USER MANUAL
Read carefully before using the machine.
Register your product and get support at
www.philips.com/welcome
English
Type HD8772
EN
02
02
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons do not immerse
cord, plugs, or appliance in water or other liquid.
4. Close supervision is necessary when the appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to “off”, then remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Save these instructions.
SAVE THESE INSTRUCTIONS
CAUTION
This appliance is for household use only. Any servicing, other than cleaning
and user maintenance, should be performed by an authorized service center.
Do not immerse machine in water. To reduce the risk of fire or electric shock,
do not disassemble the machine. There are no parts inside the machine
serviceable by the user. Repair should be done by authorized service personnel
only.
1. Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2. Never use warm or hot water to fill the water tank. Use cold water only.
3. Keep your hands and the cord away from hot parts of the appliance during
operation.
4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.
5. For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
6. Do not use caramelized or flavored coffee beans.
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer detachable power-supply cords or extension cords are available
and may used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used,
1. The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance
2. If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3. The longer cord should be arranged so that it will not drape over the
counter top or table top where it can be pulled on by children or tripped
over.
2
ENGLISH
Congratulations on your purchase of a Saeco Minuto Auto-
matic Milk Frother full automatic co ee machine!
To fully bene t from the support that Saeco o ers, please
register your product at www.philips.com/welcome.
This user manual applies to HD8772.
The machine is made for preparing espresso and co ee
using whole co ee beans and for dispensing steam and hot
water. In this user manual you will nd all the information
you need to install, use, clean and descale your machine.
3
ENGLISH
CONTENTS
INSTALLATION ................................................................................................. 4
Product Overview ......................................................................................................................................4
General Description ...................................................................................................................................5
PREPARING FOR USE ........................................................................................ 6
Machine Packaging ...................................................................................................................................6
Machine Installation .................................................................................................................................6
USING THE MACHINE FOR THE FIRST TIME ......................................................... 8
Circuit Priming ..........................................................................................................................................8
Automatic Rinse/Self-Cleaning Cycle.........................................................................................................9
Manual Rinse Cycle..................................................................................................................................10
Measuring and Programming Water Hardness ........................................................................................12
“INTENZA+” Water Filter Installation ......................................................................................................13
Replacing the “INTENZA+” Water Filter ...................................................................................................15
ADJUSTMENTS ................................................................................................16
Saeco Adapting System ...........................................................................................................................16
Adjusting the Ceramic Co ee Grinder ......................................................................................................16
Adjusting the Aroma (Beverage Strength) ..............................................................................................17
Adjusting the Dispensing Spout ..............................................................................................................18
“ESPRESSO” or “COFFEE” selection lever ...................................................................................................19
Adjusting the Beverage Cup Length .......................................................................................................21
BREWING AN "ESPRESSO". ...............................................................................22
Brewing an Espresso using Co ee Beans .................................................................................................22
Brewing an Espresso using Pre-Ground Co ee ........................................................................................23
BREWING A COFFEE.........................................................................................24
Brewing a Co ee Using Co ee Beans ......................................................................................................24
Brewing a co ee Using Pre-Ground Co ee ..............................................................................................25
DISPENSING STEAM/CAPPUCCINO BREWING ....................................................27
HOT WATER DISPENSING .................................................................................29
CLEANING AND MAINTENANCE ........................................................................31
Daily Cleaning of the Machine .................................................................................................................31
Daily Cleaning of the Water Tank .............................................................................................................32
Daily Cleaning of the Automatic Milk Frother ..........................................................................................33
Weekly Cleaning of the Machine .............................................................................................................34
Weekly Cleaning of the Brew Group ........................................................................................................35
Monthly Cleaning of the Automatic Milk Frother.....................................................................................37
Monthly Lubrication of the Brew Group ..................................................................................................43
Monthly Cleaning of the Brew Group with “Co ee Oil Remover” .............................................................44
Monthly Cleaning of the Co ee Bean Hopper ..........................................................................................46
DESCALING .....................................................................................................47
PROGRAMMING ..............................................................................................51
The following settings can be adjusted ...................................................................................................51
How to Program the Machine .................................................................................................................52
MEANING OF THE DISPLAY ICONS .....................................................................54
TROUBLESHOOTING ........................................................................................58
ENERGY SAVING ..............................................................................................60
Stand-by .................................................................................................................................................60
Disposal ..................................................................................................................................................60
TECHNICAL SPECIFICATIONS ............................................................................61
WARRANTY AND SERVICE ................................................................................61
Warranty .................................................................................................................................................61
Service ....................................................................................................................................................61
ORDERING MAINTENANCE PRODUCTS ..............................................................62
4
INSTALLATION
Product Overview
33
19
21
22
24
23
20
123
4
11 12 14
5
6
7
8
9
10
26 29
27 30
28 31
17
16
18
25
32
13
15
5
ENGLISH
5
General Description
1. Grinder adjustment knob
2. Co ee bean hopper
3. Pre-ground co ee compartment
4. Water tank + Lid
5. Co ee bean hopper lid
6. Control panel
7. Espresso / co ee dispensing spout
8. Full drip tray indicator
9. Cup holder grill
10. Drip tray
11. Co ee grounds drawer
12. Brew group
13. Co ee residues drawer
14. Service door
15. Espresso/Co ee selection lever
16. Steam wand + rubber grip for Automatic Milk Frother
(also for hot water dispensing)
17. Automatic Milk Frother (also for steam dispensing)
18. Suction tube for Automatic Milk Frother
19. Power cord socket
20. Power button
21. Grease for the brew group
22. Power cord
23. Water hardness test strip
24. Co ee grinder adjustment key + Pre-ground co ee scoop
25. Cleaning brush
26. Espresso brew button
27. Medium co ee brew button
28. Long co ee brew button
29. Hot water/steam button
30. "Aroma" - Pre-ground co ee button
31. Menu button
32. ON/OFF button
33. Descaling solution- to be purchased separately
6
ENGLISH
PREPARING FOR USE
Machine Packaging
The original packaging has been designed and constructed to protect the
machine during transport. We recommend keeping the packaging material
for possible future transport.
Machine Installation
1
Remove the machine from the packaging.
2
For best use, it is recommended to:
• Choose a safe, level surface, where there will be no danger of over-
turning the machine or being injured.
• Choose a location that is su ciently well-lit, clean and near an eas-
ily reachable socket.
• Allow for a minimum distance from the sides of the machine as
shown in the illustration.
3
Remove the water tank lid.
4
Lift the water tank using the handle.
7
ENGLISH
7
8
Slowly pour the co ee beans into the co ee bean hopper.
Note:
Do not pour too many co ee beans into the co ee bean hopper as this will
reduce the grinding performance of the machine.
Caution:
Only co ee beans must be put into the co ee bean hopper. Ground
co ee, instant co ee, avored co ee or any other object may damage
the machine.
9
Put back the co ee bean hopper lid on the co ee bean hopper.
10
Insert the plug into the socket located on the back of the machine.
11
Insert the plug at the other end of the power cord into a wall socket
with suitable power voltage.
1
2
5
Rinse the water tank with fresh water.
6
Fill the water tank with fresh water up to the MAX level and reinsert it
into the machine. Make sure it is fully inserted.
Caution:
Never ll the water tank with warm, hot, sparkling water or any other
liquid, as this may cause damage to the water tank and the machine.
7
Remove the co ee bean hopper lid.
8
ENGLISH
12
Switch the power button to “I” to turn on the machine. The “ ” button
ashes.
Yellow
13
To turn on the machine simply press the “ ” button. The control panel
indicates that the circuit must be primed.
USING THE MACHINE FOR THE FIRST TIME
When using the machine for the rst time, the following activities need to
happen:
1) You need to prime the circuit.
2) The machine will perform an automatic rinse/self-cleaning cycle.
3) You need to initiate a manual rinse cycle.
Circuit Priming
During this process fresh water ows through the internal circuit of the
machine and the machine warms up. This takes a few minutes.
1
Place a container under the steam wand.
9
ENGLISH
9
Yellow
2
Press the “ ” button to start the cycle. The machine starts the auto-
matic priming of the circuit by dispensing some water through the
steam wand.
Yellow
3
The bar under the icon shows the operation progress. When the pro-
cess is completed, the machine stops dispensing automatically.
Yellow
4
Then the control panel shows the machine warm-up icon.
Automatic Rinse/Self-Cleaning Cycle
When warm-up is complete, the machine automatically performs a rinse/
self-cleaning cycle of the internal circuit with fresh water. This takes less
than a minute.
1
Place a container under the dispensing spout to catch the small
amount of water which will be dispensed.
2
The machine shows this display. Wait for the cycle to nish automati-
cally.
Note:
You can stop dispensing by pressing the “
” button.
YellowGreen
3
When the above steps are complete, the machine shows this display.
You can now perform the manual rinse cycle.
10
ENGLISH
Manual Rinse Cycle
During this process you activate the co ee brewing cycle and fresh water
ows through the water circuit. This takes a few minutes.
1
Place a container under the dispensing spout.
Green
2
Check that the machine shows this display.
3
Select the pre-ground co ee brewing function by pressing the “ ”
button. The machine shows this display.
Note:
Do not add pre-ground co ee to the compartment.
4
Check that the selection lever is set to “ESPRESSO”. Press the “ ” but-
ton. The machine starts dispensing water.
5
When the dispensing has nished, empty the container. Repeat the
operations from step 1 to step 4 twice, then continue with step 6.
Green
6
Place a container under the steam wand.
ESPRESSO
11
ENGLISH
11
Green Red
7
Press the “ ” button. The machine shows this display.
9
Dispense water until the no water icon appears.
Note:
You can interrupt the manual rinsing by pressing the “
”button. To restart
press the “
” button and then the “ ” button.
10
Fill the water tank again up to the MAX level. Now the machine is ready
for co ee brewing.
The display to the left will be shown.
Note:
When the machine has not been operated for at least two weeks, it will
automatically perform a start-up rinse/self-cleaning cycle. Following this,
you need to initiate a manual rinse cycle as described above.
The automatic rinse/self-cleaning cycle starts automatically when the ma-
chine has been in stand-by mode or switched o for more than 15 minutes.
At the end of the cycle, it is possible to brew a co ee.
Green
8
Press the “ ” button to start dispensing hot water.
12
ENGLISH
Measuring and Programming Water Hardness
Water hardness measuring is very important in order to de ne the descal-
ing frequency and to install the “INTENZA+” water lter (for more detail on
the water lter, see next chapter).
To measure the water hardness follow the steps below:
1
Immerse the water hardness test strip (supplied with the machine) in
water for 1 second.
Note:
The test strip can only be used for one single measurement.
2
Wait for one minute.
23 4
A
B
C
Intenza Aroma System
Machine Water Hardness Setting
1
3
Check how many squares have changed to the color red and then refer
to the table.
Note:
The numbers on the water hardness test strip correspond to the water
hardness adjustment settings.
More precisely:
1 = 1 (very soft water)
2 = 2 (soft water)
3 = 3 (hard water)
4 = 4 (very hard water)
The letters correspond to the references that are located at the base of the
“INTENZA+” water lter (see next chapter).
Yellow
4
Press the “ ” button and scroll the pages by pressing the “ ” button
until the following icon is displayed.
Note:
The machine is supplied with a standard water hardness setting, suitable
for most types of water.
13
ENGLISH
13
Yellow
5
Press the “ ” button to increase the value or the “ ” button to de-
crease the value.
6
Press the “ ” button to con rm the setting.
Green
7
Press the “ ” button to exit the programming MENU. The machine
shows this display and is ready to brew.
“INTENZA+” Water Filter Installation
We recommend that you install the “INTENZA+” water lter as this prevents
limescale build-up in your machine and preserves a more intense aroma of
your co ee.
The “INTENZA+” water lter can be purchased separately. For further de-
tails, please refer to the maintenance products page in this manual.
Water is a crucial part of every espresso/co ee, so it’s important to always
have it professionally ltered. Using the “INTENZA+” water lter will prevent
mineral deposits from building up and improve your water quality.
1
Remove the small white lter from the water tank and store it in a dry
place.
2
Remove the “INTENZA+” water lter from its packaging, immerse it ver-
tically (with the opening positioned upwards) in cold water and gently
press the sides so as to let the air bubbles out.
14
ENGLISH
4
Put the “INTENZA+” water lter into the empty water tank. Press it
down until it cannot move any further.
5
Fill the water tank with fresh water and reinsert it into the machine.
6
Dispense all the water of the tank by using the hot water function (see
“Hot Water Dispensing” chapter).
7
Fill the water tank again.
8
Press the “ ” button and scroll the pages by pressing the “ ” button
until the following display is shown.
Yellow
9
Press the “ ” button to select “ON” and press the “ ” button to con-
rm.
YellowGreen
10
To exit, press the “ ” button. The machine shows this display and is
ready to brew.
The machine has been programmed to inform the user when to replace
the “INTENZA+” water lter.
3
Set the “INTENZA+” water lter according to the measurements per-
formed (see previous chapter) and indicated on the base of the lter:
A = soft water – equals 1 or 2 on the test strip
B = hard water (standard) – equals 3 on the test strip
C = very hard water – equals 4 on the test strip
15
ENGLISH
15
Yellow
Replacing the “INTENZA+” Water Filter
When the “INTENZA+” water lter needs to be replaced with a new one, the
following icon is displayed.
1
Replace the “INTENZA+” water lter as described in the previous chap-
ter.
2
Press the “ ” button and scroll the pages by pressing the “ ” button
until the following icon is displayed.
Yellow YellowGreen
3
Select the “RESET” option. Press the " " button to con rm.
4
To exit, press the “ ” button. The machine shows this display and is
ready to brew.
The machine is now programmed to manage a new “INTENZA+” water
lter.
Note:
If the “INTENZA+” water lter is already installed and you want to remove,
but not replace it, select the “OFF” option instead.
If there is no “INTENZA+” water lter installed, insert the small white lter
previously removed back into the water tank.
Yellow
16
ENGLISH
ADJUSTMENTS
The machine allows for certain adjustments so that you can brew the best
tasting co ee possible.
Saeco Adapting System
Co ee is a natural product and its characteristics may change according to
its origin, blend and roast. The machine is equipped with a self-adjusting
system that allows the use of all types of co ee beans available on the
market except for avored co ee beans.
The machine automatically adjusts itself after brewing several cups of
co ee to optimize the extraction of the co ee to the compactness of the
ground co ee.
Adjusting the Ceramic Co ee Grinder
Ceramic co ee grinders always guarantee accurate and perfect grinding
and coarseness for every co ee speciality.
This technology provides for full aroma preservation, delivering the truly
Italian taste in every cup.
Warning:
The ceramic co ee grinder contains moving parts that may be danger-
ous. Do not insert ngers or other objects. Only adjust the ceramic
co ee grinder using the grinder adjustment key.
The grinders can be set to adjust the grinding to your personal taste.
17
ENGLISH
17
1
Press and turn the grinder adjustment knob below the co ee bean
hopper one notch at a time. Use the co ee grinder adjustment key
provided with the machine.’You will taste the di erence after brewing
2-3 cups of co ee.
1
2
2
The reference marks inside the co ee bean hopper indicate the grind
setting. There are 5 di erent grind settings to choose from position
1 for coarse grind - milder taste to position 2 for ne grind - stronger
taste
Adjusting the Aroma (Beverage Strength)
Choose your favorite co ee blend and adjust the amount of co ee to be
ground according to your personal taste. You can also select the pre-
ground co ee function.
Note:
Selection must be made prior to selecting the desired beverage.
Five choices are possible by pressing the “
” button. Each time the
button is pressed, the aroma changes by one degree, according to the
selected amount:
= extra mild aroma
= mild aroma
= medium aroma
= strong aroma
= extra strong aroma
= pre-ground co ee
GreenGreen
18
ENGLISH
Adjusting the Dispensing Spout
The height of the dispensing spout can be adjusted to better t the
dimensions of the cups that you wish to use. The lower part of the dispens-
ing spout can be removed to allow a tumbler to be used.
Move the dispensing spout up or down with your ngers to adjust its
height as shown in the image.
The recommended positions are:
For the use of small cups;
For the use of large cups.
Two cups can also be placed under the dispensing spout to brew two cups
of espresso at the same time.
19
ENGLISH
19
Remove the lower part of the dispensing spout to allow a tumbler to be
used.
Note:
Before installing the lower part of the dispensing spout, clean it together
with the upper part.
“ESPRESSO” or “COFFEE” selection lever
The machine allows you to adjust the brewing pressure according to the
desired beverage type.
This selection allows you to optimize machine operation to improve the
quality of co ee brewing and the desired result in the cup.
This selection must be made prior to brewing a beverage by simply mov-
ing manually the lever positioned on the dispensing spout.
20
ENGLISH
RedRed
ESPRESSO
COFFEE
The lever allows two types of brewing:
1
Push the lever downwards to select the “ESPRESSO” function.
In this position you can brew an espresso co ee by pressing the “
”
button.
Note:
If an espresso co ee is selected with the lever in the wrong position, the
following icon will be displayed reminding you to set the lever to the cor-
rect position.
2
Push the lever upwards to select the “COFFEE” function.
In this position you can brew a medium or long co ee by pressing the
“
” button or the “ ” button.
Note:
If a “COFFEE” product is selected with the lever in the wrong position, the
following icon will be displayed reminding you to set the lever to the cor-
rect position.
21
ENGLISH
21
Adjusting the Beverage Cup Length
The machine allows you to adjust the amount of brewed co ee according
to your taste and the size of your cups.
Each time the “
”, “ ” or “ ” button is pressed, the machine brews a
pre-set amount of beverage. Each button may be individually programmed
for a speci c brew setting.
The following procedure describes how to program the “
” button.
1
Place a cup under the dispensing spout.
Green
3
Press and hold the “ ” button until the “MEMO” icon appears on
the display, then release the button. The machine has now entered
programming mode.
The machine starts brewing co ee.
4
Press the “ ” button as soon as the desired amount of co ee is
reached.
Now the “
” button is programmed; each time it is pressed, the machine
will brew the same amount of espresso that was just programmed.
Note:
To program the other two “
” or “ ” beverages, the same steps should
be followed. You should always use the “
” button to stop brewing
co ee when the desired amount of co ee is reached even when you are
programming the other two “
”or “ ” beverages.
Green
2
Check the position of the selection lever.
22
ENGLISH
BREWING AN "ESPRESSO".
Before brewing an espresso co ee, make sure that there are no warnings
shown on the control panel, and that the water tank and co ee bean hop-
per are lled.
3
To brew an espresso, press the “ ” button to select the desired
aroma.
4
To brew an espresso, press the “ ” button once. This icon will be
displayed.
5
To brew two espressos, press the “ ” button twice consecutively. This
icon will be displayed.
Note:
In this operating mode, the machine automatically grinds and doses the
correct amount of co ee. Brewing two espressos requires two grinding
and brewing cycles, automatically carried out by the machine.
GreenGreen
Brewing an Espresso using Co ee Beans
1
Place 1 or 2 cups under the dispensing spout.
ESPRESSO
2
Push the lever downwards to select the “ESPRESSO” function.
23
ENGLISH
23
6
After the prebrewing cycle, the beverage begins to pour out of the
dispensing spout.
7
Espresso brewing automatically stops when the preset level is reached;
press the “
” button to stop it earlier.
ESPRESSO
Green
2
Press the “ ” button until the display shows the icon for pre-ground
co ee.
3
Lift the pre-ground co ee compartment lid and add one scoop of pre-
ground co ee to the compartment.
Use only the measuring scoop supplied with the machine. Then close
the pre-ground co ee compartment lid.
Warning:
Add only pre-ground co ee to the pre-ground co ee compartment.
Other substances and objects may cause severe damage to the ma-
chine. Such damage will not be covered by warranty.
Brewing an Espresso using Pre-Ground Co ee
This function allows you to use pre-ground co ee.
With the pre-ground co ee function you can only brew one beverage at a
time.
1
Push the lever downwards to select the “ESPRESSO” function.
24
ENGLISH
4
Press the “ ” button to brew an espresso. The brewing cycle starts.
5
After the prebrewing cycle, the beverage begins to pour out of the
dispensing spout.
6
Brewing automatically stops when the preset level is reached; press the
“
” button to stop it earlier.
After brewing, the machine returns to the main menu.
Repeat the steps described above to brew more espressos using pre-
ground co ee.
Note:
If no pre-ground co ee is poured into the pre-ground co ee compart-
ment, only water will be dispensed.
If the dose is excessive and 2 or more scoops of pre-ground co ee are
used, the machine will not brew the product and any ground co ee will be
discharged into the co ee grounds drawer.
BREWING A COFFEE
Before brewing co ee, make sure that there are no warnings shown on the
control panel, and that the water tank and co ee bean hopper are lled.
Brewing a Co ee Using Co ee Beans
1
Place 1 MUG or 1 TUMBLER under the dispensing spout.
Note:
Refer to section “Adjusting the Dispensing Spout” for the “Tumbler” posi-
tioning.
25
ENGLISH
25
COFFEE
GreenGreen
COFFEE
2
Push the lever upwards to select the “COFFEE” function.
3
To brew a beverage, press the “ ” button to select the desired aroma.
4
To brew a medium co ee, press the “ ” button once. This icon will be
displayed.
5
To brew a long co ee, press the “ ” button once. This icon will be
displayed.
Note:
In this operating mode, the machine automatically grinds and doses the
correct amount of co ee.
6
After the prebrewing cycle, the beverage begins to pour out of the
dispensing spout.
7
Beverage brewing automatically stops when the preset level is reached;
press the “
” button to stop it earlier.
Brewing a co ee Using Pre-Ground Co ee
This function allows you to use pre-ground co ee.
With the pre-ground co ee function you can only brew one beverage at a
time.
1
Push the lever upwards to select the “COFFEE” function.
26
ENGLISH
Green
2
Press the “ ” button to select the pre-ground co ee function.
3
Lift the pre-ground co ee compartment lid and add one measuring
scoop of pre-ground co ee to the compartment. Use only the measur-
ing scoop supplied with the machine. Then close the pre-ground
co ee compartment lid.
Warning:
Add only pre-ground co ee to the pre-ground co ee compartment.
Other substances and objects may cause severe damage to the ma-
chine. Such damage will not be covered by warranty.
4
Press the “ ” button for a medium co ee or the “ ” button for a long
co ee. The brewing cycle starts.
5
After the prebrewing cycle, co ee begins to pour out of the dispensing
spout.
6
Co ee brewing automatically stops when the preset level is reached;
press the “
” button to stop it earlier.
After brewing, the machine returns to the main menu.
Repeat the steps described above to brew more co ees using pre-ground
co ee.
Note:
If no pre-ground co ee is poured into the pre-ground co ee compart-
ment, only water will be dispensed.
If more scoops have been added, the machine will not brew the product
and the ground co ee in the compartment will be discharged into the cof-
fee grounds drawer.
27
ENGLISH
27
DISPENSING STEAM/CAPPUCCINO BREWING
Warning:
Danger of scalding! Dispensing may be preceded by small jets of hot
water. The Automatic Milk Frother may reach high temperatures.
Never touch it with bare hands. Use the appropriate protective handle
only.
1
Fill 1/3 of a container with cold milk.
Note:
To make a good quality cappuccino, use cold milk (~5°C / 41°F) with a
protein content of at least 3%. Whole milk or skimmed milk may be used
depending on individual taste.
Note:
When you plan to dispense steam right after switching on the machine or
after brewing a co ee, some water still present in the circuit may need to
be dispensed rst. For this press the “
” button and then the “ ” but-
ton to dispense steam for a few seconds. Thereafter press the “
” button
to stop. Continue with step 2.
4
Plunge the suction tube in the milk container.
2
Insert the suction tube into the Automatic Milk Frother.
3
Insert the Automatic Milk Frother until it locks in place in the steam
wand seat.
Caution:
Make sure that the suction tube outer surface is clean for hygienic
reasons.
28
ENGLISH
Yellow
5
Place a cup under the Automatic Milk Frother.
Green
Red
6
Press the “ ” button. The machine shows this display.
7
Press the “ ” button to start dispensing steam.
Note:
Steam dispensing automatically stops after a continued use of 3 minutes.
Press the “
” button then the “ ” button to start dispensing steam
again.
8
The following icon is displayed during pre-heating time required by
the machine.
9
When this icon is displayed, the machine dispenses frothed milk
directly in the cup.
10
Press the “ ” button to stop brewing.
29
ENGLISH
29
11
For storage you can put the suction tube as shown in the picture.
Note:
After having pressed the “
” button it will take a few seconds before the
machine stops dispensing steam completely.
Caution:
After frothing the milk, a small quantity of hot water must be dis-
pensed into a container. See chapter "Daily cleaning of the Automatic
Milk Frother" for detailed cleaning instructions.
HOT WATER DISPENSING
Warning:
Danger of scalding! Dispensing may be preceded by small jets of hot
water. The Automatic Milk Frother may reach high temperatures.
Never touch it with bare hands. Use the appropriate protective handle
only.
Before dispensing hot water, make sure that the machine is ready to use
and the water tank is lled.
1
Place a container under the steam wand.
Note:
After frothing the milk, it is possible to brew an espresso or dispense hot
water straight after.
Green
30
ENGLISH
2
Press the “ ” button. The machine shows this display.
Red
3
Press the “ ” button to start dispensing hot water.
Green Yellow
4
The following icon is displayed during pre-heating time required by
the machine.
5
Pour the desired amount of hot water. To stop the hot water dispens-
ing, press the “
” button.
31
ENGLISH
31
CLEANING AND MAINTENANCE
Daily Cleaning of the Machine
Caution:
Timely cleaning and maintenance of your machine is very important
as it prolongs the life of your machine. Your machine is continuously
exposed to moisture, co ee and limescale!
The activities you need to perform and their frequency are described
in detail in this chapter. Not doing this will ultimately make your
machine stop working properly. This repair is NOT covered by your
warranty!
Note:
- Use a soft, dampened cloth to clean the machine.
- Only the cup holder grill and the Automatic Milk Frother can be
washed in the dishwasher. All other components must be washed with
lukewarm water.
- Do not immerse the machine in water.
- Do not use alcohol, solvents, and/or abrasive objects to clean the
machine.
- Do not dry the machine and/or its components using a microwave
and/or standard oven.
1
3
2
1
Empty and clean the co ee grounds drawer and the drip tray daily
with the machine turned on.
Other maintenance operations can only be carried out when the machine
is turned o and unplugged.
2
Remove the co ee grounds drawer and empty it.
3
Empty and clean the drip tray.
32
ENGLISH
4
Insert the co ee grounds drawer back into the drip tray and this into
the machine.
Note:
Also empty the drip tray when the full drip tray indicator is raised.
Daily Cleaning of the Water Tank
1
Remove the small white lter or the “INTENZA+” water lter (if in-
stalled) from the water tank and wash it with fresh water.
2
Put the small white lter or the “INTENZA+” water lter (if installed)
back in its housing by gently pressing and turning it at the same time.
3
Fill the water tank with fresh water.
1
3
2
33
ENGLISH
33
Daily Cleaning of the Automatic Milk Frother
For hygienic reasons and to ensure a perfect milk froth consistency, it is
important that the Automatic Milk Frother be cleaned after each use.
Warning:
Danger of scalding! Dispensing may be preceded by small jets of hot
water.
2
Place an empty container under the Automatic Milk Frother.
After each milk frothing you always need to:
1
Plunge the suction tube into a container lled with fresh water.
Red
3
Press the “ ” button. The machine shows this display.
34
ENGLISH
Weekly Cleaning of the Machine
1
Clean the seat of the drip tray.
2
Clean the pre-ground co ee compartment with the cleaning brush.
Yellow
4
Press the “ ” button to start dispensing steam.
5
This icon is displayed during pre-heating time required by the ma-
chine.
Green
6
The following icon will be displayed during the dispensing phase.
Dispense water from the Automatic Milk Frother until clear water ows
out. Press the “
” button to stop dispensing.
7
Clean the suction tube with a damp cloth.
3
Remove the lower part of the dispensing spout and wash it with luke-
warm water.
35
ENGLISH
35
Weekly Cleaning of the Brew Group
The brew group should be cleaned every time the co ee bean hopper is
lled or at least once a week.
1
Turn o the machine by pressing the “ ” button and unplug the
power cord.
2
Remove the drip tray and co ee grounds drawer. Only at this time
open the service door.
1
3
2
3
To remove the brew group, press the «PUSH» button pulling it by the
handle and pull it out horizontally without turning it.
4
Remove the co ee residues drawer and wash it thoroughly.
36
ENGLISH
5
Thoroughly wash the brew group with fresh, lukewarm water and care-
fully clean the upper lter.
Caution:
Do not use detergent or soap to clean the brew group.
6
Let the brew group air-dry thoroughly.
7
Thoroughly clean the inside of the machine using a soft, dampened
cloth.
8
Make sure the brew group is in the rest position; the two reference
signs must match. If they do no match up, proceed as described in
steps 9-10.
9
Gently pull down the lever until it is in contact with the brew group
base and the two reference signs on the side of the brew group match.
10
Make sure the hook to lock the brew group is in the correct position by
rmly pressing the “PUSH” button until it locks into place. Check if the
hook is at the top end position. If it is not, please try again.
37
ENGLISH
37
12
Insert the brew group in its seat again until it locks into place without
pressing the “PUSH” button.
13
Insert the co ee grounds drawer with the drip tray back into the ma-
chine and close the service door.
11
Insert the co ee residues drawer in its seat and ensure that it is cor-
rectly in place.
Note:
If the co ee residues drawer is not correctly positioned, the brew group
may not t into the machine.
Monthly Cleaning of the Automatic Milk Frother
Every month you need to perform a more thorough cleaning of the Auto-
matic Milk Frother using the “Saeco Milk Circuit Cleaner”. The “Saeco Milk
Circuit Cleaner” can be purchased separately. Please refer to the mainte-
nance product page in this user manual for further details.
Warning:
Danger of scalding! Dispensing may be preceded by small jets of hot
water.
38
ENGLISH
1
Make sure that the Automatic Milk Frother is correctly installed.
2
Pour the milk circuit cleaner into a container. Add 17 ounces of luke-
warm water and wait for the product to dissolve completely.
3
Insert the suction tube into the container.
4
Place a large container (51 ounces) under the Automatic Milk Frother.
Yellow
6
Press the “ ” button to start dispensing steam.
7
This icon is displayed during pre-heating time required by the ma-
chine.
Red
5
Press the “ ” button. The machine shows this display.
39
ENGLISH
39
Green
8
The following icon will be displayed during dispensing. When the
solution has been completely dispensed, press the “
” button to stop
dispensing.
Note:
Steam dispensing automatically stops after a continued use of 3 minutes.
Press the “
” button then the “ ” button to start dispensing steam
again.
Warning:
Never drink the solution dispensed during this step.
9
Rinse the container thoroughly and ll it with 17 ounces of fresh water
to be used for the rinse cycle.
10
Insert the suction tube into the container.
11
Empty the container and place it back under the Automatic Milk
Frother.
40
ENGLISH
Green
Yellow
13
Press the “ ” button to start dispensing steam.
14
This icon is displayed during pre-heating time required by the ma-
chine.
15
The following icon will be displayed during dispensing. When the
solution has been completely dispensed, press the “
” button to stop
dispensing.
Note:
Steam dispensing stops after 3 minutes. Press the “
” button then the “
” button to start dispensing steam again.
16
Wash all the Automatic Milk Frother components by following the
instructions below.
17
Remove the Automatic Milk Frother from the machine.
18
Remove the rubber grip from the steam wand.
Caution:
Warning: The tube could be hot if the machine has recently been used.
Red
12
Press the “ ” button. The machine shows this display.
41
ENGLISH
41
19
Take o the suction tube.
21
Remove the rubber lid as shown in the gure.
22
Wash all the components with lukewarm water.
20
To detach the Automatic Milk Frother, press the sides and remove it by
applying light lateral movements as shown in the gure.
23
Attach the lid by pressing in the middle, and ensure that it is rmly in
place.
42
ENGLISH
Caution:
Do not insert the rubber grip further than the seat shown. In this case,
the Automatic Milk Frother would not function correctly as it would
not be able to draw up milk.
27
Insert the Automatic Milk Frother on the rubber grip until it locks into
place.
26
Insert the rubber grip back on the steam wand.
Caution:
Warning: The tube could be hot if the machine has recently been used.
25
Install the suction tube.
24
Attach the Automatic Milk Frother to the tting and ensure it is locked
into place in its seat.
43
ENGLISH
43
Monthly Lubrication of the Brew Group
Lubricate the brew group after approximately 500 cups of co ee or once a
month.
The grease to lubricate the brew group can be purchased separately. For
further details, please refer to the maintenance products page in this
manual.
Caution:
Before lubricating the brew group, clean it with fresh water and let it
dry, as described in the “Weekly Cleaning of the Brew Group” chapter.
1
Apply the grease evenly on both side guides.
2
Also lubricate the shaft.
44
ENGLISH
3
Insert the brew group in its seat until it locks into place (see “Weekly
Cleaning of the Brew Group” chapter).
4
Close the service door and insert the drip tray and co ee grounds
drawer.
Monthly Cleaning of the Brew Group with “Co ee Oil Remover”
Besides weekly cleaning, we recommend running the cleaning cycle with
“Co ee Oil Remover” after approximately 500 cups of co ee or once a
month. This operation completes the maintenance process for the brew
group.
You can purchase separately the “Co ee Oil Remover”. For further details,
please refer to the maintenance products page in this manual.
Caution:
The “Co ee Oil Remover” tablets are to be used for cleaning only and
do not have a descaling function. For the descaling procedure use the
Saeco descaling solution and follow the procedure described in the
“Descaling” chapter.
1
Place a container under the dispensing spout.
2
Make sure the water tank is lled with fresh water up to the “MAX”
level.
45
ENGLISH
45
3
Put a “Co ee Oil Remover” tablet in the pre-ground co ee compart-
ment.
Green
4
Press the “ ” button to select the pre-ground co ee function without
adding pre-ground co ee to the compartment.
5
Push the lever downwards to select the “ESPRESSO” function.
6
Press the “ ” button to start the brewing cycle.
7
Wait until the machine has dispensed half a cup of water.
8
Switch the power button on the back of the machine to “0”.
11
Remove the drip tray and the co ee grounds drawer and open the
service door. Remove the brew group.
9
Let the solution take e ect for about 15 minutes. Make sure you dis-
card the dispensed water.
10
Switch the power button on the back of the machine, to “I”. To turn on
the machine, press the “
” button.
Wait until the end of the automatic rinse cycle.
46
ENGLISH
Green
13
After rinsing the brew group, insert it again in its seat until it locks into
place (see “Weekly Cleaning of the Brew Group” chapter). Insert the
drip tray and the co ee grounds drawer. Close the service door.
14
Press the “ ” button to select the pre-ground co ee function without
adding pre-ground co ee to the compartment.
15
Press the “ ” button to start the brewing cycle.
16
Repeat steps 14 to 15 twice. Make sure you discard the dispensed
water.
17
To clean the drip tray, place “Co ee Oil Remover” tablet inside and ll
it 2/3rds full with hot water. Let the cleaning solution take e ect for
about 30 minutes, then rinse thoroughly.
Monthly Cleaning of the Co ee Bean Hopper
Clean the co ee bean hopper once a month when it is empty with a damp
cloth to remove co ee oil. Thereafter re ll it with co ee beans.
12
Wash the brew group thoroughly with fresh water.
1
3
2
47
ENGLISH
47
DESCALING
The descaling process takes approx. 35 minutes.
Limescale builds up inside the machine during use. It needs to be removed
regularly as it may clog the water and co ee circuit of your machine. The
machine tells you when descaling is needed. If the machine display shows
the CALC CLEAN icon, it means that you need to descale it.
Caution:
Not doing this will ultimately make your machine stop working prop-
erly, and in this case repair is NOT covered by your warranty.
Yellow
Always use the specially formulated descaling solution, since it has been
designed to optimize machine performance.
The descaling solution can be purchased separately. For further details,
please refer to the maintenance products page in this manual.
Warning:
Never drink the descaling solution or any products dispensed until the
cycle has been carried out to the end. Never use vinegar as a descaling
solution.
Note:
During the descaling cycle do not switch o the machine. If the machine
has been switched o , it will continue the descaling from the point at
which it was interrupted the next time it is turned on.
To execute the descaling cycle, follow the steps below:
Before descaling:
1
Empty the drip tray and the co ee grounds drawer.
1
3
2
48
ENGLISH
Yellow
2
Remove the Automatic Milk Frother from the steam/hot water wand.
3
Remove the “INTENZA+” water lter from the water tank if it was in-
stalled and replace it with the small white original one. Place the water
tank back into the machine.
4
Press the “ ” button until the following display is shown.
5
Press the “ ” button to start the descaling process.
Yellow
Note:
If you press the “
” button by mistake, press the “ ” button to quit.
6
Remove the water tank and pour in the entire contents of the descal-
ing solution. Then top up the tank with fresh water up to the calc clean
level.
7
Place the water tank back into the machine.
8
Place a large container (1.5l) under both the steam/hot water wand
and the dispensing spout.
49
ENGLISH
49
9
Press the “ ” button to start the descaling cycle.
YellowYellow
10
The machine will start dispensing the descaling solution at regular
intervals. The bar on the control panel shows the cycle progress.
Note:
The descaling cycle may be paused by pressing the
“ ”
button. To resume
the cycle, press the
“ ”
button again. This allows you to empty the container
or to stay away from the machine for a brief period of time.
Yellow
11
When this icon is displayed, the water tank is empty.
RedRed
12
Remove the water tank, rinse it and ll it up to the MAX level with fresh
water. Place it back into the machine. When inserting the water tank
into the machine, the following display is shown.
13
Empty the drip tray and co ee grounds drawer and place them back in
position.
14
Empty the container back and place it back under both the steam/hot
water wand and the dispensing spout.
Yellow
15
Press the “ ” button to start the rinse cycle.
16
When this icon is displayed, the water tank is empty. Repeat steps 12-
15. When the machine shows this icon again, go to step 17.
50
ENGLISH
19
When the amount of water needed for the rinse cycle has been com-
pletely dispensed, this icon on the side is displayed. Press the “
”
button to quit the descaling cycle.
GreenYellow
20
Press the “ ” button to prime the circuit.
21
The machine now carries out the warm-up and automatic rinse cycle to
prepare for product brewing.
22
Remove and empty the container.
23
Empty the drip tray and place it back.
24
The descaling cycle is now complete.
25
Remove the small white lter and replace the INTENZA+ water lter (if
tted) in the water tank. Reinsert the Automatic Milk Frother.
Note:
At the end of the descaling cycle, wash the brew group as described in the
“Weekly cleaning of the brew group” chapter.
The rinse cycles are performed in order to have the circuit cleaned with
a preset amount of water to ensure proper machine performance. If the
water tank is not lled up to MAX level, the machine might require three or
more cycles.
17
When the water tank is empty, remove the water tank, rinse it and ll it
up to the MAX level with fresh water. Place it back into the machine.
18
Empty the container back and place it back under both the steam/hot
water wand and the dispensing spout.
1
3
2
51
ENGLISH
51
PROGRAMMING
It is possible to customise the machine's functions via the programming
menu.
The following settings can be adjusted
Co ee temperature
This function adjusts the co ee brewing temperature.
YellowYellowYellowYellowYellowYellow
Timer (stand-by)
This function adjusts the time taken for the machine to go into stand-by
mode after the last brewing.
Contrast
This function adjusts the contrast of the display to better view the mes-
sages.
Water hardness
This function adjusts the water hardness setting according to the area
where you live.
1 = very soft water
2 = soft water
3 = hard water
4 = very hard water
For more details, please see the “Measuring and Programming Water Hard-
ness” chapter.
"INTENZA+" Water Filter
This function manages the “INTENZA+” water lter.
For more details, see the chapter about lter handling.
Descaling cycle
This function activates the descaling cycle.
52
ENGLISH
YellowGreenYellowYellow
Factory settings
This function allows you to reset all factory values.
How to Program the Machine
In this example, it is shown how to program the display contrast. Proceed
in the same way to program the other functions.
The programming menu can only be accessed when the machine is on and
shows this display.
1
Press the “ ” button to access programming.
2
The main screen will be displayed.
3
Press the “ ” button to scroll the pages until the display contrast func-
tion is displayed.
53
ENGLISH
53
Yellow
4
Press the “ ” and “ ” buttons to increase or decrease the value of the
function.
5
When the display value is changed, the “OK” message appears. Press
the “
” button to con rm the change.
6
Press the “ ” button to exit the programming menu.
Note:
The machine automatically exits programming mode if
no button is pressed for 3 minutes. The values that have been changed but
not con rmed won’t be saved.
54
ENGLISH
MEANING OF THE DISPLAY ICONS
This machine is equipped with a color-coded system to make the user’s
understanding of the display signals easier.
The icons are color-coded according to the tra c light principle.
Ready Signals (Green Color)
The machine is ready to brew products.
The machine is ready to brew pre-ground co ee.
Steam or hot water selection.
Hot water dispensing.
Steam dispensing.
The machine is brewing one cup of espresso.
The machine is brewing two cups of espresso.
The machine is programming the amount of espresso to brew.
Espresso brewing using pre-ground co ee in progress.
55
ENGLISH
55
Ready Signals (Green Color)
The machine is brewing one cup of medium co ee.
The machine is programming the amount of medium co ee to be brewed.
The machine is brewing one cup of long co ee.
The machine is programming the amount of long co ee to be brewed.
56
ENGLISH
Warning Signals (Yellow Color)
The machine is in warm-up phase to brew beverages or dispense hot water/
steam.
The machine is performing the rinse phase. Wait until the machine has com-
pleted the cycle.
The machine needs the "INTENZA+" water lter to be replaced.
The brew group is being reset due to machine reset.
Re ll the co ee bean hopper with co ee beans. Put back the co ee bean
hopper lid and restart the cycle.
Prime the circuit.
The machine needs to be descaled. Press the “ ” button to start the descal-
ing process. Follow the steps described in the “Descaling” chapter of this
manual.
If you want to descale later, press the “
” button to continue using the
machine.
Please note that not descaling your machine will ultimately make it stop
working properly. In this case repair is NOT covered under your warranty.
57
ENGLISH
57
Warning Signals (Red Color)
Completely insert the drip tray with the co ee grounds drawer into the ma-
chine and close the service door.
Fill the co ee bean hopper.
The brew group must be inserted into the machine.
Empty the co ee grounds drawer. Wait about 5 seconds before placing it
back.
Set the “ESPRESSO” or “COFFEE” selection lever to “ESPRESSO” within 30
seconds to complete brewing.
Set the “ESPRESSO” or “COFFEE” selection lever to “COFFEE” within 30 seconds
to complete brewing.
Fill the water tank.
A beverage has been selected without the co ee bean hopper inner lid on
the machine. Place the co ee bean hopper inner lid on the machine within
30 seconds to complete brewing.
Exx
Turn o the machine. After 30 seconds, turn it on again. Try this 2 or 3 times.
If the machine will not start, contact the Philips SAECO hotline in your coun-
try and quote the error code shown on the display. You can nd its contact
details in the warranty booklet packed separately or on www.philips.com/
support.
58
ENGLISH
TROUBLESHOOTING
This chapter summarizes the most common problems you could encoun-
ter with your machine.
If you are unable to solve the problem with the information below, visit
www.philips.com/support for a list of frequently asked questions or
contact the Philips Saeco hotline in your country.
The contact details can be found in the warranty booklet supplied sepa-
rately or on www.philips.com/support.
Machine actions Causes Solutions
The machine does not switch
on.
The machine is not connected to
the electric network, or the power
button is in the “O” position.
Connect the machine to the electric
network and turn the power button
to the “I” position.
The drip tray gets lled al-
though no water is drained.
Sometimes water is drained auto-
matically by the machine into the
drip tray to manage the rinsing of
the circuits and ensure optimum
machine performance.
This is seen as normal machine
behavior.
The red
icon is always
displayed on the machine.
The co ee grounds drawer was
emptied with the machine o .
The co ee grounds drawer must
always be emptied with the machine
on. Wait until the
icon is dis-
played before re tting the drawer.
The espresso is not hot
enough.
The cups are cold. Preheat the cups with hot water.
No hot water or steam is
dispensed.
The hole of the hot water/steam
wand is clogged.
Clean the hole of the steam wand
using a pin.
Make sure that the machine is
o and has cooled down before
performing this operation.
The espresso is not creamy
enough
(See note)
The blend is unsuitable, co ee is
not freshly roasted or the grind is
too coarse.
Change co ee blend or adjust the
degree of grind as explained in
the “Adjusting the Ceramic Co ee
Grinder” chapter.
The machine takes a long
time to warm up or the
amount of water dispensed
is too little.
The machine circuit is clogged by
limescale.
Descale the machine.
The brew group cannot be
removed.
The brew group is out of place. Turn the machine on. Close the ser-
vice door. The brew group automati-
cally returns to the initial position.
The co ee grounds drawer is
inserted.
Remove the co ee grounds drawer
before removing the brew group.
59
ENGLISH
59
Machine actions Causes Solutions
The machine grinds the
co ee beans but no co ee
comes out.
(See note)
There is no water. Fill the water tank and prime the
circuit (see "Using the Machine for
the First Time" chapter).
The brew group is dirty. Clean the brew group (see "Weekly
Cleaning of the Brew Group" chap-
ter).
The circuit is not primed. Prime the circuit (see "Using the
Machine for the First Time" chapter).
This might occur when the ma-
chine is automatically adjusting
the dose.
Brew a few cups of co ee as
described in the “Saeco Adapting
System” chapter.
The dispensing spout is dirty. Clean the dispensing spout.
The beverage is too weak.
(See note)
This might occur when the ma-
chine is automatically adjusting
the dose.
Brew a few cups of co ee as
described in the “Saeco Adapting
System” chapter.
The beverage is brewed
slowly.
(See note)
The co ee grind is too ne. Change co ee blend or adjust the
grind as explained in the “Adjusting
the Ceramic Co ee Grinder” chapter.
The circuit is not primed. Prime the circuit (see "Using the
Machine for the First Time" chapter).
The brew group is dirty. Clean the brew group (see "Weekly
Cleaning of the Brew Group" chap-
ter).
Co ee leaks out of the dis-
pensing spout.
The dispensing spout is clogged. Clean the dispensing spout and its
holes.
Milk does not froth. The Automatic Milk Frother is in-
serted too deep. No milk is being
suctioned.
Leave the Automatic Milk Frother to
cool down. Move it slightly down-
wards. Reposition it in its correct
seat.
Frothed milk is too cold. The cups are cold. Preheat the cups with hot water.
Note:
* These problems can be considered normal if the co ee blend has been
changed or if the machine has just been installed. In this case wait until the
machine performs a self-adjusting operation as described in the "Saeco
Adapting System" chapter.
60
ENGLISH
ENERGY SAVING
Stand-by
The Saeco full automatic espresso machine is designed for energy saving
proven by the Class A energy label.
After 30 minutes of inactivity, the machine turns o automatically (unless
a di erent stand-by time has been programmed). If a product has been
brewed the machine performs a rinse cycle.
In stand-by mode, the energy consumption is below 1Wh.
To turn on the machine, press the
“ ” button (if power button on the
back of the machine is set to “I”). If the boiler is cold the machine performs
a rinse cycle.
Disposal
Do not throw away the machine with the normal household waste at the
end of its life, but hand it in at an o cial collection point for recycling. By
doing this, you help to preserve the environment.
- The packing materials can be recycled.
- Machine: unplug the machine and cut the power cord.
- Deliver the appliance and power cord to a service centre or public
waste disposal facility.
This product complies with EU Directive 2002/96/EC.
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead, it must be handed over to
the appropriate waste collection centre for the recycling of electrical and
electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product,
please contact your local council o ce, your household waste disposal
service or the shop where you purchased the product.
61
ENGLISH
61
TECHNICAL SPECIFICATIONS
The manufacturer reserves the right to make changes to the technical
speci cations of the product
Nominal Voltage - Power
Rating - Power Supply
See label on the inside of the service door
Housing material Thermoplastic material
Size (w x h x d) 215 x 330 x 429 mm / 8.5 x 13 x 16.9 inches
Weight 7.2 kg / 16 pounds
Power cord length 800 - 1200 mm / 32-47 inches
Control panel Front panel
Automatic Milk Frother Special for cappuccino
Cup sizes up to 178mm / 7 inches
Water Tank 1.8 liters - Removable type
Co ee bean hopper
capacity
250 g / 1 cup
Co ee grounds drawer
capacity
15
Pump pressure 15 bar
Boiler Stainless steel type
Safety devices Thermal fuse
WARRANTY AND SERVICE
Warranty
For detailed information on your warranty and related conditions, please
read the warranty booklet supplied separately.
Service
We want to ensure that you remain satis ed with your machine.
If you have not already done so, please register your purchase at
www.philips.com/welcome. This will enable us to stay in contact with you
and send you cleaning and descaling reminders.
If you need service or support, please visit the Philips website at
www.philips.com/support or contact the Philips Saeco hotline in your
country. The contact details can be found in the warranty booklet supplied
separately or on www.philips.com/support.
62
ENGLISH
ORDERING MAINTENANCE PRODUCTS
For cleaning and descaling, use Saeco maintenance products only.
You can
purchase these at the Philips online shop at www.shop.philips.com/service,
your local dealer or at authorised service centres.
If you have any di culties obtaining maintenance products for your ma-
chine, please contact the Philips Saeco hotline in your country.
The contact details can be found in the warranty booklet supplied sepa-
rately or on www.philips.com/support.
Overview of maintenance products:
- INTENZA+ Water lter cartridge CA6702
- Grease HD5061
- Co ee Oil Remover CA6704
- Descaling solution CA6700
63
ENGLISH
63
- Maintenance Kit CA 6706
- Milk Circuit Cleaner: CA6705
www.philips.com/welcome
The manufacturer reserves the right to make changes without prior notice.
Rev.00 del 15-06-13
02
EN
02
