MFL67229812
ENGLISH
2
How to exchange the water purifier
(Only applies to internal type filter model)
Height adjust
When the freezer door does not align with the
height of the refrigerator door
Vacuum storage box
Air purification
LED indicator (Freezer/Refigerator)
4
4
5
13
14
15
16
17
17
18
18
19
19
26
27
28
28
29
29
29
29
30
31
32
34
34
35
40
Energy - Saving Method
31
Do not allow the power plug to face upward or to be
squeezed at the back of the refrigerator.
Do not allow the power cord bent or pressed by the
heavy object to be damaged.
1.When connecting the power
The dedicated outlet should be used.
Do not extend or modify the length of the power plug.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the refrigerator.
Do not pull out the cord or touch the power plug with
wet hands.
Remove water or dust from the power plug and insert
it with the ends of the pins securely connected.
Make sure of grounding.
When the power cord or the power plug is damaged
or the holes of the outlet are loosed, donot use them.
It may cause electric shock or short circuit to make fire.
2. When using the refrigerator
Do not place the heavy object or the dangerous
object (container with liquid) on the refrigerator.
Do not install the refrigerator in the wet place or
the place which water or rain splashes.
Do not cling to the door or the shelves of the door or
the home bar of the freezer or the cool chamber.
Do not use or store inflammable materials ether,
benzene, alcohol, medicine, LP gas, spray or
cosmetics near or in therefrigerator.
Do not use drier to dry the inside,nor light a
candle to remove odor.
Do not insert the hands into the ice bucket or
the ice dispenser.
(only for the model with the dispenser).
Do not store the medicine or the academic materials
at the refrigerator.
Do not use the combustible spray near the
refrigerator.
Install in places away from the fire such as the
place where flammable gas is lesked.
Supply the automatic ice maker with drinkable water
only (only for the model with the dispenser).
Do not place flower vase, cup, cosmetics, medicine
or any container with water on the refrigerator.
Use the submerged refrigerator after checking it.
When gas is leaked, do not touch the refrigerator
or the outlet and ventilate the room immediately.
Do not spray water at the outside or the inside
of the refrigerator or do not clean it with benzene
or thinner.
When any strange smell or smoke is detected
from the refrigerator, disconnect the power plug
immediately and contact to the service center.
Do not allow any person except the qualified
engineer to disassemble, repair or alter the
refrigerator.
Do not use the refrigerator for non-domestic
purpose (storing medicine or testing material,
using at the ship, etc.).
When disposing the refrigerator, remove the
packing materials from the dooe or take off the
doors but leave the shelves in palce so that
children may not easily climb inside.
Install the refrigerator on the solid and level floor.
Do not insert the hands or the metal stick into
the exit of cool air, the cover, the bottom of the
refrigerator, the heatproof grill (exhaust hole)
at the backside.
When you want to dispose the refrigerator, contact
to the down-block office.
Violating this direction may cause injury or damage
house or furniture. Always be careful, please.
Do not touch food or containers at the freezer
with wet hands.
Do not put ice in thin crystal cup or ceramic
ware.
When the electricity is off, remove ice from the ice
bucket (only for the model with the dispenser).
Wait for 5 minutes or longer when reconnecting
the plug.
Do not put bottle in the freezer.
Pull out the power plug not by grasping the cord
but the plug of its end.
Do not install the refrigerator in the wet place or the
place which water or rain splashes.
Do not insert the hands into the bottom of the
refrigerator.
Carry the refrigerator with the handle bar at the
bottom of the front and the top of the rear.
Because opening or closing the door of the
refrigerator may cause injury to the person
around it, be careful, please.
Do not put any living animal in the refrigerator.
1. When connecting the power
2. When using the refrigerator
Prevent the power cord from being squeezed or imprinted if the
refrigerator is pushed in after the power plug is extracted during the
installation.
When moving your appliance away from the wall, be careful not to
roll over or damage the power cord.
Be sure to use grounded exclusive proper voltage consent for
the power plug.
If the supply cord is damaged,it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid any hazard.
Prevent children from entering the product.
Opening and closing the door of the refrigerator vigorously
may cause the stored food in the refrigerator basket to fall
by shock and hurt the foot, so take precautions.
Do not put heavy things on the Home Bar.
(Only for the models with the Home Bar)
In case of thunder and lightning, or not in use for a
long period of time, detach the power plug.
Do not insert the hands into the ice bucket or
the ice dispenser.
Do not remove the cover of the automatic ice maker.
(Only for the models with automatic ice maker)
Do not place the food in disorder inside the refrigerator.
Freezer
Compartment
Refrigerator
Compartment
Filter (Optional)
WARNING
: Risk of child entrapment.
Automatic
Icemaker
Shelf
Shelf
Shelf
Shelf
Lamp
Dairy corner
Door rack
Door rack
Door rack
Door rack
Door rack
Door rack
Door rack
Drawer
Drawer
Vegetable drawer
Vegetable drawer
Wine holder
Egg Box
Shelf
Refreshment center
(Optional)
Lamp
Air Purification
Vacuum storage box
Lamp
Drawer Cover
(Optional)
(Optional)
(Optional)
(Optional)
Ice maker basket
6.
This appliance is intended to be used in
household and similar applications such as
staff kitchen areas in shops, offices and other working environments;
farm houses and by clients in hotels, motels and other residential type
environments;bed and breakfast type environments;catering and similar
non-retail applications.
How to exchange the water purifier filter
(Only applies to internal type filter model.)
Because the filter is assembled on the top right side of the refrigerator lamp case and it
removes the residual chlorine or odor, exchange a filter once every 6 months.
How to
disassemble the
filter
2. Insert the new filter.
- Align the filter on the indicated line on the control
box (1) and then push it in.
After checking whether the indicated line and the
indicated locking line are aligned, turn the filter in
clockwise direction (2).
- When you have install the filter for the first time
or when you have exchanged the filter, press the
dispenser button once again to dispense the water for about 3 minutes
(or about 1 liter) to remove any air or residual charcoal.
(Charcoal is not hazardous to the human body.)
1. Disassemble the water purifier filter.
- Turn the filter to exchange in counterclockwise
direction by 90 degrees. (1) Pull out the filter to
the front side (2).
- Because water collected in the filter may drip,
put a bowl slightly larger than the size of the filter
underneath the filter when disassembling the
filter.
How to exchange
Removing the hinge cover ,
Removing the hinge cover,and Main PCB
cover by loosening the screws.Separate
all connection wires except for the earth
line after.
Removing the hinge cover,and Main PCB
cover by loosening the screws.Separate
all connection wires except for the earth
line after.
Main PCB cover
Main PCB cover
Upper hinge cover
Upper hinge cover
b
b
CAUTION
The new hose-sets supplied with the appliance are to be used and that old
hose-sets should not be reused.
HYGIENE FRESH
4
5
6
7
1
4
FREEZER
FRIDGE
FREEZER
FREEZER
FRIDGE
FRIDGE
EXPRESS FRZ.
CHILD LOCK 3SECS
When Quick-frezze is "ON", press the
button again to turn it off, or after a period
of time the Quick-freeze function will turn
off automatically after completion.
Air Purification
(Optional)
When you need to clean the air please select
this function.
When Air Purification is selected, rotates
3 times and shows as "ON".
Re-select this button, rotates 3 times
and shows as .
Re-select this button and it shows as "OFF".
After turning "OFF" the Air-cleaner, open the
door and the lamp surrounding the cleaner is off.
After normal usage for a year, the " " displays indicating the cleaner
need to be replaced. Customers can repl
ace it based on personal needs.
After replacing the cleaner or when replacement is not needed,
press and hold the button for more than 5 secs, the timer of
the indicator starts again and the reminder is off.
CAUTION
Water cannot be used for cleaning the filter as it may affect the efficiency.
If the opearation time exceed the validity time, it may affect the sterilization
and deodorization fucntio
ns.
If you need to replace the Air-cleaner, please contact local service center.
HYGIENE FRESH
REPLACE
HOLD 5SECS
POWER
HYGIENE FRESH
auto power
power
24
shall
Bottom of freezer
compartment
Drawer Cover
Drawer
25
26
27
LED Lamp
(a) (b) (c)
LED indicator (Freezer/Refrigerator)
When the indicator is operating in refrigerator
When the freezer/refrigerator door is opened, The
built-in LED indicator will light up.
This LED indicator will light up when the
freezer/refrigerator or Home bar door is opened.
This LED indicator can be used semi-permanently.
Air Purification
How to use
the Air Purification
The Air Purification is already installed on the refrigerator wall,
so installation is not needed.
Please use containers with tight lids to place spicy food.
Otherwise the odor will be absorbed by other food.
Disassembling
and installing
the Air Purification
Hold the case of the Air Purification, rotate it counterclockwise about 15
degrees as shown in (a).
Take out the Air Purification from the case.
Replace the new Air Purification into the case as shown in picture (b)
(Note the direction of installation).
Place the unit as shown in picture (c), insert and rotate it clockwise until you
hear a clicking sound and the installation is finished.
The word
"BACK"
should face
outward.
Index line
Please do not mix-up the installation direction. Insert the Air Purification with
yellow-green net facing inward to the case, as shown in picture (b).
If the display shows " ", please contact local service center.
The Air Purification is not capable of filtering all bacteria.
It is only capable of suspended bacteria in the air.
Do not place your fingers or foreign objects into the fan of the filter to
avoid injury or lanuch accidentally.
Air Purification
28
Vacuum storage box
The refrigerator drawer is for storing
vegetables or meats.
Press the VACUUM switch for several times
and the food can keep fresh for longer time.
VACUUM switch
29
30
Energy-Saving Method
Install the fridge in a shady,cool and well-ventilated place.
Do not open and close the door frequently if not necessary.
Please do not keep the door open for a long time, close door in the shortest time.
Allow hot food to cool prior to storing.
Too much food are not advised to be put in. Enough space should be kept for
cool air circulating freely.
Do not set the temperature of refrigerator lower than needed.
Do not put the food near the temperature sensor.
Food need’t store is not advised to be put in.
Place the deep-frozen food for thawing intorefrigerator; they can be used for
cooling the refrigerator.（Applicabe to some models only
）
Clean up the back cover and anti-condensation pipe termly (once a year) to
make sure heat exchange in gear.
（Applicabe to some models only）
Do not block air vents with food.
（ Applicabe to some models only）
32
a
b
Lift the shelf and remove it.
Hold and press the bottom part (a,b) of the
Refreshment center cover inward, then
pull to remove.
Lift the shelf and remove it.
33
34
35
36
37
38
39
40
LG Customer Information Center
Register your product Online!
www.lg.com
☎ LG SERVICE : (UNITED KINGDOM) 0844-847-5454
