USER
MANUAL
EN User Manual
Microwave combi-oven
KME565000M
KMK565000M
CONTENTS
1. SAFETY INFORMATION............................................................................................. 2
2. SAFETY INSTRUCTIONS.............................................................................................5
3. PRODUCT DESCRIPTION...........................................................................................8
4. CONTROL PANEL....................................................................................................... 8
5. BEFORE FIRST USE..................................................................................................... 9
6. DAILY USE.................................................................................................................... 9
7. CLOCK FUNCTIONS.................................................................................................11
8. USING THE ACCESSORIES...................................................................................... 14
9. ADDITIONAL FUNCTIONS...................................................................................... 14
10. HINTS AND TIPS..................................................................................................... 15
11. CARE AND CLEANING.......................................................................................... 32
12. TROUBLESHOOTING.............................................................................................34
13. ENERGY EFFICIENCY.............................................................................................35
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1.
SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
www.aeg.com
2
manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts
become hot during use.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2
General Safety
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements.
• Always use oven gloves to remove or put in
accessories or ovenware.
ENGLISH
3
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
• WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
• Do not use the appliance before installing it in the
built-in structure.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Do not activate the appliance when it is empty. Metal
parts inside the cavity can create electric arcing.
• Metallic containers for food and beverages are not
allowed during microwave cooking. This requirement
is not applicable if the manufacturer specifies size and
shape of metallic containers suitable for microwave
cooking.
• WARNING: If the door or door seals are damaged, the
appliance must not be operated until it has been
repaired by a qualified person.
• WARNING: Only a qualified person can carry out any
service or repair operation that involves the removal of
a cover which gives protection against exposure to
microwave energy.
• WARNING: Do not heat liquids and other foods in
sealed containers. They are liable to explode.
• Use only utensils that are suitable for use in microwave
ovens.
• When heating food in plastic or paper containers,
observe the appliance due to the possibility of
ignition.
• The appliance is intended for heating food and
beverages. Drying of food or clothing and heating of
www.aeg.com
4
warming pads, slippers, sponges, damp cloth and
similar may lead to risk of injury, ignition or fire.
• If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
• Microwave heating of beverages can result in delayed
eruptive boiling. Care must be taken when handling
the container.
• The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
• Eggs in their shell and whole hard-boiled eggs should
not be heated in the appliance since they may
explode, even after microwave heating has ended.
• The appliance should be cleaned regularly and any
food deposits removed.
• Failure to maintain the appliance in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Keep the minimum distance from
other appliances and units.
• Before mounting the appliance, check
if the oven door opens without
restraint.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
• The built-in unit must meet the
stability requirements of DIN 68930.
Cabinet minimum
height (Cabinet un-
der the worktop mini-
mum height)
444 (460) mm
Cabinet width 560 mm
Cabinet depth 550 (550) mm
Height of the front of
the appliance
455 mm
Height of the back of
the appliance
440 mm
Width of the front of
the appliance
595 mm
ENGLISH 5
Width of the back of
the appliance
559 mm
Depth of the appli-
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open
door
882 mm
Ventilation opening
minimum size. Open-
ing placed on the
bottom rear side
560x20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 3.5x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance is supplied only with a
main cable.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
www.aeg.com
6
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not use microwave function to
preheat the oven.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance operates. Heat and
moisture can build up behind a closed
furniture panel and cause subsequent
damage to the appliance, the housing
unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Make sure the cavity and the door are
wiped dry after each use. Steam
produced during the operation of the
appliance condensates on cavity walls
and can cause corrosion.
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Fat and food remaining in the
appliance can cause
fire and electric
arcing when the microwave function
operates.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
• If you use an oven spray, follow the
safety instructions on its packaging.
2.5 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen
lamp used for this appliance is for
household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Use only lamps with the same
specifications.
2.6 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
ENGLISH
7
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
3. PRODUCT DESCRIPTION
3.1 General overview
1 2 43
11
4
3
1
2
8
10
5
6
7
9
1
Control panel
2
Knob for the heating functions
3
Display
4
Control knob
5
Heating element
6
Microwave generator
7
Lamp
8
Fan
9
Rating plate
10
Shelf support, removable
11
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
4. CONTROL PANEL
4.1 Retractable knobs
To use the appliance press the knob. The
knob comes out.
4.2 Buttons
Sensor field / Button Description
To set the microwave function. Hold it for more than 3 sec-
onds to turn on or turn off the oven lamp. You can turn on
the light also when the oven is turned off.
www.aeg.com8
Sensor field / Button Description
To set a clock function.
To check the oven temperature or the temperature of the
core temperature sensor (if applicable). Use only while the
heating function operates.
4.3 Display
A B C
EH FG D
A. Timer / Temperature / Microwave
power
B. Heat-up and residual heat indicator
C. Microwave mode
D. Food Sensor (selected models only)
E. Door lock (selected models only)
F. Hours / minutes
G. Demo Mode
H. Clock functions
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
Set the time before you use the oven.
5.1 Initial Cleaning
Step 1 Step 2 Step 3
Remove all accessories and
removable shelf supports
from the oven.
Clean the oven and the ac-
cessories with a soft cloth,
warm water and a mild de-
tergent.
Place the accessories and
the removable shelf sup-
ports in the oven.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 How to set: Heating
function
Step 1 Turn the knob for the heating
functions to select a heating
function.
Step 2 Turn the control knob to se-
lect the temperature / the mi-
crowave power.
Step 3 When the cooking ends, turn
the knobs to the off position
to turn off the oven.
ENGLISH 9
6.2 Setting function:
Microwave
1. Remove all accessories.
2. Turn the knob for the heating
functions to select the function:
Microwave
First, the display shows the default
setting for microwave power and then
the default setting for: Duration.
To start with the default settings press:
.
3. Turn the control knob to change the
microwave power. The power setting
changes in 100 W steps.
4. Press and then turn the control
knob to change: Duration. Press
again and again to switch between
the settings for: Duration and
microwave power. Turn the control
knob to set the value. To confirm
press: .
5. Press:
.
The signal sounds and the oven stops
when cooking time ends.
6. Turn the knob for the heating
functions to the off position.
When you open the oven door, the oven
stops. To start it again, close the door
and press: .
The maximum time of microwave func-
tions depends on microwave power you
set:
MICROWAVE
POWER
MAXIMUM TIME
100 - 600 W 90 minutes
More than 600 W 7 minutes
6.3 How to set: Microwave
Combi
You can combine the microwave function
with any of the heating functions.
The oven can make noises when using
the function: Microwave Combi. They are
normal for this function.
Step 1 Turn the knob for the heating
functions to select the func-
tion.
The display shows the default
temperature.
Step 2 Turn the control knob to
change the temperature.
Step 3 To combine heating function
with the microwave mode
press: .
Step 4 Turn the control knob to
change the microwave power
settings. The power setting
changes in 100 W steps.
Around 5 degrees before the
set temperature is reached
the signal sounds. When the
set time ends the signal
sounds again and the oven
stops.
Step 5 Turn the knobs to the off posi-
tion.
Microwave power is limited to 600 W
when you use the function: Microwave
Combi.
6.4 Heat-up indicator
When the oven function operates, the
bars in the display
appear one by one
when the temperature in the oven
increases, and disappear when it
decreases.
6.5 Heating functions
Oven function Application
Off position
The oven is off.
Light
To turn on the lamp.
www.aeg.com10
Oven function Application
Microwave
Creates the heat directly
in the food. Use it to heat
pre-prepared meals and
drinks, to defrost meat or
fruit, and to cook vegeta-
bles and fish.
True Fan
Cooking
To bake on up to two
shelf positions at the
same time and to dry
food.
Set the temperature 20 -
40 °C lower than for Con-
ventional Cooking.
Pizza Function
To bake pizza. To make
intensive browning and a
crispy bottom.
Conventional
Cooking
To bake and roast food
on one shelf position.
Bottom Heat
To bake cakes with crispy
bottom and to preserve
food.
Oven function Application
Defrost
To defrost food (vegeta-
bles and fruit). The de-
frosting time depends on
the amount and size of
the frozen food.
Grill
To grill thin pieces of
food and to toast bread.
Fast Grilling
To grill thin pieces of
food in large quantities
and to toast bread.
Turbo Grilling
To roast large meat joints
or poultry with bones on
one shelf position. To
make gratins and to
brown.
The lamp may turn off
automatically at a
temperature below 60 °C
during some oven functions.
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
Time of Day
To show or change the time of day. You can change the
time of day only when the oven is off.
Duration
To set the length of cooking. Use only when a heating
function is set.
End Time
To set the oven turn-off time. Use only when a heating
function is set.
Time Delay
Combination of functions: Duration, End Time.
Minute Minder
To set a countdown time. This function has no effect on
the operation of the oven.
Minute Minder - can be set at any time, also if the oven
is off.
ENGLISH 11
7.2 How to set: Time of day
After the first connection to the mains,
wait until the display shows: hr, 12:00.
12 - flashes.
Step 1 Turn the knob for the temperature to set the hour.
Step 2
- press to confirm.
The display shows the set hour and: min. 00 - flashes.
Step 3 Turn the knob for the temperature to set the minutes.
Step 4
- press to confirm.
The display shows the set time.
- press repeatedly to change the time of day. - flashes in the display.
7.3 How to set function:
Duration
Step 1 Set a heating function.
Step 2
- press repeatedly. - starts to flash.
Step 3
Turn the control knob to set the minutes. - press to confirm.
Step 4
Turn the knob for the temperature to set the hour. - press to confirm.
When the set time ends the signal sounds for 2 min. Time setting flashes in
the display. The oven turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knob for the heating functions to the off position.
7.4 How to set function: End
Time
Step 1 Set a heating function.
Step 2
- press repeatedly. - starts to flash.
Step 3
Turn the knob for the temperature to set the hour. - press to confirm.
Step 4
Turn the knob for the temperature to set the minutes. - press to confirm.
At the set end time the signal sounds for 2 min. The time setting flashes in the
display. The oven turns off automatically.
Step 5 Press any button to stop the signal.
Step 6 Turn the knob for the heating functions to the off position.
www.aeg.com12
7.5 How to set function: Time
Delay
Step 1 Set a heating function.
Step 2
- press repeatedly. - starts to flash.
Step 3 Turn the knob for the temperature to set the minutes for the function: Dura-
tion.
Press: .
Step 4 Turn the knob for the temperature to set the hour for the function: Duration.
Press: .
The display shows: .
Step 5 Turn the knob for the temperature to set the hour for the function: End Time.
Press: .
Step 6 Turn the knob for the temperature to set the minutes for the function: End
Time.
Press: .
The display shows: the set temperature, , .
Oven turns on automatically later on, works for the set Duration time and stops at the set
End Time.
At the set End Time the signal sounds for 2 min. The time setting flashes in the display.
The oven turns off.
Step 7 Press any button to stop the signal.
Step 8 Turn the knob for the heating functions to the off position.
7.6 How to set function:
Minute Minder
Minute minder can be both set when the
oven is turned on and off.
Step 1
- press repeatedly. , 00 - flash.
Step 2 Turn the control knob for the temperature to set the seconds and than the mi-
nutes.
When the time you set is longer than 60 min, hr flashes.
Step 3 Set the hours.
Minute Minder - starts automatically after 5 sec.
After 90% of the set time the signal sounds.
Step 4
When the set time ends the signal sounds for 2 min. 00:00, - flash. Press
any button to stop the signal.
ENGLISH 13
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Inserting accessories
Use only suitable cookware and material.
Refer to "Hints and tips" chapter,
Microwave suitable cookware and
materials.
A small indentation at the top increases
safety. The indentations are also anti-tip
devices. The high rim around the shelf
prevents cookware from slipping of the
shelf.
Wire shelf:
Push the shelf between the guide bars
of the shelf support and make sure that
the feet point down.
Baking tray:
Push the tray between the guide bars of
the shelf support.
Wire shelf, Baking tray:
Push the tray between the guide bars of
the shelf support and the wire shelf on
the guide bars above.
9. ADDITIONAL FUNCTIONS
9.1 Using Child lock
When the Child lock is on the oven
cannot be turned on accidentally.
1. Ensure the knob for the heating
functions is in the off position.
2. , - press and hold at the same
time for 2 seconds.
The signal sounds. SAFE - appears on
the display.
To turn off the Child Lock, repeat the
step 2.
www.aeg.com14
9.2 Using function lock
You can turn on the Function Lock
function only when the oven works.
When the Function lock is on the
temperature and time settings cannot be
changed accidentally.
1. Select an oven function and set it
according your preferences.
2. Press and hold and at the
same time for 2 seconds.
The signal sounds. Loc appears on the
display for 5 seconds.
Loc appears on the display
when you turn the knob for
the temperature or press any
button when the Function
lock is on.
When you turn the knob for the oven
functions, the oven stops.
When you turn off the oven while the
Function Lock is on, the Function Lock
switches automatically to the Child Lock.
Refer to "Additional functions" chapter,
Using the Child Lock.
To turn off the Function Lock, repeat step
2.
9.3 Residual heat indicator
When you turn off the oven, the display
shows the residual heat indicator
if
the temperature in the oven is more than
40 °C.Turn the knob for the temperature
left or right to check the oven
temperature.
9.4 Automatic switch-off
For safety reasons the oven turns off after
some time, if a heating function works
and you do not change any settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 230 5.5
After an automatic switch-off, turn the
knobs to the off position.
The Automatic switch-off does not work
with the functions: Light, Duration, End
Time.
9.5 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
10.
HINTS AND TIPS
WARNING!
Refer to Safety chapters.
10.1 Cooking recommendations
The temperature and cooking times in the tables are guidelines only. They depend on the
recipes and the quality and quantity of the ingredients used.
Your oven may bake or roast differently to the oven you had before. The tables below
show recommended settings for temperature, cooking time and shelf position for specific
types of the food.
If you cannot find the settings for a special recipe, look for the similar one.
ENGLISH 15
10.2 Microwave
recommendations
Let's cook!
Place the food on a plate on the bottom of the cavity.
Turn or stir the food halfway through the defrosting and cooking time.
Stir liquid dishes from time to time.
Stir the food before serving.
Cover the food for cooking and reheating.
Put the spoon to the bottle or glass when heating drinks to ensure better heat distribu-
tion.
Put the food into the oven without packaging. The packaged ready meals can be put into
the oven only when the packaging is microwave safe (check information on the packag-
ing).
Microwave cooking
Microwave defrosting
Cook food covered. If you want to keep a
crust cook food without a cover.
Do not overcook the dishes by setting the
power and time too high. The food can dry
out, burn or cause fire.
Do not use the oven to cook eggs or snails
in their shells, because they can burst.
Pierce the yolk of fried egg before reheating
it.
Pierce food with skin or peel several times
before cooking.
Cut vegetables into similar-sized pieces.
After you turn off the oven, take the food
out and let it stand for a few minutes.
Put the frozen, unwrapped food on a small
upturned plate with a container below it, or
on a defrosting rack or plastic sieve so that
the defrosting liquid can leak out.
Remove defrosted pieces subsequently.
To cook fruit and vegetables without de-
frosting them first, you can use a higher mi-
crowave power.
10.3 Microwave suitable
cookware and materials
For the microwave use only suitable
cookware and materials. Use below table
as a reference.
Check the cookware / material
specification before use.
Cookware / Material Microwave function Microwave Combi
function
Defrost-
ing
Heating,
Cooking
Ovenproof glass and porcelain with
no metal components, e.g. heat-
proof glass
www.aeg.com16
Cookware / Material Microwave function Microwave Combi
function
Defrost-
ing
Heating,
Cooking
Non-ovenproof glass and porcelain
without any silver, gold, platinum or
other metal decorations
X X
Glass and glass ceramic made of
ovenproof / frost-proof material
Ceramic and earthenware without any
quartz or metal components and gla-
zes which contain metal
X
Ceramic, porcelain and earthenware
with unglazed bottom or with small
holes, e.g. on handles
X X X
Heat-resistant plastic up to 200 °C X
Cardboard, paper X X
Clingfilm X X
Roasting film with microwave safe clo-
sure
X
Roasting dishes made of metal, e.g.
enamel, cast iron
X X
Baking tins, black lacquer or silicon-
coated
X X
Baking tray X X X
Wire shelf X X
Cookware for microwave use, e.g.
crisp pan
X X
10.4 Baking
For the first baking, use the lower
temperature.
You can extend the baking time by 10 –
15 minutes if you bake cakes on more
than one shelf position.
Cakes and pastries at different heights
do not always brown equally. There is no
need to change the temperature setting
if an unequal browning occurs. The
differences equalize during baking.
Trays in the oven can distort during
baking. When the trays are cold again,
the distortions disappear.
ENGLISH 17
10.5 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not baked sufficiently.
The shelf position is incor-
rect.
Put the cake on a lower shelf.
The cake sinks and be-
comes soggy or streaky.
The oven temperature is too
high.
Next time set slightly lower oven
temperature.
The oven temperature is too
high and the baking time is
too short.
Next time set a longer baking
time and lower oven temperature.
The cake is too dry. The oven temperature is too
low.
Next time set higher oven tem-
perature.
The baking time is too long. Next time set shorter baking time.
The cake bakes uneven-
ly.
The oven temperature is too
high and the baking time is
too short.
Next time set a longer baking
time and lower oven temperature.
The cake batter is not even-
ly distributed.
Next time spread the cake batter
evenly on the baking tray.
The cake is not ready in
the baking time speci-
fied in a recipe.
The oven temperature is too
low.
Next time set a slightly higher
oven temperature.
10.6 Baking on one oven level
Use the first shelf position.
Use the function: True Fan Cooking.
BAKING IN TINS
(°C) (min)
Flan base - short pastry, preheat the empty oven 170 - 180 10 - 25
Flan base - sponge cake mixture 150 - 170 20 - 25
Sponge cake 140 - 150 35 - 50
Ring cake / Brioche 150 - 160 50 - 70
Apple pie, 2 tins Ø20 cm 160 70 - 90
Madeira cake / Fruit cakes 140 - 160 70 - 90
Use the function: Conventional Cooking.
www.aeg.com
18
BAKING IN TINS
(°C) (min)
Sponge cake 160 35 - 50 2
Cheesecake, use a deep pan 160 - 170 60 - 90 1
Apple pie, 2 tins Ø20 cm 180 70 - 90 1
Use the first shelf position.
Use the function: True Fan Cooking.
Use the baking tray unless specified otherwise.
CAKES / PASTRIES
(°C) (min)
Cake with crumble topping 150 - 160 20 - 40
Fruit flans (made of yeast dough / sponge cake mix-
ture), use a deep pan
150 - 160 35 - 55
Fruit flans made of short pastry 160 - 170 40 - 80
Preheat the empty oven unless specified otherwise.
Use the function: Conventional Cooking.
Use the baking tray.
CAKES / PASTRIES / BREADS
(°C) (min)
Swiss roll 180 - 200 10 - 20 2
Rye bread first: 230 first: 20 2
then: 160 - 180 then: 30 - 60
Buttered almond cake / Sugar cakes 190 - 210 20 - 30 2
Cream puffs / Eclairs, preheating is not needed 190 - 210 20 - 35 2
Plaited bread / Bread crown, preheating is not
needed
170 - 190 30 - 40 2
Fruit flans (made of yeast dough / sponge cake
mixture)
170 35 - 55 1
Yeast cakes with delicate toppings (e.g. quark,
cream, custard)
160 - 180 40 - 80 2
Christstollen 160 - 180 50 - 70 2
Use the function: True Fan Cooking.
ENGLISH
19
BISCUITS
(°C) (min)
Short pastry biscuits 150 - 160 10 - 20 1
Biscuits made of sponge cake mixture 150 - 160 15 - 20 1
Puff pastries, preheat the empty oven 170 - 180 20 - 30 1
Short bread / Pastry strips 140 20 - 35 1
Small cakes, preheat the empty oven 160 20 - 35 3
Biscuits made of yeast dough 150 - 160 20 - 40 1
Macaroons 100 - 120 30 - 50 1
Pastries made of egg white / Meringues 80 - 100 120 - 150 1
Preheat the empty oven.
Use the second shelf position.
Use the function: Conventional Cooking.
BISCUITS
(°C) (min)
Rolls 190 - 210 10 - 25
Short bread / Pastry strips 160 20 - 30
Small cakes 170 20 - 35
10.7 Bakes and gratins
Use the first shelf position.
(°C) (min)
Baguettes topped with
melted cheese
True Fan Cooking 160 - 170 15 - 30
Vegetables au gratin,
preheat the empty
oven
Turbo Grilling 160 - 170 15 - 30
Lasagne Conventional Cooking 180 - 200 25 - 40
Fish bakes Conventional Cooking 180 - 200 30 - 60
Stuffed vegetables True Fan Cooking 160 - 170 30 - 60
www.aeg.com20
(°C) (min)
Sweet bakes Conventional Cooking 180 - 200 40 - 60
Pasta bake Conventional Cooking 180 - 200 45 - 60
10.8 Multilevel baking
Use the first / third shelf position.
Use the function: True Fan Cooking.
Use the baking trays.
CAKES / PAS-
TRIES / BREADS
(°C) (min)
Cream puffs /
Eclairs, preheat
the empty oven
160 - 180 25 - 45
Dry streusel cake 150 - 160 30 - 45
Short pastry bis-
cuits
150 - 160 20 - 40
Biscuits made of
sponge cake mix-
ture
160 - 170 25 - 40
Short bread /
Pastry strips
140 25 - 45
Biscuits made of
yeast dough
160 - 170 30 - 60
Macaroons 100 - 120 40 - 80
CAKES / PAS-
TRIES / BREADS
(°C) (min)
Pastries made of
egg white / Mer-
ingues
80 - 100 130 -
170
10.9 Tips on Roasting
Use heat-resistant ovenware.
Roast lean meat covered (you can use
aluminium foil).
Roast large meat joints directly in the tray
or on the wire shelf placed above the
tray.
Put some water in the tray to prevent
dripping fat from burning.
Turn the roast after 1/2 - 2/3 of the
cooking time.
Roast meat and
fish in large pieces (1 kg
or more).
Baste meat joints with their own juice
several times during roasting.
10.10 Roasting
Use the first shelf position.
Use the function: Conventional Cooking.
BEEF
(kg)
(W) (°C) (min)
Pot roast 1 - 1.5 200 230 60 - 80
Use the function: Turbo Grilling.
ENGLISH 21
PORK
(kg)
(W) (°C) (min)
Shoulder /
Neck / Ham
joint
1 - 1.5 200 160 - 180 50 - 70
Meatloaf 0.75 - 1 200 160 - 170 35 - 50
Pork knuckle,
precooked
0.75 - 1 200 150 - 170 60 - 75
Use the function: Turbo Grilling.
VEAL
(kg)
(W) (°C) (min)
Roast veal 1 200 160 - 180 50 - 70
Veal knuckle 1.5 - 2 200 160 - 180 75 - 100
Use the function: Turbo Grilling.
LAMB
(kg)
(W) (°C) (min)
Lamb leg /
Roast lamb
1 - 1.5 200 150 - 170 50 - 70
Use the function: Turbo Grilling.
POUL-
TRY
(kg)
(W) (°C) (min)
Poultry, por-
tions
0.2 - 0.25 each 200 200 - 220 20 - 35
Chicken, half 0.4 - 0.5 each 200 190 - 210 25 - 40
Chicken, pou-
lard
1 - 1.5 200 190 - 210 60 - 80
Duck 1.5 - 2 200 180 - 200 80 - 110
Use the function: Conventional Cooking.
www.aeg.com
22
FISH
(kg)
(W) (°C) (min)
Whole fish 1 - 1.5 200 210 - 220 30 - 45
Use the function: True Fan Cooking.
DISHES
(kg)
(W) (°C) (min)
Sweet dishes 200 160 - 180 20 - 35 1
Savoury dishes
with cooked ingre-
dients (noodles,
vegetables)
400 - 600 160 - 180 20 - 45 1
Savoury dishes
with raw ingredi-
ents (potatoes,
vegetables)
400 - 600 160 - 180 30 - 45 2
10.11 Crispy baking with:
Pizza Function
Preheat the empty oven before cooking.
Use the third shelf position.
PIZZA
(°C) (min)
Pizza, thin
crust
200 - 230 15 - 20
Pizza, thick
crust, use a
deep pan
180 - 200 20 - 30
Tarts 180 - 200 40 - 55
Spinach flan 160 - 180 45 - 60
Quiche lor-
raine / Swiss
flan
170 - 190 45 - 55
PIZZA
(°C) (min)
Cheesecake 140 - 160 60 - 90
Apple pie,
covered
150 - 170 50 - 60
Vegetable pie 160 - 180 50 - 60
Unleavened
bread
230 10 - 20
Puff pastry flan 160 - 180 45 - 55
Flammkuchen 230 12 - 20
Pierogi 180 - 200 15 - 25
10.12 Grill
Grill only thin pieces of meat or fish.
ENGLISH
23
Use the first shelf position.
GRILL
Preheat the empty
oven before cook-
ing.Use the function:
Grill. Put a pan on the
first shelf position to
collect fat.
(°C) (min) (min)
1st side 2nd side
Roast beef, medium 210 - 230 30 - 40 30 - 40
Beef fillet, medium 230 20 - 30 20 - 30
Pork loin 210 - 230 30 - 40 30 - 40
Veal loin 210 - 230 30 - 40 30 - 40
Lamb saddle 210 - 230 25 - 35 20 - 35
Whole fish, 0.5 kg - 1 kg 210 - 230 15 - 30 15 - 30
FAST GRILL
Use the function: Fast
Grilling. Always grill with
the maximum tempera-
ture setting.
(min) (min)
1st side 2nd side
Pork fillet 10 - 12 6 - 10 2
Sausages 10 - 12 6 - 8 3
Steaks 7 - 10 6 - 8 3
Toast with topping 6 - 8 - 2
10.13 Bread Baking
Preheating is not recommended.
Use the second shelf position.
BREAD
(°C) (min)
White bread 180 - 200 40 - 60
Baguette 200 - 220 35 - 45
Brioche 160 - 180 40 - 60
Ciabatta 200 - 220 35 - 45
BREAD
(°C) (min)
Rye bread 180 - 200 50 - 70
Wholemeal bread 180 - 200 50 - 70
Whole grain bread 170 - 190 60 - 90
10.14 Frozen Foods
Remove the food packaging. Put the
food on a plate.
www.aeg.com
24
Do not cover the food.
Use the third shelf position unless
specified otherwise.
Use the function: True Fan Cooking.
DEFROST-
ING (°C) (min)
Pizza, frozen 200 - 220 15 - 25
Pizza American, fro-
zen
190 - 210 20 - 25
Pizza, chilled 210 - 230 13 - 25
Pizza snacks, frozen 180 - 200 15 - 30
French fries, thin,
turn 2 or 3 times
during cooking
210 - 230 20 - 30
French fries, thick,
turn 2 or 3 times
during cooking
210 - 230 25 - 35
Wedges / Cro-
quettes, turn 2 or 3
times during cook-
ing
210 - 230 20 - 35
DEFROST-
ING (°C) (min)
Hash browns 210 - 230 20 - 30
Lasagne / Cannello-
ni, fresh, use the
second shelf posi-
tion
170 - 190 35 - 45
Lasagne / Cannello-
ni, frozen, use the
second shelf posi-
tion
160 - 180 40 - 60
Chicken wings 190 - 210 20 - 30
10.15 Defrost
Remove the food packaging and put the
food on a plate.
Do not cover the food, as this can extend
the defrost time.
For large portions of food place an
upturned empty plate on the bottom of
the oven cavity. Put the food in a deep
dish and set it on top of the plate inside
the oven. Remove the shelf supports if
necessary.
Use the
first shelf position.
(kg)
(min)
Defrosting time
(min)
Further defrost-
ing time
Chicken 1 100 - 140 20 - 30 Turn halfway
through.
Meat 1 100 - 140 20 - 30 Turn halfway
through.
Trout 0.15 25 - 35 10 - 15 -
Strawberries 0.3 30 - 40 10 - 20 -
Butter 0.25 30 - 40 10 - 15 -
ENGLISH 25
(kg)
(min)
Defrosting time
(min)
Further defrost-
ing time
Cream 2 x 0.2 80 - 100 10 - 15 Whip the cream
when still slightly
frozen in places.
Gateau 1.4 60 60 -
10.16 Preserving
Use the function Bottom Heat.
Use only preserve jars of the same
dimensions available on the market.
Do not use jars with twist-off and
bayonet type lids or metal tins.
Use the first shelf position.
Put no more than six one-litre preserve
jars on the baking tray.
Fill the jars equally and close with a
clamp.
The jars cannot touch each other.
Put approximately 1/2 litre of water into
the baking tray to give
sufficient moisture
in the oven.
When the liquid in the jars starts to
simmer (after approximately 35 - 60
minutes with one-litre jars), stop the oven
or decrease the temperature to 100 °C
(see the table).
Set the temperature to 160 - 170 °C.
SOFT FRUIT
(min)
Cooking time un-
til simmering
Strawberries / Blue-
berries / Raspber-
ries / Ripe gooseber-
ries
35 - 45
STONE
FRUIT (min)
Cooking
time until
simmering
(min)
Continue
to cook at
100 °C
Peaches /
Quinces /
Plums
35 - 45 10 - 15
VEG-
ETABLES (min)
Cooking
time until
simmering
(min)
Continue to
cook at
100 °C
Carrots 50 - 60 5 - 10
Cucumbers 50 - 60 -
Mixed pickles 50 - 60 5 - 10
Kohlrabi /
Peas / Aspar-
agus
50 - 60 15 - 20
10.17 Dehydrating - True Fan
Cooking
Use the third shelf position.
(°C) (h)
Beans 60 - 70 6 - 8
www.aeg.com26
(°C) (h)
Peppers 60 - 70 5 - 6
Vegetables
for soup
60 - 70 5 - 6
Mushrooms 50 - 60 6 - 8
Herbs 40 - 50 2 - 3
(°C) (h)
Plums 60 - 70 8 - 10
Apricots 60 - 70 8 - 10
Apple slices 60 - 70 6 - 8
Pears 60 - 70 6 - 9
10.18 Microwave cooking
Tips for Microwave
Cooking / Defrosting results Possible cause Remedy
The food is too dry. Power was too high.
Cooking time was too
long.
Set lower power or/and
shorter cooking time.
The food is not defrosted,
cold or underdone after cook-
ing time ends.
Cooking time was too
short.
Set longer cooking time. Do
not increase microwave
power.
The food is overheated at the
edges, but underdone in the
middle.
Microwave power was too
high.
Set lower power and longer
cooking time.
DEFROSTING
MEAT / FISH
Set power for 100 W unless specified
otherwise.
(kg)
(min) Standing
time (min)
Steak 0.2 5 - 7 5 - 10
Minced meat, set 200 W 0.5 7 - 8 5 - 10
Chicken 1 30 - 35 10 - 20
Chicken breast 0.15 5 - 9 10 - 15
Chicken legs 0.15 5 - 9 10 - 15
Whole fish 0.5 10 - 15 5 - 10
Fish fillet 0.5 12 - 15 5 - 10
ENGLISH 27
DAIRY PRODUCTS
Set power for 100 W.
(kg)
(min) Standing
time (min)
Butter 0.25 4 - 6 5 - 10
Grated cheese 0.2 2 - 4 10 - 15
CAKES AND BREAD
Set power for 200 W unless specified
otherwise.
(min) Standing
time (min)
Yeast cake 1 piece 2 - 3 15 - 20
Cheesecake, set 100 W 1 piece 2 - 4 15 - 20
Dry cake 1 piece 2 - 4 15 - 20
Bread 1 kg 15 - 18 5 - 10
Sliced bread 0.2 kg 3 - 5 5 - 10
Bread rolls 4 pieces 2 - 4 2 - 5
FRUIT
(kg)
(W) (min) Standing
time (min)
Fruit 0.25 100 5 - 10 10 - 15
REHEATING
(W) (min) Standing
time (min)
Baby food in jars 0.2 kg 300 1 - 2 -
Baby milk, put a spoon into the bottle 180 ml 600 0:20 - 0:40 -
Milk 200 ml 1000 1 - 1:30 -
Water 200 ml 1000 1:30 - 2 -
Sauce 200 ml 600 1 - 3 -
Soup 300 ml 600 3 - 5 -
Ready frozen meals 0.5 kg 400 10 - 15 2 - 5
Convenience food 0.5 kg 600 6 - 9 2 - 5
www.aeg.com28
MELTING
(kg)
(W) (min) Standing
time (min)
Chocolate / Chocolate icing 0.15 300 2 - 4 1 - 2
Butter 0.1 400 0:30 -
1:30
-
COOKING
(W) (min) Standing
time (min)
Whole fish 0.5 kg 500 8 - 10 2 - 5
Fish fillet 0.5 kg 400 4 - 7 2 - 5
Vegetables, fresh 0.5 kg + 50 ml of
water
600 5 - 15 -
Vegetables, frozen 0.5 kg + 50 ml of
water
600 10 - 20 -
Jacket potatoes 0.5 kg 600 7 - 10 -
Rice 0.2 kg + 400 ml
of water
600 15 - 18 -
Popcorn - 1000 1:30 - 3 -
Microwave Combi function
Set the function: Grill + MW.
(kg)
(W) (°C) (min) Standing
time (min)
Chicken, half, use
the second shelf
position
0.55 x
2
pieces
Round glass
dish, Ø 26 cm
300 220 40 5
Au gratin pota-
toes, use the sec-
ond shelf position
1 Round glass
dish
300 200 40 10
ENGLISH 29
(kg)
(W) (°C) (min) Standing
time (min)
Roast pork neck,
use the first shelf
position
1 Glass dish with
strainer
300 200 70 10
10.19 Recommended power settings for different kinds of food
The data in the table is for guidance only.
700 - 1000 W
Cooking vegetables
Searing at the start of the
cooking process
Heating liquids
500 - 600 W
Cooking egg dishes
Simmering stews
Heating one-plate
meals
Defrosting and heat-
ing frozen meals
300 - 400 W
Melting cheese,
chocolate, butter
Simmering rice
Heating baby
food
Cooking / Heat-
ing delicate food
Continuing
cooking
100 - 200 W
Defrosting bread
Defrosting fruit and
cakes
Defrosting cheese,
cream, butter
Defrosting meat, fish
www.aeg.com30
10.20 Information for test
institutes
Use the function: Fast Grilling / Grill
Use the third shelf position.
Preheat the empty oven.
Grill with the maximum temperature
setting.
GRILL-
ING
FUNC-
TION
(min)
1st side 2nd side
Burgers 9 - 13 8 - 10
Use the function: Fast Grilling / Grill
Use the third shelf position.
Preheat the empty oven.
Grill with the maximum temperature
setting.
GRILL-
ING
FUNC-
TION
(min)
1st side 2nd side
Toast 1 - 3 1 - 3
Tests according to IEC 60705.
Use wire shelf unless otherwise specified.
MICROWAVE
FUNCTION
(W)
(kg)
(min)
Sponge cake 600 0.475 Bottom 7 - 9 Turn container
around by 1/4,
halfway through
the cooking time.
Meatloaf 400 0.9 2 25 - 32 Turn container
around by 1/4,
halfway through
the cooking time.
Egg custard 500 1 Bottom 18 -
Meat defrosting 200 0.5 Bottom 7 - 8 Turn the meat up-
side down halfway
through the cook-
ing time.
ENGLISH 31
Use the wire shelf.
MICRO-
WAVE
COMBI
FUNC-
TION
(W) (°C) (min)
Cake, 0.7
kg
True Fan
Cooking +
MW
100 180 2 29 - 31 Turn container
around by 1/4,
halfway through
the cooking time.
Potato
gratin, 1.1
kg
Grill + MW 400 160 1 40 - 45 Turn container
around by 1/4,
halfway through
the cooking time.
Chicken,
1.1 kg
Grill + MW 400 230 1 45 - 55 Put the meat in
round glass con-
tainer and turn it
upside down after
20 minutes of the
cooking time.
11. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
11.1 Notes on cleaning
Cleaning
Agents
Clean the front of the oven with a soft cloth with warm water and a mild
detergent.
Use a cleaning solution to clean metal surfaces.
Clean stains with a mild detergent.
Everyday Use
Clean the cavity after each use. Fat accumulation or other residue may
cause fire.
Clean the oven ceiling carefully from residue and fat.
Do not store the food in the oven for longer than 20 minutes. Dry the cav-
ity with a soft cloth after each use.
www.aeg.com32
Accessories
Clean all accessories after each use and let them dry. Use a soft cloth with
warm water and a mild detergent. Do not clean the accessories in a dish-
washer.
Do not clean the non-stick accessories using abrasive cleaner or sharp-
edged objects.
11.2 How to remove: Shelf
supports
Remove the shelf supports to clean the
oven.
Step 1 Turn off the oven and wait until it is cold.
Step 2 Carefully pull the shelf sup-
ports up and out of the front
catch.
2
3
1
Step 3 Pull the front end of the shelf
support away from the side
wall.
Step 4 Pull the supports out of the
rear catch.
Install the shelf supports in the opposite sequence.
11.3 How to replace: Lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
Always hold the halogen lamp with a
cloth to prevent grease residue from
burning on the lamp.
Before you replace the lamp:
Step 1 Step 2 Step 3
Turn off the oven. Wait until
the oven is cold.
Disconnect the oven from
the mains.
Put a cloth on the bottom of
the cavity.
Top lamp
Step 1 Turn the glass cover to remove it.
Step 2 Clean the glass cover.
Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp.
Step 4 Install the glass cover.
ENGLISH 33
12. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
12.1 What to do if...
Problem Possible cause Remedy
You cannot activate or oper-
ate the oven.
The oven is not connected
to an electrical supply or it is
connected incorrectly.
Check if the oven is correctly
connected to the electrical
supply (refer to the connec-
tion diagram if available).
The oven does not heat up. The oven is deactivated. Activate the oven.
The oven does not heat up. The clock is not set. Set the clock.
The oven does not heat up. The necessary settings are
not set.
Make sure that the settings
are correct.
The oven does not heat up. The automatic switch-off is
activated.
Refer to "Automatic switch-
off".
The oven does not heat up. The Child Lock is on. Refer to "Using the Child
Lock".
The oven does not heat up. The fuse is blown. Make sure that the fuse is
the cause of the malfunction.
If the fuse is blown again
and again, contact a quali-
fied electrician.
The lamp does not operate. The lamp is defective. Replace the lamp.
Steam and condensation
settle on the food and in the
cavity of the oven.
You left the dish in the oven
for too long.
Do not leave the dishes in
the oven for longer than 15 -
20 minutes after the cooking
process ends.
The display shows an error
code that is not in this table.
There is an electrical fault. • Deactivate the oven with
the house fuse or the
safety switch in the fuse
box and activate it again.
• If the display shows the
error code again, contact
the Customer Care De-
partment.
12.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
The necessary data for the service centre
is on the rating plate. The rating plate is
on the front frame of the oven cavity. Do
not remove the rating plate from the
oven cavity.
www.aeg.com34
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
13. ENERGY EFFICIENCY
13.1 Energy saving
The oven has features which
help you save energy during
everyday cooking.
Make sure that the oven door is closed
when the oven operates. Do not open
the oven door too often during cooking.
Keep the door gasket clean and make
sure it is well fixed in its position.
Use metal cookware to improve energy
saving (only when you use a non-
microwave function).
When possible, do not preheat the oven
before cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes
at one time.
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
Residual heat
If a programme with the Duration or End
Time selection is activated and the
cooking time is longer than 30 min, the
heating elements automatically turn off
earlier in some oven functions.
The fan and lamp continue to operate.
When you turn off the oven, the display
shows the residual heat. You can use that
heat to keep the food warm.
When the cooking duration is longer
than 30 min, reduce the oven
temperature to minimum 3 - 10 min
before the end of cooking. The residual
heat inside the oven will continue to
cook.
Use the residual heat to warm up other
dishes.
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm. The residual heat indicator or
temperature appears on the display.
14. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH
35
www.aeg.com/shop
867344321-C-142020
