BD350C
As an ENERGY STAR
®
Partner, LG
has determined that this product
or product models meet the
ENERGY STAR
®
guidelines for
energy efficiency.
ENERGY STAR
®
is a U.S. registered mark.
ENGLISH
http://www.lg.ca
P/No. : MFL62745202
For questions
about
this product,
please call.
11--888888--554422--22662233
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 1
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufficient magni-
tude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance (ser-
vicing) instructions in the literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: Do not install this equipment in a confined space such as a book
case or similar unit.
CAUTION: Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
Slots and openings in the cabinet are provided for ventilation and to ensure
reliable operation of the product and to protect it from over heating. The
openings shall be never be blocked by placing the product on a bed, sofa, rug
or other similar surface. This product shall not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is provided or the
manufacturer's instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully
and retain it for future reference. Shall the unit require maintenance, contact an
authorized service centre.
Use of controls, adjustments or the performance of procedures other than those
specified herein may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible laser radiation when open. DO NOT STARE INTO BEAM.
CAUTION: The apparatus shall not be exposed to water (dripping or splashing)
and no objects filled with liquids, such as vases, shall be placed on the appara-
tus.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a dedicated circuit;
That is, a single outlet circuit which powers only that appliance and has no
additional outlets or branch circuits. Check the specification page of this owner's
manual to be certain. Do not overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically examine the cord of your
appliance, and if its appearance indicates damage or deterioration, unplug it,
discontinue use of the appliance, and have the cord replaced with an exact
replacement part by an authorized service centre. Protect the power cord from
physical or mechanical abuse, such as being twisted, kinked, pinched, closed in
a door, or walked upon. Pay particular attention to plugs, wall outlets, and the
point where the cord exits the appliance. To disconnect power from the mains,
pull out the mains cord plug. When installing the product, ensure that the plug is
easily accessible.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 2
Notes on Copyrights
Because AACS (Advanced Access Content System) is approved as content
protection system for BD format, similar to use of CSS (Content Scramble
System) for DVD format, certain restrictions are imposed on playback, analog
signal output, etc., of AACS protected contents. The operation of this product
and restrictions on this product may vary depending on your time of purchase
as those restrictions may be adopted and/or changed by AACS after the
production of this product.
Furthermore, BD-ROM Mark and BD+ are additionally used as content
protection systems for BD format, which imposes certain restrictions including
playback restrictions for BD-ROM Mark and/or BD+ protected contents. To
obtain additional information on AACS, BD-ROM Mark, BD+, or this product,
please contact an authorized Customer Service Centre.
Many BD-ROM/DVD discs are encoded with copy protection. Because of
this, you should only connect your player directly to your TV, not to a VCR.
Connecting to a VCR results in a distorted picture from copy-protected discs.
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright
protection technology must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise authorized by
Macrovision. Reverse engineering or disassembly is prohibited.
Under the U.S. Copyright laws and Copyright laws of other countries,
unauthorized recording, use, display, distribution, or revision of television
programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may
subject you to civil and/or criminal liability.
Licenses
Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States and other countries.
Manufactured under license from Dolby Laboratories. Dolby and the double-D
symbol are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,392,195; 7,272,567; 7,333,929;
7,212,872 & other U.S. and worldwide patents issued & pending. DTS is
a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD
Master Audio I Essential are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All
Rights Reserved.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI licensing LLC.
“DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation.
“
x.v.Colour” is a trademark of Sony Corporation.
“Blu-ray Disc” is a trademark.
“BONUSVIEW” is trademark of Blu-ray Disc Association.
This product is licensed under the AVC patent portfolio license and VC-1 patent
portfolio license for the personal and non-commercial use of a consumer to (i)
encode video in compliance with the AVC Standard and VC-1 Standard
(“AVC/VC-1 Video”) and/or (ii) decode AVC/VC-1 Video that was encoded by a
consumer engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed to provide AVC/VC-1 Video. No license
is granted or shall be implied for any other use. Additional information may be
obtained from MPEG LA, LLC. See http://www.mpegla.com.
“AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and
Sony Corporation.
3
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 3
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provid-
ed plug does not fit into your outlet, consult an electrician for replace-
ment of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Important Safety Instructions
4
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 4
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-9
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Connections to your TV . . . . . . . . . . . . . . . . . . . . . . . . . .13-14
Connecting to an Amplifier . . . . . . . . . . . . . . . . . . . . . . .14-15
The unit’s Audio Output Specifications . . . . . . . . . . . . . . . . .16
Resolution Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-17
Using a USB Flash Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Using the Home Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Adjust the Setup settings . . . . . . . . . . . . . . . . . . . . . . . .19-23
Play a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24-26
Displaying disc Information . . . . . . . . . . . . . . . . . . . . . . . . . .27
Playing a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Listening to music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Viewing a photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30-31
Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Language Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Area Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Open source software notice . . . . . . . . . . . . . . . . . . . . . . . .36
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and completely.
5
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 5
Introduction
To ensure proper use of this product, please read this owner’s manual
carefully and retain for future reference.
This manual provides information on the operation and maintenance of
your player. Should the unit require service, contact an authorized service
location.
About the Symbol Display
“ “ may appear on your TV display during operation and indicates that
the function explained in this owner’s manual is not available on that spe-
cific media.
Symbols Used in this Manual
Note:
Indicates special notes and operating features.
Tip:
Indicates tips and hints for making the task easier.
A section whose title has one of the following symbols are applicable only
to the disc represented by the symbol.
All discs listed below
BD-ROM disc
DVD-Video, DVD±R/RW in Video mode or VR
mode and finalized
DVD±R/RW in AVCHD format
Movie files contained in the USB/Disc
Audio CDs
Music files contained in the USB/Disc
Handling the Unit
When shipping the unit
Please save the original shipping carton and packing materials. If you need
to ship the unit, for maximum protection, re-pack the unit as it was
originally packed at the factory.
Keeping the exterior surfaces clean
Do not use volatile liquids such as insecticide spray near the unit.
Wiping with strong pressure may damage the surface.
Do not leave rubber or plastic products in contact with the unit for a long
period of time.
Cleaning the unit
To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty,
use a soft cloth lightly moistened with a mild detergent solution.
Do not use strong solvents such as alcohol, benzine, or thinner, as these
might damage the surface of the unit.
Maintaining the Unit
The unit is a high-tech, precision device. If the optical pick-up lens and disc
drive parts are dirty or worn, the picture quality could be diminished.
For details, please contact your nearest authorized service centre.
Notes on Discs
Handling Discs
Do not touch the playback side of the disc. Hold the disc by the edges so
that fingerprints do not get on the surface. Never stick paper or tape on the
disc.
Storing Discs
After playing, store the disc in its case. Do not expose the disc to direct
sunlight or sources of heat and never leave it in a parked car exposed to
direct sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality and sound
distortion. Before playing, clean the disc with a clean cloth. Wipe the disc
from the centre out.
Do not use strong solvents such as alcohol, benzine, thinner, commercially
available cleaners, or anti-static spray intended for older vinyl records.
MUSIC
ACD
MOVIE
AVCHD
DVD
BD
ALL
6
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 6
Playable Discs
Blu-ray Disc
- Discs such as movies that can be purchased or rented
- BD-R/RE discs that contain audio titles, Movie, Music or Photo
files.
DVD-VIDEO (8 cm / 12 cm disc)
Discs such as movies that can be purchased or rented
DVD-R (8 cm / 12 cm disc)
-Video mode and finalized only
- Supports the dual layer disc also
-AVCHD format
- DVD-R discs that contain audio titles, Movie, Music or Photo
files.
DVD-RW (8 cm / 12 cm disc)
- VR mode, Video mode and finalized only
-AVCHD format
- DVD-RW discs that contain audio titles, Movie, Music or Photo
files.
DVD+R (8 cm / 12 cm disc)
- Finalized disc only
- Supports the dual layer disc also
-AVCHD format
- DVD+R discs that contain audio titles, Movie, Music, or Photo
files.
DVD+RW (8 cm / 12 cm disc)
-Video mode and finalized only
-AVCHD format
- DVD+RW discs that contain audio titles, Movie, Music or Photo
files.
Audio CD (8 cm / 12 cm disc)
Audio CDs or CD-Rs/CD-RWs in audio CD format that can be
purchased
CD-R/CD-RW (8 cm / 12 cm disc)
CD-R/CD-RW discs that contain audio titles, Movie, Music or Photo
files.
Notes:
Depending on the conditions of the recording equipment or the
CD-R/RW (or DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW)
discs cannot be played on the unit.
Do not attach any seal or label to either side (the labeled side or the
recorded side) of a disc.
Do not use irregularly shaped CDs (e.g., heart-shaped or octagonal).
Doing so may result in malfunctions.
Depending on the recording software & the finalization, some recorded
discs (CD-R/RW or DVD±R/RW) may not be playable.
DVD±R/RW and CD-R/RW discs recorded using a personal computer or
a DVD or CD Recorder may not play if the disc is damaged or dirty, or if
there is dirt or condensation on the player’s lens.
If you record a disc using a personal computer, even if it is recorded in a
compatible format, there are cases in which it may not play because of
the settings of the application software used to create the disc. (Check
with the software publisher for more detailed information.)
This player requires discs and recordings to meet certain technical stan-
dards in order to achieve optimal playback quality. Pre-recorded DVDs
are automatically set to these standards. There are many different types
of recordable disc formats (including CD-R containing MP3 or WMA
files) and these require certain pre-existing conditions to ensure compat-
ible playback.
Customers should note that permission is required in order to download
MP3 / WMA files and music from the Internet. Our company has no right
to grant such permission. Permission should always be sought from the
copyright owner.
7
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 7
BD-ROM Disc Features
BD-ROM Discs can store 25 GB (single layer) or 50 GB (dual layer) on a
single sided disc - about 5 to 10 times the capacity of a DVD.
BD-ROM Discs also support the highest quality HD video available in the
industry (up to 1920 x 1080) - Large capacity means no compromise on
video quality. Furthermore, a BD-ROM disc has the same familiar size and
look as DVD.
• The following BD-ROM disc features are disc dependent and will vary.
• Appearance and navigation of features will also vary from disc to disc.
• Not all discs will have the features described below.
• BD-ROM, Hybrid disc have both BD-ROM and DVD (or CD) layers on
one side. On such discs, BD-ROM layer will be only played back in this
player.
Video highlights
The BD-ROM format for movie distribution supports three highly advanced
video codecs, including MPEG-2, MPEG4 AVC (H.264), and SMPTE VC1.
HD video resolutions are also available:
• 1920 x 1080 HD
• 1280 x 720 HD
Graphic planes
Two individual, full HD resolution (1920 x 1080) graphic planes (layers) are
available, on top of the HD video layer. One plane is assigned to video-
related, frame accurate graphics (like subtitles), and the other plane is
assigned to interactive graphic elements, such as buttons or menus.
For both planes, various wipes, fades and scroll effects may be available.
For High-Definition Playback
To view high-definition contents from BD-ROM discs, an HDTV is required.
Some discs may require HDMI OUT for viewing of high-definition contents.
Ability to view high-definition contents in BD-ROM discs may be limited
depending on the resolution of your TV.
Menu sounds
When you highlight or select a menu option, sounds can be heard such as
button clicks or a voice-over explaining the highlighted menu choice.
Multi-page/PopUp Menus
With DVD-Video, playback is interrupted each time a new menu screen is
accessed. Due to BD-ROM disc’s ability to preload data from the disc with-
out interrupting playback, a menu can consist of several pages.
You can browse through the menu pages or select different menu paths,
while the audio and video remain playing in the background.
Interactivity
Certain BD-ROM Discs may contain animated menus and/or trivia games.
User Browsable Slideshows
With BD-ROM Discs, you can browse through various still pictures while
the audio remains playing.
Subtitles
Depending on what is contained on the BD-ROM disc, you may be able to
select different font styles, sizes and colours for some subtitles. Subtitles
may also be animated, scrolled or faded in and out.
BD-J Interactive Capability
The BD-ROM format supports Java for interactive functions. “BD-J” offers
content providers almost unlimited functionality when creating interactive
BD-ROM titles.
BD-ROM Disc Compatibility
This player supports BD-ROM Profile 1.1.
• Discs supporting BONUSVIEW (BD-ROM version 1.1 Profile 1 version
1.1/Final Standard Profile) that allows Virtual packages or Picture-in-
Picture functions to be used.
8
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 8
Regional Code
This unit has a regional code printed on the rear of the unit. This unit can
play only BD-ROM or DVD discs labeled same as the rear of the unit or
“ALL”.
AVCHD (Advanced Video Codec High Definition)
• This player can playback AVCHD format discs. These discs are normally
recorded and used in camcorders.
• The AVCHD format is a high definition digital video camera format.
• The MPEG-4 AVC/H.264 format is capable of compressing images at
higher efficiency than that of the conventional image compressing
format.
• Some AVCHD discs use the “x.v.Colour” format.
• This player can playback AVCHD discs using “x.v.Colour” format.
• Some AVCHD format discs may not play, depending on the recording
condition.
•AVCHD format discs need to be finalized.
• “x.v.Colour” offers a wider colour range than normal DVD camcorder
discs.
Compatibility Notes
• Because BD-ROM is a new format, certain disc, digital connection and
other compatibility issues are possible. If you experience compatibility
problems, please contact an authorized Customer Service Centre.
•Viewing high-definition content and up-converting standard DVD content
may require a HDMI-capable input or HDCP-capable DVI input on your
display device.
• Some BD-ROM and DVD discs may restrict the use of some operation
commands or features.
• Dolby TrueHD, Dolby Digital Plus and DTS-HD are supported with maxi-
mum 7.1 channels if you use HDMI connection for the audio output of
the unit.
•You can use a USB Flash Drive that is used to store some disc related
information, including downloaded on-line content. The disc you are
using will control how long this information is retained.
Certain System Requirements
For high definition video playback:
• High definition display that has HDMI input jacks.
• BD-ROM disc with high definition content.
• HDMI or HDCP capable DVI input on your display device is required for
some content (as specified by disc authors).
• For up-conversion of standard definition DVD, a HDMI or HDCP capable
DVI input on your display device is required for copy protected content.
For Dolby
®
Digital Plus, Dolby TrueHD and DTS-HD multi-channel audio
playback:
• An amplifier/receiver with a built-in (Dolby Digital, Dolby Digital Plus,
Dolby TrueHD, DTS or DTS-HD) decoder.
• Main, center, surround speakers and subwoofer as necessary for
chosen format.
9
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 9
Remote control
a
POWER (1): Switches the player ON or OFF.
0-9 numerical buttons: Select numbered options in a
menu.
RESOLUTION: Sets the output resolution for HDMI
jacks.
OPEN/CLOSE (Z): Opens and closes the disc tray.
TV Control Buttons: See page 32.
CLEAR: Removes a mark on the search menu or a
number when setting the password.
b
SCAN (m / M): Searches backward or forward.
SKIP (. / >): Go to next or previous chapter /
track / file.
PAUSE (X): Pauses playback.
PLAY (N): Starts playback.
STOP (x): Stops playback.
c
HOME: Displays or exits the [Home Menu].
DISC MENU: Accesses menu on a disc.
RETURN (O): Exits the menu or resumes playback.
The resume play function may work depending on the
BD-ROM disc.
DISPLAY: Displays or exits On-Screen Display.
Direction buttons: Selects an option in the menu.
ENTER ( ): Acknowledges menu selection.
AUDIO ( ): Selects an audio language or audio
channel.
SUBTITLE ( ): Selects a subtitle language.
SUBTITLE-ON/OFF: Switches the subtitle on or off.
TITLE/POP-UP: Displays the DVD title menu or
BD-ROM’s popup menu, if available.
d
Coloured (A, B, C, D) buttons: Use to navigate
BD-ROM menus. They are also used for [MOVIE],
[PHOTO] and [MUSIC] menu.
MARKER: Marks any point during playback.
SEARCH: Displays or exits the search menu.
REPEAT: Repeat a desired section or sequence.
ZOOM: Displays or exits the [Zoom] menu.
Remote Control Operation
Point the Remote Control at the remote sensor and
press the buttons.
Remote Control Battery Installation
Remove the battery cover on the rear of the Remote
Control, and insert a R03 (size AAA) battery with and
matched correctly.
a
b
c
d
10
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 10
a Disc Tray
Insert a disc here.
b Z (OPEN/CLOSE)
Opens or closes the disc tray.
c
11
(POWER)
Switches the unit ON or OFF.
d Display Window
Shows the current status of the player.
e Remote Sensor
Point the remote control here.
f N / X (PLAY / PAUSE)
Starts playback.
Pause playback temporarily,
press again to exit pause mode.
g x (STOP)
Stops playback.
h . / > (SKIP)
Go to next or previous file/track/chapter.
i USB Port
Connect a USB Flash Drive.
Front panel
abcdefghi
11
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 11
a AC Power Cord
Connect to a power source.
b HDMI OUT (1080p)
Connect to TV with HDMI inputs. (Interface for digital audio and video)
c VIDEO OUT
Connect to a TV with video inputs.
d 2CH AUDIO OUT (Left/Right)
Connect to a TV with 2 channel audio inputs.
e DIGITAL AUDIO OUT (COAXIAL)
Connect to digital (coaxial) audio equipment.
Rear panel
1080p
DIGITAL
AUDIO OUT
abcde
12
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 12
Connections to your TV
Make one of the following connections, depending on the capabilities of
your existing equipment.
Tips:
• Depending on your TV and other equipment you wish to connect, there
are various ways you could connect the player. Use only one of the con-
nections described below.
• Please refer to the manuals of your TV, Stereo System or other devices
as necessary to make the best connections.
Cautions:
• Make sure the player is connected directly to the TV. Tune the TV to the
correct video input channel.
• Do not connect the player’s AUDIO OUT jack to the phono in jack
(record player) of your audio system.
• Do not connect your player via your VCR. The image could be distorted
by the copy protection system.
HDMI Connection
If you have a HDMI TV or monitor, you can connect it to this player using a
HDMI cable.
Connect the HDMI OUT jack on the player to the HDMI IN jack on a HDMI
compatible TV or monitor (H).
Set the TV’s source to HDMI (refer to TV’s Owner’s manual).
Note:
If a connected HDMI device does not accept the audio output of the unit,
the HDMI device’s audio sound may be distorted or may not output.
Tips:
• When you use HDMI connection, you can change the resolution for the
HDMI output. (Refer to “Resolution Setting” on page 16-17.)
• Select the type of video output from the HDMI OUT jack using
[HDMI Color Setting] option on the [Setup] menu (see page 20).
Cautions:
• Changing the resolution when the connection has already been estab-
lished may result in malfunctions. To solve the problem, turn off the play-
er and then turn it on again.
• When the HDMI connection with HDCP is not verified, TV screen is
changed to black screen. In this case, check the HDMI connection, or
disconnect the HDMI cable.
• If there is noise or lines on the screen, please check the HDMI cable
(length is generally limited to 15 ft.).
Additional Information for HDMI
• When you connect a HDMI or DVI compatible device make sure of the
following:
-Try switching off the HDMI/DVI device and this player. Next, switch on
the HDMI/DVI device and leave it for around 30 seconds, then switch
on this player.
- The connected device’s video input is set correctly for this unit.
- The connected device is compatible with 720x480p, 1280x720p,
1920x1080i or 1920x1080p video input.
• Not all HDCP-compatible HDMI or DVI devices will work with this player.
- The picture will not be displayed properly with non-HDCP device.
- This player does not playback and TV screen is changed to black
screen.
1080p
DIGITAL
AUDIO OUT
H
1080p
DIGITAL
AUDIO OUT
BD player
TV
13
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 13
Video/Audio (Left/Right) Connection
Connect the VIDEO OUT jack on the player to the video in jack on the TV
using a video cable (V).
Connect the left and right AUDIO OUT jacks of the player to the audio left
and right IN jacks on the TV using the audio cables (A).
Connecting to an Amplifier
Make one of the following connections, depending on the capabilities of
your existing equipment.
Note:
Since many factors affect the type of audio output, see “The unit’s Audio
Output Specifications” on page 16 for details.
Connecting to an Amplifier via 2 Channel Audio Output
Connect the Left and Right 2CH AUDIO OUT jacks on the player to the
audio left and right in jacks on your amplifier, receiver, or stereo system,
using audio cables (A).
Connecting to an Amplifier via Digital Audio Output
(Coaxial)
Connect the player’s DIGITAL AUDIO OUT jack to the corresponding in
jack (COAXIAL X) on your amplifier. Use an optional digital (coaxial X)
audio cable. You will need to activate the player’s digital output. (See
“[AUDIO] Menu” on pages 21-22.)
V
A
BD player
TV
X
A
BD player
Amplifier/Receiver
14
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 14
Connecting to an Amplifier via HDMI Output
Connect the player’s HDMI OUT jack to the corresponding in jack on your
amplifier. Use a HDMI cable (H1). You will need to activate the player’s
digital output. (See “[AUDIO] Menu” on pages 21-22.)
Digital Multi-channel sound
A digital multi-channel connection provides the best sound quality. For this
you need a multi-channel Audio/Video Receiver that supports one or more
of the audio formats supported by your player. Check the receiver manual
and the logos on the front of the receiver. (PCM Stereo, PCM Multi-Ch,
Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS and/or DTS-HD)
Tip:
Connect the amplifier’s HDMI output jack to HDMI input jack on your TV
using a HDMI cable (H2) if your amplifier has HDMI output jack.
Notes:
•You must select a digital audio output and a maximum sampling
frequency that your Amplifier (or AV receiver) accepts using [SPDIF],
[HDMI] and [Sampling Freq.] options on the [Setup] menu
(see page 21-22).
•With digital audio connection (SPDIF or HDMI), Disc Menu button
sounds of BD-ROM may not be heard if the [SPDIF] or [HDMI] option is
set to [Primary Pass-Thru].
• If the audio format of the digital output does not match the capabilities of
your receiver, the receiver will produce a strong, distorted sound or no
sound at all.
• Multi-channel Digital Surround Sound via digital connection can only be
obtained if your receiver is equipped with a Digital Multi-channel
decoder.
•To see the audio format of the current disc in the on-screen display,
press AUDIO.
H2
H1
BD player
Amplifier/Receiver
TV
15
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 15
Notes:
*1 The secondary and interactive audio may not be included in the output
bitstream if [SPDIF] or [HDMI] option is set to [Primary Pass-Thru].
(Except LPCM Codec : the output always include interactive and
secondary audio.)
*2 This player automatically selects the HDMI audio according to the
decoding capability of the connected HDMI device even though [HDMI]
option is set to [Primary Pass-Thru].
*3 The [PCM Multi-CH]/[Primary Pass-Thru] setting of the [HDMI] option
and [DTS re-encode] setting of the [SPDIF] option cannot be set
together. If you set the [HDMI] option to [PCM Multi-CH] or
[Primary Pass-Thru], the [SPDIF] option is set to [PCM Stereo]
automatically. Also, if you set the [SPDIF] option to [DTS Re-encode],
the [HDMI] option is set to [PCM Stereo] automatically.
*4 The LPCM audio recorded at 192kHz sampling frequency will be
outputted as stereo sound.
*5 On the PCM audio output, the sampling frequency of SPDIF (DIGITAL
AUDIO OUT) is limited to 96 kHz.
*6 If the [HDMI] or [SPDIF] option is set to [DTS re-encode], the audio
output is limited to 48 kHz and 5.1 ch. If the [HDMI] or [SPDIF] option
is set to [DTS re-encode], the DTS Re-encode audio is outputted for
BD-ROM discs, and the original audio is outputted for the other discs
(like [Primary Pass-Thru]).
• If [HDMI] option is set to [PCM Multi-CH] and [SPDIF] option is set to
[Primary Pass-Thru] when the unit plays back Dolby Digital Plus or
TrueHD audio, SPDIF (DIGITAL AUDIO OUT) jack is limited to “PCM
2ch”.
• If the HDMI connection is version 1.3 and Dolby Digital Plus/Dolby
TrueHD is outputted from HDMI OUT jack, SPDIF (DIGITAL AUDIO
OUT) jack is limited to “PCM 2ch” (When the HDMI and SPDIF are
connected simultaneously).
• The audio is outputted as PCM 48 kHz/16 bit for MP3/WMA file and
PCM 44.1kHz/16 bit for Audio CD while playback.
• The Dolby TrueHD audio recorded on some Blu-ray discs consists of
Dolby Digital and TrueHD audio. Dolby Digital audio is output through
DIGITAL AUDIO OUT jacks and "DD" displays on the screen if TrueHD
audio is not output (for example, when [HDMI] is set to [PCM Stereo]
and [SPDIF] is set to [Primary Pass-Thru]).
Resolution Setting
The player provides several output resolutions for HDMI OUT jacks.
You can change the resolution using [Setup] menu or pressing the
RESOLUTION button in stop mode.
SPDIF (DIGITAL AUDIO OUT) *
5
PCM DTS Primary
Source Stereo Re-encode *
3
*
6
Pass-Thru *
1
Dolby Digital PCM 2ch PCM 2ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch PCM 2ch DTS Dolby Digital
Dolby TrueHD PCM 2ch PCM 2ch DTS Dolby Digital
DTS PCM 2ch PCM 2ch DTS DTS
DTS-HD PCM 2ch PCM 2ch DTS DTS
Linear PCM 2ch PCM 2ch PCM 2ch DTS PCM 2ch
Linear PCM 5.1ch PCM 2ch PCM 2ch DTS PCM 2ch
Linear PCM 7.1ch PCM 2ch PCM 2ch DTS PCM 2ch
1
Analog Output
Stereo
Jack/
Setting
HDMI OUT
PCM PCM DTS Primary
Source Stereo Multi-Ch *
3
Re-encode *
6
Pass-Thru *
1
*
2
Dolby Digital PCM 2ch PCM 5.1ch DTS Dolby Digital
Dolby Digital Plus PCM 2ch PCM 7.1ch DTS Dolby Digital Plus
Dolby TrueHD PCM 2ch PCM 7.1ch DTS Dolby TrueHD
DTS PCM 2ch PCM 5.1ch DTS DTS
DTS-HD PCM 2ch PCM 7.1ch DTS DTS-HD
Linear PCM 2ch PCM 2ch PCM 2ch DTS PCM 2ch
Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS PCM 5.1ch
Linear PCM 7.1ch PCM 2ch PCM 7.1ch DTS PCM 7.1ch *
4
1
Jack/
Setting
The unit’s Audio Output Specifications
16
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 16
Note:
Since several factors affect the resolution of video output, see “Available
resolution according to the resolution setting”.
How to change the resolution using RESOLUTION
button
Press RESOLUTION repeatedly in stop mode to change the resolution.
The display window will show you the current resolution.
How to change the resolution using the [Setup] menu
1. Press HOME and the [Home Menu] appears.
2. Select the [Setup] and press ENTER. The [Setup] menu appears.
3. Use vVto select [DISPLAY] option then press B to move to the
second level.
4. Use vVto select the [Resolution] option then press B to move to the
third level.
5. Use vVto select the desired resolution then press ENTER to confirm
your selection.
Available resolution according to the resolution setting
Notes:
• Depending on your display, some of the resolution settings may result in
the picture disappearing or an abnormal picture appearing. In this case,
press HOME then RESOLUTION repeatedly until the picture re-appear.
• This player supports simultaneous output of all video out jacks. The
resolution of the HDMI output will not be the same as the resolution
output on the component video output.
HDMI OUT connection
• For the 480i resolution setting, real output resolution of HDMI OUT will
change to 480p.
• If you select a resolution manually and then connect the HDMI jack to
TV and your TV does not accept it, the resolution setting is set to [Auto].
• If you select a resolution that your TV does not accept, the warning
message will appear. After resolution change, if you cannot see the
screen, please wait 20 seconds and the resolution will automatically
revert back to the previous resolution.
• The 1080p video output frame rate may be automatically set to either
24Hz or 60Hz depending both on the capability and preference of the
connected TV and based on the native video frame rate of the content
on the BD-ROM disc.
VIDEO OUT connection
The resolution of the VIDEO OUT jack is always outputted at 480i
resolution.
• When the copy protected media is playing back
Video Output HDMI OUT
Resolution Setting
480i 480p
480p 480p
720p 720p
1080i 1080i
1080p / 24Hz 1080p / 24Hz
1080p / 60Hz 1080p / 60Hz
• When the non-copy protected media is playing back
Video Output HDMI OUT
Resolution Setting
480i 480p
480p 480p
720p 720p
1080i 1080i
1080p / 24Hz 1080p / 24Hz
1080p / 60Hz 1080p / 60Hz
17
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 17
Tip:
If you select the [Movie], [Photo] or [Music] option when a USB Flash Drive
is connected and a disc is inserted simultaneously, the menu for selecting
a media will appear. Select a media then press ENTER.
Insert/Remove a USB Flash Drive
Inserting a USB Flash Drive – Insert straight-in until it fits into place.
Removing a USB Flash Drive – Withdraw the USB Flash Drive
carefully.
Notes:
• This unit supports only USB Flash Drive with FAT16 or FAT32 format.
• Do not extract the USB Flash Drive during operation (play, etc.).
•AUSB Flash Drive which requires additional program installation when
you have connected it to a computer is not supported.
• USB Flash Drive: USB Flash Drive that support USB1.1 and USB2.0.
• Movie Files (DivX), Music files (MP3/WMA) and photo files (JPEG/PNG)
can be played. For details of operations on each file, refer to relevant
pages.
• Regular back up is recommended to prevent data loss.
• If you use a USB extension cable or USB HUB, the USB Flash Drive
may not be recognized.
• Some USB Flash Drives may not work with this unit.
• Digital camera and mobile phone are not supported.
• USB Port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
Using a USB Flash Drive
This unit can play the movie, music and photo
files contained on the USB Flash Drive.
ON REMOTE
1. Insert a USB Flash Drive to the USB port: –
2Displays the [Home Menu]: HOME
3 Select a main option:
bb BB
, ENTER
[Music], [Photo] or [Movie] option
4 Select the [USB] option:
bb BB
5 Displays corresponding menu list: ENTER
[MOVIE], [MUSIC] or [PHOTO] menu appears.
Details for the menu are on pages 28-31.
BD player
USB Flash Drive
18
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 18
[Movie] – Start video media’s playback or displays the [MOVIE] menu.
[Photo] – Displays [PHOTO] menu. (page 30-31)
[Music] – Displays [MUSIC ]menu. (page 29)
[Setup] – Displays the [Setup] menu. (page 19-23)
Tip:
If you select the [Movie], [Photo] or [Music] option when a USB Flash Drive
is connected and a disc is inserted simultaneously, the menu for
selecting a media will appear. Select a media then press ENTER.
Note:
The unit will be in stop mode then the [Home Menu] will appear if you
press HOME during playback.
Using the Home Menu
1Displays the [Home Menu]: HOME
2 Select an option:
bb BB
3Displays the selected option menu: ENTER
4 Exit the [Home Menu]: HOME
ON REMOTE
Adjust the Setup settings
1Displays the [Home Menu]: HOME
2 Select the [Setup] option:
bb BB
, ENTER
3 Select a desired option on the first level:
vv VV
4 Move to second level:
BB
5 Select a desired option on the second level:
vv VV
6 Move to third level:
BB
7 Adjust or confirm the setting:
vv VV
, ENTER
8 Go back to the previous level:
bb
9 Exit the [Setup] menu: HOME
ON REMOTE
First level
Second level
Third level
19
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 19
[DISPLAY] Menu
TV Aspect Ratio
[4:3 Letter Box] – Select when a standard 4:3 TV is connected.
Displays theatrical images with masking bars above and below the
picture.
[4:3 Pan Scan] – Select when a standard 4:3 TV is connected.
Displays pictures cropped to fill your TV screen. Both sides of the
picture are cut off.
[16:9 Original] – Select when a 16:9 wide TV is connected.
The 4:3 picture is displayed with an original 4:3 aspect ratio, with black
bars appearing at the left and right sides.
[16:9 Full] – Select when a 16:9 wide TV is connected.
The 4:3 picture is adjusted horizontally (in a linear proportion) to fill the
entire screen.
Note:
You cannot select [4:3 Letter Box] and [4:3 Pan Scan] option when the res-
olution is set to higher than 720p.
Resolution
Sets the output resolution of the HDMI video signal.
Refer to “Resolution Setting” on page 16-17 for details about the
resolution.
[Auto] – If the HDMI OUT jack is connected for TVs providing display
information (EDID), automatically selects the resolution best suited to
the connected TV.
[480i] – Outputs 480 lines of interlaced video.
[480p] – Outputs 480 lines progressive video.
[720p] – Outputs 720 lines of progressive video.
[1080i] – Outputs 1080 lines of interlaced video.
[1080p] – Outputs 1080 lines of progressive video.
1080p Display Mode
When the resolution is set to 1080p, select [24Hz] for smooth presentation
of film material (1080/24p) with a HDMI-equipped display compatible with
1080/24p input.
Notes:
• When you select [24Hz], you may experience some picture disturbance
when the video switches video and film material. In this case, select
[60Hz].
• Even when [1080p Display Mode] is set to [24Hz], if your TV is not
compatible with 1080/24p, the actual frame frequency of the video
output will be 60Hz to match the video source format.
• When the 1080p/24Hz video source is outputted via HDMI connection,
the VIDEO OUT will not output any video signal.
HDMI Color Setting
Select the type of output from the HDMI OUT jack. For this setting, please
refer to the manuals of your display device.
[YCbCr] – Select when connecting to a HDMI display device.
[RGB] – Select when connecting to a RGB display device.
20
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 20
[LANGUAGE] Menu
Display Menu
Select a language for the [Setup] menu and on-screen display.
Disc Menu / Disc Audio / Disc Subtitle
Select the language you prefer for the audio track (disc audio), subtitles,
and the disc menu.
[Original] – Refers to the original language in which the disc was
recorded.
[Other] – Press ENTER to select another language. Use number but-
tons then ENTER to enter the corresponding 4-digit number according
to the language code list on page 33.
[Off] (for Disc Subtitle) – Turn off Subtitle.
Note:
Depending on the disc, your language setting may not work for some
discs.
[AUDIO] Menu
Each disc has a variety of audio output options. Set the player’s Audio
options according to the type of audio system you use.
Note:
Since many factors affect the type of audio output, see “The unit’s Audio
Output Specifications” on page 16 for details.
HDMI / SPDIF (Digital Audio Output)
Select the output sound format when a device equipped with a HDMI or
Digital Audio input jack is connected to the HDMI OUT or DIGITAL AUDIO
OUT jack on this player.
[PCM Stereo] – Select if you connect this unit’s HDMI OUT or
DIGITAL AUDIO OUT jack to a device with two-channel digital stereo
decoder.
[PCM Multi-Ch] (HDMI only) – Select if you connect this unit’s
HDMI OUT jack to a device with multi-channel digital decoder.
[DTS Re-Encode] – Select if you connect this unit’s HDMI OUT or
DIGITAL AUDIO OUT jack to a device with DTS decoder.
[Primary Pass-Thru] – Select if you connect this unit’s DIGITAL
AUDIO OUT and HDMI OUT jack to a device with LPCM, Dolby
Digital, Dolby Digital Plus, Dolby TrueHD, DTS and DTS-HD decoder.
21
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 21
Notes:
•When [HDMI] option is set to [PCM Multi-Ch], the audio may output as
PCM Stereo if the PCM Multi-Ch information is not detected from HDMI
device with EDID.
• If the [HDMI] or [SPDIF] option is set to [DTS re-encode], the DTS Re-
encode audio is outputted for BD-ROM discs with secondary audio and
the original audio is outputted for the other discs (like [Primary Pass-
Thru]).
Sampling Freq.
[48KHz] – Select this if your A/V Receiver or Amplifier is NOT capable
of handling 192 KHz and 96 KHz signal. When this choice is made,
this unit automatically converts any 192 KHz and 96 KHz signals to
48 KHz so your system can decode them.
[96KHz] – Select this if your A/V Receiver or Amplifier is NOT capable
of handling 192 KHz signals. When this choice is made, this unit auto-
matically converts any 192 KHz signals to 96 KHz so your system can
decode them.
[192KHz] – Select this if your A/V Receiver or Amplifier is capable of
handling 192 KHz signals.
Check the documentation for your A/V Receiver or Amplifier to verify its
capabilities.
DRC (Dynamic Range Control)
When a disc encoded in Dolby Digital or Dolby Digital Plus is playing back,
you may wish to compress the dynamic range of the audio output (the dif-
ference between the loudest sounds and the quietest ones). This allows
you to listen to a movie at a lower volume without losing clarity of sound.
Set DRC to [On] for this effect.
Note:
The DRC setting can be changed only when a disc is not inserted or the
unit is in complete stop mode.
[LOCK] Menu (Parental Control)
The [LOCK] settings affect only BD and DVD playback.
To access the any features in [LOCK] settings, you must enter the 4-digit
security code you have created.
If you have not entered a password yet, you are prompted to do so. Enter
a 4-digit password and press ENTER. Enter it again and press ENTER to
verify.
Password
You can create, change or delete the password.
[New] – Enter a 4-digit password and press ENTER. Enter it again and
press ENTER to create a new password.
[Change] – Enter the current password and press ENTER.
Enter a 4-digit password and press ENTER. Enter it again and press
ENTER to create a new password.
[Delete] – Enter the 4-digit password and press ENTER to delete the
password.
Tip:
If you make a mistake before pressing ENTER, press CLEAR. Then input
the correct password.
If you forget your password
If you forget your password, you can clear it using the following steps:
1. Remove any disc that might be in the player.
2. Select [LOCK] option in the [Setup] menu.
3. Use Number buttons to enter “210499”. The password is cleared.
22
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 22
DVD Rating
Blocks playback of rated disc based on their content. (Not all discs are
rated.)
[Rating 1-8] – Rating one (1) has the most restrictions and rating eight
(8) is the least restrictive.
[Unlock] – If you select unlock, parental control is not active and the
disc plays in full.
BD Rating
Set an age limit of BD-ROM play. Use number buttons to input an age limit
for BD-ROM viewing.
[255] – All BD-ROM can be played.
[0-254] – Prohibits play of BD-ROM with corresponding ratings
recorded on them.
Note:
The [BD rating] will be applied only for the BD disc that containing the
Advanced Rating Control.
Area Code
Enter the code of the area whose standards were used to rate the DVD
video disc, based on the list on page 33.
[OTHERS] Menu
Skin
Changes the background of the initial screen.
Initialize
You can reset the player to its original factory settings or initialize the BD
storage.
[Factory Set] – If you need to, you can reset the player to all its facto-
ry settings. Some options cannot be reset. (Rating, Password and Area
Code, etc.)
[BD Storage Clear] – Initializes the BD contents from the connected
USB Flash Drive.
DivX VOD
ABOUT DIVX VIDEO: DivX
®
is a digital video format created by DivX, Inc.
This is an official DivX Certified device that plays DivX video.
Visit www.divx.com for more information and software tools to convert your
files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified
®
device must be
registered in order to play DivX Video-on-Demand (VOD) content.
To generate the registration code, locate the DivX VOD section in the
device setup menu. Go to vod.divx.com with this code to complete the
registration process and learn more about DivX VOD.
[DivX Reg. Code] – Displays the registration code of your player.
[Deactivate] – Deactivate your player and display the deactivation
code.
Note:
All the downloaded videos from DivX
®
VOD can only be played back on
this unit.
BD
DVD
23
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 23
Notes:
• When you turn on the player or replace a disc, the player returns to the
initial default setting. Depending on the disc, a specific type of audio
that the disc has is output.
• Depending on the pre-recorded contents of the BD-ROM, some func-
tions may not be available or may be operated differently than other
media.
If a disc menu screen is displayed
The menu screen may be displayed first after loading a disc which con-
tains a menu.
Use bBvVbuttons to select the title/chapter you want to view, then
press ENTER to start playback.
Skip to the next/previous chapter/track/file
During playback, press . or > to go to the next chapter/track/file or
to return to the beginning of the current chapter/track/file.
Press . twice briefly to step back to the previous chapter/track/file.
Resume playback
During playback, press STOP (x) to stop playback.
The unit records the stopped point, depending on the disc. “Xx” appears
on the screen briefly.
Press PLAY (N) to resume playback (from the scene point). If you press
STOP (x) again or unload the disc (“x” appears on the screen.), the unit
will clear the stopped point. (Xx = Resume Stop, x = Complete Stop)
Notes:
• The resume point may be cleared when a button is pressed
(for example: POWER, OPEN/CLOSE, etc).
• On BD-Video discs including BD-J, the resume play function does not
work.
• On BD-ROM interactive title, the unit will be in Complete Stop mode if
you press STOP once during playback.
Pause a playback
During playback, press PAUSE (X) to pause playback. Press PLAY (N)
to continue playback.
Tip:
During Audio CD or MP3/WMA playback, press PAUSE (X) once again to
resume playback.
Frame-by-Frame playback
Press PAUSE (X) repeatedly to play Frame-by-Frame playback.
Slow down the playing speed
While the playback is paused, press SCAN M repeatedly to play in slow
motion (4 steps, forward only).
Fast forward or fast reverse
Press SCAN (m or M) to play fast forward or fast reverse during
playback.
You can change the various playback speeds by pressing SCAN (m or
M) repeatedly. Press PLAY (
NN
) to continue play at normal speed.
Note:
This function may not work on some disc or titles.
ALL
MOVIE
AVCHD
DVDBD
MOVIE
AVCHD
DVDBD
ALL
ALL
ALL
MOVIE
AVCHD
DVDBD
Play a disc
1 Open the disc tray: OPEN/CLOSE (
ZZ
)
2 Insert a disc: -
3Close the disc tray: OPEN/CLOSE (
ZZ
)
4 Adjust the disc menu settings: v V b B, ENTER
A disc menu may not appear on the screen
depending on the disc.
5 Starts playback: PLAY (
NN
)
6 Stops playback: STOP (
xx
)
ON REMOTE
24
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 24
Playing repeatedly
During playback, press REPEAT repeatedly to select a desired repeat
mode. The current title, chapter or track will be played back repeatedly. To
return to normal playback, press REPEAT repeatedly to select [Off].
When you are using the repeat, A-B repeat or random functions in the
[MUSIC] menu, refer to the mode icons as shown below.
Track – The current track or file will be played back repeatedly.
All – All the tracks or files will be played back repeatedly.
– Selected portion will be repeated continually. (Audio CD only)
– The tracks or files will be played back in random order.
All – All the tracks or files will be played back repeatedly in
random order.
To cancel the A-B repeat, repeat or Random playback, press CLEAR.
Notes:
• If you press SKIP (>) once during Repeat Chapter/Track playback,
the repeat playback cancels.
• This function may not work on some disc or titles.
Repeating a specific portion (A-B)
Press REPEAT to select [A-] at the beginning of the portion you wish to
repeat and press ENTER at the end of the portion. Your selected portion will
be repeated continually. You cannot select a portion less than 3 seconds.
To return to normal playback, press REPEAT repeatedly to select [Off].
See “Playing repeatedly” for more details about repeat and random icons
in the [MUSIC] menu.
Note:
This function may not work on some disc or titles.
Playing in random order
During playback, press REPEAT repeatedly to select a Random ( ) or
Random All ( All) mode icon. The tracks or files will be played in
random order. To return to normal playback, press REPEAT repeatedly to
delete the mode icons. See “Playing repeatedly” for more details about
repeat and random icons in the [MUSIC] menu.
Enlarge the playback image
During playback or pause mode, press ZOOM to display the [Zoom] menu.
Use the green or yellow buttons to zoom in or out of the picture. You can
move through the zoomed picture using bBvV buttons.
To return to the normal picture size, press the yellow button repeatedly to
fully zoom out of the picture. Press RETURN to exit [Zoom] menu.
Note:
This function may not work on some disc or titles.
Viewing the Title menu or Pop up menu
Press TITLE/POP-UP to displays the title menu or popup menu.
If the current DVD or BD-ROM disc has a menu, the Title menu or Popup
menu appears on the screen. Depending on the disc, the menu may not
be available
Marker Search
To enter a Marker
You can start playback from up to nine memorized points. To enter a mark-
er, press MARKER at the desired point on the disc. The Marker icon
appears on the TV screen briefly. Repeat to enter up to nine markers.
To Recall or Clear a Marked Scene
Press SEARCH and the search menu appears on the screen.
Press a number button to select a marker number that you want to recall.
Playback starts from the marked scene.
OR
Press V to highlight a marker number. Use b / B to select a marked scene
that you want to recall or clear.
Press ENTER and playback starts from the marked scene. Press CLEAR
and the marked scene is erased from the search menu.
Notes:
• This function may not work on some disc or titles.
• All marked points are cleared if you press STOP (x) twice (complete
stop), the title is changed or if you unload the disc.
• If the total length of the title is less than 10 seconds, this function is not
available.
MOVIE
AVCHD
DVD
BD
DVD
BD
MOVIE
AVCHD
DVD
BD
MUSIC
ACD
ACD
AVCHD
DVDBD
MUSIC
ACD
AVCHD
DVDBD
25
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 25
Hearing a different audio
During playback, press AUDIO repeatedly to hear a different audio
language, audio track or audio channel.
OR
During playback, press DISPLAY to display the playback menu.
Use v V to select the [Audio] option then use bB to select desired
audio language, audio track or audio channel.
Notes:
• Some discs allow you to change audio selections only via the disc
menu. If this is the case, press TITLE/POP-UP or DISC MENU button
and choose the appropriate audio from the selections on the disc menu.
• Immediately after you have switched sound, there may be a temporary
discrepancy between the display and actual sound.
• On BD-ROM disc, the multi audio format (5.1CH or 7.1CH) is displayed
with [MultiCH] in the on-screen display.
Selecting a subtitle language
During playback, press SUBTITLE-ON/OFF to switch the subtitle on or off
and press SUBTITLE repeatedly to select a desired subtitle language.
OR
During playback, press DISPLAY to display the playback menu.
Use v V to select the [Subtitle] option then use bB to select desired
subtitle language.
Note:
Some discs allow you to change subtitle selections only via the disc menu.
If this is the case, press TITLE/POP-UP or DISC MENU button and choose
the appropriate subtitle from the selections on the disc menu.
Using the search menu
During playback, press SEARCH to display the search menu.
Press bBto skip the playback 15 seconds forward or backward.
Tip:
You can select a point that you want to skip by pressing and holding bB
button.
Note:
This function may not work on some disc or titles.
Selecting a subtitle file
If names of the movie file and subtitle file are same, subtitle file is played
automatically when playing the movie file. If the name of the subtitle file is
different from movie file name, you need to select the subtitle file on the
[Movie] menu before playing the movie.
Use vVbB to select the subtitle file you wish to play in the [Movie]
menu, and then press MARKER. Press MARKER again to deselect the
subtitle file. Selected subtitle file will be displayed when you play the movie
file. If you press STOP (x) while playback, the subtitle selection is
canceled.
Using coloured (A, B, C, D) Buttons
These buttons are available only during BD-J contents playback. Use the
appropriate buttons as indicated by the display. Depending on the disc
contents, the functions of each button may differ.
Last Scene Memory
This unit memorizes the last scene from the last disc that is viewed. The
last scene remains in memory even if you remove the disc from the unit or
switch off the unit. If you load a disc that has the scene memorized, the
scene is automatically recalled.
Notes:
• Settings are stored in memory for use any time.
• This unit does not memorize settings of a disc if you switch off the unit
before commencing to play it.
• Last Scene Memory function for a previous disc is erased once a
different disc is played.
• This function may not work depending on the disc.
Screen Saver
The screen saver appears when you leave the player in Stop mode for
about five minutes. If the Screen Saver is displayed for five minutes, the
unit automatically turns itself off.
The screen saver also appears when you are playing music for about five
minutes, but the player will not be turned off.
DVD
BD
BD
MOVIE
MOVIE
AVCHD
DVDBD
MOVIE
AVCHD
DVDBD
MOVIE
AVCHD
DVDBD
26
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 26
a Title/Track – Current title/track number/total number of titles/tracks.
b Chapter – Current chapter number/total number of chapters.
c Time – Elapsed playing time.
d Audio – Selected audio language or channel.
e Subtitle – Selected subtitle.
f Angle – Selected angle/total number of angles.
Notes:
• If no button is pressed for a few seconds, the on-screen display
disappears.
•
A title number cannot be selected on some discs.
• An item may not be available on some discs or titles.
• If BD interactive title is playing back, some setting information is
displayed on the screen but prohibited to be changed.
Moving to another title/chapter/track
When a disc has more than one title/chapter/track, you can move to
another title/chapter/track.
Press DISPLAY during playback then use vVto select the
[Title/Chapter/Track] icon. Then, press the appropriate numbered button
(0-9) or bBto select a title/chapter/track number.
Playing from selected time
Press DISPLAY during playback. The time search box shows the elapsed
playing time. Select the [Time] option and then input the required start time
in hours, minutes, and seconds from left to right. For example, to find a
scene at 2 hours, 10 minutes, and 20 seconds, enter “21020” and press
ENTER. If you enter the wrong numbers, press CLEAR and enter the
correct numbers.
Note:
This function may not work on some disc or titles.
Watching from a different angle
If the disc contains scenes recorded at different camera angles, you can
change to a different camera angle during playback.
During playback, press DISPLAY to display the playback menu. Use v V
to select the [Angle] option, then use bB to select desired angle.
DVDBD
MOVIE
AVCHD
DVDBD
MOVIE
AVCHD
DVDBD
Displaying disc information
1 Play the disc loaded on the unit: PLAY (
NN
)
2 Displays the playback menu: DISPLAY
3Select an item:
vv VV
4 Adjust the playback menu settings:
bb BB
5 Exit the disc playback menu: DISPLAY
ON REMOTE
a
b
c
d
e
f
27
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 27
Notes:
• When the USB Flash Drive is connected and a disc is inserted
simultaneously, the menu for selecting a media will appear.
Select a media then press ENTER.
•You can use various playback functions. Refer to pages 23-25.
• On the [MOVIE] menu, use red or blue button to move to the first or the
last file or track and green or yellow button to move to the previous or
next page.
• Unfinalized DVD VR format discs may not be played in this player.
• Some DVD-VR disc are made with CPRM data by DVD RECORDER.
This unit cannot support these kinds of discs.
What is CPRM?
CPRM is a copy protection system (with scramble system) only allowing
the recording of ‘copy once’ broadcast programs. CPRM stands for
Content Protection for Recordable Media.
Notice for displaying the DivX subtitle
If the subtitle does not display properly, press and hold SUBTITLE for 3
seconds during playback. The language code will appear.
Press SUBTITLE repeatedly to select another language code until the
subtitle is displayed properly and then press ENTER.
Movie file requirement (USB/DISC)
Movie file compatibility with this player is limited as follows:
Available resolution size: 720 x 576 (W x H) pixels
File extensions: “.avi”, “.divx”
Playable subtitle: SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), VobSub (.sub)
SubViewer 1.0 (.sub), SubViewer 2.0 (.sub/.txt), TMPlayer (.txt),
DVD Subtitle System (.txt)
Playable Codec format: “DIVX3.xx”, “DIVX4.xx”, “DIVX5.xx”, “XVID”,
“DIVX6.xx” (Standard playback only)
Playable Audio format: “Dolby Digital”, “DTS”, “MP3”, “WMA”, “AC3”
Sampling frequency: within 32-48 kHz (WMA), within 16-48 kHz (MP3)
Bit rate: within 20-320 kbps (WMA), within 32-320 kbps (MP3)
Frame Rate: Less than 30 fps
CD-R/RW, DVD±R/RW, BD-R/RE Format:
ISO 9660+JOLIET, UDF and UDF Bridge format
Maximum Files/Folder: Less than 2,000
• The movie file name and subtitle are limited to 180 characters.
• Not all the WMA and AAC Audio format is compatible with this unit.
• This player does not support the file that are recorded with GMC*
1
or
Qpel*
2
. Those are video encoding techniques in MPEG4 standard, like
DivX or XVID have.
*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel
Playing a movie
1Inserts a disc/USB Flash Drive containing –
movie contents.
2Displays the [Home Menu]: HOME
3 Selects the [Movie] option:
bb BB
, ENTER
4 Selects a movie from the [MOVIE] menu: v V
5 Plays the selected movie: PLAY (
NN
)
6Stops the playback: STOP (
xx
)
The player can play movie files on the disc/USB
Flash Drive and video contents recorded on a
DVD-RW(VR mode) discs. Before playing movie
files, read “Movie file requirement”.
ON REMOTE
28
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 28
Example) MP3 files
Notes:
• When the USB Flash Drive is connected and a disc is inserted
simultaneously, the menu for selecting a media will appear. Select a
media then press ENTER.
•You can use various playback functions. Refer to pages 23-25.
Tips:
•To go directly to any track or file and play, enter the track/file number
using the numbered buttons (0-9).
• The playback may start automatically if the Audio CD inserted.
• Use vVbBto select a folder then press ENTER and you can view the
files in the folder. If you want to move to the upper or lower
directory, use vVto move to the desired directory.
• On the [MUSIC] menu, use red or blue button to move to the first or the
last file or track and green or yellow button to move to the previous or
next page.
• The equalizer indicator is not coupled with the music in play back.
• If there is impossible code to express in the file name, it may be
displayed as illegible.
MP3/WMA audio file requirement (USB/DISC)
File extensions: “.mp3”, “.wma”
Sampling frequency: within 8-48 kHz (WMA), within 11-48 kHz (MP3)
Bit rate: within 8-320 kbps (WMA, MP3)
CD-R/RW, DVD±R/RW, BD-R/RE Format:
ISO 9660+JOLIET, UDF and UDF Bridge format
Maximum Files/Folder: Less than 2000 (total number of files and fold-
ers)
Notes on MP3/WMA file
• Depending on the size and number of the MP3/WMA files, it may take
several minutes to read the contents of the media.
• This unit cannot support the ID3 Tag embedded in the MP3 file.
• The total playback time indicated on the screen may not correct for
VBR files.
Listening to music
1 Inserts an Audio CD or a disc/USB Flash –
Drive containing MP3/WMA files.
2Displays the [Home Menu]: HOME
3 Selects the [Music] option:
bb BB
, ENTER
4 Selects a music from the [MUSIC] menu: v V
bb BB
5 Plays the selected music: PLAY (
NN
)
6Stops the playback: STOP (
xx
)
The player can play Audio CDs and MP3/WMA
files. Before playing MP3/WMA files, read
“MP3/WMA audio file requirement”.
ON REMOTE
29
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 29
Notes:
• When the USB Flash Drive is connected and a disc is inserted
simultaneously, the menu for selecting a media will appear. Select a
media then press ENTER.
•You can start the slide show by pressing PLAY (N) while photo file is
selected in the [PHOTO] menu.
• On the [PHOTO] menu, use red or blue button to move to the first or
the last file and green or yellow button to move to the previous or next
page.
•You can change the content list view by pressing DISPLAY repeatedly.
Options during viewing a photo file in full screen
You can use various options during viewing a picture in full screen.
Use v V b B to select an option and use the options as described below.
a Use bBto advance to the previous or next file.
b Press ENTER to start or pause the slide show.
c Press ENTER to play or pause the background music. This option
is available after the background music is selected using
[Music Select] option.
d Selects the background music.
1) Press ENTER and the menu will appear.
2) Use vVbBto select a media or folder that there are music
file(s).
3) Press ENTER to confirm your selection.
e Press ENTER to rotate the picture clockwise.
This option is not available during slide show.
f Use green or yellow buttons to zoom in or out of the picture.
You can move through the zoomed picture using vVbBbuttons.
Press RETURN to exit the [Zoom] menu and return to the normal
picture size.
• The zoom function can be operated by the ZOOM button on the
remote control.
Viewing a photo
1Inserts a disc/USB Flash Drive containing –
photo files.
2Displays the [Home Menu]: HOME
3 Selects a [Photo] option: bB, ENTER
4Selects a photo from the [PHOTO] menu: vVbB
5Displays the selected photo in full screen: ENTER
6Displays the next or previous photo: . / >
7 Returns to the [PHOTO] menu screen: STOP (
xx
)
This unit can play a photo files. Before playing
photo files, read “Photo file requirement” on page
31.
ON REMOTE
bcdefgh
a
30
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 30
g Use vVto select an option between [Effect] or [Delay].
Use bBto adjust and press ENTER to set the selected option.
[Effects] – You can apply various effects during a photo slide show.
Off : Slide Show without any effect.
Random : Slide show effects are applied randomly.
Slide : Reveals a photo in a sliding motion from various
directions.
Door : Photo will be appear like door opening.
Lattice : Photo will be appear from tiled pieces to full screen
[Delay] – You can set the photo delaying time while Slide Show
h Press ENTER to exit the option menu.
To access the menu again, press ENTER.
Tips:
• For the files that are contained in a disc or USB Flash Drive, you can
enter the file number using the numbered buttons (0-9) to go directly to
a specific file.
•You can advance to the previous or next file by pressing . or >
during viewing a photo file in full screen.
•You can start the slide show without option menu by pressing
PLAY (N) during viewing a photo file in full screen.
• Use vVbBto select a folder then press ENTER and you can view
the files in the folder. If you want to move to the upper or lower directo-
ry, use vVto move to the desired directory.
• If there is impossible code to express in the file name, it may be
displayed as illegible.
Photo file requirement (USB/DISC)
File extensions: “.jpg”, “.jpeg”, “.png”
Recommended size:
Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel
CD-R/RW, DVD±R/RW, BD-R/RE Format:
ISO 9660+JOLIET, UDF and UDF Bridge format
Maximum Files/Folder: Less than 2,000 (total number of files and fold-
ers)
Notes on Photo file
• Progressive and lossless compression photo image files are not
supported.
• Depending on the size and number of the photo files, it may take
several minutes to read the contents of the media.
31
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 31
Reference
Controlling a TV with the Supplied Remote Control
You can control the volume, input source, and power state of your TV with
the supplied Remote Control.
You can control your TV using the buttons below.
By pressing You can
TV POWER Turn the TV on or off.
AV/INPUT Switch the TV’s input source between the
TV and other input sources.
PR/CH +/- Scan up or down through memorized
channels.
VOL +/– Adjust the volume of the TV.
TV MUTE Temporarily turns TV sound OFF, press
again to restore.
Note:
Depending on the unit being connected, you may not be able to control
your TV using some of the buttons.
Setting up the remote to control your TV
You can operate your TV with the supplied remote control.
If your TV is listed in the table below, set the appropriate manufacturer
code.
While holding down TV POWER button, and press the manufacturer code
for your TV with the numerical buttons (see the table below).
Release the TV POWER button to complete setting.
Manufacturer Code Number
LG / GoldStar 1 (Default), 2
Zenith 1, 3, 4
Samsung 6, 7
Sony 8, 9
Hitachi 4
Depending on your TV, some or all buttons may not function on the TV,
even after entering the correct manufacturer code. When you replace the
batteries of the remote, the code number you have set may be reset to the
default setting. Set the appropriate code number again.
POWERPOWER
TVTV
SCAN SKIP
PAUSE STOP
PLAY
HOME
TV Control Buttons
Resetting the unit
If you observe any of the following symptoms.
• The unit is plugged in, but the power will not turn on or off.
• The front panel display is not working.
• The unit is not operating normally.
You can reset the unit as follows.
• Press and hold the POWER button for at least five seconds. This will
force the unit to power off then turn the unit back on.
• Unplug the power cord, wait at least five seconds, and then plug it in
again.
32
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 32
Language Codes
Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu].
Area Codes
Choose an area code from this list.
Language Code
Afar 6565
Afrikaans 6570
Albanian 8381
Ameharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Chinese 9072
Language Code
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Fiji 7074
Finnish 7073
French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Language Code
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laothian 7679
Latin 7665
Latvian, Lettish 7686
Language Code
Lingala 7678
Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Language Code
Quechua 8185
Rhaeto-Romance 8277
Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378
Sindhi 8368
Singhalese 8373
Slovak 8375
Slovenian 8376
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Language Code
Tajik 8471
Tamil 8465
Telugu 8469
Thai 8472
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085
Area Code
Afghanistan AF
Argentina AR
Australia AU
Austria AT
Belgium BE
Bhutan BT
Bolivia BO
Brazil BR
Cambodia KH
Canada CA
Chile CL
China CN
Colombia CO
Congo CG
Area Code
Costa Rica CR
Croatia HR
Czech Republic CZ
Denmark DK
Ecuador EC
Egypt EG
El Salvador SV
Ethiopia ET
Fiji FJ
Finland FI
France FR
Germany DE
Great Britain GB
Greece GR
Area Code
Greenland GL
Hong Kong HK
Hungary HU
India IN
Indonesia ID
Israel IL
Italy IT
Jamaica JM
Japan JP
Kenya KE
Kuwait KW
Libya LY
Luxembourg LU
Malaysia MY
Area Code
Maldives MV
Mexico MX
Monaco MC
Mongolia MN
Morocco MA
Nepal NP
Netherlands NL
Netherlands Antilles AN
New Zealand NZ
Nigeria NG
Norway NO
Oman OM
Pakistan PK
Panama PA
Area Code
Paraguay PY
Philippines PH
Poland PL
Portugal PT
Romania RO
Russian Federation RU
Saudi Arabia SA
Senegal SN
Singapore SG
Slovak Republic SK
Slovenia SI
South Africa ZA
South Korea KR
Spain ES
Area Code
Sri Lanka LK
Sweden SE
Switzerland CH
Taiwan TW
Thailand TH
Turkey TR
Uganda UG
Ukraine UA
United States US
Uruguay UY
Uzbekistan UZ
Vietnam VN
Zimbabwe ZW
33
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 33
Troubleshooting
Possible Cause
• The power cord is disconnected.
• No disc is inserted.
• The TV is not set to receive video signal output.
• The video cable is not connected securely.
• The selected resolution is not capable with your TV.
• The equipment connected with the audio cable is not
set to receive disc signal output.
•
The power of the equipment connected with the audio
cable is turned off.
• The [AUDIO] options are set to the wrong position.
• The player is in reverse play, fast forward, slow motion
or pause mode.
• The disc is upside down.
• An unplayable disc is inserted.
• The rating level is set.
• The disc was recorded on another unit and was not
finalized.
• The Remote Control is not pointed at the remote
sensor on the player.
• The Remote Control is too far from the player.
Symptom
No power.
The power is on, but the
player does not work.
No picture.
No sound.
The player does not start
playback.
The Remote Control does
not work properly.
Correction
• Plug the power cord into the wall outlet securely.
• Insert a disc.
• Select the appropriate video input mode on the TV.
• Connect the video cable securely.
• Select another resolution using RESOLUTION button.
• Select the correct input mode of the audio receiver so you
can listen to the sound from the player.
•Turn on the equipment connected with the audio cable.
• Set the [AUDIO] options to the correct position
(see page 21).
• Return to the normal playback.
• Insert the disc with the playback side down.
• Insert a playable disc. (Check the disc type and regional
code.)
• Change the rating level.
• Finalize the disc on that unit.
• Point the Remote Control at the remote sensor of the
player.
• Operate the Remote Control closer to the player.
34
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 34
Specifications
General
Power requirements: AC 120 ~, 60 Hz
Power consumption: 23 W
Dimensions (W x H x D): Approx. 16.9 x 1.4 x 7.9 inches
(430 x 35 x 200 mm) without foot
Net Weight (Approx.): 6 lbs (2.7 kg)
Operating temperature: 41 °F to 95 °F (5 °C to 35 °C)
Operating humidity: 5 % to 90 %
Outputs
VIDEO OUT: 1.0 V (p-p), 75 Ω, sync negative,
RCA jack x 1
HDMI OUT (video/audio): 19 pin (HDMI standard, Type A)
ANALOG AUDIO OUT: 2.0 Vrms (1 kHz, 0 dB), 600 Ω,
RCA jack (L, R) x 1
DIGITAL OUT (COAXIAL): 0.5 V (p-p), 75 Ω, RCA jack x 1
Input
USB IN: 4 pin (USB 1.1/2.0 standard)
Bus power supply (USB): DC 5 V 500 mA
System
Laser: Semiconductor laser,
wavelength: 405nm / 650 nm
Signal system: Standard NTSC colour TV system
Frequency response: 20 Hz to 20 kHz
(48 kHz, 96 kHz, 192 kHz sampling)
Signal-to-noise ratio: More than 100 dB
(ANALOG OUT connectors only)
Harmonic distortion: Less than 0.008 %
Dynamic range: More than 95 dB
Accessories
Video/Audio cable (1), Remote control (1), Battery (1)
Customer Support
You can update the Player using the latest software to enhance the
products operation and/or add new features.
To obtain the latest software for this player (if updates have been made),
please visit
http://lgservice.com
or contact LG Electronics customer care
centre.
Design and specifications are subject to change without notice.
35
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 35
Open source software notice
The following GPL executables and LGPL libraries used in this product are
subject to the GPL2.0/LGPL2.1 License Agreements:
GPL EXECUTABLES: Linux kernel 2.6, bash, busybox, dhcpcd, mtd-utils,
net-tools, procps, sysutils, tinylogin
LGPL LIBRARIES: uClibc, DirectFB, iconv, cairo, gnutls, libcrypt,
libgpg-err, libusb
gSOAP Public License 1.3 LIBRARY: gsoap
LG Electronics offers to provide source code to you on CD-ROM for a
charge covering the cost of performing such distribution, such as the cost
of media, shipping and handling upon e-mail request to LG Electronics at:
This offer is valid for a period of three(3) years from the date of the
distribution of this product by LG Electronics.
You can obtain a copy of the GPL, LGPL licenses from
http://www.gnu.org/licenses/old-licenses/gpl-2.0.html and
http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html.
Also you can obtain a copy of gSOAP public license from
http://www.cs.fsu.edu/~engelen/license.html.
This software is based in part on the work of the Independent JPEG Group
copyright © 1991 - 1998, Thomas G. Lane.
This product includes
• Freetype library : copyright © 2003 The FreeType Project
(www.freetype.org).
• libpng library : copyright © 2004 Glenn Randers-Pehrson
• Zlib compression library: Copyright © 1995-2002 Jean-loup Gailly and
Mark Adler.
• Expat library : copyright © 2006 expat maintainers.
• OpenSSL library :
– cryptographic software written by Eric Young ([email protected]).
– software written by Tim Hudson ([email protected]).
– software developed by the OpenSSL Project for use in the OpenSSL
Toolkit. (http://www.openssl.org)
• libcurl library : Copyright © 1996 - 2008, Daniel Stenberg,
• boost C++ library : © Copyright Beman Dawes 1999-2003
• UPnP SDK : Copyright © 2000-2003 Intel Corporation
• Libnet : © 1998 - 2004 Mike D. Schiffman [email protected]
• Libpcap
This product includes other open source software.
• Copyright © David L. Mills 1992-2006
• Copyright © 1998-2003 Daniel Veillard.
• Copyright © 1998, 1999 Thai Open Source Software Center Ltd.
• Copyright © 1990 The Regents of the University of California.
• Copyright © 1998-2005 The OpenSSL Project.
• Copyright © 1991, 1992 Paul Kranenburg <[email protected].eur.nl>
• Copyright © 1993 Branko Lankester <[email protected]>
• Copyright © 1993 Ulrich Pegelow <[email protected].de>
• Copyright © 1995, 1996 Michael Elizabeth Chastain
• Copyright © 1993, 1994, 1995, 1996 Rick Sladkey <[email protected]>
• Copyright © 1999,2000 Wichert Akkerman <[email protected]>
All rights reserved.
Permission is hereby granted, free of charge, to any person obtaining a
copy of this software and associated documentation files (the "Software"),
to deal in the Software without restriction, including without limitation the
rights to use, copy, modify, merge, publish, distribute, sublicense, and/or
sell copies of the Software, and to permit persons to whom the Software is
furnished to do so, subject to the following conditions:
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF
ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT
SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR
ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN
ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM, OUT
OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR
OTHER DEALINGS IN THE SOFTWARE.
36
BD350-N.ACANLLK_5202_ENG 9/29/09 10:18 AM Page 36
