PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
2
FCC INFORMATION (U.S.A.)
1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC, to
use the product.
2. IMPORTANT: When connecting this product to
accessories and/or another product use only high
quality shielded cables. Cable/s supplied with this
product MUST be used. Follow all installation
instructions. Failure to follow instructions could void
your FCC authorization to use this product in the USA.
3. NOTE: This product has been tested and found to
comply with the requirements listed in FCC Regulations,
Part 15 for Class “B” digital devices. Compliance with
these requirements provides a reasonable level of
assurance that your use of this product in a residential
environment will not result in harmful interference with
other electronic devices. This equipment generates/
uses radio frequencies and, if not installed and used
according to the instructions found in the users manual,
may cause interference harmful to the operation of
other electronic devices. Compliance with FCC
regulations does not guarantee that interference will
not occur in all installations. If this product is found to
be the source of interference, which can be determined
by turning the unit “OFF” and “ON”, please try to
eliminate the problem by using one of the following
measures:
- Relocate either this product or the device that is
being affected by the interference.
- Utilize power outlets that are on different branch
(circuit breaker or fuse) circuits or install AC line
filter/s.
- In the case of radio or TV interference, relocate/
reorient the antenna. If the antenna lead-in is 300
ohm ribbon lead, change the lead-in to co-axial type
cable.
If these corrective measures do not produce
satisfactory results, please contact the local retailer
authorized to distribute this type of product. If you
cannot locate the appropriate retailer, please contact
Yamaha Corporation of America, 6600 Orangethorpe
Avenue, Buena Park, CA 90620, U.S.A.
The above statements apply ONLY to those products
distributed by Yamaha Corporation of America or its
subsidiaries.
(529-M04 FCC class B YCA 02)
COMPLIANCE INFORMATION STATEMENT
(Supplierʼs declaration of conformity procedure)
Responsible Party: Yamaha Corporation of America
Address: 6600 Orangethorpe Avenue, Buena Park, CA. 90620, U.S.A.
Telephone: 714-522-9011
Type of Equipment: Digital Keyboard
Model Name: PSR-E383, YPT-380, PSR-EW320, YPT-W320
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that
may cause undesired operation.
(529-M02 FCC sdoc YCA 02)
The model number, serial number, power
requirements, etc., may be found on or near
the name plate, which is at the bottom of the
unit. You should note this serial number in the
space provided below and retain this manual
as a permanent record of your purchase to aid
identification in the event of theft.
Model No.
Serial No.
(1003-M06 plate bottom en 01)
3
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Information for users on collection and disposal of old equipment and used batteries:
These symbols on the products, packaging, and/or accompanying documents mean that used electrical
and electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to
applicable collection points, in accordance with your national legislation.
By disposing of these products and batteries correctly, you will help to save valuable resources and
prevent any potential negative effects on human health and the environment which could otherwise
arise from inappropriate waste handling.
For more information about collection and recycling of old products and batteries, please contact your
local municipality, your waste disposal service or the point of sale where you purchased the items.
For business users in the European Union:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for
further information.
Information on Disposal in other Countries outside the European Union:
These symbols are only valid in the European Union. If you wish to discard these items, please contact
your local authorities or dealer and ask for the correct method of disposal.
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the EU Battery Directive for the chemical involved.
(58-M03 WEEE battery en 01)
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
4
For the AC adaptor
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Explanation of Graphical Symbols
The lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the product.
IMPORTANT SAFETY INSTRUCTIONS
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9 Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by
the manufacturer..
12 Use only with the cart, stand,
tripod, bracket, or table
specified by the manufacturer,
or sold with the apparatus.
When a cart is used, use caution
when moving the cart/
apparatus combination to avoid
injury from tip-over.
13 Unplug this apparatus during lightning storms or
when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
(502-M01 UL 60065-1 en 01)
5
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
DMI-11 1/3
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Especially in the case of children, a guardian should provide guidance on
how to properly use and handle the product before actual use.
Please keep this manual in a safe and handy place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury
or even death from electrical shock, short-circuiting, damages, fire or other hazards. These
precautions include, but are not limited to, the following:
Power supply
• Do not place the power cord near heat sources such as
heaters or radiators. Also, do not excessively bend or
otherwise damage the cord, or place heavy objects on it.
• Do not touch the product or the power plug during an
electrical storm.
•
Use only the correct voltage specified for the product. The
required voltage is printed on the name plate of the product.
•
Use only the supplied or the specified AC adaptor (page
30)/plug. Do not use the AC adaptor/plug for other devices.
• Check the power plug periodically and remove any dirt or
dust which may have accumulated on it.
• Insert the power plug firmly all the way into the AC outlet.
Using the product when it is not plugged in sufficiently can
cause dust to accumulate on the plug, possibly resulting in
fire or skin burns.
• When setting up the product, make sure that the AC
outlet you are using is easily accessible. If some trouble or
malfunction occurs, immediately turn off the power switch
and disconnect the plug from the outlet. Even when the
power switch is turned off, as long as the power cord is not
unplugged from the wall AC outlet, the product will not be
disconnected from the power source.
• Do not connect the product to an electrical outlet using a
multi-plug outlet extender. Doing so can result in lower
sound quality, or possibly cause overheating in the outlet.
• When disconnecting the power plug, always hold the plug
itself and not the cord. Pulling by the cord can damage it
and cause electric shocks or a fire.
• If not using the product for long periods of time, be sure to
pull the power plug from the AC outlet.
Do not disassemble
• This product contains no user-serviceable parts. Do not
attempt to disassemble the internal parts or modify them in
any way.
Water warning
• Do not expose the product to rain, use it near water or in
damp or wet conditions, or place on it any containers (such
as vases, bottles or glasses) containing liquids which might
spill into any openings or places where water may drop. A
liquid such as water getting into the product may cause a
fire, electric shocks, or malfunctions.
• Use the AC adaptor indoors only. Do not use in any wet
environments.
• Never insert or remove a power plug with wet hands.
Fire warning
• Do not place any burning items or open flames near the
product, since they may cause a fire.
Batteries
• Do not dispose of a battery in a fire.
• Do not expose the battery to conditions of extreme low air
pressure, cold or heat (such as in direct sunlight or a fire) or
excessive dust or humidity.
Doing so may result in the battery exploding, causing a fire
or injury.
• Follow the precautions below. Failure to do so might result
in overheating, fire, explosion, or battery fluid leakage. If
the contents of the battery gets on your hands or in your
eyes, it can cause blindness, chemical burns, and damage
of the product.
– Use the specified battery type (page 30) only.
– Do not use new batteries together with old ones.
– Do not mix battery types.
– Always make sure all batteries are inserted in conformity
with the +/– polarity markings.
– Do not disassemble a battery.
– When the batteries run out, or if the product is not to be
used for a long time, remove the batteries from the product.
– Do not attempt to recharge batteries that are not
designed to be charged.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
6
DMI-11 2/3
• If the batteries do leak, avoid contact with the leaked fluid.
If the battery fluid should come in contact with your eyes,
mouth, or skin, wash immediately with water and consult
a doctor. Battery fluid is corrosive and may possibly cause
loss of sight or chemical burns.
• When using rechargeable batteries, follow the instructions
that came with the batteries. Use only the specified charger
device and within the specified charging temperature range
when charging.
Charging with an unspecified charger or at a temperature
outside the range may cause leakage, overheating,
explosion, or malfunction.
• For battery installation and removal, be sure to read this
manual and follow the instructions. Failure to comply may
result in fire, overheating, explosion or malfunction.
• Keep batteries away from children. A child could
accidentally swallow a battery. Failure to observe this may
also cause inflammation due to battery fluid leaks.
• Do not subject batteries to mechanical shock.
Doing so may cause damage caused by batteries, electric
shock, explosion or malfunction.
• Do not intentionally short the battery. Explosion or liquid
leakage may cause fire or injury.
• Do not put batteries in a pocket or bag, or carry or store
them together with pieces of metal. Batteries kept in such
condition could short, burst, or leak, causing a fire or injury.
If you notice any abnormality
• If any of the following problems occur, immediately turn off
the power switch and disconnect the power plug from the
outlet. If you are using batteries, remove all batteries from
the product.
Finally have the device inspected by Yamaha service
personnel.
– The power cord or plug becomes frayed or damaged.
– Unusual smells or smoke are emitted.
– Some object, or water has been dropped into the product.
– There is a sudden loss of sound during use of the product.
– Cracks or other visible damage appear on the product.
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to
you or others, or damage to the product or other property. These precautions include, but
are not limited to, the following:
Location
• Do not place the product in an unstable position or
a location with excessive vibration, where it might
accidentally fall over and cause injury.
• Before moving the product, remove all connected cables,
to prevent damage to the cables or injury to anyone who
might trip over them.
• Use only the stand specified for the product. When
attaching it, use the provided screws only. Failure to do so
could cause damage to the internal components or result in
the product falling over.
Connections
• Before connecting the product to other devices, turn off the
power for all devices. Before turning the power on or off for
all devices, set all volume levels to minimum.
• Be sure to set the volumes of all devices at their minimum
levels and gradually raise the volume controls while playing
the product to set the desired listening level.
Handling
• Do not insert foreign materials such as metal or paper into
any openings or gaps of the product. Failure to observe this
may cause a fire, electric shocks, or malfunctions.
• Do not rest your weight on, or place heavy objects on the
product, and do not use excessive force on the buttons,
switches or connectors.
• Do not use the product or headphones for a long period
of time at a high or uncomfortable volume level, since this
can cause permanent hearing loss. If you experience any
hearing loss or ringing in the ears, consult a physician.
• Remove the power plug from the AC outlet before cleaning
the unit. Failure to observe this may cause electric shocks.
7
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
DMI-11
3/3
Yamaha cannot be held responsible for damage caused by improper use or modifications to the product, or data that is lost or
destroyed.
Always turn the power off when the product is not in use.
Even when the [ ] (Standby/On) switch is in standby status (display is off), electricity is still flowing to the product at the minimum level.
When you are not using the product for a long time, make sure you unplug the power cord from the wall AC outlet.
NOTICE
To avoid the possibility of malfunction/ damage
to the product, damage to data, or damage to
other property, follow the notices below.
■
Handling
• Do not use this product in the vicinity of a TV, radio, stereo
equipment, mobile phone, or other electric devices.
Otherwise, this product or the other device may generate
noise.
• When you use the product along with an app on your smart
device, such as a smartphone or tablet, we recommend that
you enable “Airplane Mode” on the device to avoid noise
caused by communication.
• Depending on the condition of surrounding radio waves,
the product may possibly malfunction.
• Do not expose the product to excessive dust or vibrations,
or extreme cold or heat (such as in direct sunlight, near a
heater, or in a car during the day) to prevent the possibility
of disfiguration, damage to the internal components or
unstable operation. (Verified operating temperature range:
5° – 40°C, or 41° – 104°F.)
• Do not place vinyl, plastic or rubber objects on the product,
since this might discolor the product.
• Do not press the LCD screen with your finger because it
is a sensitive, precision-made part. Doing so might cause
an appearance abnormality, such as a stripe on the LCD,
although this abnormality should disappear again within a
short time.
■
Maintenance
• When cleaning the product, use a soft and dry (or slightly
damp) cloth. Do not use paint thinners, solvents, alcohol,
cleaning fluids, or chemical-impregnated wiping cloths.
■
Saving data
• Some of the data of this product (page 28) are retained
when the power is turned off. However, the saved data may
be lost due to some failure, an operational mistake, etc.
Save your important data onto an external device such as a
computer (page 15).
Information
■
About copyrights
•
The copyright of the “content”*
1
installed in this product
belongs to Yamaha Corporation or its copyright holder. Except
as permitted by copyright laws and other relevant laws, such
as copying for personal use, it is prohibited to “reproduce
or divert”*
2
without the permission of the copyright holder.
When using the content, consult with a copyright expert.
If you create music or perform with the contents through the
original use of the pr
oduct, and then recor
d and distribute
them, the permission of Yamaha Corporation is not required
regardless of whether the distribution method is paid or free
of charge.
*1:
The word “content” includes a computer program, audio
data, Accompaniment Style data, MIDI data, waveform
data, voice recording data, music score, and score data, etc.
*2: The phrase “reproduce or divert” includes taking out the
content itself in this product, or recording and distributing
it without changes in a similar manner.
■
About functions/data bundled with the
product
•
Some of the preset Songs have been edited for length or
arrangement, and may not be exactly the same as the original.
■
About the appearance of this product
• This product may appear to have lines or scratches on the
surface.The apparent lines or scratches are called “weld
lines.” They occur during the process of modeling the case
and do not affect the functionality of the product.
■
About this manual
• The illustrations and LCD screens as shown in this manual
are for instructional purposes only.
•
Unless indicated otherwise, the illustrations and displays as
shown in this manual are based on the PSR-E383 (in English).
• “QR Code” is a registered trademark of DENSO WAVE
INCORPORATED.
• The company names and product names in this manual are
the trademarks or registered trademarks of their respective
companies.
■
About disposal
• When disposing of this product, please contact the
appropriate local authorities.
• Make sure to discard used batteries according to local
regulations.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
8
Contents
Thank you for purchasing this Yamaha Digital Keyboard!
It is loaded with various sounds and preset Songs, so that even beginners can enjoy playing it right
away.
We recommend that you read this manual carefully so that you can fully take advantage of the
advanced and convenient functions of the instrument.
We also recommend that you keep this manual in a safe and handy place for future reference.
About the Manuals ...............................................9
Included Accessories ............................................9
Setting Up 10
Power Requirements ......................................... 10
Turning the Power On/Off ................................ 11
Auto Power Off function ................................... 11
Using the Music Rest ......................................... 11
Panel Controls and Terminals 12
Basic Operations 16
Selecting a Voice/Song/Style ........................... 16
Changing the Tempo ......................................... 16
Playing a Variety of Instrument Voices 17
Selecting a Main Voice ....................................... 17
Calling up the Grand Piano Voice .................... 17
Layering another Voice over the entire
keyboard (Dual) ......................................... 17
Playing Different Voices with Your Left and
Right Hands (Split) .................................... 18
Playing the Keyboard with Two People (Duo) 18
Playing with Rhythm and Auto
Accompaniment (Styles) 19
Specify the Chords Automatically
(Auto Chord Play) ...................................... 19
Play while Specifying the Chords ..................... 20
Playing Back Songs and Using Song
Lessons 21
Listening to the Demo Songs ........................... 21
Listening to the Preset Songs .......................... 21
Practicing the Timing and Touch of Playing the
Keyboard (Rhythm & Touch Tutor) ......... 21
Practice Playing Keyboard using Song Lesson
Features ..................................................... 22
Recording Your Performance 23
Memorizing Your Favorite Settings
(Registration Memory) 23
Recalling the Panel Settings ............................. 23
Memorizing Your Favorite Panel Settings ...... 23
The Functions 24
About the Function Settings ............................. 24
Backup and Initialization 28
Backup Parameter ............................................. 28
Initializing the Instrument ................................ 28
Troubleshooting 28
Specifications 29
Index 31
9
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
About the Manuals
The following manuals are provided for the instrument.
Supplied with the instrument
Owner’s Manual (this book)
Explains the basic operations of the instrument.
General contents of the notes
WARNING
Important information to avoid the possibility of serious injury or even death from electrical shock,
short-circuiting, damages, fire or other hazards.
CAUTION
Important information to avoid the possibility of physical injury to you or others, or damage to the
instrument or other property.
NOTICE
Important information to avoid the possibility of malfunction or damage to the product, damage to
data, or damage to other property.
NOTE
Helpful information and tips.
Available on the website
Reference Manual
Explains all functions of this instrument including advanced functions.
Data List
Contains various important preset content lists such as Voices, Songs, Styles, etc., as well as MIDI-related
information of this instrument.
Smart Device Connection Manual
Explains how to connect the instrument to a smart device such as smartphone or tablet, etc.
To obtain the above manuals or the Song Book (see below), access the following Yamaha
website:
https://manual.yamaha.com/mi/kb-ekb/psr-e383/downloads/
SONG BOOK
This contains music scores for the preset Songs (excluding the Demo Songs) of
this instrument.
Use this free downloadable songbook when playing this instrument.
Video Manuals
Video manuals explaining how to use this instrument are available.
Scan the QR code to the left or access the website below.
https://manual.yamaha.com/mi/kb-ekb/psr-e383/videos/
Included Accessories
• Owner’s Manual (this book) ×1
• Music rest ×1
• AC adaptor* ×1
• Online Member Product Registration ×1
* May not be included depending on your area. Check with your Yamaha dealer.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
10
Setting Up
Power Requirements
Although the instrument will run either from an AC
adaptor or batteries, Yamaha recommends the use
of an AC adaptor whenever possible.
Using an AC Adaptor
Connect the AC adaptor in the order shown in the
illustration.
DC IN jack
(page 15)
1
2
AC outlet
AC adaptor
WARNING
• Use only the supplied or the specified AC adaptor
(page30).
• When using an AC adaptor with a removable plug,
make sure to keep the plug attached to the AC
adaptor during use and storage. Inserting just the
plug into an outlet can cause electric shock or fire.
• Never touch the inner metallic section of the plug to
avoid electric shock, short circuit, or damage. If the
plug comes off, push it in until it securely clicks in
place. Also be careful that there is no dust or other
foreign matter between the AC adaptor and plug.
Plug
• Place the plug against the
far side, and then firmly
push it in until it clicks.
• The shape of the plug
differs depending on your
area.
When using the AC adaptor with a removable plug
• When setting up the instrument, make sure that the
AC outlet you are using is easily accessible. If trouble
or a malfunction occurs, immediately turn the power
off and disconnect the plug from the outlet.
NOTE
• When disconnecting the AC adaptor, turn off the power
of the instrument and follow the order shown above in
reverse.
Using Batteries
This instrument can use AA size alkaline,
manganese dry cell, or rechargeable nickel
metal hydride batteries (rechargeable batteries).
However, the use of alkaline or rechargeable
batteries is recommended, as the instrument may
consume large amounts of power depending on
use.
WARNING
• Before installing batteries, make sure to refer to
the “Batteries” section in the Precautions (pages
5–6).
1 Make sure that the power of the instrument is
off.
2 Open the battery compartment cover located
on the instrument’s bottom panel.
3 Insert the six new batteries, being careful to
follow the polarity markings on the inside of
the compartment.
4 Replace the compartment cover, making sure
that it locks firmly in place.
5 After turning the power of the instrument on,
make sure to set the battery type correctly
(page 11).
11
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Setting Up
NOTICE
• Connecting or disconnecting the power adaptor with
batteries inserted may turn the power off, resulting in
loss of data being recorded at the time.
• When battery power becomes too low for proper
operation, the volume may be reduced, the sound may
be distorted, and other problems may occur. When
this happens, make sure to replace all batteries with
new ones or already recharged ones.
NOTE
• This instrument cannot charge the batteries. Use only the
specified charger device when charging.
• Even if batteries are inserted into the instrument, the AC
adaptor will be used as the power source when the AC
adaptor is connected.
Setting the battery type
You need to change the battery type setting on
this instrument, depending on the battery type to
be used.
To change the setting, after turning the power
on, set the battery type via Function number 063
(page 24).
Default setting: Alkaline
Alkaline Alkaline batteries, manganese dry
batteries
Ni-MH Rechargeable nickel metal hydride
batteries (rechargeable batteries)
NOTICE
• Failure to set the battery type may shorten the
amount of the battery life. Make sure to set the
battery type correctly.
Turning the Power On/Off
1 Turn down the [MASTER VOLUME] dial to
“MIN”.
2 Press the [ ] (Standby/On) switch to turn the
power on.
The display will light up.
3 Adjust the volume as desired while playing the
keyboard.
4 Press and hold the [ ] (Standby/On) switch for
about a second to turn the power off.
WARNING
• Even when the power is turned off, electricity is still
flowing to the instrument in a small amount. Remove
the electric plug from the outlet when the instrument
is not to be used for extended periods of time or
during electrical storms.
NOTICE
• Press only the [ ] (Standby/On) switch when turning
the power on. Any other operations such as pressing
keyboards/buttons or stepping on the footswitch may
cause the instrument to malfunction.
Auto Power Off function
The instrument will automatically turn off after 15
minutes of inactivity. However, you can change this
setting on the Function setting display (page 24,
Function number 062).
Easy deactivation of the Auto Power Off
function
Turn the power on while holding down the
lowest key on the keyboard. The message
“AutoOff Disabled” will appear briefly, and then the
instrument will start up with the Auto Power Off
function disabled.
Using the Music Rest
Insert the music rest into the slots as shown.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
12
Panel Controls and Terminals
Front Panel
!9
!7
!8
w
q
r
u i o !0 !1
@0
@1
@2
@3
yt
e
!5
!6
!4
!2 !3
1 2
4
5
6 7 8
9
0
3
1 2
4
5
6 7 8
9
0
3
About the alternate button names enclosed in the frame ( !5 and @3)
If you operate one of the buttons while holding down , the function indicated in the frame below the
button will be executed. For example, holding down
!5 and pressing [METRONOME] t calls up the Time
Signature setting display.
Display
Page 14
q [MASTER VOLUME] dial .........................page 11
Adjusts the overall volume.
w [ ] (Standby/On) switch ....................... page 11
Switches between standby and power on.
e [ARTICULATION] button .......................page 17
Recreates the characteristic performance
techniques for specific instruments.
r [REC] button ...........................................page 23
Records your performance.
Clears a User Song.
t [METRONOME] button ...............................
Starts/stops the metronome.
Lets you set the time signature of the
metronome on the setting display.
y [TEMPO/TAP] button .............................page 16
Lets you set the tempo of the Song/Style/
metronome.
Lets you determine the point for dividing the
keyboard into left and right areas (Split Point)
when using Duo and Style.
u [DSP] button ................................................
Switches the DSP (digital signal processor) on
or off.
Lets you select the type of DSP.
i [HARMONY/ARPEGGIO] button ................
Adds effects such as harmony, etc. or enables
the Arpeggio function.
Lets you select the HARMONY/ARPEGGIO type.
o [DUAL] button ........................................page 17
Layers another Voice over the entire keyboard
as a Dual Voice.
Lets you select the Voice for layering.
!0 [SPLIT] button ........................................page 18
Divides the keyboard into two separate areas,
allowing you to play different Voices in the Left-
hand and Right-hand areas.
Lets you select the Voice for playing in the area
lower than the Split point.
: Refer to the Reference Manual on the website (page 9).
13
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Panel Controls and Terminals
Front Panel
!9
!7
!8
w
q
r
u i o !0 !1
@0
@1
@2
@3
yt
e
!5
!6
!4
!2 !3
1 2
4
5
6 7 8
9
0
3
1 2
4
5
6 7 8
9
0
3
About the alternate button names enclosed in the frame ( !5 and @3)
If you operate one of the buttons while holding down , the function indicated in the frame below the
button will be executed. For example, holding down
!5 and pressing [METRONOME] t calls up the Time
Signature setting display.
Display
Page 14
!1 [DUO] button .........................................page 18
Lets two players play the instrument
simultaneously over the same octave range
with the same Voice.
Lets you select the Voice for the left player area.
In the Song mode
!2 [KEYS TO SUCCESS], [3-STEP LESSON] buttons
.................................................................page 22
Turns on/off the “Keys To Success” lesson for
practicing a Song or starts/stops the “3-Step
Lesson” or select the lesson mode.
!3 PART [L/2], [R/1] buttons ...........................
Lets you select a lesson part or a muted part of
the current Song.
!4 Song control buttons ............................ page 21
For controlling Song playback.
In the Style mode
!2 AUTO CHORD PLAY [ON/OFF], [SELECT]
buttons ................................................... page 19
Turns on/off the Auto Chord Play function or
lets you select chord progressions when using
the function.
!3
[FINGERING TYPE], [STYLE KEY] buttons ....
Lets you set how to play chords.
!4 Style control buttons .................... pages 19, 20
For controlling Style playback.
!5 button................................ pages 16, 24
For the main use of this button, see the
explanation in the box at the top of page 12.
This button also can be used for returning
operation to the home display (page 16).
!6 [SONG]/[STYLE] button ........... pages 16, 19, 21
Switches between Style mode and Song mode.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
14
Panel Controls and Terminals
!7 VOICE Category buttons .............. pages 16, 17
Lets you select the desired Voice.
Pressing [FUNCTION] @1 while holding down
[SHIFT] @3 allows you to enter Voice numbers or
set values, etc. with these buttons.
(One Touch Setting)
Automatically selects the most suitable Voice
when you select a Style or Song (excepting
Songs that have been input from other
devices).
!8 SONG/STYLE Category buttons
................................................... pages 16, 19, 21
Lets you select the desired Song/Style.
Pressing [FUNCTION] @1 while holding down
[SHIFT] @3 enables you to use these buttons
as numeric buttons, in the same way as Voice
Category buttons !7.
Lets you call up panel settings such as Voice
and Style by selecting the music genre.
!9 [+]/[-] buttons, [+/YES]/[-/NO] buttons
......................................................... pages 16, 24
Select items or Increase/Decrease values.
Pressing the two buttons simultaneously resets
the value to the default.
Executes operations.
@0 [PORTABLE GRAND] button .................. page 17
Automatically selects Voice Number 001
“Live! Concert Grand Piano” for the Voice.
(page 21)
Starts/stops continuous DEMO Song playback.
@1 [FUNCTION] button ...............................page 24
Calls up the Function setting display.
Lets you use the !7 or !8 buttons as Number
buttons.
@2 [REGIST MEMORY] button ....................page 23
Lets you recall the panel setting you
memorized.
Lets you memorize the panel setting.
@3 button (same as the button !5)
For the main use of this button, see the
explanation in the box at the top of page 12.
This button also can be used for returning
operation to the home display (page 16).
Front Panel
!7
!8
@0
@1
@2
@3
!9
1 2
4
5
6 7 8
9
0
3
1 2
4
5
6 7 8
9
0
3
Display
: Refer to the Reference Manual on the website (page 9).
15
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Panel Controls and Terminals
Rear Panel
The cable to be used depends on the device to be connected.
Connection Options
Standard stereo
phone plug
(6.3 mm)
Stereo-mini
plug
(3.5 mm)
Adaptor plug
(3.5 mm => 6.3 mm)
Stereo-mini plug
(3.5 mm)
Headphones
Powered speaker
Power outlet
AC
adaptor
Audio Device
(Smartphone, etc.)
Computer Smart device
+ USB conversion adaptor, etc.
Footswitch
@4 [SUSTAIN] jack ............................................
You can connect a separately sold footswitch.
The footswitch can be used as a sustain pedal.
@5 [USB TO HOST] terminal ............................
For connecting to the computer or smart device
such as a tablet or smartphone via a USB cable.
You can transfer MIDI files or send/receive
audio data between this instrument and
a computer, or playback the commercially
available Song data transferred from computer
on this instrument. In addition, using the smart
device apps enables you to use the various
function.
NOTICE
• Use an AB type USB cable of less than 3 meters.
USB 3.0 cables cannot be used.
@6 [AUX IN] jack ...............................................
For connecting an audio device such as a
smartphone.
You can output the sound of the audio device
through the instrument’s speakers and play the
keyboard along with the playback of the device.
@7 [PHONES/OUTPUT] jack .............................
For connecting a pair of headphones or an
external speaker such as a powered speaker,
computer, or keyboard amplifier. The speakers
of this instrument are automatically shut off
when a plug is inserted into this jack.
@8 DC IN jack...............................................page 10
For connecting the AC adaptor.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
16
Basic Operations
Selecting a Voice/Song/Style
Voice/Song/Style can be selected using each of the category buttons (page 14).
Voice: Select using the upper VOICE category buttons.
Song or Style: Use [SONG]/[STYLE] to switch to the mode you want to use, then select using the lower
SONG/STYLE category buttons.
Each time these category buttons are pressed, the Voice/Song/Style changes sequentially within the same
category.
1 2
4
5
6 7 8
9
0
3
1 2
4
5
6 7 8
9
0
3
For Voice selection
For Song/Style selection
Upper button names: Song category
Lower button names: Style category
Switches between
and .
Voice can be selected by pressing [+]/[-],
and Song/Style can be selected by pressing
[+/YES]/[-/NO].
Display Items
Song or Style name
Voice name
The active mode name is displayed.
Changing the Tempo
1 2
4
5
6 7 8
9
0
3
1 2
4
5
6 7 8
9
0
3
1. Press
[TEMPO/TAP].
2. Set your desired tempo value numerically using the
SONG/STYLE category buttons.
Pressing [TEMPO/TAP] enables you to use the SONG/STYLE
category buttons as numeric buttons.
The tempo can be set using
[+/YES]/[-/NO].
Press both [+/YES] and [-/NO]
simultaneously to reset the
value to the default value.
3. Press [SHIFT] to exit
the tempo setting
display.
Returning to the Home Display
([SHIFT] button)
The display with the Voice name in the
upper row and the Song/Style name in
the lower row, such as in the illustration
at left is referred to the “Home display.”
Press [SHIFT] to return to the home
display from displays other than the
home display such as the function
setting display (page 24).
17
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Selecting a Main Voice
1 Press one of the buttons from among
the VOICE Category buttons.
Each time you press the button, it changes to a
different Voice within the same category.
1 2
4
5
6 7 8
9
0
3
Voice number Voice name
2 Play the keyboard.
Playing with S.Art Lite Voices (Super
Articulation Lite Voices)
Playing with the S.Art Lite Voice can reproduce
playing techniques for particular instruments, such
as guitar harmonics, by using [ARTICULATION].
g Reference Manual
Calling up the Grand Piano Voice
When you want to reset various settings to
default and simply play a Piano sound, press
[PORTABLE GRAND].
This automatically calls up Voice 001
“Live!ConcertGrandPiano” as the Main Voice.
Layering another Voice over the entire
keyboard (Dual)
1 Press [DUAL] to turn on the layer.
Appears when Dual is on.
2 Play the keyboard.
Two Voices will
sound at the same
time.
* How to select a different layer Voice (Dual
Voice) g Reference Manual
3 To exit from the layer, press [DUAL]
again.
Playing a Variety of Instrument Voices
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
18
Playing a Variety of Instrument Voices
Playing Different Voices with Your Left
and Right Hands (Split)
By dividing the keyboard into the two separate
areas, you can play one Voice with your left hand
and a different Voice with your right.
Split Point ... default setting: 54 (F#2)
36
(C1)
48
(C2)
60
(C3)
72
(C4)
84
(C5)
96
(C6)
Left hand area
Split Voice
Right hand area
Main Voice and Dual Voice
The illustration is of the PSR-E383.
The highest key for the left-hand area is referred to as
the “Split Point” (page 24, Function number 003).
1 Press [SPLIT] to turn on Split.
The keyboard is divided into the left-hand and
right-hand areas.
Appears when Split is on.
2 Play the keyboard.
* How to select a different Split Voice
g Reference Manual
3 To exit from the Split, press the [SPLIT]
again.
Playing the Keyboard with Two People
(Duo)
1 Press [DUO] to turn Duo on.
Appears when Duo is on.
The illustrations below are of the PSR-E383.
Duo Split Point ... default setting: 66 (F#3)
Equivalent to C3
Equivalent to C3
Left player Right player
The keyboard is divided into left and right
sections with the F#3 key as a boundary, and
you can play the same range of notes on the
left and right.
* How to change the Left Voice g Reference
Manual
2 To exit from Duo, press [DUO] again.
19
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
The Auto Accompaniment (ACMP) function plays Styles (rhythm + bass + chord accompaniment) that
matches chords automatically. Use the “Auto Chord Play” to hear the Styles first, and then play with Styles
by specifying chords yourself.
There are two ways you can play the chords: “Smart Chord,” which lets you play chords by simply playing
one key, and “Multi Finger,” which lets you play them conventionally, all the constituent notes. g Reference
Manual. The explanations here apply when playing with “Smart Chord.”
4 Press [START/STOP].
The chords progress automatically with the
matching accompaniment patterns.
5 Press [START/STOP] to stop Style
playback.
Style Tutorial Video
Make sure to watch this video and how to enjoy the
Styles.
https://yamaha.io/PSR-E383_TUT_ML_EN
Playing with Rhythm and Auto Accompaniment (Styles)
Specify the Chords Automatically
(Auto Chord Play)
Auto Chord Play enables you to hear and
experience the chord progression without needing
to specify the chords. The key to be played and
chord name are displayed, so that you can learn
chord progressions or play melody part with
the appropriate rhythms and accompaniment
patterns.
1 Press [SONG]/[STYLE] to call up the
“STYLE” icon and Style mode.
lights
up.
2 Press one of the SONG/STYLE Category
buttons to select the desired Style
(page 16).
1 2
4
5
6 7 8
9
0
3
3 Press AUTO CHORD PLAY [ON/OFF] to
turn on the Auto Chord Play.
lights
up.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
20
Style Playback Variations
Styles have Intro, Main A/B, Fill-in, and Ending
sections. You can add variations to a performance by
switching sections. g Reference Manual
Play while Specifying the Chords
1 Select your favorite Style via steps 1
and 2 in “Specify the Chords
Automatically (Auto Chord Play)” (page
19).
If Auto Chord Play is on, press AUTO CHORD
PLAY [ON/OFF] to turn it off.
2 Press [ACMP ON/OFF] to call up “ACMP”
icon.
lights
up.
The “Auto Accompaniment area” of the
keyboard to the left of the Split Point (54:F#2)
functions as the range for chord recognition.
Split Point... default setting: 54 (F#2)
Auto Accompaniment area
3 Press [START/STOP] to start just the
rhythm part.
4 Play the root note of a chord in the
Auto Accompaniment area.
The bass and chord accompaniment parts start
with the rhythm part. Play various chords with
your left hand and melody part with your right
hand.
5 Press [START/STOP] to stop Style
playback.
Playing with Rhythm and Auto Accompaniment (Styles)
21
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Playing Back Songs and Using Song Lessons
Listening to the Demo Songs
While holding down [SHIFT], press
[PORTABLE GRAND].
Demo Songs (Song numbers 001 to 003) are
played back in sequence.
To stop playback, press [SHIFT] or [START/STOP].
You can play Songs repeatedly with this operation.
g Reference Manual
Listening to the Preset Songs
1 Press [SONG]/[STYLE] to call up the
“SONG” icon and Song mode.
lights
up.
2 Press one of the SONG/STYLE Category
buttons to select the desired Song
(page 16).
1 2
4
5
6 7 8
9
0
3
3 Press [START/STOP] in the Song control
button section to play the Song.
4 Press [START/STOP] again to stop Song
playback.
Practicing the Timing and Touch of Playing
the Keyboard (Rhythm & Touch Tutor)
You can practice by playing back the Songs in the
"RHYTHM & TOUCH TUTOR" category.
1 Press [SONG]/[STYLE] to call up the
“SONG” icon on the display.
2 Press [RHYTHM&TOUCH] in the SONG
Category buttons.
4
5
9
0
1 2
3 Press [START/STOP] to start Song
playback.
4 Press the keyboard in accordance with
the mark's movement.
The mark moves toward the right.
There are three marks of
different sizes depending
on the touch strength.
Play the keyboard at a
strength appropriate to
the size of mark displayed.
When the mark overlaps this white
square, play the keyboard while trying to
be aware of the strength of your playing.
This meter display shows your touch strength.
If only the timing is correct, “OK” is displayed;
if both the timing and touch strength are correct, “Good!” is displayed.
As long as your timing and touch strength are
right, any key you play will be correct.
To stop Song playback, press [START/STOP].
5 When the Song ends, the score and
message will be shown.
Soft Medium Hard
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
22
Playing Back Songs and Using Song Lessons
Practice Playing Keyboard using Song
Lesson Features
Here are two of the main lesson features available
with this instrument.
You can refer to the music score in the Song Book
(free downloadable scores).
* How to download g Page 9
Keys to Success
You can select just the key phrases of the Song—
the ones you like most or need to work on—and
practice them one by one. This lesson is ideal for
beginning players.
Select the Song you want to learn.
Practice step 1.
Practice the last Step.
You’re done!
Practice Steps 2, 3, 4... and so on.
Passed ★
Passed ★★
Passed ★★★
Each Song consists of several Steps. Each time
you play all the way through the current Step,
your performance will be evaluated. A score of
“60” or more indicates that you passed this Step
and you should try the next Step, which begins
automatically.
3-Step Lesson (Listening, Timing and Waiting)
You can practice the preset Songs in three steps,
independently for the right or left hand, or both
hands together. This is ideal when you want to
practice all the way through the Song with the
selected part.
z Lesson 1 (Listening) ...Listen to the playback
part you will play. Remember it as best as
you can.
z Lesson 2 (Timing) ........Learn to play the notes
with the correct timing. Even if you play
wrong notes, the correct notes will sound.
z Lesson 3 (Waiting) ......Learn to play the correct
notes. The Song pauses until you play the
right note.
Select the Song you want to learn.
Select the part you want to work on
(right hand, left hand, both hands).
Start the lesson!
Select lesson 1, 2, or 3.
Keys to Success with 3-Step Lesson
Combining the Keys to Success lesson with the
3-Step lesson is very convenient. For example,
you can practice your weak points in the Keys to
Success lesson by using the Timing lesson.
* Steps to combine the Keys to Success lesson with
3-Step lesson g Reference Manual
23
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Recording Your Performance
Ten settings have already been memorized as Factory settings of this instrument. However, you can
memorize your own favorite settings by overwriting the factory settings.
* Details on the factory settings g Reference Manual
You can record up to 5 of your performances as User Songs (User 1–5: Song numbers 126–130), which can
then be played back on the instrument. If you want to specify a different User Song instead of the User
Song on the display as the recording target, use [+/YES] and [-/NO].
Memorizing Your Favorite Settings (Registration Memory)
Memorizing Your Favorite Panel
Settings
1 Make the desired settings such as
those for Voice and Style.
Parameters that are memorized to Registration
Memory g Reference Manual
2 While holding down
[SHIFT], press
[REGIST MEMORY].
The SONG/STYLE category
buttons can be used as
numeric buttons.
3 Press the one of the SONG/STYLE
category buttons 1–0(10) to memorize
the current panel settings.
If an “Overwr?" message appears in the display,
press [+/YES] or [-/NO]. When memorizing is
complete, “Mem OK” is displayed.
3 Press [START/STOP] to stop recording.
4 To play back the recorded Song, press
[START/STOP].
To play the recorded Song later, press
[USER&STORAGE] in step 2 of “Listening to the
Preset Songs” (page 21).
* How to delete the User Song g Reference
Manual
1 Press [REC] to enter recording standby.
2 Play the keyboard or press
[START/STOP] to start recording.
Recalling the Panel Settings
1 Press [REGIST MEMORY].
The SONG/STYLE category
buttons can be used as
numeric buttons.
2 Press the one of the SONG/STYLE
category buttons 1–0(10) to call up the
current panel settings you memorized.
1 2
4
5
6 7 8
9
0
3
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
24
The Functions
Function List
Function
Number
Function Name Display Range/Settings
Default
Value
Backup
Overall
001 Transpose -12–12 0
002 Tuning
427.0 Hz–453.0 Hz 440.0 Hz
✓
003 Split Point
36–96
(C1–C6;PSR-E383, YPT-380)
28–103
(E0–G6;PSR-EW320, YPT-W320)
54 (F#2)
✓
004 Touch Response
1: Soft
2: Medium
3: Hard
4: Off
2: Medium
✓
Main Voice
005 Volume 000–127 *
006 Octave
-2–+2 *
007 Reverb Depth
000–127 *
008 Chorus Depth
000–127 *
2 Press [+] or [-] until the
desired item appears.
You can also call up the desired
item by inputting the function
number directly with the VOICE
Category buttons.
3 Press [+/YES] or [-/NO] to
set the value.
You can also set the value by
inputting it directly with the
SONG/STYLE Category buttons.
Pressing [+/YES] and [-/NO]
simultaneously restores the
default setting.
4 To exit the function settings, press
[FUNCTION] or [SHIFT].
About the Function Settings
The “Functions” provide access to a range of
detailed instrument parameters such as Tuning,
Split Point, Voices, and Effects. Find the desired
item in the Function List (pages 24–27), and
then follow the instructions below.
1 Press [FUNCTION] to call up the
Function Settings.
This operation enables you to use the VOICE
Category buttons or SONG/STYLE Category
buttons as numeric buttons.
Current value
Function Name
Function Number
The Functions
25
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Function
Number
Function Name Display Range/Settings
Default
Value
Backup
Dual Voice
009 Volume 000–127 *
010 Octave
-2–+2 *
011 Reverb Depth
000–127 *
012 Chorus Depth
000–127 *
Split Voice
013 Volume 000–127 *
014 Octave
-2–+2 *
015 Reverb Depth
000–127 *
016 Chorus Depth
000–127 *
Style
017 Style Volume 000–127 100
✓
018 Fingering Type
1: Smart Chord
2: Muti Finger
1:
Smart Chord
✓
019 Style Key
FL7 – SP0 – SP7
FL7 (7 Flats b) : Key of Cb major
/Ab minor
SP0 (No Key Signature) : C major
/A minor
SP7 (7 Sharps #) : C# major
/A# minor
SP0 (No Key
Signature)
:
Key of C major/
A minor
020 Chord Progression Refer to the Data List on the
website.
01
Song
021 Song Volume 000–127 100
✓
022 Song Melody Voice
001–650 **
Effects
023 Reverb Type 1–4: Hall 1, 2, 3, 4
5: Cathedral
6–9: Room 1, 2, 3, XG
10–12: Stage 1,2, XG
13–15: Plate 1, 2, XG
16: Off
**
024 Reverb Level
000–127 64
025 Chorus Type
1–3: Chorus 1, 2, 3
4–6: Flanger 1, 2, XG
7: Celeste XG
8: Off
**
026 DSP Type
01–41 *
027 Panel Sustain
On/Off Off
✓
The Functions
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
26
Function
Number
Function Name Display Range/Settings
Default
Value
Backup
028 Master EQ Type 1: Standard
2: Boost
3: Piano
4: Bright
5: Mild
1: Standard
✓
Harmony/Arpeggio
029 Harmony/Arpeggio Type 001–026 (Harmony)
027–178 (Arpeggio)
*
030 Harmony Volume
000–127 *
031 Arpeggio Velocity
1: Original
2: Key
**
032 Arpeggio Quantize
1: Off
2: 1/4
3: 1/8
4: 1/16
**
Pedal
033 Pedal Function 1: Sustain
2: Arpeggio Hold
3: Sustain+Arpeggio Hold
4: Articulation
1: Sustain
Metronome
034 Time Signature Numerator 00–60 **
035 Time Signature
Denominator
2 (Half note)
4 (Quarter note)
8 (Eighth note)
16 (Sixteenth note)
**
036 Metronome Volume
000–127 100
✓
Lesson
037 Lesson Track (R) 01–16 01
038 Lesson Track (L)
01–16 02
039 Your Tempo
On/Off On
✓
040 Guide
On/Off On
✓
MIDI
041 Local Control On/Off On
042 External Clock
On/Off Off
043 Initial Send
YES/NO -
Audio
044 [AUX IN] Audio Volume 000–127 50
✓
045 [USB TO HOST] Audio
Volume
000–127 100
✓
046 Audio Loopback
On/Off On
✓
047 Melody Suppressor
On/Off Off
048 Suppressor Pan
L63–C–R63 C
The Functions
27
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Function
Number
Function Name Display Range/Settings
Default
Value
Backup
Regist Freeze
049 Style Freeze On/Off Off
✓
050 Transpose Freeze
On/Off Off
✓
051 Voice Freeze
On/Off Off
✓
Duo
052 Duo Split Point 36–96
(C1–C6;PSR-E383, YPT-380)
28–103
(E0–G6;PSR-EW320, YPT-W320)
66 (F#3)
053 Duo R Volume
000–127 *
054 Duo L Volume
000–127 *
055 Duo R Octave
-3–+3 *
056 Duo L Octave
-3–+3 *
057 Duo Type
1: Balance
2: Separate
2: Separate
Storage
058 Storage Mode On/Off Off
Style File
059 Style Register 001–nnn -
Demo
060 Demo Group 1: Demo
2: Preset
3: User
4: Storage
1: Demo
✓
061 Demo Play Mode
1: Normal
2: Random
1: Normal
✓
AC
062 Auto Power Off Time Disabled,
5/10/15/30/60/120 minutes
15 minutes
✓
063 Battery Type
1: Alkaline (Alkaline batteries,
manganese dry batteries)
2: Ni-MH (Rechargeable nickel
metal hydride batteries)
1: Alkaline
✓
* The appropriate value is automatically set for each Voice combination.
** The appropriate value is automatically set for each Song, Style or Arpeggio.
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
28
Backup and Initialization
Backup Parameter
The following Backup parameters will be
maintained even if the power is turned off.
Backup parameters (each time)
• User Songs (page 23)
• Styles registered to Style numbers 261–
270 (transferred from external devices)
* How to register Style files g Reference
Manual
Backup parameters when turning off the
power
• Registration Memory (page 23)
• Function settings: (pages 24–27)
Settings with a check mark in the “Backup”
column in the Function List are backed up.
• Passing Status of Keys to Success g
Reference Manual
Parameters that are memorized to Registration
Memory g Reference Manual
Troubleshooting
Problem Possible Cause and Solution
Not all of the Voices seem to sound, or the
sound seems to be cut off.
The instrument is polyphonic up to a maximum of 48 notes—including auto
accompaniment, Song, and Metronome. Notes exceeding this limit will not sound.
The sound of the Voice changes from note
to note.
This is normal. The AWM tone generation method uses multiple recordings
(samples) of an instrument across the range of the keyboard; thus, the actual
sound of the Voice may be slightly different from note to note.
The power suddenly and unexpectedly turns
off.
This is normal, and the Auto Power Off function may have been activated. If you do
not want to use the Auto Power Off function, disable the Auto Power Off function
(page 11).
When the instrument is turned on, the power
turns off suddenly and unexpectedly.
The protection circuit has been activated due to over current. This may occur when
an AC adaptor other than the one specified is used or the AC adaptor is damaged.
Use the specified adaptor only (page 30). If it appears to be malfunctioning,
discontinue use immediately and have it inspected by qualified Yamaha service
personnel.
The application on your smart device doesn’t
recognize the instrument.
Is Storage Mode set to “On”? Make sure that Storage Mode is set to “Off” in the
Function Setting display (page 24, Function number 058).
Initializing the Instrument
You can erase the backup parameter settings
described above, and then restore all the default
factory settings.
Backup Clear
This operation initializes the backup parameters.
While holding down the highest white key, press
the [
] (Standby/On) switch to turn the power on.
PSR-E383, YPT-380
PSR-EW320, YPT-W320
Highest note on the
keyboard (white key)
There is an alternate operation that lets you delete
all the Songs and Styles that have been transferred
from a computer or smart device (except Style
data registered to Style numbers 261–270).
g Reference Manual
29
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Specifications
PSR-E383 YPT-380 PSR-EW320 YPT-W320
Product Name Digital Keyboard
Size/Weight
Dimensions (W x H x D)
941 mm × 105 mm × 317 mm
(37-1/16” x 4-1/8” x 12-1/2”)
1,148 mm × 105 mm × 317 mm
(45-3/16” x 4-1/8” x 12-1/2”)
Weight
4.4 kg (9 lb, 11 oz)
(not including batteries)
5.2 kg (11 lb, 7 oz)
(not including batteries)
Control
Interface
Keyboard
Number of Keys 61 76
Touch Response Soft, Medium, Hard, Off
Display
Type LCD (Liquid Crystal Display)
Backlight Yes
Language English
Panel Language English
Voices
Tone Generator AWM Stereo Sampling
Polyphony (max.) 48
Preset Number of Voices
650
(258 Panel Voices + 25 Drum/SFX kits + 20 Arpeggio + 347 XGlite Voices)
Compatibility GM/XGlite
Effects
Types
Reverb 15
Chorus 7
DSP 41
Master EQ 5
Functions
Dual Yes
Split Yes
Duo Yes
Panel Sustain Yes
Arpeggio 152
Harmony 26
Melody
Suppressor
Yes
Articulation Yes (12 Super Articulation Lite Voices)
Accompaniment
Styles
Number of Preset Styles 260
Fingering Smart Chord, Multi finger
Style Control
ACMP ON/OFF, SYNC START, START/STOP, INTRO/ENDING/rit.,
MAIN/AUTO FILL
External Styles 10
Other
Features
Music Database 200
One Touch Setting
(OTS)
Yes
Auto Chord Play 50 Chord Progressions
Compatibility Style File Format (SFF)
Songs (MIDI)
Preset
Number of Preset
Songs
125
Recording
Number of Songs 5
Number of Tracks 2
Data Capacity Approx. 10,000 notes
Format
Playback SMF (Format 0, Format 1)
Recording Original File Format
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
30
Specifications
PSR-E383 YPT-380 PSR-EW320 YPT-W320
Functions
Registration
Memory
Number of
Memories
10
Lesson
KEYS TO SUCCESS, 3-Step Lesson (Listening, Timing, Waiting),
A-B Repeat, Rhythm & Touch Tutor
Demo Yes
USB Audio (USB TO HOST) 44.1 kHz, 16 bit, stereo
Overall
Controls
Metronome Yes
Tempo Range 11–280
Transpose -12 to 0, 0 to +12
Tuning 427.0–440.0–453.0 Hz (approx. 0.2 Hz increments)
Miscellaneous
PIANO Button Yes ([PORTABLE GRAND] Button)
Storage and
Connectivity
Storage Internal Memory Approx. 1.4 MB
Connectivity
DC IN 12 V
Headphones/
Output
Standard stereo phone jack (PHONES/OUTPUT)
Sustain Pedal Yes
AUX IN Stereo mini jack
USB TO HOST Yes (MIDI/AUDIO)
Sound System
Amplifiers 2.5 W x 2
Speakers 12 cm x 2
Power Supply
Power
Supply
AC Adaptor
PA-130 or an equivalent recommended by Yamaha
(Output : DC 12 V, 0.7 A or 1.0 A)
Batteries
Six “AA” size alkaline (LR6), manganese (R6), or
Ni-MH rechargeable batteries (HR6)
Power Consumption 5 W (When using PA-130 AC adaptor)
Auto Power Off Yes
Included Accessories
• Music rest
• Owner’s Manual
• AC adaptor *(PA-130 or an equivalent recommended by Yamaha)
• Online Member Product Registration
*: May not be included depending on your particular area. Please check
with your Yamaha dealer.
Separately Sold Accessories
(May not be available depending on your area.)
• AC adaptor:
Users within U.S or Europe: PA-130 or an equivalent
recommended by Yamaha
Others: PA-3C, PA-130 or an equivalent recommended by Yamaha
• Keyboard stand: L-2C
• Headphones: HPH-150, HPH-100, HPH-50
• Footswitch: FC4A, FC5
• Keyboard bag: SC-KB630 (for PSR-E383, YPT-380), SC-KB730 (for
PSR-EW320, YPT-W320)
* The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access
the Yamaha website then download the manual file. Since specifications, equipment or separately sold accessories may
not be the same in every locale, please check with your Yamaha dealer.
31
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
Index
Numerics
3-Step Lesson ............................................................22
A–Z
A
AC Adaptor ................................................................. 10
ACMP ................................................................... 19, 20
Arpeggio ....................................................................26
Articulation ................................................................17
Auto Accompaniment ............................................... 19
Auto Accompaniment area ......................................20
Auto Chord Play ........................................................19
Auto Power Off .......................................................... 11
AUX IN ........................................................................15
B
Backup ........................................................................ 28
Battery ................................................................. 10, 11
C
Chorus Type ............................................................... 25
Computer ................................................................... 15
D
Data List .......................................................................9
Demo ..........................................................................21
Dual ............................................................................17
Dual Voice ........................................................... 17, 25
Duo ...................................................................... 18, 27
Duo Split Point .................................................... 18, 27
F
Functions....................................................................24
H
Harmony ....................................................................26
Headphones ..............................................................15
Home Display ............................................................16
I
Included Accessories .................................................. 9
Initialization ...............................................................28
K
Keys to Success .........................................................22
L
Layer (Dual) ................................................................ 17
Lesson ........................................................................22
M
Main Voice ........................................................... 17, 24
Master EQ ..................................................................26
Master Volume ................................................... 11, 12
Metronome ......................................................... 12, 26
Multi Finger ...............................................................19
Music Rest .................................................................. 11
P
PORTABLE GRAND ....................................................17
Power................................................................... 10, 11
R
Recording ................................................................... 23
Reference Manual (
) ..........................................9
Registration(Regist) Memory ................................... 23
Reverb Type ...............................................................25
Rhythm & Touch Tutor .............................................21
S
SHIFT ................................................................... 12, 16
Smart Chord ..............................................................19
Smart Device ..............................................................15
Smart Device Connection Manual ............................9
Song ............................................................... 16, 21, 25
Song Book ....................................................................9
Specifications .............................................................29
Split .............................................................................18
Split Point ...................................................... 18, 20, 24
Split Voice ............................................................ 18, 25
Style .........................................................16, 19, 20, 25
Sustain ........................................................................ 15
T
Tempo .........................................................................16
Touch Response ........................................................24
Transpose ...................................................................24
Troubleshooting ........................................................28
Tuning ........................................................................24
U
User Song...................................................................23
V
Voice .................................................................... 16, 17
Volume ................................................................ 11, 12
PSR-E383, YPT-380, PSR-EW320, YPT-W320 Owner’s Manual
32
About open source software
The firmware of this product contains open source software. For copyright information and terms of use
for each open source software, access the Yamaha website below:
Yamaha Downloads: https://download.yamaha.com/
Important Notice:
U.S. LIMITED WARRANTY for Customers in the United States
For detailed information about this Yamaha product and warranty service, please either
visit the following website address (printable file is available at our website) or contact
Customer Service at the address or telephone number identified below.
Website Address:
Yamaha.io/pkbwarranty
Customer Service:
Yamaha Corporation of America
6600 Orangethorpe Avenue, Buena Park, CA 90620
Telephone: 800-854-1569
