Charging the Battery
LG620GM
Quick Start Guide
• Depending on the software installed or your service provider or country, some of the
descriptions in this guide may not match your phone exactly.
• Depending on your country, your phone and accessories may appear different from
the picture in this guide.
P/N: MMBB0371804(1.1)
Installing the Battery
Installing the Battery
1. To install the battery, align the battery contacts (1) with those in the battery
compartment. Press the battery down until it clicks into place (2).
2. With the battery in position in the phone, replace the battery cover on the back of
your phone.
Removing the Battery
1. With your phone turned off, slide backward from the bottom of the battery cover (1)
on the back of your phone, slide the battery cover up and lift off (2).
2. Lift the battery up (1) and away (2) from the phone, as shown.
Your phone is powered by a rechargeable Li-ion battery. Use the wall charger to charge
the battery. Please remember to only use LG approved batteries and chargers.
1. Open the cover on the accessory port on the right side of the phone and plug the
charger connector into the jack. Be sure to orient the connector as shown below in
order to avoid damaging your phone.
2. Plug the other end of the charger into a standard AC wall outlet.
3. When the phone is completely charged(
), unplug the charger from the wall outlet.
4. Remove the charger from the phone by gently pulling out the connector. Replace the
plastic cover over the open jack.
Important: Do not remove the battery from the phone while charging and make sure
the charger is disconnected from the phone before removing the battery.
Please make sure that the ‘B’ side of
the connector is facing up.
Phone layout and key functions
• Messaging, voice mail, and caller ID.
• Speakerphone feature.
• Menu-driven interface with prompts for easy operation and configuration.
• Any Key answer, Auto Redial, One-Touch dial and Speed Dial (with 9 locations).
• Bilingual (English and Spanish) capabilities.
• Internal Antenna.
• Easy-to-read LCD with status icons.
Display
Idle mode is when you are not on
a call or using a menu. You must
be in Idle mode to enter a phone
number to dial.
Earpiece
LCD Screen
OK Key
Left Soft Key
SEND Key
Navigation Keys
Right Soft Key
END/PWR Key
Alphanumeric
Keypad
Silent Mode Key
Microphone
Icon Description
Your phone displays the following status indicators on the top of the screen:
Signal Strength
Outdoor
1X
Flight Mode
Meeting Mode
SSL
Battery Strength
Customized 1
TTY
In Call State
Customized 2
Location On
No Service
Customized 3
E911 Only
New Message
Alarm Only
Bluetooth On
Msg & Voicemail
Alarm
Device Connected
Speaker Phone
Calendar
Visible
Silent Mode
Roaming
Normal
Digital
Turning the Phone On or Off
1. To turn on, install a charged battery.
2. Then press
until the LCD screen lights up.
3. To turn off, press and hold
until the display turns off.
Changing the display language
Allows you to use the bilingual feature according to your preference. Choose
between English and Spanish.
1. In Idle mode, press the left soft key
Menu.
2. Select
→ → .
3. Use
to select Automatic, English, or Español, then press Select.
Making Calls
1. Make sure the phone is turned on.
2. Enter the phone number (include the area code if needed).
3. Press
to dial.
4. Press
to end the call.
Recent Calls
The Recent Calls Menu is a list of the last phone numbers or Contacts entries for calls
missed, received, or dialed. It is continually updated as new numbers are added to the
beginning of the list and the oldest entries are removed from the bottom of the list.
Note: To view a quick list of all your recent calls, press
while in idle mode.
1. Missed Calls : Allows you to view a list of the most recent missed calls.
Press left soft key
, , → Use to highlight an entry.
2. Dialed Calls : Allows you to view a list of the most recent dialed calls.
Press left soft key
, , → Use to highlight an entry.
3. Received Calls : Allows you to view a list of the most recent received calls.
Press left soft key
, , → Use to highlight an entry.
4. All Calls : Allows you to view the list of the most recent missed, received and dialed
calls. Press left soft key
, , .
5. Call Duration : Allows you to view the duration of the calls, by type.
Press left soft key
, , → Use to highlight one of the call types (below).
All Calls/ Dialed calls/ Received calls/ Last call.
6. Data Counter : Allows you to view the amount of transmitted data, by type.
Press left soft key
, , → Use to highlight one of the data types (below).
Sent data/ Received data/ All data.
Sound
Options to customize your phone’s sounds:
Ringers
1. Press the left soft key , , .
2. Select Radio recordings, Ringtone, Voice recordings, or Default Sounds.
3. Use
to highlight a sound and press Play to listen to it.
4. Press the left soft key
Options and choose Use As.
5. Choose from Voice ringtone, Message tone, Start up or Shut down and press
Select to set the sound to your phone.
Volume
1. Press the left soft key , , .
2. Use
to highlight the profile you want to edit.
3. Press the left soft key
Options and choose Edit.
4. You can change all of the tones, its volumes, and alert options from this menu.
Using the menus
Selecting a Menu or Feature :
1. Press the left soft key
Menu to access Main menu.
2. Use
to reach a desired menu and then press .
3. If the menu contains any submenus, locate the one you want by using the
.
Press
Select to enter the submenu.
If the selected menu contains additional submenus, repeat this step.
Menu map
1. Prepaid
1.1 Add Airtime
1.2 My Phone Number
1.3 Airtime Info
1.4 Serial Number
1.5 SIM Number
1.6 Code Entry Mode
2. Contacts
2.1 Contact List
2.2 New Contact
2.3 Speed Dials
2.4 Groups
2.5 Own Number
2.6 My Business Card
2.7 Settings
3. Recent Calls
3.1 Missed Calls
3.2 Dialed Calls
3.3 Received Calls
3.4 All Calls
3.5 Call Duration
3.6
Data Counter
4. Messages
4.1 Create Message
4.2 Inbox
4.3 Sent Items
4.4 Saved Items
4.5 Voicemail
4.6 Drafts
4.7 Outbox
4.8 Emoticons
4.9 Message Settings
5. Browser
5.1 Home
5.2 Bookmarks
5.3 Enter URL
5.4 Saved Pages
5.5 Recent Pages
5.6 Browser Settings
6. Media
6.1 Camera
6.2 Video
6.3 Music
6.4 FM Radio
6.5 Voice Recorder
6.6 Ringtone Creator
7. My Folder
7.1 Pictures
7.2 Sounds
7.3 Videos
7.4 Games & Apps
7.5 Other Files
7.6 Memory Card
8. Tools
8.1 Alarm Clock
8.2 Calendar
8.3 Notepad
8.4 Secret Notes
8.5 Calculator
8.6 World Clock
8.7 Tasks
8.8 Stopwatch
8.9 Unit Converter
8.0 Date Finder
8.
*
SIM App.
8.# Settings
9. Settings
9.1 Sound Profiles
9.2 Phone Settings
9.3 Display
9.4 Connection
9.5 Call
9.6 Memory
9.7 Phone Information
Status icons
Main display area
Soft key function
options
*Many of the features and services described are network dependent and may require
additional subscription and/or usage charges. Not all features are available for purchase
or use in all areas.
Other conditions and restrictions may apply. See carrier for more information.
© 2010 LG Electronics, Inc.
Bluetooth QD ID B015954
