary function, spin
speed and temperature
Depending on the step the programme has
reached, you can cancel or select auxiliary
functions. See, "Auxiliary function selection".
Also, you can change the spin speed,
temperature and drying settings. See, "Spin
speed selection" and "Temperature selection".
C
INFORMATION
• The loading door will not open if the
water temperature in the machine
is high or the water level is above
the loading door baseline.
5.18 Child Lock
Use Child Lock function to prevent children
from tampering with the machine. Thus you can
avoid any changes in a running programme.
C
INFORMATION
• You can switch the machine on and
off with On / Off button when the Child
Lock is active. When you switch on
the machine again, programme will
resume from where it has stopped.
• Machine will give an audio alarm
when the buttons are pressed
if the child lock is active.
5.18.1 To activate the child lock:
Press and hold 2nd and 3rd auxiliary
function buttons for 3 seconds.
After
the countdown as "Child Lock 3-2-1" on
the display is over, "Child Lock Enabled"
appears on the display. You can release
2nd and 3rd Auxiliary Function
buttons
when this warning is displayed.
5.18.2 To deactivate the child lock:
Press and hold 2nd and 3rd auxiliary
function buttons for 3 seconds.
After
the countdown as "Child Lock 3-2-
1" on the display is over, "Child Lock
Enabled" is turned off on the display.
5.19 Cancelling the programme
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
8.5
10.5
Malzeme rengi ARC 716
Colour of material is ARC 716
%DVN×UHQJL3DQWRQH&
3ULQWLQJFRORULV3DQWRQH&
INLAY STOCK NO:
2846559001
1400
800
1000
600
150’
Ütü Kuruluğu
Dolap Kuruluğu
Extra Kurutma
90’
20°
30’
The programme is cancelled when the
machine is turned off and on again. Press
and hold
On / Off
button for 3 seconds.
After the countdown as "3-2-1" on the
display is over, the machine turns off.
C
INFORMATION
• If you press On / Off button when the
Child Lock is active, the programme
will not be cancelled. You should
cancel the child lock first. Countdown
as “3-2-1” appears on the display.
• If you want to open the loading door
after you have cancelled the programme
but it is not possible to open the loading
door since the water level in the machine
is above the loading door baseline,
then turn the Programme Selection
knob to Pump+Spin programme and
drain the water in the machine.
31 / EN
Washer-Dryer / User’s Manual
5.20 End of programme
When the programme is over the End
of Programme indicator illuminates
and a buzzer is heard.
If you do not press any button for 2 minutes,
the machine will switch to standby mode.
Display and all indicators are turned off.
If you press any button or turn the
Programme
Selection
knob when the machine is in
standby mode, programme steps that are
completed will appear on the display.
5.21 Your machine features
a "Standby Mode".
After you switch on your machine with On-
Off button, if no programme is started or no
other procedure is performed at the selection
step or no action is taken within approx. 2
minutes after the selected programme ends,
your machine will switch to energy saving
mode automatically. Also, if your product has
a display that shows programme time, this
display will be completely turned off. If you turn
the Programme Selection knob or touch any
button, lights and display will switch back to
previous condition. The selections which you
make when exiting from the energy efficiency
may change. Please check the correctness of
your selections before starting the programme.
If necessary, please make your settings again.
6 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced
if it is cleaned at regular intervals.
6.1 Cleaning the detergent drawer
Clean the detergent
drawer at regular
intervals (every 4-5
washing cycles)
as shown below
in order to prevent
accumulation of
powder detergent
in time.
1 Remove the siphon by lifting it from behind
as shown in the picture. After performing
the below mentioned cleaning procedures,
replace the siphon back to its seating
and push its front section downwards to
make sure that the locking tab engages.
C
INFORMATION
• If more than normal amount of water and
softener mixture remains in the softener
compartment, the siphon must be cleaned.
2. Wash the detergent drawer and the siphon
with plenty of lukewarm water in a washbasin.
In order to prevent the residues to contact
your skin, clean it with an appropriate
brush by wearing a pair of gloves.
3 Insert the drawer back into its place after
cleaning and make sure that it is seated well.
6.2 Cleaning the loading
door and the drum
A washer dryer produces combustible lint;
therefore cleaning the door and rubber
gasket after each wash is important.
Use a soft damp cloth to wipe the door,
cleaning any water marks or residue off it.
Wipe the rubber seal around the door. Remove
any items or lint accumulating in the bottom
of the seal catchment and wipe out any
water accumulated here. If this is not cleaned
out, unpleasant odours can also develop.
For products with drum cleaning
programme, please see Operating
the product - Programmes.
32 / EN
Washer-Dryer / User’s Manual
C
INFORMATION
• Repeat Drum Cleaning process in
every 2 months or whenever there’s
excessive lint build up on the rubber
gasket and drum, that could adversely
affect washing & drying performance.
• Use an detergent /anti-limescale
suitable for the washing machines.
After every washing
and drying make
sure that no foreign
substance is left
in the drum.
C
INFORMATION
• Foreign metal substances will cause
rust stains in the drum. Clean the
stains on the drum surface by using
cleaning agents for stainless steel.
Never use steel wool or wire wool.
A
CAUTION!
• Never use sponge or scrub materials.
These will damage the painted,
chrome and plastic surfaces.
6.3 Cleaning the body
and control panel
Wipe the body of the machine with soapy
water or non-corrosive mild gel detergents
as necessary, and dry with a soft cloth.
Use only a soft and damp cloth
to clean the control panel.
6.4 Cleaning the water
intake filters
There is a filter at the end of each water
intake valve at the rear of the machine and
also at the end of each water intake hose
where they are connected to the tap. These
filters prevent foreign substances and dirt
in the water to enter the washing machine.
Filters should be cleaned if they are dirty.
1. Close the taps.
2. Remove the nuts of the water intake
hoses to access the filters on the water
intake valves. Clean residues on them
with an appropriate brush. If the filters are
too dirty, remove them from their places
with a pliers and clean in this way.
3. Take out the filters on the flat ends of the
water intake hoses together with the gaskets
and clean thoroughly under running water.
4. Replace the gaskets and filters
carefully in their places and tighten
the hose nuts by hand.
6.5 Draining remaining water
and cleaning the pump filter
The filter system in your machine prevents
solid items such as buttons, coins and fabric
fibres clogging the pump impeller during
discharge of washing water. Thus, the water
will be drained without any problem and
the service life of the pump will extend.
If the machine fails to drain water, the pump filter
is clogged. Filter must be cleaned whenever it
is clogged or in every 3 months. Water must
be drained off first to clean the pump filter.
In addition, prior to transporting the machine
(e.g., when moving to another house)
and in case of freezing of the water, water
may have to be drained completely.
A
CAUTION!
• Foreign substances left in the pump
filter may damage your product
or may cause noise problem.
• If the product is not being used, shut the
tap, remove mains hose and drain the
water inside the machine in places where
there is the risk of the product freezing .
• After each use, turn off the water tap to
which the mains hose is connected.
33 / EN
Washer-Dryer / User’s Manual
1. In order to clean the dirty filter and
discharge the water, unplug the
machine to cut off the supply power.
A
CAUTION!
• Temperature of the water inside the
machine may rise up to 90 ºC. To avoid
the risk of burning, clean the filter after the
water inside the machine is cooled down.
2. Open the filter cover. Press the tab
in the direction of the arrow and pull
the cover out towards yourself.
3.To drain the water in the machine.
a. In order to collect the water to flow
out of the filter, place a large shallow
vessel in front of the filter.
b. Turn and loosen the pump filter until
water starts to flow (counterclockwise).
Fill the flowing water into the container
you have placed in front of the filter.
Always keep a piece of cloth handy
to absorb any spilled water.
c When the water inside the machine is finished,
take out the filter completely by turning it.
4. Clean any residues inside the filter as well
as fibres, if any, around the pump impeller
region.
5. Replace the filter.
6. Close the filter cover.
7 Troubleshooting
Programmes do not start after the loading door is
closed.
• Start / Pause / Cancel button is not pressed.>>>
*Press Start/
Pause/Cancel button.
• It may be difficult to close the loading door in case of excessive
loading.>>>
*Reduce the amount of laundry and make sure
that the loading door is closed properly.
Programme cannot be started or selected.
• Washing machine has switched to self protection mode due to
a supply problem (line voltage, water pressure, etc. >>>
Press
and hold On/Off button for 3 seconds to reset the machine to
factory settings. (See. “Cancelling the programme”)
Water in the machine.
• Some water may remain in the product due to the quality
control processes in the production. >>>
This is not a failure;
water is not harmful to the machine.
There is water leaking from the bottom of the
machine.
• There is a problem with hoses or the pump filter. >>>
Be sure
the seals of the water inlet hoses are securely fitted. Attach the
hose to the tap tightly.
• Pump filter is not closed securely. >>>
Make sure that the
pump filter is closed securely.
Machine does not fill with water.
• Tap is turned off. >>>
Turn on the taps.
• Water inlet hose is bent. >>>
Flatten the hose.
• Water inlet filter is clogged. >>>
Clean the filter.
• Loading door is not closed. >>>
Close the loading door.
Machine does not drain water.
• Water drain hose is clogged or twisted. >>>
Clean or flatten
the hose.
• Pump filter is clogged. >>>
Clean the pump filter.
Machine vibrates or makes noise.
• Machine is standing unbalanced. >>>
Adjust the feet to level
the machine.
• A hard substance has entered into the pump filter. >>>
Clean
the pump filter.
• Transit bolts are not removed. >>>
Remove the transit bolts.
• Laundry quantity in the machine is too little. >>>
Add more
laundry to the machine.
• Machine is overloaded with laundry. >>>
Take out some of
the laundry from the machine or distribute the load by hand to
balance it.
• Machine is in contact with a rigid surface. >>>
Make sure that
the machine is not contacting anything.
Machine stopped shortly after the programme
started.
• Machine has stopped temporarily due to low voltage. >>>
It
will resume running when the voltage restores to the normal
level.
34 / EN
Washer-Dryer / User’s Manual
Machine directly discharges the water it takes in.
• Draining hose is not at adequate height. >>>
Connect the
water draining hose as described in the user manual.
No water can be seen in the machine during
washing.
• The water level is not visible from outside of the washing
machine. This is not a failure.
Loading door cannot be opened.
• Loading door lock is activated because of the water level in the
machine. >>>
Drain the water by running the Pump or Spin
programme.
• Machine is heating up the water or it is at the spinning cycle.
>>>
Wait until the programme completes.
• Loading door lock is engaged. Loading door lock will be
deactivated a couple of minutes after the programme comes
to an end. >>>
Wait for a couple of minutes for deactivation of
the loading door lock.
• Loading door may be stuck because of the pressure it is
subjected to. >>>
Grab the handle and push and pull the
loading door to release and open it.
Washing takes longer than specified in the user
manual.(*)
• Water pressure is low. >>>
Machine waits until taking in
adequate amount of water to prevent poor washing quality due
to the decreased amount of water. Therefore, the washing time
extends.
• Voltage is low. >>>
Washing time is prolonged to avoid poor
washing results when the supply voltage is low.
• Input temperature of water is low. >>>
Required time to heat
up the water extends in cold seasons. Also, washing time can
be lengthened to avoid poor washing results.
• Number of rinses and/or amount of rinse water have increased.
>>>
Machine increases the amount of rinse water when good
rinsing is needed and adds an extra rinsing step if necessary.
• Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
>>>
Use recommended amount of detergent.
Programme time does not countdown. (On models
with display) (*)
• Timer may stop during water intake. >>>
Timer indicator will
not countdown until the machine takes in adequate amount of
water. The machine will wait until there is sufficient amount of
water to avoid poor washing results due to lack of water. Timer
indicator will resume countdown after this.
• Timer may stop during heating step. >>>
Timer indicator
will not countdown until the machine reaches the selected
temperature.
• Timer may stop during spinning step. >>>
Automatic
unbalanced load detection system might be activated due to
the unbalanced distribution of the laundry in the drum.
Programme time does not countdown. (*)
• Laundry is unbalanced in the machine. >>>
Automatic
unbalanced load detection system might be activated due to
the unbalanced distribution of the laundry in the drum.
Machine does not switch to spinning step. (*)
• Laundry is unbalanced in the machine. >>>
Automatic
unbalanced load detection system might be activated due to
the unbalanced distribution of the laundry in the drum.
• The machine will not spin if water is not drained completely.
>>>
Check the filter and the draining hose.
• Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
>>>
Use recommended amount of detergent.
Washing performance is poor: Laundry turns grey.
(**)
• Insufficient amount of detergent has been used over a long
period of time. >>>
Use the recommended amount of
detergent appropriate for water hardness and the laundry.
• Washing has been performed at low temperatures for a long
time. >>>
Select the proper temperature for the laundry to be
washed.
• Insufficient amount of detergent is used with hard water. >>>
Using insufficient amount of detergent with hard water causes
the soil to accumulate on the clothes over time and turns them
grey. It is difficult to eliminate greying once it happens. Use
the recommended amount of detergent appropriate for water
hardness and the laundry.
• Excessive amount of detergent has been used. >>>
Use the
recommended amount of detergent appropriate for water
hardness and the laundry.
Washing performance is poor: Stains persist or the
laundry is not whitened. (**)
• Insufficient amount of detergent is used. >>>
Use
recommended amount of detergent appropriate for the laundry.
• Excessive laundry is loaded in. >>>
Do not load the machine in
excess. Load with amounts recommended in the "Programme
and consumption table".
• Wrong programme and temperature were selected. >>>
Select the proper programme and temperature for the laundry
to be washed.
• Wrong type of detergent is used. >>>
Use original detergent
appropriate for the machine.
• Detergent is put in the wrong compartment. >>>
Put the
detergent in the correct compartment. Do not mix the bleaching
agent and the detergent with each other.
Washing performance is poor: Oily stains appeared
on the laundry. (**)
• Regular drum cleaning is not applied. >>>
Clean the drum
regularly. For this, please see 6.2.
Washing performance is poor: Clothes smell
unpleasantly. (**)
• Odours and bacteria layers are formed on the drum as a result
of continuous washing at lower temperatures and/or in short
programmes. >>>
Leave the detergent drawer as well as the
loading door of the machine ajar after each washing. Thus, a
humid environment favorable for bacteria cannot occur in the
machine.
35 / EN
Washer-Dryer / User’s Manual
Colour of the clothes faded. (**)
• Excessive laundry was loaded in. >>>
Do not load the machine
in excess.
• Detergent in use is damp. >>>
Keep detergents closed in
an environment free of humidity and do not expose them to
excessive temperatures.
• A higher temperature is selected. >>>
Select the proper
programme and temperature according to the type and soiling
level of the laundry.
Washing machine does not rinse well.
• The amount, brand and storage conditions of the detergent
used are inappropriate. >>>
Use a detergent appropriate for
the washing machine and your laundry. Keep detergents closed
in an environment free of humidity and do not expose them to
excessive temperatures.
• Detergent is put in the wrong compartment. >>>
If detergent
is put in the prewash compartment although prewash cycle is
not selected, machine can take this detergent during rinsing or
softener steps. Put the detergent in the correct compartment.
• Pump filter is clogged. >>>
Check the filter.
• Drain hose is folded. >>>
Check the drain hose.
Laundry became stiff after washing. (**)
• Insufficient amount of detergent is used. >>>
Using insufficient
amount of detergent for the water hardness can cause the
laundry to become stiff in time. Use appropriate amount of
detergent according to the water hardness.
• Detergent is put in the wrong compartment. >>>
If detergent
is put in the prewash compartment although prewash cycle is
not selected, machine can take this detergent during rinsing or
softener steps. Put the detergent in the correct compartment.
•
Detergent was mixed with the softener. >>> Do not mix the
softener with detergent. Wash and clean the drawer with hot water.
Laundry does not smell like the softener. (**)
• Detergent is put in the wrong compartment. >>>
If detergent
is put in the prewash compartment although prewash cycle is
not selected, machine can take this detergent during rinsing or
softener steps. Wash and clean the drawer with hot water. Put
the detergent in the correct compartment.
•
Detergent was mixed with the softener. >>> Do not mix the
softener with detergent. Wash and clean the drawer with hot water.
Detergent residue in the detergent drawer. (**)
• Detergent was put in wet drawer. >>>
Dry the detergent
drawer before putting in detergent.
• Detergent has gotten damp. >>>
Keep detergents closed in
an environment free of humidity and do not expose them to
excessive temperatures.
• Water pressure is low. >>>
Check the water pressure.
• The detergent in the main wash compartment got wet
while taking in the prewash water. Holes of the detergent
compartment are blocked. >>>
Check the holes and clean if
they are clogged.
• There is a problem with the detergent drawer valves. >>>
Call
the Authorised Service Agent.
•
Detergent was mixed with the softener. >>> Do not mix the
softener with detergent. Wash and clean the drawer with hot water.
There is detergent left on the laundry. (**)
• Excessive laundry was loaded in. >>>
Do not load the machine
in excess.
• Wrong programme and temperature were selected. >>>
Select the proper programme and temperature for the laundry
to be washed.
• Wrong detergent was used. >>>
Select the proper detergent
for the laundry to be washed.
Too much foam forms in the machine. (**)
• Improper detergents for the washing machine is used. >>>
Use detergents appropriate for the washing machine.
• Excessive amount of detergent is used. >>>
Use only sufficient
amount of detergent.
• Detergent was stored under improper conditions. >>>
Store detergent in a closed and dry location. Do not store in
excessively hot places.
• Some meshed laundry such as tulle may foam too much
because of their texture. >>>
Use smaller amounts of
detergent for this type of item.
• Detergent was put in the wrong compartment. >>>
Put the
detergent in the correct compartment.
• Softener is being taken early. >>>
There may be problem
in the valves or in the detergent drawer. Call the Authorised
Service Agent.
Foam is overflowing from the detergent drawer.
• Excessive amount of detergent is used. >>>>
Mix 1
tablespoonful softener and ½ L water and pour into the main
wash compartment of the detergent drawer.
• Put detergent into the machine suitable for the programmes
and maximum loads indicated in the “Programme and
consumption table". When you use additional chemicals (stain
removers, bleaches and etc), reduce the amount of detergent.
Laundry remains wet at the end of the programme.
(*)
• Excessive foam has occurred and automatic foam absorption
system has been activated due to too much detergent usage.
>>>
Use recommended amount of detergent.
36 / EN
Washer-Dryer / User’s Manual
Drying lasts too long.
• Excessive laundry loaded. >>> Do not load the machine
in excess.
• Laundry is not spun enough.>>> Spin at a higher spin
speed in washing step in the Dryer-Washing Machine.
• Tap is turned off. >>> Turn on the taps.
Laundry is still damp after drying.
• An appropriate programme according to laundry
type might is not selected.>>>Check care labels on
clothes and select an appropriate programme or use timed
programmes in addition.
• Excessive laundry loaded. >>> Do not load the machine
in excess.
• Laundry is not spun enough.>>> Spin at a higher spin
speed in washing step in the Dryer-Washing Machine.
Machine does not start or programme cannot be started.
• Power cable is not connected. >>> Make sure the power
cable is connected.
• Programme is not set or Start / Pause / Cancel button
is not pressed. >>> Make sure the programme is set and
it is not in Stand-by mode.
• Child lock enabled. >>> Disable Child lock.
Loading door cannot be opened.
Your machine’s door is not opened for safety
reasons.>>>If door locked indicator is still active on display
after drying, machine keeps the loading door locked until it
cools for your safety.
(*) Machine does not switch to spinning step
when the laundry is not evenly distributed
in the drum to prevent any damage to the
machine and to its surrounding environment.
Laundry should be rearranged and re-spun.
(**) Regular drum cleaning is not applied.
>>> Clean the drum regularly. See 6.2
A
CAUTION!
• If you cannot eliminate the problem
although you follow the instructions in
this section, consult your dealer or the
Authorised Service Agent. Never try to
repair a nonfunctional product yourself.
www.beko.com
www.beko.com.au
