PT506BT
with Bluetooth
Specification
1.Rated Output Power………………………… ….. 2CHx30Watts( RMS, 8 Ohm)
Max Output Power……………………………….2CHx100Watts(RMS, 8 Ohm)
2.Rated Input Level/Impedance
Audio Input…………………………………………………….....230mV/47Kohm
Microphone Input…………………………………………………...7mV/600Ohm
3.Tone Control
Bass F=100Hz………………………………………………………………..+10dB
Treble F=10Khz………………………………………………………….….. +10dB
4.Separation
Master Channel ………………………………………………………..…...≥45dB
5.Frequency Response
Master Channel F=20Hz-20KHz………………………………………….+1.5dB
6.Signal To Noise
Master Channel ………………………………………..………………......≥81dB
7.Speaker System
Master Channel ……………………………………………………...4Ohm/8Ohm
8.Input Power ………………………………….………..AC 110/60Hz; 230V/50Hz
9.Power Consumption…………………………………………………..……. 200W
10. Unit Size(WxHxD) Inch……………………………………12.60"x2.95"x7.48"
11. Unit Weight………………………………………………………….…….....8.8lb
In-Wall/Wall Plate Stereo Amplifier with Bluetooth/Aux(3.5mm) /
Microphone (1/4") Input, USB Charge & USB/ SD Card Reader
Stereo Powered Amplifier with Bluetooth/AUX (3.5mm)/
Micrphone (1/4") Input/FM Tuner/USB Charge & USB/SD
Card Reader
