User Manual Yamaha PSR-E263 Portable Keyboard

• Owner's manual - (English)

Owner’s Manual DIGITAL KEYBOARD Yamaha PSR-E263

Contents

• Setting Up
• Panel Controls and Terminals
• Setting Up
• Display Items and Basic Operations
• Reference
• Playing a Variety of Instrument Voices
• Playing Styles
• Playing the keyboard with two persons (Duo mode)
• Playing Songs
• Hearing and Experiencing the Sound of the
• Chords (Chord Study)
• Using the Song Lesson Feature
• Playing an External Audio Device with the
• Built-in Speakers
• Recording Your Performance
• Phrase Recording)
• Selecting an EQ Setting for the Best Sound
• The Functions
• Backup and Initialization
• Appendix

Hear and experience a sound of a single chord

1. Select a Song from Song numbers 101 to 107 in the “CHORD STUDY” category by executing Step 1 in “Selecting and Playing Back a Song” on page 23.
2. Press the [START/STOP] button to play back the selected Song.
3. Play the keyboard while looking at the notes shown on the display.

Hear and experience basic chord progressions

1. Select a Song from Song numbers 108 to 112 by pressing the [+]/[-] buttons.
2. Press the [START/STOP] button to play back the selected Song.
3. Play the keyboard while looking at the notes shown on the display.

Playing an External Audio Device with the Built-in Speakers

1. Turn off the power for both the external audio device and this instrument.
2. Connect the audio device to the instrument’s [AUX IN] jack.
3. Turn on the external audio device, then this instrument.
4. Play back the connected external audio device.
5. Adjust the volume balance between the external audio device and this instrument
6. After finishing the performance, stop playback of the audio device.

Recording Your Performance (Phrase Recording)

1. Select the desired Voice.
2. Press the [PHRASE REC] button to enable the Record mode.
3. Play the keyboard to start recording
4. Press the [START/STOP] button to stop recording.
5. To play back the recorded Song, press the [START/STOP] button.

Selecting an EQ Setting for the Best Sound

1. Hold down the [ULTRA-WIDE STEREO] button for longer than a second to call up “013 MasterEQ” (Function 013; page 32).
2. Use the [+] or [-] button to select the desired Master EQ type.

Troubleshooting

When the instrument is turned on or off, a popping sound is temporarily produced.

• This is normal and indicates that the instrument is receiving electrical power.

When using a mobile phone, noise is produced.

• Using a mobile phone in close proximity to the instrument may produce interference. To prevent this, turn off the mobile phone or use it further away from the instrument.

The Style does not sound as you play a chord

• The auto accompaniment will sometimes not change when related chords are played in sequence (e.g., some minor chords followed by the minor seventh).
• Two-note fingerings will produce a chord based on the previously played chord.
• Playing two same root keys in the adjacent octaves produces accompaniment based only on the root.
