Model No.

NA-140VG4

NA-148VG4

Operating Instructions

& Installation Instructions

Washing Machine

(Domestic use)

Thank you for purchasing this appliance.

- For optimum performance and safety, please read these instructions

carefully.

- Before connecting, operating or adjusting this appliance, please read the

instructions completely. Please keep this manual for future reference.

 ReadBeforeUsing 4

 SAFETYPRECAUTIONS 4

 WashingInstructions 12

 OptionalFunctions 20

 Maintenance 22

 Troubleshooting 25

 InstallationInstructions 30

NA-140_148VG4_EN_20140213.indb 1 2014/02/13 13:13:30

NA-140_148VG4_EN_20140213.indb 2 2014/02/13 13:13:30

Contents

Read Before Using

SAFETYPRECAUTIONS        4

CheckingYourWashingMachine

   6

Yourwashingmachine             6

Accessories                     6

BeforeWashing                 7

Checkingbeforeuse               7

Beforeinitialuse7

Preparingthelaundry             7

UsingtheButtons               8

Unlockingthedoor                9

AddingDetergentandOther

Chemicals                   10

Detergentcompartment           10

Softenercompartment            11

Prewashingcompartment          11

Washing Instructions

Washing                     12

Settingwashing                 12

Requiredtime                  13

Changingsettingswhilewashing   13

SelectingtheProgramme       14

DetailsofProgrammes         16

TipsforWashing              18

Wool,Silk/Lingerie,andDelicates

programmes                   18

Beddingprogramme19

Outdoorprogramme             19

OptionalFunctions             20

Individualwashingfunctions        20

Additionalfunctions              20

Presettimer                    21

Childsafetylock                21

Settingthebuzzer                21

Maintenance

Maintenance                 22

Cleaningtheoutsideofthe

appliance                      22

Cleaningthedrum               22

Cleaningthedetergentdrawer     22

Cleaningthedoorsealandwindow

  23

Cleaningthedrainfilter            23

Cleaningthewatersupplyfilter     24

Preventingafrozenwatersupply

hose                          24

Troubleshooting

FaultChecklist                25

ErrorDisplay                 29

Installation Instructions

ChoosingtheRightLocation      30

Carryingtheappliance            30

Therightplacefortheappliance    30

Installingtheset-inappliance      31

MovingandInstalling           32

Removingtheanchorbolts         32

Movingtheappliance             32

Levellingtheappliance33

ConnectingHosesandPower

Supply34

Hosesandcablelengths          34

Watersupplyhose               34

Waterdrainhose                35

Connectingtothepowersupply    35

CheckingafterInstallation        36

Installationchecklist              36

Testrunafterinstallation           37

ConsidertheEnvironment       38

PowerandWaterConsumption   39

Specifications                 40

NA-140_148VG4_EN_20140213.indb 3 2014/02/13 13:13:30

4 - Read Before Using

SAFETY PRECAUTIONS

Readandfollowthesesafetyprecautions

3 WARNING

This describes issues which could

cause death or serious injury.

General Use

- Thisapplianceisnotintendedforuse

bypersons(includingchildren)with

reducedphysical,sensoryormental

capabilities,orlackofexperienceand

knowledge,unlesstheyhavebeengiven

supervisionorinstructionconcerninguse

oftheappliancebyapersonresponsible

fortheirsafety

- Childrenshouldbesupervisedtoensure

thattheydonotplaywiththeappliance

- DoNOTplaceastandorachaircloseto

theappliance

Childrenmayreachthecontrolpanelor

climbontoorintotheappliance

- Turnoffthewatersupplytothe

applianceifitwillnotbeusedfora

prolongedperiod,suchasduringa

holidayThisisparticularlyimportant

ifthereisnodrainagearoundthe

appliance

Ifthewatersupplyislefton,thewater

pressuremayincreaseandresultina

leak

- DoNOTinstalltheapplianceinadamp

locationorinalocationexposedtothe

weather

Thismayresultinproductmalfunctionor

deterioration,electricshockorfire

- DoNOTspillwaterdirectlyontoanypart

oftheappliance

Thismayresultinmalfunction,electric

shockorfire

- Keepsourcesofignition,suchas

candlesorcigarettes,awayfromthe

appliance

Theymaycauseafireordamagetothe

appliance

- Keepflammablematerialsawayfrom

theappliance,forexample,gasoline,

thinner,alcohol,orclothingsoakedwith

thesematerials

Theymaycauseanexplosionorafire

Power source and cable

- Unplugthemainsleadwhencleaning

theappliance

- Checkthemainsleadandmainsplug

fordamage

Ifthemainsleadisdamaged,itmustbe

replacedbythemanufacturer,itsservice

agentorsimilarlyqualifiedpersonsto

avoidahazard

- DoNOTuseamainsplugadaptoror

extensioncableThereisapossibilityof

overheatingwhichmaycauseafireUse

anunusedhouseholdmainssocket,fully

ratedatAC220Vto240VIfyouare

notsure,contactaqualifiedelectrician

- ENSUREthemainsplugisfullyinserted

intothehouseholdmainssocket

Otherwise,alooseconnectionmay

overheatandcauseanelectricshockor

fire

- DoNOTtouchthemainsleadormains

plugwithwethands

Doingsomaycauseanelectricshock

- DoNOTpullthemainsleadbutholdthe

mainsplugtounplugtheappliance

Otherwise,themainsleadmaybe

damaged,whichmayleadtoanelectric

shockorfire

NA-140_148VG4_EN_20140213.indb 4 2014/02/13 13:13:30

Read Before Using - 5

SAFETY PRECAUTIONS

To Prevent Injury

- Theapplianceshouldbeinstalledbythe

manufacturer’sdealerorserviceagent

Iftheinstallation,testrunandinspection

arenotcarriedoutfollowingthe

installationmethodoutlinedinthese

instructions,themanufacturerwillnot

beliableforanyaccidentordamage

caused

- DoNOTdismantle,repairormodifythe

appliance

Theappliancemaymalfunction,which

mayresultinafireoraninjuryIfrepairs

areneeded,contactyourlocalCustomer

ServiceCentre

- DoNOTtouchthelaundryinsidethe

drumuntilithascompletelystopped,

asthereisapossibilityofinjuryKeep

childrenawayfromtherotatingdrum

3 CAUTION

This describes issues which could cause

injury or damage your belongings.

General Use

- Priortouse,turnonthetapandcheck

thehoseandconnectionsforanyleaks

Improperconnectioncouldcauseleaks

- Usethenewhose-setssuppliedwiththe

applianceandoldhose-setsshouldnot

bereused

- Thisapplianceisonlysuitablefortextiles

labelledwashingmachinewashable

- DoNOTconnecttothehotwatersupply

ThisapplianceworksONLYwithcold

water

- DoNOTapplypesticide,hairsprayor

deodoranttotheappliance

- DoNOTputanyelectricalequipment,for

example,TV,radioorbatterycharger,on

orneartheappliance

- DoNOTputexcessivelaundryor

detergentintotheappliance

Thismaycausedamagetotheappliance

- REMOVEtheanchorboltsusingthe

suppliedspannerorasimilartoolbefore

installingtheapplianceTheanchorbolts

areusedtotransporttheappliance

Iftheanchorboltsarenotremoved,the

appliancewillvibrateseverelyduringuse

To Prevent Injury

- DoNOTclimbontotheappliance

Thismaycauseinjuryordamagetothe

appliance

- Keepfingersawayfromthedoorhinge

whenopeningandclosingthedoor

- DoNOTslideyourhand(orunprotected

foot)underneaththeappliancewhenin

use

- Checkallofthelaundryandremoveall

objectssuchasnails,pins,coins,clips,

metalwires,etc

Theymaycausedamagetothelaundry

ortheappliance

- DoNOTusetheappliancetowash

waterproofsheetsorclothingThere

isapossibilityofexcessivevibration

orfailureduringthespincycle,which

mayresultinaninjury,damagetothe

applianceorawaterleak

- BECAREFULwhendraininghotwater

outofthedrum

- BECAREFULnottogetlaundrycaught

inthedoorsealwhenitisclosedThis

mayresultinawaterleakordamageto

thelaundryduringthewashcycle

NA-140_148VG4_EN_20140213.indb 5 2014/02/13 13:13:31

6 - Read Before Using

Checking Your Washing Machine

Your washing machine

Door

Water drain hose

Adjustable stands

(seepage33)

Drain filter cover

(seepage23)

Mains lead/

Mains plug

Door seal

Drum

(Washing/

Spin-drying tub)

Detergent drawer

(seepage10)

CAUTION

Do NOT bend the mains lead when the appliance is running.

Accessories

Makesurethatalltheaccessoriesare

suppliedwiththeappliance

Elbow (seepage35)

Forfixingthewaterdrainhose

Spanner (seepages32-33)

EndAisforadjustingthestandEndBis

fortheanchorbolts

Cover cap (4) (seepages32-33)

Water supply hose (seepage34)

Eitheroneofthesehosesissuppliedwith

theappliance

StandardHose

Hosewithwater

supplyvalve

NA-140_148VG4_EN_20140213.indb 6 2014/02/13 13:13:32

Read Before Using - 7

Before Washing

Checking before use

Fortheappliance’sinitialoperationor

afteraprolongedperiodofnon-operation,

performthefollowingprocedures:

1. Secure the water supply hose.

2. Turn on the tap.

3. Connect the power supply.

4. Make sure that the water drain hose

is positioned towards a drain.

Formoredetails,seepage35

Before initial use

Thedefaultsettingisthe40°CCotton

programmeBeforeusingtheappliance

forthefirsttime,runtheprogramme

WITHOUTanydetergentorclothingto

rinseoutresidueormoisture

NOTE

Theremayberesidualwaterinthe

applianceduetothefactoryinspection

priortoshipmentThisisnota

malfunction

Preparing the laundry

Sorting the laundry

- Readclothingcarelabelstosortthe

laundryintodifferentloads

- Sortthelaundrybycolour,typeoffabric

andhowsoileditisDoingsowillhelp

youchoosethecorrectprogrammeand

temperatureforeachwash

- Clothesthatarenotcolourfastshould

bewashedseparatelyWashdenim

separately

- Youshouldputbraswithmetalwires,

tights,laceclothingandsmallitemsinto

alaundrynettopreventthemorthe

appliancefrombeingdamaged

Treating stains

Applystainremovertostainedportions

Fordirtandsolidstains,washlightlyby

handfirst

Checking clothing

- Checkthatthepocketsonclothing

donotcontainanyobjectsthatmay

damagetheclothesortheappliance

- Tieupanyloosestringsontheclothing

andclosezippersTurnclothingwith

raisedfabricsandzippersinsideout

Otherwise,theclothesmaybedamaged

- Removeanyhair,animalfur,sandand

othermaterialswithabrushbefore

washing

NOTE

Donotwashclothesheavilystained

withlargequantitiesofvegetableoilor

cosmeticoil(aromaoil,etc)Failure

toobservethismayresultinthedoor

sealswelling,causingthewaterto

overflowandleadingtomalfunctions

NA-140_148VG4_EN_20140213.indb 7 2014/02/13 13:13:32

8 - Read Before Using

Using the Buttons

1. Power buttons

- IfyoudonotpresstheStartbutton

within10minutesaftertheappliance

hasbeenswitchedon,theappliance

automaticallyswitchesitselfoff

- Thedisplaybelowappearsfor

3secondsaftertheappliancehas

beenswitchedoffYoucannotturn

theapplianceonuntilthisdisplay

disappears

2. Start/Pause button

Pressthisbuttontostartorpausethe

washprogramme

3. Programme selection dial

Usethisdialtochoosethebest

programmeforthelaundry

(Seepages14-15)

4. Additional function buttons

Pressthesebuttonstoaddfunctions

totheprogrammetosuitthelaundry

(Seepage20)

5. Mode/Child Lock button

- Pressthisbuttontoselectthefunctionof

processes,forexample,theRinseand

SpinfunctionortheDrainonlyfunction

(Seepage20)

- Pressandholdthisbuttontosetthe

childsafetylockThedoorandthe

controlswillbelocked(Seepage21)

6. Time button

Pressthisbuttontopresetthetime

forwhentheprogrammefinishes

(Seepage21)

7. Spin speed button

Pressthisbuttontoseethespinspeed

(r/min)ortochoosethespinspeed

fortheprogrammeyouhaveselected

(Seepage17)

8. Temperature button

Pressthisbuttontochoosewater

temperaturesrangingfromcoldto90°C

Youcanchoosehottertemperaturesfor

whites,cottons,orsoiledlaundry

ModelNA-148VG4

Speed

Eco

123

NA-140_148VG4_EN_20140213.indb 8 2014/02/13 13:13:33

Read Before Using - 9

Using the Buttons

Speed

Eco

91011

9. Process indicator

- Thisindicatorshowsthecurrentprocess

oftheprogrammeTheprocessconsists

ofwashN,rinseK,spinM,and

drainO

- Thelightturnsoffwhentheprogramme

isfinished

10. Remaining time indicator

- Thisindicatorshowstheapproximate

timeuntiltheprogrammefinishesFor

example,‘2:05’means2hoursand

5minutes

- Thetimeiscalculatedfromtheweight

ofthelaundrymeasuredwhenwashing

starts

11. ECONAVI lamp

(Seepage12)

Unlocking the door

Thedoorautomaticallylockswhileinuse

andtheHsymbolisshowninlockedstate

Aclickwillbeheardwhenthedoorlocksor

unlocks

NOTE

- Iftheapplianceisswitchedoffwith

thedoorlocked,orifthereisapower

interruption,thedoorremainslocked

untiltheapplianceisturnedonagain

- Thisisdifferentfromthechildsafety

lock(Seepage21)

Press the Start button to unlock the

door during operation.

Afterapproximately1minute,the

drumstopsspinningandthedoorwill

automaticallyunlock

Ifthedoordoesnotopen,seepage25

CAUTION

If you have to unlock the door mid-

programme, make sure that water

from the drum does not overflow

onto the floor.

Waterandsoapsudsmaycomeout

ofthedoorandthedooropeningYou

mayneedatoweltosoakthemup

Speed

Eco

123

NA-140_148VG4_EN_20140213.indb 9 2014/02/13 13:13:34

10 - Read Before Using

Adding Detergent and Other Chemicals

Detergent compartment

Thefollowingdetergentsandadditivesmay

beaddedtothiscompartment:

- Detergent

- Watersofteningagent

- Stainremover

- Tubcleaningdetergentorbleach

Ifyouusemultiplechemicalsinthis

compartmentforwashing,addtheminthe

followingorder:

1Detergent

2Watersofteningagent

3Stainremover

Detergent

Useonlydetergentsthatarerecommended

forfully-automatedwashingmachines

Pleaseuselowsudsdetergents

CAUTION

If the instructions on the package

indicate that detergent should be

placed in the drum, do NOT put it

into the detergent drawer.

Thesedetergentsmaynotflowwell

andremaininthedetergentdrawer

DonotoverfillwithdetergentFailure

toobservethismayresultinthe

detergentblockingthewatersupply,

causingthewatertooverflowfrom

thefrontofthedetergentdrawerand

leadingtomalfunctions

1. Liquid detergent

NOTE

DoNOTuseliquiddetergentwiththe

PrewashfunctionItmayflowaway

duringtheprewash

FortheWoolprogramme,usemildliquid

detergent

Pull out the detergent drawer and add detergent or softener to the correct

compartment. Check the packages for the recommended amounts.

CAUTION

Do NOT use the appliance when the detergent drawer is removed.

Thismayresultinawaterleak

Prewashing compartment

Softener compartment

Detergent compartment

NA-140_148VG4_EN_20140213.indb 10 2014/02/13 13:13:34

Read Before Using - 11

Adding Detergent and Other Chemicals

2. Powdered detergent

Detergentreachesthedrumonlywhen

waterflushesthroughthedetergent

drawerThus,ifyouhaveforgottentoadd

detergent,runtheDrainonlyfunctionusing

theModebutton

Then,adddetergentandstartwashing

again

Topreventpowdereddetergentfrom

remaininginthedrawer,performthe

following:

- Drytheinsideofthedrawerwithacloth

- Makesurethatthedetergentisnot

lumpywhenyouadditbecausethismay

causeablockageovertime

- Ifthedetergentremainsinthedetergent

compartment,putitintothedrum

Amount of Detergent

Theamountofdetergentyoushoulduse

dependsonthefollowingfactors:

- Howsoiledthelaundryis

- Amountofthelaundry

- Waterhardness

Theamountoffoamvariesaccordingto

theamountandtypeofdetergent,how

soiledthelaundryis,andthehardnessand

temperatureofthewater

Water softening agent

Ifyouliveinahardwaterarea(total

hardnessof13mmol/Lorhigher),we

recommendusingawatersofteningagent

Formoredetailsonwaterhardness,

contactyourlocalwaterauthority

Useofawatersofteningagentcanhelp

reducetheamountofdetergentrequired

foreachwashandhelppreventthe

formationoflimescaledeposits,whichmay

damagetheappliance

Softener compartment

Fabric Softener

Topreventstatic,addsoftenerbeforeyou

startwashingItwillbeautomaticallyadded

inthefinalrinsecycle

Ifthesofterremainsinthesoftener

compartment,dilutethesoftenerbefore

addingitAdduptoonly130mltothe

compartmenttoavoidoverflowing

Undiluted

softener

Water

Rinseouttheremainingsoftenerwith

asplashofwateroradampclothafter

washingIfitstickstothecompartment,

pulloutthedrawerandcleanitout

(Seepage22)

Prewashing compartment

Detergent for prewashing

Wheneveryouuseprogrammeswiththe

Prewashfunction,alwaysputdetergentfor

theprewashinthiscompartment

NA-140_148VG4_EN_20140213.indb 11 2014/02/13 13:13:34

12 - Washing Instructions

Washing

Setting washing

1. Open the door and put the laundry

into the drum.

Fordetailsaboutpreparingandsorting

thelaundry,seepages7,14,and15

NOTE

- Make sure to place the laundry

within the drum so that it does not

get caught in the door.

Failuretoobservethismayresultin

damagetothedoorseal,leadingto

malfunctions

- Do NOT overload the drum.

Thismaycauseexcessivevibration

ordamagetotheappliance

Speed

Eco

2634

ModelNA-148VG4

2. Close the door and press the On

button.

3. Turn the programme selection dial

in either direction to select the

programme.

Theprogrammetimewillbedisplayed

ECONAVI programme

Thisprogrammedetectsthelaundry

amountandtypes(cotton,chemicalfibre,

etc)anddeterminesthebestsuitedwash

timeandwateramounttosaveenergyand

water

Thewashtimeandwateramountcan

besavedmorewithsmalleramountof

laundry,largeramountofclothesthat

easilydry,suchaschemicalfibre,orwith

highertemperature

- Lampindications

Blinking:Detecting

Lighting:InECONAVIoperation

OFF:NotinECONAVIoperation

4. Select optional functions.

- Processselection(seepage20)

- Additionalfunctions(seepage20)

- Temperature(seepage8)

- Spinspeed(seepage8)

Formoredetailsaboutavailable

functionsandsettingsforeach

programme,seepages16-17

NA-140_148VG4_EN_20140213.indb 12 2014/02/13 13:13:35

Washing Instructions - 13

Washing

5. Add detergent to the detergent

drawer.

(Seepages10-11)

6. Press the Start button.

Theappliancestartssupplyingwater

Aftertheappliancehasstarted,the

laundryisweighedAfterapproximately

5seconds,anewprogrammetime

willbedisplayedIfyouselectthe

Wool,Silk/Lingerie,Rapid15,Shirts,

Sportswear,Bedding,Outdooror

Denimprogrammes,thelaundryisnot

weighed

The buzzer will sound when the

programme has finished, and the door

will unlock immediately.

Removethelaundryandrearrangewhere

necessaryDonotleaveitinthedrumtoo

longaftertheprogrammeendstoprevent

colourtransfer

CAUTION

After a high temperature wash, be

careful not to burn yourself when

handling the laundry or touching

the inside of the drum.

NOTE

- Ifthedetergentisnotcompletely

removedfromthelaundrybyusing

thebasicprogramme,usetheExtra

Rinsefunction

- WiththeEcoandtheSpeedfunctions,

iftheloadisbig,thelaundrymay

sticktotheinsideofthedrumThisis

normal

Required time

Requiredtimedependsontheprogramme

andtemperaturesetting

- Actualtimemaydifferslightlyfromthe

displayedtime

- Thedisplayedtimeincludesthetime

neededforthewatertofillupandto

drainout,thustheyvarydependingon

waterpressure,drainageandamountof

laundry

- Ifyouchangethefunctionsetting

whilewashing,thedisplayedtimemay

change

- Ifthelaundryinthedrumneedstobe

balanced,thetimewillbeextended

Changing settings while

washing

Afterwashinghasstarted,theprogramme,

temperatureandpresettimecannotbe

changed

- Tochangetheprogrammeortemperature

setting,turntheapplianceoffandthenon

again

- Tochangetherinseorspinsettingwhile

washing,pressthePausebuttononce

theapplianceisfullofwater

- YoucanchangetheSpinspeed,Extra

RinseandEasyIroningfunctionduring

thewashingprocess

- Nosettingscanbechangedafterthe

washingprocesshasfinished

Speed

Eco

26344

NA-140_148VG4_EN_20140213.indb 13 2014/02/13 13:13:35

14 - Washing Instructions

Selecting the Programme

Programme Description

Max load

140VG4 148VG4

ECONAVI

Foritemswithmixedfabrics,forexample,

cotton,linenandsyntheticfibres

(FordetailsaboutECONAVIprogramme,see

page12)

10 kg 8 kg

Cotton

Dailywashingforcotton,linenandcottonblend

items(Forexamples,T-shirts,underwear,

towels,tablecloths)

10 kg 8 kg

Cotton

Rinse Plus

Washingtakeslongeroverallbutrinsingis

morethoroughthantheCottonprogramme

10 kg 8 kg

Colours

Forwashingcolouredcottonsorcoloured

cottonblenditemsseparately

5 kg 4 kg

Delicates

Gentlewashingforsyntheticfibres,textiles,

satin,lace,etc

5 kg 4 kg

Wool

Gentlewashingforhandwashonlywool,

machinewashablewool,andwoolblends

2 kg 2 kg

Silk/Lingerie

Forlingerieandwashablesilkitems

WashesgentlerthantheWoolprogramme

2 kg ―

Denim

Thespraywashingisusedtopreventjeans

fromfading

― 2 kg

Mixed

Foritemswithmixedfabrics,forexample,

cotton,linenandsyntheticfibres

10 kg ―

Outdoor

Forsyntheticfabricoutdoorwearandwater-

repellentclothing

― 3 kg

NA-140_148VG4_EN_20140213.indb 14 2014/02/13 13:13:36

Washing Instructions - 15

Selecting the Programme

Programme Description

Max load

140VG4 148VG4

Memory

ProgrammebasedontheCottonprogramme

featuringselectedoptionalfunctionsand

settings

SelectMemoryprogrammeandsetother

settings,thenruntheprogramme

10 kg 8 kg

Baby-care Forbabywear 5 kg ―

Skin-care

Foritemsthatneedtobegentletotheskin,

forexample,underwear,sheets,towels,and

babyclothesItemsarespraywashedand

thoroughlyrinsed

― 4 kg

Bedding

Forlargeitems,forexample,blankets,curtains,

andbedspreads

3 kg 3 kg

Shirts Forshirtsandblouses 2 kg 2 kg

Sportswear Forsyntheticsportswear 3 kg 3 kg

Rapid 15

Washesafewlightlysoileditemsin

15minutes

2 kg 2 kg

Quick 50 Washeslightlysoileditemsin50minutes 5 kg 4 kg

Cold Wash

Washeslaundrywithoutwarmingupwater

Forcottonsandlinenblends

10 kg 8 kg

NA-140_148VG4_EN_20140213.indb 15 2014/02/13 13:13:36

16 - Washing Instructions

Details of Programmes

Programme

Available

programme

Auto setting

Manual setting Additional functions

140VG4 148VG4

Temperature

Number

rinses

Spin

speed

Approximate

time

Temperature Spin speed

Eco/

Speed

Extra

Rinse

Prewash

Easy

Ironing

140VG4 148VG4

ECONAVI

 

Cold 2 1200 0:51-2:10 0:51-2:05 Cold-60°C 800-1400 ― ― ― ―

Cotton

 

40°C 2 1200 1:15-2:15 1:15-2:10 Cold-90°C 500-1400

   

Cotton

Rinse Plus

 

40°C 2 1200 1:22–2:12 1:22–1:57 Cold-90°C 500-1400

   

Colours

 

40°C 2 1200 0:58-1:23 0:58-1:13 Cold-40°C 500-1400

   

Delicates

 

40°C 2 800 0:55-1:00 0:55-1:00 Cold-40°C 500-800 ―

  

Wool

 

30°C 3 500 0:40 0:40 Cold-40°C 500 ―



― ―

Silk/

Lingerie



― 30°C 3 500 0:40 ― Cold-40°C 500 ―



― ―

Denim ―



30°C 2 800 ― 0:55 Cold-40°C 500-1200

   

Mixed



― 40°C 2 1200 1:09-1:44 ― Cold-40°C 500-1400

   

Outdoor ―



30°C 3 800 ― 1:48 Cold-40°C 800

  

―

Memory

 

― ― ― ― ― Cold-90°C 500-1400

   

Baby-care



― 40°C 3 1200 1:29–2:04 ― Cold-90°C 500-1200

   

Skin-care ―



40°C 3 1200 ― 1:29-1:49 Cold-90°C 500-1200

   

Bedding

 

30°C 2 800 1:02 1:02 Cold-40°C 500-800 ―



―



Shirts

 

40°C 2 500 1:08 1:08 Cold-60°C 500-800

   

Sportswear

 

40°C 2 800 1:30 1:30 Cold-40°C 500-1200

   

Rapid 15

 

30°C 1 800 0:15 0:15 Cold-30°C 500-800 ― ― ― ―

Quick 50

 

40°C 2 1200 0:46-0:49 0:46-0:49 Cold-60°C 500-1400 ―

  

Cold Wash

 

Cold 2 1200 1:37-2:42 1:37-2:27 Cold 500-1400 ―

  

NA-140_148VG4_EN_20140213.indb 16 2014/02/13 13:13:36

Washing Instructions - 17

Details of Programmes

Programme

Available

programme

Auto setting

Manual setting Additional functions

140VG4 148VG4

Temperature

Number

rinses

Spin

speed

Approximate

time

Temperature Spin speed

Eco/

Speed

Extra

Rinse

Prewash

Easy

Ironing

140VG4 148VG4

ECONAVI

 

Cold 2 1200 0:51-2:10 0:51-2:05 Cold-60°C 800-1400 ― ― ― ―

Cotton

 

40°C 2 1200 1:15-2:15 1:15-2:10 Cold-90°C 500-1400

   

Cotton

Rinse Plus

 

40°C 2 1200 1:22–2:12 1:22–1:57 Cold-90°C 500-1400

   

Colours

 

40°C 2 1200 0:58-1:23 0:58-1:13 Cold-40°C 500-1400

   

Delicates

 

40°C 2 800 0:55-1:00 0:55-1:00 Cold-40°C 500-800 ―

  

Wool

 

30°C 3 500 0:40 0:40 Cold-40°C 500 ―



― ―

Silk/

Lingerie



― 30°C 3 500 0:40 ― Cold-40°C 500 ―



― ―

Denim ―



30°C 2 800 ― 0:55 Cold-40°C 500-1200

   

Mixed



― 40°C 2 1200 1:09-1:44 ― Cold-40°C 500-1400

   

Outdoor ―



30°C 3 800 ― 1:48 Cold-40°C 800

  

―

Memory

 

― ― ― ― ― Cold-90°C 500-1400

   

Baby-care



― 40°C 3 1200 1:29–2:04 ― Cold-90°C 500-1200

   

Skin-care ―



40°C 3 1200 ― 1:29-1:49 Cold-90°C 500-1200

   

Bedding

 

30°C 2 800 1:02 1:02 Cold-40°C 500-800 ―



―



Shirts

 

40°C 2 500 1:08 1:08 Cold-60°C 500-800

   

Sportswear

 

40°C 2 800 1:30 1:30 Cold-40°C 500-1200

   

Rapid 15

 

30°C 1 800 0:15 0:15 Cold-30°C 500-800 ― ― ― ―

Quick 50

 

40°C 2 1200 0:46-0:49 0:46-0:49 Cold-60°C 500-1400 ―

  

Cold Wash

 

Cold 2 1200 1:37-2:42 1:37-2:27 Cold 500-1400 ―

  

NA-140_148VG4_EN_20140213.indb 17 2014/02/13 13:13:36

18 - Washing Instructions

Tips for Washing

Wool, Silk/Lingerie, and

Delicates programmes

Thedrumspinsgentlyinthese

programmes

Laundry loads

- Woolprogramme:2kgorless

- Delicatesprogramme:

5kgorless(140VG4),

4kgorless(148VG4)

- Silk/Lingerieprogramme:2kgorless

(140VG4)

Approximate weights

- Woolsweater:400g



- Silkblouse:200g



- Trousers:400g



Putting laundry in the drum

Pileitemsoneontopofeachother

Detergents

- Forwoolitems,useamildliquid

detergentOtherdetergentsmay

damagetheclothes

- WithWool,Delicates,andSilk/Lingerie

programmes,youmayneedtouse

theExtraRinsefunctiontoremove

excessdetergentfromthelaundry

(Seepage20)

Hanging the laundry

- Hangoutwhiteorlight-colouredwool

andnylonitemsawayfromdirectheator

sunlight

- Afterwashing,layoutwoolandnylon

clothes,andreturnthemtotheirnormal

shapebeforehangingintheshadeThis

willhelptoreducetheironingtime

- Hangwoolitemswithcreasessmoothed

out,orspreadthemouttodry

- Usehangersforshirts,blousesand

trousers

Youmaywrapatowelaroundthe

hangertoapproximatetheclothing’s

shoulderwidthsothatitwillretainits

shapeasitdries

If clothing shrinks in the wash

Spreadtheitemouttoitsoriginalsizeon

anironingboardUsedresspinstohold

thesizeandshapeThen,useanironto

steamitandleaveittodry

NA-140_148VG4_EN_20140213.indb 18 2014/02/13 13:13:36

Washing Instructions - 19

Tips for Washing

Bedding programme

- Makesurethatthelabelofeachitem

tobewashedshowseitherthewashor

hand-washsymbol(S,P)

- Washonlyoneblanketatatime

Available

- 100%syntheticfibreblankets–upto3kg

- 100%syntheticfibrefutonsand100%

cottonblankets–upto15kg(single

bedsize)

- Sheets

- Bedspreads

- 100%syntheticfibreundersheets

Not available

- 100%woolblankets

- Long-piledblankets

- Electricblankets(includingcover)

Putting bedding into the drum

1. Fold down the blanket or bedspread

into a quarter of their original size.

2. Put the blanket or bedspread into the

drum.

Folditwhileputtingitintothedrum

Bothendsoftheblanketshouldbeface

therearofthedrum

CAUTION

Do NOT roll the blanket or bedspread

into balls, or haphazardly fold them.

Thismaycauseexcessivevibrationand

damagethelaundryortheappliance

NOTE

AvoidusingblanketnetsTheyprevent

thelaundryfromspinningproperly

Outdoor programme

Makesurethatthelabelofeachitemtobe

washedshowseitherthewash,handwash,

ornodrycleaningsymbol(S,P,Q)

Available

Syntheticfabricoutdoorwear,forexample,

rainwear,outerwearjacketsandtrousers–

upto3kg

Not available

- Clothingwithcottonliningorpadding,or

downfeathers

- Sleepingbagsandsyntheticfabric

covers

NOTE

- Beforewashing,closeanyzippers

andbuttonuptheclothing

- Donotwashclothinginlaundrynets

byitselfbecausetheloadwillbe

unbalancedandnotbesmoothly

washed

- Waterrepellentfinishesmightbe

washedoutovertimeTorestore

waterrepellency,ironthegarment

withalowtemperaturesetting,dryit

inadryer,orre-applyacommercially

availablewaterrepellenttreatment

Ifatreatmentisused,followthe

product’sinstructions,orthe

instructionsinthegarment

- Werecommendlayingdowntowels

infrontoftheappliancewhentaking

outwater-repellentclothingafterthe

spincyclebecausewatermaydrip

fromtheclothing

NA-140_148VG4_EN_20140213.indb 19 2014/02/13 13:13:37

20 - Washing Instructions

Optional Functions

Individual washing functions

(Process selection)

Youcanselectasingleprocess,or

combineseveralprocessesbyselecting

individualwashingfunctions

NOTE

Youcannotselectanymodefunctions

inRapid15programme

Press the Mode button

to select a

function.

Function Description

Rinseonly

Rinsewashedlaundry

(Rinsewaterremains)

Spinonly

Spin-drywashedlaundry

Wash-Rinse

N K

Washandrinselaundry

(Rinsewaterremains)

Rinse-Spin

K M

Rinseandspin-dry

washedlaundry

Drainonly

Drainwaterfromthe

drum

- Wheneveryoustartwashing,the

processindicationflashestoshowwhich

functionisinprogress

- Ifwaterremainsinthedrumwiththe

Rinseonly,SpinonlyorRinse-Spin

function,theoperationstartsfromthe

drainprocess

Additional functions

Dependingontheprogramme,youcan

combinedifferentadditionalfunctions

NOTE

Someadditionalfunctionscannot

beusedwithcertainprogrammes

(Seepages16-17)

Ifyouselectanunavailablefunction,

anerroralarmwillsound

Press one or more of the function

buttons

you wish to combine.

Function

Description

Eco

Washingconsumesless

energyandwaterbuttakes

longer

Speed

Thisfunctionrequiresless

timeforwashingandis

suitableforlightlysoiled

laundry

Extra

Rinse

Rinseyourlaundrymore

thoroughlywithanextra

rinsingprocess

Prewash

Prewashcycleforheavily

soiledlaundry

Easy

Ironing

- Makeironingeasierbyspin-

dryingyourlaundrymore

gently(at800r/minorless)

- Aftertheprogrammehas

finished,thelaundryis

rotatedintermittentlyforup

to30minutesoruntilthe

doorisopened

- Reducingwrinkleshelpsto

unraveltangledlaundry

YoucanactivateordeactivatetheExtra

RinseandEasyIroningfunctionsduringa

washingprocessbutnotaftertheprocess

hasfinished

NA-140_148VG4_EN_20140213.indb 20 2014/02/13 13:13:37

Washing Instructions - 21

Optional Functions

Preset timer

Timefunctionisavailabletopresetthetime

fortheprogrammetofinish

- YoucannotpresettheWoolandSilk/

Lingerieprogrammes

- Thewashmayfinishbeforeorafter

presettimedependingonthekindof

laundry,thetemperatureandconditions

ofwatersupplyanddrainage

NOTE

DoNOTusedetergentwhichdoesnot

dissolvethoroughlywiththepreset

functionbecausethedetergentmay

cakeupbeforethewashstartsand

doesnotflowout

Setting a preset time

PressandholdtheTimebuttonuntilthe

desiredpresettimeisdisplayed

Changing a preset time

1. Press the Off button and then press

the On button.

2. Choose the desired programme and

optional functions.

3. Set a preset time.

Cancelling a preset time

PresstheOffbutton(Allsettingswillbe

cancelled)

Checking a preset time

PresstheTimebutton

Child safety lock

Thechildsafetylockpreventschildrenfrom

climbingintothedrumandgettingtrapped

Thisfunctionkeepsthedoorclosedand

lockedevenwhentheapplianceisnotin

useItalsodisablesthecontrolbuttons

Activating/deactivating child safety lock

1. Switch on the appliance.

2. Press and hold the Mode button for at

least 5 seconds.

TheABsymbolslightuptoshowthat

thechildsafetylockisactivated

3. To deactivate, hold down the Mode

button again for 5 seconds (please

ignore three beeps heard), and keep

Mode button pressed until it unlocks.

Setting the buzzer

Thebuzzerthatsoundswhena

programmefinishescanbeturnedoff

1. Press the Start and On buttons at the

same time.

2. Release the On button and keep

pressing the Start button for

3 seconds. The buzzer setting will be

turned off after a beep is heard.

Ifyouwishtoresetthesetting,perform

thesamesteps1and2Thebuzzer

settingwillbeturnedonaftertwobeeps

areheard

NA-140_148VG4_EN_20140213.indb 21 2014/02/13 13:13:37

22 - Maintenance

Maintenance

Cleaning the detergent

drawer

Detergentresiduesoonbuildsupifthe

detergentdrawerisnotcleanedregularly

Detergentbuildupmaydevelopmould

1. Pull out the detergent drawer.

Softenercover

2. Remove the detergent drawer by

simultaneously lifting and pulling it.

3. Put your finger on the tab near the

front of the softener cover and pull

it up to remove it from the detergent

drawer.

4. Wash out the detergent residue with

water.

Useaclothtowipethewaterfromthe

appliance

Cleaning the outside of the

appliance

Cleantheoutsideoftheappliancewitha

softclothandmilddetergent,forexample,

kitchendetergent,andsoapywater

WARNING

- Do NOT splash water over the

appliance.

- Do NOT use cream cleansers,

thinners, or products containing

alcohol or paraffin oil.

Cleaning the drum

Ifyoukeepusingcoldwaterinthe

appliance,bacteriamaybuildupinside

thedrumandemitanodourYoucan

avoidthisbyrunningthe90°CCotton

programmeonceamonth(Whenusinga

scaleremover,followthemanufacturer’s

instructions)

CAUTION

Viruses and bacteria are not killed

in water temperature of 40 °C.

Pathogens can spread via the

mingling of clothes and thus

transmit diseases.

Pathogensdieatthetemperatureofat

least60°C

NOTE

DoNOTputlaundryorlaundry

detergentintotheapplianceduring

cleaning

Ifyouusetubcleaningdetergentor

bleach,putitintothedetergentdrawer

beforestartingthewashTheappropriate

amounttobeusedisapproximately30ml

(Seepages10-11)

NA-140_148VG4_EN_20140213.indb 22 2014/02/13 13:13:37

Maintenance - 23

Maintenance

5. Align the hole of the softener cover

with the click of the detergent drawer

to replace the softener cover in its

original position. Then, insert the

detergent drawer back to the main

unit.

Cleaning the door seal and

window

Aftereachwash,performthefollowing:

- Removeanyobjectsfromthedoorseal

- Wipethewindowandsealtoremovelint

andstains

Cleaning the drain filter

Werecommendcleaningthedrainfilter

onceamonthThefilterwillhavelint

buildup,whichmayinterruptdrainage

waterflow

1. Switch off and unplug the appliance.

2. Open and remove the drain filter

cover. Then, place a container

underneath it to collect the drainage.

Cap

Pumphose

Drainfilter

3. Pull out the pump hose and remove

the cap to drain the water.

4. After all the water has drained away,

loosen the drain filter.

5. Carefully loosen the drain filter. More

water may drain out.

Thisisnormal

6. Turn the drain filter anticlockwise to

unscrew it. Then, remove it.

7. Remove any lint and debris.

8. Replace the drain filter.

9. Replace the cap and pump hose to

the original position.

CAUTION

BE CAREFUL when draining hot

water.

NA-140_148VG4_EN_20140213.indb 23 2014/02/13 13:13:38

24 - Maintenance

Maintenance

Cleaning the water supply

filter

Cleanthefilterifwaterisnotsupplied

properly

1. Turn off the tap.

2. Switch on the appliance.

3. Select the Cotton programme, and

then press the Start button.

4. After 1 minute, switch off the

appliance. Water has drained out of

the water supply hose.

5. Disconnect the water supply hose

from the appliance.

6. Clean the filter, which is on the rear

of the appliance.

Useasmallbrush,forexample,a

toothbrush

7. If the unit is supplied with the hose

fitted with a water supply valve, turn

off the tap supplying water to the

appliance, disconnect the hose from

the tap and then clean the filter on

the hose in the same way.

8. Reconnect the water supply hose.

Tightentheplasticjointfirmly

9. Turn on the tap and then check for

leaks.

Preventing a frozen water

supply hose

Iftheapplianceisdeliveredinfreezing

weatherconditions,aftersettingup,leave

itatroomtemperaturefor24hoursbefore

usingThiswillensurethatthewatersupply

hosedoesnotbecomecloggedwithice

Ifyourwatersupplyhosefreezes,perform

thefollowingprocedures:

1. Wrap warm towels around the joints

of the water supply hose.

Joints

Watersupplyhose

2. Add 2 to 3 litres of warm water to the

drum.

approximately

50°C

3. Start washing with the Drain only

function, using the Mode button.

(Seepage20)

NA-140_148VG4_EN_20140213.indb 24 2014/02/13 13:13:38

Troubleshooting - 25

Fault Checklist

Problem Cause

Washing machine

Buttons do not work. - Theprogramme,temperatureandprocesssettingscannot

bechangedwhilewashingisinprogress(therinseand

spinsettingscanbechanged)

- Childsafetylockmaybeactivated(Seepage21)

Door does not open. - Doorlockmaybeactivated(Seepage9)

- Childsafetylockmaybeactivated(Seepage21)

- Thewatertemperatureorlevelmaybetoohigh

Unusual odour - Rubberpartsmaygiveoffasmellwhenyoustartusing

theappliance,butthesmellwillgoawayovertime

Youcanwashthedrumbyrunningthe90°Cprogramme

(Seepage22)

Wash

No water going into

the appliance.

- Thewatertapmaybeturnedoff

- Thewatersupplyhosemaybefrozen(Seepage24)

- Thewatersupplymaybedisrupted

- Thewatersupplyfiltermaybeclogged(Seepage24)

There is only a small

amount of water.

- Ifyouhavepausedthewashingandthenrestartit,the

appliancemaydrainoutsomewater

DoNOTpourwaterinthroughthedoor

Water builds up

during the wash

process.

- Thisisnormal;waterisautomaticallysuppliedifthe

amountofwaterhasdecreasedForheavyloads,the

watermayfilluprepeatedly

Water drains out

during the wash

process.

- Thisisnormal;thewaterfrequentlydrainsoutandbuilds

upinordertowashawayexcessfoamThisfeatureis

calledfoamdetection

NA-140_148VG4_EN_20140213.indb 25 2014/02/13 13:13:38

26 - Troubleshooting

Fault Checklist

Problem Cause

Rinse/Spin

No water flows into

the appliance during

the rinse process.

- Beforerinsing,theappliancespinstodrainoutremaining

waterThewaterwillfillupafterthat

Rinsing begins

before the spin

process finishes.

- Theappliancemayhavedetectedanunbalancedload,

whichiscausedbythelaundryshiftingtoonesideof

thedrum,sorinsingstartedautomaticallytocorrectthe

imbalance

- Afterwashing,excessfoammayremain,sothewateris

drainedoutandrefilledtowashitawayThisfeatureis

calledfoamdetection

During spin-dry,

the drum stops and

rotates several times.

- Thisisnormal;theappliancehasdetectedanunbalanced

loadandistryingtocorrectit

Foam and water

remain in the door or

door seal.

- Althoughsomefoamandwatermayremaindepending

uponthestateofthelaundryandtheamountofdetergent

used,rinseperformanceisunaffected

The spin process

repeatedly starts and

stops.

- Thisisnormal;intermittentspinningofthetubhelpsthe

spinprocesstooperatequietly

- ThelaundrymaybetoolightIfso,addoneortwobath

towels

Time

The displayed

remaining time

changes.

- Theremainingtimeisestimatedandcorrectedcontinually

Thus,thetimedisplayedmaychange

- Theremainingtimeincreasesifextrarinsingandspinning

arerequiredtocorrectanunbalancedload,whichis

causedbythelaundryshiftingtoonesideofthedrum

NA-140_148VG4_EN_20140213.indb 26 2014/02/13 13:13:38

Troubleshooting - 27

Fault Checklist

Problem Cause

Detergent and foam

There is no foam or

hardly any foam.

- Theamountoffoamvaries,dependingonthe

temperature,levelandsoftnessofthewater

- Youmayhaveputpowdereddetergentdirectlyintothe

drum;youmustputitinthedetergentdrawer

- Youmaynotbeusingenoughdetergent

- Youmaybeusingareduced-foamtypeofdetergent

- Heavilysoiledlaundryandlargerloadsoflaundrymay

reducetheamountoffoam

There is a lot of foam. - Theamountoffoamvaries,dependingonthe

temperature,levelandsoftnessofthewater

- Youmayhaveusedtoomuchdetergent

- Thetypeofdetergentyouareusingmaycauseexcess

foam

Fabric softener

overflows.

- ThesoftenermayhaveexceededtheMAXlevelofthe

detergentdrawer(Seepage11)

- Youmayhavespilttheliquidwhenclosingthedetergent

drawertoostrongly

After the wash has

finished, powdered

detergent residue

remains.

- Youmayhaveputpowdereddetergentdirectlyintothe

drum;youmustputitinthedetergentdrawer

Noise

There is an unusual

noise or vibration.

- Theremaybemetalitemsinthedrum

- Theanchorboltsmaynothavebeenremoved

(Seepage32)

- Theappliancemaybeonaslopingorunstablesurface

Ifnoneoftheaboveisthecause,contactyourlocal

CustomerServiceCentre

There is noise when

the water drains out.

- Thisisnormal;itisnoisegeneratedbytheoperationof

thedrainpump

The fan makes noise. - Thisisnormal;thefaniscoolingofftheelectricalparts

NA-140_148VG4_EN_20140213.indb 27 2014/02/13 13:13:38

28 - Troubleshooting

Fault Checklist

Problem Cause

Others

The electricity supply

cuts out while the

appliance is on.

- Theappliancestopsandwillnotstartbyitselfwhenthe

powercomesbackonYouhavetoselectaprogramme

andstartitagain

A circuit breaker trips

and the electricity

supply is cut.

- Theappliancestopsandwillnotstartbyitselfwhenyou

resetthebreakerYouhavetofindoutwhatcausedthe

breakertotripandsolveitThen,resetthebreakertoturn

theelectricitysupplybackonandswitchontheappliance

again

The water supply is

disrupted.

- Whenthewaterissuppliedagain,itmaybeimpureatfirst

Youhavetodisconnectthewatersupplyhoseanddrain

awaytheimpurewaterthroughthetapMakesurethatthe

watersupplyhosehasbeenreconnectedbeforeusingthe

appliance

The display is not

clear.

- Theappliancemaybeinabrightlylitorsunlitarea

NA-140_148VG4_EN_20140213.indb 28 2014/02/13 13:13:38

Troubleshooting - 29

Error Display

Unable to drain

What to do

Checkthedrainhoseforanyofthefollowingproblems

- Itclogsup

- Itstipisimmersedinwater

- Itextendsfurtherthan3m

- Thewaterisfrozen

Cleanthedrainfilterifitclogsup(Seepage23)

Aftercorrectingtheproblem,openandclosethedoor,andthen

startthewashagain

Door is open

What to do

Makesurethatthedoorisshutproperly

Unable to spin-dry

Theappliancehasbeendesignedtodetectunbalancedloads,

particularlysmallloads,inordertoensurequietoperationand

achievethebestresults

ThisisnotamalfunctionPerformanyofthefollowingsolutions

What to do

- Ifthelaundryistooheavy,untangleclumpsofclothing

- Ifthelaundrysuchasablanketistooheavy,reducetheload

- Ifthelaundryistoolight,addoneortwobathtowels

- Iftheapplianceisonanunstableorunevensurface,change

thesettinglocation

Aftercorrectingtheproblem,openandclosethedoor,andthen

startthewashagain

Unable to supply

water

What to do

Checkforanyofthefollowingproblems

- Thetapisclosed

- Thewaterpipeorhoseisfrozen

- Thewatersupplyhasbeendisrupted

- Thewatersupplyfilterisclogged(Seepage24)

Aftercorrectingtheproblem,openandclosethedoor,andthen

startthewashagain

Iftheredmarkappearsinthehosewithawatersupplyvalve,the

watersupplyhasstopped

Youshouldreplacewithanewhose

Hosewithwatersupplyvalve(AXW12C-7SR0)

AnerrordisplaystartingwithH

What to do

PresstheOffbuttonIfthedisplaystayson,orifitreappears

whenyoupresstheStartbutton,unplugtheapplianceand

contactyourlocalCustomerServiceCentre

NA-140_148VG4_EN_20140213.indb 29 2014/02/13 13:13:39

30 - Installation Instructions

Choosing the Right Location

Carrying the appliance

The appliance must be carried by 2 or

more people.

Startbytiltingtheappliancebackwards

Onepersonshouldstandbehindit,holding

therearofthetoppanelTheotherperson

shouldgripthebottomstandsinthefront

The right place for the

appliance

Makesurethatthereisenoughspacefor

theapplianceandthatopeningsonthe

basearenotobstructedbyacarpet

582

596

240

516

594

625

845

Dimensionsinmillimetres

CAUTION

- Install the appliance on a flat,

stable surface to avoid excessive

vibration and noise.

- Do NOT install the appliance in

direct sunlight or in a place where

temperatures reach freezing.

- Do NOT let metallic portions of the

appliance come into contact with

metal sinks or other appliances.

Theinstallationshallbeinaccordancewith

therequirementsofAS/NZS35001

NA-140_148VG4_EN_20140213.indb 30 2014/02/13 13:13:39

Installation Instructions - 31

Choosing the Right Location

Installing the set-in

appliance

- Youneedaspaceofatleast60cm

wide

Provideatleast2mmofclearance

onbothsidesandatleast3mmof

clearancebothonthetopandtheback

oftheappliance

- Thecounterabovetheappliance

mustbefirmlyfixedtotheadjoining

cupboards

- Haveatechnicianinstallametalcover

insteadofthestandardcoverpanel

- Theplugmustbeaccessibleafter

installation

Metalcover

Metalcover(AXW4595-7SR0)

NA-140_148VG4_EN_20140213.indb 31 2014/02/13 13:13:40

32 - Installation Instructions

Moving and Installing

Removing the anchor bolts

Fouranchorboltskeeptheinteriorofthe

applianceinplacewhiletheappliance

isbeingmovedRemovethembefore

installation,usingthespannersupplied

withtheapplianceFollowtheinstructions

below

NOTE

Theanchorboltsmustberemoved

beforetheapplianceisoperated

Theymaycauseexcessivevibration

1. Use the ‘B’ end of the spanner to

loosen the four bolts.

2. Pull the bolts out horizontally.

3. Remove the screws adjacent to the

bolt holes.

4. Attach each cover cap (included

with the accessories) over each bolt

hole, and then secure them with the

screws removed in step 3.

NOTE

- Makesurethatyoustoretheanchor

boltsbecausetheyareusedwhen

transportingtheapplianceIfthe

applianceispassedontoanother

person,makesuretogivetheanchor

boltstothatperson

- Makesuretheboltcapsare

attachedFailuretoobservethismay

resultinwaterenteringthewashing

machine,leadingtomalfunctions

Moving the appliance

NOTE

Makesuretoinstalltheanchorboltsin

theappliance

Before you move the appliance

- Shutthetapandruntheapplianceto

drainthewaterDrainremainingwater

fromthepumphose(Seepage23)

- Depressurizeandremovethewater

supplyhose

- Disconnectthepowercable

- Installtheanchorbolts(Seepage33)

NA-140_148VG4_EN_20140213.indb 32 2014/02/13 13:13:40

Installation Instructions - 33

Moving and Installing

Installing the anchor bolts

1. Unscrew and remove each cover cap.

2. Pull the bolt out until the tip is level

with the tip of the sleeve.

Haveanotherpersonholdthetopofthe

drum

Samelevel

3. Insert each anchor bolt.

4. Tighten each bolt so that the spring

extends out to the length of 26 mm.

26mm

Levelling the appliance

Usingalevelenableseaseinadjustments

Toadjustthestands,usethe‘A’endofthe

spanner

Locknut

Stand

1. Loosen the lock nut on each stand by

turning it clockwise.

2. Adjust each stand by turning it

clockwise or anticlockwise.

3. Use a spirit level to make sure that

the appliance is properly levelled.

4. Tighten each lock nut by turning it

anticlockwise.

CAUTION

Make sure that all lock nuts are

tightened securely and the stands

are still securely bolted to the

appliance.

Iftheyareunbolted,theappliancewill

movearound

NA-140_148VG4_EN_20140213.indb 33 2014/02/13 13:13:41

34 - Installation Instructions

Connecting Hoses and Power Supply

Water supply hose

CAUTION

- Do NOT connect the water supply

hose to a combination tap.

- Do NOT twist, squash, modify or

cut the hose.

- Optimummainswaterpressureis

003-10MPaIfthewaterpressure

exceedsthisvalue,installapressure

reducingvalve

- Waterflowfromthetapshouldbemore

than5L/min

Connecting the water supply hose

1. Attach one end of the hose to

the water inlet on the back of the

appliance and tighten the joint by

hand.

2. Attach the other end of the hose to

the tap and tighten it the same way.

min10mm

3/4”

Hosewithwater

supplyvalve

Standardhose

3. Open the tap slowly and make sure

that there are no leaks around the

joints.

Thejointsaresubjecttowaterpressure

FollowtheinstructionsinthissectiontopreventwaterleaksIfyouareunsure,askaservice

agenttoconnectthehoses

Hoses and cable lengths

Leftsideconnections Rightsideconnections

~105cm ~135cm

~130cm ~90cm

~100cm ~140cm

0–max100cm

NA-140_148VG4_EN_20140213.indb 34 2014/02/13 13:13:41

Installation Instructions - 35

Connecting Hoses and Power Supply

Leak-proof System

Theapplianceisinstalledwiththe

systemthatisdesignedtopreventwater

leaksThesystemincludesthefollowing

components

1)Leaksensor

Thissensorwillceaseoperationof

theapplianceifitdetectsanyleaks

Itislocatedonthebaseplateofthe

applianceIfaleakhasbeendetected,

anerrordisplaystartingwithH,for

example,H01,willappearInthatcase,

contactyourlocalCustomerService

Centre

2)Overflowdetection

Ifwaterintheapplianceincreasesto

acertainlevel,thisfunctionstopsthe

watersupplyandactivatesthedrain

pump

Water drain hose

Draining to a sink or wash-basin

Elbow

Draining to a drain hose

CAUTION

- Do NOT twist, pull out or bend the

drain hose.

- Secure the water drain hose so

that it will not come out of the

basin.

- Do NOT block the drain outlet of

the basin. Make sure that drainage

into the drain is sufficient.

- Do NOT let the tip of the water

drain hose dip into the drained

water.

Thiscancausewatertoflowback

intotheappliance

Connecting to the power

supply

Nameplate

CAUTION

The name plate indicates the rated

power that the appliance needs.

Make sure that the power supply

specifications in your residence

match the information mentioned

here.

NA-140_148VG4_EN_20140213.indb 35 2014/02/13 13:13:42

36 - Installation Instructions

Checking after Installation

Installation checklist

5 6 5 6

5)Adjustablestands

Aretheyboltedsecurelytothe

appliance?

6)Standcushions

Aretheystandingflat?

Iftheapplianceisnotlevel,theremay

beabnormalsoundswhenwateris

drainedout

7)Powersupply

Isthehouseholddedicatedmainssocket

fullyratedatAC220Vto240V?

1)Anchorbolts

Haveyouremovedthemandattached

thecovercapsproperly?

2)Location

Istheapplianceonaflat,stable

surface?

Doesitrunwithoutvibrating?

3)Watersupplyhose

Isitfreefromleaks?

Isthewatersupplynormal?

4)Waterdrainhose

Isitfreefromleaks?

Doesitdrainnormally?

NA-140_148VG4_EN_20140213.indb 36 2014/02/13 13:13:42

Installation Instructions - 37

Checking after Installation

Test run after installation

Checkforwaterleakage,abnormalnoise,

andproperdrainage

Performthefollowingprocedures

WITHOUTlaundryinthedrum

1. Turn on the tap.

2. Close the door.

3. Press the On button. You have to

select “Quick 50” course and “Spin

only” mode. Then, press the Start

button.

After the water is drained, start a test

run.

4. While holding down the Speed/Eco

and Easy Ironing buttons, press the

On button.

5. When the display appears as below

(3 seconds), press the Speed/Eco

button.

Theremainingtimeisdisplayedasshown

below

Thetestisrunforapproximately3minutes

- Whenthewaterpressureislow,the

operationmaystopforseveralminutes

with“0:03”displayed

Checkthefollowing:

- Isthereanyabnormalnoise?

Ifso,makesurethattheapplianceis

level

- Isthereanywaterleakage?

Ifso,makesurethatthehosesare

properlyconnected

Thefollowingerrorsmayoccur:

- Arethehosesproperlyconnected?

Isthedrainclogged?

- Haveyouproperlyconnectedthe

watersupplyhoseandturnedonthetap?

Aftertheappliancehasrecoveredfrom

anerror,reopenandreclosethedoorto

resumethetest

NA-140_148VG4_EN_20140213.indb 37 2014/02/13 13:13:43

38 - Installation Instructions

Consider the Environment

Disposing of packaging

Thepackagingusedtoprotectthe

washingmachinefromdamageduring

transportationisallrecyclableFor

informationonrecycling,contactyourlocal

authority

Disposing of Waste

Electrical & Electronic

Equipment

Information on disposal for users of

waste electrical & electronic equipment

(private households)

Thissymbolontheproductsand/or

accompanyingdocumentsmeansthat

usedelectricalandelectronicproducts

shouldnotbemixedwithgeneral

householdwaste

Forpropertreatment,recoveryand

recycling,pleasetaketheseproductsto

designatedcollectionpoints,wherethey

willbeacceptedonafreeofchargebasis

Alternatively,insomecountriesyoumaybe

abletoreturnyourproductstoyourlocal

retaileruponthepurchaseofanequivalent

newproduct

Disposingofthisproductcorrectlywill

helptosavevaluableresourcesand

preventanypotentialnegativeeffectson

humanhealthandtheenvironmentwhich

couldotherwisearisefrominappropriate

wastehandlingPleasecontactyourlocal

authorityforfurtherdetailsofyournearest

designateddisposablepoint

Penaltiesmaybeapplicableforincorrect

disposalofthiswaste,inaccordancewith

nationallegislation

Information on disposal in other

countries outside the European Union

ThissymbolisonlyvalidintheEuropean

Union

Ifyouwishtodiscardthisproduct,please

contactyourlocalauthoritiesordealerand

askforthecorrectmethodofdisposal

Eco-friendly Laundry

- Keeptotheloadlimitofeach

programme

- Thewashingmachineautomatically

adjuststheoperatingtimeofeach

programmedependingontheload

- Youonlyneedtouseapreliminarywash

ifyourlaundryisheavilysoiled

- Usingthe60°CCottonprogramme

insteadofthe90°CCottononewillsave

energyandwillremoveordinarystains

- Forlightlysoiledlaundry,usingtheCold

Washprogrammeinsteadofthe40°C

Quick50programmewillsavemore

energy

Detergent amount

- Usethecorrectamountofdetergent

basedonthedetergentpackinstructions

andlocalwaterhardness

- Adjusttheamountofdetergent

dependingonhowsoiledyourlaundryis

When using a tumble dryer

Tosaveenergy,pleaseselectthecorrect

spinspeedaccordingtotheinstructionof

yourtumbledryer

NA-140_148VG4_EN_20140213.indb 38 2014/02/13 13:13:43

Installation Instructions - 39

Power and Water Consumption

Programme

Temperature

Additional

function

Load

Power

consumption

Water

consumption

Time

Cotton

40°C ―

10kg 107kWh 85L 2:15

8kg 090kWh 72L 2:10

60°C

―

10kg 210kWh 85L 2:40

8kg 185kWh 72L 2:20

60°C

Eco

10kg 085kWh 63L 3:45

8kg 065kWh 50L 3:45

Cotton

Rinse Plus

60°C ―

10kg 155kWh 87L 3:02

8kg 148kWh 74L 2:22

40°C Eco

10kg 083kWh 80L 3:23

8kg 067kWh 68L 2:53

Wool 30°C ― 2kg 020kWh 50L 0:40

Silk/Lingerie 30°C ― 2kg 022kWh 60L 0:40

Denim 30°C ― 2kg 024kWh 40L 0:55

Outdoor 30°C ― 3kg 027kWh 58L 1:48

Shirts 40°C ― 2kg 042kWh 35L 1:08

Sportswear 40°C ― 3kg 065kWh 45L 1:30

Rapid 15 30°C ― 2kg 015kWh 23L 0:15

Quick 50

40°C ―

5kg 048kWh 50L 0:49

4kg 045kWh 40L 0:49

Cold Wash

Cold ―

10kg 028kWh 87L 2:42

8kg 026kWh 74L 2:27

1)ResultscalculatedbasedontheusageoftheEcofunctionandthemaximumspinspeed

complywithIEC60456

2)Thepower,waterconsumptionandtimeindicatedinthetablemayvarydependingon

variationsinpressures,waterhardnessandtemperatures,roomtemperatures,typesand

amountsoflaundry,voltagefluctuationsandfunctionstobeused

3)CottonRinsePlus,40°C,Eco,1400r/minisfornormallycottonsoiledloadwith

AS/NZS20401,AS/NZS20402,AS/NZS6400

NA-140_148VG4_EN_20140213.indb 39 2014/02/13 13:13:43

Specifications

Panasonic Corporation

http://panasonicnet

PrintedinChina

March2014

H0314-0

NA-140VG4 NA-148VG4

Rated voltage 220-240V

Rated frequency 50Hz

Maximum energy rated power input 2000-2350W

Heating energy rated power input 2000W(230V)

Power consumption Off-mode/LeftOn-mode02W

Maximum spin speed 1400r/min

Product weight 74kg

Maximum mass of dry cloth 10kg 8kg

Product dimensions 596mm(W)×625mm(D)×845mm(H)

Water consumption Referto“PowerandWaterConsumption”

Pressure of tap water 003-1MPa

NA-140_148VG4_EN_20140213.indb 40 2014/02/13 13:13:43

Panasonic NA-140VG4WAU 10kg ECONAVI Front Load Washing Machine

Product's Documents

Operating Instructions & Installation Instructions

Specifications

Panasonic NA-140VG4WAU Questions and Answers

Related Products

Panasonic NA-120VG6WAU 10kg Front Load Washing Machine

Panasonic NA-148VG4WAU 8kg Front Load Washing Machine

Panasonic NA-140VS4WAU - 10kg Steam Front Load Washing Machine

HWF5I1215 Hisense Series 5I 12kg Max Drum Front Load Washing Machine White

HWF5I1015 Hisense Series 5I 10kg Max Drum Front Load Washing Machine White

HWF3S8514X Hisense Series 3S 8.5kg Front Load Washing Machine White
