2018
NAVIGATION MANUAL
The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd., reserves the right,
however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.
Accessories Precautions
The GPS antenna is located in the dashboard. Metallic front or side window tinting can seriously degrade or obstruct GPS reception.
Signal noise from devices such as radar detectors, vehicle tracking devices, remote starters, and additional amplifiers can disrupt the navigation system. If you
install any such item, install it away from the navigation display and antenna.
Important Safety Information
Avoid focusing on the screen or manually operating the system controls while driving.
Certain on-screen controls are disabled when driving, however most of the voice commands continue to function. Pull to the side of the road if you need to devote
more attention and time to look at the screen or access additional menus.
Route guidance may conflict with street closures, road construction, detours, and out-of-date map data.
The system itself may also have limitations. Verify route information by carefully observing roads, signs, and signals. Always use your own judgment and obey
traffic laws.
2
System Limitations
P. 130
NOTICE
This vehicle’s navigation display, if so equipped, includes mercury-containing components. Upon removal, please reuse, recycle, or dispose of as hazardous waste.
Clean the screen with a soft, damp cloth. You may use a mild cleaner intended for use on navigation screens.
3 WARNING
Using the navigation system while driving can take your
attention away from the road, causing a crash in which you
could be seriously injured or killed.
Only operate system controls when the conditions permit you
to safely do so.
18 RIDGELINE NAVI-31T6Z8100.book 0 ページ ２０１７年６月７日 水曜日 午後５時３７分
00X31-T6Z-8100 2018 Ridgeline Navigation Manual NM-05469
Contents
2 System Setup P. 15
Start-up 16 Personal Information 18 Display Mode Settings 26 Map & Vehicle 28
Navigation 36 Traffic 45 Other Settings 46 Data Reset 52
2 Navigation P. 53
Entering a Destination 54 Calculating the Route 74 Driving to Your Destination 77 Map Operation 81
Changing Your Route 91 Changing Your Destination 94
2 Other Features P. 107
About Apps Menu 108 ecoRoute
TM
109 Information Functions 117
2 Troubleshooting P. 123
Troubleshooting 124
2 Reference Information P. 129
System Limitations 130 Customer Assistance 132 Legal Information 134
2 Voice Commands P. 137
Voice Commands 138 List of Categories 140
Quick Reference Guide
P. 2
System Setup
P. 15
Navigation
P. 53
Other Features
P. 107
Troubleshooting
P. 123
Reference Information
P. 129
Voice Commands
P. 137
Index
P. 141
18 RIDGELINE NAVI-31T6Z8100.book 1 ページ ２０１７年６月７日 水曜日 午後５時３７分
2
Quick Reference Guide
Quick Reference Guide
Overview—Functions at a Glance
Navigation
You can select any place/landmark as a destination by using the touchscreen. The navigation system gives you
turn-by-turn driving directions to your destination.
Store home address
(P18)
Register
1
home address.
Track route
(P77 )
Follow your route in real-time with voice guidance.
Store contacts
(P19 )
Store locations to use as the destination.
Enter destination
(P54 )
Select your destination using several methods.
Select route
(P75)
Set route preferences and select one of the available routes.
Avoid certain areas
(P39 )
Set streets and areas to detour around.
Add waypoints
(P93 )
Add “pit stops” along your route.
Traffic Information* (P86 )
View and avoid congestion and traffic incidents.
*: Available only in certain areas.
18 RIDGELINE NAVI-31T6Z8100.book 2 ページ ２０１７年６月７日 水曜日 午後５時３７分
3
Quick Reference Guide
HOME Screen
The system displays various functions from the HOME screen. Press the (Home) icon at any time to return to the main HOME screen.
Navigation Top Screen
Display the map screen and operate the navigation features. From the HOME screen, select and then press the (Back) icon. The
navigation top screen is displayed.
(Home)
Display the HOME screen.
VOL (Volume)
Increase or decrease the audio
volume.
(Menu)
Display the map menu.
(Back)
Go back to the previous screen.
(Display Mode)
Switch between Day and Night
modes manually.
Display the map screen.
Navigation
Display the navigation feature that
was used the last time.
At start-up, the navigation top screen
is displayed.
GPS signal strength (P121)
Display the satellites' status.
Where To? (P54)
Select search methods to enter a destination for
route guidance.
Apps (P108 )
Display the useful functions incorporated into the
navigation system.
View Map (P6)
Display the map screen.
Settings (P15)
Change the settings for the navigation
functions.
18 RIDGELINE NAVI-31T6Z8100.book 3 ページ ２０１７年６月７日 水曜日 午後５時３７分
6
Quick Reference Guide
Map Screen Legend
The color of the map is different depending on the selected Map Theme.
Map operation icons
(P81 )
Map menu (P82)
Map scale (P81 )
Current vehicle position
Streets
Landmark icons
Traffic incident icons
Traffic flow indicator
Traffic is flowing
normally.
Traffic is slightly
congested.
Traffic is heavily
congested or stopped.
Searching specific category (P54)
Traffic has not
updated.
Map buttons (P33)
Feature areas
18 RIDGELINE NAVI-31T6Z8100.book 6 ページ ２０１７年６月７日 水曜日 午後５時３７分
7
Quick Reference Guide
During Route Guidance
During route guidance, route information is displayed on the map screen.
You can see the detailed information on the turn information screen.
Map Screen
Guidance Screen
Dashboards (P77 )
Next guidance indicator (P77 )
Distance to the next guidance point and street name of
next guidance point.
Where To? (P54)
Waypoint
Calculated route
Speed limit
Cancel route
Street name of next
guidance point
Distance to next guidance pointEstimated time to
next guidance point
Scrolls key
Select this key to scroll
the display.
Day or Night Mode
Press the (Display Mode) icon to
manually switch between Day and
Night modes.
Turn-by-Turn Directions
The next guidance point appears on
the Multi-Information Display (MID).
Day Mode Night Mode
Remaining
distance
Street name of next
guidance point
Next driving maneuver is
approaching.
18 RIDGELINE NAVI-31T6Z8100.book 7 ページ ２０１７年６月７日 水曜日 午後５時３７分
12
Quick Reference Guide
Troubleshooting
For more Information
(P123 )
Why does the vehicle position icon on the map appear
slightly off my actual position, especially at intersections?
This is normal. The navigation system is unaware of the
width of intersections. Large differences in vehicle position
can indicate a temporary loss of the GPS signal.
Why does the “Arrival time” display sometimes increase
even though I am getting closer to my destination?
The “Arrival time” is based on the speed limit on each
road. Depending on the traffic conditions, the “arrival
time” may be calculated to be earlier or later.
Why does my clock frequently change the time forward
and backward by one hour?
The clock setting is automatically updated based on your
GPS location. If you are driving near a time zone border,
the automatic update likely is the reason.
How do I turn on the navigation system voice guidance?
1.Press the (Home) icon.
Select Settings > System > Sound/Beep tab.
Turn up Guidance Volume, if guidance volume is low.
2.Select and then press the (Back) icon.
Select Settings > Navigation.
Check that Voice Prompts is not set to off.
For more details, see the Owner’s Manual.
How do I specify a destination when an entered city or
street could not be found?
Try selecting the destination directly from the map.
18 RIDGELINE NAVI-31T6Z8100.book 12 ページ ２０１７年６月７日 水曜日 午後５時３７分
13
How to Use This Manual
This section explains different methods on how you can easily find information in this manual.
Searching the Table of Contents
(P1 )
First, find the general chapter related to
what you are looking for (e.g., entering
a destination from the Saved Places).
Then, go to that chapter to view a more
specific table of contents.
Searching the Index
(P141 )
This more detailed table of contents
shows you exactly what information is
listed by section and title.
The Index consists of
main terms and sub-
entries. The sub-entries
help you get to the
desired page depending
on what you are looking
for.
Table of Contents
Chapter Contents
Navigation Screen
Index
Two types of Tables of Contents help
you find your desired information.
Menu items displayed on the
navigation screen (e.g., Saved) can be
found individually in the Index.
More Detailed
Contents
Go to the
Next Page
18 RIDGELINE NAVI-31T6Z8100.book 13 ページ ２０１７年６月７日 水曜日 午後５時３７分
14
Select the item on the system
control panel.
Menu Tree
The menu tree helps guide you
through the system’s menu options.
To get to your desired function, follow
the menu tree in order of the steps
shown.
Select the menu option.
After following the menu
tree, step-by-step
instructions explain how to
achieve the desired result.
* Sample pages and images in this section may differ from the actual ones.
Select Saved.
(Home)
Saved
18 RIDGELINE NAVI-31T6Z8100.book 14 ページ ２０１７年６月７日 水曜日 午後５時３７分
15
System Setup
This section describes the start-up procedure and the navigation and setup functions.
Start-up ................................................... 16
Voice Control System ............................. 17
Voice Recognition .................................. 17
Personal Information.............................. 18
Setting Home Location........................... 18
Saved Locations ..................................... 19
Display Mode Settings ........................... 26
Switching Display Mode Manually .......... 26
Map & Vehicle ......................................... 28
Vehicle................................................... 29
Driving Map View (Map Orientation)...... 30
Map Detail............................................. 31
Map Theme ........................................... 32
Map Buttons.......................................... 33
Map Layers .............................................34
Dashboards.............................................34
myMaps..................................................35
Navigation................................................36
Calculation Mode ...................................37
Avoidances .............................................38
Custom Avoidances ................................39
Traffic .......................................................45
Other Settings..........................................46
Units.......................................................46
Language & Keyboard.............................47
Device.....................................................50
Data Reset ............................................... 52
Reset Factory Default Settings ................ 52
18 RIDGELINE NAVI-31T6Z8100.book 15 ページ ２０１７年６月７日 水曜日 午後５時３７分
16
System Setup
Start-up
The navigation system starts automatically when you set the power mode to
ACCESSORY or ON. At start-up, the following confirmation screen is displayed.
1. Select OK.
u The HOME screen is displayed.
u If you do not select OK, the
system will automatically select
OK after a certain period of
time.
u The system will automatically
start up the feature that was
used the last time.
2. Select .
u The map screen is displayed.
u When you want to display the
navigation top screen, you
press the (Back) icon.
Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.
Voice commands are still operable while the vehicle is in motion.
1 Start-up
Avoid focusing on the screen and drive safely
following the actual traffic restrictions.
When you use the navigation system, the system may
close other apps.
When you select Navigation, the system displays the
navigation feature that was used the last time. At
start-up, the navigation top screen is displayed.
■
Limitations for Manual Operation
18 RIDGELINE NAVI-31T6Z8100.book 16 ページ ２０１７年６月７日 水曜日 午後５時３７分
17
System Setup
Voice Control System
Your vehicle has a voice control system that allows hands-free operation of the
navigation system functions.
The voice control system uses the (Talk) and (Hang-Up/Back) buttons on
the steering wheel and a microphone near the map lights on the ceiling.
For details of the (Talk) button, (Hang-Up/Back) button and microphone
position, see the Owner's Manual.
Voice Recognition
To achieve optimum voice recognition when using the navigation voice control
system:
• Make sure the correct screen is displayed for the voice command that you are
using.
The system recognizes only certain commands.
Available navigation commands:
2 Navigation Commands P. 138
• Close the windows and moonroof
*
.
• Adjust the dashboard and side vents so air does not blow onto the microphone
on the ceiling.
• Speak clearly in a clear, natural speaking voice without pausing between words.
• Reduce any background noise if possible. The system may misinterpret your
command if more than one person is speaking at the same time.
1 Voice Control System
When you press the (Talk) button, the system
prompts you to say a voice command. Press and
release the (Talk) button again to bypass this
prompt and give a command.
1 Voice Recognition
The voice control system can only be used from the
driver’s seat because the microphone unit removes
noises from the front passenger’s side.
* Not available on all models
18 RIDGELINE NAVI-31T6Z8100.book 17 ページ ２０１７年６月７日 水曜日 午後５時３７分
18
System Setup
Personal Information
Setting Home Location
H uu (Menu)
Use the personal information menu to set your home location.
1. Select Set Home Location.
2. Select an option.
u Select Use Current Location
to set home location.
u Select Enter My Address or
Recently Found, proceed to
steps 3 and 4.
3. Select the home location.
4. Select Select.
The following options are available:
• Enter My Address: Sets the home location by entering the address.
2 Storing Your Home Address P. 8
• Use Current Location: Sets your current location as your home location.
• Recently Found: Sets the home location from a recently found location.
1 Personal Information
You can also display the same screen by selecting
on the Where To? screen.
If you want to delete a shortcut(s), select Remove
Shortcut(s).
2 Deleting Shortcuts P. 59
The home location can be overwritten.
18 RIDGELINE NAVI-31T6Z8100.book 18 ページ ２０１７年６月７日 水曜日 午後５時３７分
Continued
21
uuPersonal InformationuSaved Locations
System Setup
H u (Back) u View Map
1. Select the vehicle icon.
2. Select Save.
3. Enter a name of the location.
4. Select Done.
5. Select OK.
■
Saving Your Current Location
1 Saving Your Current Location
Vehicle position may not be displayed when:
•
The vehicle is traveling off-road.
•
The vehicle position data cannot be updated.
18 RIDGELINE NAVI-31T6Z8100.book 21 ページ ２０１７年６月７日 水曜日 午後５時３７分
22
uuPersonal InformationuSaved Locations
System Setup
H uuSaved
1. Select a saved location you want
to edit.
2. Select .
3. Press the (Menu) icon or select
.
4. Select Edit.
■
Editing a Saved Location
18 RIDGELINE NAVI-31T6Z8100.book 22 ページ ２０１７年６月７日 水曜日 午後５時３７分
23
uuPersonal InformationuSaved Locations
Continued
System Setup
5. Select an option.
The following options are available:
• Name: Enters a new name for the location.
• Phone Number: Enters a phone number.
• Categories: Creates or changes the category in which this location is saved.
• Change Map Symbol: Select a new symbol.
18 RIDGELINE NAVI-31T6Z8100.book 23 ページ ２０１７年６月７日 水曜日 午後５時３７分
28
System Setup
Map & Vehicle
H u (Back) u Settings u Map & Vehicle
Change the map settings.
Select an option.
The following options are available:
• Vehicle: Changes the icon to represent your position on the map.
2 Vehicle P. 29
• Driving Map View: Sets the perspective on the map.
2 Driving Map View (Map Orientation) P. 30
• Map Detail: Sets the level of detail on the map. More detail may cause the map
to draw slower.
2 Map Detail P. 31
• Map Theme: Changes the color of the map data.
2 Map Theme P. 32
• Map Buttons: Sets which icons are included on the map. Up to three icons can
be included on the map.
2 Map Buttons P. 33
• Map Layers: Sets the data that appears on the map.
2 Map Layers P. 34
• Dashboards: Sets the map dashboard layout.
2 Dashboards P. 34
18 RIDGELINE NAVI-31T6Z8100.book 28 ページ ２０１７年６月７日 水曜日 午後５時３７分
33
uuMap & VehicleuMap Buttons
System Setup
Map Buttons
H u (Back) u Settings u Map & Vehicle u Map Buttons
Sets up to three shortcuts that appear in the map tools menu.
1. Select if you want to delete a
shortcut and then select OK.
2. Select to add a new shortcut.
3. Select an option.
4. Select Save.
1 Map Buttons
Reset to Defaults
Resets the settings to the factory defaults.
18 RIDGELINE NAVI-31T6Z8100.book 33 ページ ２０１７年６月７日 水曜日 午後５時３７分
34
uuMap & VehicleuMap Layers
System Setup
Map Layers
H u (Back) u Settings u Map & Vehicle u Map Layers
Sets the data that appears on the map screen.
1. Select an option(s).
2. Select Save.
Dashboards
H u (Back) u Settings u Map & Vehicle u Dashboards
Switches the dashboard layout at the bottom of the map.
1. Select or .
2. Select Save.
1 Map Layers
Trip Log is set to off as factory default.
18 RIDGELINE NAVI-31T6Z8100.book 34 ページ ２０１７年６月７日 水曜日 午後５時３７分
35
uuMap & VehicleumyMaps
System Setup
myMaps
H u (Back) u Settings u Map & Vehicle u myMaps
Sets which installed maps the system uses.
Select an option(s).
18 RIDGELINE NAVI-31T6Z8100.book 35 ページ ２０１７年６月７日 水曜日 午後５時３７分
37
uuNavigationuCalculation Mode
System Setup
Calculation Mode
H u (Back) u Settings u Navigation u Calculation Mode
Sets the route preference.
1. Select an option.
2. Select Save.
The following options are available:
• Faster Time (factory default): Calculates routes that are faster to drive but can be
longer in distance.
• Shorter Distance: Calculates routes that are shorter in distance but can take
more time to drive.
• Less Fuel: Calculates routes that could use less fuel than other routes.
18 RIDGELINE NAVI-31T6Z8100.book 37 ページ ２０１７年６月７日 水曜日 午後５時３７分
38
uuNavigationu Avoidances
System Setup
Avoidances
H u (Back) u Settings u Navigation u Avoidances
Set preferences for route options to avoid.
1. Select an option(s).
2. Select Save.
The following options are available:
• U-Turns: Avoids u-turns.
• Highways: Avoids highways.
• Tolls and Fees: Avoids toll roads.
• Ferries: Avoids ferries.
• Carpool Lanes: Avoids car share lanes.
• Unpaved Roads: Avoids unpaved roads.
1 Avoidances
Highways, Tolls and Fees, and Ferries are set to off
as factory default.
18 RIDGELINE NAVI-31T6Z8100.book 38 ページ ２０１７年６月７日 水曜日 午後５時３７分
40
uuNavigationu Custom Avoidances
System Setup
H u (Back) u Settings u Navigation u Custom Avoidances
u Add Avoid Area
1. Select the upper-left (right) corner
of the area to avoid. Select Next.
u The icon is displayed on the
map.
2. Select the lower-right (left) corner
of the area to avoid. Select Next.
u The selected area is shaded on
the map.
■
Adding an Avoid Area
18 RIDGELINE NAVI-31T6Z8100.book 40 ページ ２０１７年６月７日 水曜日 午後５時３７分
41
uuNavigationu Custom Avoidances
Continued
System Setup
3. Select Done.
H u (Back) u Settings u Navigation u Custom Avoidances
u Add Avoid Road
1. Select the starting point of the
section of road to avoid. Select
Next.
u The icon is displayed on the
map.
■
Adding an Avoid Road
18 RIDGELINE NAVI-31T6Z8100.book 41 ページ ２０１７年６月７日 水曜日 午後５時３７分
uuNavigationu Custom Avoidances
44
System Setup
H u (Back) u Settings u Navigation u Custom Avoidances
1. Select .
2. Select options you want to delete.
u Select Select All for all options
in the list.
3. Select Delete.
■
Deleting Custom Avoidances
1 Deleting Custom Avoidances
Select if you want to search the saved custom
avoidance.
18 RIDGELINE NAVI-31T6Z8100.book 44 ページ ２０１７年６月７日 水曜日 午後５時３７分
45
System Setup
Traffic
H u (Back) u Settings u Traffic
Sets the traffic feature.
Select an option.
The following options are available:
• Traffic: Enables the traffic feature.
2 Traffic Information P. 86
• Current Provider: Sets the traffic provider to use for traffic data.
• Subscriptions: Displays the lists of the current traffic subscriptions.
• Optimize Route: Sets whether to use optimized alternate routes On Request
(factory default) or Automatic.
18 RIDGELINE NAVI-31T6Z8100.book 45 ページ ２０１７年６月７日 水曜日 午後５時３７分
46
System Setup
Other Settings
Units
H u (Back) u Settings u Units u Units
Set the units and display on the map of the navigation system.
1. Select an option.
2. Select Save.
The following options are available:
• Miles (factory default): Sets the units to miles.
• Kilometers: Sets the units to kilometers.
18 RIDGELINE NAVI-31T6Z8100.book 46 ページ ２０１７年６月７日 水曜日 午後５時３７分
48
uuOther SettingsuLanguage & Keyboard
System Setup
H u (Back) u Settings u Language & Keyboard u Voice
Language
1. Select an option.
2. Select Save.
H u (Back) u Settings u Language & Keyboard u Keyboard
Language
1. Select an option.
2. Select Save.
■
Voice Language
■
Keyboard Language
18 RIDGELINE NAVI-31T6Z8100.book 48 ページ ２０１７年６月７日 水曜日 午後５時３７分
50
uuOther SettingsuDevice
System Setup
Device
H u (Back) u Settings u Device
Select an option.
The following options are available:
• About: Displays the device information.
2 About P. 51
• Travel History: Allows the system to record information for suggested routes,
previous routes and destinations, and Trip Log features.
• Clear Travel History: Deletes the recorded information.
• Update Map: Displays the description screen of map update.
2 Obtaining a Navigation Update P. 132
18 RIDGELINE NAVI-31T6Z8100.book 50 ページ ２０１７年６月７日 水曜日 午後５時３７分
52
System Setup
Data Reset
Reset Factory Default Settings
H u (Back) u Settings u (Menu)
You can restore all settings to the factory default values.
1. Select Restore.
2. Select Yes.
1 Reset Factory Default Settings
When you want to reset the following options, see
the below references:
•
Home
2 Deleting Saved Locations P. 25
•
Recent
2 Recent P. 72
•
Saved
2 Saved Locations P. 19
When you press the (Menu) icon or select in
each settings category, you can restore the selected
category.
When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.
18 RIDGELINE NAVI-31T6Z8100.book 52 ページ ２０１７年６月７日 水曜日 午後５時３７分
55
uuEntering a Destinationu
Continued
Navigation
• Saved: Sets a destination by selecting a place stored in the Saved list.
2 Saved P. 72
• Recent: Sets a destination by selecting a previous destination.
2 Recent P. 72
• Add Shortcut: Adds shortcuts to the Where To? menu.
2 Adding Shortcuts P. 58
18 RIDGELINE NAVI-31T6Z8100.book 55 ページ ２０１７年６月７日 水曜日 午後５時３７分
Continued
57
uuEntering a Destinationu
Navigation
H uuSearching near
By default, your system finds locations closest to your current location. You can find
a location near another city or location.
Select an option.
The following options are available:
• Where I Am Now: Searches near your current location.
• My Active Route: Searches along your current route.
• My Destination: Searches near your current destination.
• A Different City: Searches near the city you enter.
• Recent Destination: Searches near a recent destination.
• Saved Place: Searches near a saved place.
■
Changing the Search Area
1 Changing the Search Area
My Active Route and My Destination can be set
when the route is active.
18 RIDGELINE NAVI-31T6Z8100.book 57 ページ ２０１７年６月７日 水曜日 午後５時３７分
59
uuEntering a Destinationu
Navigation
H uu (Menu) u Remove Shortcut(s)
1. Select a shortcut with if you
want to delete it.
2. Select Touch to Remove.
3. Select Save.
■
Deleting Shortcuts
18 RIDGELINE NAVI-31T6Z8100.book 59 ページ ２０１７年６月７日 水曜日 午後５時３７分
61
uuEntering a DestinationuAddress
Continued
Navigation
Address
H uuAddress
Enter an address to use as the destination. The state or country you are currently in
is displayed.
Select an option.
The following options are available:
• Spell City: Selects your destination city.
2 Selecting the City P. 64
• Enter Postal Code: Selects your destination postal code.
2 Selecting the Postal Code P. 65
• Search All: Sets an address to use as the destination.
2 Search All P. 63
• State or Country: Selects the state or country.
2 Selecting the State/Country P. 62
1 Address
Using Voice Command
You can say the entire address at once using voice
commands.
From the Voice Portal screen, say “Navigation.”
Say “Find Address” on the voice command
screen, then say the entire address. (e.g., “1-2-3-4
Main Street, Los Angeles, California”).
Say “Change Country” if you want to change the
country.
The system interprets the address.
Say “Yes” or a line number of a screen if the
destination list appears (e.g., “1”).
Say “Navigate” or “Yes” to set the route.
2 Using Voice Commands P. 5
2 Voice Control Operation P. 11
18 RIDGELINE NAVI-31T6Z8100.book 61 ページ ２０１７年６月７日 水曜日 午後５時３７分
Continued
63
uuEntering a DestinationuAddress
Navigation
H uuAddress u Search All
1. Enter the house number. Select
Done.
2. Enter the street name. Select
Done.
u A list of matching hits is
automatically displayed after
you enter several letters, with
the closest match at the top of
the list.
3. Select your destination from the
list.
u If the select city screen is
displayed, select a city.
4. Select Go! to set the route to your
destination.
2 Calculating the Route P. 74
■
Search All
1 Search All
The order of the steps may change depending on the
map data loaded on your system.
18 RIDGELINE NAVI-31T6Z8100.book 63 ページ ２０１７年６月７日 水曜日 午後５時３７分
66
uuEntering a DestinationuCategories
Navigation
Categories
Select the category of a place (e.g., Restaurants, Gas Stations, Shopping) stored in
the map database to search for the destination.
H uuCategories
1. Select a category.
2. Select a subcategory.
u If the subcategory screen is not
displayed, proceed to step 3.
■
Finding a Location by Category
1 Categories
This option is convenient if you do not know the
exact name of a place or if you want to narrow down
the number of matches returned for places with a
common name.
When you set the destination or waypoint, the same
categories of icons do not appear.
Using Voice Command
You can find a place by the name using voice
commands.
From the Voice Portal screen, say “Navigation.
Say “Find Category” on the voice command
screen, then say a category (e.g., “Fast Food”).
Say “View Categories” if you want to confirm
the category list.
Say a subcategory if the subcategory screen is
displayed.
Say a line number of a screen (e.g., “1”).
Say “Navigate” or “Yes” to set the route.
2 Using Voice Commands P. 5
2 Voice Control Operation P. 11
18 RIDGELINE NAVI-31T6Z8100.book 66 ページ ２０１７年６月７日 水曜日 午後５時３７分
uuEntering a DestinationuCategories
70
Navigation
H uuCategories u Cities
Selects your destination city.
1. Select a city.
u Select Enter Search and enter
a city name if you want to
narrow down the number of
matches.
2. Select Go! to set the route to your
destination.
2 Calculating the Route P. 74
■
Finding a City
1 Finding a City
Using Voice Command
You can find a city by using voice commands.
From the Voice Portal screen, say “Navigation.”
Say “Find City” on the voice command screen,
then say a city name. (e.g., “Los Angeles”).
Say a line number of a screen (e.g., “1”).
Say “Navigate” or “Yes” to set the route.
2 Using Voice Commands P. 5
2 Voice Control Operation P. 11
18 RIDGELINE NAVI-31T6Z8100.book 70 ページ ２０１７年６月７日 水曜日 午後５時３７分
71
uuEntering a DestinationuCategories
Navigation
H uuCategories u Coordinates
You can find a location using latitude and longitude coordinates. This can be helpful
when geocaching.
1. Select the latitude coordinate.
2. Enter the new coordinate. Select
Done.
3. Select the longitude coordinate.
4. Enter the new coordinate. Select
Done.
5. Select View on Map.
6. Select Go! to set the route to your
destination.
2 Viewing the Destination Map
P. 76
■
Finding a Location Using Coordinates
1 Finding a Location Using Coordinates
If you want to change the coordinate format, press
the (Menu) icon or select and then select
Format.
18 RIDGELINE NAVI-31T6Z8100.book 71 ページ ２０１７年６月７日 水曜日 午後５時３７分
73
uuEntering a Destinationu Map Input
Navigation
Map Input
H u (Back) u View Map
Scroll the map to manually select an icon or a location as the destination.
1. Select any point on the map, a
street, intersection, or category
icon.
u Return to the current location
when you press the (Back)
icon.
2. Select Go! to set the route to your
destination.
2 Calculating the Route P. 74
1 Map Input
You can customize the map as you like using ,
, , or .
2 Map Operation P. 81
If you want to display a specific category of places,
select and then select a category icon.
The place information is displayed when you select
on the map.
2 Viewing the Destination Map P. 76
18 RIDGELINE NAVI-31T6Z8100.book 73 ページ ２０１７年６月７日 水曜日 午後５時３７分
75
uuCalculating the RouteuViewing and Selecting the Routes
Navigation
Viewing and Selecting the Routes
View and select different routes to your destination.
1. Select or to change a route.
u The travel distance, estimated
travel time, and traffic
information are displayed for
each route.
2. Select Go!.
u The system calculates and
displays the route line on the
map screen.
18 RIDGELINE NAVI-31T6Z8100.book 75 ページ ２０１７年６月７日 水曜日 午後５時３７分
77
Continued
Navigation
Driving to Your Destination
Viewing the Route
This section describes how to follow the route guidance to your destination.
After calculating the route to your
destination, the route is displayed on
the map screen.
2 During Route Guidance P. 7
As you drive, the system tracks your
position on the map in real time and
provides guidance as you approach
each guidance point on the route.
The following options are available:
• Select the text bar on the top of the map to display the turn list screen.
2 Turn List P. 78
• Select the next guidance indicator to display the turn information screen or
intersection view screen.
2 Turn Information P. 79
• Select to cancel the route guidance and remove your current route.
2 Canceling Your Route P. 10
• Select to display the map menu.
2 Map Menu P. 82
• Select to display the parking information screen of nearby parking.
■
Map Screen
1 Viewing the Route
When your phone is connected to Bluetooth®
HandsFreeLink®, the navigation screen will switch to
the incoming call screen when receiving a call.
Speed limit icon
The speed limit shown on the map may be different
from the actual speed limit.
The speed limit icon is not displayed on all roads.
Select the vehicle icon to view the Where Am I?
screen.
2 Viewing the Current Location Information
P. 84
You can stop your vehicle en route (e.g., to rest, stop
for gas, etc.), and then continue on your route.
If you did not complete your route, the navigation
restarts when you restart your vehicle.
When LaneWatch
*
is activated, the navigation screen
will switch to the LaneWatch screen.
Next guidance indicator
Speed limit icon
Dashboards
* Not available on all models
18 RIDGELINE NAVI-31T6Z8100.book 77 ページ ２０１７年６月７日 水曜日 午後５時３７分
uuDriving to Your Destination uViewing the Route
78
Navigation
• Select the map dashboards when you want to change the information that is
displayed. Select the following options:
Arrival Time, Distance, Time to Destination, Via Arrival, Distance to Via,
Time to Via, Direction of Travel, Elevation.
The turn list screen displays turn-by-turn instructions and the distance between
turns.
Select the text bar on the top of the
map.
u Select a turn to display the
detailed information.
2 Turn Information P. 79
u Press the (Menu) icon or select
to display the entire route on
the map.
2 Entire Route P. 79
■
Turn List
1 Viewing the Route
The next guidance indicator does not appear in the
following cases.
•
The vehicle speed is 3 mph (4.8 km/h) or less
•
The GPS signal is weak
•
The vehicle position on the map and current vehicle
position do not match
The system displays a roundabout to the next
guidance indicator in the following cases.
•
Its diameter is 82 ft (25 m) or more
•
There is no road inside it
•
There is no stop sign
Turn-by-Turn Directions
The next guidance point appears on the Multi-
Information Display (MID).
The Turn-by-Turn directions may not be displayed if
the information cannot be received correctly.
18 RIDGELINE NAVI-31T6Z8100.book 78 ページ ２０１７年６月７日 水曜日 午後５時３７分
Continued
79
uuDriving to Your DestinationuViewing the Route
Navigation
The turn information screen displays the turn on the map and the distance and time
remaining before you reach the turn. The lane assist screen may display a view of the
upcoming intersection.
Select the next guidance indicator of
the map or select any turn on the
turn list screen.
The entire route screen displays the entire route, destination name, time to
destination, and distance to destination.
1. Select the text bar on the top of
the map.
2. Press the (Menu) icon or select
.
3. Select Map to display the entire
route screen.
u Press the (Back) icon to
return to the previous screen.
■
Turn Information
1 Viewing the Route
Intersection View Screen
The intersection view screen displays a view of the
upcoming intersection and which lane you should be
driving.
■
Entire Route
18 RIDGELINE NAVI-31T6Z8100.book 79 ページ ２０１７年６月７日 水曜日 午後５時３７分
uuDriving to Your Destination uViewing the Route
80
Navigation
If you leave the calculated route, the system automatically recalculates a route to the
set destination based on your current location and direction.
If you set the trip log to show, a series of lines (breadcrumbs) are displayed to track
the path you are taking.
2 Map Layers P. 34
■
Deviating From the Planned Route
■
Trip Log Display
1 Trip Log Display
You can delete the Trip Log.
2 Device P. 50
2 Reset Factory Default Settings P. 52
18 RIDGELINE NAVI-31T6Z8100.book 80 ページ ２０１７年６月７日 水曜日 午後５時３７分
81
Navigation
Map Operation
Customize the map, set a destination, and save a place from the map.
1. Select any point on the map.
2. Select an option.
u If you want to set a destination
or save a location in the map,
scroll the map and select the
desired location.
2 Saved Locations P. 19
2 Map Input P. 73
The following options are available:
• : Zooms in to the map.
• : Zooms out of the map.
• : Switches the map to 2D or 3D.
• : Rotates the 3D map.
• : Sets the data that appears on the map.
2 Map Layers P. 34
1 Map Operation
When you select Track Up or North Up, the current
map scale and the (Track Up only) appear on the
map.
The always points to North.
2 Driving Map View (Map Orientation) P. 30
18 RIDGELINE NAVI-31T6Z8100.book 81 ページ ２０１７年６月７日 水曜日 午後５時３７分
Continued
83
uuMap OperationuMap Menu
Navigation
• Settings: Change settings for navigation functions.
2 System Setup P. 15
H u (Menu) u Exit Services
You can view exit services (e.g., whether the exit is near gas stations, restaurants,
etc.) and add new destinations or waypoints to the calculated route.
1. Select or to display your
desired list of exit services.
2. Select a category tab.
3. Select an option.
u The location is displayed on the
Calculate Route screen.
2 Viewing the Destination Map
P. 76
■
Viewing Exit Services
1 Viewing Exit Services
The map screen of the selected exit is displayed when
you select .
18 RIDGELINE NAVI-31T6Z8100.book 83 ページ ２０１７年６月７日 水曜日 午後５時３７分
87
uuMap OperationuTraffic Information
Continued
Navigation
2. Select an option.
The following options are available:
• Alternate Route: Display the alternate route screen.
2 Alternate Route P. 88
• Traffic On Route: Displays the traffic delays on your route. You can select the
traffic you want to avoid.
2 Traffic Rerouting Manually P. 89
• Traffic Conditions: Display the traffic flow and delays on nearby roads.
2 Viewing Traffic Delays P. 90
• Traffic Legend: Displays an overview of traffic legends.
2 Viewing Traffic Legends P. 90
18 RIDGELINE NAVI-31T6Z8100.book 87 ページ ２０１７年６月７日 水曜日 午後５時３７分
88
uuMap OperationuTraffic Information
Navigation
H uuAlternate Route
Display the alternate route screen.
Select Go!.
■
Alternate Route
18 RIDGELINE NAVI-31T6Z8100.book 88 ページ ２０１７年６月７日 水曜日 午後５時３７分
89
uuMap OperationuTraffic Information
Continued
Navigation
H uuTraffic On Route
View the traffic delays on your route, including the estimated time of each delay and
the distance to each delay. You can select the traffic you want to avoid manually.
1. Display a list of traffic events.
2. Select an option.
3. Select and then select Avoid
to avoid the traffic delay.
u Select or to view other
traffic delays on your route.
■
Traffic Rerouting Manually
18 RIDGELINE NAVI-31T6Z8100.book 89 ページ ２０１７年６月７日 水曜日 午後５時３７分
93
uuChanging Your Routeu Adding Waypoints
Navigation
Adding Waypoints
Add waypoints (pit stops) along the route to your destination.
1. While en route, select a search
method to add a new destination
or waypoint.
2 Entering a Destination P. 54
2. Select a place. Select Go!.
3. Select Add to Active Route.
u Select Start New Route to set
the location as your new
destination.
2 Entering a New Destination
P. 97
4. Select and hold , or
and then move the destination to
the desired position.
5. Select Done.
u The route is automatically
recalculated and displayed on
the map screen.
1 Adding Waypoints
When you add a waypoint, the system may take
some time to update the arrival time.
18 RIDGELINE NAVI-31T6Z8100.book 93 ページ ２０１７年６月７日 水曜日 午後５時３７分
94
Navigation
Changing Your Destination
Selecting a Destination on the Map
Select a new destination when en route by selecting a location on the map.
1. Select any point on the map, or a
street, intersection, or category
icon.
2. Select Go!.
3. Select an option.
The following options are available:
• Start New Route: Sets the location as your new destination.
• Add to Active Route: Sets the location as the first waypoint in the Edit Route
screen.
2 Adding Waypoints P. 93
18 RIDGELINE NAVI-31T6Z8100.book 94 ページ ２０１７年６月７日 水曜日 午後５時３７分
95
uuChanging Your DestinationuSearching Near Establishment
Continued
Navigation
Searching Near Establishment
H u (Menu) u Where Am I?
Search for a hospital, police station, or gas station around your current location.
1. Select a category type.
u You can also confirm your
current location, address, and
nearest intersection.
2. Select a place.
3. Select Go!.
18 RIDGELINE NAVI-31T6Z8100.book 95 ページ ２０１７年６月７日 水曜日 午後５時３７分
99
uuChanging Your DestinationuEntering a New Destination from Trip Planner
Continued
Navigation
5. Enter a route name.
6. Select Done.
7. Select Go!.
u Select Map to display the
destination and waypoints on
the map screen.
2 Reorder Your Destination
List Automatically P. 105
u Select to display the Edit
Trip screen.
2 Editing the Saved Route
P. 100
8. Select the next destination from
the list.
9. Select Start.
u The route is automatically
recalculated and displayed on
the map screen.
18 RIDGELINE NAVI-31T6Z8100.book 99 ページ ２０１７年６月７日 水曜日 午後５時３７分
100
uuChanging Your DestinationuEntering a New Destination from Trip Planner
Navigation
H u (Back) u Apps u Trip Planner
1. Select a saved route.
2. Select Go!.
3. Select the next destination from
the list.
4. Select Start.
u The route is automatically
recalculated and displayed on
the map screen.
H u (Back) u Apps u Trip Planner
1. Select a saved route you want to
edit.
2. Select .
■
Using the Saved Route
■
Editing the Saved Route
18 RIDGELINE NAVI-31T6Z8100.book 100 ページ ２０１７年６月７日 水曜日 午後５時３７分
102
uuChanging Your DestinationuEditing the Destination List
Navigation
Editing the Destination List
You can use the trip planner to edit and save a route with multiple destinations.
H u (Back) u Apps u Trip Planner
1. Select the trip you want to edit.
2. Select a place from the destination
list.
■
Editing Places on the Your Route
1 Editing the Destination List
Select Map to display the destination and waypoints
on the map screen.
2 Reorder Your Destination List
Automatically P. 105
18 RIDGELINE NAVI-31T6Z8100.book 102 ページ ２０１７年６月７日 水曜日 午後５時３７分
103
uuChanging Your Destinationu Editing the Destination List
Continued
Navigation
3. Select an option.
The following options are available:
• Departure Time (current location only): Sets the departure time.
• Clear Departure Time (current location only): Clears the departure time.
• Arrival Time (destination and waypoints): Sets the arrival time.
• Clear Arrival Time (destination and waypoints): Clears the arrival time.
• Duration (waypoints only): Sets the duration time.
• Change Location: Changes the destination or waypoint.
• Remove Location: Removes the destination or waypoint.
• Rename Location: Enters a new name for the location.
18 RIDGELINE NAVI-31T6Z8100.book 103 ページ ２０１７年６月７日 水曜日 午後５時３７分
107
Other Features
This section describes the useful functions incorporated into the
navigation system.
About Apps Menu ................................ 108
ecoRoute
TM
............................................ 109
Setting Up the Vehicle Profile ............... 110
Viewing the Vehicle Profile................... 112
Calibrating the Fuel Economy ............... 113
Viewing the ecoChallenge Scores......... 114
Viewing Fuel Economy Information ...... 115
Viewing a Mileage Report .................... 116
Information Functions .......................... 117
Help..................................................... 117
Where I've Been................................... 118
Calculator ............................................ 119
Unit Converter ..................................... 120
GPS Information................................... 121
18 RIDGELINE NAVI-31T6Z8100.book 107 ページ ２０１７年６月７日 水曜日 午後５時３７分
108
Other Features
About Apps Menu
H u (Back) u Apps
Display the useful functions incorporated into the navigation system.
Select an option.
The following options are available:
• Help: Displays the Help function.
2 Help P. 117
• ecoRoute
TM
: Allows for mileage and fuel cost entry and displays fuel economy
information, mileage reports, your driving habits, and vehicle information.
2 ecoRoute
TM
P. 109
• Trip Planner: Sets the trip planner to create and save a trip with multiple
destinations.
2 Editing the Destination List P. 102
2 Entering a New Destination from Trip Planner P. 98
• Where I've Been: Displays your previous routes and places you have stopped on
the map.
2 Where I've Been P. 118
• Calculator: Displays the calculator function.
2 Calculator P. 119
• Unit Converter: Displays the unit converter function.
2 Unit Converter P. 120
18 RIDGELINE NAVI-31T6Z8100.book 108 ページ ２０１７年６月７日 水曜日 午後５時３７分
109
Other Features
ecoRoute
TM
H u (Back) u Apps u ecoRoute
TM
The ecoRoute
TM
feature calculates the fuel economy and the fuel price of navigating
to a destination and offers tools for improving fuel efficiency.
The data provided by the ecoRoute
TM
feature is an estimate only.
To receive more accurate fuel reports for your specific vehicle and driving habits,
calibrate the fuel economy.
Select an option.
The following options are available:
• At The Pump: Calibrates the fuel economy to receive more accurate fuel reports.
2 Calibrating the Fuel Economy P. 113
• ecoChallenge: Helps you maximize the vehicle fuel economy by scoring your
driving habits.
2 Viewing the ecoChallenge Scores P. 114
• Fuel Economy: Displays fuel economy information.
2 Viewing Fuel Economy Information P. 115
• Vehicle Profile: Checks or resets your vehicle information.
2 Viewing the Vehicle Profile P. 112
• Mileage Report: Displays mileage reports for your vehicle.
2 Viewing a Mileage Report P. 116
1 ecoRoute
TM
The first time you use the ecoRoute
TM
features, you
must enter vehicle information.
2 Setting Up the Vehicle Profile P. 110
18 RIDGELINE NAVI-31T6Z8100.book 109 ページ ２０１７年６月７日 水曜日 午後５時３７分
113
uuecoRoute
TM
uCalibrating the Fuel Economy
Other Features
Calibrating the Fuel Economy
H u (Back) u Apps u ecoRoute
TM
u At The Pump
You can calibrate the fuel economy to receive more accurate fuel reports for your
specific vehicle and driving habits. You should calibrate when you fill up your fuel
tank.
1. Enter the current fuel price.
2. Enter the amount of fuel the
vehicle has used since the last time
the fuel tank was filled.
3. Enter the distance you have
traveled since the last time the fuel
tank was filled.
4. Select Next.
u The system calculates the
average vehicle fuel economy.
5. Select Save.
18 RIDGELINE NAVI-31T6Z8100.book 113 ページ ２０１７年６月７日 水曜日 午後５時３７分
114
uuecoRoute
TM
uViewing the ecoChallenge Scores
Other Features
Viewing the ecoChallenge Scores
H u (Back) u Apps u ecoRoute
TM
u ecoChallenge
The ecoChallenge feature helps you maximize fuel economy by scoring your driving
habits. When your ecoChallenge scores are high, it means you have saved more fuel.
The ecoChallenge collects data and calculates a score whenever the vehicle is
moving.
The following information is displayed:
• Current: Displays the score for your current driving activity.
• Overall: Displays an average of the speed, acceleration, and braking score.
• Speed: Displays your score for driving your vehicle at the optimal speed for
conserving fuel (45–60 mph (72–96 km/h) for most vehicles).
• Acceleration: Displays your score for smooth and gradual acceleration. You lose
points for rapid acceleration.
• Braking: Displays your score for smooth and gradual braking. You lose points for
hard braking.
1 Viewing the ecoChallenge Scores
If you want to reset the ecoChallenge scores, select
and then select Reset.
18 RIDGELINE NAVI-31T6Z8100.book 114 ページ ２０１７年６月７日 水曜日 午後５時３７分
115
uuecoRoute
TM
uViewing Fuel Economy Information
Other Features
Viewing Fuel Economy Information
H u (Back) u Apps u ecoRoute
TM
u Fuel Economy
You can view your fuel consumption, your total fuel cost, and your average fuel
economy.
Select a section of the graph to zoom
in.
1 Viewing Fuel Economy Information
If you want to reset the Fuel Economy information,
select and then select Reset.
18 RIDGELINE NAVI-31T6Z8100.book 115 ページ ２０１７年６月７日 水曜日 午後５時３７分
117
Continued
Other Features
Information Functions
Help
H u (Back) u Apps u Help
Select a help topic you want to
display.
H u (Back) u Apps u Help u
1. Enter a keyword. Select Done.
1 Help
You can also display the help topic to select on
each menu screen.
■
Searching Help Topics
18 RIDGELINE NAVI-31T6Z8100.book 117 ページ ２０１７年６月７日 水曜日 午後５時３７分
uuInformation FunctionsuWhere I've Been
118
Other Features
2. Select a help topic you want to
display.
Where I've Been
H u (Back) u Apps u Where I've Been
Before you can use this feature, you must enable the travel history feature. You can
view your previous routes and places you have stopped on the map.
1 Where I've Been
If you want to delete the recorded information, select
and then select Clear Travel History.
If you select , you can select the day to
display the travel history.
18 RIDGELINE NAVI-31T6Z8100.book 118 ページ ２０１７年６月７日 水曜日 午後５時３７分
119
uuInformation FunctionsuCalculator
Other Features
Calculator
H u (Back) u Apps u Calculator
Enter a numeric value to calculate.
18 RIDGELINE NAVI-31T6Z8100.book 119 ページ ２０１７年６月７日 水曜日 午後５時３７分
121
uuInformation FunctionsuGPS Information
Other Features
GPS Information
H u (Back)
The GPS info screen displays the satellites' status.
Select and hold .
u A solid bar indicates that the GPS
satellite is ready for use.
18 RIDGELINE NAVI-31T6Z8100.book 121 ページ ２０１７年６月７日 水曜日 午後５時３７分
124
Troubleshooting
Troubleshooting
Map, Voice, Entering Destinations
Problem Solution
The Startup Confirmation screen is displayed every
time I start the car.
This is normal. The Startup Confirmation screen reminds you and your guest
drivers to always operate the navigation system in a safe manner. The Startup
Confirmation screen goes off after a certain period of time, even if you do not
select OK.
The navigation system reboots by itself (returns to
the opening screen).
A reboot can be caused by extreme temperatures or shock from bumpy roads, and
does not necessarily indicate a problem. If this happens frequently, please see your
dealer.
How do I specify a destination when an entered city
or street could not be found?
Try selecting the destination directly from the map.
2 Map Input P. 73
How do I delete saved places? 1. Select > > Saved > > Delete Saved Places.
2. Select saved places you want to delete.
3. Select Delete.
4. Select Yes.
I cannot hear the navigation system voice. 1. Select and then select the (Back) icon. Select Settings >
Navigation and set Voice Prompt to on.
2. Press the (Home) icon. Select Settings > System > Sound/Beep tab.
Turn up Guidance Volume, if guidance volume is low.
For more details, see the Owner’s Manual.
18 RIDGELINE NAVI-31T6Z8100.book 124 ページ ２０１７年６月７日 水曜日 午後５時３７分
125
uuTroubleshootinguTraffic
Troubleshooting
Traffic
Problem Solution
Traffic information is missing or is not displaying
properly. What is wrong?
Verify the following:
●
Traffic information relies on a clear signal. If signal strength is low, traffic data
may not be available.
●
Check that the traffic icons are turned on.
2 Traffic Information P. 86
●
It is possible that there is a temporary technical problem with your metropolitan
area traffic provider. You can call Honda Automobile Customer Service to see if
there is an outage.
2 Honda Automobile Customer Service Contact Information P. 132
●
If the situation persists, see your Honda dealer for assistance.
●
Traffic information is available only in certain areas.
18 RIDGELINE NAVI-31T6Z8100.book 125 ページ ２０１７年６月７日 水曜日 午後５時３７分
126
uuTroubleshootinguGuidance, Routing
Troubleshooting
Guidance, Routing
Problem Solution
The navigation system does not route me the same
way I would go or the same way as other mapping
systems.
The navigation system attempts to generate the optimal route. You can change the
route preferences used when calculating a route.
2 Recalculate Using Another Route Preference P. 106
The street I’m on is not shown on the map screen. The mapping database is constantly undergoing revision.
The vehicle position icon is not following the road.
●
Check that the GPS antenna (located in the dashboard) is not blocked. For best
reception, remove items from the dashboard, such as radar detectors, cellular
phones, or loose articles.
●
Metallic tinting or other aftermarket devices can interfere with GPS reception.
Please consult your dealer.
2 GPS P. 130
How do I stop the map from rotating as I drive
along?
1. Select and then press the (Back) icon.
2. Select Settings > Map & Vehicle > Driving Map View.
3. Check that Driving Map View is set to Track Up or 3-D.
4. Select North Up and then select Save.
The “Arrival time” display sometimes increases
even though I am getting closer to my destination.
“Arrival time” is based on the speed limit on each road. Depending on the traffic
conditions, the “Arrival time” may be calculated to be earlier or later.
My elevation (shown when I display the current
position) seems to fluctuate even though my
elevation has not changed.
This is normal. The elevation can vary ±100 ft (30 m) due to GPS calculation errors.
2 GPS P. 130
My elevation is missing on the “current position”
screen.
The elevation is only displayed if the GPS antenna can receive signals from at least
four satellites. Try moving the vehicle into an open area. The elevation is also not
displayed if the calculated elevation is zero or below sea level.
18 RIDGELINE NAVI-31T6Z8100.book 126 ページ ２０１７年６月７日 水曜日 午後５時３７分
127
uuTroubleshootingu Update, Coverage, Map Errors
Troubleshooting
Update, Coverage, Map Errors
Display, Accessories
Problem Solution
My city is not part of a fully verified detailed
coverage area.
The mapping database is constantly undergoing revision.
Does the navigation system work outside North
America?
The system contains maps for the contiguous United States, Canada, Mexico,
Puerto Rico, US Virgin islands, Cayman Islands, Bahamas, French Guyana,
Guadeloupe, Martinique, Saint Barthelme, and Jamaica. The navigation system
will not work in other countries.
2 Map Coverage P. 133
Problem Solution
The display appears dim when starting the car in
really cold weather.
This is normal. The display will become brighter after a few minutes.
18 RIDGELINE NAVI-31T6Z8100.book 127 ページ ２０１７年６月７日 水曜日 午後５時３７分
129
Reference Information
System Limitations ................................130
GPS ......................................................130
Address Calculation ..............................130
Database ..............................................130
Customer Assistance .............................132
Resolving Problems ...............................132
Obtaining a Navigation Update .............132
Honda Automobile Customer Service
Contact Information............................132
Visiting Your Dealer ..............................133
Map Coverage ......................................133
Traffic Information ................................133
Legal Information ................................. 134
User Agreement................................... 134
18 RIDGELINE NAVI-31T6Z8100.book 129 ページ ２０１７年６月７日 水曜日 午後５時３７分
130
Reference Information
System Limitations
GPS
The signals received from GPS satellites are
extremely weak (less than a millionth of the
strength of a local FM station) and require
an unobstructed view of the sky. The GPS
antenna is located in the dashboard. The
signal reception can easily be interrupted or
interfered with by the following:
• Metallic window tint on the front or side
windows
• Cellular phones, PDAs, or other electronic
devices docked in a cradle or lying loose
on the dashboard
• Remote starters or “hidden” vehicle
tracking systems mounted near the
navigation unit
• Audio electronic devices mounted near
the navigation unit
• Trees, tall buildings, highway overpasses,
tunnels, or overhead electrical power
wires
GPS is operated by the U.S. Department of
Defense. For security reasons, there are
certain inaccuracies built into GPS for which
the navigation system must constantly
compensate. This can cause occasional
positioning errors of up to several hundred
feet (meters).
Address Calculation
The destination icon shows only the
approximate location of a destination
address. This occurs if the number of
possible addresses is different from the
number of actual addresses on a block. For
example, the address 1425 on a 1400 block
with 100 possible addresses (because it is
followed by the 1500 block) will be shown a
quarter of the way down the block by the
system. If there are only 25 actual addresses
on the block, the actual location of address
1425 would be at the end of the block.
Database
The digitized map database reflects
conditions as they existed at various points
in time before production. Accordingly,
your database may contain inaccurate or
incomplete data or information due to the
passage of time, road construction,
changing conditions, or other causes.
For example, some places/landmarks may
be missing when you search the database
because the name was misspelled, the place
was improperly categorized, or a place/
landmark is not yet in the database. This is
also true for police stations, hospitals, and
other public institutions. Do not rely on the
navigation system if you need law
enforcement or hospital services. Always
check with local information sources.
18 RIDGELINE NAVI-31T6Z8100.book 130 ページ ２０１７年６月７日 水曜日 午後５時３７分
131
uuSystem LimitationsuDatabase
Reference Information
The database does not include, analyze,
process, consider, or reflect any of the
following categories of information:
• Neighborhood quality or safety
• Population density
• Availability or proximity of law
enforcement
• Emergency, rescue, medical, or other
assistance
• Construction work, zones, or hazards
• Road and lane closures
• Legal restrictions (such as vehicular type,
weight, load, height, and speed
restrictions)
• Road slope or grade
• Bridge height, width, weight, or other
limits
• Traffic facilities safety
• Special events
• Pavement characteristics or conditions
Every effort has been made to verify that
the database is accurate. The number of
inaccuracies you experience increases the
longer you go without obtaining an
updated map database.
2 Obtaining a Navigation Update P. 132
We assume no liability for any incident that
may result from an error in the program, or
from changed conditions not noted above.
18 RIDGELINE NAVI-31T6Z8100.book 131 ページ ２０１７年６月７日 水曜日 午後５時３７分
132
Reference Information
Customer Assistance
Resolving Problems
If you run into a specific issue that you
cannot resolve, consult the following help
resources:
• For navigation system issues:
2 Troubleshooting P. 124
Or, please contact your dealer.
• For traffic-related issues:
2 Traffic P. 125
• For reporting issues with the database or
places/landmarks:
• Visit
https://my.garmin.com/mapErrors/
report.faces
• Or call Garmin OEM support directly at
(855) 607-2536.
Obtaining a Navigation
Update
Honda is continuously updating the
navigation system and new software is
usually made available on an annual basis.
For information on navigation updates for
your vehicle, please visit:
• U.S.: hondanavi.navigation.com
• Canada: www.honda.ca
You can also contact your Honda dealer for
further information regarding the update
program available for your vehicle.
Honda Automobile
Customer Service Contact
Information
Honda Navi
American Honda Motor Co., Inc.
Honda Automobile Customer Service
Mail Stop 100-5E-8A
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: (800) 999-1009
Fax: (310) 783-3023
Honda Canada Inc.
Honda Customer Relations
180 Honda Blvd.
Markham, ON
L6C 0H9
Tel: (888)-9-HONDA-9
Hours: 8:00 am to 7:30 pm Mon to Fri (EST)
18 RIDGELINE NAVI-31T6Z8100.book 132 ページ ２０１７年６月７日 水曜日 午後５時３７分
138
Voice Commands
Voice Commands
Navigation Commands
The system only accepts these commands
on a Map/Guidance screen.
Navigation
View Map
Go Home
Find Place
Find Address
Find Category
Find City
Find Intersection
Saved Places
Recently Found
Stop Route
Detour
Back
Page Up
Page Down
Exit
■
Voice Portal Commands
■
Navigation Commands
■
Other Commands
Yes
No
Navigate
Main Menu
Start New Route
Add to Active Route
View List
Change Country
Along Route
Near Destination
Near Current Location
View Categories
1
2
3
4
5
Restaurants
Everyday Life
Banks & ATMs
Rest Areas
Attractions
■
Line Number Commands
■
Category Commands
Medical Care
Shopping
Gas Station
Parking
Art & Entertainment
Recreation
Transit
Lodging
All Restaurants
Browse By Style
Barbecue
Coffee and Tea
Delis
Donuts and Baked Goods
Fast Food
Fish and Seafood
Grills
Pizza
Steakhouses
Wine, Beer, and Liquor
All Everyday Life
Auto Services
Car Washes
Colleges and Universities
Community Services
■
Sub Category Commands
18 RIDGELINE NAVI-31T6Z8100.book 138 ページ ２０１７年６月７日 水曜日 午後５時３７分
139
uuVoice CommandsuNavigation Commands
Voice Commands
Convenience Store
Fitness and Gyms
Laundry Services
Libraries
Places of Worship
Post Offices
Schools
Veterinary Clinics
All Attractions
Amusement Parks
Event Centers
Historical Landmarks
Museums and Galleries
Offbeat Places
Parks and Gardens
Tourist Information
Wineries and Breweries
Zoos and Aquariums
All Medical Care
Hospitals
Doctor Offices
Pharmacies
All Shopping
Books, Music, and Movies
Clothing and Accessories
Computers and Electronics
Convenience Store
Department Stores
Florists and Gifts
Grocery Stores
Home and Garden
Housewares
Office Supply and Shipping
Pharmacies
Shopping Centers
Sporting Goods
Wine, Beer, and Liquor
All Art & Entertainment
Bars and Pubs
Casinos
Movie Theaters
Museums and Galleries
Nightclubs
Performing Arts
All Recreation
Amusement Parks
Bowling Center
Camps and Retreats
Golfing
Skiing and Winter Sports
Sport Centers
Stadiums and Tracks
All Transit
Bus Stations
Ferry Terminals
Transit Service
Truck Stops
Airports
Car Rental
Train Stations
Travel Agents
All Lodging
Bed and Breakfast or Inn
Campground or RV Park
Hotel or Motel
18 RIDGELINE NAVI-31T6Z8100.book 139 ページ ２０１７年６月７日 水曜日 午後５時３７分
140
Voice Commands
List of Categories
Restaurants Everyday Life Recreation
Barbecue Fish and Seafood Auto Services Laundry Services Amusement Parks
Skiing and Winter Sports
Coffee and Tea Grills Car Washes Libraries Bowling Center Sports Centers
Delis Pizza
Colleges and Universities
Places of Worship Camps and Retreats Stadiums and Tracks
Donuts and Baked Goods
Steakhouses Community Services Post Offices Golfing
Fast Food Wine, Beer, and Liquor Convenience Store Schools Medical Care
Shopping Fitness and Gyms Veterinary Clinics Doctor Offices Pharmacies
Books, Music, and Movies
Home and Garden Art & Entertainment Hospitals
Clothing and Accessories
Housewares Bars and Pubs Museums and Galleries Transit
Computers and Electronics
Office Supply and Shipping
Casinos Nightclubs Airports Train Stations
Convenience Store Pharmacies Movie Theaters Performing Arts Bus Stations Transit Service
Department Stores Shopping Centers Attractions Car Rental Travel Agents
Florists and Gifts Sporting Goods Amusement Parks Parks and Gardens Ferry Terminals Truck Stops
Grocery Stores Wine, Beer, and Liquor Event Centers Tourist Information Gas Stations
Lodging Historical Landmarks Wineries and Breweries Banks & ATMs
Bed and Breakfast or Inn
Hotel or Motel Museums and Galleries Zoos and Aquariums Parking
Campground or RV Park
Offbeat Places Rest Areas
18 RIDGELINE NAVI-31T6Z8100.book 140 ページ ２０１７年６月７日 水曜日 午後５時３７分
142
Index
N
Navigation................................................... 36
Navigation Top Screen ................................. 3
North Up ..................................................... 30
O
Other Settings............................................. 46
P
Personal Information.................................. 18
S
Saved Locations .......................................... 19
Deleting............................................... 24, 25
Editing....................................................... 22
Saving ....................................................... 19
Setting
Data Reset................................................. 52
Device ....................................................... 50
Display Mode Settings ............................... 26
Language & Keyboard ............................... 47
Map & Vehicle ........................................... 28
Navigation................................................. 36
Other Settings ........................................... 46
Personal Information.................................. 18
Traffic........................................................ 45
Start-up ....................................................... 16
Stopping the Route .................................... 91
System Limitations.................................... 130
T
Track Up...................................................... 30
Traffic
Indicator...................................................... 6
Setting ...................................................... 45
Traffic Information .................................... 86
Troubleshooting................................. 12, 124
U
Unit Converter.......................................... 120
Units............................................................ 46
Update System Software
Obtaining Update Data ........................... 132
V
Vehicle ........................................................ 29
Vehicle Profile .................................. 110, 112
Voice Commands
Basic Operation ........................................... 5
Voice Commands List .............................. 138
Voice Control System ................................ 17
Voice Control Operation............................ 11
Voice Recognition ...................................... 17
W
Where I’ve Been ....................................... 118
18 RIDGELINE NAVI-31T6Z8100.book 142 ページ ２０１７年６月７日 水曜日 午後５時３７分
18 RIDGELINE NAVI-31T6Z8100.book 143 ページ ２０１７年６月７日 水曜日 午後５時３７分
