Danby DLS060WDB Laundry Stacking Kit User Manual

DANBY PRODUCTS LIMITED, ONTARIO, CANADA N1H 6Z9

DANBY PRODUCTS INC., FINDLAY, OHIO, USA 45840

OWNER’S MANUAL

MANUEL DU PROPRIÉTAIRE

MANUAL DEL PROPIETARIO

2018.01.03

LAUNDRY STACKING KIT

Owner’s Manual...............................1 - 5

KIT D’EMPILAGE POUR LA LESSIVE

Manuel du propriétaire...................6 - 10

KIT DE APILAMIENTO PARA LAVANDERÍA

Manual del propietario.................11 - 16

MODEL • MODÈLE • MODELO

DLS060WDB

Welcome

Welcome to the Danby family. We are proud of our quality products and we believe in

dependable service. We suggest that you read this owner’s manual before plugging in your new

appliance as it contains important operation information, safety information, troubleshooting and

maintenance tips to ensure the reliability and longevity of your appliance.

Visit www.Danby.com to access self service tools, FAQs and much more. For additional assistance

call 1-800-263-2629.

Note the information below; you will need this information to obtain service under warranty.

You must provide the original purchase receipt to validate your warranty and receive service.

Model Number: _________________________________________________

Serial Number: _________________________________________________

Date of Purchase: _______________________________________________

Need Help?

Before you call for service, here are a few things you can do to help us serve you better.

Read this owner’s manual:

It contains instructions to help you use and maintain your appliance properly.

If you receive a damaged appliance:

Immediately contact the retailer or builder that sold you the appliance.

Save time and money:

Check the troubleshooting section at the end of this manual before calling. This section

will help you solve common problems that may occur.

1-800-26- Danby

(1-800-263-2629)

1

INSTALLATION INSTRUCTIONS

COMPONENTS

Before beginning to assemble the laundry stacking

kit, ensure that you have all parts listed below.

Part Description Quantity

A Left side bracket 1

B Right side bracket 1

C Top bracket 1

D Crossbeam 1

E Screw 8

F Allen key 1

G Nut 8

H Wall mount anti tip support 2

I Wall anchor 2

J Self tapping screw 2

A

B

C

D

E

F

G

A

H

I

J

72.5 cm (28.6 in)

55 cm (21.7 in)

117.3 cm (46.2 in)

48 cm (18.9 in)

DIMENSIONS

2

INSTALLATION INSTRUCTIONS

ASSEMBLY

The laundry stacking kit is designed to

accommodate both top loading or front loading

washing machines. Follow assembly instructions

below.

Assemble the bracket

1. Lay the left side bracket on its side with the

connections pointed upward. Insert the top

bracket and the crossbeam into the connection

points on the left side bracket. Secure them with

the screws and nuts.

2. Attach the right side bracket to the top bracket

and the crossbeam and secure it with the screws

and nuts.

3. Stand the bracket up and ensure that all nuts are

tightened and all connection points are secure.

1

2

3

INSTALLATION INSTRUCTIONS

Install the wall mount anti tip supports

1. Attach the wall mount anti tip supports to the left

and right side brackets. Secure them with the

screws and nuts.

2. Attach the wall mount anti tip supports to the

wall using the wall anchors and the self tapping

screws.

Note: The laundry stacking kit must be secured to

the wall to ensure that the dryer does not present a

falling hazard.

1

2

DRYER INSTALLATION

Remove the adjustable feet from the dryer before

placing on the stacking kit. Center the dryer on the

stacking kit and the reinstall the four legs to secure

the dryer to the stacking kit.

Important note: If the dryer seems

unstable or if there is signiﬁ cant motion

or noise from the dryer when it is in use,

ensure that the leveling legs are tightened

to minimize vibration and noise.

4

LIMITED IN-HOME APPLIANCE WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under the normal operating

conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.) (hereafter

“Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

Plastic parts, are warranted for thirty (30) days only from purchase date, with no extensions provided.

First Year

During the rst twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced, at warrantor’s

option, at no charge to the ORIGINAL purchaser.

To obtain

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an Authorized Service Depot. Any app liance

Service

requiring service outside the limited boundaries of “In Home Service” , it will be the consumer’s responsibility to transport the appliance (at

their own expense) to the original retailer (point of purchase) or a service depot for repair. See “Boundaries of In Home Serv ice” below.

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service

must be performed by a qualied service technician.

If service is performed on the units by anyone other than an authorized service depot, or the unit is used for commercial appli cation, all

obligations of Danby under this warranty shall be void.

Boundaries of

If the appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center your unit must be

In Home Service

delivered to the nearest authorized Danby Service Depot, as service must only be performed by a technician qualied and certif ied for

warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are t he

responsibility of the purchaser.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other c ontents of this appliance, whether due

to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, m ade or intended by Danby or its

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditio ns, representations or guarantees

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall no t be responsible for any damages

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction o f the unit and by the purchase of

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or propert y caused by the unit.

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating con ditions

(extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, oods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for out door application).

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our

AUTHORIZED SERVICE DEPOT.

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

04/09

1-800-263-2629

Warranty Service

In-home

Transportation charges to and from the service location are not protected by this warranty and are the responsibility of the purchaser.

During the ﬁrst twelve (12) months, any functional parts of this product found to be defective, will be repaired or

replaced, at warrantor’s option, at no charge to the original purchaser.

Contact the dealer where the unit was purchased, or contact the nearest authorized Danby service depot, where

service must be performed by a qualiﬁed service technician. If service is performed on the unit by anyone other

than an authorized service depot, all obligations of Danby under this warranty shall be void.

It is the responsibility of the purchaser to transport the appliance to the nearest authorized service depot.

First 12 months

To obtain service

LIMITED “CARRY IN” WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used

under the normal operating conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby

Products Inc. (U.S.A.) (hereafter “Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

Plastic parts are warranted for thirty (30) days from the date of purchase, with no extensions provided.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other

contents of this appliance, whether due to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS

Save as herein provided, by Danby, there are no other warranties, conditions, representations or guarantees, express or implied, made

or intended by Danby or its authorized distributors and all other warranties, conditions, representations or guarantees, including any

warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or statute is hereby expressly

excluded. Save as herein provided, Danby shall not be responsible for any damages to persons or property, including the unit itself,

howsoever caused or any consequential damages arising from the malfunction of the unit and by the purchase of the unit, the

purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or property caused by

the unit.

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating

conditions (ie. extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, ﬂoods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for outdoor

application, including but not limited to: garages, patios, porches or anywhere that is not properly insulated or climate controlled).

Proof of purchase date will be required for warranty claims; retain bills of sale. In the event that warranty service is required, present

the proof of purchase to our authorized service depot.

Warranty Service

Carry In

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

1-800-263-2629

04/17

Bienvenue

Bienvenue à la famille Danby. Nous sommes ﬁ ers de la qualité de nos produits et nous croyons

en le service ﬁ able. Nous vous suggérons de lire ce manual d’utilisation avant de brancher

votre nouvel appareil car il contient des informations inportantes sur l’utilisation, la sécurité, le

dépannage et la maintenance, aﬁ n d’assurer la ﬁ abilité et la longévité de votre appareil.

Visitez www.Danby.com pour accéder aux outils d’autoservice, aux FAQ et bien plus encore. Pour

obtenir de l’aide supplémentaire, composez 1-800-263-2629.

Notez les informations ci-dessous; Vous aurez besoin de cette information pour obtenir un

service sous garantie.

Vous devez fournir le reçu d’achat original pour valider votre garantie et recevoir le service.

Numéro de modèle: _____________________________________________

Numéro de serie: _______________________________________________

Date d’achat: __________________________________________________

Besoin d’assistance?

Avant d’appeler pour service, voici quelques choses que vous pouvez faire pour nous

aider à mieux vous servir.

Lire ce manuel du propriétaire:

Il contient des instructions pour vous aider à utiliser et à maintenir votre appareil

correctement.

Si vous recevez un appareil endommagé:

Contactez immédiatement le revendeur ou l’entrepreneur qui vous a vendu l’appareil.

Gagnez du temps et de l’argent:

Avant d’appeler pour service, consultez la section de dépannage à la ﬁ n de ce manuel.

Cette section vous aidera à résoudre les problèmes courants pouvant survenir.

1-800-26- Danby

(1-800-263-2629)

6

INSTRUCTIONS D’INSTALLATION

COMPOSANTS

Avant de commencer à assembler le kit d’empilage,

assurez-vous d’avoir toutes les pièces listées ci-

dessous.

Partie Description Quantité

A Support latéral gauche 1

B Support latéral droit 1

C Support supérieur 1

D Traverse 1

E Vis 8

F Clé mécanique 1

G Écrou 8

H Support anti-basculement 2

I Ancrage mural 2

J Vis autotaraudeuse 2

A

B

C

D

E

F

G

A

H

I

J

72.5 cm (28.6 po)

55 cm (21.7 po)

117.3 cm (46.2 po)

48 cm (18.9 po)

DIMENSIONS

7

INSTRUCTIONS D'INSTALLATION

ASSEMBLÉE

Le kit d’empilage de linge est conçu pour accueillir

les machines à laver à chargement par le haut ou

à chargement frontal. Suivez les instructions de

montage ci-dessous.

Assemblez le support

1. Poser le support gauche sur le côté avec les

connexions pointées vers le haut. Insérez le

support supérieur et la traverse dans les points

de connexion sur le support latéral gauche.

Fixez-les avec les vis et les écrous.

2. Fixez le support latéral droit au support

supérieur et à la traverse et ﬁ xez-le avec les vis

et les écrous.

3. Tenez le support vers le haut et assurez-vous que

tous les écrous sont serrés et que tous les points

de connexion sont bien ﬁ xés.

1

2

3

8

INSTRUCTIONS D'INSTALLATION

Installez les supports anti-basculement

1. Fixez les supports anti-basculement aux supports

latéraux gauche et droit. Fixez-les avec les vis et

les écrous.

2. Fixez les supports anti-basculement au mur

en utilisant les ancrages muraux et les vis

autotaraudeuses.

Remarque: Le kit d’empilage du linge doit être

ﬁ xé au mur pour s’assurer que le sèche-linge ne

présente pas de risque de chute.

1

2

INSTALLATION DE SÉCHEUSE

Retirez les pieds réglables de la sécheuse avant de

les placer sur le kit d’empilage. Centrez la sécheuse

sur le kit d’empilage et réinstallez les quatre pattes

pour ﬁ xer la sécheuse au kit d’empilage.

Remarque importante: Si le sèche-linge

semble instable ou s’il y a un mouvement

ou un bruit important de la sécheuse

lorsqu’il est utilisé, assurez-vous que les

pieds de nivellement sont serrés pour

minimiser les vibrations et le bruit.

9

LIMITED IN-HOME APPLIANCE WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under the normal operating

conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.) (hereafter

“Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

Plastic parts, are warranted for thirty (30) days only from purchase date, with no extensions provided.

First Year

During the rst twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced, at warrantor’s

option, at no charge to the ORIGINAL purchaser.

To obtain

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an Authorized Service Depot. Any app liance

Service

requiring service outside the limited boundaries of “In Home Service” , it will be the consumer’s responsibility to transport the appliance (at

their own expense) to the original retailer (point of purchase) or a service depot for repair. See “Boundaries of In Home Serv ice” below.

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service

must be performed by a qualied service technician.

If service is performed on the units by anyone other than an authorized service depot, or the unit is used for commercial appli cation, all

obligations of Danby under this warranty shall be void.

Boundaries of

If the appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center your unit must be

In Home Service

delivered to the nearest authorized Danby Service Depot, as service must only be performed by a technician qualied and certif ied for

warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are t he

responsibility of the purchaser.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other c ontents of this appliance, whether due

to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, m ade or intended by Danby or its

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditio ns, representations or guarantees

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall no t be responsible for any damages

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction o f the unit and by the purchase of

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or propert y caused by the unit.

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating con ditions

(extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, oods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for out door application).

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our

AUTHORIZED SERVICE DEPOT.

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

04/09

1-800-263-2629

Warranty Service

In-home

Les frais de transport entre votre domicile et le lieu de l'entretien ne sont pas couverts par la présente garantie et doivent être

acquittés par l'acheteur.

Pendant les premiers douze (12) mois, toutes les pièces fonctionnelles de ce produit qui s’avèrent défectueuses

seront réparées ou remplacées, selon le choix du garant, sans frais à l’acheteur initial.

Contactez le revendeur où l'appareil a été acheté ou contactez le dépôt de service Danby autorisé le plus

proche, où le service doit être effectué par un technicien de service qualiﬁé. Si le service est effectué sur

l'appareil par une personne autre qu'un dépôt de service autorisé, toutes les obligations de Danby en vertu de

cette garantie seront annulées.

Il est de la responsabilité de l'acheteur de transporter l'appareil vers le dépôt de service agréé le plus proche.

Premiers 12 mois

Pour obtenir un

service

GARANTIE LIMITÉE “EN ATELIER”

Cet appareil de qualité est garanti exempt de tout vice de matière première et de fabrication, s’il est utilisé dans les conditions normales

recommandées par le fabricant.

Cette garantie n’est offerte qu’à l’acheteur initial de l’appareil vendu par Danby Products Limited (Canada) ou Danby Products Inc.

(E.- U.A.) (ci-après « Danby ») ou par l’un des ses distributeurs agréés et elle ne peut être transférée.

CONDITIONS

Les pièces en plastique sont garanties pendant trente (30) jours seulement à partir de la date de l’achat, sans aucune prolongation

prévue.

Aucune partie de la garantie ne prévoit implicitement que le fabricant sera tenu responsable des dommages subis par les aliments ou

d’autres types de contenu, qu’ils soient causés par la défectuosité de l’appareil ou par son usage adéquat ou inadéquat.

EXCLUSIONS

En vertu de la présente, il n’existe aucune autre garantie, condition ou représentation, qu’elle soit exprimée ou tacite, de façon

manifeste ou intentionnelle, par Danby ou ses distributeurs agréés. De même, sont exclues toutes les autres garanties, conditions ou

représentations, y compris les garanties, conditions ou représentations en vertu de toute loi régissant la vente de produits ou de toute

autre législation ou règlement semblables. En vertu de la présente, Danby ne peut être tenue responsable en cas de blessures

corporelles ou des dégâts matériels, y compris à l’appareil, quelle qu’en soit les causes. Danby ne peut pas être tenue responsable

des dommages indirects dus au fonctionnement défectueux de l’appareil. En achetant l’appareil, l’acheteur accepte de mettre à

couvert et de dégager Danby de toute responsabilité en cas de réclamation pour toute blessure corporelle ou tout dégât matériel

causé par cet appareil.

CONDITIONS GÉNÉRALES

La garantie ou assurance ci-dessus ne s’applique pas si les dégâts ou réparations sont dus aux cas suivants:

1) Panne de courant.

2) Dommage subis pendant le transport ou le déplacement de l’appareil.

3) Alimentation électrique incorrecte (tension faible, câblage défectueux, fusibles incorrects).

4) Accident, modiﬁcation, emploi abusif ou incorrect de l’appareil tel qu'une circulation d'air inadéquate dans la pièce ou des

conditions de fonctionnement anormales (température extrêmement élevée ou basse).

5) Utilisation dans un but commercial ou industriel (à savoir, si l'appareil n'est pas installé dans un domicile résidentiel).

6) Incendie, dommages causés par l’eau, vol, guerre, émeute, hostilités, cas de force majeure (ouragan, inondation, etc.).

7) Visites d’un technicien pour expliquer le fonctionnement de l’appareil au propriétaire.

8) Installation inappropriée (par exemple, encastrement d'un appareil autoportant, ou utilisation extérieure d'un appareil non conçu à

cet effet, y compris, mais sans s'y limiter: les garages, les patios, les porches ou ailleurs qui ne sont pas correctement isolés ou

climatisés).

La preuve de la date d'achat sera requise pour les réclamations de garantie; Conserver les factures de vente. Dans le cas où un

service de garantie est requis, présentez la preuve d'achat à notre dépôt de service agréé.

Service sous garantie

En Atelier

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Téléphone : (519) 837-0920 Télécopieur: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Téléphone: (419) 425-8627 Télécopieur: (419) 425-8629

1-800-263-2629

04/17

1-800-26- Danby

(1-800-263-2629)

Bienvenido

Bienvenido a la familia Danby. Estamos orgullosos de nuestros productos de calidad y creemos en

un servicio conﬁ able. Sugerimos que lea este manual del propietario antes de conectar el nuevo

aparato ya que contiene información importante sobre la operación, información de seguridad,

solución de problemas y consejos de mantenimiento para garantizar la ﬁ abilidad y longevidad de

su electrodoméstico.

Visite www.Danby.com para acceder a herramientas de autoservicio, preguntas frecuentes y

mucho más. Para asistencia adicional, llame al 1-800-263-2629.

Tenga en cuenta la información siguiente; Necesitará esta información para obtener un servicio

bajo garantía.

Debe proporcionar el recibo de compra original para validar su garantía y recibir servicio.

Número de modelo: _____________________________________________

Número de serie: _______________________________________________

Fecha de compra: _______________________________________________

Necesitas ayuda?

Antes de llamar al servicio, aquí hay algunas cosas que puede hacer para ayudarnos a

servirle mejor.

Lea este manual del propietario:

Contiene instrucciones para ayudarle a usar y mantener su aparato correctamente.

Si recibe un aparato dañado:

Inmediatamente póngase en contacto con el minorista o el constructor que le vendió el

aparato.

Ahorre tiempo y dinero:

Consulte la sección de solución de problemas al ﬁ nal de este manual antes de llamar. Esta

sección le ayudará a resolver problemas comunes que pueden ocurrir.

11

INSTRUCCIONES DE INSTALACIÓN

COMPONENTES

Antes de comenzar a armar el kit de apilamiento

de ropa, asegúrese de tener todas las piezas que se

detallan a continuación.

Parte Descripción Cantidad

A Soporte lateral izquierdo 1

B Soporte lateral derecho 1

C Soporte superior 1

D Travesaño 1

E Tornillo 8

F Allen key 1

G Tuerca 8

H Soporte antideslizante 2

I Ancla de pared 2

J Tornillo penetrante 2

A

B

C

D

E

F

G

A

H

I

J

72.5 cm (28.6 pulg)

55 cm (21.7 pulg)

117.3 cm (46.2 pulg)

48 cm

(18.9 pulg)

DIMENSIONES

12

INSTRUCCIONES DE INSTALACIÓN

MONTAJE

El kit de apilamiento de ropa está diseñado para

acomodar lavadoras de carga superior o carga

frontal. Siga las instrucciones de ensamblaje a

continuación.

Montar el soporte

1. Coloque el soporte lateral izquierdo de lado

con las conexiones apuntando hacia arriba.

Inserte el soporte superior y la viga transversal

en los puntos de conexión en el soporte lateral

izquierdo. Asegúrelos con los tornillos y tuercas.

2. Fije el soporte lateral derecho al soporte

superior y la viga transversal y asegúrelo con

los tornillos y tuercas.

3. Coloque el soporte hacia arriba y asegúrese

de que todas las tuercas estén apretadas y que

todos los puntos de conexión estén seguros.

1

2

3

13

14

INSTRUCCIONES DE INSTALACIÓN

Instale los soportes anti-punta

1. Coloque los soportes antivuelco en los soportes

laterales izquierdo y derecho. Asegúrelos con

los tornillos y tuercas.

2. Fije los soportes antivuelco a la pared con los

anclajes de pared y los tornillos autorroscantes.

Nota: El kit de apilamiento de la colada debe

asegurarse a la pared para asegurar que la

secadora no presente un peligro de caídas.

1

2

INSTALACIÓN DE LA SECADORA

Retire los pies ajustables de la secadora antes

de colocarlos en el kit de apilamiento. Centre la

secadora en el kit de apilamiento y vuelva a instalar

las cuatro patas para asegurar la secadora al kit de

apilamiento.

Nota importante: Si la secadora parece

inestable o si hay un movimiento o ruido

signiﬁ cativo de la secadora cuando

está en uso, asegúrese de que las patas

niveladoras estén apretadas para

minimizar la vibración y el ruido.

LIMITED IN-HOME APPLIANCE WARRANTY

This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under the normal operating

conditions intended by the manufacturer.

This warranty is available only to the person to whom the unit was originally sold by Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.) (hereafter

“Danby”) or by an authorized distributor of Danby, and is non-transferable.

TERMS OF WARRANTY

Plastic parts, are warranted for thirty (30) days only from purchase date, with no extensions provided.

First Year

During the rst twelve (12) months, any functional parts of this product found to be defective, will be repaired or replaced, at warrantor’s

option, at no charge to the ORIGINAL purchaser.

To obtain

Danby reserves the right to limit the boundaries of “In Home Service” to the proximity of an Authorized Service Depot. Any app liance

Service

requiring service outside the limited boundaries of “In Home Service” , it will be the consumer’s responsibility to transport the appliance (at

their own expense) to the original retailer (point of purchase) or a service depot for repair. See “Boundaries of In Home Serv ice” below.

Contact your dealer from whom your unit was purchased, or contact your nearest authorized Danby service depot, where service

must be performed by a qualied service technician.

If service is performed on the units by anyone other than an authorized service depot, or the unit is used for commercial appli cation, all

obligations of Danby under this warranty shall be void.

Boundaries of

If the appliance is installed in a location that is 100 kilometers (62 miles) or more from the nearest service center your unit must be

In Home Service

delivered to the nearest authorized Danby Service Depot, as service must only be performed by a technician qualied and certif ied for

warranty service by Danby. Transportation charges to and from the service location are not protected by this warranty and are t he

responsibility of the purchaser.

Nothing within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other c ontents of this appliance, whether due

to any defect of the appliance, or its use, whether proper or improper.

EXCLUSIONS

Save as herein provided, Danby, there are no other warranties, conditions, representations or guarantees, express or implied, m ade or intended by Danby or its

authorized distributors and all other warranties, conditions, representations or guarantees, including any warranties, conditio ns, representations or guarantees

under any Sale of Goods Act or like legislation or statue is hereby expressly excluded. Save as herein provided, Danby shall no t be responsible for any damages

to persons or property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction o f the unit and by the purchase of

the unit, the purchaser does hereby agree to indemnify and hold harmless Danby from any claim for damages to persons or propert y caused by the unit.

GENERAL PROVISIONS

No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:

1) Power failure.

2) Damage in transit or when moving the appliance.

3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.

4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating con ditions

(extremely high or low room temperature).

5) Use for commercial or industrial purposes (ie. If the appliance is not installed in a domestic residence).

6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, oods etc.

7) Service calls resulting in customer education.

8) Improper Installation (ie. Building-in of a free standing appliance or using an appliance outdoors that is not approved for out door application).

Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our

AUTHORIZED SERVICE DEPOT.

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

04/09

1-800-263-2629

Warranty Service

In-home

Durante los primeros doce (12) meses, cualquier parte en buen estado de este producto que resulte defectuosa,

incluyendo cualquier sistema sellado, será reparado o reemplazado, a opción del fabricante, sin cargo para

el comprador original.

Póngase en contacto con el distribuidor donde adquirió el electrodoméstico o póngase en contacto con el

centro de servicio autorizado más cercano de Danby, donde el servicio debe ser realizado por un técnico

cualiﬁcado. Si el servicio es realizado por cualquier persona que no sea un depósito de servicio autorizado,

todas las obligaciones de Danby bajo esta garantía serán nulas.

Es responsabilidad del comprador transportar el aparato al centro de servicio autorizado más cercano.

Primeros 12 meses

Para obtener servicio

GARANTÍA LIMITADA “ACARREADO SOLAMENTE”

Este producto de calidad está garantizado contra defectos de fabricación, incluyendo partes y mano de obra, siempre y cuando la

unidad se utilice bajo las condiciones normales de funcionamiento para las que fue diseñado.

Esta garantía está solamente disponible para la persona que haya comprado originalmente esta unidad directamente de Danby

Products Limited (Canada) o Danby Products Inc. (U.S.A.) (en adelante “Danby”) o uno de sus distribuidores autorizados, y no es

transferible.

CONDICIONES DE LA GARANTÍA

Las piezas plásticas, se autorizan por treinta (30) días solamente a partir de la fecha de la compra, sin las extensiones

proporcionadas.

Nada dentro de esta garantía implica que Danby será responsable por cualquier daño que hayan sufrido los alimentos u otros

contenidos de este aparato, ya sea debido a un defecto del aparato, o su uso, adecuado o inadecuado.

EXCLUSIONES

Salvo lo aquí indicado por Danby, no existen otras garantías, condiciones o representaciones, explícitas o implícitas, concretas o

intencionales por parte de Danby o sus distribuidores autorizados y todas las demás garantías, condiciones o representaciones,

incluyendo cualquier garantía, condiciones o representaciones bajo cualquier Acta de Venta de Productos o legislación o estatuto

similar, quedan de esta forma expresamente excluidas. Salvo lo aquí indicado, Danby no serán responsables por ningún daño a

personas o bienes, incluyendo la propia unidad, sin importar su causa, o de ningún daño indirecto causado por el desperfecto de la

unidad, y al comprar esta unidad, el comprador acepta por la presente, indemnizar y proteger a Danby contra cualquier reclamo

por daños a personas o bienes causados por la unidad.

CONDICIONES GENERALES

No se considerará ninguna de estas garantías o seguros cuando el daño o la necesidad de reparación sea el producto de los

siguientes casos:

1) Falla del suministro eléctrico.

2) Daños en tránsito o durante el transporte de la unidad.

3) Alimentación incorrecta, como bajo voltaje, instalación eléctrica defectuosa o fusibles inadecuados.

4) Accidente, modiﬁcación, abuso o uso incorrecto del artefacto, tal como insuﬁciente ventilación del ambiente o condiciones de

operación anormales (temperatura ambiente extremadamente alta o baja).

5) Utilización comercial o industrial (v.g., si el electrodoméstico no está instalado en una vivienda particular).

6) Incendio, daños por agua, robo, guerra, disturbios, hostilidades, actos de fuerza mayor como huracanes, inundaciones, etc.

7) Pedidos de servicio debido a desinformación del usuario.

8) Instalación inadecuada (v.g., instalación de un electrodoméstico independiente o uso de un aparato al aire libre que no esté

aprobado para aplicaciones en exteriores, incluyendo pero no limitado a: garajes, patios, porches o cualquier lugar que no esté bien

aislado o controlado por el clima).

Se requerirá una prueba de la fecha de compra para reclamaciones de garantía; conservar las facturas de venta. En el caso de que

se requiera servicio de garantía, presente el comprobante de compra a nuestro depósito de servicio autorizado.

Servicio de Garantía

Acarreado Solamente

Danby Products Limited

PO Box 1778, Guelph, Ontario, Canada N1H 6Z9

Telephone: (519) 837-0920 FAX: (519) 837-0449

Danby Products Inc.

PO Box 669, Findlay, Ohio, U.S.A. 45840

Telephone: (419) 425-8627 FAX: (419) 425-8629

1-800-263-2629

04/17

Los cargos de transporte desde y hacia el lugar de servicio no están protegidos por esta garantía y son responsabilidad del

comprador.

NOTES / REMARQUES / NOTAS :

__________________________________________________________________________________________

NOTES / REMARQUES / NOTAS :

__________________________________________________________________________________________

NOTES / REMARQUES / NOTAS :

__________________________________________________________________________________________

MODEL • MODÈLE • MODELO

Printed in China

Imprimé en Chine

Impreso en China

Danby Products Limited, Guelph, ON, Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio, USA 45840

DLS060WDB

Danby DLS060WDB Laundry Stacking Kit

Product's Documents

Owner's Manual

Specifications

Danby DLS060WDB Questions and Answers

Related Products

Danby DDY040D4WDB 24-inch, 4.0 cu ft. Compact Condensing Sensor Dryer in White with Stacking kit

Blomberg DHP24404W3 24 inch Ventless Heat Pump Dryer with Stacking Kit and 4.5 cu. ft. Capacity

HPSS8I Hisense Series 8i Stacking Kit-Black

ASKS60G5 Fisher & Paykel Contemporary Stacking Kit with Tray Graphite ASKS60G4

ASKS60W5 Fisher & Paykel Contemporary Stacking Kit with Tray White

STKIT-EW LG Washer+Dryer Stacking Kit with Shelf Essence White
