USER
MANUAL
EN User Manual
Microwave combi-oven
KMK868000B
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler -
features you might not find on ordinary appliances. Please spend a few minutes reading to
get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2/48
CONTENTS
1. SAFETY INFORMATION............................................................................... 5
1.1 Children and vulnerable people safety............................................................. 5
1.2 General Safety..................................................................................................5
2. SAFETY INSTRUCTIONS..............................................................................8
2.1 Installation.........................................................................................................8
2.2 Electrical connection.........................................................................................9
2.3 Use................................................................................................................... 9
2.4 Care and cleaning...........................................................................................10
2.5 Internal lighting............................................................................................... 10
2.6 Service............................................................................................................11
2.7 Disposal.......................................................................................................... 11
3. PRODUCT DESCRIPTION...........................................................................12
3.1 General overview............................................................................................12
3.2 Accessories.................................................................................................... 12
4. HOW TO TURN OVEN ON AND OFF..........................................................13
4.1 Control panel.................................................................................................. 13
4.2 Display............................................................................................................ 13
5. BEFORE FIRST USE................................................................................... 16
5.1 Initial Cleaning ............................................................................................... 16
5.2 First Connection..............................................................................................16
5.3 Wireless connection........................................................................................16
5.4 Software Licences.......................................................................................... 17
6. DAILY USE...................................................................................................18
6.1 How to set: Heating Functions........................................................................18
6.2 How to use: Microwave Quick Start ...............................................................18
6.3 How to set: Assisted Cooking......................................................................... 19
6.4 Heating Functions...........................................................................................20
7. CLOCK FUNCTIONS................................................................................... 23
7.1 Clock functions description............................................................................. 23
7.2 How to set: Clock functions............................................................................ 23
8. HOW TO USE: ACCESSORIES.................................................................. 27
8.1 Inserting accessories...................................................................................... 27
9. ADDITIONAL FUNCTIONS..........................................................................28
9.1 Automatic Switch-Off...................................................................................... 28
9.2 Cooling fan......................................................................................................28
10. HINTS AND TIPS....................................................................................... 29
10.1 Cooking recommendations........................................................................... 29
10.2 Microwave recommendations ...................................................................... 29
10.3 Microwave suitable cookware and materials ............................................... 29
10.4 Recommended power settings for different kinds of food.............................31
10.5 Cooking tables for test institutes...................................................................31
11. CARE AND CLEANING............................................................................. 34
11.1 Notes on cleaning......................................................................................... 34
11.2 How to remove: Shelf supports.....................................................................34
3/48
11.3 How to replace: Lamp...................................................................................35
12. TROUBLESHOOTING............................................................................... 36
12.1 What to do if..................................................................................................36
12.2 How to manage: Error codes........................................................................ 37
12.3 Service data..................................................................................................38
13. ENERGY EFFICIENCY.............................................................................. 39
13.1 Energy saving............................................................................................... 39
14. MENU STRUCTURE.................................................................................. 40
14.1 Menu.............................................................................................................40
14.2 Submenu for: Options...................................................................................40
14.3 Submenu for: Connections........................................................................... 41
14.4 Submenu for: Setup......................................................................................41
14.5 Submenu for: Service................................................................................... 41
15. IT'S EASY!..................................................................................................42
16. TAKE A SHORTCUT!................................................................................ 44
4/48
CONTENTS
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
• Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
• Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
• Do not let children play with the appliance and mobile
devices with My AEG Kitchen.
• Keep all packaging away from children and dispose of it
appropriately.
• Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts may
become hot during use.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• Only a qualified person must install this appliance and
replace the cable.
5/48
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
• Always use oven gloves to remove or put in accessories or
ovenware.
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• Do not use the appliance before installing it in the built-in
structure.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
• Do not activate the appliance when it is empty. Metal parts
inside the cavity can create electric arcing.
• Metallic containers for food and beverages are not allowed
during microwave cooking. This requirement is not
applicable if the manufacturer specifies size and shape of
metallic containers suitable for microwave cooking.
• The means for disconnection must be incorporated in the
fixed wiring in accordance with the wiring rules.
• If the door or door seals are damaged, the appliance must
not be operated until it has been repaired by a qualified
person.
• Only a qualified person can carry out any service or repair
operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
• Do not heat liquids and other foods in sealed containers.
They are liable to explode.
6/48
SAFETY INFORMATION
• Use only utensils that are suitable for use in microwave
ovens.
• When heating food in plastic or paper containers, keep an
eye on the appliance due to the possibility of ignition.
• The appliance is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads,
slippers, sponges, damp cloth and similar may lead to risk of
injury, ignition or fire.
• If smoke is emitted, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed
eruptive boiling. Care must be taken when handling the
container.
• The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
• Eggs in their shell and whole hard-boiled eggs should not be
heated in the appliance since they may explode, even after
microwave heating has ended.
• The appliance should be cleaned regularly and any food
deposits removed.
• Failure to maintain the appliance in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
7/48
SAFETY INFORMATION
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Follow the installation instructions supplied with the appliance.
• Always take care when moving the appliance as it is heavy. Always use safety gloves and
enclosed footwear.
• Do not pull the appliance by the handle.
• Install the appliance in a safe and suitable place that meets installation requirements.
• Keep the minimum distance from other appliances and units.
• Before mounting the appliance, check if the oven door opens without restraint.
• The appliance is equipped with an electric cooling system. It must be operated with the
electric power supply.
• The built-in unit must meet the stability requirements of DIN 68930.
Cabinet minimum height (Cabinet under the work‐
top minimum height)
444 (460) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of the appliance 455 mm
Height of the back of the appliance 440 mm
Width of the front of the appliance 595 mm
Width of the back of the appliance 559 mm
Depth of the appliance 567 mm
Built in depth of the appliance 546 mm
Depth with open door 882 mm
Ventilation opening minimum size. Opening placed
on the bottom rear side
560x20 mm
Mounting screws 3.5x25 mm
8/48
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the rating plate are compatible with the electrical ratings
of the mains power supply.
• Always use a correctly installed shockproof socket.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the mains cable. Should the mains
cable need to be replaced, this must be carried out by our Authorised Service Centre.
• Do not let mains cables touch or come near the appliance door or the niche below the
appliance, especially when it operates or the door is hot.
• The shock protection of live and insulated parts must be fastened in such a way that it
cannot be removed without tools.
• Connect the mains plug to the mains socket only at the end of the installation. Make sure
that there is access to the mains plug after the installation.
• If the mains socket is loose, do not connect the mains plug.
• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed
from the holder), earth leakage trips and contactors.
• The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
• This appliance is supplied without a main plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and electric shock or explosion.
• This appliance is for household use only.
• Do not change the specification of this appliance.
• Make sure that the ventilation openings are not blocked.
• Do not let the appliance stay unattended during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance door while the appliance is in operation. Hot air can
release.
• Do not operate the appliance with wet hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface or as a storage surface.
• Open the appliance door carefully. The use of ingredients with alcohol can cause a mixture
of alcohol and air.
• Do not let sparks or open flames to come in contact with the appliance when you open the
door.
• Do not put flammable products or items that are wet with flammable products in, near or on
the appliance.
9/48
SAFETY INSTRUCTIONS
• Do not share your Wi-Fi password.
• Do not use microwave function to preheat the oven.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the enamel:
– do not put aluminium foil directly on the bottom of cavity of the appliance.
– do not put water directly into the hot appliance.
– do not keep moist dishes and food in the appliance after you finish the cooking.
– be careful when you remove or install the accessories.
• Discoloration of the enamel or stainless steel has no effect on the performance of the
appliance.
• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.
• This appliance is for cooking purposes only. It must not be used for other purposes, for
example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a furniture panel (e.g. a door) make sure the door is never
closed when the appliance is in operation. Heat and moisture can build up behind a closed
furniture panel and cause subsequent damage to the appliance, the housing unit or the floor.
Do not close the furniture panel until the appliance has cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage to the appliance.
• Before maintenance, deactivate the appliance and disconnect the mains plug from the mains
socket.
• Make sure the appliance is cold. There is the risk that the glass panels can break.
• Replace immediately the door glass panels when they are damaged. Contact the Authorised
Service Centre.
• Be careful when you remove the door from the appliance. The door is heavy!
• Make sure the cavity and the door are wiped dry after each use. Steam produced during the
operation of the appliance condensates on cavity walls and can cause corrosion.
• Clean regularly the appliance to prevent the deterioration of the surface material.
• Fat and food remaining in the appliance can cause fire and electric arcing when the
microwave function operates.
• Clean the appliance with a moist soft cloth. Use only neutral detergents. Do not use abrasive
products, abrasive cleaning pads, solvents or metal objects.
• If you use an oven spray, follow the safety instruction on it's packaging.
• Do not clean the catalytic enamel (if applicable) with detergents.
2.5 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen lamp used for this appliance is for household appliances
only. Do not use it for house lighting.
10/48
SAFETY INSTRUCTIONS
• Before replacing the lamp, disconnect the appliance from the power supply.
• Use only lamps with the same specifications.
2.6 Service
• To repair the appliance contact the Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains supply.
• Cut off the mains electrical cable close to the appliance and dispose of it.
• Remove the door catch to prevent children or pets from becoming trapped in the appliance.
11/48
SAFETY INSTRUCTIONS
3. PRODUCT DESCRIPTION
3.1 General overview
1 2
8
4
3
1
2
3
6
4
5
7
1
Control panel
2
Display
3
Heating element
4
Microwave generator
5
Lamp
6
Fan
7
Shelf support, removable
8
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect fat.
12/48
4. HOW TO TURN OVEN ON AND OFF
4.1 Control panel
1 2
Function Comment
1
On / Off Press and hold to turn the oven on and off.
2
Display Shows the current settings of the oven.
Press Move
3s
Press and hold
Touch the surface with finger‐
tip.
Slide fingertip over the sur‐
face.
Touch the surface for 3 sec‐
onds.
4.2 Display
Conventional cooking
After turning on, the display shows the main
screen with heating functions and the default
temperature.
13:00
If you do not use the oven for 2 minutes, the
display goes to standby.
STOP
29sec
1000 W
+5 sec
+10 sec
+30 sec
Microwave
When you cook, the display shows the set
functions and other available options.
13/48
Conventional cooking
A
K
J
I H G F E
B C D
The display with the maximum number of func‐
tions set.
A. Menu / Back
B. Wi-Fi
C. Time of Day
D. Information
E. Timer
F. Food Sensor (selected models only)
Microwave Quick Start
G. START / STOP
H. Temperature / Microwave Timer
I. Progress Bar / Slider
J. More
K. Heating Functions
Display indicators
Basic indicators - to navigate on the display.
To confirm
the selec‐
tion / set‐
ting.
To confirm the
selection / set‐
ting or to go
one level back
in the menu.
To go one level back in
the menu / undo the last
action.
To turn the options on and off.
Sound alarm function indicators - when the set time of cooking ends, the signal sounds.
The function is on.
The function is on.
Cooking stops automati‐
cally.
Sound alarm is off.
Timer indicators
14/48
HOW TO TURN OVEN ON AND OFF
Display indicators
To set the function: Set Start
Time.
To cancel
the setting.
The timer
starts after
closing the
oven door.
The timer starts
when the oven
reaches the set
temperature.
The timer starts
when cooking
starts.
Door function indicators
The oven door is locked.
Wi-Fi indicators - the oven can be connected to Wi-Fi.
Wi-Fi connection is turned on.
Wi-Fi connection is turned off.
15/48
HOW TO TURN OVEN ON AND OFF
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial Cleaning
Step 1
Remove all accessories and
removable shelf supports from
the oven.
Step 2
Clean the oven and the ac‐
cessories before the first use.
Refer to "Care and cleaning"
chapter.
Step 3
Put the accessories and the
removable shelf supports
back to their initial position.
5.2 First Connection
The display shows welcome message after the first connection.
You have to set: Language, Display Brightness, Buzzer Volume, Time of Day.
5.3 Wireless connection
To connect the oven you need:
• Wireless network with the Internet connection.
Step 1 Turn on the oven.
Step 2 Press Menu / Settings / Connections.
Step 3
Slide or press to turn on Wi-Fi.
Step 4 Choose wireless network with the Internet connection. The oven wireless module will
start within 90 seconds.
To configure the wireless connection at any other time press on the display.
Take a shortcut!
Frequency 2412 - 2484 MHz
Protocol IEEE 802.11b DSSS/802.11g/n OFDM
16/48
Max Power EIRP < 20 dBm (100 mW)
5.4 Software Licences
The oven software contains copyrighted software that is licensed under the BSD, fontconfig, FTL,
GPL-2.0, LGPL-2.0, LGPL-2.1, libJpeg, zLib/ libpng, MIT, OpenSSL / SSLEAY ISC, Apache 2.0
and others.
Check the full copy of the licence in: Basic Settings / Service / Licence.
You can download the source code of the open source software by following the hyperlink present
on the product web page.
Look for the oven model and Wi-Fi Module Software version on http://aeg.opensoftwarereposito‐
ry.com inside "NIUX" folder.
17/48
BEFORE FIRST USE
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 How to set: Heating Functions
Step 1 Turn on the oven.
Step 2 Select a heating function.
The display shows the default heating functions. To see more heating functions
press .
Step 3
Press .
Display goes into the temperature settings.
170°C
-5°C +5°C
210°C
170°C70°C
OK
Step 4 Move the finger on the slider to set the temperature.
Step 5
Press .
Step 6
Press .
Step 7
Press to turn off the heating function.
Step 8 Turn off the oven.
Take a shortcut!
6.2 How to use: Microwave Quick Start
Step 1
Press and hold on the display. The microwave runs for 30 seconds.
18/48
Step 2 To extend the cooking time:
Press one of the time shortcuts on the
display.
STOP
29sec
1000 W
+5 sec
+10 sec
+30 sec
Microwave
Press on the running time value to go to the
time slider. Move the dot on the time slider
to the chosen value.
18sec
2min50sec30sec
+60sec
Now
The microwave can be switched on with: Microwave Quick Start any time.
The only exception: ECO Mode.
6.3 How to set: Assisted Cooking
Every dish in this submenu has a recommended function and temperature. Temperature and
time can be adjusted manually according to the user's preference.
The degree to which a dish is cooked:
• Rare or Less
• Medium
• Well done or More
Step 1
Press .
Step 2
Press to enter Assisted Cooking.
Step 3 Choose a dish or food type.
Step 4
Press .
Take a shortcut!
19/48
DAILY USE
6.4 Heating Functions
Standard Heating Functions
Heating function Application
Grill
To grill flat food and to toast bread.
Turbo Grilling
To roast larger meat joints or poultry with bones on one shelf posi‐
tion. To make gratins and to brown.
True Fan Cooking
To bake on up to two shelf positions at the same time and to dry
food.Set the temperature 20 - 40 °C lower than for Conventional
Cooking.
Frozen Foods
To make convenience food (e.g. french fries, potato wedges or
spring rolls) crispy.
Conventional Cooking
To bake and roast food on one shelf position.
Pizza Function
To bake pizza. To make intensive browning and a crispy bottom.
Bottom Heat
To bake cakes with crispy bottom and to preserve food.
Microwave
To heat and cook food.The microwave power range is from 100 -
1000 W.
20/48
DAILY USE
Special Heating Functions
Heating function Application
Preserving
To preserve vegetables (e.g. pickles).
Dehydrating
To dry sliced fruit, vegetables and mushrooms.
Plate Warming
To preheat plates for serving.
Dough Proving
To speed up the rising of the yeast dough. It prevents dough sur‐
face from drying and keeps the dough elastic.
Au Gratin
For dishes such as lasagna or potato gratin. To make gratins and
to brown.
Slow Cooking
To prepare tender, succulent roasts.
Keep Warm
To keep food warm.
Bread Baking
Use this function to prepare bread and bread rolls with a very good
professional-like result in terms of crispiness, colour and crust
gloss.
Microwave Oven Functions
Heating function Application
Defrost
To defrost meat, fish, fruit, cakes, bread and butter. Power range
is 100 - 200 W.
21/48
DAILY USE
Heating function Application
Reheat
To heat pre-prepared meals and delicate food.Power range is 300
- 700 W.
Liquid
To heat drinks and soups.Power range is 800 - 1000 W.
True Fan Cooking + MW
To bake on one shelf position. Function with MW boost.
Conventional Cooking +
MW
To bake and roast food on one shelf position. Function with MW
boost.
Grill + MW
To grill thin pieces of food and to toast bread. Function with MW
boost.
Turbo Grilling + MW
To roast large pieces of meat on one level. To make gratins and to
brown. Function with MW boost.
22/48
DAILY USE
7. CLOCK FUNCTIONS
7.1 Clock functions description
Clock function Application
Cooking time To set the length of cooking. Maximum is 23 h 59 min.
Start Criteria To set when the timer starts counting.
End Criteria To set what happens when the timer ends counting.
Set Start Time To postpone the start and / or end of cooking.
Time Extension To extend cooking time.
Reminder To set a countdown. Maximum is 23 h 59 min. This function has no ef‐
fect on the operation of the oven.
Start Criteria, End Action and Delay of cooking are not available for microwave functions.
7.2 How to set: Clock functions
How to set the clock
Step 1
Press on the display.
Step 2 Press: Settings / Setup / Time of Day.
Step 3 Slide and press to set the clock.
Step 4
Press or .
How to set cooking time
Step 1 Choose a heating function and set the temperature.
Step 2
Press to set the cooking time.
Step 3 Move the dot on the slider or press the preferred time icon.
Step 4
Press . Timer starts counting down immediately.
23/48
Take a shortcut!
70°C
How to choose cooking start / end option
Step 1 Choose a heating function and set the temperature.
Step 2
Press to set cooking time.
Step 3
Press .
Step 4 Press Start Criteria / End Criteria.
Step 5 Choose the preferred Start Criteria / End Criteria.
Step 6
Press or .
Press to cancel chosen starting or end option.
Start criteria Comment
- The timer starts when you turn it on.
The timer starts after closing the door.
The timer starts when cooking starts.
The timer starts when the oven reaches the set temperature.
End action Comment
When the set cooking time ends, the signal sounds.
When the set cooking time ends, the signal sounds. Cooking stops auto‐
matically.
When the set cooking time ends, the display shows the message with‐
out a sound signal.
24/48
CLOCK FUNCTIONS
How to delay start and end of cooking
Step 1
Press on the display.
Step 2 Move the dot on the slider or press the preferred time icon.
Step 3
Press .
Take a shortcut!
How to delay start without setting the end of cooking
Step 1 Set a heating function and the temperature.
Step 2
Press .
Step 3
Press .
Step 4 Press Set Start Time.
Step 5 Move the left dot to the preferred value.
Step 6
Press .
How to set extra time
When 10% of cooking time is left and the food seems not to be ready, you can extend cooking
time. You can also change the oven function.
Step 1 Press the preferred time icon to extend cooking time.
Step 2 Also, select the preferred heating function to change it.
What if it's better to change extra time?
It's possible to reset extra time.
25/48
CLOCK FUNCTIONS
How to set extra time
Step 1
Press .
Step 2 Move the dot on the slider or press one of the preferred time icons to set the
time.
Step 3
Press .
How to change timer settings
Step 1 Move the dot on the slider or use shortcuts to change the timer value.
Step 2
Press or press to reset changes.
You can change the set time during cooking at any time.
How to cancel set timer
Step 1
Press .
Step 2
Press to cancel set timer.
Step 3
Press .
Take a shortcut!
26/48
CLOCK FUNCTIONS
8. HOW TO USE: ACCESSORIES
8.1 Inserting accessories
Use only suitable cookware and material. Refer to "Hints and tips" chapter, Microwave suitable
cookware and materials.
A small indentation at the top increases safety. The indentations are also anti-tip devices. The
high rim around the shelf prevents cookware from slipping of the shelf.
Wire shelf: Push the shelf between the guide bars of the shelf support and make sure
that the feet point down.
Baking tray /
Deep pan:
Push the baking tray / deep pan between the guide bars of the shelf support.
Wire shelf and
baking tray /
deep pan to‐
gether:
Push the baking tray / deep pan between the guide bars of the shelf support
and the wire shelf on the guide bars above.
27/48
9. ADDITIONAL FUNCTIONS
9.1 Automatic Switch-Off
For safety reasons the oven turns off automatically after some time, if a heating function works
and you do not change any settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 230 5.5
The Automatic Switch-off does not work with the functions: Light, Duration, End Time.
9.2 Cooling fan
When the oven operates, the cooling fan turns on automatically to keep the surfaces of the
oven cool. If you turn off the oven, the cooling fan can continue to operate until the oven cools
down.
28/48
10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
10.1 Cooking recommendations
Your oven may bake or roast differently to the oven you had before. The tables below show
recommended settings for temperature, cooking time and shelf position for specific types of the
food.
If you cannot find the settings for a special recipe, look for the similar one.
For more cooking recommendations refer to cooking tables on our website. To find the Cooking
Hints check the PNC number on the rating plate on the front frame of the oven cavity.
10.2 Microwave recommendations
Place the food on a plate on the bottom of the cavity.
Turn or stir the food halfway through the defrosting and cooking time.
Cover the food for cooking and reheating.
Put the spoon to the bottle or glass when heating drinks to ensure better heat distribution.
Put the food into the oven without any packaging. The packaged ready meals can be put into
the oven only when the packaging is microwave safe (check information on the packaging).
Microwave cooking
Cook food covered. If you want to keep a crust cook food without a cover.
Do not overcook the dishes by setting the power and time too high. The food can dry out, burn
or cause fire.
Do not use the oven to cook eggs or snails in their shells, because they can burst. Pierce the
yolk of fried egg before reheating it.
Pierce food with skin or peel with a fork several times before cooking.
Cut vegetables into similar-sized pieces.
Stir liquid dishes from time to time.
Stir the food before serving.
After you turn off the oven, take the food out and let it stand for a few minutes.
Microwave defrosting
Put the frozen, unwrapped food on a small upturned plate with a container below it, or on a
defrosting rack or plastic sieve so that the defrosting liquid can run off.
Remove defrosted pieces subsequently.
To cook fruit and vegetables without defrosting them first, you can use a higher microwave
power.
10.3 Microwave suitable cookware and materials
For the microwave use only suitable cookware and materials. Use below table as a reference.
Cookware / Material
Ovenproof glass and porcelain
with no metal components, e.g.
heat-proof glass
Non-ovenproof glass and porce‐
lain without any silver, gold, plat‐
inum or other metal decorations
X X
29/48
Cookware / Material
Glass and glass ceramic made
of ovenproof / frost-proof materi‐
al
Ceramic and earthenware with‐
out any quartz or metal compo‐
nents and glazes which contain
metal
X
Ceramic, porcelain and earthen‐
ware with unglazed bottom or
with small holes, e.g. on handles
X X X
Heat-resistant plastic up to 200
°C (please always check the
plastic container specification
before use)
X
Cardboard, paper X X
Clingfilm X X
Roasting film with microwave
safe closure (please always
check the film specification be‐
fore use)
X
Roasting dishes made of metal,
e.g. enamel, cast iron
X X X
Baking tins, black lacquer or sili‐
con-coated (please always
check the baking tins specifica‐
tion before use)
X X X
Baking tray X X X
Wire shelf X X
Cookware for microwave use,
e.g. crisp pan
X X
30/48
HINTS AND TIPS
10.4 Recommended power settings for different kinds of food
The data in the table is for guidance only.
700 Watt 800 Watt 900 Watt 1000 Watt
Cooking vegetables
Searing at the start of
the cooking process
Heating liquids
500 Watt 600 Watt
Cooking egg dishes
Simmering stews
Heating one-plate
meals
Defrosting and heat‐
ing frozen meals
300 Watt 400 Watt
Melting cheese,
chocolate, butter
Simmering rice
Heating baby
food
Cooking / Heating
delicate food
Continuing
cooking
100 Watt 200 Watt
Defrosting
Defrosting bread
Defrosting fruits and
cakes
Defrosting cheese,
cream, butter
Defrosting meat, fish
10.5 Cooking tables for test institutes
Information for test institutes
Tests according to IEC 60705.
31/48
HINTS AND TIPS
MICROWAVE FUNCTION
Use wire shelf unless otherwise specified.
(W)
(kg)
(min)
Sponge
cake
600 0.475 Bottom 7 - 9 Turn container around by
1/4, halfway through the
cooking time.
Meatloaf 400 0.9 2 25 - 32 Turn container around by
1/4, halfway through the
cooking time.
Egg custard 500 1 Bottom 18 -
Meat de‐
frosting
200 0.5 Bottom 7 - 8 Turn the meat upside
down halfway through
the cooking time.
Tests according to IEC 60705.
MICROWAVE COMBI FUNCTION
Use the wire shelf.
(W) (°C) (min)
Cake, 0.7
kg
Conven‐
tional Cook‐
ing + MW
100 200 2 23 - 27 Turn container
around by 1/4,
halfway through
the cooking time.
Potato
gratin,
1.1 kg
True Fan
Cooking +
MW
300 180 2 38 - 42 Turn container
around by 1/4,
halfway through
the cooking time.
32/48
HINTS AND TIPS
MICROWAVE COMBI FUNCTION
Use the wire shelf.
(W) (°C) (min)
Chicken,
1.1 kg
Turbo Grill‐
ing + MW
400 230 1 35 - 40 Put the meat in
round glass con‐
tainer and turn it
upside down half‐
way through the
cooking time.
33/48
HINTS AND TIPS
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
Cleaning
Agents
Clean the front of the oven with a soft cloth with warm water and a mild cleaning
agent.
To clean metal surfaces, use a dedicated cleaning agent.
Clean stubborn stains with a special oven cleaner.
Everyday Use
Clean the oven cavity after each use. Fat accumulation or other food remains
may cause fire. The risk is higher for the grill pan.
Dry the cavity with a soft cloth after each use.
Clean the cavity ceiling carefully from food residuals and fat.
Accessories
Clean all accessories after each use and let them dry. Use a soft cloth with
warm water and a cleaning agent. Do not clean the accessories in a dishwash‐
er.
Do not clean the non-stick accessories using aggressive agents, sharp-edged
objects or in a dishwasher
11.2 How to remove: Shelf supports
Before maintenance, make sure that the oven is cold. There is a risk of burns.
To clean the oven, remove the shelf supports.
Step 1
2
3
1
Pull carefully the supports up and out of the front catch.
Step 2 Pull the front end of the shelf support away from the side wall.
Step 3 Pull the supports out of the rear catch.
Install the shelf supports in the opposite sequence.
34/48
11.3 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the oven.
Wait until the oven is cooled down.
2. Disconnect the oven from the mains.
3. Put a cloth on the bottom of the cavity.
CAUTION!
Always hold the halogen lamp with a cloth to prevent grease residue from burning on the
lamp.
The top lamp
Step 1 Turn the lamp glass cover to remove it.
Step 2 Clean the glass cover.
Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp.
Step 4 Install the glass cover.
35/48
CARE AND CLEANING
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
The oven does not turn on or does not heat up
Possible cause
Remedy
The oven is not connected to an electrical sup‐
ply or it is connected incorrectly.
Check if the oven is correctly connected to the
electrical supply.
The clock is not set. Set the clock, for details refer to "Clock Func‐
tions" chapter, How to set: Clock functions.
The door is not closed correctly. Fully close the door.
The fuse is blown. Make sure the fuse is the cause of the prob‐
lem. If the problem recurs, contact a qualified
electrician.
The oven Child Lock is on. Refer to "Menu" chapter, Submenu for: Op‐
tions.
Components need to be replaced
Description Remedy
The lamp is burnt out. Replace the lamp, for details refer to "Care and
Cleaning" chapter, How to replace: Lamp.
Problems with Wi-Fi signal
Possible cause
Remedy
Trouble with wireless network signal. Check your wireless network and router.
Restart the router.
36/48
Problems with Wi-Fi signal
Possible cause
Remedy
New router installed or router configuration
changed.
To configure oven and mobile device again, re‐
fer to "Before first use" chapter, Wireless con‐
nection.
The wireless network signal is weak. Move router as close to the oven as possible.
The wireless signal is disrupted by a micro‐
wave appliance placed near the oven.
Turn off the microwave appliance.
12.2 How to manage: Error codes
When the software error occurs, the display shows error message.
In this section, you will find the list of the problems that you can handle on your own.
Code and description Action
F240, F439 - the touch fields on the display do not
work properly.
Clean the surface of the display. Make
sure there is no dirt on the touch fields.
F601 - there is a problem with Wi-Fi signal. Check your network connection. Refer to
"Before first use" chapter, Wireless con‐
nection.
F604 - the first connection to Wi-Fi failed. Turn the oven off and on and try again.
Refer to "Before first use" chapter, Wire‐
less connection.
F908 - the oven system cannot connect with the
control panel.
Turn the oven off and on.
In this section, you will find the list of the problems that have to be handled by a qualified
technician.
Code and description Action
F131 - the temperature of magnetron sensor is too
high.
Turn the oven off and wait until it cools
down. Turn the oven on again.
37/48
TROUBLESHOOTING
Code and description Action
F602, F603 - Wi-Fi is not available. Turn the oven off and on.
When one of these error messages continues to appear on the display, it means a faulty
subsystem may have been disabled. In such a case contact your dealer or an Authorized
Service Centre. If one of these errors occurs, the rest of the oven functions will continue to work
as usually.
12.3 Service data
If you cannot find a solution to the problem yourself, contact your dealer or an Authorised
Service Centre.
The necessary data for the service centre is on the rating plate. The rating plate is on the front
frame of the oven cavity. Do not remove the rating plate from the oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
38/48
TROUBLESHOOTING
13. ENERGY EFFICIENCY
13.1 Energy saving
The oven contains features which help you save energy during everyday cooking.
Make sure that the oven door is closed properly when the oven operates. Do not open the door
too often during cooking. Keep the door gasket clean and make sure it is well fixed in its
position.
Use metal cookware to improve energy saving(only when you use a non-microwave function).
When possible, do not preheat the oven before cooking.
Keep breaks between baking as short as possible when you prepare a few dishes at one time.
Cooking with fan
When possible, use the cooking functions with fan to save energy.
Residual heat
If a programme with the Duration or End Time selection is activated and the cooking time is
longer than 30 minutes, the heating elements automatically turn off earlier in some oven
functions.
The fan and lamp continue to operate. When you turn off the oven, the display shows the
residual heat. You can use that heat to keep the food warm.
When the cooking duration is longer than 30 minutes, reduce the oven temperature to minimum
3 - 10 minutes before the end of cooking. The residual heat inside the oven will continue to
cook.
Use the residual heat to warm up other dishes.
Keep food warm
Choose the lowest possible temperature setting to use residual heat and keep a meal warm.
The residual heat indicator or temperature appears on the display.
Cooking with the lamp off
Turn off the lamp during cooking. Turn it on only when you need it.
Standby mode
After 2 minutes the display goes to standby mode.
39/48
14. MENU STRUCTURE
14.1 Menu
Press on the display to open Menu.
Options
Cleaning
Choose dish
Menu
Menu item Application
Assisted Cooking Contains a list of automatic pro‐
grammes.
Options To set the oven configuration.
Settings Connections To set the network configuration.
Setup To set the oven configuration.
Service Shows the software version and con‐
figuration.
14.2 Submenu for: Options
Submenu Application
Light To turn the lamp on and off.
Lamp Icon Visible Lamp icon appears on the screen.
Fast Heat Up Shortens heat up time. Note that it is available only for
some of the oven functions.
Child Lock Prevents accidental activation of the oven. When the option
is on, the text "Child Lock" appears on the display when you
turn on the oven. To enable the oven use, choose the code
letters in the alphabetical order.
ECO Mode Switches off Wi-Fi and the display to save as much power
as possible. Microwave quickstart is not available on stand‐
by in ECO Mode .
40/48
14.3 Submenu for: Connections
Submenu Description
Wi-Fi To enable and disable Wi-Fi.
Network To check network status and Wi-Fi signal power.
Forget Network To disable current network from auto connection with the
oven.
14.4 Submenu for: Setup
Submenu Description
Language Sets the oven language.
Time of Day Sets the current time and date.
Time Indication Turns the clock on and off.
Digital Clock Style Changes the format of the displayed time indication.
Key Tones Turns the tone of the touch fields on and off. It is not possi‐
ble to switch off the tone of the ON / OFF and STOP.
Alarm / Error Tones Turns the alarm tones on and off .
Buzzer Volume Regulates the volume of key tones and signals.
Display Brightness Regulates the display brightness.
14.5 Submenu for: Service
Submenu Description
Demo mode Activation / deactivation code: 2468
Licence Information about licenses.
Software Version Information about software version.
Reset All Settings Restores factory settings.
Reset all popups Restores all pop-ups to the original settings.
41/48
MENU STRUCTURE
15. IT'S EASY!
Before first use you have to set:
Language
Display Bright‐
ness
Buzzer Volume Time of Day
Wireless connec‐
tion
Familiarize yourself with the basic icons on the control panel and the display:
On / Off
Menu /
Back
Wi-Fi
Information Timer
/
More
Start using the oven
Quick start Turn on the
oven and start
cooking with the
default tempera‐
ture and time of
the function.
Step 1 Step 2 Step 3
Press and hold
.
Set the oven
function .
Press .
Quick Off Turn off the
oven at any
time, any screen
or message.
Press and hold until the oven turns off.
Quick MW Start Microwave
at any time with
the default set‐
tings: 30 sec /
1000W.
Press .
Start cooking
Step 1 Step 2 Step 3 Step 4 Step 5 Step 6
Turn on the
oven.
Press the
function.
Press to go
to the tem‐
perature set‐
tings.
Move the fin‐
ger on the
slider to set
the tempera‐
ture.
Press to con‐
firm.
Press to start
cooking.
Get to know how to cook quickly
Use the automatic programmes to prepare a dish quickly with the default settings:
42/48
Get to know how to cook quickly
Assisted Cooking Step 1 Step 2 Step 3
Press . Press Assisted
Cooking.
Choose the dish.
Use quick functions to set the cooking time or change the cooking function
Quick timer settings
Use the most used timer settings by choosing
from the shortcuts.
Step 1 Step 2
Press .
Press the preferred
timer value.
10% Finish assist
Use 10% Finish assist to add extra time or
change cooking function when 10% of the
cooking time is left.
To extend the cooking time press the preferred
time icon:
+1 min +5 min +10 min
.
Change function:
Press preferred function .
43/48
IT'S EASY!
16. TAKE A SHORTCUT!
Here you can see all the useful shortcuts. You can also find them in the dedicated chapters in
the user manual.
Wireless connection
How to set: Oven Functions
How to set: Assisted Cooking
How to set cooking time
70°C
How to delay start and end of cooking
How to cancel set timer
44/48
17. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the packaging in relevant containers to recycle it.
Help protect the environment and human health by recycling waste of electrical and electronic
appliances. Do not dispose of appliances marked with the symbol
with the household waste.
Return the product to your local recycling facility or contact your municipal office.
45/48
*
46/48
47/48
www.aeg.com/shop
867353280-B-262019
