User Manual Thermador MBES Masterpiece Series Built In 2.1 cu. ft. Capacity Microwave Oven

Thermador MBES Masterpiece Series Built In 2.1 cu. ft. Capacity Microwave Oven - Use Manual - Use Guide PDF.
Documents: Go to donwload!
User Manual
  • User Manual - (English, French, Spanish)
Other Documents
  • Specification Sheet - (English)
  • Installation Intructions - (English)

User manual Microwave for Thermador MBES

Table of contents

  • Safety
  • Important Safety Instructions
  • Installation
  • Before you Begin
  • Trim Kits
  • Combination with Wall Ovens
  • Tools and Parts Needed
  • Parts Included
  • Power Requirements
  • Cabinet Cutout Dimensions
  • Outlet Area
  • Installation Procedure
  • Prepare the Appliance
  • Prepare Cabinet Cutout
  • Connect to Electricity
  • Install the Appliance
  • Service
  • Before Calling Service
  • Data Plate


  • Remove all tape and packaging before using the appliance. Destroy the packaging after unpacking the appliance. Never allow children to play with packaging material.
  • Never modify or alter the construction of the appliance. For example, do not remove leveling legs, panels, wire covers or anti-tip brackets/screws.


  • Before you plug in an electrical cord, be sure all controls are in the OFF position.
  • Do not plug the microwave into the wall until after the installation is complete. This is to prevent accidentally turning the microwave on during the installation.
  • For appliances equipped with a cord and plug, do not cut or remove the ground prong. It must be plugged into a matching grounding type receptacle to avoid electrical shock. If there is any doubt as to whether the wall receptacle is properly grounded, the customer should have it checked by a qualified electrician.
  • If required by the National Electrical Code (or Canadian Electrical Code), this appliance must be installed on a separate branch circuit.
  • Installer - show the owner the location of the circuit breaker or fuse. Mark it for easy reference.



Do not operate or allow the oven to be operated with the door open.

Make the following safety checks on all ovens to be serviced before activating the magnetron or other microwave source, and make repairs as necessary:

  • Interlock operation,
  • Proper door closing,
  • Seal and sealing surfaces (arcing, wear, and other damage),
  • Damage to or loosening of hinges and latches,
  • Evidence of dropping or abuse.

Before turning on microwave power for any service test or inspection within the microwave generating compartments, check the magnetron, wave guide or transmission line, and cavity for proper alignment, integrity, and connection.

Any defective or misadjusted components in the interlock, monitor, door seal, and microwave generation and transmission systems shall be repaired, replaced, or adjusted by procedures described in this manual before the oven is released to the owner.

A microwave leakage check to verify compliance with the Federal Performance Standard should be performed on each oven prior to release to the owner

Newest Added: MD24JS MD30RS MD30WS

Also, These documents are for others Thermador models: MBE..., MET27E..., MET30E...

Tags: Thermador Microwaves User Manuals, Thermador Microwaves Use Manual, Thermador Microwave, Thermador Microwave Drawer MD24Ws

Thermador MBES | File type: PDF | Filename: Thermador MBES Masterpiece Series Built In 2.1 cu. ft. Capacity Microwave Oven.pdf | Size: 4.39 MB | Language: English, French, Spanish | Other documents: 2 files.
