Instruction manual air conditioner Dimplex DCSS12

Contents

  • SAFETY PRECAUTIONS
  • NAMES OF PARTS
  • INDOOR UNIT DISPLAY
  • OPERATING INSTRUCTIONS
  • PROTECTION
  • INSTALLATION MANUAL
  • MAINTENANCE
  • TROUBLESHOOTING
  • EMERGENCY FUNCTION & AUTO-RESTART FUNCTION
  • REMOTE CONTROLLER

Cleaning the heat exchanger

  •  Open the front panel of the unit and lift it till its greatest stroke and then unhooking it from the hinges to make the cleaning easier.
  • Clean the indoor unit using a cloth with the water ( not higher than 40 ) and neutral soap . Never use aggressive solvents or detergents.
  • If the outdoor unit is clogged , remove the leaves and the waste and remove the dust with air jet or a bit of water

End of season maintenance

  • Disconnect the automatic switch or the plug.
  • Clean and replace the filters
  • On a sunny day let the conditioner work in ventilation for some hours , so that the inside of the unit can dry completely.

Troubleshooting

The appliance does not operate:

  • Power failure/plug pulled out Damaged indoor/outdoor unit fan motor
  • Faulty compressor thermomagnetic circuit breaker
  • Faulty protective device or fuses.
  • Loose connections or plug pulled out It sometimes stops operating to protect the appliance.
  • Voltage higher or lower than the voltage range Active TIMER-ON function
  • Damaged electronic control board
