Getting started
3 About this manual
7 Layout
14 Turning the computer on
and off
16 Unlocking the screen
16 Windows
Basics
18 Using the computer as a
tablet
20 Using the S Pen
32 Touch screen (optional)
37 Keyboard
39 Touchpad
42 Fingerprint recognition
44 Memory card tray
47 External display
49 Wireless LAN
51 Bluetooth
53 Thunderbolt
™
3
54 Wireless PowerShare
(WPS)
Applications
57 Using applications
58 Samsung Settings
59 Samsung Security
61 Samsung Update
62 Online Support (S Service)
63 Samsung PC Help (Self-
help application)
64 Samsung PC Cleaner
65 Quick Search
Settings & Upgrade
66 LCD brightness
68 Volume
69 BIOS (Setup utility)
75 Battery
Troubleshooting
78 Samsung Recovery
83 Windows recovery
function
83 Q&A
Appendix
86 Product specifications
87 Ergonomic tips
91 Safety precautions
101 Important safety
information
104 Replacement parts and
accessories
107 Regulatory compliance
statements
116 WEEE symbol information
118 Samsung package Take-
Back program (USA only)
Table of contents
3
Getting started
About this manual
•
This user manual is specially designed to detail the computer’s
functions and features.
•
The user manual supplied with the computer may vary
depending on the model.
•
Please read this manual before using the computer to ensure
safe and proper use.
•
Optional accessories, some devices, and software referred to
in this manual may not be provided or may not be subject to
upgrades. Note that the computer environment referred to in
the user manual may not be the same as your environment.
•
Descriptions are based on the computer’s default settings
and the Windows 10 operating system. Available features and
additional services may vary depending on the computer or
operating system.
•
This user manual describes procedures for using the
touchpad, mouse and touch screen. Instructions for using the
touch screen are for models with the touch screen feature.
•
Images and screenshots are those of the representative model
of the series and may differ in appearance from the actual
product.
•
Content may differ from the final product and is subject to
change without prior notice. For the latest version of the
manual, refer to the Samsung website, www.samsung.com.
Getting started
4
Copyright
Copyright © 2020 Samsung Electronics
This manual is protected under international copyright laws.
No part of this manual may be reproduced, distributed, translated,
or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording, or storing in any
information storage and retrieval system.
Computer specifications or the contents of this manual may
be changed without prior notice due to an upgrade of the
computer’s functions.
Instructional icons and expressions
Warning
: situations that could cause injury to yourself or
others
Caution
: situations that could cause damage to the
computer or other equipment
Note
: notes, usage tips, or additional information
The path you should follow to carry out an instruction. For
example, “select
Settings
→
Devices
” indicates that you
should select
Settings
and then
Devices
.
Select Click the mouse or tap the touchpad or touch screen.
Getting started
5
•
HDMI, the HDMI logo, and
the term High Definition
Multimedia Interface are
trademarks or registered
trademarks of HDMI Licensing
LLC.
•
Thunderbolt and the Thunderbolt logo are trademarks of Intel
Corporation in the U.S. and/or other countries.
•
All other trademarks and copyrights are the property of their
respective owners.
As an ENERGY STAR
®
Partner,
Samsung has determined that this
product meets the ENERGY STAR
®
guidelines for energy efficiency.
•
The ENERGY STAR Program has reduced greenhouse gas
emissions and saved energy through voluntary labeling.
•
Power management setting of this product has been enabled
by default, and has various timing settings from 1 minute to
5 hours.
•
The product can wake with a button press on the chassis from
sleep mode.
Trademarks
•
Samsung and the Samsung logo are trademarks or registered
trademarks of Samsung Electronics.
•
Intel and Core are trademarks or registered trademarks of the
Intel Corporation.
•
Microsoft, MS-DOS, and Windows are trademarks or registered
trademarks of the Microsoft Corporation.
•
Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc.
worldwide.
•
Wi-Fi
®
, Wi-Fi Direct
™
, Wi-Fi CERTIFIED
™
, and the Wi-Fi logo
are registered trademarks of the Wi-Fi Alliance.
Getting started
6
Product capacity representation
Storage capacity representation
The capacity of the storage device (HDD, SSD) of the manufacturer
is calculated assuming that 1 KB = 1,000 Bytes.
However, the operating system (Windows) calculates the storage
device capacity assuming that 1 KB = 1,024 Bytes. Therefore, the
available capacity of the HDD in Windows is smaller than the
actual capacity due to the difference in capacity calculation. For
example, for an 80 GB HDD, Windows calculates the capacity as
74.5 GB, (80x1,000x1,000x1,000) Bytes/(1,024x1,024x1,024) Bytes
= 74.505 GB.
In addition, the capacity representation in Windows may be even
smaller because some programs, such as Samsung Recovery, may
reside in a hidden area of the HDD.
Memory capacity representation
The available memory capacity in Windows is less than the actual
capacity of memory. This is because some memory is required for
regular system operations.
For example, for 1 GB (= 1,024 MB) memory installed, Windows
may report the capacity as 1,022 MB or less.
Data precautions
Samsung Electronics shall not be liable for any data loss. Please
take care to avoid losing any important data and back up your
data to prevent any such data loss.
Operating system and software support
If you change the product’s factory OS (Operating System) to
another OS or if you install software which is not supported by the
product’s original factory OS, you will not receive any technical
support, product exchange or refund, and a fee will be charged
when requesting a service.
Please use your computer with the original factory OS. If you
install an OS other than the factory OS, data may be deleted or the
computer may not start.
* Please use Windows 10 64-bit only for this model.
Getting started
8
►
For 15.6 inch models
8
3
4
2
1
6
7
5
Front view
►
For 13.3 inch models
8
3
4
2
1
6
7
5
Getting started
9
Number/Name Description
Fingerprint
recognition
sensor
•
The fingerprint recognition sensor
recognizes fingerprints. Scans a
fingerprint to sign in to Windows,
apps, and services.
Touchpad
•
Moves the cursor and selects
options.
•
Functions as a mouse.
Number/Name Description
Microphone
•
You can use the built-in
microphone.
Camera
•
Using this camera, you can take
still pictures and record video.
Camera indicator
light
•
This indicates the camera
operating status.
LCD/Touch screen
(optional)
•
The screen’s images are displayed
here.
•
Recognizes touch interactions
(Only for touch screen models).
Operating
status LED and
Illumination
sensor
•
Shows the operating status of the
computer.
Keyboard
•
Enter text or control computer
functions.
Getting started
13
Number/Name Description
Fan vents
•
Sucks in outside air and discharges
heat generated inside the computer
through these holes.
•
If the vents are blocked the computer
may overheat. Avoid blocking the vents
as this may be dangerous.
Internal
battery
•
Provides power to the computer when
not connected to an AC adapter.
•
To remove or replace the internal
battery, take it to a Samsung Service
Center. You will be charged for this
service.
If the case on the bottom of the device is replaced, the
laser-carved model name, serial number, and various
logos will not be displayed anymore.
For more information, contact a Samsung Service Center.
Bottom view
2
1
Getting started
14
3
The computer turns on automatically when the LCD panel is
opened.
If the computer does not turn on automatically, press the
Power button.
Set the device to not turn on the computer automatically
when the LCD panel is opened.
1. Select the Start button (
)
→
Samsung Settings
.
2. Select
System
→
Auto booting
→
Off
.
Turning the computer on and off
Fully charge the battery using the AC adapter before using
the computer
for the first time
.
Turning the computer on
1
Before turning on the computer, check that the battery is
charged and charge it if necessary.
2
Open the LCD panel.
Getting started
15
Turning the computer off
1
Select the Start button ( ).
2
Select
→
Shut down
.
Save all data before turning off the computer.
About Windows Activation
When you turn the computer on for the first time, the Windows
activation screen appears.
Follow the activation procedures according to the instructions on
the screen to use the computer.
The computer’s date and time may be incorrect when you turn it
on for the first time. They may also be incorrect if the battery has
been fully discharged or removed. To set the date and time, go to
the desktop taskbar and right-click the date and clock area. Then,
select
Adjust date/time
and set the current date and time.
Getting started
16
Windows
Microsoft Windows is an operating system that is used to control a
computer.
•
Images and available features may differ depending on
the model and operating system.
•
This manual is designed for Windows 10 and content
may differ depending on the OS version.
•
The image displayed on the desktop screen may differ
between models and OS versions.
Unlocking the screen
To unlock the lock screen, do one of the following:
•
Touch screen
: Swipe upwards from the bottom of the screen.
•
Mouse
: Click the lock screen.
•
Keyboard
: Press any key.
•
Touchpad
: Tap the touchpad.
If the account has a password, enter the password to log in after
unlocking the screen.
Getting started
17
Configuring the Windows Settings
You can configure the basic system settings, such as installing
or uninstalling apps and managing accounts, on the Windows
Settings screen.
Select the Start button (
)
→
.
Then, select an option you want to change after the Windows
Settings screen appears.
You can also configure the settings from the Control Panel
like previous OS versions. Select the Start button (
)
→
Windows System
→
Control Panel
.
Action Center
The Windows 10 action center allows you to receive system
notifications, such as updates, and push notifications, such as
emails and SNS updates. You can also adjust settings conveniently.
For example, you can select wireless network options or adjust the
volume and screen brightness via hot keys in the action center.
Checking notifications
1
Select on the taskbar.
2
When the action center panel appears, select a message to
check it.
•
You can enable or disable push notifications for
applications. You can also set personalized quick
actions to appear in the action center by selecting the
Start button (
)
→
→
System
→
Notifications &
actions
.
•
Select
Expand
or
Collapse
to expand or minimize the
action center menu and select the feature you want to
use.
18
When the LCD panel is tilted past the transition point
•
The keyboard and touchpad will automatically be
locked and will not function. But, during processes that
start before Windows operation, such as the BIOS setup
or DOS, the keyboard and touchpad will not be locked.
•
The display will rotate automatically depending on the
computer’s orientation.
When storing the computer in a bag or carrying it, close
the LCD panel to protect the computer.
Basics
Using the computer as a tablet
You can use the computer as a tablet by folding the LCD panel
behind the keyboard.
1
Open the LCD panel and rotate it away from the keyboard
until it touches the bottom side of the computer.
Basics
19
•
When you rotate the LCD panel back to the normal
position, a mode switch confirmation message will
appear. Select
Yes
to switch the computer’s display to
desktop mode.
•
When the screen is turned off while using the computer
as a tablet, touch the screen to unlock it. When the
computer is in sleep mode, press the Power button to
unlock the screen.
You can also switch the computer’s display to tablet mode without
rotating the LCD panel.
1
Select on the taskbar.
2
When the action center panel appears, select
Tablet mode
.
2
A mode switch confirmation message will appear when the
LCD panel is tilted past the transition point. Select
Yes
to
switch the computer’s display to tablet mode.
The display will switch to tablet mode.
Basics
20
Using the S Pen
S Pen
S Pen button
S Pen nib
Name Functions
S Pen nib
•
Use the S Pen to write, draw, or perform
touch actions on the screen.
Hover the S Pen over items on the
screen to access additional S Pen
features, such as the Air view feature.
S Pen button
•
Hover the S Pen over the screen and
press the S Pen button to display the
Air command features.
The FCC ID of the S Pen can be found below (USA only).
FCC ID: A3LEJPN970
Basics
23
Air command
Introduction
Air command is a menu that provides S Pen features quickly.
To open the Air command panel, hover the S Pen over the screen
and press the S Pen button.
Alternatively, select the Start button (
)
→
Air Command
.
View all notes
Create note
Smart select
Show Window
Air command
Screen write
Live Message
•
Create note
: Launch the Samsung Notes application
and create a new note. Refer to Samsung Notes for more
information.
•
View all notes
: Launch the Samsung Notes application and
check all saved notes.
•
Smart select
: Use the S Pen to select an area and perform
actions, such as sharing or saving. Refer to Smart select for
more information.
•
Screen write
: Capture screenshots to write or draw on
them or crop an area from the captured image. Also you can
capture content that continues across multiple screens at
once. Refer to Screen write for more information.
•
Live Message
: Instead of a text message, create a unique
message by recording your actions while handwriting or
drawing a live message and saving it as an animated file.
•
Show Window
: Select an area on the screen and show
it in full screen mode on an external display. Refer to Show
Window for more information.
Basics
24
3
Select an editing option and edit the selected area.
Eraser mode
Pen mode
Undo
Redo
Extract text from the selected area.
Crop the selected area.
Share the selected area.
Copy the selected area.
Save the selected area.
Smart select
Use the S Pen to select an area and perform actions, such as
sharing or saving. You can also select an area from a video and
capture it as a GIF animation.
1
When there is content you want to capture, open the Air
command panel and select
Smart select
.
2
Select a desired shape icon on the toolbar and drag the S Pen
across the content you want to select.
Basics
25
3
Select an option to use with the screenshot.
•
: Extract text from the screenshot.
•
: Crop a portion of the screenshot.
•
: Share the screenshot.
•
: Copy the screenshot.
•
: Save the screenshot.
It is not possible to capture a screenshot while using some
application or some features.
Show Window
Show Window allows you to select an area on the screen and
show it in full screen mode on an external display. You can draw or
highlight items on the screen using the S Pen.
Before using this feature, you must connect the computer to an
external display.
Showing a selected area on an external display device
1
Connect the computer to an external display device.
2
Open the Air command panel and select
Show Window
.
Screen write
Capture screenshots to write or draw on them or crop an area
from the captured image.
1
When there is content you want to capture, open the Air
command panel and select
Screen write
.
The current screen is automatically captured and the editing
toolbar appears.
2
Write a memo on the screenshot.
Basics
30
Inserting voice recordings into a note
On the note composer screen, tap
→
Voice recordings
to
make a voice recording. Tap
to stop recording. The voice
recording will be inserted into your note.
Deleting notes
1
Select the Start button ( )
→
Samsung Notes
.
You can also open the Air command panel and select the
View all notes
shortcut.
2
Right-click the note you want to delete on the note list.
To delete multiple notes, tick the notes you wish to delete.
3
Select .
Painting with brushes
On the note composer screen, select
Brush
to paint with various
brushes.
When you are finished, select
Done
to insert your painting into
the note.
Eraser
mode
Change
the brush
color.
Brush
settings
Redo
Undo
Insert the
painting
into the
note.
Select a new color using
the color picker.
Inserting images into a note
On the note composer screen, select
→
and select the
image you want. The image will be inserted into your note.
Basics
35
Changing the keyboard layout
To change the keyboard layout, select and select one of the
following:
•
: Simplified QWERTY keyboard
•
: Mini keyboard
•
: Split QWERTY keyboard for entering text with two hands
•
: Standard QWERTY keyboard
•
: Fixed keyboard
•
: Floating keyboard
Entering text
Use the on-screen keyboard to enter text.
To open the on-screen keyboard, select
on the taskbar.
•
Some languages are not supported by the virtual
keyboard. To enter text, change the input language to
one of the supported languages.
•
When using the computer for extended periods, it is
recommended to enter text with the physical keyboard.
•
The on-screen keyboard is only available in tablet
mode. To change to tablet mode, select
→
Tablet
mode
in the taskbar.
Basics
36
Number Description
•
Delete a preceding character.
•
Move to the next line.
•
Create an uppercase character. For all caps, tap
it twice.
•
Change the keyboard language.
•
Move the cursor.
•
Enter a space.
•
Enter emoticons.
•
Enter numerals and punctuation marks.
•
Change the keyboard layout.
•
Activate the dictation feature to convert
spoken words into text.
•
Add an item from the clipboard.
Entering uppercase
Select before entering a character. For all caps, tap it twice.
Changing language keyboards
Add keyboards to enter text in other languages. Select
→
→
under
Preferred languages
and select a language. Then,
select
and select a language.
Copying and pasting
1
Tap and drag your finger across text to select it.
2
Tap and hold the text to display the options.
3
Select
Copy
or
Cut
.
4
Tap and hold a text input field and then select
Paste
.
Basics
37
Using hot keys
To use keyboard hot keys, do one of the following:
•
Press and hold the
Fn
key and press a hot key.
Keyboard
Enter text or access computer functions with the keyboard.
•
Images and available features may differ depending on the model and operating system.
•
The keyboard layout may differ depending on the country. The hot keys will be mainly explained in this manual.
•
Press the
Fn Lock
key. When the
Fn Lock
key turns on, press a
hot key.
When the
Fn Lock
key is on, hot keys are activated without
pressing the
Fn
key.
Basics
39
Clicking
Tap the touchpad or press the left touchpad button.
or
Tap
Click
Double-clicking
Double-tap the touchpad or press the left touchpad button twice.
or
Tap-tap
Click-click
Touchpad
Use the touchpad to move the cursor or select an item. The left
and right buttons of the touchpad act the same as the left and
right buttons of a mouse.
•
Use the touchpad only with fingers. The touchpad will
not recognize actions of other objects.
•
Images and the touchpad layout may differ depending
on the model.
Basic touchpad functions
Moving
To move the cursor, move a finger on the touchpad.
Basics
40
Gesture functions
Swiping
To scroll up, down, left or right to a desired location, swipe with
two fingers on the touchpad.
or
Pinching
To zoom in, spread two fingers apart while viewing a website,
map, or image. Pinch to zoom out.
Right-clicking
This function enables right-clicking.
To right-click an item, press the right touchpad button.
Click
Dragging
To move an icon or an app tile to a desired location, press and hold
it and then drag it to the target position with the left touchpad
button pressed.
Press and hold
the left touchpad
button
Move
Basics
42
2
Select
Password
→
Add
to create a password.
3
Select
Windows Hello PIN
→
Add
to create a PIN number.
4
Select
Windows Hello Fingerprint
→
Set up
to start the
fingerprint registration.
5
Select
Get started
on the
Windows Hello setup
window.
6
Enter your PIN in the
Making sure it’s you
window.
7
Repeatedly lift and rest your finger on the fingerprint
recognition sensor until setup is complete.
The fingerprint recognition sensor’s location may vary
depending on the model.
Fingerprint recognition
You can sign in to Windows, apps, and services by teaching
Windows to recognize your fingerprint.
Registering your fingerprint
Create a password and PIN first to use the fingerprint scan feature.
1
Select the Start button ( )
→
→
Accounts
→
Sign-in
options
.
Basics
43
For better fingerprint recognition
•
Prevent the fingerprint recognition sensor from being
scratched or damaged by metal objects, such as coins, keys,
and necklaces.
•
Ensure that the fingerprint recognition sensor and your
fingers are clean and dry.
•
The fingerprint recognition sensor may not recognize
fingerprints that are affected by wrinkles or scars.
•
The fingerprint recognition sensor may not recognize
fingerprints from small or thin fingers.
•
If you bend your finger or use your fingertips, the fingerprint
recognition sensor may not recognize your fingerprints. Make
sure to cover the entire fingerprint recognition sensor with
your finger.
•
To improve recognition performance, register the fingerprints
of the hand you use most often to perform tasks.
•
In dry environments, static electricity can build up in the
computer. Avoid using this feature in dry environments
or before using the feature, discharge static electricity by
touching a metal object.
8
Fingerprint registration is complete.
If you want to add another fingerprint, select
Add another
.
Removing a fingerprint
1
Select the Start button ( )
→
→
Accounts
→
Sign-in
options
.
2
Select
Windows Hello Fingerprint
→
Remove
.
The fingerprint will be removed.
Unlocking the screen with a fingerprint
You can unlock the screen by resting your fingerprint on the
fingerprint recognition sensor.
Place a registered finger on the fingerprint recognition sensor.
The screen will be unlocked if the fingerprint is scanned correctly.
Basics
46
3
Select
Start
.
•
To use a memory card to exchange data with a digital
device, formatting the data with the digital device is
recommended.
•
When trying to use a formatted memory card in
another digital device, format the memory card again in
the device.
•
Data protected by copyright laws cannot be reviewed
or modified.
•
Inserting and removing a memory card repeatedly may
damage the memory card.
•
Secure Digital Input Output (SDIO) is not supported.
•
If the write-protect tab is in the locked position, you
cannot format, write, or delete data on the card.
Removing a memory card
1
Insert the ejection pin into the hole on the memory card tray
and gently remove the memory card tray from the memory
card tray slot.
2
Remove the memory card and reinsert the memory card tray.
Formatting a memory card
Before using the memory card for the first time, you should format
the memory card to remove unwanted data.
Format the memory card to remove all data or before using it for
the first time.
Formatting a memory card deletes all data saved on the
card. Make sure you have backed up any important data
before formatting.
1
On the taskbar, select File Explorer ( ).
2
Right-click the memory card drive, and then select
Format
.
Basics
47
Connecting to a display
1
Connect the cable to the USB-C
®
port or the Thunderbolt
™
3
port of the computer.
2
Connect the other end of the cable to the HDMI port of the
external display.
USB-C
®
port or
Thunderbolt
™
3 port
HDMI port
External display
Connecting the computer to an external display device can be
useful for presentations or when watching a movie. The cables
and adapters required to connect an external display are sold
separately. The computer supports USB-C
®
display cables.
USB-C
®
display cable
Check the available ports on the display device to ensure
that it is compatible with the computer.
Basics
48
You can select the dual view (extend) mode.
Select the Start button (
)
→
→
System
→
Display
,
and then select
Detect
on the
Multiple displays
option.
3
Connect the power cord to the external display.
4
Turn on the display and change its display mode to one that
supports an external input.
5
Press and hold the
Fn
key and press the
F4
key.
6
Select a mode.
PC screen only
Show the screen on the computer monitor only.
Duplicate
Show the screen on both the computer and the
external display.
Extend
Extend the screen to the external display.
Second screen only
Show the screen on the external display only.
Basics
50
Deactivating the Wi-Fi feature
When you are not using the Wi-Fi feature, turn it off to save battery
power.
1
Select on the taskbar.
2
Select
WiFi
.
The Wi-Fi feature is deactivated.
Airplane mode
This disables all wireless functions on your computer. You can use
only non-network services.
To activate
Airplane mode
, on the taskbar, select
→
Airplane
mode
.
2
Select a network from the list of detected wireless networks
and select
Connect automatically
→
Connect
.
3
Enter a password, if necessary, and select
Next
.
Once the computer has been connected to a wireless
network, it will attempt to connect to it automatically when
it is available. If you require a network password, contact the
system administrator.
Basics
52
Unpairing Bluetooth devices
1
Select the Start button ( )
→
→
Devices
.
Your computer will display the paired devices.
2
Select the device to unpair from your computer and select
Remove device
→
Yes
.
The connection to the Bluetooth device will be disconnected.
4
Select
Bluetooth
to select a device you want to add and finish
pairing.
Basics
54
Wireless PowerShare (WPS)
Wireless PowerShare is a feature that allows you to charge other
devices, such as a smartphones, using your computer’s battery.
Turn on the Wireless PowerShare feature and place the device
you want to charge onto the touchpad. The device will then be
charged.
•
When the computer is turned off, the Wireless
PowerShare feature will not work.
•
When the Wireless PowerShare feature is on, the
touchpad will not work.
•
Depending on the type of accessories or cover being
used, the Wireless PowerShare feature may not work
properly. It is recommended to remove any accessories
and cover being used before using this feature.
1
Press and hold the
Fn
key and press the
F11
key to activate
the Wireless PowerShare feature.
4
On the main computer’s Desktop, select the icon for the
connected computer to access the folder being shared.
If the computer does not properly scan your
Thunderbolt
™
3 device after connecting it
After removing a Thunderbolt
™
3 device, you can connect
a new Thunderbolt
™
device after a few seconds. Your
computer may fail to recognize a device connected
immediately after removing the previous device.
Basics
55
3
When you are finished charging, press and hold the
Fn
key
and press the
F11
key to deactivate the Wireless PowerShare
feature.
Alternatively, disconnect the other device from your
computer. After disconnecting the charged device from the
touchpad, the Wireless PowerShare feature will automatically
turn off after a minute.
Precautions for sharing power
•
Do not place the device on the touchpad with a credit
card or radio-frequency identification (RFID) card (such
as a transportation card or a key card) placed between
the touchpad and the other device.
•
Do not place the device on the touchpad when
conductive materials, such as metal objects and
magnets, are placed at the back of the device to be
charged. The device may not charge properly or may
overheat, or the device may be damaged.
2
Place the device you want to charge onto the touchpad with
the device’s back facing.
•
When charging starts, a notification sound or vibration
will occur.
•
The location of the wireless charging coil may vary by
device model. Adjust the devices to connect with each
other properly.
Smartphone Galaxy BudsGalaxy Watch
57
Applications
Using applications
•
Images and features may differ depending on the
model and the application version.
•
Some applications may not be supported depending
on the model.
•
Applications that are provided by Samsung can be
installed from
Samsung Update
.
•
Third-party software related services
For descriptions about and service requests for
third-party applications, please contact the relevant
manufacturer. Some troubleshooting actions in
response to service requests may not work depending
on the application manufacturer.
Applications
58
Menu Description
System
•
Set system settings.
Power management
•
Set power-related settings.
•
Set Wireless PowerShare (WPS)
mode.
Network
•
Set network functions and settings.
Display
•
Set the appropriate color for the user
environment.
•
Set the flicker free, video HDR+, and
outdoor+ mode.
Audio
•
Set sound settings.
Input
•
Set input functions and settings.
S Pen
•
Set S Pen features and settings.
Quick settings
•
Manage the quick settings displayed
on the taskbar.
About
•
View the application version.
Samsung Settings
Samsung Settings
, a Samsung-integrated settings application,
offers various settings functions.
Images and features may differ depending on the model
and the application version.
1
Select the Start button ( )
→
Samsung Settings
.
2
Select an option to configure the corresponding function.
Applications
59
2
Select
Privacy Folder
→
Create Windows password
.
Follow the on-screen instructions to create a password.
If you have already set a Windows password, this step will
not appear.
3
Select
Set folder settings
, and enter your password, then
select
OK
.
4
Select
Select Folder
and select a folder as the privacy folder.
When folder setup is complete, the folder will be changed to
hidden.
Showing the privacy folder
1
Press and hold the key and press the
F12
key.
Alternatively, select the Start button (
)
→
Samsung
Security
→
Privacy Folder
and select the
Hide
switch.
2
Enter the password and select
OK
.
3
Check the privacy folder in the File Explorer. You can save or
move files into the privacy folder.
Samsung Security
Create a privacy folder to hide private files on your computer
from other users. Also, you can set the various privacy protection
feature such as the secret screen feature or blocking recording
feature.
Features may differ depending on the model and the
application version.
Using the privacy folder
Set a folder as the privacy folder and hide private files in your
computer from other users. To set the privacy folder, you need a
password set up for Windows.
Setting the privacy folder
1
Select the Start button ( )
→
Samsung Security
.
Applications
61
3
Select
Update all
. Or, select
Install
or
Update
of the item to
be updated.
The items will be updated.
Samsung Update
Install and update Samsung applications and drivers on the
computer easily and conveniently. This application enables the
user to search for or download the BIOS, drivers, and applications
over the Internet. Keep the computer performing better and more
stably with
Samsung Update
.
•
To check for available updates, the computer must be
connected to the Internet.
•
Only applications that have been installed with this
application can be updated.
•
Images and features may differ depending on the
model and the application version.
1
Select the Start button ( )
→
Samsung Update
.
2
Read and agree to the User Agreement.
This step appears only when the application runs for the first
time.
Applications
63
Installing Samsung PC Help
1
On a smartphone, tap
Play Store
and search for
Samsung PC
Help
.
2
Install the application on your smartphone.
Using Samsung PC Help
1
On a smartphone, tap
Samsung PC Help
.
2
On the
Samsung PC Help
main screen, select a menu to
display the available content.
•
You may incur additional charges when you access
content.
•
When you register your computer in the
Settings
menu, you can view its information on the Samsung PC
Help app.
Samsung PC Help (Self-help
application)
Use
Samsung PC Help
to access help-related content for
Samsung computers from a smartphone.
Watch the
Samsung PC Help
videos to become familiar with new
functions or to find solutions to problems.
•
For more information, visit www.samsungpchelp.com.
•
Videos from Samsung PC Help are also available
on the Samsung Newsroom YouTube channel
(www.youtube.com/samsungnewsroom).
Applications
65
Quick Search
Search for content on the computer quickly.
1
Select the Start button ( )
→
Quick Search
.
Alternatively, press and hold the
Fn
key and press the
F12
key.
2
Tap to select the types of content you want to search.
3
Tap the search field to enter a keyword.
Content on your computer will be searched.
If you choose a search category, you can get more exact
results.
Settings & Upgrade
68
•
To mute or unmute the volume, press and hold the
Fn
key and
press the
F6
key.
Controlling volume using the taskbar
1
Select on the taskbar.
2
Drag the adjustment bar to the desired volume.
Volume adjustment bar
Volume
Adjust the system volume or sound volume when playing music
or video.
Controlling volume using the keyboard
•
To turn down the volume, press and hold the
Fn
key and press
the
F7
key.
•
To turn up the volume, press and hold the
Fn
key and press
the
F8
key.
Settings & Upgrade
69
Entering the BIOS screen
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
•
If the computer is password-protected, press the
F2
key
several times before the password screen appears.
•
If the password screen or the Windows start screen
appears, restart the computer and try again.
BIOS (Setup utility)
Define a boot password, change the boot priority, or configure the
installed chipsets.
•
Incorrect settings may cause the system to malfunction
or crash.
•
The BIOS setup screens, menus, and items may appear
differently depending on the model and BIOS version.
•
BIOS setup functions are subject to upgrades.
Settings & Upgrade
72
5
Enter a password and select
Ok
.
The password can be up to 20 characters.
6
Enter the password again to confirm it and select
Ok
.
7
Select
Save
→
Ok
to save and restart.
•
To enable the
Password On Boot
option, set a
Supervisor Password
and enter the password when
starting up the computer.
•
To change the
HDD Password
after setting it, restart
the computer.
•
For some models, if the password entered message
appears in the Setup Notice window, select
Ok
to
complete the setup.
Setting a boot password
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
3
Access the
Security
menu.
4
Select a password type (
Supervisor Password
,
User
Password
, or
HDD Password
).
If you cannot select an item or the
HDD Password Frozen
message appears, turn off the computer and turn it on again.
Then, press the
F2
key several times before the Samsung logo
appears to enter the BIOS setup screen.
Settings & Upgrade
73
Boot priority
Change the boot priority from the BIOS setup.
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
3
Access the
Boot
menu.
4
Select
Boot Device Priority
.
5
Select an option menu to open the list.
6
Select an option.
7
Select
Save
→
Ok
to save and restart.
Select
Exit
→
Ok
to restart without saving the changes.
Removing a password
1
Turn on the computer.
2
Before the Samsung logo appears, press the
F2
key several
times.
3
Access the
Security
menu.
4
Select a password type (
Supervisor Password
,
User
Password
, or
HDD Password
).
5
Enter the current password and select
Ok
.
6
Without entering any characters, select
Ok
→
Ok
.
7
Select
Save
→
Ok
to save and restart.
For some models, to cancel the password, select
Cancel
in
the Setup Notice window.
Settings & Upgrade
75
Charging the battery
1
Connect the AC adapter to the Thunderbolt
™
3 or the USB-C
®
port of the computer.
2
Plug the AC adapter into an electric socket.
Battery
Fully charge the battery using the AC adapter before using the
computer for the first time.
•
Use only Samsung-approved AC adapters, batteries,
and cables. Unapproved adapters or cables can cause
the battery to explode or damage the computer.
•
Incorrectly connecting the charger may cause serious
damage to the computer.
•
This computer is equipped with an internal battery.
The battery is not user-serviceable or user-replaceable.
•
To safely remove or replace the battery, take the device
to a Samsung Service Center. You will be charged for
this service.
•
You can use the computer while it is charging, but
the battery charging time may increase. If the battery
temperature rises too much, the charging may stop as a
safety measure.
To restore the battery power after cutting it, connect the
AC adapter.
Settings & Upgrade
77
When battery expiration is imminent
Batteries are consumable parts and the remaining battery life is
currently low. Continued use may result in charge or discharge
failures. Whether or not batteries can be used is determined
based on safety evaluations. Please replace it with a new battery
(genuine) to prevent data loss and ensure safe usage.
When the battery has expired
Batteries are consumable parts and the current battery cannot be
used as the battery life has expired. Please replace it with a new
battery (genuine) to prevent data loss and ensure safe usage.
Whether or not batteries can be used is determined based on
safety evaluations. To prevent data loss while replacing batteries,
please be sure to save your work first.
Instruction messages related to battery life are displayed
properly when the
Samsung Settings
application is
installed on your computer. The messages may vary
depending on the model and software version.
Saving battery power
On the taskbar, select
→
Battery saver
.
Battery saver
mode is activated.
Battery saver
mode is disabled when the AC adapter is
connected.
Battery usage time
Batteries are replaceable items and over time the battery’s
capacity to hold a charge and its power level is reduced. If a
battery can only hold its charge for half of the time that it could
when new, it is recommended to purchase a new, replacement
battery.
Checking battery life instruction messages
When the battery has expired, an instruction message may appear
on the screen. To prevent the computer from losing data and to
use the computer safely, follow the on-screen instructions.
Troubleshooting
79
2
Select
PC factory reset
→
Start factory reset
.
Follow the on-screen instructions to complete the recovery to
its initial status.
Recovering to factory default
You can restore the computer to its factory default settings. If
necessary, back up important data to an external storage device
before restoring the system. See Backing up data.
1
When the computer starts Windows
:
Select the Start button (
)
→
Samsung Recovery
.
When the computer does not start Windows
:
Turn on the computer and press the
F4
key several times
before the Samsung logo appears.
Troubleshooting
80
2
Select a drive to save the backed up data
→
Start backup
.
•
When backing up to an external storage device, connect
the device to the computer and then select the external
drive.
3
Follow the on-screen instructions to complete the backup.
Backing up user data
You can back up data files and folders.
1
Turn on the computer and press the
F4
key several times.
2
Select
Back up user data
.
3
Select the files or folders to back up and choose a storage
device to save the data to and then select
Start backup
.
•
The backed up folders or files can be saved only on an
external storage device. Connect an external storage
device to your computer first and then select the external
drive.
4
Follow the on-screen instructions to complete the backup.
Backing up data
Back up important data to an alternate internal drive or an
external storage device regularly to prevent data loss.
Backing up the current system
You can back up the factory default system or current system to an
alternate internal drive or an external storage device.
1
Select the Start button ( )
→
Samsung Recovery
→
Back
up computer
.
Troubleshooting
81
3
Select
Backup and restore management
.
4
Select
Restore
of the data you want to recover
→
Start
restore
.
5
Follow the on-screen instructions to complete data recovery.
Recovering after a backup
Select a backup point saved on an alternate internal drive or an
external storage device to recover the computer to that point.
1
When backing up to an external storage device, connect the
device to the computer.
2
Select the Start button ( )
→
Samsung Recovery
.
Troubleshooting
82
4
Select a disk to be copied
→
Start copy
.
The data on the disk is copied to the new disk.
Copying the drive (making a disk image)
To replace the drive, move the data to the new drive by making a
disk image. The new drive must be large enough to hold the data
from the current drive. Purchase an external hard drive connector
separately to connect the new drive to the computer.
When Windows is installed on a non-user replaceable disk,
such as an eMMC, you cannot copy the drive.
1
Connect the new drive to the computer with an external hard
drive connector.
2
Select the Start button ( )
→
Samsung Recovery
.
3
Select
Create a factory state disk
or
Create a disk copy
.
Troubleshooting
83
Q&A
When experiencing problems with the computer, try these
solutions.
Windows
How can I uninstall an application?
1
Select the Start button ( )
→
→
Apps
→
Apps &
features
.
2
On the list, select an app to delete, and then select
Uninstall
.
Windows recovery function
If the
Samsung Recovery
application is not supported by the
computer, reinstall Windows using the recovery function of
Windows.
Reinstalling Windows will erase all data saved on the
computer. Back up applications and personal data to an
external storage device before reinstalling Windows.
1
Select the Start button ( )
→
→
Update & Security
→
Recovery
.
2
Select
Reset this PC
→
Get started
.
3
Select
Keep my files
or
Remove everything
.
After the system is recovered, select the Start button
(
)
→
Samsung Update
to install the required Samsung
applications.
Troubleshooting
85
Miscellaneous
The camera and the microphone are not working.
How do I turn them on again?
When recording protect mode is activated, the camera and
microphone will not work.
Select the Start button (
)
→
Samsung Security
→
Block
Recording
and tap the switch to turn the features off.
The computer does not turn on automatically when
the LCD panel is opened.
To turn on the computer, the LCD panel should be opened greater
than a certain angle.
The angle may differ depending on the model.
If the computer LED does not turn on automatically, press the
Power button.
What is a recovery image?
This refers to the operating system, drivers, and software that are
converted to a data image. It is required to recover the computer
and is embedded in the computer’s HDD. However, this is not
provided for storage devices where the capacity is less than 64 GB.
How can I restore a computer that does not have the
Samsung Recovery application?
Restore the computer with the recovery function provided by
Windows. Refer to the Recover Functionality item in the help for
more details.
Appendix
89
Hearing and volume control
VOLUME
Check your volume!
•
Ensure that the volume is not too loud before using a headset
or earphones. Excessive exposure to loud sounds can cause
hearing damage.
•
Always turn the volume down before plugging the earphones
into an audio source and use only the minimum volume
setting necessary to hear your conversation or music.
•
Avoid using earphones for long periods of time.
•
Default audio settings can be changed by software and driver
updates without your knowledge. Always recheck equalizer
and volume settings before listening to audio.
•
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
Eye position and display illumination
50 cm
•
Position the screen at least 50 cm away from your eyes.
•
Adjust the height of the screen so that its top edge is equal to
or just below the level of your eyes.
•
Avoid setting the screen’s brightness settings excessively high.
•
Keep the screen clean.
•
If wearing glasses, clean them before using the computer.
•
When referring to printed content while typing, use a static
paper holder to hold the paper at about the same height as
the monitor.
Appendix
90
•
If anyone related to you has experienced seizures or blackouts
while using a similar product, consult a physician before using
the computer.
•
If you feel discomfort, such as a muscle spasm, or disoriented,
stop using the computer immediately and consult a physician.
•
To prevent eye strain, take frequent breaks while using the
computer.
Reduce the risk of repetitive motion injuries.
When you repetitively perform actions, such as pressing keys,
drawing characters on a touch screen with your fingers, or
playing games, you may experience occasional discomfort in your
hands, neck, shoulders, or other parts of your body. When using
your computer for extended periods, hold the computer with a
relaxed grip, press the keys lightly, and take frequent breaks. If you
continue to have discomfort during or after such use, stop using
the computer and consult a physician.
Operating conditions
•
Take at least a 10 minute break every hour.
•
Avoid using the computer in dark locations. Use the computer
with as much ambient light as you would when reading a
book.
•
Indirect illumination is recommended. Use a curtain to
prevent reflections and glare on the screen.
•
While operating a computer and talking on a phone, use a
headset. Using the computer while holding a phone on your
shoulder or with your neck may lead to muscle strain or injury.
•
Keep frequently used items within reach.
•
Only use the computer within the temperature and humidity
ranges specified in this manual.
Use caution when exposed to flashing lights.
•
While using your computer, leave some lights on in the room
and do not hold the screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed to
flashing lights while watching videos or playing Flash-based
games for extended periods. If you feel any discomfort, stop
using the computer immediately.
Appendix
91
Power related
Handle the power cord with care.
•
Do not touch with wet hands.
•
Do not use a damaged power cord.
•
Do not overload a multi-outlet or an extension cord beyond
the specified voltage/current capacity.
•
Firmly insert the power cable into the AC adapter.
•
Do not unplug the power cord by pulling on the cable.
•
Unplug the wall-mount AC adapter (integrated plug and
power adapter) from the wall outlet while holding the body
and pulling it in the direction of the arrow.
Failure to do so may result in electric shock or fire.
Connect the power cord to the AC adapter firmly.
An improper connection may result in a fire.
Use the approved adapter or cable included in the product box.
If you use the unapproved adapter or cable, it cause the damage
or malfunction of the computer.
Safety precautions
For your safety and security and to prevent damage, carefully read
the following safety instructions. This ’Safety precautions’ relate to
computer use. Some of the content may not be applicable to your
computer.
•
Since this is commonly applied to Samsung Computers,
some pictures may differ from actual products.
•
The product mentioned in this guide refers to all items
supplied with the computer including the battery,
the AC adapter, and all other Samsung-provided
accessories.
Warning
Failure to follow the instructions marked with this symbol may
result in physical injury or fatality.
NP UM Rev 4.2
Appendix
95
Usage related
Do not use the pen for unintended purposes, such as poking
the body like eyes or ears, and do not put it in your mouth.
Doing so may result in physical injury.
Do not place a candle, lit cigar, etc., over or on the product.
There is a danger of fire.
Make sure to have the product tested by a safety service
engineer after repairing the product.
Using a repaired product without testing it for safety may cause an
electric shock or fire.
In case of lightning, immediately turn the system off, then
disconnect the power cord from the wall outlet and phone line
from modem.
There is a danger of electric shock or fire.
Connect only permitted devices to the connectors or ports of
the computer.
Failure to do so may result in an electric shock or fire.
Do not place or use the computer on slanted or vibrating
surfaces.
Failure to do so may result in computer malfunction or damage.
Do not place heavy objects on the product.
This may cause a problem with the computer. In addition, the
object may fall and cause injury or damage the computer.
Properly shut down, disconnect and secure the computer cables
before moving it.
Failure to do so may damage the computer or cause someone to
trip over a loose cable.
Appendix
96
Do not store your device near or in heaters, microwaves, hot
cooking equipment, or high pressure containers.
•
The battery may leak.
•
Your device may overheat and cause a fire.
Do not use damaged or illegally modified CDs.
There is a danger of damaging the product or personal injury.
Do not insert your fingers into the ports (holes), card slot, or
vents.
There is a danger of injury or electric shock.
Use recommended computer cleansing solutions when
cleaning the product and only use the computer when it is
completely dry.
Failure to do so may result in electric shock or fire.
You should not use a paper clip to perform an emergency
disc ejection while the disc is in motion. Make sure to use the
emergency disc eject method only when the Optical Disc Drive
has stopped.
There is a danger of injury.
Close the LCD panel only after checking if the notebook
computer is turned off.
The temperature may rise and it may cause deformation of the
product.
Do not press the eject button while the CD-ROM drive is in
operation.
You might lose data and the disc might be suddenly ejected and
could cause an injury.
Do not drop or hit the computer against anything.
Failure to do so may result in physical injury or computer
malfunction.
When handling computer parts, follow the instructions on the
manual supplied with the parts.
Failure to do so may result in damage to the product.
If the product emits smoke or there is a burning smell,
disconnect the power plug from the wall outlet and contact a
Samsung Service Center immediately. For notebook computers
that are supplied with an optional removable battery,
disconnect the battery.
There is a danger of fire.
Appendix
97
Do not use your computer in a hospital or on an aircraft that can
be interfered with by radio frequency.
•
Avoid using your computer within a 15 cm range of a
pacemaker, if possible, as your computer can interfere with
the pacemaker.
•
To minimize possible interference with a pacemaker, use your
computer only on the side of your body that is opposite the
pacemaker.
•
If you use medical equipment, contact the equipment
manufacturer before using your computer to determine
whether or not the equipment will be affected by radio
frequencies emitted by the computer.
•
When in a hospital, turn off your computer and follow all
hospital regulations. Radio frequencies emitted from the
computer may affect medical equipment.
Do not place your face close to the Optical Disc Drive tray when
it is operating.
There is a danger of injury due to an abrupt ejection.
Do not use the product if it is cracked or broken.
Broken glass or acrylic could cause injury to your hands and face.
Take the device to a Samsung Service Center to have it repaired.
When using wireless communication (LAN, Bluetooth, etc.)
always follow applicable instructions. For example, airlines and
hospitals have strict requirements.
Avoid exposing a drive to magnetic fields. Security devices
with magnetic fields include airport walk-through devices and
security wands. The airport security devices that check carry-on
luggage use X-rays instead of magnetism and will not damage a
drive.
Keep the computer away from magnetic material.
•
Magnetic materials may cause computer malfunction or cause
the battery to discharge.
•
To avoid damaging the computer or magnetic stripe cards,
such as credit cards, keep magnetic stripe cards away from the
computer.
Appendix
101
Setting up the system
•
Read and follow all instructions marked on the product and
in the documentation before operating the system. Retain all
safety and operating instructions for future use.
•
Do not use this product near water or a heat source such as a
radiator.
•
Set up the system on a stable work surface.
•
The product should be operated only with the type of power
source indicated on the rating label.
•
Ensure that the electrical outlet to power the equipment is
easily accessible in case of fire or short circuit.
•
If the computer has a voltage selector switch, make sure that
the switch is in the proper position for your area.
•
Openings in the computer case are provided for ventilation.
Do not block or cover these openings. Make sure you provide
adequate space, at least 6 inches (15 cm), around the system
for ventilation when setting up your work area. Never insert
objects of any kind into the computer ventilation openings.
Important safety information
Safety instructions
The system is designed and tested to meet the latest standards for
safety of information technology equipment. However, to ensure
safe use of this product, it is important that the safety instructions
marked on the product and in the documentation are followed.
Always follow these instructions to help guard against
personal injury and damage to the system.
Appendix
102
Care during use
•
Do not walk on the power cord or allow anything to rest on it.
•
Do not spill anything on the computer or its components.
The best way to avoid spills is to not eat or drink near the
computer or its components.
•
Some products have a replaceable CMOS battery on the
system board. There is a danger of explosion if the CMOS
battery is replaced incorrectly. Replace the battery with the
same or equivalent type recommended by the manufacturer.
Dispose of batteries according to the manufacturers
instructions. If the CMOS battery requires replacement ensure
that a qualified technician performs the task.
•
When the computer is turned off, a small amount of electrical
current still flows through the computer.
To avoid electrical shock, always unplug all power cables,
remove the battery and modem cables from the wall outlets
before cleaning the system.
•
Ensure that the fan vents on the bottom of the casing are
clear at all times. Do not place the computer on a soft surface,
doing so will block the bottom vents.
•
When using an extension cord with this system, make sure
that the total power rating on the products plugged into the
extension cord does not exceed the extension cord power
rating.
•
For computers with glossy display bezels the user should
consider the placement of the computer as the bezel may
cause reflections from surrounding light and bright surfaces.
Appendix
104
Battery disposal
Do not put rechargeable batteries or products powered by
non-removable rechargeable batteries in the garbage.
Contact the Samsung Service Center for information on how to
dispose of batteries that you cannot use or recharge any longer.
Follow all local regulations when disposing of old batteries.
THERE IS RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Replacement parts and
accessories
Use only replacement parts and accessories recommended by
manufacturer.
To reduce the risk of fire, use only No. 26 AWG or larger
telecommunications line cord.
Do not use this product in areas classified as hazardous.
Such areas include patient care areas of medical and
dental facilities, oxygen rich environments, or industrial
areas.
Appendix
105
•
Laser Safety Note: Use of controls or adjustments or
performance of procedures other than those specified
in this manual may result in hazardous radiation
exposure. To prevent exposure to laser beams, do not
try to open the enclosure of a CD or DVD drive.
•
Class 1M laser radiation when operating part is open.
Do not view directly with optical instruments.
•
Class 3B invisible laser radiation when open.
Avoid exposure to the beam.
Connecting and disconnecting the AC
adapter
The socket-outlet shall be installed near the equipment and shall
be easily accessible.
Do not unplug the power cord by pulling the cable only.
Laser safety
All systems equipped with CD or DVD drives comply with the
appropriate safety standards, including IEC 60825-1. The laser
devices in these components are classified as “Class 1 Laser
Products” under a US Department of Health and Human Services
(DHHS) Radiation Performance Standard. Should the unit ever
need servicing, contact an authorized service location.
Appendix
109
Explosive Device Proximity Warning
Do not operate a portable transmitter (such as a wireless
network device) near unshielded blasting caps or in
an explosive environment unless the device has been
modified to be qualified for such use.
Use On Aircraft Caution
FCC, FAA, and TCCA regulations prohibit airborne
operation of radio-frequency wireless devices because
their signals could interfere with critical aircraft
instruments.
Other wireless devices
Safety notices for other devices in the wireless network:
Refer to the documentation supplied with wireless Ethernet
adapters or other devices in the wireless network.
United States of America and Canada
USA and Canada Safety Requirements and Notices
Do not touch or move antenna while the unit is transmitting or
receiving.
Do not hold any component containing the radio such that the
antenna is very close to touching any exposed parts of the body,
especially the face or eyes, while transmitting.
Do not operate the radio or attempt to transmit data unless the
antenna is connected; if not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is limited by the
constraints posed by the safety directors of such environments.
The use of wireless devices on airplanes is governed by the Federal
Aviation Administration (FAA) in the USA and Transport Canada
Civil Aviation (TCCA) in Canada.
The use of wireless devices in hospitals is restricted to the limits
set forth by each hospital.
Appendix
110
This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy. If not installed
and used in accordance with the instructions, it may
cause harmful interference. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and
receiver.
•
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV
technician for help.
The Part 15 radio device operates on a non-interference
basis with other devices operating at this frequency. Any
changes or modification to said product not expressly
approved by Intel could void the user’s authority to
operate this device.
Unintentional emitter per FCC Part 15
Responsible Party – U.S. Contact Information
Samsung Electronics America, Inc.
85 Challenger Road.
Ridgefield Park, NJ 07660
Phone: 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Appendix
111
Intentional emitter per FCC Part 15
(If fitted with 2.4 G band or 5 G band)
Low power, Radio LAN type devices (radio frequency (RF) wireless
communication devices), operating in the 2.4 GHz/5 GHz Band,
may be present (embedded) in the notebook system. This section
is only applicable if these devices are present. Refer to the system
label to verify the presence of wireless devices.
Wireless devices that may be in the system are only qualified for
use in the United States of America if an FCC ID number is on the
system label.
This device is restricted to indoor use due to its operation in the
5.15 to 5.25 GHz frequency range. FCC requires this product to be
used indoors for the frequency range 5.15 to 5.25 GHz to reduce
the potential for harmful interference to co-channel Mobile
Satellite systems. High power radars are allocated as primary users
of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar
stations can cause interference with and/or damage this device.
If necessary, the user should consult the dealer or an experienced
radio/television technician for additional suggestions. The user
may find the following booklet helpful: “Something About
Interference.”
This is available at FCC local regional offices. Our company is not
responsible for any radio or television interference caused by
unauthorized modifications of this equipment or the substitution
or attachment of connecting cables and equipment other than
those specified by our company. The correction will be the
responsibility of the user. Use only shielded data cables with this
system.
Appendix
115
Innovation, Sciences et Développement
économique Canada
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de brouillage.
2. L’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Avertissement:
Les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont
réservés uniquement pour une utilisation à l’intérieur a n de
réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux.
Canada
Innovation, Science and Economic Development
Statement:
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference
that may cause undesired operation of the device.
Industry Canada Caution
The device for operation in the band 5150-5250 MHz is only for
indoor use to reduce the potential for harmful interference to co-
channel mobile satellite systems.
Appendix
116
Household users should contact either the retailer where
they purchased this product, or their local government office,
for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product and its
electronic accessories should not be mixed with other commercial
wastes for disposal.
For information on Samsung’s environmental commitments and
product regulatory obligations, e.g. REACH, WEEE or Batteries, visit
our sustainability page available via www.samsung.com.
India only
For more information on safe disposal and recycling visit our
website www.samsung.com/in or contact our Helpline numbers -
18002668282, 180030008282.
This product is RoHS compliant.
WEEE symbol information
Correct disposal of this product (Waste Electrical &
Electronic Equipment)
(Applicable in countries with separate collection
systems)
This marking on the product, accessories or literature indicates
that the product and its electronic accessories (for example,
charger, headset, USB cable) should not be disposed of with other
household waste at the end of their working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources.
Appendix
117
Removing the battery (Europe only)
•
To remove the battery, contact an authorised service
centre. To obtain battery removal instructions, please visit
www.samsung.com/global/ecodesign_energy
.
•
For your safety, you must not attempt to remove the battery.
If the battery is not properly removed, it may lead to damage
to the battery and device, cause personal injury, and/or result
in the device being unsafe.
•
Samsung does not accept liability for any damage or loss
(whether in contract or tort, including negligence) which
may arise from failure to precisely follow these warnings and
instructions, other than death or personal injury caused by
Samsung’s negligence.
Correct disposal of batteries in this product
(Applicable in countries with separate collection
systems)
This marking on the battery, manual or packaging indicates that
the batteries in this product should not be disposed of with other
household waste at the end of their working life. Where marked,
the chemical symbols Hg, Cd or Pb indicate that the battery
contains mercury, cadmium or lead above the reference levels
in EC Directive 2006/66. If batteries are not properly disposed
of, these substances can cause harm to human health or the
environment.
To protect natural resources and to promote material re-use,
please separate batteries from other types of waste and recycle
them through your local, free battery return system.
PO BOX 12987, DUBLIN, IE
