The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd., reserves the right,
however, to discontinue or change specifications or design at any time without notice and without incurring any obligation.
Accessories Precautions
The GPS antenna is located in the dashboard. Metallic front or side window tinting can seriously degrade or obstruct GPS reception.
Signal noise from devices such as radar detectors, vehicle tracking devices, remote starters, and additional amplifiers can disrupt the navigation system. If you
install any such item, install it away from the navigation display and antenna.
Important Safety Information
Avoid focusing on the screen or manually operating the system controls while driving.
Certain on-screen controls are disabled when driving, but most of the audible instructions and voice commands continue to function. Pull to the side of the road
if you need to devote more attention and time to look at the screen or access additional menus.
Route guidance may conflict with street closures, road construction, detours, and out-of-date map data.
The system itself may also have limitations. Verify route information by carefully observing roads, signs, and signals. Always use your own judgment and obey
traffic laws.
2
System Limitations P. 184
NOTICE
This vehicle’s navigation display, if so equipped, includes mercury-containing components. Upon removal, please reuse, recycle, or dispose of as hazardous waste.
Clean the screen with a soft, damp cloth. You may use a mild cleaner intended for use on navigation screens.
Using the navigation system while driving can take your
attention away from the road, causing a crash in which you
could be seriously injured or killed.
Only operate system controls when the conditions permit you
to safely do so.
WARNING
CR‑ZKA‑31SZT820.book0ページ２０１２年１０月９日 火曜日 午前８時１７分
Contents
2 System Setup P. 17
Start-up 18 Voice Control System 19 Interface Settings 21 Personal Information 29
Routing & Guidance 39 Clock Adjustment 46 Vehicle 49 Data Reset 52
2 Navigation P. 55
Entering a Destination 56 Calculating the Route 77 Driving to Your Destination 80 Map Menu 85
Changing Your Route 101 Changing Your Destination 108 Resuming Your Trip 112
2 Audio P. 113
Audio System 114 Playing FM/AM Radio 116 Playing a Disc 121 Playing an iPod® 125
Playing Pandora® 129 Playing a USB Flash Drive 132 Playing Bluetooth®
Audio 136
Adjusting the Sound 139
Audio Remote Controls 140
2 Bluetooth® HandsFreeLink® P. 143
Bluetooth®
HandsFreeLink® 144
Pairing a Phone 146 Setting Up Speed Dialing 151 Editing Phone
Information 154
Phone Setup 155 Making a Call 156 Receiving a Call 159 HFL Menus 160
Text Messages 163
2 Other Features P. 165
Trip Computer 166 Information Functions 167 Multi-View Rear Camera 168
2 Troubleshooting P. 169
Troubleshooting 170 Error Messages 177
2 Reference Information P. 181
System Initialization 182 System Limitations 184 Customer Assistance 186 Legal Information 189
2 Voice Commands P. 193
Voice Commands 194
Quick Reference Guide
P.2
System Setup
P.17
Navigation
P.55
Audio
P.113
Bluetooth
® HandsFreeLink®
P.143
Other Features
P.165
Troubleshooting
P.169
Reference Information
P.181
Voice Commands
P.193
Index
P.204
CR‑ZKA‑31SZT820.book1ページ２０１２年１０月９日 火曜日 午前８時１７分
Quick Reference Guide
2
Overview—Functions at a Glance
Navigation
You can select any place/landmark as a destination by using voice control or the touch screen. The navigation
system gives you turn-by-turn driving directions to your destination.
Store home addresses (P35)
Register
2 home addresses.
Store contacts (P30)
Store up to
200 contacts in 2 address books.
Enter destination (P56)
Select your destination using
11 methods.
Select route (P78)
Set route preferences and select one of
3 routes.
Track route (P80)
Follow your route in real-time with voice guidance.
FM Traffic (P99)
View and avoid congestion and traffic incidents.
Avoid certain areas (P102)
Set streets and areas to detour around.
Add waypoints (P103)
Add up to
4 “pit stops” along your route.
CR-Z_KA-31SZT820.book 2 ページ ２０１２年８月１５日 水曜日 午前９時２９分
3
Quick Reference Guide
Other Features
Multi-View Rear Camera (P168)
Helps you check for obstacles around the rear of your vehicle on the navigation screen when reversing.
Audio
The advanced audio system provides clear, well-defined sound and makes the most of your music.
Enjoy listening to a variety of audio sources, such as:
AM/FM Radio (P116)
Compact Disc (P121)
Pandora
®
(P129)
USB Flash Drive (P132)
Bluetooth
®
Audio (P136)iPod
®
(P125)
Voice Control (P19)
Use voice commands to control the system while driving. You can operate all key functions of
the navigation, audio, and climate control systems.
Bluetooth
®
HandsFreeLink
®
(P144)
Pair a compatible cell phone to receive incoming and make outgoing calls. You can operate the
phone features without ever taking your hands off the wheel.
Text Messages (P163)
Receive text messages on the navigation screen from a compatible device and hear them read
aloud. Reply to them using preloaded messages.
CR-Z_KA-31SZT820.book 3 ページ ２０１２年８月１５日 水曜日 午前９時２９分
4
Quick Reference Guide
System Controls
3 CD/AUX Button (P121)
1 E (Eject) Button
2 FM/AM Button
(P116)
Navigation Screen
(Touch Screen)
Audio
Navigation
Voice Control/
Bluetooth® HandsFreeLink®
6 Disc Slot (P6)
4 AUDIO Button (P6)
5 SEEK/SKIP Button (P116)
7 a (Display Mode)
Button
(P26)
lb DEST Button (P56)
9 PHONE Button (P144)
la MAP/GUIDE Button (P90)
le CANCEL Button
lc INFO Button
(P10)
ld ZOOM IN/OUT Button (P95)
lf Joystick/ENT Button
8 VOL 9 Knob
(P6)
Press ENTER
Selects map location
or list item.
Move up Move Left Move down Move right
Scrolls map or list.
CR-Z_KA-31SZT820.book 4 ページ ２０１２年８月１５日 水曜日 午前９時２９分
5
Quick Reference Guide
lg Microphone
(P19)
lh MODE Button (P140)
lj NB (Channel) Button
(P141)
mc d (Talk) Button (P5)
mb j (Hang-Up) Button (P159)
ma h (Pick-Up) Button (P159)
li RU (Volume) Button
(P141)
md K (Back) Button (P5)
Voice Control Operation
z The audio system is muted during voice control mode.
z Say “Help” to see all supported commands. A voice help
tutorial is also available.
Voice Help (P13)
z Carefully read the usage note for the voice control.
Voice Control System (P19)
a Press and release the d (Talk) button.
z The icon is displayed and the system beeps when ready for a
command. Press the K (Back) button to cancel.
z Available voice commands are highlighted on the screen.
b Say a voice command.
Voice Command (P193)
d (Talk) Button
A helpful prompt asks what you
would like to do. Press and release
the d (Talk) button again to bypass
this prompt.
CR-Z_KA-31SZT820.book 5 ページ ２０１２年８月１５日 水曜日 午前９時２９分
6
Quick Reference Guide
Audio System
You can play music from a wide array of media sources. You can also control the audio system using voice commands.
Basic Operation
a Press the VOL 9 (Volume/Power) button to turn the audio
system on or off.
b Press the AUDIO button and select SOURCE on the screen.
c Select the audio source.
Or, press the FM/AM button or CD/AUX button repeatedly to
select the audio source.
d Rotate the VOL 9 (Volume/Power) knob to adjust
the volume.
Audio source
Audio Control Display
Press the AUDIO button to display the audio system on the
navigation screen.
Track list
Open icon
Audio source
Displays selected source.
Music
information
Close icon
Sound
preferences
Folder/Track tab
Displays the list.
Repeat and random play
Play mode
Displays or hides the
music information.
Audio control
CR-Z_KA-31SZT820.book 6 ページ ２０１２年８月１５日 水曜日 午前９時２９分
7
Quick Reference Guide
Map Screen Legend
Map orientation (P97)
GPS signal strength
North up
Heading up
Best reception
Good reception
No icon: Poor/No reception
Traffic status indicator (P99)
Traffic information available
Flow or incident data not available
Traffic information not available
Traffic information off or map
scale too large
Current map scale
Current street name/audio control
(Select to switch the display.)
Map menu (P85)
Map scale (P95)
Current vehicle position
(P98)
Feature areas
Streets
Landmark icons (P92)
Park
Hospital
Shopping Mall
Golf Course
Airport
Water Area
Cemetery
University
Freeways
State routes
Verified streets
Unverified streets
One-way streets
Acura dealer
Honda dealer
ATM
School
Parking lot
Parking garage
Grocery store
Hotel/Lodging
Gas station
Hospital
Post office
Restaurant
Freeway exit information
Traffic flow indicator (P99)
Heavy (approx.)
surface: 0 to 20 mph
freeway: 0 to 25 mph
Moderate (approx.)
surface: 21 to 30 mph
freeway: 25 to 52 mph
Congestion
Accident/Incident
Weather
Construction
Road Closed
Traffic incident icons (P99)
CR-Z_KA-31SZT820.book 7 ページ ２０１２年８月１５日 水曜日 午前９時２９分
8
Quick Reference Guide
During Route Guidance
During route guidance, route information is displayed on the map/guidance screen.
Press the MAP/GUIDE button to display the guidance screen (factory default).
Map Screen
Guidance Screen
Calculated route
(P80)
Destination direction
indicator
Direction “as the crow
flies.”
Guidance indicator
Distance to the next
guidance point.
Distance to destination
Distance of the actual
route.
Estimated time to
destination
Waypoint (P103)
Destination icon
(P79)
Calculated route
(unverified roads)
(P82)
Street name of
guidance point
Route guidance list scroll bar
Select R or U to scroll the list of
guidance points.
Route progress bar
Distance to
guidance point
No entry icon
Day or Night Mode
Press the a (Display mode) button
to manually switch between day and
night mode.
Night modeDay mode
CR-Z_KA-31SZT820.book 8 ページ ２０１２年８月１５日 水曜日 午前９時２９分
9
Quick Reference Guide
How to Enter Information
You can enter information (e.g., city names, street names, personal names, and business names comprising letters, numbers, and symbols)
when prompted on input screens by two different methods.
Using Voice Control
When you see d in this manual, voice commands are available for
that feature.
z Say the letter, number, or symbol (e.g., say d “A”).
z Use spelling assist (e.g., say d “Alpha” to enter the letter “A” or
d “Hyphen” to enter a hyphen).
z The system beeps if you say an unavailable (grayed out) letter or
number.
z If a voice command is not recognized, a list is displayed with
possible options.
On list screens:
z Say the number of the list item (e.g., say d “Five” to select item
5).
z Say d “Up” or d “Previous” to scroll up one page.
z Say d “Down” or d “Next” to scroll down one page.
Using the Touch Screen
Touch a character or icon on the screen to select it.
z Select Delete to remove the last entered character.
z Select Shift to display accented and upper/lower case characters.
z Select Space to enter a space character.
z Select More to display symbols.
You can also use the joystick to enter information.
2 System Controls P. 4
On list screens:
Scrolling through lists or tabs is limited while the vehicle is moving.
Certain touch screen functions are limited or inoperable while the
vehicle is moving. For these functions, use available voice
commands or pull over to proceed.
Number of Hits
On input search screens, the number of hits in the map database is
displayed. Select List to display a list of possible entries.
NOTE
CR-Z_KA-31SZT820.book 9 ページ ２０１２年８月１５日 水曜日 午前９時２９分
10
Quick Reference Guide
Navigation—Home Addresses and Going Home
The “Home” feature automatically routes you to your home address from any location simply by selecting Go Home 1 or 2, or saying d “Go
Home.” You can store two home addresses as Home Address 1 and Home Address 2. (P35)
Storing Your Home Address
a Press the INFO button.
b Select Setup.
c Select Personal Information.
d Select Home Address 1.
e Select Edit Name.
f Enter a name and select OK.
g Select Edit Address.
h Select Address.
i Enter an address.
j Select Edit Phone No.
k Enter a phone number and select OK.
l Select OK.
Going Home
a Press the DEST button.
b Select Go Home 1.
Alternatively, you can say d “Go
Home” from any screen. Your home
address is displayed on the Calculate
Route screen.
c Select Set as Dest.
z The following voice commands are
available: say d “Go Home,” d “Go
Home 1,” d “Go Home 2.”
z If you have two home addresses stored,
saying d “Go Home” will select Home
Address 1.
CR-Z_KA-31SZT820.book 10 ページ ２０１２年８月１５日 水曜日 午前９時２９分
11
Quick Reference Guide
Navigation—Entering a Destination
Enter your destination using one of several methods, then follow route guidance on the map or guidance screen to your destination. You
can also perform these steps using d voice control.
a Press the DEST button.
b Select Address.
c Select Street.
d Enter the name of your destination
street and select List if necessary.
e Select your destination street from
the list.
f Enter the street number. Select OK
when finished.
g If there is more than one city with the
specified street, a list of cities is
displayed. Select the desired city from
the list.
h Select Set as Dest.
Route guidance to the destination
begins.
z View Routes: Choose one of three
routes.
z Route Pref.: Choose MAX or MIN for
the three settings.
CR-Z_KA-31SZT820.book 11 ページ ２０１２年８月１５日 水曜日 午前９時２９分
12
Quick Reference Guide
Navigation—Changing Route or Destination
You can alter your route by adding waypoints to visit, adding streets to avoid, or changing your destination during route guidance.
Adding a Waypoint
(“Pit Stop”)
You can add up to four waypoints along
your route. (P103)
a Press the DEST button.
b Select Waypoint.
c Select search method.
When you select Places Around the
Waypoint, select the desired waypoint.
d Select the icon category and location
to add to the destination list when
prompted.
Changing Your
Destination
There are four methods you can use to
specify a new destination during route
guidance.
z Say d “Find Nearest…” (P108)
Searches for the nearest place/landmark
on the map screen (e.g., d “Find
nearest gas station”).
z Say d “Go Home” (P10)
Routes to your home address.
z Selecting an icon on the map (P109)
Scroll the map to position the cursor over
a place/landmark icon or a new area on
the map. Press the Enter button twice.
z Entering a new destination (P110)
Press the DEST button. Select DEST
Menu1/2 and enter a new destination.
Canceling Your Route
From the map screen:
a Press the DEST button.
b Select Cancel Route.
a Select MAP MENU.
b Select Cancel Route.
CR-Z_KA-31SZT820.book 12 ページ ２０１２年８月１５日 水曜日 午前９時２９分
13
Quick Reference Guide
Voice Help
This navigation system comes with voice help information, which tells you how to use the voice command functions.
Go to Voice Info for tips when using the voice command functions.
Getting Started Tutorial
a Press the INFO button.
b Select Voice Info.
c Select Getting started.
You can also view the available
command list for each system. See
Command Help on this page.
d Select Using the talk button.
e Select Read to hear the tutorial read
aloud.
Select Stop to stop the tutorial.
Command Help
For “Command Help” menu items, all voice
commands that are available for that
system are listed.
Select Read to hear the commands in the
list read aloud.
Voice Commands (P193)
CR-Z_KA-31SZT820.book 13 ページ ２０１２年８月１５日 水曜日 午前９時２９分
14
Quick Reference Guide
Troubleshooting For more Information (P169)
Why does the vehicle position icon on the map “lag” a
short distance behind my actual position, especially at
intersections?
This is normal. The navigation system is unaware of the
width of intersections. Large differences in vehicle position
can indicate a temporary loss of the GPS signal.
Why does the “time to destination” display sometimes
increase even though I am getting closer to my
destination?
The “time to destination” is based on the posted road
speed signs and your actual road speed to give you a
better estimate of arrival time.
Why does my clock frequently change the time forward
and backward by one hour?
The clock setting is automatically updated based on your
GPS location. If you normally drive between two time
zones, the clock may keep adjusting the time. You can
turn this feature off.
2
Clock Adjustment P. 46
How do I specify a destination when an entered city or
street could not be found?
Try entering the street first. Some cities are lumped in with
a major metro area. In rural “unverified” areas or new
subdivisions, streets may be missing or only partially
numbered.
How do I turn on the navigation system voice guidance?
1. Press the INFO button. Select Setup. Check that
Volume is not set to Off.
2. Select Other, then Basic Settings. Set Voice
Recognition Tutor to On if you want the system to
provide confirmations and system prompts.
My battery was disconnected or went dead, and the
navigation system is asking for a code. Where do I find it?
Your vehicle comes with a label in the Owner’s Manual kit
that includes the system’s security code and serial number.
You should keep this label in a safe place outside your
vehicle. If you cannot find it, contact your dealer.
CR-Z_KA-31SZT820.book 14 ページ ２０１２年８月１５日 水曜日 午前９時２９分
15
How to Use This Manual
This section explains different methods on how you can easily find information in this manual.
Contents
Contents
More Detailed
Contents
Go to the
Next Page
Searching the Table of Contents
(P1)
Two types of Tables of Contents help
you find your desired information.
First, find the general chapter related to
what you are looking for (e.g., entering
a destination from the Address Book).
Then, go to that chapter to view a more
specific table of contents.
Searching the Index (P204)
Menu items displayed on the
navigation screen (e.g., Address Book)
can be found individually in the Index.
This more detailed table of contents
shows you exactly what information is
listed by section and title.
The Index consists of
main terms and sub-
entries. The sub-entries
help you get to the
desired page depending
on what you are looking
for.
Table of Contents Chapter Contents
Navigation Screen
Index
CR‑ZKA‑31SZT820.book15ページ２０１２年１０月９日 火曜日 午前８時１７分
16
DEST button
Menu Tree
The menu tree helps guide you
through the system’s menu options.
To get to your desired function, follow
the menu tree in order of the steps
shown.
NOTE:
All menu options can also be
activated with voice commands.
Press the hard button on the
system control panel.
Press the DEST button.
Select the menu option.
Select Address Book.
After following the menu
tree, step-by-step
instructions explain how to
achieve the desired result.
* Sample pages and images in this section may differ from the actual ones.
CR‑ZKA‑31SZT820.book16ページ２０１２年１０月９日 火曜日 午前８時１７分
17
System Setup
This section describes the start-up procedure and the navigation and
setup functions.
Start-up ................................................... 18
Voice Control System ............................. 19
Command Input .................................... 19
Voice Recognition .................................. 20
Interface Settings ................................... 21
Display and Volume Settings .................. 21
Guidance Prompts.................................. 22
Basic Settings......................................... 23
Color ..................................................... 24
Language............................................... 28
Personal Information.............................. 29
Address Book......................................... 30
Home Addresses .................................... 35
PIN Numbers.......................................... 36
User Name..............................................37
Previous Destinations ..............................38
Routing & Guidance ................................39
Rerouting................................................40
Unverified Area Routing..........................41
Edit Avoid Area.......................................43
Edit Waypoint Search Area......................45
Clock Adjustment ....................................46
Adjust Time ............................................47
Resetting the Clock Settings....................47
Setting the Clock Type ............................48
Vehicle ......................................................49
Off-road Tracking ...................................50
Correct Vehicle Position ..........................51
Data Reset ............................................... 52
Reset Factory Default Settings ................ 52
Clear All Speed Dial................................ 53
CR‑ZKA‑31SZT820.book17ページ２０１２年１０月９日 火曜日 午前８時１７分
18
System Setup
Start-up
The navigation system starts automatically when you turn the ignition to
ACCESSORY (I) or ON (II). At start-up, the following Confirmation screen is displayed.
Select OK.
Your current position is
displayed on the map screen.
If you do not select OK, the map
screen is displayed after a
certain period of time.
Certain manual functions are disabled
or inoperable while the vehicle is in
motion. You cannot select a grayed-
out option until the vehicle is stopped.
Voice commands are still operable
while the vehicle is in motion.
1 Start-up
If the navigation system loses power at any time,
you may need to press and hold the VOL 9
(Volume/Power) button for more than two
seconds, or you may be prompted for the 5-digit
security code.
2 System Initialization P. 182
“OK” on the Confirmation screen cannot be
selected by using a voice command.
■ Limitations for Manual Operation
Disabled Option
CR‑ZKA‑31SZT820.book18ページ２０１２年１０月９日 火曜日 午前８時１７分
19
System Setup
Voice Control System
Your vehicle has a voice control system that allows hands-free operation of most of
the navigation system functions. You can also control the audio and climate control
system, and make and receive phone calls using Bluetooth® HandsFreeLink®.
The voice control system uses the d (Talk) and K (Back) buttons on the steering
wheel and a microphone near the map lights on the ceiling.
A “Voice Info” feature provides a tutorial that explains how to use the voice control
system.
2 Voice Help P. 13
Command Input
If the system does not understand a command or you wait too long to give a
command, it responds with “Pardon? No command was heard. Please press the talk
button and say a command.”
When you give a command, the system generally either repeats the command as a
confirmation or asks you for further information. If you do not wish to hear this
feedback, you can turn it off. However, listening to the feedback will help familiarize
you with the way the system expects commands to be phrased.
2 Basic Settings P. 23
If the system cannot perform a command or the command is not appropriate for the
screen you are on, the system beeps.
If the system responds with prompts such as “Please use the touch screen to…” or
“Please use the joystick to…,” the system is asking for input that cannot be
performed using the voice control system.
On character input screens, a list of possible characters is displayed if the system
does not recognize your command.
You can find out which voice commands are available for a particular screen using
the d Help command. The system will display and read the list of available
commands to you.
1 d (Talk) Button
When you press the d (Talk) button, a helpful
prompt asks what you would like to do. Press
and release the d (Talk) button again to bypass
this prompt and give a command.
1 Command Input
The audio system is muted while using the voice
control system.
CR‑ZKA‑31SZT820.book19ページ２０１２年１０月９日 火曜日 午前８時１７分
20
Voice Control System
Voice Recognition
System Setup
Voice Recognition
To achieve optimum voice recognition when using either the navigation voice
control system or Bluetooth® HandsFreeLink®:
• Make sure the correct screen is displayed for the voice command that you are
using.
2 Voice Commands P. 194
• Close the windows and moonroof.
• Adjust the dashboard and side vents so air does not blow onto the microphone on
the ceiling.
• Speak clearly in a clear, natural speaking voice without pausing between words.
• Reduce any background noise if possible. The system may misinterpret your
command if more than one person is speaking at the same time.
• Refer to the Voice Info tutorial.
2 Voice Help P. 13
1 Voice Recognition
The voice control system can only be used from
the driver’s seat because the microphone unit
removes noises from the front passenger’s side.
CR‑ZKA‑31SZT820.book20ページ２０１２年１０月９日 火曜日 午前８時１７分
21
System Setup
Interface Settings
Display and Volume Settings
H INFO button
Setup
Use the Main Setup screen to adjust the display and volume.
Select b or n to adjust the desired
item.
The following items are available:
• Brightness: Adjusts the screen’s brightness.
• Contrast: Adjusts the screen’s contrast.
• Black Level: Adjusts the screen’s black level.
• Volume: Adjusts the navigation system volume level.
1 Display and Volume Settings
You can set separate daytime and nighttime
settings for Brightness, Contrast, and Black
Level. Adjust each setting when the display is in
either daytime or nighttime mode.
You can set the display and volume settings
using voice commands.
2 Main Setup Screen Commands P. 199
Volume
If you set Volume to Off, you will not hear route
guidance or voice command confirmations. If
you then select Voice on the map menu, you will
hear route guidance at the default volume.
CR‑ZKA‑31SZT820.book21ページ２０１２年１０月９日 火曜日 午前８時１７分
24
Interface Settings
Color
System Setup
• Verbal Reminder: Turns the verbal reminders on or off.
On (factory default): Provides warning voice messages when:
– Driving with the parking brake on
– Driving without wearing the driver and/or passenger seat belt
Off: Disables the feature.
Color
H INFO button
Setup
Other
Color
Choose the color of the navigation map and system menus.
Select an item.
The following items are available:
• Map: Sets the color of the map screen.
2 Map Color P. 25
• Menu: Sets the color of the menu screens.
2 Menu Color P. 25
CR‑ZKA‑31SZT820.book24ページ２０１２年１０月９日 火曜日 午前８時１７分
25
Interface Settings
Color
System Setup
H INFO button
Setup
Other
Color
Map
Set separate map colors for Day and Night modes.
Select a color for the map screen.
H INFO button
Setup
Other
Color
Menu
Set separate menu colors for Day and Night modes.
Select a color for the menu screens.
■ Map Color
1 Map Color
For Day mode
Set to White (factory default is Beige) to obtain
the best daytime display contrast.
For Night mode
Set to Black (factory default) to obtain the best
nighttime display contrast.
■ Menu Color
1 Menu Color
For Day mode
Set to Black (factory default is Blue) to obtain
the best daytime display contrast.
For Night mode
Set to Black (factory default is Blue) to obtain
the best nighttime display contrast.
CR‑ZKA‑31SZT820.book25ページ２０１２年１０月９日 火曜日 午前８時１７分
26
Interface Settings
Color
System Setup
Set the screen brightness separately for Day and Night modes. Press the
a
(Display mode) button to cycle through the display modes (Day to Night to Off).
1. Press the a button.
The Brightness bar is displayed
for a few seconds.
2. Press the a button again.
Repeat the procedure to switch
the display modes.
Select b or n to adjust the
brightness.
■ Switching Display Mode Manually
1 Switching Display Mode Manually
A visual guide helps you see the difference
between Day and Night modes.
2 Day or Night Mode P. 8
Recommended Settings
• Select mid-range for the dash illumination.
• Select White for the map Day display and
Black for the map Night display.
CR‑ZKA‑31SZT820.book26ページ２０１２年１０月９日 火曜日 午前８時１７分
27
Interface Settings
Color
System Setup
Illumination
control
Priority Operation
a button 1 Selects Day, Night, or Off display mode. This button has
the highest priority and overrides all other display control
adjustments listed below.
Sunlight sensor
(see your
Owner’s Manual
for location)
2 If the sunlight sensor detects daylight and the headlights
are turned on, the system automatically overrides the
Night display and displays the Day display mode.
Remember: If desired, use the a button to override
this automatic choice.
Dash illumination
adjustment
buttons (see your
Owner’s Manual
for location)
3 When the headlights are turned on, and you wish to have
the Day display mode, adjust the illumination to full
brightness (beeps).
Remember: Adjust the dash brightness back to mid-range
to allow auto switching by sensing the headlights are on or
off.
Headlights
(Auto/On/Off)
4 When turned on, the display changes to Night display
mode. The previous three controls listed above can
“cancel” this function.
Remember: Use the a button, or adjust the dash
illumination to full brightness, to set the display to your
desired choice.
Screen color
choice
N/A The user can select the color of the screen that will be
displayed for the Day and Night display modes described
above.
Remember: For best contrast, ensure that the map color is
white for Day and black for Night.
CR‑ZKA‑31SZT820.book27ページ２０１２年１０月９日 火曜日 午前８時１７分
28
Interface Settings
Language
System Setup
Language
H INFO button
Setup
Other
Language
Set the system language used on all screens. You can choose from three languages:
English, Français (French), Español (Spanish).
Select the system language.
1 Language
Voice confirmation of cities and streets only
occurs when English is the system language.
When Français or Español is selected, some
messages continue to be displayed in English.
CR‑ZKA‑31SZT820.book28ページ２０１２年１０月９日 火曜日 午前８時１７分
29
System Setup
Personal Information
H INFO button
Setup
Personal Information
Use the personal information menu to select and set your address books, home
addresses, and PINs. You can also delete unwanted destinations from the list of
previously routed destinations.
Select an item.
The following items are available:
• Address Book: Stores new addresses or edits your address book.
2 Address Book P. 30
• Home Address 1: Sets or edits your home address.
2 Home Addresses P. 35
• Home Address 2: Sets or edits another home address.
2 Home Addresses P. 35
• PIN Number: Sets or changes your PIN.
2 PIN Numbers P. 36
• User Name: Sets or changes your user name.
2 User Name P. 37
• Previous Destinations: Deletes the destination history.
2 Previous Destinations P. 38
1 Personal Information
Personal information cannot be backed up or
moved to another navigation system.
CR‑ZKA‑31SZT820.book29ページ２０１２年１０月９日 火曜日 午前８時１７分
30
Personal Information
Address Book
System Setup
Address Book
H INFO button
Setup
Personal Information
Address Book
Store up to 200 address entries in two address books (User 1 and User 2). You can
add, edit, and delete information in the address books.
Select the user name to edit the user
address book.
Displays the address book.
Select the user name to change the
user address book.
Select the category tab to display
only the address in the selected
category.
1 Address Book
The number of addresses is shared by the two
address books. For example, if User 1 has 150
addresses, User 2 can only have 50.
If you have PIN-protected your address book,
enter your PIN when prompted. Select OK. PINs
are optional.
2 PIN Numbers P. 36
Any address book categories you create are also
displayed on the Select an Address screen.
2 Selecting an Address Book Category P. 33
CR‑ZKA‑31SZT820.book30ページ２０１２年１０月９日 火曜日 午前８時１７分
31
Personal Information
Address Book
System Setup
H INFO button
Setup
Personal Information
Address Book
This section explains how to enter the name and address.
1. Select New Address.
2. Select an item.
The following items are available:
• Edit Name: Edits the name of the entry.
• Edit Address: Edits the address of the entry.
• Edit Phone No.: Edits the phone number of the entry.
• Edit Category: Specifies the category of the entry.
• Delete: Deletes the entry.
■ Adding an Address Book Entry
1 Adding an Address Book Entry
If you do not give the address a name, one is
automatically assigned (e.g., Address 001). You
can re-enter, edit, or make changes to any entry.
“Address” is the only required field.
Continued
CR‑ZKA‑31SZT820.book31ページ２０１２年１０月９日 火曜日 午前８時１７分
32
Personal Information
Address Book
System Setup
3. Select Edit Name.
4. Enter a name or title. Select OK.
5. Select Edit Address.
6. Select an item for specifying the
address.
The following items are available:
• Current Position: Select your current location.
• Address: Enter an address on the character input screen when prompted.
2 Address P. 58
• Previous Destinations: Select a previous destination.
2 Previous Destinations P. 64
• Place Name: Enter the name of a place/landmark.
2 Place Name P. 65
• Place Category: Select a category to search for a place/landmark (e.g., Banking,
Lodging).
2 Place Category P. 67
• Place Phone Number: Enter the phone number of a place/landmark.
2 Place Phone Number P. 72
1 Adding an Address Book Entry
When you use Place Name or Place Category,
the name and phone number are automatically
entered.
CR‑ZKA‑31SZT820.book32ページ２０１２年１０月９日 火曜日 午前８時１７分
33
Personal Information
Address Book
System Setup
H INFO button
Setup
Personal Information
Address Book
1. Select the address to edit.
2. Enter the name, address, phone
number, and category fields.
2 Adding an Address Book Entry
P. 31
3. Select OK.
H INFO button
Setup
Personal Information
Address Book
1. Select an address.
2. Select Edit Category.
3. Select BUSINESS, PERSONAL, or a
category you created.
■ Editing an Address Book Entry
1 Editing an Address Book Entry
The entered contents are displayed on the Edit
address screen.
■ Selecting an Address Book Category
1 Selecting an Address Book Category
You can have up to 100 categories (including
“UNFILED”). These categories can be shared with
User 1 and User 2. For example, if User 1 creates
some categories, User 2 can also use them.
If you delete a category that is used by other
addresses, the category type for those addresses
changes to “UNFILED.”
Category Icons
The following icons can be selected for a
category:
Continued
CR‑ZKA‑31SZT820.book33ページ２０１２年１０月９日 火曜日 午前８時１７分
34
Personal Information
Address Book
System Setup
■ Creating a New Category
1. Select New Category.
2. Enter a name and select an icon when prompted. Select OK.
The created category is displayed in the list of categories.
■ Deleting or Editing a Category
1. Select Edit Category.
2. Select Edit Category or Delete.
3. Delete an existing category, or change the name and icon.
H INFO button
Setup
Personal Information
Address Book
1. Select the address to delete.
2. Select Delete.
3. Select Yes.
■ Deleting an Address Book Entry
1 Deleting an Address Book Entry
When you transfer the vehicle to a third party,
delete all address book entries.
CR‑ZKA‑31SZT820.book34ページ２０１２年１０月９日 火曜日 午前８時１７分
35
Personal Information
Home Addresses
System Setup
Home Addresses
H INFO button
Setup
Personal Information
Home Address 1 or Home
Address 2
Set two home addresses that you frequently use.
1. Edit the name, address, and phone
number the same way as an
address in the address book.
2 Adding an Address Book Entry
P. 31
2. Select OK.
1 Home Addresses
If you have PIN-protected your home addresses,
enter your PIN when prompted. Select OK. PINs
are optional.
2 PIN Numbers P. 36
If your home street is not in the system database,
park on the nearest verified street to your home.
When entering the “Address” field, select
Current Position to use your current location as
the home address.
You can delete a home address if necessary.
Select Delete. Select Yes.
When you transfer the vehicle to a third party,
delete all home addresses.
The home icon is shown on the map screen on 5
mile or less map scales.
CR‑ZKA‑31SZT820.book35ページ２０１２年１０月９日 火曜日 午前８時１７分
36
Personal Information
PIN Numbers
System Setup
PIN Numbers
H INFO button
Setup
Personal Information
PIN Number
Set a 4-digit PIN for protecting personal addresses and your home addresses. Once
you set a PIN, you are prompted to enter it whenever you access a personal address
or a home address.
1. Select the PIN to create.
2. Select the user name (when
selecting Address Book PIN).
3. Enter a 4-digit PIN.
4. Re-enter the new PIN when
prompted to confirm the number
you just entered.
If you do not enter the same
number both times, an
“INCORRECT PIN” message is
displayed. Enter your PIN again.
1 PIN Numbers
PIN
Personal Identification Number (PIN) is a
password used to access some personal data.
PINs are optional. If you choose to use a PIN,
keep a note of the number in a secure location. If
you forget your PIN, your dealer will have to reset
the navigation system and all of your stored
information will be erased. The factory default is
no PIN.
Go Home PIN
Go Home PINs are shared with User 1 and User
2. If either User 1 or User 2 sets a Go Home PIN,
both of them need to enter the PIN when:
• selecting Go Home for a destination
• selecting Home Address for editing
If you want to stop using a PIN, select Do not
use PIN.
CR‑ZKA‑31SZT820.book36ページ２０１２年１０月９日 火曜日 午前８時１７分
37
Personal Information
User Name
System Setup
User Name
H INFO button
Setup
Personal Information
User Name
Change the user name (“User 1” or “User 2”) to your desired name.
1. Select the name to change.
2. Enter a name. Select OK.
CR‑ZKA‑31SZT820.book37ページ２０１２年１０月９日 火曜日 午前８時１７分
38
Personal Information
Previous Destinations
System Setup
Previous Destinations
H INFO button
Setup
Personal Information
Previous Destinations
The navigation system maintains a list of your previously routed destinations as a
shortcut for entering the same destination in the future. You can delete some or all
of your previous destinations from the list.
1. Select the destination to delete.
Repeat the procedure as
necessary.
Items to be deleted are indicated
with a trash icon.
2. Select OK to delete the selected
destinations.
1 Previous Destinations
Up to 50 destinations can be stored.
The list of previous destinations is shared with
User 1 and User 2. For example, if User 1 deletes
some previous destinations, they are deleted for
User 2 as well.
To cancel the selection of a previous destination,
select the destination again.
Selecting Delete All allows you to delete all
destinations.
Trash icon
CR‑ZKA‑31SZT820.book38ページ２０１２年１０月９日 火曜日 午前８時１７分
39
System Setup
Routing & Guidance
H INFO button
Setup
Other
Routing & Guidance
Choose various settings that determine the navigation system functionality during
route guidance.
Select an item.
The following items are available:
• Rerouting: Sets the route recalculation to automatic or manual mode.
2 Rerouting P. 40
• Unverified Area Routing: Sets whether you use the route guidance in unverified
areas.
2 Unverified Area Routing P. 41
• Edit Avoid Area: Specifies areas to avoid when calculating a route.
2 Edit Avoid Area P. 43
• Edit Waypoint Search Area: Sets the distance from the route to find waypoints.
2 Edit Waypoint Search Area P. 45
• Guidance Mode: Sets whether to display only the map screen or a split map-
guidance screen.
2 Guidance Mode P. 90
CR‑ZKA‑31SZT820.book39ページ２０１２年１０月９日 火曜日 午前８時１７分
40
Routing & Guidance
Rerouting
System Setup
Rerouting
H INFO button
Setup
Other
Routing & Guidance
Set whether route recalculation occurs automatically or manually during route
guidance.
Select an option.
The following options are available:
• Automatic (factory default): The system calculates a new route automatically
when you deviate from the route. It is strongly recommended that you leave the
system set to Automatic.
• Manual: Disables route recalculation. The system beeps and “Off Route” is
displayed when you deviate from the route.
1 Rerouting
If you live in an area with poor mapping, you
may wish to set Rerouting to Manual to avoid
constant recalculation. You will need to select
Recalc. manually to make the system recalculate
your new route.
CR‑ZKA‑31SZT820.book40ページ２０１２年１０月９日 火曜日 午前８時１７分
41
Routing & Guidance
Unverified Area Routing
System Setup
Unverified Area Routing
H INFO button
Setup
Other
Routing & Guidance
Receive turn-by-turn map and voice guidance in unverified areas.
Select On or Off.
1 Unverified Area Routing
Unverified roads are found in rural areas, and
typically include residential streets away from the
center of a town. They may not be accurate, and
can contain errors in location, naming, and
address range.
Unverified roads are shown only when viewing
the map in the 1/20, 1/8, 1/4, 1/2, 1, or 2 mile
map scales.
Vector line (dotted)
Blue-pink route line
Differences Off On (factory default)
On or Off? The driver wishes to manually
navigate using the navigation map
and choose the streets that lead to
the destination.
The driver chooses to let the
navigation system suggest
possible routing, knowing that the
guidance may not be accurate.
Route
calculation
Route is usually longer, using
verified roads whenever possible.
Route is shorter, but uses
unverified (purple) streets that
may not be accurate.
Route line A blue dotted vector line is displayed
on the map that continually points
to your destination.
A blue-pink dashed route line
highlights suggested unverified
streets on the map while traveling
to your destination.
Cautionary
messages
Cautionary pop-up screens and
voice announcements remind you to
obey all traffic restrictions.
Cautionary pop-up screens and
voice announcements remind you
to exercise additional caution and
obey all traffic restrictions.
Continued
CR‑ZKA‑31SZT820.book41ページ２０１２年１０月９日 火曜日 午前８時１７分
42
Routing & Guidance
Unverified Area Routing
System Setup
Guidance
(map/voice)
There is no turn-by-turn map or
voice guidance.
Voice guidance commands end
with the phrase “if possible” to
remind you to verify all traffic
restrictions.
My
Destination
(Direction
list)
A direction list is typically not
available. However, depending on
your route, directions are provided
to help you reach the first available
verified road.
A direction list is provided
showing unverified street names
in blue boxes and turn symbols in
pink.
Differences Off On (factory default)
CR‑ZKA‑31SZT820.book42ページ２０１２年１０月９日 火曜日 午前８時１７分
43
Routing & Guidance
Edit Avoid Area
System Setup
Edit Avoid Area
H INFO button
Setup
Other
Routing & Guidance
Edit Avoid Area
“Edit”
Specify up to five areas to avoid (e.g., road construction, closures), if possible, when
the system calculates routes to your destination.
1. Select New Area or an existing
area to edit.
2. Select Edit Name to label the area
to avoid.
3. Enter a name or title. Select OK.
4. Select Edit Area to define the area
to avoid.
The following items are available (after an area is set):
• View Area Map: Displays the selected avoid area on the map.
• Delete: Deletes the selected avoid area.
1 Edit Avoid Area
The avoid areas are shared with User 1 and
User 2. For example, if User 1 specifies some
avoid areas, User 2 can also use them for setting
a route.
The maximum size of an “avoid area” is about 1
square mile.
If your selected area contains a freeway, you are
asked “Do you want to avoid freeways?”
Answering “No” allows you to use a route
through an avoid area on a freeway without any
pop-up messages.
You can select areas to avoid, however you
cannot select roads or areas that you want the
system to use for routing.
You can enter characters for the name until the
input field is full.
Continued
CR‑ZKA‑31SZT820.book43ページ２０１２年１０月９日 火曜日 午前８時１７分
44
Routing & Guidance
Edit Avoid Area
System Setup
5. Select a method for specifying the
area.
The following items are available:
• Address: Specify the general area by entering an address.
2 Address P. 58
• Map Input: Specify the general area by map input.
2 Map Input P. 75
6. Scroll the map to position the
cursor over your desired start point,
adjusting the map scale as
necessary. Press the ENTER button
to mark the start point.
To redo the area selection, press
the CANCEL button.
7. Scroll the map to “draw” the area.
Press the ENTER button to mark the
end point.
8. Select OK.
The area you specify is displayed
in the list of areas to avoid.
Cursor
Avoid area
CR‑ZKA‑31SZT820.book44ページ２０１２年１０月９日 火曜日 午前８時１７分
45
Routing & Guidance
Edit Waypoint Search Area
System Setup
Edit Waypoint Search Area
H INFO button
Setup
Other
Routing & Guidance
Edit Waypoint
Search Area “Edit”
Select the distance from your highlighted route line (on either side of your route)
that the system will search for a waypoint.
2 Adding Waypoints P. 103
You can specify a different search distance for freeways and surface streets.
1. Select a search distance.
2. Select OK.
The following options are available:
• On Freeways: 1, 2, 5, or 10 miles can be set. Factory default is 2 miles.
• On Surface Street: 1/2, 1, 2, or 5 miles can be set. Factory default is 1/2 mile.
1 Edit Waypoint Search Area
The search distance does not affect the search
range used for the Find Nearest voice commands
(e.g., say
d “Find nearest gas station”).
CR‑ZKA‑31SZT820.book45ページ２０１２年１０月９日 火曜日 午前８時１７分
46
System Setup
Clock Adjustment
H INFO button
Setup
Other
Clock Adjustment
Clock Adjustment
Set the automatic adjustment of the system clock for daylight saving and
international time zones.
Select an item.
The following items are available:
• Auto Daylight: The navigation system automatically adjusts the clock (“spring
ahead” or “fall back” by one hour) when a daylight saving time change occurs.
On (factory default): Adjusts the clock automatically.
Off: Disables the feature.
• Auto Time Zone: The navigation system automatically adjusts the clock when
driving through different time zones.
On (factory default): Adjusts the clock automatically.
Off: Disables the feature.
• Clock Format: Sets the time notation to either 12-hour clock (12H, factory
default) or 24-hour clock (24H).
• Time Adjustment: Adjust the current time manually.
2 Adjust Time P. 47
• Reset: Reset the clock settings to the factory default.
2 Resetting the Clock Settings P. 47
1 Clock Adjustment
You can check the time and date from any
screen using voice commands.
2 Global Commands P. 194
Auto Daylight
This function is not activated in areas that have
not adopted daylight saving time, even if you
have set Auto Daylight to On.
Auto Time Zone
If you live and work in two different time zones,
you may want to turn Auto Time Zone to Off.
When driving near a time zone boundary, the
displayed time zone may fluctuate between the
two zone times.
CR‑ZKA‑31SZT820.book46ページ２０１２年１０月９日 火曜日 午前８時１７分
47
Clock Adjustment
Adjust Time
System Setup
Adjust Time
H INFO button
Setup
Other
Clock Adjustment
Clock Adjustment
Adjust the current time (hours and minutes).
1. Select B or N to adjust the value.
2. Select OK on the top right of the
screen.
Resetting the Clock Settings
H INFO button
Setup
Other
Clock Adjustment
Clock Adjustment
Reset all clock settings to the factory defaults.
Select OK under Reset.
CR‑ZKA‑31SZT820.book47ページ２０１２年１０月９日 火曜日 午前８時１７分
48
Clock Adjustment
Setting the Clock Type
System Setup
Setting the Clock Type
H INFO button
Setup
Other
Clock Adjustment
Clock Type
Set the design of the clock screen.
1. Select Clock Type or Background.
2. Select an option to change the
design.
3. Select OK.
CR‑ZKA‑31SZT820.book48ページ２０１２年１０月９日 火曜日 午前８時１７分
50
Vehicle
Off-road Tracking
System Setup
Off-road Tracking
H INFO button
Setup
Other
Vehicle
The navigation system can be set to display white off-road tracking dots
(“breadcrumbs”) on the map screen whenever you drive into an area approximately
1/2 mile away from a mapped road.
Select an option.
The following options are available:
• On: The system displays the white tracking dots.
2 Driving Off-road P. 83
• Off (factory default): Disables the feature.
1 Off-road Tracking
To clear existing breadcrumbs, set Off-road
Tracking to Off, exit the Setup screen, and then
set Off-road Tracking to On again.
CR‑ZKA‑31SZT820.book50ページ２０１２年１０月９日 火曜日 午前８時１７分
51
Vehicle
Correct Vehicle Position
System Setup
Correct Vehicle Position
H INFO button
Setup
Other
Vehicle
Manually adjust the current position of the vehicle as displayed on the map screen if
the position appears to be incorrect.
1. Put the vehicle in Park.
2. Select ADJUST under Current
Vehicle Position.
3. Scroll the map to position the
arrowhead at your correct position.
4. Select or to position the
arrowhead in the correct direction
the vehicle is facing.
5. Select OK.
1 Correct Vehicle Position
An apparent position error can occur where
buildings, tunnels, and other objects block or
reflect the GPS signals, forcing the system to use
“dead reckoning” to determine your location
and direction.
Using this function to adjust vehicle position is
not recommended. When the system reacquires
a GPS signal, it will automatically place the
vehicle in the correct location.
If you continually have to adjust the vehicle
position, you may have problems with the GPS
reception or there may be database errors.
2 System Limitations P. 184
CR‑ZKA‑31SZT820.book51ページ２０１２年１０月９日 火曜日 午前８時１７分
52
System Setup
Data Reset
Reset Factory Default Settings
H INFO button
Setup
Other
Reset Factory Default
Reset all the settings on the Setup screens to their factory defaults.
Select Yes.
1 Reset Factory Default Settings
The following settings are reset:
• Brightness, Contrast, Black Level, Volume,
Guidance Prompts
• Basic Settings: Keyboard Layout, Units, Voice
Recognition Tutor, Verbal Reminder, Display
Voice Commands Tips
• Routing & Guidance: Rerouting, Unverified
Area Routing, Edit Waypoint Search Area,
Guidance Mode
• Clock Adjustment: Auto Daylight, Auto Time
Zone, Clock Format Time, Clock Type
• Vehicle: Off-road Tracking
• Color: Map Color, Menu Color
When you transfer the vehicle to a third party,
reset all settings to default and delete all
personal data.
2 Deleting an Address Book Entry P. 34
2 Home Addresses P. 35
2 PIN Numbers P. 36
2 User Name P. 37
2 Previous Destinations P. 38
2 Edit Avoid Area P. 43
2 Deleting a Paired Phone P. 149
CR‑ZKA‑31SZT820.book52ページ２０１２年１０月９日 火曜日 午前８時１７分
53
Data Reset
Clear All Speed Dial
System Setup
Clear All Speed Dial
H INFO button
Setup
Other
Clear All Speed Dial
Delete all registered speed dials stored in Bluetooth® HandsFreeLink®.
Select Yes.
1 Clear All Speed Dial
You can also delete a speed dial individually.
2 Setting Up Speed Dialing P. 151
CR‑ZKA‑31SZT820.book53ページ２０１２年１０月９日 火曜日 午前８時１７分
54
CR‑ZKA‑31SZT820.book54ページ２０１２年１０月９日 火曜日 午前８時１７分
55
Navigation
This section describes how to enter a destination, select a route to take,
and follow the route to your destination. It also describes how to change
your route or destination along the way.
Entering a Destination ........................... 56
Address ................................................. 58
Address Book......................................... 63
Previous Destinations ............................. 64
Place Name............................................ 65
Place Category....................................... 67
Place Phone Number.............................. 72
Coordinate ............................................ 73
Intersection............................................ 74
Map Input.............................................. 75
Calculating the Route ..............................77
Changing the Route Preference ..............78
Viewing the Routes.................................78
Calculating the Route on the Destination
Map......................................................79
Driving to Your Destination ...................80
Viewing the Route ..................................80
Listening to Voice Guidance....................84
Map Menu................................................85
Displaying the Map Menu .......................85
Guidance Menu ......................................87
Showing Icons on the Map .....................92
Map Legend ...........................................94
FM Traffic ...............................................99
Changing Your Route ........................... 101
Canceling the Route............................. 102
Taking a Detour ................................... 102
Avoiding Streets................................... 102
Adding Waypoints ............................... 103
Editing My Destination ......................... 107
Changing Your Destination ................. 108
Find Nearest Place ................................ 108
Selecting a Destination on the Map...... 109
Entering a New Destination.................. 110
Resuming Your Trip .............................. 112
CR‑ZKA‑31SZT820.book55ページ２０１２年１０月９日 火曜日 午前８時１７分
56
Navigation
Entering a Destination
H DEST button
This section describes how to enter a destination for route guidance.
Select an item.
Select DEST Menu 2 to display
additional menu entries.
The following items are available:
• Address: Sets a destination by entering an address.
2 Address P. 58
• Address Book: Sets a destination by selecting an address stored in your Address
Book.
2 Address Book P. 63
• Previous Destinations: Sets a destination by selecting a previous destination.
2 Previous Destinations P. 64
1 Entering a Destination
d “Display Menu”, d “Display Navigation”
If you press the DEST button when en route, the
Route Menu screen is displayed.
2 Changing Your Route P. 101
Prior to departure, you can set areas along your
route to avoid.
2 Avoiding Streets P. 102
Certain touchscreen functions are disabled while
the vehicle is moving.
2 Limitations for Manual Operation P. 18
CR‑ZKA‑31SZT820.book56ページ２０１２年１０月９日 火曜日 午前８時１７分
57
Entering a Destination
Navigation
• Place Name: Sets a destination by entering a place name.
2 Place Name P. 65
• Place Category: Sets a destination by selecting a place/landmark.
2 Place Category P. 67
• Place Phone Number: Sets a destination by entering the phone number of a
place/landmark.
2 Place Phone Number P. 72
• Coordinate: Sets a destination by entering latitude and longitude.
2 Coordinate P. 73
• Intersection: Sets a destination (intersection) by entering two streets.
2 Intersection P. 74
• Map Input: Sets a destination by scrolling through the map.
2 Map Input P. 75
• Go Home 1 or 2: Sets your home address as a destination.
2 Going Home P. 10
CR‑ZKA‑31SZT820.book57ページ２０１２年１０月９日 火曜日 午前８時１７分
58
Entering a Destination
Address
Navigation
Address
H DEST button
Address
Enter an address to use as the destination. The state or province you are currently in
is displayed (e.g., California).
Select an item.
The following items are available:
• City: Selects your destination city.
2 Selecting a City P. 60
• Street: Selects your destination street.
2 Selecting a Street P. 61
• Change State: Selects the state or province.
2 Selecting the State or Province P. 59
CR‑ZKA‑31SZT820.book58ページ２０１２年１０月９日 火曜日 午前８時１７分
59
Entering a Destination
Address
Navigation
H DEST button
Address
Change State
1. Enter a state name.
Select List to display a list of
states.
2. Select a state from the list.
■ Selecting the State or Province
CR‑ZKA‑31SZT820.book59ページ２０１２年１０月９日 火曜日 午前８時１７分
60
Entering a Destination
Address
Navigation
H DEST button
Address
City
The name of the city where you are currently located is displayed.
1. Enter the name of a different city,
or select List for the current city.
Select List to display a list of
cities.
2. Select your destination city from
the list.
A list of matching hits is
automatically displayed after
you enter several letters, with
the closest match at the top of
the list.
Next, you are prompted to enter
a street name.
2 Selecting a Street P. 61
■ Selecting a City
1 Selecting a City by Name
Vehicle position may not be displayed when:
• The automobile is traveling off-road.
• The vehicle position data cannot be updated.
Using Voice Command (English only)
Say d “City” on the Find address by screen, and
the following screen is displayed:
Say d “Current City” to select your current
location, or say the name of a different city.
2 Selecting a Street P. 61
If your city is not listed, it may be part of a larger
metropolitan area. Try entering the street first.
Non-detailed area mark: Try entering the
street first and then select the city.
CR‑ZKA‑31SZT820.book60ページ２０１２年１０月９日 火曜日 午前８時１７分
61
Entering a Destination
Address
Navigation
H DEST button
Address
Street
1. Enter the name of your destination
street.
Do not enter the street type
(e.g., street, road, avenue) or
direction (e.g., north, south,
east, west).
Select List to display a list of
streets.
2. Select your destination street from
the list.
A list of matching hits is
automatically displayed after
you enter several letters, with
the closest match at the top of
the list.
■ Selecting a Street
1 Selecting a Street
When entering the names of major freeways,
you can use the following abbreviations. For
interstates, use an “I” (e.g., I-10). For U.S.
freeways, use “US” (e.g., US-18). For state
freeways, use the two-character state
designation (e.g., CA-101). For county roads, use
the appropriate designation (e.g., G-2).
Using Voice Command (English only)
Say d “Street” on the Find address by screen,
and the following screen is displayed:
• Say the name of your destination street, and
say the street number as a string of individual
numbers.
• Set the route to your destination.
2 Calculating the Route P. 77
Continued
CR‑ZKA‑31SZT820.book61ページ２０１２年１０月９日 火曜日 午前８時１７分
62
Entering a Destination
Address
Navigation
3. Enter the street number. Select OK.
Only valid street numbers can be
entered.
4. Set the route to your destination.
2 Calculating the Route P. 77
1 Selecting a Street
If you did not select a city first and there is more
than one city with the specified street, a list of
cities is displayed.
Select the desired city from the list.
CR‑ZKA‑31SZT820.book62ページ２０１２年１０月９日 火曜日 午前８時１７分
63
Entering a Destination
Address Book
Navigation
Address Book
H DEST button
Address Book
Select an address stored in your address book to use as the destination.
1. Select your user name.
2. Select your destination from the
list.
3. Set the route to your destination.
2 Calculating the Route P. 77
Select C or X to display only
the entries in a category: ALL,
BUSINESS, PERSONAL, or other
categories you have created.
2 Selecting an Address Book
Category
P. 33
1 Address Book
If you have PIN-protected your address book,
enter your PIN when prompted. Select OK. PINs
are optional.
2 PIN Numbers P. 36
You can select New Address on the Select an
address screen to add an entry to the address
book.
2 Adding an Address Book Entry P. 31
To switch the list between User 1 or User 2,
select the user name on the top right of the
screen.
CR‑ZKA‑31SZT820.book63ページ２０１２年１０月９日 火曜日 午前８時１７分
64
Entering a Destination
Previous Destinations
Navigation
Previous Destinations
H DEST button
Previous Destinations
Select an address from a list of your 50 most recent destinations to use as the
destination. The list is displayed with the most recent destination at the top.
1. Select a destination from the list.
2. Set the route to your destination.
2 Calculating the Route P. 77
1 Previous Destinations
Your home addresses and addresses stored in
your address book are not added to the list of
previous destinations.
You can delete unwanted previous destinations
from the list.
2 Previous Destinations P. 38
CR‑ZKA‑31SZT820.book64ページ２０１２年１０月９日 火曜日 午前８時１７分
65
Entering a Destination
Place Name
Navigation
Place Name
H DEST button
Place Name
Enter the name of a place (e.g., business, hotel, restaurant) stored in the map
database to use as the destination.
1. Enter a place name.
2. Select List to display a list of
matching hits.
3. Select a place name from the list.
If the place name is in multiple
categories, the categories are
displayed when you select it.
2 Place Name in Multiple
Categories
P. 66
4. Set the route to your destination.
2 Calculating the Route P. 77
1 Place Name
This option is convenient if you know the exact
name of a place.
Select More to enter symbols and accented
letters, select Space to enter a space character,
or select Delete to remove the last character.
Once a name is entered and selected, select
SORT BY Name or SORT BY Distance.
Matching letters are in yellow.
CR‑ZKA‑31SZT820.book65ページ２０１２年１０月９日 火曜日 午前８時１７分
66
Entering a Destination
Place Name
Navigation
If the place name is in multiple categories in the map database, the following screen
is displayed.
1. Select a place name.
2. Select a subcategory.
3. Set the route to your destination.
2 Calculating the Route P. 77
■ Place Name in Multiple Categories
1 Place Name in Multiple Categories
Select SORT BY Name or SORT BY Distance.
Matching letters are in yellow.
CR‑ZKA‑31SZT820.book66ページ２０１２年１０月９日 火曜日 午前８時１７分
67
Entering a Destination
Place Category
Navigation
Place Category
H DEST button
Place Category
Select the category of a place (e.g., Banking, Lodging, Restaurant) stored in the map
database to search for the destination.
1. Select a category.
2. Select a subcategory.
Select b or n to change the
main category.
2 List of Categories P. 203
1 Place Category
This option is convenient if you do not know the
exact name of a place or if you want to narrow
down the number of matches returned for places
with a common name.
You can store up to 30 favorite subcategories.
Select Fav. Subcategory to access your
favorites.
2 Favorite Subcategories P. 69
Advanced helps you to search the subcategory.
When you enter a keyword and select List, the
list of appropriate subcategories is displayed.
Continued
CR‑ZKA‑31SZT820.book67ページ２０１２年１０月９日 火曜日 午前８時１７分
68
Entering a Destination
Place Category
Navigation
3. Select an item.
The following items are available:
• Place Name: Searches for a place in the subcategory by name. Enter a city name
when prompted.
• Sort by Distance to Travel: Displays all the places in the subcategory sorted by
distance from your current location. The closest place is displayed at the top.
• City Vicinity: Searches for a place in the subcategory within a 20-mile radius of a
specific city. Enter a city name and then a place name when prompted. Only the
first approximately 1000 matching places/landmarks are displayed.
• Search by Keyword: Searches for a place by keyword when you do not know the
exact category. Select Sort by Distance to Travel for locations near your current
location, or select City Vicinity for locations in a specific city. Enter a keyword
when prompted. Select List to view a list of possible locations if one is not found
automatically.
1 Place Category
Sort by Distance to Travel
For locations sorted by distance to travel, you can
select More to increase the scope of the search.
The number of locations increases to 100, 200,
and up to approximately 1000. When the
number of locations is 100 or less, you can
increase the scope to 500 miles, 1000 miles, or
all of U.S.
CR‑ZKA‑31SZT820.book68ページ２０１２年１０月９日 火曜日 午前８時１７分
69
Entering a Destination
Place Category
Navigation
4. Select a place name from the list.
5. Set the route to your destination.
2 Calculating the Route P. 77
H DEST button
Place Category
Fav. Subcategory
Store up to 30 favorite subcategories.
1 Place Category
The straight line distance (as the crow flies, not
driving distance) and direction to the destination
are shown for the highlighted place.
■ Favorite Subcategories
Continued
CR‑ZKA‑31SZT820.book69ページ２０１２年１０月９日 火曜日 午前８時１７分
70
Entering a Destination
Place Category
Navigation
■ To store a subcategory in favorites:
1. Select a category on the Category
screen.
2. Select Add to Fav. Subcategory.
3. Select the favorite subcategories to
add. Select OK.
1 Favorite Subcategories
Stored categories
A subcategory stored in Fav. Subcategory has a
star at the end of the line.
CR‑ZKA‑31SZT820.book70ページ２０１２年１０月９日 火曜日 午前８時１７分
71
Entering a Destination
Place Category
Navigation
■ To delete a subcategory from favorites:
1. Select Delete on the Favorite
Subcategory screen.
2. Select the subcategories to delete.
Repeat the procedure as
necessary.
Items to be deleted are indicated
with a trash icon.
3. Select OK.
1 Favorite Subcategories
Deleting categories
You can also delete a favorite subcategory on
any Subcategory screen. Select R or U to
select a favorite subcategory (which has a star at
the end of line) and select Delete from Fav.
Subcategory.
Trash icon
CR‑ZKA‑31SZT820.book71ページ２０１２年１０月９日 火曜日 午前８時１７分
72
Entering a Destination
Place Phone Number
Navigation
Place Phone Number
H DEST button
DEST Menu 2
Place Phone Number
Select a destination by phone number. Only phone numbers in the database are
recognized.
1. Enter the area code and phone
number. Select OK.
2. Set the route to your destination.
2 Calculating the Route P. 77
1 Place Phone Number
All 10 digits must be entered.
Phone numbers of private residences entered in
your address book are not stored in the database
and thus cannot be used to search for a
destination.
A list is displayed if there are multiple locations in
the database with the same phone number.
Select a place from the list.
CR‑ZKA‑31SZT820.book72ページ２０１２年１０月９日 火曜日 午前８時１７分
73
Entering a Destination
Coordinate
Navigation
Coordinate
H DEST button
DEST Menu 2
Coordinate
Specify a location using latitude and longitude map coordinates.
1. Enter the latitude. Select OK.
2. Enter the longitude. Select OK.
3. Scroll the map to position the
cursor over your desired
destination, adjusting the map
scale as necessary. Press the ENTER
button.
If the address is not the desired
location, scroll to another
location and try again.
4. Press the ENTER button again to
display the route calculation menu.
2 Calculating the Route P. 77
5. Select Set as Dest.
1 Coordinate
Latitude and longitude must be entered up to
the seconds’ value.
A yellow box (shown at scales above 1/4 mile)
denotes the area that can be viewed when you
press the ENTER button on the current map.
Information icons are displayed at scales from 1
mile to 1/4 mile. Place/landmark icons are
displayed at 1/8 mile or less. Roads are displayed
at 1/4 mile or less.
If you select multiple icons within the cursor
radius, you are prompted to select one of the
items from a list.
CR‑ZKA‑31SZT820.book73ページ２０１２年１０月９日 火曜日 午前８時１７分
74
Entering a Destination
Intersection
Navigation
Intersection
H DEST button
DEST Menu 2
Intersection
Select the intersection of two streets as the destination. The state or province for
your current location is displayed at the top of the screen (e.g., California).
1. Select the intersection search
method.
2. Set the route to your destination.
2 Calculating the Route P. 77
The following items are available:
• City: Selects the city where the intersection is located. You are prompted to enter
the name of the two intersecting streets.
2 Selecting a City P. 60
• Street: Selects the two intersecting streets. The city or cities that the streets are
located in are displayed.
2 Selecting a Street P. 61
• Change State: Selects the state or province.
2 Selecting the State or Province P. 59
1 Intersection
It is usually easier to select Street to find the
streets first. The city or cities that the streets are
in will be displayed. If you select City and your
city is not listed, it may be part of a larger
metropolitan area. Try entering the street first.
If the intersection is outside the state you are
currently in, select Change State.
2 Selecting the State or Province P. 59
If there is more than one intersection, you are
prompted to select the intersection. If the two
streets that you have selected do not intersect,
no intersection is entered.
CR‑ZKA‑31SZT820.book74ページ２０１２年１０月９日 火曜日 午前８時１７分
75
Entering a Destination
Map Input
Navigation
Map Input
H DEST button
DEST Menu 2
Map Input
Use the joystick to manually select an icon or a location on the map screen as the
destination.
You are prompted to define the map area to display.
1. Select an item.
The following items are available:
• Current Position: Your current location is centered on the map.
• City: You are prompted to select the city.
2 Selecting a City P. 60
• State: You are prompted to select the state.
2 Selecting the State or Province P. 59
Continued
CR‑ZKA‑31SZT820.book75ページ２０１２年１０月９日 火曜日 午前８時１７分
76
Entering a Destination
Map Input
Navigation
2. Scroll the map to position the
cursor over your desired
destination, adjusting the map
scale as necessary. Press the ENTER
button.
If the address is not the desired
location, scroll the map to
another location and try again.
3. Press the ENTER button again to
display the route calculation menu.
2 Calculating the Route P. 77
4. Select Set as Dest.
1 Map Input
A yellow box (shown at scales above 1/4 mile)
denotes the area that can be viewed when you
press the ENTER button on the current map.
Information icons are displayed at scales from 1
mile to 1/4 mile. Place/landmark icons are
displayed at 1/8 mile or less. Roads are displayed
at 1/4 mile or less.
If you select multiple icons within the cursor
radius, you are prompted to select one of the
items from a list.
2 Selecting a Destination on the Map P. 109
CR‑ZKA‑31SZT820.book76ページ２０１２年１０月９日 火曜日 午前８時１７分
77
Navigation
Calculating the Route
This section describes how to calculate your route.
1. Select Set as Dest.
The system calculates and
displays the route line on the
map screen.
2 Route Line P. 82
The following items are available:
• Route Pref.: Changes the route preferences (calculating method).
2 Changing the Route Preference P. 78
• View Routes: Displays three different routes.
2 Viewing the Routes P. 78
• Destination Map: Displays a map of the destination.
2 Calculating the Route on the Destination Map P. 79
2. Follow the route guidance to your
destination.
2 Driving to Your Destination P. 80
The system provides you with
pop-up messages if your route
passes through unverified areas,
avoid areas, or areas with traffic
restrictions.
1 Calculating the Route
The current route preferences are displayed as
icons on the top right of the Calculate Route
screen. The straight line distance (as the crow
flies, not driving distance) and direction to the
destination are shown.
You cannot use voice commands while the
system is calculating the route.
Add to Address Book
You can add the destination address to the
address book.
2 Adding an Address Book Entry P. 31
Add to My Dest.
You can add the address to the destination list.
2 Editing My Destination P. 107
Call
You can place a telephone call to the destination
phone number.
2 Bluetooth® HandsFreeLink® P. 144
CR‑ZKA‑31SZT820.book77ページ２０１２年１０月９日 火曜日 午前８時１７分
79
Calculating the Route
Calculating the Route on the Destination Map
Navigation
Calculating the Route on the Destination Map
Calculate the route from the map of the destination address.
Select Calculate the Route.
The system calculates and displays
the route line on the map screen.
2 Route Line P. 82
1 Calculating the Route on the Destination Map
d “Display Destination Map” (when en route)
CR‑ZKA‑31SZT820.book79ページ２０１２年１０月９日 火曜日 午前８時１７分
80
Navigation
Driving to Your Destination
This section describes how to follow the route guidance to your destination, receive
traffic information, and choose the icons displayed on the map screen.
Viewing the Route
After calculating the route to your
destination, the route is displayed on
the map screen.
2 Map Screen Legend P. 7
As you drive, the system tracks your
position on the map in real time and
provides guidance as you approach
each guidance point on the route.
■ Map Screen
1 Viewing the Route
d “Display Map”
You can change the map scale using voice
control commands (e.g., say d “Display 2 mile
scale”).
2 Map Scale Commands P. 195
You can also change the map scale by using the
ZOOM button.
You can control the icons displayed on the map
screen using voice control commands (e.g., say
d “Display post office”).
2 Map Display Commands P. 194
You can obtain information about the route
using voice control commands (e.g., say d
“How long to the destination?”).
2 Route Commands P. 196
You can display the next guidance point on the
map screen by saying d “Display Map Guide”
(when en route).
If you scroll the map while en route, the time and
distance to destination indicators are replaced
with an indicator showing distance from the
current vehicle position.
The map screen can be viewed in single-screen or
split-screen mode.
2 Guidance Mode P. 90
CR‑ZKA‑31SZT820.book80ページ２０１２年１０月９日 火曜日 午前８時１７分
81
Driving to Your Destination
Viewing the Route
Navigation
The guidance screen offers an alternative way to view your route.
In single-screen mode, press the
MAP/GUIDE button to switch
between the map and guidance
screens.
In split-screen mode, press the
MAP/GUIDE button to switch
between the next guidance
direction and a list of guidance
directions.
■ Guidance Screen
1 Guidance Screen
A visual guide helps you check the guidance
screen.
2 Guidance Screen P. 8
CR‑ZKA‑31SZT820.book81ページ２０１２年１０月９日 火曜日 午前８時１７分
82
Driving to Your Destination
Viewing the Route
Navigation
When driving on verified streets, the route line is light blue. The route line display
changes when driving on unverified streets:
If Unverified Area Routing is Off,
the route line uses verified streets
only (when possible). A dotted
“vector line” pointing directly
towards your destination is also
displayed.
If Unverified Area Routing is On,
the route line changes to a dashed
blue-pink line to indicate that the
route line uses unverified streets.
■ Route Line
1 Route Line
You can set Unverified Area Routing to Off to
follow your own route to the destination. If
Unverified Area Routing is On, be aware that
unverified streets may not be displayed
accurately.
2 Unverified Area Routing P. 41
You can always view the entire route by simply
saying d “Display entire route.”
The route line may also consist of red or orange
segments when your route line displays traffic
information.
2 Map Screen Legend P. 7
2 FM Traffic P. 99
Vector line (dotted)
Blue-pink route line
CR‑ZKA‑31SZT820.book82ページ２０１２年１０月９日 火曜日 午前８時１７分
83
Driving to Your Destination
Viewing the Route
Navigation
If you leave the calculated route, the system automatically recalculates a route to the
desired destination based on your current location and direction.
2 Rerouting P. 40
If you leave all mapped (digitized) roads, the system automatically starts displaying a
series of dots (breadcrumbs) to track the path you are taking. If needed, you can
follow the dots back to the mapped road you originally left.
2 Off-road Tracking P. 50
■ Deviating From the Planned Route
1 Deviating From the Planned Route
If Rerouting is set to Manual and you go off
route, the system waits for you to manually
initiate recalculation. Select Recalc.
2 Rerouting P. 40
■ Driving Off-road
1 Driving Off-road
A message “Not on a digitized road” may appear
when you drive half a mile away from a mapped
road.
Breadcrumbs may occasionally be displayed in
urban areas, such as large parking lots in
shopping malls, in new subdivisions where the
roads are not yet in the database, or in areas
where a GPS signal is unavailable, such as in a
parking garage.
Off-road tracking breadcrumbs are limited to
approximately 150 miles. Breadcrumbs at the
beginning of the trail are deleted if you exceed
that distance.
Breadcrumbs are displayed only at 1/20, 1/8, 1/4,
and 1/2 mile map scales.
CR‑ZKA‑31SZT820.book83ページ２０１２年１０月９日 火曜日 午前８時１７分
84
Driving to Your Destination
Listening to Voice Guidance
Navigation
Listening to Voice Guidance
H MAP MENU (on map)
Voice
As you approach each guidance point, a pop-up window is displayed on the map
screen with instructions for you to follow. Voice guidance for each guidance point is
also provided.
Typically, you hear three prompts:
• 1/2 mile from the guidance point (2 miles on freeway)
• 1/4 mile from the guidance point (1.2 miles on freeway)
• Just before the guidance point
To replay voice guidance, select Voice on the map menu.
If you select Voice on the map menu between guidance points, voice guidance for
the next guidance point is provided.
1 Listening to Voice Guidance
d “Voice” (on the map screen)
You can turn voice guidance off if you prefer.
2 Display and Volume Settings P. 21
When driving in unverified areas, the phrase “if
possible” is inserted before each voice guidance
prompt.
Voice on the map menu may be grayed out if
the vehicle is approaching or is in an unverified
area with Unverified Area Routing set to Off.
The timing of voice guidance varies depending
on the type of road you are on and the distance
to the next guidance point.
CR‑ZKA‑31SZT820.book84ページ２０１２年１０月９日 火曜日 午前８時１７分
85
Navigation
Map Menu
Displaying the Map Menu
Use the Map Menu to control the icons displayed on the screen and to display traffic
information. You can also use the Map Menu to find locations or to cancel the route.
1. On the map screen, select MAP
MENU (if displayed).
The Map Menu is displayed on
the map screen.
2. Select an item.
The following items are available:
• Cancel Route: Cancels your current route.
2 Canceling the Route P. 102
• Show icon on Map: Selects the icons to display on the map.
2 Showing Icons on the Map P. 92
• Traffic Incidents: Displays a list of the traffic incidents around your current
location or on your current route.
2 FM Traffic P. 99
1 Map Menu
If you scroll the map while en route, press the
MAP/GUIDE (or CANCEL/BACK) button to return
to the current position map screen, then select
MAP MENU.
Traffic Incidents
You must be in or near a traffic-enabled city to
receive coverage for that area. FM Traffic is
available in the lower 48 states and Hawaii.
The incident icons are displayed on the 5 mile (8
km) or less map scale.
2 Map Scale and Functions P. 95
Continued
CR‑ZKA‑31SZT820.book85ページ２０１２年１０月９日 火曜日 午前８時１７分
86
Map Menu
Displaying the Map Menu
Navigation
• Map Legend: Displays an overview of the map features.
2 Map Legend P. 94
• Guidance Menu: Allows you to set or confirm the guidance points and freeway
exits for your route.
2 Guidance Menu P. 87
• Find Nearest…: Allows you to find the nearest place/landmark (e.g., nearest gas
station) by specifying a category. You can then add the location to the list of
destinations, set as a waypoint, or set as your destination.
2 Changing Your Destination P. 108
• Exit Info: Displays a list of the freeway exits.
2 Freeway Exit Information P. 89
CR‑ZKA‑31SZT820.book86ページ２０１２年１０月９日 火曜日 午前８時１７分
87
Map Menu
Guidance Menu
Navigation
Guidance Menu
H MAP MENU (on map)
Guidance Menu
Display the guidance points and freeway exits for your route, and set the display
mode for the map and guidance screens.
Select an item.
The following items are available:
• Directions: Displays a list of the guidance points.
2 Directions P. 88
• Guidance Mode: Selects the guidance display mode.
2 Guidance Mode P. 90
CR‑ZKA‑31SZT820.book87ページ２０１２年１０月９日 火曜日 午前８時１７分
88
Map Menu
Guidance Menu
Navigation
H MAP MENU (on map)
Guidance Menu
Directions
Display a list of the guidance points on your route for your confirmation.
Select R or U to scroll through the
list.
Press the MAP/GUIDE button to
return to the map screen.
■ Directions
1 Directions
Guidance points with exit information are
indicated by a (freeway exit information)
icon. Select Exit Information to display the exit
information.
2 Freeway Exit Information P. 89
The route guidance information is automatically
deleted when you reach your destination.
CR‑ZKA‑31SZT820.book88ページ２０１２年１０月９日 火曜日 午前８時１７分
90
Map Menu
Guidance Menu
Navigation
H MAP MENU (on map)
Guidance Menu
Guidance Mode
Select the display mode during route guidance: single-screen mode (default) or split-
screen mode.
Select an option.
The following options are available:
• Single Screen: Displays the map and guidance screens on separate screens.
■ Guidance Mode
1 Guidance Mode
The guidance mode can also be selected from
the System Setup menu.
2 Routing & Guidance P. 39
Map screen
Press the
MAP/GUIDE
button
Guidance screen
Press the
MAP/GUIDE
button
Press the
MAP/GUIDE
button
Directions list screen
CR‑ZKA‑31SZT820.book90ページ２０１２年１０月９日 火曜日 午前８時１７分
91
Map Menu
Guidance Menu
Navigation
• Split Screen: Displays the map and guidance information simultaneously on the
map screen.
1 Guidance Mode
Next guidance point
The next guidance point (the pop-up window) is
displayed on the map screen as you approach a
guidance point in the single-screen mode.
Next guidance point
Press the
MAP/GUIDE
button
Press the
MAP/GUIDE
button
Guidance direction list
Press the
MAP/GUIDE
button
Directions list screen
CR‑ZKA‑31SZT820.book91ページ２０１２年１０月９日 火曜日 午前８時１７分
92
Map Menu
Showing Icons on the Map
Navigation
Showing Icons on the Map
H MAP MENU (on map)
Show icon on Map
The icon bar along the bottom of the screen allows you to select the icons that are
displayed on the map.
Select an icon in the icon bar.
Selecting toggles the icon display
on or off.
Repeat the procedure as necessary.
The following options are available:
• Icon check boxes: Displays or hides the traffic and landmark icons.
2 Map Screen Legend P. 7
2 FM Traffic P. 99
• ALL OFF: Hides all icons.
• Icon Options: Fine-tunes the icon display.
2 Fine-tuning the Icons P. 93
1 Showing Icons on the Map
You can display or hide the icons using voice
commands on the map screen (e.g., say d
“Display hospital”).
2 Map Display Commands P. 194
CR‑ZKA‑31SZT820.book92ページ２０１２年１０月９日 火曜日 午前８時１７分
93
Map Menu
Showing Icons on the Map
Navigation
H MAP MENU (on map)
Show icon on Map
Icon Options
Icons in some categories can be fine-tuned to display or hide.
1. Select an icon category from the list
(e.g., Other Icons).
2. Select the icons to display on the
map.
Selecting toggles the icon
display on or off.
Repeat the procedure as
necessary.
3. Select OK.
■ Fine-tuning the Icons
1 Fine-tuning the Icons
To display the “Other Icons,” be sure to turn on
OTHER ICON in the icon bar.
CR‑ZKA‑31SZT820.book93ページ２０１２年１０月９日 火曜日 午前８時１７分
94
Map Menu
Map Legend
Navigation
Map Legend
H MAP MENU (on map)
Map Legend
See an overview of the map lines, areas, routes, traffic information, and navigation
icons.
Select an item.
The system displays the map
legend.
1 Map Legend
A visual guide helps you see the map legend.
2 Map Screen Legend P. 7
2 FM Traffic P. 99
CR‑ZKA‑31SZT820.book94ページ２０１２年１０月９日 火曜日 午前８時１７分
95
Map Menu
Map Legend
Navigation
The functions that are available from the map screen depend on the map scale.
■ Map Scale and Functions
Function page
Map Scale (top: mile, bottom: metric)
1/20 1/8 1/4 1/2 1 2 5 15 50 150 350 1000
80 200 400 800 1.6 3 8 24 80 240 560 1600
Icon display
Landmark icon 7 ✔ ✔
Exit info. 7 ✔ ✔ ✔
One-way traffic 7 ✔
Waypoint
“flag”
8 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
Traffic incident 7 ✔ ✔ ✔ ✔ ✔ ✔ ✔
Map orientation
Heading-up 97 ✔ ✔ ✔ ✔ ✔
North-up 97 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
Others
Off-road
tracking dots
83 ✔ ✔ ✔ ✔
Unverified road 7 ✔ ✔ ✔ ✔ ✔ ✔
Map features 7 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔
Avoid areas 43 ✔ ✔ ✔
Traffic speed 7 ✔ ✔ ✔ ✔ ✔ ✔ ✔
1 Map Scale & Functions
You can change the map scale using voice
commands on the map screen (e.g., say d
“Display 2 mile scale”).
2 Map Scale Commands P. 195
You can change between miles or kilometers.
2 Basic Settings P. 23
CR‑ZKA‑31SZT820.book95ページ２０１２年１０月９日 火曜日 午前８時１７分
96
Map Menu
Map Legend
Navigation
Display or hide all icons on the map screen, with the exception of Honda/Acura
Dealer icons which are always shown.
■ Landmark icon
■ Map Icons and Functions
Type
Icon display
control
Icon
selectable
Icon
searchable
Honda/Acura dealer Always on Yes Yes
Hospital Yes Yes Yes
School Yes Yes Yes
ATM Yes Yes Yes
Gas station Yes Yes Yes
Restaurants Yes Yes Yes
Post office Yes Yes Yes
Grocery store Yes Yes Yes
Hotel/Lodging Yes Yes Yes
Police station No icon No Yes
Shopping, Tourist attraction, Bank No icon No Yes
Parking garage Yes Yes Yes
Parking lot Yes Yes Yes
Freeway exit info. Yes Yes No
1 Map Icons & Functions
You can display or hide the icons using voice
commands on the map screen (e.g., say d
“Display hospital”).
2 Map Display Commands P. 194
Some icons, like police stations, are not shown,
but you can still locate the nearest one with the
Find Nearest voice command (e.g., say d “Find
nearest police station”).
2 Find Place Commands P. 195
Icon display control
Icons that can be displayed or hidden.
Icon selectable
Icons that can be selected as a destination using
the joystick.
Icon searchable
Icons that can be searched using the d Find
Nearest voice command.
CR‑ZKA‑31SZT820.book96ページ２０１２年１０月９日 火曜日 午前８時１７分
97
Map Menu
Map Legend
Navigation
■ Traffic icon
Select the map orientation icon to change the map orientation.
Type
Icon display
control
Icon
selectable
Icon
searchable
Traffic speed Yes No No
Traffic incident Yes No Yes
■ Map Orientation
1 Traffic Incident
When you use the joystick to position the cursor
(round red circle) over the traffic incident icon,
you can view the summary of the incident.
When you press the ENTER button to select the
traffic incident icon, you can view a pop-up
message describing the incident in detail.
1 Map Orientation
d “Display Heading-up” (from map screen), d
“Display North-up” (from map screen)
The red arrow in the symbol always points North.
On scales greater than 1 mile, North-up mode is
always used.
Map orientation icon
North-up: Displays the map with
North always pointing up.
Map orientation icon
Heading-up: Displays the map
so that the direction you are
traveling is always pointing up.
Select
Select
CR‑ZKA‑31SZT820.book97ページ２０１２年１０月９日 火曜日 午前８時１７分
98
Map Menu
Map Legend
Navigation
Display and save your current location for future use as a destination. The address,
latitude, longitude, and elevation of your current location are displayed.
■ To save your current location in the address book:
1. Select the vehicle icon on the map.
2. Select Save.
3. Edit the name, phone number, and
category.
2 Address Book P. 30
4. Select OK.
■ Current Location
1 Current Location
d “Display Current Location” (on map screen)
You can also save the current location by saying
d “Register the Current Location”.
If you have PIN-protected your address book,
enter your PIN when prompted. Select OK. PINs
are optional.
2 PIN Numbers P. 36
The elevation is not displayed if the system is
receiving insufficient GPS information. When
elevation is displayed, it may differ with roadside
elevation signs by ±100 feet or more.
Saving your current location does not change or
cancel your current route.
CR‑ZKA‑31SZT820.book98ページ２０１２年１０月９日 火曜日 午前８時１７分
99
Map Menu
FM Traffic
Navigation
FM Traffic
H MAP MENU (on map)
Traffic Incidents
View and avoid specific incidents and/or congestion on your route:
1. Select On Route.
2. Select an incident from the list.
The system displays the map
screen and the incident location.
3. Select Traffic Detail.
1 FM Traffic
You must be in or near a traffic-enabled city to
receive coverage for that area. FM Traffic is
available in the lower 48 states and Hawaii.
Automatic traffic rerouting may not provide a
detour route depending on circumstances.
d “Display traffic incidents”, d “Display traffic
list”
You can also display the traffic incidents from the
INFO screen.
You can display traffic incidents and related
information on the map screen using voice
commands.
2 Map Display Commands P. 194
Continued
CR‑ZKA‑31SZT820.book99ページ２０１２年１０月９日 火曜日 午前８時１７分
100
Map Menu
FM Traffic
Navigation
4. Select Avoid.
Repeat step 2 to 4 as necessary.
5. Select Reroute.
The system recalculates a detour
route that avoids the traffic
incidents.
1 FM Traffic
You can choose to avoid up to 10 traffic
incidents. It is not always possible for the system
to calculate a route that avoids all traffic
incidents or specific traffic incidents you select.
The “On Route” tab on the Traffic List screen is
only available during route guidance.
You cannot select an incident to avoid from the
“All” tab.
You can also detour around a traffic incident
manually if you encounter an unexpected
obstacle.
2 Taking a Detour P. 102
CR‑ZKA‑31SZT820.book100ページ２０１２年１０月９日 火曜日 午前８時１７分
101
Navigation
Changing Your Route
H DEST button (when en route)
This section describes how to alter your route, add an interim “waypoint” (pit stop),
choose a different destination, cancel your current destination, and continue your
trip after stopping.
Select an item.
The following items are available:
• Cancel Route: Cancels the route guidance.
2 Canceling the Route P. 102
• Detour: Calculates a detour route.
2 Taking a Detour P. 102
• Avoid Streets: Avoids streets along your route.
2 Avoiding Streets P. 102
• Change Route Pref.: Changes the route preferences (calculating method).
2 Changing the Route Preference P. 78
• Waypoint: Sets waypoints along your route.
2 Adding Waypoints from the Route Menu P. 104
• My Destination: Shows a list of waypoints. You can delete waypoints or edit the
order of them.
2 Editing My Destination P. 107
1 Changing Your Route
d “Display Menu”, d “Display Navigation”
(when en route)
If you press the DEST button when not en route,
the Destination Menu screen is displayed.
2 Entering a Destination P. 56
CR‑ZKA‑31SZT820.book101ページ２０１２年１０月９日 火曜日 午前８時１７分
102
Changing Your Route
Canceling the Route
Navigation
Canceling the Route
H DEST button (when en route)
Cancel Route
Cancel the route guidance and remove the destination and all waypoints from the
destination list. The system then returns to the map screen.
Taking a Detour
H DEST button (when en route)
Detour
Calculate a detour route manually. The system attempts to calculate a new route by
avoiding the next 5 miles (while on a freeway) or 1 mile (while on a surface street).
Avoiding Streets
H DEST button (when en route)
Avoid Streets
Select a street or streets along your route to avoid.
1. Select the street you want to avoid.
Repeat the procedure to avoid
other streets.
Streets to be avoided are
indicated with a trash icon.
1 Canceling the Route
You can also cancel your route from the Map
Menu.
2 Map Menu P. 85
1 Taking a Detour
The detour option is convenient if you encounter
an unexpected obstacle such as a road closure or
extremely heavy traffic congestion.
1 Avoiding Streets
Avoiding certain streets is convenient if you
know of road construction, road closures, or
excessive traffic along the route.
You cannot choose specific streets you want to
use, only those to avoid. However, you can select
intersections or waypoints (places/landmarks)
that the system will use in your route.
2 Adding Waypoints P. 103
You can store up to 10 streets to avoid. You
cannot avoid your current street or the streets of
your waypoint(s) or destination (system beeps if
selected).
CR‑ZKA‑31SZT820.book102ページ２０１２年１０月９日 火曜日 午前８時１７分
103
Changing Your Route
Adding Waypoints
Navigation
2. Select OK.
The system calculates a new
route.
Adding Waypoints
Add up to four waypoints (pit stops) along the route to your destination.
Waypoints are displayed on the map
screen as small, numbered red flags.
The route follows the waypoints in
the order they are listed in the
destination list.
1 Adding Waypoints
Waypoints allow you to stop for gas or food, for
example, and then continue on to your
destination.
Press the MAP/GUIDE button to return to the
map screen without adding a waypoint at any
time.
The search corridor used for adding waypoints
can be adjusted.
2 Edit Waypoint Search Area P. 45
You can delete waypoints or edit the order of
waypoints in the destination list.
2 Editing My Destination P. 107
CR‑ZKA‑31SZT820.book103ページ２０１２年１０月９日 火曜日 午前８時１７分
104
Changing Your Route
Adding Waypoints
Navigation
H DEST button (when en route)
Waypoint
1. Select a search method to add a
waypoint.
The following items are available:
• Places Along the Route: Searches within a “corridor” on either side of the
route.
• Places Around the Destination: Searches in a spiral pattern around the
destination.
• Places Around the Waypoint: Searches in a spiral pattern around the location
you select.
2. Select the location when you select
Places Around the Waypoint.
■ Adding Waypoints from the Route Menu
1 Adding Waypoints
Search method
The search corridor used for adding waypoints
can be adjusted.
2 Edit Waypoint Search Area P. 45
“Search around” method
“Search along” method
CR‑ZKA‑31SZT820.book104ページ２０１２年１０月９日 火曜日 午前８時１７分
105
Changing Your Route
Adding Waypoints
Navigation
3. Select a waypoint category (e.g.,
Auto Service).
4. Select a waypoint subcategory
(e.g., GAS STATION).
5. Select a place.
The waypoint is added to the
destination list.
The route is automatically
recalculated and displayed on
the map screen.
CR‑ZKA‑31SZT820.book105ページ２０１２年１０月９日 火曜日 午前８時１７分
106
Changing Your Route
Adding Waypoints
Navigation
1. Select a new address or location.
2. Select ADD TO My Dest.
3. Select R or U to select a location
in the destination list. Select OK.
4. Select OK.
The route is automatically
recalculated and displayed on
the map screen.
■ Adding Waypoints from the Calculate Route Screen
CR‑ZKA‑31SZT820.book106ページ２０１２年１０月９日 火曜日 午前８時１７分
107
Changing Your Route
Editing My Destination
Navigation
Editing My Destination
H DEST button (when en route)
My Destination
Delete or edit the order of waypoints.
1. Select Edit.
Select Map to display the
destination and waypoints on
the map screen.
2. Select an item.
3. Select OK.
The route is automatically
recalculated and displayed on
the map screen.
The following items are available:
• Delete: Select a list item to delete.
• Edit Order: Select a list item to move, select R or U to select a new location.
CR‑ZKA‑31SZT820.book107ページ２０１２年１０月９日 火曜日 午前８時１７分
108
Navigation
Changing Your Destination
There are several methods you can use to change the route destination.
Find Nearest Place
H MAP MENU (on map)
Search for the nearest place/landmark on the map screen and set it as your
destination.
1. Select Find Nearest….
2. Select a category type.
3. Select a subcategory.
4. Select a place.
5. Select Set as Dest.
6. Select an item to set the place as a
destination or add to the
destination list.
The system calculates the route.
2 Calculating the Route P. 77
1 Find Nearest Place
d “Find Nearest…” (on map screen)
The Find Nearest voice command is the fastest
method of specifying a place/landmark as your
destination. Many kinds of places can be found.
2 Find Place Commands P. 195
CR‑ZKA‑31SZT820.book108ページ２０１２年１０月９日 火曜日 午前８時１７分
109
Changing Your Destination
Selecting a Destination on the Map
Navigation
Selecting a Destination on the Map
Select a new destination when en route by selecting a location on the map.
1. Scroll the map to position the
cursor over your desired
destination, adjusting the map
scale as necessary. Press the ENTER
button.
If the address displayed is not
the desired location, press the
CANCEL/BACK button and
repeat the procedure.
2. Press the ENTER button again.
3. Select a place.
4. Select Set as Dest.
2 Calculating the Route P. 77
1 Selecting a Destination on the Map
If there is more than one icon or street under the
map cursor, you are prompted to select the item
from a list.
• Select an item.
• If you select Map Icon, select a place.
Continued
CR‑ZKA‑31SZT820.book109ページ２０１２年１０月９日 火曜日 午前８時１７分
110
Changing Your Destination
Entering a New Destination
Navigation
5. Select an option.
The route is automatically
recalculated and displayed on
the map screen.
The following options are available:
• Set as New Destination: Sets the location as your new destination.
• Add to My Destination: Sets the location as a new waypoint.
Entering a New Destination
H DEST button (when en route)
DEST Menu 1 or DEST Menu 2
Enter a new destination using the Destination Menu screen even when you are en
route.
1. Select a method to enter a new
destination.
2 Entering a Destination P. 56
After entering a new
destination, the address is
displayed on the Calculate
Route screen.
2. Select Set as Dest.
1 Entering a New Destination
d “Display Menu”, d “Display Navigation”
CR‑ZKA‑31SZT820.book110ページ２０１２年１０月９日 火曜日 午前８時１７分
111
Changing Your Destination
Entering a New Destination
Navigation
3. Select an option.
The route is automatically
recalculated and displayed on
the map screen.
The following options are available:
• Set as New Destination: Sets the location as your new destination.
• Add to My Destination: Sets the location as a new waypoint.
CR‑ZKA‑31SZT820.book111ページ２０１２年１０月９日 火曜日 午前８時１７分
112
Navigation
Resuming Your Trip
Stop your vehicle en route (e.g., to rest, stop for gas, etc.), and then continue on
your route.
If you did not complete your route, the Continue Trip screen is displayed when you
restart your vehicle.
Select OK.
You can continue on the same
route.
• Route Pref.: Changes the route preferences (calculating method).
2 Changing the Route Preference P. 78
• View Routes: Displays three different routes.
2 Viewing the Routes P. 78
• Destination Map: Display a map of the destination.
2 Calculating the Route on the Destination Map P. 79
1 Resuming Your Trip
The Continue Trip screen has the same options
as when you calculate a route.
2 Calculating the Route P. 77
To cancel your destination, press the CANCEL/
BACK button.
Add to Address Book
You can add the destination address to the
address book.
2 Adding an Address Book Entry P. 31
Call
You can place a phone call to the destination
phone number.
2 Bluetooth® HandsFreeLink® P. 144
CR‑ZKA‑31SZT820.book112ページ２０１２年１０月９日 火曜日 午前８時１７分
113
Audio
This section describes how to operate the audio system. You can play
music from a wide array of media sources, and control the audio system
using the audio buttons, the touch screen, or voice control.
Audio System ........................................ 114
About Your Audio System.................... 114
Auxiliary Input Jack .............................. 114
System Theft Protection ....................... 115
Playing FM/AM Radio........................... 116
Selecting FM/AM Mode........................ 116
Audio Screen Control........................... 117
Audio Menu ........................................ 118
Radio Data System (RDS)...................... 119
Playing a Disc ........................................ 121
Selecting Disc Mode............................. 121
Audio Screen Control........................... 122
Playing MP3/WMA/AAC Discs .............. 123
Recommended Discs ............................ 124
Playing an iPod® ...................................125
Selecting iPod® Mode ..........................126
Audio Screen Control............................127
Searching for Music ..............................128
Playing Pandora® ..................................129
Selecting Pandora® Mode ....................129
Audio Screen Control............................130
Quick Mix .............................................131
Playing a USB Flash Drive .....................132
Selecting USB Mode..............................133
Audio Screen Control............................134
Playing Tracks in Folders........................135
Playing Bluetooth® Audio ................... 136
Selecting Bluetooth® Audio Mode....... 136
Switching to HFL Mode ........................ 137
Audio Screen Control........................... 138
Adjusting the Sound............................. 139
Audio Remote Controls ........................ 140
Steering Wheel Controls ...................... 140
CR‑ZKA‑31SZT820.book113ページ２０１２年１０月９日 火曜日 午前８時１７分
114
Audio
Audio System
About Your Audio System
The audio system features FM/AM radio. It can also play audio discs, WMA/MP3/
AAC tracks, iPods®, USB flash drives, and Bluetooth® devices.
The audio system is operable from the buttons and switches on the panel, or the
remote controls on the steering wheel.
2 Audio Remote Controls P. 140
2 Audio System P. 6
Auxiliary Input Jack
Use the jack in the front console compartment to connect standard audio devices.
1. Open the AUX cover.
2. Connect a standard audio device to
the input jack using a 1/8 inch/3.5
mm stereo miniplug.
The audio system automatically
switches to the AUX mode.
1 About Your Audio System
Video CDs, DVDs, and 3-inch/8-cm mini discs are
not supported.
Do not leave the iPod® or USB flash drive in the
vehicle. Direct sunlight and high temperatures
may damage it.
iPod® and iPhone® are registered trademarks
owned by Apple Inc.
You can operate the audio system by voice
commands.
2 Audio Commands P. 197
Remote Control
iPod®
iPhone®
USB Flash
Memory
1 Auxiliary Input Jack
To switch the mode, press any of the other audio
mode buttons. You can return to the AUX mode
by pressing the AUX button.
CR‑ZKA‑31SZT820.book114ページ２０１２年１０月９日 火曜日 午前８時１７分
115
XX
Audio System
X
System Theft Protection
Audio
System Theft Protection
The system is disabled when it is disconnected from the power source, such as when
the battery is disconnected or goes dead.
■ Reactivating the system
1. Turn the ignition switch to ON (II), and turn on the system.
X
If you turn the ignition switch to ACCESSORY (I), you will be requested to enter
the security code. See step 2.
2. Enter the security code. If you do not enter the code correctly after 10 tries, leave
the system for one hour before trying again, or visit a dealer to have the system
reset.
1 System Theft Protection
Find the audio system’s security code and serial
number label in your Owner’s Manual kit.
Do not store the label in your vehicle. If you lose
the label, you must first retrieve the serial
number, and then obtain the code from a dealer.
U.S. Only
You can register the security code at Honda
Owners (owners.honda.com.). To find
information on how to retrieve the serial number
and obtain the code, visit radio-
navicode.honda.com.
2 Entering the Security Code P. 182
CR-Z_KA-31SZT830_03.fm Page 115 Thursday, April 10, 2014 5:12 PM
116
Audio
Playing FM/AM Radio
Selecting FM/AM Mode
1. Press the FM/AM button.
Press the FM/AM button again,
if necessary, to select the
frequency band (FM1, FM2,
AM).
The band and frequency are
displayed.
2. Select AUDIO/STREET until
AUDIO is highlighted in blue.
The preset keys are displayed at
the bottom of the screen.
3. Select the preset key.
You can also select a station
using the SEEK/SKIP button.
1 Playing FM/AM Radio
d “Display audio screen”
You can control the radio using voice
commands.
2 Radio Commands P. 197
A visual guide helps you operate the audio
system.
2 System Controls P. 4
2 Basic Operation P. 6
The ST indicator comes on the display for stereo
FM broadcasts. Stereo reproduction in AM is not
available.
The radio can receive the complete AM and FM
bands:
AM band: 530 to 1710 kHz
FM band: 87.7 to 107.9 MHz
You can store six AM stations and 12 FM stations
in the preset buttons. FM1 and FM2 let you store
six stations each.
Preset keys
CR‑ZKA‑31SZT820.book116ページ２０１２年１０月９日 火曜日 午前８時１７分
117
Playing FM/AM Radio
Audio Screen Control
Audio
Audio Screen Control
H AUDIO button (in FM/AM mode)
Control the audio system through the navigation screen.
1. Select a frequency band (AM,
FM1, or FM2).
2. Select a preset station.
Touch and hold a preset key
until a beep sounds to store the
current station in the key.
The following items are available:
• TUNE: Tunes the radio to the frequency you select. Select b or n to select a
frequency.
• SCAN: Scans for stations with a strong signal in the current band and plays a 10-
second sample. Select Stop to stop scanning and play the current selection.
• AUTO SELECT: Scans and automatically stores up to six AM stations and 12 FM
stations with a strong signal in the preset buttons.
• AUDIO MENU: Sets the RDS options and sound preferences.
• SOURCE: Changes the source mode.
• Open/Close icon: Displays/hides the detailed information.
1 Audio Screen Control
The A.SEL indicator comes on the display when
AUTO SELECT is on. If you do not like the
stations Auto Select has stored, you can change
the frequencies stored in the preset buttons
manually.
Stereo indicatorFrequency band
Preset stations
Open/Close icon
CR‑ZKA‑31SZT820.book117ページ２０１２年１０月９日 火曜日 午前８時１７分
118
Playing FM/AM Radio
Audio Menu
Audio
Audio Menu
H AUDIO button (in FM/AM mode)
AUDIO MENU
Select an item.
The following items are available:
• RDS search: Searches for programs by RDS category.
2 Searching for Programs by RDS Category P. 119
• Radio Text: Displays the text information broadcast by the current RDS station.
2 Radio Text Display P. 120
• RDS INFO: Sets whether to display the RDS Information on the screen.
2 RDS Info Display P. 119
• Sound: Displays the sound preferences screen.
2 Adjusting the Sound P. 139
CR‑ZKA‑31SZT820.book118ページ２０１２年１０月９日 火曜日 午前８時１７分
119
Playing FM/AM Radio
Radio Data System (RDS)
Audio
Radio Data System (RDS)
Provides text data information related to your selected RDS-capable FM station.
When RDS INFO is set to ON, the name of the FM station is displayed. When set to
OFF, the frequency of the station is displayed.
H AUDIO button (in FM/AM mode)
AUDIO MENU
RDS search
Search for FM stations with a strong signal that broadcast the selected RDS category
information.
1. Select a search method (Seek up,
Seek down, Scan).
2. Select a category.
Scanning for stations in that
category begins. When an RDS
station is found, it begins to
play.
If there are no RDS-capable
stations in the area, “NOTHING”
briefly appears on the display.
■ RDS Info Display
■ Searching for Programs by RDS Category
CR‑ZKA‑31SZT820.book119ページ２０１２年１０月９日 火曜日 午前８時１７分
120
Playing FM/AM Radio
Radio Data System (RDS)
Audio
H AUDIO button (in FM/AM mode)
AUDIO MENU
Radio Text
Display the radio text information of the selected RDS station.
■ Radio Text Display
1 Radio Text Display
The RDS indicator comes on the display when the
selected RDS station is broadcasting text data.
CR‑ZKA‑31SZT820.book120ページ２０１２年１０月９日 火曜日 午前８時１７分
121
Audio
Playing a Disc
Selecting Disc Mode
1. Press the CD/AUX button.
2. Insert a disc into the disc slot.
The disc automatically begins
playing.
3. Select AUDIO/STREET until
AUDIO is highlighted in blue.
4. Select c or x to select a track.
You can also select a track using
the SEEK/SKIP button.
The track number and elapsed
time are displayed on the
display. Text information stored
on MP3/WMA/AAC discs is also
displayed.
1 Playing a Disc
d “Display audio screen”
You can control the disc using voice commands.
2 Disc Commands P. 198
A visual guide helps you operate the audio
system.
2 System Controls P. 4
2 Basic Operation P. 6
In some cases, the name of the artist, album, or
track may not appear correctly.
Do not use discs with adhesive labels. The label
can cause the disc to jam in the unit.
WMA tracks protected by digital rights
management (DRM) cannot be played. The
audio system displays Unplayable File, then skips
to the next track.
If there is a problem, you may see an error
message on the display.
2 Error Messages P. 177
If you eject the disc but do not remove it from
the slot, the system reloads the disc automatically
after several seconds.
Audio control
CR‑ZKA‑31SZT820.book121ページ２０１２年１０月９日 火曜日 午前８時１７分
122
Playing a Disc
Audio Screen Control
Audio
Audio Screen Control
H AUDIO button (in DISC mode)
Control the audio system through the navigation screen.
Select a track.
Select the Folder tab to display the
list of folders on MP3/WMA/AAC
discs having a folder structure.
2 Playing MP3/WMA/AAC Discs
P. 123
The following items are available, depending on the type of disc:
• FOLDER: Select b or n to select a folder on MP3/WMA/AAC discs having a
folder structure.
• SCAN:
S Scan Track: Scans all tracks on the disc (or in the selected folder) in the
order they were recorded (stored) and plays a 10-second sample. Select Stop to
stop scanning and play the current selection.
( Scan Folder: Scans the first track in each folder on the disc and plays a 10-
second sample. Select Stop to stop scanning and play the current selection.
• PLAY MODE:
" Random All: Plays all tracks on the current disc in random order.
# Random in Folder: Plays all tracks in the current folder in random order.
$ Repeat 1 Track: Repeats the current track.
% Repeat 1 Folder: Repeats all tracks in the current folder.
1 Repeat and Random Play
To stop repeat- or random-play, select the
current play mode button again.
Disc mode
Track list
Open/Close icon
CR‑ZKA‑31SZT820.book122ページ２０１２年１０月９日 火曜日 午前８時１７分
123
Playing a Disc
Playing MP3/WMA/AAC Discs
Audio
• SOUND: Displays the sound preferences screen.
2 Adjusting the Sound P. 139
• SOURCE: Changes the source mode.
• Open/Close icon: Displays/hides the detailed information.
Playing MP3/WMA/AAC Discs
H AUDIO button (in DISC mode)
Folder
Change the folder on MP3/WMA/AAC discs that have tracks stored in a folder
structure.
1. Select a folder.
The system displays the track
list.
2. Select a track.
The system begins playing the
selected track.
1 Playing MP3/WMA/AAC Discs
Folder List
• Any tracks not in a folder are automatically
added to a “ROOT” folder, which is displayed
at the top of the Folder List.
• If the root folder has additional folders in a
lower layer, they are listed on the screen.
Back to Current Track: Displays the current
track at the top of the list.
Touch to close the folder.
Touch to open the folder.
Folder list
CR‑ZKA‑31SZT820.book123ページ２０１２年１０月９日 火曜日 午前８時１７分
124
Playing a Disc
Recommended Discs
Audio
Recommended Discs
• Use only high-quality CD-R or CD-RW discs labeled for audio use.
• Use only CD-R or CD-RW discs on which the recordings are closed.
• Play only standard round-shaped discs.
■ Discs with MP3, WMA, or AAC Tracks
• Some software files may not allow for audio play or text data display.
• Some versions of MP3, WMA, or AAC formats may be unsupported. If an
unsupported track is found, the audio unit displays Unsupported, and then skips
to the next track.
1 Recommended Discs
A Dual-disc cannot play on this audio unit. If
recorded under certain conditions, a CD-R or CD-
RW may not play either.
The disc packages or jackets should have one of these symbols.
CR‑ZKA‑31SZT820.book124ページ２０１２年１０月９日 火曜日 午前８時１７分
126
Playing an iPod®
Selecting iPod® Mode
Audio
Selecting iPod® Mode
1. Connect the iPod® to the USB
adapter cable in the center pocket.
2. Press the CD/AUX button until you
get to iPod® mode.
3. Select AUDIO/STREET until
AUDIO is highlighted in blue.
4. Select c or x to select a track.
You can also select a track using
the SEEK/SKIP button.
The current track number and
total number of tracks are
displayed.
1 Playing an iPod®
d “Display audio screen”
You can control the iPod® using voice
commands.
2 iPod® Commands P. 198
A visual guide helps you operate the audio
system.
2 System Controls P. 4
2 Basic Operation P. 6
In some cases, the name of the artist, album, or
track may not appear correctly.
Available operating functions vary on models or
versions. Some functions may not be available on
the vehicle’s audio system.
If there is a problem, you may see an error
message on the display.
2 Error Messages P. 177
Audio control
CR‑ZKA‑31SZT820.book126ページ２０１２年１０月９日 火曜日 午前８時１７分
127
Playing an iPod®
Audio Screen Control
Audio
Audio Screen Control
H AUDIO button (in iPod® mode)
Control the audio screen through the navigation system.
Select a track.
Select the menu tab to change
songs in the track list.
2 Searching for Music P. 128
The following items are available:
• PLAY MODE
" Shuffle All: Plays all tracks in the track list in random order.
& Shuffle Album: Plays all tracks in the track list in random order by albums.
Each song in an album is played in the right order and only the order of albums is
randomized.
$ Repeat 1 Track: Repeats the current track.
• SOUND: Displays the sound preferences screen.
2 Adjusting the Sound P. 139
• SOURCE: Changes the source mode.
• Open/Close icon: Displays/hides the detailed information.
1 Repeat and Shuffle Play
To stop repeat- or shuffle-play, select the current
play mode button again.
iPod® mode
Track list
Open/Close icon
CR‑ZKA‑31SZT820.book127ページ２０１２年１０月９日 火曜日 午前８時１７分
128
Playing an iPod®
Searching for Music
Audio
Searching for Music
H AUDIO button (in iPod® mode)
Search for music using the iPod® menu.
1. Select the menu tab.
2. Select a search category (e.g.,
Album).
3. Select an item.
The selection begins playing.
1 Searching for Music
The order of the track list displayed if you select
“All” on the iPod® menu varies depending on
the iPod® model and software.
Back to Current Track: Displays the current
track at the top of the list.
iPod® menu tab
CR‑ZKA‑31SZT820.book128ページ２０１２年１０月９日 火曜日 午前８時１７分
129
Audio
Playing Pandora®
Pandora® is a personalized Internet radio service that selects music based on an
artist, song, or genre a user enters, and streams what is likely to be of interest.
Selecting Pandora® Mode
1. Activate Pandora® on your
iPhone®.
2. Connect the iPhone® to the USB
adapter cable in the center pocket.
2 Connecting an iPod® P. 125
3. Press the CD/AUX button until you
get to Pandora® mode.
4. Select AUDIO/STREET until
AUDIO is highlighted in blue.
The current station name, artist
name, rating, and track artist
name are displayed.
1 Playing Pandora®
d “Display audio screen” (when in Pandora®
mode)
You can control Pandora® using voice
commands.
2 Pandora® Commands P. 198
A visual guide helps you operate the audio
system.
2 System Controls P. 4
2 Basic Operation P. 6
To use this service in your vehicle, the Pandora®
app must first be installed on your iPhone®. Visit
www.pandora.com for more information.
Pandora® Mode and Audio Screen Control is
only available for iPhone®. For other phones,
Pandora® can be played through Bluetooth®
Audio.
2 Playing Bluetooth® Audio P. 136
If there is a problem, you may see an error
message on the display.
2 Error Messages P. 177
If Pandora® is not selected from your phone,
iPod® music is played.
Press the Home button on your iPhone to switch
from Pandora® to iPod®. To play Pandora®
again, you must reactivate it from your phone.
Audio control
CR‑ZKA‑31SZT820.book129ページ２０１２年１０月９日 火曜日 午前８時１７分
130
Playing Pandora®
Audio Screen Control
Audio
Audio Screen Control
H AUDIO button (in Pandora® mode)
Control the audio screen through the navigation system.
Select a station by selecting B or N
at the bottom of the screen.
Select x to skip the current song.
The following items are available:
• w Dislike: Dislikes the current song and skips to the next song. Pandora® will
avoid playing songs similar to the one disliked.
• e Like: Likes the current song. Pandora® will play songs similar to the one liked.
• STATION: Select B or N to select a station.
• BOOKMARK: Bookmarks the current song or artist. Select BOOKMARK This
Song or BOOKMARK This Artist.
• STATION LIST: Displays the list of all your stored stations. Select a station from
the list to play. You can also select QuickMix to play all stations randomly.
2 Quick Mix P. 131
1 Audio Screen Control
The following functions are not available on this
navigation system:
• Buy from iTunes
• Email the current Station
• Check Song Detail
• Create Station
You can skip the song or select w only a
predetermined number of times in an hour. If
exceeded, an error message is displayed and the
operation is not performed.
For details, please visit and check
www.pandora.com.
You can only check bookmark information from
your iPhone®.
If you cannot operate Pandora® through the
audio system, it may be streaming through
Bluetooth® Audio. Make sure Pandora® mode
on your audio system is selected.
Pandora® mode
Audio control
CR‑ZKA‑31SZT820.book130ページ２０１２年１０月９日 火曜日 午前８時１７分
131
Playing Pandora®
Quick Mix
Audio
Quick Mix
H AUDIO button (in Pandora® mode)
STATION LIST
Select QuickMix.
Starts to randomly play tracks from
all your stored stations in the list.
To cancel the QuickMix mode,
select another station.
CR‑ZKA‑31SZT820.book131ページ２０１２年１０月９日 火曜日 午前８時１７分
132
Audio
Playing a USB Flash Drive
1. Unclip the USB connector in the center pocket and loosen the adapter cable.
2. Install the USB flash drive to the USB connector.
Use a recommended USB flash drive of 256 MB or higher.
Some digital audio players may not be compatible.
Some USB flash drives (e.g., a device with security lockout) may not work.
Some software files may not allow for audio play or text data display.
Some versions of MP3, WMA, or AAC formats may be unsupported.
■ Connecting a USB Flash Drive
1 Connecting a USB Flash Drive
• Do not use an extension cable with the USB
adapter cable.
• Do not connect the USB flash drive using a
hub.
• Do not use a device such as a card reader or
hard disk drive, as the device or your tracks
may be damaged.
• We recommend backing up your data before
using the device in your vehicle.
■ USB Flash Drives
CR‑ZKA‑31SZT820.book132ページ２０１２年１０月９日 火曜日 午前８時１７分
133
Playing a USB Flash Drive
Selecting USB Mode
Audio
Selecting USB Mode
1. Connect the USB flash drive to the
USB adapter cable in the center
pocket.
2. Press the CD/AUX button until you
get to USB mode.
3. Select AUDIO/STREET until
AUDIO is highlighted in blue.
4. Select c or x to select a track.
You can also select a track using
the SEEK/SKIP button.
The current track number and
total number of tracks are
displayed.
1 Playing a USB Flash Drive
d “Display audio screen”
You can control the USB flash drive using voice
commands.
2 USB Commands P. 198
A visual guide helps you operate the audio
system.
2 System Controls P. 4
2 Basic Operation P. 6
In some cases, the name of the artist, album, or
track may not appear correctly.
Tracks on the USB flash drive are played in their
stored order. This order may be different from
the order displayed on your PC or device.
The audio system displays Unplayable File, and
then skips to the next track when the following
tracks are played:
• Tracks in WMA format protected by digital
rights management (DRM)
• Tracks in unsupported format
If there is a problem, you may see an error
message on the display.
2 Error Messages P. 177
Audio control
CR‑ZKA‑31SZT820.book133ページ２０１２年１０月９日 火曜日 午前８時１７分
134
Playing a USB Flash Drive
Audio Screen Control
Audio
Audio Screen Control
H AUDIO button (in USB mode)
Control the audio screen through the navigation system.
Select a track.
Select the Folder tab to display the
folder list.
2 Playing Tracks in Folders P. 135
The following items are available:
• FOLDER: Select b or n to select a folder.
• SCAN:
S Scan Track: Scans all tracks in the current folder in the order they were
stored and plays a 10-second sample. Select Stop to stop scanning and play the
current selection.
( Scan Folder: Scans the first track in each folder on the USB flash drive and
plays a 10-second sample. Select Stop to stop scanning and play the current
selection.
USB mode
Track list
Open/Close icon
CR‑ZKA‑31SZT820.book134ページ２０１２年１０月９日 火曜日 午前８時１７分
135
Playing a USB Flash Drive
Playing Tracks in Folders
Audio
• PLAY MODE:
" Random All: Plays all tracks on the USB flash drive in random order.
# Random in Folder: Plays all tracks in the current folder in random order.
$ Repeat 1 Track: Repeats the current track.
% Repeat 1 Folder: Repeats all tracks in the current folder.
• SOUND: Displays the sound preferences screen.
2 Adjusting the Sound P. 139
• SOURCE: Changes the source mode.
• Open/Close icon: Displays/hides the detail information.
Playing Tracks in Folders
H AUDIO button (in USB mode)
Folder
Change the folder if the tracks are stored in a folder structure.
1. Select a folder.
The system displays the track
list.
2. Select a track.
The system begins playing the
selected track.
1 Repeat and Random Play
To stop repeat- or random-play, select the
current play mode button again.
1 Playing Tracks in Folders
Folder List
• Any music tracks not in a folder are
automatically added to a “ROOT” folder,
which is displayed at the top of the Folder List.
• If the root folder has additional folders in a
lower layer, they are listed on the screen.
Back to Current Track: Displays the current
track at the top of the list.
Touch to close the folder.
Touch to open the folder.
Folder list
CR‑ZKA‑31SZT820.book135ページ２０１２年１０月９日 火曜日 午前８時１７分
136
Audio
Playing Bluetooth® Audio
Your audio system allows you to listen to music tracks stored on your Bluetooth-
compatible phone.
This function is available when the phone is linked to the vehicle’s Bluetooth®
HandsFreeLink® (HFL) system.
2 Bluetooth® HandsFreeLink® P. 143
Selecting Bluetooth® Audio Mode
1. Make sure that your phone is on,
paired, and linked to HFL.
2 Pairing a Phone P. 146
2. Press the CD/AUX button until you
get to Bluetooth® Audio mode.
A Bluetooth® message and icon
are displayed on the display and
screen.
3. Select AUDIO/STREET until
AUDIO is highlighted in blue.
1 Playing Bluetooth® Audio
d “Display audio screen”
You can control the Bluetooth® Audio using
voice commands.
2 Bluetooth® Audio Commands P. 199
Not all Bluetooth-enabled phones with
streaming audio capabilities are compatible. To
check if your phone is compatible:
• U.S.: Visit automobiles.honda.com/
handsfreelink.
• Canada: Visit www.handsfreelink.ca.
• Call HandsFreeLink customer support at
(888) 528-7876.
In some states, it may be illegal to perform some
data device functions while driving.
In some cases, the name of the artist, album, or
track may not appear correctly.
Only one phone can be used with HFL at a time.
When there are more than two paired phones in
the vehicle, the first paired phone the system
finds is automatically linked.
CR‑ZKA‑31SZT820.book136ページ２０１２年１０月９日 火曜日 午前８時１７分
137
Playing Bluetooth® Audio
Switching to HFL Mode
Audio
4. Select c or x to select a track.
5. If necessary, follow the cell phone
operating instructions for playing
audio tracks.
Check the following if the phone is not recognized:
• Another HFL-compatible phone, which is not compatible for Bluetooth® Audio, is
already connected.
Switching to HFL Mode
1. If you receive a call when
Bluetooth® Audio is playing, press
the h (Pick-Up) button on the
steering wheel to answer the call.
2 Bluetooth® HandsFreeLink®
P. 144
2. Press the j (Hang-Up) button to
end the call, and Bluetooth® Audio
is resumed.
1 Playing Bluetooth® Audio
If more than one phone is paired to the HFL
system, there may be a delay before the system
begins to play.
A “NO CONNECT” message may be displayed if:
• The phone is not linked to HFL.
• The phone is not turned on.
• The phone is not in the vehicle.
• An incompatible phone is connected.
Audio control
h (Pick-Up) button
j (Hang-Up) button
CR‑ZKA‑31SZT820.book137ページ２０１２年１０月９日 火曜日 午前８時１７分
138
Playing Bluetooth® Audio
Audio Screen Control
Audio
Audio Screen Control
H AUDIO button (in BT mode)
Control the audio screen through the navigation system.
Select an item.
The following items are available:
• GROUP: Select b or n to select a playlist, album, genre, etc.
• SOUND: Displays the sound preferences screen.
2 Adjusting the Sound P. 139
• SOURCE: Changes the source mode.
1 Audio Screen Control
The display items vary on the connected device.
The following functions may not be available on
some devices:
• Pause function
• Group selection
Bluetooth® Audio mode
Audio control
CR‑ZKA‑31SZT820.book138ページ２０１２年１０月９日 火曜日 午前８時１７分
139
Audio
Adjusting the Sound
H AUDIO button (
AUDIO MENU )
SOUND
Adjust the sound bass, treble, fader, and balance. You can also adjust the strength
of the sound coming from the subwoofer speaker. In addition, you can set Speed-
sensitive Volume Compensation (SVC).
1. Select the tab to adjust the desired
sound mode.
2. Adjust the desired level.
1 Adjusting the Sound
Fader adjusts the front-to-back strength, while
balance adjusts the side-to-side strength. If the
fader adjustment is set to the maximum front
level, the subwoofer is turned off.
The SVC has four modes: Off, Low, Mid, and
High. SVC adjusts the volume level based on the
vehicle speed. The faster you go, the audio
volume increases. As you slow down, the audio
volume decreases. If you feel the sound is too
loud, choose Low, and vice versa.
CR‑ZKA‑31SZT820.book139ページ２０１２年１０月９日 火曜日 午前８時１７分
140
Audio
Audio Remote Controls
Steering Wheel Controls
Control basic audio system functions using the controls mounted on the steering
wheel.
Cycles through the audio modes as follows:
■ MODE Button
1 MODE Button
DISC mode appears only when a disc is loaded.
When in AUX mode, the following are operable
from the remote audio controls:
• iPod®/iPhone® USB flash drive connected to
the USB adapter cable
• Bluetooth® Audio (not all phones support this
function)
NB Channel button
MODE button
RU Volume button
FM2FM1 AM
DISCAUX
CR‑ZKA‑31SZT820.book140ページ２０１２年１０月９日 火曜日 午前８時１７分
141
Audio Remote Controls
Steering Wheel Controls
Audio
Adjusts the volume.
• Press the R (Volume) button to increase the volume.
• Press the U (Volume) button to decrease the volume.
FM/AM
• Press the N (Channel) button to select the next preset station (channel).
• Press the B (Channel) button to select the previous preset station (channel).
• Press and hold the N button to skip to the next station in the frequency.
DISC, iPod®, USB, or Bluetooth® Audio
• Press the N button to skip to the next track.
• Press the B button to skip to the beginning of the current track. Press the B
button again to go to the beginning of the previous track.
• Press and hold the B or N button to skip up or down a folder (DISC/USB).
Pandora®
• Press the N button to skip to the next song.
• Press and hold B or N button to select the upper or lower station.
■ RU (Volume) Button
■ NB (Channel) Button
CR‑ZKA‑31SZT820.book141ページ２０１２年１０月９日 火曜日 午前８時１７分
142
CR‑ZKA‑31SZT820.book142ページ２０１２年１０月９日 火曜日 午前８時１７分
143
Bluetooth® HandsFreeLink®
This section describes how to operate Bluetooth® HandsFreeLink®. You
can place and receive phone calls using your vehicle’s audio system
without handling your cell phone.
Bluetooth® HandsFreeLink® ............... 144
Pairing a Phone .................................... 146
Setting Up Speed Dialing...................... 151
Editing Phone Information.................... 154
Phone Setup ........................................ 155
Making a Call....................................... 156
Receiving a Call.................................... 159
HFL Menus........................................... 160
Text Messages....................................... 163
CR‑ZKA‑31SZT820.book143ページ２０１２年１０月９日 火曜日 午前８時１７分
144
Bluetooth® HandsFreeLink®
Bluetooth® HandsFreeLink®
H PHONE button
Select an item.
The following items are available:
• Redial: Dials the last number.
• Call History: Displays the call history.
2 Using Call History P. 158
• Phonebook: Displays the cell phone’s imported phonebook.
2 Using the Phonebook P. 157
• Dial: Makes a call by entering the phone number.
2 Entering a Phone Number P. 157
• Text Messages: Displays received text messages list. is displayed if there is an
unread message.
2 Text Messages P. 163
• Phone Setup: Sets up the HFL features.
2 Pairing a Phone P. 146
• Speed Dial 1, 2: Makes a call to stored speed dial entries.
2 Using Speed Dial P. 158
2 Setting Up Speed Dialing P. 151
1 Bluetooth® HandsFreeLink®
You can control the HFL system using voice
commands.
2 HFL Menus P. 160
To use HFL, you need a Bluetooth-compatible
cell phone. For a list of compatible phones,
pairing procedures, and special feature
capabilities:
• U.S.: Visit automobiles.honda.com/
handsfreelink.
• Canada: Visit www.handsfreelink.ca.
• Call HandsFreeLink customer support at
(888) 528-7876.
Voice Control Tips
• Aim the vents away from the ceiling and close
the windows, as noise coming from them may
interfere with the microphone.
• Press and release the d (Talk) button before
giving a command. Speak clearly and naturally
after a beep.
2 Voice Control Operation P. 5
• If the microphone picks up voices other than
yours, the command may be misinterpreted.
• To change the volume level, use the audio
system’s volume knob or the remote audio
controls.
CR‑ZKA‑31SZT820.book144ページ２０１２年１０月９日 火曜日 午前８時１７分
145
Bluetooth® HandsFreeLink®
Bluetooth® HandsFreeLink®
Say d “Hands-free help” or d “Help” any time to get help or hear a list of
commands.
2 Voice Help P. 13
■ Help Features
1 Bluetooth® HandsFreeLink®
Bluetooth® Wireless Technology
Bluetooth® name and logos are registered
trademarks owned by Bluetooth SIG, Inc., and
any use of such marks by Honda Motors Co.,
Ltd., is under license. Other trademarks and
trade names are those of their respective owners.
HFL Limitations
An incoming call on HFL will interrupt
Bluetooth® Audio when it is playing. Audio will
resume when the call is ended.
Certain touchscreen functions are disabled while
the vehicle is moving.
2 Limitations for Manual Operation P. 18
CR‑ZKA‑31SZT820.book145ページ２０１２年１０月９日 火曜日 午前８時１７分
146
Bluetooth® HandsFreeLink®
Pairing a Phone
Bluetooth® HandsFreeLink®
Pairing a Phone
H PHONE button
When no Bluetooth-compatible phone has ever been paired to the system, the
following screen appears:
1. Select Yes.
2. Put your cell phone in “Discovery”
or “Search” mode.
3. Select OK.
The system begins to search for
your phone.
4. Select your phone in the list.
Select Find Another Phone if
your phone is not found.
Refer to your phone manual for
instructions on searching for a
Bluetooth® device.
5. Enter the 4-digit pairing code on
your phone when prompted to
complete the pairing process.
1 Pairing a Phone
Your Bluetooth-compatible phone must be
paired to HFL before you can make and receive
hands-free calls.
The maximum range between your phone and
vehicle is about 30 feet (10 meters).
Phone Pairing Tips
• You cannot pair your phone while the vehicle
is moving.
• Your phone must be in discovery or search
mode when pairing the phone. Refer to your
phone’s manual.
• Up to six phones can be paired.
• Your phone’s battery may drain faster when it
is paired to HFL.
• If your phone is not ready for pairing or not
found by the system within three minutes, the
system will time out and returns to idle.
• The default pairing code “0000” is used unless
you change the setting.
Pairing Code
You can change the pairing code setting.
2 Changing the Pairing Code P. 148
Delete a Phone
You can delete the paired phone.
2 Deleting a Paired Phone P. 149
CR‑ZKA‑31SZT820.book146ページ２０１２年１０月９日 火曜日 午前８時１７分
148
Bluetooth® HandsFreeLink®
Pairing a Phone
Bluetooth® HandsFreeLink®
H PHONE button
Phone Setup
Add/Select a phone
1. Select Edit under Pairing Code.
2. Select an item.
The following items are available:
• Random: Uses a randomly generated pairing code.
• Fixed: Create your own pairing code.
■ Changing the Pairing Code
CR‑ZKA‑31SZT820.book148ページ２０１２年１０月９日 火曜日 午前８時１７分
149
Bluetooth® HandsFreeLink®
Pairing a Phone
Bluetooth® HandsFreeLink®
3. If you select Fixed, enter a new
pairing code. Select OK.
Select Delete to remove the
current pairing code.
H PHONE button
Phone Setup
Add/Select a phone
1. Select List under Paired Phone
List.
2. Select a phone to delete.
The Bluetooth® icon indicates
the currently linked phone.
■ Deleting a Paired Phone
1 Deleting a Paired Phone
When you transfer the vehicle to a third party,
delete all paired phones.
Continued
CR‑ZKA‑31SZT820.book149ページ２０１２年１０月９日 火曜日 午前８時１７分
150
Bluetooth® HandsFreeLink®
Pairing a Phone
Bluetooth® HandsFreeLink®
3. Select Delete this Phone.
4. Select Yes.
H PHONE button
Phone Setup
Add/Select a phone
1. Select List under Paired Phone
List.
2. Select a phone to connect.
3. Select Connect.
HFL disconnects the linked
phone and starts connecting to
another paired phone.
Bluetooth® icon
■ Changing the Currently Paired Phone
1 Changing the Currently Paired Phone
If no other phones are found or paired when
trying to switch to another phone, HFL will
inform you that the original phone is linked
again.
CR‑ZKA‑31SZT820.book150ページ２０１２年１０月９日 火曜日 午前８時１７分
151
Bluetooth® HandsFreeLink®
Setting Up Speed Dialing
Bluetooth® HandsFreeLink®
Setting Up Speed Dialing
H PHONE button
Speed Dial 1 or Speed Dial 2
Create speed dial entries with voice tags for easy calling.
1. Select Add New.
2. Select a number entry option.
3. Select a number.
4. Select Voice Tag.
Select OK to store the speed dial
without a voice tag.
5. Follow the prompt to enter a voice
tag.
The following options are available:
• Phonebook: Adds a number from the imported phonebook.
• History: Adds a number from the last 20 numbers.
• Phone Number: Enters a number manually.
1 Setting Up Speed Dialing
You can control the HFL system using voice
commands.
2 HFL Menus P. 160
Up to 15 speed dial entries can be stored per
phone.
CR‑ZKA‑31SZT820.book151ページ２０１２年１０月９日 火曜日 午前８時１７分
152
Bluetooth® HandsFreeLink®
Setting Up Speed Dialing
Bluetooth® HandsFreeLink®
H PHONE button
Speed Dial 1 or Speed Dial 2
1. Select a speed dial entry.
2. Select Edit Speed Dial.
3. Select Voice Tag.
4. Follow the prompt to enter a voice
tag.
■ Registering a Voice Tag to a Speed Dial Entry
1 Registering a Voice Tag to a Speed Dial Entry
Voice tags allow you to call speed dial entries
from any screen by saying d “Dial by voice tag”
and the voice tag, followed by d “Dial.”
• Avoid using duplicate voice tags.
• Avoid using “Home” as a voice tag.
• Avoid using voice tags that only contain
numbers.
• It is easier for HFL to recognize a longer name
(e.g., “John Smith” instead of “John”).
1 Deleting a Speed Dial Entry
1. Select Delete Speed Dial.
2. Select Yes.
CR‑ZKA‑31SZT820.book152ページ２０１２年１０月９日 火曜日 午前８時１７分
153
Bluetooth® HandsFreeLink®
Setting Up Speed Dialing
Bluetooth® HandsFreeLink®
H PHONE button
Speed Dial 1 or Speed Dial 2
1. Select a speed dial entry.
2. Select Edit Speed Dial.
3. Select Voice Tag.
4. Select an item.
The following items are available:
• Play Stored Voice Tag: Plays the stored voice tag.
• Record Voice Tag: Stores a voice tag. Follow the prompt to enter a voice tag.
• Delete Voice Tag: Deletes the stored voice tag. Select Yes.
■ Editing a Voice Tag
CR‑ZKA‑31SZT820.book153ページ２０１２年１０月９日 火曜日 午前８時１７分
154
Bluetooth® HandsFreeLink®
Editing Phone Information
Bluetooth® HandsFreeLink®
Editing Phone Information
H PHONE button
Phone Setup
Add/Select a phone
List
Edit the user name of a paired phone, and protect the phonebook and speed dial
entries with a PIN.
1. Select a phone to edit.
2. Select an item.
The following items are available:
• Connect: Connects the selected phone to the HFL.
• Edit Name: Enter a name.
• PIN: Enter a 4-digit PIN. Re-enter to confirm. You can select Do Not Use PIN to
remove a PIN.
• Replace this Phone: Deletes the selected phone and adds a new phone.
2 Pairing a Phone P. 146
• Delete this Phone: Deletes the user name, call history, and phonebook.
1 Editing Phone Information
You can control the HFL system using voice
commands.
2 HFL Menus P. 160
You can name up to six HFL users. Each can be
PIN protected, and have their own phonebook,
speed dial entries, and call history.
CR‑ZKA‑31SZT820.book154ページ２０１２年１０月９日 火曜日 午前８時１７分
155
Bluetooth® HandsFreeLink®
Phone Setup
Bluetooth® HandsFreeLink®
Phone Setup
H PHONE button
Phone Setup
Set HFL options and features.
1. Select an item.
2. Select OK.
The following items are available:
• Bluetooth Setup: Pairs your phone to the system.
2 Pairing a Phone P. 146
• Bluetooth Connection: Turns the Bluetooth® connection on or off.
On: Connects your Bluetooth-compatible device to the system.
Off (factory default): Disables the feature.
• Auto Transfer: Sets whether to automatically transfer a call from your phone to
HFL when you enter and turn on the vehicle.
On (factory default): Automatically transfers your call to HFL.
Off: Disables the feature.
• Auto Answer: Sets whether to automatically answer an incoming call.
On: Automatically connects an incoming call after about five seconds.
Off (factory default): Disables the feature.
• Text Message Notice: Sets whether to give an incoming message notification.
On (factory default): Gives an incoming message notification.
Off: Messages are still received, but without notification.
1 Phone Setup
You can control the HFL system using voice
commands.
2 HFL Menus P. 160
Text Message Notice can be set separately for
each paired phone.
Continued
CR‑ZKA‑31SZT820.book155ページ２０１２年１０月９日 火曜日 午前８時１７分
156
Bluetooth® HandsFreeLink®
Making a Call
Bluetooth® HandsFreeLink®
• Volume: Select B or N to adjust the receiver and ring volume. If you change
the volume during a call, it is maintained at that level until you change it again.
Making a Call
Make calls by entering a number or using the imported phonebook, call history, or
speed dial entries.
2 Using the Phonebook P. 157
2 Entering a Phone Number P. 157
2 Using Call History P. 158
2 Using Speed Dial P. 158
1 Making a Call
You can control the HFL system using voice
commands.
2 HFL Menus P. 160
When you say d “Dial by number” or d “Dial
by voice tag” on most screens, the following
screen appears:
Say the phone number or the voice tag (e.g., d
“John Smith”), followed by d “Dial.”
2 Registering a Voice Tag to a Speed Dial
Entry P. 152
Only one phone can be used with HFL at a time.
When there are more than two paired phones in
the vehicle, the first paired phone the system
finds is automatically linked.
CR‑ZKA‑31SZT820.book156ページ２０１２年１０月９日 火曜日 午前８時１７分
157
Bluetooth® HandsFreeLink®
Making a Call
Bluetooth® HandsFreeLink®
H PHONE button
Phonebook
1. Select a name.
Select alphabetical tabs to
display the entries in the group.
2. Select a number.
3. Select Call to begin dialing.
H PHONE button
Dial
1. Enter a phone number.
2. Select Dial to begin dialing.
■ Using the Phonebook
1 Using the Phonebook
Up to three icons are displayed for each
phonebook entry. If there are more than three
numbers for an entry, “…” is displayed.
This feature is not available on all phones.
Home Fax
Mobile Car phone
Other Voice
Work Preference
Pager
■ Entering a Phone Number
1 Entering a Phone Number
A command that consists of several numbers can
be spoken together. For example, say d “123-
456-7890” at once.
CR‑ZKA‑31SZT820.book157ページ２０１２年１０月９日 火曜日 午前８時１７分
158
Bluetooth® HandsFreeLink®
Making a Call
Bluetooth® HandsFreeLink®
H PHONE button
Call History
1. Select a call.
Select All, Dialed, Received,
Missed to view the call history
by category.
2. Select Call to begin dialing.
H PHONE button
Speed Dial 1 or Speed Dial 2
1. Select a speed dial entry.
2. Select Call to begin dialing.
■ Using Call History
1 Using Call History
The call history shows the last 20 calls from your
phone.
■ Using Speed Dial
1 Using Speed Dial
To make a call using speed dial, you need to
create speed dial entries.
2 Setting Up Speed Dialing P. 151
More Speed Dial Lists
You can make a call by using more speed dials
on the other phones.
1. Select another paired phone in the list.
2. Select a speed dial entry.
3. Select Call to begin dialing.
If the other phone is PIN-protected, enter the PIN
when prompted. Select OK. PINs are optional.
2 Editing Phone Information P. 154
CR‑ZKA‑31SZT820.book158ページ２０１２年１０月９日 火曜日 午前８時１７分
159
Bluetooth® HandsFreeLink®
Receiving a Call
Bluetooth® HandsFreeLink®
Receiving a Call
1. Press the h (Pick-Up) button to
answer a call and display the
Calling screen.
2. Press the j (Hang-Up) button to
terminate the call.
The following options are available during a call:
• MUTE: Allows you to mute your voice.
• Touch Tones (available on some phones): Allows you to send numbers or names
during a call. This is useful when you call an automated phone system.
• Transfer Call: Allows you to transfer a call from HFL to your phone, or from your
phone to HFL.
1 Receiving a Call
An incoming call notification appears on the
navigation screen, and you hear an audible ring
tone.
If your phone has Call Waiting, press the h
button to put the original call on hold and
answer the incoming call. To return to the
original call, press the h button again. If you
want to hang up the original call and answer the
new call, press the j button.
To change the volume level of HFL, use the audio
system volume knob or the steering wheel
volume controls.
Some phones may send battery, signal strength,
and roaming status information to the screen.
Phonebook
Displays the cell phone’s imported phonebook.
2 Using the Phonebook P. 157
Call ID Bluetooth indicator Roaming status
Signal strength Battery level
CR‑ZKA‑31SZT820.book159ページ２０１２年１０月９日 火曜日 午前８時１７分
160
XX
Bluetooth® HandsFreeLink®
X
HFL Menus
Bluetooth® HandsFreeLink®
HFL Menus
Use HFL when the vehicle’s ignition is in the ACCESSORY (I) or ON (II) position.
You can operate HFL by voice when on the PHONE screen. Below is the flow chart
showing available voice commands.
1 HFL Menus
To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the
vehicle is parked.
“PIN”
“Replace this Phone”
“Delete this Phone”
“Phone Setup”
“Edit Name”
“Paired Phone List”
Select a phone
“Connect”
“Add a New Phone”
“Pairing Code”
“Bluetooth setup add select a phone”
Press the h (Pick-Up) button to display the PHONE screen.
Press the d (Talk) button each time you give a voice command.
Pair your phone to the system. 2 Pairing a Phone P. 146
Set a “fixed” or “random” pass-key code for phone pairing.
2 Changing the Pairing Code P. 148
Delete a previously paired phone.
2 Deleting a Paired Phone P. 149
Switch from a currently linked phone to another paired
phone. 2 Changing the Currently Paired Phone P. 150
Display the list of the paired phones.
Create a PIN for a paired phone.
Replace the previously paired phone with a new
phone.
Create a user name for a paired phone.
CR-Z_KA-31SZT830_04.fm Page 160 Thursday, April 10, 2014 3:35 PM
161
Bluetooth® HandsFreeLink®
HFL Menus
Bluetooth® HandsFreeLink®
“Auto Answer On/Off”
“Volume Plus/Minus”
“Text Message Notice
On/Off”
“Auto Transfer On/Off”
“Bluetooth
Connection On/Off”
“MUTE”
“Touch Tones”
“Redial”
“Call History”
“Phonebook”
“Dial”
“Phone Setup”
“Transfer Call”
“Dial”
Press the h (Pick-Up) button to display the PHONE screen.
Press the d (Talk) button each time you give a voice command.
Turn the auto transfer on or off.
Adjust the HFL volume.
Display the last 20 incoming, outgoing, or missed calls.
2 Using Call History P. 158
Display the paired phone’s imported phonebook (or import a new one).
2 Using the Phonebook P. 157
Say a phone number to dial.
2 Entering a Phone Number P. 157
Dial the last phone number.
Send numbers or names during a call.
Mute your voice during a call.
Transfer a call from HFL to your phone, or from your
phone to HFL.
Turn the Bluetooth connection on or off.
Turn the auto answer on or off.
2 Phone Setup P. 155
Turn the text message notification on or off.
Continued
CR‑ZKA‑31SZT820.book161ページ２０１２年１０月９日 火曜日 午前８時１７分
162
Bluetooth® HandsFreeLink®
HFL Menus
Bluetooth® HandsFreeLink®
“Speed Dial 1” or
“Speed Dial 2”
“Voice Tag”
“Edit Phone
Number”
“More Speed Dial
Lists”
“Edit Speed Dial”
“Delete Speed Dial”
“Call”
Select an entry
Dial the phone number of the selected speed dial entry.
Create a voice tag for a speed dial number.
2 Registering a Voice Tag to a Speed Dial Entry P. 152
Delete a previously stored speed dial number.
2 Setting Up Speed Dialing P. 151
Edit the phone number of the selected speed dial entry.
2 Using Speed Dial P. 158
Make a call by using another paired phone’s speed dial list
(Speed Dial 2 only).
2 Using Speed Dial P. 158
Press the h (Pick-Up) button to display the Cellular Phone screen.
Press the d (Talk) button each time you give a voice command.
CR‑ZKA‑31SZT820.book162ページ２０１２年１０月９日 火曜日 午前８時１７分
163
Bluetooth® HandsFreeLink®
Text Messages
If your paired phone is MAP-compatible, you can receive and hear text messages and
reply to them using fixed reply messages.
2 Pairing a Phone P. 146
If a text message is received, the following screen is displayed.
1. Select Read.
The text message is read aloud.
Select Cancel to check the text
message later.
If the phone number of the
sender is stored to the
Phonebook, the name is
displayed.
2. Select an item.
The entire message body is not
displayed while driving.
The following items are available:
• Read: Reads the text message aloud. Select Stop to stop reading. Adjust the
volume using the VOL 9 (Volume/Power) knob.
• Reply: Replies to the message using a fixed reply message. You cannot create
your own messages.
2 Replying to the Message P. 164
1 Text Messages
You can control the text messages feature using
voice commands.
2 Text Message Commands P. 199
To use this function, you need a Bluetooth- and
MAP (Message Access Profile)-compatible cell
phone. For a list of compatible phones and
special feature capabilities:
• U.S.: Visit automobiles.honda.com/
handsfreelink.
• Canada: Visit www.handsfreelink.ca.
• Call HandsFreeLink customer support at (888)
528-7876.
If your phone is not capable of this function, a
notification appears when you select the text
message option.
Select Text Messages from the Phone screen to
view a list of the 20 most recently received text
messages. You can select each one to read,
reply, or call back. The list cannot be scrolled
while the vehicle is moving.
Continued
CR‑ZKA‑31SZT820.book163ページ２０１２年１０月９日 火曜日 午前８時１７分
164
Text Messages
Bluetooth® HandsFreeLink®
• Call: Calls the sender.
• Previous message: Displays the previous message.
• Next message: Displays the next message.
1. Select the message you want to
use.
2. Select Send.
■ Replying to the Message
1 Text Messages
You can set up text message notification when
the first message for the paired phone is
received. You can change the setting from the
Phone setup screen.
2 Phone Setup P. 155
If you delete a message on the phone, the
message is also deleted in the system. If you send
a message from the system, the message goes to
your phone’s outbox.
CR‑ZKA‑31SZT820.book164ページ２０１２年１０月９日 火曜日 午前８時１７分
165
Other Features
This section describes the useful functions incorporated into the
navigation system.
Trip Computer ....................................... 166
Information Functions .......................... 167
System/Device Information ................... 167
Map Update......................................... 167
Multi-View Rear Camera ...................... 168
CR‑ZKA‑31SZT820.book165ページ２０１２年１０月９日 火曜日 午前８時１７分
166
Other Features
Trip Computer
H INFO button
Trip Computer
View the distance traveled and average fuel consumption.
Select an item.
The following items are available:
• Current Drive: Displays the current trip information.
• History of Trip A: Displays information for three previous histories. The
information is stored every time you reset Trip A.
• Delete History: Deletes the trip information. Select Yes.
1 Trip Computer
Displays the following trip information:
• Instant Fuel: The current estimated instant
fuel economy.
• Average Fuel: The average fuel economy
since the last key cycle.
• 1st, 2nd, 3rd Prev.: The previous average fuel
consumption.
• RANGE: The estimated distance you can travel
on the fuel remaining in the tank.
These values are estimates only.
CR‑ZKA‑31SZT820.book166ページ２０１２年１０月９日 火曜日 午前８時１７分
167
Other Features
Information Functions
System/Device Information
H INFO button
System/Device Information
View database, software, device, and vehicle identification information.
Map Update
H INFO button
Map Update
Update the map database.
1 System/Device Information
You will need this information when ordering a
map update.
2 Obtaining Navigation Update Data P. 187
1 Map Update
When you order a map update, it is mailed to
you on a USB flash drive.
2 Obtaining Navigation Update Data P. 187
CR‑ZKA‑31SZT820.book167ページ２０１２年１０月９日 火曜日 午前８時１７分
168
Other Features
Multi-View Rear Camera
Your vehicle is equipped with a multi-view rear camera. When you shift into Reverse,
the rear view is displayed on the navigation system screen. The edge of the bumper
and parking guide lines are also displayed.
To turn the guide lines on or off, press
and hold the CANCEL button until the
guide lines turn on or off.
Press the ZOOM IN/OUT button to
adjust the screen brightness.
While the rear view is displayed, touch
c, z or x to switch
between wide, normal, and top down
view modes.
1 Multi-View Rear Camera
Always keep the camera lens clean and
unobstructed. The multi-view rear camera has a
lens that makes distances appear different than
they actually are. Always take care when
reversing, and look behind you for obstacles.
Navigation controls are disabled when in
Reverse.
If you turn the guide lines off, they remain off
until you turn them back on.
Adjusting the brightness for the multi-view rear
camera display does not affect the brightness for
the navigation screen.
If the last used viewing mode is wide or normal,
the same mode is selected the next time you shift
into Reverse. If top view was last used, wide
mode is selected.
Multi-View
Rear Camera
Screen display
Bumper
Guide lines
Camera
Approx. 1 m (3.3 ft)
Approx. 2 m (6.6 ft)
Approx. 3 m (9.8 ft)
Approx. 50 cm
(1.7 ft)
Tailgate open range
Approx. 3 m (9.8 ft)
Approx. 2 m (6.6 ft)
Approx. 1 m (3.3 ft)
c:
Displays in wide view mode.
z:
Displays in normal view mode.
x:
Displays in top down view mode.
CR‑ZKA‑31SZT820.book168ページ２０１２年１０月９日 火曜日 午前８時１７分
169
Troubleshooting
Troubleshooting ................................... 170
Map, Voice, Entering Destinations........ 170
Traffic .................................................. 172
Guidance, Routing ............................... 172
Update, Coverage, Map Errors ............. 174
Display, Accessories.............................. 175
Multi-View Rear Camera ...................... 175
Miscellaneous Questions ...................... 176
Error Messages...................................... 177
Navigation System................................ 177
Disc Player............................................ 178
iPod®/Pandora®.................................. 179
USB Flash Drive .................................... 180
CR‑ZKA‑31SZT820.book169ページ２０１２年１０月９日 火曜日 午前８時１７分
170
Troubleshooting
Troubleshooting
Map, Voice, Entering Destinations
Problem Solution
The Startup Confirmation screen is displayed every
time I start the car.
This is normal. The Startup Confirmation screen reminds you and your guest drivers to
always operate the navigation system in a safe manner. If you do not select OK at
startup, voice commands will not work.
The navigation system reboots by itself (returns to the
opening screen).
A reboot can be caused by extreme temperatures or shock from bumpy roads, and
does not necessarily indicate a problem. If this happens frequently, please see your
dealer.
How do I specify a destination when an entered city or
street could not be found?
• Try entering the street first. Some cities are lumped in with a major metro area. In
rural “unverified” areas or new subdivisions, streets may be missing or only partially
numbered.
• Try selecting the destination directly from the map.
2 Map Input P. 75
Why do some letters become grayed out when I enter
an address?
As you enter each letter in an address or a place/landmark, the navigation system
looks in the database to see what letters are possible and grays out letters that do not
apply.
How do I delete Personal Addresses, Previous
Destinations, or the Home Address?
1. Press the INFO button. Select Setup > Personal Information to display the types
of information.
2. Select the type of address to delete.
3. Select Delete.
I cannot hear the navigation system voice. Press the INFO button. Select Setup and check that Volume is not set to Off.
2 Display and Volume Settings P. 21
The voice control system is having difficulty
recognizing my voice commands.
• Check that the vents are not blowing air onto the microphone on the ceiling, the
vehicle is as quiet as possible, and you are using the correct command when
speaking.
2 Voice Recognition P. 20
•Say d “Help” on any screen to see a list of the applicable voice commands.
The navigation system pronunciation of street names
in the guidance command or destination address
sounds strange.
The basic guidance phrases use a studio-recorded voice, but street names are
pronounced using a machine-generated voice. Consequently, the name may be
mispronounced or sound strange at times.
CR‑ZKA‑31SZT820.book170ページ２０１２年１０月９日 火曜日 午前８時１７分
171
Troubleshooting
Map, Voice, Entering Destinations
Troubleshooting
I cannot give voice commands. Make sure you selected “OK” at the Startup Confirmation screen.
2 Start-up P. 18
I cannot select an option on the touch screen. To prevent driver distraction, certain touch screen functions and features are limited or
inoperable while the vehicle is moving. Use voice commands, or pull over to proceed.
The screen is bright when I drive at night. 1. Check that the nighttime dashboard brightness control is not set to maximum.
2. Press the INFO button. Select Setup > Other > Color > Map. Set the Night color to
Black for the best contrast.
2 Switching Display Mode Manually P. 26
The screen is dark when I drive during the day. Press the INFO button. Select Setup > Other > Color > Map. Set the Day color to
White for the best contrast.
2 Switching Display Mode Manually P. 26
How do I change or remove my PIN? 1. Press the INFO button. Select Setup > Personal Information > PIN Number > GO
Home 1 PIN or GO Home 2 PIN or Address Book PIN.
2. Enter your existing PIN. You then have the choice to change or remove the PIN.
2 PIN Numbers P. 36
I have forgotten my PIN. How do I reset the PIN for
Home or the PIN for personal addresses (User 1 or User
2)?
Your dealer must reset the PIN for you.
Why is Call grayed out on the Calculate Route screen? Your phone is not paired to Bluetooth® HandsFreeLink® or, if paired, your phone is in
use.
Problem Solution
CR‑ZKA‑31SZT820.book171ページ２０１２年１０月９日 火曜日 午前８時１７分
172
Troubleshooting
Traffic
Troubleshooting
Traffic
Guidance, Routing
Problem Solution
My FM Traffic is missing or is not displaying properly.
What is wrong?
Verify the following:
• FM Traffic relies on a clear FM signal. If signal strength is low, traffic data may not
be available.
• Check the traffic icon on the icon bar, and the icon options for traffic.
2 Showing Icons on the Map P. 92
• It is possible that there is a temporary technical problem with your metropolitan
area traffic. You can call Honda Automobile Customer Service to see if there is an
outrage.
2 Honda Automobile Customer Service Contact Information P. 186
• If the situation persists, see your Honda dealer for assistance.
Problem Solution
The navigation system does not route me the same
way I would go or the same way as other mapping
systems.
The navigation system attempts to generate the optimal route. You can change the
route preferences used when calculating a route.
2 Changing the Route Preference P. 78
The street I’m on is not shown on the map screen. The mapping database is constantly undergoing revision. You can access the most
recent information on the internet.
2 Map Coverage P. 187
The vehicle position icon is not following the road and
the “GPS icon” text in the upper left hand corner of
the screen is white or missing.
• Check that the GPS antenna (located in the dashboard) is not blocked. For best
reception, remove items from the dashboard, such as radar detectors, cell phones,
or loose articles.
• Metallic tinting or other aftermarket devices can interfere with the GPS reception.
Please consult your dealer.
2 GPS System P. 184
CR‑ZKA‑31SZT820.book172ページ２０１２年１０月９日 火曜日 午前８時１７分
173
Troubleshooting
Guidance, Routing
Troubleshooting
The blue highlighted route and voice guidance
stopped or turned into a blue/pink dashed line before I
got to my destination.
Your route has entered an unverified area.
2 Unverified Area Routing P. 41
How do I stop the map from rotating as I drive along? Select the map orientation icon on the map screen, or say d “Display north-up” to
change the map orientation.
Sometimes, I cannot select between the North-up and
Heading-up map orientations.
The Heading-up map orientation can only be shown in the lower scales (1/20 - 1 mile
scales).
2 Map Scale and Functions P. 95
The “time to destination” display sometimes increases
even though I am getting closer to my destination.
If your speed reduces due to slower traffic, the navigation system updates the “time to
destination” based on your actual road speed to give you a better estimate of arrival
time.
The vehicle position icon on the map “lags” a short
distance behind, especially when I arrive at an
intersection.
This is normal. The navigation system is unaware of the width of intersections. Large
differences in vehicle position can indicate a temporary loss of the GPS signal.
2 GPS System P. 184
The screen is showing white dots as I drive along. These dots are called “breadcrumbs.” These are displayed if Off-road Tracking is set
to On and you drive more than 1/2 mile off mapped roads.
2 Off-road Tracking P. 50
How do I remove the white dots (“breadcrumbs”)
from my screen?
Press the INFO button. Select Setup > Other > Vehicle, and set Off-road Tracking
to Off, then return to the map.
2 Off-road Tracking P. 50
A road that I selected to avoid is being used when
routing.
When you “draw” your area to avoid, make sure to select sections of roads that
include at least one intersection.
2 Avoiding Streets P. 102
My elevation (shown when I display the current
position) seems to fluctuate even though my elevation
has not changed.
This is normal. The elevation can vary ±100 feet due to GPS calculation errors.
2 GPS System P. 184
Problem Solution
Continued
CR‑ZKA‑31SZT820.book173ページ２０１２年１０月９日 火曜日 午前８時１７分
174
Troubleshooting
Update, Coverage, Map Errors
Troubleshooting
Update, Coverage, Map Errors
My elevation is missing on the “current position”
screen.
The elevation is only displayed if the GPS antenna can receive signals from at least four
satellites. Try moving the vehicle into an open area. The elevation is also not displayed
if the calculated elevation is zero or below sea level.
Problem Solution
My city is not part of a fully verified detailed coverage
area.
The mapping database is constantly undergoing revision. You can access the most
recent information on the internet.
2 Map Coverage P. 187
Does the navigation system work outside North
America?
The navigation system contains maps for the 50 U.S. states, Canada, and Puerto Rico.
The navigation system will not work in Mexico or other countries.
2 Map Coverage P. 187
Can I play video DVDs in my navigation system? No. The navigation system is designed only to read music discs. If you experience any
problems that you cannot resolve, please contact your dealer.
How do I report errors I find in the database? Minor errors are bound to occur in a large database. If you encounter major errors, see
2 Reporting Errors P. 186
Problem Solution
CR‑ZKA‑31SZT820.book174ページ２０１２年１０月９日 火曜日 午前８時１７分
175
Troubleshooting
Display, Accessories
Troubleshooting
Display, Accessories
Multi-View Rear Camera
Problem Solution
The display appears dim when starting the car in really
cold weather.
This is normal. The display will become brighter after a few minutes.
Problem Solution
When I shift gears, the multi-view rear camera image
display is delayed.
This is normal. When shifting into or out of Reverse, you may experience a delay while
the screen image switches between the navigation screen and the multi-view rear
camera image.
The multi-view rear camera image is too dark or too
bright. How do I adjust the brightness?
While the camera image is displayed, press the ZOOM IN/OUT button to adjust the
brightness.
This adjustment does not affect the navigation screen brightness settings.
CR‑ZKA‑31SZT820.book175ページ２０１２年１０月９日 火曜日 午前８時１７分
176
Troubleshooting
Miscellaneous Questions
Troubleshooting
Miscellaneous Questions
Problem Solution
My clock frequently changes forward and backward by
one hour.
The clock setting is automatically updated based on your GPS location. If you live and
work on the boundary between two time zones, you can turn off this feature.
2 Clock Adjustment P. 46
The clock changes even when I am not driving near a
time zone boundary.
The time zone boundaries are only approximated in the navigation system. Depending
on the geography of the time zone boundary, the switch to a different zone can be
erratic.
2 Clock Adjustment P. 46
My state does not observe daylight saving time. How
do I turn off this feature?
Press the INFO button. Select Setup > Other > Clock Adjustment > Clock
Adjustment, and set Auto Daylight to Off.
2 Clock Adjustment P. 46
Daylight saving time has started, but the navigation
system did not change time even though Auto
Daylight is set to ON.
The automatic daylight saving time feature does not work in regions where the
daylight saving time system has not been adopted.
The navigation system automatic daylight feature is
not switching the navigation system clock on the
correct dates.
Press the INFO button. Select Setup > Other > Clock Adjustment > Clock
Adjustment, and set Auto Daylight to On. Note that the automatic daylight feature
does not work in regions where the daylight saving time system has not been
adopted.
2 Clock Adjustment P. 46
The navigation system clock switched by one hour for
no apparent reason.
You may be driving near a time zone boundary.
2 Clock Adjustment P. 46
My battery was disconnected or went dead, and the
navigation system is asking for a code.
Your vehicle comes with a label in the Owner’s Manual kit that includes the system’s
security code and serial number. You should keep this label in a safe place outside
your vehicle. If you cannot find it, contact your dealer.
How do I change the interface language? Press the INFO button. Select Setup > Other > Language, and set the language to
English, Français, or Español.
CR‑ZKA‑31SZT820.book176ページ２０１２年１０月９日 火曜日 午前８時１７分
177
Troubleshooting
Error Messages
Navigation System
Error Message Solution
The display temperature is too high! For protection,
the display will shut down.
This message appears briefly when the display temperature is too high. The navigation
system turns off until the display cools down. The system turns back on automatically
when the display cools down.
The navigation system is unable to start due to
excessive heat. The system will start after the system
cools.
The navigation system has difficulty accessing to the map database when the
temperature is high. The navigation system starts up automatically when the display
cools down.
Route has not been completed. Please try again from a
different location.
This message appears when you are on a route to or from a new area that is not in the
database. Try planning a different route to or from a different location. If the error
persists or is shown for a wide area, see your dealer.
Destination is not in this database version. Please set
from map.
The destination was not found in the database. Try another destination nearby, or
select the destination from the map using the joystick. If the error persists or is shown
for a wide area, see your dealer.
No POI found...
CR‑ZKA‑31SZT820.book177ページ２０１２年１０月９日 火曜日 午前８時１７分
178
Error Messages
Disc Player
Troubleshooting
Disc Player
Error Message Cause Solution
Bad Disc
Please Check Owners Manual
Servo error • Press the E (Eject) button and remove the disc, and check that the
error message is cleared.
• Check that the disc is not damaged or deformed, and insert the disc
again.
2 Recommended Discs P. 124
• If the error message reappears, press the E button, and pull out
the disc.
• Insert a different disc. If the new disc plays, there is a problem with
the first disc.
• If the error message repeats, or the disc cannot be removed, contact
your dealer. Do not try to force the disc out of the player.
Mechanical error
Mecha Error Mechanical error
Check Disc Focus error
Disc violates copyright
Disc not supported
Load error
Unsupported Appears when an unsupported
disc is inserted.
• If it appears when a supported disc is inserted, reinsert the disc.
Unplayable File Appears when the tracks on the
disc are DRM or an unsupported
format.
• This error message appears for about three seconds, then plays the
next song.
The system cannot read the
track(s).
• Check the tracks on the disc. There is a possibility that the tracks
have been damaged.
Heat Error High temperature • Turn the audio system off and allow the player to cool down until
the error message is cleared.
CR‑ZKA‑31SZT820.book178ページ２０１２年１０月９日 火曜日 午前８時１７分
179
Error Messages
iPod®/Pandora®
Troubleshooting
iPod®/Pandora®
Error Message Cause Solution
Unsupported Appears when an unsupported
iPod®/iPhone® is connected.
• Update the iPod®/iPhone® software to the latest version.
• If it appears when a supported iPod®/iPhone® is connected,
reconnect the iPod®/iPhone®.
Connect Retry Appears when the iPod®/iPhone®
cannot be authenticated.
Reconnect the iPod®/iPhone®.
No Data Appears when there are no tracks
in the iPod®.
Store tracks in the iPod®.
Bad Use Device
Please Check Owners Manual
Appears when the overcurrent
protection feature of the system
stops supplying power to USB
because an incompatible iPod®/
iPhone® is connected.
Disconnect the iPod®/iPhone®. Turn the audio system off, and turn it
on again. Do not reconnect the iPod®/iPhone® that caused the error.
USB Error Appears when the internal USB
error occurs.
Try a different iPod®/iPhone®.
No station Appears when there are no
stations in Pandora®.
Check the iPhone®.
Unsupported Ver. Appears when the Pandora®
version is not supported.
Update Pandora® to the latest version.
No active station Appears when the station is
deleted from the iPhone®.
Select another station.
No Connection Appears when the iPhone® has
an error, including out of service.
Check the iPhone®.
Rating error Appears when the like/dislike
operation is failed.
Try again later.
Bookmark error Appears when the bookmark
operation is failed.
Try again later.
CR‑ZKA‑31SZT820.book179ページ２０１２年１０月９日 火曜日 午前８時１７分
180
Error Messages
USB Flash Drive
Troubleshooting
USB Flash Drive
Skip error Appears when the number of
skips exceeds the skip limit or
advertisements are broadcasted.
• You can skip after the skip limit is removed. Try again later.
• You can skip after the advertisements are finished.
Maintenance Appears when the Pandora®
server is in maintenance.
Try again later.
Error Message Cause Solution
Unsupported Appears when an unsupported
device is connected.
If it appears when a supported device is connected, reconnect the
device.
Unplayable File Appears when the tracks in the
USB flash drive are DRM or an
unsupported format.
This error message appears for about three seconds, then plays the
next song.
The system cannot read the
track(s).
Check the tracks in the USB flash drive. There is a possibility that the
tracks have been damaged.
No Data Appears when the USB flash drive
is empty or there are no tracks in
MP3, WMA, or AAC format in the
drive.
Save tracks in MP3, WMA, or AAC format in the USB flash drive.
Bad Use Device
Please Check Owners Manual
Appears when the overcurrent
protection feature of the system
stops supplying power to USB
because an incompatible device is
connected.
Disconnect the device. Turn the audio system off, and turn it on again.
Do not reconnect the device that caused the error.
USB Error Appears when the Internal USB
ROM error occurs.
Try a different USB flash drive.
Error Message Cause Solution
CR‑ZKA‑31SZT820.book180ページ２０１２年１０月９日 火曜日 午前８時１７分
181
Reference Information
System Initialization..............................182
Entering the Security Code....................182
Acquiring GPS Information....................182
Startup Confirmation Screen.................183
Map Matching ......................................183
System Limitations ................................184
GPS System...........................................184
Address Calculation ..............................184
Database ..............................................184
Customer Assistance .............................186
Resolving Problems ...............................186
Reporting Errors....................................186
Honda Automobile Customer Service
Contact Information............................186
Visiting Your Dealer ............................. 186
Map Coverage ..................................... 187
Obtaining Navigation Update Data....... 187
Traffic Information ............................... 188
Operation in Alaska, Hawaii, Canada, and
Puerto Rico......................................... 188
Legal Information ................................. 189
END-USER TERMS ................................ 189
As required by the FCC ........................ 191
CR‑ZKA‑31SZT820.book181ページ２０１２年１０月９日 火曜日 午前８時１７分
182
Reference Information
System Initialization
The navigation system must be initialized if
power to the navigation system is
interrupted for any reason (e.g., the
battery was disconnected).
Entering the Security Code
Find the navigation system’s security code
and serial number label in your Owner’s
Manual kit. Do not store the label in your
vehicle. If you lose the label, you must first
retrieve the serial number, and then obtain
the code. You can find out about your
serial number and security code from a
dealer.
1. Turn the ignition switch to ON (II), and
turn on the audio system.
X
If you turn the ignition switch to
ACCESSORY (I), you will be
requested to enter the security code.
See step 2.
2. Enter the security code.
X
If you do not enter the security code
correctly after 10 tries, leave the
system for one hour before trying
again, or visit a dealer to have the
system reset.
NOTE:
In the U.S., you can register the security
code on Honda Owners
(owners.honda.com.). To find information
on how to retrieve the serial number and
obtain the code, visit radio-
navicode.honda.com.
Acquiring GPS Information
Depending on the length of time the
power was interrupted, your system may
require GPS initialization.
If initialization is not necessary, the system
proceeds directly to the Startup
Confirmation screen.
If the system fails to locate a sufficient
number of satellites to locate your position
within 10 minutes, the following screen is
displayed.
CR-Z_KA-31SZT830_07.fm Page 182 Thursday, April 10, 2014 5:13 PM
183
System Initialization
Startup Confirmation Screen
Reference Information
If you are experiencing GPS reception
problems:
2 GPS System P. 184
Startup Confirmation
Screen
The Startup Confirmation screen is
displayed when initialization has
successfully completed. It is displayed every
time you start your vehicle. Select OK to
continue.
NOTE:
“OK” cannot be selected using a voice
command.
Map Matching
Map matching is the process of using the
acquired GPS information to locate your
position on the map screen. If you are on a
mapped road, the name of the road is
displayed along the bottom of the map
screen when map matching is completed.
Do not enter a destination until the road
name is displayed.
The system may initially show your location
on a different street (e.g., in urban areas
where streets are close together), may
show an incorrect elevation, or may delay
the display of the vehicle position icon at
intersections. This is normal; the system
will correct itself while you drive.
CR‑ZKA‑31SZT820.book183ページ２０１２年１０月９日 火曜日 午前８時１７分
184
Reference Information
System Limitations
GPS System
The signals received from the GPS satellites
are extremely weak (less than a millionth
of the strength of a local FM station) and
require an unobstructed view of the sky.
The GPS antenna is located in the
dashboard. The signal reception can easily
be interrupted or interfered with by the
following:
• Metallic window tint on the front or side
windows
• Cell phones, PDAs, or other electronic
devices docked in a cradle or lying loose
on the dashboard
• Remote starters or “hidden” vehicle
tracking systems mounted near the
navigation unit
• Audio electronic devices mounted near
the navigation unit
• Trees, tall buildings, freeway overpasses,
tunnels, or overhead electrical power
wires
The GPS is operated by the U.S.
Department of Defense. For security
reasons, there are certain inaccuracies built
into the GPS for which the navigation
system must constantly compensate. This
can cause occasional positioning errors of
up to several hundred feet.
Address Calculation
The destination icon shows only the
approximate location of a destination
address. This occurs if the number of
possible addresses is different from the
number of actual addresses on a block. For
example, the address 1425 on a 1400
block with 100 possible addresses
(because it is followed by the 1500 block)
will be shown a quarter of the way down
the block by the system. If there are only
25 actual addresses on the block, the
actual location of address 1425 would be
at the end of the block.
Database
The digitized map database reflects
conditions as they existed at various points
in time before production. Accordingly,
your database may contain inaccurate or
incomplete data or information due to the
passage of time, road construction,
changing conditions, or other causes.
For example, some places/landmarks may
be missing when you search the database
because the name was misspelled, the
place was improperly categorized, or a
place/landmark is not yet in the database.
This is also true for police stations,
hospitals, and other public institutions. Do
not rely on the navigation system if you
need law enforcement or hospital services.
Always check with local information
sources.
CR‑ZKA‑31SZT820.book184ページ２０１２年１０月９日 火曜日 午前８時１７分
185
System Limitations
Database
Reference Information
In addition, the map database contains
verified and unverified areas. Unverified
streets may be missing from the map, in
the wrong location, or have an incorrect
name or address range. A message will
warn you if your route includes unverified
streets. Exercise additional caution when
driving in unverified areas.
The database does not include, analyze,
process, consider, or reflect any of the
following categories of information:
• Neighborhood quality or safety
• Population density
• Availability or proximity of law
enforcement
• Emergency, rescue, medical, or other
assistance
• Construction work, zones, or hazards
• Road and lane closures
• Legal restrictions (such as vehicular type,
weight, load, height, and speed
restrictions)
• Road slope or grade
• Bridge height, width, weight, or other
limits
• Traffic facilities safety
• Special events
• Pavement characteristics or conditions
Every effort has been made to verify that
the database is accurate. The number of
inaccuracies you experience increases the
longer you go without obtaining an
updated map database.
2 Obtaining Navigation Update Data
P. 187
We assume no liability for any incident that
may result from an error in the program, or
from changed conditions not noted above.
CR‑ZKA‑31SZT820.book185ページ２０１２年１０月９日 火曜日 午前８時１７分
186
Reference Information
Customer Assistance
Resolving Problems
If you run into a specific issue that you
cannot resolve, consult the following help
resources:
• For navigation system issues:
2 Troubleshooting P. 170
There are also FAQs available online at
automobiles.honda.com.
• For questions regarding Bluetooth®
HandsFreeLink:
2 Bluetooth® HandsFreeLink® P. 144
• For traffic-related issues:
2 Traffic P. 172
• For reporting issues with the database
or places/landmarks:
2 Reporting Errors P. 186
• Call Honda Automobile Customer
Service.
2 Honda Automobile Customer Service
Contact Information
P. 186
Reporting Errors
You can help to improve database
accuracy by reporting any errors you
encounter.
• Report errors in freeways and main
“verified” roads shown in black on the
map at http://mapreporter.navteq.com/
dur-web-external/.
• Please do not report errors in purple
“unverified” roads. Maps for these
areas are provided for reference only.
2 Unverified Area Routing P. 41
• Please do not report errors in places/
landmarks, such as changes in business
names. Information about points of
interest are constantly being updated.
An updated database is available for
purchase, usually in the fall of each year.
2 Obtaining Navigation Update Data
P. 187
• For vehicle position icon errors, screen
error messages, or other GPS-related
errors:
2 Troubleshooting P. 170
2 System Limitations P. 184
Honda Automobile
Customer Service Contact
Information
Honda Navi
American Honda Motor Co., Inc.
Honda Customer Service
Mail Stop 500-2N-7E
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: (800) 999-1009
Fax: (310) 783-3273
Visiting Your Dealer
If you have a question that you cannot
resolve using the available help resources,
you can consult your dealer. Please identify
the specific issue (e.g., error occurs when
you enter a specific address, when driving
on a certain road, or just when it’s cold) so
that the service technician can refer the
issue to the factory so that a solution can
be found. Be patient, the service technician
may be unfamiliar with your specific issue.
CR‑ZKA‑31SZT820.book186ページ２０１２年１０月９日 火曜日 午前８時１７分
187
Customer Assistance
Map Coverage
Reference Information
Map Coverage
The navigation system provides map
coverage for the contiguous United States,
Alaska, Hawaii, Canada, and Puerto Rico.
The map coverage consists of accurately
mapped (verified) metropolitan areas and a
less accurate (unverified) rural database.
Note that unverified areas are constantly
being reviewed and converted to verified
areas each year.
Contiguous United States
Puerto Rico
Canada
Hawaii
Alaska
Map coverage update information is
available from Honda Automobile
Customer Service or online at
www.hondanavi.com.
To find navigation system update
information:
1. Visit www.hondanavi.com.
2. Enter your vehicle model and model
year.
3. Click Map Coverage to display a list of
verified coverage areas on the most
recent update.
4. Click Map Coverage Details to display a
PDF document with a full listing of all
coverage areas.
Adobe® Reader® is required for
viewing and printing the Portable
Document Format (PDF) documents.
To download the latest version of
Adobe Reader, visit http://
get.adobe.com/reader/.
Obtaining Navigation
Update Data
Honda is continually expanding the scope
of the navigation system. Navigation
system software upgrades may be made
available periodically, usually in the fall of
each year.
To purchase an updated data file:
1. Obtain your vehicle’s VIN number and
the System/Device Information.
2 System/Device Information P. 167
2. Call the Honda Navigation Disc
Fulfilment Center at (888) 291-4675, or
order online at www.hondanavi.com.
Update data is not available from your
dealer. However, the dealer may assist you
in obtaining an update data for you out of
courtesy. There is no program for free
updates.
CR‑ZKA‑31SZT820.book187ページ２０１２年１０月９日 火曜日 午前８時１７分
188
Customer Assistance
Traffic Information
Reference Information
Traffic Information
• Continuously updated traffic
information is available in major
metropolitan areas across the 48
contiguous states and Hawaii.
• Visit automobiles.honda.com/traffic for
a complete listing of coverage areas and
other information.
Operation in Alaska,
Hawaii, Canada, and
Puerto Rico
All roads displayed on the map screens are
verified roads. Information in this manual
relating to “unverified” roads or areas is
not applicable.
Entering a destination address or place/
landmark on another island may result in a
screen caution message. This is because
there are no ferry routes between islands
in the database.
■ Map Coverage
■ Address and Place Entry
Screens
CR‑ZKA‑31SZT820.book188ページ２０１２年１０月９日 火曜日 午前８時１７分
189
Reference Information
Legal Information
END-USER TERMS
The data (“Data”) is provided for your
personal, internal use only and not for
resale. It is protected by copyright, and is
subject to the following terms and
conditions which are agreed to by you, on
the one hand, and NAVTEQ North
America, LLC (“NT”) and its licensors
(including their licensors and suppliers) on
the other hand.
© 2011 NAVTEQ. All rights reserved.
This data includes information taken with
permission from Canadian authorities,
including © Her Majesty the Queen in
Right of Canada, © Queen’s Printer for
Ontario, © Canada Post Corporation,
GeoBase®, © The Department of Natural
Resources Canada. All rights reserved.
NAVTEQ holds a non-exclusive license
from the United States Postal Service® to
publish and sell ZIP+4® information.
©United States Postal Service® 2011.
Prices are not established, controlled or
approved by the United States Postal
Service®. The following trademarks and
registrations are owned by the USPS:
United States Postal Service, USPS, and
ZIP+4.
Personal Use Only. You agree to use this
Data for the solely personal, non-
commercial purposes for which you were
licensed, and not for service bureau, time-
sharing or other similar purposes.
Accordingly, but subject to the restrictions
set forth in the following paragraphs, you
may copy this Data only as necessary for
your personal use to (i) view it, and (ii) save
it, provided that you do not remove any
copyright notices that appear and do not
modify the Data in any way. You agree
not to otherwise reproduce, copy, modify,
decompile, disassemble or reverse
engineer any portion of this Data, and may
not transfer or distribute it in any form, for
any purpose, except to the extent
permitted by mandatory laws. Multi-disc
sets may only be transferred or sold as a
complete set as provided by you and not as
a subset thereof.
Restrictions. Except where you have been
specifically licensed to do so by NT, and
without limiting the preceding paragraph,
you may not (a) use this Data with any
products, systems, or applications installed
or otherwise connected to or in
communication with vehicles, capable of
■ TERMS AND CONDITIONS
vehicle navigation, positioning, dispatch,
real time route guidance, fleet
management or similar applications; or (b)
with or in communication with any
positioning devices or any mobile or
wireless-connected electronic or computer
devices, including without limitation
cellular phones, palmtop and handheld
computers, pagers, and personal digital
assistants or PDAs.
Warning. The Data may contain
inaccurate or incomplete information due
to the passage of time, changing
circumstances, sources used and the
nature of collecting comprehensive
geographic data, any of which may lead to
incorrect results.
No Warranty. This Data is provided to
you “as is,” and you agree to use it at your
own risk. NT and its licensors (and their
licensors and suppliers) make no
guarantees, representations or warranties
of any kind, express or implied, arising by
law or otherwise, including but not limited
to, content, quality, accuracy,
completeness, effectiveness, reliability,
fitness for a particular purpose, usefulness,
use or results to be obtained from this
Data, or that the Data or server will be
uninterrupted or error-free.
CR‑ZKA‑31SZT820.book189ページ２０１２年１０月９日 火曜日 午前８時１７分
190
Legal Information
END-USER TERMS
Reference Information
Disclaimer of Warranty: NT AND ITS
LICENSORS (INCLUDING THEIR LICENSORS
AND SUPPLIERS) DISCLAIM ANY
WARRANTIES, EXPRESS OR IMPLIED, OF
QUALITY, PERFORMANCE,
MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE OR NON-
INFRINGEMENT. Some States, Territories
and Countries do not allow certain
warranty exclusions, so to that extent the
above exclusion may not apply to you.
Disclaimer of Liability: NT AND ITS
LICENSORS (INCLUDING THEIR LICENSORS
AND SUPPLIERS) SHALL NOT BE LIABLE TO
YOU: IN RESPECT OF ANY CLAIM,
DEMAND OR ACTION, IRRESPECTIVE OF
THE NATURE OF THE CAUSE OF THE
CLAIM, DEMAND OR ACTION ALLEGING
ANY LOSS, INJURY OR DAMAGES, DIRECT
OR INDIRECT, WHICH MAY RESULT FROM
THE USE OR POSSESSION OF THE
INFORMATION; OR FOR ANY LOSS OF
PROFIT, REVENUE, CONTRACTS OR
SAVINGS, OR ANY OTHER DIRECT,
INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES ARISING OUT
OF YOUR USE OF OR INABILITY TO USE
THIS INFORMATION, ANY DEFECT IN THE
INFORMATION, OR THE BREACH OF THESE
TERMS OR CONDITIONS, WHETHER IN AN
ACTION IN CONTRACT OR TORT OR
BASED ON A WARRANTY, EVEN IF NT OR
ITS LICENSORS HAVE BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES.
Some States, Territories and Countries do
not allow certain liability exclusions or
damages limitations, so to that extent the
above may not apply to you.
Export Control. You agree not to export
from anywhere any part of the Data
provided to you or any direct product
thereof except in compliance with, and
with all licenses and approvals required
under, applicable export laws, rules and
regulations.
Entire Agreement. These terms and
conditions constitute the entire agreement
between NT (and its licensors, including
their licensors and suppliers) and you
pertaining to the subject matter hereof,
and supersedes in their entirety any and all
written or oral agreements previously
existing between us with respect to such
subject matter.
Governing Law. The above terms and
conditions shall be governed by the laws of
the State of Illinois, without giving effect
to (i) its conflict of laws provisions, or (ii)
the United Nations Convention for
Contracts for the International Sale of
Goods, which is explicitly excluded. You
agree to submit to the jurisdiction of the
State of Illinois for any and all disputes,
claims and actions arising from or in
connection with the Data provided to you
hereunder.
Government End Users. If the Data is
being acquired by or on behalf of the
United States government or any other
entity seeking or applying rights similar to
those customarily claimed by the United
States government, this Data is a
“commercial item” as that term is defined
at 48 C.F.R. (“FAR”) 2.101, is licensed in
accordance with this End User License
Agreement, and each copy of the Data
delivered or otherwise furnished shall be
marked and embedded as appropriate
with the following “Notice of Use,” and
shall be treated in accordance with such
Notice:
CR‑ZKA‑31SZT820.book190ページ２０１２年１０月９日 火曜日 午前８時１７分
191
Legal Information
As required by the FCC
Reference Information
If the Contracting Officer, federal
government agency, or any federal official
refuses to use the legend provided herein,
the Contracting Officer, federal
government agency, or any federal official
must notify NAVTEQ prior to seeking
additional or alternative rights in the Data.
CONTRACTOR (MANUFACTURER/
SUPPLIER) NAME: NAVTEQ
CONTRACTOR (MANUFACTURER/
SUPPLIER) ADDRESS: 425 West Randolph
St., Chicago, Illinois 60606
NOTICE OF USE
This Data is a commercial item as dened
in FAR 2.101 and is subject to the End
User License Agreement under which this
Data was provided.
© 2011 NAVTEQ - All rights reserved.
As required by the FCC
1)This device complies with Part 15 of the
FCC Rules and Canadian RSS-210/RSS-
Gen. Operation is subject to the following
two conditions: (1) this device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
2)The FCC requires the user to be notified
that any changes or modifications made to
this device that are not expressly approved
by the party responsible for compliance
may void the user's authority to operate
the equipment.
3)This product emits radio frequency
energy, but the radiated output power of
this device is far below the FCC and IC
radio frequency exposure limits. This
equipment complies with FCC and IC RF
radiation exposure limits set forth for an
uncontrolled environment. Nevertheless,
the device should be used in such a
manner that the potential for human
contact with the antenna during normal
operation is minimized.
CR‑ZKA‑31SZT820.book191ページ２０１２年１０月９日 火曜日 午前８時１７分
192
CR‑ZKA‑31SZT820.book192ページ２０１２年１０月９日 火曜日 午前８時１７分
193
Voice Commands
Voice Commands .................................. 194
Global Commands ............................... 194
Navigation Commands......................... 194
Climate Control Commands................. 196
Audio Commands ................................ 197
Cellular Phone Commands ................... 199
Main Setup Screen Commands ............ 199
On-Screen Commands ......................... 200
Spelling Assistance ............................... 200
CR‑ZKA‑31SZT820.book193ページ２０１２年１０月９日 火曜日 午前８時１７分
194
Voice Commands
Voice Commands
Global Commands
The system accepts these commands on
any screen.
Help (displays available commands for
current screen)
Display map (equivalent to MAP)
Display menu (equivalent to DEST)
Display information (equivalent to INFO)
Display audio screen (equivalent to
AUDIO)
Back (equivalent to K (Back))
Cancel (equivalent to CANCEL)
What is today’s date?
What time is it?
Navigation Commands
The system accepts these commands on a
map/guidance screen.
Display menu (if en route, displays the
Route screen)
Display navigation (if en route, displays
the Route screen)
Display map
Display map guide (when en route,
shows the next guidance point)
Display information (or Information)
Display audio screen
Display phone screen
Cancel
Backward (or Back)
What time is it?
What is today’s date?
Help (reads list of General and Map
Display Commands)
■ General Commands
Display current location (shows current
latitude, longitude, and elevation)
Display/Hide (specify icon type):
ATM
gas station
restaurant
post office
grocery store
lodging (hotel, motel)
parking garage
parking lot
school
hospital
freeway exit information
traffic
traffic speeds
traffic icons
traffic incidents
Go home 1
Go home 2
Register the current location (stores
current location in the Address Book)
■ Map Display Commands
CR‑ZKA‑31SZT820.book194ページ２０１２年１０月９日 火曜日 午前８時１７分
195
Voice Commands
Navigation Commands
Voice Commands
Display north up
Display heading up
Display zoom in
Display zoom out
Display (specify scale):
1/20 mile (80 m) scale
1/8 mile (200 m) scale
1/4 mile (400 m) scale
1/2 mile (800 m) scale
1 mile (1600 m) scale
2 mile (3 km) scale
5 mile (8 km) scale
15 mile (24 km) scale
50 mile (80 km) scale
150 mile (240 km) scale
350 mile (560 km) scale
1000 mile (1600 km) scale
Max zoom in
Max zoom out
■ Map Scale Commands
Find nearest (specify place):
Auto service center
ACURA dealers
HONDA dealers
Gas station
Hydrogen station
Auto parts & electronics shop
Auto repair & maintenance shop
Car wash & detailing shop
Motorcycle dealers
Other car dealers
Roadside assistance
Banking center
ATM
Bank
Check cashing
Community
Business
City hall
Civic center
Convention center
Court house
Higher education
Library
Post office
School
■ Find Place Commands
Emergency room
Hospital
Police station
Veterinarian
Lodging
Bed & breakfast
Hotel
Leisure center
Amusement park
Golf course
Historical monument
Marina
Movie theater
Museum
Park
Performing arts
Sports complex
Tourist attraction
Restaurant
American restaurant
Californian restaurant
Chinese restaurant
Coffee shop
Continental restaurant
Fast food restaurant
French restaurant
German restaurant
Greek restaurant
Continued
CR‑ZKA‑31SZT820.book195ページ２０１２年１０月９日 火曜日 午前８時１７分
196
Voice Commands
Climate Control Commands
Voice Commands
Ice cream shop
Indian restaurant
Italian restaurant
Japanese restaurant
Korean restaurant
Mexican restaurant
Pizza
Seafood restaurant
Thai restaurant
Vegetarian restaurant
Vietnamese restaurant
Other restaurant
Shopping area
Accessory store
Book store
Clothing store
Furniture store
Grocery store
Home improvement store
Mall
Office supply store
Pharmacy
Pet food store
Sewing store
Shoe store
Sporting goods store
Toy store
Travel center
Airport
Automobile club
Bus station
Camping
Commuter rail station
Ferry terminal
Named place
Park & ride
Parking garage
Parking lot
Rental car agency
Rest area
Ski area
Tourist information
Train station
Travel agency
Truck stop
The system accepts these commands
when a route is set.
How long to the destination?
How far to the destination?
Display destination map
Display entire route
■ Route Commands
Climate Control
Commands
The system accepts these commands on
most screens.
Climate control automatic (maintains
selected temperature)
Climate control off
Air conditioner on*
Air conditioner off*
Climate control defrost on*
Climate control defrost off*
Rear defrost on*
Rear defrost off*
Climate control fresh air
Climate control recirculate
Climate control vent
Climate control bi-level (vent and floor)
Climate control floor
Climate control floor and defrost
Fan speed up
Fan speed down
Fan speed # (#: 1 to 7)
Temperature # degrees (#: 57 to 87 °F/
15 to 29 °C)
Driver temperature # degrees (#: 57 to
87 °F/15 to 29 °C)
CR‑ZKA‑31SZT820.book196ページ２０１２年１０月９日 火曜日 午前８時１７分
197
Voice Commands
Audio Commands
Voice Commands
Passenger temperature # degrees (#: 57
to 87 °F/15 to 29 °C)
Temperature up
Temperature down
Temperature max hot
Temperature max cold
* These commands toggle the function
on and off, so the command may not
match your intended action.
Audio Commands
The system accepts these commands on
most screens.
Audio*
Audio on
Audio off
* This command toggles the function on
and off, so the command may not
match your intended action.
NOTE:
Audio volume levels cannot be controlled
using voice control.
Radio*
Radio on
Radio off
Radio select FM1
Radio select FM2
Radio select AM
Radio tune to # FM (#: frequency, e.g.,
95.5)
Radio tune to # AM (#: frequency, e.g.,
1020)
Radio seek up
Radio seek down
Radio next station
■ Radio Commands
Radio preset # (#: 1 to 6)
Radio FM preset # (#: 1 to 6)
Radio FM1 preset # (#: 1 to 6)
Radio FM2 preset # (#: 1 to 6)
Radio AM preset # (#: 1 to 6)
Radio auto select*
Radio scan*
* These commands toggle the function
on and off, so the command may not
match your intended action.
CR‑ZKA‑31SZT820.book197ページ２０１２年１０月９日 火曜日 午前８時１７分
198
Voice Commands
Audio Commands
Voice Commands
DISC play
DISC play track # (#: 1 to 30)
DISC skip forward
DISC skip back
DISC track random*
DISC track repeat*
DISC track scan*
DISC folder up
DISC folder down
DISC folder random*
DISC folder repeat*
DISC folder scan*
DISC normal play (cancels random,
repeat, or scan play mode, resumes
normal play mode)
* These commands toggle the function
on and off, so the command may not
match your intended action.
■ Disc Commands
USB play
USB play track # (#: 1 to 30)
USB skip forward
USB skip back
USB track random*
USB track repeat*
USB track scan*
USB folder up
USB folder down
USB folder random*
USB folder repeat*
USB folder scan*
USB normal play (cancels random,
repeat, or scan play mode, resumes
normal play mode)
* These commands toggle the function
on and off, so the command may not
match your intended action.
■ USB Commands
iPod play
iPod play track # (#: 1 to 30)
iPod skip forward
iPod skip back
iPod track shuffle*
iPod album shuffle*
iPod track repeat*
iPod normal play (cancels repeat or shuffle
play mode, resumes normal play mode)
* These commands toggle the function
on and off, so the command may not
match your intended action.
Pandora play*1
Pandora on*1
Pandora off*1
Pandora like song
Pandora dislike song
Pandora skip forward (or next song)
Pandora bookmark song
Pandora bookmark artist
Pandora station up
Pandora station down
Pause*2
Resume*2
■ iPod® Commands
■ Pandora® Commands
CR‑ZKA‑31SZT820.book198ページ２０１２年１０月９日 火曜日 午前８時１７分
199
Voice Commands
Cellular Phone Commands
Voice Commands
*1. These commands toggle the function
on and off, so the command may not
match your intended action.
*2. These commands can be accepted
from Audio screen only.
Bluetooth audio play
Bluetooth audio skip forward
Bluetooth audio skip back
Bluetooth audio pause
Bluetooth audio resume
NOTE:
Bluetooth® Audio commands may not
work on some phones or Bluetooth®
audio devices.
AUX play (or Auxiliary play)
■ Bluetooth® Audio Commands
■ AUX Commands
Cellular Phone Commands
The system accepts these commands only
on the PHONE screen.
Redial
Call History
Phonebook
Dial
Phone Setup
Phone Menu
Speed Dial 1
Speed Dial 2
More Speed Dial Lists
These commands can be made from any screen.
Dial (Call) by number
Dial (Call) by voice tag
Text message
Text message notice off*
Text message notice on*
Read
Reply
Send
Cancel
Next message
Previous message
* From the Phone setup screen only.
■ Text Message Commands
Main Setup Screen
Commands
The system accepts these commands on
the Main Setup screen.
Brightness up
Brightness down
Brightness minimum/min.
Brightness maximum/max.
Contrast up
Contrast down
Contrast minimum/min.
Contrast maximum/max.
Black level up
Black level down
Black level minimum/min.
Black level maximum/max.
Volume up
Volume down
Volume minimum/min.
Volume maximum/max.
Volume off
Guidance prompts normal
Guidance prompts maximum/max
Guidance prompts minimum/min
CR‑ZKA‑31SZT820.book199ページ２０１２年１０月９日 火曜日 午前８時１７分
200
Voice Commands
On-Screen Commands
Voice Commands
On-Screen Commands
The system accepts these commands on
any screen. There are over 100 on-screen
commands. Say what is written on the
screen to activate that selection. For lists,
you can say the list item number to select
that item.
Next/Previous*1
Right/Left*1
Up/Down*2
Return
OK (excluding Startup Confirmation
screen)
Delete
*1. To get to another page or tab.
*2. While driving, you can scroll down
the list up to three pages.
Spelling Assistance
The voice control system can also
recognize phonetic alphabet input for
numbers, letters, accented letters,
punctuation marks, and symbols.
NOTE:
When selecting letters using the voice
control system, a confirmation box may
pop up to confirm the entry.
■ Numbers
Say … Say … or Number …
1 One
2Two
3 Three
4 Four
5 Five
6Six
7 Seven
8Eight
9 Nine
0Zero
CR‑ZKA‑31SZT820.book200ページ２０１２年１０月９日 火曜日 午前８時１７分
201
Voice Commands
Spelling Assistance
Voice Commands
■ Letters
Say … Or say…
A Alpha/Apple
B Bravo/Boy
C Charlie
DDelta/Dog
E Echo/Edward
F Foxtrot/Frank
G Golf/George
H Hotel/Henry
I India/Igloo
J Juliet/John
K Kilo/King
L Lima/Larry
M Mike/Mary
N November/Nancy
O Oscar
P Papa/Paul
Q Quebec/Queen
R Romeo/Robert
S Sierra/Sam
T Tango/Tom
U Uniform/Uncle
VVictor
W Whiskey/William
X X-ray
Y Yankee/Yellow
Z Zulu/Zebra
Say … Or say…
■ Accented Letters
Say … Say … or Symbol …
À A grave
 A circumflex
Ä A umlaut
Ç C cedilla
È E grave
ÉE acute
Ê E circumflex
Ë E umlaut
Ì I grave
Î I circumflex
Ï I umlaut
Ô O circumflex
Ù U grave
Û U circumflex
Continued
CR‑ZKA‑31SZT820.book201ページ２０１２年１０月９日 火曜日 午前８時１７分
202
Voice Commands
Spelling Assistance
Voice Commands
Ü U umlaut
Say … Say … or Symbol …
■ Symbols
Say … Say … or Symbol …
@ At sign
^ Caret
* Asterisk
_ Underscore
` Back quote
, Comma
. Dot
? Question mark
: Colon
;Semicolon
+ Plus
-Hyphen
! Exclamation point
“ Double quote
# Pound
$Dollar
% Percent
&Ampersand
‘ Apostrophe
( Open parenthesis
) Close parenthesis
~Tilde
/ Slash
< Less than
> Greater than
{ Open brace
} Close brace
k Enter
Say … Say … or Symbol …
CR‑ZKA‑31SZT820.book202ページ２０１２年１０月９日 火曜日 午前８時１７分
204
Index
Index
Symbols
K (Back) Button
....................................5
,
19
NB (Channel) Button
............................141
a (Display Mode) Button
......................26
j (Hang-Up) Button
............................5
,
159
h (Pick-Up) Button
...................... 5
,
159
,
160
d (Talk) Button
......................................5
,
19
RU (Volume) Button
..............................141
A
A.SEL (Auto Select)
....................................117
Add to Address Book
..........................77
,
112
Add to Dest. List
.................. 77
,
106
,
110
,
111
Address
Editing Address Book
.................................32
Editing Avoid Area
......................................44
Setting Destination
.....................................58
Address Book
Editing Address Book
.................................30
Setting Destination
.....................................63
Address Book PIN
.........................................36
Adjust Time
...................................................47
Advanced (Place Category)
........................67
Audio
...........................................................113
Basic Operation
.............................................6
Remote Control
........................................140
Sound Setup
.............................................139
Voice Commands List
...............................197
AUDIO Button
................................................4
Audio Menu
Bluetooth® Audio
....................................138
FM/AM Radio
............................................118
Auto Answer
..............................................155
Auto Daylight
.............................................. 46
Auto Service (Place Category)
................... 67
Auto Time Zone
.......................................... 46
Auto Transfer
............................................ 155
AUX
Input Jack
................................................. 114
Voice Commands List
.............................. 199
Avoid Streets
.............................................. 102
B
Banking (Place Category)
........................... 67
Basic Settings
......................................... 23
,
24
Black Level
.................................................... 21
Bluetooth Setup
........................................ 155
Bluetooth Connection
.............................. 155
Bluetooth® Audio
Playing
...................................................... 136
Voice Commands List
.............................. 199
Bluetooth® HandsFreeLink®
.................. 143
Editing Phone Info
................................... 154
Making a Call
........................................... 156
Pairing a Phone
........................................ 146
Phone Setup
............................................. 155
Receiving a Call
........................................ 159
Setting Speed Dials
.................................. 151
Brightness
............................................... 21
,
26
C
Call
Calculate Route Screen
...................... 77
,
112
Call History
................................................. 158
Cancel Route
.............................................. 102
Category
Editing Address Book
................................. 32
Place Category List
................................... 203
Setting Destination
..................................... 67
CD/AUX Button
..... 6
,
121
,
126
,
129
,
133
,
136
Change Language
....................................... 18
Change Route Preference
.......................... 78
Change State
................................................ 59
City
................................................................ 60
City Vicinity
Setting Destination
..................................... 68
Clear All Speed Dial
.................................... 53
Clock Adjustment
........................................ 46
Adjust Time
................................................ 47
Auto Daylight
............................................. 46
Auto Time Zone
.......................................... 46
Clock Format
.............................................. 46
Resetting
.................................................... 47
Clock Format
................................................ 46
Clock Type
.................................................... 48
Color
.............................................................. 24
Map Color
.................................................. 25
Menu Color
................................................ 25
Community (Place Category)
..................... 67
Connect (Phone)
........................................ 154
Continue Trip
............................................. 112
Contrast
........................................................ 21
Coordinate
................................................... 73
Correct Vehicle Position
............................. 51
Current Location
.......................................... 98
Current Position
Editing Address Book
................................. 32
Setting Destination
..................................... 75
CR‑ZKA‑31SZT820.book204ページ２０１２年１０月９日 火曜日 午前８時１７分
205
Index
Index
D
Day Mode
Map Color
.................................................. 25
Menu Color
................................................ 25
Switching Display Mode
.............................26
Delete this Phone
......................................149
DEST Button
Changing Route
.......................................101
Entering a Destination
................................56
DEST Menu 1
................................................ 56
DEST Menu 2
................................................ 56
Destination Map
.......................................... 79
Detour
......................................................... 102
Dial
..............................................................157
Directions
...................................................... 88
Disc
Playing
...................................................... 121
Voice Commands List
...............................198
Display Voice Command Tips
..................... 23
E
Edit Avoid Area
........................................... 43
Edit Speed Dial
........................................... 151
Edit Waypoint Search Area
........................ 45
Emergency (Place Category)
...................... 67
Error Messages
........................................... 177
Disc Player
................................................ 178
iPod®
........................................................ 179
Navigation System
....................................177
Pandora®
................................................. 179
USB Flash Drive
......................................... 180
Exit Info.
....................................................... 89
F
Favorite Subcategory
..................................69
Find Nearest...
............................................108
FM/AM Button
.......................................6
,
116
FM/AM Radio
Playing
......................................................116
Voice Commands List
...............................197
Folder List
Disc
...........................................................123
USB Flash Drive
.........................................135
G
Go Home 1
....................................................10
Go Home 1 PIN
.............................................36
Go Home 2
....................................................10
Go Home 2 PIN
.............................................36
Guidance Menu
............................................87
Directions
....................................................88
Exit Info
.......................................................89
Guidance Mode
..........................................90
Guidance Mode
............................................90
Guidance Prompts
.......................................22
H
Heading-up
...................................................97
Home Address 1
.....................................10
,
35
Home Address 2
.....................................10
,
35
Honda Customer Services
.........................186
I
Icon Option
...................................................93
Intersection
.................................................. 74
iPod®
Connecting, Disconnecting
............. 125
,
132
Playing
...................................................... 125
Voice Commands List
.............................. 198
K
Keyboard Layout
......................................... 23
L
Language
..................................................... 28
Leisure (Place Category)
............................. 67
Lodging (Place Category)
........................... 67
M
Map Color
.................................................... 25
Map Input
Editing Avoid Area
..................................... 44
Setting Destination
.................................... 75
Map Legend
............................................. 7
,
94
Map Menu
................................................... 85
Map Screen
.................................................. 80
Icon
.................................................. 7
,
92
,
96
Orientation
................................................. 97
Scale
........................................................... 95
Map Update
Checking Version
..................................... 167
Obtaining Update Data
............................ 187
Viewing Update Status
............................ 167
MAP/GUIDE Button
................................. 8
,
90
Menu (DEST Menu 1)
.................................. 56
Menu (DEST Menu 2)
.................................. 56
CR‑ZKA‑31SZT820.book205ページ２０１２年１０月９日 火曜日 午前８時１７分
206
Index
Index
Menu (Route)
.............................................101
Menu Color
...................................................25
MODE Button
.............................................140
Multi-View Rear Camera
..........................168
Music Search
iPod®
........................................................128
Mute
............................................................159
My Destination
Adding Waypoint
.....................................103
Editing
.......................................................107
N
Night Mode
Map Color
...................................................25
Menu Color
................................................25
Switching Display Mode
.............................26
North-up
.......................................................97
O
Off-road Tracking
Driving
........................................................83
Setting
........................................................50
P
Pair Phone
...................................................146
Pairing Code
...............................................148
Pandora®
Playing
......................................................129
Voice Commands List
...............................198
Personal Information
..................................29
Phone
Voice Commands List
...............................199
PHONE Button
............................................... 4
Phone Setup
............................................... 144
Phonebook
Making a Call
........................................... 157
PIN Numbers
Personal Info
.............................................. 36
Phone
....................................................... 154
Place Category
Editing Address Book
................................. 32
Place Category List
................................... 203
Setting Destination
.................................... 67
Place Name
Editing Address Book
................................. 32
Setting Destination
.............................. 65
,
68
Place Phone No.
Editing Address Book
................................. 32
Setting Destination
.................................... 72
Previous Destination
Deleting
...................................................... 38
Editing Address Book
................................. 32
Setting Destination
.................................... 64
Q
Quick Mix
................................................... 131
R
Radio
FM/AM
..................................................... 116
Random (Pairing Code)
............................ 148
RDS Search
................................................. 119
Read Radio Text
........................................ 120
Recalculation
......................................... 40
,
83
Repeat
iPod®
....................................................... 127
USB Flash Drive
......................................... 135
Replace this Phone
.................................... 154
Rerouting
...................................................... 40
Reset Clock Settings
.................................... 47
Reset Factory Default
.................................. 52
Restaurant (Place Category)
...................... 67
Route (Menu)
............................................. 101
Route Pref.
................................................... 78
Routing & Guidance
.................................... 39
S
Scan
Disc
........................................................... 122
FM/AM Radio
........................................... 117
USB Flash Drive
......................................... 134
Search by Keyword
...................................... 68
Security PIN Code
...................................... 182
SEEK/SKIP Button
........................................... 4
Shopping (Place Category)
......................... 67
Show icon on Map
...................................... 92
Single Screen
................................................ 90
Sort by Distance to Travel
.......................... 68
Sound Setup
............................................... 139
Speed Dial
Making a Call
........................................... 158
Registering
................................................ 151
Split Screen
................................................... 91
Street
............................................................. 61
System/Device Information
...................... 167
CR‑ZKA‑31SZT820.book206ページ２０１２年１０月９日 火曜日 午前８時１７分
207
Index
Index
T
Text Message Notice
.................................155
Text Messages
Receiving
.................................................. 163
Replying
.................................................... 164
Voice Commands List
...............................199
Touch Tones
............................................... 159
Traffic Detail
................................................ 99
Traffic Rerouting
......................................... 99
Transfer Call
............................................... 159
Travel (Place Category)
...............................67
Trip Computer
............................................ 166
Tune
FM/AM Radio
........................................... 117
U
Units (mile or km)
........................................ 23
Unverified Area Routing
............................41
Update System Software
Finding Update Information
..................... 187
Obtaining Update Data
............................187
USB Flash Drive
Connecting, Disconnecting
..............125
,
132
Playing
...................................................... 132
Voice Commands List
...............................198
V
Vehicle
.......................................................... 49
Correct Vehicle Position
.............................51
Off-road Tracking
....................................... 50
Verbal Reminder
.......................................... 24
View Area Map
............................................ 43
View Routes
..................................................78
Voice
Map Menu
..................................................84
Voice Commands
Basic Operation
.............................................9
Help
............................................................13
Voice Commands List
...............................194
Voice Control System
.................................19
Voice Control Operation
Basic Operation
.............................................5
Voice Recognition Tutor
.............................23
Voice Tag
....................................................152
Editing
.......................................................153
Registering
................................................152
VOL 9 (Volume/Power) Knob
....................6
Volume
..........................................................21
Guidance
....................................................21
Phone
........................................................156
W
Waypoint
Adding
......................................................103
Deleting, Ordering
....................................107
Z
ZOOM IN/OUT Button
.............................4
,
95
CR‑ZKA‑31SZT820.book207ページ２０１２年１０月９日 火曜日 午前８時１７分
