Lutron
app
Lutron Smart
Bridge
Motorized
shade
In-wall light
dimmer
Plug-in lamp
dimmer
Remote
control
NEW
Lutron Wireless
Adjust your lights, shades, and temperature from anywhere
Control from anywhere
•
Turn lights on from your car
•
Adjust temperature from your office
•
Turn off lights and close shades from your bed
•
Schedule lights, shades, and temperature to automatically adjust at set times of day
Install in minutes
•
Ideal for existing or new homes
•
No new wiring required
•
Set up is easy — watch the installation videos on
www.casetawireless.com
NEW!
Wi-Fi thermostat
Turn lights on
as you arrive home
Peace of mind.
Comfort.
Convenience.
Caséta Wireless provides all of these,
at the touch of a button.
Whether you want your lights on,
off, or somewhere in between, your
shades raised or lowered, or your
temperature set back a few degrees,
you can count on Caséta Wireless to
deliver what you need.
Caséta Wireless also uses Lutron’s
Clear Connect
® wireless technology,
for reliable operation.
Once you try Caséta Wireless, you’ll
wonder how you ever lived without it.
Turn lights off
and close shades
from your bedside
Adjust temperature
from your office
Welcome to
Turn entryway and outdoor lights
on from the security of your car.
No need to get out of bed.
Simply turn the lights off and
close shades from your bedside
and drift into sleep.
Forgot to set your thermostat
back? Lower it from work, to save
energy during the day. Then raise it
before you leave, for a comfortable
welcome home.
Product Information
Smart Bridge
•
enables control of lights, shades, and temperature
using the Lutron app
•
compatible with Caséta
™
Wireless dimmers and
switches, Serena
® battery-powered shades, and
the Honeywell
® Wi-Fi thermostat
•
easy to install; just plugs into your Wi-Fi router
•
uses Clear Connect® wireless technology—
no callbacks
Smart Bridge Pro
•
also compatible with Lutron Triathlon® battery-
powered shades and select styles of Sivoia
® QS
Wireless shades
•
adds integration with third-party A/V remote
controls and security systems
Lutron app
•
works in conjunction with the Smart Bridge and
Smart Bridge Pro
•
control individual lights, shades, and thermostats—
even when you’re away from home
•
add scenes to control multiple lights and shades
with a single touch
•
schedule scenes to adjust lights and
shades automatically
•
download for free from the App Store or
Google play
Pico® remote control
•
provides convenient remote control
•
add a light switch without having to
wire anything
•
battery powered
•
use as a hand-held remote, clipped to a car
visor, mounted to a tabletop pedestal, or
mounted to a wall
•
features a 10-year battery life
•
works with Caséta Wireless dimmers
and wireless shades
Wallplate bracket kit
1
2
Car visor clip
Tabletop pedestal
Accessories for
Pico remote control
Black
Black
Product information
Switch
•
controls wall and ceiling lights as well as
general purpose fans
•
doesn’t require a neutral wire
•
minimum load cap included (for switching
LED, CFL, and ELV loads)
•
use Pico remotes for additional switches in
multi-location applications
In-wall dimmer
•
controls wall and ceiling lights
•
installs in as little as 15 minutes
•
doesn’t require a neutral wire—ideal for retrofit or
new construction
•
no polarity for line or load wiring—
mistake-proof wiring
•
works with approved dimmable LEDs and
compact fluorescents (CFLs)
•
also works with halogen and incandescent bulbs
•
use Pico® remotes for additional switches in multi-
location applications
Black
Black
LED CFL
Halogen Incandescent
•
The Lutron LED Center of Excellence
is the industry resource for LED control:
1.877.DIM.LED8 or LEDS@lutron.com.
•
UL Listed to dim over 500 different LED
and CFL light bulbs. The bulb list is
available at www.casetawireless.com.
•
Patent-pending technology ensures
superior performance with dimmable
LEDs and CFLs, as well as halogen
and incandescent bulbs. You can even
use different light bulb types with the
same dimmer.
Caséta
™
Wireless works
with energy-efficient,
dimmable light bulbs
Plug-in lamp dimmer
•
controls table and floor lamps
•
features two receptacles for simultaneous control
of two lamps
•
simply plugs into a standard wall receptacle
•
works with dimmable LEDs and CFLs
•
also works with halogen and incandescent bulbs
Product information
Lutron motorized shades
•
battery-powered; batteries last 3 – 5 years
•
wireless, easy to install
•
cordless design
•
available in roller or insulating honeycomb styles
•
Serena® shades compatible with Lutron Smart Bridge and Smart Bridge Pro
•
Triathlon® shades and select styles of Sivoia® QS Wireless shades compatible with Smart Bridge Pro only
HoneycombRoller
Honeywell® VisionPRO programmable Wi-Fi thermostat
•
7-day programmable schedule
•
large touchscreen display with backlight
•
precise comfort control
Lutron app also compatible with other select Honeywell Wi-Fi programmable thermostats.
NEW
Caséta
™
Wireless ordering information
** For multi-location applications, replace additional switches with Pico remote controls using wallplate brackets.
†
Switching ELV, LED, CFL requires minimum load cap LUT-MLC (included)
* XX denotes gloss color suffix (at right).
In-wall dimmers and switches not
available in White/Gray (WG)
White (WH)
Ivory (IV)
Light Almond (LA) White/Gray (WG)
Black (BL)
Product Name Model Number Specifications/Descriptions Voltage
List
Price
Dimmers and Switches
In-wall
Light
Dimmer
PD-6WCL-XX*
Single pole/multi-location**
150 W dimmable LED/CFL,
600 W incandescent/halogen
434 MHz
120 V~
no polarity for
line or load
wiring
$72.00
In-wall
Light
Switch
PD-5WS-DV-XX*
Single pole/multi-location**
600 W incandescent/ELV
†
600 VA MLV
5 A LED/CFL
†
3A general purpose fan
434 MHz
120 /277 V~
no neutral
$89.00
Plug-in
Lamp
Dimmer
PD-3PCL-WH
Use with one or two lamps
100 W dimmable LED/CFL
300 W incandescent/halogen
434 MHz
120 V~
plugs into
a standard
receptacle
$72.00
Pico® Remote Control and Accessories
Pico
Remote
Control
PJ2-3BRL-WH-L01R
(White)
3-button with raise/lower and
light icon engraving
434 MHz
Additional styles of Pico available.
Please visit www.lutron.com/pico
to view the full selection
3 V- 10 mA
uses single
CR 2032
battery
(included)
$21.00
PJ2-3BRL-LA-L01R
(Light Almond)
Wallplate
Bracket
PICO-WBX-ADAPT
Wallplate bracket allows for easy
installation of a Pico remote control
over an existing wallbox or directly
on any wall surface
$8.00
Car Visor
Clip
PICO-CAR-CLIP
Provides an easy way to attach a
Pico remote control to your car’s
sun visor
$9.00
Tabletop
Pedestal
L-PED1-WH Single pedestal—White
$15.00
L-PED1-BL Single pedestal—Black
$25.00
L-PED2-WH Double pedestal—White
$30.00
L-PED2-BL Double pedestal—Black
$40.00
Product Name Model Number Specifications/Descriptions Voltage
List
Price
Smart Bridge and Smart Bridge Pro
Smart Bridge L-BDG-WH
Smart Bridge allows control via
the Lutron app
$150.00
Smart Bridge
Pro
L-BDGPRO-WH
Smart Bridge Pro allows third-
party integration and control via
the Lutron app
$200.00
Thermostat
Honeywell
VisionPro
Wi-Fi
Thermostat
L-HWLV-WIFI
Up to 3 heat/2 cool heat pump or
up to 2 heat/2 cool conventional
24 V~
Requires common wire connection
$331.00
Motorized Shades
Please visit:
www.lutron.com/triathlon
www.lutron.com/serena
Kits
In-wall Light
Dimmer
with Pico
®
Remote Kit
P-PKG1W-WH
(White only)
(1) PD-6WCL-WH
(1) PJ2-3BRL-WH-L01R
(1) CW-1-WH (Claro
® wallplate)
$80.00
Plug-in Lamp
Dimmer with
Pico Remote
Kit
P-PKG1P-WH
(White only)
(1) PD-3PCL-WH
(1) PJ2-3BRL-WH-L01R
$80.00
Pico Remote
Control
with Wall
Mounting Kit
PJ2-WALL-WH-L01
(White only)
(1) PJ2-3BRL-WH-L01R
(1) PICO-WBX-ADAPT
(1) CW-1-WH (Claro wallplate)
$32.00
