2960311253_EN/230316.1013
Dryer
User Manual
EN
DPE7400
This product was manufactured using the latest technology in environmentally friendly conditions.
Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been manufac-
tured with high quality and technology will give you the best results. We advise you to read
through this manual and the other accompanying documentation carefully before using your
product and keep it for future reference. If you transfer the product to someone else, give its
manual as well. Pay attention to all details and warnings specied in the user manual and fol-
low the instructions given therein.
Use this user manual for the model indicated on the cover page.
Explanation of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful
hints about usage.
A
Warning for hazardous situations
with regard to life and property.
B
Warning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the
product are manufactured from
recyclable materials in accordance
with our National Environment
Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
3 / EN
Dryer / User Manual
1 Important safety and environmental
instructions
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons shall vod any warranty.
1.1 General safety
• Dryer can be used by chldren at the age of 8 and over
and persons wth physcal, sensory or mental dsorders
or unlearned or nexperenced people as long as they
are attended by a person who wll be responsble for
ther safety or who wll nstruct them accordngly about
use of the product. Chldren should not tamper wth the
machne. Cleanng and user mantenance works should
not be carred out by chldren unless they are attended by
someone.
• Chldren of less than 3 years should be kept away unless
contnuously supervsed.
• Adjustable feet should not be removed. (See Overvew)
The gap between the dryer and the surface should not be
reduced by the materals such as carpet, wood and tape.
Ths wll cause problems wth the dryer.
• Always have the nstallaton and reparng procedures
carred out by the Authorzed Servce Agent.
Manufacturer shall not be held lable for damages that
may arse from procedures carred out by unauthorzed
persons.
• Never wash the dryer by sprayng or pourng water onto t!
There s the rsk of electrc shock!
4 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.1.1 Electrcal safety
A
Electrcal safety nstructons should be followed
whle electrcal connecton s made durng the
nstallaton.
• Connect the dryer to a grounded outlet protected by
a fuse at the value specfed on the type label. (See
Overvew) Have the groundng nstallaton performed by
a qualfed electrcan. Our company shall not be lable for
any damages that wll arse when the dryer s used wthout
groundng n accordance wth the local regulatons.
• The voltage and allowed fuse protecton s stated on the
type label plate.(See Overvew)
• The voltage specfed on the type label must be equal to
your mans voltage. (See Overvew)
• Unplug the dryer when t s not n use.
• Unplug the dryer from the mans durng nstallaton,
mantenance, cleanng and repar works.
• Do not touch the plug wth wet hands! Never unplug by
pullng on the cable, always pull out by grabbng the plug.
• Do not use extenson cords, mult-plugs or adaptors to
connect the dryer to power supply n order to decrease the
rsk of fre and electrc shock.
• Power cable plug must be wthn easy reach after
nstallaton.
B
Damaged mans cable should be changed notfyng
the Authorzed Servce.
B
If the dryer s faulty, t must not be operated unless
t s repared by an authorzed servce agent! There s
the rsk of electrc shock!
5 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.1.2 Product safety
Ponts to be taken nto consderaton for fre hazard:
Below specfed laundry or tems must not be dred
n the dryer consderng fre hazard.
• Unwashed laundry tems
• Items soled wth ol, acetone, alcohol, fuel ol,
kerosene, stan removers, turpentne, paraffn or
paraffn removers must be washed n hot water
wth plenty of detergent before beng dred n the
dryer.
For ths reason especally the tems contanng the
above specfed stans must be washed very well, to
do ths use adequate detergent and choose a hgh
washng temperature.
Below specfed laundry or tems must not be dred n
the dryer due to the fre hazard:
• Garments or pllows bolstered wth rubber foam
(latex foam), shower bonnets, water resstant
textles, materals wth rubber renforcement and
rubber foam pads.
• Clothng cleaned wth ndustral chemcals.
Items such as lghters, matches, cons, metal parts,
needle etc. may damage the drum set or may lead to
functonal problems. Therefore check all the laundry
that you wll load nto your dryer.
Never stop your dryer before the programme
completes. If you must do ths, remove all laundry
quckly and lay them out to dsspate the heat.
6 / EN
Dryer / User Manual
Important instructions for safety and
environment
Clothes that are washed nadequately may gnte on
ther own and even may gnte after dryng ends.
Ol-affected tems can gnte spontaneously,
especally when exposed to heat sources such as n
a tumble dryer. The tems become warm, causng an
oxdaton reacton n the ol. Oxdaton creates heat.
If the heat cannot escape, the tems can become hot
enough to catch fre. Plng, stackng or storng ol-
affected tems can prevent heat from escapng and
so create a fre hazard.
If t s unavodable that fabrcs that contan
vegetable or cookng ol or have been contamnated
by har care products be placed n a tumble dryer
they should frst be washed n hot water wth extra
detergent - ths wll reduce, but not elmnate, the
hazard.
• You must provde enough ventlaton n order to prevent
gases extng from devces operatng wth other types of
fuels ncludng the naked flame from accumulatng n the
room due to the back fre effect.
A
Underwear that contans metal renforcements
should not be dred n the dryer. Dryer may be
damaged f metal renforcements come loose and
break off durng dryng.
C
Use softeners and smlar products n accordance
wth the nstructons of ther manufacturers.
C
Always clean the lnt flter before or after each
loadng. Never operate the dryer wthout the lnt
flter nstalled.
7 / EN
Dryer / User Manual
Important instructions for safety and
environment
• Never attempt to repar the dryer by yourself. Do not
perform any repar or replacement procedures on the
product even f you know or have the ablty to perform
the requred procedure unless t s clearly suggested n the
operatng nstructons or the publshed servce manual.
Otherwse, you wll be puttng your lfe and others' lves n
danger.
• There must not be a lockable, sldng or hnged door that
may block the openng of the loadng door n the place
where your dryer s to be nstalled.
• Install your dryer at places sutable for home use. (Laundry,
bathroom, closed balcony, garage etc.)
• Make sure that pets do not enter the dryer. Check the
nsde of the dryer before operatng t.
• Do not lean on the loadng door of your dryer when t s
open, otherwse t may fall over.
• The lnt must not be allowed to accumulate around the
tumble dryer.
• The fnal step of the dryng cycle (cool-down cycle) occurs
wthout applyng heat to ensure that the tems are left at a
temperature that wll not damage them.
8 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.2 Mountng over a washng machne
• A fxng devce should be used between the two machnes
when nstallng the dryer above a washng machne. The
fttng devce must be nstalled by the authorzed servce
agent.
• Total weght of the washng machne and the dryer -wth
full load- when they are placed on top of each other
reaches to approx. 180 klograms. Place the products on a
sold floor that has suffcent load carryng capacty!
A
Washng machne cannot be placed on the dryer.
Pay attenton to the above warnngs durng the
nstallaton on your washng machne.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm
Can be installed
Can be
installed
Cannot be
installed
60 cm
Can be installed
Cannot be
installed
9 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.3 Intended use
• Dryer has been desgned for domestc use. It s not
desgned for commercal purposes and should not be used
for other purposes.
• Use the dryer only for dryng laundry that are marked
accordngly.
• Manufacturer denes any lablty for the damages arsng
from msuse or faulty handlng of the product.
• The servce lfe of the dryer that you purchased s 10 years.
Durng ths perod, orgnal spare parts wll be avalable to
operate the dryer properly.
1.4 Chldren's safety
• Packagng materals are dangerous to chldren. Keep
packagng materals away from chldren.
• Electrcal products are dangerous for the chldren. Keep
chldren away from the product when t s operatng. Do
not let them tamper wth the dryer. Use the chld-proof
lock n order to prevent the chldren to tamper wth the
dryer.
C
Chld-proof lock s on the control panel. (See Chld-
proof lock)
• Keep loadng door closed even when the dryer s not n
use.
10 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.5 Compliance with the WEEE regulation and disposing of the
waste product
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which
can be reused and are suitable for recycling. Do not dispose of the waste product
with normal domestic and other wastes at the end of its service life. Take it to the
collection center for the recycling of electrical and electronic equipment. Please
consult your local authorities to learn about these collection centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not
contain harmful and prohibited materials specified in the Directive.
1.7 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance
with our National Environment Regulations. Do not dispose of the packaging materials
together with the domestic or other wastes. Take them to the packaging material collection
points designated by the local authorities.
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 54 cm
Capacity (max.) 7 kg**
Net weight (plastic front door usage) 46,5 kg
Net weight (glass front door usage) 48,5 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
C
Technical specifications of the dryer are subject to change without notice to
improve the quality of the product.
C
Figures in this manual are schematic and may not match the product exactly.
C
Values stated on markers on the dryer or in the other published documentation
accompanying with the dryer are obtained in laboratory in accordance with the
relevant standards. Depending on operational and environmental conditions of the
dryer, these values may vary.
11 / EN
Dryer / User Manual
2 Your Dryer
2.1 Package Contents
1
2 3
5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.
12 / EN
Dryer / User Manual
3 Installation
Before the calling the nearest Authorized
Service for the installation of the dryer, en-
sure that electrical installation and water
drain is appropriate referring to the user’s
manual. (See 3.3 Connecting to the drain
and 3.5 Electrical connection) If they are
not suitable, contact a qualied electrician
and technician to make necessary arrange-
ments.
C
Preparation of the dryer's location
as well as the electrical and waste
water installations is the owners
responsibility.
A
Prior to installation, visually check
if the dryer has any defects on it.
If the dryer is damaged, do not
have it installed. Damaged prod-
ucts cause risks for your safety.
A
Let your dryer wait for 12 hours
before starting to use it.
3.1 Appropriate installation
location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer
will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer
shall be placed against a wall.
B
Do not place the dryer on the
power cable.
3.2 Removing the
transportation safety
assembly
A
Remove the transportation safety
assembly before using the dryer
for the rst time.
• Open the loading door.
• There is a nylon bag inside the drum that
contains a piece of styrofoam. Hold it
from its section marked with XX XX.
• Pull the nylon towards yourself and
remove the transportation safety
assembly.
A
Check that no part of the trans-
portation safety assembly re-
mains inside the drum.
3.3 Connecting to the drain
In products equipped with condenser unit,
water accumulates in the water tank during
the drying cycle. You should drain accumu-
lated water after each drying cycle.
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.
13 / EN
Dryer / User Manual
Installation
Connecting the water drain hose
1-2 Pull hose at the behnd of the dryer
by hand n order to dsconnect t from
where t s connected. Do not use any
tools to remove the hose.
3 Connect one end of the dran hose
suppled wth the dryer to the
connecton pont from where you
removed the hose of the product n
prevous step.
4 Connect the other end of the dran hose
drectly to the wastewater dran or to
the washbasn.
1
3 4
2
A
Hose connection should be made
in a safe manner. Your drain
house will be ooded if the hose
comes out of its housing during
water discharge.
C
Water drain hose should be at-
tached to a height of maximum
80 cm.
C
Make sure that the water drain
hose is not stepped on and it is
not folded between the drain and
the machine.
3.4 Adjusting the feet
• In order to ensure that the dryer
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet.
• Turn the feet to left or right until the
dryer stands level and firmly.
C
Never unscrew the adjustable
feet from their housings.
3.5 Electrical connection
For specic instructions for electrical connec-
tion required during installation (see 1.1.1
Electrical Safety)
3.6 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the
dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the dryer
in upright position. If it is not pos-
sible to carry the machine in the
upright position, we recommend
carrying it by tilting towards the
right side when looked from the
front.
14 / EN
Dryer / User Manual
Installation
3.7 Warnings about sounds
C
It is normal to hear a metallic
noise from the compressor some-
times during operation.
C
Water collected during operation
is pumped to water tank. It is nor-
mal to hear pumping noise during
this process.
3.8 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.
The lamp(s) used in this appliance is not suit-
able for household room illumination. The
intended purpose of this lamp is to assist the
user to place laundry in the tumble dryer in a
comfortable way. The lamps used in this ap-
pliance have to withstand extreme physical
conditions such as vibrations and tempera-
tures above 50 °C
15 / EN
Dryer / User Manual
4 Preparation
4.1 Laundry suitable for drying in the dryer
• Always obey the instructions given on the garment tags. Dry only the laundry having a
label stating that they are suitable for drying in a dryer and make sure that you select the
appropriate programme.
Drying
Settings
At any temperature
At high temperature
At medium
temperature
At low temperature
Without heating
Hang to dry
Lay to dry
Hang wet to dry
Lay in shadow
to dry
Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature
Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature
200
0
C 150
0
C 110
0
C
LAUNDRY DRYING SYMBOLS
Drying
Symbols
Suitable for
dryer
No Iron
Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry
Do not dry-
clean
4.2 Laundry not suitable for
drying in the dryer
C
Delicate embroidered fabrics,
woollen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for
energy saving
Following information will help you use the
dryer in an ecological and energy-ecient
manner.
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and tableclothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation
16 / EN
Dryer / User Manual
Preparation
• Clean the lint filter before or after each
drying cycle. (See 6.1 Cleaning Lint
Filter / Loading Door Inner Surface)
• Clean the filter periodically when there
is visible air collection on it or when
the symbol lights up, if there is a filter
drawer cleaning warning symbol « »
available. (See 6. 4 Cleaning the filter
drawer)
• Ventilate the room, where the dryer is
located, well during drying.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
C
It is not recommended to load
the dryer with laundry exceeding
the level indicated in the figure.
Drying performance will degrade
when the machine is overloaded.
Furthermore, dryer and the laundry
can get damaged.
Following weights are given as examples.
Laundry
Approximate
weights (g)*
Cotton quilt covers
(double)
1500
Cotton quilt covers
(single)
1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces)
100
T-Shirts 125
*Dry laundry weight before washing.
17 / EN
Dryer / User Manual
5 Operating your dryer
5.1 Control panel
1. Program selection knob
2. Remaining duration indicator
3. On/Off button
4. Start/pause button
5. End duration button
6. Sound warning button
1 2
456
3
Volume up
Filter
cleaning
Tank
full
Child-proof
lock
Mute
Anti
Creasing
5.2 Screen symbols
18 / EN
Dryer / User Manual
Operating your dryer
5.3 Preparing the machine
1. Plug in the machine
2. Place laundry inside the machine.
3. Press the On/Off button.
4. When your machine turns on for the first
time, it turns on with the declaration
(cotton cabinet dryness) program.
C
Pressing the On/Off button
doesn‘t mean the program starts.
Press the Start / Pause button to
start the program.
5.4 Program selection
1. Determine the appropriate program from
the chart below containing the drying
levels.
2. Select the program you desire using the
Program Selection knob.
Extra Dry
Only cotton laundry is dried in
normal temperature.
Thick and multi-layered laun-
dry (towels, sheets, jeans
etc.) are dried so that they
can be placed into wardrobe
without ironing.
Cupboard
dry
Normal laundry (tablecloths,
underwear etc.) are dried so
that they can be placed into
wardrobe without ironing.
Cupboard
dry +
Normal laundry (Ex: table-
cloths, underwear) are
again dried so that they can
be placed into the wardrobe
but more so than the ward-
robe dryness option.
Iron Dry
Normal laundry (shirts,
dresses etc) are dried ready
for ironing.
C
For detailed program information
see. “Program selection and
consumption table“..
5.5 Main programs
The main programs are given below based on
fabric type.
• Cotton
Dry durable laundry with this program. It
dries in normal temperature. Recommended
for use with your cotton laundry (sheets, bed
covers, towels, bathrobes etc.)
• Synthetc
Dry laundry that is not very durable with this
program. Recommended for use with your
synthetic laundry.
5.6 Extra programs
The following extra programs are available in
the machine for special conditions.
C
Extra programs may vary
according to the specifications of
your machine.
C
In order to receive better results
from drying machine programs,
your laundry should be washed
with the appropriate program
in your washing machine and
wringed with recommended
wringing revolution..
• Jeans
Use to dry jeans that are wringed with high
rpm in washing machine.
• Sport
Use to dry laundry made from synthetic, cot-
ton or mixed fabrics.
• Express
You can use this program to dry cotton laun-
dry that you had wringed in high rpm in your
washing machine. It dries 1 kg of your Cotton
laundry (3 shirts / 3 T-shirts) in 45 minutes.
• Daly
Program for daily drying of cotton and syn-
thetic laundry and lasts 80 minutes.
• Shrts
Dries shirts more delicately and thus causes
less wrinkles for easy ironing.
• BabyProtect
Program used for baby clothing with can be
dried approval on the label.
19 / EN
Dryer / User Manual
Operating your dryer
C
Very little dampness might
remain on the shirts after the
program. It is recommended that
you do not leave the shirts in the
drying machine.
• Delcates
You can dry your delicates suitable for dry-
ing or laundry that is recommended to hand
wash (silk blouses, thin underwear etc.) in low
temperature.
C
It is recommended to dry your
delicates in laundry bag to
prevent wrinkles and damage.
When the program ends, take
your laundry out of the machine
immediately and hang them to
prevent wrinkles.
• Freshen Up
It only performs ventilation for 10 minutes
without blowing hot air. You can ventilate the
cotton and linen clothing that has remained
closed for a long duration and remove their
odor.
• Tmed programs
You can select the 30 mins and 45 mins time
programs to achieve the desired nal drying
level with low temperature.
C
On this program, the machine
dries as long as the set duration,
regardless of the drying level.
20 / EN
Dryer / User Manual
Operating your dryer
5.7 Program selection and consumption table
* : Energy Label standard program (EN 61121:2012) “All the lters must be cleaned prior to
test series.” All the values in the table are determined according to EN 61121:2012 standard.
Consumption values may vary from the values in the table depending on laundry type, wring-
ing revolution, ambient conditions and changes in voltage.
5.8 Auxiliary functions
EN
Programs
Capacity
(kg)
Spin speed in washing
machine (rpm)
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
A
Extra dry 7 1000 % 60 220
A
Cupboard dry 7 1000 % 60 174
A
Iron dry 7 1000 % 60 140
Shirts
1.5 1200 % 60 60
Jeans
4 1200 %50 150
Daily
4 1200 %50 110
Sport
4 1000 %60 135
Express
1 1200 %50 50
Delicates
2 600 %40 70
BabyProtect
3 1000 % 60 80
Synthetics
B
Cupboard dry 3.5 800 % 40 70
B
Iron dry 3.5 800 % 40 60
Energy consumption values
Programs
Capacity
(kg)
Energy consumption value kWh per
year
Energy rating
star
Cottons Extra Dry*
7 145 6
Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed.
R134a / 0,35kg
* : Energy Label standard program (AS/NZS 2442) “All the filters must be cleaned prior to test
series.”
All values given in the table have been fixed according to standard laboratory conditions.
These values may deviate from the table according to the laundry type, laundry spin speed,
environmental conditions and voltage fluctuations.
21 / EN
Dryer / User Manual
Operating your dryer
EN
Programs
Capacity
(kg)
Spin speed in washing
machine (rpm)
Approximate
amount of
remaining
humidity
Drying time
(minutes)
Cottons / Coloreds
A
Extra dry 7 1000 % 60 220
A
Cupboard dry 7 1000 % 60 174
A
Iron dry 7 1000 % 60 140
Shirts
1.5 1200 % 60 60
Jeans
4 1200 %50 150
Daily
4 1200 %50 110
Sport
4 1000 %60 135
Express
1 1200 %50 50
Delicates
2 600 %40 70
BabyProtect
3 1000 % 60 80
Synthetics
B
Cupboard dry 3.5 800 % 40 70
B
Iron dry 3.5 800 % 40 60
Energy consumption values
Programs
Capacity
(kg)
Energy consumption value kWh per
year
Energy rating
star
Cottons Extra Dry*
7 145 6
Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed.
R134a / 0,35kg
Sound warning cancel
Drying machine makes sound warnings
when the program is completed. If you don’t
want sound notications, press the “Sound
Notication” button.
When you press the sound notication but-
ton it lights up, and program does not make
sound notications when completed.
C
You can select this function
before or after the program
starts.
5.9 Warning symbols
C
Warning symbols may vary
according to the specifications of
your machine.
Fiber filter cleaning
When the program is completed, a warning
LED lights up, which indicates that the lter
has to be cleaned.
C
If the filter cleaning LED blinks,
see the „Troubleshooting“
chapter.
Water tank
When the program is completed, a warning
LED lights up, which indicates that the water
tank must be emptied.
If the water tank lls up while the program
is running, warning LED starts blinking and
the machine goes into stand-by. In that case
empty the water in the water tank and start
the program by pressing the Start / Pause
button. Warning LED turns o and the pro-
gram resumes.
Loading door open
Start/Pause LED blinks when the loading
door of the drying machine is open.
5.10 End duration
You can delay the end duration of the pro-
gram for up to 24 hours with the end dura-
tion function.
1. Open the loadng door and place your
laundry.
2. Select the dryng program.
3. Press the end duraton selecton button
and set the delay duraton you want.
End duraton LED lghts up. (End
duraton moves contnuously when you
keep pressng the button).
4. Press the Start / Pause button. End
duraton countdown begns. The “:”
sgn n the mddle of the dsplayed delay
duraton blnks.
C
You can add or remove laundry
for the duration of the end
duration. The duration displayed
on the screen is the sum of the
normal drying duration and the
end duration. At the end of the
countdown the end duration
LED turns off, drying beings and
drying LED lights up.
Changing the end duration
If you want to change the duration during
the countdown:
1. Cancel the program by pressng the On/
Off button. Turn on the dryng machne
agan by pressng the On/Off button.
When your dryng machne turns on
for the frst tme, t turns on wth the
declaraton (cotton wardrobe dryness)
program.
2. Select the program you desre usng the
Program Selecton knob.
3. Repeat the end duraton operaton for
the duraton you want.
4. Start the program by pressng the Start /
Pause button.
22 / EN
Dryer / User Manual
Operating your dryer
5.13 Changing the program
after it is started
After the machine starts running, you can
change the program you selected to dry your
laundry with a dierent program.
1. For example, to select Extra Dry program
nstead of the Iron Dryness, stop the
program by pressng the Start / Pause
button.
2. Turn the Program Selecton knob to
select the Extra Dry program.
3. Start the program by pressng the Start /
Pause button.
Adding and removing laundry in
stand-by mode
If you want to add or remove laundry after
the drying program starts:
1. Press the Start/Pause button to take
the machne nto Stand-by mode. Dryng
operaton stops.
2. Open the loadng door, add or remove
laundry and close the loadng door.
3. Start the program by pressng the Start /
Pause button.
C
The laundry adding made after
the drying operation started may
cause the dried laundry inside
the machine to mix with the wet
laundry and the laundry to remain
damp after the operation ends..
C
Laundry adding and removing can
be repeated as much as desired
during drying operation.
But this process would
continuously interrupt the
drying operation, and so would
cause the program duration
to lengthen and increase
energy consumption. Thus, it is
recommended to add laundry
before the program starts.
C
If a new program is selected by
changing the position of the
program selection knob while
your machine is in stand-by
mode, the running program ends.
Canceling the end duration function
If you want to cancel the end duration set-
ting countdown and start the program right
away:
1. Cancel the program by pressng the On/
Off button. Turn on the dryng machne
agan by pressng the On/Off button.
When your dryng machne turns on
for the frst tme, t turns on wth the
declaraton (cotton wardrobe dryness)
program.
2. Select the program you desre usng the
Program Selecton knob.
3. Start the program by pressng the Start /
Pause button.
5.11 Starting the program
Start the program by pressing the Start /
Pause button.
Start/Pause LED and the Drying LED light up,
indicating the program started. The “:” sign in
the middle of the remaining duration starts
to blink.
5.12 Child Lock
The machine features a child lock which pre-
vents the machine program ow from being
aected when buttons are pressed during
operation.
When the Child Lock is active, all buttons ex-
cept for the On/O button are deactivated.
To activate the child lock, press the Sound
Notication button and End Duration button
simultaneously for 3 seconds.
The child lock should be deactivated to be
able to start a new program after the current
program ends or to be able to interfere with
the current program. Keep the same buttons
pressed for 3 seconds again to deactivate the
child lock.
C
The lock LED on the screen
lights up when the Child Lock is
activated.
C
Child Lock deactivates when the
machine is turned off and on
again using the On/Off button.
A warning sound is heard when any button
is pressed (except for On/O button) or the
Program Selection knob is turned while the
child lock is active.
23 / EN
Dryer / User Manual
Operating your dryer
Do not touch the inner surface
of the drum when adding or
removing laundry during a
continuing program. The drum
surface is hot.
5.14 Canceling the program
If you want to cancel the program and end
the drying operation for any reason after the
machine starts running, press the On/O
button.
A
As it will be extremely hot inside
the machine when you cancel
the program while the machine is
in operation; run the ventilation
program to cool it down.
5.15 Program end
When the program ends, the Final/Wrinkle
Prevention, Fiber Filter Cleaning and Water
Tank Warning LEDs on the program follow
up indicator light up. Loading door can be
opened and machine becomes ready for a
second run.
Press the On/O button to turn o the ma-
chine.
C
In case the laundry is not removed
after the program is completed,
the wrinkle prevention program
that lasts 2 hours start in order to
prevent wrinkling of the laundry
that remains inside the machine.
C
Clean the fiber filter after each
drying. (See. “Fiber filter and
loading door inner surface“)
C
Empty the water tank after each
drying. (See. “Emptying the water
tank“)
24 / EN
Dryer / User Manual
6 Maintenance and cleaning
Service life of the product extends and
frequently experienced problems will be re-
duced if it is cleaned at regular intervals.
6.1 Cleaning Lint Filter /
Loading Door Inner Surface
Lint and bre released from the laundry to
the air during the drying cycle are collected in
the Lint Filter.
C
Such fibre and lint are generally
formed during wearing and
washing.
A
Always clean the lint filter and the
inner surfaces of the loading door
after each drying process.
C
You can clean the lint filter
housing with a vacuum cleaner.
To clean the lint lter:
• Open the loading door.
• Remove the lint filter by pulling it up and
open the lint filter.
• Clean lint, fibre, and cotton thread by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
• A layer can build up on the filter pores
that can cause clogging of the filter after
using the dryer for a while. Wash the
lint filter with warm water to remove
the layer that builds up on the lint filter
surface. Dry the lint filter completely
before reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
25 / EN
Dryer / User Manual
Maintenance and cleaning
6.2 Cleaning the sensor
There are dampness sensors in the dryer
that detect whether the laundry is dry or not.
To clean the sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is
still hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
C
Clean metal surfaces of the
sensors 4 times a year.
C
Do not use metal tools when
cleaning metal surfaces of the
sensors.
A
Never use solvents, cleaning
agents or similar substances for
cleaning due to the risk of fire and
explosion!
6.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the
water that arise accumulates in the water
tank. Drain the water tank after each drying
cycle.
A
Condensed water is not drinkable!
A
Never remove the water tank
when the program is running!
If you forget to drain the water tank, the ma-
chine will stop during the subsequent drying
cycles when the water tank is full and the
Water Tank warning symbol will ash. If this
is the case, drain the water tank and press
Start / Pause button to resume the drying
cycle.
To drain the water tank:
• Pull the drawer and remove the water
tank carefully.
• Drain the water in the tank.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
26 / EN
Dryer / User Manual
Maintenance and cleaning
C
If the direct water draining is used
as an option, there is no need to
empty the water tank.
6.4 Cleaning the filter drawer
Lint and ber that could not be captured by
the lint lter are blocked in the lter drawer
behind the kick plate. Filter Drawer Cleaning
warning light will light up maximum at every
5 drying cycles as a reminder.
There is a two-level lter in the lter drawer.
Te rst level is the lter drawer sponge and
the second level is the lter cloth.
To clean the lter drawer:
• Press the kick plate button to open the
kick plate.
• Remove the filter drawer cover by
turning it in the direction of arrow.
• Pull out the filter drawer.
• Open the filter drawer by pressing the
red button.
• Take out the filter drawer sponge.
• Clean lint, fiber, and cotton thread on the
filter cloth by hand or with a soft piece
of cloth.
• When you notice a layer that may lead to
clogging on the filter cloth, please clean
the layer by washing in warm water. Let
the filter cloth dry thoroughly before
installing back the filter drawer.
• Wash the filter drawer sponge by hand
to remove the fiber and lint on the
surface. After washing the sponge,
squeeze it by hand and remove the
excess water. Well-dry the sponge
before storing it.
C
It is not necessary to clean
the sponge if lint and fiber
accumulation on it is not
significant.
27 / EN
Dryer / User Manual
Maintenance and cleaning
• Place the sponge back into its place.
• Close the filter drawer as to lock the red
button.
• Place the filter drawer back into its place,
turn the filter drawer cover in the arrow
direction and close it securely.
• Close the kick plate cover.
A
Drying without the filter drawer
sponge in place will damage the
machine!
C
A dirty lint filter and filter drawer
will cause longer drying periods
and higher energy consumption.
6.5 Cleaning the evaporator
Clean the lint accumulated on the ns of the
evaporator located behind the lter drawer
with a vacuum cleaner.
A
You can also clean by hand
provided that you wear protective
gloves. Do not attempt to clean
with bare hands. Evaporator fins
can harm your hand.
28 / EN
Dryer / User Manual
7 Troubleshooting
Drying process takes too much time.
• Pores of the lint lter are clogged. >>> Wash the lint lter with warm water.
• Filter drawer is clogged. >>> Clean the sponge and the lter cloth in the lter drawer.
• Ventilation grids on the front side of the machine are blocked. >>> Remove the objects
(if any) that block ventilation in front of the ventilation grids.
• Ventilation is not sucient since the room where the machine is installed is very small.
>>> Open the door and window of the room to avoid the room temperature increase
too much.
• Lime deposit has built up on the dampness sensor. >>> Clean the dampness sensor.
• Excessive laundry is loaded. >>> Do not load the dryer in excess.
• Laundry is not spun suciently. >>> Spin your laundry at a higher speed in your wash-
ing machine.
Laundry comes out wet at the end of drying.
C
After drying, the hot clothes feel damper than their actual dampness level.
• It is likely that the selected programme did not suit the laundry type.>>>Checking the
care labels on clothes, select appropriate programme for the laundry type or use timer
programmes in addition.
• Pores of the lint lter are clogged. >>> Wash the lint lter with warm water.
• Filter drawer is clogged. >>> Clean the sponge and the lter cloth in the lter drawer.
• Excessive laundry is loaded. >>> Do not load the dryer in excess.
• Laundry is not spun suciently. >>> Spin your laundry at a higher speed in your wash-
ing machine.
Dryer does not switch on or the programme does not start. Dryer does not start when it is
set.
• It is not plugged in. >>> Make sure that the machine is plugged in.
• The loading door is ajar. >>> Make sure that the loading door is closed securely.
• Programme is not selected or the Start / Pause / Cancel button is not pressed. >>> Make
sure that the programme is selected and the machine is not in Pause mode.
• Childproof Lock is activated. >>> Deactivate the Childproof Lock.
Programme is interrupted without any cause.
• Loading door is ajar. >>> Make sure that the loading door is closed securely.
• There was a power failure. >>> Press Start / Pause / Cancel button to start the pro-
gramme.
• Water tank is full. >>> Drain the water tank.
Laundry has shrunk, become felted or deteriorated.
• A programme suitable for the laundry type is not used. >>> Check the garment tag and
select a programme suitable for the fabric type.
Drum lighting does not turn on. (On models with lamp)
• Dryer is not switched on with the On / O button. >>> Make sure that the dryer is
switched on.
• Lamp is defective. >>> Call Authorized Service Agent to have the lamp replaced.
End/Anti-creasing symbol is on.
• Anti-creasing programme is activated in order to prevent laundry that has remained in
the machine from creasing. >>> Turn o the dryer and take out the laundry.
29 / EN
Dryer / User Manual
Troubleshooting
End symbol is on.
• Programme is over. Turn o the dryer and take out the laundry.
Lint Filter Cleaning symbol is on.
• Lint lter is not cleaned. >>> Clean the lint lter.
Lint Filter Cleaning symbol is ashing.
• Filter housing is clogged with lints. >>> Clean the lint lter housing.
• A deposit has built up on the lint lter pores that may cause clogging. >>> Wash the lint
lter with warm water.
• Filter drawer is clogged. >>> Clean the sponge and the lter cloth in the lter drawer.
Water leaks from the loading door
• Lint has accumulated on the inner surfaces of the loading door and on the surfaces of
the loading door gasket. >>> Clean the inner surfaces of the loading door and the sur-
faces of the loading door gasket.
Loading door opens spontaneously.
• Loading door is ajar. >>> Push the loading door to close until you hear a locking sound.
• Water Tank warning symbol is on/ashing.
• Water tank is full. >>> Drain the water tank.
• Water draining hose is bent. >>> If the product is connected directly to a wastewater
drain, check the water drain hose.
Filter Drawer Cleaning warning symbol is ashing.
• Filter drawer is not cleaned. >>> Clean the sponge and the lter cloth in the lter
drawer.
A
If you cannot eliminate the problem although you follow the instructions in this
section, consult your dealer or the Authorized Service Agent. Never try to repair a
nonfunctional product yourself.
