User Manual Omron HEM-6161 Health

Documents for Omron HEM-6161

The following documents are available:
User Manual Photos
HEM-6161 photo
Introduction
Important Safety Information
1. Know Your Monitor
2. Preparation
3. Using Your Monitor
4. Using Memory Function
5. Other Settings
6. Error Messages and Troubleshooting
7. Maintenance
8. Specifications
9. Guidance and Manufacturer’s Declaration
Thank you for purchasing the OMRON HEM-6161 Wrist Blood
Pressure Monitor. This blood pressure monitor is to be worn on your
wrist.
This new blood pressure monitor uses the oscillometric method of
blood pressure measurement. When the cuff inflates, this monitor
senses the pressure pulsations of the artery underneath the cuff.
The pulses are called oscillometric pulses. The electronic pressure
sensor displays a digital reading of blood pressure.
Safety Instructions
This instruction manual provides you with important information
about the OMRON HEM-6161 Wrist Blood Pressure Monitor. To
ensure the safe and proper use of this monitor, READ and
UNDERSTAND all of the safety and operating instructions. If you do
not understand these instructions or have any questions, contact
your local OMRON representative before attempting to use this
monitor. For specific information about your own blood pressure,
consult with your physician.
Intended Use
This device is a digital monitor intended for use in measuring blood
pressure and pulse rate in adult patient population with wrist
circumference ranging from 13.5 cm to 21.5 cm. This monitor
detects the appearance of irregular heartbeats during measurement
and gives a warning signal with readings. It is mainly designed for
general household use.
Receiving and Inspection
Remove this monitor from the packaging and inspect for damage. If
this monitor is damaged, DO NOT USE and consult with your local
OMRON representative.
Please read the Important Safety Information in this instruction
manual before using this monitor.
Please follow this instruction manual thoroughly for your safety.
Please keep for future reference. For specific information about your
own blood pressure, CONSULT WITH YOUR PHYSICIAN.
Warning
Indicates a potentially hazardous situation
which, if not avoided, could result in death or
serious injury.
DO NOT use this monitor on infants, toddlers, children or
persons who cannot express themselves.
DO NOT adjust medication based on readings from this blood
pressure monitor. Take medication as prescribed by your
physician. ONLY a physician is qualified to diagnose and treat
high blood pressure.
DO NOT use this monitor on an injured wrist or a wrist under
medical treatment.
DO NOT apply the wrist cuff on your wrist while on an
intravenous drip or blood transfusion.
DO NOT use this monitor in areas containing high frequency
(HF) surgical equipment, magnetic resonance imaging (MRI)
equipment, computerized tomography (CT) scanners. This
may result in incorrect operation of the monitor and/or cause
an inaccurate reading.
DO NOT use this monitor in oxygen rich environments or near
flammable gas.
Consult with your physician before using this monitor if you
have common arrhythmias such as atrial or ventricular
premature beats or atrial fibrillation; arterial sclerosis; poor
perfusion; diabetes; pregnancy; pre-eclampsia or renal
disease. NOTE that any of these conditions in addition to
patient motion, trembling, or shivering may affect the
measurement reading.
NEVER diagnose or treat yourself based on your readings.
ALWAYS consult with your physician.
This product contains small parts that may cause a choking
hazard if swallowed by infants, toddlers or children.
Battery Handling and Usage
Keep batteries out of the reach of infants, toddlers or
children.
Caution
Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury to the user or patient, or cause
damage to the equipment or other property.
Stop using this monitor and consult with your physician if
you experience skin irritation or discomfort.
Consult with your physician before using this monitor on a
wrist where intravascular access or therapy, or an arterio-
venous (A-V) shunt, is present because of temporary
interference to blood flow which could result in injury.
Consult with your physician before using this monitor if you
have had a mastectomy.
Consult with your physician before using this monitor if you
have severe blood flow problems or blood disorders as cuff
inflation can cause bruising.
Wrist Blood Pressure
Monitor
HEM-6161
Instruction Manual
2829548-5B
Table of Contents
Introduction
Important Safety Information
DO NOT take measurements more often than necessary
because bruising, due to blood flow interference, may occur.
ONLY inflate the wrist cuff when it is applied on your wrist.
Remove the wrist cuff if it does not start deflating during a
measurement.
DO NOT use this monitor for any purpose other than
measuring blood pressure.
During measurement, make sure that no mobile device or any
other electrical device that emits electromagnetic fields is
within 30 cm of this monitor. This may result in incorrect
operation of the monitor and/or cause an inaccurate reading.
DO NOT disassemble or attempt to repair this monitor or
other components. This may cause an inaccurate reading.
DO NOT use in a location where there is moisture or a risk of
water splashing this monitor. This may damage this monitor.
DO NOT use this monitor in a moving vehicle such as in a car.
DO NOT drop or subject this monitor to strong shocks or
vibrations.
DO NOT use this monitor in places with high or low humidity
or high or low temperatures. Refer to chapter 8.
Ensure this monitor is not impairing blood circulation by
observing the wrist while measurement is occurring.
DO NOT use this monitor in high-use environments such as
medical clinics or physician offices.
DO NOT use this monitor with other medical electrical (ME)
equipment simultaneously. This may result in incorrect
operation of the monitor and/or cause an inaccurate reading.
Avoid bathing, drinking alcohol or caffeine, smoking,
exercising and eating for at least 30 minutes before taking a
measurement.
Rest for at least 5 minutes before taking a measurement.
Remove tight-fitting, thick clothing and any accessories from
your wrist while taking a measurement.
Remain still and DO NOT talk while taking a measurement.
ONLY use this monitor on persons whose wrist
circumference is within the specified range of the cuff.
Ensure that this monitor has acclimated to room temperature
before taking a measurement. Taking a measurement after an
extreme temperature change could lead to an inaccurate
reading. OMRON recommends waiting for approximately 2
hours for the monitor to warm up or cool down when the
monitor is used in an environment within the temperature
specified as operating conditions after it is stored either at
the maximum or at the minimum storage temperature. For
additional information of operating and storage/transport
temperature, refer to chapter 8.
DO NOT crease the wrist cuff excessively.
Read and follow the “Correct Disposal of This Product” in
chapter 9 when disposing of the device and any used
accessories or optional parts.
DO NOT use this monitor after the durable period has ended.
Refer to chapter 8.
Battery Handling and Usage
DO NOT insert batteries with their polarities incorrectly
aligned.
ONLY use 2 “AAA” alkaline batteries with this monitor. DO
NOT use other types of batteries. DO NOT use new and used
batteries together. DO NOT use different brands of batteries
together.
Remove batteries if this monitor will not be used for a long
period of time.
If battery fluid should get in your eyes, immediately rinse with
plenty of clean water. Consult with your physician
immediately.
If battery fluid should get on your skin, wash your skin
immediately with plenty of clean, lukewarm water. If irritation,
injury or pain persists, consult with your physician.
DO NOT use batteries after their expiration date.
Periodically check batteries to ensure they are in good
working condition.
ONLY use batteries specified for this monitor. Use of
unsupported batteries may damage and/or may be hazardous
to this monitor.
1.1 Contents
Monitor, 2 “AAA” alkaline batteries, storage case, instruction manual
1.2 Monitor
a. Wrist cuff
(Wrist circumference 13.5 cm to 21.5 cm)
b. Display
c. Battery compartment
d. [Memory] button
e. [START/STOP] button
1.3 Display and Symbols
1. Know Your Monitor
a
c
b
d
e
B
A
D
C
G
E
F
H
I
2013 ESH/ESC* Guidelines for the management of
arterial hypertension
Definitions of hypertension by office and home blood pressure levels
These ranges are from statistical values for blood pressure.
Warning
NEVER diagnose or treat yourself based on your readings.
ALWAYS consult with your physician.
2.1 Installing Batteries
1. Push down the hook of the battery
cover and pull downward.
2. Insert 2 “AAA” alkaline batteries as
indicated in the battery compartment.
3. Close the battery cover.
Note
When the “ ” symbol flashes on the display, it is recommended
you replace batteries.
To replace batteries, turn your monitor off and remove all batteries.
Then replace with 2 new alkaline batteries at the same time.
Replacing batteries will not delete previous readings.
The supplied batteries may have a shorter life than new batteries.
Disposal of used batteries should be carried out in accordance
with local regulations.
A
Systolic blood pressure reading
B
Diastolic blood pressure reading
C
Heartbeat symbol
Flashes while taking a measurement.
Appears if your systolic blood pressure is 135
mmHg or above and/or the diastolic blood pressure
is 85 mmHg or above.
D
Cuff wrap guide symbol (OK)
Appears if the wrist cuff is wrapped around the wrist
correctly while taking a measurement. It also
appears when viewing past readings.
Cuff wrap guide symbol (loose)
Appears if the wrist cuff is not wrapped around the
wrist correctly while taking a measurement. It also
appears when viewing past readings.
E
Memory symbol
Appears when viewing readings stored in the
memory.
F
Irregular heartbeat symbol
Appears along
with readings
when an irregular
rhythm is detected
2 or more times
during a
measurement.
An irregular
heartbeat rhythm
is defined as a
rhythm that is 25% less or 25% more than the
average rhythm detected while your monitor is
measuring blood pressure. If it continues to appear,
we recommend you to consult with and follow the
directions of your physician.
G
flashes
Battery symbol (low)
Flashes when batteries are low.
appears
Battery symbol (depleted)
Appears when batteries are depleted.
H
Deflation symbol
Appears during cuff deflation.
I
Pulse display / Memory number
Pulse rate appears after the measurement.
When pressing the button, the memory number appears
for approximately one second before the pulse rate appears on
the display.
Office Home
Systolic Blood
Pressure
140 mmHg 135 mmHg
Diastolic Blood
Pressure
90 mmHg 85 mmHg
Irregular Heartbeat
Normal Heartbeat
Pulse
Blood pressure
Blood pressure
Short
Long
Pulse
* European Society of Hypertension (ESH) and European Society
of Cardiology (ESC).
2. Preparation
1
2
2.2 Blood Pressure Measurement Tips
To help ensure an accurate reading, follow these directions:
Stress raises blood pressure. Avoid taking measurements during
stressful times.
Measurements should be taken in a quiet place.
It is important to take measurements at same times each day.
Taking measurements in the morning and in the evening is
recommended.
Remember to have a record of your blood pressure and pulse
readings for your physician. A single measurement does not
provide an accurate indication of your true blood pressure. You
need to take and record several readings over a period of time.
Caution
Avoid bathing, drinking alcohol or caffeine, smoking, exercising
and eating for at least 30 minutes before taking a measurement.
Rest for at least 5 minutes before taking a measurement.
2.3 Applying the Wrist Cuff
Note
Following steps are for applying the wrist cuff to your left wrist.
When you take a measurement on your right wrist, apply the wrist
cuff using the same steps as on your left wrist.
The blood pressure can differ between the right wrist and the left
wrist, and the measured blood pressure values can be different.
OMRON recommends to always use the same wrist for
measurement. If the values between both wrists differ
substantially, please check with your physician as to which wrist to
use for your measurements.
Caution
Remove tight-fitting, thick clothing and any accessories from your
wrist while taking a measurement.
1. Apply the wrist cuff to your left
wrist.
Roll up sleeve. Make sure your
sleeve is not rolled up too tightly on
your arm. This may constrict the flow
of blood in your arm.
2. Put your wrist through the cuff loop.
Your palm and monitor display should both
face upward.
3. Position the wrist cuff leaving a
clearance of 1 to 2 cm between
the cuff and the bottom of your
palm.
4. Wrap the wrist cuff firmly around
your wrist. Do not apply over
clothing.
Check to make sure that there is no gap
between your wrist and the cuff.
Note
Make sure the wrist cuff does not
cover the protruding part of the wrist
bone on the outside of your wrist.
2.4 Sitting Correctly
To take a measurement, you
need to be relaxed and
comfortably seated in a room with
a comfortable temperature. Place
your elbow on the table to support
your arm.
Sit in a chair with your legs
uncrossed and your feet flat on
the floor.
Sit with your back and arm
being supported.
Your monitor must be
approximately the same level
as your heart. If the monitor is
too high above your heart, your blood pressure will be artificially
low. If the monitor is too low below your heart, your blood pressure
will be artificially high.
Relax your wrist and hand. Do not bend your wrist back, clench
your fist, or bend your wrist forward.
Wrist cuff
1 to 2 cm
Loading ...
