User Manual Bosch HSLP751UC 30" Steam Convection Combination Oven

Bosch HSLP751UC 30" Steam Convection Combination Oven - Use Manual - Use Guide PDF.
Documents: Go to donwload!
User Manual
  • Owner's manual - (English, French)
Other Documents
  • Product spec sheet - (English)

User manual Oven for Bosch HSLP751UC

Table of contents

  • About This Manual
  • How This Manual is Organized
  • Safety Definitions
  • Getting Started
  • Parts
  • Accessories
  • Control
  • Operation
  • About the Appliance
  • Before Using the Oven for the First Time
  • Using Buttons and Entering Numeric Values
  • Setting the Clock
  • Setting the Cooking Mode and Temperature
  • Timers
  • Fast Preheat
  • Cleaning
  • Self Clean
  • Avoid These Cleaners
  • Cleaning Guide
  • Maintenance
  • Replacing an Oven Light
  • Removing the Oven Door
  • Service
  • Data Plate
  • Self Help
  • Troubleshooting Chart
  • Statement of Limited Product Warranty
  • Cooking Charts

To remove the telescopic rack from the oven:

  • Lift the front of the telescopic rack assembly about 1/2 inch and push the rack to the rear about 3/4 inch. This allows the rack to disengage from the rack position guide.
  • Lift the rear of the telescopic rack assembly so it clears the rack position guide and gently pull the rack from the oven.
  • Note: Take care to avoid pulling the rack unevenly which will cause it to bind during removal, catching on the oven walls.

To insert the telescopic rack into the oven:

  • Slide the rack in evenly until the rear of the rack is about 2 inches from the back of the oven.
  • Tilt the front of the rack up about three-quarters of an inch (A) and finish pushing the rack all the way back (B).
  • Note: Avoid striking the oven light cover glass or the back of the oven when pushing the rack into position.
  • The back of the telescopic rack drops into place.
  • Pull the rack forward to engage the bottom of the rack onto the rear of the rack position guide.

Before Using the Oven for the First Time

  • Oven must be properly installed by a qualified technician before use.
  • Remove all packing materials from inside and outside the oven.
  • While cool, wipe with a clean, damp cloth and dry.
  • There may be a slight odor during first uses; this is normal and will disappear.
  • Optimum cooking results depend on proper bakeware being used.
  • Read and understand all safety precautions and Use and Care Manual information prior to operating.

Setting the Cooking Mode and Temperature

  • For double oven models, the particular oven must be selected before the cooking mode can be selected. Press the Upper Oven or Lower Oven button to select an oven.
  • Press the desired Cooking Mode button. For example, press the “Bake” button. The cooking mode and default temperature are displayed. The temperature blinks to show it can be edited.
  • Press Enter to start the mode using the default temperature. For modes that require preheating, the preheat indicator progresses until the target temperature is reached.

To set an oven timer:

  • For double ovens, first select the Upper or Lower oven. The oven must be running a cooking mode in order to set an oven timer. Note: An oven timer can not run during Self Clean.
  • Select a cooking mode. The soft keys at the bottom of the display show Kitchen Timer and Oven Timer. Select Oven Timer.
  •  “00:00” is displayed blinking to the left of the mode name. Use the numeric keypad to replace “00:00” with the desired timer value.
  • Press Enter to save the oven timer setting. The oven timer starts. The oven timer counts down to 0:00.
  • When the timer reaches :00 the cooking mode ends. The oven alarm tone sounds every 10 seconds for 2 minutes.
