GB
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
For all testing institutes:
2) Long cotton cycle: set wash cycle Cotton with a temperature of 40°C.
3) Long synthetics cycle: set wash cycle Synthetics with a temperature of 40°C.
* By selecting the Spin & Drain cycle and excluding the spin cycle, the washing machine will
drain only.
** The duration of the wash cycles can be checked on the display.
*** For Prewash press the “Temp.” button until the symbol lights up (only 90°).
****
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected.The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient
programme in terms of energy and water consumption for washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly differs from the values stated in the table.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
Maximum load 9 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Add
Gar-
ments
(
)
Detergents and
Additives
Recommended
detergent
Residual
dampness % (****)
Energy
consumption kWh
Total water lt
Laundry
temperature °C
Wash cycle
Temperature
Max.
spin speed
(rpm)
Max.
load
(kg)
Dura-
tion
(h : m)
Pre-
wash
Wash
Fabric
softener
Pow-
der
Liquid
Setting Range 1 2 3
Eco 40-60 (1) 40 °C 40°C
1351
9,0
3:40 –
–
53 0,80 58 34
1351
4,5
2:50 –
–
53 0,52 51 35
1351
2,25
2:10 –
–
53 0,40 41 32
Cotton (2)
40°C
- 60°C
1400
9,0
3:55 –
–
49 1,10 97 45
Synthetics (3)
40°C
- 60°C
1200
4,5
2:55 –
–
35 0,80 55 43
Mixed
40°C
- 40°C
1400
9,0
**
–
–
– – – –
Delicates
40°C
- 40°C
1000
4,5
**
–
–
– – – –
White
40°C
- 90°C
1400
9,0
2:00
(***)
55 0,89 89 42
Anti Stain 40°
40°C
- 40°C
1000
4,5
**
–
– – – –
Rapid 30 min
30°C
- 30°C
1200
4,5
0:30
–
–
71 0,18 37 27
Spin & Drain * – – 1400
9,0
** – – – – – – – – – – –
Rinse & Spin – – 1400
9,0
** – – – –
– – – – – –
Steam Refresh – – –
2,0
** – – – – – – – – – – –
20°C 20 °C
- 20 °C
1400
9,0
1:50 –
–
–
55 0,14 78 22
Wool
40°C
- 40°C
800
2,0
** –
–
–
– – – –
Anti Allergy 60°C 40°C - 60°C 1400
5,0
** –
–
– – – –
Bed & Bath
60°C
- 60°C
1400
9,0
**
–
– – – –
Dosing required Dosing optional
DETERGENT DISPENSER DRAWER
compartment 1: Pre-wash detergent (powder)
compartment 2: Detergent for the wash cycle
(powder or liquid)
If liquid detergent is used, it is recommended that
the removable plastic partition A (supplied) be
used for proper dosage.
If powder detergent is used, place the partition
into slot B.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overow the grid.
! Use powder detergent for white cotton
garments, for pre-washing, and for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
3
A
B
1. STEAM HYGIENE / MUTE button
2. FINAL CARE / KEY LOCK button
3. ON/OFF button
4. ACTIVE CARE button and indicator light
5. START/PAUSE button
6. RAPID / GREEN button
7. SPIN button
8. START DELAY button
9. TEMPERATURE button
10. WASH CYCLE SELECTOR KNOB
1 2
4
5
67
8
9
3
10
DISPLAY
