Model YF2200BL
OPERATOR'S MANUAL
ELECTRIC HIGH-PRESSURE WASHER
Before operating this product, please read this manual
thoroughly and retain it for future reference.
SUMEC NORTH AMERICA
3939 Royal Drive NW
Unit #234
Kennesaw, GA 30144
YF2200BL.indd 1 15-4-30 ��2:27
2
DO NOT RETURN PRODUCT TO PLACE OF PURCHASE.
IF YOU HAVE ANY QUESTIONS, CALL OUR TOLL-FREE HOTLINE.
(866) 902-9690
ForceToolsUSA.com
YF2200BL.indd 2 15-4-30 ��2:27
I
TABLE OF CONTENTS
YF2200BL Operator's Manual
Description of Product Parts………………………………………………………………………………......02
Technical Specifications…………………………………………………………………………………….....04
Intended Use……………………………………..…………………………………………………………......04
Important Safety Instructions……………………………………………………………………………….....05
Installation Instructions………………………………………………………………………………………...10
Operating Instructions……………………………………………………………………………………….....15
Cleaning and Maintenance………………………………………………………………………………….....19
Moving and Storage Instructions………………………………………………………………….................20
Disposal....…………………………………………………………………………………………………........21
Troubleshooting……....………………………………………………………………………………………...21
Warranty………………………………………………………………………………………………...............24
YF2200BL.indd 1 15-4-30 ��2:27
2
DESCRIPTION OF PRODUCT PARTS
Parts list
As shown in Fig. 1-3
1. Gun / power cord / hose holder
2. Handle with soft grip
3. Spray tips storage slots
4. Pressure adjusting knob
5. Support
6. High-pressure water outlet
7. Water inlet
8. Locking/releasing pin (not visible in this illustration)
9. On / Off Switch
10. Wheel
11. Plug
12. Power cord with GFCI
13. Attachments storage
14. Detergent intake hose
15. Nozzle cleaning needle
16. High-pressure hose
17. Quick-connect wand
18. Spray gun high-pressure water inlet
19. Trigger switch
20. Safety lock
21. Trigger handle
22. 15° nozzle
23. 25° nozzle
24. 40° nozzle
25. Soap nozzle
26. Turbo nozzle
27. Nozzle cleaning needle
Fig.1
Fig.2
Fig.3
YF2200BL.indd 2 15-4-30 ��2:27
3
CHECK THE DELIVERY PARTS
As shown in Fig. 4
Carefully remove the pressure washer and parts from its packaging. Identify all the parts packaged in
the carton against the parts list. Please contact our customer service center (Monday-Friday 8:30AM-
5:00PM ET) at (866) 902 9690 if anything is missing.
A High-pressure washer x1
B High-pressure hose x1
C Quick-connect wand x1
D Trigger handle x1
E1 15° nozzle x1
E2 25° nozzle x1
E3 40° nozzle x1
E4 Soap nozzle x1
E5 Turbo nozzle x1
F Tip cleaning needle x1
G Operating manual x1
WARNING: If any parts are damaged or missing, do not operate this tool until the missing parts
are replaced. Failure to heed this warning could result in serious personal injury.
NOTE! Always recycle the packaging in accordance with local recycling schemes.
Fig.4
YF2200BL.indd 3 15-4-30 ��2:28
4
TECHNICAL SPECIFICATIONS
INTENDED USE
Model YF2200BL
Input voltage rating 120 V, 60 Hz
Input power 13 A
Working pressure 2200psi
Max. pressure 2500psi
Flow rate 1.25GPM (280L/H)
Inlet pressure 44psi
Supply water temperature (max.) Cold tap water 104
o
F (40
o
C)
Electrical cord 35ft. (10.7m)
High-pressure hose 25ft. (7.6m)
Detergent injection rate 3%~12%
The pressure washer is intended for cleaning the walls of buildings, facades, terraces,
footpaths, garden equipment, machinery, vehicles, tools, etc. with a pressure water
nozzle. If required, you can also use the pressure washer with added household
cleaning agents.
The pressure washer is to be used only for its prescribed purpose, any other use is
deemed to be a case of misuse. The user/operator and not the manuafacturer will be
liable for any damage or injuries of any kind caused as a result of this.
Please note that our equipment has not been designed for use in commercial, trade
or industrial applications. Our warranty will be voided if the pressure washer is used
in commercial, trade or industrial businesses or for equivalent purposes.
YF2200BL.indd 4 15-4-30 ��2:28
5
IMPORTANT SAFETY INSTRUCTIONS
Please read all of the safety precautions before operating this pressure washer
every time.
Please pay particular attention to all sections with following symbols.
The following signal words and meanings are intended to explain the levels of risk
associated with this pressure washer.
DANGER!
Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING!
Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
CAUTION!
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
CAUTION!
(Without Safety Alert Symbol) Indicates a situation that may result in property damage.
WARNING! -
When using this pressure washer, basic precautions should always
be followed, including the following:
1. Read all the instructions before using the pressure washer.
2. To reduce the risk of injury, close supervision is necessary when a product is used
near children.
3. Know how to stop the pressure washer and release pressure quickly. Be
thoroughly familiar with the controls.
YF2200BL.indd 5 15-4-30 ��2:28
6
4. Stay alert-watch what you are doing.
5. Do not operate the pressure washer when fatigued or under the influence of
alcohol or drugs.
6. Keep operating area clear of all persons.
7. Do not overreach or stand on unstable support. Keep good footing and balance
at all times.
8. Follow the maintenance instructions specified in the manual.
9. This pressure washer is provided with a Ground Fault Circuit Interrupter built
into the power cord plug. If replacement of the plug or cord is needed, use only
identical replacement parts.
10. This pressure washer or its power cord contains lead, a chemical known to cause
cancer, birth defects or other reproductive harm. Wash hands after handling.
WARNING -
Risk of injection or injury – Do Not Direct Discharge Stream At
persons.
11. Never operate the pressure washer without all components properly connected to
the pressure washer (handle, gun/wand assembly, nozzle, etc.).
12. Never operate pressure washer with broken or missing parts. Check equipment
regularly and repair or replace worn or damaged parts immediately.
13. Never put hand or fingers over the nozzle or spray tip while operating the pressure
washer.
14. Never spray flammable liquids or use pressure washer in areas containing
combustible dust, liquids or vapors. An electric spark could cause an explosion.
15. Never leave the wand unattended while the pressure washer is running or
switched on.
16. Never disconnect the high-pressure discharge hose from the pressure washer
while the system is pressurized. To depressurize washer, turn power and water
supply off, then depress gun trigger 2-3 times.
17. Never cover the pressure washer during operation to allow free air cooling.
18. Always wear safety glasses or goggles when operating or performing
maintenance.
19. Always move switch on washer to “OFF” position before connecting or
disconnecting cord to electrical outlets.
20. Always turn water supply "ON" before turning pressure washer "ON" unless
draining for storage. Running pump dry causes serious damage.
21. Always hold gun and wand firmly when starting and operating the pressure
YF2200BL.indd 6 15-4-30 ��2:28
7
washer.
22. Always follow detergent manufacturer’s label recommendations for proper use
of detergents. Always protect eyes, skin and respiratory system from detergent if
used.
23. Always lock the trigger of spray gun in the safety position when not in use.
24. Do not use pressure that exceeds the operating pressure of any of the parts (hoses,
fittings, etc.) in the pressurized system. Never use with any other manufacturer’s
accessories or components.
25. Do not spray electrical apparatus and wiring or the pressure washer itself.
26. Do not operate the pressure washer with the inlet water filter removed. Keep filter
clear of debris and sediment.
27. Discharge residual pressure by depressing the trigger until no more water comes
out of the nozzle.
28. Keep clear of nozzle. Never direct high-pressure spray at any person, animal or
self.
29. To minimize the amount of water getting into the pressure washer, the pressure
washer should be placed as far as possible from the cleaning site during
operation.
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION
This pressure washer is provided with a ground fault circuit interrupter (GFCI) built
into the plug of the power cord. This device provides additional protection from the
risk of electric shock. Should replacement of the plug or cord become necessary,
use only identical replacement parts that including of GFCI protection.
TEST BEFORE EACH USE. Press the “TEST” button. Red indicator should disappear.
Press “RESET” button again for use. DO NOT USE if above test fails.
EXTENSION CORDS
If possible, do not use extension cords with this pressure washer; however, if you
must use one, observe all of the warning and instructions listed below:
WARNING
Extension cords are not recommended unless these are plugged into a ground fault
circuit interrupter (GFCI) found in circuit boxes or protected receptacles.
1. Use only extension cords that are intended for outdoor use. These extension
YF2200BL.indd 7 15-4-30 ��2:28
8
cords are identified by a marking “Acceptable for use with outdoor appliances; store
indoors while not in use.”
2. Use only extension cords having an electrical rating not less than the rating of the
pressure washer.
3. Do not use damaged extension cords. Examine extension cord before using and
replace if damaged.
4. Do not abuse extension cord and do not yank on any cord to disconnect. Keep
cord away from heat and sharp edges.
5. Always disconnect the extension cord from the power source before
disconnecting the pressure washer from the extension cord.
WARNING –
To reduce the risk of electrocution, keep all connections dry and
off the ground. Do not touch plug with wet hands.
WARNING
RISK OF INJURY
INJECTION HAZARD
1. Equipment can cause serious injury if the spray penetrates the skin. Do not point
the gun at anyone or any part of the body. In case of penetration, seek medical
aid immediately.
2. This system is capable of producing 1885psi. To avoid rupture and injury, do not
operate this pump with components rated less than 1885psi working pressure
(including but not limited to spray guns, hose, and hose connections).
3. Before servicing, cleaning, or removal of any part, switch off power and relieve
pressure.
WARNING
RISK OF INJURY
DO NOT DIRECT DISCHARGE STREAM AT SELF OR OTHER
PERSONS.
1. High-Pressure jet can be dangerous if misused.
2. The jet must not be directed at persons, animals, electrical devices, or the unit
itself.
YF2200BL.indd 8 15-4-30 ��2:28
9
WARNING
RISK OF EXPLOSION-DO NOT SPRAY FLAMMABLE LIQUIDS
Do not use acids, alkaline, solvents or any flammable material in this product.
These products can cause physical injuries to the operator and irreversible damage
to the pressure washer.
WARNING
RISK OF ELECTRIC SHOCK
1. Inspect cord before using –Do not use if cord is damaged.
2. Keep all connections dry and off the ground.
3. Do not touch plug with wet hands.
CAUTION
GUN KICK BACK
1. Hold with both hands.
2. The trigger gun safety lock prevents the trigger from being engaged accidentally.
3. The safety feature does not lock trigger in the ON position.
CAUTION
This pressure washer has been designed for use with detergents that are specifically
approved for pressure washer use. The use of other cleaning detergents may affect
the operation of the pressure washer and void the warranty.
YF2200BL.indd 9 15-4-30 ��2:28
10
INSTALLATION INSTRUCTIONS
WARNING!
Remove power cord from power source before carrying out any work on the
equipment, and use only original parts.
Before starting any cleaning task, it is important to inspect the area for objects that
could create a hazard. Remove any objects from the work area that could be tripped
over, such as toys or outdoor furniture. Ensure that all doors and windows are
closed tightly.
Fig.5 Fig.6
Unfold the handle
As shown in Fig. 5 & 6
Turning the handle upward around 100°, until the locking/releasing pin engages
into the corresponding hole on the handle.
Make sure the handle was fixed securely before each using.
To fold the handle:
Pull the locking/releasing pin outward on the right side of the pressure washer, and
turn the handle downward to fold the handle.
YF2200BL.indd 10 15-4-30 ��2:28
11
Connect the hose to the pressure washer
As shown in Fig. 7
Attach high-pressure hose to the washer's water outlet (hand tighten only).
Fig.7
Fig.8
Connect the hose and spray gun
As shown in Fig. 8
Screw the high-pressure hose firmly onto the spray gun.
Fit the spray nozzles to spray gun
As shown in Fig. 9
Attach desired color coded spray tip to quick - connect wand by pushing to ensure it
is clicked in securely. Insert quick – connect wand into the spray gun, hand tighten
until two parts are locked.
Fig.9
Storage position of turbo nozzle as shown in Fig.10.
Connect garden hose and inlet adapter
As shown in Fig. 11
Attach a hose with a quick-connect coupling (not supplied) to water inlet on the
high-pressure washer.
MC2200BL.indd 11 15-4-30 2:26
15 25 40 Soap
Turbo
12
Fig.10
Fig.11
Connect to water supply
As shown in Fig. 12 & 13
WARNING! Before carrying out actions below, make sure the ON/OFF switch is
on the OFF position.
WARING! The pressure washer may not be connected directly to the potable
water supply. In this case, use an appropriate back-flow prevention device
conforming to the requirements of the American Society of Sanitary Engineers.
1. Connect the water supply hose to water supply.
2. Open the water inlet valve.
Fig.12
Fig.13
YF2200BL.indd 12 15-4-30 ��2:28
13
As shown in Fig. 14
The spray tips are for purposes as below:
T1: Yellow-15
o
T2: Green-25
o
: Delivers balanced pressure and flow for general cleaning
: Delivers balanced pressure and flow for general cleaning
T3: White-40
o
: For delicate cleaning
T4: Black-Soap: Low pressure / to apply detergent
T5: Turbo: To remove particularly stubborn dirt
Fig.14
Adjusting the pressure
As shown in Fig. 15
This pressure washer is equipped with a pressure regulator. It has four settings. The
approximate value for each setting is shown below:
Fig.15
KNOWLEDGE OF SPRAY TIPS
ADJUSTMENT
MC2200BL.indd 13 15-4-30 2:26
15 25 40 Soap
Turbo
14
1.
1300psi;
2.
1600psi;
3.
1900psi;
4.
2200psi;
To select the desired pressure
Turn knob so the indicator mark aligns with the desired PSI setting.
How to make use of the power cord/hose/gun holder
As shown in Fig. 16-1&16-2
This pressure washer is equipped with 5 pieces of power cord/hose/gun holder. Each
of them consists of three parts ( support and lever, central pin),each lever also could
rotate 360 degree around its central pin clockwise or counter-clockwise, can stop in
any required position.
To rotate holder to specific position
Simply put your hand on the holder/bracket and move to the required position.
Two holders/brackets on the same side of the washer can be used together to store
the power cord/hose.
To tidy the power cord/hose quickly .
Rotate two holders so that raised lever can point outward at the same time. At this
moment, it will prevent power cord/hose from slipping off.
To remove the power cord/hose quickly.
Rotate two holders so that the raised lever can point inward at the same time.
At this moment, it allows the user to remove the power cord/hose easily off the
holder freely, which could save a lot of efforts.
In order to address it clearly. here take one holder as an
example .and rotate it clockwise.
Fig.16-1
Fig.16-2
To remove the power cord/hose
Rremove the
power
cord/hose
YF2200BL.indd 14 15-4-30 ��2:28
15
OPERATING INSTRUCTIONS
Connect to electrical main supply
As shown in Fig. 17
DANGER! Before you connect the pressure washer to the power source make
sure that the data on the rating plate are identical to the mains data.
If possible, do not use extension cords with this pressure washer; however, if you
must use one, it must comply with requirement mentioned in section of “IMPORTANT
SAFETY INSTRUCTIONS:
Insert the power cord into the socket.
Switch on/off
CAUTION! Put the high-pressure washer on a smooth ground. Stand in a secure and
stable position.
WARNING! Before switching on, ensure you have completely assembled the
high-pressure washer and connected all connections.
Fig.17 Fig.18
To switch on
As shown in Fig. 18 & 19
You should maintain the correct operating position every time you start the pressure
washer by placing one hand on the trigger handle handle and the other on the wand.
YF2200BL.indd 15 15-4-30 ��2:28
16
Fig.19
Fig.20
CAUTION!
Before switching on, first purge pump by squeezing trigger handle
for around 5 seconds.
To switch the pressure washer on, set the On/Off switch to ON.
1. Unlock the safety trigger lever on the spray gun, and press the trigger lever until
there is a steady stream of water.
CAUTION!
This pressure washer is equipped with SOFT START FUNCTION,
which controlled by software. After switching on for 10 seconds, the motor will
reach to the rated operating speed.
To temporarily switch off
Release the trigger lever, at this point the equipment goes to standby. As soon as
you press the trigger lever again, the equipment restarts.
To completely switch off
As shown in Fig. 20
1. Release the trigger lever, and replace the safety lock.
2. To switch the pressure washer off, set the On/Off switch to OFF.
3. Close the water inlet valve.
CAUTION ! After releasing the trigger for 10 seconds, the motor can be
completely stopped, due to this pressure washer is soft stop function which
controlled by software.
YF2200BL.indd 16 15-4-30 ��2:28
17
CAUTION ! Risk of pressure washer damage!
Never operate the pressure washer without water inlet as dry running may damage
the pump.
Use a water filter if the inlet water is contaminated.
To temporarily store the spray gun
As shown in Fig. 21
When fixing the handle to operating position, this pressure washer provides gun
holder on right side. Which consist of three pieces power cord/hose/gun holder. It
allows to temporarily rest the spray gun on it.
Working with the electric high-pressure washer risk of fatal injury!
Use special care when cleaning tires. Vehicle tires/tire valves may become damaged
or burst when handled improperly. First signs of damage included discolorations on
the tire.
Damaged vehicle tires/tire valves pose a life-threatening risk. Keep the jet at a
distance of at least 12 inches!
Fig.21
Risk of fatal injury!
The high-pressure jet may be dangerous when handled improperly. The jet may not
be directed towards living beings (persons, animals), live-equipment or the pressure
washer itself.
To operate trigger handle and wand
Hold the handheld spray gun and the jet tube firmly with both hands. Be aware of the
recoil when switching on the high-pressure jet.
Unlock the safety button and press the trigger on the handheld spray gun.
YF2200BL.indd 17 15-4-30 ��2:28
18
The high-pressure pump starts running as soon as you operate the hand-held
spray gun. Due to the soft start function, after switching on for 10 seconds, the motor
will reach to the rated operating speed.
After releasing the trigger for 10 seconds, the motor can be completely stopped, due
to this pressure washer is soft stop function which controlled by software.
Use the detergent bottle (not supplied)
As shown in Fig. 22
1. Stop the pressure washer.
2. Add detergent to the bottle (not supplied). Gently pull the detergent intake hose
out, and put the end of detergent intake hose into the bottle. Make sure the end of
the hose can reach the bottom of the detergent bottle.
NOTE: Put the detergent bottle nearby the pressure washer, there is no specific
detergent bottle storage location on the pressure washer.
3. Insert soap nozzle, and turn the pressure regulator for the best results.
4. When you have finished using the detergent injection system, fill detergent bottle
with clean water. Siphon water by using soap tip for one minute, so that all detergent
is flushed through system. Remove detergent bottle, and rinse it thoroughly.
Fig.22
YF2200BL.indd 18 15-4-30 ��2:28
19
CLEANING AND MAINTENANCE
Clean the outside of high-pressure washer
Clean the pressure washer. Wipe the washer with a slightly damp cloth. Do not clean
the pressure washer using a high-pressure water jet.
Clean the water filter
As shown in Fig. 23
The pressure washer is equipped with a water filter to protect the pump. If the filter is
not kept clean, the water flow to the pressure washer will be restricted and the pump
may be damaged.
To clean water inlet filter,
1. remove the water inlet filter inside the inlet adaptor.
2. Rinse water inlet filter until it is free of debris and blockage.
3. Place water inlet filter back in position to prevent any foreign matter from entering
the pump.
Clean the spray nozzles
Clean the high-pressure spray nozzles.
As shown in Fig. 24
Maintenance
The pressure washer has no user serviceable parts.
Fig.23
Fig.24
YF2200BL.indd 19 15-4-30 ��2:28
20
MOVING AND STORAGE INSTRUCTIONS
CAUTION!
Before servicing, cleaning, or removal of any part, switch off power and relieve
pressure.
STORAGE
As shown in Fig. 25 & 26
1. Remove the cleaning agent and drain all the water left in the hoses.
2. Clean the high-pressure washer.
3. Fold the handle.
4. Tidy the hose and power cord by winding them around the power cord/hose/gun
holder, located on the metal support.
5. Store the pressure washer where it is dry and well ventilated, when placing the
pressure washer out of service for short period of time.
6. To store the pressure washer for long period of time.
The storage method is the same as above mentioned. In addition, store the pressure
washer by using the original package as much as you can.
Moving
If shipping, use the original packaging whenever possible.
Fig.25
Fig.26
Tidy the power cord
YF2200BL.indd 20 15-4-30 ��2:28
21
DISPOSAL
TROUBLESHOOTING
Disposing of the pressure washer
Pressure washers which are labeled with the adjacent symbol must not be disposed
of in household garbage. You must dispose of such old electrical and electronic
appliances separately. Please check with your local authority about the possibilities
for correct disposal. Through separate disposal you send old equipment for recycling
or for other forms of re-use. You will thus help to avoid in some cases that damaging
material gets into the environment.
Disposing of the packaging
The packaging consists of cardboard and correspondingly marked sheets that can
be recycled. Make these materials available for recycling.
CAUTION!
Before servicing, cleaning, or removal of any part, switch off power and relieve
pressure.
CAUTION!
Improper repairs can result in the pressure washer functioning unsafely. This
endangers yourself and your environment.
Faults which cannot be rectified with the aid of following table may be rectified by a
specialist company only (customer service center).
Please be aware that any improper repairs will also invalidate the warranty and
additional costs may be incurred.
Use only genuine spare parts. Only these spare parts are designed and suitable for
the pressure washer. The use of other spare parts not only voids the warranty, but
can also endanger yourself and your environment.
YF2200BL.indd 21 15-4-30 ��2:28
22
Fault/malfunction Cause Remedy
Pressure washers does not
work
No electrical voltage at the
device
Check the fuse, power cord,
power plug and power source
and have them replaced by
qualified personnel if necessary
On/off switch set to "0" On/off switch set to "I"
Cross section of the extension
cord no large enough and/or the
extension cord is too long
Use extension cord with lager
cross sections and/or use
shorter extension cords
Extension cord damaged Try without extension cord
The protector on the PCB has
activated
Switch off the Pressure washer
and pull the plug out from the
power source, then restart the
Pressure washer
The mains voltage is lower than
that specified
Contact the power supply
company if necessary
The pump is frozen Check and thaw if necessary
Pressure too low, but steady
Wrong spray tips was selected Change to right spray nozzles
Hight-pressure hose are
damaged or leaks in the
connection
Change the hight-pressure
hose or hand-tighten the screw
connection
Leaks in the Pressure washer
Leaks from the pump or internal
connections
Consult customer service
Hose connections loose Hand-tighten the water intake
adapter and the high-pressure
hose screw connection
Irregular operating pressure
Air intake in the water inlet Check the supply hose and
hose connection and replace if
necessary
The water filter is clogged Clean the water filter
Water supply hoses squeezed Straighten out kinked water
supply hoses
Inadequate water supply Check the water supply
The high-pressure washer
operates intermittently
Power cord is damaged Consult customer service
Internal loose electrical
connection
Consult customer service
On/Off switch defective Consult customer service
YF2200BL.indd 22 15-4-30 ��2:28
23
The motor starts but there is no
buildup of pressure
The water filter is clogged Clean the water filter
Air intake in the water inlet Check the supply hose and
hose connection and replace if
necessary
Air in the system Ventilate the pressure washer!
Run the pressure washer
without the pressure washer
hose connected until water
starts leaking without bubbles.
Re-attach the high-pressure
hose.
Spray tips partly blocked Clean spray nozzles
No detergent taken in
Detergent too dense Dilute with water
Deposits or restriction in
detergent circuit
Flush with clean water and
eliminate any restrictions
YF2200BL.indd 23 15-4-30 ��2:28
24
WARRANTY
Product Warranty
Please keep your original purchase receipt in a safe place as proof of purchase.
Warranty coverage for this product must be verified by the original purchase receipt.
The warranty period begins on the day that the product was purchased from an
authorized retailer of Yard Force products. Warranty coverage only applies to the
original purchaser and is not transferrable. Warranty coverage is only provided on
products purchased and used in the USA from authorized Yard Force retailers.
Products purchased or used outside of the USA are not covered by this warranty.
(2) Two-Year Warranty – Pump and Motor
The YF2200BL has a 2-Year Limited Warranty from the date of purchase against
manufacturer defects for residential use only. Commercial use voids the warranty.
This warranty does not cover accidental damage, unreasonable use, normal wear
and tear, neglect or non-compliance with the Operating, Safety and Maintenance
Instructions. All service, outside of normal maintenance as described in this manual,
must be done by an authorized service technician. Any unauthorized service or
changes to the original configuration of this product will void the warranty. All
parts and accessories used on and with this product must be manufacturer/or and
authorized by SUMEC North America.
(90) Ninety-Day Warranty – Accessories
The accessories included with the YF2200BL; including hose, trigger handle and
wand, and other similar parts are warranted against manufacturer defects for
residential use only for a period of 90 days from date of purchase.
Warranty does not cover loss of use or other consequential damages arising from any
of the above, nor does it cover repairs made or attempted by unauthorized persons.
This warranty is void if the product is used for commercial, rental or industrial
purposes. Certain parts, attachments and accessories are subject to normal wear
and tear and are excluded from the warranty.
Service and Warranty Claims Process
Contact the Yard Force Support Center toll-free at (866) 902-9690 Monday-Friday
between 8:30 AM and 5:00 PM Eastern Time for service and warranty support.
YF2200BL.indd 24 15-4-30 ��2:28
25
Yard Force USA Service Support agents can help you troubleshoot problems over
the phone to get you back up and running as quickly as possible. In the situation
where service or warranty inspection is needed, please follow these steps:
1. Contact Yard Force USA at (866) 902-9690 Monday-Friday between 8:30 AM and
5:00 PM Eastern Time.
2. Send in proof-of-purchase and serial number (if applicable) to confirm warranty
coverage.
3. If service or a warranty evaluation is requested, Yard Force USA will provide an
RGA number that should be used in all communications with Yard Force USA and is
required to be indicated on the product itself and on the outside of the box.
4. All shipments to Yard Force USA must have an RGA number. Any shipment
received that does not have an RGA number clearly marked on the outside of the
box will be refused.
5. All shipments must be sent pre-paid, Yard Force USA does not pay for any
shipping costs for service or warranty evaluation. Yard Force USA is not responsible
for any packages that are lost by carrier. We recommend that shipments are made
by a carrier that provides tracking and delivery confirmation.
For more information or to ask questions, please call toll-free (866) 902-9690
Monday-Friday between
8:30 AM and 5:00 PM Eastern Time.
SAVE THESE INSTRUCTIONS
YF2200BL.indd 25 15-4-30 ��2:28
