Quick Setup Guide
Read the Product Safety Guide first, then read this Quick
Setup Guide for the correct installation procedure.
Not all models are available in all countries.
The latest manuals are available at the Brother Solutions
Center: support.brother.com/manuals.
Unpack the machine and check the components
NOTE:
• Manuals in Spanish for this model are available on the Brother Solutions
Center. (USA only): support.brother.com/manuals
Los manuales en español de este modelo están disponibles en
el Brother Solutions Center. (Solamente en los Estados Unidos):
support.brother.com/manuals
• The components included in the box may differ depending on your country.
• The available connection interfaces vary depending on the model.
• Interface cables are not included. You must purchase the correct interface
cable if you require one.
USB cable
We recommend using a USB 2.0 cable (Type A/B) that is no more than
6 feet (2 meters) long.
Network cable
Use a straight-through Category 5 (or greater) twisted-pair cable.
• The illustrations in this Quick Setup Guide show the HL-L2370DW.
• This machine’s Reference Guide is either printed for you or is available on
the Brother Installation Disc included in the carton.
Remove the packing materials and install the drum unit and toner cartridge assembly
Load paper in the paper tray
Connect the power cord and turn on the machine
Select your language (if needed)
3
4
2
1
Back Front
Watch our Video FAQs for
help with setting up your
Brother machine:
support.brother.com/videos.
Adjust the paper
guides.
Do not exceed this mark.
Brother Installation Disc Quick Setup Guide
Reference Guide (only for certain models)
Product Safety Guide
1. Press ▼ or ▲ to select [Initial Setup], and then press OK.
2. Press OK to select [Local Language].
3. Press ▼ or ▲ to select your language, and then press OK.
HL-L2370DWXL / HL-L2370DW / HL-L2350DW
Toner Cartridge Replacement
(For HL-L2370DWXL model)
Use the toner cartridge that is pre-installed in the
drum unit first.
1
1
2
Remove the orange part. Push firmly.
Drum Unit and Toner Cartridge
D00PKF001-00
USA/CAN
Version 0
