Dryer
User Manual
BDP700W
2960311705/290518.1351
EN
Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been
manufactured with high quality and technology will give you the best results. We advise you
to read through this manual and the other accompanying documentation carefully before
using your product and keep it for future reference. If you transfer the product to someone
else, give its manual as well. Pay attention to all details and warnings specified in the user
manual and follow the instructions given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful hints about usage.
A
Warning for hazardous situations with regard to life and property.
B
Warning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Warning against scalding hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.
3 / EN
Dryer / User Manual
1 Important instructions for safety and
environment
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons shall vod any warranty.
1.1 General safety
• The dryer can be used by chldren at and above 8
years old and by persons whose physcal, sensory or
mental capabltes were not fully developed or who
lack experence and knowledge provded that they are
supervsed or traned on the safe usage of the product
and the rsks t brngs out. Chldren should not play wth
the product. Cleanng and mantenance works should not
be performed by chldren unless they are supervsed by
someone.
• Chldren of less than 3 years should be kept away unless
contnously supervsed.
• Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced wth
materals such as carpet, wood and tape. Ths wll cause
problems wth the dryer.
• Always have the nstallaton and reparng procedures
carred out by an Authorsed Servce Agent. The
manufacturer shall not be held lable for damages that
may arse from procedures carred out by unauthorzed
persons.
• Never wash the dryer by sprayng or pourng water onto t!
There s the rsk of electrc shock!
For the products wth a steam functon:
• Use only dstlled water or water condensed n the water
tank of the machne n steam programs. Do not use mans
water or addtves. When usng condensed water n the
water tank, t should be fltered and cleared of fbres.
4 / EN
Dryer / User Manual
Important instructions for safety and
environment
• Do not open the door when steam programs are runnng.
Hot water may be expelled.
• Before puttng laundry n a steam program, stans on t
should be removed.
• You may only put laundry that s not drty or staned
but permeated wth unpleasant odour n steam (odour
removal) program.
• Do not use any dry cleanng sets or addtonal materals n
a steam program or n any program.
1.1.1 Electrcal safety
A
Electrcal safety nstructons should be followed
whle electrcal connecton s made durng the
nstallaton.
A
The applance must not be suppled through an
external swtchng devce, such as a tmer,or
connected to a crcut that s regularly swtched on
and off by utlty.
• Connect the dryer to a grounded outlet protected by a
fuse at the value specfed on the type label. Have the
groundng nstallaton performed by a qualfed electrcan.
The manufacturer shall not be lable for any damages that
wll arse when the dryer s used wthout groundng n
accordance wth the local regulatons.
• The voltage and allowed fuse protecton s stated on the
type label plate.
• The voltage specfed on the type label must be equal to
your mans voltage.
• Unplug the dryer when t s not n use.
• Unplug the dryer from the mans durng nstallaton,
mantenance, cleanng and repar works.
• Do not touch the plug wth wet hands! Never unplug by
pullng on the cable, always pull out by grabbng the plug.
5 / EN
Dryer / User Manual
Important instructions for safety and
environment
• Do not use extenson cords, mult-plugs or adaptors to
connect the dryer to power supply n order to decrease the
rsk of fre and electrc shock.
• Power cable plug must be easly accessble after
nstallaton.
B
Damaged mans cable should be changed notfyng
an Authorsed Servce Agent.
B
If the dryer s faulty, t must not be operated unless
t s repared by an authorzed servce agent! There s
the rsk of electrc shock!
1.1.2 Product safety
Superheatng of the clothes nsde of the dryer can
occur f you cancel the programme or n the event
of a power falure whlst the dryer s runnng, ths
concentraton of heat can cause self-combuston and
fre so always actvate the ventlaton programme
to cool down or quckly remove all laundry from the
dryer n order to hang them up and dsspate the
heat.
Ponts to be taken nto consderaton for fre
hazard:
Below specfed laundry or tems must not be dred n
the dryer consderng fre hazard.
• Unwashed laundry tems
• Items soled wth ol, acetone, alcohol, fuel ol,
kerosene, stan removers, turpentne, paraffn or
paraffn removers must be washed n hot water
wth plenty of detergent before beng dred n the
dryer.
For ths reason especally the tems contanng the
above specfed stans must be washed very well, to
do ths use adequate detergent and choose a hgh
washng temperature.
6 / EN
Dryer / User Manual
Important instructions for safety and
environment
Below specfed laundry or tems must not be
dred n the dryer due to the fre hazard:
• Garments or pllows bolstered wth rubber foam
(latex foam), shower hats, water resstant textles,
materals wth rubber renforcement and rubber
foam pads.
• Clothng cleaned wth ndustral chemcals.
Items such as lghter, match, cons, metal parts,
needle etc. may damage the drum set or may lead to
functonal problems. Therefore check all the laundry
that you wll load nto your dryer.
Never stop your dryer before the programme
completes. If you must do ths, remove all laundry
quckly and lay them out to dsspate the heat.
Clothes that are washed nadequately may gnte on
ther own and even may gnte after dryng ends.
Ol-affected tems can gnte spontaneously,
especally when exposed to heat sources such as n
a tumble dryer. The tems become warm, causng an
oxdaton reacton n the ol. Oxdaton creates heat.
If the heat cannot escape, the tems can become hot
enough to catch fre. Plng, stackng or storng ol-
affected tems can prevent heat from escapng and
so create a fre hazard.
If t s unavodable that fabrcs that contan vegetable
or cookng ol or have been contamnated by har care
products be placed n a tumble dryer they should frst
be washed n hot water wth extra detergent - ths
wll reduce, but not elmnate, the hazard.
• You must provde enough ventlaton n order to prevent
gases extng from devces operatng wth other types of
fuels ncludng the naked flame from accumulatng n the
room due to the back fre effect.
7 / EN
Dryer / User Manual
Important instructions for safety and
environment
A
Underwear that contans metal renforcements
should not be dred n the dryer. Dryer may be
damaged f metal renforcements come loose and
break off durng dryng.
C
Use softeners and smlar products n accordance
wth the nstructons of ther manufacturers.
C
Always clean the lnt flter before or after each
loadng. Never operate the dryer wthout the lnt
flter nstalled.
• Never attempt to repar the dryer by yourself. Do not
perform any repar or replacement procedures on the
product even f you know or have the ablty to perform
the requred procedure unless t s clearly suggested n the
operatng nstructons or the publshed servce manual.
Otherwse, you wll be puttng your lfe and others’ lves n
danger.
• There must not be a lockable, sldng or hnged door that
may block the openng of the loadng door n the place
where your dryer s to be nstalled.
• Install your dryer at places sutable for home use.
(Bathroom, closed balcony, garage etc.)
• Make sure that pets do not enter the dryer. Check the
nsde of the dryer before operatng t.
• Do not lean on the loadng door of your dryer when t s
open, otherwse t may fall over.
• The lnt must not be allowed to accumulate around the
tumble dryer
• The tumble dryer s not to be used f ndustral chemcals
have been used for cleanng.
• Fabrc softeners, or smlar products.should be used as
specfed by the fabrc softener nstructons.
8 / EN
Dryer / User Manual
Important instructions for safety and
environment
• Exhaust ar must not be dscharged nto a flue whch s
used for exhaustng fumes from applances burnng gas or
other fuels.
• The fnal step of the dryng cycle (cool-down cycle) occurs
wthout applyng heat to ensure that the tems are left at a
temperature that wll not damage them.
1.2 Stackng on top of a washng machne
• A fxng devce should be used between the two machnes
when nstallng the dryer above a washng machne. The
fttng devce must be nstalled by an Authorsed Servce
Agent.
• Total weght of the washng machne and the dryer -wth
full load- when they are placed on top of each other
reaches to approx. 180 klograms. Place the products on a
sold floor that has suffcent load carryng capacty!
A
Washng machne cannot be placed on the dryer.
Pay attenton to the above warnngs durng the
nstallaton on your washng machne.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm
Can be nstalled
Can be
nstalled
Cannot be
nstalled
60 cm
Can be nstalled
Cannot be
nstalled
9 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.3 Intended use
• Dryer has been desgned for domestc use. It s not sutable
for commercal use and t must not be used out of ts
ntended use.
• Use the dryer only for dryng laundry that are marked
accordngly.
• The manufacturer waves any responsblty arsen from
ncorrect usage or transportaton.
1.4 Chld safety
• Packagng materals are dangerous for the chldren. Keep
packagng materals away from chldren.
• Electrcal products are dangerous for the chldren. Keep
chldren away from the product when t s operatng. Do
not let them tamper wth the dryer. Use the chld-proof
lock n order to prevent the chldren to tamper wth the
dryer.
C
Chld-proof lock s on the control panel.
(See Chld lock)
• Keep loadng door closed even when the dryer s not n
use.
10 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.5 Complance wth the WEEE regulaton
and dsposng of the waste product
Ths product comples wth EU WEEE Drectve
(2012/19/EU). Ths product bears a classfcaton
symbol for waste electrcal and electronc equpment
(WEEE).
Ths product has been manufactured wth hgh
qualty parts and materals whch can be reused and are
sutable for recyclng. Do not dspose of the waste product
wth normal domestc and other wastes at the end of ts
servce lfe. Take t to the collecton center for the recyclng
of electrcal and electronc equpment. Please consult your
local authortes to learn about these collecton centers.
1.6 Complance wth RoHS Drectve:
The product you have purchased comples wth EU RoHS
Drectve (2011/65/EU). It does not contan harmful and
prohbted materals specfed n the Drectve.
1.7 Package nformaton
Packagng materals of the product are manufactured
from recyclable materals n accordance wth our Natonal
Envronment Regulatons. Do not dspose of the packagng
materals together wth the domestc or other wastes. Take
them to the packagng materal collecton ponts desgnated
by the local authortes.
11 / EN
Dryer / User Manual
Important instructions for safety and
environment
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 56,8 cm
Capacity (max.) 7 kg**
Net weight (± 4 kg) 46 kg
Width
See type label***Voltage
Rated power input
1.8 Techncal Specfcatons
* Mn. heght: Heght wth adjustable feet are closed.
Max. heght: Heght wth adjustable feet are opened
maxmum.
** Dry laundry weght before washng.
*** Type label s located behnd the loadng door.
C
Techncal specfcatons of the dryer are subject to
change wthout notce to mprove the qualty of the
product.
C
Fgures n ths manual are schematc and may not
match the product exactly.
C
Values stated on markers on the dryer or n the other
publshed documentaton accompanyng wth the
dryer are obtaned n laboratory n accordance wth
the relevant standards. Dependng on operatonal and
envronmental condtons of the dryer, these values
may vary.
12 / EN
Dryer / User Manual
2 Your Dryer
2.1 Overview
11
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In in models where the tank is placed
below, the water tank is inside the toe board
8. Type label
9. Lint filter
10. Water tank drawer (in models where the
tank is placed above)
11. Power cord
2.2 Package Contents
1
2 3
5
6
4
7 8
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
6. Water Filling Container*
7. Pure Water*
8. Fragrance Capsules Group*
*It can be supplied with your machine depending on its model.
13 / EN
Dryer / User Manual
3 Installaton
Before the calling the nearest Authorized
Service for the installation of the dryer,
ensure that electrical installation and water
drain is appropriate referring to the user’s
manual. If they are not suitable, contact a
qualified electrician and technician to make
necessary arrangements.
C
Preparation of the dryer's location
as well as the electrical and
waste water installations is under
customer's responsibility.
A
Prior to installation, visually check
if the dryer has any defects on
it. If the drier is damaged, do
not have it installed. Damaged
products cause risks for your
safety.
A
Let your dryer wait for 12 hours
before starting to use it.
3.1 Appropriate installation
location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer
will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer
shall be placed against a wall.
B
Do not place the dryer on the
power cable.
A
f the appliance installed above
carpet, please ensure that the
carpet does not obstruct the
openings
3.2 Removing the
transportation safety
assembly
A
Remove the transportation safety
assembly before using the dryer
for the first time.
3.3 Connecting to the drain
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.
Connecting the water drain hose
1-2 Pull hose at the behnd of the dryer
by hand n order to dsconnect t from
where t s connected. Do not use any
tools to remove the hose.
3 Connect one end of the dran hose
suppled wth the dryer to the
connecton pont from where you
removed the hose of the product n
prevous step.
4 Connect the other end of the dran hose
drectly to the wastewater dran or to
the washbasn.
14 / EN
Dryer / User Manual
Installation
1
3 4
2
C
Water drain hose should be
attached to a height of maximum
80 cm.
C
Make sure that the water drain
hose is not stepped on and it is not
folded between the drain and the
machine.
C
If there is an accessories pack
supplied with your product, please
see the detailed description.
3.4 Adjusting the feet
• Turn the feet to left or right until the
dryer stands level and firmly.
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the
dryer in upright position. If it is
not possible to carry the machine
in the upright position, we
recommend carrying it by tilting
towards the right side when
looked from the front.
3.6 Warnings about sounds
C
It is normal to hear a metallic noise
from the compressor sometimes
during operation.
C
Water collected during operation is
pumped to water tank. It is normal
to hear pumping noise during this
process.
3.7 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call an
Authorised Service Agent.The lamp(s) used
in this appliance is not suitable for household
room illumination. The intended purpose of
this lamp is to assist the user to place laundry
in the tumble dryer in a comfortable way.
The lamps used in this appliance have to
withstand extreme physical conditions such
as vibrations and temperatures above 50 °C
15 / EN
Dryer / User Manual
4 Preparaton
4.1 Laundry suitable for drying
in the dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying
in a dryer and make sure that you select the
appropriate programme.
Do not dry with
dryer
At high
temperature
At medium
temperature
At low
temperature
4.2 Laundry not suitable for
drying in the dryer
C
Delicate embroidered fabrics,
woollen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for
energy saving
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and tableclothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation
• For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• For models with heat pump unit: clean
the filter drawer periodically when there
is a visible accumulation of fluff or when
the filter drawer cleaning indicator «
» lights up.
• For models with flue unit: comply with
the flue connection instructions and
clean the flue.
• During the drying process, air the
room well where your tumble dryer is
operating.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
16 / EN
Dryer / User Manual
Preparation
Following weights are given as examples.
Laundry
Approximate
weights (g)*
Cotton quilt covers
(double)
1500
Cotton quilt covers
(single)
1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea towels 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces)
100
T-Shirts 125
*Dry laundry weight before washing.
17 / EN
Dryer / User Manual
5 Operatng the product
5.1 Control Panel
1. On/Off/Program selection button
2. Start/Pause button
5.2 Symbols
Volume up
Filter
cleaning
Tank
full
Child-proof
lock
Mute
Filter drawer /
Heat exchanger
cleaning
End/anti-
creasing
On/O
Timer
Delay
Drying
Cupboard
Dry
Iron Dry
Express
14’
Delicates
Jeans
BabyProtect
Extra dry
Cupboard
dry plus
Sport
Freshen Up
Start
pause
cancel
Cottons
Synthetics
Mix
Express
30’
Drying Rack/
TimeDry
Daily
Exspress
Shirts 30
Wool Refresh
Shirts
5.3 Preparation of the clothes
dryer
Plug in the clothes dryer.
• Open the loading door.
• Place the laundry into the clothes dryer
without jamming them.
• Push and close the loading door.
A
Ensure that no laundry is jammed
to the loading door.
Select the desired program using the On/
Off/Program selection knob, the machine will
turn on.
C
Selecting a program using the
On/Off/Program selection
button does not mean that the
program started. Press the Start
/ Stand-by button to start the
program.
1
2
3
4
3. End Time button
4. Audio warning level button
18 / EN
Dryer / User Manual
Operating the product
EN
Programmes Programme Description
Capacity
(kg)
Spin speed in
washing machine
(rpm)
Drying Time
(minutes)
Cotton Iron Dry
You may dry your cotton laundry to be ironed in
this programme to have them slightly damp for
ease of ironing. (Shirt, T-shirt, tablecloth, etc.)
7 1000 139
Cotton Cupboard Dry
You may dry all your cotton laundry in this
programme. (T-shirt, pants, pyjamas, baby
clothes, underwear, linen, etc.) You can put
your laundry in the wardrobe without ironing.
7 1000 174
Cotton Cupboard Dry
Plus
You may use this programme for extra dryness
in thick laundry such as pants, tracksuit. You
can put your laundry in the wardrobe without
ironing.
7 1000 179
Cotton Extra Dry
You may dry your thick cotton laundry in this
programme such as towels, bathrobe, etc. You
can put your laundry in the wardrobe without
ironing.
7 1000 190
Synthetic Iron Dry
You may dry your synthetic laundry to be
ironed in this programme to have them slightly
damp for ease of ironing. (Shirt, T-shirt,
tablecloth, etc.)
3,5 800 59
Synthetic Cupboard
Dry
You may dry all your synthetic laundry in
this programme. (Shirt, T-shirt, underwear,
tablecloth, etc.) You can put your laundry in
the wardrobe without ironing.
3,5 800 70
Sport
You may dry your sports clothes that are
appropriate for tumble drying with this
programme.
4 1000 110
Freshen up
It just provides airing for 10 minutes without
any hot air. You can air the cotton and linen
laundry that have been stored for a long time ,
and eliminate the odour in them.
- - 10
Time Programmes
You may select from time programmes
between 30 and 60 minutes to achieve the
desired drying level at low temperature. In this
programme, tumble dryer’s operation lasts for
the set time independently from the dryness
of laundry.
- - -
Mix
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
4 1000 120
Babyprotect
This program is used for baby clothes that bear
machine dryable approval on its label.
3 1000 90
Jeans
You may dry denim pants, skirts, shirts or
jackets with this program.
4 1200 125
5.4 Programme selection and consumption tablee
19 / EN
Dryer / User Manual
Operating the product
Gentle Care / Shirts
It dries the shirts in a more sensitive manner,
and causes less creasing and easier ironing.
2 600 55
Express Super Short
Dries shirts more delicately and thus causes
less wrinkles for easy ironing.
0,5 1200 30
Energy consumption values
Programmes Capacity (kg)
Energy consumption value
kWh per year
Energy rating
star
Cottons-Extra Dry* 7 144 6
Contains fluorinated greenhouse gases covered by the Kyoto
Protocol. Hermetically sealed.
R134a / 0,225 kg - GWP:1430 - 0,321 tCO2e
* : Energy Label standard program (EN 61121:2012)
All the values on the chart are identified according to EN 61121:2012 standard. Consumption
values may vary from the values in the chart depending on laundry type, wringing speed,
ambient conditions and voltage levels.
* : Energy Label standard program (AS/NZS 2442) “All the filters must be cleaned prior to test
series.”
All values given in the table have been fixed according to standard laboratory conditions.
These values may deviate from the table according to the laundry type, laundry spin speed,
environmental conditions and voltage fluctuations.
5
.
5 Auxiliary functions
Audible warning
Drying machine makes an audible warning
when the program is completed. If you don’t
want it to make an audible warning, press the
“Buzzer” button. When you press the Buzzer
button, a light will illuminate and no audible
warning will be made when the program
ends.
C
You can select this function
before or after the program
starts.
End time
If you prefer to dry your laundry at a later
time, you can delay start time of the program
up to 3 hours, 6 hours or 9 hours using the
Delay function.
Open the loading door and place the laundry.
Select the drying program.
Press the End Time selection button and
set the delay time you wish. When the End
Time button is pressed once, 3 hours delay is
selected and the delay indicator will light up.
If you press the same button again, 6 hours
delay will be selected and when you press for
the third time, 9 hours delay will be selected.
If you press the End Time button once again,
the delay will be cancelled.
After the End Time selection is made, start
delayed running for the program selected
pressing the “Start/Stand-by” button.
C
You can add or remove laundry
within end time. At the end of
the Time Delay countdown, the
Time Delay warning indicator
turns off and drying begins
Changing the end time
If you want to change the duration during
the countdown:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and repeat the End Time selection
process.
20 / EN
Dryer / User Manual
Operating the product
Press the End Time and Buzzer buttons
simultaneously for 3 buttons to activate the
child lock.
The child lock has to be deactivated to be
able to start a new program after the current
program is finished or to be able to interfere
with the program. To deactivate the child
lock, keep the same buttons pressed for 3
seconds.
C
When the child lock is activated,
the child lock warning indicator
on the screen turns on.
C
Child lock deactivates when the
drying machine is turned off and
on by the On/Off/Cancel knob.
When the child lock is active:
When the drying machine runs, or in stand-
by state, the indicator symbols won’t change
upon changing the position of the program
selection knob.
C
When the drying machine runs
and the child lock is active, it
beeps twice when the program
selection knob is turned. If the
child lock is deactivated without
returning the program selection
knob to its previous position,
program will terminate due
to the change in the program
selection knob position.
5.9 Changing the program
after it is started
You can change the program you selected
to dry your laundry with a different program
after the drying machine starts running
• For instance, select Extra Dry program
by turning the On/Off/Program selection
knob to select Extra Dry instead of Iron
Dry.
• Press the Start/Stand-by button to start
the program.
Cancelling the end time function
If you want to cancel the end time
countdown and start the program
immediately:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and press the Start/Stand-by
button.
5.6 Warning indicators
C
Warning indicators may vary
depending on the model of your
dryer.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
When the program is completed, the warning
indicator to empty the water tank turns on.
If the water tank fills up while the program
continues, the warning indicator starts
flashing and the machine goes into stand-by.
In this case, empty the water tank and start
the program by pressing the Start / Stand-
by button. Warning indicator turns off and
program resumes.
Filter drawer /Heat exchanger
cleaning
When the programme is finished, the
cleaning symbol of the heat exchanger or
filter drawer may light up.
5.7 Starting the program
Press the Start/Stand-by button to start the
program.
Drying indicator will light up, indicating that
the program has started.
5.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the child lock is
activated, all buttons on the panel except
the On/Off/Program selection knob are
deactivated.
21 / EN
Dryer / User Manual
Operating the product
5.10 Cancelling the program
If you want to cancel the program and
terminate the drying operation for any
reason after the drying machine starts
running, turn the On/Off/Cancel knob, the
program will be cancelled.
A
The inside of the the clothes
dryer shall be extremely hot
when you cancel the program
during machine operation, so run
the refresh program to allow it to
cool down.
5.11 End of program
When the program ends, the Fibre Filter
Cleaning and Water Tank warning symbols on
the program observation indicator turn on.
Loading door may be opened and the dryer
machine becomes ready for another run.
Bring the On/Off/Program selection knob to
On/Off position to turn the the clothes dryer
off.
C
If the laundry is not removed
after the program is completed,
the wrinkle prevention function
activates for 2 hours to prevent
the laundry inside the machine
to get wrinkled. The program
tumbles the laundry with
10-minute intervals to prevent
them from wrinkling.
Adding and removing clothes during
stand-by
If you want to add or remove clothes to/
from the the clothes dryer after the drying
program starts:
• Press the Start/Stand-by button to put
the the clothes dryer in Stand-by mode.
The drying operation stops.
• Open the loading door while in Stand-
by mode, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.
C
Adding laundry after the drying
operation starts may cause the
dried laundry inside the machine
to mix with wet laundry and
leave the laundry damp at the
end of operation.
C
Adding or removing laundry
during drying may be
repeated as many times as
you wish. But this operation
continuously interrupts the
drying operation, and thus
increases program duration and
energy consumption. So, it is
recommended to add laundry
before the program starts.
C
If a new program is selected by
turning the program selection
knob while the drying machine is
in stand-by, the running program
terminates.
Do not touch the inner surface
of the drum while adding or
removing clothes during a
continuing program. The drum
surface is hot.
22 / EN
Dryer / User Manual
6 Mantenance and cleanng
Service life of product extends and
frequently experienced problems will be
reduced if it is cleaned at regular intervals.
6.1 Cleaning Lint Filter /
Loading Door Inner Surface
Lint and fiber released from the laundry to
the air during the drying cycle are collected in
the Lint Filter.
C
Such fiber and lint are generally
formed during wearing and
washing.
A
Always clean the lint filter and the
inner surfaces of the loading door
after each drying process.
C
You can clean the lint filter
housing with a vacuum cleaner.
To clean the lint filter:
• Open the loading door.
• Remove the lint filter by pulling it up and
open the lint filter.
• Clean lint, fiber, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
• A layer can build up on the filter pores
that can cause clogging of the filter after
using the dryer for a while. Wash the
lint filter with warm water to remove
the layer that builds up on the lint filter
surface. Dry the lint filter completely
before reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
6.2 Cleaning the sensor
There are dampness sensors in the dryer
that detect whether the laundry is dry or not.
To clean the sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is
still hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
23 / EN
Dryer / User Manual
Maintenance and cleaning
C
Clean metal surfaces of the
sensors 4 times a year.
C
Do not use metal tools when
cleaning metal surfaces of the
sensors.
A
Never use solvents, cleaning
agents or similar substances for
cleaning due to the risk of fire and
explosion!
6.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the
water that arise accumulates in the water
tank. Drain the water tank after each drying
cycle.
A
Condensed water is not drinkable!
A
Never remove the water tank
when the program is running!
If you forget to drain the water tank, the
machine will stop during the subsequent
drying cycles when the water tank is full and
the Water Tank warning symbol will flash.
If this is the case, drain the water tank and
press Start / Pause button to resume the
drying cycle.
To drain the water tank:
1. Remove the water tank in the drawer or
container carefully.
2. Drain the water in the tank.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
C
If the direct water draining is used
as an option, there is no need to
empty the water tank.
6.4 Cleaning the filter drawer
Lint and fiber that could not be captured
by the lint filter are blocked in the filter
drawer behind the kick plate. Clean the
filter periodically when there is visible air
collection on it or when the symbol lights up,
if there is a filter drawer cleaning warning
symbol « » available.
There is a one stage filter. This one stage
filter isn the form of a sponge
To clean the filter drawer:
• Press the kick plate button to open the
kick plate.
24 / EN
Dryer / User Manual
Maintenance and cleaning
• Open the filter drawer cap turning the
cap lock on it and pull it out..
• Open the filter drawer by pressing the
red button.
• Take out the filter drawer sponge.
• Clean the fluff and lint over the filter
sponge washing it with your hands.
Remove the moisture squeezing the
sponge with your hands after washing it.
• Clean the fluff, lint and cotton pellets
with your hands or with a soft cloth.
• If you observe a layer over the filter
which can block the filter, remove the
layer washing with a water and then
cleaning it. Dry the filter cloth properly
before replacing the filter drawer.
C
There may be no cloth in the filter
cassette of your drying machine,
depending on its model.
• Place the sponge back into its place.
C
Please place the sponge carefully
inside the frame of the filter
cassette shown by arrows in order
to avoid squeezing when filter
drawer closed”.:
• Close the filter drawer as to lock the red
button.
• Replace the filter drawer and tighten
the cap turning the filter drawer lock
turning it in the arrow direction.
25 / EN
Dryer / User Manual
Maintenance and cleaning
• Close the kick plate cover.
A
Drying without the filter drawer
sponge in place will damage the
machine!
C
A dirty lint filter and filter drawer
will cause longer drying periods
and higher energy consumption.
6.5 Cleaning the evaporator
Clean the lint accumulated on the fins of the
evaporator located behind the filter drawer
with a vacuum cleaner.
A
You can also clean by hand
provided that you wear protective
gloves. Do not attempt to clean
with bare hands. Evaporator fins
can harm your hand.
26 / EN
Dryer / User Manual
7 Troubleshootng
Drying operation takes too long.
• Fibre filter pores might be clogged. >>> Wash the filter with warm water.
• Filter drawer might be clogged. >>> Clean the sponge and filter cloth (if any) in the filter
drawer. (for the products with a heat pump)
• The condenser might be blocked. >>> Wash the condenser.(for the products with a
condenser )
• The ventilation grills in front of the machine may be clogged. >>> Remove any objects in
front of the ventilation grills that blocks air.
• Ventilation may be inadequate because the area where the machine is installed is too
small. >>> Open the door or windows to prevent the room temperature from rising very
high.
• A lime layer may have accumulated on the humidity sensor. >>> Clean the humidity
sensor.
• Excessive amount of laundry might be loaded. >>> Do not load the the clothes dryer
excessively.
• Laundry might not have been spun dry adequately. >>> Perform a higher speed spin dry
on the washing machine.
Clothes come out damp after drying.
• A program not suitable for the laundry type may have been used.>>> Check the
maintenance labels on the clothes and select a program suitable for the clothes’ type or
use time programs as extra.
• Fibre filter pores might be clogged. >>> Wash the filter with warm water.
• The condenser might be blocked. >>> Wash the condenser. (for the products with a
condenser)
• Filter drawer might be clogged. >>> Clean the sponge and filter cloth (if any) in the filter
drawer.(For the products with a heat pump)
• Excessive amount of laundry might be loaded. >>> Do not load the the clothes dryer
excessively.
• Laundry might not have beenspun dry adequately. >>> Perform a higher speed spin dry
on the washing machine.
The clothes dryer does not turn on or program cannot be started. The clothes dryer does not
run after it is programmed.
• Power plug might be unplugged. >>> Make sure the power cord is plugged in.
• Loading door might be open. >>> Ensure that the loading door is properly closed.
• A program might not be set or Start/Stand-by button might not be pressed. >>> Check
that the program is set and it is not in Stand-by position.
• Child lock may be activated. >>> Turn off the child lock.
Program terminated prematurely for no reason.
• Loading door might not be closed completely. >>> Ensure that the loading door is
properly closed.
• There might be a power outage. >>> Press the Start/Stand-by button to start the
program.
• Water tank may be full. >>> Empty the water tank.
Clothes have shrunk, hardened or spoiled.
• A program not suitable with the laundry type might have been used. >>> Check the
maintenance labels on the clothes and select a program suitable for the clothes.
27 / EN
Dryer / User Manual
Troubleshooting
The lighting inside the drying machine does not turn on. (For models with a lamp)
• The clothes dryer might not be turned on with the On/Off button or program might not
be selected for machines without an On/Off button. >>> Make sure that the the clothes
dryer is turned on.
• Lamp might be malfunctioning. >>> Contact an Authorised Service agent to replace the
lamp.
Filter cleaning warning symbol/LED is on/flashing.
• Fibre filter might not be cleaned. >>> Clean the filter.
• The filter slot might be clogged with lints. >>> Clean the filter slot.
• A layer of fluff might have accumulated clogging up the lint filter pores. >>> Wash the
filter with warm water.
• The condenser might be blocked. >>> Wash the condenser.
Water drips from the loading door.
• Fibres might have gathered on the inner sides of the loading door and the loading door
gasket. >>> Clean the inner surfaces of the loading door and the loading door gasket
surfaces.
Loading door opens by itself.
• Loading door might not be closed completely. >>> Push the loading door until the closing
sound is heard.
Water tank warning symbol / led is on/flashing.
• Water tank may be full. >>> Empty the water tank.
• Water discharge hose might have collapsed. >>> If the product is connected directly to
the water drain check the water discharge hose.
Steam symbol is flashing.(For the products with a steam function)
• Steam tank may be empty => Fill the steam tank with distilled or condensed water.
Steam programs do not start (For the products with a steam function)
• Steam tank may be empty, steam tank warning icon may light up on the screen => Fill
the steam tank until the steam icon goes off.
Wrinkles are not removed with wrinkle removing program. (For the products with a steam
function)
• Excess amount of laundry may have been placed => Place specified amount of laundry.
• Steam application time may be selected in low level => Choose a program with high
amount of steam.
• After completion of the program, the laundry may have stayed in the machine for a long
time => Take the laundry out as soon as the program finishes, and hang it out.
Laundry odour not lessened with the odour removal program.(For the products with an odour
removal program)
• Excess amount of laundry may have been placed => Place specified amount of laundry.
• Steam application time may be selected in low level => Choose a program with high
amount of steam.
A
If the problem persists after following the instructions in this section, contact your
vendor or an Authorised Service Agent.. Never try to repair your product yourself.
C
In an event that you encounter an issue on any part on your appliance, you can ask
for a replacement by contacting an Authorised Service Agent with the appliance
model number.
Operating the appliance with non-authentic parts may lead the appliance to
malfunction.
Manufacturer and distributor are not liable for malfunctions resulting from using
non-authentic parts.
