Quick Reference Guide
Samsung Solution Displays
ME32B, ME40B, ME46B, ME55B, ME65B, ME75B
The ME series is a slimline range designed for up to 16/7 applications and
now includes sizes 32, 40, 46, 55, 65 and 75 inch to cover a wide range of
applications. The ME range can also be paired with the new range of Touch
Module overlays to create interactive touch screens in sizes from 32 inch to
65 inch.
Samsung Solution Displays
Samsung large format commercial displays are engineered for performance and reliability. Samsung is a world leader in
LCD technology and offers a comprehensive range of commercial displays to meet the needs of multiple applications for
information sharing and signage applications. Included in the range is six series of video wall displays, including the new
SL46B for window display, which is compatible with the MID stands for freestanding video wall, as well as five model series
of Samsung LED* backlit slimline displays.
*Samsung LED Displays combine LCD screens with LED back or edge lights.
ME Series LED*BLU Displays
MD Series LED*BLU
DE Series LED*BLU
UE Series LED*BLU
UD Series LED*BLU
DX Series Displays
UX Series Displays
UT Series Displays
MX/MP Series Displays
TS Series Interactive Displays
Media Players
Touch Overlays
High Bright Series
MD32B, MD40B, MD46B, MD55B
The new MD series, available in 32, 40, 46 and 55 inch utilises direct LED back-
lighting and is an affordable LED backlit solution within the Samsung range.
DE40C, DE46C, DE55C
The new DE-C series (available soon) in 40, 46 and 55 inch, will offer 700
cdm/2 brightness for 24/7 applications. lLow glare screens help ensure
reected light is minimised for increased exceptional clarity.
UE46A, UE55A
The UE series in 46 and 55 inch, offers stunning image quality in an LED
slimline (30mm) edge lit display. The narrow 5.15mm bezel suits video wall or
stand alone applications.
UD46A, UD55A and now the UD22 square display
Available in 22, 46, and 55 inch, the Samsung solution for 24/7 video wall
applications. 700 candela with screen surface combined with 5.5mm image to
image gap provide a near seamless video wall solution.
400DX-3, 460DX-3, 550DX, 700DX-3 and 820DX-3
Available in 40, 46, 55, 70 and 82 inch, the DX series is designed for 24/ 7
applications. 40 to 55 inch is a super bright 700 cd/m2 and a bright 600 cdm/2
for the 70 and 82 inch which helps ensure visibility in high ambient light condi-
tions.
400UX-3, 400UXn-3, 460UX-3 and 460UXn-3
Available in 40 and 46 inch (n) models with embedded PC, the UX series of-
fers 24/7 use, narrow 11mm metal bezel for stand alone or video applications
and a bright 700cd/m2 to help ensure readability in high ambient light.
460UT2, 460UTn-2, 460UT-B, 460UTn-B
The UT(n)-2 Series is 700cd/m2 brightness for 24/7 video application and
the UT(n)-B is 450 cd/m2 for 16/7 video wall applications both offer a 6.7mm
image to image gap for virtually seamless video walls.
320MX-3, 320MXn-3, 400MX-3, 460MX-3, 650MP-2
Available in 32, 40, 46 and 65 inch, the MX/MP series are designed for 16/7
applications. The MX series offers typical brightness of 450 cd/m2 and low
glare screen surface to help ensure readability. 650MP-2 offers 500 cd/m2
brightness, with low glare screen surface.
320TSn-3, 400TS-3,460TS-3, 650TS-2, 700TSn-2
Available in 32, 40, 46, 65 and 70 inch, the TS series is a range of out of the
box touch screen solutions.
SBB-A, SBB-SIM, and PIM (OPS) options
The new range of SBB (set back box) and SIM (slide in module) media play-
ers along with MagicInfo Premium software (rst ve licenses free)**, com-
plete the digital signage solution. SBB-A models are suited to the ME, MD,
UE, DE and UD series as well as 700 and 820DX-3 models. The SIM model
suits 40 and 46 inch in MX series and 40, 46 and 55 inch in DX series.
**Internet connection required. Data charges may apply.
CY-TM32, CY-TM40, CY-TM46, CY-TM55, CY-TM65, CY-TM75TBC
Our new Touch Module Overlays are available in 32, 40, 46 and 55 inch with
6 point IR touch technology. The 65 inch Overlay uses optical technology
with dual touch and supports dual draw function**. The new TM series Touch
Overlays come with Magic IWB 2.0 Basic Whiteboard Software supporting
dual draw function included with the Overlay.
**Third party software needs to be dual draw capable to allow for dual draw
function and may need to be purchased separately.
OL46B, SL46B and 460DR-2
The new High brightness series includes the OL46B, IP rated all in one Out-
door Display, the SL46B display for window displays, (MID video wall capable
with MID46 stands – sold separately), and the 460DR-2 panel only solution
for third party encasements. Very bright 1500cd/m2 brightness for readability
in the most demanding applications.
*Samsung LED BLU Displays combine LCD screens with LED back or edge lights.
Model ME32B ME40B ME46B ME55B ME65B ME75B specs TBC
Display
Screen Size 32” 40” 46” 55” 65” 75”
Panel Technology 60Hz LED BLU 60Hz LED BLU 60Hz LED BLU 120Hz LED BLU Edge LED BLU(AMV3) 240Hz LED BLU
Resolution 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) CD/M2 350cd/m2 350cd/m2 350cd/m2 380cd/m2 450 cd/m2 450 cd/m2(TBD)
Contrast Ratio 5000:1 5000:1 5000:1 5000:1 4,000:1 5,000:1(TBD)
Viewing Angle(H/V) 178:178 178:178 178:178 178:178 178/178 178/178
Response Time(G-to-G) 8ms 8ms 8ms 8ms 8ms 6ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port
VIDEO Component(CVBS Common), HDMI Component(CVBS Common), HDMI Component(CVBS Common), HDMI Component(CVBS Common), HDMI Component(CVBS Common), HDMI Component(CVBS Common), HDMI
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
OUTPUT
RGB DVI-D DVI-D DVI-D DVI-D DVI-D DVI-D
VIDEO N/A N/A N/A N/A N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
Power Out N/A N/A N/A N/A N/A N/A
EXTERNAL CONTROL RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45
EXTERNAL SENSOR IR, Ambient Light IR, Ambient Light IR, Ambient Light IR, Ambient Light IR, Ambient Light IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 64/71 86/102 92/ 110 117/143 TBD TBD
Sleep mode less than 1W less than 1W less than 1W less than 1W less than 1W less than 1W
Off mode less than 1W less than 1W less than 1W less than 1W less than 1W less than 1W
Dimensions
Dimension (mm)
Product 733.7 X 430.2 X 29.9 921.2 X 536.1 X 29.9 1056.3 X 612.3 X 29.9 1246.4 X 718.2 X 29.9 1480.5 X 855.5 X 33.5 1678.2 × 958.7 × 49.9(TBD)
Packaging 811 X 525 X 120 1036.0 X 633.0 X 150.0 1170.0 X 730.0 X 199.0 1364.0 X 848.0 X 199.0 1641x 220 x 988 1863.0 × 1173.0 × 473.0(TBD)
Weight (kg)
Product 6.5 10.5 12.5 17.1 25.1 44.1(TBD)
Packaging 7.6 12.9 16.6 22.2 32.2 69.7(TBD)
VESA Mount 200 x 200mm 200 x 200mm 400 x 400mm 400 x 400mm 400 x 400mm 400 x 400mm
Bezel Width (mm) 15.1mm (Bottom 16.6mm) 15.1mm (Bottom 16.6mm) 15.1mm (Bottom 16.6mm) 15.1mm (Bottom 16.6mm) 21.5mm 12.5mm (Bottom 15.0mm)(TBD)
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C~ 40
o
C 0
o
C~ 40
o
C
Humidity 10~80% 10~80% 10~80% 10~80% 10~80% 10~80%
Features
Key
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Special
“Built in MagicInfo Lite, Built in Speaker
(10W + 10W), Plug and Play (through
USB), PIP/PBP”
“Built in MagicInfo Lite, Built in Speaker
(10W + 10W), Plug and Play
(through USB), PIP/PBP”
“Built in MagicInfo Lite, Built in Speaker
(10W + 10W), Plug and Play (through
USB), PIP/PBP”
“Built in MagicInfo Lite, Built in Speaker
(10W + 10W), Plug and Play (through
USB), PIP/PBP”
Built in MagicInfo Lite, Built in
Speaker(15W + 15W), Plug and Play
(through USB)
Narrow Bezel, Slim Depth, PIM Module,
Digital Daisy Chains,Temperature Sensor,
Smart Scheduling, Built in Speaker(15W +
15W), Plug and Play (through USB)
“Internal Player
MagicInfo Lite Only”
Processor
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
“Main Memory
Interface”
Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667 (1333MHz)
Storage (FDM) “4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“4GB (1.2GB Occupied by O/S,
2.8GB Available)”
Multimedia “ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
Accessories
Included
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power Cord,
Remote Controller, Batteries, RS232C to
Stereo Gender in/out Cable,Component
Gender, Holder P-Ring, Holder Wire Stand”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power
Cord, Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, Power Cord,
Remote Controller, Batteries, D-Sub cable
RS232C to Stereo Gender in/out Cable,
External IR Sensor”
“Quick Setup Guide, Warranty Card,
Application CD, Power Cord,
Remote Controller, Batteries, D-Sub cable
RS232C to Stereo Gender in/out Cable”
Optional
Stand STN-L32D STN-L4055AD STN-L4055AD STN-L4055AD TBD STN-L75D(TBD)
Mount WMN250MD WMN250MD WMN250MD WMN250MD WMN250MD
Media Player SBB-A (optional) ** No SBB-A mount
points on display
SBB-A (optional) SBB-A (optional) SBB-A (optional) SBB-A (optional), PIM (optional) SBB-A (optional), PIM (optional)
ME Series
ME32B, ME40B, ME46B, ME55B, ME65B, ME75B
The ME series is a slimline range designed for up to 16/7 applications and
now includes sizes 32, 40, 46, 55, 65 and 75 inch to cover a wide range of
applications. The ME range can also be paired with the new range of Touch
Module overlays to create interactive touch screens in sizes from 32 inch to
65 inch.
ME Series LED*BLU Displays
MD Series LED*BLU
MD32B, MD40B, MD46B, MD55B
The new MD series, available in 32, 40, 46 and 55 inch utilises direct LED back-
lighting and is an affordable LED backlit solution within the Samsung range.
Model MD32B MD40B MD46B MD55B
Display
Screen Size 32” 40” 46” 55”
Panel Technology 60Hz LED BLU 60Hz LED BLU 60Hz LED BLU 120Hz LED BLU
Resolution 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) cd/m2 350 cdm/2 350 cdm/2 350 cd/m2 350 cd/m2
Contrast Ratio 5000:1 5000:1 5000:1 5000:1
Viewing Angle(H/V) 178:178 178:178 178:178 178:178
Response Time(G-to-G) 8ms 8ms 8ms 8ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D Analog D-SUB, DVI-D Analog D-SUB, DVI-D Analog D-SUB, DVI-D
VIDEO Component, CVBS, HDMI Component, CVBS, HDMI Component, CVBS, HDMI Component, CVBS, HDMI
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
OUTPUT
RGB N/A N/A N/A N/A
VIDEO N/A N/A N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
Power Out N/A N/A N/A N/A
EXTERNAL CONTROL RS232C(in/out), RJ45 RS232C(in/out), RJ45 RS232C(in/out), RJ45 RS232C(in/out), RJ45
EXTERNAL SENSOR N/A N/A N/A N/A
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 50/94 87/119 94/136 124/164
Sleep mode less than 1W less than 1W less than 1W less than 1W
Off mode less than 1W less than 1W less than 1W less than 1W
Dimensions
Dimension (mm)
Product 736 X 434.5 X 93.5 925.4 x 541.0 x 93.5 1057.7 x 615.8 x 94.9 1247.7 x 722.9 x 95.2
Packaging 826 x 530 x 162 1005 x 615 x 151 1154 x 723 x 165 1381 x 838 x 170
Weight (kg)
Product 6.4 9.6 12.2 17.9
Packaging 8.0 11.7 14.8 23.7
VESA Mount 200 x 200mm 200 x 200mm 400 x 400mm 400 x 400mm
Bezel Width (mm) 16.5mm(Bottom 20.5mm) 17.5mm(Bottom 21.5mm) 17.5mm(Bottom 21.5mm) 17.5mm(Bottom 21.5mm)
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80% 10~80%
Features
Key
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Slim & Light LFD with Built-in
MagicInfo Lite
Special
“Built in MagicInfo Lite, Built in
Speaker
(10W + 10W), Plug and Play
(through USB), PIP/PBP, Narrow
Bezel, Light Weight”
“Built in MagicInfo Lite, Built in
Speaker
(10W + 10W), Plug and Play (through
USB), PIP/PBP, Narrow Bezel, Light
Weight”
“Built in MagicInfo Lite, Built in
Speaker
(10W + 10W), Plug and Play
(through USB), PIP/PBP, Narrow
Bezel, Light Weight”
“Built in MagicInfo Lite, Built in
Speaker
(10W + 10W), Plug and Play (through
USB), PIP/PBP, Narrow Bezel, Light
Weight”
“Internal Player
MagicInfo Lite Only”
Processor Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
Cortex-A8 Single Core CPU with
NEON DSP
“Main Memory
Interface”
Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667
(1333MHz)
Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667
(1333MHz)
Storage (FDM) “4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“2GB (1.2GB Occupied by O/S,
800MB Available)”
“4GB (1.2GB Occupied by O/S,
2.8GB Available)”
“2GB (1.2GB Occupied by O/S,
800MB Available)”
Multimedia “ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
Accessories
Included
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable,
Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power
Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty
Card, Application CD, D-Sub cable,
Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable,
Power Cord,
Remote Controller, Batteries”
Optional
Stand STN-L32D STN-L4055AD STN-L4055AD STN-L4055AD
Mount “WMN4070SD
WMN250MD(TBD)”
“WMN4070SD
WMN250MD(TBD)”
“WMN4270SD
WMN250MD(TBD)”
“WMN4270SD
WMN250MD(TBD)”
Media Player SBB-A (optional) ** No SBB Mount-
ing Point
SBB-A (optional) ** No SBB
Mounting Point
SBB-A (optional) ** No SBB
Mounting Point
SBB-A (optional) ** No SBB
Mounting Point
MD Series
DE Series LED*BLU
DE40C, DE46C, DE55C
The new DE-C series (available soon) in 40, 46 and 55 inch, will offer 700
cdm/2 brightness for 24/7 applications. lLow glare screens help ensure
reected light is minimised for increased exceptional clarity.
DE Series
Model DE40C specs TBC DE46C specs TBC DE55C specs TBC
Display
Screen Size 40” 46” 55”
Panel Technology 60Hz LED BLU 60Hz LED BLU 60Hz LED BLU
Resolution 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) CD/M2 700 cd/m2 700 cd/m2 700 cd/m2
Contrast Ratio 4000:1 4000:1 4000:1
Viewing Angle(H/V) 178:178 178:178 178:178
Response Time(G-to-G) 8ms 8ms 8ms
Connectivity
INPUT
RGB D-Sub, DVI-D, Display Port D-Sub, DVI-D, Display Port D-Sub, DVI-D, Display Port
VIDEO Component(VCBS common), HDMI Component(VCBS common), HDMI Component(VCBS common), HDMI
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack
OUTPUT
RGB DP(Loop-out) DP(Loop-out) DP(Loop-out)
VIDEO - - -
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack
Power Out - - -
EXTERNAL CONTROL RS-232C(In/Out) thru Stereo Jack, RJ-45 RS-232C(In/Out) thru Stereo Jack, RJ-45 RS-232C(In/Out) thru Stereo Jack, RJ-45
EXTERNAL SENSOR IR, Ambient Light IR, Ambient Light IR, Ambient Light
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] TBD TBD TBD
Sleep mode less than 0.5W(W/O Ethernet) less than 0.5W(W/O Ethernet) less than 0.5W(W/O Ethernet)
Off mode less than 0.5W(W/O Ethernet) less than 0.5W(W/O Ethernet) less than 0.5W(W/O Ethernet)
Dimensions
Dimension (mm)
Display 919.6 X 532.0 X 35.1(TBD) 1054.5 X 608.5 X 35.1(TBD) 1249.5 X 721.0 X 35.1(TBD)
Packaging TBD TBD TBD
Weight (kg)
Display 13.6(TBD) 16.4(TBD) 19.9(TBD)
Packaging 16.0(TBD) TBD TBD
VESA Mount 200 x 200mm 400 x 400mm 400 x 400mm
Bezel Width (mm) 13.5mm (Bottom 14.5mm) 14.6mm (Bottom 15.4mm) 16.5mm (Bottom 17.1mm)
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80%
Features
Key Professional Heavy Usage LED LFD Professional Heavy Usage LED LFD Professional Heavy Usage LED LFD
Special
“Anit Reection, Non Glossy Design, Built in MagicInfo Lite,
Built in Speaker, (10W + 10W), Plug and Play (through USB), “
“Anit Reection, Non Glossy Design, Built in MagicInfo Lite,
Built in Speaker, (10W + 10W), Plug and Play (through USB), “
“Anit Reection, Non Glossy Design, Built in MagicInfo Lite,
Built in Speaker, (10W + 10W), Plug and Play (through USB), “
“Internal Player
MagicInfo Lite Only”
Processor Cortex-A9 1GHz Dual Core CPU Cortex-A9 1GHz Dual Core CPU Cortex-A9 1GHz Dual Core CPU
“Main Memory
Interface”
“8Gbyte DDR3
Dual 32bit DDR3-667 (1333MHz)”
“8Gbyte DDR3
Dual 32bit DDR3-667 (1333MHz)”
“8Gbyte DDR3
Dual 32bit DDR3-667 (1333MHz)”
Storage (FDM) “8GB(TBD) (2.0GB Occupied by O/S, 6GB Available)” “8GB(TBD) (2.0GB Occupied by O/S,
6GB Available)”
“8GB(TBD) (2.0GB Occupied by O/S,
6GB Available)”
Multimedia
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
Accessories
Included TBD TBD TBD
Optional
Stand STN-L4055AD STN-L4055AD STN-L4055AD
Mount “WMN4070SD
WMN250MD”
“WMN4270SD
WMN250MD”
“WMN4270SD
WMN250MD”
Media Player SBB or PIM Type Optional SBB or PIM Type Optional SBB or PIM Type Optional
UE Series LED*BLU
UE46A, UE55A
The UE series in 46 and 55 inch, offers stunning image quality in an LED
slimline (30mm) edge lit display. The narrow 5.15mm bezel suits video wall or
stand alone applications.
UE Series
Model UE46A UE55A
Display
Screen Size 46” 55”
Panel Technology 240Hz LED BLU 240Hz LED BLU
Resolution 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) cd/m2 450 cd/m2 450 cd/m2
Contrast Ratio 5000:1 5000:1
Viewing Angle(H/V) 178:178 178:178
Response Time(G-to-G) 4ms 4ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port
VIDEO Component(CVBS Common), HDMI Component(CVBS Common), HDMI
AUDIO Stereo mini Jack Stereo mini Jack
OUTPUT
RGB DVI-D DVI-D
VIDEO - -
AUDIO Stereo mini Jack Stereo mini Jack
Power Out N/A N/A
EXTERNAL CONTROL RS232C(in/out) thru stereo jack, RJ45 RS232C(in/out) thru stereo jack, RJ45
EXTERNAL SENSOR N/A N/A
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 125/150 125/176
Sleep mode less than 1W less than 1W
Off mode less than 1W less than 1W
Dimensions
Dimension (mm)
Display 1030.4 X 585.0 X 29.9 1221.8 X 692.7 X 29.9
Packaging 1170.0 X 705.0 X 199.0 1364.0 X 848.0 X 199.0
Weight (kg)
Display 12.0 16.0
Packaging 15.9 21.0
VESA Mount 400 x 400mm 400 x 400mm
Bezel Width (mm) 5.2mm 5.2mm
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80%
Features
Key LED Slim Video wall LED Slim Video wall
Special
“Built in MagicInfo Lite, Built in Speaker, (10W + 10W), Plug and Play
(through USB), Narrow Bezel, Slim Depth (29.9,mm)”
“Built in MagicInfo Lite, Built in Speaker, (10W + 10W), Plug and
Play (through USB), Narrow Bezel, Slim Depth (29.9,mm)”
“Internal Player
MagicInfo Lite Only”
Processor
Cortex-A8 Single Core CPU with NEON DSP Cortex-A8 Single Core CPU with NEON DSP
“Main Memory
Interface”
Dual 32bit DDR3-667 (1333MHz) Dual 32bit DDR3-667 (1333MHz)
Storage (FDM) “4GB (1.2GB Occupied by O/S, 2.8GB Available)” “4GB (1.2GB Occupied by O/S, 2.8GB Available)”
Multimedia
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
Accessories
Included “Quick Setup Guide, Warranty Card, Application CD, D-Sub cable,
Power Cord, Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card, Application CD, D-Sub
cable, Power Cord, Remote Controller, Batteries”
Optional
Stand STN-L4055AD STN-L4055AD
Mount
“WMN4270SD
WMN2000BD
WMN4655MD(for Video wall W/M)”
“WMN4270SD
WMN2000BD
WMN4655MD(for Video wall W/M)”
Media Player SBB-A (optional) SBB-A (optional)
DX Series Displays
400DX-3, 460DX-3, 550DX, 700DX-3 and 820DX-3
Available in 40, 46, 55, 70 and 82 inch, the DX series is designed for 24/ 7
applications. 40 to 55 inch is a super bright 700 cd/m2 and a bright 600 cdm/2
for the 70 and 82 inch which helps ensure visibility in high ambient light condi-
tions.
DX Series
Model 400DX-3 460DX-3 550DX 700DX-3 820DX-3
Display
Display Size 40” 46” 55” 70” 82”
Panel technology S-PVA(DID) S-PVA(DID) S-PVA(DID) 120Hz S-PVA(DID) S-PVA(DID)
Resolution 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) 700 cd/m2 700 cd/m2 700 cd/m2 600cd/m2 600 cd/m2
Contrast Ratio 3000:1 3000:1 4000:1 2000:1 2000:1
Viewing Angle(H/V) 178/178 178/178 178/178 178/178 178 / 178
Response Time(G-to-G) 8ms 8ms 8ms 8ms 8 ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port
VIDEO “CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1, HDMI2,
Component (D-Sub 15 Pin)”
“CVBS, HDMI1, HDMI2,
Component (D-Sub 15 Pin)”
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo Mini Jack RCA(L/R) , Stereo Mini Jack
OUTPUT
RGB DVI-D(Loop-out) DVI-D(Loop-out) DVI-D(Loop-out) N/A N/A
VIDEO N/A N/A N/A N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
Power Out 5V 5V 5V 5V 5V
EXTERNAL CONTROL RS232C(in/out), RJ45 RS232C(in/out), RJ45 RS232C(in/out), RJ45 RJ45, RS232C(in/out) RJ45, RS232C(in/out)
EXTERNAL SENSOR Stero mini jack(IR in/out) Stero mini jack(IR in/out) Stero mini jack(IR in/out) N/A N/A
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 220 1 281/388.3 1 950/1114
Sleep Mode less than 2W less than 2W less than 2W less than 1W less than 1W
Off Mode less than 1W less than 1W less than 1W less than 1W less than 1W
Dimensions
Dimension (mm)
Display 932 X 548 X 130 1068 X 624 X 130 1263.8 x 741.7 x 136.3 1668 x 990 x 138 1915 x 1126 x 139
Packaging 1042.0 x 668.0 x 295 1190.0 x 755.0 x 315 1690 x 450 x 1060 1850 x 1231 x 630 2095 x 1488 x 618
Weight (kg)
Display 17.0 21.2 35.5 83 120
Packaging 22.0 25.7 42.0 104 160
VESA Mount 600 x 400mm 600 x 400mm 600 x 400 mm 800 x 400 mm 1400 x 800 mm
Bezel Width (mm) 20 20 22.5mm(top, side),30mm(bottom) 55 55
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80% 10~80% 10~80%
Features
Key Professional heavy usage Professional Heavy Usage Professional Heavy Usage Professional Heavy Usage Professional Heavy Usage
Special
Lamp Error Detection, Anti Retention,
Brightness Sensor, Temperature Sensor,
RS232C MDC, Built in Speaker (10W +
10W), Plug and Play (DDC2B, DDC/CI),
PIP/PBP, Video Wall(10x10), Pivot Dis-
play, Button Lock, Digital Daisy Chain
“Lamp Error Detection,Brightness Sensor, Anti
Retention, Temperature Sensor, RS232C/RJ45
MDC,Built in Speaker (10W + 10W),Plug and
Play (DDC2B), PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Digital Daisy Chain,
Smart Scheduling, Smart F/W update”
“Lamp Error Detection,Brightness Sensor, Anti
Retention, Temperature Sensor, RS232C/RJ45
MDC,Built in Speaker (10W + 10W),Plug and
Play (DDC2B), PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Digital Daisy Chain,
Smart Scheduling, Smart F/W update”
Lamp Error Detection, Anti Retention,
Temperature Sensor, Built-In Fan Control,
RS232C/RJ45 MDC,Built in Speaker (15W
+ 15W),Plug and Play (DDC2B), PIP/PBP,
Pivot Display, Button Lock, Smart Schedul-
ing, Smart F/W update
Lamp Error Detection, Anti Retention,
Temperature Sensor, Built-In Fan Control,
RS232C/RJ45 MDC,Built in Speaker (15W
+ 15W),Plug and Play (DDC2B), PIP/PBP,
Pivot Display, Button Lock, Smart Schedul-
ing, Smart F/W update
Accessories
Included
“Quick Setup Guide, Warranty Card, Ap-
plication CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card, Application
CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card, Application
CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD,
D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD,
D-Sub cable, Power Cord,
Remote Controller, Batteries”
Optional
Stand STN-L3255D STN-L3255D STN-L3255D In BOX In BOX
Mount WMN5770D,WMN4250D, VMN4240D WMN5770D WMN5770D WMN7070D, VMN7070D WMN7070D, VMN7070D
Specialty STN-520WE(welcome Board) STN-520WE(welcome Board) STN-520WE(welcome Board) N/A N/A
Media Player Optional SBB-SIM type Optional SBB-SIM type Optional SBB-SIM type SBB-A(Optional) SBB-A(Optional)
UX Series Displays
400UX-3, 400UXn-3, 460UX-3 and 460UXn-3
Available in 40 and 46 inch (n) models with embedded PC, the UX series of-
fers 24/7 use, narrow 11mm metal bezel for stand alone or video applications
and a bright 700cd/m2 to help ensure readability in high ambient light.
UX Series
Model 400UX-3 / 400UXn-3 460UX-3 / 460UXn-3
Display
Display Size 40” 46”
Panel Technology S-PVA(DID) S-PVA(DID)
Resolution 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) 700 cd/m2 700 cd/m2
Contrast Ratio 3000:1 3000:1
Viewing Angle(H/V) 178/178 178/178
Response Time(G-to-G) 8ms 8ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port
VIDEO
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack
OUTPUT
RGB DVI-D(Loop-out) DVI-D(Loop-out)
VIDEO N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack
Power Out 5V 5V
EXTERNAL CONTROL RS232C(in/out), RJ45 RS232C(in/out), RJ45
EXTERNAL SENSOR
“Stero mini jack(IR in/out), mini USB (Ext. BR/IR sensor)” “Stero mini jack(IR in/out), mini USB (Ext. BR/IR sensor)”
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 168/220 198/253
Sleep Mode less than 2W less than 2W
Off Mode less than 1W less than 1W
Dimensions
Dimension (mm)
Display 914 X 526 X 118 1049 X 603 X 118
Packaging 1016 x 625 x 270 1145 X 720 X 300
Weight (kg)
Display 17.5 24.5
Packaging 22.5 29.5
VESA Mount 600 x 400mm 600 x 400mm
Bezel Width (mm) 11 11
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80%
Features
Key Narrow Bezel Narrow Bezel
Special
Lamp Error Detection, Anti Retention, Temperature
Sensor, RS232C/RJ45 MDC, Built in Speaker (10W
+ 10W), Plug and Play (DDC2B), PIP/PBP, Video
Wall(10x10), Pivot Display, Button Lock, Digital Daisy
Chain, Smart Scheduling, Smart F/W update
Lamp Error Detection, Anti Retention, Temperature
Sensor, RS232C/RJ45 MDC, Built in Speaker (10W
+ 10W), Plug and Play (DDC2B), PIP/PBP, Video
Wall(10x10), Pivot Display, Button Lock, Digital
Daisy Chain, Smart Scheduling, Smart F/W update
Accessories
Included
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power Cord, Remote
Controller, Batteries, Panel Cover”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power Cord, Remote
Controller, Batteries, Panel Cover”
Optional
Stand STN-L3255D STN-L3255D
Mount N/A WMN5770D
Specialty
“STN-520WE(Welcome Board)
MID40-UX3,MID462K,MID40DS(SamsungID)
CY-EBIS(Ext.Sensor)”
“STN-520WE(Welcome Board)
MID46-UX3,MID462K,MID46DS(SamsungID)
CY-EBIS(Ext.Sensor)”
Media Player
400UXn-3 has built in PC 400UXn-3 has built in PC
n series only AMD Athlon II 235 Dual (2.7Ghz)
SSD 32GB DDR3 1GB
AMD Athlon II 235 Dual (2.7Ghz)
SSD 32GB DDR3 1GB
UT Series Displays
460UT2, 460UTn-2, 460UT-B, 460UTn-B
The UT(n)-2 Series is 700cd/m2 brightness for 24/7 video application and
the UT(n)-B is 450 cd/m2 for 16/7 video wall applications both offer a 6.7mm
image to image gap for virtually seamless video walls.
UT Series
Model 460UT-2 / 460UTn-2 460UT-B / 460UTn-B
Display
Screen Size 46” 46”
Panel technology S-PVA(DID) S-PVA(DID)
Resolution 1366 × 768 1366 × 768
Brightness(Typ.) cd/m2 450 cd/m2 (Max 700 cd/m2) 450 cd/m2
Contrast Ratio 3000:1 4500:1
Viewing Angle(H/V) 178/178 178/178
Response Time(G-to-G) 8ms 8ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port
VIDEO “CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack
OUTPUT
RGB DVI-D(Loop-out) DVI-D(Loop-out)
VIDEO N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack
Power Out 5V 5V
EXTERNAL CONTROL RS232C(in/out), RJ45 RS232C(in/out), RJ45
EXTERNAL SENSOR
“Stero mini jack(IR in/out),
mini USB (Ext. BR/IR sensor)”
“Stero mini jack(IR in/out),
mini USB (Ext. BR/IR sensor)”
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 208/253 190/214.5
Sleep Mode less than 2W less than 2W
Off Mode less than 1W less than 1W
Dimensions
Dimension (mm)
Dsiplay 1025.7 x 579.8 x 130.0 1025.7 x 579.8 x 130.0
Packaging 1148.0 x 705.0 x 330.0 1148.0 x 705.0 x 330.0
Weight (kg)
Display 26.3 19.3
Packaging 31.7 24.6
VESA Mount 600 x 400mm 600 x 400mm
Bezel Width (mm) 4.3mm(U/L), 2.4mm(R/B) 4.3mm(U/L), 2.4mm(R/B)
Environment
Operating Temperature 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80%
Features
Key Super Narrow Bezel Economic Super Narrow Bezel
Special
Lamp Error Detection, Anti Retention, Temperature Sensor, RS232C/RJ45
MDC,Plug and Play (DDC2B), PIP/PBP, Video Wall(10x10), Pivot Display,
Button Lock, Digital Daisy Chain, Smart Scheduling, Smart F/W update
Lamp Error Detection, Anti Retention, Temperature Sensor, RS232C/RJ45
MDC,Plug and Play (DDC2B), PIP/PBP, Video Wall(10x10), Pivot Display,
Button Lock, Digital Daisy Chain, Smart Scheduling, Smart F/W update
Accessories
Included
“Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power
Cord, Remote Controller, Batteries, Panel Cover”
“Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power
Cord, Remote Controller, Batteries”
Optional
Stand STN-L3255D STN-L3255D
Mount WMN460UTD WMN460UTD
Specialty “STN-520WE(Welcome Board)
MID462-UT2,MID462K,MID462DS(SamsungID)
CY-EBIS(Ext.Sensor), MID462MB”
“STN-520WE(Welcome Board)
MID462-UT2,MID462K,MID462DS(SamsungID)
CY-EBIS(Ext.Sensor), MID462MB”
Media Player
460UTn-2 has built in PC 460Utn-B has built in PC
n series only AMD Athlon II 235 Dual (2.7Ghz)
SSD 32GB DDR3 1GB
AMD Athlon II 235 Dual (2.7Ghz)
SSD 32GB DDR3 1GB
MX/MP Series Displays
320MX-3, 320MXn-3, 400MX-3, 460MX-3, 650MP-2
Available in 32, 40, 46 and 65 inch, the MX/MP series are designed for 16/7
applications. The MX series offers typical brightness of 450 cd/m2 and low
glare screen surface to help ensure readability. 650MP-2 offers 500 cd/m2
brightness, with low glare screen surface.
MX/MP Series
Model 320MX-3 320MXn-3 400MX-3 460MX-3 650MP-2
Display
Display Size 32” 32” 40” 46” 65”
Panel Technology S-PVA( B-DID) S-PVA( B-DID) S-PVA( B-DID) S-PVA( B-DID) AMV3
Resolution 1366 × 768 (16:9) 1366 × 768 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9) 1920 × 1080 (16:9)
Brightness(Typ.) 450cd/m2 450cd/m2 450cd/m2 450cd/m2 500cd/m2
Contrast Ratio 3500:1 3500:1 3000:1 3000:1 5000:1
Viewing Angle(H/V) 178/178 178/178 178/178 178/178 178/178
Response Time(G-to-G) 8ms 8ms 8ms 8ms 8ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D
VIDEO
“CVBS, HDMI1,HDMI2, Component(D-
sub 15pin)”
“CVBS, HDMI1,HDMI2, Component(D-sub
15pin)”
“CVBS, HDMI1,HDMI2, Component(D-
sub 15pin)”
“CVBS, HDMI1,HDMI2, Component(D-
sub 15pin)”
CVBS, Component, BNC, HDMI
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack
OUTPUT
RGB N/A N/A N/A N/A DVI-D(Loop-out)
VIDEO N/A N/A N/A N/A BNC
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack
Power Out 5V 5V 5V 5V N/A
EXTERNAL CONTROL RJ45, RS232C(in/out) RJ45, RS232C(in/out) RJ45, RS232C(in/out) RJ45, RS232C(in/out) RS232C(in/out)
EXTERNAL SENSOR N/A N/A N/A N/A N/A
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 97/121 177/220 163/212.3 197/256.3 430/470
Sleep Mode less than 2W less than 5W less than 2W less than 2W less than 2W
Off Mode less than 1W less than 5W less than 1W less than 1W less than 1W
Dimensions
Dimension (mm)
Set 780X482X109 780X482X109 971 X 582.0 X 118.5 1102 X 658 X 125.5 1554 X 924 X 123.9
Package 890X590X256 890X590X256 1085 X 703 X 310 1220 X 780 X 310 1690 X 1060 X 450
Weight (kg)
Set 13.7 15.1 19.3 22.8 58
Package 16.7 18.1 23.8 29.8 67.4
VESA Mount 200 x 200mm 200 x 200mm 600 x 400mm 600 x 400mm 800 x 400mm
Protection Glass Optional Optional TBD TBD N/A
Stand Type Foot Stand(optional) Foot Stand(optional) Foot Stand(optional) Foot Stand(optional) Foot Stand(optional)
Media Player Option Type N/A Internal SIM (Slide in Module ) SIM (Slide in Module ) SBB-NT
Bezel Width (mm) 40 40 40 40 54
Environment
Operating Temperature 0
o
C ~ 40
o
C 10
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80% 10~80% 10~80%
Features
Key Economy and Reliability Economy and Reliability Economy and Reliability Economy and Reliability Economy and Reliability
Special
Lamp Error Detection, Anti Retention, Tem-
perature Sensor, RS232C/RJ45 MDC,Built
in Speaker(5W + 5W),Plug and Play
(DDC2B), PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Smart Schedul-
ing, Smart F/W update
Lamp Error Detection, Anti Retention, Temperature
Sensor, RS232C/RJ45 MDC,Built in Speaker (5W
+ 5W), Plug and Play (DDC2B), PIP/PBP, Video
Wall(10x10), Pivot Display, Button Lock, Smart
Scheduling, Smart F/W update, MagicInfo S/W,
Windows embedded 2009
Lamp Error Detection, Anti Retention,
Temperature Sensor, RS232C/RJ45
MDC,Built in Speaker (10W + 10W),Plug and
Play (DDC2B), PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Smart Scheduling,
Smart F/W update
Lamp Error Detection, Anti Retention, Tem-
perature Sensor, RS232C/RJ45 MDC,Built
in Speaker (10W + 10W),Plug and Play
(DDC2B), PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Smart Schedul-
ing, Smart F/W update
Lamp Error Detection, Anti Retention, Bright-
ness Sensor, Temperature Sensor, Built-In Fan
Control, RS232C MDC, Built in Speaker (15W
+ 15W), Plug and Play (DDC2B, DDC/CI), PIP/
PBP, Video Wall(5x5), Button Lock, Digital
Daisy Chain, Slide In Moduler Design
Accessories
Included
“Quick Setup Guide, Warranty Card, Ap-
plication CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card, Applica-
tion CD, D-Sub cable, Power Cord, Remote
Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card, Ap-
plication CD, D-Sub cable, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD,D-Sub cable, Power Cord,
Remote Controller, Batteries”
Optional
Stand STN-L32D STN-L32D STN-L3255D STN-L3255D STN-L65D
Mount WMTL4001D WMTL4001D WMN5770D,WMN4250D, VMN4240D WMN5770D WMN7070D
Specialty N/A N/A STN-520WE(welcome Board) STN-520WE(welcome Board) N/A
Media Player
320MXn-3 only -AMD Athlon II Dual
SSD 32GB DDR3 1GB
Optional SBB SIM Type Optional SBB SIM Type Optional SBB-NT Type
TS Series Interactive Displays
320TSn-3, 400TS-3,460TS-3, 650TS-2, 700TSn-2
Available in 32, 40, 46, 65 and 70 inch, the TS series is a range of out of the
box touch screen solutions.
TS Series
Model 320TSn-3 400TS-3 460TS-3 650TS-2
Display
DisplaySize 32” 40” 46” 65”
Panel Technology S-PVA( B-DID) S-PVA( B-DID) S-PVA( B-DID) AMV3
Resolution 1366 x 768 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080 (16:9)
Brightness(Typ.) 450cd/m2 450cd/m2 450cd/m2 500cd/m2
Contrast Ratio 3500:1 3000:1 3000:1 5000:1
Viewing Angle(H/V) 178/178 178/178 178/178 178/178
Response Time(G-to-G) 8ms 8ms 8ms 8ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D
VIDEO “CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
CVBS, HDMI
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack
OUTPUT
RGB N/A N/A N/A DVI-D(Loop-out)
VIDEO N/A N/A N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack Stereo mini Jack, Speaker Out
Power Out 5V 5V 5V N/A
EXTERNAL CONTROL
RJ45, RS232C(in/out) “RJ45, RS232C(in/out) , USB B type
(touch screen)”
“RJ45, RS232C(in/out) , USB B type
(touch screen)”
RS232C(in/out)
EXTERNAL SENSOR N/A N/A N/A N/A
Power
Power Supply
AC 100 - 240 V~ (+/- 10 %),
50/60 Hz
AC 100 - 240 V~ (+/- 10 %),
50/60 Hz
AC 100 - 240 V~ (+/- 10 %),
50/60 Hz
AC 100 - 240 V~ (+/- 10 %),
50/60 Hz
Power Consumption
Typical/ Max[W/h] 177/220 162/212.3 188/256.3 430/470
Sleep mode less than 5W less than 2W less than 2W less than 2W
Off mode less than 5W less than 1W less than 1W less than 1W
Dimensions
Dimension (mm)
Display 787 x 482 x 116 973.2 x 584.4 x 128.1 1104.2 x 658.4 x 134.3 1554 x 924 x 138
Packaging 890 x 590 x 256 1085 x 70 x 310 1220 x 780 x 310 1690 x 1060 x 450
Weight (kg)
Display 20.8 24.8 31.3 70
Packaging 23.9 29.2 36.2 80.4
VESA Mount 200 x 200mm 600 x 400mm 600 x 400mm 800 x 400mm
Stand Type Foot Stand(optional) Foot Stand(optional) Foot Stand(optional) Foot Stand(optional)
Bezel Width (mm) 40 40 40 54
Environment
Operating Temperature 10
o
C ~ 40
o
C 10
o
C ~ 40
o
C 10
o
C ~ 40
o
C 10
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80% 10~80%
Features
Key All-in-one Touchscreen All-in-one Touchscreen All-in-one Touchscreen All-in-one Touchscreen
special
Embedded Touch (IR), Lamp Error
Detection,Brightness Sensor, Anti
Retention, Temperature Sensor,
RS232C/RJ45 MDC,Built in Speaker
(5W + 5W),Plug and Play (DDC2B),
PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Smart
Scheduling,MagicInfo S/W, Smart F/W
update,Windows embedded 2009
Embedded Touch (IR), Lamp Error
Detection,Brightness Sensor, Anti
Retention, Temperature Sensor,
RS232C/RJ45 MDC,Built in
Speaker (10W + 10W),Plug and
Play (DDC2B), PIP/PBP, Video
Wall(10x10), Pivot Display, Button
Lock, Smart Scheduling, Smart
F/W update
Embedded Touch (IR), Lamp Error
Detection,Brightness Sensor, Anti
Retention, Temperature Sensor,
RS232C/RJ45 MDC,Built in
Speaker (10W + 10W),Plug and
Play (DDC2B), PIP/PBP, Video
Wall(10x10), Pivot Display, Button
Lock, Smart Scheduling, Smart
F/W update
Embedded Touch (Optical) ,Lamp
Error Detection, Anti Retention,
Brightness Sensor, Temperature
Sensor, Built-In Fan Control, RS232C
MDC, Built in Speaker (15W + 15W),
Plug and Play (DDC2B, DDC/CI),
PIP/PBP, Video Wall(5x5), Button
Lock, Digital Daisy Chain, Slide In
Moduler Design
Accessories
Included
“Quick Setup Guide, Warranty
Card, Application CD, D-Sub cable,
Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty
Card, Application CD, D-Sub cable,
Power Cord, Remote Controller,
Batteries, USB cable”
“Quick Setup Guide, Warranty Card,
Application CD, D-Sub cable, Power
Cord, Remote Controller, Batteries,
USB cable”
“Quick Setup Guide, Warranty Card,
Application CD,D-Sub cable, Power
Cord, Remote Controller, Batteries,
USB cable, touch pen”
optional
stand STN-L32D STN-L3255D STN-L3255D STN-L65D
mount WMTL4001D WMN5770D,WMN4250D, VMN4240D WMN5770D WMN7070D
specialty N/A STN-520WE(welcome Board) STN-520WE(welcome Board) N/A
Media Player
CPU Built- in AMD Athlon Dual, SSD
32GB DDR3 1GB
Optional SBB SIM Type Optional SBB SIM Type Optional SBB-NT Type
Media Players
SBB-A, SBB-SIM, and PIM (OPS) options
The new range of SBB (set back box) and SIM (slide in module) media play-
ers along with MagicInfo Premium software (rst ve licenses free)**, com-
plete the digital signage solution. SBB-A models are suited to the ME, MD,
UE, DE and UD series as well as 700 and 820DX-3 models. The SIM model
suits 40 and 46 inch in MX series and 40, 46 and 55 inch in DX series.
**Internet connection required. Data charges may apply.
Model SBB-SVDSBD SBB-NTBSB SBB-D32AV2 SBB-Q32AV4
Media Player MX, TS and DX series 650MP-2 and 650TS-2 ME, DE, UE and UD series ( MD series**) ME, DE, UE and UD series ( MD series**)
CPU AMD Athlon II Dual Athlon X2 Dual-Core AMD A4-3310M Dual-Core AMD A8-3510M Quad-Core
N/B AMD RS780 AMD RS780 Integrated Integrated
S/B AMD SB700 AMD SB700
GPU AMD RS780 (IGP) AMD RS780 (IGP) Radeon HD6480G (Integrated on APU) Radeon HD6620G (Integrated on APU)
FDM/HDD/SSD SSD 32GB SSD 32GB SSD 32GB SSD 32GB
Memory DDR3 2GB DDR2 1GB 2GB (DDR3 SO-DIMM 2GB x 1) 4GB (DDR3 SO-DIMM 2GB x 2)
Ethernet Marvell 88E8055 Gigabit LAN Marvell 88E8055 Gigabit LAN GbE Ethernet (RJ-45) GbE Ethernet (RJ-45)
Connectivity
USB 4 EA USB 2.0 (4 EA) USB 2.0 Port x 2, USB 3.0 Port x 2 USB 2.0 Port x 2, USB 3.0 Port x 2
Output
D-SUB (RGB OUT), DP(MagicInfo OUT), Stereo
mini Jack(Audio out)
D-SUB (RGB OUT), HDMI(MagicInfo OUT),
Stereo mini Jack(Audio out)
“1st: Magicinfo Out (DP Port, Up-to 1080p), 2nd:
Display Port”
“1st: Magicinfo Out (DP Port, Up-to 1080p), 2nd:
Display Port”
Others LAN RJ45, RS232C LAN RJ45, RS232C RJ-45, RS232 (D-SUB 9P) RJ-45, RS232 (D-SUB 9P)
Operating System Win7e Standard WES Win7e Standard Win7e Standard
Power
Type Internal Internal Internal Internal
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption 34W (Typical) 36W (Typical) 70W (Max) 70W (Max)
Dimensions
Dimension (mm)
Media Player 310 x 282 x 52.2 223.7 x 302 x 49.2 310.0 x 219.0 x 32.0 310.0 x 219.0 x 32.0
Packaging 441(W) x 375(D) x 149(H) 413 x 322 x 156
Weight (kg)
Media Player 2.5 2.75 1.8kg 1.8kg
Packaging 3.4kg 3.35 2.5kg 2.5kg
Operating Temperature 10
o
C~ 40
o
C 10
o
C~ 40
o
C 10
o
C~ 40
o
C 10
o
C~ 40
o
C
Humidity 10~80% 10~80% 10~80% 10~80%
Certication
Safety
UL/c-UL, CSA,TUV, NEMKO, KC, CCC UL/c-UL, CSA,TUV, NEMKO, KC, CCC UL/c-UL, CSA,TUV, NEMKO, KC, CCC UL/c-UL, CSA,TUV, NEMKO, KC, CCC
EMC
“FCC class A, CE, VCCI, KCC, BSMI, C-Tick, CCC” “FCC class A, CE, VCCI, KCC, BSMI, C-Tick, CCC” “FCC class A, CE, VCCI, KCC, BSMI, C-Tick, CCC” “FCC class A, CE, VCCI, KCC, BSMI, C-Tick, CCC”
Environment N/A N/A N/A N/A
Accessories
Included
“ User Manual, Power In/Out Cord
HDMI to DP Cable, Cable Holder”
“ User Manual, Power In/Out Cord
HDMI Cable”
“ User Manual, Power In/Out Cord
HDMI Cable”
“ User Manual, Power In/Out Cord
HDMI Cable”
SBB Series
Media Players
Touch Overlays
CY-TM32, CY-TM40, CY-TM46, CY-TM55, CY-TM65, CY-TM75TBC
Our new Touch Module Overlays are available in 32, 40, 46 and 55 inch with
6 point IR touch technology. The 65 inch Overlay uses optical technology
with dual touch and supports dual draw function**. The new TM series Touch
Overlays come with Magic IWB 2.0 Basic Whiteboard Software supporting
dual draw function included with the Overlay.
**Third party software needs to be dual draw capable to allow for dual draw
function and may need to be purchased separately.
Touch Overlays
Model CY-TM32 CY-TM40 CY-TM46 CY-TM55 CY-TM65 CY-TM75 TBC
Overlay
Product Concept Touch Overlay Touch Overlay Touch Overlay Touch Overlay Touch Overlay Touch Overlay
to Suit Series ME32B ME40A, ME40B, DE40A ME46A, ME46B, DE46A ME55A, ME55B, DE55A ME65B ME75B
Inch 32” 40” 46” 55” 65” 75”
Dimensions
“Dimension (mm)”
Overlay 752.4 x 446.3 x 32.1 939.0 x 551.0 x 32.1 1076.1 x 628.5 x 32.1 1267.0 x 735.7 x 32.1 1501.0 x 876 x 33.1 TBC
Package 842 x 535 x 102 1029 x 640 x 102 1187 x 738 x 102 1377 x 844 x 102 1640 x 1070 x 171 TBC
“Weight (kg)”
Overlay 4.2 5.6 7.1 9.3 15.9 TBC
Package 5.4 7.1 9.2 12.2 21.9 TBC
glass thickness 2.8 2.8 2.8 2.8 3.2 TBC
glass lm AG(front),PET(rear) AG(front),PET(rear) AG(front),PET(rear) AG(front),PET(rear) AG(front),PET(rear) TBC
Glass Reection rate ≤10% ≤10% ≤10% ≤10% ≤10% TBC
Glass Haze ≤15% ≤15% ≤15% ≤15% ≤15% TBC
Frame material Aluminum Extrusion Aluminum Extrusion Aluminum Extrusion Aluminum Extrusion Aluminum Extrusion TBC
Bezel Width (mm) 26.5mm 23.6mm 26.5mm 26.5mm 30.0mm TBC
Features
Touch technology IR IR IR IR Opitical(4EA cameras) TBC
Number of simultaneous touch 6 point 6 point 6 point 6 point 2 drawing for eBoard TBC
Accessories
Included
Software
Magic IWB 2.0 Basic
(eBoard S/W)
Magic IWB 2.0
Basic(eBoard S/W)
Magic IWB 2.0 Basic(eBoard
S/W)
Magic IWB 2.0 Basic(eBoard
S/W)
Magic IWB 2.0 Basic(eBoard
S/W)
TBC
Hardware N/A N/A N/A N/A
Pen tray(Including USB Hub
with 1 up 2 down), Pen
TBC
High Bright Series
OL46B, SL46B and 460DR-2
The new High brightness series includes the OL46B, IP rated all in one Out-
door Display, the SL46B display for window displays, (MID video wall capable
with MID46 stands – sold separately), and the 460DR-2 panel only solution
for third party encasements. Very bright 1500cd/m2 brightness for readability
in the most demanding applications.
High Brightness Series
Model SL46B OL46B 460DR-2
Display
Display Size 46” 46” 46”
Panel Technology S-PVA(E-DID) S-PVA(E-DID) S-PVA(E-DID)
Resolution 1920 x 1080 (16:9) 1920 x 1080 (16:9) 1920 x 1080
Brightness(Typ.) 1500 cd/m2 1500 cd/m2 1500 cd/m2
Contrast Ratio 4,000:1 4,000:1 4,000:1
Viewing Angle(H/V) 178/178 178/178 178/178
Response Time(G-to-G) 8ms 8ms 8ms
Connectivity
INPUT
RGB D-SUB, DVI-D Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port
VIDEO USB, HDMI, CVBS, Component(by D-SUB) “CVBS, HDMI1,HDMI2, Component(D-sub 15pin)” “CVBS, HDMI1,HDMI2, Component(D-sub 15pin)”
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack
OUTPUT
RGB DVI-D(Loop-out) N/A N/A
VIDEO N/A N/A N/A
AUDIO Stereo MINI Jack Stereo mini Jack Stereo mini Jack
Power Out N/A N/A N/A
EXTERNAL CONTROL RJ45, RS232C(in/out) RJ45, RS232C(in/out) RJ45, RS232C(in/out)
EXTERNAL SENSOR Attached N/A N/A
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz “AC 220V (+/- 10%), 50Hz :EU, China AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 356/440 395/592 1
Sleep mode less than 1W less than 2W less than 1W
Off mode less than 1W less than 2W less than 1W
Dimensions
Dimension (mm)
Set 1049.4 x 602.6 x 125 mm 614.2 x 1730.0 x 618.5 (TBD) 1047.4 x 632.8 x 151.5
Package 1145 x 726 x 300 mm TBD 1162.0 x 755.0 x 325.0
Weight (kg)
Set 26.8 kg TBD 24.0
Package 32.6 kg TBD 30.0
VESA Mount 600 x 400mm N/A 400 x 400
Protection Glass N/A Yes N/A
Stand Type N/A N/A N/A
Media Player Option Type Embedded, SIM (Slide in Module ) SIM (Slide in Module )
Bezel Width (mm) 11mm 19.7mm (TBD) N/A
Environment
Operating Temperature 0
o
C ~ 30
o
C (Direct Sunlight) -30
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80%
Features
Key Extremely High Brightness Extremely High Brightness, All in one for outdoor/ IP rated Extremely High Brightness
Special
Plug and Play, MagicInfo Lite, Slide in Module, Digital Daisy
Chains, Built in Speakers, Lamp Error Detection, Anti Image
Retention, Temperature Sensor, RS232C/RJ45 MDC, PIP/PBP,
Video Wall(10x10), Pivot Display, Button Lock, Smart Scheduling
Air Conditioning Guide, Lamp Error Detection, Anti
Retention, Temperature Sensor, RS232C/RJ45 MDC, Plug
and Play (DDC2B), PIP/PBP, Pivot Display, Button Lock,
Smart Scheduling, Smart F/W update
Kit type, Air Conditioning Guide, Lamp Error Detection,
Anti Retention, Temperature Sensor, RS232C/RJ45
MDC, Plug and Play (DDC2B), PIP/PBP, Pivot Display,
Button Lock, Smart Scheduling, Smart F/W update
“Internal Player
(Embedded H/W)”
Processor Cortex-A8 Single Core CPU with NEON DSP
“Main Memory Interface” Dual 32bit DDR3-667 (1333MHz)
Storage (FDM) 4GB (1.2GB Occupied by O/S)
Multimedia
“ Video Decoder
- MPEG-1/2, H.264/AVC (Dual)
- VC-1, JPEG, PNG
Audio DSP (Decoder)
- AC3 (DD), MPEG, DTS and etc.”
Accessories
Included
“Quick Setup Guide, Warranty Card,
Application CD, Power Cord,
Remote Controller, Batteries, D-Sub cable”
“Quick Setup Guide, Warranty Card,
Application CD, Power Cord,
Remote Controller, Batteries”
“Quick Setup Guide, Warranty Card,
Application CD, Power Cord,
Remote Controller, Batteries”
Media Player SBB-A (optional) SBB-A (optional) SBB-A (optional)
UD Series LED*BLU
UD46A, UD55A and now the UD22 square display
Available in 22, 46, and 55 inch, the Samsung solution for 24/7 video wall
applications. 700 candela with screen surface combined with 5.5mm image to
image gap provide a near seamless video wall solution.
UD Series
Model UD46A UD55A UD22B specs TBC
Display
Screen Size 46” 55” 21.6”
Pane Technology S-PVA(DID) S-PVA(DID) S-PVA(DID)
Resolution 1920 × 1080 1920 × 1080 960 × 960 (1:1 Aspect Ratio)
Brightness(Typ.) cd/m2 700 cd/m2 700 cd/m2 450 cd/m2
Contrast Ratio 3500:1 3500:1 4000:1
Viewing Angle(H/V) 178/178 178/178 178/178
Response Time(G-to-G) 8ms 8ms 8ms
Connectivity
INPUT
RGB Analog D-SUB, DVI-D, Display Port Analog D-SUB, DVI-D, Display Port DVI-D, Display Port
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
“CVBS, HDMI1,HDMI2,
Component(D-sub 15pin)”
HDMI
AUDIO RCA(L/R) , Stereo mini Jack RCA(L/R) , Stereo mini Jack Stereo mini Jack
OUTPUT
RGB DVI-D(Loop-out) DVI-D(Loop-out) DVI-D(Loop-out)
VIDEO N/A N/A N/A
AUDIO Stereo mini Jack Stereo mini Jack Stereo mini Jack
Power Out 5V 5V N/A
EXTERNAL CONTROL RS232C(in/out), RJ45 RS232C(in/out), RJ45 RS232C(in/out), RJ45
EXTERNAL SENSOR Attached Attached Attached
Power
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] 175/220 206/248 TBD/71.5(TBD)
Sleep Mode less than 1W less than 1W less than 1W
Off Mode less than 1W less than 1W less than 1W
Dimensions
Dimension (mm)
Display 1023.8mm x 578.4mm x 96.0mm 1215.3mm x 686.1mm x 96.0mm 393.3 x 393.3 x 79.5
Packaging 1160.0mm x 707.0mm x 295.0mm 1355.0 x 820.0 x 310.0mm 473.0 x 473.0 x 187
Weight (kg)
Display 18.0Kg 24.0kg 5.8Kg
Packaging 25.0Kg 35.0kg TBD
VESA Mount 600 x 400mm 600 x 400mm 200 x 200mm, 300 x 300mm
Stand Type N/A N/A N/A
Bezel Width (mm) 3.7mm(U/L), 1.8mm(R/B) 3.7mm(U/L), 1.8mm(R/B) 3.7mm(U/L), 1.8mm(R/B)
Environment
Operating Temperature
0
o
C ~ 40
o
C 0
o
C ~ 40
o
C 0
o
C ~ 40
o
C
Humidity 10~80% 10~80% 10~80%
Features
Key
Super Narrow Bezel/ High Brighness/
Low Glare
Super Narrow Bezel/ High Brighness/
Low Glare
Super Narrow Bezel/ High Brighness/
Low Glare
Special
Lamp Error Detection, Anti Retention, Tem-
perature Sensor, RS232C/RJ45 MDC,Plug and
Play (DDC2B), PIP/PBP, Video Wall(10x10),
Pivot Display, Button Lock, Digital Daisy Chain,
Smart Scheduling, Smart F/W update
Lamp Error Detection, Anti Retention, Tempera-
ture Sensor, RS232C/RJ45 MDC,Plug and Play
(DDC2B), PIP/PBP, Video Wall(10x10), Pivot
Display, Button Lock, Digital Daisy Chain, Smart
Scheduling, Smart F/W update
Lamp Error Detection, Anti Retention, Tempera-
ture Sensor, RS232C/RJ45 MDC,Plug and Play
(DDC2B), PIP/PBP, Video Wall(10x10), Pivot
Display, Button Lock, Digital Daisy Chain, Smart
Scheduling, Smart F/W update
Accessories
Included
“Quick Setup Guide, Warranty Card, Applica-
tion CD, D-Sub cable, Power Cord,
Remote Controller, Batteries,
Panel Cover”
“Quick Setup Guide, Warranty Card, Applica-
tion CD, D-Sub cable, Power Cord,
Remote Controller, Batteries,
Panel Cover”
“Quick Setup Guide, Warranty Card, Applica-
tion CD, Power Cord,
Remote Controller, Batteries,
Panel Cover”
optional
Stand N/A N/A N/A
Mount WMN-4655MD WMN-4655MD WMN-22UDPD
Specialty MID-UD46FS MID-UD55FS N/A
Media Player SIM Type - SBB-A (optional) SIM Type SBB-A (optional) SBB-A Type (optional)
Model NL22B
Display
Display Size 22”
Panel Technology 60Hz Transparent Display
Resolution 1680 x 1050
Brightness(Typ.) 210nit(TBD)
Contrast Ratio 500:1
Viewing Angle(H/V) 160:140
Response Time(G-to-G) 5ms
Transmittance 15%
Power
Type Internal
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Typical/ Max[W/h] (TBD)
Sleep mode less than 3W(TBD)
Off mode less than 3W(TBD)
Dimensions
Dimension (mm)
Display Case (W x H x D) 513.6 x 390.7(411.9 With Rubber Foot)
x 377.5
Package TBD
Weight (kg)
Set 12.5 Kg
Package TBD
Protection Glass Yes
Environment
Operating Temperature 0
o
C ~ 40
o
C
Humidity 10~80%
Features
Key All In one type Transparent Display Show Case
Special
“Internal Thermal Protection,
Timer, MagicInfo Premium embedded”
Accessories
Included
“Quick Setup Guide, Warranty Card,
Application CD, Power Cord,
Remote Controller, Batteries”
Internal Media Player
CPU AMD A4-3310M Dual-Core
FDM/HDD SSD 32GB
Memory 2GB (DDR3 SO-DIMM 2GB x 2)
Ethernet GbE Ethernet (RJ-45)
Connectivity
USB USB 2.0 Port x 2, USB 3.0 Port x 2
Others RJ-45
Operating System Windows 7 Professional for Embedded
NL22B Transparent LCD
Display Case series
Warranty
Samsung Electronics Australia offers a three (3) year limited
warranty for commercial LCD displays parts and labour. Terms
and conditions of warranty can be found on the Samsung
Commercial Displays Warranty Card or at www.samsung.com.au
Product support
B2B Hotline phone number: 1300 550 226
www.samsunglfd.com
Specifications and designs are subject to change without notice.
NL22B Transparent LCD Display Case series
