Nikon COOLPIX P900 Digital Camera 26499 User Manual

Reference Manual

DIGITAL CAMERA

Introduction

Table of Contents

xiv

Parts of the Camera

Preparing for Shooting

Basic Shooting and Playback Operations

Shooting Features

Functions That Can Be Set with the d (Menu) Button

Using Location Data Functions

Using the Wi-Fi (Wireless LAN) Function

Connecting the Camera to a TV, Printer, or Computer

Reference Section

Technical Notes and Index

Introduction

To get the most from this Nikon product, be sure to read “For Your Safety”

(Avi-viii), “<Important> Notes About Location Data Functions (GPS/

GLONASS)” (Axi) and “Wi-Fi (Wireless LAN Network)” (Axii), and all other

instructions thoroughly and keep them where they will be read by all who use

the camera.

• If you want to start using the camera right away, see “Preparing for

Shooting” (A9) and “Basic Shooting and Playback Operations” (A16).

Other Information

• Symbols and Conventions

• SD, SDHC, and SDXC memory cards are referred to as “memory cards” in this

manual.

• The setting at the time of purchase is referred to as the “default setting.”

• The names of menu items displayed in the camera monitor, and the names

of buttons or messages displayed on a computer monitor appear in bold.

• In this manual, images are sometimes omitted from monitor display samples

so that monitor indicators can be more clearly shown.

Read This First

Symbol Description

This icon marks cautions and information that should be read

before using the camera.

This icon marks notes and information that should be read before

using the camera.

A/E/F

These icons mark other pages containing relevant information;

E: “Reference Section”, F:“Technical Notes and Index.”

iii

Introduction

Information and Precautions

Life-Long Learning

As part of Nikon’s “Life-Long Learning” commitment to ongoing product support

and education, continually updated information is available online at the following

websites:

• For users in the U.S.A.: http://www.nikonusa.com/

• For users in Europe and Africa: http://www.europe-nikon.com/support/

• For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/

Visit these websites to keep up-to-date with the latest product information, tips,

answers to frequently asked questions (FAQs), and general advice on digital imaging

and photography. Additional information may be available from the Nikon

representative in your area. Visit the website below for contact information.

http://imaging.nikon.com/

Use Only Nikon Brand Electronic Accessories

Nikon COOLPIX cameras are designed to the highest standards and include complex

electronic circuitry. Only Nikon brand electronic accessories (including battery

chargers, batteries, AC adapters and, USB cables) certified by Nikon specifically for

use with this Nikon digital camera are engineered and proven to operate within the

operational and safety requirements of this electronic circuitry.

THE USE OF NON-NIKON ELECTRONIC ACCESSORIES COULD DAMAGE THE CAMERA

AND MAY VOID YOUR

NIKON WARRANTY.

The use of third-party rechargeable Li-ion batteries not bearing the Nikon

holographic seal could interfere with normal operation of the camera or result in the

batteries overheating, igniting, rupturing, or leaking.

For more information about Nikon brand accessories, contact a local authorized

Nikon dealer.

Before Taking Important Pictures

Before taking pictures on important occasions (such as at weddings or before taking

the camera on a trip), take a test shot to ensure that the camera is functioning

normally. Nikon will not be held liable for damages or lost profits that may result from

product malfunction.

Holographic seal: Identifies this

device as an authentic Nikon product.

Introduction

About the Manuals

• No part of the manuals included with this product may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any

language in any form, by any means, without Nikon’s prior written permission.

• Illustrations and monitor content shown in this manual may differ from the actual

product.

• Nikon reserves the right to change the specifications of the hardware and software

described in these manuals at any time and without prior notice.

• Nikon will not be held liable for any damages resulting from the use of this

product.

• While every effort was made to ensure that the information in these manuals is

accurate and complete, we would appreciate it were you to bring any errors or

omissions to the attention of the Nikon representative in your area (address

provided separately).

Notice Concerning Prohibition of Copying or Reproduction

Note that simply being in possession of material that was digitally copied or

reproduced by means of a scanner, digital camera or other device may be

punishable by law.

• Items prohibited by law from being copied or reproduced

Do not copy or reproduce paper money, coins, securities, government bonds or local

government bonds, even if such copies or reproductions are stamped “Sample.” The

copying or reproduction of paper money, coins, or securities which are circulated in a

foreign country is prohibited. Unless the prior permission of the government was

obtained, the copying or reproduction of unused postage stamps or post cards

issued by the government is prohibited.

The copying or reproduction of stamps issued by the government and of certified

documents stipulated by law is prohibited.

• Cautions on certain copies and reproductions

The government has issued cautions on copies or reproductions of securities issued

by private companies (shares, bills, checks, gift certificates, etc.), commuter passes, or

coupon tickets, except when a minimum of necessary copies are to be provided for

business use by a company. Also, do not copy or reproduce passports issued by the

government, licenses issued by public agencies and private groups, ID cards and

tickets, such as passes and meal coupons.

• Comply with copyright notices

The copying or reproduction of copyrighted creative works such as books, music,

paintings, woodcut prints, maps, drawings, movies, and photographs is governed by

national and international copyright laws. Do not use this product for the purpose of

making illegal copies or to infringe copyright laws.

Introduction

Disposing of Data Storage Devices

Please note that deleting images or formatting data storage devices such as memory

cards does not completely erase the original image data. Deleted files can

sometimes be recovered from discarded storage devices using commercially

available software, potentially resulting in the malicious use of personal image data.

Ensuring the privacy of such data is the user’s responsibility.

Before discarding a data storage device or transferring ownership to another person,

erase all data using commercial deletion software, or format the device, set Record

location data to Off in Location data options (E94), and then completely refill

it with images containing no private information (for example, images of empty sky).

Care should be taken to avoid injury or damage to property when physically

destroying data storage devices.

For the COOLPIX P900, the log data saved on the memory card is handled in the

same way as other data. To erase the log data that is obtained but not stored on the

memory card, select Create log ➝ End log ➝ Erase log.

To delete the Wi-Fi settings, select Restore default settings in the Wi-Fi options

menu (E92).

Introduction

To prevent damage to your Nikon product or injury to yourself or to others,

read the following safety precautions in their entirety before using this

equipment. Keep these safety instructions where all those who use the product

will read them.

The consequences that could result from failure to observe the precautions

listed in this section are indicated by the following symbol:

WARNINGS

Turn off in the event of malfunction

Should you notice smoke or an unusual smell coming from the camera or

Charging AC Adapter, unplug the Charging AC Adapter and remove the

battery immediately, taking care to avoid burns. Continued operation could

result in injury. After removing or disconnecting the power source, take the

equipment to a Nikon-authorized service representative for inspection.

Do not disassemble

Touching the internal parts of the camera or Charging AC Adapter could result

in injury. Repairs should be performed only by qualified technicians. Should the

camera or Charging AC Adapter break open as the result of a fall or other

accident, take the product to a Nikon-authorized service representative for

inspection, after unplugging the product and/or removing the battery.

Do not use the camera or Charging AC Adapter in the presence of

flammable gas

Do not use electronic equipment in the presence of flammable gas, as this

could result in explosion or fire.

Handle the camera strap with care

Never place the strap around the neck of an infant or child.

Keep out of reach of children

Particular care should be taken to prevent infants from putting the battery or

other small parts into their mouths.

Do not remain in contact with the camera, Charging AC Adapter,

or AC adapter for extended periods while the devices are on or in

use

Parts of the devices become hot. Leaving the devices in direct contact with the

skin for extended periods may result in low-temperature burns.

For Your Safety

This icon marks warnings, information that should be read before using

this Nikon product, to prevent possible injury.

vii

Introduction

Do not leave the product where it will be exposed to extremely

high temperatures, such as in an enclosed automobile or in direct

sunlight

Failure to observe this precaution could cause damage or fire.

Keep the sun out of the frame

Keep the sun well out of the frame when shooting backlit subjects. Sunlight

focused into the camera when the sun is in or close to the frame could cause a

fire.

Observe caution when handling the battery

The battery may leak, overheat, or explode if improperly handled. Observe the

following precautions when handling the battery for use in this product:

• Before replacing the battery, turn the product off. If you are using the

Charging AC Adapter/AC adapter, be sure it is unplugged.

• Use only the EN-EL23 Rechargeable Li-ion Battery (included). Charge the

battery by using a camera that supports battery charging. To perform this

operation, use the EH-71P/EH-71PCH/EH-73P/EH-73PCH Charging AC

Adapter (included) and UC-E21 USB Cable (included). The MH-67P Battery

Charger (available separately) is also available to charge the battery without

using a camera.

• When inserting the battery, do not attempt to insert it upside down or

backwards.

• Do not short or disassemble the battery or attempt to remove or break the

battery insulation or casing.

• Do not expose the battery to flame or to excessive heat.

• Do not immerse in or expose to water.

• Put the battery in a plastic bag, etc. in order to insulate it before transporting.

Do not transport or store with metal objects such as necklaces or hairpins.

• The battery is prone to leakage when fully discharged. To avoid damage to

the product, be sure to remove the battery when no charge remains.

• Discontinue use immediately should you notice any change in the battery,

such as discoloration or deformation.

• If liquid from the damaged battery comes in contact with clothing or skin,

rinse immediately with plenty of water.

Observe the following precautions when handling the Charging

AC Adapter

• Keep dry. Failure to observe this precaution could result in fire or electric

shock.

• Dust on or near the metal parts of the plug should be removed with a dry

cloth. Continued use could result in fire.

• Do not handle the plug or go near the Charging AC Adapter during

lightning storms. Failure to observe this precaution could result in electric

shock.

viii

Introduction

• Do not damage, modify, forcibly tug or bend the USB cable, place it under

heavy objects, or expose it to heat or flames. Should the insulation be

damaged and the wires become exposed, take it to a Nikon-authorized

service representative for inspection. Failure to observe these precautions

could result in fire or electric shock.

• Do not handle the plug or Charging AC Adapter with wet hands. Failure to

observe this precaution could result in electric shock.

• Do not use with travel converters or adapters designed to convert from one

voltage to another or with DC-to-AC inverters. Failure to observe this

precaution could damage the product or cause overheating or fire.

Use the appropriate power supply (battery, Charging AC Adapter,

AC adapter, USB cable)

Using a power supply other than those provided or sold by Nikon could result

in damage or malfunction.

Use appropriate cables

When connecting cables to the input and output jacks, use only the cables

provided or sold by Nikon for the purpose, to maintain compliance with

product regulations.

Do not touch the moving parts of the lens

Failure to observe this precaution could result in injury.

Handle moving parts with care

Be careful that your fingers or other objects are not pinched by the lens cover

or other moving parts.

Using the flash close to your subject’s eyes could cause temporary

visual impairment

The flash should be no less than 1 meter (3 ft 4 in.) from the subject.

Particular care should be observed when photographing infants.

Do not operate the flash with the flash window touching a person

or object

Failure to observe this precaution could result in burns or fire.

Avoid contact with liquid crystal

Should the monitor break, care should be taken to avoid injury caused by

broken glass and to prevent liquid crystal from the monitor touching the skin

or entering the eyes or mouth.

Follow the instructions of airline and hospital personnel

Introduction

Notices for Customers in the U.S.A.

IMPORTANT SAFETY INSTRUCTIONS -

SAVE THESE INSTRUCTIONS.

DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

CAREFULLY FOLLOW THESE INSTRUCTIONS

For connection to a supply not in the U.S.A., use an attachment plug adapter of

the proper configuration for the power outlet if needed.

The power supply unit is intended to be correctly orientated in a vertical or

floor mount position.

Federal Communications Commission (FCC) Radio Frequency

Interference Statement

This equipment has been tested

and found to comply with the

limits for a Class B digital device,

pursuant to Part 15 of the FCC

rules. These limits are designed

to provide reasonable

protection against harmful

interference in a residential installation. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

CAUTIONS

Modifications

The FCC requires the user to be notified that any changes or modifications

made to this device that are not expressly approved by Nikon Corporation may

void the user’s authority to operate the equipment.

Interface Cables

Use the interface cables sold or provided by Nikon for your equipment. Using

other interface cables may exceed the limits of Class B Part 15 of the FCC rules.

Notices

Introduction

Notice for Customers in the State of California

WARNING

Handling the cord on this product will expose you to lead, a chemical known to

the State of California to cause birth defects or other reproductive harm.

Wash hands after handling.

Nikon Inc.,

1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A.

Tel: 631-547-4200

Notice for Customers in Canada

CAN ICES-3 B / NMB-3 B

Notices for Customers in Europe

CAUTIONS

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

This symbol indicates that electrical and electronic equipment is to

be collected separately.

The following apply only to users in European countries:

• This product is designated for separate collection at an

appropriate collection point. Do not dispose of as household

waste.

• Separate collection and recycling helps conserve natural resources and

prevent negative consequences for human health and the environment

that might result from incorrect disposal.

• For more information, contact the retailer or the local authorities in charge

of waste management.

This symbol on the battery indicates that the battery is to be

collected separately.

The following apply only to users in European countries:

• All batteries, whether marked with this symbol or not, are

designated for separate collection at an appropriate collection

point. Do not dispose of as household waste.

• For more information, contact the retailer or the local authorities in charge

of waste management.

Introduction

bLocation name data of this camera

Before using the location data functions, make sure to read “USER LICENSE

AGREEMENT FOR LOCATION NAME DATA” (F22) and agree to the terms.

• The location name information (Points of Interest: POI) are as of April 2014.

The location name information will not be updated.

• Use the location name information only as a guide.

• The location name information (Points of Interest: POI) of the People’s

Republic of China (“China”) and the Republic of Korea are not provided for

the COOLPIX P900.

bNotes about record location data functions and log recording

• Use information measured by the camera as a guideline only.

This information cannot be used for navigation of an airplane, car, and

person or land survey applications.

• When Record location data in Location data options of the location

data options menu is set to On or during log recording, record location data

functions and log recording function will continue to operate even after the

camera is turned off (E40).

• An individual may be identified from still images or movies that have been

recorded with location data. Observe caution when you transfer still images

or movies recorded with location data, or log files to a third party or upload

them to a network such as the Internet where the public can view them.

Make sure to read “Disposing of Data Storage Devices” (Av).

bUsing the camera overseas

• Before taking the camera with location data functions overseas for travel,

consult your travel agency or embassy of the country you are visiting to

confirm whether there is any restriction on use.

For example, you cannot record location data logs without permission from

the government in China.

Set Record location data to Off.

• The location data may not function properly in China and on the borders

between China and neighboring countries (as of December 2014).

<Important> Notes About Location Data

Functions (GPS/GLONASS)

xii

Introduction

This product is controlled by the United States Export Administration

Regulations, and you are required to obtain permission from the United States

government if you export or re-export this product to any country to which the

United States embargoes goods. The following countries were subject to

embargo: Cuba, Iran, North Korea, Sudan, and Syria. Since the target countries

are subject to change, please contact the United States Department of

Commerce for the latest information.

Restrictions on Wireless Devices

The wireless transceiver included in this product conforms to wireless

regulations in the country of sale and is not for use in other countries (products

purchased in the EU or EFTA can be used anywhere within the EU and EFTA).

Nikon does not accept liability for use in other countries. Users who are unsure

as to the original country of sale should consult with their local Nikon service

center or Nikon-authorized service representative. This restriction applies to

wireless operation only and not to any other use of the product.

Notice for Customers in the U.S.A. and Canada

Federal Communications Commission (FCC) and Industry of Canada (IC)

Declaration of Conformity

This device complies with Part 15 of FCC Rules and Industry Canada licence-

exempt RSS standard(s). Operation is subject to the following two conditions:

(1) this device may not cause interference, and (2) this device must accept any

interference, including interference that may cause undesired operation of this

device.

FCC/IC RF Exposure Statement

This transmitter must not be co-located or operated in conjunction with any

other antenna or transmitter.

The available scientific evidence does not show that any health problems are

associated with using low power wireless devices. There is no proof, however,

that these low power wireless devices are absolutely safe. Low power wireless

devices emit low levels of radio frequency energy (RF) in the microwave range

while being used. Whereas high levels of RF can produce health effects (by

heating tissue), exposure of low-level RF that does not produce heating effects

causes no known adverse health effects. Many studies of low-level RF

exposures have not found any biological effects. Some studies have suggested

that some biological effects might occur, but such findings have not been

confirmed by additional research.

Wi-Fi (Wireless LAN Network)

xiii

Introduction

COOLPIX P900, which is equipped with a DW092 (FCC ID:EW4DW092/IC

ID:4634A-3149EC) Wireless LAN Module, has been tested and found to comply

with FCC/IC radiation exposure limits set forth for an uncontrolled environment

and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C

to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. Please refer

to the SAR test report that was uploaded to FCC website.

Declaration of Conformity (Europe)

Hereby, Nikon Corporation, declares that COOLPIX P900 is in compliance with

the essential requirements and other relevant provisions of Directive 1999/5/

EC. The declaration of conformity may be consulted at

http://imaging.nikon.com/support/pdf/DoC_P900.pdf.

Notice for Customers in Jamaica

This product contains a Type Approved Module by Jamaica: “SMA – DW092”

Precautions when Using Radio Transmissions

Always keep in mind that radio transmission or reception of data is subject to

interception by third parties. Note that Nikon is not responsible for data or

information leaks that may occur during data transfer.

Personal Information Management and Disclaimer

• User information registered and configured on the product, including

wireless LAN connection settings and other personal information, is

susceptible to alteration and loss resulting from operational error, static

electricity, accident, malfunction, repair or other handling. Always keep

separate copies of important information. Nikon is not responsible for any

direct or indirect damages or lost profits resulting from alteration or loss of

content that is not attributable to Nikon.

• Before discarding this product or transferring it to another owner, perform

Reset all in the setup menu (A57) to delete all user information registered

and configured with the product, including wireless LAN connection

settings and other personal information.

xiv

Table of Contents

Introduction ................................................................................................................ ii

Read This First ............................................................................................................................ ii

Other Information........................................................................................................................................ ii

Information and Precautions ............................................................................................................... iii

For Your Safety ......................................................................................................................... vi

WARNINGS ...................................................................................................................................................... vi

Notices......................................................................................................................................... ix

<Important> Notes About Location Data Functions (GPS/GLONASS) ................ xi

Wi-Fi (Wireless LAN Network)............................................................................................. xii

Parts of the Camera .................................................................................................. 1

The Camera Body...................................................................................................................... 1

The Monitor ................................................................................................................................ 3

Switching the Information Displayed in the Monitor (s Button).......................... 3

For Shooting ................................................................................................................................................... 4

For Playback..................................................................................................................................................... 7

Preparing for Shooting............................................................................................ 9

How to Attach the Camera Strap and Lens Cap ............................................................ 9

Insert the Battery and Memory Card ............................................................................... 10

Removing the Battery or Memory Card ...................................................................................... 10

Charge the Battery ................................................................................................................. 11

Opening and Adjusting the Angle of the Monitor ..................................................... 13

Turn the Camera On and Set the Display Language, Date, and Time ................. 14

Basic Shooting and Playback Operations....................................................... 16

Shooting with A (Auto) Mode.......................................................................................... 16

Using the Flash ........................................................................................................................................... 18

Switching Between the Monitor and Viewfinder.................................................................. 19

Using the Zoom......................................................................................................................................... 20

The Shutter-release Button................................................................................................................. 21

Recording Movies ................................................................................................................... 21

Play Back Images..................................................................................................................... 22

Delete Images .......................................................................................................................... 23

Changing the Shooting Mode ........................................................................................... 24

Functions That Can Be Set Using the Multi Selector (for Shooting)..................... 25

Table of Contents

Shooting Features................................................................................................... 26

A (Auto) Mode ....................................................................................................................... 26

Scene Mode (Shooting Suited to Scenes)...................................................................... 27

Special Effects Mode (Applying Effects When Shooting)......................................... 28

j, k, l, m Modes (Setting the Exposure for Shooting) ......................................... 30

M (User Settings) Mode ........................................................................................................ 34

Saving Settings in M Mode (Save User Settings)................................................................... 35

Flash Mode ................................................................................................................................ 36

Self-timer ................................................................................................................................... 38

Smile Timer (Shooting Smiling Faces Automatically)................................................ 39

Focus Mode............................................................................................................................... 40

Using Manual Focus ................................................................................................................................ 42

Exposure Compensation (Adjusting Brightness) ........................................................ 44

Functions That Can Be Set with the Fn (Function) Button....................................... 45

Functions That Cannot Be Used Simultaneously When Shooting........................ 46

Functions That Can Be Set with the d (Menu) Button.......................... 49

The Shooting Menu ............................................................................................................... 51

Common Options..................................................................................................................................... 51

For j, k, l, m, M modes .................................................................................................................. 51

The Movie Menu ..................................................................................................................... 54

The Playback Menu ................................................................................................................ 55

The Image Selection Screen............................................................................................................... 56

The Setup Menu ...................................................................................................................... 57

Using Location Data Functions .......................................................................... 59

Using the Wi-Fi (Wireless LAN) Function ........................................................ 60

Installing the Software on the Smart Device ................................................................ 60

Connecting the Camera to a TV, Printer, or Computer.............................. 61

xvi

Table of Contents

Reference Section .............................................................................................. E1

Hints and Notes About the Scene Mode................................................................... E3

Shooting with Easy Panorama................................................................................................. E10

Playback with Easy Panorama .................................................................................................. E12

Shooting Time-lapse Movies .................................................................................................... E13

Default Settings (Flash, Focus mode, Etc.)............................................................. E15

Focusing............................................................................................................................. E18

Using Target Finding AF .............................................................................................................. E18

Using Face Detection .................................................................................................................... E19

Using Skin Softening...................................................................................................................... E20

Subjects Not Suitable for Autofocus.................................................................................... E20

Focus Lock............................................................................................................................................ E21

The Control Range of the Shutter Speed (j, k, l, m Modes)...................... E22

Playback Zoom ................................................................................................................ E23

Thumbnail Playback/Calendar Display................................................................... E24

Viewing and Deleting Images Captured Continuously (Sequence)............. E25

Viewing Images in a Sequence ............................................................................................... E25

Deleting Images in a Sequence .............................................................................................. E26

Editing Images (Still Images) ...................................................................................... E26

Before Editing Images ................................................................................................................... E26

Quick Retouch: Enhancing Contrast and Saturation ................................................. E27

D-Lighting: Enhancing Brightness and Contrast ......................................................... E27

Skin Softening: Softening Skin Tones .................................................................................. E28

ilt

er Effects: Applying Digital Filter Effects...................................................................... E29

Small Picture: Reducing the Size of an Image ............................................................... E30

Crop: Creating a Cropped Copy ............................................................................................. E31

Recording and Playing Back Movies ........................................................................ E32

Capturing Still Images While Recording Movies ................................................. E35

Operations During Movie Playback ......................................................................... E36

Editing Movies ................................................................................................................. E37

Extracting Only the Desired Portion of a Movie............................................................ E37

Saving a Frame from a Movie as a Still Image................................................................ E38

Recording the Location Data on the Image.......................................................... E39

Recording the Log of Movement Information..................................................... E42

Ending Log to Save it on Memory Cards........................................................................... E44

Connecting to a Smart Device (Wi-Fi) ..................................................................... E45

Preselecting Images in the Camera That You Want to Transfer to a

Smart Device .................................................................................................................... E47

Connecting the Camera to a TV (Playback on a TV) ........................................... E48

xvii

Table of Contents

Connecting the Camera to a Printer (Direct Print).............................................. E49

Connecting the Camera to a Printer.................................................................................... E49

Printing Images One at a Time ................................................................................................ E50

Printing Multiple Images ............................................................................................................. E51

Using ViewNX-i (Transferring Images to a Computer) ...................................... E53

Installing ViewNX-i .......................................................................................................................... E53

Transferring Images to a Computer ..................................................................................... E53

The Shooting Menu (The Common Shooting Options).................................... E56

Image Quality ..................................................................................................................................... E56

Image Size............................................................................................................................................. E57

The Shooting Menu (j, k, l or m Mode) ........................................................... E58

Picture Control (COOLPIX Picture Control) ...................................................................... E58

Custom Picture Control (COOLPIX Custom Picture Control)................................ E62

White Balance (Adjusting Hue) ............................................................................................... E63

Metering ................................................................................................................................................ E66

Continuous Shooting .................................................................................................................... E67

ISO Sensitivity ..................................................................................................................................... E71

Exposure Bracketing....................................................................................................................... E72

AF Area Mode..................................................................................................................................... E73

Autofocus Mode............................................................................................................................... E76

Flash Exp. Comp. ............................................................................................................................. E76

Noise Reduction Filter................................................................................................................... E77

Active D-Lighting ............................................................................................................................ E77

Multiple Exposure............................................................................................................................ E78

Zoom

Mem

ory................................................................................................................................... E80

Startup Zoom Position.................................................................................................................. E81

M Exposure Preview ...................................................................................................................... E81

The Movie Menu ............................................................................................................. E82

Movie Options.................................................................................................................................... E82

Autofocus Mode............................................................................................................................... E85

Electronic VR ....................................................................................................................................... E86

Wind Noise Reduction ................................................................................................................. E86

Zoom Microphone.......................................................................................................................... E87

Frame Rate .......................................................................................................................................... E87

The Playback Menu ........................................................................................................ E88

Mark for Wi-Fi Upload .................................................................................................................. E88

Slide Show............................................................................................................................................ E89

Protect..................................................................................................................................................... E90

Rotate Image ..................................................................................................................................... E90

Sequence Display Options......................................................................................................... E91

Choose Key Picture ........................................................................................................................ E91

xviii

Table of Contents

The Wi-Fi Options Menu............................................................................................... E92

Operating the Text Input Keyboard ..................................................................................... E93

The Location Data Options Menu............................................................................. E94

Location Data Options.................................................................................................................. E94

Updating the A-GPS File .............................................................................................................. E95

Points of Interest (POI) (Recording and Displaying Location Name

Information)......................................................................................................................................... E96

Set Clock from Satellite................................................................................................................. E97

The Setup Menu .............................................................................................................. E98

Time Zone and Date ...................................................................................................................... E98

Slot Empty Release Lock ........................................................................................................... E100

Monitor Settings............................................................................................................................ E101

EVF Auto Toggle (Automatically Switching the Display to the

Viewfinder) ........................................................................................................................................ E103

Date Stamp ...................................................................................................................................... E103

Vibration Reduction ................................................................................................................... E104

AF Assist ............................................................................................................................................. E105

Digital Zoom ................................................................................................................................... E105

Assign Side Zoom Control....................................................................................................... E106

Sound Settings .............................................................................................................................. E106

Auto Off .............................................................................................................................................. E107

Format Card .................................................................................................................................... E107

Language .......................................................................................................................................... E107

Charge by Computer.................................................................................................................. E108

Toggle Av/Tv Selection ............................................................................................................. E109

Reset File Numbering ................................................................................................................ E109

Peaking ................................................................................................................................................ E110

Reset All ............................................................................................................................................. E110

Firmware Version ......................................................................................................................... E110

Error Me

ssages....

........................................................................................................... E111

File Names ....................................................................................................................... E115

Optional Accessories ................................................................................................... E116

Shooting with ML-L3 Remote Control .................................................................. E117

Principle Functions of the Controls........................................................................ E119

xix

Table of Contents

Technical Notes and Index............................................................................... F1

Caring for the Product ...................................................................................................... F2

The Camera............................................................................................................................................... F2

The Battery ................................................................................................................................................ F3

The Charging AC Adapter................................................................................................................ F4

Memory Cards......................................................................................................................................... F5

Cleaning and Storage........................................................................................................ F6

Cleaning...................................................................................................................................................... F6

Storage ........................................................................................................................................................ F6

Troubleshooting ................................................................................................................. F7

Specifications ..................................................................................................................... F16

Approved Memory Cards.............................................................................................................. F20

USER LICENSE AGREEMENT FOR LOCATION NAME DATA ................................. F22

Index...................................................................................................................................... F28

Parts of the Camera

The Camera Body

1 4 5

16 17

1413

Flash raised

1 Eyelet for camera strap

....................... 9

Power switch/power-on lamp

(charge lamp)

..........................11,

3 w (function) button

... 45,

E120

4 Mode dial

............................................16,

5 Microphone (stereo)

......... 54,

E32

6 Flash

.............................................................. 36

7 m (flash pop-up) button

.................. 36

8 Micro-USB connector

............... 11,

HDMI micro connector (Type D)

....................................................................... 61

Connector cover

..............................11,

11 N-Mark (NFC antenna)

............

E46

Power connector cover (for

optional AC adapter)

.............

E116

Shutter-release button

.........................................................17,

E120

Infrared receiver (for optional

ML-L3 Remote Control) ...... E117

Zoom control ........................................20

f : wide-angle ................... 20

g : telephoto ...................... 20

h : thumbnail playback

.....................................................E24

i : playback zoom .........E23

Self-timer lamp

...................................... 38

Red-eye reduction lamp ................37

AF-assist illuminator..........................57

17 Lens

2
Parts of the Camera
* Also referred to as the “multi selector” in this manual.
11 1312 1716 1814 15
1 3 62 4 5 10987
19 2120
1 p (snap-back zoom) button......21
2
Side zoom control
...............................20
f : wide-angle...........................20
g : telephoto ..............................20
3 Diopter adjustment control.........19
4 Positioning antenna................. E40
5 Electronic viewfinder........................19
6 Eye sensor ...............................................19
7 x (monitor) button .......................19
8 s (display) button.........................3
9
b (e movie-record) button
..........................................................21
, E32
10
Command dial
......................... 30, 32, E120, E122
11 Monitor
.................................................. 4
, 13
12 q (Wi-Fi) button
................ 60,
E45
13 c (playback) button ...................... 22
14
d (menu) button
...........................................49, 51, 54, 55, 57
15 l (delete) button .............................. 23
16
Infrared receiver (for optional
ML-L3 Remote Control) .......E117
17
k (apply selection) button
.................................50, E119, E122
18
Rotary multi selector
(multi selector)*
.................................25, E119, E121
19 Tripod socket
20 Speaker
...................................... 57,
E36
21
Battery-chamber/memory card
slot cover ................................................. 10

Parts of the Camera

The information that is displayed in the monitor during shooting and playback

changes depending on the camera’s settings and state of use.

Switching the Information Displayed in the

Monitor (s Button)

To switch the information displayed

in the monitor during shooting and

playback, press the s (display)

button.

C Histogram, Framing Grid and Virtual Horizon for Shooting

Each setting can be set using Monitor settings in the setup menu (A57).

• To display a histogram or virtual horizon in j, k, l or m shooting mode, set AF

area mode (A52) to one of the manual options.

• The histogram or virtual horizon cannot be displayed in A (auto) mode or some

scene modes.

The Monitor

For Shooting

Show information

Display the image and

the shooting information.

Movie frame

Display the range of a

movie in a frame.

Hide information

Display the image only.

For Playback

Show information

Display the image and

photo information.

Tone level information

(except movies)

Display a histogram,

tone level and shooting

information (A8).

Hide information

Display the image only.

1/250

1/250 F5.6

F5.6

25m 0s

840

1/250

1/250 F5.6

F5.6

25m 0s

840

4/132

0112. JPG

15/11/2015 15:30

15/11/2015

15:30:59


1.0

100

F5.6

1/250

4/132

Parts of the Camera

For Shooting

9999

1.0

F5.6

120

1/250

3200

1000

2021

Shooting mode....................................24

Flash mode .............................................36

Focus mode............................................40

Zoom indicator.............................20, 41

Focus indicator.....................................17

Zoom memory .....................................53

Movie options (normal

speed movies).......................................54

Movie options (HS movies)...........54

Image quality.........................................51

Image size................................................51

Easy panorama ....................27, E10

Noise reduction filter ........................52

Wind noise reduction.......................54

Vibration reduction icon ................57

Electronic VR icon...............................54

Exposure indicator .............................32

Flash exp. comp...................................52

Exposure compensation value

...44

Remaining movie recording time

...............................................E32, E33

Ready light ..............................................36

Number of exposures remaining

(still images) .......................... 16, E56

Enable release icon (when no

memory card is inserted)

........................................ 57, E100, F9

Parts of the Camera

9999

1.0

F5.6

120

1/250

3200

1000

1.0

0.7

0.3

120

2223

27 252829

43 42

Aperture value......................................30

Shutter speed........................................30

ISO sensitivity ........................................52

Charging AC adapter

connection indicator

Battery level indicator ......................16

“Date not set” indicator...... 57, F8

Date stamp .............................................57

Travel destination icon ....................57

Location data reception .................59

Log display.....................................E42

Wi-Fi communication

indicator...................................60, E45

White balance .......................................51

COOLPIX Picture Control................51

Active D-Lighting................................52

Continuous shooting

mode............................................52, E8

Backlighting (HDR)...............27, E7

Noise reduction burst/single

shot.......................................... E4, E5

Time-lapse movie.............. 27, E13

Exposure bracketing........................ 52

Hand-held/tripod .........................E3

Multiple exposure ..............................52

Self-timer indicator ............................38

Remote control ........................ E117

Smile timer..............................................39

Pet portrait auto release ...38, E8

Parts of the Camera

F5.6F5.6

1/2501/250

12 4356

99999999

10 10

0 0

F5.6F5.6

1/2501/250

99999999

10 10

0 0

F5.6F5.6

99999999

10 10

0 0

F5.6F5.61/2501/250

99999999

10 10

0 0

F5.6F5.6

99999999

10 10

0 0

F5.6F5.61/2501/250

1110

Focus area (target finding AF)

............................................... 45, 52, E18

Focus area (center/manual)

............................... 27, 28, 45, 52, E21

Focus area (face detection, pet

detection)

..........................39, 45, 52, E8, E19

Focus area (subject tracking)

............................................... 45, 52, E75

Spot metering area............................52

Center-weighted area ......................52

View/hide histograms

....................................................... 3, E101

Framing border (Moon or Bird-

watching scene mode, or snap-

back zoom)...............................21, E9

View/hide framing grid

....................................................... 3, E101

Virtual horizon

....................................3, E101, E102

Location name information

(POI information)................ 59, E41

Parts of the Camera

For Playback

15/11/2015

15:30


9999/9999

1m 0s

Demo mode

20 19 18

22 21

12 13

1234567

Protect icon............................................ 55

Sequence display (when

Individual pictures

is selected)

........................................................56,

Skin softening icon............................ 55

Filter effects icon................................. 55

D-Lighting icon ................................... 55

Quick retouch icon............................ 55

Wi-Fi upload reservation icon

...............................................................E88

Current image number/

total number of images

Movie length or elapsed playback

time

Volume indicator........................E36

Enable release icon (when no

memory card is inserted)

....................................................57, E100

Image quality........................................ 51

Image size ............................................... 51

Movie options ...................................... 54

Easy panorama indicator.......E12

Small picture icon.............................. 55

Crop icon.........................................E23

Easy panorama playback guide

............................................E12, E122

Sequence playback guide

............................................E25, E122

Movie playback guide.............E32

Time of recording .............................. 14

Date of recording............................... 14

Charging AC adapter connection

indicator

Battery level indicator ..................... 16

File number and type........... E115

Recorded location data

indicator

...........................................

E94

Location name information

(POI information)........................E41

Parts of the Camera

Tone level information display

You can check for loss of contrast detail in highlights and shadows from the

histogram that is displayed, or the flashing display for each tone level. These

provide guidelines when adjusting the image brightness with functions such

as exposure compensation.

A histogram is a graph showing the distribution of tones in the image. The

horizontal axis corresponds to pixel brightness, with dark tones to the left and

bright tones to the right. The vertical axis shows the number of pixels.

The tone level indicates the brightness level. When the tone level to check is

selected using the multi selector JK or rotating it, the area of the image that

corresponds to the selected tone level flashes.

15/11/2015

15:30:59


1.0

100

F5.6

1/250

4/132

879

Current image number/

total number of images

Histogram

Tone level

ISO sensitivity........................................ 52

COOLPIX Picture Control............... 51

Image quality/Image size.............. 51

White balance ...................................... 51

Time of recording .............................. 14

Date of recording............................... 14

File number and type........... E115

Exposure compensation value

... 44

Shooting mode ................................... 24

Shutter speed....................................... 30

Aperture value..................................... 30

Preparing for Shooting

B Lens Cap

At times when you are not shooting images, attach the lens cap to the lens to

protect it.

How to Attach the Camera Strap and Lens

Cap

Attach the strap at two places.

Preparing for Shooting

• With the battery’s positive and negative terminals oriented correctly, move

the orange battery latch (3), and fully insert the battery (4).

• Slide the memory card in until it clicks into place (5).

• Be careful not to insert the battery or memory card upside-down or

backward, as this could cause a malfunction.

B Formatting a Memory Card

The first time you insert a memory card that has been used in another device

into this camera, make sure to format it with this camera. Insert the memory

card into the camera, press the d button, and select Format card in the

setup menu (A57).

Removing the Battery or Memory Card

Turn the camera off and make sure that the power-on lamp and monitor have

turned off, and then open the battery-chamber/memory card slot cover.

• Move the battery latch to eject the battery.

• Gently push the memory card into the camera to partially eject the memory

card.

• Be careful when handling the camera, battery, and memory card

immediately after using the camera, as they may become hot.

Insert the Battery and Memory Card

Battery latch

Memory card slot

Preparing for Shooting

1 With the battery installed, connect the camera to an

electrical outlet.

If a plug adapter* is included with your camera, securely connect it to the

Charging AC Adapter. Once the two are connected, attempting to forcibly

remove the plug adapter could damage the product.

* The shape of the plug adapter varies according to the country or region in

which the camera was purchased.

This step can be omitted if the plug adapter comes permanently bonded to

the charging AC adapter.

• The power-on lamp (charge lamp) slowly flashes green to indicate that the

battery is charging.

• When charging is complete, the power-on lamp turns off. It takes about

3 hours and 40 minutes to charge a fully exhausted battery.

• The battery cannot be charged when the power-on lamp quickly flashes

green, possibly due to one of the reasons described below.

- The ambient temperature is not suited to charging.

- The USB cable or Charging AC Adapter is not properly connected.

- The battery is damaged.

2 Disconnect the charging AC adapter from the electrical

outlet and then disconnect the USB cable.

Charge the Battery

Power-on lamp (charge lamp)

Electrical

outlet

USB cable (included)

Charging

AC Adapter

Preparing for Shooting

B Notes About the USB Cable

• Do not use a USB cable other than the UC-E21. Using a USB cable other than the

UC-E21 could result in overheating, fire or electric shock.

• Make sure that the plugs are properly oriented. Do not insert or remove the plugs

at an angle when connecting or disconnecting them.

B Notes About Charging the Battery

Do not, under any circumstances, use another make or model of AC adapter other

than the EH-71P/EH-71PCH/EH-73P/EH-73PCH Charging AC Adapter, and do not use

a commercially available USB-AC adapter or a battery charger for a mobile phone.

Failure to observe this precaution could result in overheating or in damage to the

camera.

C Charging Using a Computer or Battery Charger

• You can also charge the battery by connecting the camera to a computer.

• You can use the MH-67P Battery Charger (available separately) to charge the

battery without using the camera.

Preparing for Shooting

Changing the orientation of the monitor is useful when shooting with the

camera in a high or a low position, or when taking selfies.

For normal shooting, fold the monitor against the camera body with the screen

facing out (3).

When you are not using or carrying the

camera, fold the monitor against the

camera body with the screen facing inward

to prevent scratches or contamination.

B Notes About the Monitor

When moving the monitor, do not apply excessive force and turn slowly within the

monitor’s adjustable range so that the connection will not be damaged.

Opening and Adjusting the Angle of the

Monitor

Preparing for Shooting

When the camera is turned on for the first time, the language-selection screen

and the date and time setting screen for the camera clock are displayed.

1 Press the power switch to

turn on the camera.

• The monitor turns on.

• To turn the camera off, press the

power switch again.

2 Use the multi selector

HI to select the

desired language and

press the k button.

3 Select Ye s and press the k button.

4 Select your home time

zone and press the k

button.

• Press H to display W

above the map and enable

daylight saving time. Press

I to disable it.

5 Use HI to select the date format and press the k button.

Turn the Camera On and Set the Display

Language, Date, and Time

Dansk

Deutsch

Čeština

Español

English

Български

Cancel

Language

London, Casablanca

Back

Preparing for Shooting

6 Set the date and time, and press

the k button.

• Use J K to select a field and then use HI

to set the date and time.

• Select the minute field and press the k

button to confirm the setting.

7 When the confirmation dialog is displayed, use HI to

select Ye s and press the k button.

• When settings are finished, the lens extends.

C Changing the Language or the Date and Time Setting

• You can change these settings using the Language and Time zone and date

settings in the z setup menu (A57).

• You can enable or disable daylight saving time in the z setup menu by selecting

Time zone and date followed by Time zone. Enabling day light saving time

moves the clock forward one hour, and disabling it moves the clock back one hour.

C The Clock Battery

• The camera’s clock is powered by a built-in backup battery.

The backup battery charges when the main battery is inserted into the camera or

when the camera is connected to an optional AC adapter, and it can run the clock

for several days after about 10 hours of charging.

• If the camera’s backup battery becomes exhausted, the date and time setting

screen is displayed when the camera is turned on. Set the date and time again

(A14).

15201515 11 10

Edit

mhDM Y

Date and time

Basic Shooting and Playback Operations

Basic Shooting and Playback

Operations

1 Rotate the mode dial to A.

• The camera is set to A (auto) mode and

general shooting can be performed.

• Press the s (display) button to switch

the information displayed in the monitor

during shooting and play back.

• Battery level indicator

b: The battery level is high.

B: The battery level is low.

2 Hold the camera steady.

• Keep fingers and other objects away from the lens, flash, AF-assist illuminator,

microphone, and speaker.

Shooting with A (Auto) Mode

1/250

F5.6

840

25m 0s

Battery level

indicator

Number of

exposures

remaining

Basic Shooting and Playback Operations

3 Frame the picture.

• Move the zoom control or the side zoom control to change the zoom lens

position.

• When the subject is lost at the telephoto zoom position, press the p (snap-

back zoom) button to temporarily widen the angle of view so that you can

frame the subject more easily.

4 Press the shutter-release

button halfway.

• When the subject is in focus, the

focus area or focus indicator is

displayed in green.

• When you are using digital zoom,

the camera focuses in the center

of the frame and the focus area is

not displayed.

• If the focus area or focus indicator

flashes, the camera is unable to

focus. Modify the composition

and try pressing the shutter-

release button halfway again.

5 Without lifting your finger, press

the shutter-release button the rest

of the way down.

Zoom out

Zoom in

Zoom out

p button

1/250

F5.6

Focus area

Basic Shooting and Playback Operations

B Notes About Saving Images or Movies

The indicator showing the number of exposures remaining or the indicator showing

the remaining recording time flashes while images or movies are being saved. Do

not open the battery-chamber/memory card slot cover or remove the

battery or memory card while an indicator is flashing. Doing this could result in

loss of data, or in damage to the camera or the memory card.

C The Auto Off Function

• When no operations are performed for about one minute, the monitor turns off,

the camera enters standby mode, and then the power-on lamp flashes. The

camera turns off after remaining in standby mode for about three minutes.

• To turn the monitor back on while the camera is in standby mode, perform an

operation such as pressing the power switch or shutter-release button.

C When Using a Tripod

• We recommend using a tripod to stabilize the camera in the following situations:

- When shooting in dim lighting with the flash mode set to W (off)

- When the zoom is at a telephoto position

• When using a tripod to stabilize the camera during shooting, set Vibration

reduction to Off in the setup menu (A57) to prevent potential errors caused by

this function.

Using the Flash

In situations where a flash is needed, such as in

dark locations or when the subject is backlit,

press the m (flash pop-up) button to raise the

flash.

• When not using the flash, gently push to

lower the flash until it clicks shut.

Basic Shooting and Playback Operations

Switching Between the Monitor and Viewfinder

You can use the viewfinder when bright

light under the open sky makes it difficult to

see the monitor.

• When you bring your face close to the

viewfinder, the eye sensor responds to it

and the viewfinder turns on while the

monitor turns off (default setting).

• You can also press the x button to

switch the display between the monitor

and viewfinder.

Diopter Adjustment of the Viewfinder

When the image in the viewfinder is difficult

to see, adjust by rotating the diopter

adjustment control while looking through

the viewfinder.

• Take care not to scratch your eye with

your fingertips or nails.

B Notes About Checking and Adjusting Image Colors

Use the monitor on the back of the camera because the monitor has higher color

reproducibility than the viewfinder.

Viewfinder

x button

Diopter adjustment control

Basic Shooting and Playback Operations

Using the Zoom

When you move the zoom control, the zoom lens

position changes.

• To zoom in: Move toward g

• To zoom out: Move toward f

• Rotating the zoom control all the way in either

direction adjusts the zoom quickly.

• The zoom can also be operated by moving the side

zoom control toward g or f.

The function of the side zoom control can be set in

the Assign side zoom control in the setup menu

(A57).

• A zoom indicator is displayed on the shooting

screen when the zoom control is moved.

• Digital zoom, which allows you to further magnify

the subject up to approximately 4× the maximum

optical zoom ratio, can be activated by moving and

holding the zoom control toward g when the

camera is zoomed in to the maximum optical zoom

position.

C Digital Zoom

The zoom indicator changes to blue when the digital zoom is activated, and it

changes to yellow when the zoom magnification is increased further.

• Zoom indicator is blue: Image quality is not noticeably reduced by using the

Dynamic Fine Zoom.

• Zoom indicator is yellow: There may be cases in which image quality is noticeably

reduced.

• The indicator remains blue across a wider area when the image size is smaller.

• The zoom indicator may not change to blue when using certain continuous

shooting settings or other settings.

Zoom out Zoom in

Optical

zoom

Digital

zoom

Basic Shooting and Playback Operations

Using the Snap-back Zoom

When the subject is lost at the telephoto zoom

position, press the p (snap-back zoom)

button to temporarily widen the angle of view

so that you can frame the subject more easily.

• While pressing the p button, frame the

subject inside the framing border of the

shooting screen. To widen the angle of

view further, move the zoom control

toward f while pressing the p button.

• Release the p button to return to the

original zoom position.

• Snap-back zoom is not available during

movie recording.

The Shutter-release Button

Display the shooting screen and press the b (e

movie-record) button to start recording a movie.

Press the b (e) button again to end recording.

Press halfway

To set focus and exposure (shutter speed and

aperture value), press the shutter-release button

lightly until you feel a slight resistance. Focus and

exposure remain locked while the shutter-release

button is pressed halfway.

Press all the

way

Press the shutter-release button all the way to

release the shutter and take a picture.

Do not use force when pressing the shutter-

release button, as this may result in camera shake

and blurred images. Press the button gently.

Recording Movies

840

F5.6

1/250

Framing border

Basic Shooting and Playback Operations

1 Press the c (playback)

button to enter playback

mode.

• If you press and hold down the

c button while the camera is

turned off, the camera turns on

in playback mode.

2 Use the multi selector to select

an image to display.

• Press and hold down HIJK to scroll

through the images quickly.

• Images can also be selected by rotating

the multi selector.

• Press the s button to switch between

showing and hiding the photo

information or shooting information that

is displayed in the monitor.

• To play back a recorded movie, press the

k button.

• To return to shooting mode, press the c

button or shutter-release button.

• Move the zoom control toward

g (i) in full-frame playback

mode to zoom in on an image.

• In full-frame playback mode,

move the zoom control toward

f (h) to switch to thumbnail

playback mode and display

multiple images on the screen.

Play Back Images

4/132

0112. JPG

15/11/2015 15:30

Display the previous image

Display the next image

1/132

Basic Shooting and Playback Operations

1 Press the l (delete)

button to delete the

image currently displayed

in the monitor.

2 Use the multi selector HI to

select the desired deletion

method and press the k button.

• To exit without deleting, press the d

button.

• When Erase selected images is selected,

see “The Image Selection Screen” (A56).

3 Select Yes and press the k

button.

• Deleted images cannot be recovered.

B Deleting Images Captured Continuously (Sequence)

• Images captured continuously are saved as a

sequence, and only the first image of the sequence

(the key picture) is displayed in playback mode

(default setting).

• If you press the l button while a key picture is

displayed for a sequence of images, all images in

the sequence are deleted.

• To delete individual images in a sequence, press the

k button to display them one at a time and press the l button.

C Deleting the Image Captured While in Shooting Mode

When using shooting mode, press the l button to delete the last image that was

saved.

Delete Images

All images

Erase selected images

Delete

Current image

Yes

Erase 1 image?

0004. JPG

15/11/2015 15:30

4/132

0004. JPG

Basic Shooting and Playback Operations

You can change to the following shooting modes by rotating the mode dial.

• A (Auto) mode

Used for general shooting.

• y, X, s, c (Scene) modes

Camera settings are optimized according to the scene that you select.

- y: Press the d button and select a scene. When using Scene

auto selector, the camera automatically recognizes the shooting scene

when you frame a picture, making it easier to take pictures in accordance

with the scene.

When using time-lapse movie, the camera automatically captures still

images at a specified interval to create time-lapse movies that are

approximately 10 seconds long.

- X (night landscape): Use this mode to shoot night landscapes.

- s (night portrait): Use this mode to shoot evening and night portraits that

include background scenery.

- c (landscape): Use this mode to shoot landscapes.

• u (Special effects) mode

Effects can be applied to images during shooting. Press the d button and

select an effect.

• j, k, l, m modes

Select these modes for greater control over shutter speed and aperture

value.

• M (User settings) mode

Setting combinations that are frequently used for shooting can be saved.

The saved settings can be immediately retrieved for shooting simply by

rotating the mode dial to M.

Changing the Shooting Mode

Basic Shooting and Playback Operations

When the shooting screen is displayed, you can press the multi selector H (m)

J (n) I (p) K (o) to set the functions described below.

• m Flash mode

When the flash is raised, the flash mode can be set according to shooting

conditions.

• n Self-timer/Remote control/Smile timer

The self-timer can be selected from 10 seconds or 2 seconds.

When smile timer is selected, the camera detects a smiling face and

automatically releases the shutter.

When one of the remote control options is selected, the shutter can be

released with the ML-L3 Remote Control (available separately) (E117).

• p Focus mode

According to the distance to the subject, A (autofocus), D (macro close-

up) or B (infinity) can be set. When the shooting mode is j, k, l, m or M,

u, or Sports, Fireworks show, Bird-watching or Time-lapse

movie (night sky, star trails) scene mode, E (manual focus) can be set.

• o Exposure compensation

You can adjust overall image brightness.

The functions that can be set vary depending on the shooting mode.

Functions That Can Be Set Using the Multi

Selector (for Shooting)

Shooting Features

Used for general shooting.

• The camera detects the main subject and

focuses on it (target finding AF). If a human

face is detected, the camera automatically sets

focus priority on it.

• See “Focusing” (E18) for more information.

Functions Available in A (Auto) Mode

• Flash mode (A36)

• Self-timer (A38)

• Smile timer (A39)

• Focus mode (A40)

• Exposure compensation (A44)

• Shooting menu (A51)

A (Auto) Mode

Shooting Features

When a scene is selected, camera settings are automatically optimized for the

selected scene.

The camera focuses on the area in the center of the frame. The position of the area

cannot be moved.

The camera focuses at infinity.

Use of a tripod is recommended. Set Vibration reduction to Off in the setup

menu (A57) when using a tripod to stabilize the camera during shooting.

The camera automatically captures still images at a specified interval to create

time-lapse movies that are approximately 10 seconds long.

Scene Mode (Shooting Suited to Scenes)

X Night landscape (E3)

1, 2

, s Night portrait

(E3), c Landscape (E4)

Rotate the mode dial to X, s or c and take

pictures.

y (Scene)

Press the d button to display the scene menu and select one of the

following scenes using the multi selector.

Scene auto selector (default setting)

(E4)

l Museum (E6)

b Portrait m Fireworks show (E6)

d Sports (E5)

n Black and white copy (E6)

f Party/indoor (E5)

o Backlighting (E7)

Z Beach

p Easy panorama (E10)

z Snow

O Pet portrait (E8)

h Sunset

1, 2, 3

g Moon (E9)

1, 2, 3

i Dusk/dawn

1, 2, 3

L Bird-watching (E9)

k Close-up (E5) i Time-lapse movie (E13)

3, 4

u Food (E6)

Scene auto selector

PortraitPortrait

SportsSports

Party/indoorParty/indoor

BeachBeach

SnowSnow

SunsetSunset

Shooting Features

Effects can be applied to images during shooting.

Press the d (menu) button to display the special effects menu and select an

effect using the multi selector.

Special Effects Mode (Applying Effects When

Shooting)

Type Description

Soft

(default

setting)

Softens the image by adding a slight blur to the entire

image.

Nostalgic sepia

Adds a sepia tone and reduces the contrast to simulate the

qualities of an old photograph.

High-contrast

mono.

Creates a black-and-white photograph with a clear contrast.

High key Gives the entire image a bright tone.

Low key Gives the entire image a dark tone.

Selective color

Keeps only a selected color and makes other colors black-

and-white.

High ISO

monochrome

Creates monotone (black-and-white) images by

intentionally taking pictures with high ISO sensitivity. This

setting is effective when shooting subjects in low lighting

conditions.

• The images captured may contain noise (randomly-

spaced bright pixels, spots or lines).

Special eects

Image size

Image quality

Soft

Special eects

High ISO monochromeHigh ISO monochrome

Selective colorSelective color

Low keyLow key

High keyHigh key

High-contrast mono

.High-contrast mono.

Nostalgic sepiaNostalgic sepia

igh ISO monochrome

elective color

Low key

High key

High-contrast mono.

Nostalgic sepia

Shooting Features

*Certain Movie options (A54) are not available.

• The camera focuses on the area in the center of the frame. The position of

the area cannot be moved.

• When Selective color or Cross process is

selected, rotate the command dial to select

the desired color, and press the k button

to apply the color. To change the color

selection, press the k button again.

Functions Available in Special Effects Mode

• Flash mode (A36)

• Self-timer (A38)

• Focus mode (A40)

• Exposure compensation (A44)

• Shooting menu (A51)

Cross process

Creates images with an unusual hue by converting a

positive color image into negative or negative color image

into positive.

Type Description

1/2501/250 F5.6F5.6

Save

Shooting Features

Images can be shot with greater control by

setting the shooting menu (A51) items in

addition to setting the shutter speed or aperture

value manually according to shooting conditions

and requirements.

• The focus area for autofocus differs depending

on the setting of AF area mode (A52).

• When set to Target finding AF (default setting), the camera detects the

main subject and focuses on it. If a human face is detected, the camera

automatically sets focus priority on it.

Rotate the command dial or multi selector to set the shutter speed and

aperture value.

C More Information

See “Toggle Av/Tv selection” (A58) for more information.

Modes (Setting the Exposure for

Shooting)

Exposure mode

Shutter speed

Aperture value

Programmed auto

(A32)

Automatically adjusted (flexible program is enabled by

the command dial).

Shutter-priority

auto (A32)

Adjusted by the

command dial.

Automatically adjusted.

Aperture-priority

auto (A32)

Automatically adjusted.

Adjusted by the multi

selector.

m Manual (A32)

Adjusted by the

command dial.

Adjusted by the multi

selector.

1/250

1/250 F5.6

F5.6

25m 0s

840

Multi

selector

Command

dial

Shutter speed

Aperture

value

Shooting Features

Exposure

The procedure for shooting images at the desired brightness (exposure) by

adjusting the shutter speed or aperture value is called “determine exposure.”

The sense of dynamism and amount of background defocus in images to be

shot vary depending on the combinations of shutter speed and aperture value

even if the exposure is the same.

Adjusting the Shutter Speed

Adjusting the Aperture Value

C The Control Range of the Shutter Speed

The control range of the shutter speed differs depending on the zoom position,

aperture, or ISO sensitivity setting.

C Aperture Value (F-number) and Zoom

Large apertures (expressed by small fnumbers) let more light into the camera, and

small apertures (large f-numbers) let less light.

The aperture value of this camera also changes depending on the zoom position.

Faster 1/1000 s Slower 1/30 s

Larger aperture (Small f-number)

f/2.8

Smaller aperture (Large f-number)

f/8

Shooting Features

j (Programmed auto)

Use for automatic control of the exposure by the

camera.

•

Different combinations of shutter speed and

aperture value can be selected without

changing the exposure by rotating the

command dial (“flexible program”). While

flexible program is in effect, a flexible program

mark (

) is displayed next to the mode indicator (

) in the upper left of the

monitor.

• To cancel flexible program, rotate the command dial until the flexible

program mark (A) is no longer displayed. Changing the shooting mode, or

turning off the camera, also cancels flexible program.

k (Shutter-priority auto)

Use to shoot fast-moving subjects at a fast shutter

speed, or use to emphasize the movements of a

moving subject at a slow shutter speed.

• The shutter speed can be adjusted by rotating

the command dial.

l (Aperture-priority auto)

Use to bring subjects including both the

foreground and background into focus or blur

the subject’s background intentionally.

• The aperture value can be adjusted by rotating

the multi selector.

m (Manual)

Use to control the exposure according to

shooting requirements.

• When adjusting the aperture value or shutter

speed, the degree of deviation from the

exposure value measured by the camera is

displayed in the exposure indicator of the

monitor. The degree of deviation in the

exposure indicator is displayed in EVs (–2 to +2

EV in increments of 1/3 EV).

• The shutter speed can be adjusted by rotating the command dial and the

aperture value can be adjusted by rotating the multi selector.

1/250

1/250 F5.6

F5.6

25m 0s

840

1/250

1/250 F5.6

F5.6

25m 0s

840

1/250

1/250 F5.6

F5.6

25m 0s

840

1/250

1/250 F5.6

F5.6

840

25m 0s

Exposure indicator

Shooting Features

B Notes About Shooting

• When zooming is performed after the exposure is set, exposure combinations or

aperture value may be changed.

• When the subject is too dark or too bright, it may not be possible to obtain the

appropriate exposure. In such cases, the shutter speed indicator or aperture value

indicator flashes when the shutter-release button is pressed halfway (except when

the m mode is used). Change the shutter speed setting or aperture value.

B Notes About ISO Sensitivity

When ISO sensitivity (A52) is set to Auto (default setting) or Fixed range auto,

the ISO sensitivity in m mode is fixed at ISO 100.

Functions Available in j, k, l, m Modes

• Flash mode (A36)

• Self-timer (A38)

• Smile timer (A39)

• Focus mode (A40)

• Exposure compensation (A44)

• Shooting menu (A51)

• Functions That Can Be Set Using the w (Function) Button (A45)

Shooting Features

Setting combinations that are frequently used for shooting (User settings) can

be saved in M. Shooting is possible in j (programmed auto), k (shutter-

priority auto), l (aperture-priority auto) or m (manual).

Rotate the mode dial to M to retrieve the settings

saved in Save user settings.

• Frame the subject and shoot with these

settings, or change the settings as required.

• The setting combinations that are retrieved

when the mode dial is rotated to M can be

changed as many times as you want in Save

user settings.

The following settings can be saved.

General Settings

Shooting menu

M (User Settings) Mode

• Shooting modes j, k, l, m (A30) • Focus mode (A40)

• Zoom position (A20) • Exposure compensation (A44)

• Flash mode (A36) • Fn button (A45)

• Self-timer (A38)

• Image quality (A51) • AF area mode (A52)

• Image size (A51) • Autofocus mode (A52)

• Picture Control (A51) • Flash exp. comp. (A52)

• Custom Picture Control (A51) • Noise reduction filter (A52)

• White balance (A51) • Active D-Lighting (A52)

• Metering (A52) • Multiple exposure (A52)

• Continuous (A52) • Zoom memory (A53)

• ISO sensitivity (A52) • Startup zoom position (A53)

• Exposure bracketing (A52) • M exposure preview (A53)

Shooting Features

Saving Settings in M Mode (Save User Settings)

The frequently used settings for shooting can be changed and saved in M.

1 Rotate the mode dial to one of j, k, l or m shooting

mode that you want to save in M mode.

• You can also rotate the mode dial to M to save settings (at the time of

purchase, the default setting of j shooting mode is saved).

2 Change to a frequently used combination of shooting

settings.

• See A34 for settings details.

• The flexible program (when set to j), shutter speed (when set to k or m), or

aperture value (when set to l or m) settings will also be saved.

3 Press the d (menu) button to

display the shooting menu.

4 Use the multi selector HI to

select Save user settings, and

press the k button.

• The current settings are saved.

B The Clock Battery

If the internal clock battery (A15) is exhausted, the settings saved in M will be reset.

Writing down any important setting is recommended.

C Resetting M (User Settings) Mode

If Reset user settings is selected in the shooting menu, the settings that are saved

in the user settings are restored to their default values. The shooting mode is set to

Save user settings

Noise reduction filter

Zoom memory

Active D-Lighting

Reset user settings

Multiple exposure

Shooting Features

When the flash is raised, the flash mode can be set according to shooting

conditions.

1 Press the m (flash pop-up) button

to raise the flash.

• When the flash is lowered, flash operation is

disabled and S is displayed.

2 Press the multi selector H (m).

3 Select the desired flash mode

(A37) and press the k button.

• If the setting is not applied by pressing the

k button within a few seconds, the

selection will be canceled.

B The Ready Light

While the flash is charging, q flashes. The camera

cannot shoot images.

If charging is complete, q is displayed steadily when

you press the shutter-release button halfway.

Flash Mode

Auto

1/250

1/250 F5.6

F5.6

25m 0s

840

Ready light

Shooting Features

Available Flash Modes

C The Flash Mode Setting

• The available flash modes differ depending on the shooting mode. The flash mode

setting may not be available in some shooting modes.

• When the shooting mode is j, k, l, m or M, Auto cannot be selected.

• The setting applied in the following situations is saved in the camera’s memory

even after the camera is turned off.

- When shooting mode j, k, l or m is used

- When V (auto with red-eye reduction) is selected in A (auto) mode

C Auto with Red-eye Reduction/Red-eye Reduction

The red-eye reduction lamp glows before the main flash to reduce the red-eye effect.

In addition, if the camera detects red-eye while saving an image, the affected area is

processed to reduce red-eye before the image is saved.

Note the following when shooting:

• Because the red-eye reduction lamp glows, more time than usual is required until

the shutter is released after you press the shutter-release button.

• More time than usual is required to save images.

• Red-eye reduction may not produce the desired results in some situations.

• In rare cases, red-eye reduction may be applied to areas of an image unnecessarily.

In these cases, select another flash mode and take the picture again.

Auto

The flash fires when necessary, such as in dim lighting.

• The flash mode indicator is only displayed immediately after setting in

the shooting screen.

Auto with red-eye reduction/Red-eye reduction

Reduce red-eye in portraits caused by the flash (A37).

• When Red-eye reduction is selected, the flash fires whenever a picture

is taken.

Fill flash/Standard flash

The flash fires whenever a picture is taken.

Slow sync

Suited to evening and night portraits that include background scenery. Fill

flash fires to illuminate the main subject; slow shutter speeds are used to

capture background at night or under dim lighting.

Rear-curtain sync

Fill flash fires just before the shutter closes, creating the effect of a stream

of light behind moving subjects.

Shooting Features

The camera is equipped with a self-timer that releases the shutter 10 seconds or

2 seconds after you press the shutter-release button. Set

Vibration reduction

Off

in the setup menu (

57) when using a tripod to stabilize the camera during

shooting.

1 Press the multi selector J (n).

2 Select the desired self-timer

mode, and press the k button.

• n10s (10 seconds): Use on important

occasions, such as weddings.

• n2s (2 seconds): Use to prevent camera

shake.

• Z / Z 10s (10 seconds) / Z 2s (2 seconds):

Use the ML-L3 Remote Control (available

separately) to release the shutter (E117).

• If the setting is not applied by pressing the k button within a few seconds,

the selection will be canceled.

• When the shooting mode is Pet portrait scene mode, Y (pet portrait auto

release) is displayed (E8). The self-timer cannot be used.

3 Frame the picture and press the shutter-release button

halfway.

• Focus and exposure are set.

Self-timer

Shooting Features

4 Press the shutter-release

button the rest of the way

down.

•

Countdown starts. The self-timer

lamp flashes and then glows

steadily about one second before

the shutter is released.

• When the shutter is released, the

self-timer is set to OFF.

• To stop the countdown, press

the shutter-release button again.

When the camera detects a smiling face, you can take a picture automatically

without pressing the shutter-release button.

• This function can be used when the shooting mode is A (auto), j, k, l, m

or M, or Portrait or Night portrait scene mode.

1 Press the multi selector J (n).

• Change any flash mode, exposure, or

shooting menu settings before pressing J.

2 Select a (smile timer), and press

the k button.

• If the setting is not applied by pressing the

k button within a few seconds, the

selection will be canceled.

Smile Timer (Shooting Smiling Faces

Automatically)

1/250

1/250 F5.6

F5.6

Smile timer

Shooting Features

3 Frame the picture and wait for the

subject to smile without pressing

the shutter-release button.

• Point the camera at a human face.

• If the camera detects that the face framed

by the double border is smiling, the shutter

is automatically released.

• Whenever the camera detects a smiling

face, it automatically releases the shutter.

4 End automatic shooting.

• To end automatic shooting with smile timer, return to step 1 and select OFF.

B Notes About Smile Timer

Under some shooting conditions, the camera may be unable to detect faces or

detect smiles (E19). The shutter-release button can also be used for shooting.

C When the Self-timer Lamp Flashes

When using smile timer, the self-timer lamp flashes when the camera detects a face

and flashes quickly immediately after the shutter is released.

Set the focus mode according to the distance to the subject.

1 Press the multi selector I (p).

2 Select the desired focus mode and

press the k button.

• If the setting is not applied by pressing the

k button within a few seconds, the

selection will be canceled.

Focus Mode

25m 0s

1/250

F5.6

840

Autofocus

Shooting Features

Available Focus Modes

B Notes About Shooting with the Flash

The flash may be unable to light the entire subject at distances of less than 50 cm

(1 ft 8 in.).

C Focus Mode Setting

• The setting may not be available with some shooting modes (E15).

• For shooting modes j, k, l and m, the setting is saved in the camera’s memory

even after the camera is turned off.

Autofocus

The camera automatically adjusts the focus according to the distance to the

subject. Use when the distance from the subject to the lens is 50 cm (1 ft 8

in.) or more, or 5.0 m (16 ft 5 in.) or more at the maximum telephoto zoom

position.

• The focus mode icon on the shooting screen is displayed only

immediately after the setting is made.

Macro close-up

Set when taking close-up pictures.

When the zoom ratio is set to a position where F and the zoom indicator

is displayed in green, the camera can focus on subjects as close as

approximately 10 cm (4 in.) from the lens. When the zoom is at the position

where G is displayed, the camera can focus on subjects as close as

approximately 1 cm (0.4 in.) from the lens.

Infinity

Use when shooting distant scenes through window glass or when shooting

landscapes.

The camera automatically adjusts the focus near infinity.

• The camera may not be able to focus on nearby objects.

Infinity

Use when shooting the sky and the fireworks show.

Manual focus

The focus can be adjusted on any subject at a distance from approximately

1 cm (0.4 in.) to infinity (∞) from the lens (A42). The closest distance at

which the camera can focus varies depending on the zoom position.

Shooting Features

Using Manual Focus

Available when the shooting mode is j, k, l, m or M, special effects mode, or

Sports, Fireworks show, Bird-watching or Time-lapse movie (night sky,

star trails) scene mode.

1 Press the multi

selector I (p), select

E (manual focus),

and then press the k

button.

2 Use the multi selector to adjust

the focus while checking the

enlarged view.

• An enlarged view of the center area of the

image is displayed. Press J to switch the

view between 2× and 4×.

• Rotate the multi selector clockwise to focus

on near subjects, or counterclockwise to

focus on far subjects. The focus can be

adjusted in higher detail by rotating the

multi selector slowly or rotating the

command dial.

• When K is pressed, the camera focuses on the subject in the center of the

frame with autofocus. The manual focus can be operated after the camera

focuses with autofocus.

• Focusing is assisted by highlighting areas that are in focus in white (peaking)

(A43). Press HI to adjust the peaking level.

• Press the shutter-release button halfway to confirm the composition of the

picture. Press the shutter-release button all the way to take the picture.

3 Press the k button.

• The set focus is locked.

• Press the shutter-release button all the way

to take the picture.

• To readjust the focus, press the k button to

display the screen in step 2.

Manual focus

1/250

F5.6

840

0.3

1AF

Peaking level

1/250

1/250 F5.6

F5.6

25m 0s

840

Shooting Features

C E (Manual Focus)

• The digits displayed for the gauge on the right of the monitor in step 2 serve as a

guideline for the distance to a subject that is in focus when the gauge is near the

center.

• The actual range at which the subject can be in focus varies depending on the

aperture value and zoom position. To see whether the subject is in focus, check the

image after shooting.

• Set Assign side zoom control in the setup menu (A57) to Manual focus to

focus by using the side zoom control instead of the multi selector in step 2.

C Peaking

• The range of the contrast level considered to be in focus can be changed by

adjusting the peaking level. It is effective to set the level low for high contrast

subjects, and high for low contrast subjects.

• Peaking highlights high contrast areas of the image in white. Depending on the

shooting conditions, highlighting may not work properly or areas that are not in

focus may be highlighted.

• You can disable the peaking display using Peaking in the setup menu (A57).

Shooting Features

You can adjust overall image brightness.

1 Press the multi selector K (o).

2 Select a compensation value and

press the k button.

• To brighten the image, set a positive (+)

value.

• To darken the image, set a negative (–)

value.

• The compensation value is applied, even

without pressing the k button.

C Exposure Compensation Value

• If the setting is applied in j, k or l mode, it will remain saved in the camera’s

memory even after the camera is turned off.

• When the shooting mode is Fireworks show scene mode (E6) or m (manual)

(A32), exposure compensation cannot be used.

• When the exposure compensation is set while using a flash, the compensation is

applied to both the background exposure and to the flash output.

C Using the Histogram

A histogram is a graph showing the distribution of tones in the image. Use as a guide

when using exposure compensation and shooting without the flash.

• The horizontal axis corresponds to pixel brightness, with dark tones to the left and

bright tones to the right. The vertical axis shows the number of pixels.

• Increasing exposure compensation value shifts tone distribution to the right, and

decreasing it shifts tone distribution to the left.

Exposure Compensation (Adjusting

Brightness)

+2.0

-2.0

-0.3

Exposure compensation

Histogram

Guide

Shooting Features

The following functions can be also set by pressing the w (function) button

instead of displaying the corresponding menu by pressing the d (menu)

button.

• This function can be used when the shooting mode is j, k, l, m or M.

1 Press the w (function) button when the shooting screen

is displayed.

• The U Fn button function menu or the setting items of the function

(default setting is Continuous) that was last assigned to the w (function)

button can be selected.

2 Use the multi selector to select a

menu item.

• To assign another function, select the U

Fn button function menu and press the

k button. Then, select the desired

function from the displayed menu.

3 After you finish assigning the function, press the k button

or w button.

• The camera returns to the shooting screen.

Functions That Can Be Set with the Fn

(Function) Button

Image quality (A51) Continuous (A52)

Image size (A51) ISO sensitivity (A52)

Picture Control (A51) AF area mode (A52)

White balance (A51) Vibration reduction (A57)

Metering (A52)

Single

Apply selection

Shooting Features

Some functions cannot be used with other menu settings.

Functions That Cannot Be Used

Simultaneously When Shooting

Restricted

function

Setting Description

Flash mode

Focus mode

(A40)

When B (infinity) or Q (infinity) is

selected, the flash is not available.

Continuous

(A52)

The flash is not available (except for Intvl

timer shooting).

Exposure

bracketing

(A52)

The flash is not available.

Self-timer/

Remote

control/Smile

timer

Focus mode

(A40)

When a setting other than A (autofocus) is

selected, smile timer is set to OFF.

AF area mode

(A52)

When Subject tracking is selected, the

self-timer/smile timer/remote control is not

available.

Focus mode

Smile timer

(A39)

When smile timer is selected, the focus

mode is fixed at A (autofocus).

AF area mode

(A52)

When Subject tracking is selected, E

(manual focus) is not available.

Image quality

Continuous

(A52)

When Pre-shooting cache is selected,

Image quality is fixed at Normal.

Image size

Continuous

(A52)

Image size is set as follows depending on

the continuous shooting setting:

• Pre-shooting cache:

A (image size: 1280 × 960 pixels)

• Continuous H: 120 fps:

f (image size: 640 × 480 pixels)

• Continuous H: 60 fps:

O (image size: 1920 × 1080 pixels)

•Multi-shot 16:

D (image size: 2560 × 1920 pixels)

Picture Control

AF area mode

(A52

)

When Subject tracking is selected,

Monochrome cannot be set.

Active D-Lighting

(A52)

When using Active D-Lighting, Contrast

in manual adjustment cannot be adjusted.

White balance

Picture Control

(A51)

When Monochrome is selected, White

balance is fixed at Auto (normal).

Metering

Active D-Lighting

(A52)

When Active D-Lighting is set to any

mode other than Off, Metering is reset to

Matrix.

Shooting Features

Continuous/

Exposure

bracketing

Continuous

(A52)/Exposure

bracketing

(A52)

Continuous and Exposure bracketing

are not available simultaneously.

Self-timer

(A38)/

Remote control

(E117)

• When self-timer/remote control is used,

a single image is shot even if

Continuous H, Continuous L, Pre-

shooting cache, or BSS has been set. If

Intvl timer shooting is set, shooting

finishes automatically after one image is

shot.

• Exposure bracketing is not available.

Smile timer

(A39)

• When the camera detects smiling faces

and the shutter is released, only one

image is shot. If Intvl timer shooting is

set, shooting finishes automatically after

one image is shot.

• Exposure bracketing is not available.

Picture Control

(A51)

When Monochrome is selected, Exposure

bracketing is not available.

Multiple exposure

(A52)

Not available simultaneously.

ISO sensitivity

Continuous

(A52)

When Pre-shooting cache, Multi-shot

16, Continuous H: 120 fps or

Continuous H: 60 fps is selected, ISO

sensitivity is fixed at Auto.

AF area mode

Smile timer

(A39)

The camera captures images using face

detection regardless of the applied AF area

mode option.

Focus mode

(A40

)

• When a

setting other than Subject

tracking is selected and B (infinity) is

selected as the focus mode for shooting,

the camera focuses at infinity regardless

of the applied AF area mode option.

• When set to E (manual focus), the AF

area mode cannot be set.

Picture Control

(A51)

When Monochrome is selected, Subject

tracking cannot be set.

White balance

(A51)

When Target finding AF is selected, and if

the white balance is set to Preset manual,

Incandescent, Fluorescent or Choose

color temp., or fine adjustment of white

balance is performed, the camera focuses

on a face or selects one or more of the 9

focus areas containing the subject closest

to the camera.

Restricted

function

Setting Description

Shooting Features

B Notes About Digital Zoom

• Depending on the shooting mode or the current settings, digital zoom may not be

available (E105).

• When digital zoom is in effect, selectable options for AF area mode or metering

mode are restricted.

Autofocus

mode

Smile timer

(A39)

When smile timer is selected, the autofocus

mode operates using the Single AF

setting.

Focus mode

(A40)

When the focus mode is set to B (infinity),

the autofocus mode operates using the

Single AF setting.

Active D-

Lighting

ISO sensitivity

(A52)

When

ISO sensitivity

is set to

1600

3200

6400

Active D-Lighting

is not available.

Multiple

exposure

Continuous

(A52)

Not available simultaneously.

Exposure

bracketing (

52)

Not available simultaneously.

Monitor

settings

Smile timer

(

39)

The virtual horizon is not displayed when

smile timer is selected.

AF area mode

(

52)

• The virtual horizon is not displayed when

Face priority is selected.

•

The virtual horizon is not displayed when

Subject tracking

is selected. After the

subject has been registered (during subject

tracking), the histogram is not displayed.

• The virtual horizon and histogram are

not displayed when Target finding AF

is selected.

Date stamp

Continuous

(A52)

When

Pre-shooting cache

Continuous H:

120 fps

Continuous H: 60 fps

is selected,

date and time cannot be stamped on images.

Digital zoom

Smile timer

(A39)

When smile timer is selected, digital zoom

is not available.

Continuous

(A52)

When Multi-shot 16 is selected, digital

zoom is not available.

AF area mode

(A52)

When Subject tracking is selected, digital

zoom is not available.

Zoom memory

(A53)

When Zoom memory is set to On, digital

zoom is not available.

Shutter sound

Continuous

(A52)

When Continuous H, Continuous L, Pre-

shooting cache, Continuous H: 120 fps,

Continuous H: 60 fps, BSS, or Multi-shot

16 is selected, shutter sound is disabled.

Exposure

bracketing (

52)

Shutter sound is disabled.

Restricted

function

Setting Description

Functions That Can Be Set with the d (Menu) Button

Functions That Can Be Set with

the d (Menu) Button

You can set the menus listed below by pressing the d (menu) button.

• A, y, X, s, c, u, j, k, l, m, M Shooting menu

Available by pressing the d button when the shooting screen is

displayed.

Allows you to change the settings for shooting such as the combination of

the image size and image quality.

Menu icons and options that can be set differ depending on the shooting

mode.

• c Playback menu

Available by pressing the d button when viewing images in full-frame

playback mode or thumbnail playback mode.

Allows you to edit images, play slide shows, etc.

• e Movie menu

Available by pressing the d button when the shooting screen is

displayed.

Allows you to change movie recording settings.

• q Wi-Fi options menu

Allows you to configure Wi-Fi settings for connecting the camera and a

smart device.

• z Location data options menu

Allows you to configure settings for the location data functions.

When Record location data in Location data options is set to On, the

camera starts receiving signals from the positioning satellites.

• z Setup menu

Allows you to adjust basic camera functions such as date and time, display

language, etc.

1 Press the d (menu)

button.

• The menu is displayed.

25m 0s25m 0s

1/2501/250 F5.6

F5. 6

F5.6

840

Functions That Can Be Set with the d (Menu) Button

2 Press the multi selector

• The current menu icon is

displayed in yellow.

3 Select a menu icon and

press the k button.

• The menu options become

selectable.

4 Select a menu option

and press the k

button.

• Certain menu options

cannot be set depending on

the current shooting mode

or the state of the camera.

• Items can also be selected

by rotating the multi selector.

5 Select a setting and

press the k button.

• The setting you selected is

applied.

• When you are finished using

the menu, press the d

button.

• When a menu is displayed,

you can switch to shooting mode by pressing the shutter-release button or

b (e) button.

Custom Picture Control

Image quality

Image size

White balance

Metering

Picture Control

Shooting menu

Menu icons

Set up

Vibration reduction

Date stamp

EVF auto toggle

Monitor settings

Slot empty release lock

Time zone and date

Vibration reduction

Date stamp

EVF auto toggle

Monitor settings

Slot empty release lock

Time zone and date

O

Date and time

Date

Date stamp

Functions That Can Be Set with the d (Menu) Button

Common Options

For j, k, l, m, M modes

The Shooting Menu

Enter shooting mode M d button

Option Description A

Image quality

Allows you to set the image quality (compression

ratio) of images to be saved.

• Default setting: Normal

E56

Image size

Allows you to set the image size of images to be

saved.

• Default setting: i 4608×3456

E57

Option Description A

Picture Control

(COOLPIX Picture

Control)

Allows you to change the settings for image

recording according to the shooting scene or your

preferences.

• Default setting: Standard

E58

Custom Picture

Control

(COOLPIX

Custom Picture

Control)

Allows you to customize the settings of COOLPIX

Picture Control and register them in Custom 1 or

Custom 2 of Picture Control.

E62

White balance

Allows you to adjust white balance to suit the

weather conditions or light source in order to make

the colors in images match what you see with your

eyes.

• Default setting: Auto (normal)

E63

Image quality

Image size

White balance

Metering

Picture Control

Custom Picture Control

Functions That Can Be Set with the d (Menu) Button

Metering

Allows you to set the method that the camera uses

to measure the brightness of the subject.

• Default setting: Matrix

E66

Continuous

Allows you to select single or continuous shooting.

• Default setting: Single

E67

ISO sensitivity

Allows you to control the camera’s sensitivity to light.

• Default setting: Auto

When Auto is selected, E is displayed in the

monitor while shooting if ISO sensitivity increases.

• In m (manual) mode, when set to Auto or Fixed

range auto, the ISO sensitivity is fixed at ISO 100.

E71

Exposure

bracketing

The exposure (brightness) can be changed

automatically during continuous shooting.

• Default setting: Off

E72

AF area mode

Allows you to change the method of how the

camera selects the focus area for autofocus.

• Default setting: Target finding AF

E73

Autofocus mode

Allows you to select either Single AF, which focuses

only when the shutter-release button is pressed

halfway, or Full-time AF, which continues focusing

even when the shutter-release button is not pressed

halfway.

• Default setting: Full-time AF

E76

Flash exp. comp.

Allows you to adjust the flash output.

• Default setting: 0.0

E76

Noise reduction

filter

Allows you to set the strength of the noise reduction

function that is normally performed when saving

images.

• Default setting: Normal

E77

Active D-Lighting

Allows you to prevent loss of contrast details in

highlights and shadows to make the contrasts in

images match what you see with your eyes.

• Default setting: Off

E77

Multiple

exposure

Allows you to combine two to three images and save

them as a single image.

• Default setting:

- Multiple exposure mode: Off

-Auto gain: On

E78

Save user

settings

Allows you to save the current settings in mode dial

M (A34).

Option Description A

Functions That Can Be Set with the d (Menu) Button

Reset user

settings

Allows you to reset the settings saved to mode dial

Zoom memory

When the zoom control is moved, the zoom position

(equivalent to focal length/angle of view in 35mm

[135] format) is switched to the positions that have

been selected by setting the check box to on in this

menu option.

• Default setting: Off

E80

Startup zoom

position

Allows you to set the zoom position (equivalent to

focal length/angle of view in 35mm [135] format) for

when the camera is turned on.

• Default setting: 24 mm

E81

M exposure

preview

Allows you to set whether or not to reflect the

brightness to the shooting screen when the

exposure is changed in m (manual) mode.

• Default setting: Off

E81

Option Description A

Functions That Can Be Set with the d (Menu) Button

The Movie Menu

Enter shooting mode M d button M e menu icon M k button

Option Description A

Movie options

Select the movie type.

Select normal speed to record movies at normal

speed, or HS (high speed) to record movies that play

in slow or fast motion.

•

Default setting:

1080/30p

1080/25p

E82

Autofocus mode

Select either Single AF, which locks focus when

movie recording begins, or Full-time AF, which

continues focusing during movie recording.

• Default setting: Single AF

E85

Electronic VR

Set whether or not to perform electronic VR when

recording movies.

• Default setting: On

E86

Wind noise

reduction

Set whether or not to reduce wind noise during

movie recording.

• Default setting: Off

E86

Zoom

microphone

In accordance with the angle of view, the camera

records sounds over a wide area at the wide-angle

zoom position, and records sounds in the limited

area at the telephoto zoom position.

• Default setting: On

E87

Frame rate Select the frame rate used when recording movies. E87

Frame rate

Zoom microphone

Wind noise reduction

Electronic VR

Autofocus mode

Movie options

Functions That Can Be Set with the d (Menu) Button

The Playback Menu

Press the c button (playback mode) M d button

Option Description A

Mark for Wi-Fi

upload

Allows you to select images in the camera that you

want to transfer to a smart device in advance before

transferring them.

E88

Quick retouch

Allows you to create retouched copies in which

contrast and saturation have been enhanced.

E27

D-Lighting

Allows you to create copies with enhanced

brightness and contrast, brightening dark portions

of an image.

E27

Skin softening

Detects faces in images and allows you to create a

copy with softer facial skin tones.

E28

Filter effects

Allows you to apply a variety of effects using digital

filters.

E29

Slide show

Allows you to view images in an automated slide

show.

E89

Protect

Allows you to protect selected images and movies

from accidental deletion.

E90

Rotate image

Allows you to rotate the displayed image to portrait

or landscape orientation.

E90

Small picture

Allows you to create a reduced-size copy of images. E30

Quick retouch

Skin softening

Filter eﬀects

Slide show

Mark for Wi-Fi upload

D-Lighting

Functions That Can Be Set with the d (Menu) Button

Select an image on the image selection screen. See “The Image Selection Screen”

(A56) for more information.

Edited images are saved as separate files. Some images may not be edited.

The Image Selection Screen

When an image selection screen such as the one

shown on the right is displayed while operating

the camera, follow the procedures described

below to select the images.

1 Use the multi selector JK or

rotate it to select the desired image.

• Move the zoom control (A1) toward g (i)

to switch to full-frame playback, or f (h) to

switch to thumbnail playback.

• Only one image can be selected for Rotate

image and Choose key picture.

Proceed to step 3.

2 Use HI to select ON or OFF.

• When ON is selected, an icon is displayed

under the selected image. Repeat steps 1

and 2 to select additional images.

3 Press the k button to apply the image selection.

• When a confirmation dialog is displayed, follow the on-screen instructions to

operate.

Sequence display

options

Allows you to select whether to display only the key

picture for a sequence of images captured

continuously or to display the sequence as

individual images.

• When only the key picture is displayed for a

sequence, press the k button to display each

image in the sequence. Press the multi selector

H to return to the key picture display.

E91

Choose key


Allows you to change the key picture for images

captured in sequence.

E91

Option Description A

Erase selected images

Back

Erase selected images

Back

Erase selected images

Functions That Can Be Set with the d (Menu) Button

The Setup Menu

Press the d button M z menu icon M k button

Option Description A

Time zone and date Allows you to set the camera clock. E98

Slot empty release

lock

Allows you to set the operation of the shutter

button when the memory card is not inserted in

the camera.

E100

Monitor settings

Allows you to adjust post-shooting image review,

monitor brightness, and photo information display

settings.

E101

EVF auto toggle

Allows you to set whether or not to automatically

switch the display to the viewfinder when you

bring your face close to the viewfinder.

E103

Date stamp

Allows you to imprint the shooting date and time

on images.

E103

Vibration reduction

Allows you to select the vibration reduction

setting used when shooting.

E104

AF assist

Allows you to enable or disable the AF-assist

illuminator.

E105

Digital zoom

Allows you to set whether or not to use digital

zoom.

E105

Assign side zoom

control

Allows you to select the function to be performed

during shooting when the side zoom control is

moved.

E106

Sound settings Allows you to adjust sound settings.

E106

Auto off

Allows you to set the amount of time that passes

before the monitor turns off to save power.

E107

Vibration reduction

Date stamp

EVF auto toggle

Monitor settings

Slot empty release lock

Time zone and date

Functions That Can Be Set with the d (Menu) Button

Format card Allows you to format the memory card.

E107

Language

Allows you to change the camera’s display

language.

E107

Charge by

computer

Allows you to set whether or not the battery in the

camera is charged when the camera is connected

to a computer.

E108

Toggle Av/Tv

selection

Allows you to switch the method for setting the

flexible program, shutter speed or aperture value.

E109

Reset file

numbering

Allows you to reset the sequential numbering of

file numbers when Yes is selected.

E109

Peaking

Allows you to set whether or not to highlight areas

that are in focus in white on the image displayed

in the monitor when operating manual focus.

E110

Reset all

Allows you to reset the camera’s settings to their

default values.

E110

Firmware version View the current camera firmware version.

E110

Option Description A

Using Location Data Functions

When Record location data in Location data options of the z (location

data options) menu (E94) is set to On, the camera starts receiving signals

from the positioning satellites.

Location data reception can be checked

on the shooting screen.

• n or o: Signals are being received

from four or more satellites, or from

three satellites, and positioning is

being performed.

• z: Signals are being received, but

positioning is not possible.

• y: Signals are not received.

Recording the Shooting Location Data on the Image

• When shooting while positioning is being performed, the obtained location

data (latitude and longitude) are recorded on the images to be shot.

• The recorded location data can be checked on a map with ViewNX-i after

transferring the image to a computer (E53).

Recording the Log

• When selecting Start log in Create log in the location data options menu,

while positioning is being performed, the location data of places you visit

with the camera is recorded at the certain interval.

• After the recorded log is saved to a memory card by using Save log in the

location data options menu, view the log with software that can display log

data.

• Log data is NMEA format-compliant. However, display in all NMEA format-

compliant software or on all NMEA format-compliant cameras is not

guaranteed.

Displaying POI Information

• When Embed POI in Points of interest (POI) of the location data options

menu is set to On, the nearest location name information for the current

position is also recorded on the images to be shot.

• When Display POI of the location data

options menu is set to On, the nearest

location name information for the current

position is displayed on the shooting screen,

and the location name information recorded

on the image is displayed on the playback

screen.

F5.6

840

F5.6

1/250

F5.6

840

F5.6

1/250

Using the Wi-Fi (Wireless LAN) Function

Using the Wi-Fi (Wireless LAN)

Function

You can perform the following functions if you install the dedicated software

“Wireless Mobile Utility” on your smart device that runs on Android OS or iOS,

and connect it to the camera.

Take Photos

You can save images to a smart device by pressing the shutter-release button

of the camera or remotely releasing the camera shutter from the smart device.

• Operations cannot be performed on the camera during remote control

operation. The shooting mode is set to A (auto) mode and the focus area is

set to the center of the frame, regardless of the camera’s settings.

View Photos

Images that are saved in the camera’s memory card can be transferred and

viewed on your smart device. You can also preselect the images in the camera

that you want to transfer to your smart device.

B Notes About Security Settings

No security settings such as password are configured for the camera at the time of

purchase. We strongly recommend performing the required security settings before

using the Wi-Fi function. Use Options in the Wi-Fi options menu (A49) to perform

the security settings.

1 Use your smart device to connect to the Google Play Store,

App Store or other online apps marketplace and search for

“Wireless Mobile Utility.”

• Check the user’s manual provided with your smart device for further details.

2 Check the description and other information and install the

software.

C User’s Manual for Wireless Mobile Utility

Download the user’s manual from the website below.

• Android OS: http://nikonimglib.com/ManDL/WMAU/

• iOS: http://nikonimglib.com/ManDL/WMAU-ios/

Installing the Software on the Smart Device

To establish a connection with the camera, press the q (Wi-Fi) button on

the camera, and turn on the Wi-Fi function of the smart device, and then start

the “Wireless Mobile Utility” while Negotiating... Please wait. is displayed

on the camera.

Connecting the Camera to a TV, Printer, or Computer

Connecting the Camera to a TV,

Printer, or Computer

You can enhance your enjoyment of images and movies by connecting the

camera to a TV, printer, or computer.

• Before connecting the camera to an external device, make sure the

remaining battery level is sufficient and turn the camera off. Before

disconnecting, make sure to turn the camera off.

• If the EH-67A AC Adapter (available separately) is used, this camera can be

powered from an electrical outlet. Do not use any other make or model of

AC adapter as it may cause the camera to heat up or malfunction.

• For information about the connection methods and subsequent operations,

refer to the documentation included with the device in addition to this

document.

Open the connector

cover.

HDMI micro connector

(Type D)

Insert the plug straight.

Micro-USB connector

Connecting the Camera to a TV, Printer, or Computer

Viewing images on a TV

Images and movies captured with the camera can be viewed

on a TV.

Connection method: Connect a commercially available HDMI

cable to the TV’s HDMI input jack.

Printing images without using a computer

If you connect the camera to a PictBridge-compatible printer,

you can print images without using a computer.

Connection method: Connect the camera directly to the

printer’s USB port with the included USB cable.

Viewing images on a computer

You can transfer images and movies to a computer for

viewing.

Connection method: Connect the camera to the computer’s

USB port with the USB cable.

• Before connecting to a computer, install ViewNX-i on the

computer.

• If any USB devices that draw the power from the computer

are connected, disconnect them from the computer before

you connect the camera to it. Connecting the camera and

other USB-powered devices to the same computer

simultaneously may cause a camera malfunction or

excessive power supply from the computer, which could

damage the camera or memory card.

The Reference Section provides detailed information and hints about using the

camera.

Shooting

Hints and Notes About the Scene Mode.................................... E3

Default Settings (Flash, Focus mode, Etc.)...............................E15

Focusing ..............................................................................................E18

The Control Range of the Shutter Speed

(j, k, l, m Modes) ........................................................................E22

Playback

Playback Zoom..................................................................................E23

Thumbnail Playback/Calendar Display.....................................E24

Viewing and Deleting Images Captured Continuously

(Sequence) ..........................................................................................E25

Editing Images (Still Images) ........................................................E26

Movie

Recording and Playing Back Movies..........................................E32

Capturing Still Images While Recording Movies ...................E35

Operations During Movie Playback ...........................................E35

Editing Movies ...................................................................................E37

Location Data Functions

Recording the Location Data on the Image............................E39

Recording the Log of Movement Information.......................E42

Connection

Connecting to a Smart Device (Wi-Fi) .......................................E45

Preselecting Images in the Camera That You Want to Transfer to a

Smart Device

.........................................................................................E47

Connecting the Camera to a TV (Playback on a TV)

.......................E48

Connecting the Camera to a Printer (Direct Print) ...............E49

Using ViewNX-i (Transferring Images to a Computer)........E53

Reference Section

The Shooting Menu (The Common Shooting Options) .....E56

The Shooting Menu (j, k, l or m Mode) .............................E58

The Movie Menu ...............................................................................E82

The Playback Menu..........................................................................E88

The Wi-Fi Options Menu ................................................................E92

The Location Data Options Menu ..............................................E94

The Setup Menu................................................................................E98

Additional Information

Error Messages ............................................................................... E111

File Names........................................................................................ E115

Optional Accessories.................................................................... E116

Shooting with ML-L3 Remote Control................................... E117

Principle Functions of the Controls ........................................ E119

Reference Section

Hints and Notes About the Scene Mode

X Night landscape

• Press the d button to select u Hand-held or w Tripod in Night

landscape.

• u Hand-held (default setting):

- Press the shutter-release button all the way to capture a series of images which

are combined into a single image and saved.

- Once the shutter-release button is pressed all the way, hold the camera still

until a still image is displayed. After taking a picture, do not turn the camera off

before the monitor switches to the shooting screen.

- The angle of view (i.e., the area visible in the frame) seen in the saved image is

narrower than that seen in the monitor at the time of shooting.

- Continuous shooting may not be possible in certain shooting conditions.

• w Tripod:

- One image is captured at a slow shutter speed when the shutter-release

button is pressed all the way.

- Vibration reduction is disabled regardless of the Vibration reduction setting

in the setup menu (A57).

s Night portrait

• Press the d button to select u Hand-held or w Tripod in Night portrait.

• One image is captured at a slow shutter speed. Compared to using w

Tripod, when u Hand-held is selected, the camera sets a slightly faster

shutter speed in accordance with the shooting conditions to prevent

camera shake.

• When w Tripod is selected, vibration reduction is disabled regardless of

the Vibration reduction setting in the setup menu (A57).

• The flash always fires. Raise the flash before shooting.

Reference Section

c Landscape

• Press the d button to select Noise reduction burst or Single shot in

Landscape.

• Noise reduction burst: This enables you to shoot a sharp landscape with a

minimum of noise.

- Press the shutter-release button all the way to capture a series of images

which are combined into a single image and saved.

- Once the shutter-release button is pressed all the way, hold the camera still

until a still image is displayed. After taking a picture, do not turn the camera

off before the monitor switches to the shooting screen.

- The angle of view (i.e., the area visible in the frame) seen in the saved image is

narrower than that seen in the monitor at the time of shooting.

- Continuous shooting may not be possible in certain shooting conditions.

•Single shot (default setting): Saves images with emphasized outlines and

contrast.

- One image is captured when the shutter-release button is pressed all the way.

y M x Scene auto selector

• When you point the camera at the subject, the camera automatically recognizes

the optimum scene mode from the list below and adjusts the shooting settings

accordingly.

• Depending on shooting conditions, the camera may not select the desired

scene mode. In this case, select another shooting mode (A24).

e Portrait (for taking close-up portraits of one or two people)

Portrait (for taking portraits of large numbers of people, or images in

which the background takes up a large portion of the frame)

f Landscape

h Night portrait (for taking close-up portraits of one or two people)

Night portrait (for taking portraits of large numbers of people, or images

in which the background takes up a large portion of the frame)

Night landscape

• The camera shoots images continuously and combines and saves

them as a single image in the same way as when Hand-held in X

(night landscape) (E3) is selected.

i Close-up

j Backlighting (for taking pictures of subjects other than people)

d Backlighting (for taking portrait pictures)

d Other shooting scenes

Reference Section

y M d Sports

• While the shutter-release button is held all the way down, the camera shoots up

to about 7 images continuously at a rate of about 7 fps (when image quality is

set to Normal and image size is set to i 4608×3456).

• The frame rate for continuous shooting may become slow depending on the

current image quality setting, image size setting, the memory card used, or

shooting condition.

• Focus, exposure, and hue are fixed at the values determined with the first image

in each series.

y M f Party/indoor

• To avoid the effects of camera shake, hold the camera steady. Set Vibration

reduction to Off in the setup menu (A57) when using a tripod to stabilize the

camera during shooting.

y M k Close-up

On the screen displayed when k Close-up is selected, select Noise reduction

burst or Single shot.

•Noise reduction burst: This enables you to shoot a sharp image with a

minimum of noise.

- Press the shutter-release button all the way to capture a series of images

which are combined into a single image and saved.

- Once the shutter-release button is pressed all the way, hold the camera still

until a still image is displayed. After taking a picture, do not turn the camera

off before the monitor switches to the shooting screen.

- If the subject moves or there is a significant camera shake during continuous

shooting, the image may be distorted, overlapped, or blurred.

- The angle of view (i.e., the area visible in the frame) seen in the saved image is

narrower than that seen in the monitor at the time of shooting.

- Continuous shooting may not be possible in certain shooting conditions.

•Single shot (default setting): Saves images with emphasized outlines and

contrast.

- One image is captured when the shutter-release button is pressed all the way.

• The focus mode (A40) setting is changed to D (macro close-up) and the

camera automatically zooms to the closest position at which it can focus.

• You can move the focus area. Press the k button, use the multi selector

HIJK or rotate it to move the focus area, and press the k button to apply

the setting.

Reference Section

y M u Food

• The focus mode (A40) setting is changed to D

(macro close-up) and the camera automatically

zooms to the closest position at which it can

focus.

• You can adjust hue by using the command dial.

The hue setting is saved in the camera’s memory

even after the camera is turned off.

• You can move the focus area. Press the k

button, use the multi selector HIJK or rotate

it to move the focus area, and press the k button to apply the setting.

y M l Museum

• The camera captures a series of up to 10 images while the shutter-release

button is held all the way down, and the sharpest image in the series is

automatically selected and saved (BSS (Best Shot Selector)).

• The flash does not fire.

y M m Fireworks show

• The shutter speed is fixed at about 4 seconds.

y M n Black and white copy

• Use together with D (macro close-up) focus mode (A40) when shooting

subjects that are close to the camera.

1/250

F5.6

840

10m 0s

Reference Section

B Notes About HDR

• Use of a tripod is recommended. Set Vibration reduction in the setup menu

(A57) to Off when using a tripod to stabilize the camera.

• When the shutter-release button is pressed all the way, the camera shoots images

continuously and saves the following two images.

- A non-HDR composite image

- An HDR composite image in which the loss of details in highlights or shadows is

minimized

• If there is only enough memory to save one image, an image processed by D-

Lighting (A55) at the time of shooting, in which dark areas of the image are

corrected, is the only image saved.

• Once the shutter-release button is pressed all the way, hold the camera still until a

still image is displayed. After taking a picture, do not turn the camera off before the

monitor switches to the shooting screen.

• The angle of view (i.e., the area visible in the frame) seen in the saved image is

narrower than that seen in the monitor at the time of shooting.

• Depending on the shooting conditions, dark shadows may appear around bright

subjects and bright areas may appear around dark subjects.

y M o Backlighting

• On the screen displayed when o Backlighting is selected, select On or Off to

enable or disable the high dynamic range (HDR) function based on the type of

image you want to capture.

•Off (default setting): The flash fires to prevent the subject from being hidden in

shadow. Shoot images with the flash raised.

•

: Use when taking pictures with very bright and dark areas in the same frame.

Reference Section

B Pet Portrait Auto Release

• Press the multi selector J (n) to change the Pet portrait auto release setting.

- Y: The camera automatically releases the shutter when it detects a dog or cat

face.

- Off: The camera does not release the shutter automatically, even if a dog or cat

face is detected. Press the shutter-release button. The camera also detects

human faces when Off is selected.

• Pet portrait auto release is set to Off after 5 bursts have been taken.

• Shooting is also possible by pressing the shutter-release button, regardless of the

Pet portrait auto release setting.

B Focus Area

• When the camera detects a face, the face is

displayed inside a yellow border. When the

camera acquires focus on a face displayed inside

a double border (focus area), the double border

changes to green. If no faces are detected, the

camera focuses on the area in the center of the

frame.

• Under some shooting conditions, the pet face

may not be detected and other subjects may be displayed inside a border.

y M O Pet portrait

• When you point the camera at a dog or cat, the camera detects the pet’s face

and focuses on it. By default, the shutter is automatically released when a dog or

cat face is detected (pet portrait auto release).

• On the screen displayed when O Pet portrait is selected, select U Single or

V Continuous.

- U Single: Whenever a dog or cat face is detected, the camera captures 1

image.

- V Continuous: Whenever a dog or cat face is detected, the camera captures

3 images continuously.

1/250 F5.6

840

25m 0s25m 0s

Reference Section

y M g Moon

• You can adjust hue by using the command dial. The hue setting is saved in the

camera’s memory even after the camera is turned off.

• Adjust the brightness with exposure compensation (A44) according to

shooting conditions such as the waxing and waning of the moon and shooting

requirements.

• At the wide-angle zoom position, the framing border is displayed to indicate the

angle of view equivalent to that of 2000 mm lens (in 35mm [135] format). The

angle of view becomes equivalent to that of 2000 mm lens by pressing the k

button.

y M L Bird-watching

• On the screen displayed when L Bird-watching is selected, select U Single

or V Continuous.

• U Single: One image is shot each time the shutter-release button is pressed.

• V Continuous: While the shutter-release button is held all the way down,

images are captured continuously.

- The frame rate for continuous shooting is about 7 fps and the maximum

number of continuous shots is about 7 (when image quality is set to Normal

and image size is set to i 4608×3456).

• At the wide-angle zoom position, the framing border is displayed to indicate the

angle of view equivalent to that of 800 mm lens (in 35mm [135] format). The

angle of view becomes equivalent to that of 800 mm lens by pressing the k

button.

E10

Reference Section

Shooting with Easy Panorama

1 Select W Normal (180°) or X

Wide (360°) as the shooting

range and press the k button.

• When the camera is readied in the

horizontal position, the image size (width ×

height) is as follows.

- W Normal (180°):

4800 × 920 when moved horizontally,

1536 × 4800 when moved vertically

- X Wide (360°):

9600 × 920 when moved horizontally,

1536 × 9600 when moved vertically

2 Frame the first edge of the

panorama scene, and then press

the shutter-release button

halfway to focus.

• The zoom position is fixed at wide-angle.

• The camera focuses in the center of the

frame.

3 Press the shutter-release button

all the way, and then remove your

finger from the shutter-release

button.

• KLJI are displayed to indicate the

direction of camera movement.

Rotate the mode dial to y M d button M p Easy panorama M

k button

Wide (360°)

Normal (180°)

Easy panorama

1/2501/250 F5.6

F5.6

840

25m 0s25m 0s25m 0s

E11

Reference Section

4 Move the camera in one of the

four directions until the guide

indicator reaches the end.

• When the camera detects which direction

it is moving in, shooting begins.

• Shooting ends when the camera captures

the specified shooting range.

• Focus and exposure are locked until

shooting ends.

Example of Camera Movement

• Using your body as the axis of rotation,

move the camera slowly in an arc, in

the direction of the marking

(KLJI).

• Shooting stops if the guide does not

reach the edge within about 15

seconds (when

W Normal (180°) is

selected) or within about 30 seconds

(when

X Wide (360°) is selected)

after shooting starts.

B Notes About Easy Panorama Shooting

• The range of the image seen in the saved image is narrower than that seen in the

monitor at the time of shooting.

• If the camera is moved too quickly or shaken too much, or if the subject is too

uniform (e.g. walls or darkness), an error may occur.

• If shooting is stopped before the camera reaches the half-way point in the

panorama range, a panorama image is not saved.

• If more than half of the panorama range is captured but shooting ends before

reaching the edge of the range, the range not captured is recorded and displayed

in gray.

Guide

E12

Reference Section

Playback with Easy Panorama

Switch to playback mode (A22), display an

image captured using easy panorama in full-

frame playback mode, and then press the k

button to scroll the image in the direction that

was used when shooting.

• Rotate the multi selector to scroll forward or

backward quickly.

Playback controls are displayed in the monitor

during playback.

Use the multi selector JK to select a control,

and then press the k button to perform the

operations described below.

* These operations can also be performed by rotating the multi selector.

B Notes About Easy Panorama Images

• The images cannot be edited on this camera.

• This camera may not be able to scroll the playback of, or zoom in on, easy

panorama images captured with another make or model of digital camera.

B Notes About Printing Panorama Images

The entire image may not be able to be printed depending on the printer’s settings.

Additionally, printing may not be possible depending on the printer.

Function Icon Description

Rewind A Hold down the k button to scroll backward quickly.*

Advance B Hold down the k button to scroll forward quickly.*

Pause E

Pause playback. The operations listed below can be

performed while paused.

C Hold down the k button to rewind.*

D Hold down the k button to scroll.*

F Resume automatic scrolling.

End G Switch to full-frame playback mode.

4/4/1321324/132

0004. JPG

2014/05/15 15:30

15/11/2015 15:30

E13

Reference Section

Shooting Time-lapse Movies

The camera can automatically capture still images at a specified interval to

create time-lapse movies that are approximately 10 seconds long.

• When the Frame rate setting of the movie menu is set to 30 fps (30p/

60p), 300 images are captured and saved with e 1080/30p. When set to

25 fps (25p/50p), 250 images are captured and saved with p 1080/

25p.

The camera focuses on the area in the center of the frame.

Suited for recording the movement of stars.

Star movement appears as lines of light due to image processing.

1 Use the multi selector HI to

select a type, and press the k

button.

2 Select whether or not to fix

exposure (brightness), and press

the k button. (except Night sky

and Star trails)

• When AE-L on is selected, the exposure

used for the first image is used for all

images. When the brightness changes

drastically like at dusk, AE-L off is recommended.

Rotate the mode dial to y M d button M i Time-lapse movie

M k button

Type (scene/required shooting time)

Interval time

30 fps (30p/60p)

25 fps (25p/50p)

U Cityscape (10 minutes)

(default setting)

2 s 2.4 s

V Landscape (25 minutes)

5 s 6 s

Y Sunset (50 minutes)

10 s 12 s

X Night sky (150 minutes)

30 s 36 s

W Star trails (150 minutes)

30 s 36 s

Star trails (150 minutes)

Night sky (150 minutes)

Sunset (50 minutes)

Landscape (25 minutes)

Cityscape (10 minutes)

Time-lapse movie

AE-L o

AE-L on

Landscape (25 minutes)

E14

Reference Section

3 Stabilize the camera by using a tool such as a tripod.

4 Press the shutter-release button to

capture the first image.

• Set exposure compensation (A44) before

releasing the shutter for the first image.

Exposure compensation cannot be

changed after the first image is captured.

Focus and hue are fixed when the first

image is captured.

• The shutter is automatically released for the second and subsequent images.

• The monitor may turn off while the camera is not capturing images.

• Shooting ends automatically when 300 or 250 images are captured.

• Press the k button to end shooting before the required shooting time

elapses and create a time-lapse movie.

• Sound and still images cannot be saved.

B Notes About Time-lapse Movie

• Do not exchange the memory card until shooting is complete.

• Use a fully charged battery to prevent the camera from turning off unexpectedly.

• Time-lapse movies cannot be recorded by pressing the b (e) button.

• Do not rotate the mode dial to a different setting until shooting is complete.

• Vibration reduction is disabled regardless of the Vibration reduction setting in

the setup menu (A57).

1/250

1/250 F5.6

F5.6

25m 0s

840

E15

Reference Section

The default settings for each shooting mode are listed below.

Default Settings (Flash, Focus mode, Etc.)

Flash

mode

(A36)

Self-timer

(A38)

Focus

mode

(A40)

Exposure

compensation

(A44)

A (auto) U OFF

0.0

u (special effects) U

OFF A 0.0

j, k, l, m X OFF

A 0.0

M (user settings) X OFF

A 0.0

Scene

X (night landscape) W

OFF B

0.0

s (night portrait) V

OFF

0.0

c (landscape) W

OFF B

0.0

x (scene auto

selector)

OFF A

0.0

b (portrait) V OFF

0.0

d (sports) W

OFF

0.0

f (party/indoor) V

OFF A

0.0

Z (beach) U OFF A

0.0

z (snow) U OFF A

0.0

h (sunset) W

OFF B

0.0

i (dusk/dawn) W

OFF B

0.0

k (close-up) U

OFF D

0.0

u (food) W

OFF D

0.0

l (museum) W

OFF A

0.0

m (fireworks show) W

OFF

0.0

n (black and white

copy)

U OFF A

0.0

o (backlighting) X/W

OFF A

0.0

E16

Reference Section

Smile timer can also be selected.

E (manual focus) cannot be selected.

The flash is fixed at W (off) when High ISO monochrome is selected.

Cannot be changed.

Cannot be changed. The flash mode setting is fixed at fill flash with slow sync and

red-eye reduction.

Cannot be changed. The camera automatically selects the flash mode appropriate

for the scene it has selected.

A (autofocus) or E (manual focus) can be selected.

May switch to slow sync with red-eye reduction flash mode.

A (autofocus) or D (macro close-up) can be selected.

The flash is fixed at W (off) when using Noise reduction burst.

Q (infinity) or E (manual focus) can be selected.

When HDR is set to Off, the flash mode is fixed at X (fill flash). When HDR is set to

On, the flash mode is fixed at W (off).

Pet portrait auto release (E8) can be set to on or off. Self-timer and remote

control cannot be used.

Can be selected from A (autofocus), B (infinity) or E (manual focus).

The focus is fixed at A (autofocus) when using Cityscape (10 minutes), or

B (infinity) when using Landscape (25 minutes) or Sunset (50 minutes).

Q (infinity) or E (manual focus) can be selected when using Night sky (150

minutes) or Star trails (150 minutes).

Flash

mode

(A36)

Self-timer

(A38)

Focus

mode

(A40)

Exposure

compensation

(A44)

p (easy panorama) W

OFF

0.0

O (pet portrait) W

0.0

g (moon) W

n2s B

0.0

L (bird-watching) W

OFF A

0.0

i (time-lapse movie) W

OFF

A/B/

0.0

E17

Reference Section

C The Flash Mode Setting

The available flash modes differ depending on the shooting mode.

Availability depends on the setting. See “Default Settings (Flash, Focus mode, Etc.)”

(E15) for more information.

The flash is fixed at W (off) when High ISO monochrome is selected.

Flash mode A

y, X,

s, c

j k l m

U Auto w

w ––––

Auto with red-eye

reduction

w w – – – –

Red-eye reduction – – wwww

Fill flash w w – – – –

Standard flash – – wwww

Y Slow sync w w w – w –

Z Rear-curtain sync w w wwww

E18

Reference Section

The focus area varies depending on the shooting mode.

Using Target Finding AF

In A (auto) mode, or when AF area mode (A52) in j, k, l, m or M mode

is set to Target finding AF, the camera focuses in the manner described

below when you press the shutter-release button halfway.

• The camera detects the main subject and

focuses on it. When the subject is in focus,

the focus area is displayed in green. If a

human face is detected, the camera

automatically sets focus priority on it.

• If no main subject is detected, the camera

automatically selects one or more of the 9

focus areas containing the subject closest to

the camera. When the subject is in focus, the

focus areas that are in focus are displayed in

green.

B Notes About Target Finding AF

• Depending on shooting conditions, the subject that the camera determines to be

the main subject may vary.

• The main subject may not be detected when using certain White balance or

Picture Control settings.

• The camera may not detect the main subject appropriately in the following

situations:

- When the subject is very dark or bright

- When the main subject lacks clearly defined colors

- When the shot is framed so that the main subject is on the edge of the monitor

- When the main subject is composed of a repeating pattern

Focusing

1/2501/250 F5.6F5.6

Focus areas

1/250

1/250 F5.6

F5.6

Focus areas

E19

Reference Section

Using Face Detection

In the following settings, the camera uses face

detection to automatically focus on human

faces.

• s (night portrait), Scene auto selector or

Portrait scene mode (A27)

• a (smile timer) (A39)

• When AF area mode (A52) is set to Face

priority

If the camera detects more than one face, a double border is displayed around

the face that the camera focuses on, and single borders are displayed around

the other faces.

If the shutter-release button is pressed halfway when no faces are detected:

• When Scene auto selector is selected, the focus area changes depending

on the scene.

• In s (night portrait) and Portrait, the camera focuses on the area in the

center of the frame.

• When a (smile timer) is selected, the camera focuses on the subject in the

center of the frame.

• When AF area mode is set to Face priority, the camera selects the focus

area containing the subject closest to the camera.

B Notes About Face Detection

• The camera’s ability to detect faces depends on a variety of factors, including the

direction in which the faces are looking.

• The camera cannot detect faces in the following situations:

- When faces are partially hidden by sunglasses or otherwise obstructed

- When faces take up too much or too little of the frame

C Viewing Images Captured Using Face Detection

During playback, the camera automatically rotates images according to the

orientation of the faces that were detected at the time of shooting (except for

images captured using Continuous (A52) or Exposure bracketing (A52)).

1/250

1/250 F5.6

F5.6

25m 0s

840

E20

Reference Section

Using Skin Softening

When the shutter is released while using one of the shooting modes listed

below, the camera detects human faces and processes the image to soften

facial skin tones (up to 3 faces).

• s (night portrait), Scene auto selector or Portrait scene mode (A27)

Skin softening can also be applied to saved images (A55).

B Notes About Skin Softening

• It may take more time than usual to save images after shooting.

• Under some shooting conditions, the desired skin softening results may not be

achieved, and skin softening may be applied to areas of the image where there are

no faces.

Subjects Not Suitable for Autofocus

The camera may not focus as expected in the following situations. In rare cases,

the subject may not be in focus despite the fact that the focus area or the focus

indicator is displayed in green:

• Subject is very dark

• Objects of sharply differing brightness are included in the scene (e.g. the sun

behind the subject makes that subject appear very dark)

• No contrast between the subject and surroundings (e.g. a portrait subject

wearing a white shirt is standing in front of a white wall)

• Several objects are at different distances from the camera (e.g. the subject is

inside a cage)

• Subjects with repeating patterns (window blinds, buildings with multiple

rows of similarly shaped windows, etc.)

• Subject is moving rapidly

In the situations noted above, try pressing the shutter-release button halfway

to refocus several times, or focus on another subject positioned at the same

distance from the camera as the actual desired subject, and use focus lock

(E21).

The camera can also focus using manual focus (A41, 42).

E21

Reference Section

Focus Lock

Use focus lock to capture creative compositions even when the focus area is

set to the center of the frame.

1 Position the subject in the

center of the frame and

press the shutter-release

button halfway.

• The camera focuses on the

subject and the focus area is

displayed in green.

• Exposure is also locked.

2 Without lifting your finger,

recompose the picture.

• Make sure to maintain the same distance

between the camera and the subject.

3 Press the shutter-release button

the rest of the way down to take

the picture.

C Moving the Focus Area to the Desired Position

In j, k, l or m shooting mode, the focus area can be moved using the multi

selector by setting AF area mode in the shooting menu (A51) to one of the

manual options.

1/250

1/250 F5.6

F5.6

25m 0s

840

1/2501/250 F5.6F5.6

E22

Reference Section

The control range of the shutter speed differs depending on the zoom position,

aperture, or ISO sensitivity setting. Additionally, the control range changes in

the following continuous shooting settings.

The ISO sensitivity setting is restricted depending on the continuous shooting

setting (

46).

In m mode, the ISO sensitivity is fixed at ISO 100.

The maximum shutter speed value is 1/4000 second when the aperture value is

set to f/8 at the maximum wide-angle position. The shutter speed becomes slower

when the zoom position moves to the telephoto zoom position and the aperture

is larger. The shutter speed is 1/2500 second when the aperture value is set to

maximum f/8 at the maximum telephoto zoom position.

The Control Range of the Shutter Speed

(j, k, l, m Modes)

Setting Control range

ISO sensitivity

(A52)

Auto

Fixed range auto

1/4000

–1 s (j, k, l modes)

1/4000

–15 s (m mode)

ISO 100

1/4000

–8 s (j, k, l modes)

1/4000

–15 s (m mode)

ISO 200

1/4000

–4 s (j, k, l modes)

1/4000

–8 s (m mode)

ISO 400 1/4000

–4 s

ISO 800 1/4000

–2 s

ISO 1600 1/4000

–1 s

ISO 3200, 6400 1/4000

–1/2 s

Continuous (A52)

Continuous H,

Continuous L, BSS

1/4000

–1/30 s

Pre-shooting cache,

Continuous H: 120 fps

1/4000–1/125 s

Continuous H: 60 fps 1/4000–1/60 s

Multi-shot 16 1/4000–1/30 s

Intvl timer shooting Same as when Single is set

E23

Reference Section

Moving the zoom control toward

(

playback

zoom) in full-frame playback mode (

22) zooms in

on the image.

• You can change the magnification rate by moving the zoom control toward f

(h) or g (i). The zoom can also be adjusted by rotating the command dial.

• To view a different area of the image, press the multi selector HIJK.

• If you are viewing an image that was captured using face detection or pet

detection, the camera zooms in on the face detected at the time of shooting

(except images captured using Continuous or Exposure bracketing). To zoom

in on an area of the image where there are no faces, adjust the magnification rate

and then press HIJK.

• When a zoomed image is displayed, press the k button to return to full-frame

playback mode.

C Cropping Images

When a zoomed image is displayed, you can press the d button to crop the image

to include only the visible portion and save it as a separate file (E31).

Playback Zoom

g (i)

0112. JPG

4/132

15/11/2015 15:30

(i)

(h)

Image is zoomed in.Full-frame Playback

Displayed

area guide

E24

Reference Section

Moving the zoom control toward

(

thumbnail

playback) in full-frame playback mode (

22) displays

images as thumbnails.

• You can change the number of thumbnails displayed by moving the zoom

control toward f

(

)

or g (i).

• While using thumbnail playback mode, use the multi selector HIJK or

rotate it to select an image, and then press the k button to display that

image in full-frame playback mode.

• While using calendar display mode, use HIJK or rotate it to select a

date, and then press the k button to display the images captured on that

day.

B Notes About Calendar Display

Images captured when the camera’s date is not set are treated as images captured

on January 1, 2015.

Thumbnail Playback/Calendar Display

f (h)

2015

Sun Sat

Fri

Thu

Wed

Tue

Mon

1/132

4/132

0112. JPG

15/11/2015 15:30

Thumbnail PlaybackFull-frame Playback

Calendar Display

(i)

(h)

(i)

(h)

E25

Reference Section

Viewing Images in a Sequence

Images captured continuously are saved as a sequence.

The first image of a sequence is used as the key

picture to represent the sequence when displayed

in full-frame playback mode or thumbnail

playback mode (default setting).

To display each image in the sequence

individually, press the k button.

After pressing the k button, the operations listed

below are available.

• To display the previous or next image, rotate

the multi selector or press JK.

• To display images that are not included in the

sequence, press H to return to the key picture

display.

• To display images in a sequence as thumbnails,

or to play them back in a slide show, set Sequence display options to

Individual pictures in the playback menu (E91).

B Sequence Display Options

Images captured continuously with cameras other than this camera cannot be

displayed as a sequence.

C Playback Menu Options Available When Using Sequence

• When images in a sequence are displayed in full-frame playback mode, press the

d button to select functions in playback menu (A55).

• If you press the d button when a key picture is displayed, the following settings

can be applied to all images in the sequence:

- Mark for Wi-Fi upload, Protect

Viewing and Deleting Images Captured

Continuously (Sequence)

0004. JPG

15/11/2015 15:30

4/132

0004. JPG

1/5

0004. JPG

Back

15/11/2015 15:30

E26

Reference Section

Deleting Images in a Sequence

When the l (delete) button is pressed for images in a sequence, the images

that are deleted vary depending on how the sequences are displayed.

• When the key picture is displayed:

- Current image: All images in the displayed sequence are

deleted.

- Erase selected images: When a key picture is selected on the erase

selected images screen (A56), all images in

that sequence are deleted.

- All images: All images on the memory card are deleted.

• When images in a sequence are displayed in full-frame playback mode:

- Current image: The image currently displayed is deleted.

- Erase selected images: Images that are selected in the sequence are

deleted.

- Entire sequence: All images in the displayed sequence are

deleted.

Before Editing Images

You can easily edit images on this camera. Edited copies are saved as separate

files.

Edited copies are saved with the same shooting date and time as the original.

C Restrictions on Image Editing

• An image can be edited up to 10 times. A still image created by editing a movie

can be edited up to 9 times.

• You may not be able to edit images of a certain size or with certain editing

functions.

Editing Images (Still Images)

E27

Reference Section

Quick Retouch: Enhancing Contrast and Saturation

Use the multi selector HI to select

the desired effect level and press the

k button.

• The edited version is displayed on the right.

• To exit without saving the copy, press J.

D-Lighting: Enhancing Brightness and Contrast

Use the multi selector HI to select

the desired effect level and press the

k button.

• The edited version is displayed on the right.

• To exit without saving the copy, press J.

Press the c button (playback mode) M Select an image M d button

M Quick retouch M k button

Press the c button (playback mode) M Select an image M d button

M D-Lighting M k button

Amount

Normal

Quick retouch

Amount

Normal

D-Lighting

E28

Reference Section

Skin Softening: Softening Skin Tones

1 Use the multi selector HI to

select the desired effect level and

press the k button.

• To exit without saving the copy, press J.

2 Preview the result and press the

k button.

• The edited face is zoomed in.

• When more than one face has been edited,

press JK to switch the face that is

displayed.

• To change the effect level, press the d

button and return to step 1.

• An edited copy is created.

B Notes About Skin Softening

• Up to 12 faces, in order of proximity to the center of the frame, can be enhanced.

• Depending on the direction in which faces are looking, or the brightness of faces,

the camera may be unable to accurately detect faces, or the skin softening

function may not perform as expected.

• If no faces are detected, a warning is displayed and the screen returns to the

playback menu.

Press the c button (playback mode) M Select an image M d button

M Skin softening M k button

Amount

Skin softening

Normal

SaveBack

Preview

E29

Reference Section

Filter Effects: Applying Digital Filter Effects

1 Use the multi selector HI to

select the desired filter effect and

press the k button.

• When effects other than Selective color

are selected, proceed to step 3.

Press the c button (playback mode) M Select an image M d button

M Filter effects M k button

Option Description

Soft portrait

Blurs the background of human subjects. When no human

subjects are detected, keeps the area in the center of the

frame in focus and blurs the surrounding area.

Selective color

Keeps only a selected image color and makes other colors

black-and-white.

Cross screen

Produces star-like rays of light that radiate outward from

bright objects such as sunlight reflections and city lights.

Suitable for night scenes.

Fisheye

Creates images that look like they were shot with a fisheye

lens. Suitable for images shot in macro mode.

Miniature effect

Creates images that look like close-up photos of a diorama.

Suitable for images shot while looking down from a high

location, with the main subject near the center of the frame.

Painting Creates images with the ambience of paintings.

Vignette

Lowers the peripheral light intensity from the center to the

edges of an image.

Photo illustration

Emphasizes outlines and reduces the number of colors to

create images with the ambience of illustrations.

Portrait (color +

B&W)

Makes colors of the background of human subjects black-

and-white. When no human subjects are detected, keeps

colors of the area in the center of the frame and makes the

surrounding area black-and-white.

Painting

Miniature eect

Fisheye

Cross screen

Selective color

Soft portrait

Filter eects

E30

Reference Section

2 Use HI to select the color to

keep and press the k button.

3 Preview the result and press the k

button.

• An edited copy is created.

• To exit without saving the copy, press J.

Small Picture: Reducing the Size of an Image

1 Use the multi selector HI to

select the desired copy size and

press the k button.

• When the aspect ratio of the image is 16:9,

the image is reduced to 640 × 360 in size.

Press the k button to proceed to step 2.

2 Select Yes and press the k

button.

• An edited copy is created (compression

ratio of approximately 1:16).

B Notes About Small Picture

When the aspect ratio of the image is 3:2 or 1:1, the image cannot be edited.

Press the c button (playback mode) M Select an image M d button

M Small picture M k button

Selective color

SaveBack

Preview

160×120

320×240

640×480

Small picture

Yes

Create small picture ﬁle?

E31

Reference Section

Crop: Creating a Cropped Copy

1 Move the zoom control to enlarge the image (E23).

2 Adjust the image so that only the

portion that you want to keep is

displayed, and then press the d

(menu) button.

• Move the zoom control toward g (i) or f

(h) to adjust the magnification rate. Set a

magnification rate at which u is

displayed.

• Use the multi selector HIJK to scroll to the portion of the image that you

want to display.

3 Check the image and press the k

button.

• To change the portion you want to keep,

return to step 2 by pressing J.

• To exit without saving the cropped image,

press the d button.

4 Select Yes and press the k button.

• An edited copy is created.

C Image Size

• The aspect ratio (horizontal to vertical) of the cropped copy is the same as the

original.

• When the image size of the cropped copy is 320 × 240 or smaller, the image is

displayed at a smaller size during playback.

4.0

SaveBack

Trim

Save

Trim

Back

Yes

displayed?

Save this image as

E32

Reference Section

1 Display the shooting screen.

• Check the remaining amount of movie

recording time.

2 Press the b (e movie-record)

button to start movie recording.

• The camera focuses on the subject in the

center of the frame.

• Press k button to pause recording, and

press k button again to resume recording

(except when an HS movie option is selected

in Movie options). Recording automatically

ends if it remains paused for about five

minutes.

• You can capture a still image by pressing the shutter-release button while

recording a movie (E35).

3 Press the b (e movie-record) button again to end

recording.

4 Select a movie in full-frame

playback mode and press the k

button to play it back.

• An image with a movie options icon is a

movie.

Recording and Playing Back Movies

1/250

F5.6

840

25m 0s

Remaining movie

recording time

7m23s

004. MOV

2014/07/16 10:03

15/11/2015 15:30

22m16s

Movie options

E33

Reference Section

Area Captured in Movies

• The area that is captured in a movie varies depending on the Movie

options or Electronic VR settings in the movie menu.

• Press the s button and display the movie frame (A3) to check the

range of a movie in a frame before movie recording.

Focusing During Movie Recording

• The focus can be adjusted during movie recording in the following manner in

accordance with the Autofocus mode (A54) setting of the movie menu.

- A Single AF (default setting): The focus is locked when movie recording

starts. To perform the autofocus function during movie recording, press the multi

selector J.

- B Full-time AF: The focus is adjusted repeatedly even during movie

recording.

• When the focus mode (A40) is E (manual focus), adjust the focus manually. The

focus can be adjusted while recording movies by rotating the multi selector

counterclockwise to focus on far subjects or clockwise to focus on near subjects.

Exposure Locking

• When the multi selector K is pressed during movie recording, the exposure is

locked. To unlock, press K again.

Maximum Movie Recording Time

Individual movie files cannot exceed 4 GB in size or 29 minutes in length, even when

there is sufficient free space on the memory card for longer recording.

• The remaining recording time for a single movie is displayed on the shooting

screen.

• Recording may end before either limit is reached if camera temperature becomes

elevated.

• The actual remaining recording time may vary depending on the movie content,

subject movement, or type of memory card.

• Memory cards with an SD Speed Class rating of 6 or faster are recommended when

recording movies (F20). Movie recording may stop unexpectedly when a memory

card with a lower Speed Class rating is used.

B Notes About Camera Temperature

• The camera may become hot when recording movies for an extended period of

time or when the camera is used in a hot area.

• If the inside of the camera becomes extremely hot when recording movies, the

camera will automatically stop recording. The amount of time remaining until the

camera stops recording (B10s) is displayed.

After the camera stops recording, it turns itself off.

Leave the camera off until the inside of the camera has cooled.

E34

Reference Section

Notes About Movie Recording

B Notes About Saving Images or Movies

The indicator showing the number of exposures remaining or the indicator showing

the remaining recording time flashes while images or movies are being saved. Do

not open the battery-chamber/memory card slot cover or remove the

battery or memory card while an indicator is flashing. Doing this could result in

loss of data, or in damage to the camera or the memory card.

B Notes About Recorded Movies

• The zoom indicator is not displayed during movie recording.

• There may be some degradation in image quality when digital zoom is used. If you

zoom in on the subject while recording a movie, the zoom motion temporarily

stops at the position where optical zoom is changed to digital zoom.

•

The sounds of zoom control operation, zoom, autofocus lens drive movement, vibration

reduction, and aperture operation when brightness changes may be recorded.

• The following phenomena may be seen in the monitor while recording movies.

These phenomena are saved in the recorded movies.

- Banding may occur in images under fluorescent, mercury-vapor, or sodium-vapor

lighting.

- Subjects that move quickly from one side of the frame to the other, such as a

moving train or car, may appear skewed.

- The entire movie image may be skewed when the camera is panned.

- Lighting or other bright areas may leave residual images when the camera is

moved.

• Depending on the distance to the subject or the amount of zoom applied, colored

stripes may appear on subjects with repeating patterns (fabrics, lattice windows,

etc.) during movie recording and playback.

This occurs when the pattern in the subject and the layout of the image sensor

interfere with each other; it is not a malfunction.

B Notes About Autofocus for Movie Recording

Autofocus may not perform as expected (E20). Should this occur, focus using

manual focus (A41, 42) or try the following:

1. Set

Autofocus mode

in the movie menu to Single AF (default setting) before

starting movie recording.

2. Frame another subject (positioned at the same distance from the camera as the

intended subject) in the center of the frame, press the b (e) button to start

recording, and modify the composition.

E35

Reference Section

If the shutter-release button is pressed all the

way while recording a movie, one frame is saved

as a still image. Movie recording continues while

the still image is being saved.

• A still image can be captured when Q is

displayed in the monitor. When f is

displayed, a still image cannot be captured.

• The image size of the still images to be saved

is determined by the type (image size) (E82)

of the original movie.

B Notes About Capturing Still Images During Movie Recording

• Still images cannot be saved during movie recording in the following situations:

- When movie recording is paused

- When the remaining movie recording time is less than 5 seconds

- When Movie options (A54) is set to g 480/30p, s 480/25p or HS

movie

• The frames of a movie that were recorded when a still image was being captured

may not play back smoothly.

• The sounds of operating the shutter-release button when saving a still image may

be heard in the recorded movie.

• If the camera moves when the shutter-release button is pressed, the image may be

blurred.

Capturing Still Images While Recording

Movies

7m23s

E36

Reference Section

To adjust the volume, move the zoom control

while a movie is playing (

A1).

Rotate the multi selector or the command dial to

advance or rewind.

Playback controls are displayed in the monitor.

The operations described below can be

performed by using the multi selector JK to

select a control and then pressing the k

button.

* The movie can also be advanced or rewound by one frame by rotating the multi

selector or command dial.

Operations During Movie Playback

Function Icon Description

Rewind A Hold down the k button to rewind the movie.

Advance B Hold down the k button to advance the movie.

Pause E

Pause playback. The operations listed below can be

performed while paused.

Rewind the movie one frame. Hold down the k

button for continuous rewinding.*

Advance the movie one frame. Hold down the k

button for continuous advancing.*

F Resume playback.

Extract the desired portion of a movie and save it as a

separate file.

Extract a single frame of a movie and save it as a still

image.

End G Return to full-frame playback mode.

7m 42s

Volume indicator

7m 42s

When

paused

E37

Reference Section

When editing movies, use a sufficiently charged battery to prevent the camera

from turning off during editing. When the battery level indicator is B, movie

editing is not possible.

Extracting Only the Desired Portion of a Movie

The desired portion of a recorded movie can be saved as a separate file.

1 Play back a desired movie and pause at the start point of

the portion that you want to extract (E36).

2 Use the multi selector JK to

select the I control, and then

press the k button.

3 Use HI to select J (choose start

point).

• Use JK or rotate the command dial to

move the start point.

• To cancel editing, select O (back), and

press the k button.

Use

to select

(choose end

point).

• Use JK or rotate the command dial to

move the end point.

•

To preview the specified portion, use

select

and then press the

button.

Press the

button again to stop

previewing.

Editing Movies

7m42s

8m 48s

Choose start point

5m 52s5m 52s5m 52s

Choose end point

E38

Reference Section

5 Use HI to select m (save) and

press the k button.

• Follow the instructions on the screen to save

the movie.

B Notes About Movie Extracting

• A movie that was created by editing cannot be edited again.

• The actual trimmed portion of a movie may differ slightly from the portion selected

using the start and end points.

• Movies cannot be trimmed so that they are less than two seconds long.

Saving a Frame from a Movie as a Still Image

The desired frame of a recorded movie can be extracted and saved as a still

image.

• Pause a movie and display the frame to be

extracted (E36).

• Use the multi selector JK to select the

H control and press the k button.

• Select Yes when a confirmation dialog is

displayed, and press the k button to save the

image.

• The still image is saved with Normal as the

image quality. The image size is determined by

the type (image size) (E82) of the original

movie.

B Restrictions on Extracting Still Images

Still images cannot be extracted from a movie recorded with g 480/30p, s

480/25p, or an HS movie option.

5m 52s5m 52s5m 52s

Save

7m42s7m42s7m42s

7m42s

Yes

Copy this frame as a still image?

E39

Reference Section

Set Time zone and date (E98) correctly before using the location data

functions.

1 Set Record location data to On.

• After the settings are complete, press the

d button or shutter-release button to exit

the menu.

• To receive signals easily, operate in an open-

air area.

2 Check the location data

reception on the shooting

screen.

• n or o: Signals are being received

from four or more satellites, or from

three satellites, and positioning is

being performed. The location data is

recorded on the image.

• z: Signals are being received, but

positioning is not possible. If the location data was obtained within the last

one minute, it is recorded on the image.

• y: Signals are not received. The location data is not recorded on the image.

3 Shoot images while positioning is being performed.

• The location data is recorded on shot images.

• The recorded location data can be checked on a map with ViewNX-i after

transferring the image to a computer (E53).

Recording the Location Data on the Image

Press the d button M z menu icon M Location data options M k

button

O

Record location data

F5.6

840

F5.6

1/250

Location data reception

E40

Reference Section

B Notes About Location Data Functions

• Before using the location data functions, read “<Important> Notes About Location

Data Functions (GPS/GLONASS)” (Axi).

• It takes a few minutes to obtain location data when positioning is performed for

the first time or in a situation where positioning cannot be performed for a long

period of time, or just after the battery is replaced.

Using the latest A-GPS file can shorten the time needed for obtaining the location

data (E94).

• Positions of the positioning satellites change constantly.

You may not be able to determine the position or it may take some time

depending on your location and the time.

To use the location data functions, use the camera in an open-air area with few

obstacles in the sky.

Signal receiving will be smoother if the positioning antenna (A2) is facing the sky.

• The following locations which block or reflect signals may result in failed or

inaccurate positioning.

- Inside buildings or underground locations

- Between high-rise buildings

- Under overpasses

-Inside tunnels

- Near high-voltage electrical power lines

- Between clusters of trees

• Using a mobile phone of 1.5 GHz band near this camera may disrupt positioning.

• When carrying this camera around while positioning, do not place it in a metal bag.

Positioning cannot be performed if the camera is covered with metal materials.

• When there is a significant difference in the signals from the positioning satellites,

there could be a deviation of up to several hundred meters.

• Be aware of your surroundings when positioning.

• The shooting date and time that is displayed when playing back images is

determined by the camera’s internal clock at the time of shooting.

The time when location data is obtained will be recorded on images, but it will not

be displayed on the camera.

• The location data for the first frame will be recorded on a series of images shot

using continuous shooting.

B Battery Drain While Recording Location Data and Log Recording

• When Record location data is set to On, record location data functions will

continue to operate at the specified interval for approximately 6 hours even after

the camera is turned off. Also, record location data functions and log recording

function will continue to operate during log recording (E42) even after the

camera is turned off.

• When Record location data is set to On or during log recording, the battery

power will drain faster than usual.

E41

Reference Section

C Points of Interest (POI) Information

• POI information is location name information for

landmarks (facilities) and other details.

• When Display POI in Points of interest (POI)

(E96) of the location data options menu is set

to On, the nearest location name information for

the current position is displayed during shooting

(only when positioning is being performed).

• When Embed POI is set to On, location name

information can be recorded on the image

during shooting (only when positioning is being

performed).

• If the location name information was recorded on the image during shooting, this

information is displayed when Display POI is set to On during playback.

• The location name information may not be displayed depending on the setting

level in Level of detail of Points of interest (POI). Also, certain landmark names

may not be registered, or the landmark name may be different.

C Images with Recorded Location Data

• The z icon is displayed during playback for images which have the location data

recorded (A7).

• Images which have the location data recorded can be checked on a map with

ViewNX-i after transferring them to a computer (E53).

• The actual place of shooting may differ from the location data recorded on the

image files due to the accuracy of the location data obtained and a difference in

the geodetic system used.

• The location data and POI information recorded on images can be erased using

Erase location data in Location data options (E94). The erased information

cannot be recovered.

F5.6

840

F5.6

1/250

Location name information

(POI information)

E42

Reference Section

1 Use the multi selector HI to

select

Log interval, and press the

k button.

2 Select the intervals of log

recording, and press the

button.

• The default setting is 15 s.

3 Select Start log, and press the k

button.

4 Select the duration that the log

will be recorded, and press the k

button.

• Log recording starts. Press the d button

to exit the menu.

• D is displayed on the shooting screen

during log recording (A5).

• When a preset time has elapsed, log

recording ends automatically, and the log data is temporarily stored in the

camera.

When log recording ends, save it to a memory card (E44).

Recording the Log of Movement

Information

Press the d button M z menu icon M Create log M k button

End log

Log interval

Start log

Create log

1 min

30 s

15 s

10 s

5 s

Log interval

End log

Log interval

Start log

Create log

Log data for next 24 hrs

Log data for next 12 hrs

Log data for next 6 hrs

Start log

E43

Reference Section

B Notes About Log Recording

• If the date and time are not set, the log cannot be recorded.

• Use a fully charged battery to prevent the camera from turning off during log

recording. When the battery power becomes exhausted, log recording ends.

• Even when the camera is turned off, log recording is continuously performed until

the preset time has elapsed if there is still time remaining for log recording.

• Log recording ends due to the operations below even when there is time

remaining for log recording.

- The battery is removed

- Record location data in Location data options is set to Off

- Reset all in the setup menu is performed

- The setting of the internal clock (time zone or date and time) is changed

- End log is selected in Create log of the location data options menu (E44)

• Log recording is paused during the operations below.

- During continuous shooting

- During movie recording

- When connected with a USB cable or HDMI cable

Log recording is resumed when the above operations are finished.

• The log data cannot be recorded when positioning cannot be performed at all

during log recording.

• After recording log data, save it to a memory card (E44). New logs cannot be

recorded if the log data remains in the camera.

E44

Reference Section

Ending Log to Save it on Memory Cards

After the obtained log is saved to a memory card by using Save log in the

location data options menu, view the log with software that can display log

data.

1 When log recording is completed,

select End log on the screen, and

press the k button.

• Ending log can also be performed before

the preset time elapses.

2 Select Save log, and press the k

button.

• The log data is saved to a memory card.

• To confirm that the log data is saved to the

memory card, select View log of the

location data options menu.

• See E115 for information about storage

destination and file name of log data.

C To Erase Log Data

• To erase the log data that is temporarily stored in the camera, select Erase log in

step 2.

• To erase the log data that is stored on the memory card, press the l button in

View log of the location data options menu to select either function.

- Selected log: The selected log data is erased.

- All logs: All log data stored on the memory card is erased.

C Location Data Log

Log data is NMEA format-compliant. However, display in all NMEA format-compliant

software or on all NMEA format-compliant cameras is not guaranteed.

Press the d button M z menu icon M Create log M k button

End log

Log interval

Start log

Create log

Erase log

Save log

End log

E45

Reference Section

1 Press the q (Wi-Fi) button on the

camera.

• The screen shown on the right is displayed.

• If no connection confirmation is received

from the smart device within 3 minutes, the

message No access. is displayed and the

camera returns to the Wi-Fi options screen.

• You can also select Connect to smart

device in the Wi-Fi options menu to

display the screen shown on the right.

2 Set the Wi-Fi setting on the smart device to On.

• Check the user’s manual provided with your smart device for further details.

• After the network names (SSIDs) that can be used for the smart device are

displayed, select the SSID displayed on the camera.

• When the Auth./encryp. is set to WPA2-PSK-AES in the Wi-Fi options

menu, the message for entering a password is displayed.

Enter the password that is displayed on the camera.

3 Start the “Wireless Mobile Utility” installed on the smart

device, while Negotiating... Please wait. is displayed on

the camera.

• The screen for selecting “Take photos” or “View photos” is displayed.

• When the message “Cannot connect to camera.” is displayed, return to step

1 and retry the procedure.

• See “Installing the Software on the Smart Device” (A60).

C When Take photos Is Selected

You can capture still images using the two methods described below.

• Release the shutter on the camera and save the captured images to a smart device.

• Use a smart device to remotely release the camera shutter and save images to the

smart device.

Connecting to a Smart Device (Wi-Fi)

XXXXXXXXXXXXXXXXXX

Cancel

Password:

SSID:

Connect to smart device

E46

Reference Section

B Notes About Shooting

• When Wi-Fi is connected, Intvl timer shooting in Continuous cannot be used.

• Operations cannot be performed on the camera during remote control operation.

The shooting mode is set to A (auto) mode and the focus area is set to the center

of the frame, regardless of the camera's settings.

C Touching an NFC-compatible Smart Device to the Camera for a

Wi-Fi Connection

When you use a smart device that is compatible

with near field communication (NFC) functions

and runs on Android OS, you can establish a

Wi-Fi connection and start the “Wireless Mobile

Utility” by touching the NFC antenna on the

smart device to the Z (N-Mark) on the camera.

To Terminate the Wi-Fi Connection

Perform one of the operations described below.

• Turn off the camera.

• Select Disable Wi-Fi in the Wi-Fi options menu of the camera (except during

remote control operation).

• Set the Wi-Fi setting on the smart device to Off.

B Notes About Wi-Fi Connection

• Wi-Fi connection operations are disabled in the following situations:

- When no memory card is inserted in the camera

- When the camera is connected to a TV, printer, or computer

-While recording movies

- When the camera is connected to a smart device

• If the battery level is low, the Wi-Fi connection is terminated.

• Select Disable Wi-Fi in areas where the use of radio waves is prohibited.

• When Wi-Fi is connected, Auto off is disabled.

• When Wi-Fi is connected, the battery drains faster than normal.

C Security Settings

If no security settings (encryption and password) are configured for the camera’s

Wi-Fi function, unauthorized third parties may access the network and cause harm.

We strongly recommend performing the required security settings before using the

Wi-Fi function.

Use Options in the Wi-Fi options menu (E92) to perform the security settings.

E47

Reference Section

You can preselect images in the camera that you want to transfer to a smart

device. Movies cannot be preselected for transfer.

1 Select images to transfer.

You can preselect the images to transfer to a smart device in the following

menus:

• Mark for Wi-Fi upload in the playback menu (E88)

• Upload from camera in the Wi-Fi options menu (E92)

When using Upload from camera, the SSID and password of the camera are

displayed after images are selected.

2 Connect the camera and smart device (E45).

• Tapping “View photos” in the “Wireless Mobile Utility” displays the

confirmation screen to transfer the specified images to the smart device.

B Preselecting Images to Transfer During Playback

While the camera is in playback mode, press the q button or use the NFC function

to establish a Wi-Fi connection, and preselect the displayed images that you want to

transfer.

• You can preselect one image at a time in full-frame playback mode. You can

preselect all images in the sequence when the key picture is displayed for images

in a sequence.

• You can preselect the currently selected image in thumbnail playback mode. You

can preselect all images in the sequence when the key picture is displayed for

images in a sequence.

• You can preselect all the images captured on the selected date in calendar display

playback mode.

This operation is not available when you use Connect to smart device in the Wi-Fi

options menu to establish the Wi-Fi connection.

Preselecting Images in the Camera That

You Want to Transfer to a Smart Device

E48

Reference Section

1 Turn off the camera and connect it to the TV.

• Make sure that the plugs are properly oriented. Do not insert or remove the

plugs at an angle when connecting or disconnecting them.

2 Set the TV’s input to external input.

• See the documentation provided with your TV for details.

3 Press and hold down the c

(playback) button to turn on the

camera.

• Images are displayed on the TV.

• The camera monitor does not turn on.

Connecting the Camera to a TV (Playback

on a TV)

HDMI micro connector

(Type D)

to HDMI jack

E49

Reference Section

Users of PictBridge-compatible printers can connect the camera directly to the

printer and print images without using a computer.

Connecting the Camera to a Printer

1 Turn on the printer.

2 Turn off the camera and connect it to the printer using the

USB cable.

• Make sure that the plugs are properly oriented. Do not insert or remove the

plugs at an angle when connecting or disconnecting them.

3 The camera is automatically turned on.

• The PictBridge startup screen (1) is displayed in the camera monitor,

followed by the Print selection screen (2).

B If the PictBridge Startup Screen Is Not Displayed

When Auto is selected for Charge by computer (E108), it may be impossible

to print images with direct connection of the camera to some printers.

If the PictBridge startup screen is not displayed after the camera is turned on,

turn the camera off and disconnect the USB cable. Set Charge by computer

to Off and reconnect the camera to the printer.

Connecting the Camera to a Printer (Direct

Print)

No. 3215/11/2015 [ 32]

Print selection

E50

Reference Section

Printing Images One at a Time

1 Use the multi selector JK to

select the desired image and press

the k button.

• Move the zoom control toward f (h) to

switch to thumbnail playback or g (i) to

switch to full-frame playback.

2 Use HI to select Copies and

press the k button.

• Use HI to set the desired number of

copies (up to 9) and press the k button.

3 Select Paper size and press the k

button.

• Select the desired paper size and press the

k button.

• To print with the paper size setting

configured on the printer, select Default.

• The paper size options available on the

camera vary depending on the printer that

you use.

4 Select Start print and press the k

button.

• Printing starts.

No. 3215/11/2015 [ 32]

Print selection

Copies

prints

Start print

Paper size

PictBridge

Copies

prints

Start print

Paper size

PictBridge

Copies

prints

Start print

Paper size

PictBridge

E51

Reference Section

Printing Multiple Images

1 When the Print selection screen

is displayed, press the d (menu)

button.

2 Use the multi selector HI to

select Paper size and press the k

button.

• Select the desired paper size and press the

k button.

• To print with the paper size setting

configured on the printer, select Default.

• The paper size options available on the

camera vary depending on the printer that you use.

• To exit the print menu, press the d button.

3 Select Print selection or Print all

images and press the k button.

No. 3215/11/2015 [ 32]

Print selection

Paper size

Print all images

Print selection

Print menu

Paper size

Print all images

Print selection

Print menu

E52

Reference Section

Print selection

Select images (up to 99) and the

number of copies (up to 9) of each.

• Use the multi selector JK to select

images, and use HI to specify the

number of copies to be printed.

• Images selected for printing are

indicated by a and the number of

copies to be printed. To cancel the

print selection, set the number of copies to 0.

• Move the zoom control toward g (i) to switch to full-frame

playback or f (h) to switch to thumbnail playback.

• Press the k button when setting is complete. When the screen for

confirming the number of print copies is displayed, select Start

print and press the k button to start printing.

Print all images

One copy each of all images saved on the memory card is printed.

• When the screen for confirming the number of print copies is

displayed, select Start print and press the k button to start

printing.

Back

113

Print selection

E53

Reference Section

Installing ViewNX-i

ViewNX-i is free software that enables you to transfer images and movies to

your computer for viewing.

To install ViewNX-i, download the latest version of the ViewNX-i installer from

the following website and follow the onscreen instructions to complete

installation.

ViewNX-i: http://nikonimglib.com/nvnxi/

For system requirements and other information, see the Nikon website for your

region.

Transferring Images to a Computer

1 Prepare a memory card that contains images.

You can use any of the methods below to transfer images from the memory

card to a computer.

• SD memory card slot/card reader: Insert the memory card into the card

slot of your computer or the card reader (commercially available) that is

connected to the computer.

• Direct USB connection: Turn the camera off and ensure that the memory

card is inserted in the camera. Connect the camera to the computer using

the USB cable.

The camera automatically turns on.

Using ViewNX-i (Transferring Images to a

Computer)

E54

Reference Section

If a message is displayed prompting you to choose a program, select Nikon

Transfer 2.

• When using Windows 7

If the dialog shown at right is

displayed, follow the steps

below to select Nikon Transfer

1Under Import pictures

and videos, click Change

program. A program

selection dialog will be

displayed; select Import File using Nikon Transfer 2 and click OK.

2Double-click Import File.

• When using Windows 8.1

If the dialog shown at right is displayed,

click the dialog and then click Import File/

Nikon Transfer 2.

If the memory card contains a large number of images, it may take a while for

Nikon Transfer 2 to start. Wait until Nikon Transfer 2 starts.

B Notes About Connecting the USB Cable

Operation is not guaranteed if the camera is connected to the computer via a USB

hub.

E55

Reference Section

2 After Nikon Transfer 2 starts, click Start Transfer.

• Image transfer begins. When image transfer is complete, ViewNX-i starts and

the transferred images are displayed.

• Consult online help for more information on using ViewNX-i.

3 Terminate the connection.

• If you are using a card reader or card slot, choose the appropriate option in

the computer operating system to eject the removable disk corresponding

to the memory card and then remove the memory card from the card reader

or card slot.

• If the camera is connected to the computer, turn the camera off and

disconnect the USB cable.

Start Transfer

E56

Reference Section

• See “M (User Settings) Mode” (A34) for information about Save user

settings and Reset user settings.

Image Quality

* The image quality can be set in any shooting mode. The setting is also applied to

other shooting modes (except shooting mode M and Easy panorama scene

mode).

Set the image quality (compression ratio) used when saving images.

Lower compression ratios result in higher quality images, but the number of

images that can be saved is reduced.

B Notes About Image Quality

This function may not be available to use in combination with other functions

(A46).

C Number of Images That Can Be Saved

• The approximate number of images that can be saved can be checked in the

monitor when shooting (A16).

•

Note that due to JPEG compression, the number of images that can be saved may vary

greatly depending on the image content, even when using memory cards with the same

capacity and the same image quality and image size settings. In addition, the number of

images that can be saved may vary depending on the make of the memory card.

• If the number of exposures remaining is 10,000 or more, the number of exposures

remaining display shows “9999.”

The Shooting Menu (The Common

Shooting Options)

Enter shooting mode* M d button M shooting mode menu icon M

Image quality M k button

Option

Description

a Fine

Finer image quality than Normal.

Compression ratio of about 1:4

Normal

(default setting)

Normal image quality, suitable for most applications.

Compression ratio of about 1:8

E57

Reference Section

Image Size

* The image size can be set in any shooting mode. The setting is also applied to

other shooting modes (except shooting mode M and Easy panorama scene

mode).

Set the image size (number of pixels) used when saving images.

The larger the image size, the larger the size at which it can be printed, but the

number of images that can be saved is reduced.

* The numerical values indicate the number of pixels that are captured.

Example: i 4608×3456 = approx. 16 megapixels, 4608 × 3456 pixels

B Notes About Printing Images at 1:1 Aspect Ratio

Change the printer setting to “Border” when printing images at a 1:1 aspect ratio.

Some printers may not be able to print images at a 1:1 aspect ratio.

B Notes About Image Size

This function may not be available to use in combination with other functions

(A46).

Enter shooting mode* M d button M shooting mode menu icon M

Image size M k button

Option* Aspect ratio (horizontal to vertical)

4608×3456 (default setting)

4:3

3264×2448

4:3

2272×1704

4:3

1600×1200

4:3

640×480

4:3

4608×2592

16:9

1920×1080

16:9

4608×3072

3:2

3456×3456

1:1

E58

Reference Section

Picture Control (COOLPIX Picture Control)

Change the settings for image recording according to the shooting scene or

your preferences. Sharpness, contrast and saturation can be adjusted in detail.

* Only displayed when the setting customized in Custom Picture Control (E62)

has been registered.

B COOLPIX Picture Control

• The COOLPIX Picture Control function of this camera cannot be used with other

makes of cameras, Picture Control function of software such as Capture NX-D,

Picture Control Utility 2, etc.

• This function may not be available to use in combination with other functions

(A46).

The Shooting Menu (j, k, l or m Mode)

Rotate the mode dial to j, k, l, m or M M d button M j, k, l, m or

M menu icon M Picture Control M k button

Option

Description

Standard

(default setting)

Standard processing for balanced results.

Recommended for most situations.

c Neutral

Minimal processing for natural results. Select for

images that will later be processed or retouched.

d Vivid

Images are enhanced for a vivid, photoprint effect.

Select for images that emphasize primary colors, such

as blue, red, and green.

e Monochrome

Shoots monochrome photographs such as in black-

and-white or sepia.

f Custom 1

Changes to the setting of Custom 1 in COOLPIX

Custom Picture Control.

g Custom 2

Changes to the setting of Custom 2 in COOLPIX

Custom Picture Control.

E59

Reference Section

Customizing Existing COOLPIX Picture Controls: Quick

Adjust and Manual Adjust

COOLPIX Picture Control can be customized using Quick adjust, which allows

for balanced adjustment of sharpness, contrast, saturation and other image

editing components, or manual adjust, which allows for detailed adjustment of

the components individually.

1 Use the multi selector HI to

select the desired type of COOLPIX

Picture Control and press the

button.

• Items can also be selected by rotating the

multi selector.

2 Use HI to highlight the desired

option (E60) and use JK to

select a value.

• Press the k button to set the value.

• To change the adjusted values to the

default setting, select Reset and press the

k button.

Monochrome

Vivid

Neutral

Standard

Picture Control

Back

Reset

Saturation

Contrast

Image sharpening

Quick adjust

Standard

E60

Reference Section

Types of Quick Adjust and Manual Adjust

Option Description

Quick adjust

Adjusts the sharpness, contrast and saturation levels

automatically.

Setting to the – side reduces the effect of the selected

COOLPIX Picture Control, and setting to the + side

emphasizes its effect.

• Default setting: 0

Image sharpening

Controls how much outlines are sharpened during shooting.

The higher the number, the sharper the image, and the lower

the number, the softer the image.

Select A (auto) for automatic adjustment.

• Default setting: 3 for Standard or Monochrome, 2 for

Neutral and 4 for Vivid

Contrast

Controls the contrast.

Setting to the – side gives the image a softer appearance,

and setting to the + side gives it a harder appearance. Select

lower values to prevent highlights in portrait subjects from

being “washed out” in direct sunlight, higher values to

preserve detail in misty landscapes and other low contrast

subjects.

Select A (auto) for automatic adjustment.

• Default setting: 0

Saturation

Controls the vividness of colors.

Setting to the – side reduces the vividness, and setting to the

+ side increases the vividness.

Select A (auto) for automatic adjustment.

• Default setting: 0

Filter effects

Simulates the effect of color filters on monochrome

photographs.

•OFF: Filter effects are not used.

•Y (yellow), O (orange), R (red):

Enhance contrast. Can be used to tone down the

brightness of the sky in landscape photographs. The

contrast is strengthened in the order Y ➝ O ➝ R.

•G (green):

Softens skin tones. Suitable for portraits.

• Default setting: OFF

E61

Reference Section

Quick adjust is not available in Neutral, Monochrome, Custom 1 and Custom 2.

The values set manually are disabled if quick adjust is used after manual setting.

Not displayed for Monochrome.

Only displayed for Monochrome.

B Notes About Image Sharpening

The effects of Image sharpening cannot be previewed in the monitor during

shooting. Check the results in playback mode.

B Contrast, Saturation and A (Auto)

Results for contrast and saturation vary with the exposure, and the position and size

of the subject in the frame.

Toning

Controls the tint used in monochrome photographs from

B&W (black-and-white), Sepia, and Cyanotype (blue-tinted

monochrome).

Pressing the multi selector I when Sepia or Cyanotype is

selected enables you to select a saturation level. Press JK to

adjust the saturation.

• Default setting: B&W (black-and-white)

Option Description

E62

Reference Section

Custom Picture Control (COOLPIX Custom Picture

Control)

Customize the settings of COOLPIX Picture Control (E59) and register them

in Custom 1 or Custom 2 of Picture Control.

1 Use the multi selector HI to

select Edit and save, and press

the k button.

• Select Delete to delete a registered

COOLPIX Custom Picture Control.

2 Select the original COOLPIX Picture Control (E59) to be

edited, and press the k button.

3 Use HI to highlight the desired option and use JK to

select a value (E59).

• The options are the same as those for adjusting the COOLPIX Picture Control.

• Press the k button when you finish adjustment.

• To change the adjusted values to the default setting, select Reset and press

the k button.

4 Select the registration destination

and press the k button.

•Custom 1 or Custom 2 becomes

selectable in Picture Control or Custom

Picture Control.

• To change the adjusted values, select

Custom 1 or Custom 2 in Picture Control

or Custom Picture Control.

Rotate the mode dial to

button

menu icon

Custom Picture Control

M k button

Delete

Edit and save

Custom Picture Control

Custom 2

Custom 1

Save as

E63

Reference Section

White Balance (Adjusting Hue)

Adjust white balance to suit the light source or weather conditions in order to

make the colors in images match what you see with your eyes.

* Fine adjustments in 7 steps are available. Apply positive (+) to increase blue hue

and negative (–) to increase red hue.

B Notes About White Balance

• Lower the flash when white balance is set to any setting other than Auto

(normal), Auto (warm lighting) or Flash (A18).

• This function may not be available to use in combination with other functions

(A46).

Rotate the mode dial to j, k, l, m or M M d button M j, k, l, m or

M menu icon M White balance M k button

Option

Description

Auto (normal)

(default setting)

White balance is automatically adjusted.

When set to Auto (warm lighting), the images are

preserved with warm colors if they are shot under an

incandescent light source. When using the flash,

white balance is adjusted according to the flash

lighting condition.

Auto (warm

lighting)

b Preset manual

Use when the desired result is not achieved with

Auto (normal), Auto (warm lighting),

Incandescent, etc. (E65).

c Daylight

Use under direct sunlight.

d Incandescent

Use under incandescent lighting.

e Fluorescent

Use under most types of fluorescent lighting. Choose

one of 1 (cool-white fluorescent), 2 (day white

fluorescent) and 3 (daylight fluorescent).

f Cloudy

Use under overcast skies.

g Flash

Use with the flash.

Choose color

temp.

Use to directly specify color temperature (E64).

E64

Reference Section

C Color Temperature

Color temperature is an objective measure of colors of light sources which are

expressed in the unit of absolute temperature (K: Kelvin). Light sources with lower

color temperatures appear more reddish, while light sources with higher color

temperatures appear more bluish.

3000 4000 5000 6000 8000 10000

[K]

234 890a567

Red Blue

Sodium-vapor lamps: 2700K

Incandescent/

Warm-white fluorescent: 3000K

White fluorescent: 3700K

Cool-white fluorescent: 4200K

Day white fluorescent: 5000K

Direct sunlight: 5200K

Flash: 5400K

Cloudy: 6000K

Daylight fluorescent: 6500K

High temp. mercury-vapor: 7200K

Shade: 8000K

E65

Reference Section

Using Preset Manual

Use the procedure below to measure the white balance value under the

lighting used during shooting.

1 Place a white or gray reference object under the lighting

that will be used during shooting.

2 Use the multi selector HI to

select Preset manual, and press

the k button.

• The lens extends to the zoom position for

measurement.

3 Select Measure.

• To apply the last measured value, select

Cancel.

4 Frame the white or gray reference

object in the measuring window,

and press the k button to

measure the value.

• The shutter is released and measurement is

complete (no image is saved).

B Notes About Preset Manual

A white balance value for flash lighting cannot be measured with Preset manual.

When shooting using the flash, set White balance to Auto (normal), Auto (warm

lighting) or Flash.

Auto (normal)

Auto (warm lighting)

Daylight

Incandescent

Fluorescent

Cloudy

Preset manual

White balance

Cancel

Measure

Preset manual

Cancel

Measure

Preset manual

Measuring window

E66

Reference Section

Metering

The process of measuring the brightness of the subject to determine the

exposure is known as “metering.”

Use this option to set the method of how the camera meters exposure.

* To set focus and exposure for off-center subjects, change AF area mode to

manual and set the focus area to the center of the frame, and then use focus lock

(E21).

B Notes About Metering

• When digital zoom is in effect, Center-weighted or Spot is selected depending

on the magnification of an enlargement.

• This function may not be available to use in combination with other functions

(A46).

C Display on the Shooting Screen

When Center-weighted or Spot is selected, the metering range guide (A6) is

displayed (except when digital zoom is used).

Rotate the mode dial to j, k, l

M M d button M j, k, l

m or

M menu icon M Metering M k button

Option Description

Matrix

(default setting)

The camera uses a wide area of the screen for metering.

Recommended for typical shooting.

Center-weighted

The camera meters the entire frame but assigns greatest

weight to the subject in the center of the frame. The

classic metering for portraits; it preserves background

details while letting lighting conditions in the center of

the frame determine exposure.*

Spot

The camera meters the area shown by the circle in the

center of the frame. This can be used when the subject

is much lighter or darker than the background. Ensure

that the subject is within the area shown by the circle

when shooting.*

E67

Reference Section

Continuous Shooting

Rotate the mode dial to j

or M M d button M j

m or

M menu icon M Continuous M k button

Option Description

Single

(default setting)

One image is captured each time the shutter-release

button is pressed.

k Continuous H

While the shutter-release button is held all the way

down, images are captured continuously.

• The frame rate for continuous shooting is about 7 fps

and the maximum number of continuous shots is

about 7 (when image quality is set to Normal and

image size is set to i 4608×3456).

m Continuous L

While the shutter-release button is held all the way

down, images are captured continuously.

• The frame rate for continuous shooting is about 2 fps

and the maximum number of continuous shots is

about 200 (when image quality is set to Normal and

image size is set to i 4608×3456).

Pre-shooting

cache

Pre-shooting cache shooting begins when the shutter-

release button is pressed halfway. When the shutter-

release button is pressed the rest of the way down, the

camera saves the current image as well as the images

captured immediately before the button is pressed

(E69). Pre-shooting cache makes it easy to capture

perfect moments.

• The frame rate for continuous shooting is about 15 fps

and the maximum number of continuous shots is 20

(including a maximum of 5 frames captured in the

pre-shooting cache).

• The image quality is fixed at Normal and the image

size is fixed at A (1280 × 960 pixels).

Continuous H:

120 fps

Each time the shutter-release button is pressed all the

way, images are captured at a high speed rate.

• The frame rate for continuous shooting is about

120 fps and the maximum number of continuous

shots is 60.

• Image size is fixed at f 640×480.

E68

Reference Section

B Notes About Continuous Shooting

• Focus, exposure and white balance are fixed at the values determined with the first

shot in each series.

• It may take some time to save the images after shooting.

• When ISO sensitivity increases, noise may appear in captured images.

• The frame rate may become slower depending on the image quality, image size,

memory card type or shooting conditions.

• When using Multi-shot 16, Continuous H: 120 fps or Continuous H: 60 fps,

banding or variance in brightness or hue may occur in images that were captured

under lighting that flashes quickly at high speeds, such as fluorescent, mercury-

vapor, or sodium-vapor lighting.

• This function may not be available to use in combination with other functions

(A46).

Continuous H:

60 fps

Each time the shutter-release button is pressed all the

way, images are captured at a high speed rate.

• The frame rate for continuous shooting is about 60 fps

and the maximum number of continuous shots is 60.

• Image size is fixed at O 1920×1080.

BSS (Best Shot

Selector)

While the shutter-release button is held all the way

down, the camera captures a series of up to 10 images

and automatically saves the sharpest image.

Use when shooting a stationary subject in a place where

flash photography is prohibited and camera shake is

likely to occur.

W Multi-shot 16

Each time the shutter-release

button is pressed all the way, the

camera captures a series of

16 images and saves it as a single

image.

• The frame rate for continuous

shooting is about 30 fps.

• Image size is fixed at D (2560 × 1920 pixels).

• Digital zoom is not available.

Intvl timer

shooting

The camera shoots still images automatically at the

specified interval (E69).

Option Description

E69

Reference Section

C Pre-shooting Cache

When the shutter-release button is pressed halfway or all the way down, images are

saved as described below.

• The pre-shooting cache icon (Q) on the shooting screen changes to green while

the shutter-release button is pressed halfway.

Interval Timer Shooting

1 Use the multi selector HI to

select X Intvl timer shooting,

and then press the k button.

Rotate the mode dial to j

M M d button M j

M menu icon M Continuous M k button

Press down halfway Press down all the way

Images saved before

pressing all the way

Images saved by

pressing all the way

Intvl timer shooting

Multi-shot 16

BSS

Continuous

E70

Reference Section

2 Set the desired interval between

each shot.

• Use JK to select an item, and use HI to

set the time.

• Press the k button when setting is

complete.

3 Press the d (menu) to display the shooting screen.

4 Press the shutter-release button to

shoot the first image.

• The shutter is automatically released at the

specified interval to shoot subsequent

images.

• The monitor turns off and the power-on

lamp flashes during the intervals between

shots (when the battery is used).

5 When the desired number of images have been captured,

press the shutter-release button.

• Shooting ends.

• Shooting ends automatically when the memory card becomes full.

B Notes About Interval Timer Shooting

• To prevent the camera from turning off unexpectedly during shooting, use a fully

charged battery.

• If the EH-67A AC Adapter (available separately; E116) is used, this camera can be

powered from an electrical outlet. Do not, under any circumstances, use an AC

adapter other than the EH-67A. Failure to observe this precaution could result in

overheating or damage to the camera.

• Do not rotate the mode dial to a different setting while performing interval timer

shooting.

• If the shutter speed is slow and saving an image takes time compared to the

specified interval, some of the shots during Interval timer shooting may be

canceled.

00 30

Intvl timer shooting

Edit

1/250

F5.6

840

25m 0s

E71

Reference Section

ISO Sensitivity

A higher ISO sensitivity allows darker subjects to be captured. Additionally,

even with subjects of similar brightness, pictures can be taken at faster shutter

speeds, and blurring caused by camera shake and subject movement can be

reduced.

• When a higher ISO sensitivity is set, images may contain noise.

B Notes About ISO Sensitivity

• In m (manual) mode, when set to Auto, ISO 100-400 or ISO 100-800, the ISO

sensitivity is fixed at ISO 100.

• This function may not be available to use in combination with other functions

(A46).

C ISO Sensitivity Display on the Shooting Screen

• When Auto is selected, E is displayed when the ISO sensitivity increases.

• When ISO 100-400 or ISO 100-800 is selected, the maximum value for ISO

sensitivity is displayed.

Rotate the mode dial to j, k, l, m or M M d button M j, k, l, m or

M menu icon M ISO sensitivity M k button

Option Description

ISO sensitivity

•Auto (default setting):

Sensitivity is automatically selected from the range of ISO

100 to 1600.

• Fixed range auto:

The range in which the camera automatically adjusts ISO

sensitivity can be selected from Y ISO 100-400 or

Z ISO 100-800.

•100 to 6400:

ISO sensitivity is fixed at the specified value.

Minimum shutter

speed

Set the shutter speed at which ISO sensitivity starts to be

automatically adjusted when the shooting mode is

j or l.

If the exposure is insufficient with the shutter speed that is set

here, the ISO sensitivity is increased automatically to obtain

the correct exposure.

• The setting is enabled when ISO sensitivity is set to Auto

or Fixed range auto.

• If the exposure is still insufficient even after ISO sensitivity is

increased, the shutter speed slows down.

• Default setting: None

E72

Reference Section

Exposure Bracketing

The exposure (brightness) can be changed automatically during continuous

shooting. This is effective for shooting when it is difficult to adjust the picture

brightness.

B Notes About Exposure Bracketing

• Exposure bracketing is not available in m (manual) mode.

• When exposure compensation (A44) and ±0.3, ±0.7 or ±1.0 in Exposure

bracketing are set simultaneously, the combined exposure compensation values

are applied.

• This function may not be available to use in combination with other functions

(A46).

Rotate the mode dial to j, k or l M d button M j, k or l menu

icon M Exposure bracketing M k button

Option Description

Off (default

setting)

Exposure bracketing is not performed.

±0.3

When the shutter-release button is pressed all the way, 3 shots

are taken in sequence and the camera varies exposure by 0, –0.3,

and +0.3 over the shots.

±0.7

When the shutter-release button is pressed all the way, 3 shots

are taken in sequence and the camera varies exposure by 0, –0.7,

and +0.7 over the shots.

±1.0

When the shutter-release button is pressed all the way, 3 shots

are taken in sequence and the camera varies exposure by 0, –1.0,

and +1.0 over the shots.

E73

Reference Section

AF Area Mode

Set how the camera selects the focus area for autofocus.

Rotate the mode dial to j

M d button M j

M menu icon M AF area mode M k button

Option Description

a Face priority

When the camera detects a

human face, it focuses on that

face. See “Using Face

Detection” (E19) for more

information.

When framing a composition

with no human subjects or

detected faces, the camera

automatically selects one or

more of the 9 focus areas

containing the subject closest to the camera.

Manual

(spot)

Manual

(normal)

Manual

(wide)

Use the multi selector

HIJK or rotate it to move

the focus area to where you

want to focus.

To use the multi selector to

configure the flash mode or

other settings, press the k

button. To return to moving

the focus area, press the k

button again.

25m 0s

1/250

F5.6

840

25m 0s

Focus area

Focus area (center)

Scope of movable

focus area

Focus area (moved)

E74

Reference Section

B Notes About AF Area Mode

• When digital zoom is in effect, the camera focuses on the area in the center of the

frame regardless of the AF area mode setting.

• This function may not be available to use in combination with other functions

(A46).

Subject

tracking

Use this function to take

pictures of moving subjects.

the camera focuses. The

focus area automatically

moves to track the subject.

See “Using Subject Tracking”

(E75) for more information.

Target

finding AF

(default

setting)

When the camera detects the

main subject, it focuses on

that subject.

See “Using Target Finding AF”

(E18).

Option Description

1/250

F5.6

25m 0s

840

25m 0s

End

1/250

F5.6

Focus areas

E75

Reference Section

Using Subject Tracking

1 Register a subject.

• Align the subject that you want to track

with the border in the center of the monitor

and press the k button.

• When the subject is registered, a yellow

border (focus area) is displayed around it

and the camera begins tracking the subject.

• If the subject cannot be registered, the

border is displayed in red. Change the

composition and try registering the subject

again.

• To cancel subject registration, press the k

button.

• If the camera can no longer track the

registered subject, the focus area

disappears. Register the subject again.

2 Press the shutter-release button

fully to take the picture.

• If the shutter-release button is pressed

while the focus area is not displayed, the

camera focuses on the subject in the center

of the frame.

B Notes About Subject Tracking

• If you perform operations such as zooming while the camera is tracking the

subject, the registration is canceled.

• Subject tracking may not be possible in certain shooting conditions.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M AF area mode M k button M s Subject tracking M k

button M d button

25m 0s

840

25m 0s

1/2501/250 F5.6F5.6

Start

25m 0s

840

25m 0s

1/250

F5.6

End

1/250

F5.6

E76

Reference Section

Autofocus Mode

Set how the camera focuses when shooting still images.

B Notes About Autofocus Mode

This function may not be available to use in combination with other functions

(A46).

C Autofocus Mode for Movie Recording

Autofocus mode for movie recording can be set with Autofocus mode (E85) in

the movie menu.

Flash Exp. Comp.

Adjust the flash output.

Use this option when the flash is too bright or too dark.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Autofocus mode M k button

Option Description

A Single AF

The camera focuses only when the shutter-release

button is pressed halfway.

Full-time AF

(default setting)

The camera continues focusing even when the

shutter-release button is not pressed halfway. The

sound of lens drive movement is heard while the

camera focuses.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Flash exp. comp. M k button

Option Description

+0.3 to +2.0

The flash output is increased from +0.3 to +2.0 EV, in

increments of 1/3 EV, to make the main subject of the frame

appear brighter.

0.0 (default setting) The flash output is not adjusted.

-0.3 to -2.0

The flash output is reduced from –0.3 to –2.0 EV, in

increments of 1/3 EV, to prevent unwanted highlights or

reflections.

E77

Reference Section

Noise Reduction Filter

Set the strength of the noise reduction function that is normally performed

when saving images.

Active D-Lighting

Details in highlights and shadows are preserved, and the natural contrast that is

seen with the naked eye is well reproduced in the image captured. This is

particularly effective for shooting scenes with high contrast, such as brightly lit

outdoor scenery from a dark room or shaded subjects at a sunny seaside.

B Notes About Active D-Lighting

• Additional time is required to save images after shooting.

• This function may not be available to use in combination with other functions

(A46).

B Active D-Lighting Versus D-Lighting

The Active D-Lighting option in the shooting menu reduces exposure before

shooting to adjust the dynamic range properly. The D-Lighting (E27) option in

the playback menu readjusts the dynamic range properly in images captured.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M

Noise reduction filter

M k button

Option Description

e High

Performs noise reduction at a level higher than the

standard strength.

Normal

(default setting)

Performs noise reduction at the standard strength.

l Low

Performs noise reduction at a level lower than the

standard strength.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Active D-Lighting M k button

Option Description

High

Normal

Low

Set the effect level.

Off

(default setting)

Active D-Lighting is not applied.

E78

Reference Section

Multiple Exposure

The camera combines two to three images and saves them as a single image.

B Notes About Multiple Exposure

• It may take some time to combine images.

• Multiple exposure is terminated if the auto off function (A57) triggers the

standby mode during shooting. When shooting with a long interval between

shots, setting a longer time for the auto off function is recommended.

• This function may not be available to use in combination with other functions

(A46).

• When shooting at a slow shutter speed in multiple exposure mode, noise (bright

spots) may appear in saved images.

Multiple Exposure Shooting

1 Use the multi selector HI to

select Multiple exposure mode,

and then press the k button.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Multiple exposure M k button

Option Description

Multiple exposure

mode

Shoots images in multiple exposure mode when set to On.

• Individual images are also saved.

• Default setting: Off

Auto gain

Set whether or not to automatically adjust the brightness of

the image when combining images.

• Default setting: On

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Multiple exposure M k button

Auto gain

Multiple exposure mode

Multiple exposure

E79

Reference Section

2 Select On, and then press the k

button.

3 Press the d (menu) button to display the shooting

screen.

4 Press the shutter-release button to

shoot the first image.

5 Press the shutter-release button to

shoot the second image.

• Frame the picture while looking at the first

image displayed translucently.

• When shooting the second image, the

combined image of the first and second

images is saved, and displayed translucently.

• To end multiple exposure at the second

image, set Multiple exposure mode to Off or change the mode dial to any

mode other than j, k, l, m or M.

6 Press the shutter-release button to shoot the third image.

• The combined image of the first to third images is saved and multiple

exposure ends.

• It may take some time until the third image is shot.

O

Multiple exposure mode

1/250

1/250 F5.6

F5.6

25m 0s

840

1/250

1/250 F5.6

F5.6

25m 0s

840

E80

Reference Section

Zoom Memory

B Notes About Zoom Operation

• When more than one focal length has been set, move the zoom control to switch

to the focal length closest to that before the operation. To switch to a different

focal length, release the zoom control and then move it again.

• Set Zoom memory to Off when using the digital zoom.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Zoom memory M k button

Option Description

When the zoom control is moved, the zoom position

(equivalent to focal length/angle of view in 35mm [135]

format) is switched to the positions that have been

selected by setting the check box to on in this menu

option.

• Choose the focal length with the multi selector HI,

and then press the k button to set the check box to

on [w] or off.

The following settings are available: 24 mm, 28 mm,

35 mm, 50 mm, 85 mm, 105 mm, 135 mm, 200 mm,

300 mm, 400 mm, 500 mm, 600 mm, 800 mm, 1000

mm, 1200 mm, 1400 mm, 1600 mm, 1800 mm and

2000 mm.

• Default setting: On [w] for all the check boxes

• To finish setting, press the multi selector K.

• The zoom position set in the Startup zoom position

is automatically set to on [w].

• The zoom memory function cannot be used with the

side zoom control.

Off (default setting)

The zoom position can be moved to any position,

including the positions that can be set with On.

E81

Reference Section

Startup Zoom Position

Set the zoom position (equivalent to focal length/angle of view in 35mm [135]

format) for when the camera is turned on.

The following settings are available: 24 mm (default setting), 28 mm, 35 mm,

50 mm, 85 mm, 105 mm and 135 mm.

M Exposure Preview

Set whether or not to reflect the brightness to the shooting screen when the

exposure is changed in m (manual) mode.

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M Startup zoom position M k button

Rotate the mode dial to j

l, m or M M d button M j

l, m or

M menu icon M M exposure preview M k button

Option Description

Reflects the brightness to the shooting screen.

Off

(default setting)

Does not reflect the brightness to the shooting screen.

E82

Reference Section

Movie Options

Select the desired movie option to record. Select normal speed movie options

to record at normal speed, or HS movie options (E83) to record in slow or fast

motion. The movie options that can be selected vary depending on the Frame

rate setting (E87).

• Memory cards with an SD Speed Class rating of 6 or faster are

recommended for recording movies (F20).

Normal Speed Movie Options

The Movie Menu

Enter shooting mode M d button M e menu icon M Movie options

M k button

Option (Image size/

Frame rate, File format)

Image size

Aspect ratio

(horizontal to vertical)

1080/30p

1080/25p

(default setting) 1920 × 1080 16:9

1080/60p

1080/50p

1920 × 1080 16:9

720/30p

720/25p

1280 × 720 16:9

720/60p

720/50p

1280 × 720 16:9

480/30p

480/25p

640 × 480 4:3

E83

Reference Section

HS Movie Options

Recorded movies are played back in fast or slow motion.

See “Playing Back in Slow Motion and Fast Motion” (E84).

* The setting is not available when using certain special effects.

B Notes About HS Movie

• Sound is not recorded.

• Zoom position, focus, exposure, and white balance are locked when movie

recording starts.

Option

Image size

Aspect ratio

(horizontal to vertical)

Description

HS 480/4×*

640 × 480

4:3

1/4-speed slow motion movies

• Max. recording time:

7 minutes 15 seconds

(playback time: 29 minutes)

HS 720/2×

1280 × 720

16:9

1/2-speed slow motion movies

• Max. recording time:

14 minutes 30 seconds

(playback time: 29 minutes)

HS 1080/

0.5×

1920 × 1080

16:9

2× speed fast motion movies

• Max. recording time:

29 minutes (playback time:

14 minutes 30 seconds)

E84

Reference Section

C Playing Back in Slow Motion and Fast Motion

When recording at normal speed:

When recording at h HS 480/4×, or u HS 480/4×:

Movies are recorded at 4× normal speed.

They are played back in slow motion at 4× slower speed.

When recording at j HS 1080/0.5×, or x HS 1080/0.5×:

Movies are recorded at 1/2 normal speed.

They are played back in fast motion at 2× faster speed.

Playback

time

Recording

time

10 s

Recording

time

Playback

time

40 s

10 s

Slow motion playback

Recording

time

Playback

time

10 s

5 s

Fast motion playback

E85

Reference Section

Autofocus Mode

Set how the camera focuses when recording movies.

B Autofocus Mode

• When an HS movie option is selected in Movie options, the setting is fixed at

Single AF.

• This function may not be available to use in combination with other functions.

Enter shooting mode M d button M e menu icon M Autofocus mode

M k button

Option Description

Single AF

(default setting)

Focus is locked when movie recording starts.

Select this option when the distance between the

camera and the subject will remain fairly consistent.

B Full-time AF

The camera focuses continuously.

Select this option when the distance between the

camera and subject will change significantly during

recording. The sound of the camera focusing may be

heard in the recorded movie. Use of Single AF is

recommended to prevent the sound of the camera

focusing from interfering with recording.

E86

Reference Section

Electronic VR

Set whether or not to perform electronic VR when recording movies.

B Notes About Electronic VR

When an HS movie option is selected in Movie options, the setting is fixed at Off.

Wind Noise Reduction

B Notes About Wind Noise Reduction

When an HS movie option is selected in Movie options, the setting is fixed at Off.

Enter shooting mode M d button M e menu icon M Electronic VR M

k button

Option Description

(default setting)

Performs electronic VR.

• The angle of view (i.e., the area seen in the frame)

becomes narrower.

• When Vibration reduction is set to Normal or

Active in the setup menu (A57), optical vibration

reduction is performed simultaneously.

Off

Does not perform electronic VR.

Enter shooting mode M d button M e menu icon M Wind noise

reduction M k button

Option Description

Reduces the sound that is produced when wind passes

over the microphone during movie recording. Other

sounds may become difficult to hear during playback.

Off

(default setting)

Wind noise reduction is disabled.

E87

Reference Section

Zoom Microphone

B Notes About Zoom Microphone

When an HS movie option is selected in Movie options, the setting is fixed at Off.

Frame Rate

Select the frame rate used when recording movies. When the frame rate

setting is switched, options that can be set in Movie options (E82) change.

Enter shooting mode M d button M e menu icon M Zoom

microphone M k button

Option Description

(default setting)

In accordance with the angle of view, the camera

records sounds over a wide area at the wide-angle

zoom position, and records sounds in the limited area at

the telephoto zoom position.

Off

Zoom microphone is disabled.

Enter shooting mode M d button M e menu icon M Frame rate M k

button

Option Description

30 fps (30p/60p)

Suited for playback on a TV using the NTSC standard.

25 fps (25p/50p)

Suited for playback on a TV using the PAL standard.

E88

Reference Section

See “Editing Images (Still Images)” (E26) for information about image editing

functions.

Mark for Wi-Fi Upload

Select still images in the camera that you want to transfer to a smart device in

advance before transferring them. Movies cannot be selected.

On the image selection screen (A56), select or deselect images for the Mark

for Wi-Fi upload function.

Note that when you select Reset all (E110) in the setup menu or Restore

default settings (E92) in the Wi-Fi options menu, the Mark for Wi-Fi upload

settings that you made are canceled.

The Playback Menu

Press the c button (playback mode) M d button M Mark for Wi-Fi

upload M k button

E89

Reference Section

Slide Show

Play back images one by one in an automated “slide show.” When movie files are

played back in the slide show, only the first frame of each movie is displayed.

1 Use the multi selector HI to

select Start and press the k

button.

• The slide show begins.

• To change the interval between images,

select Frame intvl, press the k button,

and specify the desired interval time before

selecting Start.

• To repeat the slide show automatically, select Loop and press the k button

before selecting Start.

• The maximum playback time is up to about 30 minutes even if Loop is

enabled.

2 End or restart the slide show.

• The screen shown on the right is displayed

after the slide show ends or is paused. To

exit the show, select G and then press the

k button. To resume the slide show, select

F and then press the k button.

Operations During Playback

• Use the multi selector JK to display the previous/next image. Press and

hold to rewind/fast forward.

• Press the k button to pause or end the slide show.

Press the c button (playback mode) M d button M Slide show M k

button

Pause

Loop

Frame intvl

Start

Slide show

E90

Reference Section

Protect

The camera protects selected images from accidental deletion.

Select images to protect or cancel protection from the image selection screen

(A56).

Note that formatting the memory card permanently deletes all data including

protected files (E107).

Rotate Image

Specify the orientation in which saved images are displayed during playback.

Still images can be rotated 90 degrees clockwise or 90 degrees

counterclockwise.

Images that were saved in the “tall” orientation can be rotated up to 180 degrees

in either direction.

Select an image from the image selection screen (A56). When the Rotate

image screen is displayed, use the multi selector JK or rotate it to rotate the

image 90 degrees.

Press the k button to finalize display orientation, and save orientation

information with the image.

Press the c button (playback mode) M d button M Protect M k

button

Press the c button (playback mode) M d button M Rotate image M k

button

Back

Rotate

Rotate image

Back

Rotate

Rotate image

Back

Rotate

Rotate image

Rotate 90 degrees

counterclockwise

Rotate 90 degrees

clockwise

E91

Reference Section

Sequence Display Options

Select the method used to display images in the sequence (E25).

Settings are applied to all sequences, and the setting is saved in the camera’s

memory even if the camera is turned off.

Choose Key Picture

Specify a different image in the sequence as the key picture.

• When the key picture selection screen is displayed, select an image (A56).

Press the c button (playback mode) M d button M Sequence display

options M k button

Option Description

Individual pictures

Displays each image in a sequence individually. F is

displayed on the playback screen.

Key picture only

(default setting)

Displays only the key picture for images in a sequence.

Press the c button (playback mode) M display a sequence for which you

want to change the key picture M d button M Choose key picture M

k button

E92

Reference Section

Configure the Wi-Fi (wireless LAN) settings to connect the camera and a smart

device.

The Wi-Fi Options Menu

Press the d button M q menu icon M k button

Option Description

Connect to

smart device

Select when wirelessly connecting the camera and a smart

device.

See “Connecting to a Smart Device (Wi-Fi)” (E45) for more

information.

Upload from

camera

Select when wirelessly connecting the camera and a smart

device.

See “Preselecting Images in the Camera That You Want to

Transfer to a Smart Device” (E47) for more information.

• The images to transfer can be selected on the image

selection screen before establishing a Wi-Fi connection

(A56, E88). The SSID and password of the camera are

displayed on the screen after images are selected.

Disable Wi-Fi

Select to terminate the wireless connection between the

camera and a smart device.

See “To Terminate the Wi-Fi Connection” (E46) for more

information.

Options

SSID: Change the SSID. The SSID configured here is displayed

on the smart device. Set a 1- to 24-character alphanumeric

SSID.

Auth./encryp.: Select whether or not to encrypt the

communications between the camera and the connected

smart device.

Communications are not encrypted when Open (default

setting) is selected.

• When WPA2-PSK-AES is set, the message for entering a

password is displayed when the camera is connected to

smart device (E45).

Password: Set an 8- to 16-character alphanumeric password.

Channel: Select the channel used for wireless connections.

Subnet mask: Use the default setting (255.255.255.0) under

normal conditions.

DHCP server IP address: Use the default setting

(192.168.0.10) under normal conditions.

Current settings Display the current settings.

Restore default

settings

Restore the Wi-Fi settings to their default values. The wireless

connection is terminated if this option is performed while Wi-Fi

is connected.

E93

Reference Section

Operating the Text Input Keyboard

Character Input for SSID and Password

• Use the multi selector HIJK to select

alphanumeric characters. Press the k button to

enter the selected character in the text field and

move the cursor to the next space.

• To move the cursor in the text field, select N or

O on the keyboard, and press the k button.

• To delete one character, press the l button.

• To apply the setting, select P on the keyboard

and press the k button.

Character Input for Channel, Subnet mask and DHCP server IP address

• Use the multi selector HI to set the numbers.

To move to the next digit, press K or the k

button. To return to the previous digit, press J.

• To apply the setting, select the last digit and press

the k button.

GH I J

KLM S TNOP

U V WX Y Z

ABCDEF

0 234567891

DeleteBack

SSID

05234 6789AB

LIJK MNOPQR

CDEF1

Text field

Keyboard

DHCP server IP address

1 9 2 1 6 8 0 1 00 0 0

Edit

E94

Reference Section

Location Data Options

The Location Data Options Menu

Press the d button M z menu icon M Location data options M k

button

Option Description

Record location data

When set to On, signals are received from the positioning

satellites, and positioning starts (E39).

• Default setting: Off

Update A-GPS file

A memory card is used to update the A-GPS (assist GPS)

file. Using the latest A-GPS file can shorten the time

needed for obtaining the location data.

• See “Updating the A-GPS File” (E95) for more

information.

Erase location data

The location data and POI information recorded on

images are erased.

• The deleted location data or POI information cannot

be recovered.

• The location data of images captured with cameras

other than this camera cannot be erased.

E95

Reference Section

Updating the A-GPS File

Download the latest A-GPS file from the website below, and use it to update

the file.

http://nikonimglib.com/agps3/

• The A-GPS file for the COOLPIX P900 is only available from the website

above.

1 Download the latest A-GPS file to the computer from the

website.

2 Use a card reader or other device to copy the downloaded

file to the “NCFL” folder of the memory card.

• The “NCFL” folder is located directly under the memory card root directory. If

the memory card does not have “NCFL” folder, create a new folder.

3 Insert the memory card containing the copied file into the

camera.

4 Turn on the camera.

5 Press the d (menu) button to display the location data

options menu, and use the multi selector to select

Location data options.

6 Select Update A-GPS file, and update the file.

• About 2 minutes are needed to update the A-GPS file.

B Notes About Updating A-GPS File

• The A-GPS file is disabled when a position is determined for the first time after the

camera is purchased. The A-GPS file becomes active from the second operation for

determining a location.

• The validity period of the A-GPS file can be checked on the update screen. If the

validity period has expired, it is displayed in gray.

• Once the validity period of the A-GPS file has expired, obtaining the location data

will not become faster. Updating of the A-GPS file before using the location data

functions is recommended.

E96

Reference Section

Points of Interest (POI) (Recording and Displaying

Location Name Information)

Configure the POI (points of interest, location name information) settings.

C POI Display

If there is no location name information at the set display level, no information may

be displayed.

Press the d button M z menu icon M Points of interest (POI) M k

button

Option Description

Embed POI

Set whether or not to record the location name

information on the images to be shot.

• Default setting: Off

• The location name information can be recorded on

both still images and movies.

Display POI

Set whether or not to display the location name

information on the shooting screen or playback screen

(A6, 7).

• If Embed POI was set to On when an image was

captured, the location name information for the image

is displayed on the playback screen.

• Default setting: Off

Level of detail

Set the display level of the location name information. A

higher display level shows more detailed regional

information.

• When set to level 1: country names are displayed.

• When set to levels 2 to 5: the information displayed

varies depending on the country.

• When set to level 6: landmark names (facilities) are

displayed.

Edit POI

If Update POI is selected during playback mode, the

location name information recorded on the image can be

changed. Before pressing the d button, select the

image to change the location name information.

• When level 6 is selected, press the multi selector JK to

change the landmark name.

• To change the POI information level, press the multi

selector HI.

If Remove POI is selected, the location name information

recorded on the image is deleted.

E97

Reference Section

Set Clock from Satellite

Signals from the positioning satellites are used to set the date and time of the

camera’s internal clock. Check the positioning status before setting the clock

using this option.

B Notes About Set Clock from Satellite

• To set the camera’s internal clock, positioning must have been done successfully

(E39).

• Date/time adjustment by Set clock from satellite is set according to the time

zone set in Time zone and date (A57, E98) of the setup menu. Check the

time zone before setting Set clock from satellite.

• The date/time set using Set clock from satellite is not as accurate as radio clocks.

Use Time zone and date in the setup menu to set the time if it is not accurate in

Set clock from satellite.

Press the d button M z menu icon M Set clock from satellite M k

button

E98

Reference Section

Time Zone and Date

Set the camera clock.

Setting the Time Zone

1 Use the multi selector HI to

select Time zone and press the k

button.

The Setup Menu

Press the d button M z menu icon M Time zone and date M k button

Option Description

Date and time

• Select a field: Press the multi

selector JK.

• Edit the date and time: Press

HI. Date and time can also

be changed by rotating the

multi selector or command

dial.

• Apply the setting: Select the

minute field setting and press

the k button or K.

Date format

Select Year/Month/Day, Month/Day/Year, or Day/Month/

Year.

Time zone

Set time zone and daylight saving time.

• When Travel destination (

x) is set after having set the

home time zone (w), the time difference between the travel

destination and the home time zone is automatically

calculated, and the date and time are saved for the selected

region.

15201515 11 10

Date and time

Edit

D M Y h m

Time zone

Date and time

London, Casablanca

15/11/2015 15:30

Date format

Time zone and date

E99

Reference Section

2 Select w Home time zone or

x Travel destination and press

the k button.

• The date and time displayed in the monitor

changes depending on whether the home

time zone or travel destination is selected.

3 Press K.

4 Use JK to select the time zone.

• Press H to enable daylight saving time

function, and W is displayed. Press I to

disable the daylight saving time function.

• Press the k button to apply the time zone.

• If the correct time is not displayed for the

home or travel destination time zone

setting, set the appropriate time in Date

and time.

Travel destination

Home time zone

Time zone

London, Casablanca

15/11/2015 15:30

Travel destination

Home time zone

Time zone

London, Casablanca

15/11/2015 15:30

New York, Toronto, Lima

-5:00

Back

10:30

E100

Reference Section

Slot Empty Release Lock

Set whether or not the shutter can be released when no memory card is

inserted in the camera.

Press the d button M z menu icon M Slot empty release lock M k

button

Option Description

Release locked

(default setting)

Unless a memory card is inserted in the camera, the shutter

cannot be released.

Enable release

Even when no memory card is inserted in the camera, the

shutter can be released. However, Demo mode is

displayed on the image captured when no memory card is

inserted and the image cannot be printed or saved on a

memory card, although the image is displayed on the

monitor.

E101

Reference Section

Monitor Settings

B Notes About View/Hide Framing Grid

When the enlarged center of the image is displayed in E (manual focus), the

framing grid is not displayed.

B Notes About View/Hide Histograms

Histograms are not displayed in the following situations:

• A (auto) mode

• When recording a movie

• When the enlarged center of the image is displayed in E (manual focus)

• When shooting with easy panorama

• When the flash mode, self-timer or focus mode menu is displayed

Press the d button M z menu icon M Monitor settings M k button

Option Description

Image review

Set whether or not to display the captured image immediately

after shooting.

• Default setting: On

Monitor options

Adjust the monitor brightness and hue.

• Use the multi selector HI to adjust brightness, JK to

adjust hue and then press the k button.

• Default setting: Brightness 3

Hue 0

• Cannot be set when the viewfinder is used.

EVF options

Adjust the viewfinder brightness and hue.

• Use the multi selector HI to adjust brightness, JK to

adjust hue and then press the k button.

• Default setting: Brightness 2

Hue 0

• Cannot be set when the monitor is used.

View/hide

framing grid

Set whether or not to display a boxed guide for framing on the

shooting screen.

• Default setting: Off

View/hide

histograms

Set whether or not to display a graph that shows the

brightness distribution in the image (A44) on the shooting

screen.

• Default setting: Off

Virtual horizon

Set whether or not to display a virtual horizon on the shooting

screen (E102).

• Default setting: Off

E102

Reference Section

Virtual Horizon

The virtual horizon for rolling and pitching directions is displayed on the

monitor using a built-in tilt sensor.

The virtual horizon can be displayed when AF area mode is set to Manual

(spot), Manual (normal) or Manual (wide) in j, k, l or m mode, and in

some scene modes or special effects modes with the focus area set to the

center of the frame.

• When the camera is in a normal position (without inclination), for the rolling

direction, the reference line on the virtual horizon display changes to green.

As for the pitching direction, b in the center changes to green.

• One graduation of the virtual horizon represents 5 degrees for the rolling

direction, and 10 degrees for the pitching direction.

B Notes About Virtual Horizon

The virtual horizon is not displayed in the following situations:

• A (auto) mode

• When the scene mode is set to s (night portrait), Scene auto selector, Portrait,

Food, Easy panorama, or Pet portrait

• When recording a movie

• When smile timer is selected

C Precision of the Virtual Horizon

Note that an error becomes large if the camera is tilted forward or backward greatly.

If the camera is tilted to the unmeasurable extent, the graduations of the virtual

horizon turns off.

The camera is in a normal

position for both rolling

and pitching directions.

The camera tilts to the

rolling direction.

The camera tilts to the

pitching direction.

840840

2525

0 0

F5.6F5.6

0 0

F5.6F5.61/2501/250

840840

2525

0 0

F5.6F5.6

0 0

F5.6F5.61/2501/250

840840

2525

0 0

F5.6F5.6

0 0

F5.6F5.61/2501/250

E103

Reference Section

EVF Auto Toggle (Automatically Switching the

Display to the Viewfinder)

Date Stamp

The shooting date and time can be stamped on

images when shooting.

Press the d button M z menu icon M EVF auto toggle M k button

Option Description

(default setting)

When you bring your face close to the viewfinder, the eye

sensor responds to it and the display is automatically

switched from the monitor to viewfinder.

Off

Even when you bring your face close to the viewfinder, the

display is not switched to the viewfinder.

Press the d button M z menu icon M Date stamp M k button

Option Description

fDate

Date is stamped on images.

SDate and time Date and time are stamped on images.

Off (default setting) Date and time are not stamped on images.

15/11/2015

15 /11/2 015

15/11/2015

E104

Reference Section

B Notes About Date Stamp

• Stamped dates form a permanent part of image data and cannot be deleted. The

date and time cannot be stamped on images after they have been captured.

• The date and time cannot be stamped in the following situations:

- When the scene mode is set to Night landscape (when set to Hand-held),

Night portrait (when set to Hand-held), Sports, Museum, Backlighting

(when HDR is set to On), Easy panorama, Pet portrait (when set to

Continuous), or Bird-watching (when set to Continuous)

- When Pre-shooting cache, Continuous H: 120 fps or Continuous H: 60 fps

is selected for Continuous (E67)

- When recording movies

- When saving still images during movie recording

- When extracting still images from a movie during movie playback

• The stamped date and time may be difficult to read when using a small image size.

Vibration Reduction

Select the vibration reduction setting used when shooting.

Select Off when using a tripod to stabilize the camera during shooting.

B Notes About Vibration Reduction

• After turning on the camera or after switching from playback mode to shooting

mode, wait for the shooting mode screen to be displayed completely before

taking pictures.

• Images in the camera monitor may be displayed blurry immediately after shooting.

• Vibration reduction may be unable to completely eliminate the effects of camera

shake in some situations.

Press the d button M z menu icon M Vibration reduction M k button

Option Description

Normal

(default setting)

Compensates camera shake that commonly occurs when

shooting at telephoto zoom positions or slow shutter

speeds. The camera automatically detects the panning

direction and only compensates for vibration caused by

camera shake.

When the camera is panned horizontally, for example,

vibration reduction only reduces vertical shake. If the

camera is panned vertically, vibration reduction only

compensates for horizontal shake.

Z Active

Camera shake is automatically compensated during

shooting if a comparatively large camera shake is likely to

occur when shooting from a car or under poor foothold

conditions.

Off

Compensation is not performed.

E105

Reference Section

AF Assist

Digital Zoom

B Notes About Digital Zoom

• Digital zoom cannot be used in the following scene modes.

- Scene auto selector, Portrait, Night portrait, Easy panorama, Pet portrait

• Digital zoom cannot be used in other shooting modes when using certain settings

(A48).

Press the d button M z menu icon M AF assist M k button

Option Description

Auto

(default setting)

The AF-assist illuminator automatically lights up when

you press the shutter-release button under dim

lighting. The illuminator has a range of about 5.0 m

(16 ft) at the maximum wide-angle position and about

5.0 m (16 ft) at the maximum telephoto position.

• Note that for some scene modes or focus areas, the

AF-assist illuminator may not light.

Off The AF-assist illuminator does not light.

Press the d button M z menu icon M Digital zoom M k button

Option Description

(default setting)

Digital zoom is enabled.

Off Digital zoom is disabled.

E106

Reference Section

Assign Side Zoom Control

Choose the function to be performed during shooting when the side zoom

control is moved.

Sound Settings

Press the d button M z menu icon M Assign side zoom control M k

button

Option Description

Zoom (default setting)

When shooting, use the side zoom control (A20) to

adjust the zoom.

Manual focus

When the focus mode is set to E (manual focus), use

the side zoom control to focus (A42).

• Move the side zoom control toward g to focus on

distant subjects.

• Move the side zoom control toward f to focus on

near subjects.

Press the d button M z menu icon M Sound settings M k button

Option Description

Button sound

When On (default setting) is selected, the camera

produces one beep when operations are performed,

two beeps when focus is acquired on the subject, and

three beeps when an error occurs.

• Sounds are disabled when using Pet portrait or

Bird-watching scene mode.

Shutter sound

When On (default setting) is selected, the shutter

sound is produced when the shutter is released.

• The shutter sound is not produced when using

continuous shooting mode, when recording

movies, or when using Easy panorama, Pet

portrait or Bird-watching scene mode.

E107

Reference Section

Auto Off

Set the amount of time that elapses before the camera enters standby mode

(A18).

You can select 30 s, 1 min (default setting), 5 min, or 30 min.

C Setting the Auto Off Function

The time that passes before the camera enters standby mode is fixed in the following

situations:

• When a menu is displayed: 3 minutes (when auto off is set to 30 s or 1 min)

• When the AC adapter is connected: 30 minutes

Format Card

Use this option to format a memory card.

Formatting the memory cards permanently deletes all data. Data that

has been deleted cannot be recovered. Make sure to save important

images to a computer before formatting.

To start formatting, select Format on the screen that is displayed and press the

k button.

• Do not turn the camera off or open the battery-chamber/memory card slot

cover during formatting.

Language

Select a language for display of camera menus and messages.

Press the d button M z menu icon M Auto off M k button

Press the d button M z menu icon M Format card M k button

Press the d button M z menu icon M Language M k button

E108

Reference Section

Charge by Computer

B Notes About Charging with a Computer

• When connected to a computer, the camera turns on and starts charging. If the

camera is turned off, charging stops.

• About 6 hours and 10 minutes are required to charge a fully exhausted battery.

Charging time increases when images are transferred while the battery is charging.

• The camera turns off automatically if there is no communication with the

computer for 30 minutes after the battery has finished charging.

B When the Power-on Lamp (Charge Lamp) Quickly Flashes Green

Charging cannot be performed, possibly due to one of the reasons described below.

• The ambient temperature is not suited to charging. Charge the battery indoors

with an ambient temperature of 5°C to 35°C (41°F to 95°F).

• The USB cable is not connected correctly or the battery is faulty. Make sure the USB

cable is connected correctly or replace the battery if necessary.

• The computer is in sleep mode and is not supplying power. Wake up the

computer.

• The battery cannot be charged because the computer cannot supply power to the

camera due to the computer’s settings or its specifications.

Press the d button M z menu icon M Charge by computer M k button

Option Description

a Auto

(default setting)

When the camera is connected to a computer that is running

(A61), the battery inserted into the camera is automatically

charged using power supplied by the computer.

• The power-on lamp slowly flashes while the battery is

charging. When charging is complete, the power-on lamp

stops flashing and turns on.

Off

The battery inserted into the camera is not charged when the

camera is connected to a computer.

E109

Reference Section

Toggle Av/Tv Selection

Switch the method for setting the flexible program, shutter speed or aperture

value when shooting mode is set to j, k, l, m or M.

Reset File Numbering

When Ye s is selected, the sequential numbering of file numbers is reset

(E115). After resetting, a new folder is created and the file number for the next

image captured starts with “0001.”

B Notes About Reset File Numbering

Reset file numbering cannot be applied when the folder number reaches 999 and

there are images in the folder. Insert a new memory card or format the memory card

(E107).

C Folders for Storing Files

Still images and movies shot or recorded with this camera are saved in folders of the

memory card.

• Sequential numbers are added to folder names in ascending order, starting with

“100” and ending with “999” (the folder names are not displayed on the camera).

• A new folder is created in the following situations:

- When the number of files in a folder reaches 200

- When a file in a folder is numbered “9999”

- When Reset file numbering is performed

• A new folder is created each time a series of images are captured using interval

timer shooting, and the images are saved in that folder with file numbers starting

with “0001.”

Press the d button M z menu icon M Toggle Av/Tv selection M k

button

Option Description

Do not toggle selection

(default setting)

Use the command dial to set the flexible program or shutter

speed, and the multi selector to set the aperture value.

Toggle selection

Use the multi selector to set the flexible program or

shutter speed, and the command dial to set the

aperture value.

Press the d button M z menu icon M Reset file numbering M k button

E110

Reference Section

Peaking

Reset All

When Reset is selected, the camera’s settings are restored to their default

values.

• Some settings, such as Time zone and date or Language, are not reset.

• User settings that were saved in M of the mode dial are not reset. To reset

these settings, use Reset user settings (A35).

C Resetting File Numbering

To reset file numbering to “0001”, delete all images saved on the memory card before

selecting Reset all. Reset file numbering can also be used to reset to “0001”

(E109).

Firmware Version

View the current camera firmware version.

Press the d button M z menu icon M Peaking M k button

Option Description

(default setting)

When operating E (manual focus), focusing is assisted by

highlighting areas that are in focus in white on the image

displayed in the monitor (A42, 43).

Off Peaking is disabled.

Press the d button M z menu icon M Reset all M k button

Press the d button M z menu icon M Firmware version M k button

E111

Reference Section

Refer to the table below if an error message is displayed.

Error Messages

Display Cause/Solution A

Battery temperature

is elevated. The

camera will turn off.

The camera turns off automatically. Wait until

the battery has cooled before resuming use.

–

The camera will turn

off to prevent

overheating.

Memory card is write

protected.

The write-protect switch is in the “lock” position.

Slide the write-protect switch to the “write”

position.

–

This card cannot be

used.

An error occurred while accessing the memory

card.

• Use an approved memory card.

• Check that the terminals are clean.

• Confirm that the memory card is correctly

inserted.

10,

F20

This card cannot be

read.

Card is not formatted.

Format card?

The memory card has not been formatted for

use in the camera.

Formatting deletes all data saved on the

memory card. If you need to keep copies of any

images, make sure to select No and save the

copies to a computer or other medium before

formatting the memory card. Select Ye s and

press the k button to format the memory card.

10, F5

Out of memory. Delete images or insert a new memory card. 10, 23

Image cannot be

saved.

An error occurred while saving the image.

Insert a new memory card or format the

memory card.

10,

E107

The camera has run out of file numbers.

Insert a new memory card or format the

memory card.

10,

E107

Image cannot be

modified.

Check that the images can be edited.

E26,

F13

Cannot record movie.

A time-out error occurred while saving the

movie on the memory card.

Select a memory card with a faster write speed.

F20

E112

Reference Section

Cannot reset file

numbering.

File numbering cannot be reset because the

sequential number of a folder has reached the

upper limit.

Insert a new memory card or format the

memory card.

10,

E107

Memory contains no

images.

Insert a memory card that contains images. 10

File contains no

image data.

The file was not created or edited with this

camera.

The file cannot be viewed on this camera.

View the file using a computer or the device

used to create or edit this file.

–

All images are hidden.

• There are no images available for a slide

show, etc.

• There are no images that can be displayed on

the image selection screen for deletion.

–

This image cannot be

deleted.

The image is protected.

Disable protection.

E90

Raise the flash.

• When the scene mode is Scene auto

selector, you can capture an image even if

the flash is lowered but the flash will not fire.

• When the scene mode is Night portrait or

Backlighting with HDR set to Off, you must

raise the flash to capture an image.

E3,

Failed to set clock

from satellite.

The camera clock was not set correctly. Change

the location or time and determine the location

again.

–

No A-GPS file found

on card.

An A-GPS file that can be updated is not found

on the memory card.

Check the following items:

• Whether the memory card is inserted

• Whether the A-GPS file is stored on the

memory card

• Whether the A-GPS file saved on the memory

card is more recent than the A-GPS file saved

in the camera

• Whether the A-GPS file is still valid

–

Update failed.

Unable to update A-GPS file.

The A-GPS file may be corrupted. Download the

file from the website once more.

E95

Display Cause/Solution A

E113

Reference Section

Cannot save to card.

A memory card is not inserted.

Insert a memory card.

The maximum number of log data events that

can be saved per day is 36.

–

Log has not been obtained. E43

The maximum number of log data events that

can be saved in one memory card is 100.

Replace the memory card with a new one or

delete log data that is no longer required from

the memory card.

10,

E44

No access.

The camera could not receive the

communication signal from the smart device.

Wirelessly connect the camera and smart device

again.

• Press the q button.

• Touch an NFC-compatible smart device to

the camera.

• Select Connect to smart device in the Wi-Fi

options menu.

E45,

E92

Could not connect.

The camera failed to establish the connection

while receiving the communication signals from

the smart device. Select a different channel for

Channel in Options in the Wi-Fi options menu

and establish the wireless connection again.

E45,

E92

Wi-Fi connection

terminated.

The Wi-Fi connection is terminated in the

following situations:

• Poor connectivity.

• The battery level is low.

• A cable or a memory card is inserted or

removed.

Use a fully charged battery, disconnect the TV,

computer or printer and establish the wireless

connection again.

E45,

E92

Lens error. Try again

after turning the

camera off and on.

If the error persists, contact your retailer or

Nikon-authorized service representative.

Communications

error

An error occurred while communicating with

the printer.

Turn the camera off and reconnect the USB

cable.

E49

System error

An error occurred in the camera’s internal circuitry.

Turn the camera off, remove and reinsert the

battery, and turn the camera on. If the error

persists, contact your retailer or Nikon-

authorized service representative.

Display Cause/Solution A

E114

Reference Section

* See the documentation provided with your printer for further guidance and

information.

Printer error: check

printer status.

After solving the problem, select Resume and

press the k button to resume printing.*

–

Printer error: check

paper.

Load the specified size of paper, select Resume,

and press the k button to resume printing.*

–

Printer error: paper

jam.

Remove the jammed paper, select Resume, and

press the k button to resume printing.*

–

Printer error: out of

paper.

Load the specified size of paper, select Resume,

and press the k button to resume printing.*

–

Printer error: check

ink.

There is a problem with the printer’s ink.

Check the ink, select Resume, and press the k

button to resume printing.*

–

Printer error: out of

ink.

Replace the ink cartridge, select Resume, and

press the k button to resume printing.*

–

Printer error: file

corrupt.

There is a problem with the image file to be

printed.

Select Cancel and press the k button to cancel

printing.

–

Display Cause/Solution A

E115

Reference Section

Images or movies are assigned file names as follows.

C Log Data Saved on Memory Cards

The log data is saved in the “NCFL” folder.

• The file names consist of “N”, “date (the last two digits of the year, month, and day

in YYMMDD format)”, “identification number (0 to 9 or A to Z)” and “extension

(.log)”.

Example: the first location data log recorded on 15 November 2015 is

N1511150.log

• Up to 36 files can be recorded a day and up to 100 files can be recorded on a

memory card.

File Names

(1) Identifier

Not shown on the screen of the camera.

• DSCN: Original still images, movies, still images created by

the movie editing function

• SSCN: Small picture copies

• RSCN: Cropped copies

• FSCN: Images created by an image editing function other

than crop and small picture, movies created by the movie

editing function

(2) File number

Assigned in ascending order, starting with “0001” and ending

with “9999.”

• A new folder is created each time a series of images are

captured using interval timer shooting, and the images are

saved in that folder with file numbers starting with “0001.”

(3) Extension

Indicates file format.

• .JPG: Still images

• .MOV: Movies

File name: DSCN0001.JPG

(1) (2) (3)

E116

Reference Section

* Setting a longer Auto off time (E107) is recommended when using the remote

control function.

Availability may vary with country or region.

See our website or brochures for the latest information.

Optional Accessories

Battery Charger

MH-67P Battery Charger

It takes about 3 hours and 20 minutes to charge a fully

exhausted battery.

AC Adapter

EH-67A AC Adapter

(connect as shown)

Before closing the battery-chamber/memory card slot

cover, fully insert the power connector cable into the slot

in the battery chamber. If part of the cable protrudes from

the slots, the cover or cable may be damaged when the

cover is closed.

Remote Control* ML-L3 Remote Control

Filter 67mm screw-on filter (Nikon product)

E117

Reference Section

Use the ML-L3 Remote Control (available separately) (E116) to release the

shutter. Set Vibration reduction (E104) in the setup menu to Off when

using a tripod to stabilize the camera.

1 Press the multi selector J (n).

2 Select remote control mode and

press the k button.

• Z: Press the transmission button on the

remote control to shoot instantly (remote

instant shooting).

• Z 10s (10 seconds) and Z 2s (2 seconds):

Press the transmission button on the

remote control to shoot with the selected

seconds delay (self-timer remote control).

• If the k button is not pressed within a few seconds, the selection will be

canceled.

3 Frame the picture.

Shooting with ML-L3 Remote Control

Self-timer

1/250

1/250 F5.6

F5.6

25m 0s

840

E118

Reference Section

4 Aim the transmitter

at the infrared

receiver of the

camera (A1) and

press the

transmission button.

• Press the transmission

button from a distance of

5 m (16 ft) or less.

• In the remote instant shooting mode, once the subject is in focus, the

shutter is released.

• When the time for self-timer is set to Z 10s (10 seconds) or Z 2s (2 seconds),

the self-timer lamp flashes when the subject is in focus, and then about 1

second before the shutter is released, the lamp stops flashing and remains lit.

To stop the self-timer before an image is captured, press the transmission

button again.

• In the self-timer remote control mode, the remote control mode is set to Z

(remote instant shooting) when the shutter is released.

Replacing the Battery for ML-L3 Remote Control (3V

CR2025 Lithium Battery)

• When changing the remote control battery, make sure that the battery’s

positive (+) and negative (–) terminals are oriented correctly.

• Make sure to read and follow the warnings of “For Your Safety” (Avi).

B Notes About the Remote Control

• The remote control may not function even from a distance of 5 m (16 ft) or less

when shooting in backlit conditions.

• The setting may not be changed when using certain settings of other functions.

E119

Reference Section

For Shooting

Principle Functions of the Controls

Control Main Function A

Mode dial

Change the shooting mode. 24

Zoom control

Move toward g (i) (telephoto) to zoom in

closer to the subject, and move toward f

(h) (wide-angle) to zoom out and view a

larger area.

Snap-back zoom button

Widen the angle of view temporarily. 21

Side zoom control

Use the function assigned in Assign side

zoom control.

• Zoom: Move toward g (telephoto) to

zoom in closer to the subject, and move

toward f (wide-angle) to zoom out and

view a larger area.

• Manual focus: When the focus mode is set

to E (manual focus), adjust the focus.

20, 57

41, 42

Multi selector

• While the shooting screen is displayed:

Display the following setting screens by

pressing:

-Up (H): m (flash mode)

-Left (J): n (self-timer/remote control/

smile timer)

-Down (I): p (focus mode)

-Right (K): o (exposure compensation)

• When the shooting mode is l or m:

Rotate the multi selector to set the

aperture value.

30, 32

• While the setting screen is displayed:

Select an item using HIJK or by

rotating the multi selector; apply the

selection by pressing the k button.

E120

Reference Section

Command dial

• When the shooting mode is

Set the flexible program.

• When the shooting mode is

k or m:

Set the shutter speed.

30, 32

d (menu) button

Display and hide the menu.

49, 51,

54, 55,

Shutter-release button

When pressed halfway (i.e., if you stop

pressing when you feel resistance slightly):

Set focus and exposure.

When pressed all the way (i.e., if you press

the button all the way down): Release the

shutter.

17, 21

b (e movie-record)

button

Start and stop movie recording. E32

w (function) button

When the shooting mode is j, k, l, m or

Display or close the setting menus such as

Continuous or Vibration reduction.

x (monitor) button

Switch between the monitor and viewfinder. 19

s (display) button

Switch the information displayed in the

monitor.

q (Wi-Fi) button

Turn on the Wi-Fi function and connect the

camera and a smart device.

60,

E45

Control Main Function A

E121

Reference Section

For Playback

c (playback) button

Play back images. 22

l (delete) button

Delete the last image that was saved. 23

Control Main Function A

c (playback) button

•

When the camera is turned off, press and hold

this button to turn the camera on in playback

mode.

• Return to shooting mode. 22

Zoom control

•

Move toward

(

) to zoom in on the

image, and move toward

(

) to

display images as thumbnails or the

calendar.

E23,

E24

• Adjust the volume for movie playback. E36

Multi selector

• While the playback screen is displayed:

Change the displayed image using up

(

H), left (J), down (I), right (K), or by

rotating the multi selector.

• While the setting screen is displayed:

Select an item using HIJK or by

rotating the multi selector.

• While an enlarged image is displayed:

Move the display area.

E23

Control Main Function A

E122

Reference Section

k (apply selection)

button

• Display individual images of a sequence in

full-frame playback mode.

56,

E25

• Scroll an image shot with Easy panorama. E12

• Play back movies. E32

• Switch from thumbnail playback or

zoomed image display to full-frame

playback.

E23,

E24

• While the setting screen is displayed,

apply the selection.

Command dial

Switch the magnification of an enlarged

image.

E23

d (menu) button

Display and hide the menu. 49, 55

l (delete) button

Delete images. 23

x (monitor) button

Switch between the monitor and viewfinder. 19

s (display) button

Switch the information displayed in the

monitor.

q (Wi-Fi) button

Turn on the Wi-Fi function and connect the

camera and a smart device.

60,

E45

Control Main Function A

E123

Reference Section

Shutter-release button

Return to shooting mode. –

b (e movie-record)

button

Control Main Function A

E124

Caring for the Product.....................................F2

The Camera.............................................................................................F2

The Battery..............................................................................................F3

The Charging AC Adapter .................................................................F4

Memory Cards........................................................................................F5

Cleaning and Storage......................................F6

Cleaning...................................................................................................F6

Storage .....................................................................................................F6

Troubleshooting..............................................F7

Specifications.................................................F16

Approved Memory Cards ............................................................... F20

USER LICENSE AGREEMENT FOR LOCATION

NAME DATA ...................................................F22

Index...............................................................F28

Technical Notes

and Index

Technical Notes and Index

Observe the precautions described below in addition to the warnings in “For

Your Safety” (Avi-viii) when using or storing the device.

The Camera

Do Not Apply Strong Impact to the Camera

The product may malfunction if subjected to strong shock or vibration. In addition,

do not touch or apply force to the lens or lens cover.

Keep Dry

The device will be damaged if immersed in water or subjected to high humidity.

Avoid Sudden Changes in Temperature

Sudden changes in temperature, such as when entering or leaving a heated building

on a cold day, can cause condensation to form inside the device. To prevent

condensation, place the device in a carrying case or a plastic bag before exposing it

to sudden changes in temperature.

Keep Away from Strong Magnetic Fields

Do not use or store this device in the vicinity of equipment that generates strong

electromagnetic radiation or magnetic fields. Doing so could result in loss of data or

camera malfunction.

Do Not Point the Lens at Strong Light Sources for Extended

Periods

Avoid pointing the lens at the sun or other strong light sources for extended periods

when using or storing the camera. Intense light may cause the image sensor to

deteriorate or produce a white blur effect in photographs.

Turn the Product Off Before Removing or Disconnecting

the Power Source or Memory Card

Do not remove the battery while the product is on, or while images are being saved

or deleted. Forcibly cutting power in these circumstances could result in loss of data

or in damage to product memory or internal circuitry.

Caring for the Product

Technical Notes and Index

Notes About the Monitor

• Monitors and electronic viewfinders are constructed with extremely high precision;

at least 99.99% of pixels are effective, with no more than 0.01% being missing or

defective. Hence while these displays may contain pixels that are always lit (white,

red, blue, or green) or always off (black), this is not a malfunction and has no effect

on images recorded with the device.

• Images in the monitor may be difficult to see under bright lighting.

• Do not apply pressure to the monitor, as this could cause damage or malfunction.

Should the monitor break, care should be taken to avoid injury caused by broken

glass and to prevent the liquid crystal from the display touching the skin or

entering the eyes or mouth.

Do not Attach a Commercially Available Step-up Ring, Etc.

to the Lens

Attaching accessories other than the provided lens cap or the Nikon 67mm screw-on

filter could cause a malfunction.

The Battery

Precautions for Use

• Note that the battery may become hot after use.

• Do not use the battery at ambient temperatures below 0°C (32°F) or above 40°C

(104°F) as this could cause damage or malfunction.

• If you notice any abnormalities such as excessive heat, smoke, or an unusual smell

coming from the battery, immediately discontinue use and consult your retailer or

Nikon-authorized service representative.

• After removing the battery from the camera or optional battery charger, put the

battery in a plastic bag, etc. in order to insulate it.

Charging the Battery

Check the battery level before using the camera and replace or charge the battery if

necessary.

• Charge the battery indoors with an ambient temperature of 5°C to 35°C (41°F to

95°F) before use.

• A high battery temperature may prevent the battery from charging properly or

completely, and may reduce battery performance. Note that the battery may

become hot after use; wait for the battery to cool before charging.

When charging the battery inserted into this camera using the Charging AC

Adapter or a computer, the battery is not charged at battery temperatures below

0°C (32°F) or above 50°C (122°F).

• Do not continue charging once the battery is fully charged as this will result in

reduced battery performance.

• The battery temperature may increase during charging. However, this is not a

malfunction.

Carrying Spare Batteries

Whenever possible, carry fully charged spare batteries when taking pictures on

important occasions.

Technical Notes and Index

Using the Battery When Cold

On cold days, the capacity of batteries tends to decrease. If an exhausted battery is used

at a low temperature, the camera may not turn on. Keep spare batteries in a warm place

and exchange as necessary. Once warmed, a cold battery may recover some of its charge.

Battery Terminals

Dirt on the battery terminals may prevent the camera from functioning. Should the

battery terminals become dirty, wipe them off with a clean, dry cloth before use.

Charging an Exhausted Battery

Turning the camera on or off while an exhausted battery is inserted in the camera

may result in reduced battery life. Charge the exhausted battery before use.

Storing the Battery

• Always remove the battery from the camera or optional battery charger when it is

not being used. Minute amounts of current are drawn from the battery while it is in

the camera, even when not in use. This may result in excessive battery drain and

complete loss of function.

• Recharge the battery at least once every six months and completely exhaust it

before returning it to storage.

• Put the battery in a plastic bag, etc. in order to insulate it and store it in a cool place.

The battery should be stored in a dry location with an ambient temperature of 15°C

to 25°C (59°F to 77°F). Do not store the battery in hot or extremely cold locations.

Battery Life

A marked drop in the time a fully charged battery retains its charge, when used at room

temperature, indicates that the battery needs to be replaced. Purchase a new battery.

Recycling Used Batteries

Replace the battery when it no longer holds a charge. Used batteries are a valuable

resource. Please recycle used batteries in accordance with local regulations.

The Charging AC Adapter

• The EH-71P/EH-71PCH/EH-73P/EH-73PCH Charging AC Adapter is for use only with

compatible devices. Do not use with another make or model of device.

• Do not use any USB cable other than the UC-E21. Using a USB cable other than the

UC-E21 could result in overheating, fire or electric shock.

•

Do not, under any circumstances, use another make or model of AC adapter other than

the EH-71P/EH-71PCH/EH-73P/EH-73PCH Charging AC Adapter, and do not use a

commercially available USB-AC adapter or a battery charger for a mobile phone. Failure

to observe this precaution could result in overheating or in damage to the camera.

• The EH-71P/EH-71PCH/EH-73P/EH-73PCH is compatible with AC 100–240 V, 50/60

Hz electrical outlets. When using in other countries, use a plug adapter

(commercially available) as necessary. For more information about plug adapters,

consult your travel agency.

Technical Notes and Index

Memory Cards

Precautions for Use

• Use only Secure Digital memory cards. See “Approved Memory Cards” (F20) for

recommended memory cards.

• Be sure to follow the precautions described in the documentation included with

the memory card.

• Do not put labels or stickers on memory cards.

Formatting

• Do not format the memory card using a computer.

• The first time you insert a memory card that has been used in another device into

this camera, be sure to format it with this camera. We recommend formatting new

memory cards with this camera before using them with this camera.

• Note that formatting a memory card permanently deletes all images and

other data on the memory card. Be sure to make copies of any images you wish

to keep before formatting the memory card.

• If the message Card is not formatted. Format card? is displayed when the

camera is turned on, the memory card must be formatted. If there is data that you

do not want to delete, select No. Copy the necessary data to a computer, etc. If you

want to format the memory card, select Yes. The confirmation dialog will be

displayed. To start formatting, press the k button.

• Do not perform the following during formatting, while data is being written to or

deleted from the memory card, or during data transfer to a computer. Failure to

observe this precaution could result in the loss of data or in damage to the camera

or memory card:

- Open the battery-chamber/memory card slot cover to remove/insert the battery

or memory card.

- Turn off the camera.

- Disconnect the AC adapter.

Technical Notes and Index

Cleaning

Do not use alcohol, thinner, or other volatile chemicals.

Storage

Remove the battery if the camera will not be used for an extended period. To

prevent mold or mildew, take the camera out of storage at least once a month.

Turn the camera on and release the shutter a few times before putting the

camera away again. Do not store the camera in any of the following locations:

• Places that are poorly ventilated or subject to humidity of over 60%

• Exposed to temperatures above 50°C (122°F) or below –10°C (14°F)

• Next to equipment that produces strong electromagnetic fields, such as

televisions or radios

For storing the battery, follow the precautions in “The Battery” (F3) in “Caring

for the Product” (F2).

Cleaning and Storage

Lens/

viewfinder

Avoid touching glass parts with your fingers. Remove dust or lint with

a blower (typically a small device with a rubber bulb attached to one

end that is pumped to produce a stream of air out the other end). To

remove fingerprints or other stains that cannot be removed with a

blower, wipe the lens with a soft cloth, using a spiral motion that

starts at the center of the lens and working toward the edges. If this

fails, clean the lens using a cloth lightly dampened with commercial

lens cleaner.

Monitor

Remove dust or lint with a blower. To remove fingerprints and other

stains, clean the monitor with a soft, dry cloth, being careful not to

apply pressure.

Body

Use a blower to remove dust, dirt, or sand, then wipe gently with a

soft, dry cloth. After using the camera at the beach or other sandy or

dusty environment, wipe off any sand, dust, or salt with a dry cloth

lightly dampened with fresh water and dry thoroughly. Note that

foreign matter inside the camera could cause damage not

covered by the warranty.

Technical Notes and Index

If the camera fails to function as expected, check the list of common problems

below before consulting your retailer or Nikon-authorized service

representative.

Power, Display, Settings Issues

Troubleshooting

Problem Cause/Solution

The camera is on

but does not

respond.

• Wait for recording to end.

• If the problem persists, turn the camera off.

If the camera does not turn off, remove and reinsert

the battery or batteries or, if you are using an AC

adapter, disconnect and reconnect the AC adapter.

Note that although any data currently being

recorded will be lost, data that have already been

recorded will not be affected by removing or

disconnecting the power source.

–

The camera

cannot be

turned on.

The battery is exhausted.

10, 11,

The camera

turns off without

warning.

• The camera automatically turns off to save power

(auto off function).

• The camera and battery may not work properly at

low temperatures.

• The inside of the camera has become hot. Leave the

camera off until the inside of the camera has cooled,

and then try turning it on again.

–

The monitor or

viewfinder is

blank.

• The camera is off.

• The battery is exhausted. 16

• The camera automatically turns off to save power

(auto off function).

• You cannot turn on both the monitor and viewfinder

at the same time. It may take a while to switch

between the monitor and viewfinder.

–

• The camera is connected to a TV or computer. –

• Interval timer shooting or time-lapse movie shooting

is in progress.

E13,

E69

• The camera and smart device are connected using

Wi-Fi connection and the camera is operated by

remote control.

–

Technical Notes and Index

The camera

becomes hot.

The camera may become hot when used for an

extended period of time such as to shoot movies, or

when used in a hot environment; this is not a

malfunction.

–

The battery

inserted in the

camera cannot

be charged.

• Confirm all connections.

• When connected to a computer, the camera may not

charge for any of the reasons described below.

- Off is selected for Charge by computer in the

setup menu.

49, 58

- Battery charging stops if the camera is turned off. –

- Battery charging is not possible if the camera’s

display language and date and time have not been

set, or the date and time were reset after the

camera’s clock battery was exhausted. Use the

charging AC adapter to charge the battery.

14, 15

- Battery charging may stop when the computer

enters sleep mode.

–

- Depending on the computer specifications,

settings, and status, battery charging may not be

possible.

–

The monitor is

hard to read.

• The ambient light is too bright. Move to a darker

place or use the viewfinder.

• Adjust the monitor brightness. 49, 57

• The monitor is dirty. Clean the monitor.

Image in the

viewfinder is

difficult to see.

Adjust the viewfinder using the diopter adjustment

control.

O flashes on the

screen.

• If the camera clock has not been set, O flashes on

the shooting screen, and images and movies saved

before the clock is set are dated “00/00/0000 00:00”

and “01/01/2015 00:00” respectively. Set the correct

time and date for Time zone and date in the setup

menu.

5, 57

Date and time of

recording are

not correct.

• The camera clock is not as accurate as ordinary

watches or clocks. Periodically compare the time of

the camera clock with that of a more accurate

timepiece and reset as required.

No information

displayed in

monitor.

Shooting and photo information may be hidden. Press

the s button until information is displayed.

Date stamp not

available.

Time zone and date has not been set in the setup

menu.

49, 57

Problem Cause/Solution

Technical Notes and Index

Shooting Issues

Date not

stamped on

images even

when Date

stamp is

enabled.

• The current shooting mode does not support Date

stamp.

49, 57

• A function that restricts the Date stamp function is

enabled.

• The date cannot be stamped on movies.

–

Screen for

setting time

zone and date is

displayed when

the camera is

turned on.

The clock battery is exhausted; all settings were

restored to their default values.

15,

The camera

settings reset.

Reset file

numbering

cannot be done.

Although a new folder is created on the memory card

by resetting file numbering, etc., if the sequential

number of a folder name (which is not displayed on the

camera) reaches the upper limit (“999”), reset is not

possible. Change the memory card, or format the

memory card.

49, 58,

E109

The camera

makes sound.

When Autofocus mode is set to Full-time AF or while

in some shooting modes, the camera may produce an

audible focusing sound.

24, 49,

52, 54

Problem Cause/Solution

Cannot switch

to shooting

mode.

Disconnect the HDMI cable or USB cable.

Cannot take

pictures or

record movies.

• When the camera is in playback mode, press the c

button, shutter-release button or b (e) button.

1, 22

• When menus are displayed, press the d button. 50

• When the scene mode is Night portrait or

Backlighting with HDR set to Off, raise the flash.

18,

E3,

• The flash is charging while q is flashing. 36

• The battery is exhausted.

• Insert a memory card with sufficient free space.

10, 11,

–

Problem Cause/Solution

F10

Technical Notes and Index

The camera

cannot focus.

• The subject is too close. Try shooting using the

Scene auto selector or Close-up scene mode, or

the macro close-up focus mode.

24, 25,

40,

E4,

• Incorrect focus mode setting. Check or change the

setting.

40, 41

• The subject is hard to focus on. E20

• Set AF assist in the setup menu to Auto. 49, 57

• Subject is not in focus area when the shutter-release

button is pressed halfway.

17, 49,

• The focus mode is set to E (manual focus). 40, 42

• Turn the camera off and then on again.

–

Colored stripes

appear in the

monitor when

shooting.

Colored stripes may appear when shooting subjects

with repeating patterns (such as window blinds); this is

not a malfunction.

The colored stripes will not appear in captured images

or recorded movies. However, when using Continuous

H: 120 fps or HS 480/4×, the colored stripes may be

seen in the captured images and recorded movies.

–

Images are

blurred.

• Use the flash.

18, 36

• Enable vibration reduction. 49, 57

• Use D (Best Shot Selector) of Continuous. 49, 52,

• Use a tripod to stabilize the camera (using the self-

timer at the same time is more effective).

Bright specks

appear in

images captured

with flash.

Flash is reflecting off particles in air. Lower the flash, and

set the flash mode to W (off ).

Flash does not

fire.

• A shooting mode where the flash cannot fire is

selected.

E15

• A function that restricts the flash is enabled.

Digital zoom

cannot be used.

• Digital zoom is set to Off

in the setup menu.

49, 57

• D

igi

tal zoom cannot be used with certain shooting

modes or when using certain settings in other

functions.

48, 57

Image size not

available.

• A function that restricts the Image size option is

enabled.

• When the scene mode is set to Easy panorama, the

image size is fixed.

E10

Problem Cause/Solution

F11

Technical Notes and Index

No sound when

the shutter is

released.

Off is selected for Shutter sound in Sound settings

in the setup menu. No sound is produced with some

shooting modes and settings, even when On is

selected.

46, 49,

AF-assist

illuminator does

not light.

Off is selected for the AF assist option in the setup

menu. AF-assist illuminator may not light depending on

the position of the focus area or the current scene

mode, even when Auto is selected.

49, 57

Images appear

smeared.

The lens is dirty. Clean the lens. F6

Colors are

unnatural.

White balance or hue is not adjusted properly.

49, 51,

Randomly

spaced bright

pixels (“noise”)

appear in image.

The subject is dark and the shutter speed is too slow or

ISO sensitivity is too high. Noise can be reduced by:

• Using the flash 18, 36

• Specifying a lower ISO sensitivity setting

49, 52

Bright spots

appear in image.

When shooting at a slow shutter speed in multiple

exposure mode, noise (bright spots) may appear in

saved images.

–

Images are too

dark

(underexposed).

• The flash window is blocked.

• The subject is beyond the range of the flash. F17

• Adjust exposure compensation. 44

• Increase ISO sensitivity. 49, 52

• The subject is backlit. Raise the flash, or set the scene

mode to Backlighting with HDR set to Off.

18,

Images are too

bright

(overexposed).

Adjust exposure compensation. 44

Unexpected

results when

flash set to V

(auto with red-

eye reduction).

Use any scene mode other than Night portrait, and

change the flash mode to any setting other than V

(auto with red-eye reduction/red-eye reduction) and try

taking the picture again.

36,

E15

in ton

es are

not softened.

• In some shooting conditions, facial skin tones may

not be softened.

E20

• For images containing 4 or more faces, try using Skin

softening in the playback menu.

49, 55

Problem Cause/Solution

F12

Technical Notes and Index

Saving images

takes time.

It may take more time to save images in the following

situations:

• When the noise reduction function is in operation –

• When the flash mode is set to V (auto with red-eye

reduction/red-eye reduction)

• When capturing images in the following scene

modes.

- Hand-held in Night landscape E3

- Noise reduction burst in Landscape or Close-

E4,

- Backlighting (when HDR is set to On) E7

- Easy panorama E10

•Continuous in the shooting menu is set to

Continuous H: 120 fps or Continuous H: 60 fps

49, 52

• When using smile timer while shooting 39

• When using Active D-Lighting while shooting 49, 52

• When using multiple exposure while shooting

49, 52

A ring-shaped

belt or rainbow-

colored stripe

appears in the

monitor or

images.

When shooting with backlighting or when a very strong

light source (such as sunlight) is in the frame, a ring-

shaped belt or rainbow-colored stripe (ghosting) may

occur.

Change the position of the light source, or frame the

picture so that the light source does not enter the

frame, and try again.

–

Cannot select a

setting/Selected

setting is

disabled.

• Certain menu items are unavailable depending on

the shooting mode. Menu items that cannot be

selected are displayed in gray.

• A function that restricts the selected function is

enabled.

–

Problem Cause/Solution

F13

Technical Notes and Index

Playback Issues

Problem Cause/Solution

File cannot be

played back.

• This camera may not be able to play back images

saved with another make or model of digital camera.

–

• This camera may not be able to play back data edited

on a computer.

–

•

Files cannot be played back during interval timer

shooting.

49, 52

Cannot zoom in

on image.

•

Playback zoom cannot be used with movies.

• This camera may not be able to zoom in on images

captured with another make or model of digital

camera.

• When zooming in on a small-sized image, the

magnification rate shown on the screen may differ

from the actual magnification rate of the image.

–

Cannot edit

image.

• Some images cannot be edited. Images that have

already been edited may not be edited again.

• There is not enough free space on the memory card.

• This camera is unable to edit images captured with

other cameras.

• Editing functions used for images are not available

for movies.

E12,

E26

–

Cannot rotate

image.

This camera cannot rotate images captured with

another make or model of digital camera.

–

Images are not

displayed on TV.

• A computer or printer is connected to the camera.

–

• The memory card contains no images.

Nikon Transfer 2

does not start

when the

camera is

connected to a

computer.

• The camera is off.

–

• The battery is exhausted. 49, 58,

• The USB cable is not correctly connected. 61,

E53

• The camera is not recognized by the computer. –

• The computer is not set to start Nikon Transfer 2

automatically. For more information about Nikon

Transfer 2, refer to help information contained in

ViewNX-i.

–

The PictBridge

screen is not

displayed when

the camera is

connected to a

printer.

With some PictBridge-compatible printers, the

PictBridge startup screen may not be displayed and it

may be impossible to print images when Auto is

selected for Charge by computer in the setup menu.

Set Charge by computer to Off and reconnect the

camera to the printer.

49, 58

F14

Technical Notes and Index

Location Data Functions

Images to be

printed are not

displayed.

The memory card contains no images.

–

Cannot select

paper size with

the camera.

The camera cannot be used to select the paper size in

the following situations, even when printing from a

PictBridge-compatible printer. Use the printer to select

the paper size.

• The printer does not support the paper sizes

specified by the camera.

• The printer automatically selects the paper size.

–

Problem Cause/Solution

Unable to

identify the

location or it

takes time to

identify the

location.

• The camera may not be able to identify the location

in some shooting environments. To use the location

data functions, use the camera as much as possible

in an open-air area.

• When positioning for the first time or when

positioning was unable to be performed for about

two hours, it takes a few minutes to obtain the

location data.

E40

Unable to record

location data on

shot images.

When z or y is displayed on the shooting screen, the

location data is not recorded. Before shooting images,

check the location data reception.

Difference

between the

actual shooting

location and

recorded

location data.

The acquired location data may deviate in some

shooting environments. When there is a significant

difference in the signals from the positioning satellites,

there could be a deviation of up to several hundred

meters.

E40

The recorded

location name is

different from

the intended

one or is not

displayed.

The desired landmark name may not be registered, or a

different landmark name may be registered.

–

Problem Cause/Solution

F15

Technical Notes and Index

Unable to

update the A-

GPS file.

• Check the following items.

- Whether the memory card is inserted

- Whether the A-GPS file is stored on the memory

card

- Whether the A-GPS file saved on the memory card

is more recent than the A-GPS file saved in the

camera

- Whether the A-GPS file is still valid

• The A-GPS file may be corrupted. Download the file

from the website once more.

–

E95

Unable to select

Create log in

the location data

options menu.

Clock not set.

Set date and time.

49, 57

Unable to select

Start log.

• Record location data in the location data options

menu is set to Off.

• The camera is recording log data. To record a new

log, select End log, and end the log currently being

recorded.

E39

49,

E44

Unable to save

log data.

• Make sure that a memory card is inserted in the

camera.

• Up to 36 log data events can be recorded per day.

• Log has not been obtained.

• The total number of log data events that can be

saved on a single memory card is up to 100. Delete

log data that is no longer required from the memory

card or replace the memory card with a new one.

–

E43

49,

E44

Problem Cause/Solution

F16

Technical Notes and Index

Nikon COOLPIX P900 Digital Camera

Specifications

Type Compact digital camera

Number of effective

pixels

16.0 million (Image processing may reduce the

number of effective pixels.)

Image sensor 1/2.3-in. type CMOS; approx. 16.76 million total pixels

Lens NIKKOR lens with 83× optical zoom

Focal length

4.3–357 mm (angle of view equivalent to that of 24–

2000 mm lens in 35mm [135] format)

f/-number f/2.8–6.5

Construction

16 elements in 12 groups (5 ED lens elements and 1

super ED lens element)

Digital zoom

magnification

Up to 4× (angle of view equivalent to that of approx. 8000

mm lens in 35mm [135] format)

Vibration reduction

Lens shift (still images)

Combination of lens shift and electronic VR (movies)

Autofocus (AF) Contrast-detect AF

Focus range

• [W]: Approx. 50 cm (1 ft 8 in.)–,

[T]: Approx. 5.0 m (16 ft 5 in.)–

• Macro close-up mode: Approx. 1 cm (0.4 in.)–(wide-

angle position)

(All distances measured from center of front surface of

lens)

Focus-area selection

Target finding AF, face priority, manual (spot), manual

(normal), manual (wide), subject tracking

Viewfinder

Electronic viewfinder, 0.5 cm (0.2-in.) approx. 921k-dot

LCD with the diopter adjustment function

(–3 – +1 m

-1

)

Frame coverage

(shooting mode)

Approx. 100% horizontal and vertical (compared to

actual picture)

Frame coverage

(playback mode)

Approx. 100% horizontal and vertical (compared to

actual picture)

Monitor

7.5 cm (3-in.), approx. 921k-dot (RGBW), wide viewing

angle TFT LCD with anti-reflection coating and 6-level

brightness adjustment, vari-angle TFT LCD

Frame coverage

(shooting mode)

Approx. 100% horizontal and vertical (compared to

actual picture)

Frame coverage

(playback mode)

Approx. 100% horizontal and vertical (compared to

actual picture)

F17

Technical Notes and Index

Storage

Media SD/SDHC/SDXC memory card

File system DCF and Exif 2.3 compliant

File formats

Still images: JPEG

Movies: MOV (Video: H.264/MPEG-4 AVC, Audio: LPCM

stereo)

Image size (pixels)

ISO sensitivity

(Standard output

sensitivity)

• ISO 100–1600

• ISO 3200, 6400 (available when using j, k, l or m

mode)

• Hi 1 (equivalent to ISO 12800) (available when using

High ISO monochrome in special effects mode)

Exposure

Metering mode Matrix, center-weighted, spot

Exposure control

Programmed auto exposure with flexible program,

shutter-priority auto, aperture-priority auto, manual,

exposure bracketing, exposure compensation (–2.0 EV

– +2.0 EV in steps of 1/3 EV)

Shutter Mechanical and CMOS electronic shutter

Speed

• 1/4000 *–1 s

• 1/4000 *–15 s (when ISO sensitivity is 100 in m

mode)

* When the aperture value is set to f/8 (wide-angle

position)

Aperture Electronically-controlled 6-blade iris diaphragm

Range 10 steps of 1/3 EV (W) (l, m mode)

Self-timer Can be selected from 10 s and 2 s

Flash

Range (approx.)

(ISO sensitivity: Auto)

[W]: Approx. 0.5–11.5 m (1 ft 8 in.–37 ft)

[T]: Approx. 5.0–7.0 m (16 ft 5 in.–22 ft)

Flash control TTL auto flash with monitor preflashes

Flash exposure

compensation

In steps of 1/3 EV in the range between –2 and +2 EV

• 16 M 4608×3456

• 8 M 3264×2448

• 4 M 2272×1704

• 2 M 1600×1200

• VGA 640×480

• 16:9 12 M 4608×2592

• 16:9 2 M 1920×1080

• 3:2 14 M 4608×3072

• 1:1 12 M 3456×3456

F18

Technical Notes and Index

Interface

USB connector

Micro-USB connector (Do not use any USB cable other

than the UC-E21.), Hi-Speed USB

• Supports Direct Print (PictBridge)

HDMI output

connector

HDMI micro connector (Type D)

Wireless LAN

Standards IEEE 802.11b/g/n (standard wireless LAN protocol)

Range (line of sight) Approx. 10 m (10 yd)

Operating frequency 2412–2462 MHz (1–11 channels)

Authentication Open system, WPA2-PSK

Access protocols Infrastructure

Location data

•GPS

Receiving frequency: 1575.42 MHz

Geodetic system: WGS 84

•GLONASS

Receiving frequency: 1598.0625 MHz–

1605.3750 MHz

Geodetic system: WGS 84

Supported languages

Arabic, Bengali, Bulgarian, Chinese (Simplified and

Traditional), Czech, Danish, Dutch, English, Finnish,

French, German, Greek, Hindi, Hungarian, Indonesian,

Italian, Japanese, Korean, Marathi, Norwegian, Persian,

Polish, Portuguese (European and Brazilian), Romanian,

Russian, Serbian, Spanish, Swedish, Tamil, Telugu, Thai,

Turkish, Ukrainian, Vietnamese

Power sources

One EN-EL23 Rechargeable Li-ion Battery (included)

EH-67A AC Adapter (available separately)

Charging time

Approx. 3 h 40 min (when using EH-71P/EH-71PCH/

EH-73P/EH-73PCH Charging AC Adapter and when no

charge remains)

Battery life

Still images Approx. 360 shots when using EN-EL23

Movie recording

(actual battery life

for recording)

Approx. 1 h 20 min when using EN-EL23

Tripod socket 1/4 (ISO 1222)

F19

Technical Notes and Index

• Unless otherwise stated, all figures assume a fully-charged battery and an

ambient temperature of 23 ±3°C (73.4 ±5.4°F) as specified by the Camera

and Imaging Products Association (CIPA).

Battery life may vary depending on conditions of use, such as the interval between

shots or the length of time that menus and images are displayed.

Individual movie files cannot exceed 4 GB in size or 29 minutes in length.

Recording may end before this limit is reached if camera temperature becomes

elevated.

EN-EL23 Rechargeable Li-ion Battery

Dimensions

(W × H × D)

Approx. 139.5 × 103.2 × 137.4 mm (5.5 × 4.1 × 5.5 in.)

(excluding projections)

Weight

Approx. 899 g (1 lb 15.8 oz) (including battery and

memory card)

Operating environment

Temperature 0°C–40°C (32°F–104°F)

Humidity 85% or less (no condensation)

Type Rechargeable lithium-ion battery

Rated capacity DC 3.8 V, 1850 mAh

Operating temperature 0°C–40°C (32°F–104°F)

Dimensions (W × H × D) Approx. 34.9 × 47 × 10.5 mm (1.4 × 1.9 × 0.5 in.)

Weight Approx. 34 g (1.2 oz)

F20

Technical Notes and Index

EH-71P/EH-71PCH/EH-73P/EH-73PCH Charging AC Adapter

The symbols on this product represent the following:

D AC, E DC, F Class II equipment (The construction of the product is double-

insulated.)

• Nikon will not be held liable for any errors this manual may contain.

• The appearance of this product and its specifications are subject to change

without notice.

Approved Memory Cards

The following Secure Digital (SD) memory cards have been tested and

approved for use in this camera.

• Memory cards with an SD Speed Class rating of 6 or faster are

recommended for recording movies. When using a memory card with a

lower Speed Class rating, movie recording may stop unexpectedly.

•

Contact the manufacturer for details on the above cards. We cannot guarantee

camera performance when using memory cards made by other manufacturers.

•

If you use a card reader, make sure that it is compatible with your memory card.

Rated input

EH-71P/EH-71PCH AC 100–240 V, 50/60 Hz, MAX 0.2 A

EH-73P/EH-73PCH AC 100–240 V, 50/60 Hz, MAX 0.14 A

Rated output DC 5.0 V, 1.0 A

Operating temperature 0°C–40°C (32°F–104°F)

Dimensions (W × H × D)

Approx. 55 × 22 × 54 mm (2.2 × 0.9 × 2.2 in.)

(excluding plug adapter)

For Argentina: Approx. 55 × 63 × 59 mm (2.2 × 2.5 × 2.4 in.)

For Brazil: Approx. 55 × 67 × 59 mm (2.2 × 2.7 × 2.4 in.)

For India: Approx. 55 × 63.5 × 59 mm

Weight

EH-71P/EH-71PCH

Approx. 48 g (1.7 oz) (excluding plug adapter)

For Argentina and India: Approx. 73 g (2.6 oz)

For Brazil: Approx. 70 g

EH-73P/EH-73PCH

Approx. 51 g (1.8 oz) (excluding plug adapter)

For Argentina and India: Approx. 76 g (2.7 oz)

For Brazil: Approx. 73 g

SD memory card SDHC memory card SDXC memory card

SanDisk

4 GB, 8 GB, 16 GB, 32 GB 64 GB, 128 GB

TOSHIBA

4 GB, 8 GB, 16 GB, 32 GB 64 GB

Panasonic 2 GB 4 GB, 8 GB, 16 GB, 32 GB 64 GB

Lexar

8 GB, 16 GB, 32 GB 64 GB, 128 GB

F21

Technical Notes and Index

Trademark Information

• Windows is either a registered trademark or trademark of Microsoft

Corporation in the United States and/or other countries.

• Adobe, the Adobe logo, and Reader are either trademarks or registered

trademarks of Adobe Systems Incorporated in the United States and/or

other countries.

• SDXC, SDHC, and SD Logos are trademarks of SD-3C, LLC.

• PictBridge is a trademark.

• HDMI, HDMI logo and High-Definition Multimedia Interface are trademarks

or registered trademarks of HDMI Licensing LLC.

• Wi-Fi and the Wi-Fi logo are trademarks or registered trademarks of the Wi-Fi

Alliance.

• Android and Google Play are trademarks or registered trademarks of Google,

Inc.

• The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the

United States and in other countries.

• All other trade names mentioned in this manual or the other

documentation provided with your Nikon product are trademarks or

registered trademarks of their respective holders.

AVC Patent Portfolio License

This product is licensed under the AVC Patent Portfolio License for the personal

and non-commercial use of a consumer to (i) encode video in compliance with

the AVC standard (“AVC video”) and/or (ii) decode AVC video that was encoded

by a consumer engaged in a personal and non-commercial activity and/or was

obtained from a video provider licensed to provide AVC video. No license is

granted or shall be implied for any other use. Additional information may be

obtained from MPEG LA, L.L.C.

See http://www.mpegla.com.

FreeType License (FreeType2)

MIT License (HarfBuzz)

F22

Technical Notes and Index

The location name data that is stored in this digital camera (“Data”) is provided for

your personal, internal use only and not for resale. It is protected by copyright, and is

subject to the following terms and conditions which are agreed to by you, on the

one hand, and Nikon Corporation (“Nikon”) and its licensors (including their licensors

and suppliers) on the other hand.

Terms and Conditions

Personal Use Only. You agree to use this Data together with this digital camera and

the image data taken by the digital camera for the solely personal, non-commercial

purposes for which you were licensed, and not for service bureau, time-sharing or

other similar purposes.

Accordingly, but subject to the restrictions set forth in the following paragraphs, you

agree not to otherwise reproduce, copy, modify, decompile, disassemble or reverse

engineer any portion of this Data, and may not transfer or distribute it in any form, for

any purpose, except to the extent permitted by mandatory laws.

Restrictions.

Except where you have been specifically licensed to do so by Nikon, and

without limiting the preceding paragraph, you may not (a) use this Data with any

products, systems, or applications installed or otherwise connected to or in

communication with vehicles, capable of vehicle navigation, positioning, dispatch,

real time route guidance, fleet management or similar applications; or (b) with or in

communication with any positioning devices or any mobile or wireless-connected

electronic or computer devices, including without limitation cellular phones,

palmtop and handheld computers, pagers, and personal digital assistants or PDAs.

Warning.

The Data may contain inaccurate or incomplete information due to the

passage of time, changing circumstances, sources used and the nature of collecting

comprehensive geographic data, any of which may lead to incorrect results.

No Warranty.

This Data is provided to you “as is,” and you agree to use it at your own

risk. Nikon and its licensors (and their licensors and suppliers) make no guarantees,

representations or warranties of any kind, express or implied, arising by law or

otherwise, including but not limited to, content, quality, accuracy, completeness,

effectiveness, reliability, fitness for a particular purpose, usefulness, use or results to

be obtained from this Data, or that the Data or server will be uninterrupted or error-

free.

Disclaimer of Warranty:

NIKON AND ITS LICENSORS (INCLUDING THEIR LICENSORS

AND SUPPLIERS) DISCLAIM ANY WARRANTIES, EXPRESS OR IMPLIED, OF QUALITY,

PERFORMANCE, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-

INFRINGEMENT. Some States, Territories and Countries do not allow certain warranty

exclusions, so to that extent the above exclusion may not apply to you.

USER LICENSE AGREEMENT FOR LOCATION

NAME DATA

F23

Technical Notes and Index

Disclaimer of Liability: NIKON AND ITS LICENSORS (INCLUDING THEIR LICENSORS

AND SUPPLIERS) SHALL NOT BE LIABLE TO YOU: IN RESPECT OF ANY CLAIM, DEMAND

OR ACTION, IRRESPECTIVE OF THE NATURE OF THE CAUSE OF THE CLAIM, DEMAND

OR ACTION ALLEGING ANY LOSS, INJURY OR DAMAGES, DIRECT OR INDIRECT, WHICH

MAY RESULT FROM THE USE OR POSSESSION OF THE INFORMATION; OR FOR ANY

LOSS OF PROFIT, REVENUE, CONTRACTS OR SAVINGS, OR ANY OTHER DIRECT,

INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF

YOUR USE OF OR INABILITY TO USE THIS INFORMATION, ANY DEFECT IN THE

INFORMATION, OR THE BREACH OF THESE TERMS OR CONDITIONS, WHETHER IN AN

ACTION IN CONTRACT OR TORT OR BASED ON A WARRANTY, EVEN IF NIKON OR ITS

LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some

States, Territories and Countries do not allow certain liability exclusions or damages

limitations, so to that extent the above may not apply to you.

Export Control.

You agree not to export from anywhere any part of the Data or any

direct product thereof except in compliance with, and with all licenses and approvals

required under, applicable export laws, rules and regulations, including but not

limited to the laws, rules and regulations administered by the Office of Foreign Assets

Control of the U.S. Department of Commerce and the Bureau of Industry and Security

of the U.S. Department of Commerce. To the extent that any such export laws, rules

or regulations prohibit Nikon and its licensors from complying with any of its

obligations hereunder to deliver or distribute Data, such failure shall be excused and

shall not constitute a breach of this Agreement.

Entire Agreement.

These terms and conditions constitute the entire agreement

between Nikon (and its licensors, including their licensors and suppliers) and you

pertaining to the subject matter hereof, and supersedes in their entirety any and all

written or oral agreements previously existing between us with respect to such

subject matter.

Governing Law.

The above terms and conditions shall be governed by the laws of

the Japan, without giving effect to (i) its conflict of laws provisions, or (ii) the United

Nations Convention for Contracts for the International Sale of Goods, which is

explicitly excluded; provided that in the event that the laws of the Japan is not

deemed applicable to this Agreement for any reason in the country where you

obtained the Data, this Agreement shall be governed with the laws of the country

where you obtained the Data. You agree to submit to the jurisdiction of Japan for

any and all disputes, claims and actions arising from or in connection with the Data

provided to you hereunder.

F24

Technical Notes and Index

Government End Users. If the Data supplied by HERE is being acquired by or on

behalf of the United States government or any other entity seeking or applying rights

similar to those customarily claimed by the United States government, the Data is a

“commercial item” as that term is defined at 48 C.F.R. (“FAR”) 2.101, is licensed in

accordance with the End-User Terms under which this Data was provided, and each

copy of the Data delivered or otherwise furnished shall be marked and embedded as

appropriate with the following “Notice of Use,” and shall be treated in accordance

with such Notice:

If the Contracting Officer, federal government agency, or any federal official refuses

to use the legend provided herein, the Contracting Officer, federal government

agency, or any federal official must notify HERE prior to seeking additional or

alternative rights in the Data.

NOTICE OF USE

CONTRACTOR (MANUFACTURER/ SUPPLIER) NAME:

HERE

CONTRACTOR (MANUFACTURER/ SUPPLIER) ADDRESS:

425 West Randolph Street, Chicago, Illinois 60606

This Data is a commercial item as defined in

FAR 2.101 and is subject to the End-User

Terms under which this Data was provided.

F25

Technical Notes and Index

Notices related to licensed software copyright holders.

• Location name data for Japan

• Location name data except for Japan

Austria:  Bundesamt für Eich- und Vermessungswesen

Belgium:  - Distribution & Copyright CIRB

Croatia/Cyprus/Estonia/Latvia/Lithuania/Moldova/Poland/Slovenia/Ukraine: 

EuroGeographics

Denmark: Contains data that is made available by the Danish Geodata Agency (FOT) Retrieved by

HERE 01/2014

Finland: Contains data from the National Land Survey of Finland Topographic Database 06/2012.

(Terms of Use available at

(

http://www.maanmittauslaitos.fi/en/

NLS_open_data_licence_version1_20120501

)

Contains data that is made available by Itella in accordance with the terms available at

(

http://

www.itella.fi/liitteet/palvelutjatuotteet/yhteystietopalvelut/

uusi_postal_code_services_service_description_and_terms_of_use.pdf

)

. Retrieved by HERE 09/2013

France: source:  IGN 2009 – BD TOPO 

Germany: Die Grundlagendaten wurden mit Genehmigung der zuständigen Behörden entnommen

Contains content of „ BayrischeVermessungsverwaltung –

(

www.geodaten.bayern.de

)

“, licensed in

accordance with

(

http://creativecommons.org/licenses/by/3.0/legalcode

)

Contains content of “LGL,

(

www.lgl-bw.de

)

“, licensed in accordance with

(

http://

creativecommons,.org/licenses/by/3.0/legalcode

)

Contains content of “Stadt Köln – offenedaten-koeln.de”, licensed in accordance with

(

http://

creativecommons.org/licenses/by/3.0/legalcode

)

Contains Content of “Geoportal Berlin / ATKIS Basis-DLM”, licensed in accordance with

(

http://

www.stadtentwicklung.berlin.de/geoinformation/download/nutzIII.pdf

)

Contains Content of “Geoportal Berlin / Karte von Berlin 1:5000 (K5-Farbausgabe)”, licensed in

accordance with

(

http://www.stadtentwicklung.berlin.de/geoinformation/download/nutzIII.pdf

)

Great Britain: Contains Ordnance Survey data  Crown copyright and database right 2010

Greece: Copyright Geomatics Ltd.

Italy: La Banca Dati Italiana è stata prodotta usando quale riferimento anche cartografia numerica ed

al tratto prodotta e fornita dalla Regione Toscana.

Contains data from Trasporto Passeggeri Emilia-Romagna- S.p.A.

Includes content of Comune di Bologna licensed under

(

http://creativecommons.org/licenses/by/3.0/

legalcode

)

and updated by licensee July 1, 2013.

Includes content of Comune di Cesena licensed under

(

http://creativecommons.org/licenses/by/3.0/

legalcode

)

and updated by licensee July 1, 2013.

Includes contents of Ministero della Salute, and Regione Sicilia, licensed under

(

http://www.formez.it/

iodl/

)

and updated by licensee September 1, 2013.

This service uses POI data of ZENRIN CO., LTD.

“ZENRIN” is a registered trademark of ZENRIN CO., LTD.

F26

Technical Notes and Index

Includes contents of Provincia di Enna, Comune di Torino, Comune di Pisa, Comune di Trapani,

Comune di Vicenza, Regione Lombardia, Regione Umbria, licensed under

(

http://www.dati.gov.it/

iodl/2.0/

)

and updated by licensee September 1, 2013.

Includes content of GeoforUs, licensed in accordance with

(

http://creativecommons.org/licenses/by/

3.0/legalcode

)

Includes content of Comune di Milano, licensed under

(

http://creativecommons.org/licenses/by/2.5/

it/legalcode

)

and updated by licensee November 1, 2013.

Includes content of the “Comunità Montana della Carnia”, licensed under

(

http://www.dati.gov.it/iodl/

2.0/

)

and updated by licensee December 1, 2013.

Includes content of “Agenzia per la mobilità” licensed under

(

http://creativecommons.org/licenses/

by/3.0/legalcode

)

and updated by licensee January 1, 2014.

Includes content of Regione Sardegna, licensed under

(

http://www.dati.gov.it/iodl/2.0/

)

and updated

by licensee May 1, 2014.

Includes content of CISIS, licensed under

(

http://creativecommons.org/licenses/by/2.5/legalcode

)

Includes data under the Norwegian licence for Open Government data (NLOD), available at

(

http://

data.norge.no/nlod/en/1.0

)

Contains information copyrighted by  Kartverket, made available in accordance with

(

http://

creativecommons.org/licenses/by/3.0/no/

)

Contains data under the Norwegian licence for Open Government data (NLOD) distributed by

Norwegian Public Roads Administration (NPRA)

Portugal: Source: IgeoE – Portugal

Spain: Información geográfica propiedad del CNIG

Contains data that is made available by the Generalitat de Catalunya Government in accordance with

the terms available at

(

http://www.gencat.cat/web/eng/avis_legal.htm

)

. Retrieved by HERE 05/2013.

Contains content of Centro Municipal de Informatica – Malaga, licensed in accordance with

(

http://

creativecommons.org/licenses/by /3.0/legalcode

)

Contains content of Administración General de la Comunidad Autónoma de Euskadi, licensed in

accordance with

(

http://creativecommons.org/licenses/by/3.0/legalcode

)

Contains data made available by the Ayuntamiento de Santander, licensed in accordance with

(

http://

creativecommons.org/licenses/by/3.0/es/legalcode.es

)

Contains data of Ajuntament de Sabadell, licensed per

(

http://creativecommons.org/licences/by/3.0/

legalcode

)

, updated 4/2013

Sweden: Based upon electronic data  National Land Survey Sweden.

Contains public data, licensed under Go Open v1.0, available at

(

http://data.goteborg.se/goopen/

Avtal%20GoOpen%201.0.0.pdf

)

Switzerland: Topografische Grundlage:  Bundesamt für Landestopographie

United Kingdom: Contains public sector information licensed under the Open Government Licence

v1.0 (see for the license

(

http://www.nationalarchives.gov.uk/doc/open-government-licence/

)

Adapted from data from the office for National Statistics licensed under the Open Government

Licence v.1.0

Canada: This data includes information taken with permission from Canadian authorities, including

Mexico: Fuente: INEGI (Instituto Nacional de Estadística y Geografía.)

approved by the United States Postal Service. The following trademarks and registrations are

owned by the USPS: United States Postal Service, USPS, and ZIP+4.

Includes data available from the U.S. Geological Survey.

Australia: Copyright. Based on data provided under license from PSMA Australia Limited

(www.psma.com.au).

Product incorporates data which is  2013 Telstra Corporation Limited, Intelematics Australia Pty Ltd

and HERE International LLC.

F27

Technical Notes and Index

Nepal: Copyright  Survey Department, Government of Nepal.

Sri Lanka: This product incorporates original source digital data obtained from the Survey

Department of Sri Lanka

 2009 Survey Department of Sri Lanka

The data has been used with the permission of the Survey Department of Sri Lanka

Israel:  Survey of Israel data source

Jordan:  Royal Jordanian Geographic Centre.

Mozambique: Certain Data for Mozambique provided by Cenacarta  2013 by Cenacarta

Nicaragua: The Pacific Ocean and Caribbean Sea maritime borders have not been entirely defined.

Northern land border defined by the natural course of the Coco River (also known as Segovia River or

Wangki River) corresponds to the source of information available at the moment of its representation.

Réunion: source:  IGN 2009 - BD TOPO 

Ecuador: INSTITUTO GEOGRAFICO MILITAR DEL ECUADRO

AUTORIZACION N° IGM-2011-01- PCO-01 DEL 25 DE ENERO DE 2011

Guadeloupe: source:  IGN 2009 - BD TOPO 

Guatemala: Aprobado por el INSTITUTO GEOGRAFICO NACIONAL – Resolución del IGN No 186-2011

French Guiana: source:  IGN 2009 - BD TOPO 

Martinique: source:  IGN 2009 - BD TOPO 

F28

Technical Notes and Index

Symbols

A Auto mode ............................ 16, 26

y Scene mode......................... 27

l Aperture-priority auto mode

.............................................................. 30, 32

k Shutter-priority auto mode

.............................................................. 30, 32

u Special effects mode..... 28

c Landscape mode ......... 24, E4

j Programmed auto mode

.............................................................. 30, 32

m Manual mode ....................... 30, 32

s Night portrait mode... 24, E3

X Night landscape mode

........................................................ 24, E3

M (User settings) mode................... 34

i Playback zoom ............. 22, E23

f (Wide-angle).................................... 20

h Thumbnail display

..................................................... 22, E24

g (Telephoto)......................................... 20

q Wi-Fi button

......................... 2, 60, E45, E47

k Apply selection button

...................................................... 2, E122

c Playback button ..... 22, E121

l Delete button............... 23, E26

b (e Movie-record) button

...................................................... 21, E32

s Display button ............................ 3

w Function button ... 45, E120

m Flash pop-up button .................... 36

d Menu button

.............................. 49, 51, 54, 55, 57

x Monitor button............................. 19

n Self-timer/Remote control/Smile

timer ....................................... 25, 38, 39

p Focus mode.......................... 25, 40

m Flash mode............................... 25, 36

o Exposure compensation

............................................................. 25, 44

N-Mark ....................................... E4

AC adapter.......................... 61, E116

Active D-Lighting ............. 52, E77

AF area mode........... 45, 52, E73

AF assist ............................... 57, E105

Aperture value....................................... 30

Aperture-priority auto mode

.............................................................. 30, 32

Assign side zoom control

.................................................. 57, E106

Auto ............................................................. 37

Auto off...................... 18, 57, E107

Auto with red-eye reduction ....... 37

Autofocus....... 41, 52, 54, E20,

E76, E85

Autofocus mode

...................... 52, 54, E76, E85

Backlighting o..................... 27, E7

Battery ....................................... 10, F18

Battery charger................. 12, E116

Battery level indicator........................ 16

Best Shot Selector ...... E6, E68

Bird-watching L ................ 27, E9

Index

F29

Technical Notes and Index

Black and white copy n

........................................................ 27, E6

Brightness ........................... 57, E101

BSS....................................... E6, E68

Button sound.............................. E106

Calendar display .......................... E24

Charge by computer .. 58, E108

Charge lamp...................................... 1, 11

Charging AC adapter........ 11, F20

Choose key picture .......... 56, E91

Close-up k............................. 27, E5

Color temperature...................... E64

Command dial

............................ 30, E120, E122

Computer.............................. 62, E53

Connector cover................... 1, 11, 61

Continuous ............... 45, 52, E67

Contrast............................................. E60

COOLPIX Custom Picture Control

...................................................... 51, E62

COOLPIX Picture Control

........................................... 45, 51, E58

Create log ............................. 59, E42

Crop.................................. E23, E31

Cross process.......................................... 29

Custom Picture Control

...................................................... 51, E62

Date and time .......... 14, 57, E98

Date stamp......................... 57, E103

Daylight saving time ...... 14, E99

Delete...................................... 23, E26

Digital zoom........... 20, 57, E105

Diopter adjustment control .......... 19

Direct Print ........................... 62, E49

D-Lighting............................. 55, E27

Dynamic Fine Zoom.......................... 20

Easy panorama p .......... 27, E10

Editing movies............................... E37

Editing still images...................... E26

Electronic VR............... 4, 54, E86

EVF auto toggle .............. 57, E103

EVF options ................................... E101

Exposure bracketing....... 52, E72

Exposure compensation...... 25, 44

Exposure mode .................................... 30

Extension ........................................ E115

Extracting still images............... E38

Eye sensor ......................................... 2, 19

Eyelet for camera strap ....................... 9

Face detection .............................. E19

Face priority .................................... E73

Fast motion movies

............................................ E83, E84

File name ........................................ E115

Fill flash ...................................................... 37

Filter effects...... 55, E29, E60

Fireworks show m.............. 27, E6

Firmware version ............ 58, E110

Flash............................................................. 36

Flash exp. comp. ............... 52, E76

Flash mode.................................... 25, 36

Fn button setting ................................ 45

Focal length....... 53, E80, F16

Focus.................... 17, E18, E33,

E73, E76, E85

Focus area

........... 6, 17, E8, E18, E73

Focus indicator .............................. 4, 17

F30

Technical Notes and Index

Focus lock......................................... E21

Focus mode.................................. 25, 40

Food u ...................................... 27, E6

Format........................ 10, 58, E107

Format memory cards

........................................ 10, 58, E107

Frame rate............................. 54, E87

Full-frame playback

.......................... 7, 22, E23, E24

Full-time AF

....................... 52, 54, E76, E85

Functions that cannot be used

simultaneously...................................... 46

HDMI micro connector............ E48

HDR......................................................... E7

High ISO monochrome.................... 28

High key..................................................... 28

High-contrast monochrome......... 28

High-speed continuous.......... E67

Histogram ........ 8, 44, 57, E101

HS movie ...................... E83, E84

Identifier.......................................... E115

Image quality............ 45, 51, E56

Image selection screen .................... 56

Image sharpening ...................... E60

Image size................... 45, 51, E57

Infinity.......................................................... 41

Infrared receiver................................ 1, 2

Interval timer shooting

............................................ E68, E69

ISO sensitivity............ 45, 52, E71

Language ............................ 58, E107

Lens......................................... F6, F16

Lens cap ....................................................... 9

Li-ion rechargeable battery

....................................................... 10, F19

Location data options

................................ 49, E39, E94

Low key...................................................... 28

M exposure preview........ 53, E81

Macro close-up ...................................... 41

Manual focus............................... 41, 42

Manual mode .............................. 30, 32

Mark for Wi-Fi upload

................................. 55, E47, E88

Memory capacity.............. 16, E32

Memory card.......... 10, F5, F20

Metering...................... 45, 52, E66

Micro-USB connector

........................ 11, 61, E49, E53

Minimum shutter speed ......... E71

Mode dial........................................ 16, 24

Monitor ................................. 3, 13, F6

Monitor options ......................... E101

Monitor settings.............. 57, E101

Moon g.................................... 27, E9

Movie menu ....................... 54, E82

Movie options.................... 54, E82

Movie playback.................. 22, E32

Movie recording................. 21, E32

Movie recording time remaining

............................................. E32, E33

Multi selector

............................. 25, E119, E121

Multiple exposure ............ 52, E78

Multi-shot 16 ................................. E68

Museum l............................. 27, E6

F31

Technical Notes and Index

Night landscape mode..... 27, E3

Night portrait mode........... 27, E3

N-Mark................................................ E46

Noise reduction filter ..... 52, E77

Nostalgic sepia....................................... 28

Number of exposures remaining

...................................................... 16, E56

Optical zoom .......................................... 20

Optional accessories ............... E116

Paper size ...................... E50, E51

Party/indoor f..................... 27, E5

Peaking................................. 58, E110

Pet portrait O....................... 27, E8

PictBridge.............................. 62, E49

Picture Control......... 45, 51, E58

Playback................................. 22, E32

Playback menu ...................................... 55

Playback mode ...................................... 22

Playback zoom................... 22, E23

Points of interest (POI)

..................................................... 59, E96

Positioning antenna.............................. 2

Power........................................................... 14

Power switch ................................... 1, 14

Power-on lamp............................... 1, 18

Preset manual ............................... E65

Pre-shooting cache

............................................ E67, E69

Pressing halfway ... 17, 21, E120

Print .............. E49, E50, E51

Printer...................................... 61, E49

Programmed auto mode..... 30, 32

Protect..................................... 55, E90

Quick adjust ................................... E60

Quick retouch..................... 55, E27

Ready light....................................... 4, 36

Rear-curtain sync ................................. 37

Rechargeable battery.......................... 11

Red-eye reduction .............................. 37

Remote control..... 25, 38, E117

Reset all................................. 58, E110

Reset file numbering... 58, E109

Reset user settings............................... 35

Rotary multi selector

............................. 25, E119, E121

Rotate image....................... 55, E90

Saturation........................................ E60

Save user settings................................. 35

Scene auto selector x

....................................................... 24, E4

Scene mode............................................ 27

Selecting images ................................. 56

Selective color ....................................... 28

Self-timer ........................................ 25, 38

Self-timer lamp .......................... 39, 40

Sequence............ 23, E23, E25

Sequence display options

..................................................... 56, E91

Set clock from satellite ............. E97

Setup menu ......................... 57, E98

Shooting ................................ 24, E32

Shooting information ........................... 3

Shooting menu

.................................. 51, E56, E58

Shooting mode ......................... 24, 54

Shutter sound............................. E106

F32

Technical Notes and Index

Shutter speed..................... 30, E22

Shutter-priority auto mode

.............................................................. 30, 32

Shutter-release button

................... 17, 21, E120, E123

Side zoom control .......... 17, E119

Single....................................... 52, E67

Single AF

....................... 52, 54, E76, E85

Skin softening

.................................. 55, E20, E28

Slide show ............................ 55, E89

Slot empty release lock

................................................... 57, E100

Slow motion movies

............................................ E83, E84

Slow sync .................................................. 37

Small picture ....................... 55, E30

Smile timer.................................... 25, 39

Snap-back zoom button........... 2, 21

Snow z..................................................... 27

Soft................................................................ 28

Sound settings................ 57, E106

Special effects mode.......................... 28

Sports d.................................... 27, E5

Standard flash......................................... 37

Startup zoom position

...................................................... 53, E81

Subject tracking....... E74, E75

Sunset h.................................................. 27

Target finding AF...... E18, E74

Telephoto ................................................. 20

Thumbnail display........... 22, E24

Time difference ............................ E99

Time zone ............................. 14, E98

Time zone and date

.......................................... 14, 57, E98

Time-lapse movie i................ E13

Toggle Av/Tv selection

.................................................. 58, E109

Tone level.................................................... 8

Tone level information................. 3, 8

Toning ................................................ E61

TV................................................ 61, E48

Upload from camera

............................................ E47, E92

USB cable

....................... 11, 62, E49, E53

User settings mode............................ 34

Vibration reduction

....................................... 45, 57, E104

View log............................................ E44

View/hide framing grid

...................................................... 6, E101

Viewfinder.................................. 19, F6

ViewNX-i................................. 62, E53

Virtual horizon

................................ 6, E101, E102

Volume............................................... E36

White balance.......... 45, 51, E63

Wide-angle .............................................. 20

Wi-Fi button........ 2, E45, E47

Wi-Fi options ...................... 60, E92

Wi-Fi options menu ....... 49, E92

Wind noise reduction... 54, E86

Wireless LAN........................................... 60

F33

Technical Notes and Index

Zoom........................................................... 20

Zoom control ................... 20, E121

Zoom memory .................. 53, E80

Zoom microphone.......... 54, E87

6MN49411-05

FX6F05(11)

No reproduction in any form of this manual, in whole or in part

(except for brief quotation in critical articles or reviews), may be

made without written authorization from NIKON CORPORATION.

Nikon COOLPIX P900 Digital Camera 26499

Product's Documents

Reference Manual

Specifications

Nikon 26499 Questions and Answers

Related Products

Nikon 1 J5 Digital Camera

Nikon Z5II Digital Camera 24.5MP Body Only

Nikon 1 AW1 Digital Camera

Nikon 1 J4 Digital Camera

Nikon 1 S1 Digital Camera

Nikon 1 V1 Digital Camera
