DETAILED
INSTRUCTIONS FOR USE
OF UPRIGHT
REFRIGERATOR AND
FREEZER
2
We thank you for the confidence you have shown by purchasing
our appliance which is designed to simplify your life. To make the use of the
product easier, we have supplied detailed instructions for use, and installation
instructions supplied on a separate sheet. The instructions should allow you to
learn about your new appliance as quickly as possible.
We wish you find a lot of pleasure in its use.
The appliance is intended solely for household use.
The refrigerator is intended for storing fresh food at temperatures above 0°C.
The freezer is intended for freezing fresh food and for long-term storage of
frozen food (up to one year, depending on the type of food).
Please visit our website where you can enter your appliance model number,
indicated on the rating plate or the warranty sheet, to find detailed description
of your appliance, tips on use, troubleshooting, service information, instructions
for use etc.
http://www.gorenje.com
Link to the EU EPREL database
The QR code on the energy label supplied with the appliance provides a web
link to the registration of this appliance in the EU EPREL database. Keep
the energy label for reference together with the user manual and all other
documents provided with this appliance.
It is possible to find information related to the performance of the product
in the EU EPREL database using the link https://eprel.ec.europa.eu and the
model name and product number that you can find on the rating plate of the
appliance.
For more detailed information about the energy label, visit www.theenergylabel.eu.
Important safety warning
General information and tips
i
Protecting the environment
!
Do not wash in the dishwasher
3
CONTENTS
INTRODUCTION
APPLIANCE
DESCRIPTION
DEFROSTING
AND CLEANING
THE APPLIANCE
4 IMPORTANT NOTES AND PRECAUTIONS
4 BEFORE USING THE APPLIANCE FOR THE FIRST TIME
5 IMPORTANT SAFETY INSTRUCTIONS
8 IMPORTANT INFORMATION ON THE USE OF APPLIANCE
9 ENVIRONMENT PROTECTION
10 ADVICE FOR SAVING POWER WITH REFRIGERATION
APPLIANCES
11 INSTALLATION AND CONNECTION
13 APPLIANCE DESCRIPTION
14 OPERATING THE APPLIANCE
15 APPLIANCE INTERIOR EQUIPMENT
16 RECOMMENDED DISTRIBUTION OF FOOD IN THE
APPLIANCE
17 STORING FOOD IN THE REFRIGERATOR
18 FREEZING AND STORING FROZEN FOOD
18 Important warnings on freezing
18 Storing industrially frozen food
19 Frozen food storage time
19 Defrosting frozen food
20 DEFROSTING THE APPLIANCE
21 CLEANING THE APPLIANCE
22 TROUBLESHOOTING
24 INFORMATION ABOUT APPLIANCE NOISE
OTHER
STORING AND
FREEZING FOOD
4
IMPORTANT NOTES AND
PRECAUTIONS
Before connecting the appliance to the power mains, please
read carefully the instructions for use which describe the
appliance and its correct and safe use. The instructions
apply to several appliance types/models; thus, settings or
equipment may be described herein which is not available
in your appliance. We recommend saving this instruction
manual for future reference and attach it to the appliance if
it is sold in the future.
Check for any damage or irregularities on your appliance. If
you find your appliance is damaged, notify the retailer from
which you have purchased the appliance.
Before connecting the appliance to the power mains, let
the appliance rest in a vertical position for a minimum of 2
hours. This will reduce the possibility of operation faults due
to the effect of transport on the cooling system.
BEFORE USING THE APPLIANCE FOR
THE FIRST TIME
i
5
WARNING! Risk of fire/flammable materials.
The appliance must be connected to the power mains and
grounded in compliance with the effective standards and
regulations.
WARNING! Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Before cleaning the appliance, unplug it from the power
mains (unplug the power cord from the wall outlet).
WARNING! If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING! When positioning the appliance, ensure the
supply cord is not trapped or damaged.
IMPORTANT SAFETY INSTRUCTIONS
!
WARNING! Do not use any electric devices inside the
appliance, except for those allowed by the manufacturer
of this refrigeration appliance.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING! To avoid any hazard resulting from poor
stability of the appliance, make sure it is installed as
instructed.
!
!
!
6
Danger of frostbite
Never put frozen food in your mouth and avoid touching
frozen food as this may cause frostnip or frostbite.
Safety of children and vulnerable persons
The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Remove the packaging intended to protect the appliance
or particular parts during transport and keep it outside the
reach of children.
It presents danger of injury or suffocation.
When removing a used appliance, disconnect the
power cord, remove the door, and leave the shelves in
the appliance. This will prevent children from locking
themselves in the appliance.
For European markets only
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
7
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
Warning regarding the refrigerant
The appliance contains a small amount of an
environmentally friendly yet flammable gas R600a. Make
sure that no parts of the cooling system are damaged. A
gas leak is not hazardous to the environment, but it could
cause eye injury or fire.
In case of a gas leak, ventilate the room thoroughly,
disconnect the appliance from the power mains, and call a
service technician.
8
The appliance may not be used outdoors and it may not be
exposed to rain.
Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
If the appliance will be out of use for an extended period of
time, switch it off using the relevant button, and unplug it
from the power mains. Empty the appliance, defrost it, clean
it, and leave the door ajar.
In case of an error or power supply failure, do not open the
freezer compartment unless the freezer has not operated
for over 16 hours. After this period, use the frozen food or
provide sufficient cooling (e.g. a replacement appliance).
Technical information on the appliance
Rating plate can be found in the appliance interior. It
indicates data on voltage, gross and net volume, type
and amount of refrigerant, and information on the climate
classes.
IMPORTANT INFORMATION ON THE USE
OF APPLIANCE
WARNING! Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
!
WARNING! This appliance is intended to be used in
household and similar applications such as
– sta kitchen areas in shops, o ces and other working
environments;
– farm houses and by clients in hotels, motels and other
residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
9
The symbol on the product or its packaging indicates that the product
should not be treated as normal household waste. The product should be
taken to an authorized collection centre for waste electric and electronic
equipment processing. Correct disposal of the product will help prevent
any negative effects on the environment and health of people which could
occur in case of incorrect product removal. For detailed information on
removal and processing of the product, please contact the relevant municipal
body in charge of waste management, your waste disposal service, or the
store where you bought the product.
Packaging is made of environmentally friendly materials
that can be recycled, disposed of, or destroyed without any
hazard to the environment.
!
Removing an obsolete appliance
To protect the environment, take the obsolete appliance to
an authorized home appliance collection centre.
Before doing so, do the following:
• disconnect the appliance from the power mains;
• do not allow children to play with the appliance.
ENVIRONMENT PROTECTION
WARNING! Do not damage the refrigerant circuit.
This will also prevent pollution.
!
10
ADVICE FOR SAVING POWER
WITH REFRIGERATION
APPLIANCES
• Install the appliance as specified in the instruction manual.
• Do not open the door more often than necessary.
• Occasionally make sure air circulation underneath the appliance is
unobstructed.
• Condenser unit on the rear wall should be kept clean (see chapter Cleaning the
appliance).
• If the gasket is damaged or does not provide a perfect seal for any reason,
have it replaced as soon as possible.
• Store the food in tightly sealed containers or appropriate packaging.
• Before placing the food in the refrigerator, allow it to cool down to room
temperature.
• Defrost frozen food in the refrigerator compartment.
• To make use of the entire freezer compartment interior volume, remove
some of the drawers as described in the instruction manual.
• Defrost your conventional freezer when an approximately 3–5 millimetre
layer of frost or ice has built up on the refrigerated surfaces.
• Make sure the layout of shelves in the compartment is uniform and that
the food is placed so that the air can freely circulate in the appliance
interior (observe the recommended placement of food as described in the
instructions).
• In appliances with a fan, do not block the fan slots or vents.
11
INSTALLATION AND CONNECTION
SELECTING THE ROOM
• Install the appliance in a dry and well ventilated room. The appliance will operate
correctly if the environment temperature is in the interval specifi ed in the table. The
appliance class is indicated on the rating plate / label with the basic information on
the appliance.
Description Class Ambient temperature
range °C
Relative humidity
Extended temperate SN +10 to +32
75%
Temperate N +16 to +32
Subtropical ST +16 to +38
Tropical T +16 to +43
• Do not place an appliance in a room where temperature can drop to
below 5 °C as this may cause abnormal appliance operation or failure!
i
• Do not place the appliance near appliances or devices radiating heat, such as
a cooker, a stove, a radiator, water heater etc., and do not expose it to direct
sunlight. The appliance should stand at least 3 cm away from an electric or gas
cooker or at least 30 cm away from an oil or solid fuel stove. If the distance
between such source of heat and the appliance is smaller, use an insulating
panel.
Note: Place the appliance in a su ciently large room. There should be at least
1 m
3
of space per 8 grams of refrigerant. Amount of refrigerant is indicated on
the rating plate in the appliance interior.
• At the base of the kitchen unit intended for building in the integrated
appliance, there should be at least 200 cm
2
free space, for adequate air
circulation.
On the upper part of the appliance the air is coming out, so try not to cover
the opening for the outfl ow air.
Ignoring this caution may result in damage to the appliance.
12
CONNECTING THE APPLIANCE
• Connect the appliance to the power mains using the
power cord. The wall outlet should be fi tted with a ground
contact (safety socket). Nominal voltage and frequency
are indicated on the rating plate/label with basic
information on the appliance.
• The appliance must be connected to the power mains
and grounded in compliance with the e ective standards
and regulations. The appliance will withstand short-term
deviations from the nominal voltage, but not more than
+/- 6%.
13
APPLIANCE DESCRIPTION
1
2
3
4
5
6
1 Freezer Shelf
2 Control unit&LED
lighting
3 Glass shelves
4 Fruit and vegetable
drawer
5 Door balconies
6 Bottle balcony
Appliance interior equipment may change according to the appliance model.
14
OPERATING THE APPLIANCE
A Temperature setting and on/off knob
To switch on: rotate the A dial clockwise.
Switching off: Rotate the A knob back to the position in which the arrow is
aligned with the symbol (caution: appliance will remain powered, i.e. there will
still be electric current in the appliance).
• To set the desired temperature, rotate the A dial in clockwise direction, i.e. to
the right.
• A change in the environment temperature will a ect the temperature in the
appliance. Adjust the setting with the A dial accordingly. Positions towards the
thicker part of the sign mean a lower temperature in the appliance (cooler).
Settings towards the thinner part of the sign mean a higher temperature
(warmer).
• If the temperature of the room where the appliance is installed is below 16°C,
we recommend setting the A dial temperature to the thickest part of the sign.
SWITCHING THE APPLIANCE ON/OFF
ADJUSTING THE TEMPERATURE IN THE APPLIANCE
A
15
APPLIANCE INTERIOR
EQUIPMENT
(* EQUIPMENT DEPENDS ON THE MODEL)
Interior side of the refrigerator door is
fitted with shelves intended for storing
cheese, butter, eggs, yoghurt, and
other smaller packages, tubes, cans
etc.
Maximum load on each door shelf is
5 kg.
MOVABLE SHELVES
The walls of the refrigerator are
equipped with a series of runners so
that the shelves can be positioned as
desired.
DOOR BALCONIES
16
RECOMMENDED DISTRIBUTION
OF FOOD IN THE APPLIANCE
Sections in the refrigerator compartment:
- upper part: canned food, bread, wine, pastry etc.
- middle part: dairy products, ready-made meals, desserts, soft drinks, beer,
cooked food, etc.
- Crisper: fresh fruit, vegetables, salads, root vegetables, potatoes, onions,
garlic, tomatoes, sauerkraut, turnips etc.
Sections in the refrigerator
compartment door:
- upper/middle door bins: eggs,
butter, cheese etc.
- lower door bins: beverages, cans,
bottles
Do not store fruit (bananas,
pineapples, papaya, citruses) and
vegetables (zucchini, eggplant,
cucumbers, bell peppers,
tomatoes, and potatoes) sensitive
to low temperatures in the
refrigerator.
i
Freezer sections:
- freezing, storing frozen food (see chapter Freezing and storing frozen food).
Do not store the following in the freezer: lettuce, eggs, apples, pears,
grapes, peaches, yoghurt, soured milk, sour cream, and mayonnaise.
i
17
STORING FOOD IN THE
REFRIGERATOR
IMPORTANT WARNINGS REGARDING FOOD STORAGE
i
Correct use of the appliance, appropriate packaging, maintaining
the right temperature, and observing the food hygiene standards
have a decisive impact on the quality of food storage.
Observe the expiry dates for the food, indicated on the packaging.
Food stored in the refrigerator should be kept in closed
containers or in appropriate packaging to prevent it from
emitting or receiving odours and humidity.
Do not store inflammable, volatile, and explosive substances in
the refrigerator.
Bottles with high alcohol content should be tightly sealed and
stored in an upright position.
Some organic solutions, essential oils in lemon and orange peel,
butter acid, etc. may damage the plastic surfaces in case of a
prolonged contact, causing damage and premature ageing of
these materials.
Unpleasant odour warns of lacking cleanliness of the appliance or
perished contents (see chapter Cleaning the Appliance).
If you are leaving home for a longer period of time, remove
perishables from the refrigerator.
AVOID CONTAMINATION OF FOOD
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a signifi cant increase of the
temperature in the compartments of the appliance.
• Regularly clean surfaces that can come in contact with food and accessible
drainage systems.
• Store raw meat and fi sh in suitable containers in the refrigerator, so that it is
not in contact with or drip onto other food.
• If the refrigerating appliance is left empty for long periods, switch o , defrost,
clean, dry, and leave the door open to prevent mould developing within the
appliance.
18
FREEZING AND STORING
FROZEN FOOD
i
Only use the freezer to freeze food appropriate for freezing.
Always use quality and fresh food.
Select the most suitable packaging for the food and use the
packaging correctly.
Make sure the packaging is air and water tight so that the
food does not dry out and loose its vitamins.
Indicate the type of food, amount, and date of freezing on
the packaging.
It is important that the food freezes quickly. Therefore,
smaller packages are recommended. Refrigerate the food
before freezing.
IMPORTANT WARNINGS ON FREEZING
STORING INDUSTRIALLY FROZEN FOOD
• When storing and using frozen food, observe the manufacturer's instructions.
Temperature and expiry date are indicated on the packaging.
• Only choose food with undamaged packaging, stored in freezers at
temperatures of –18 °C or lower.
• Do not purchase food covered in frost as this indicates it has been partly
thawed several times and that it is of inferior quality.
• Protect the food from thawing during transport. In case of an increase in
temperature, storage time will be shorter and quality will deteriorate.
19
FROZEN FOOD STORAGE TIME
RECOMMENDED STORAGE TIME IN THE FREEZER
Type of food Time
fruit, beef from 10 to 12 months
vegetables, veal, poultry from 8 to 10 months
Venison from 6 to 8 months
Pork from 4 to 6 months
finely chopped or ground meat 4 months
bread, pastry, cooked meals, lean fish 3 months
entrails 2 months
smoked sausage, fatty fish 1 month
DEFROSTING FROZEN FOOD
Freezing the food does not kill the microorganisms. After the food is defrosted
or thawed, bacteria are re-activated and the food spoils quickly. Use the
partially or completely defrosted food as soon as possible.
Partial thawing decreases the nutritive value of the food, particularly fruit,
vegetables, and ready-to-eat food.
20
DEFROSTING THE APPLIANCE
Refrigerator does not need defrosting because the ice on the back interior wall
is thawed automatically.
Any accumulated ice will melt when the compressor unit is inactive. Drops will
flow through an opening in the refrigerator rear wall into a tray fitted above the
compressor, from where they will evaporate.
Make sure the opening in the back wall in the refrigerator interior is never
blocked by food or any other object.
If an excessive layer of ice is formed on the rear wall of refrigerator interior (3–5
mm), switch off the appliance and defrost the appliance manually.
AUTOMATIC REFRIGERATOR DEFROSTING
DEFROSTING A CONVENTIONAL FREEZER
• Defrost the freezer when an approximately 3–5 millimetre layer of frost or ice
has built up.
• 24 hours before defrosting rotate the A dial towards the thickest part of the
marking;
After this period, remove the food from the freezer and protect them from
defrosting.
• Switch o the appliance (see chapter Switching the appliance on/o ) and
unplug the power cord.
• Do not use a knife or any other sharp object to remove the frost, as you may
damage the cooling system.
• Do not use a knife or any other sharp object to remove the frost, because you
may damage a pipe of the cooling system.
• To speed up the defrosting process, place a pot of hot water on the glass shelf.
• Clean and dry the appliance interior (see chapter Cleaning the Appliance).
21
CLEANING THE APPLIANCE
• Use a soft cloth to clean all surfaces. Cleaners that contain abrasive
substances, acids, or solvents are not suitable for cleaning as they may
damage the surface.
Clean the appliance exterior with water or a mild solution of suds.
Lacquer-coated and aluminium surfaces may be cleaned with lukewarm water
to which you have added a mild detergent. Use of cleaners with low alcohol
content is allowed (e.g. window cleaners). Do not use cleaners containing
alcohol for cleaning plastic materials.
• To avoid defrost water overfl owing into
the fridge, periodically clean the drain
hole at back of fridge compartment. Use
a cleaner to clean the hole as showed in
right picture.
• After cleaning, switch the appliance
back on and insert the food.
Appliance interior can be cleaned with lukewarm water to which you
can add some vinegar.
Before cleaning, unplug the appliance from the power mains – switch off the
appliance (see chapter Switching the Appliance On/Off) and unplug the power
cord from the wall outlet.
!
• Do not wash the parts of appliance interior equipment in a dishwasher as
they may be damaged.
22
TROUBLESHOOTING
Problem: Possible cause Solution
Appliance does
not work
• Mains plug is not plugged in
or is loose
• Insert mains plug.
• Fuse has blown or is
defective
• Check fuse, replace if
necessary.
• Socket is defective
• Mains malfunctions are
to be corrected by an
electrician.
The food is too
warm.
• Temperature is not properly
adjusted.
• Please look in the initial
Temperature Setting
section.
• Door was open for an
extended period.
• Open the door only as
long as necessary.
• A large quantity of warm
food was placed in the
appliance within the last 24
hours.
• Turn the temperature
regulation to a colder
setting temporarily.
• The appliance is near a heat
source.
• Please look in the
installation location
section.
Appliance cools
too much
• Temperature is set too cold.
• Turn the temperature
regulation knob to
a warmer setting
temporarily.
Unusual noises
• The appliance is touching the
wall or other objects.
• Move the appliance
slightly.
• A component, e.g. a pipe, on
the rear of the appliance is
touching another part of the
appliance or the wall.
• If necessary, carefully
bend the component out
of the way.
Water on the
floor
• Water drain hole is blocked. • See the Cleaning section.
23
Problem: Possible cause Solution
Replacing the
bulb:
• Before replacing the bulb, disconnect the appliance from
the power mains (unplug the power cord from the wall
outlet / socket). Insert a screwdriver into the slot in the
cover, lift it and remove it. Replace the bulb with a new
one (E14, same power rating as the one provided by the
manufacturer - AC200-240V, 50/60Hz, 1W, 0.06A) and
replace the cover.
• Do not dispose of the blown bulb with organic waste.
• The bulb is considered a consumable and is excluded from
any warranty!
• Bulb lamps used in this appliance are special purpose
lamps selected for household appliances use only. They
are not suitable for household room illumination.
• Replaceable (LED only) light source by a professional
• This product contains a light source of energy efficiency
class G.
If the malfunction shows again, contact the Service Center.
INFORMATION ABOUT
APPLIANCE NOISE
Gorenje, d.o.o
Partizanska 12
SI - 3320 Velenje, Slovenija
www.gorenje.com
Cooling in refrigerator freezers is made possible by a cooling system that also
includes a compressor (and a fan with some appliances), which generates some
noise. The level of noise depends on installation, proper use, and age of the
appliance.
• After connecting the appliance to the power mains, compressor operation,
or the sound of fl owing liquid, may be somewhat louder. This is not a sign
of malfunction and it will not a ect the useful life of the appliance. In time,
appliance operation and this noise will become quieter.
• Sometimes, unusual or loud noises may appear during appliance operation;
these are mostly the result of improper installation:
- The appliance must stand level and stable on a solid base.
- The appliance may not be in contact with a wall or adjacent furniture.
- Make sure the interior equipment sits firmly in its place and that the noise is
not caused by rattling cans, bottles or other containers placed next to each
other.
• Due to the higher workload on the cooling system when the door is opened
more frequently or for a longer time, when a large amount of fresh food is
introduced or when intensive freezing or cooling functions are activated, the
appliance can temporarily generate more noise.
WE RESERVE THE RIGHT TO CHANGES THAT DO NOT AFFECT THE
APPLIANCE FUNCTIONALITY.
